OPERATING MANUAL

English

CONTENTS

1. Introduction ....................................................................................................... 3

1.1 General ....................................................................................................................................... 3

1.2 About FastMig X 350 and X 450 ........................................................................................ 3

2. Installation..........................................................................................................4

2.1 Before use .................................................................................................................................. 4

2.2 Distribution network ............................................................................................................. 4

2.3 Machine introduction ........................................................................................................... 5

2.4 Positioning of the machine ................................................................................................ 5

2.5 Connecting cables ................................................................................................................. 6

2.5.1 Liquid-cooled system: FastMig X 350 or X 450 + WFX + Cool X ................................... 6

2.5.2 Air-cooled system: FastMig X 350 or X 450 + WFX ........................................................ 7

2.5.3 Cable positions for multiple machine congurations ................................................... 8

2.5.4 Connecting to mains power ........................................................................................... 8

2.5.5 Cables ............................................................................................................................... 9

2.5.6 Interconnection with wire feeder ................................................................................... 9

3. Operation control .......................................................................................... 10

3.1 Main switch I/O .....................................................................................................................10

3.2 Pilot lamps ...............................................................................................................................10

3.3 Operation of cooling fan ...................................................................................................10

3.4 Manual Metal Arc Welding ................................................................................................ 10

3.5 Using external devices with CC and CV modes ........................................................10

4. Control panel X 37 ......................................................................................... 11

4.1 Layout and button functions ...........................................................................................11

4.2 Using the menus ...................................................................................................................13

4.2.1 Selecting the interface language .................................................................................13

4.2.2 About memory channels ..............................................................................................13

4.2.3 Creating the rst memory channel ..............................................................................13

4.2.4 Creating the rst MMA/CC/CV memory channel ........................................................14

4.2.5 Creating and modifying memory channels .................................................................14

4.3 Welding parameters ............................................................................................................14

4.4 Welding functions ................................................................................................................17

4.5 Arc voltage display ...............................................................................................................21

4.6 Welding software delivery prole ..................................................................................22

5. Troubleshooting.............................................................................................22

6. Operation disturbances ...............................................................................24

7. Maintenance ....................................................................................................25

7.1 Daily maintenance ...............................................................................................................25

7.2 Periodic maintenance .........................................................................................................25

7.3 Service Workshop maintenance .....................................................................................26

8. Disposal of the machine ..............................................................................26

9. Ordering codes ............................................................................................... 27

10. Technical data ................................................................................................. 29

FastMig X 350, X 450

1. INTRODUCTION

1.1 General

Congratulations on choosing the FastMig X welding equipment. Used correctly, Kemppi products can signicantly increase the productivity of your welding, and provide years of economical service.

This operating manual contains important information on the use, maintenance and safety of your Kemppi product. The technical specications of the equipment can be found at the end of the manual.

Please read the operating manual and the safety instructions booklet carefully before using the equipment for the rst time. For your own safety and that of your working environment, pay particular attention to the safety instructions in the manual.

For more information on Kemppi products, contact Kemppi Oy, consult an authorised Kemppi dealer, or visit the Kemppi web site at www.kemppi.com.

The specications presented in this manual are subject to change without prior notice.

Important notes

Items in the manual that require particular attention in order to minimise damage and personal harm are indicated with the ’NOTE!’ notation. Read these sections carefully and follow their instructions.

Disclaimer

While every eort has been made to ensure that the information contained in this guide is accurate and complete, no liability can be accepted for any errors or omissions. Kemppi reserves the right to change the specication of the product described at any time without prior notice. Do not copy, record, reproduce or transmit the contents of this guide without prior written permission from Kemppi.

1.2 About FastMig X 350 and X 450

FastMig X 350 and X 450 are multi-purpose welding power sources designed for demanding professional use. They are suitable for synergic pulsed MIG/MAG, synergic 1-MIG and basic MIG/MAG welding, as well as the modied WiseRoot+™ and WiseThin+™ processes. They can also be used as a welding power source for MMA welding. TIG welding is also available when connected to MasterTig LT 250.

Control panel X 37 is included in the delivery for selecting, setting and managing the welding system prior to and during system use.

FastMig X 350 and X 450 oer a multi-process solution for a wide range of welding applications. Various cable options, welding software options, remote control units including tablet computer based ARC Mobile Control (adapter included with WFX 200 AMC and 300 AMC wire feeders) and other accessories are available for this product. Please see the list at the end of this manual.

2. INSTALLATION

2.1 Before use

The product is packed in specially designed transport cartons. However, before use always make sure the products have not been damaged during transportation.

Check also that you have received the components you ordered and the corresponding instruction manuals. Product packaging material is recyclable.

NOTE! When moving the welding machine, always lift it from the handle, never pull it from the

welding gun or other cables.

Operating environment

This machine is suitable for both indoor and outdoor use. Always make sure that the air ow to the machine is unrestricted. The recommended operating temperature range is –20…+40°C.

Please ensure you read the safety instructions concerning operating environments supplied in this manual.

2.2 Distribution network

All regular electrical devices without special circuits generate harmonic currents into distribution network. High rates of harmonic current may cause losses and disturbance to some equipment.

FastMig X 350 and X 450

This equipment complies with IEC 61000-3-12 provided that the short-circuit power Ssc is greater than or equal to 5.5 MVA at the interface point between the user’s supply and the public suply network. It is the responsibility of the installer or user of the equipment to ensure, by consultation with the distribution network operator if necessary, that the equipment is connected only to a supply with a short-circuit power Ssc greater than or equal to 5.5 MVA.

FastMig X 350, X 450

2.3 Machine introduction

CHANNEL

10.

6,3A

11.

1. Control panel X 37

2. Main switch (ON/OFF)

3. Power on pilot lamp

4. Overheating pilot lamp

5. Welding cable connection, negative pole (–)

6. Welding cable connection, positive pole (+)

7. Control cable connection

8. Fuse (delayed 6.3 A)

9. Control cable connection

10. Mains power cable

11. Measurement cable connection

2.4 Positioning of the machine

Place the machine on a sturdy, level surface that is dry and does not allow dust or other impurities to enter the machines cooling air ow. Preferably site the machine to a suitable carriage unit so it is above oor level.

Notes for positioning the machine

• The surface inclination may not exceed 15 degrees.

• Ensure the free circulation of the cooling air. There must be at least 20 cm of free space in

front of and behind the machine for cooling air circulation.

• Protect the machine against heavy rain and direct sunshine.

NOTE! The machine is not allowed to be operated in the rain as the protection class of the machine,

IP23S, allows preserving and storing outside only.

NOTE! Never aim the spray of sparks from a grinding machine toward the equipment.

2.5 Connecting cables

NOTE! Always check before use that the mains cable, earth return cable and its clamp,

interconnection cable and shielding gas hose are in a serviceable condition. Ensure that connectors are correctly fastened. Lose connectors can impair welding performance and damage connectors.

2.5.1 Liquid-cooled system: FastMig X 350 or X 450 + WFX + Cool X

11.

10.

1. WFX wire feed unit

2. FastMig X 350 or X 450 power source

3. Cool X cooling unit and power connection

4. Gas supply

5. MMA electrode holder

6. Remote control device

7. Liquid-cooled welding gun

8. Power cable

9. Earth return cable and clamp

10. Measurement cable (from power source to wire feeder)

11. Voltage sensing cable (from wire feeder to work piece)

FastMig X 350, X 450

2.5.2 Air-cooled system: FastMig X 350 or X 450 + WFX

10.

1. WFX wire feed unit

2. FastMig X 350 or X 450 power source

3. Gas supply

4. MMA electrode holder

5. Remote control device

6. Air-cooled welding gun

7. Power cable

8. Earth return cable and clamp

9. Measurement cable (from power source to wire feeder)

10. Voltage sensing cable (from wire feeder to work piece)

2.5.3 Cable positions for multiple machine congurations

When using two or more FastMig X units working on the same work piece, the right positioning of voltage sensing cable and the earth return cable is important.

In order for the voltage sensing function to work properly, the earth return cable and the voltage sensing cable for each FastMig X power source should be connected close to each other and away from other units’ cables (see the pictures below).

2.5.4 Connecting to mains power

FastMig power sources are delivered as standard with 5 meters of mains power cable. No mains plug is tted at the Kemppi factory.

NOTE! If local country-based regulations state an alternative power cable is required, the mains

cable must be replaced in conformity with the regulations. Connection and installation of the mains cable and plug should only be carried out by a suitably qualied person.

Remove the machine cover plate to enable mounting of a mains cable. FastMig X 350 and X 450 power sources can be connected to the mains supply of 400 V 3~ .

If changing the mains cable take into consideration the following:

The cable is entered into the machine through the inlet ring on the rear panel of the machine and fastened with a cable clamp (05). The phase conductors of the cable are coupled to connectors L1, L2 and L3. The earth protection coloured green-yellow is coupled to the marked connector.

If you are using 5-lead cable, do not connect the neutral conductor.

L1 L2 L3

*) In S type cables there is a protective grounding conductor coloured green-yellow.

Generator use

If no mains connection is available, you can use FastMig X 350 and X 450 on a generator. The minimum recommended generator output is 35 kVA. The greater the output, the more stable is the FastMig X power source operation.

FastMig X 350, X 450

2.5.5 Cables

Kemppi always recommend the use of high quality copper cables with a suitable crosssectional area. Cable size should be selected depending on the intended welding application.

50 mm² copper cables may be used for low duty work in basic or synergic 1-MIG. However, using pulsed MIG/MAG process, longer cables, or higher welding power increase the voltage loss, and therefore smaller cross sectional interconnection cables and earth return cables will restrict the welding performance of your machine.

Recommended cross-sectional area of FastMig X power source cables: 70 – 90 mm².

The enclosed table shows typical load capacities and voltage loss values of rubber insulated copper cables for duty cycles 100%, 60% and 30%, when ambient temperature is 25 °C and the cable temperature is 85 °C.

Cable size 100 % 60 % 30 % Voltage loss / 10 m 50 mm² 70 mm² 95 mm²

Do not overload the cables due to voltage losses and heating.

NOTE! Always check the serviceability of the earth return cable and clamp. Ensure the metal

surface to which the cable is connected is clean from metal oxide or paint. Check the connector to the power source is fastened correctly.

285 A 370 A 520 A 0.35 V / 100 A 355 A 460 A 650 A 0.25 V / 100 A 430 A 560 A 790 A 0.18 V / 100 A

2.5.6 Interconnection with wire feeder

Kemppi provide a choice of interconnection cable sets for dierent environments. Only materials that meet the demands of Kemppi's international markets are used in their construction.

Used correctly, Kemppi cable sets ensure high welding performance and serviceability. Before use, always ensure the cable set is in good condition and that connectors are correctly

fastened. Loose connections reduce welding performance and may result in damage to connectors due to heating eects.

For correct connection and conguration of cable sets, please refer to schematic drawings in section 2.5 of this manual.

NOTE! FastMig X 350 and X 450 power sources are designed to be used with WFX wire feed units.

3. OPERATION CONTROL

3.1 Main switch I/O

When you turn the on/o switch into position I, the pilot warning lamp is illuminated and the machine is ready for use. Always turn the machine on and o with the power source mains switch. Never use the mains plugs as a switch.

3.2 Pilot lamps

The pilot lamps of the machine report its operational state: When the green pilot lamp is on, it indicates that the machine is switched on and ready for

use. When the orange pilot lamp is on, it indicates that the machine is overheated due to higher

than normal working loads that exceed the rated duty cycle. The cooling fan will continue to run and cool the machine down. When the lamp is o the machine is again ready to weld.

3.3 Operation of cooling fan

FastMig X power sources incorporate two simultaneously operating fans.

• The fan is started momentarily when the main switch is turned into position I.

• The fan will start during welding as the machine reaches operational temperature, and

it will run for 1 to 10 minutes after the welding has stopped, depending on the welding cycle completed.

3.4 Manual Metal Arc Welding

MMA electrode welding is a standard feature of the FastMig X power sources. To use it you need to connect the electrode holder to the power source positive pole (+) and select the MMA welding mode either from the power source or from the wire feeder:

• In power source control panel, select MMA/CC/CV Mode from the main menu list. – OR –

• in wire feeder control panel, select MMA/CC/CV option with a long press of the corresponding up-down-arrow.

NOTE! There must be an MMA memory channel dened before you can use these modes. To create

a memory channel, see the Control panel section of this manual.

3.5 Using external devices with CC and CV modes

FastMig X 350 and X 450 are CC (constant current) and CV (constant voltage) power sources. With this function you can use them as power sources for the voltage sensing wire feeder ArcFeed and TIG welding device MasterTig LT 250.

To use the CC/CV function you select MMA/CC/CV Mode option from the main menu of the power source control panel.

NOTE! There must be a CC or CV memory channel dened before you can use these modes. To

create a memory channel, see the Control panel section of this manual.

FastMig X 350, X 450

4. CONTROL PANEL X 37

FastMig X power sources feature X 37 control panel with a clear and logical LCD menu display. The menu allows the operator to rene, adapt and manage the arc process and system function before, during and after welding.

The following information details control panel layout, button functions, operation and setup. The menu options and their descriptions are listed for each menu command.

4.1 Layout and button functions

1. 4.

2. 7.

CHANNEL

INFO

F1 F2 F3

1. ON/OFF button

• Short press returns the panel to default initial view (channel information).

• Long press (>5 sec) turns X 37 panel and wire feeder panel XF 37 (or XF 38) ON or OFF.

• Keeping this button pressed while turning the machine ON restores to factory settings.

The panel asks for a conrmation before restoring to defaults.

• If X 37 panel is OFF and a wire feeder panel XF 37 (or XF 38) is turned ON, the X 37 panel will also be turned ON and linked automatically to this wire feeder panel.

NOTE! This button connects power to the control panel. Use the main switch on the front of the

power source to switch the power source on or o.

2. Welding channel selection buttons

FastMig X power sources oer 100 memory channels (10 for each user) for storing frequently used welding jobs.

• To browse memory channels, press + and – buttons.

• To store a new welding job to an empty channel, press the soft key under the display

text NEW.

USER

WF#

X 37

5.6.

W007238

3. MENU button

This button takes you to the main menu list. Proceed following the instructions on screen.

X 37 main menu list Edit Channel User Identification Weld Data System Config Menu Language Select Feeder (WF#) MMA/CC/CV Mode

4. Control knob

Turn the knob to change the value of the selected parameter. In MMA/CV/CC mode when panel is in default initial view (channel information), knob can be used to adjust current (MMA and CC) or voltage (CV).

Make changes to existing welding channel Selecti one user out of ten Check out the values of the last weld Show device conguration and information Select your menu language Select another parallel wire feeder as a setup target Activate MMA welding, or use CC or CV mode for ArcFeed or MasterTig LT

250

5. Menu browsing buttons

Use up and down arrows to move the selection up and down in the menu structure. In MMA/CV/CC mode when panel is in default initial view (channel information), Up/Down buttons can be used to adjust Arcforce (MMA) and Dynamics (CV/CC).

6. Menu shortcut buttons

• F1 (CHANNEL INFO) displays the basic data recorded to the displayed channel. Pressing F1 multiple times gives more information of the selected memory channel. Keeping F1 pressed while turning the machine ON restores the menu language to English.

• F2 (USER) Browses and selects users: 1…10, Administrator. When MMA/CC/CV is selected, only Administrator is allowed.

• F3 (WF#) Selects another wire feeder as a setup target. Panel allows selecting only those WF numbers that are found connected on the system. When MMA/CC/CV is selected, the display shows text ”MMA/CC/CV Mode”.

NOTE! FastMig X power sources allow up to 3 wire feeders to be connected to one power source.

Only one wire feeder can be active at a time and must be selected before it will operate.

7. LCD menu display

8. Soft key buttons for menu selection

Use these buttons to select menu items. Their functions depend on selected menu items. The function is shown on the display.

FastMig X 350, X 450

4.2 Using the menus

4.2.1 Selecting the interface language

The default menu language is English. If you want to select another menu language, do the following:

1. Connect the mains power and switch on the power source at the main switch.

• If this is the initial system activation (if SYSTEM OFF text is in the display), you may need to press and hold the POWER ON button in the to left corner of the X 37 control panel. Hold the button down for 5 seconds.

2. Press the MENU button to display the main menu, which includes 7 menu items.

• You can move around in the menu list by pressing the up and down arrow buttons.

• As you browse the menu item list, the currently selected item is shown at the bottom

of the display, marked as 1/7, 2/7, 3/7 etc.

• The selected menu item is marked with a black arrow-shaped cursor.

3. Browse to the menu item LANGUAGE (5/7) and press the SELECT soft key button.

4. Browse to your language and press the SELECT/SAV E soft key button. Your language choice is now conrmed and will remain selected unless you change it later.

4.2.2 About memory channels

You can have several setups of welding parameter values for use in various welding applications. These setups (or welding jobs) are stored as memory channels in X 37 control panel.

Up to 10 user proles can be dened in one FastMig X unit, and each of them are assigned up to 10 memory channels. So, you have maximum of 100 memory channels to store your frequently used welding jobs. In addition to them, there are 10 memory channels available for MMA/CC/CV use.

To dene a new welding job, you need to make the necessary welding parameter selections and then save them to a memory channel of your choice.

When you want to use these settings, you simply select the corresponding memory channel number on the power source or wire feeder control panel and start welding. Only the most often used controls are available in the wire feeder control panel, making welding easy and convenient.

You can use and update any memory channel, unless it is locked via the four-digit administrator pin code lock.

4.2.3 Creating the rst memory channel

If you are starting with a new FastMig X power source that contains no memory channels, follow these steps to create the rst memory channel.

1. Power on the machine from the main switch. You may need to press the control panel's Power On button for 5 seconds to activate the X 37 control panel.

2. An empty memory channel appears. Press the NEW soft key.

3. With Create New selected, press SELECT soft key.

4. Select the desired welding process and other welding parameters.

• Use up and down arrow buttons to move around in the menus

• Approve selections by pressing the SELECT soft key.

5. When you have made all settings , press SAVE soft key to store the settings in the active memory channel.

4.2.4 Creating the rst MMA/CC/CV memory channel

If you are starting with a new FastMig X power source that contains no MMA/CC/CV memory channels, follow these steps to create the rst MMA/CC/CV memory channel.

1. Press MENU button to display the main menu.

2. With up and down arrows, browse to MMA/CC/CV Mode (7/7) and press SELECT.

• MMA/CC/CV Mode view appears

3. With the control knob, select ON and press SELECT.

• An empty MMA/CC/CV memory channel appears.

4. When an empty MMA/CC/CV memory channel appears, press NEW soft key.

5. With Create New selected, press SELECT soft key.

6. Select MMA, CC or CV and other parameters.

7. When you have made all settings, press SAVE soft key to store the settings in the active memory channel.

4.2.5 Creating and modifying memory channels

1. Press MENU button to display the main menu.

2. With Edit Channel selected, press SELECT.

3. Select the channel number to be changed and press SELECT.

• Use up and down arrow buttons to browse the displayed channel numbers.

• Use Channel Info (F1) button to see the show the settings of the displayed channel.

• To create a new channel, select a channel that is marked (Empty).

4. Browse the menu to select the desired options and parameters.

• Use up and down arrow buttons to move around in the menus.

• Approve selections by pressing the SELECT soft key.

• See the welding parameters and functions section of this manual.

5. When you have made all settings, press SAVE soft key to store the settings in the selected memory channel number.

When you have created a memory channel, the system is ready to weld. You select the desired memory channel number on wire feeder's control panel, set the welding power and arc length and start welding.

4.3 Welding parameters

MIG

WFSpeed

WFS-Max WFS-Min Voltage VoltageMax VoltageMin Dynamics

0.7…25 m/min Sets the wire feed speed.

8…50 V Step: 0.1 Controls the length of the arc

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower

Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed

Sets the limit for maximum voltage value Sets the limit for minimum voltage value

the value the softer the arc is. The higher the value the rougher the arc is.

FastMig X 350, X 450

1-MIG

WFSpeed

WFS-Max WFS-Min FineTuning

FineTuningMax FineTuningMin Dynamics

PULSE MIG

WFSpeed

WFS-Max WFS-Min FineTuning

FineTuningMax FineTuningMin Dynamics

Pulse Current

0.7…25 m/min * Sets the wire feed speed. Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed

-9.0 … +9.0 Factory setting is 0.0

( = curve point)

-9.0 … +9.0 Step: 0.5 Sets the limit for maximum arc length

-9.0 … +9.0 Step: 0.5 Sets the limit for minimum arc length

-9 … +9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower

0.7…25 m/min * Sets the wire feed speed.

-9.0 … +9.0 Factory setting is 0.0

( = curve point)

-9.0 … +9.0 Step: 0.5 Sets the limit for maximum arc length

-9.0 … +9.0 Step: 0.5 Sets the limit for minimum arc length

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower

-10…+15% Factory setting is

0 %

Adjusts the arc voltage of the curve (arc length) within certain limits

the value the softer the arc is. The higher the value the rougher the arc is.

Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed Adjusts the base current of the curve (arc length) in

certain limits

the value the softer the arc is. The higher the value the rougher the arc is.

Reduces (–) or raises (+) the pulse current of the curve

DOUBLE PULSE MIG

WFSpeed

WFS-Max WFS-Min FineTuning

FineTuningMax FineTuningMin Dynamics

Pulse Current

DPulseAmp

DPulseFreq

0.7…25 m/min * Sets the wire feed speed. Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed

-9.0 … +9.0 Factory setting is 0.0

( = curve point)

-9.0 … +9.0 Step: 0.5 Sets the limit for maximum arc length

-9.0 … +9.0 Step: 0.5 Sets the limit for minimum arc length

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower

-10…+15% Factory setting

is 0%

0.1…3.0 m/min Factory setting is

CURVE

0.4…8.0 Hz Factory setting is

CURVE

Adjusts the base current of the curve (arc length) in certain limits

the value the softer the arc is. The higher the value the rougher the arc is.

Reduces (-) or raises (+) the pulse current of the curve

Adjusts the amplitude of the WFSpeed by steps of 0.1. Value comes from welding program.

Adjusts the frequency of the double pulse by steps of 0.1. Value comes from welding program.

WISEROOT+

WFSpeed

WFS-Max WFS-Min FineTuning

FineTuningMax FineTuningMin

* Dierent welding programs may further restrict the value range.

WISETHIN+

WFSpeed

WFS-Max WFS-Min FineTuning

FineTuningMax FineTuningMin Dynamics

1.5…8.0 m/min * Sets the wire feed speed. Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed

-9.0 … +9.0 Factory setting is 0.0

( = curve point)

-9.0 … +9.0 Step: 0.5 Sets the limit for maximum heat of the arc

-9.0 … +9.0 Step: 0.5 Sets the limit for minimum heat of the arc

0.7…25 m/min * Sets the wire feed speed.

-9.0 … +9.0 Factory setting is 0.0 ( = curve point)

-9.0 … +9.0 Step: 0.5 Sets the limit for maximum arc length

-9.0 … +9.0 Step: 0.5 Sets the limit for minimum arc length

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower

Adjusts the base current of the curve (heat of the arc) within certain limits.

Changes by steps of 0.05, when WFSpeed < 5 m/min, and by 0.1, when WFSpeed > 5 m/min

Sets the limit for maximum WFSpeed Sets the limit for minimum WFSpeed Adjusts the arc voltage of the curve (arc length) within

certain limits

the value the softer the arc is. The higher the value the rougher the arc is.

MMA PROCESSES

Current CurrentMax CurrentMin ArcForce

StartPower

CC PROCESS

Current CurrentMax CurrentMin Dynamics

StartPower

14…350/450 A Welding current 14…350/450 A Set the limit for maximum current value 14…350/450 A Set the limit for minimum current value

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower the value the softer the arc is. The higher the value the rougher the arc is.

-9…+9 Factory setting is 0 Adjusts arc ignition

10…350/450 A Welding current 10…350/450 A Set the limit for maximum current value 10…350/450 A Set the limit for minimum current value

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The lower the value the softer the arc is. The higher the value the rougher the arc is.

-9…+9 Factory setting is 0 Adjusts arc ignition

FastMig X 350, X 450

CV PROCESS

Voltage VoltageMax VoltageMin Dynamics

StartPower

10…50 V Welding voltage 10…50 V Set the limit for maximum voltage value 10…50 V Set the limit for minimum voltage value

-9…+9 Factory setting is 0 Controls the short circuit behaviour of the arc. The

-9…+9 Factory setting is 0 Adjusts arc ignition

4.4 Welding functions

WISEROOT+ AND OTHER PROCESSES

2T/4T

HotStart

HotStartLevel

Hot 2T Time

CraterFill

CraterStart

CraterFillEnd

CraterTime

Crater 4T Timer

Creep Start

StartPower

2T, 4T, MATCHLOG, USER

ON, OFF, USER Factory setting is USER (user

-50…+100 % Step: 1

0…9.9 s Step: 0.1

ON, OFF, USER Factory setting is USER (user

10…250 % Factory setting is 100% Sets the level of the curve where the crater

10…250 %, not higher than start

0.0…10.0 s Step: 0.1.

On, OFF Factory setting is OFF ON: if 4T is selected, crater lling will last

10…99 % Step: 1

-9…+9 Factory setting is 0 Adjusts arc ignition.

lower the value the softer the arc is. The higher the value the rougher the arc is.

Factory setting is USER (user chooses the switching logic)

chooses ON or OFF)

Factory setting 40%

Factory setting is 1.2 s

chooses ON or OFF)

Step: 1 Factory setting is 30%

Factory setting is 1.0 s

OFF, CURVE (OFF=100%) Factory setting is CURVE

Sets switching logic

lling will start Sets the level of the curve where the crater

lling will end. Sets slope time for crate lling

at least time that has been adjusted by CraterTime or as long as trigger is pressed. OFF: if 4T is selected, crater lling will last as long as trigger is pressed.

CURVE means that the creep start value comes from welding program.

ADVANCED FUNCTIONS

WisePenet Penet%(123A)

WiseFusion WiseFusion%

MatchFunc *

MinilogLevel

MatchMemChannel

* MatchFunc is a function that allows you to use two pre-dened sets of welding parameters during welding. You can toggle between these parameter sets by pressing the welding gun trigger briey without having to stop welding.

ON, OFF Penetration control selection

-30…+30 % Factory setting: 0 % WisePenetration percent setting. Set penetration current.

ON, OFF WiseFusion selection 10…60 % or

CURVE

Minilog, MatchCh OFF

-99…+125 % Factory setting is 20 Sets the alternative current level to a

0…9 Factory setting is 0 Sets the pre-dened memory channel,

Factory setting is CURVE When WiseFusion is ON, it controls the

amount of short circuits in the arc. The lower the value, the less short circuits in the arc, and the higher the value, the more short circuits in the arc.

Default is OFF Selects the type of function for toggling

between two sets of welding parameters during welding: Minilog=percentage of base current MatchCh=alternative memory channel

percentage of the base current

where the alternative set of parameters is stored

FastMig X 350, X 450

SYSTEM CONFIG MENU

Water Cooling

Cable Length

FineCalib

System Clock Device List Info

Restore Settings

Licence Menu

WeldData Delay

Display Delay

ON, OFF, AUTO Factory setting is AUTO Water cooler control.

ON: Water cooler is always ON OFF: Water cooler is always OFF AUTO: Water cooler starts when welding starts and turns o after a delay when welding stops.

10…100 m Step: 5

Factory setting is 10m

0V/100A…10V/100A Step: 0.1 V

Factory setting is 1.0V/100A

System Clock Settings Shows a list of connected devices. Shows following information about the selected device.

Device name: DevSW: Unit software version. SysSW: System software version (base software version). BootSW: Boot software version. SW Item: Software item number (IFS code). Serial: Device serial number. Prog: Programmer name Date: Programming time and date.

User 1 (one of ten users) Channel: Selected user can restore to his backup memory channels one by one. Other users’ memory channels remain untouched. Setup settings remain untouched.

User 1 (one of ten users) All Channels: Selected user can restore all of his backup memory channels (0-9) at one time. Other users’ memory channels remain untouched. Setup settings remain untouched.

Restore To Factory: All channels (of all users) are removed. All users’ backup channels are removed. All setup settings are set to defaults.

When MMA/CC/CV Mode is selected, the Restore Settings options are: MMA/CC/CV Channel MMA All channels Restore To Factory

Licence Code allows you to enter the licence code:

- Up and down arrows are used to select the code number position.

- Pulse encoder is used to select the code number (0–255) to be entered.

- Soft key button on the right is used to activate the licence number (after all numbers have been entered). In case the code was wrong the earlier view will be displayed. Licence Timers allows you to check the remaining time of the time-based Wise features.

1…60 s Step: 1

Factory setting is 20 s.

1…20 s Step: 1

Factory setting is 10

Welding cable loop length setting for optimising arc control.

Fine Tuning Calibration Point. Compensation for varying cable resistance.

Denes how long time the Weld Data is displayed after welding ends. Weld Data display is also turned o when pulse encoder is turned or any button is pressed.

Denes how long time the information is displayed (e.g. “Setting Saved” text). This is not always the exact time.

Pre Gas Time

Post Gas Time

Control *

RemoteAutoRecog

MIG CurrentDisp

WFMotorWarnLev

WF End Step

AutoWireInch

Gas Guard

ArcVoltage

SubFeederLength

0.0…9.9 s, CURVE. Step: 0.1 Factory setting is CURVE

USER, PANEL, REMOTE, GUN.

ON, OFF. Factory setting is ON Automatic remote control unit recognition.

ON, OFF Factory setting is OFF ON: Displays amperage (A) preset values

1.5…5.0 A Factory setting is 3.5A The alarm level of wire feed motor current.

ON, OFF Factory setting is OFF ON: The ller wire steps forward at the end

ON, OFF Factory setting is ON Automatic SuperSnake Wire Inch feature.

ON, OFF Factory setting is OFF Turns the gas guard on and o, provided

ON, OFF Factory setting is OFF Measured and calculated arc voltage.

10...25 m Factory setting is 10 m Sub feeder length selection for arc voltage

Factory settings is USER This setting aects the XF 37 (or XF 38)

CURVE: Pre Gas time is read from the Welding program.

0.0 – 9.9s: User Pre Gas time setting. CURVE: Post Gas time is read from the

Welding program.

0.0 – 9.9s: User Post Gas time setting.

control panel remote control unit selection. USER: User can select the remote control device at XF 37 panel PANEL: Selection is locked to PANEL, and user can not select the remote device at XF37 panel. REMOTE: Selection is locked to HAND REMOTE device. GUN: Selection is locked to GUN REMOTE device.

ON: Remote control units are recognized. Wire feeder panel XF 37 (or XF 38) jumps to PANEL selection, if the selected remote control unit disappears. OFF: Remote control units are not recognized. Remote control unit selection remains unchanged if the selected remote control unit disappears.

OFF: Displays wire feed speed (m/min).

Check/service wire feed mechanism, adjustment and gun components.

of the welding cycle. OFF: Filler wire remains static at the end of the welding cycle.

When ON, the Wire Inch button drives the ller wire automatically up to SuperSnake.

that one is installed.

This must be calibrated using voltage measurement cable. If ON, welding panel and subfeeder/R30 shows arc voltage value in voltage display.

calculation.

* When connecting a remote control device to the power source in MMA/CC/CV welding, you don't need to make adjustments to this setting. Remote control device is automatically recognised, when USER option is selected (default) and RemoteAutoRecog=ON.

FastMig X 350, X 450

ADMINISTRATOR MENU

Change PIN Code Ask PIN

OFF, StartUp, Menu Factory setting is OFF PIN code inquiry selection

4.5 Arc voltage display

FastMig X is capable of measuring and showing the voltage close to the welding arc. By taking this feature into use you don't need to be concerned about the voltage losses in welding cables anymore. With this feature you are only required to set the voltage for the arc before welding and after welding you can see the voltage close to the arc.

In order to use the arc voltage feature, follow these steps:

1. After setting up the welding equipment for the rst time, connect the voltage sensing cable to the welding piece and the measurement cable between the wire feeder and the power source.

2. If you are using a sub-feeder, enter the length of the sub-feeder to the SubFeederLength parameter.

3. Set the welding parameters according to your application. Note that the set voltage when using 1-MIG, MIG and WiseThin+ welding processes means always the voltage in the arc despite of ArcVoltage setting.

4. Weld with 1-MIG, MIG or with Pulse MIG for at least 5 seconds. During that time the welding machine calibrates itself for the welding cable length in question. Calibration values are stored into the welding machine, therefore this calibration is required only once after installing the welding machine package.

5. If you want to see arc voltage in panels during and after welding, turn the ArcVoltage setting to ON. Dot after voltage value in XF 37 or XF 38 panel means that showed value is arc voltage. In the weld data after welding in X 37 panel 'AVol' means also the arc voltage.

6. Voltage sensing cable can be removed after the calibration procedure, but it is recommended to use it always.

NOTE! Steps 1-3 should be repeated every time, when the length of the welding or grounding cable

is changed.

Factory PIN code is 0000 Administrator pin code change.

OFF: No PIN code inquiry. StartUp: Control panel X 37 always asks for the PIN code when the machine is turned on. Wire feeder panel XF 37 (or XF 38) is not aected and always works without PIN. Menu: Control panel X 37 asks for the PIN code every time when MENU button is pressed and when the display is in channel info mode (in start-up view). PIN code inquiry is made only once when entering the menu. After that the menu button can be pressed any time without PIN inquiry.

4.6 Welding software delivery prole

Connected to Kemppi's WFX wire feed units, FastMig X power sources make a very ecient, multi-process welding system.

After delivery and installation, your system will include welding software specied at the point of order.

If your welding needs change and you wish to update your FastMig X system in the future, you can order additional welding programs or Wise™ and Match™ welding software and load them to your system with Kemppi DataGun eld programming device.

See further information about the available welding programs, modied processes, Match™ functions and special enhanced arc performance solutions in the wire feeder's operating manual or on Kemppi's web site at www.kemppi.com.

More welding programs are available by purchasing MatchCurve and MatchCustom products.

5. TROUBLESHOOTING

NOTE! The problems listed and the possible causes are not denitive, but serve to suggest some

standard and typical situations that may present during normal environmental use when using the MIG/MAG process with FastMig X 350 or X 450.

Problem Check the following Machine won’t work

Dirty, poor quality weld

Variable welding performance

Filler wire won’t feed

• Check mains plug is connected correctly

• Check mains power distribution is switched on

• Check the mains fuse and or circuit breaker

• Check power source 0/I switch is ON

• Check interconnection cable set and connectors between the power source and

wire feed unit are correctly fastened. See the manual schematic

• Check earth return lead is connected

• Check control panels are switched on.

• Check shielding gas supply

• Check and set gas ow rate

• Check gas type for application

• Check gun/electrode polarity

• Check correct welding program selected

• Check correct channel number selected on wire feeder control panel

• Check power supply – Phase down?

• Check wire feed mechanism is correctly adjusted

• Check correct drive rolls are tted

• Check wire spool overrun tension is correctly adjusted

• Check gun liner is not blocked, replace if necessary

• Check correct gun liner is tted for the ller wire size and type

• Check contact tip for size, type and wear

• Check gun is not over heating in application

• Check cable connections and earth return clamp

• Check welding parameter settings.

• Check that pressure arms are closed and adjusted in wire feed mechanism

• Check welding gun switch function

• Check Euro gun collar is correctly fastened

• Check gun liner is not blocked

• Check contact tip, size, type, wear

• Check and try alternative gun

FastMig X 350, X 450

High spatter volume

Err1

Err 3

Err 4

Err 5

Err 8

Err 9

Err 10

Err 12

Err 27

Err 42 or Err 43

Err 45

Err 50

Err 51

Err 52

Err 62

Err 81

• Check welding parameter values

• Check inductance/Dynamics values

• Check cable compensation value if long cables are tted

• Check gas type and ow

• Check welding polarity – cable connections

• Check ller material selection

• Check correct welding program selected

• Check correct channel number selection

• Check ller wire delivery system

• Check power supply – 3-phase present?

Power source is not calibrated or calibration data cannot be read

• Restart power source

• if the problem continues after multiple startups contact Kemppi service

representative

Overvoltage in the mains supply

• Check the mains voltage Power source is overheated

• Do not shut down, let the fans cool the machine.

• Check ventilation.

• If cooling fans are not running, contact Kemppi service representative.

Mains power supply voltage is too low or one of the phases is missing or auxiliary supply is faulty

• Check the mains supply and auxiliary supply and contact Kemppi service representative if necessary.

FPGA is not congured

• Restart the power source.

• If the error persists, contact Kemppi service representative

Loose cable connections

• Check the voltage sensing cable, measurement cable and earth return cable.

Illegal process

• The welding process is not available in this machine.

Plus and minus DIX cable connectors are in contact Check welding cables

Error in the liquid cooling unit

• Check the connections in the cooling unit.

Over current in wire feeder motor

• Check that the welding gun and consumable parts are properly mounted

Gas guard alert

• Check the shielding gas, gas guard and all connections.

The function is not activated in this machine

• If you need this function, order a licence for it from a Kemppi representative.

• WiseDemo period might be over.

Rear feed roll may be loose

• Check that the feed rolls are properly tightened.

Front feed roll may be loose

• Check that the feed rolls are properly tightened

Power source is not connected or not identied by the wire feeder

• Check the intermediate cable and its connections.

Welding program is not found

• If you need the welding program, order a licence for it from Kemppi representative.

MEMORY ERROR

SYSTEM BUS ERROR

LICENSE FILE ERROR

NOTE! Many of these checks may be carried out by the operator. However certain checks relating to

mains power must be completed by an authorised trained electrician.

NOTE! In the case of an error code other than the listed above, contact Kemppi service

representative.

Machine cannot complete read or write functions on the wire feeder memory card

• Check the cables and connections.

• Contact Kemppi service representative.

Control panel cannot establish a connection to the CAN bus

• Check the at cables and the control panels.

• Contact Kemppi service representative.

Machine cannot read wire feeder memory lisence le

• Check the cables and connection.

• Contact Kemppi service representative.

6. OPERATION DISTURBANCES

Should you experience a malfunction from your machine, please consult the basic troubleshooting text above rst, and complete some basic checks.

If the machine malfunction cannot be corrected with these measures, contact your Kemppi maintenance service workshop.

Operation of the overload protection

Yellow thermal protection lamp is lit when the thermostat is operating due to loading beyond the stated duty cycle.

The thermostat will operate, if machine is continuously loaded over rated values or cooling air circulation is blocked.

Internal fans will cool the machine, and when the pilot lamp is not lit the machine is automatically ready for welding.

Control fuses

Fuse, 6.3 A delayed, on the rear wall of machine provides protection for auxiliary devices. Use the same type and rating of fuse as marked beside the fuse adapter. Damage caused by

incorrect fuse selection is not covered by the guarantee.

Under and over voltages in the mains supply

Primary circuits of the machine are protected against sudden, transient overvoltages. The machine is designed to withstand 3 x 440 V voltage continuously. Ensure that voltage is kept within this permissible limit, especially when the mains supply is provided by a combustion engine generator. If the mains has under voltage (under approx. 300 V) or overvoltage (over approx. 480 V) machine control stops operation automatically.

Loss of a phase in the mains supply

Loss of a mains power phase causes noticeably poor welding properties. In some cases the machine won't start at all. Loss of a phase can be due to following:

• Blowing of mains supply fuse

• Defective mains cable

• Bad connection of mains power cable on machine terminal block or plug of machine.

FastMig X 350, X 450

7. MAINTENANCE

When considering and planning routine maintenance, please consider the frequency of machine use and the working environment.

Correct operation of the machine and regular maintenance will help you avoid unnecessary downtime and equipment failure.

NOTE! Disconnect the machine from the mains before handling the electrical cables.

7.1 Daily maintenance

• Check the overall condition of the welding gun. Remove welding spatter from the contact tip and clean the gas nozzle. Replace worn or damaged parts. Only use original Kemppi spare parts.

• Check the condition and connection of the welding circuit components: welding gun, earth return cable and clamp, sockets and connectors.

• Check the condition of the feed rolls, needle bearings and shafts. Clean and lubricate bearings and shafts with a small quantity of light machine oil if necessary. Assemble, adjust and test function.

• Check that the feed rolls are suitable for the ller wire you are using, and that their pressure adjustment is correct.

7.2 Periodic maintenance

NOTE! Periodic maintenance should only be carried out by a suitably qualied person. Disconnect

the plug of the machine from the mains socket and wait about 2 minutes (capacitor charge) before removing the cover plate.

Check at least every half year:

• Electric connectors of the machine – clean any oxidized parts and tighten loose connections.

NOTE! You must know the correct tension torques values before starting the reparation of the loose

joints.

Clean the inner parts of the machine from dust and dirt e.g. with a soft brush and vacuum cleaner. Also clean the ventilation net behind the front grill.

Do not use compressed air, there is a risk that the dirt will compact even more tightly into gaps of cooling proles.

Do not use pressure washing devices. Only an authorized trained electrician should carry out repairs to Kemppi machines.

7.3 Service Workshop maintenance

Kemppi Service Workshops complete maintenance according to their Kemppi service agreement.

The major points in the maintenance procedure are listed as follows:

• Cleaning of the machine

• Checking and maintenance of the welding tools

• Checking of connectors, switches and potentiometers

• Checking of electric connections

• Checking of mains cable and plug

• Damaged parts or parts in bad condition are replaced by new ones

• Maintenance testing.

• Operation and performance values of the machine are checked, and when necessary

adjusted by means of software and test equipment.

Software loading

Kemppi Service Workshops can also test and load rmware and welding software.

8. DISPOSAL OF THE MACHINE

Do not dispose of electrical equipment with normal waste! In observance of European Directive 2002/96/EC on waste electrical and electronic

equipment, and its implementation in accordance with national law, electrical equipment that has reached the end of its life must be collected separately and taken to an appropriate environmentally responsible recycling facility.

The owner of the equipment is obliged to deliver a decommissioned unit to a regional collection centre, as per the instructions of local authorities or a Kemppi representative. By applying this European Directive you will improve the environment and human health.

FastMig X 350, X 450

9. ORDERING CODES

FastMig X 350 power source X 37 control panel included 6103350 FastMig X 350 power source No control panel 610335001 FastMig X 450 power source X 37 control panel included 6103450 FastMig X 450 power source No control panel 610345001 WFX 200 wire feeder 200 mm, regular pulse welding 6103520 WFX 300 wire feeder 300 mm, regular pulse welding 6103530 WFX 200 P Fe wire feeder 200 mm, pipe welding, steel 6103521 WFX 300 P Fe wire feeder 300 mm, pipe welding, steel 6103531 WFX 200 P Ss wire feeder 200 mm, pipe welding, stainless steel 6103522 WFX 300 P Ss wire feeder 300 mm, pipe welding, stainless steel 6103532 WFX 200 AMC wire feeder 200 mm, intelligent pulse welding 6103523 WFX 300 AMC wire feeder 300 mm, intelligent pulse welding 6103533 WFX 200-T wire feeder 200 mm, tailored 6103524 WFX 300 P-T wire feeder 300 mm, tailored 6103535 WFX 300-T wire feeder 300 mm, tailored 6103534

Control devices

Remote X 37 control panel 6103800 ARC Mobile Control adapter * Included with WFX 200 AMC and WFX 300 AMC 6103100 * To use the ARC Mobile Control you need a mobile device with Android 4.0 operating system or newer, Bluetooth feature,

and Kemppi’s ARC Mobile Control mobile application. With certain mobile device models, Near Field Communication (NFC) can also be used for smart connection between the welding machine and the mobile device. For more information, please visit www.kemppi.com.

Cables

Earth return cable 5 m, 50 mm² 6184511 Earth return cable 5 m, 70 mm² 6184711 MMA welding cable 5 m, 50 mm² 6184501 MMA welding cable 5 m, 70 mm² 6184701

Interconnection cables, air-cooled

FASTMIG X 70-1.8-GH 1.8 m 6260468 FASTMIG X 70-5-GH 5 m 6260469 FASTMIG X 70-10-GH 10 m 6260470 FASTMIG X 70-20-GH 20 m 6260471 FASTMIG X 70-30-GH 30 m 6260472 – For other lengths, please contact Kemppi.

Interconnection cables, liquid-cooled

FASTMIG X 70-1.8-WH 1.8 m 6260473 FASTMIG X 70-5-WH 5 m 6260474 FASTMIG X 70-10-WH 10 m 6260475 FASTMIG X 70-20-WH 20 m 6260476 FASTMIG X 70-30-WH 30 m 6260477 – For other lengths, please contact Kemppi.

Software products

MatchLog™ Included with WFX 200 AMC and 300 AMC 9991017 MatchChannel™ Included with MatchLog™ licence WiseRoot+™ Included with WFX 200 P Fe/Ss and 300 P Fe/Ss 9990418 WiseThin+™ Included with WFX 200 AMC and 300 AMC 9990419 WiseFusion™ Included with all WFX wire feeders 9991014 WisePenetration™ function Included with WFX 200 AMC and 300 AMC 9991000 Pipe Steel welding program package Inlcuded with WFX 200 P Fe and 300 P Fe 99904274 Pipe Stainless welding program package Inlcuded with WFX 200 P Ss and 300 P Ss 99904275 Steel Pack for WiseThin+ welding

program package Steel Pack Included with WFX 200 AMC and 300 AMC 99904232 Stainless Steel Pack Included with WFX 200 AMC and 300 AMC 99904233 Aluminium Pack Included with WFX 200 AMC and 300 AMC 99904231 Work Pack Included with WFX 200 and 300 99904230 – Other welding software available.

Included with WFX 200 AMC and 300 AMC 99904301

Accessories

Cool X cooling unit 6068200 SuperSnake GT02S sub feeder 10 m 6153100 SuperSnake GT02S sub feeder 15 m 6153150 SuperSnake GT02S sub feeder 20 m 6153200 SuperSnake GT02S sub feeder 25 m 6153250 SuperSnake GT02S W sub feeder 10 m 6154100 SuperSnake GT02S W sub feeder 15 m 6154150 SuperSnake GT02S W sub feeder 20 m 6154200 SuperSnake GT02S W sub feeder 25 m 6154250 SuperSnake GT02S sub feeder

synchronization unit for WFX 300 series wire feeders

KV 200 mounting plate for two wire feeders and TIG unit

Gun holder GH 30 6256030 Transport unit PM 500 6185291 Remote control unit R10 5 m 6185409 Remote control unit R10 10 m 618540901 Remote control unit R20 5 m 6185419 Remote control unit R30 DataRemote 5 m 6185420

W004030

6185249

FastMig X 350, X 450

Remote control unit R30 DataRemote 10 m 618542001 Remote control extension cable 10 m 6185481 Software installation device DataGun 6265023

NOTE! WiseRoot+™ and WiseThin+™ welding processes are not available with SuperSnake sub

feeder.

10. TECHNICAL DATA

FastMig X 350 X 450

Connection voltage 3~50/60 Hz 400 V, -15…+20 % 400 V, -15…+20 % Rated power 60 % ED 22.1 kVA

Connection cable HO7RN-F 4G6 (5 m) 4G6 (5 m) Fuse Delayed 35 A 35 A Output 40 °C 60 % ED 450 A

Welding current and voltage range MMA 15 A/20 V – 350 A/46 V 15 A/20 V – 450 A/46 V

Max. welding voltage MMA 46 V 46 V Open circuit voltage MMA U

Open circuit power 100 W 100 W Power factor at max. current 0.85 0.88 Eciency at 100 % ED 87 % 87 % Operating temperature range -20…+40 °C -20…+40 °C Storage temperature range -40…+60 °C -40…+60 °C EMC class A A Minimun short circuit power S Degree of protection IP23S IP23S External dimensions L x W x H 590 x 230 x 430 mm 590 x 230 x 430 mm Weight 38 kg 38 kg Voltage supply for auxiliary devices 50 V DC / 100 W 50 V DC / 100 W Fuse (auxiliary device) Delayed 6.3 A 6.3 A Voltage supply for cooling unit 24V DC / 50 VA 24V DC / 50 VA The minimum recommended generator output is 35 kVA.

of supply network* 5.5 MVA 5.5 MVA

80 % ED 16.0 kVA 100 % ED 15.3 kVA 16.0 kVA

80 % ED 350 A 100 % ED 330 A 350 A

MIG 20 A/12 V – 350 A/46 V 20 A/12 V – 450 A/46 V

MIG/MAG/Pulse U

= 70 – 98 V

Uav = 50 V

= 80 – 98 V U

= 70 – 98 V

Uav = 50 V

= 80 – 98 V

* See section 2.2: Distribution network.

KEMPPI OY

Kempinkatu 1 PL 13 FIN-15801 LAHTI FINLAND Tel +358 3 899 11 Telefax +358 3 899 428 export@kemppi.com www.kemppi.com

Kotimaan myynti:

Tel +358 3 899 11 Telefax +358 3 734 8398 myynti.@kemppi.com

KEMPPI SVERIGE AB

Box 717 S-194 27 UPPLANDS VÄSBY SVERIGE Tel +46 8 590 783 00 Telefax +46 8 590 823 94 sales.se@kemppi.com

KEMPPI NORGE A/S

Postboks 2151, Postterminalen N-3103 TØNSBERG NORGE Tel +47 33 346000 Telefax +47 33 346010 sales.no@kemppi.com

KEMPPI DANMARK A/S

Literbuen 11 DK-2740 SKOVLUNDE DANMARK Tel +45 4494 1677 Telefax +45 4494 1536 sales.dk@kemppi.com

KEMPPI BENELUX B.V.

NL-4801 EA BREDA NEDERLAND Tel +31 765717750 Telefax +31 765716345 sales.nl@kemppi.com

KEMPPI (UK) LTD

Martti Kemppi Building Fraser Road Priory Business Park BEDFORD, MK44 3WH UNITED KINGDOM Tel +44 (0)845 6444201

Telefax +44 (0)845 6444202 sales.uk@kemppi.com

KEMPPI FRANCE S.A.S.

65 Avenue de la Couronne des Prés 78681 EPONE CEDEX FRANCE Tel +33 1 30 90 04 40 Telefax +33 1 30 90 04 45 sales.fr@kemppi.com

KEMPPI GMBH

Perchstetten 10 D-35428 LANGGÖNS DEUTSCHLAND Tel +49 6 403 7792 0 Telefax +49 6 403 779 79 74 sales.de@kemppi.com

KEMPPI SPÓŁKA Z O.O.

Ul. Borzymowska 32 03-565 WARSZAWA POLAND Tel +48 22 7816162 Telefax +48 22 7816505 info.pl@kemppi.com

KEMPPI AUSTRALIA PTY LTD

13 Cullen Place P.O. Box 5256, Greystanes NSW 2145 SMITHFIELD NSW 2164 AUSTRALIA Tel. +61 2 9605 9500 Telefax +61 2 9605 5999 info.au@kemppi.com

OOO KEMPPI

Polkovaya str. 1, Building 6 127018 MOSCOW RUSSIA Tel +7 495 240 84 03 Telefax +7 495 240 84 07 info.ru@kemppi.com

ООО КЕМППИ

ул. Полковая 1, строение 6 127018 Москва Tel +7 495 240 84 03 Telefax +7 495 240 84 07 info.ru@kemppi.com

KEMPPI WELDING TECHNOLOGY (BEIJING) CO., LTD.

Unit 105, 1/F, Building #1, No. 26 Xihuan South Rd., Beijing Economic-Technological Development Area (BDA), 100176 BEIJING CHINA Tel +86-10-6787 6064 +86-10-6787 1282 Telefax +86-10-6787 5259 sales.cn@kemppi.com

肯倍焊接技术（北京）有限公司

中国北京经济技术开发区西环南路26号

1号楼1层105室(100176)

电话：+86-10-6787 6064/1282 传真：+86-10-6787 5259

sales.cn@kemppi.com

KEMPPI INDIA PVT LTD

LAKSHMI TOWERS New No. 2/770, First Main Road, Kazura Garden, Neelankarai, CHENNAI - 600 041 TAMIL NADU Tel +91-44-4567 1200 Telefax +91-44-4567 1234 sales.india@kemppi.com

KEMPPI WELDING SOLUTIONS SDN BHD

No 12A, Jalan TP5A, Taman Perindustrian UEP, 47600 Subang Jaya, SELANGOR, MALAYSIA Tel +60 3 80207035 Telefax +60 3 80207835 sales.malaysia@kemppi.com

1903450

1520

www.kemppi.com

Kemppi FastMig X 350 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
