Page 1

KGniUlillí^

Electric Range Estufa eléctrica

Models, Modelos 790.9621*, 9622*, 9623*, 9631*, 9632*, 9633*,

9634*, 9641*, 9642*, 9643* * = color number, número de color

ni 3f!'

I»

ffl

www.sears.conn Sears Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

p/n 316417230(0601)

Page 2

Table of Contents Product Record

Free-Standing Range Warranty....................................................2 In this space below, record the date of purchase, model and

Product Record...............................................................................2 serial number of your product. You will find the model and

IMPORTANT SAFETY INSTRUCTIONS

Protection Agreements...................................................................5 plate is located on the right side of the oven front frame in

Range Features ............................................................................6 the storage or Warmer Drawer compartment. See bottom

Before Setting Oven Controls.....................................................7-8 of this page for the serial plate location.

Setting Surface Controls

Surface Cooking.....................................................................11-12 Model No. 790.___________________________________

Oven Control Functions

Setting Oven Controls...........................................................13-15 Serial No. _____________________________________________

Setting Warmer Drawer Controls

Select Self-Cleaning...............................................................17-18 Date of Purchase

General Care & Cleaning Adjusting Your Oven Temperature Before You Call Sears Service

............................................................................

.............................................................

........................................................

..............

...............................................

.........................................

...........

.................................... 19-21

Ken more Appliance Warranty

One Year Limited Warranty When installed, operated and maintained according to ail instructions supplied with the product, if this appliance fails due to a defect in material or workmanship within one year from the date of purchase, call 1-800-4-MY-HOME ® to arrange for free repair. If this appliance is used for other than private family purposes, this warranty applies for only 90 days from the date of purchase.

...................................

9-10

16-17

...............................................

Back Page

3-4 serial number printed on an identification plate. This serial

_____________________________________

21 Save these instructions and your sales receipt for future 22 reference.

This warranty covers only defects in material and workmanship. Sears will NOT pay for:

1. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.

2. A service technician to instruct the user in correct product installation, operation or maintenance.

3. A service technician to clean or maintain this product.

4. Damage to or failure of this product if it is not installed, operated or maintained according to all instructions supplied with the product.

5. Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.

6. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those recommended in all instructions supplied with the product.

7. Damage to or failure of parts or systems resulting from unauthorized modifications made to this product.

Disclaimer of implied warranties; limitation of remedies Customer’s sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Implied warranties, including warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by law. Sears shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or limitation of incidental or consequential damages, or limitations on the duration of implied warranties of merchantability or fitness, so these exclusions or limitation may not apply to you.

This warranty applies only while this appliance Is used in the United States and Canada. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Sears, Roebuck and Co., Dept. 81 TWA, Hoffman Estates, IL 60179

Sears Canada Inc., Toronto, Ontario, Canada MSB 2B8

Serial Plate Location

You will find the model and serial number printed on the serial plate. The serial plate is located on the right side of the oven front frame in the storage orwarmerdrawer compartment.

Please see the illustration for exact location.

Remember to record the serial numberforfuture reference (See top of page under Product Record).

Serial plate location; Open the Warmer Drawer (some models) orstorage drawer (some models).

Page 3

important Safety instructions

Read a!! instructions before using this appliance. Save these instructions for future reference.

This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given.

A WARNING ià CAUTION

• Remove all tape and packaging before using the range.

Destroy the carton and plastic bags after unpacking the range. Never allow children to play with packaging material.

• Proper Installation—Be sure your appliance is properly

installed and grounded by a qualified technician in accordance with the National Electrical Code ANSI/ NFPA No. 70 latest edition and local electrical code requirements, install only perinstallation instructions provided

in the literature package for this range. Askyourdeaierto recommend a qualified technician and an authorized repairservice. Know how to disconnect the power to the range at the circuit breaker or fuse box in case of an emergency.

• User servicing—Do not repair or replace any part of the

appliance unless specifically recommended in the manuals. All other servicing should be done only by a

qualified technician. This may reduce the risk of personal injury and damage to the range.

• Never modify or alter the construction of a range by

removing leveling legs, panels, wire covers, anti-tip brackets/screws, or any other part of the product.

^WARNING

All ranges can tip.

Injury to persons could result. Install anti-tip device packed with range.

See Installation Instructions.

This symbol will help alert.you to situations that may .cause serious bodily harm, death orproperty damage.

This symbol will help alert you to situations that may cause bodily injury or property damage.

WARNING

Do not use the oven or warmer drawer (if

equipped) for storage.

A WARNING

I Never Use Your Appliance for Warming or

Heating the Room.

• Storage in or on Appliance—Flammable materials should not be stored in an oven, warmer drawer, near surface units or in the storage drawer. This includes

paper, plasticand cloth items, such as cookbooks, plasticware and towels, as well as flammable liquids. Do not store explosives, such as aerosol cans, on or near the range.

• Do Not Leave Children Alone—Children should not be left alone or unattended in the area where appliance is in use. They should never be allowed to sit or stand on any

part of the appliance.

• DO NOTTOUCHSURFACE UNITS, AREAS NEAR THESE UNITS, HEATING ELEMENTS OR INTERIORSURFACES OF THE OVEN. Both surface unitsand oven heating elements

may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing orotherflammable materials touch these areas until they have had sufficient time to cool. Among these areas are the cooktop, surfacesfacing the cooktop, the oven ventopenings and surfaces near these openings, oven doorand window.

ikWARNfNG

tipping, the range must be secured by properly installed anti-tip bracket provided with the range. To check if the bracket is installed properly, visually check that rear leveling leg is inserted into and fully secured by the anti-tip bracket by removing lower panel or storage drawer. For models with a warmer drawer, grasp the top rear edge of the range and carefully attempt to tilt it forward. Refer to the installation instructions for proper anti tip bracket installation.

To reduce the risk of

• Wear Proper Apparel—Loose-fitting orhanging garments should never be worn while using the appliance. Do not

let clothing orotherflammable materials contact hot surfaces.

• Do Not Use Water or Flour on Grease Fires—Smother the fire with a pan lid, or use baking soda, a dry chemical or foam-type extinguisher.

•When heating fat or grease, watch it closely. Fat or

grease may catch fire if allowed to become too hot.

• Use Only Dry Potholders - Moist or damp potholders on hot surfaces may result in burns from steam. Do not let

potholders touch hot heating elements. Do not use a towel or other bulky cloth instead of a pothoider.

• Do Not Heat Unopened Food Containers - Buildup of pressure may cause container to burst and result in

A WARNING

i Stepping, leaning orsittingon the doors or drawers of this range can result in serious injuries and also cause damage to the range. Do not allow children to

climb or play around the range. The weight of a child on an open door may cause the range to tip, resulting in serious burns or other injury.

^CAUTION

Do not store items of interest to children in the cabinets above a range or on the backguard of a range. Children climbing on the range to reach items could be

seriously injured.

injury.

• Remove the oven door from any unused range if it is to be stored or discarded.

IMPORTANT—Do not attempt to operate the range during a power failure. If the power fails, always turn off the range.

Ifthe range is not turned off and the power resumes, the range will begin to operate again. Once the power resumes, reset the clockand oven function.

Page 4

Important Safety Instructions

IMPORTANT INSTRUCTIONS FOR USING YOUR COOKTOP

• Know which knob controls each surface heating unit. Place a

pan of food on the unit before turning It on, and turn the unit off before removing the pan.

• Use Proper Pan Size—This appliance is equipped with one or

more surface units of different sizes. Select utensils having fiat bottoms large enough to cover the surface unit heating element. The use of undersized utensils will expose a portion of the heating element to direct contact and may result in ignition of clothing. Proper relationship of utensil to element will also improve efficiency.

• Utensil HandlesShould Be Turned Inward and Not Extend Over

Adjacent Surface Elements—To reduce the risk of burns, ignition

of flammable materials, and spillage due to unintentional contact with the utensil, the handle of the utensil should be positioned so that it Is turned inward, and does not extend over adjacent surface units.

• Never Leave Surface Elements Unattended at High Heat

Settings—Boilovers cause smoking and greasy spillovers that

may ignite, or a pan that has boiled dry may melt.

• Do Not Immerse or Soak Removable Heating Elements—

Heating elements should never be immersed in water. Heating elements clean themselves during normal operation.

• Glazed Cooking Utensils—Only certain types of glass, glass/

ceramic, ceramic, earthenware, or other glazed utensils are suitable for cook top service without breaking due to the sudden change in temperature. Check the manufacturer’s recommendations for cook top use.

• When flaming foods under a ventilating hood, turn the fan on.

IMPORTANT INSTRUCTIONS FOR USINGYOUR OVEN

• Use Care When Opening Oven Door or Warmer Drawer (if equipped)—Stand to the side of the range when opening the door

of a hot oven. Let hot air or steam escape before you remove or replace food in the oven.

• Keep Oven Vent Ducts Unobstructed. The oven vent is located

under the left rear surface element if your model is equipped with coil elements. The oven vent is located below the backguard for models equipped with ceramic-glass cook tops. Touching the surfaces in this area when the oven is operating may cause severe burns. Also, do not place plastic or heat-sensitive items on or near the oven vent. These items could melt or ignite.

• Placement of Oven Racks. Always place oven racks in desired

location while oven is cool. If rack must be moved while oven is hot use extreme caution. Use potholders and grasp the rack with both hands to reposition. Do not let potholders contact the hot heating elements in the oven. Remove all utensils from the rack before moving.

• Do not use the broiler pan without its insert (some models). The

broiler pan and its insert allow dripping fat to drain and be kept away from the high heat of the broiler.

• Do notcoverthe broilerinsertwith aluminum foil. Exposed fat and grease could ignite.

• Protective Liners—Do not use aluminum foil to line the oven

bottom. Only use aluminum foil as recommended in this manual. Improper installation of these liners may result in risk of electric shock, or fire.

SELF CLEANING OVENS

• Clean in the self-cleaning cycle only the parts listed in this Use & Care Manual. Before self cleaning the oven, remove the broiler

pan and any utensils or foods from the oven.

• Do Not Use Oven Cleaners—No commercial oven cleaner or oven liner protective coating of any kind should be used in or around any part of the oven.

• Do NotClean Door Gasket—The door gasket is essential fora good seal. Care should be taken not to rub, damage or move the gasket.

•The health of some birds is extremely sensitive to the fumes given off during the self-cleaning cycle of any range. Move birds to another well-ventilated room.

IMPORTANT INSTRUCTIONS FOR CLEANING YOUR RANGE

• Clean the range regularly to keep all parts free of grease that could catch fire. Pay particular attention to the area underneath each

surface element. Do not allow grease to accumulate.

• Kitchen cleaners and aerosols—Always follow the manufacturer’s recommended directions for use. Be aware that excess residue from cleaners and aerosols may ignite causing damage and injury.

• Clean Ventilating Hoods Frequently—Grease should not be allowed to accumulate on the hood or filter. Follow manufacturer’s instructions for cleaning.

FOR CERAMIC-GLASS COOK TOP MODELS

• Do Not Cook on Broken Cook Top—If cook top should break, cleaning solutions and spillovers may penetrate the broken cook top and create a risk of electric shock. Contact a qualified technician immediately.

• Clean Cook Top with Caution—If a wet sponge or cloth is used to wipe spills on a hot cooking area, be careful to avoid a steam burn. Some cleaners can produce noxious fumes if applied to a hot surface.

Important Safety Notice

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to warn customers of potential exposure to such substances.

Page 5

PROTECTION AGREEMENTS

ACUERDOS DE PROTECCION

In the U.S.A.

Master Protection Agreements

Congratulations on making a smart purchase. Your new Kenmore® product is designed and manufactured for years of dependable operation. But like all products, it may require preventive maintenance or repairfrom time to time. That’s when having a Master Protection Agreement can save you money and aggravation.

Purchase a Master Protection Agreement now and protect yourself from unexpected hassle and expense.

The Master Protection Agreement also helps extend the life ofyour new product. Here’s what’s included in the Agreement:

gf Expert service by our 12,000 professional repair

specialists.

gf Unlimited service and no charge for parts and labor

on all covered repairs.

0" “No-lemon” guarantee - replacement

ofyour covered product iffour or more product failures occurwithin twelve months.

^ Product replacement if your covered product can’t be

fixed.

0" Annual Preventive Maintenance Check at your

request - no extra charge.

gf Fast help by phone - phone support from a Sears

technician on products requiring in-home repair, plus convenient repairscheduling.

0' Power surge protection against electrical damage

due to powerfluctuations.

0" Rental reimbursement if repair ofyour covered

product takes longer than promised.

Once you purchase the Agreement, a simple phone call is all that it takes for you to schedule service. You can call anytime day or night, or schedule a service appointment online.

Sears has over 12,000 professional repair specialists, who have access to over 4.5 million quality parts and accessories. That’s the kind of professionalism you can count on to help prolong the life ofyour new purchase for years to come. Purchase your Master Protection Agreement today!

Some limitations and exclusions apply. For prices and additional information call 1-800-827-6655.

Acuerdos maestros de protección

Lo felicitamos por haber hecho una compra inteligente. Su nuevo producto Kenmore® fue diseñado y fabricado para ofrecer muchos años de servicio confiable. Sin embargo, como todo producto, el mismo podría requerir mantenimiento preventivo o reparaciones ocasionales. Es por eso que el tener un Acuerdo maestro de protección podría ahorrarle dinero y molestias.

Adquiera ya un Acuerdo maestro de protección y protéjase de gastos y frustraciones inesperados.

El Acuerdo maestro de protección también ayuda a extender la vida de su producto nuevo. El Acuerdo incluye lo siguiente:

0" Servicio profesional por nuestros 12.000 profesionales

especialistas en reparación.

0" Servicio ilimitado sin cargos adicionales por piezas

y servicio en todas las reparaciones cubiertas.

0f Garantía de “no-limón” - reemplaza su producto

cubierto si ocurren cuatro o más desperfectos en los primeros doce meses.

0f Reemplazo del producto si el mismo no puede ser

reparado.

0f Verificación de mantenimiento preventivo anual a

su petición y sin cargos adicionales.

0f Pronta ayuda por teléfono - apoyo por teléfono por un

técnico de Sears en los productos que requieran reparación en casa, además de la conveniencia de hacer una cita para la reparación.

0f Protección contra picos de energía o daños

eléctricos causados por fluctuaciones de la corriente eléctrica.

0f Reembolso del alquiler si la reparación de su producto

cubierto toma más del tiempo prometido.

Una vez que adquiera este Acuerdo, una simple llamada telefónica es todo lo que necesita para hacer una cita de servicio. Usted puede llamar a cualquier hora del día o de la

noche para programar una cita de servicio por Internet.

Sears cuenta con más de 12.000 profesionales especialistas de reparación con acceso a más de 4,5 millones de piezas y accesorios de calidad. Esa es la ciase de profesionalismo con la que puede contar para extender la vida útil de su nueva adquisición por muchos años. ¡Adquiera su Acuerdo maestro de protección hoy!

Algunas limitaciones y exclusiones podrían aplicarse.

Para precios e información adicional, llame al

1-800-827-6655.

Sears Installation Service

For Sears professional installation of home appliances, garagedoor openers, water heaters, and other major home items, in the U.S.A. call

1-800-4-MY-HOME®.

Servicio de instalación Sears

Para una instalación profesional de Sears en electrodomésticos, abridores de puertas de garaje,

calentadores de agua y otros artículos mayores del hogar,

llameal 1-888-SU-HOGAR®.

En los EE.UU.

REV. 030.1^09

Page 6

Range Features

Electronic Oven Control with Kitchen Tinner.

Simmer Select Element Control (some models) or

Single Radiant Element Control (some models) or Single

Radiant Power Boil Control (some models).

Single Radiant Element Control. Warm & Ready Drawer Control & Indicator Light (some models).

Warm & Ready Zone & Surface Indicator Light (some mo(

Single Radiant Element Control.

Single Radiant Element Control (some models) or Dual

Element Radiant Control (some models).

Simmer Select Push Button & Indicator Light (some modi

HOT SURFACE Indicator Lights.

“ELEMENT ON” indicator Light.

Oven Interior Light with removable Cover.

Automatic Oven Door Light Switch (some models).

Seif-Cleaning Oven interior.

Self-Clean Door Latch.

Adjustable Oven Rack(s).

Large 1 piece Oven Door Handle.

Full width Oven Door with Window.

Warm & Ready Drawer (some models) or Storage Drawer

Drawer Handle.

Easy to clean upswept Cooktop.

Ceramic Smoothtop.

6" Single Radiant Element(s).

9” Single Radiant Element (some models).

9” Single Radiant “Power Element" (some models).

6-9" Dual Radiant Element (some models).

9-12” Dual Radiant Element (some models).

Warm & Ready Zone Radiant Element (some models).

Broil Pan (some models).

Broil Pan Insert (some models).

Leveling Legs and Anti-tip Bracket (included). '..ZSt

NOTE; The features of your range may vary according to model type & color.

\2:;

Page 7

Before Setting Oven Controls

OVEN VENT

Oven with visible

Bake Element - Fig. ;

Oven Vent Location

The oven vent is located under the left side of the control panel (See Fig. 1). When the oven is on, warm air passes through the vent. This venting is necessary for proper air circulation in the oven and good baking results. DO NOT BLOCK OVEN VENT.

Removing & Replacing Oven Racks To remove, pull the rack forward until it stops. Lift upfront of rackand slide

out. To replace, fit the rack onto the guides on the oven walls. Tiitthefront of the rack upward and slide the rack back into place.

Arranging Oven Racks

ALWAYS ARRANGE OVEN RACKS WHEN THE OVEN IS COOL

(PRIOR TO OPERATING THE OVEN). Always use oven mitts when

using the oven.

For models with a visible Bake Element (Refer to Fig. 2) For models with a hidden Bake Element* (Refer to Fig. 3)

Food Rack PositionRack Position*

Broiling hamburgers & steaks See Broil section See Broil section Broiling meats, chicken or fish 4, 5 or 6 4, 5. or 6 Cookies, cakes, pies, biscuits

& Muffins

Frozen pies, angel food cake,

yeast, bread, casseroles, small

cuts of meat or poultry

Turkey, roast or ham 1 Roasting Shelf

3or4 3or4

1 or2 1

Roasting

Shelf

Oven with hidden

Bake Element - Fig. 3*

Types of Oven Racks

Your range may be equipped with one or more of the oven rack types shown; Flat Rack, Handle Rack and Offset Rack. To maximize cooking space the Offset rack can be used in the lowest rack position to roast large cuts of meat and poultry.

Baking Layer Cakes with 1 or 2 Oven Racks

For best results when baking cakes using 2 oven racks, place cookware on rack positions 2 & 5 as shown (for models with a visible bake element). For modeiswith a hidden bake element place oven racks in positions 3 (Fiat rack) & 6 with the Offset rack if equipped (Refer to Fig. 4).

For best results when using a single oven rack, place cookware on rack positions 3 or 4 (for all models - Refer to Fig. 5).

Air Circulation in the Oven

For best air circulation and baking results allow 2-4" (5-10 cm) around the cookware for properair circulation and be sure pansand cookware do not touch each other, the oven door, sides or back of the oven cavity. The hot air must be able to circulate around the pans and cookware in the oven for even heat to reach around the food. Fig. 4 Fig. 5

Flat

Oven Rack

Handle

Oven Rack

Offset

Oven Rack

Page 8

Before Setting Oven Controls (cont’d)

About the Ceramic Glass Cooktop

The ceramic cooktop has radiant surface elements located below the surface of the glass. The design of the ceramic

cooktop outlines the area of the surface element underneath. Be sure to match the pan size with the diameter of the

element outline on the cooktop. Heat is transferred up through the surface of the cooktop to the cookware. Only flatbottomed cookware should be used.

The type and size of cookware, the number of surface elements in use and their settings, are all factors that will affect the amount of heat that will spread to areas beyond the surface elements. The areas surrounding the elements may become

hot enough to cause burns.

About the Radiant Surface Elements

o@o

o o

WARMER ZONE

Warmer Zone

Surface Control

(some models)

NOTE: Please read detailed instructions for ceramic glass cooktop cleaning in the General Care & Cleaning and Before

009

O O

RIGHT REAR

RIGHT FRONT

€>

Single Radiant Single Radiant (some models)

Surface Control Dual Radiant (some models)

(some models) Surface Control

The elementtemperature rises gradually and evenly. As the temperature rises, the element will glow red. To maintain the selected setting, the element will

cycle on and off. The heating element retains

enough heat to provide a uniform and consistent

heat during the off cycle.

For efficient cooking. turn off the element several minutes before cooking is compiete. This will allow residual heat to complete the cooking process.

You Call checklist sections of this Use & Care Guide.

NOTE: Radiant elements have a limiter that allows the element to cycle ON and OFF, even at the HI setting. This helps to prevent damage to the ceramic smooth top. Cycling at the HI setting is normal and will occur more often if the cookware is too small for the radiant element or if the cookware bottom is not flat.

- - -- -- .. ELEMENT ON and Hot Surface Indicator Lights

OOI

Your range is equipped with two different types of radiant surface control indicator

lights that will glow on your range— the ELEMENT ON indicator light and the Hot

Surface indicator lights (See illustration at left).

The ELEMENT ON located on the control panel and will glow when a surface element is turned ON. A quick glance at this indicator light after cooking is an easy check to be sure ALL surface controls are turned OFF.

The Hot Surface indicator lights located above each surface radiant control

knob will glow as the surface cooking area heats up and will REMAIN ON until

the glass cooktop has cooled to a MODERATE level.

Page 9

Setting Surface Controls

To Operate Single Radiant Surface Elements (all models) To Operate a Single Radiant Element:

1. Place correctly sized cookware on the radiant surface element,

2. Push in and turn the surface control knob in either direction to the desired setting (See Fig. 1). Start most cooking operations on a higher setting and then turn to a lower

setting to finish cooking. The surface control knobs do not have to be set exactly on a

particular mark. Use the marks as a guide and adjust the control knob as needed. Each

surface element provides a constant amount of heat at each setting, A glowing red surface heating area extending beyond the bottom edge ofthe cookware indicates the

cookware is too small for the surface heating area,

3. When cooking is complete, turn the surface element OFF before removing the cookware. Note: The ELEMENT ON indicatorlight will glow when one or more elements

are turned ON. A quick glance at this indicator light when cooking is finished is an easy

check to be sure all control knobs are turned OFF. The Hot Surface indicator light will continue to glow AFTER the control knob is turned to the “OFF” position and will glow until the heating surface area has cooled sufficiently.

To Operate Simmer Select Surface Element (some models)

OO®

ELEMENT ON

The left front element control may be used as a normal element or as a simmer element. The “Simmer Select” feature heats the element at a much lower temperature than when used as a normal surface element. You may switch between normal cooking and the Simmer Select feature at any time during the cooking process. When using the element control for normal cooking all ofthe settings on the control knob (LO to HI) function as normal.

To Start Simmer Select:

1. Place correctly sized cookware on the radiant surface element.

2. Push in the Simmer button located below the left front control knob. The Simmer Select indicator light will glow and remain ON while simmering (See Fig. 2).

3. Turn the surface control knob to the desired simmer setting within the dark band on the control knob (LO to 4), Use the marks as a guide and adjust the control knob from LO to 4 as needed (see illustration below).

4. To return to normal cooking, push in and release the “Simmer Select” button and the indicator light will turn OFF. When cooking is complete, be sure to set the control knob to the OFF position.

The suggested settings found in the table below are based on cooking in medium-weight aluminum pans with lids. Settings may vary when using other types of pans.

STANDARD SETTING FORSURFACE ELEMENTS

Setting Type of Cooking

HIGH (HI-9) Start most foods, bring water to a boil, pan broiling MEDIUM HIGH (7-8) Continue a rapid boil, fry, deep fat fry MEDIUM (5-6) Maintain a slow boil, thicken sauces and gravies, steam vegetables MEDIUM LOW (2-4) Keep foods cooking, poach, stew

LOW{LO- 1) Keep warm, melt, simmer

o r”

;

Simmer Select Surface Control

shown in LO setting

Fig. 2

iOkCAUTION

Radiant surface elements may appear to have cooled after they have been turned off. The glass surface may

Max. Simmer (4) Larger quantities of food, stews and soups

Min. Simmer (LO) Smaller quanitites of food, delicate foods, melting chocolate or

SIMMERSELECTSURFACE ELEMENT

butter

still be hot and burns may occur if the glass surface is touched before it has cooled sufficiently.

ikCAUTION

Do not place plastic items such as salt and pepper shakers, spoon holders or plastic wrappings on top

ofthe range when itis in use. These items could melt or ignite. Potholders, towels orwooden spoons could catch fire if placed

too close to the surface elements.

Page 10

Setting Surface Controls (cont’d)

To Operate Dual Radiant Surface Element (some models)

The right front control knob offers fiexibiityfor different sized cookware with the Dual Radiant surface element. The inner element alone can be used for smaller or both the innerand outer in combination for larger cookware.

To operate the Dual Radiant surface element push in the control knob and turn counterclockwise to operate the small inner coil or turn clockwise to operate both the innerand outer portions of the element together (See Fig 1).

Setting

HIGH (HI-9) Start most foods, bring water fo a boil, pan broiling

MEDIUM HIGH (7-8) Continue a rapid boil, fry, deep fat fry

MEDIUM (5-6) Maintain a slow boil, thicken sauces and gravies or

Dual Radiant heating areas

on ceramic smooth top (shown in black)

Fig. 1

MEDIUM LOW(2-4) Keep foods cooking, poach, stew

LOW (LO - 1) Keep warm, melt, simmer

Note: The size and type of utensil used, and the amount and type of food being

cooked will influence the setting needed for best cooking results.

SINGLE ANDDUALRADIANTSURFACE ELEMENTS

Type of Cooking

steam vegetables

orno

o o

WARMER ZONE

Warmer Zone Recommended Food

Settings Table

Food Item Heating

Level

Breads/Pastries LO Casseroles LO Dinner Plates with Food LO Eggs LO Gravies LO Meats MED Sauces MED Soups (cream) MED Stews MED Vegetables MED Fried Foods HI Hot Beverages HI Soups (liquid) HI

Setting the Warmer (Warm & Ready™) Zone (some models)

The purpose of the Warmer Zone is to keep hot cooked foods at serving

temperature. Always start with hot food. It is not recommended to heat cold

food on the WarmerZone. All food placed on the Warmer Zone should be covered with a lid or aluminum

foil to maintain quality. For best results, when warming pastries or breads, the

cover should have an opening to aiiow moisture to escape. Do not use plastic

wrap to cover food. Plastic may melt onto the surface and be very difficult to clean.

Use only dishware, utensils and cookware recommended for oven and cooktop use on the Warmer Zone.

iàCAUTION

when it is hot.

iàCAUTION

the warm zone as cookware and plates will be hot.

Unlike the surface elements, the Warmer Zone will not glow red

I Always use potholders or oven mitts when removing food from

Setting the Warmer (Warm & Ready™) Zone Control

To set the control, push in either direction and turn the knob (See Fig 2). The temperatures are approximate, and are designated by HI, MED and

LO. However, the control can be set at any position between HI and LO for

different levels of heating.

When ready to serve, turn the control to OFF. The Warmer Zone will remain

warm until the indicator light goes OFF.

Temperature Selection - Refer to the chart at the side column for

recommended heating levels. If a particular food is not listed, start with the medium level, and adjust as needed. Most foods can be kept at serving temperatures by using the medium level.

Note; Use the Warmer Zone to keep cooked foods hot such as; vegetables,

gravies, casseroles, soups, stews, breads, pastries and oven-safe dinner plates.

Page 11

Surface Cooking

To Set the Cooktop Lockout Feature (some models) Hi Lockout

The pad is used to activate the Cooktop Lockout feature which will lock all surface elements from being accidentally turned ON. This feature will only lock the cooktop.

To turn the Cooktop Lockout Feature ON;

1. BE SURE ALL surface element controls are set to the OFF position.

2. Press and hold until one beep is heard (after 3 seconds), if a triple beep sounds instead, check all surface elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn ON and the

cooktop controls and functions are locked out until the cooktop is unlocked.

To turn the Cooktop Lockout Feature OFF:

1. BE SURE ALL surface element controls are set to the OFF position.

2. Press and hold © until one beep is heard (after 3 seconds). If a triple beep sounds instead, check all surface elements and turn them to the OFF position and repeat this step. The Cooktop Locked indicator light will turn OFF and the

cooktop may be used normally. Note: Starting a Self-Clean cycle will also turn ON the Cooktop Lockout feature. The cooktop will remain locked until the Self-Clean cycle has completed and the oven door has unlocked. If a power failure occurs after the Cooktop Lockout has been activated, you must turn OFF the Cooktop Lockout feature before being able to use the cooktop features again.

Using proper cookware

The size and type of cookware used will influence the setting needed for best cooking results. Cookware should have flat bottoms that make good contact with the entire surface heating element (See Fig. 2). Check for flatness by rotating a ruler across the bottom of the cookware (See Fig. 3).

Cookware Material Types

The cookware material determines how evenly and quickly heat is transferred from the surface element to the pan bottom. The most popular materials available are:

ALUMINUM - Excellent heat conductor. Some types of food will

cause it to darken (Anodized aluminum cookware resists staining & pitting). If aluminum pans slide across the ceramic cooktop, they may leave metal marks which will resemble scratches. Remove these marks immediately.

‘CORRECT

Flat bottom and straight

sides. Tight fitting lids. Weight of handle does not

tilt pan. Pan is well

balanced. Pan sizes match the

amount of food to be prepared and the size of

the surface element.

Made of a material that

conducts heat well.

Easy to clean.

Always match pot diameter to element surface diameter. Fig. 2

INCORRECT

Curved and warped pan bottoms.

Pan overhangs element b more than one-half inch.

Pan is smaller than element.

Heavy handle tilts pan.

ffl

■ÎJ

COPPER - Excellent heat conductor but discolors easily. May

leave metal marks on ceramic glass (see Aluminum above).

STAINLESS STEEL - Slow heat conductorwith uneven cooking

results. Is durable, easy to clean and resists staining.

CAST IRON - A poor heat conductor however will retain heat very

well. Cooks evenly once cooking temperature is reached. Not recommended for use on ceramic cooktops.

PORCELAIN-ENAMEL on METAL - Heating characteristics will

vary depending on base material. Porcelain-enamel coating must be smooth to avoid scratching ceramic cooktops.

GLASS - Slow heat conductor. Not recommended for ceramic

cooktop surfaces because it may scratch the glass.

Be sure to follow the recommendationsfor using proper cookware as illustrated in

Figs. 2 & 3, For more information about the ceramic cooktop see “Cooktop Cleaning &

Maintenance” in the General

Care & Cleaning section.

Important Note: DO NOT place EMPTY aluminum, glass or porcelain-enamel coated cookware on the ceramic cooktop! The melting

point of cookware made with these materials may be reached quickly especially if left empty & they may bond to the ceramic cooktop. If the cookware melts it WILL damage the cooktop! BE SURE to follow ALL the cookware manufacturer’s suggestions when using ANY type of cookware on the ceramic cooktop.

Page 12

Surface Cooking (cont’d)

Using Power Element (some models)

The “Power Element” feature uses a higherwattage surface radiant element which can bring food items to boil much quicker. The left front radiant element will be clearly marked if this feature is available on your range (See Fig. 1). If equipped with the “Power Element” feature, place the cookware to boil on the left front surface element and follow the instructions “To Operate a Single

Radiant Element” in the Settings Surface Controls section.

E R E I f a?

Fig. 1

Oven Control Functions

READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use ofyouroven, becomefamiliarwith

the various pad functions of the oven as described below.

CLOCK SET

PAD— Used to set the time of day.

OVEN INTERIOR LIGHT PAD— Used to

turn oven interior light ON or OFF. This pad is also used to activate the Cooktop Lockout feature (some models)

SELECT SELF-CLEAN PAD— Used to select

the Self-Cleaning ^ cycle. A 2, 3 or 4 hour Self-Clean time may be selected.

TIMER SET/OFF PAD—

Used to set or cancel the minute timer. The minute timer does not start or stop cooking. Also, TIMER SET/OFF pad is used to set the Continuous Bake feature.

COOK TIME

PAD— Used to enter the length of the baking time.

DELAY START PAD— Used to set

the desired start time for baking & Self-Clean. May be

used with COOK TIME to program a delayed bake cycle.

UP and DOWN ARROW PADS— Used along with the function pads to select oven temperature, cook time, start time (when programming an automatic start time), time of day, clean time and minute timer.

BAKE PAD—Used to select the bake function.

,/v

• 0VÍÍÍ?

• P'fgtiieat

® Csoktsp Laaksti

OVEN, PREHEAT & DOOR LOCKED LIGHTS* — The "OVEN" light will glow each time the oven turns on to maintain the set oven temperature. The "PREHEAT" light will glow when the oven is first set to operate, or if the desired temperature is reset higher than the actual oven temperature. The "DOOR LOCKED" light will flash when the oven door locks and unlocks or when using the Self Clean cycle or the oven door lockout is activated. The indicator light will glow constantly after the door locks. COOKTOP LOCKED light will glow when the cooktop has been locked (some models).

■ —

FEATURE INDICATOR LIGHTS— These light to

show which feature is in

use.

BROIL PAD— Used to select the variable broil function.

WARM & HOLD PAD—

Used to set the Warm &

Hold feature.

STOP/CLEAR PAD—

Used to clear any function previously entered except the time of day and minute timer. Press STOP/CLEAR to stop cooking. Also the STOP/CLEAR pad is used to activate oven door lockout setting.

*Note; The OVEN indicator light on the electronic display . will turn .ON and OFF when using the Bake feature and during preheat. This is normal and indicates that the oven is cycling to maintain the selected baking temperature. Wher*

the preheat indicator light turns OFF, your oven is ready.

For a silent control panel

When choosing a function, a beep will be heard each time a pad is pressed. If desired, the control can be programmed

for silent operation. Press and hold (&). After 7 seconds, the control will beep once. This will block the controls from

sounding when a pad is pressed. To return the sound, press and hold (^) again for 7 seconds until the control beeps

once.

Temperature conversion

The electronic oven control is set to operate in °F (Fahrenheit) when shipped from the factory. The oven can be programmed for any temperature from 170°F to 550°F (77°C to287°C).

To change the temperature to °C (Celsius) or from °C to °F (control should not be in a Bake or Clean mode):

1. Press . "--------------" appears in the display.

2. Press and hold the until "Hi" appears in the display.

3. Press and hold ^ until °F or °C appears in the display.

4. Press the vN. or "V' to change °F to °C or °C to °F.

5. Press any control pad to return to normal operating mode.

Page 13

Setting Oven Controls

To Set the Clock

When the range is first plugged in, or when the power supply to the range has been interrupted, the display will

flash "12:00".

1. Press once (do not hold pad down).

2. Within 5 seconds, press and hold the y\ or 'V" until

the correct time of day appears in the display.

Note: The clock cannot be changed during any timed

bake or Self-Clean cycle.

To Set the Minute Timer:

1. Press (is) .

2. Press the W to increase the time in one minute

increments. Press and hold the VV to increase the time in 10 minute increments. The timer can be set for

any amount of time from 1 minute to 11 hours & 59 minutes.

Note: If the "V" pad is pressed first, the timer will

advance to 11 hours & 59 minutes.

3. The display shows the timer countdown in minutes until 1 minute remains. Then the display will countdown in

seconds.

4. When the set time has run out, the timer will beep 3 times and will continue to beep 3 times every 60

seconds until (S) is pressed.

Note; To turn the time of :day display OFF or ON in the. display press and hold for 15 seconds (the control will

beep once) and then release. This feature does not remove the settime of dayfrom the memory of the control. When the display is turned OFF the time of day will re-appearforafew

seconds any time the pad is touched.: . . . . .

To Set or Change the Temperature for Baking

The oven can be programmed to bake at any temperature from 170T to 550T (77X to 287X).

To Set the Controls for Baking;

1. Press Bake, "

2. Within 5 seconds, press the У\ or 'V'. The display

will show "350°F (177°C)." By pressing and holding

the yv or , the temperature can then be adjusted in 5°F increments (1 °C if the control is set to display

Celsius).

3. As soon as the Уч or 'V' pad is released, the oven will begin heating to the selected temperature. When

the displayed temperature reaches the desired baking temperature, the preheat indicator light will turn OFF and the control will beep 3 times.

4. To cancel baking, press (S).

------------

" appears in the display.

To Change the Oven Temperature after Baking has Started:

1. Press Bake and make sure the bake temperature is

ffl Ж íTlí

Note: The indicator light located above the (S) pad will glow

while the minute timer is active.

Note: The minute timer does not start or stop cooking. It

serves as an extra timer in the kitchen that will beep when the set time has run out. The minute timer can be used alone or during any of the other oven functions. When the

minute timer is in use with any other function, the minute

timer will be shown in the display. To view otherfunctions,

press the pad for that function.

To Change the Minute Timer while it is in use:

While the timer is active and shows in the display, press and hold the W or ’V" to increase or decrease the time.

To Cancel the Minute Timer before the set time

has run out: Press (S).

Note; The time of day most first be set in order to operate

the oven. ■■■.

.....

........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................

displayed.

2. Press the Уч or Ny pad to increase or decrease the

set temperature.

To Set Control for Continuous Bake or 12 Hour Energy Saving

The oven control has a built-in 12 Hour Energy Saving feature that will shut off the oven if the control is left on for more than 11 hours and 59 minutes. The oven can be programmed to override this feature for continuous baking.

To set control for continuous baking:

1. Press and hold (S) down for 5 seconds until tone is heard, "

cooking. The current time of day will return to the display.

2. To cancel the Continuous Bake function, press (S)

and hold for 5 seconds until tone is heard. "12hr" will appear in display indicating that the control has returned to the 12 Hour Energy Saving feature.

---------

hr" will appear in display for continuous

Page 14

Setting Oven Controls (cont’d)

O Oven

To Set Control for Oven Lockout ^ tockaut

The control can be programmed to lock the oven door and lockout the oven control pads.

To set Control for Oven Lockout feature:

1. Press and hold for 3 seconds. "Loc” will appear in display, the “Door Locked” indicator light will flash and

the motor driven door lock will begin to close

automatically. DO NOT open the oven door while the

indicator light is flashing. Allow about 15 seconds for

the oven door to lock. Once the oven door is locked, the

current time of day will appear in the display.

2. To cancel the Oven Lockout feature, press (;^and hold for 3 seconds. The control will unlock the oven door

and resume normal operation.

;Note; If any control, pad is pressed while in the Oven.

Lockout mode, “Loc” will appear in the display until

ithe control pad is released.

4. Within 5 seconds, press the yV or . The display

will show "350T (177°C)." By holding the yV or ,

the temperature can then be adjusted in 5°F increments (1°C if the control is set to display Celsius).

5. Press @. "0:00" will flash in the display (HR:MIN).

6. Press the yV or ”V until the desired baking time appears,

7. Press (S). The earliest possible start time will appear in the display.

8. Press the yV or "V until the desired start time appears in the display.

9. Once the controls are set, the control calculates the time when baking will stop in order to start at the time you have set.

10. The oven will turn ON at the delayed start time and begin heating.

To Set the Timed Bake & Delay Start Features

The @ COOK TIME and @ DELAY START pads

operate the features that will turn the oven ON and OFF at the times you select in advance. The oven can be programmed to start immediately and shut off automatically (Timed Bake) or to begin baking at a later time with a delayed start time (Delay Start).

\To Program the Oven to Begin Baking Immediately

and To Shut Off Automatically (Timed Bake):

1. Be sure that the clock shows the correct time of day,

2. Place the food in the oven.

3. Press Bake, "

4. Within 5 seconds, press the or N/", The display will

show "350°F (177°C)." By holding the xV or , the temperature can then be adjusted in 5°F increments

(1 °C if the control is set to display Celsius).

5. Press (S). "0:00" will flash in the display (HR:iVliN).

6. Press the yV or 'V' until the desired baking time appears in the display.

7. The oven will turn ON and begin heating.

------------

° " appears in the display.

When the Set Bake Time Runs Out:

a. "END" will appear in the display window and the oven

will shut-off automatically.

b. The control will beep 3 times every 60 seconds until

(®) is pressed.

To Change the Oven Temperature or Bake Time after Baking has Started:

1. Press the function pad you want to change.

2. Press the or "V to adjust the setting. NOTE: During Timed Bake the preheat indicator light will

not function. ^ ^ ^ . , . , . . ^ . .

ik CAUTION

Delayed Start features. Foods that can easily spoil such as milk, eggs, fish, meat or poultry should be chilled in the refrigeratorfirst. Even when chilled, they should not stand in the oven for more than 1 hour before cooking begins

and should be removed promptly when cooking is

completed.

To Operate the Oven Light

The interior oven light will automatically turn ON when the oven door is opened. Press to turn the interior oven

light ON and OFF whenever the oven door is closed.

............

Use caution with the Timed Bake and

To Program Oven for a Delayed Start Time and to Shut-Off Automatically (Delayed Start Bake):

1. Be sure that the clock shows the correct time of day,

2. Place the food in the oven.

3. Press BakB, "

-----------

° " appears in the display.

The interior oven light is located at the upper left rear wail of the oven interior and is covered with a glass shield held by a wire holder. The glass shield must be in place whenever the oven is in use. To change the interior oven light, see

"Changing the Oven Light" in the General Care &

Cleaning section.

Page 15

Setting Oven Controls (cont’d)

To Set for Broiling:

1. Arrange the oven rack while oven is still cool. Position the rack as suggested in

the Broil Rack Position Table below,

2. Press "

3. Press and hold the vV or until the desired broil setting level appears in the

----------------

display. Press the W for HI broil or the 'V' for LO broil. Most foods may be

broiled at the HI broil setting. Select the LO broil setting to avoid excess browning or drying of foods that should be cooked to the well-done stage.

"will appear in display.

For optimum browning, preheat broil element for 3 - 4 minutes before

adding food.

Place the insert on the broil pan, then place the food on the insert (See Fig. 1;

some models). DO NOT use the broil pan without the insert or cover the insert with aluminum foil. The exposed fat could ignite.

Place the pan on the oven rack. Open the oven door to the broil stop

position when broiling (See Fig 2).

Broil on one side until food is browned. Turn and broil food on 2nd side.

Note: Always pull the oven rack out to the stop position before turning or

removing the food.

8. When broiling is finished, press (S

ACAUTION

OFF. If the fire continues, use a fire extinguisher. DO NOT put water or flour on the

fire. Flour may be explosive.

Should an oven fire occur, close the oven door and turn the oven

Broil Rack Position Table (Refer to Fig, 3)

Position Food category

NOTE: The broiler pan and the insert (some models) allows grease to drain and be kept away from the high heat of the broiler. DO NOT use the pan without the insert. DO NOT cover the insert with foil; the exposed grease could ignite.

Setting the Warm & Hold™ Feature

The W pad turns ON the Serve Warm & Hold feature and

will maintain an oven temperature of 170° F, The Warm &

Hold feature will keep oven baked foods warm for serving up

to 3 hours after cooking has finished. After 3 hours the Warm & Hold feature will shut the oven OFF automatically. The Warm & Hold feature may be used without any other cooking operations or can be used after cooking has

finished using TIMED BAKE or DELAY START BAKE.

To set Warm & Hold:

1. Arrange interior oven racks and place baked food in oven. If the food is already in the oven go to step 2.

2. Press W. "

Medium steaks and hamburgers Fish, medium-well steaks and pork chops

Well-done foods such as chicken and lobster

-------------

"will appear in the display and the Warm

Fig.3

To turn Warm & Hold OFF at any time press (|^. The Warm & Hold indicator light above the pad will turn OFF,

set Warm & Hold to turn ON automatically:

Arrange i nterior oven racks and place food in oven. Set the oven properly for Timed Bake or Delay Start Bake.

Press S , "

& Hold indicator light above the pad will turn ON.

Press yV or ’V" to start. Warm & Hold is set to turn ON

automatically afterTimed Bake or Delayed StartBake has finished.

----------

" will appear in the display and the Warm

& Hold indicator light above the pad will turn ON. Note: if no further pads are touched within 6 seconds the request to turn ON Warm & Hold will be cleared.

3. Press >V or "V" to start.

To turn Warm & Hold OFF at any time press The Warm & Hold indicator light above the pad will turn OFF.

Page 16

Setting Warmer Drawer Controls

Arranging Warmer Drawer (Warm & Ready™

Drawer) Rack Positions (some models)

Note: Use the warmer drawer to keep hot foods hot such as: vegetables, gravies, meats, casseroles, biscuits and rolls, pastries and heated dinner plates. The rack can be used in 2 ways:

• In the upright position to allow low profile food items to

be placed both underand on top of the rack (for

example, roils or biscuits on top of the rack and a

casserole dish under - See Fig. 1 ).

• in the downward position to allow you to place light

weight food items and empty dishware (for example,

rolls or pastries and dinner plates - See Fig. 2).

NOTE: The warmerdrawer is equipped with a catch which may require extra force when opening and closing the drawer.

To Operate the Warmer (Warm & Ready™) Drawer

Always start with hot food. It is not recommended to heat

cold food in the warmerdrawer.

All food placed in the warmer drawer should be covered with

a lid or aluminum foil to maintain quality. Do not use

plastic wrap to cover food. Plastic may melt onto the drawer and be very difficult to clean.

Use only dishes, utensils and cookware recommended for oven use in the warmerdrawer.

il^CAUTION

removing food from the warmer drawer as cookware and plates will be HOT.

To Set the Warmer (Warm & Ready™) Drawer Thermostat Control (some models)

The thermostat control is used to select the temperature of the warmer drawer. It is located on the control panel (See Fig. 3 on previous page). To set the thermostat, push in and turn the knob to the desired setting. The temperatures are approximate, and are designated by HI, MED and LO.

1. Turn the knob to select the desired temperature setting.

2. For best results, preheat the drawer before adding food. An empty drawer will preheat in approximately 15

minutes.

3. Turn the thermostat control to OFF after use.

! Always use pot holders or oven mitts when

WARMER DRAWER

■■

Warmer (Warm &

Ready™) Drawer Indicator Light

The indicator light is located above the Warmer Drawer thermostat control (some models). It turns on when the control is set, and stays on until the control is turned OFF. The warmer drawer is inoperable during the Self Clean cycle. The indicator light will not come on during the Self-Clean cycle.

NOTE: The warmer drawerwill NOT operate while in the Self-Clean and “Oven Lockout” modes

Warmer (Warm & Ready™) Drawer Temperature Selection (some models)

Refer to the table in the side column for recommended settings. If a particular food is not listed, start with the medium setting, if more crispness is desired, remove the lid oraluminumfoil.

Most foods can be kept at serving temperatures by using the medium setting.

When a combination of foods are to be kept warm (for instance, a meat with 2 vegetables and roils), use the high setting.

Refrain from opening the warmerdrawerwhile in use to eliminate loss of heat from the drawer.

Warmer Drawer Recommended Food Settings Table Food Item Setting

Hamburger patties, poultry & porks chops Hi Pizza, fried foods 8s bacon Hi Gravies, roasts (beef, pork & lamb) MED Vegetables &eggs MED Pastries, biscuits & hard rolls MED Rolls (soft) & empty dinner plates LC

To Remove & Replace Warmer (Warm &

Ready™) Drawer (some models)

A WARNING

occur and result in serious injury or death. Disconnectappiiancefromeiectricpower before cleaning and servicing the warmerdrawer.

Electrical Shock Hazard can

Page 17

Setting Warmer Drawer Controls (cont’d)

To Remove Warmer Drawer:

Acaution

2. Open the drawer to the fuiiy opened position.

3. On the right glide you will find a shield attached with a hex-head screw (see figure 1). Using a 1/4” socket and ratchet remove the shield.

4. Locate glide lever on each side of drawer, pull up on the left glide lever and push down on the right glide lever.

5. Pull the drawer away from the range.

To Replace Warmer Drawer:

Replace shield on the right glide of the drawer body.

Pull the bearing glides to the front of the chassis glide (see

figure 2). Align the glide on each side of the drawer with the glide slots on the

range.

Push the drawer into the range until levers “click” (approximately

2”). Pull the drawer open again to seat bearing glides into position.

If you do not hear the levers “click” or the bearing glides do

not feel seated remove the drawer and repeat steps 2-4. This

will minimize possible damage to the bearing glides.

I Turn power OFF before removing the warmer drawer.

Fig. 2

ffl

Self "Cleaning

Acaution

the range can become very hot to the touch. DO NOT leave small children unattended near the appliance.

Acaution

sensitive to the fumes given off during the Self-Cleaning cycle of any range. Move birds to another well-ventilated room.

Acaution

BOTTOM or any part of the range with aluminum foil

Doing so will destroy heat distribution, produce poor baking results & cause permanent damage to the oven interior (aluminum foil will melt to the interior surface of the oven).

Acaution

damage the automatic door locking system. Use caution

when opening the door after the Self-Cleaning cycle is

completed. The oven may still be VERY HOT.

Seif-Cleaning Oven

A Self-Cleaning oven cleans itself with high temperatures

(well above cooking temperatures) which eliminate soils completely or reduces them to a fine powdered ash you can

wipe away with a damp cloth.

Prepare for the Self-Cleaning Cycle with the following precautions:

• DO NOT use oven cleaners or oven protective coatings

in oraround any part of the Seif-Cleaning oven.

• DO NOT clean the oven door gasket. The woven

During the Self-Cleaning cycle, the outside of

The health of some birds is extremely

DO NOT line the oven walls, racks, OVEN

DO NOT force the oven door open. This can

material of the oven door gasket is essential fora good seal. Care should be taken not to rub, damage or remove the gasket.

DO NOT use any cleaning materials on the oven door

gasket. Doing so could cause damage.

Remove the broiler pan & insert, all utensils & ANY

aluminum foil. These items cannot withstand high cieaning temperatures.

Remove the oven racks, if the racks are left in the oven during the Self-Clean cycle their color will turn slightly blue & the finish will be dull. After the cycle is complete and the oven has cooled, rub the sides of the oven racks with wax paper or a cloth containing a small amount of salad oil (this will make the oven racks glide easier into the oven rack positions).

Remove any excessive spiilovers in the oven cavity before starting the Seif-Cleaning cycle. To clean, use

hot, soapy water and a cloth. Large spillovers can cause heavy smoke or fire when subjected to high temperatures. DO NOT allow food spills with a high sugar or acid content (such as milk, tomatoes, sauerkraut, fruit juices or pie filling) to remain on the surface as they may leave a dull spot even after cleaning. Clean any soil from the oven frame, the doorliner outside the oven door gasket and the small area at the

front center of the oven bottom. These areas heat

sufficiently to burn soil on. Clean with soap and water.

NOTE; Prior to setting the Seif-Clean cycle, any spills

remaining on the oven bottom should be removed.

Page 18

Self-Cleaning (cont’d)

ikCAUTION

and broil elements may appear to have cooled after they have been turned OFF. The

i The oven bake

elements may still be hot

and burns may occur if these elements are touched before they have cooled sufficiently.

Baking element may be tilted about 4 or 6 inches to clean oven bottom.

Starting the Select Self-Clean Cycle or a Delayed Start Self-Clean Cycle

For satisfactory results, use a 2 hour Self-Clean cycle for

light soils and a 3 hour cycle for average or a 4 hour cycle

for heavy soils. NOTE: The kitchen area should be well

ventilated using an open window, ventitlation fan orexhaust hood during the 1 st Seif-Clean cycle. This will help eliminate the normal odors associated with the 1st Self-Clean cycle.

To Set the Controls for a Self-Clean Cycle or a Delayed Start Self-Clean Cycle:

(Note: If you do not want to start a Delayed Seif-Clean

Cycle, skips steps 2 & 3.)

1. Be sure the clock shows the correct time of day.

When the Self-Clean Cycle is Completed:

1. The time of day or "End" will appear in the display

window and the “Clean” and "LOCK" lightwill continue

to glow.

2. Once the oven has cooled down for about 1 HOUR and the "LOCK" light has gone out, the oven door can be opened.

3. If “End” is in the display and the Select Clean indicator

light remains ON, press (s). The time of day will appear in the display.

NOTE: When the oven is cool, wipe away any residue or

powdered ash with a damp cloth or paper towel.

Stopping or Interrupting a Select Self Cleaning Cycle

If it becomes necessary to stop or interrupt a Self-Cleaning cycle:

1. Press (S).

2. Once the oven has cooled down for about 1 HOURand the "LOCK" light has gone out, the oven door can be opened.

3. Restart the Self-Clean cycle once all conditions have been corrected.

2. Press (^). The " : " in the time of day will flash.

3. Press and hold the >N. pad to scroll to the time to start the delayed Self-Clean cycle. Release the pad when the desired time is displayed,

4. Press "------------------------" appears in the display.

5. Press the >V or once. "3:00" appears in the display for a cle. To change to a 2 hour cycle

press 'V", "2:00" appears in the display or to select a 4

hour cycle press VV . "4:00" appears in the display.

As soon as the controls are set, the motor driven lock will begin to close automatically and the “LOCK”

indicator light will flash. DO NOT open the oven door

while the light is flashing (it takes about 15 seconds for the oven door to lock).

6. "CLn" will appear in the display during the Self-Clean

cycle and the "LOCK" light will glow until the Self

ikCAUTION

opening the oven door after the Seif-Cleaning cycle. Stand to the side of the oven when opening the door to allow hot air or steam to escape.

ikCAUTION

damage the automatic door locking system. Use caution and avoid possible burns when opening the door after the

Seif-Cleaning cycle has completed. The oven may still be

VERY HOT.

j To avoid possible burns use care when

DO NOT force the oven door open. This can

Cleaning cycle is complete or cancelled and the oven

temperature has cooled.

Page 19

Generai Care & Cleaning

Cleaning Table

Surfaces

Glass, Painted Plastic Body Parts & Control Knobs

How to Clean

For general cleaning, use a soft cloth, clean with mild dish detergent & water or a 50/50 solution

of vinegar & water. Follow by rinsing the area with clean water; dry & polish with a soft cloth.

Glass cleaners may be used if sprayed on a soft cloth. DO NOT spray liquids directly on the control pad and display areas. DO NOT use large amounts of water on the control panel - excess

water on the control area may cause damage to the appliance. DO NOT use other liquid

cleaners, abrasive cleaners, scouring pads, or some paper towels - they will damage the finish.

Painted Control Panels & Display

areas

Porcelain Enamel Burner Grates,

Before cleaning the control panel, turn all controls to OFF & remove the control knobs. To

remove, pull each knob straight off the shaft. Use the general cleaning instructions provided in the paragraph above.

Clean burner grates, broiler pan & insert in the dishwasher and dry upon removal. If soils are not removed, follow the cooktop cleaning instructions below.

Cooktop Surface, Below Cooktop, Broiler Pan & Insert, Broiler Drawer, Door Liner & Oven Bottom

Oven Racks

Oven Door

Gentle scouring with a soapy scouring pad will remove most spots. Rinse with a 1:1 solution of

clean water & ammonia, if necessary, cover difficult spots with an ammonia-soaked paper towel

for 30 to 40 minutes. Rinse with clean water and a damp cloth, then scrub with a soap-filled scouring pad. Rinse & wipe dry with a clean cloth. Remove all cleaners or the porcelain may

become damaged during future heating. DO NOT use spray oven cleaners on the range top.

Remove racks. See "Removing & Replacing Oven Racks" under Before Setting Oven Controls.

Use a mild, abrasive cleaner, following the cleaner’s recommendations. Rinse with clean water & let dry. After cleaning the racks, rub the sides of the racks with wax paper or a cloth containing a small amount of salad oil (this will make the racks glide easier into the oven rack positions).

Use soap & water to thoroughly clean the top, sides & front of the oven door. Rinse well. You

may use a glass cleaner on the outside glass of the oven door. DO NOT immerse the door in water. DO NOT spray or allow water or the glass cleaner to enter the door vents. DO NOT

use oven cleaners, cleaning powders or any harsh abrasive cleaning materials on the outside of

the oven door. DO NOT clean the oven door gasket. The oven door gasket is made of a woven

material, on Self-Cleaning models, which is essential for a good seal. Care should be taken not to rub, damage or remove this gasket.

ffl

■ÎJ

Stainless Steel

Ceramic Cooktop

Clean stainless steel with hot soapy water & a dishcloth. Rinse with clean water and a cloth.

DO NOT use cleaners with high conecentrations of chlorides or chlorines. DO NOT use harsh scrubbing cleaners. Only use kitchen cleaners that are especially made for cleaning stainless steel. Always be sure to rinse the cleaners form the surface as bluish stains may occur during heating that cannot be removed.'

See “Cooktop Cleaning & Maintenance” in this section for complete instructions.

Changing the Oven Light

The oven light automatically turns ON when the door is opened. The oven light may also be manually operated by pressing the pad. The oven light bulb is located at the rear of the oven and is covered with a glass shield held by a wire holder.

The glass shield must be in place whenever the oven is in use.

To replace the oven light bulb:

1. Turn electrical power off at the main source or unplug the range.

2. Press wire holder to one side to release the glass shield.

3. Replace bulb with a new40 watt appliance bulb.

4. Replace glass shield over bulb and snap wire holder into place.

5. Turn power back on again at the main source (or plug the range back in).

6. The clock will then need to be reset. To reset, see Setting the Clock and Minute

Oven

Light

Wire

Holder

Timer in this Use & Care Guide.

^CAUTION

light. Wear a leather-faced glove for protection against possible broken glass.

Be sure the range is unplugged and all parts are COOL before replacing oven

Page 20

General Care & Cleaning (cont’d)

Ceramic Glass Cooktop Cleaning & Maintenance

Consistent andproper cleaning is essential to maintaining your Ceramic .Glass cooktop.

Prior to using your cooktop for the first time, apply the recommended CookTop® Cleaning Creme to the ceramic surface (on the web visit www.sears.com for replacement cooktop cleaner, item number 40079). Buff with a non-abrasive cloth or no-scratch cleaning pad. This will make cleaning easier when soiled from cooking. The special cooktop cleaning cream leaves a protective finish on the glass to help prevent scratches and abrasions.

......

i Sliding aluminum or copper clad bottom pans on the cooktop can cause metal markings on

the cooktop surface. These marks should be removed immediately after the cooktop has

cooled using the cooktop cleaning cream. Metal marks can become permanent if not removed prior to future use.

Cookware (cast iron, metal, ceramic or glass) with rough bottoms can mark or scratch the cooktop surface. Do not slide anything metal or glass across the cooktop. Do not use your cooktop as a cutting board or work surface in the kitchen. Do not cook foods directly on the cooktop surface without a pan. Do not drop heavy or hard objects on the glass cooktop, they may cause it to crack.

Cleaning Recommendations for Ceramic Glass Cooktop

Acaution

iiWARNING

chemically damage the ceramic-glass surface.

For lightto moderate soil:

Apply a few drops of CookTop® Cleaning Creme directly to the cooktop. Use a paper towel or use a non-abrasive plastic type no

scratch cleaning pad to clean the entire cooktop surface. Make sure the cooktop is cleaned thoroughly, leaving no residue.

For heavy, burned on soil:

Apply a few drops of CookTop® Cleaning Creme directly to the soiled area. Rub the soiled area using a non-abrasive plastic type

no-scratch cleaning pad, applying pressure as needed. Do not use the pad you use to clean the cooktop for any other purpose. If soils remain, carefully scrape soils with a metal razor blade scraper, holding scraper at a 30

degree angle to the surface. Remove loosened soils with cooktop cleaning cream and buff surface clean. IMPORTANT NOTE: Damage to the ceramic glass cooktop may occur if you use an abrasive type cleaning pad. Only use cleaning products that have been specifically designed for ceramic glass cooktops.

Plastic or foods with a high sugar content:

These types of soils need be removed immediately if spilled or melted onto the ceramic cooktop surface. Permanent damage (such as pitting of the cooktop surface) may occur if not removed immediately. After turning the surface elements OFF, use a razor blade scraper or a metal spatula

with a mitt and scrape the soil from the hot surface (as illustrated). Allow the cooktop to cool, and

use the same method for heavy or burned on soils.

Before cleaning the cooktop, be sure the controls are turned to OFF and the cooktop is COOL.

DO NOT use a cooktop cleaner on a hot cooktop. The fumes can be hazardous to your health, and can

Do not use the following on the ceramic glass cooktop:

• Do not use abrasive cleaners and scouring pads, such as metal and some nylon pads. They may scratch the cooktop, making it more difficult to clean.

• Do not use harsh cleaners, such as chlorine bleach, ammonia or oven cleaners, as they may etch or discolor the cooktop.

• Do not use dirty sponges, cloths or paper towels, as they can leave soil or lint on the cooktop which can burn and cause discoloration.

Special Caution for Aluminum Use on the Ceramic Cooktop:

• Aluminum Foil - Use of aluminum foil on a hot cooktop will damage the ceramic

cooktop. Do not use thin aluminum cooking utensils or allow aluminum foil to touch

the ceramic cooktop under ANY circumstances.

• Aluminum utensils - The melting point of aluminum is much lower than that of

other metals. Care must be taken when aluminum pots or pans are used on the cooktop. If allowed to boil dry, not only will the utensil be destroyed. but it may fuse to, break or mark the ceramic glass surface, permanently damaging the cooktop surface. 2q

Page 21

General Care & Cleaning (cont’d)

Removing & Replacing the Lift-Off Oven Door

.oc

^CAUTION

the inside of the door facing down.

The door is heavy. For safe, temporary storage, lay the door flat with

To Remove Oven Door:

1. Open oven door completely (horizontal with floor - See Fig. 1).

2. Pull the door hinge locks on both left and right door hinges down from the oven frame completely towards the oven door (See Fig. 2). A tool such as a small flat-blade screwdriver may be required.

3. Firmly grasp both sides of oven door along the door sides (Do not use the oven door handle - See Fig. 3).

4. Close the door to the broil stop position (the oven door will stop into this position just before fully closing).

5. With the oven door in the broil stop position, lift the oven door hinge arms over the roller pins located on each side of the oven frame (See Fig. 4).

To Replace Oven Door:

1. Firmly grasp both sides of oven door along the door sides (Do not use the oven door handle - See Fig. 3).

Holding the oven door at the same angle as the removal position, seat the

hook of the hinge arm over the roller pins located on each side of the oven doorframe (See Fig. 4). The hook of the hinge arms must be fully seated onto the roller pins.

Fully open the oven door (horizontal with floor - See Fig. 1).

Push the door hinge locks up towards and into the oven frame on both left and right oven door hinges (See Fig. 2) to the locked position. Close the oven door.

ffl

Special Door Care Instructions:

Roller Pin cm

HIngi

Arm

H«k

Fig. 4

Most oven doors contain glass that can break. Read the following recommendations:

1. Do not close the oven door until all the oven racks are fully in place.

2. Do not hit the glass with pots, pans, or any other object.

3. Scratching, hitting, jarring or stressing the glass may weaken its structure causing an increased risk of breakage at a later time.

Adjusting the Oven Temperature

Your oven control has been precisely set at the factory. This setting may differ from your previous oven however, so your recipe times may not give you the results you expect, if you think that the oven is cooking too hot or too cool for your 4. recipe times, you can adjust the control so that the oven cooks hotter or cooler than the temperature displayed.

To Adjust Oven Temperature:

1. Press Bake .

2. Set the temperature to 550°F (287°C) by pressing and holding the W . 5

original factory temperature setting and the current temperature setting. If the oven control has the original factory calibration, the display will read "0." The temperature can now be adjusted up or down 35°F

(17°C), in 5°F steps by pressing and holding the yV or

'V . Adjust until the desired amount of offset appears

in the display. When lowering the oven temperature, a

minus sign (-) will appear before the number to indicate that the oven will be cooler by the displayed amount of degrees. When you have made the desired adjustment, press

3. Within 2 seconds, press and hold soke until the 2 digit

display appears. Release Bake. The display now

indicates the amount of degrees offset between the

S) to go back to the time of day display.

Note: Oven temperature adjustments made will not change

the Self-Cleaning feature temperature.

Page 22

Before You Call

Solutions to Common Problems

Before you call for service, review the following list. It may save you time & expense. The list includes common occurrences (shown in bold) that are not the result of defective workmanship or materials in this appliance. The possible corrections to these problems are provided with the problem listed;

Range is not level - (1) Poor installation. Place oven rack in center of oven. Place a level on the oven rack. Adjust leveling legs at base of range until the oven rack is level. (2) Be sure

floor is level, strong & stable enough to adequately support

range. (3) If floor is sagging or sloping, contact a carpenter to correct the situation, (4) Kitchen cabinet alignment may make range appear not level. Be sure cabinets are square & have sufficient room for range clearance.

Cannot move appliance easily. Appliance must be accessible

for service - (1 ) Cabinets not square or are built in too tightly.

Contact builder or installer to make appliance accessible. (2) Carpet interferes with range. Provide sufficient space so range can be lifted over carpet.

Surface element too hot or not hot enough - Incorrect control setting. Be sure the correct control is ON for the element to be used.

Surface element does not heat - (1 ) Lightweight or warped pans used. Use only flat, evenly balanced, medium or heavyweight cookware. Flat pans heat better than warped pans. Cookware materials and weight of the material affect heating. Heavy & medium-weight pans heat evenly. Because lightweight pans heat unevenly, foods may burn easily. (2) No power to the appliance. Check steps under Does Not Operate" in this checklist. (3) Incorrect control setting. Make sure the correct control is ON for the surface element to be used.

Entire appliance does not operate - (1 ) The time of day is not set. The time of day must first be set in order to operate the oven. See “To Set the Clock” in the Setting Oven Controls section.(2) Make sure cord/plug is plugged correctly into outlet. (3) Service wiring is not complete. Call 1-800-4-MY-HOME®

for assistance (See back cover). (4) Electrical power outage.

Check house lights to be sure. Call your local electric company

for service.

Oven does not operate - Be sure the oven controls are set properly for the desired function. See Setting Oven Controls in this Use & Care Manual or read the instructions “Entire

appliance does not operate" in this checklist. Oven light does not work (some models) - Replace or tighten

bulb. See Changing Oven Lightsection in this Use & Care Manual, Oven control beeps and displays any “F” code error if or

example F11) - Electronic control has detected a fault

condition. Press CLEAR/OFF to clear the display & stop beeping. Reprogram oven. If fault recurs, record fault number. Press CLEAR/OFF & call 1-800-4-MY-HOME® for assistance (See back cover).

Flames inside oven or smoking from oven vent - Excessive spillovers in oven. For example this will happen for pie spillovers or large amounts of grease left on the oven bottom. Wipe up excessive spillovers before starting oven. If flames or excessive smoke are present see “Broiling” in the Setting

Oven Controls section.

"Entire Appliance

Oven smokes excessively during broiling - (1) Control(s) not set properly. Follow Broil instructions under Setting Oven Controls. (2) Make sure oven door is opened to broil stop position. (3) Meat too close to the broil element. Reposition the

broil rack to provide proper clearance between the meat & the element. Preheat the broil element for searing. (4) Meat not properly prepared. Remove excess fat from meat. Cut fatty edges to prevent curling, but do not cut into lean. (5) Insert on broiler pan wrong side up & grease not draining. Always place grid on the broiler pan with ribs up & slots down to allow grease to drip into pan (some models). (6) Grease has built up on oven surfaces. Regular cleaning Is necessary when broiling frequently. Old grease or food spatters cause excessive smoking.

Poor baking results - Many factors affect baking results. Make sure the proper oven rack position is used. Center food in the oven & space pans to allow air to circulate. Allow the oven to preheat to the set temperature before placing food in the oven. Try adjusting the recipe's recommended temperature or baking time. If you feel the oven is too hot or cool, see

Oven Temperature in this Use & Care Manual. Soil not completely removed after Self-Cleaning cycle -

Failure to clean bottom, front top of oven, frame of oven or door area outside oven seal. These areas are not in the Self Cleaning area, but get hot enough to burn on residue. Clean these areas before the Self-Cleaning cycle is started. Burnedon residue can be cleaned with a stiff nylon brush and water or a nylon scrubber. Be careful not to damage the oven gasket.

Self-Cleaning cycle does not work - (1) Oven control not set properly. Follow instructions under Self-Cleaning. (2) Self Cleaning cycle was interrupted. Follow steps under "Stopping or Interrupting a Self-Cleaning Cycle" under Self-Cleaning.

Metal marks (Ceramic Cooktop models) - Sliding or scraping of metal utensils on cooktop surface. Do not slide metal utensils on cooktop surface. Use a ceramic-glass cooktop cleaning creme to remove the marks. See "Cooktop Cleaning and Maintenance" in the Care & Cleaning section.

Scratches or abrasions on cooktop surface (Ceramic Cooktop models) - (1) Coarse particles such as salt or sand

between cooktop and utensils can cause scratches. Be sure cooktop surface and bottoms of utensils are clean before usage. Small scratches do not affect cooking and will become less visible with time. (2) Cleaning materials not recommended for ceramic-glass cooktop have been used. See "Cooktop Cleaning & Maintenance." (3) Cookware with rough bottom has been used. Use smooth, flat-bottomed cookware.

Brown streaks or specks on cooktop surface (Ceramic Cooktop models) - Boilovers are cooked onto surface. Use

razor blade scraper to remove soil. See "Cooktop Cleaning and Maintenance" in the Care & Cleaning section.

Areas of discoloration with metallic sheen (Ceramic Cooktop models) - Mineral deposits from water and food. Remove using

a ceramic-glass cooktop cleaning creme. Use cookware with clean, dry bottoms.

Adjusting Your

Page 23

Get it

Your Home

For repair-in your home-of all major brand appliances,

lawn and garden equipment, or heating and cooling systems,

no matter who made it, no matter who sold it!

For the replacement parts, accessories and

owner’s manuals that you need to do-it-yourself.

For Sears professional installation of home appliances

and items like garage door openers and water heaters.

1 -800-4“!iY-HOME® (1-800-469-4663)

Call anytime, day or night (U.S.A. and Canada)

www.sears.com www.sears.ca

Our Home

For repair of carry-in items like vacuums, lawn equipment,

and electronics, cal! or go on-line for the location of your nearest

Sears Parts & Repair Center.

1-800-488-1222

Call anytime, day or night (U.S.A. only)

www.sears.com

To purchase a protection agreement (U.S.A.)

or maintenance agreement (Canada) on a product serviced by Sears:

1 -800-827-6655 (u.s.A.) 1 -800-361 -6665 (Canada)

Para pedir servicio de reparación

a domicilio, y para ordenar piezas:

1-888-SU-HOGAR®

(1-888-784-6427)

Au Canada pour service en français:

1-800-LE-FOYER^^

(1-800-533-6937)

www.sears.ca

® Registered Trademark / ™ Trademark / Service Mark of Sears Brands, LLC © Marca Registrada / ™ Marca de Fábrica / Marca de Servicio de Sears Brands, LLC

Marque de commerce / “° Marque déposée de Sears Brands, LLC

) Sears Brands, LLC
