Kenmore 790. 7830 User Manual

Use & Care Guide Guía de uso y cuidada

English / Español

Model/Modelos: 790. 7830*, 7840*, 7841*

Kenmore Elite

a gas

color number, código de color

P/N 316901017

Sears Brands Management Corporation

Hoffman Estates, IL 60179 U.S.A.

www.kenmore.com
www.sears.com

Table of Contents

Warranty..............................................................................................................................2

Important Safety Instructions.......................................................................................... 3-6

Product Record/Serial Plate Location.................................................................................6

Range Features..................................................................................................................7

Before Setting Oven Controls.............................................................................................8

Removing, replacing and arranging oven racks

Before Setting Surface Controls.........................................................................................9

Setting Surface Controls..............................................................................................10-11

Setting surface burners................................................................................................10

Setting Double Ring burner (some models)

Oven Control Functions....................................................................................................12

Setting Oven Controls..................................................................................................13-25

Setting clock.................................................................................................................13

Setting timer.................................................................................................................13

Add 1 minute................................................................................................................13

Setting 12 or 24 hour display mode.............................................................................13

Changing betv/een continuous bake setting or 12-Hour

Energy Saving feature.................................................................................................13

Changing oven temperature display mode..................................................................14

Setting silent or audible control mode..........................................................................14

Oven Lockout...............................................................................................................14

Setting Preheat............................................................................................................15

Setting Bake................................................................................................................ 15

Setting Cook Time.......................................................................................................16

Setting Delay Start.......................................................................................................16

............................................................

...............................................................

11

Conv Bake.................................................................................................................. 17

Conv Roast..................................................................................................................18

Conv Convert...............................................................................................................18

Broil ............................................................................................................................ 19

Cakes Breads..............................................................................................................20

8

Meat probe.............................................................................................................20-21

Slov/ Cook................................................................................................................... 22

Warm & Hold™ ...........................................................................................................23

Recipe Recall.............................................................................................................. 23

Accent light..................................................................................................................24

Adjusting oven temperature.........................................................................................25

Restoring factory default settings................................................................................25

Sabbath feature......................................................................................................26-27

Warmer Drav/er...........................................................................................................28-31

Warmer drav/er controls..............................................................................................29

Proof Bread................................................................................................................. 30

Flex Clean....................................................................................................................31-32

Care & Cleaning..........................................................................................................33-36

Cleaning recommendation table..................................................................................33

Cleaning the cooktop and surface burners..................................................................34

Replacing oven lights..................................................................................................35

Removing and replacing lift-off oven door...................................................................36

Before You Call - Solutions to common problems.......................................................37-39

Master Protection Agreements.........................................................................................41

Sears Service...................................................................................................back cover

Kenmore Elite Limited Warranty

When installed, operated and maintained according to all instructions supplied with the product, if this appliance fails due to a defect
in material and workmanship within one year from the dote of purchase, call 1-800-4-MY-HOME® to arrange for free repair.

For five years from the dote of purchase, if the cooktop gloss fails due to thermal shock or the cooktop elements ore defective, coll
1-800-4-MY-HOME® to arrange for free repair. After the first year from purchase date, you must pay the labor cost of part installation. This
warranty applies for only 90 days from the dote of purchase if this appliance is ever used for other than private family purposes.

This warranty covers only defects in material and workmanship. Sears will NOT pay for:

1. Cracks in a ceramic gloss cooktop that are not a result of thermal shock.

2. Stains and scratches on a ceramic gloss cooktop resulting from failure to maintain it properly according to all instructions supplied with the

product.

3. Expendable items that can wear out from normal use, including but not limited to filters, belts, light bulbs, and bags.

4. A service technician to instruct the user in correct product installation, operation or maintenance.

5. A service technician to clean or maintain this product.

6. Damage to or failure of this product if it is not installed, operated or maintained according to all instructions supplied with the product.
7 Damage to or failure of this product resulting from accident, abuse, misuse or use for other than its intended purpose.

8. Damage to or failure of this product caused by the use of detergents, cleaners, chemicals or utensils other than those recommended in oil

instructions supplied with the product.

9. Damage to or failure of ports or systems resulting from unauthorized modifications made to this product.

Disclaimer of implied warranties; limitation of remedies

Customer’s sole and exclusive remedy under this limited warranty shall be product repair as provided herein. Implied warranties,
including warranties of merchantability or fitness for a particular purpose, are limited to one year or the shortest period allowed by low.
Sears shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion or limitation of
incidental or consequential damages, or limitation on the duration of implied warranties of merchantability or fitness, so these
exclusions or limitations may not apply to you.

This warranty applies only while this appliance is used in the United States or Canada.

This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
Sears Canada Inc., Toronto, Ontario, Canada AA5B 2B8

All rights reserved. Printed in the USA.

Important Safety Instructions

Read all instructions before using this appliance.

This manual contains important safety symbols and
instructions. Please pay attention to these symbols and
follow all instructions given.

Definitions

^^This is the safety alert symbol. It is used to alert you to

potential personal injury hazards. Obey all safety

messages that follow this symbol to avoid possible injury or
death.

Do not attempt to install or operate your appliance until
you have read the safety precautions in this manual. Safety
items throughout this manual are labeled with a
WARNING or CAUTION statement based on the risk type.

A WARNING

situation which, if not avoided, may result in death or
serious injury.

A CAUTION

situation which, if not avoided, may result in minor or
moderate injury.

- indicates a potentially hazardous

indicates a potentially hazardous

A WARNING

followed exactly, a fire or explosion may result
causing property damage, personal injury or death.

FOR YOUR SAFETY:

— Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any

other appliance.
— WHAT TO DO IF YOU SMELL GAS:
* Do not try to light any appliance.
* Do not touch any electrical switch; do not use

any phone in your building.
* Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.
* If you cannot reach your gas supplier, call the

fire department.
— Installation and service must be performed by a

qualified installer, servicer or the gas supplier.

If the information in this manual is not

Remove all tape and packaging before using the range.

Destroy the carton and plastic bags after unpacking the
range. Never allow children to play with packaging
material.

Proper Installation—Be sure your appliance is properly

installed and grounded by a qualified technician in
accordance with the National Fuel Gas Code ANSI
Z223.- latest edition, or in Canada CAN/CGA B149.1,
and CAN/CGA B149.2, and the National Electrical Code
ANSI/NFPA No.70-latest edition, or in Canada CSA
Standard C22.1, Canadian Electrical Code, Part 1, and
local code requirements. Install only per installation

instructions provided in the literature package for this
range. Ask your dealer to recommend a qualified
technician and an authorized repair service. Know how
to disconnect the power to the range at the circuit
breaker or fuse box in case of an emergency.

User servicing—Do not repair or replace any part of the

appliance unless specifically recommended in the
manuals. All other servicing should be done only by a

qualified technician. This may reduce the risk of personal
injury and damage to the range.

Ask your dealer to recommend a qualified technician and
an authorized repair service. Know how to disconnect the
power to the range at the circuit breaker or fuse box in
case of an emergency.

A WARNING

* All ranges can tip.
* Injury to persons could result.
* Install anti-tip device packed with

range.

* See Installation Instructions.

To reduce the risk of tipping, the range
must be secured by properly installed
anti-tip bracket provided with the
range. To check if the bracket is
installed properly, visually check that
rear leveling leg is inserted into and
fully secured by the anti-tip bracket by
removing lower front panel or storage
drawer from the range.

For models equipped with a warmer drawer or lower oven,
grasp the top rear edge of the range and carefully attempt
to tilt it forward. Refer to the installation instructions for
proper anti- tip bracket installation.

• Never modify or alter the construction of a range by
removing the leveling legs, panels, wire covers, anti-tip
brackets/screws, or any other part of the range.

• Remove the oven door from any unused range if it is to
be stored or discarded.

Save these instructions for future reference.

Important Safety Instructions

Air curtain or other overhead range hoods, which operate

by blowing a downward air flow on to a range, shall not
be used in conjunction with gas ranges other than when the

hood and range have been designed, tested and listed by
an independent test laboratory for use in combination with
each other.

For electric ignition models only: Do not attempt to
operate the range during a power failure. If the power

fails, always turn off the range. If the range is not turned
off and the power resumes, the range will begin to operate
again. Once the power resumes, reset the clock and oven
function.

I

A WARNING

heater to heat or warm the room. Doing so may result in
CARBON MONOXIDE poisoning.

A WARNING

the oven bottom or cover an entire oven rack with materials
such as aluminum foil. Doing so blocks air flow through the
oven and may cause CARBON MONOXIDE poisoning.
Aluminum foil linings may trap heat, causing a fire hazard.

A WARNING

drawers of a range can result in serious injuries and also
cause damage to the appliance. DO NOT allow children

to climb or play around the range. The weight of a child on
an open oven door may cause the range to tip, resulting in
serious burns or other injury.

F!Vi7Jt-l^ll^[cl Storage in or on appliance — flammable
materials should not be stored in an oven, near surface
units or in the storage drawer, warmer drawer or lower
oven. This includes paper, plastic and cloth items, such as

cookbooks, plasticware and towels, as well as flammable

liquids. Do not store explosives, such as aerosol cans, on or

near the range.

NEVER use this appliance as a space

I

NEVER cover any slots, holes or passages in

I Stepping, leaning or sitting on the door or

A CAUTION

— smother the fire with a pan lid, or use baking soda, a
dry chemical or foam-type extinguisher.

closely. Fat or grease may catch fire if allowed to become

too hot.

A CAUTION

potholders on hot surfaces may result in burns from
steam. Do not let potholders touch hot heating elements.

Do not use a towel or other bulky cloth instead of a

potholder.

A CAUTION

buildup of pressure may cause container to burst and
result in injury.

I Do not use water or flour on grease fires

When heating fat or grease, watch it

I Use dry potholders — moist or damp

I

Do not heat unopened food containers —

IMPORTANT INSTRUCTIONS FOR USING YOUR

OVEN

I

A CAUTION

aluminum foil to line the oven bottom. Only use aluminum

foil as recommended in this manual. Improper installation
of these liners may result in risk of electric shock, or fire.

• Use care when opening oven door , warmer drawer or
lower oven door — Stand to the side of the range when

opening the door of a hot oven. Let hot air or steam
escape before you remove or replace food in the oven.

• Keep oven vent ducts unobstructed. The oven vent is
located below the backguard. Touching the surfaces in
this area when the oven is operating may cause severe
burns. Also, do not place plastic or heat-sensitive items
on or near the oven vent. These items could melt or
ignite.

Protective Liners — DO NOT use

I

A WARNING

children should not be left alone or unattended in the
area where appliance is in use. They should never be

allowed to sit or stand on any part of the appliance,
including the storage drawer, lower broiler drawer, warmer
drawer or lower double oven.

A CAUTION

the cabinets above a range or on the backguard of the
range. Children climbing on the range to reach items

could be seriously injured.

DO NOT LEAVE CHILDREN ALONE —

I Do not store items of interest to children in

Save these instructions for future reference.

• Placement of Oven Racks. Always place oven racks in

desired location while oven is cool. If rack must be
moved while oven is hot use extreme caution. Use
potholders and grasp the rack with both hands to
reposition. Do not let potholders contact the hot heating
elements in the oven. Remove all utensils from the rack
before moving.

• Do not use the broiler pan without its insert. The broiler
pan and its insert allow dripping fat to drain and be kept
away from the high heat of the broiler.

• Do not cover the broiler insert with aluminum foil.
Exposed fat and grease could ignite.

Important Safety Instructions

Important safety notice

The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects
or other reproductive harm, and requires businesses to
warn customers of potential exposure to such substances.

IMPORTANT INSTRUCTIONS FOR USING YOUR

COOKTOP

I

A WARNING

so it does not extend beyond the edge of the utensil. The
use of undersized utensils will expose a portion of the

burner flame to direct contact and may result in ignition of
clothing. Proper relationship of utensil to flame will also
improve efficiency.

• Know which knob controls each surface burner. Place a

pan of food on the burner before turning it on, and turn
the burner off before removing the pan.

■ Always turn knob to the full LITE position when igniting

top burners. Visually check that burner has lit. Then

adjust the flame so it does not extend beyond the edge
of the utensil.

■ Utensil handles should be turned inward and not extend

over adjacent surface burners — To reduce the risk of

burns, ignition of flammable materials, and spillage due
to unintentional contact with the utensil, the handle of the
utensil should be positioned so that it is turned inward,
and does not extend over adjacent surface burners.

■ Never leave surface burners unattended at high heat

settings — Boilovers cause smoking and greasy spillovers

that may ignite, or a pan that has boiled dry may melt.

• Glazed cooking utensils — Only certain types of glass,

glass/ceramic, ceramic, earthenware, or other glazed
utensils are suitable for cook top service without breaking
due to the sudden change in temperature. Check the
manufacturer’s recommendations for cook top use.

■ When flaming foods under a ventilating hood, turn the

fan on.

Use Proper Flame Size — Adjust flame size

IMPORTANT INSTRUCTIONS FOR SELF
CLEANING OVENS

• Clean in the self-cleaning cycle only the parts listed in
this Use & Care Manual. Before self-cleaning the oven,

remove the oven racks, broil pan, broil pan insert and
any cookware, cooking utensils or foods from the oven.

• Do Not Use Oven Cleaners — No commercial oven
cleaner or oven liner protective coating of any kind
should be used in or around any part of the oven.

• Do Not Clean Door Gasket — The door gasket is
essential for a good seal. Care should be taken not to
rub, damage or move the gasket.

• The health of some birds is extremely sensitive to the
fumes given off during the self-cleaning cycle of any
range. Move birds to another well-ventilated room.

IMPORTANT INSTRUCTIONS FOR CLEANING YOUR RANGE

A CAUTION

range, be sure all controls are turned OFF and the range is
COOL. The range may be hot and can cause burns.

• Clean the range regularly to keep all parts free of
grease that could catch fire. Pay particular attention to

the area around each surface burner. Do not allow
grease to accumulate.

• Kitchen cleaners and aerosols — Always follow the
manufacturer's recommended directions for use. Be

aware that excess residue from cleaners and aerosols
may ignite causing damage and injury.

• Clean ventilating hoods frequently — Grease should not
be allowed to accumulate on the hood or filter. Follow

the manufacturer’s instructions for cleaning hoods.

Before manually cleaning any part of the

Save these instructions for future reference.

5

Grounding Instructions

Important Safety Instructions

Avoid fire hazard or electrical shock. DO

NOT use an adapter plug, an extension cord, or remove

grounding prong from electrical power cord. Failure to
follow this warning can cause serious injury, fire or death.

This appliance is equipped with a 3-prong grounding plug
for your protection against shock hazard and should be

plugged directly into a properly grounded receptacle. DO

NOT cut or remove the grounding prong from this plug.

For personal safety, the range must be properly grounded.

For maximum safety, the power cord must be plugged into
an electrical outlet that is correctly polarized and properly
grounded.

Grounding type
wall receptacle

Do not under any
circumstance, cut,
remove, or bypass
the grounding prong.

Power supply cord

with 3-prong
grounding plug.

If a 2-prong wall receptacle is the only available outlet, it

is the personal responsibility of the consumer to have it

replaced with a properly grounded 3-prong wall
receptacle installed by a qualified electrician.

See the INSTALLATION INSTRUCTIONS packaged with
this range for complete installation and grounding
instructions.

Conversion to L.P. Gas

I

 WARNING

shock may occur if the range is not installed by a
qualified installer or electrician.

 WARNING

required in order for this appliance to satisfactorily meet
the application needs must be made by a qualified
technician.

This appliance allows for conversion to Liquefied Petroleum
(L.P.) Gas.

If L.P. conversion is needed, contact your local L.P. Gas
provider for assistance. The L.P. conversion kit is provided
with this appliance and is located on the lower REAR (back
side) panel of the range. Before installing the kit be sure to
follow the L.P. Installation Instructions carefully.

Personal injury or death from electrical

I Any additions, changes or conversions

Save these instructions for future reference.

Product Record

In this space below, record the date of purchase, model
and serial number of your product. You will find the model
and serial number printed on an identification plate. See

bottom of this page for serial plate location.

Model No. ________________________________________

Serial No.

Date of Purchase___________________________________________

Save sales receipt for future reference.

________________________________________________

Serial Plate Location

To locate the serial plate open warmer
drawer. The serial plate is attached to the
lower right oven frame.

Range Features

К

Your gas range features include:

1. Electronic oven control with timer.

2. Glass touch sensitive control panel.

3. Warm & Ready™ drawer control & indica

4. Proof Bread indicator light.

5. Accent Light.

6. Oven Lockout control.

7. Left Front burner valve & knob.

8. Left Rear burner valve & knob.

9. Center Burner valve & knob.
Ю. Right Front burner valve & knob,
n. Right Rear burner valve & knob.

12. Easy to clean upswept cooktop.

13. Automatic door interior light switch.

14. Oven door latch mechanism.

15. Two interior oven lights with protective covers.

16. Self-Cleaning oven interior.

17. Adjustable heavy duty porcelain oven racks.

18. Oven convection fan & cover.

19. Full width oven door with large window.

20. Large 1-piece oven door handle.

21. Warm & Ready™ Drawer.

22. Large 1-piece warmer drawer handle.

23. Leveling legs and Anti-tip bracket (included).

24. 12,000 BTU burner (some models)

25. 14,200 BTU Power Burner (some models).

26. 9,500 BTU burner

27. 10,000 BTU Center Burner (some models).

28. 5,000 BTU Simmer Burner.

29. 18,000 BTU Turbo Boil burner (some models).

30. 650 to 18,000 BTU Double Ring burner (on

some models).

31. Warmer drawer rack.

2 3

5 6

8 9

= s

ight.

, rb. I I I I

О О о . 0 о

•©

о

о

о

о

Please note: The features shown for your

appliance may vary according to model type and
color.

H0-

Before Setting Oven Controls

Oven vent location

The oven vent is centered just below the control panel as
shown in Fig. 1. When the oven is on, warm air passes
through this vent. This venting is necessary for proper air
circulation in the oven and good baking results. Do not

block oven vent.

oven vent

Removing, replacing and arranging oven racks

A CAUTION

using the oven. When cooking, the oven interior and
exterior, oven racks and cooktop will become very hot
which can cause burns.

A WARNING

ALUMINUM FOIL to line the oven bottom. Only use

aluminum foil as recommended in this manual. Improper
installation of these liners may result in risk of electric
shock, or fire.

I Always use pot holders or oven mitts when

Protective Liners — DO NOT USE

Types of oven racks

flat
oven rack

flat handle
oven rack

offset
oven rack

Arranging - always arrange
the oven racks when the oven
is cool (prior to operating the
oven).

To remove - pull the rack
forward until it stops. Lift up
front of rack and slide out.

To replace - fit oven rack
onto the rack guides on both
sides of oven walls. Tilt the
front of oven rack upward
and slide the rack back into

place. Be sure oven racks are

level before using.

Recommended oven rack positions by food type

(Refer to Fig. 2)

Food type Position

Broiling See broil
Cookies, cakes, pies, biscuits & muffins 3 or 4

Frozen pies, angel food cake, yeast, bread

and casseroles 2 or 3
Small cuts of meat or poultry 1 or 2
Turkey, roast or ham 1 or 2

o
o
o

o

e

o

Fig. 2

The flat oven rack (some models) or flat handle oven rack
(some models) may be used for most cooking needs.

The offset oven rack (some models) is designed to place
the base of the rack about 1/2 of a rack position lower
than flat oven racks. This design provides several additional
possible positions between the flat rack positions.

Air circulation in the oven

For best baking results allow 2-4" (5-10 cm) around the
cookware for proper air circulation and be sure pans and
cookware do not touch each other, the oven door, sides or
back of the oven cavity. Hot air must be able to circulate
around the cookware in the oven for even heat to reach
around the food (See Fig. 3 ).

Before Setting Surface Controls

Using proper cookware

I

A CAUTION

plastic salt and pepper shakers, spoon holders or plastic
wrappings on the cooktop when it is in use. These items
could melt or ignite. Potholders, towels or wooden spoons
could catch fire if placed too close to the range cooktop.

Important: DO NOT place aluminum foil, or ANY material
that can melt on the range cooktop. If these items melt they

may damage the cooktop.

For best cooking results,
cookware should have
flat bottoms that rest

level on the surface

burner grate. Before
using cookware, check
for flatness by rotating
a ruler across the

bottom of the cookware
(Fig. 1).

DO NOT place flammable items such as

Setting proper burner flame size

A CAUTION

edge of the cooking utensil. A higher flame wastes energy,
and increases your risk of being burned by the flame.

The color of the flame is the key to proper burner adjustment.
A good flame is clear, blue and hardly visible in a well-lighted
room. Each cone of flame should be steady and sharp. Adjust
or clean burner if flame is yellow-orange.

Never extend the flame beyond the outer

Correct
flame setting

Incorrect

flame setting

Please note: The size and type of utensil used, and the

amount and type of food being cooked will influence the

burner flame setting needed for best cooking results.

Cookware material types

The most popular materials for cookware available are:

Aluminum - Excellent heat conductor. Some types of food
will cause it to darken (Anodized aluminum cookware

resists staining & pitting).

Copper - Excellent heat conductor but discolors easily.

Stainless - Slow heat conductor with uneven cooking

results. Is durable, easy to clean and resists staining.

Cast Iron - A slow heat conductor however will retain heat
very well. Cooks evenly once cooking temperature is

reached.

Porcelain-enamel on metal - Heating characteristics will
vary depending on base material.

For most cooking; start on the highest setting and then turn
to a lower setting to complete the process. Use the
recommendations below as a guide for determining proper
flame size for various types of cooking (Fig. 2)

For deep fat frying; use a thermometer and adjust the
surface knob accordingly. If the fat is too cool, the food
will absorb the fat and be greasy. If the fat is too hot, the
food will brown so quickly that the center will be under
cooked. Do not attempt to deep fat fry too much food at
once as the food will neither brown or cook properly.

Flame size* Type of cooking

High flame Start most foods; bring water to a boil;

pan broiling.

Medium flame Maintain a slow boil; thicken sauces,

gravies; steaming.

Low flame Keep foods cooking; poach; stewing.

Fig. 2

Glass - Slow heat conductor.

*These settings are based for medium-weight metal or
aluminum pans with lids. Settings may vary when using
cookware made from different materials.

Setting Surface Controls

Setting surface burners

Your gas appliance may be equipped with different sized
surface burners. The ability to heat food quicker and in

larger volumes increases as the burner size increases. It is
important to select cookware that is suitable for the
amount and type of food being prepared.

The smaller cooktop SIMAAER burner (right rear cooktop

position) is best suited for simmering delicate sauces, etc.
The standard size cooktop burners may be used for most

surface cooking needs. Some models are equipped with an
oblong shaped

BTU and will heat like any other standard sized burner.
The larger cooktop POWER burner (on some models) or

TURBO BOIL burner (on some models) are recommended
for bringing large quantities of liquid to temperature and
when preparing larger quantities of food.

CENTER burner. This burner is rated 10,000

To set surface burners:

1. Place cooking utensil on center of surface burner grate.

Be sure the cooking utensil sets stable on the burner

grate.

2. Push the desired surface control knob in and turn

counterclockwise out of the OFF position (Fig. 1).

3. Release the surface control knob and rotate to the LITE

position. Visually check that the burner has lit.

4. Once the burner has a flame, push the control knob in

and turn counterclockwise to the desired flame size.
Use the control knob markings and adjust the flame as
needed.

I

A CAUTION

plastic salt and pepper shakers, spoon holders or plastic
wrappings on the cooktop when it is in use. These items
could melt or ignite. Potholders, towels or wooden spoons
could catch fire if placed too close to the range cooktop.

A CAUTION

material that can melt on the range cooktop. If these items
melt they may permanently damage the cooktop surface.

Do not place flammable items such as

I

Do not place aluminum foil, or ANY

Important notes:

• DO NOT cook with the surface control knob left in the

LITE position. The electronic ignitor will continue to spark

if the control knob setting remains in the LITE position .

• When setting any surface control knob to the LITE
position, all electronic surface ignitors will spark at the
same time. However, only the surface burner you are
setting will ignite.

• NEVER place or straddle a cooking utensil over two
different surface cooking areas at the same time. This
can cause uneven heating results.

• In the event of an electrical power outage, the surface
burners can be lit manually. Use caution when lighting
surface burners manually. To light a surface burner, hold
a lit match to the burner head, then slowly turn the
surface control knob to LITE. After burner lights push in
and turn knob to desired setting.

Fig. 1

10

Setting Surface Controls

Setting Double Ring Burner (some models]

The versatile Double Ring surface burner offers a complete

range of gas surface settings from the same burner
position.

At the lowest setting, only the burner’s inner ring is active,

providing a smaller flame that is perfect for simmering. If
needed, the burner’s outer ring may be added and when

set for HI will provide a gas flame that may be used to

bring a large pan of liquid to boil quickly.

I

A CAUTION

plastic salt and pepper shakers, spoon holders or plastic
wrappings on the cooktop when it is in use. These items
could melt or ignite. Potholders, towels or wooden spoons
could catch fire if placed too close to the range cooktop.

A CAUTION

material that can melt on the range cooktop. If these items

melt they may permanently damage the cooktop surface.

Do not place flammable items such as

I

Do not place aluminum foil, or ANY

Operating the Double Ring Burner:

1. Push right front surface burner control knob in and turn
counterclockwise out of the OFF position -Fig. 1.

2. Release the knob and rotate to the Lite position.

3. Visually check that both inner and outer rings for the

Double Ring burner are lit (See Fig. 3).

Once lit, push in the control knob and to turn
counterclockwise out of the Lite position and adjust to
the desired flame size.

4. When adjusting for a low or simmer type flame setting,
continue to rotate the control knob counterclockwise
from

AAED setting towards LO (See Fig 2). Between the

MED and LO setting the flame for the outer ring portion

of the burner will turn off leaving only the inner burner
with a flame for simmering (See Fig. 4). Make any
further flame adjustments as needed.

Important notes:

• DO NOT cook with the surface control knob left in the

LITE position. The electronic ignitor will continue to spark

if the control knob setting remains in the LITE position .

• When setting any surface control knob to the LITE
position, all electronic surface ignitors will spark at the
same time. However, only the surface burner you are
setting will ignite.

• NEVER place or straddle a cooking utensil over two
different surface cooking areas at the same time. This
can cause uneven heating results.

• In the event of an electrical power outage, the surface
burners can be lit manually. Use caution when lighting
surface burners manually. To light a surface burner, hold
a lit match to the burner head, then slowly turn the
surface control knob to LITE. After burner lights push in
and turn knob to desired setting.

Home canning

Be sure to read and observe all the following points when
home canning with your appliance. Check with the USDA
(United States Department of Agriculture) website and be
sure to read all the information they have available as well
as follow their recommendations for home canning
procedures.

Fig. 1

OFF HI MED

Fig. 2

Fig. 3 Fig. 4

LO

• Use only quality flat bottom canners when home canning.
Use a straight-edge to check canner bottom.

• Use only a completely flat bottom canner.

• Make sure the diameter of the canner does not exceed 1
inch beyond the surface element markings or burner.

• Start with hot tap water to bring water to boil more
quickly.

• Use the highest heat setting when first bringing the water
to a boil. Once boiling is achieved, reduce heat to lowest
possible setting to maintain that boil.

• NEVER place or straddle a cooking utensil over two
different surface cooking areas at the same time. This
will cause uneven heating results.

n

Oven Control Functions

For satisfactory use of your oven, become familiar with the various keypad functions and features of the oven.

Timer I Add 1

Set/Off I Minute

@ (6)

Delay I Slow

Start I Cook

(3;

Pre

Heat

0

Meat
Probe

0

Cakes

Breads

Flex

Clean

0

Cook

Time

Warm

& Hold

Conv

Convert

d2;

Conv
Bake

Oven control keypads

1. Timer Set/Off - Use to set or cancel Timer.

2. Delay Start - Use with Bake, Conv Bake , Conv Convert
and Flex Clean functions to program a delay start time
or delay start self-cleaning cycle.

3. Preheat - Use to pre-condition the oven temperature.

4. Meat Probe - Use to set meat probe.

5. Add 1 Minute - Use to add additonal minutes to Timer.

6. Slow Cook - Use to set Slow Cook function.

7. Cakes Breads - Use to select Cakes or Breads function.

8. Flex Clean - Use to set a 2 to 4 hour self-clean cycle.

9. Cook Time - Use to enter length of cook time desired.

10. Warm & Hold - Use to select Warm & Hold function.

11. Conv Convert - Use to select Conv Convert function.

1

4

(17;

Broil

ll8 0—

©

12. Conv Bake - Use to select Conv Bake function.

13. Bake - Use to start normal Bake function.

14. Oven Light - Use to turn the oven lights ON or OFF.

15. START - Use to start oven functions.

16. STOP - Use to cancel any oven function previously
entered except Clock and Timer.

17. Broil - Use to select Broil function.

18. Clock - Use to set the time of day.

19. Conv Roast - Use to select Conv Roast function.

20. Accent Light - Use to turn Accent Light ON or OFF.

21. Oven Lockout - Use to lockout oven functions and door.

0-9 keypads - Use to enter temperatures and times.

19

Conv
Roast

7

¡20)

Accent

Light

2

5

8

0

3

6

9

É

OVEN

LOCKOUT

(21)

Minimum & maximum control settings

All of the features listed have minimum
and maximum time and temperature
settings that may be entered into the
control. An ENTRY acceptance beep will
sound each time a keypad is touched (the
Oven Lockout keypad is delayed by 3
seconds).

An ENTRY ERROR tone (3 short beeps) will
sound if the entry of the temperature or
time is below the minimum or above the

maximum settings for the feature.

Feature

PreHeat
Bake
Broil
Timer
Flex Clean
Conv Bake
Conv Convert
Conv Roast
Slow Cook
Cook Time
Delay Time 12 Hr.
Delay Time 24 Hr.
Clock 12 Hr.
Clock 24 Hr.

12

Min. temp, or time

170°F / 77°C
170°F / 77°C
400°F / 205°C
1 minute
2 hours
300°F / 149°C
300°F / 149°C
300°F / 149°C

Lo (225°F / 108°C)
1 minute
1:00
0:00
1:00
0:00

Max. temp, or time

550°F / 288°C
550°F / 288°C
550°F / 288°C
11 hrs. 59 minutes
4 hours
550°F / 288°C
550°F / 288°C
550°F / 288°C

Hi (275°F / 134°C)
11:59
12:59
23:59
12:59
23:59

Setting Oven Controls

Setting Clock

When the appliance is first powered up, 12:00 will flash in
the display (See Fig. 1). The time of day must first be set

before operating the oven.

Ijnn

ICUU

Fig. 1

Example — To set the clock to 1:30:

1. Press keypad.

2. Enter 13 0 using numeric keypads.

3. Press START .

Important note:

The clock cannot be changed during any active oven
cooking or cleaning function.

Setting Tinner

The minute timer allows you to track your cooking times
without interfering with the cooking process. The timer may

be set from 1 minute up to 11 hours and 59 minutes.

Add 1 Minute

Use the Add 1 Minute keypad to set additional minutes to
the timer. Each press of the keypad will add 1 additional
minute. If Add 1 Minute keypad is pressed when the timer is
not active, the timer will activate and begin counting down
from 1 minute.

Example — To add 2 minutes to the timer:
Press Add 1 Minute keypad twice.

Setting 12 or 24 hour display mode

The clock display mode allows you to choose between 12
or 24 hr modes. The factory preset clock display mode is
12 hours.

Example — To set 12 or 24 hour display mode:

1. Press and hold keypad for 6 seconds.

2. Press Flex Clean keypad to toggle between 12 Hr
day or 24 Hr day display modes (See Figs. 2 & 3).

3. Press to accept choice.

Example — To set the timer for 5 minutes:

1. Press Timer Set/Off keypad.

2. Enter 5 using numeric keypad.

3. Press keypad to start timer.

To cancel the timer when active press Timer Set/Off

keypad again.

Important notes:

• The timer does not start or stop the cooking process. It
serves as an extra minute timer in the kitchen that will
beep when the set time has run out. The timer may be
used alone or while using any of the other oven functions.

• The timer will display hours and minutes until 1 hour
remains. When less than 1 hour remains, the display will
count down in minutes and seconds. Once the timer has
less than 1 minute remaining only seconds will display.

• When the timer is active during a cooking process, the
minute timer will show in the display. To view the
information of any other active oven function, press the
keypad once for the other function to view the status.

Fig. 2 Fig. 3

Changing between continuous bake setting or 12-Hour Energy Saving feature

The oven control has a factory preset built-in 12 Hour
Energy Saving feature that will turn off the oven if the oven
is left on for more than 12 hours. The control may be
programmed to override this feature to continuously bake.

Example — To change between continuous bake or 12­Hour Energy saving feature:

1. Press and hold Timer Set/Off keypad for 6 seconds.

2. Press Flex Clean to toggle between 12 Hour OFF
(Fig. 4) or Stay On (Fig. 5) feature.

3. Press to accept choice.

St fiy On

Fig. 4

Fig. 5

13

Setting Oven Controls

Changing oven temperature display mode

The oven control is preset to display °F (Fahrenheit) when
shipped from the factory. The control can be changed to
display either Fahrenheit or Celsius.

Example — To change the temperature to display °C
(Celsius) or °F (Fahrenheit):

1. Press and hold Broil keypad for 6 seconds.

2. Press Flex Clean keypad to toggle between Fahrenheit
or Celsius temperature display modes (Figs. 1 & 2).

3. Press to accept choice.

Important note:

The oven temperature display cannot be modified during
any active oven cooking or cleaning function.

Fig. 1 Fig. 2

Setting silent or audible control mode

Silent mode allows the oven control to operate without
audible tones. The control may be programmed for silent
operation and later returned to operating with all the

normal audible tones.

Example — To set for silent or audible mode:

1. Press and hold Delay Start keypad for 6 seconds.

2. Press Flex Clean keypad to toggle between beep on

or beep off. (See Figs. 3 & 4).

3. Press to accept choice.

Oven Lockout ^

The control may be programmed to lock the
oven door and lock the oven control keypads.

To activate the Oven Lockout feature:

1. Be sure oven door is completely closed.

2. Press and hold the OVEN LOCKOUT keypad for 3
seconds, door Loc (See Fig. 5) will appear in the display.
The motor driven door latch mechanism will begin
locking the oven door automatically. Do not open the
oven door. Allow about 15 seconds for the oven door to
completely lock. Once the oven door is locked, the Loc
will appear in the display (See Fig. 6).

Fig. 5

To cancel the Oven Lockout feature:

1.

Press and hold the OVEN LOCKOUT keypad for 3
seconds. The motor driven door latch mechanism will
begin unlocking the oven door automatically. Do not
open the oven door. Allow about 15 seconds for the
oven door to completely unlock.

2. When the Loc message (Fig. 6) is no longer displayed,
the oven door may be opened and the oven control
keypads will be available for use.

Important notes:

• To avoid possible damage to the oven door latching

mechanism, do not attempt to open or close the oven
door whenever the door Loc message is displayed.

Fig. 6

OVEN

LOCKOUT

b£ EP On

Fig. 3 Fig. 4

• If a control keypad is pressed when OVEN LOCKOUT is

active, the control may triple beep indicating the keypad
action is not available when the OVEN LOCKOUT
feature is active.

14

Setting Oven Controls

Setting Preheat

For best baking performance use the Preheat feature. The

Preheat feature will bring the oven up to the set cooking
temperature. A reminder tone will sound indicating when
the set temperature is reached and to place the food in the

When the oven is finished preheating the preheat feature
will perform like the Bake feature and continue to maintain
the oven set temperature until cancelled.

Preheat may be set for any oven temperature between
170°F (77°C) to 550°F (288°C).

Example — To set Preheat with default oven temperature
of 350° F:

1. Press Preheat keypad.

2. Press START (See Fig. 1).

To cancel preheating at anytime press stop .

PIPE

Setting Bake

Use the bake function whenever the recipe calls for baking
using normal temperatures. A reminder tone will sound
indicating when preheating is finished and to place the
food in the oven.

Bake may be set for any oven temperature between 170°F
(77°C) to 550°F (288°C).

A CAUTION

using the oven. When cooking, the oven interior, oven

racks and cooktop will become very hot which can cause
burns.

Example — To set Bake with default oven temperature of
350°F:

1. Press Bake keypad.

2. Press START .

To cancel baking at anytime press stop .

Example — To set Bake for oven temperature of 425°F:

1. Press Bake keypad.

2. Enter 4 2 5 using numeric keypads.

I Always use pot holders or oven mitts when

Fig. 1

Example — To set oven for Preheat to 450°F:

1. Press Preheat keypad.

2. Press 4 5 0 using numeric keypads.

3. Press START .

To cancel preheating at anytime press stop .

Important notes:

• Preheating is not necessary when roasting or cooking

casseroles.

3. Press START .

To cancel baking at anytime press stop .

Important notes:

• Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended for
cakes, cookies and muffins.

• The oven will bake no longer than 12 hours. If you wish to
continuously bake, see Changing between continuous
bake setting or 12-Hour Energy Saving feature for
detailed information.

15

Setting Oven Controls

Setting Cook Time

Use Cook Time to program the oven control to

automatically turn the oven function off after a desired

length of time.

FOOD POISONING HAZARD. Do not let

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods

that can easily spoil such as milk, eggs, fish, meat or

poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed

promptly when finished cooking.

Example — To program oven to Bake with oven default
temperature of 350°F and to shut-off after 30 mintues:

1. Press Cook Time keypad.

2. Enter 3 0 using numeric keypads.

3. Press START to accept.

4. Press Bake keypad.

5. Press START .

Setting Delay Start

Delay Start sets a delayed starting time to oven cooking or
cleaning functions. Prior to setting a delay start, be sure the
time of day is set correctly.

A WARNING

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods
that can easily spoil such as milk, eggs, fish, meat or
poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed
promptly when finished cooking.

Example — To program oven for a delayed start
beginning at 5:30 and to shut-off automatically after 50
minutes and for baking at 375 F:

1. Press Cook Time keypad.

2. Enter 5 0 using numeric keypads.

3. Press start to accept

4. Press Delay Start keypad.

5. Enter 5 3 0 using numeric keypads.

FOOD POISONING HAZARD. Do not let

Fig. 1

When the programmed cook time runs out:

1. END will appear in the display window and the oven
will shut-off automatically (See Fig. 1)

2. The oven control will provide a beep 3 times every 30

seconds as a reminder until stop keypad is pressed.

Important notes:

• The Cook Time feature may be set with Bake, Conv Bake,

Conv Roast, Slow Cook and Preheat. Cook Time or Delay
Start will not operate with the Broil function.

• The maximum default Cook Time setting is 11 hours and

59 minutes.

• After the Cook Time feature has been activated, press
the Cook Time keypad to display any cook time
remaining.

• Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended for
cakes, cookies and muffins.

6. Press start to accept.

7. Press Bake keypad.

8. Enter 3 7 5 using numeric keypads.

9. Press START .

When the programmed cook time runs out:

1. END will appear in the display window and the oven
will shut-off automatically (See Fig. 1).

2. The oven control will provide 3 short beeps every 30
seconds as a reminder until stop keypad is pressed.

Important notes:

• Delay Start may be set using a 24 hour clock. See

Setting 12 or 24 hour display modes for more
information.

• The Delay Start feature may be used with Bake, Conv

Bake, Conv Roast, Conv Convert, Slow Cook and Flex
Clean functions. Delay Start or Cook Time will not
operate with the Broil function.

16

Setting Oven Controls

Conv Bake

Benefits of the convection bake feature

— Foods may cook up to 25 to 30% faster, saving time and

energy.
— Multiple rack baking.
— No special pans or bakeware needed.

Convection functions use a fan to circulate the oven's heat
uniformly and continuously around the oven. This improved

heat distribution allows for fast, even cooking and browning
results.

Heated air flows around the food from all sides, sealing in

juices and flavors.
Most foods will cook faster and more evenly with the

convection feature.

Fig. 1

Conv Bake may be set for any oven temperature between
300°F (149°C) to 550°F (288°C).

Suggestions for Convection baking:

• Reduce oven temperature 25°F from recipe’s

recommended oven temperature. Follow the remainder
of the recipe’s instructions using the minimum
recommended cook time.

• For best results when using a single oven rack, place rack

in position 3 or 4 (See Fig. 1). When using 2 oven racks,
place in positions 1 and 4. When using 3 oven racks
place in positions 1, 3, and 6 (use offset oven rack only in
position 6).

Example — To set Conv Bake with a default oven set

temperature of 350° F:

1. Press Conv Bake keypad.

2. Press START .

To cancel Conv Bake at anytime press stop .

Important notes:

• The convection fan will begin rotating 6 minutes after
Conv Bake, Conv Roast or Conv Convert has been
activated.

• If the oven door is opened when any convection function
is active and the convection fan is rotating, the
convection fan will
closed.

• When using Conv Bake cook time reductions may vary
depending on the amount and type of food being
cooked.

• Layer cakes will have better results using the Cakes
Breads function.

• Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time

to prevent overbrowning of some foods. Dark pans are

recommended for pies. Shiny pans are recommended for
cakes, cookies and muffins.

stop rotating until the oven door is

17

Setting Oven Controls

Conv Roast

The Conv Roast function combines a cook cycle with the
convection fan to roast meats and poultry. Meats cooked
with Conv Roast function will be juicer and poultry will be
crisp on the outside while staying tender and moist on the
inside.

Conv Roast may be set for any oven temperature between
300°F (149°C) to 550°F (288°C).

Suggestions for Conv Roast:

• Preheating is not necessary when roasting foods using
Conv Roast.

• Since Conv Roast cooks food faster, reduce the cook time
by 25% from the recommended cook time of your recipe
(check the food at this time). If necessary, increase cook
time until the desired doneness is obtained.

• Do not cover foods when dry roasting - this will prevent
the meat from browning properly.

Example — To set Conv Roast with a default oven set

temperature of 350° F:

1. Press Conv Roast keypad.

2. Press START .

To cancel Conv Roast at anytime press stop .

Important notes:

• The convection fan will begin rotating 6 minutes after
Conv Bake, Conv Roast or Conv Convert has been
activated.

• If the oven door is opened when any convection function
is active and the convection fan is rotating, the
convection fan will
closed.

stop rotating until the oven door is

Conv Convert

The Conv Convert function makes it easy to convert any
baking recipe and include the convection feature. The oven
control uses the normal recipe settings and adjusts to a
lower temperature for convection baking.

When Conv Convert is used with a Cook Time setting, the
Conv Convert function will display a CF (See Fig. 1) as a
reminder to “check food” when the bake time is 75%
complete. At this time the oven control will sound 1 long
beep at regular intervals until the set cook time has
finished.

Fig. 1

Example — To add Conv Convert to Conv Bake function
using default oven set temperature:

1. Press Conv Bake keypad.

2. Press Conv Convert keypad.
To cancel Conv Convert at anytime press stop .

Example — To program oven for Conv Convert with oven
default temperature of 350°F and to shut-off after 30
mintues:

1. Press Conv Bake keypad.

2. Press start to accept.

3. Press Cook Time keypad.

4. Enter 3 0 using numeric keypads.

5. Press start to accept.

6. Press Conv Convert keypad.

Important notes:

• Conv Convert may only be used with the Conv Bake
function.

• When using Conv Convert function Cook Time reductions
may vary depending on the oven set temperature.

• The minimum amount of Cook Time that may be entered
using the Conv Convert function is 20 minutes.

• The convection fan will begin rotating 6 minutes after
Conv Bake, Conv Roast or Conv Convert has been
activated.

• If the oven door is opened when any convection function
is active and the convection fan is rotating, the
convection fan will stop rotating until the oven door is
closed.

18

Setting Oven Controls

Broil

Use the broil function to cook meats that require direct

exposure to radiant heat for optimum browning results. The

Broil feature is factory preset to broil at 550°F. The Broil

function temperature may be set at any temperature

between 400°F (205°C) and 550°F (288°C).

Be aware that the suggested broil settings table (Fig. 2) are

recommendations only. Increase or decrease broiling times,
or move to a different oven rack position to suit for
doneness. If the food you are broiling is not listed in the
table, follow the instructions provided in your cookbook
and watch the item closely.

s

o

Fig. 1

Example - To set Broil with the default broil oven
temperature of 550° F:

1. Arrange the oven racks when cool. For optimum

browning results, you may preheat oven for 5 minutes
before adding food.

2. Position cookware in oven. Close the oven door.

3. Press Broil key pad.

4. Press START .

5. Broil on one side until food is browned; turn and broil on

other side.

6. When finished broiling press stop .

To cancel Broil at anytime press stop .

Suggested broil settings table (gas oven)

A WARNING

door and turn the oven OFF. If the fire continues, use a fire
extinguisher. DO NOT put water or flour on the fire. Flour
may be explosive.

A CAUTION

using the oven. When cooking, the oven interior, exterior,
oven racks and cooktop will become very hot which can
cause burns

Important notes:

• Always arrange oven racks when the oven is cool.

• For best results when broiling, use a quality broil pan
along with a broil pan insert. A broil pan is designed to
drain the fat from the food, help avoid spatter and
reduce smoking.

• When broiling, always pull the oven rack out to the stop
position before turning or removing food.

• Cook Time or Delay Start will not operate with the Broil
function.

I Should an oven fire occur, close the oven

I Always use pot holders or oven mitts when

Food Rack position Setting Cook time in minutes

(See Fig. 1) 1st side 2nd side Doneness

Steak 1” thick 5th or 6th* 550° 8 6 Medium
Steak 1” thick 5th or 6th* 550° 10 8 Medium-well
Steak 1” thick 5th or 6th* 550° 11 10 Well

Pork chops 3/4” thick 5th 550° 12 8 Well
Chicken-bone in 4th 450° 25 15 Well
Chicken-boneless 5th 450° 10 8 Well

Fish 5th 550° - as directed
Shrimp 4th 550° - as directed

Hamburger 1” thick 5th or 6th* 550° 12 10 Medium

Hamburger 1” thick 5th 550° 14 12 Well

Cook times provided are approximate and should be used only as a guide.
'"Use the off-set rack only in oven rack position 6.

Fig. 2

19

-

-

Well
Well

Setting Oven Controls

Cakes Breads

The Cakes Breads functions are designed to give optimum

baking performance for Cakes or Breads. These functions

work well for baking cakes, brownies, pies (fresh or frozen),

baked custards, cheesecakes, breads, rolls, biscuits, muffins

and cornbread.
The Cakes function provides a preheat with a gentle

cycling of heat giving cakes more volume and allowing
delicate foods to cook more evenly.

The Breads function adds a special preheat feature to the

bake cycle that thoroughly heats the oven from top to
bottom to give more evenly browned foods.

Example - To set the Cakes or Breads features:

1. Arrange interior oven racks when cool. If needed
Preheat oven as desired and place food in oven.

2. For Cakes, press the Cakes Breads keypad until CAKES
appears in the oven control display (See Fig. 1).

For Breads, press the Cakes Breads keypad until

BREADS appears in the oven control display (See Fig. 2).

Meat probe (some models)

When cooking meat such as roasts, hams or poultry, use
the meat probe function to check the internal temperature
without any guesswork. For some foods, especially poultry
and roasts, testing the internal temperature is the best
method to insure properly cooked meats.

Important notes:

• Use ONLY the meat probe supplied with appliance. Using
any other probe or device may result in damage to
appliance and the meat probe receptacle.

• Never leave or store meat probe inside oven.

• Handle the meat probe carefully when inserting and
removing from food or probe receptacle. Do not use
tongs to pull on meat probe cable when inserting or
removing from food or receptacle.

• Defrost food completely before inserting meat probe to
avoid damaging probe.

• To avoid possibility of burns, after cooking carefully
unplug meat probe using a pot holder to protect hands.

3. Press START .

Press STOP to cancel Cakes or Breads function at any

time.

Fig. 1 Fig. 2

Important notes:

• Dark or dull pans absorb more heat than shiny bakeware
resulting in dark or overbrowning of foods. It may be
necessary to reduce the oven temperature or cook time
to prevent overbrowning of some foods. Dark pans are
recommended for pies. Shiny pans are recommended for
cakes, cookies and muffins.

• Breads will have better results baking on a single oven
rack.

• Layer cakes will have best results using the Cakes
function.

Proper meal probe placement:

• Always insert meat probe so that the probe tip rests in
the center of the thickest part of meat. Do not allow
meat probe to touch bone, fat, gristle or cookware.

• For bone-in ham or lamb, insert meat probe into the
center of lowest large muscle or joint. For dishes such as
meat loaf or casseroles, insert meat probe into center of
food. To find center of the food visually measure using
probe as a guide (See Fig. 3). When cooking fish, insert
meat probe just above the gill.

• For whole poultry or turkey, insert meat probe into the
thickest part of inner thigh, below the leg (See Fig. 4).

Baking layer cakes with 1 or 2 oven racks

For best results when baking cakes or cookies using 2 oven

racks, place cookware on rack in positions 2 and 4 (5 if
using the offset oven rack). For best results when baking
cakes or cookies using a single oven rack, place offset oven

rack in positions 2 or 3.

Fig. 4

20

Setting Oven Controls

Meat probe (cont’d)

Important note:

Changing how the oven reacts after reaching the target
temperature must be done before starting the cooking

process.

To set meat probe:

1. Prepare the food and properly insert the temperature

probe into the food. DO NOT preheat or start cooking

before properly inserting the meat probe. The probe
should be inserted into the food and receptacle while
the oven is still cool.

2. Place the prepared food on the desired oven rack
position and slide into the oven.

3. Plug the meat probe into the probe receptacle located

on the left front oven cavity side (See Fig. 1 for location
of probe receptacle).

4. The oven control detects if the meat probe is correctly
plugged in to receptacle and when recognized will

See the following Instructions for changing how the oven
reacts after reaching the internal target temperature.

illuminate the ^ icon in the oven control display.

5. To set the target temperature press Meal Probe keypad

once then enter the desired target internal temperature
using the numeric key pads (default setting is 170°F/

77°C)f. Press START to accept the meat probe target
temperature. Close the oven door.

6. Set the oven control for Bake, Conv Bake or Conv
Roast and the desired oven temperature. You may use

the meat probe with some other baking features, but the

meat probe cannot be set with Broil or Flex-Clean.

7. During the cooking process the actual meat probe

temperature will display by default. To view the target
temperature press the Meal Probe keypad once. After 6
seconds the display will show the actual meat probe
temperature. If the target temperature needs to be
changed during the cooking process, press the Meal

Probe keypad once and use the numeric keypads to

adjust the target temperature. Press the start key to
accept any change.

8. The oven control will provide 3 beeps when the internal

target temperature is reached. By default the oven will
automatically change to a Warm & Hold setting. The
Warm & Hold function will maintain the oven
temperature at 170° F (77°C). Instructions for changing

how the oven reacts after reaching the internal target

temperature may be found later in this section.

Press STOP to cancel cooking at any time.

To sel the oven to continue cooking after reaching the
probe target temperature:

1. Press Meal Probe keypad and hold for 6 seconds.

2. Press Flex Clean keypad and toggle until the “Continu”
message appears (Fig. 2) then press start to accept.

To set the oven to cancel cooking and automatically start
Warm & Hold after reaching the probe target
temperature:

1. Press Meal Probe keypad and hold for 6 seconds.

2. Press Flex Clean keypad and toggle until “CAnCEL”
message appears (Fig. 3) then press start to accept.

Co nt

Fig. 2

The U.S. Department of Agriculture states, “Rare fresh
beef is popular, but you should know that cooking it to
only 140°F/60°C means some food poisoning organisms
may survive.” (Source: Safe Food Book, Your Kitchen
Guide, USDA Rev. June 1985.)

The lowest temperature recommended by the USDA is
145°F/63°C for medium rare fresh beef.

LÑ n[ El

Fig. 3

21

Setting Oven Controls

Setting Slow Cook

The Slow Cook function may be used to cook foods more
slowly and at lower oven temperatures. Slow Cook provides
cooking results much the same way as a Slow Cooker or
Crock-Pot.

Slow Cook is ideal for roasting beef, pork & poultry. Slow
cooking meats may result in the exterior of meats

becoming dark but not burnt. This is normal.

À WARNING

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods
that can easily spoil such as milk, eggs, fish, meat or
poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed
promptly when finished cooking.

FOOD POISONING HAZARD. Do not let

For Slow Cook two settings are available, high (Hi) or low
(Lo). The high setting is best for cooking foods from a 4 to
5 hour time period. The low setting is best for cooking
foods from a 8 to 9 hour time period.

Some tips for best results when using Slow Cook:

• Completely thaw all frozen foods before cooking with

the Slow Cook.

• When using a single oven rack, place in oven rack

position 2 or 3.

• Position multiple racks to accommodate size of cooking

utensils when cooking multiple food items.

• Do not open the oven door often or leave the door open

when checking foods. If the oven heat escapes often, the
Slow Cook time may need to extended.

• Cover the foods to keep them moist or use a loose or

vented type cover to allow foods to turn crisp or brown.

• Roasts may be left uncovered so browning can occur.

Cook times will vary; depending on the weight, fat
content, bone & the shape of the roast.

Example — To set Slow Cook:

1. Position cookware in oven and close oven door.

2. Press Slow Cook keypad. Hi will appear in the display
indicating the default temperature setting is for high.

3. If a low setting is needed, press Slow Cook keypad
again to select the low setting.

4. Press to activate Slow Cook.

To cancel Slow Cook at anytime press stop .

Important notes:

• Slow Cook may be used with additional settings of Cook

Time and Delay Start.

• The maximum cook time for the Slow Cook is 11 hours

and 59 minutes unless the control has been changed to
the continuous Bake mode.

• Use the recipe’s recommended food temperature and a
food thermometer to determine when the food is done.

• Preheating the oven will not be necessary when using the
Slow Cook feature.

• Add any cream or cheese sauces during the last hour of
cooking.

22

Setting Oven Controls

Warm & Hold™

Warm & Hold will keep cooked foods warm for serving up
to 3 hours after cooking has finished. After 3 hours the
Warm & Hold will shut-off automatically. Warm & Hold
should only be used with foods that are already at serving
temperatures. Warm & Hold will maintain the oven
temperature at 170° F (77°C).

A WARNING

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods

that can easily spoil such as milk, eggs, fish, meat or

poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed

promptly when finished cooking.

Example — To set Warm & Hold:

1. If needed, arrange interior oven racks and place cooked

food in oven.

2. Press Warm & Hold keypad. HLd will appear in the

display. If no further keypads are touched within 25
seconds the request for Warm & Hold will clear.

3. Press START . Warm & Hold will automatically turn off

after 3 hours.

To turn Warm & Hold off at any time press stop .

Example — To add Warm & Hold to turn ON
automatically after baking 45 minutes with default oven
set temperature of 350°F:

1. Press Cook Time keypad.

2. Enter 4 5 using numeric keypads.

3. Press START to accept.

4. Press Bake keypad.

5. Press START to accept.

6. Press Warm & Hold keypad. HLd will appear in the

oven control display.

FOOD POISONING HAZARD. Do not let

Recipe Recall

The Recipe Recall feature may be used to record and
recall your favorite recipe settings. This feature allows you
to store one setting for each of the basic cooking keypads.
The keypads that a recipe may be stored with are Bake,

Conv Bake, Conv Roast, Cakes Breads, PreHeat and Slow
Cook. Th is feature will also store and recall any added

Cook Time or Warm & Hold settings.

Example - To store a typical cookie recipe for baking at
375°F for 9 minutes and to shut-off automatically:

1. Close oven door.

2. Press Bake keypad.

3. Press 3 7 5 numeric keypads.

4. Press START .

5. Press Cook Time keypad.

6. Enter the desired baking time. Press 9 numeric keypad.

7. Press and hold start keypad until acceptance tone
sounds (about 3 seconds). The recipe will now be stored

with the Bake keypad for future recall. If you wish to
store the recipe but not start the oven at this time press

after pressing the keypad.

Example - To recall the cookie recipe previously stored
with the Bake keypad:

1. Arrange interior oven racks when cool.

2. Press Bake. The previously stored recipe with the Bake
keypad will be recalled.

3. Press START .

Important notes:

• Once a recipe has been stored with a keypad the recipe

information will be recalled when pressing the
corresponding keypad in the future.

• If a recalled recipe includes Cook Time the oven will

automatically shut-off when the Cook Time is finished.

7. Press START to accept. When the cook time runs out, the
Warm & Hold will turn ON automatically. Warm &

Hold will automatically turn off after 3 hours.

Important notes:

• Warm & Hold will maintain the oven temperature at

170° F (77°C) for 3 hours.

• Warm & Hold may be set when finished cooking or may

be added to automatically turn on after cooking using
Cook Time. Delay Start may also be added.

•

• To erase all recipes stored see section for Restoring

factory default settings.

23

Setting Oven Controls

Operating oven lights

The interior oven lights will automatically turn ON when the
oven door is opened.

Press O to turn the interior oven light ON and OFF

whenever the oven door is closed.

The interior oven lights are located on the rear wall of the
oven interior and are covered with a glass shield. The glass
shield protects the bulb from high temperatures and should
always be in place whenever the oven is in use.

To replace the interior oven lights, see Replacing oven

lights in the Care & Cleaning section.

Accent light

Your appliance includes a decorative Accent light centered
horizontally behind the touch-sensitive control panel. The
Accent light provides a theatre style intensity feature that
slowly increases brightness at turn on and slowly fades
when turning off.

When the Accent light is off, the light is in automatic mode
by default. This means the Accent light will turn on
automatically when an oven, cooktop function or features
such as the Timer have been activated. The Accent light
will turn off automatically when these functions or features
are no longer active.

When the Accent light is OFF, it may be manually turned
ON by pressing the Accent Light keypad once. When the
Accent light has been manually turned on, it will remain on
until manually turned off by pressing the Accent Light
keypad again.

The brightness of the Accent light may also be adjusted.

Example - To adjust Accent light brightness:

1. Press and hold the Accent Light keypad until an
acceptance tone sounds (about 6 seconds).

2. The default brightness setting of TOO will appear in the
display (Fig. 1).

3. Using the numeric keypads, enter any digit from 0 to
100 to change the brightness level. Entering 0 (Fig. 2)
will effectively turn the Accent light OFF until the
brightness level is adjusted to a higher level.

4. Press START to save the desired brightness setting.

Fig. 1

Fig. 2

24

Setting Oven Controls

Adjusting oven temperature

Your appliance has been factory calibrated and tested to
ensure an accurate baking temperature. For the first few
uses, follow your recipe times and temperature

recommendations carefully. If you think the oven is cooking
too hot or too cool for your recipe times, you may adjust
the control so the oven cooks hotter or cooler than the oven
temperature displayed.

The oven temperature offset may be increased as much as

+35°F (+19°C) or decreased -35°F (-19°C) from the factory
calibrated settings.

Example — To increase (+) or decrease (-) the oven
temperature by 20° F:

1. Press and hold Bake keypad until the control provides

the 2nd audible tone (about 6 seconds).

2. Enter 2 0 using numeric keypad.

3. Press Flex Clean keypad to toggle between plus (+) if

increasing temperature or minus (-) if decreasing the
temperature. These symbols will show in the display.

4. Press START to accept change.

Important notes:

• Oven temperature adjustments made will not change the

Broil or Flex Clean function temperatures.

• If the temperature shows an adjustment of -20°F, and a

+20°F adjustment is needed, you can toggle between the
minus (-) or plus (+) in the display when pressing

Clean keypad (See step 3).

Flex

Restoring factory default settings

When new, your appliance was set with predetermined
oven control settings. Over time, the user may make
changes to these default settings. The following features or
functions have user options or adjustments that may have
been changed from the factory default settings:

• 12 or 24 hour display mode

• Continuous bake or 12-Hour Energy Savings mode

• Silent or audible control

• Oven temperature display (Fahrenheit or Celsius)

• Oven temperature adjustments

• All stored recipes

• Meat Probe settings

• Accent Light brightness setting

Please be aware before restoring to factory default
settings that ALL of the above user settings will be restored,
including any oven temperature offset and any stored
recipe information.

Example — To restore to factory default settings:

1. Press and hold the 7 numeric keypad until acceptance
tone sounds (about 6 seconds).

2. Press START . The control will reset all user preference
settings back to factory default settings.

• DO NOT USE oven thermometers such as those found in
grocery stores to check the temperature settings inside
your oven. These oven thermometers may vary as much
as 20 to 40°F from actual temperatures.

• The oven temperature adjustment may be made if your

oven control has been set to display °C (Celsius)
temperatures. Minimum and maximum settings for
Celsius are plus (+) or minus (-) 19°C.

25

Setting Oven Controls

Sabbath feature (for use on the Jewish

Sabbath & Holidays)

For further assistance, guidelines for proper
usage and a complete list of models with

the Sabbath feature, please visit the web at

http:\\www.star-k.org.

The Cook Time and Delay Start keypads are used to set
the Sabbath feature. The Sabbath feature may only be
used after the Bake function is active.

Once the oven is properly set using the Bake function and
the Sabbath mode is active, the oven will remain
continuously ON until the Sabbath feature is cancelled. The
Sabbath feature will override the factory preset 12-Hour

Energy Saving feature and start the continuous bake mode.

A WARNING

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods

that can easily spoil such as milk, eggs, fish, meat or

poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed

promptly when finished cooking.

FOOD POISONING HAZARD. Do not let

Important notes:

• It is not advised to attempt to activate any other oven
function except Bake while the Sabbath feature is active.
ONLY the following keypads will function correctly when
the Sabbath feature is active: 0-9 number keypads.

Bake, START and stop . ALL OTHER KEYPADS should not

be used once the Sabbath feature is activate.

• You may change the oven temperature once baking has
started. Press Bake keypad, use the numeric keypads to
enter the oven temperature change (170 to 550F°) and

press START (for Jewish Holidays only). Remember that the
oven control will no longer provide audible tones or

display any further changes once the Sabbath feature is
active.

• It is recommended that any oven temperature change
with the Sabbath feature active be followed with two

presses of the start keypad. This will insure the oven
remains ON even if the attempt to set the oven

temperature was lower or higher than the oven control
can accept. If the oven temperature is set incorrectly, the
oven temperature will default to 170°F or 550°F. Try to
set the desired oven temperature again.

Example — To program the oven to Bake at default oven

temperature of 350°F and activate the Sabbath feature:

1. Be sure the clock is set with the correct time of day.

2. Arrange oven racks, place cookware in oven and close
oven door.

3. Press Bake keypad.

4. Press START .

5. If Cook Time or Delay Start are not needed, skip this

step and continue to step 6. If a Cook Time or Delay

Start are desired enter the times at this point. Refer to

the Cook Time and Delay Start sections for detailed

instructions.

6. Press and hold both Cook Time and Delay Start
keypads simultaneously for about 3 seconds to set the
Sabbath feature. Once the feature is set SAb (See Fig. 1)

will appear in the display indicating the oven is properly

set for the Sabbath feature.

5Rb

• If the oven light is needed during the Sabbath, press the
O keypad to turn oven light on before activating the

Sabbath feature. Once the oven light is turned on and
the Sabbath feature is active, the oven light will remain
on until the Sabbath feature is turned OFF. If the oven
light needs to be off, be sure to turn the oven light off

activating the Sabbath feature.

before

• Remember the oven will shut-off automatically after

completing a Cook Time, Delay Start or Warm & Hold
and therefore may only be used once during the
Sabbath/Jewish Holidays.

• If a Delay Start time longer than a maximum of 11 hours

and 59 minutes in advance is desired, set the oven
control for the 24 hour day display mode setting. For
detailed instructions see

modes.

• The Accent light will not operate while the Sabbath

feature is active.

Setting 12 or 24 hour display

Fig. 1

26

Setting Oven Controls

Sabbath feature (for use on the Jewish

Sabbath & Holidays)

Example - to turn the oven off and keep the Sabbath

feature active:

Press STOP .

Example — To turn off the Sabbath feature:

Press and hold both Cook Time and Delay Start key pads
simultaneously for at least 3 seconds to turn the Sabbath
feature off. The control will provide an acceptance tone

SAb will disappear from the display. The oven is no

and

longer programmed for the Sabbath feature.

What to do during a power failure or power interruption
after the Sabbath feature was activated:

Should you experience a power failure or interruption, the
oven will shut-off. When power is restored the oven will not
turn back on automatically. The oven will remember that it
is set for the Sabbath and the oven display will show the

message SF for Sabbath failure (Fig. 1).

Fig. 1

The food may be safely removed from the oven while still
in the Sabbath feature, however the oven cannot be turned

back on until after the Sabbath/Holidays. After the
Sabbath observance turn OFF the Sabbath feature. Press
and hold both

least 3 seconds simultaneously to turn the Sabbath feature
off. SF will disappear from the display and the oven may

be used with all normal functions.

Cook Time and Delay Start keypads for at

27

Warmer Drawer

Warm & Ready™ drawer (some models)

The purpose of the warmer drawer is to keep hot cooked
foods at serving temperatures. Examples are vegetables,
gravies, meats, casseroles, biscuits, rolls and pastries. It is

not recommended to heat cold food in the warmer drawer;
always start with hot food.

The warmer drawer may also be used to warm dinner

plates. All food items placed in the warmer drawer should

be covered with a lid or aluminum foil to maintain quality.

A WARNING

food sit for more than one hour before or after cooking.

Doing so can result in food poisoning or sickness. Foods
that can easily spoil such as milk, eggs, fish, meat or

poultry, should be chilled in the refrigerator first. Even
when chilled, they should not stand in the oven for more
than 1 hour before cooking begins, and should be removed

promptly when finished cooking.

A WARNING

materials should not be stored in an oven, warmer
drawer, near surface units. This includes paper, plastic and

cloth items, such as cookbooks, plasticware and towels, as
well as flammable liquids. Do not store explosives, such as
aerosol cans, on or near the range.

FOOD POISONING HAZARD. Do not let

I

Storage in or on appliance—flammable

Arranging warmer drawer rack positions

The keep warmer drawer rack may be used in 2 ways:

• In the upright position (See Fig. 1) to allow low profile
food items to be placed both under and on top of the
rack (for example, rolls or biscuits on top of the rack and
a casserole dish underneath).

• In the downward position (See Fig. 2) to allow for light
weight food items and empty cookware (for example,
rolls or pastries and dinner plates) on the rack.

A WARNING

children should not be left alone or unattended in the
area where appliance is in use. They should never be

allowed to sit or stand on any part of the appliance,
including the warmer drawer.

A CAUTION

removing food from the warmer drawer as cookware and
plates will be hot and you can be burned.

Important note:

The warmer drawer is equipped with a catch that may

require extra force to open and close the drawer.

DO NOT LEAVE CHILDREN ALONE —

I

Always use potholders or oven mitts when

28

Warmer Drawer

Warmer drawer controls

The warmer drawer controls are located on the control

panel. Use the warmer drawer control keypads to turn the
warmer drawer ON and OFF and make temperature
adjustments. Five available heat settings are provided
from low to high (See Fig. 2).

Warmer drawer indicator light

The warmer drawer indicator light is located beside the
warmer drawer

warmer drawer is turned ON, and remains on until the
warmer drawer is turned OFF.

A CAUTION

removing food from the warmer drawer as cookware and

plates will be hot and you can be burned.

To set warmer drawer:

1. Arrange the warmer drawer rack (if needed) in warmer

drawer and place the cooked food or dishes in the
warmer drawer. Close warmer drawer.

2. To activate press and hold the warmer drawer

keypad until acceptance tone sounds.

3. To set heat level press Hi or Lo keypad and if needed

toggle using these keypads to adjust to the desired
power level setting. Release keypad when the desired
heat level is displayed by the indicator lights. Fig. 2
shows examples for low, medium and high settings.

4. Once warming is finished, press ^ to turn warmer

drawer OFF and carefully remove items.

Hi

Lo

Lo

ON

keypad (See Fig. 1). It glows when the

, OFF ;

Warmer drawer

indicator light

Warmer

Drawer

Fig. 1

I

Always use potholders or oven mitts when

ON
OFF ;

Hi

Lo

f

.......

Hi

Lo

Hi

Lo

Hi

Lo

V -J

Warmer drawer settings

The recommended warmer drawer food settings are shown
in Fig. 3. The settings provided are meant to be used as a
recommendation only. If a particular food item is not listed,
start with a medium setting. If more crispness is desired,
remove the lid or aluminum foil from the food.

Most foods may be maintained at serving temperatures
using a medium heat setting. When a combination of foods
are to be kept warm (for example, a meat with 2
vegetables and rolls) use a high setting.

Warmer drawer recommended food settings

Food Item

Bacon
Hamburger patties
Poultry
Pork chops
Fried foods
Pizza
Gravies
Casseroles
Eggs
Roasts (beef, pork or lamb)
Vegetables
Biscuits
Rolls (hard)
Pastries
Rolls (soft)
Empty dinner plates

* •

Setting

Hi
Hi
Hi
Hi
Hi
Hi
medium
medium
medium
medium
medium
medium
medium
medium
Lo
Lo

Fig. 3

Important notes:

• Do not use plastic wrap to cover food. Plastic may melt

on warmer the drawer and be very difficult to clean up.
Only use utensils and cookware recommended by the
manufacturer for use in the warmer drawer.

• Always start with hot food when using the warmer
drawer. DO NOT heat cold food in the warmer drawer.

• To minimize heat loss, avoid opening warmer drawer
frequently while in use.

• Flex Clean can not be set when the warmer drawer is
active.

Warmer

Drawer

Warmer

Drawer

Fig. 2

Warmer

Drawer

• If Proof Bread indicator light turns on when setting the
heat level press Hi keypad once to toggle back to the
warmer drawer settings.

29

Warmer Drawer

Proof Bread

The warmer drawer has a Proof Bread feature that may be
used to prepare bread dough. The recommended length of
time to keep the bread dough in the warmer drawer is
about 45-60 minutes. Be sure however to follow the recipe’s

recommended times.

Since the bread dough will nearly double in volume be sure
to place the prepared dough in a large bowl. Arrange the
warmer drawer rack in the downward position (See Fig. 1)
and place the bowl with dough on the warmer drawer

rack.

To set Proof Bread using warmer drawer:

1. Arrange the warmer drawer rack in warmer drawer

(See Fig. 1) and place bread dough in a large bowl on
warmer drawer rack. Close warmer drawer.

2. Press

3. Press Lo keypad once set warmer drawer to Lo power

setting.

4. Press Lo keypad again to activate Proof Bread feature.

The Proof Bread indicator light will glow when the Proof
Bread feature is active (See Fig. 2).

ON

keypad to turn ON warmer drawer.

OFF

Fig. 1

5. When the bread dough is ready, press the

to turn the warmer drawer off and remove bread dough
from warmer drawer.

Hi

• PROOF
BREAD

W keypad

Lo

Hi

Lo

ON

.OFF,

Warmer

Drawer

30

Fig. 2

Warmer Drawer

Removing and replacing the warmer drawer

I

A WARNING

result in serious injury or death. Disconnect appliance
from electric power before cleaning and servicing the
warmer drawer.

To remove the warmer drawer:

1. Turn power OFF to the appliance before removing the
warmer drawer.

2. Open the warmer drawer completely.

3. On left warmer drawer rail, locate black release lever
and press up with finger while pulling out slightly on the
oven drawer handle. On right warmer drawer rail,

locate black release lever and press down with finger
while pulling out slightly on the warmer drawer handle
(See Fig. 1).

4. The warmer drawer should now be released from the
rails. Remove warmer oven drawer (using level & square
motion) completely out and away from the appliance.

Electrical shock hazard can occur and

Left-hand rail and release

X

Warmer
drawer
handle

To replace the warmer drawer:

1. Pull the bearing glides to the front of the outer

compartment glide channels until they snap into place
(See Fig. 3).

2. Carefully line up both sides of the warmer drawer glide
rails to the outer compartment glide channels located

inside the empty warmer drawer compartment (See Fig.

2).

3. While holding the warmer drawer level and square

using the warmer drawer handle, push (do not force) the
warmer drawer all the way into the outer compartment
glide channels all the way into the range. Open the
warmer drawer again to verify the glides have seated.

4. If you do not hear the levers “click” or the bearing

glides do not feel seated remove the warmer drawer
and repeat steps 1 through 3 again. This will minimize

possible damage to the bearing glides.

Right-hand rail and release

Fig. 1

31

Flex Clean

A self-cleaning oven cleans itself with high temperatures
that are well above normal cooking temperatures. The high
cleaning temperature eliminates soils completely or reduces
them to a fine powdered ash you can wipe away
afterwards with a damp cloth.

The Flex Clean function allows you to set any amount of
cleaning time from 2 hours to 4 hours. A 3-hour cleaning
time is best used for normal cleaning; 2-hour time for light
soils and a 4-hour clean time for heavier stubborn soils.

Read before starting Flex Clean

Be sure to read all the following caution and important

statements BEFORE starting a self-clean cycle:

A CAUTION

near the appliance. During the self-cleaning cycle, the
outside of the range can become very hot to touch and can
cause burns.

or any other part of the range with aluminum foil. Doing
so will destroy heat distribution, produce poor baking

results and cause permanent damage to the oven interior.

Aluminum foil will melt to the interior of the oven.

DO NOT leave small children unattended

DO NOT line the oven walls, racks, bottom

• Remove any excessive spillovers. Any spills on the oven
bottom should be wiped-up and removed before starting
a self-clean cycle. To clean, use hot, soapy water and a
cloth. Large spillovers can cause heavy smoke or fire

when subjected to high temperatures. DO NOT allow

food spills with a high sugar or acid content (such as
milk, tomatoes, sauerkraut, fruit juices or pie filling) to
remain on the surface as they may leave a dull spot even
after cleaning.

• DO NOT clean the oven door gasket (See Fig. 1). The

woven material of the oven door gasket is essential for a

good seal. Care should be taken not to rub, damage or
remove the gasket. DO NOT use any cleaning materials
on the oven door gasket. Doing so could cause damage

to the door gasket.

I

 CAUTION

sensitive to the fumes given off during the self-cleaning
cycle of any range. Move birds to another well-ventilated

room.

A CAUTION

damage the automatic door locking system.

after self-cleaning. The oven may still be VERY HOT and
can cause burns. To avoid possible burns stand to the side
of the oven when opening the oven door to allow hot air or
steam to escape.

Important notes:

• Completely remove all items and accessories from oven
cavity to avoid damage. Porcelain coated heavy duty

oven racks may be left in oven.

• Remove ALL items from the cooktop including cookware,
utensils and ANY ALUMINUM FOIL. Aluminum foil will
not withstand high temperatures from a self-clean cycle
and can melt.

• DO NOT use oven cleaners or oven protective coatings in
or around any part of the oven interior.

• Clean any soil from the oven frame, the door liner outside
the oven door gasket and the small area at the front
center of the oven bottom (See Fig. 1). These areas heat
sufficiently to burn soil on. Clean using soap and water
prior to starting Flex Clean (See Fig. 1).

The health of some birds is extremely

DO NOT force the oven door open. This can

Use caution when opening the oven door

Fig. 1

Setting Flex Clean

Example — To set Flex Clean to start immediately:

1. Be sure to remove ALL items from oven except porcelain
coated heavy duty oven racks. Remove all items from
the cooktop. Be sure oven door is completely closed.

2. Press Flex Clean keypad for a default 3-hour clean
time. After pressing Flex Clean you may accept the
default 3-hour clean time by going to step 3.

At this time you may choose a different clean time. The
amount of clean time must be within 2 to 4 hours and
entered using the numeric keys pads. For example enter

2 0 0 for a 2-hour time or enter 4 0 0 for a 4-hour self

clean time. You may choose a 2 hour 15 minute clean
time by entering 2 15 (hours and minutes).

3. Press to activate Flex Clean.

32

Flex Clean

As soon as Flex Clean becomes active, a motor driven

lock mechanism will begin locking the oven door

automatically, door Loc will appear in the display (See

Fig. 1). DO NOT open the oven door when door Loc is

displayed (allow 15 seconds for the lock mechanism to

lock the oven door).

Once the oven door has locked, CLn will appear in the
display indicating Flex Clean has started (Fig. 2).

or «-OC

DOOR LOCKED CLEAN I

Fig. 1 Fig. 2

DOOR LOCKED CLEAN I

do or uPn

Fig. 3

When Flex Clean is finished:

1. CLn message will turn off and Hot will appear in display
window (See Fig. 3).

2. Once the oven has cooled down (about 1 hour) and Hot
is no longer displayed the door OPn message will
appear (Fig. 4). When this message turns off the oven

door may be opened.

A CAUTION

after self-cleaning. The oven may still be VERY HOT
and can cause burns. To avoid possible burns stand to

the side of the oven when opening the oven door to
allow hot air or steam to escape.

3. When the oven interior has completely cooled, wipe
away any residue or powdered ash with a damp cloth
or paper towel.

Important notes:

• The kitchen area should be well ventilated using an open

window, ventilation fan or exhaust hood during the 1st
self-clean cycle. This will help eliminate the normal odors
associated with the 1st self-clean cycle.

Use caution when opening the oven door

Fig. 4

llh

Delayed Start Flex Clean

Example — To start a delay Flex Clean with default clean
time of 3 hours and a start time of 9:00 o'clock:

1. Be sure the clock is set with the correct time of day, the
oven is empty and ALL oven racks are removed. Be sure
oven door is completely closed.

2. Press Delay Start keypad.

3. Using numeric keypad enter 9 0 0 for time to start.

4. Press START to accept.

5. Press Flex Clean keypad.

6. Press START .

If it becomes necessary to stop Flex Clean when active:

1. Press STOP .

2. If Flex Clean has heated the oven to a high
temperature, allow enough time for the oven to cool
and for the door OPn message to appear (Fig. 4).
When this message turns OFF the oven door may be
opened.

3. Restart Flex Clean if needed.

Important notes:

• When Flex Clean function is active you may check the

amount of clean time remaining by pressing the Flex
Clean keypad once.

• If your control is set with the default 12 hour display

mode, the Delay Flex Clean can only be set to start up to
11 hours and 59 minutes in advance. To set a Delay Start
Flex Clean to begin 12 or more hours (maximum is 23
hours and 59 minutes) in advance, be sure to set the
control for 24 hour display mode.

• If Flex Clean is active and then interrupted by power

failure or cancelled before the oven was thoroughly
cleaned, it may be necessary to run a self-clean cycle
again. If the oven temperature was high enough when
interrupted you may need to allow up to 4 hours for the
oven to cool before Flex Clean can be started again.

• When the clean time finishes the oven door will remain
locked until the range has cooled sufficiently. In addition
to the clean time that was programmed, you must allow
about 1 additional hour for the oven to cool before you
will be able to open the oven door.

• The Flex Clean function will not operate whenever a
radiant surface element is ON or the oven lockout is
active.

33

Care & Cleaning

Cleaning recommendation table

Surface type Recommendation

Painted body parts

Painted decorative trim
Aluminum, plastic or vinyl trim
Control knobs (some models)

Control panel
Control keypad membrane

Decorative trim (some models)

Porcelain enamel parts & door

liner

For general cleaning, use hot, soapy water and a cloth. For more difficult soils and
built-up grease, apply a liquid detergent directly onto the soil. Leave on soil for 30
60 minutes. Rinse with a damp cloth and dry. Do not use abrasive cleaners on any
of these materials; they can scratch. To remove control knobs, turn to OFF position;
grasp firmly and pull straight off the shaft. To replace knobs after cleaning, line up
the flat sides of both knob and shaft; then push knob into place.

Before cleaning the control panel, turn all controls OFF, activate oven lockout (on
some models) and if needed remove any knobs from panel. Do not use abrasive
cleaners on any of these materials; they can scratch. Clean using hot, soapy water
and a dishcloth. Be sure to squeeze excess water from dishcloth before wiping
control panel; especially when wiping around the controls area. Excess water in or
around the controls may cause damage to the appliance. When rinsing, use clean
water and a dishcloth and be sure to squeeze excess water from dishcloth before
wiping the control panel.

Gentle scrubbing with a soapy no-scratch cleaning pad will remove most spots.
Rinse with a 1:1 solution of clear water and ammonia. If necessary, cover difficult
spots with an ammonia-soaked paper towel for 30 to 40 minutes. Rinse with clean
water and a damp cloth, and then scrub with a soap-filled no-scratch cleaning pad.
Rinse and wipe dry with a clean cloth. Do not allow food spills with high sugar or
acid content (milk, tomatoes, sauerkraut, fruit juices or pie filling) to remain on the
surface; they may cause a dull spot even after cleaning.

Oven interior

Porcelain coated oven racks Porcelain coated heavy duty oven racks may be left in oven during Flex Clean. After

Oven door

Cooktop surface, surface burners
and burner grates

Stainless Steel (some models) Only use cleaners and polishes that are specifically manufactured for cleaning

For oven interior remove excessive spillovers from oven cavity bottom before
starting Flex Clean. Clean any soils from oven frame and door liner outside the oven
door gasket. For very important cleaning precautions be sure to read all the
instructions in the Flex Clean section.

a self-cleaning cycle, let the oven completely cool. If needed use a damp cloth to
wipe any ash from oven racks.

Use soap & water to thoroughly clean the top, sides and front of the oven door.
Rinse well. You may use a glass cleaner on the outside glass of the oven door. Do
not immerse the door in water. Do not spray or allow water or the glass cleaner to
enter the door vents. Do not use oven cleaners, cleaning powders or any harsh
abrasive cleaning materials on the outside of the oven door.

Do not use spray oven cleaners on the cooktop. See Cleaning the cooktop and
burner grates instructions provided in the Care & Cleaning section.

stainless steel. Always wipe in direction of metal grain to avoid damaging. Do not
use cleaners with high concentrations of chlorides or chlorine. Do not use harsh
scrubbing cleaners. Polish with a lint-free cloth. Always be sure to wipe excess
cleaner/polish off from the metal surface as bluish stains may occur during future
oven heating that cannot be removed. Clean heavier soils with hot, soapy water and
a dishcloth. Rinse and dry using clean water and a cloth.

34

Care & Cleaning

Cleaning the cooktop and surface burners

I

A CAUTION

any of the cooktop cleaning instructions provided before
turning OFF all of the surface burners and allow them to
completely cool.

A CAUTION

required in order for this appliance to satisfactorily meet
the application needs must be made by an authorized
qualified agency.

Routinely clean the cooktop. Wipe with a clean, damp
cloth and wipe dry to avoid scratches.

Keeping the surface burner head ports and slots clean will

prevent improper ignition and an uneven flame. See the
following sections for more instructions.

Cleaning recessed and contoured areas of cooktop

If a spill occurs on or in the recessed or contoured areas,

blot up spill with an absorbent cloth. Rinse with a clean,
damp cloth and wipe dry.

Cleaning surface burner grates

• Clean only after the grates are completely cool.

• Use nonabrasive plastic scrubbing pad and mild abrasive

cleanser or clean in the dishwasher.

• Food soils containing acids may affect the finish. Clean

immediately after the grates are cool.

• Thoroughly dry grates immediately following cleaning.

Cleaning burner caps

• Remove caps from burner heads after they have cooled.

• Clean heavy soils with a plastic scrubbing pad and

absorbent cloth.

• Thoroughly dry burner caps immediately following

cleaning including the bottom and inside of cap.

• Do not use abrasive cleaners. They can scratch porcelain.

• Do not clean burner caps in the dishwasher.

• Do not operate surface burners without burner caps

properly in place. Read important notes.

To avoid possible burns DO NOT attempt

I

Any additions, changes or conversions

slots

ignition port

orifice port

I

Fig. 1 - cooktop burner head

Cleaning surface burner heads

For proper gas flow it may be necessary to clean the
burner head and slots. To clean, first use a clean DAMP
cloth to soak up any spills. Remove any food from between
the burner slots using a small nonabrasive brush like a
toothbrush and afterwards wipe up using a damp cloth. For
stubborn soils located in the slots, use a small-gauge wire
or needle to clean.

Any spill on or around the electrode must be carefully
cleaned. Take care not to hit the electrode with any thing
hard or it could be damaged.

To clean the burner head ignition ports

Each burner head has a small ignition port located as
shown. Should you experience ignition problems it may be
that this port hole is partially blocked with soil. With the
burner head in place, use a small wire gauge needle or the
end of a paper clip to clear the ignition port (See to Fig. 1;
round style shown - oval or Dual Ring burner on some
models not shown).

Important notes:

• The surface burner heads are secured to the cooktop and
must be cleaned in place on the cooktop.

• Always keep the surface burner caps in place whenever
a surface burner is in use.

• When replacing the burner caps, be sure the burner caps
are seated firmly on top of the burner heads.

• For proper flow of gas and ignition of burners DO NOT
allow spills, food, cleaning agents or any other material
to enter the gas orifice port opening.

35

Care & Cleaning

General cleaning

Refer to the Cleaning recommendation table in the Care &
Cleaning section for more detailed information about
cleaning specific parts of the range.

A CAUTION

range, be sure all controls are turned OFF and the range is
COOL. The range may be hot and can cause burns.

A CAUTION

oven. Provide adequate ventilation.

Before manually cleaning any part of the

I Ammonia must be rinsed before operating the

Aluminum foil and utensils

I

A WARNING

the oven bottom or cover an entire oven rack with materials
such as aluminum foil. Doing so blocks air flow through the
oven and may cause CARBON MONOXIDE poisoning.
Aluminum foil linings may trap heat, causing a fire hazard.

• Al uminum foil - Use of aluminum foil on a hot cooktop

can damage the cooktop. Do not use thin aluminum
cooking utensils or allow aluminum foil to touch the
surface burners under ANY circumstances.

NEVER cover any slots, holes or passages in

Replacing oven lights

A CAUTION

are COOL before replacing oven light. Wear a leather
faced glove for protection against possible broken glass.

The oven lights are located at the rear of the oven cavity
and are covered with a glass shield held by a wire holder.
The glass shield protects the light bulb and must be in
place whenever the oven is in use.

Be sure the range is unplugged and all parts

• Aluminum utensils - The melting point of aluminum is

much lower than that of other metals. Care must be
taken when aluminum pots or pans are used on the
cooktop. If aluminum pans are allowed to boil dry when
using the cooktop, the utensil may be damaged or
destroyed.

To replace the interior oven light bulb:

1. Turn electrical power off at the main source or unplug
the range.

2. Press wire holder to one side to release the glass shield
that covers the light bulb.

3. Replace light with a new 40 watt appliance bulb.

4. Replace glass shield over bulb and snap wire holder
back into place.

5. Turn power on at the main source (or plug the appliance
in).

6. The clock will then need to be reset. To reset, see
Setting clock in this Use & Care Guide.

36

Care & Cleaning

Removing and replacing the lift-off oven door

A CAUTION

replacing the oven door, follow the instructions below carefully

and always hold the oven door with both hands positioned away

from the door hinge area.

A CAUTION

lay the door flat with the inside of the door facing down.

To remove oven door:

1. Open oven door completely (horizontal with floor - Fig.1).

2. Pull the door hinge locks on both left and right door hinges
down from the oven frame completely towards the oven door
(Fig. 2). A tool such as a small flat-blade screwdriver may be

required.

3. Firmly grasp both sides of oven door along the door sides (Do

not use the oven door handle - Fig. 3).

4. Close the door to the broil stop position (the oven door will stop
into this position just before fully closing).

5. With the oven door in the broil stop position, lift the oven door

hinge arms over the roller pins located on each side of the oven

frame (Fig. 4).

To replace oven door:

1. Firmly grasp both sides of oven door along the door sides (Do

not use the oven door handle - Fig. 3).

2. Holding the oven door at the same angle as the removal

position, seat the hook of the hinge arm over the roller pins
located on each side of the oven door frame (Fig. 4). The hook

of the hinge arms must be fully seated onto the roller pins.

3. Fully open the oven door (horizontal with floor - Fig. 1).

4. Push the door hinge locks up towards and into the oven frame
on both left and right oven door hinges (Fig. 2) to the locked

position; then close the oven door.

I To avoid possible injury when removing or

I

The door is heavy. For safe, temporary storage,

voc-

Fig. 2

Special door care instructions

Most oven doors contain glass that can break. Read the following
recommendations:

• Do not close the oven door until all the oven racks are fully in

place inside the oven cavity.

• Do not hit the glass with pots, pans, or any other object.

• Scratching, hitting, jarring or stressing the glass may weaken its

structure causing an increased risk of breakage at a later time.

37

Before You Call • Solutions to common problems

Before you call for service, review the following list. It may save you time & expense. Possible solutions to these problems

are provided with the problem listed:

Problem Solution

Poor baking results. Many factors affect baking results. Make sure the proper oven rack position

is used. Center food in the oven and space pans to allow air to circulate.
Allow the oven to preheat to the set temperature before placing food in the
oven. Try adjusting the recipe's recommended temperature or baking time.

If you feel the oven is too hot or cool, see Adjusting oven temperature in

Setting Oven Controls section.

Appliance is not level.

Cannot move appliance easily.
Appliance must be accessible for
service.

Oven portion of appliance does not
operate.

• Be sure floor is level, strong & stable enough to adequately support range.

• If floor is sagging or sloping, contact a carpenter to correct the situation.

• Poor installation. Place oven rack in center of oven. Place a level on the
oven rack. Adjust leveling legs at base of appliance until the rack is level.

• Kitchen cabinet alignment may make range appear not level. Be sure
cabinets are square & have sufficient room for appliance clearance.

• Cabinets not square or are built in too tightly. Contact builder or installer to

make appliance accessible.

• Carpet interferes with appliance. Provide sufficient space so appliance can

be lifted over carpet.

• Gas line is hard-plumbed. Have a flexible CSA International approved

metal appliance connector installed.

• Be sure regulator gas valve is turned to ON. See installation instructions.

• The time of day is not set. The time of day must first be set in order to
operate the oven. See Setting clock in Setting Oven Controls section.

• Be sure the oven controls are set properly for the desired function. See
Setting Oven Controls section and review instructions for the desired cooking
function in this manual or see "Entire appliance does not operate” in this
checklist.

Entire appliance does not operate.

Oven control beeps and displays F
code error.

• Make sure power cord is plugged properly into outlet.

• Electrical power outage. Check house lights to be sure. Call your local

electric company for service outage information.

• Service wiring is not complete. Call 1-800-4-MY-HOME® for assistance (See

back cover).

Oven control has detected a fault or error condition. Press stop key pad to
clear the error code. Try Bake or Broil function. If the F code error repeats,

remove power from appliance, wait 5 minutes and then repower appliance
and set clock with the correct time of day. Try Bake or Broil function again.

If the fault recurs, press stop to clear and call 1-800-4-MY-HOME® for
assistance (See back cover).

38

Before You Call • Solutions to common problems

Problem

Oven smokes excessively when broiling.

Flames inside oven or smoking from oven

vent.

Convection fan does not rotate.

Solution

• Incorrect setting. Follow broiling instructions in Setting Oven Controls
section.

• Be sure oven door is closed when broiling.

• Meat too close to upper burner. Reposition the oven rack to provide proper
clearance between the meat & the upper burner. Preheat oven when
searing.

• Meat not properly prepared. Remove excess fat from meat. Cut remaining
fatty edges to prevent curling, but do not cut into lean.

• Grease has built up on oven surfaces. Regular cleaning is necessary when
broiling frequently. Old grease or food spatters cause excessive smoking.

Excessive spillovers in oven. For example this will happen for pie
spillovers or large amounts of grease left on the oven bottom. Wipe up
excessive spillovers before starting oven. If flames or excessive smoke are
present see Broil in Setting Oven Controls section.

• Allow 6 minutes for convection fan to start rotating after setting Convection.

• Oven door is open. Convection fan will turn off if oven door is opened when
Convection is active. Close oven door.

Flex Clean does not work.

Soil not completely removed after Flex
Clean.

Oven light does not work. Be sure the oven light is secure in the socket. Also see Replacing oven light

• Oven control not set properly. Review instructions in Flex Clean section.

• Flex Clean was interrupted. Review instructions in Flex Clean section.

• Excessive spillovers on oven bottom. Remove before starting Flex Clean.

• Failure to clean soil from the oven frame, the door liner outside the oven

door gasket and the small area at the front center of the oven bottom.
These areas are not in the self-cleaning area, but get hot enough to burn
on residue. Clean these areas before the self-cleaning cycle is started.
Burned-on residue can be cleaned with a stiff nylon brush and water or a
nylon scrubber. Be careful not to damage the oven gasket.

in the Care & Cleaning section.

39

Before You Call • Solutions to common problems

Problem

Surface burners do not ignite.

Surface burner flame uneven or only

part way around burner cap.

Solution

• Surface control knob was not completely turned to LITE. Push in & turn the
surface control knob to LITE until burner ignites and then turn control knob to
desired flame size.

• Burner ports are clogged. With the burner OFF, use a small-gauge wire or
needle to burner head slots and ignition ports. See Cleaning the cooktop

and surface burners in the Care & Cleaning section for additional cleaning

instructions.

• Range power cord is disconnected from outlet (electric ignition models only).
Be sure power cord is securely plugged into the power outlet.

• Electrical power outage. Burners may be lit manually. See section on Setting
Surface Controls.

• Burner slots or ports are clogged. With the surface burner OFF, clean ports

with a small-gauge wire or needle.

• Moisture is present after cleaning. Lightly fan the flame and allow burner to
operate until flame is full.

• Burner caps are not seated properly. Check that all burner caps are level
and seated correctly on burner heads. See Cleaning the cooktop and

surface burners in the Care & Cleaning section.

Surface burner flame is too high.

Surface burner flame is orange.

• Surface control knob is set too high. Adjust to lower flame setting.

• Burner caps are not seated properly. Check that all surface burner caps are
level and seated correctly on surface burner heads. See Cleaning the

cooktop and surface burners in the Care & Cleaning section.

• Incorrect L.P. conversion. Refer to L.P. conversion kit instructions to correct.

Dust particles in main gas line. Allow the burner to operate a few minutes

until flame turns blue. In coastal areas, a slightly orange flame is
unavoidable due to salt content in air.

40

Protection Agreements

Acuerodes de protección

Master Protection Agreements

Congratulations on making a smart purchase. Your new Kenmore®
product is designed and manufactured for years of dependable operation.

But like all products, it may require preventive maintenance or repair from
time to time. That’s when having a Master Protection Agreement can
save you money and aggravation.

The Master Protection Agreement also helps extend the life of your new

product. Here’s what the Agreement* includes:

0 Parts and labor needed to help keep products operating properly

under normal use, not Just defects. Our coverage goes well
beyond the product warranty. No deductibles, no functional failure

excluded from coverage - real protection.

0 Expert service by a force of more than 10,000 authorized Sears

service technicians, which means someone you can trust will be
working on your product.

0 Unlimited service calls and nationwide service, as often as you

want us, whenever you want us.

0 “No-lemon” guarantee - replacement of your covered product if

four or more product failures occur within twelve months.
0 Product replacement if your covered product can’t be fixed.
0 Annual Preventive Maintenance Check at your request - no extra

charge.
0 Fast help by phone - we call it Rapid Resolution - phone support

from a Sears representative on all products. Think of us as a “talking

owner’s manual”.
0 Power surge protection against electrical damage due to power

fluctuations.
0 $250 Food Loss Protection annually for any food spoilage that is

the result of mechanical failure of any covered refrigerator or

freezer.
0 Rental reimbursement if repair of your covered product takes

longer than promised.
0 10% discount off the regular price of any non-covered repair

service and related installed parts.

Once you purchase the Agreement, a simple phone call is all that it takes
for you to schedule service. You can call anytime day or night, or
schedule a service appointment online.

The Master Protection Agreement is a risk free purchase. If you cancel
for any reason during the product warranty period, we will provide a full

refund. Or, a prorated refund anytime after the product warranty period

expires. Purchase your Master Protection Agreement today!

Some limitations and exclusions apply. For prices and additional

information in the U.S.A. call 1-800-827-6655.

* Coverage in Canada varies on some items. For full details call
Sears Canada at 1-800-361-6665.

Sears Installation Service

For Sears professional installation of home appliances, garage door

openers, water heaters, and other major home items, in the U.S.A. or
Canada call 1-800-4-MY-HOME®.

Acuerdos maestros de protección

Enhorabuena por haber hecho una compra inteiigente. Su nuevo
producto Kenmore®está diseñado y fabricado para brindarle años de
funcionamiento fiable. Pero, como cualquier producto, puede necesitar
mantenimiento preventivo o reparaciones periódicas. Es por eso que
tener un Acuerdo maestro de protección podría ahorrarle dinero y
molestias.

El Acuerdo maestro de protección también sirve para prolongar la
durabilidad de su nuevo producto. El acuerdo* incluye lo siguiente:

0 Piezas y mano de obra necesarias para contribuir a mantener el

funcionamiento adecuado de los productos utilizados en

condiciones normales de uso, no sólo en caso de defectos de los
productos. Nuestra cobertura va mucho más allá que la garantía
del producto. No se aplican deducibles ni exclusiones por fallas del

funcionamiento: es decir, verdadera protección.

0 Servicio técnico por expertos (más de 10000 técnicos

autorizados de Sears), lo cual significa que quien repare o realice
el mantenimiento de su producto será un profesional de confianza.

0 Servicio técnico a escala nacional y número ilimitado de

llamadas de solicitud de servicio técnico: se puede poner en
contacto con nosotros cuantas veces lo desee y cuando lo desee.

0 Garantía “sin sorpresas”: se reemplaza el producto cubierto por el

acuerdo si ocurren cuatro o más fallas del producto en un periodo
de 12 meses.

0 Reemplazo del producto: en caso de que no se pueda reparar el

producto cubierto por el acuerdo.

0 Revisión anual preventiva de mantenimiento del producto:

puede solicitarla en cualquier momento, sin costo alguno.

0 Rápida asistencia telefónica, la cual denominamos Solución

rápida: es decir, asistencia telefónica a través de cualquiera de
nuestros representantes de Sears, sobre cualquiera de nuestros
productos. Piense en nosotros como en un “manual parlante del
usuario”.

0 Protección contra fallas eléctricas, contra daños debidos a

fluctuaciones de la corriente eléctrica.

0 $250 al año para cubrir cualquier posible deterioro de

alimentos que haya tenido que desechar debido a una falla
mecánica de cualquiera de nuestros refrigeradores o congeladores
cubiertos por este acuerdo.

0 Devolución de gastos de alquiler de electrodomésticos si la

reparación de su producto asegurado toma más que el tiempo
prometido.

0 10% de descuento aplicable tanto a los costos del servicio de

reparación, como de las piezas instaladas relacionadas que no
hayan quedado cubiertos por este acuerdo.

Una vez que haya realizado el pago de este acuerdo, bastará una simple
llamada telefónica para concertar una visita de servicio. Puede llamar a
cualquier hora del día o de la noche, o bien concertar una visita de
servicio por Internet.

La adquisición del Acuerdo maestro de protección es una inversión
exenta de riesgos. Si por cualquier motivo decide cancelar dicho acuerdo
durante el periodo de garantía del producto, le haremos un reintegro total
del valor. O bien un importe proporcional si cancela el acuerdo en
cualquier otro momento posterior al vencimiento del periodo de garantía
del producto. ¡Adquiera hoy mismo su Acuerdo maestro de protección!

Algunas limitaciones y exclusiones podrían aplicarse. Para solicitar
precios e información adicional, llame al 1-800-827-6655 (en los
EE.UU.).

* La cobertura en Canadá varía en el caso de algunos artículos. Para
obtener detalles completos al respecto, llame al 1-800-361-6665 de
Sears de Canadá.

Servicio de instalación de Sears

Para solicitar la instalación por profesionales de Sears de
electrodomésticos, abridores de puertas de garaje, calentadores de agua
y otros artículos de uso prioritario en el hogar, llame al 1-800-4-MY-
HOME en los EE.UU. o Canadá.

41

Get it fixed, at your home or ours!

Your Home

For troubleshooting, product manuals and expert advice:

managemylife

www.managemylife.com

For repair - in your home - of all major brand appliances,

lawn and garden equipment, or heating and cooling systems,

no matter who made it, no matter who sold it!

For the replacement parts, accessories and

owner’s manuals that you need to do-it-yourself.

For Sears professional installation of home appliances

and items like garage door openers and water heaters.

1-800-4-IVIY-HOME® (1-800-469-4663)

Call anytime, day or night (U.S.A. and Canada)

www.sears.com www.sears.ca

Our Home

For repair of carry-in items like vacuums, lawn equipment,

and electronics, call anytime for the location of your nearest

Sears Parts & Repair Service Center

1 -800-488-1222 (U.S.A.) 1 -800-469-4663 (Canada)

www.sears.com www.sears.ca

To purchase a protection agreement on a product serviced by Sears:

1-800-827-6655 (U.S.A.) 1-800-361-6665 (Canada)

Para pedir servicio de reparación

a domicilio, y para ordenar piezas

1-888-SU-HOGAR®

(1-888-784-6427)

www.sears.com

Au Canada pour service en français:

1-800-LE-FOYER'"''

(1-800-533-6937)

www.sears.ca

® Registered Trademark / ™ Trademark of KCD IP, LLC in the United States, or Sears Brands, LLC in other countries
® Marca Registrada / ™ Marca de Fábrica de KCD IP, LLC en Estados Unidos, o Sears Brands, LLC in otros países

Marque de commerce / ““ Marque déposée de Sears Brands, LLC
