Keeprite KVD016V6-B User Manual

KV-Line

04/17/13

Condensing Units

PRODUCT DATA &
SPECIFICATIONS

Bulletin K40-KV-PDS-17

1073950

Latest product updates and further information
at www.keepriterefrigeration.com

Now featuring HIGH EFFICIENCY MODELS

Outdoor Air Cooled
Condensing Units

15 to 100 HP - High and Medium
Temperature Refrigeration
10 to 80 HP - Low Temperature
Refrigeration

CONTENTS

Nomenclature............................................................................................................................................. 2

Features...................................................................................................................................................... 3 - 4

Capacity Ratings and Selection................................................................................................................ 4

STANDARD EFFICIENCY MODELS

Capacity Data.......................................... 5 - 22

KVS (Copeland Single Compressor )... 5 - 8

KVD (Copeland Dual Compressor)....... 9 - 12

KVS (Bitzer Single Compressor)........... 13 - 17

KVD (Bitzer Dual Compressor)............. 18 - 22

Electrical Data........................................ 24 - 27

KVS (Copeland Single Compressor)..... 24

KVD (Copeland Dual Compressor)........ 25

KVS (Bitzer Single Compressor)............ 26

KVD (Bitzer Dual Compressor).............. 27

Dimensional Data................................... 28 - 31

KVS (All Single Compressor Models)... 28 - 29

KVD (All Dual Compressor Models)..... 30 - 31

Specications.........................................32-33

KVS/KVD (All Copeland Models).......... 32

KVS/KVD (All Bitzer Models)................ 33

Wiring Diagrams (All Models).................................................................................................................. 34 - 39

Warranty..................................................................................................................................................... 67

Project Information.................................................................................................................................... 67

“As Built” Service Parts List.................................................................................................................... BACK

Capacity Data......................................... 40 - 55

KVS (Copeland Single Compressor )... 40 - 43

KVD (Copeland Dual Compressor)....... 44 - 47

KVS (Bitzer Single Compressor)........... 48 - 51

KVD (Bitzer Dual Compressor)............. 52 - 55

Electrical Data......................................... 56 - 59

KVS (Copeland Single Compressor)..... 56

KVD (Copeland Dual Compressor)........ 57

KVS (Bitzer Single Compressor)............ 58

KVD (Bitzer Dual Compressor).............. 59

Dimensional Data................................... 60 - 63

KVS (All Single Compressor Models)... 60 - 61

KVD (All Dual Compressor Models)..... 62 - 63

Specications.........................................64-65

KVS/KVD (All Copeland Models).......... 64

KVS/KVD (All Bitzer Models)................ 65

HIGH EFFICIENCY MODELS

NOMENCLATURE

04/17/13

K40-KV-PDS-17

- 2 -

KVS 040 M8 -H T4 B A

KeepRite Vertical Air Flow Condensing Unit

KVS = Single Compressor/Single Condenser Unit
KVD = Dual Compressor/Dual Condenser Unit

Total HP

040 = If single, one 40 HP compressor.
If dual, two 20 HP compressors.

High efciency models = Standard HP +1 (i.e.: 041 = 040 + 001)

Application

H = High Temp. M = Medium Temp.
L = Low Temp. V = Extended Low Temp.

2 = R22 6 = R404A / R507
8 = R404A / R507 / R22/R407C

Enclosure

H = Outdoor

FEATURES

Compressor

A = Catalog Standard
D = Copeland Discus Semi-Hermetic
B = Bitzer Semi-Hermetic
T = Bitzer 2 Stage Semi-Hermetic
Z = Copeland Scroll

Series Generation

B = 2nd Generation
X = Special Custom Model
(Deviates from catalog)

Electrical Designation

T3 = 208-230/3/60
T4 = 460/3/60
T5 = 575/3/60

* Subject to compressor availability

Electrical
panel

Pre-formed

internal piping

Raceway for pressure control
connections

Sub cooler circuit on medium
and low temperature models

FEATURES - ALL MODELS

04/17/13

K40-KV-PDS-17

- 3 -

· Units are CUL

· Designed for use with R22, R404A, R507 and R407C.

· Energy efcient compressors with POE oil. Several

options to choose from: Copeland Discus, Bitzer

reciprocating.

· Single, dual and parallel-piped (optional) compressor

congurations available.

· ThermospanTM condenser core design eliminates tube
sheet leaks and provides reliable operation.

· 3/8" condenser tubes reduces refrigerant charge.

· Generously sized condenser allows unit to operate at

higher than normal ambient conditions.

· Optional coating and n surfaces for condenser core

protection available.

· Specially designed, thermally protected and
permanently lubricated ball bearing condenser fan

motor(s).

· Receivers (where used) are liberally sized and include

inlet as well as outlet service valves.

US

Listed.

· Subcooling circuit in condenser on all models

(except H8 models) increases overall system
efciency and provides dependable compressor

operation.

· Utilizes pre-formed internal piping, eliminates
welded joints and reduces chances of a leak.

· Electrical components are housed in a spacious

and conveniently located panel. In case of a

compressor trip, (except on air conditioning

models) a Lock-out relay de-energizes the liquid

line solenoid valve. In addition, SPDT contact is

provided for eld wired alarm circuit.

· End compartment panels allow unrestricted
access to service the compressor(s) and all other
components.

· Raceway for pressure control wiring and

connections provides neat appearance.

· Units are available with energy efcient

ThermosaverTM hot gas defrost option.

· Units are environmently friendly operating on less

power and refrigerant charge.

STANDARD EFFICIENCY MODELS

Standard features include:

· Spring mount compressor with discharge

vibration eliminator.

· Compressor head cooling fans on low

temperature models

· Compressor crankcase heater

· Flexible hose on all compressor pressure

control connections

· Two valve adjustable (pre-set at factory)

Low Ambient head pressure control.

· Condenser fan cycling control (pressure)

on two-fan models and up.

· Fused condenser fan motors

HIGH EFFICIENCY MODELS

FEATURES

· Receiver inlet/outlet valves and safety

pressure relief valve

· Replaceable liquid line drier & sight glass

· Anti-short cycle time delay relay

· Oil failure control (non-electronic)

· Separate HP and LP compressor controls.

· Part-winding start on all 30 HP and up,

operating on 208/230V-3Ph.

· Lock out relay.

· Sub-cooling circuit on medium and low

temperature units.

FEATURES

· All Standard Efciency Model features

· Oversized condenser coils

OPTIONAL FEATURES

04/17/13

K40-KV-PDS-17

- 4 -

Factory installed Optional Features include:

· Suction line vibration eliminator

· Suction accumulator

(with or without heat exchanger)

· Replaceable suction lter

· Insulated suction lines.

· Crankcase Pressure Regulating valve

· Compressor capacity control (cylinder

unloading on 4D-6D-6F compressors or
ModuloadTM on 3D compressor)

· Discharge line check valve

· Hot gas bypass tees / regulating valves /

de-superheating TXV

· Oil separator

· Discharge line thermostat

· Oversized receiver

· Heated and insulated receiver

· Thermosaver

· Disconnect switch (fused or non-fused).

· Compressor circuit breaker

· Electronic Oil failure control

· Voltage / Phase monitor

· Part-winding start (standard on 30HP and up

operating on 208/230-3)

· Defrost Time clock

· Defrost Heater / Evaporator Fan Contactors

with fuse block

· Single point electrical service hook up for
evaporator and controls

TM

defrost.

CAPACITY RATINGS AND SELECTION

RATING INFORMATION: 1. Ratings as shown are at saturated suction temperatures.

2. 60Hz capacity ratings are shown in imperial and metric units:

MBH in bold type, (KW) in italics with in brackets.

3. Ratings may be interpolated but should not be extrapolated.

SELECTION PROCEDURE: Determine following requirements:

1. Ambient temperature, - °F / °C.

2. Total cooling load - MBH / (KW).

3. SST (saturated suction temperature) - °F / °C.

4. Refrigerant type - R22/R404A/R507.

EXAMPLE SELECTION: GIVEN:

- Ambient temperature, 95°F / 35°C.

- Total cooling load 115MBH.

- SST, - 20°F/-28.8°C.

- Refrigerant, R404A.

METHOD:

- Go to the R404A low temperature capacity chart.

- Determine the capacity rating under 95°F ambient column and -20°F

SST row.

- Select the model with closest capacity requirement which is KVS030L6

with capacity 115.2 MBH.

SELECTION OF TWO-COMPRESSOR UNITS

KVD condensing units are double compressor units.

The ratings shown are the total capacity of two
compressors operating simultaneously.

Standard KVD models are designed with two

independently operating systems, each with a

separate refrigeration circuit. Optional parallel

piped compressors (one total system) are
available. Consult factory.

COPELAND

04/17/13

K40-KV-PDS-17

- 5 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS015H8-A

Compressor

Model

3DS3R17ME

KVS025H8-A

Compressor

Model

4DHNR22ME

KVS030H8-A

Compressor

Model

4DJNR28ME

KVS035H8-A

Compressor

Model

6DHNR35ME

KVS040H8-A

Compressor

Model

6DJNR40ME

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 235.7 (69.1) 226.9 (66.5) 218.4 (64) 210.1 (61.6) 202.1 (59.2) 194.2 (56.9)
50 (10) 217.2 (63.7) 209.3 (61.3) 201.7 (59.1) 194.2 (56.9) 186.9 (54.8) 179.8 (52.7)
45 (7.2) 199.5 (58.5) 192.4 (56.4) 185.6 (54.4) 178.9 (52.4) 172.3 (50.5) 165.9 (48.6)
40 (4.4) 182.6 (53.5) 176.3 (51.7) 170.2 (49.9) 164.2 (48.1) 158.3 (46.4) 152.5 (44.7)
35 (1.7) 166.4 (48.8) 160.9 (47.2) 155.4 (45.5) 150.1 (44) 144.8 (42.4) 139.5 (40.9)
55 (12.8) 334.1 (97.9) 317.0 (92.9) 300.3 (88) 283.8 (83.2) 267.8 (78.5) 252.2 (73.9)
50 (10) 308.8 (90.5) 293.3 (86) 278.0 (81.5) 263.1 (77.1) 248.7 (72.9) 234.7 (68.8)
45 (7.2) 283.8 (83.2) 269.8 (79.1) 256.1 (75.1) 242.8 (71.2) 229.9 (67.4) 217.6 (63.8)
40 (4.4) 259.4 (76) 247.0 (72.4) 234.8 (68.8) 223.0 (65.4) 211.7 (62) 200.9 (58.9)
35 (1.7) 235.8 (69.1) 224.9 (65.9) 214.2 (62.8) 203.9 (59.8) 194.1 (56.9) 184.7 (54.1)
55 (12.8) 393.6 (115.4) 374.2 (109.7) 354.9 (104) 336.0 (98.5) 317.4 (93) --- --­50 (10) 362.0 (106.1) 344.2 (100.9) 326.8 (95.8) 309.7 (90.8) 293.0 (85.9) 276.6 (81.1)
45 (7.2) 331.3 (97.1) 315.3 (92.4) 299.7 (87.8) 284.5 (83.4) 269.7 (79) 255.3 (74.8)
40 (4.4) 301.9 (88.5) 287.7 (84.3) 274.0 (80.3) 260.6 (76.4) 247.7 (72.6) 235.2 (68.9)
35 (1.7) 274.0 (80.3) 261.6 (76.7) 249.7 (73.2) 238.1 (69.8) 227.0 (66.5) 216.3 (63.4)
55 (12.8) 502.7 (147.3) 482.7 (141.5) 462.6 (135.6) 442.4 (129.7) 422.1 (123.7) --- --­50 (10) 454.4 (133.2) 436.5 (127.9) 418.5 (122.6) 400.3 (117.3) 382.0 (112) 363.6 (106.6)
45 (7.2) 409.9 (120.1) 394.0 (115.5) 377.9 (110.8) 361.8 (106) 345.5 (101.3) 329.0 (96.4)
40 (4.4) 369.2 (108.2) 355.2 (104.1) 341.1 (100) 326.8 (95.8) 312.4 (91.6) 297.7 (87.2)
35 (1.7) 332.3 (97.4) 320.1 (93.8) 307.8 (90.2) 295.3 (86.5) 282.6 (82.8) 269.6 (79)
55 (12.8) 677.7 (198.6) 645.7 (189.2) 612.1 (179.4) 577.2 (169.2) 540.9 (158.5) --- --­50 (10) 605.7 (177.5) 575.9 (168.8) 544.8 (159.7) 512.3 (150.1) 478.6 (140.3) 443.9 (130.1)
45 (7.2) 537.9 (157.6) 511.0 (149.8) 482.6 (141.4) 452.9 (132.7) 422.2 (123.7) 390.5 (114.4)
40 (4.4) 476.5 (139.6) 452.3 (132.6) 426.8 (125.1) 400.0 (117.2) 372.3 (109.1) 343.8 (100.8)
35 (1.7) 422.0 (123.7) 400.5 (117.4) 377.7 (110.7) 353.9 (103.7) 329.2 (96.5) 303.8 (89)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

CONDENSING

UNIT

MODEL

KVS015H8-A

Compressor

3DS3R17ME

KVS025H8-A

Compressor

4DHNR22ME

KVS030H8-A

Compressor

4DJNR28ME

KVS035H8-A

Compressor

6DHNR35ME

KVS040H8-A

Compressor

6DJNR40ME

TEMPERATURE

CAPACITY DATA -

R404A

R507

60HzKVS-A

HIGH TEMPERATURE

SATURATED

SUCTION

° F ° C

45 (7.2) 221.0 (64.8) 211.4 (62) 202.0 (59.2) 192.6 (56.4) 183.4 (53.7) 174.3 (51.1)
40 (4.4) 203.9 (59.8) 195.2 (57.2) 186.5 (54.7) 178.0 (52.2) 169.5 (49.7) 161.2 (47.2)
35 (1.7) 187.7 (55) 179.7 (52.7) 171.8 (50.3) 164.0 (48.1) 156.2 (45.8) 148.6 (43.6)
45 (7.2) 286.3 (83.9) 274.1 (80.3) 262.2 (76.8) 250.6 (73.4) 239.2 (70.1) 228.1 (66.8)
40 (4.4) 267.5 (78.4) 256.0 (75) 244.9 (71.8) 234.0 (68.6) 223.4 (65.5) 213.0 (62.4)
35 (1.7) 248.5 (72.8) 237.8 (69.7) 227.4 (66.6) 217.3 (63.7) 207.4 (60.8) 197.6 (57.9)
45 (7.2) 348.9 (102.3) 333.8 (97.8) 318.8 (93.4) 303.9 (89.1) 288.9 (84.7) 274.0 (80.3)
40 (4.4) 323.2 (94.7) 309.2 (90.6) 295.3 (86.5) 281.4 (82.5) 267.6 (78.4) 253.7 (74.4)
35 (1.7) 298.4 (87.5) 285.4 (83.6) 272.5 (79.9) 259.7 (76.1) 246.9 (72.4) 234.1 (68.6)
45 (7.2) 448.1 (131.3) 428.9 (125.7) 409.6 (120) 390.3 (114.4) 370.9 (108.7) 351.4 (103)
40 (4.4) 413.4 (121.2) 395.7 (116) 377.9 (110.8) 360.2 (105.6) 342.4 (100.3) 324.5 (95.1)
35 (1.7) 380.2 (111.4) 364.0 (106.7) 347.7 (101.9) 331.5 (97.2) 315.1 (92.3) 298.8 (87.6)
45 (7.2) 511.2 (149.8) 490.3 (143.7) 469.3 (137.5) 448.2 (131.4) 427.0 (125.1) 405.4 (118.8)
40 (4.4) 474.6 (139.1) 455.2 (133.4) 435.8 (127.7) 416.2 (122) 396.5 (116.2) 376.5 (110.3)
35 (1.7) 439.0 (128.7) 421.1 (123.4) 403.2 (118.2) 385.2 (112.9) 367.0 (107.6) 348.6 (102.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 6 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS015M8-A

Compressor

Model

3DS3R17ME

KVS025M8-A

Compressor

Model

4DHNR22ME

KVS030M8-A

Compressor

Model

4DJNR28ME

KVS035M8-A

Compressor

Model

6DHNR35ME

KVS040M8-A

Compressor

Model

6DJNR40ME

KVS050M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 172.1 (50.4) 164.9 (48.3) 157.7 (46.2) 150.6 (44.1) 143.6 (42.1) 136.7 (40.1)
25 (-3.9) 157.4 (46.1) 150.8 (44.2) 144.3 (42.3) 137.9 (40.4) 131.6 (38.6) 125.4 (36.8)
20 (-6.7) 143.4 (42) 137.5 (40.3) 131.7 (38.6) 125.9 (36.9) 120.2 (35.2) 114.6 (33.6)
15 (-9.4) 130.3 (38.2) 125.0 (36.6) 119.7 (35.1) 114.6 (33.6) 109.5 (32.1) 104.4 (30.6)
10 (-12.2) 117.9 (34.6) 113.2 (33.2) 108.5 (31.8) 103.9 (30.4) 99.3 (29.1) 94.8 (27.8)

5 (-15) 106.3 (31.2) 102.1 (29.9) 98.0 (28.7) 93.8 (27.5) 89.8 (26.3) 85.8 (25.1)

0 (-17.8) 95.6 (28) 91.8 (26.9) 88.1 (25.8) 84.4 (24.7) 80.8 (23.7) 77.2 (22.6)
30 (-1.1) 229.6 (67.3) 219.7 (64.4) 210.0 (61.5) 200.6 (58.8) 191.3 (56.1) 182.3 (53.4)
25 (-3.9) 210.9 (61.8) 201.7 (59.1) 192.8 (56.5) 184.0 (53.9) 175.5 (51.4) 167.1 (49)
20 (-6.7) 192.5 (56.4) 184.1 (54) 175.9 (51.6) 167.9 (49.2) 160.0 (46.9) 152.3 (44.6)
15 (-9.4) 174.8 (51.2) 167.1 (49) 159.6 (46.8) 152.3 (44.6) 145.1 (42.5) 138.0 (40.4)
10 (-12.2) 157.8 (46.2) 150.8 (44.2) 144.1 (42.2) 137.4 (40.3) 130.9 (38.4) 124.4 (36.5)

5 (-15) 141.8 (41.6) 135.6 (39.7) 129.5 (38) 123.6 (36.2) 117.7 (34.5) 111.9 (32.8)

0 (-17.8) 127.1 (37.2) 121.6 (35.6) 116.2 (34.1) 110.9 (32.5) 105.7 (31) 100.5 (29.5)
30 (-1.1) 274.4 (80.4) 262.4 (76.9) 250.6 (73.4) 238.8 (70) 227.1 (66.6) 215.3 (63.1)
25 (-3.9) 251.3 (73.6) 240.3 (70.4) 229.5 (67.3) 218.7 (64.1) 208.0 (61) 197.3 (57.8)
20 (-6.7) 229.2 (67.2) 219.2 (64.2) 209.3 (61.3) 199.5 (58.5) 189.8 (55.6) 180.1 (52.8)
15 (-9.4) 208.1 (61) 199.0 (58.3) 190.1 (55.7) 181.3 (53.1) 172.5 (50.6) 163.7 (48)
10 (-12.2) 188.0 (55.1) 179.9 (52.7) 171.8 (50.3) 163.9 (48) 156.0 (45.7) 148.2 (43.4)

5 (-15) 169.1 (49.6) 161.8 (47.4) 154.6 (45.3) 147.6 (43.3) 140.6 (41.2) 133.6 (39.2)

0 (-17.8) 151.3 (44.3) 144.8 (42.4) 138.4 (40.6) 132.2 (38.7) 126.1 (37) 119.9 (35.1)
30 (-1.1) 348.6 (102.2) 333.8 (97.8) 319.0 (93.5) 304.1 (89.1) 289.2 (84.8) 274.3 (80.4)
25 (-3.9) 318.6 (93.4) 305.1 (89.4) 291.6 (85.5) 278.2 (81.5) 264.6 (77.5) 251.1 (73.6)
20 (-6.7) 290.2 (85) 278.0 (81.5) 265.8 (77.9) 253.6 (74.3) 241.3 (70.7) 229.0 (67.1)
15 (-9.4) 263.5 (77.2) 252.5 (74) 241.4 (70.7) 230.3 (67.5) 219.3 (64.3) 208.2 (61)
10 (-12.2) 238.5 (69.9) 228.5 (67) 218.5 (64) 208.5 (61.1) 198.5 (58.2) 188.4 (55.2)

5 (-15) 215.2

0 (-17.8) 193.6 (56.7) 185.2 (54.3) 176.9 (51.8) 168.6 (49.4) 160.4 (47) 152.2 (44.6)
30 (-1.1) 404.7 (118.6) 388.1 (113.7) 371.6 (108.9) 355.1 (104.1) 338.4 (99.2) 321.5 (94.2)
25 (-3.9) 371.6 (108.9) 356.4 (104.5) 341.2 (100) 326.1 (95.6) 310.8 (91.1) 295.3 (86.5)
20 (-6.7) 339.9 (99.6) 326.0 (95.5) 312.1 (91.5) 298.3 (87.4) 284.4 (83.3) 270.3 (79.2)
15 (-9.4) 309.7 (90.8) 296.9 (87) 284.3 (83.3) 271.7 (79.6) 259.1 (75.9) 246.4 (72.2)
10 (-12.2) 281.1 (82.4) 269.4 (79) 257.9 (75.6) 246.5 (72.2) 235.1 (68.9) 223.6 (65.5)

5 (-15) 254.1 (74.5) 243.5 (71.4) 233.0 (68.3) 222.7 (65.3) 212.5 (62.3) 202.1 (59.2)

0 (-17.8) 228.9 (67.1) 219.2 (64.2) 209.7 (61.5) 200.5 (58.8) 191.3 (56.1) 182.0 (53.3)
30 (-1.1) 471.5 (138.2) 452.6 (132.6) 433.5 (127) 414.3 (121.4) 395.0 (115.8) 375.7 (1
25 (-3.9) 434.2 (127.3) 416.7 (122.1) 399.1 (117) 381.4 (111.8) 363.5 (106.5) 345.6 (101.3)
20 (-6.7) 397.7 (116.6) 381.6 (111.8) 365.4 (107.1) 349.0 (102.3) 332.5 (97.4) 316.0 (92.6)
15 (-9.4) 362.4 (106.2) 347.6 (101.9) 332.7 (97.5) 317.7 (93.1) 302.5 (88.7) 287.3 (84.2)
10 (-12.2) 328.8 (96.4) 315.3 (92.4) 301.7 (88.4) 287.9 (84.4) 274.0 (80.3) 260.1 (76.2)

5 (-15) 297.5 (87.2) 285.2 (83.6) 272.8 (79.9) 260.2 (76.3) 247.5 (72.5) 234.8 (68.8)

0 (-17.8) 269.1 (78.9) 257.9 (75.6) 246.5 (72.2) 235.0 (68.9) 223.5 (65.5) 212.0 (62.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(63.1) 206.1 (60.4) 197.0 (57.7) 187.9 (55.1) 178.8 (52.4) 169.8 (49.8)

R404A R507

AMBIENT TEMPERATURE °F (°C)

10.1)

COPELAND

04/17/13

K40-KV-PDS-17

- 7 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS015M8-A

Compressor

Model

3DS3R17ME

KVS025M8-A

Compressor

Model

4DHNR22ME

KVS030M8-A

Compressor

Model

4DJNR28ME

KVS035M8-A

Compressor

Model

6DHNR35ME

KVS040M8-A

Compressor

Model

6DJNR40ME

KVS050M8-A

Compressor

Model

6DUNR49ME

NOTE: The capacities shown above are rated at dew point.

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 151.2 (44.3) 146.3 (42.9) 141.5 (41.5) 136.7 (40.1) 131.9 (38.7) 127.1 (37.2)
25 (-3.9) 136.8 (40.1) 132.5 (38.8) 128.2 (37.6) 123.9 (36.3) 119.6 (35.1) 115.1 (33.7)
20 (-6.7) 123.3 (36.1) 119.5 (35) 115.7 (33.9) 111.8 (32.8) 107.8 (31.6) 103.6 (30.4)
15 (-9.4) 110.7 (32.4) 107.3 (31.4) 103.8 (30.4) 100.3 (29.4) 96.5 (28.3) 92.6 (27.1)
10 (-12.2) 99.0 (29) 95.9 (28.1) 92.7 (27.2) 89.4 (26.2) 85.8 (25.1) 81.9 (24)
30 (-1.1) 213.3 (62.5) 203.7 (59.7) 194.5 (57) 185.6 (54.4) 177.0 (51.9) 169.0 (49.5)
25 (-3.9) 191.9 (56.2) 183.7 (53.8) 175.7 (51.5) 168.0 (49.2) 160.7 (47.1) 153.8 (45.1)
20 (-6.7) 171.8 (50.3) 164.8 (48.3) 158.0 (46.3) 151.4 (44.4) 145.1 (42.5) 139.3 (40.8)
15 (-9.4) 153.2 (44.9) 147.2 (43.1) 141.3 (41.4) 135.7 (39.8) 130.3 (38.2) 125.2 (36.7)
10 (-12.2) 136.1 (39.9) 130.9 (38.4) 125.9 (36.9) 120.9 (35.4) 116.2 (34.1) 111.7 (32.7)
30 (-1.1) 247.7 (72.6) 237.1 (69.5) 226.8 (66.5) 217.0 (63.6) 207.5 (60.8) 198.4 (58.1)
25 (-3.9) 223.3 (65.4) 214.2 (62.8) 205.5 (60.2) 197.1 (57.8) 189.1 (55.4) 181.5 (53.2)
20 (-6.7) 200.6 (58.8) 193.0 (56.6) 185.6 (54.4) 178.6 (52.3) 171.9 (50.4) 165.5 (48.5)
15 (-9.4) 179.7 (52.7) 173.2 (50.8) 167.0 (48.9) 161.1 (47.2) 155.5 (45.6) 150.1 (44)
10 (-12.2) 160.4 (47) 154.9 (45.4) 149.7 (43.9) 144.6 (42.4) 139.8 (41) 135.2 (39.6)
30 (-1.1) 299.1 (87.7) 288.5 (84.6) 277.8 (81.4) 266.9 (78.2) 255.7 (74.9) 244.3 (71.6)
25 (-3.9) 269.2 (78.9) 260.1 (76.2) 250.8 (73.5) 241.2 (70.7) 231.4 (67.8) 221.3 (64.9)
20 (-6.7) 242.3 (71) 234.4 (68.7) 226.2 (66.3) 217.8 (63.8) 209.1 (61.3) 200.1 (58.6)
15 (-9.4) 217.9 (63.9) 210.9 (61.8) 203.8 (59.7) 196.3 (57.5) 188.5 (55.2) 180.3 (52.8)
10 (-12.2) 195.4 (57.3) 189.2 (55.4) 182.7 (53.5) 175.9 (51.6) 168.8 (49.5) 161.2 (47.2)
30 (-1.1) 374.6 (109.8) 355.5 (104.2) 335.4 (98.3) 314.3 (92.1) 292.5 (85.7) 270.3 (79.2)
25 (-3.9) 333.6 (97.8) 316.8 (92.8) 299.1 (87.7) 280.7 (82.3) 261.8 (76.7) 242.7 (71.1)
20 (-6.7) 298.2 (87.4) 283.4 (83.1) 268.0 (78.5) 252.2 (73.9) 236.2 (69.2) 220.3 (64.6)
15 (-9.4) 267.4 (78.4) 254.5 (74.6) 241.2 (70.7) 227.8 (66.8) 214.7 (62.9) 202.0 (59.2)
10 (-12.2) 239.8 (70.3) 228.6 (67) 217.4 (63.7) 206.4 (60.5) 196.1 (57.5) 186.6 (54.7)
30 (-1.1) 430.8 (126.3) 408.7 (119.8) 386.1 (113.2) 363.0 (106.4) 339.8 (99.6) 316.6 (92.8)
25 (-3.9) 384.5 (112.7) 364.6 (106.9) 344.3 (100.9) 323.9 (94.9) 303.5 (88.9) 283.4 (83.1)
20 (-6.7) 342.0 (100.2) 324.4 (95.1) 306.5 (89.8) 288.8 (84.6) 271.3 (79.5) 254.4 (74.6)
15 (-9.4) 303.6 (89) 288.1 (84.4) 272.8 (79.9) 257.8 (75.6) 243.4 (71.3) 229.9 (67.4)
10 (-12.2) 269.2 (78.9) 255.9 (75) 243.1 (71.2) 231.0 (67.7) 219.9 (64.4) 210.1 (61.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

The dew point is a saturation point and is the condition (pressure and temperature) at

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 8 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS010L6-A

Compressor

Model

3DS3F46KE

KVS015L6-A

Compressor

Model

4DHNF63KE

KVS022L6-A

Compressor

Model

4DJNF76KE

KVS027L6-A

Compressor

Model

6DHNF93KE

KVS030L6-A

Compressor

Model

6DJNF11ME

KVS040L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 89.1 (26.1) 85.6 (25.1) 82.1 (24.1) 78.6 (23) 75.1 (22) 71.7 (21)

-5 (-20.6) 80.6 (23.6) 77.4 (22.7) 74.2 (21.7) 71.1 (20.8) 68.0 (19.9) 64.9 (19)

-10 (-23.3) 72.5 (21.2) 69.7 (20.4) 66.8 (19.6) 64.0 (18.8) 61.1 (17.9) 58.3 (17.1)

-15 (-26.1) 64.9 (19) 62.3 (18.3) 59.8 (17.5) 57.2 (16.8) 54.6 (16) 52.1 (15.3)

-20 (-28.9) 57.7 (16.9) 55.4 (16.2) 53.1 (15.6) 50.8 (14.9) 48.4 (14.2) 46.1 (13.5)

-25 (-31.7) 50.9 (14.9) 48.9 (14.3) 46.8 (13.7) 44.7 (13.1) 42.6 (12.5) 40.5 (11.9)

-30 (-34.4) 44.7 (13.1) 42.9 (12.6) 41.0 (12) 39.1 (11.5) 37.1 (10.9) 35.2 (10.3)

-35 (-37.2) 39.0 (11.4) 37.3 (10.9) 35.6 (10.4) 33.8 (9.9) 32.0 (9.4) 30.2 (8.9)

-40 (-40) 33.7 (9.9) 32.2 (9.4) 30.6 (9) 28.9 (8.5) 27.2 (8) 25.5 (7.5)
0 (-17.8) 117.4 (34.4) 113.0 (33.1) 108.6 (31.8) 104.2 (30.5) 99.7 (29.2) 95.0 (27.8)

-5 (-20.6) 106.3 (31.2) 102.2 (30) 98.2 (28.8) 94.2 (27.6) 90.1 (26.4) 85.7 (25.1)

-10 (-23.3) 96.0 (28.1) 92.3 (27.1) 88.7 (26) 85.0 (24.9) 81.3 (23.8) 77.3 (22.7)

-15 (-26.1) 86.4 (25.3) 83.1 (24.4) 79.8 (23.4) 76.6 (22.4) 73.1 (21.4) 69.5 (20.4)

-20 (-28.9) 77.5 (22.7) 74.5 (21.8) 71.6 (21) 68.6 (20.1) 65.5 (19.2) 62.2 (18.2)

-25 (-31.7) 69.1 (20.3) 66.4 (19.5) 63.8 (18.7) 61.1 (17.9) 58.3 (17.1) 55.2 (16.2)

-30 (-34.4) 61.1 (17.9) 58.7 (17.2) 56.3 (16.5) 53.9 (15.8) 51.3 (15) 48.5 (14.2)

-35 (-37.2) 53.2 (15.6) 51.1 (15) 49.0 (14.4) 46.8 (13.7) 44.4 (13) 41.8 (12.3)

-40 (-40) 45.5 (13.3) 43.5 (12.7) 41.6 (12.2) 39.6 (11.6) 37.4 (11) 35.0 (10.3)
0 (-17.8) 144.1 (42.2) 137.7 (40.4) 131.6 (38.6) 125.8 (36.9) 120.3 (35.3) 115.1 (33.7)

-5 (-20.6) 131.0 (38.4) 125.2 (36.7) 119.6 (35.1) 114.3 (33.5) 109.2 (32) 104.3 (30.6)

-10 (-23.3) 118.6 (34.8) 113.3 (33.2) 108.2 (31.7) 103.3 (30.3) 98.6 (28.9) 94.1 (27.6)

-15 (-26.1) 106.8 (31.3) 102.0 (29.9) 97.4 (28.5) 92.9 (27.2) 88.5 (25.9) 84.2 (24.7)

-20 (-28.9) 95.6 (28) 91.3 (26.8) 87.1 (25.5) 82.9 (24.3) 78.8 (23.1) 74.8 (21.9)

-25 (-31.7) 84.9 (24.9) 81.0 (23.7) 77.2 (22.6) 73.3 (21.5) 69.5 (20.4) 65.7 (19.3)

-30 (-34.4) 74.6 (21.9) 71.2 (20.9) 67.6 (19.8) 64.1 (18.8) 60.4 (17.7) 56.7 (16.6)

-35 (-37.2) 64.8 (19) 61.7 (18.1) 58.4 (17.1) 55.1 (16.1) 51.6 (15.1) 48.0 (14.1)

-40 (-40) 55.3 (16.2) 52.5 (15.4) 49.4 (14.5) 46.3 (13.6) 42.9 (12.6) 39.3 (11.5)
0 (-17.8) 183.0 (53.6) 175.7 (51.5) 168.5 (49.4) 161.4 (47.3) 154.3 (45.2) 147.1 (43.1)

-5 (-20.6) 165.9 (48.6) 159.3 (46.7) 152.8 (44.8) 146.3 (42.9) 139.8 (41) 133.2 (39)

-10 (-23.3) 149.3 (43.8) 143.3 (42) 137.5 (40.3) 131.6 (38.6) 125.7 (36.8) 119.7 (35.1)

-15 (-26.1) 133.4 (39.1) 128.0 (37.5) 122.7 (36) 117.4 (34.4) 1

-20 (-28.9) 118.3 (34.7) 113.4 (33.2) 108.6 (31.8) 103.8 (30.4) 98.9 (29) 93.7 (27.5)

-25 (-31.7) 104.0 (30.5) 99.6 (29.2) 95.3 (27.9) 90.9 (26.6) 86.4 (25.3) 81.6 (23.9)

-30 (-34.4) 90.8 (26.6) 86.8 (25.4) 82.9 (24.3) 78.8 (23.1) 74.6 (21.9) 70.1 (20.5)

-35 (-37.2) 78.7 (23.1) 75.1 (22) 71.4 (20.9) 67.6 (19.8) 63.7 (18.7) 59.4 (17.4)

-40 (-40) 67.8 (19.9) 64.4 (18.9) 61.0 (17.9) 57.4 (16.8) 53.6 (15.7) 49.5 (14.5)
0 (-17.8) 200.8 (58.8) 192.0 (56.3) 183.3 (53.7) 174.7 (51.2) 166.4 (48.8) --- ---

-5 (-20.6) 181.9 (53.3) 173.9 (51) 166.1 (48.7) 158.3 (46.4) 150.8 (44.2) 143.4 (42)

-10 (-23.3) 163.8 (48) 156.7 (45.9) 149.6 (43.8) 142.6 (41.8) 135.8 (39.8) 129.1 (37.8)

-15 (-26.1) 146.7 (43) 140.3 (41.1) 134.0 (39.3) 127.7 (37.4) 121.5 (35.6) 115.4 (33.8)

-20 (-28.9) 130.6 (38.3) 124.9 (36.6) 119.1 (34.9) 113.4 (33.2) 107.8 (31.6) 102.3 (30)

-25 (-31.7) 115.5 (33.8) 110.3 (32.3) 105.1 (30.8) 99.9 (29.3) 94.8 (27.8) 89.7 (26.3)

-30 (-34.4) 101.4 (29.7) 96.7 (28.3) 92.0 (27) 87.2 (25.6) 82.4 (24.1) 77.7 (22.8)

-35 (-37.2) 88.3 (25.9) 84.0 (24.6) 79.7 (23.4) 75.2 (22) 70.7 (20.7) 66.2 (19.4)

-40 (-40) 76.3 (22.4) 72.3 (21.2) 68.2 (20) 63.9 (18.7) 59.6 (17.5) 55.2 (16.2)
0 (-17.8) 246.4 (72.2) 235.8 (69.1) 225.5 (66.1) 215.7 (63.2) 206.5 (60.5) - -

-5 (-20.6) 222.9 (65.3) 212.7 (62.3) 202.9 (59.5) 193.3 (56.7) 184.3 (54) 175.8 (51.5)

-10 (-23.3) 201.8 (59.1) 192.2 (56.3) 182.8 (53.6) 173.7 (50.9) 164.9 (48.3) 156.6 (45.9)

-15 (-26.1) 182.7 (53.5) 173.7 (50.9) 164.8 (48.3) 156.1 (45.7) 147.8 (43.3) 139.8 (41)

-20 (-28.9) 164.8 (48.3) 156.5 (45.9) 148.2 (43.4) 140.1 (41.1) 132.2 (38.7) 124.7 (36.5)

-25 (-31.7) 147.7 (43.3) 140.1 (41.1) 132.6 (38.9) 125.0 (36.6) 117.7 (34.5) 110.6 (32.4)

-30 (-34.4) 130.8 (38.3) 124.0 (36.3) 117.1 (34.3) 110.3 (32.3) 103.5 (30.3) 96.9 (28.4)

-35 (-37.2) 113.4 (33.2) 107.4 (31.5) 101.4 (29.7) 95.2 (27.9) 89.1 (26.1) 83.1 (24.4)

-40 (-40) 94.8 (27.8) 89.9 (26.3) 84.6 (24.8) 79.3 (23.2) 73.9 (21.7) 68.5 (20.1)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

12.0 (32.8) 106.5 (31.2)

--- Outside Operating Range

COPELAND

04/17/13

K40-KV-PDS-17

- 9 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD030H8-A

Compressor

Model

3DS3R17ME

KVD050H8-A

Compressor

Model

4DHNR22ME

KVD060H8-A

Compressor

Model

4DJNR28ME

KVD070H8-A

Compressor

Model

6DHNR35ME

KVD080H8-A

Compressor

Model

6DJNR40ME

--- Outside Operating Range
NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 471.4 (138.2) 453.8 (133) 436.8 (128) 420.2 (123.1) 404.2 (118.5) 388.4 (113.8)
50 (10) 434.4 (127.3) 418.6 (122.7) 403.4 (118.2) 388.4 (113.8) 373.8 (109.5) 359.6 (105.4)
45 (7.2) 399.0 (116.9) 384.8 (112.8) 371.2 (108.8) 357.8 (104.9) 344.6 (101) 331.8 (97.2)
40 (4.4) 365.2 (107) 352.6 (103.3) 340.4 (99.8) 328.4 (96.2) 316.6 (92.8) 305.0 (89.4)
35 (1.7) 332.8 (97.5) 321.8 (94.3) 310.8 (91.1) 300.2 (88) 289.6 (84.9) 279.0 (81.8)
55 (12.8) 668.2 (195.8) 634.0 (185.8) 600.6 (176) 567.6 (166.3) 535.6 (157) 504.4 (147.8)
50 (10) 617.6 (181) 586.6 (171.9) 556.0 (162.9) 526.2 (154.2) 497.4 (145.8) 469.4 (137.6)
45 (7.2) 567.6 (166.3) 539.6 (158.1) 512.2 (150.1) 485.6 (142.3) 459.8 (134.8) 435.2 (127.5)
40 (4.4) 518.8 (152) 494.0 (144.8) 469.6 (137.6) 446.0 (130.7) 423.4 (124.1) 401.8 (117.8)
35 (1.7) 471.6 (138.2) 449.8 (131.8) 428.4 (125.6) 407.8 (119.5) 388.2 (113.8) 369.4 (108.3)
55 (12.8) 787.2 (230.7) 748.4 (219.3) 709.8 (208) 672.0 (196.9) 634.8 (186) --- --­50 (10) 724.0 (212.2) 688.4 (201.7) 653.6 (191.6) 619.4 (181.5) 586.0 (171.7) 553.2 (162.1)
45 (7.2) 662.6 (194.2) 630.6 (184.8) 599.4 (175.7) 569.0 (166.8) 539.4 (158.1) 510.6 (149.6)
40 (4.4) 603.8 (177) 575.4 (168.6) 548.0 (160.6) 521.2 (152.7) 495.4 (145.2) 470.4 (137.9)
35 (1.7) 548.0 (160.6) 523.2 (153.3) 499.4 (146.4) 476.2 (139.6) 454.0 (133.1) 432.6 (126.8)
55 (12.8) 1005.4 (294.7) 965.4 (282.9) 925.2 (271.1) 884.8 (259.3) 844.2 (247.4) --- --­50 (10) 908.8 (266.3) 873.0 (255.9) 837.0 (245.3) 800.6 (234.6) 764.0 (223.9) 727.2 (213.1)
45 (7.2) 819.8 (240.3) 788.0 (230.9) 755.8 (221.5) 723.6 (212.1) 691.0 (202.5) 658.0 (192.8)
40 (4.4) 738.4 (216.4) 710.4 (208.2) 682.2 (199.9) 653.6 (191.6) 624.8 (183.1) 595.4 (174.5)
35 (1.7) 664.6 (194.8) 640.2 (187.6) 615.6 (180.4) 590.6 (173.1) 565.2 (165.6) 539.2 (158)
55 (12.8) 1355.4 (397.2) 1291.4 (378.5) 1224.2 (358.8) 1154.4 (338.3) 1081.8 (317) --- --­50 (10) 1211.4 (355) 1151.8 (337.6) 1089.6 (319.3) 1024.6 (300.3) 957.2 (280.5) 887.8 (260.2)
45 (7.2) 1075.8 (315.3) 1022.0 (299.5) 965.2 (282.9) 905.8 (265.5) 844.4 (247.5) 781.0 (228.9)
40 (4.4) 953.0 (279.3) 904.6 (265.1) 853.6 (250.2) 800.0 (234.5) 744.6 (218.2) 687.6 (201.5)
35 (1.7) 844.0 (247.4) 801.0 (234.7) 755.4 (221.4) 707.8 (207.4) 658.4 (193) 607.6 (178.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

CONDENSING

UNIT

MODEL

KVD030H8-A

Compressor

3DS3R17ME

KVD050H8-A

Compressor

4DHNR22ME

KVD060H8-A

Compressor

4DJNR28ME

KVD070H8-A

Compressor

6DHNR35ME

KVD080H8-A

Compressor

6DJNR40ME

TEMPERATURE

CAPACITY DATA -

R404A

R507

60HzKVD-A

HIGH TEMPERATURE

SATURATED

SUCTION

° F ° C
45 (7.2) 442.0 (129.5) 422.8 (123.9) 404.0 (118.4) 385.2 (112.9) 366.8 (107.5) 348.6 (102.2)
40 (4.4) 407.8 (119.5) 390.4 (114.4) 373.0 (109.3) 356.0 (104.3) 339.0 (99.4) 322.4 (94.5)
35 (1.7) 375.4 (110) 359.4 (105.3) 343.6 (100.7) 328.0 (96.1) 312.4 (91.6) 297.2 (87.1)
45 (7.2) 572.6 (167.8) 548.2 (160.7) 524.4 (153.7) 501.2 (146.9) 478.4 (140.2) 456.2 (133.7)
40 (4.4) 535.0 (156.8) 512.0 (150.1) 489.8 (143.5) 468.0 (137.2) 446.8 (130.9) 426.0 (124.8)
35 (1.7) 497.0 (145.7) 475.6 (139.4) 454.8 (133.3) 434.6 (127.4) 414.8 (121.6) 395.2 (115.8)
45 (7.2) 697.8 (204.5) 667.6 (195.7) 637.6 (186.9) 607.8 (178.1) 577.8 (169.3) 548.0 (160.6)
40 (4.4) 646.4 (189.4) 618.4 (181.2) 590.6 (173.1) 562.8 (164.9) 535.2 (156.9) 507.4 (148.7)
35 (1.7) 596.8 (174.9) 570.8 (167.3) 545.0 (159.7) 519.4 (152.2) 493.8 (144.7) 468.2 (137.2)
45 (7.2) 896.2 (262.6) 857.8 (251.4) 819.2 (240.1) 780.6 (228.8) 741.8 (217.4) 702.8 (206)
40 (4.4) 826.8 (242.3) 791.4 (231.9) 755.8 (221.5) 720.4 (211.1) 684.8 (200.7) 649.0 (190.2)
35 (1.7) 760.4 (222.9) 728.0 (213.4) 695.4 (203.8) 663.0 (194.3) 630.2 (184.7) 597.6 (175.1)
45 (7.2) 1022.4 (299.6) 980.6 (287.4) 938.6 (275.1) 896.4 (262.7) 854.0 (250.3) 810.8 (237.6)
40 (4.4) 949.2 (278.2) 910.4 (266.8) 871.6 (255.4) 832.4 (244) 793.0 (232.4) 753.0 (220.7)
35 (1.7) 878.0 (257.3) 842.2 (246.8) 806.4 (236.3) 770.4 (225.8) 734.0 (215.1) 697.2 (204.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

COPELAND

04/17/13

K40-KV-PDS-17

- 10 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD030M8-A

Compressor

Model

3DS3R17ME

KVD050M8-A

Compressor

Model

4DHNR22ME

KVD060M8-A

Compressor

Model

4DJNR28ME

KVD070M8-A

Compressor

Model

6DHNR35ME

KVD080M8-A

Compressor

Model

6DJNR40ME

KVD100M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 344.2 (100.9) 329.8 (96.7) 315.4 (92.4) 301.2 (88.3) 287.2 (84.2) 273.4 (80.1)
25 (-3.9) 314.8 (92.3) 301.6 (88.4) 288.6 (84.6) 275.8 (80.8) 263.2 (77.1) 250.8 (73.5)
20 (-6.7) 286.8 (84.1) 275.0 (80.6) 263.4 (77.2) 251.8 (73.8) 240.4 (70.5) 229.2 (67.2)
15 (-9.4) 260.6 (76.4) 250.0 (73.3) 239.4 (70.2) 229.2 (67.2) 219.0 (64.2) 208.8 (61.2)
10 (-12.2) 235.8 (69.1) 226.4 (66.4) 217.0 (63.6) 207.8 (60.9) 198.6 (58.2) 189.6 (55.6)

5 (-15) 212.6 (62.3) 204.2 (59.8) 196.0 (57.4) 187.6 (55) 179.6 (52.6) 171.6 (50.3)

0 (-17.8) 191.2 (56) 183.6 (53.8) 176.2 (51.6) 168.8 (49.5) 161.6 (47.4) 154.4 (45.3)
30 (-1.1) 459.2 (134.6) 439.4 (128.8) 420.0 (123.1) 401.2 (117.6) 382.6 (112.1) 364.6 (106.9)
25 (-3.9) 421.8 (123.6) 403.4 (118.2) 385.6 (113) 368.0 (107.8) 351.0 (102.9) 334.2 (97.9)
20 (-6.7) 385.0 (112.8) 368.2 (107.9) 351.8 (103.1) 335.8 (98.4) 320.0 (93.8) 304.6 (89.3)
15 (-9.4) 349.6 (102.5) 334.2 (97.9) 319.2 (93.5) 304.6 (89.3) 290.2 (85) 276.0 (80.9)
10 (-12.2) 315.6 (92.5) 301.6 (88.4) 288.2 (84.5) 274.8 (80.5) 261.8 (76.7) 248.8 (72.9)

5 (-15) 283.6 (83.1) 271.2 (79.5) 259.0 (75.9) 247.2 (72.4) 235.4 (69) 223.8 (65.6)

0 (-17.8) 254.2 (74.5) 243.2 (71.3) 232.4 (68.1) 221.8 (65) 211.4 (62) 201.0 (58.9)
30 (-1.1) 548.8 (160.8) 524.8 (153.8) 501.2 (146.9) 477.6 (140) 454.2 (133.1) 430.6 (126.2)
25 (-3.9) 502.6 (147.3) 480.6 (140.8) 459.0 (134.5) 437.4 (128.2) 416.0 (121.9) 394.6 (115.6)
20 (-6.7) 458.4 (134.3) 438.4 (128.5) 418.6 (122.7) 399.0 (116.9) 379.6 (111.2) 360.2 (105.6)
15 (-9.4) 416.2 (122) 398.0 (116.6) 380.2 (111.4) 362.6 (106.3) 345.0 (101.1) 327.4 (96)
10 (-12.2) 376.0 (110.2) 359.8 (105.4) 343.6 (100.7) 327.8 (96.1) 312.0 (91.4) 296.4 (86.9)

5 (-15) 338.2 (99.1) 323.6 (94.8) 309.2 (90.6) 295.2 (86.5) 281.2 (82.4) 267.2 (78.3)

0 (-17.8) 302.6 (88.7) 289.6 (84.9) 276.8 (81.1) 264.4 (77.5) 252.2 (73.9) 239.8 (70.3)
30 (-1.1) 697.2 (204.3) 667.6 (195.7) 638.0 (187) 608.2 (178.2) 578.4 (169.5) 548.6 (160.8)
25 (-3.9) 637.2 (186.7) 610.2 (178.8) 583.2 (170.9) 556.4 (163.1) 529.2 (155.1) 502.2 (147.2)
20 (-6.7) 580.4 (170.1) 556.0 (162.9) 531.6 (155.8) 507.2 (148.6) 482.6 (141.4) 458.0 (134.2)
15 (-9.4) 527.0 (154.4) 505.0 (148) 482.8 (141.5) 460.6 (135) 438.6 (128.5) 416.4 (122)
10 (-12.2) 477.0 (139.8) 457.0 (133.9) 437.0 (128.1) 417.0 (122.2) 397.0 (116.3) 376.8 (110.4)

5 (-15) 430.4

0 (-17.8) 387.2 (113.5) 370.4 (108.6) 353.8 (103.7) 337.2 (98.8) 320.8 (94) 304.4 (89.2)
30 (-1.1) 809.4 (237.2) 776.2 (227.5) 743.2 (217.8) 710.2 (208.1) 676.8 (198.3) 643.0 (188.4)
25 (-3.9) 743.2 (217.8) 712.8 (208.9) 682.4 (200) 652.2 (191.1) 621.6 (182.2) 590.6 (173.1)
20 (-6.7) 679.8 (199.2) 652.0 (191.1) 624.2 (182.9) 596.6 (174.8) 568.8 (166.7) 540.6 (158.4)
15 (-9.4) 619.4 (181.5) 593.8 (174) 568.6 (166.6) 543.4 (159.3) 518.2 (151.9) 492.8 (144.4)
10 (-12.2) 562.2 (164.8) 538.8 (157.9) 515.8 (151.2) 493.0 (144.5) 470.2 (137.8) 447.2 (131.1)

5 (-15) 508.2 (148.9) 487.0 (142.7) 466.0 (136.6) 445.4 (130.5) 425.0 (124.6) 404.2 (1

0 (-17.8) 457.8 (134.2) 438.4 (128.5) 419.4 (122.9) 401.0 (117.5) 382.6 (112.1) 364.0 (106.7)
30 (-1.1) 943.0 (276.4) 905.2 (265.3) 867.0 (254.1) 828.6 (242.8) 790.0 (231.5) 751.4 (220.2)
25 (-3.9) 868.4 (254.5) 833.4 (244.2) 798.2 (233.9) 762.8 (223.6) 727.0 (213.1) 691.2 (202.6)
20 (-6.7) 795.4 (233.1) 763.2 (223.7) 730.8 (214.2) 698.0 (204.6) 665.0 (194.9) 632.0 (185.2)
15 (-9.4) 724.8 (212.4) 695.2 (203.7) 665.4 (195) 635.4 (186.2) 605.0 (177.3) 574.6 (168.4)
10 (-12.2) 657.6 (192.7) 630.6 (184.8) 603.4 (176.8) 575.8 (168.7) 548.0 (160.6) 520.2 (152.5)

5 (-15) 595.0 (174.4) 570.4 (167.2) 545.6 (159.9) 520.4 (152.5) 495.0 (145.1) 469.6 (137.6)

0 (-17.8) 538.2 (157.7) 515.8 (151.2) 493.0 (144.5) 470.0 (137.7) 447.0 (131) 424.0 (124.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(126.1) 412.2 (120.8) 394.0 (115.5) 375.8 (110.1) 357.6 (104.8) 339.6 (99.5)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

18.5)

COPELAND

04/17/13

K40-KV-PDS-17

- 11 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD030M8-A

Compressor

Model

3DS3R17ME

KVD050M8-A

Compressor

Model

4DHNR22ME

KVD060M8-A

Compressor

Model

4DJNR28ME

KVD070M8-A

Compressor

Model

6DHNR35ME

KVD080M8-A

Compressor

Model

6DJNR40ME

KVD100M8-A

Compressor

Model

6DUNR49ME

NOTE: The capacities shown above are rated at dew point.

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 302.4 (88.6) 292.6 (85.8) 283.0 (82.9) 273.4 (80.1) 263.8 (77.3) 254.2 (74.5)
25 (-3.9) 273.6 (80.2) 265.0 (77.7) 256.4 (75.1) 247.8 (72.6) 239.2 (70.1) 230.2 (67.5)
20 (-6.7) 246.6 (72.3) 239.0 (70) 231.4 (67.8) 223.6 (65.5) 215.6 (63.2) 207.2 (60.7)
15 (-9.4) 221.4 (64.9) 214.6 (62.9) 207.6 (60.8) 200.6 (58.8) 193.0 (56.6) 185.2 (54.3)
10 (-12.2) 198.0 (58) 191.8 (56.2) 185.4 (54.3) 178.8 (52.4) 171.6 (50.3) 163.8 (48)
30 (-1.1) 426.6 (125) 407.4 (119.4) 389.0 (114) 371.2 (108.8) 354.0 (103.7) 338.0 (99.1)
25 (-3.9) 383.8 (112.5) 367.4 (107.7) 351.4 (103) 336.0 (98.5) 321.4 (94.2) 307.6 (90.1)
20 (-6.7) 343.6 (100.7) 329.6 (96.6) 316.0 (92.6) 302.8 (88.7) 290.2 (85) 278.6 (81.6)
15 (-9.4) 306.4 (89.8) 294.4 (86.3) 282.6 (82.8) 271.4 (79.5) 260.6 (76.4) 250.4 (73.4)
10 (-12.2) 272.2 (79.8) 261.8 (76.7) 251.8 (73.8) 241.8 (70.9) 232.4 (68.1) 223.4 (65.5)
30 (-1.1) 495.4 (145.2) 474.2 (139) 453.6 (132.9) 434.0 (127.2) 415.0 (121.6) 396.8 (116.3)
25 (-3.9) 446.6 (130.9) 428.4 (125.6) 411.0 (120.5) 394.2 (115.5) 378.2 (110.8) 363.0 (106.4)
20 (-6.7) 401.2 (117.6) 386.0 (113.1) 371.2 (108.8) 357.2 (104.7) 343.8 (100.8) 331.0 (97)
15 (-9.4) 359.4 (105.3) 346.4 (101.5) 334.0 (97.9) 322.2 (94.4) 311.0 (91.1) 300.2 (88)
10 (-12.2) 320.8 (94) 309.8 (90.8) 299.4 (87.7) 289.2 (84.8) 279.6 (81.9) 270.4 (79.2)
30 (-1.1) 598.2 (175.3) 577.0 (169.1) 555.6 (162.8) 533.8 (156.4) 511.4 (149.9) 488.6 (143.2)
25 (-3.9) 538.4 (157.8) 520.2 (152.5) 501.6 (147) 482.4 (141.4) 462.8 (135.6) 442.6 (129.7)
20 (-6.7) 484.6 (142) 468.8 (137.4) 452.4 (132.6) 435.6 (127.7) 418.2 (122.6) 400.2 (117.3)
15 (-9.4) 435.8 (127.7) 421.8 (123.6) 407.6 (119.5) 392.6 (115.1) 377.0 (110.5) 360.6 (105.7)
10 (-12.2) 390.8 (114.5) 378.4 (110.9) 365.4 (107.1) 351.8 (103.1) 337.6 (98.9) 322.4 (94.5)
30 (-1.1) 749.2 (219.6) 711.0 (208.4) 670.8 (196.6) 628.6 (184.2) 585.0 (171.4) 540.6 (158.4)
25 (-3.9) 667.2 (195.5) 633.6 (185.7) 598.2 (175.3) 561.4 (164.5) 523.6 (153.5) 485.4 (142.3)
20 (-6.7) 596.4 (174.8) 566.8 (166.1) 536.0 (157.1) 504.4 (147.8) 472.4 (138.4) 440.6 (129.1)
15 (-9.4) 534.8 (156.7) 509.0 (149.2) 482.4 (141.4) 455.6 (133.5) 429.4 (125.8) 404.0 (118.4)
10 (-12.2) 479.6 (140.6) 457.2 (134) 434.8 (127.4) 412.8 (121) 392.2 (114.9) 373.2 (109.4)
30 (-1.1) 861.6 (252.5) 817.4 (239.6) 772.2 (226.3) 726.0 (212.8) 679.6 (199.2) 633.2 (185.6)
25 (-3.9) 769.0 (225.4) 729.2 (213.7) 688.6 (201.8) 647.8 (189.9) 607.0 (177.9) 566.8 (166.1)
20 (-6.7) 684.0 (200.5) 648.8 (190.1) 613.0 (179.7) 577.6 (169.3) 542.6 (159) 508.8 (149.1)
15 (-9.4) 607.2 (178) 576.2 (168.9) 545.6 (159.9) 515.6 (151.1) 486.8 (142.7) 459.8 (134.8)
10 (-12.2) 538.4 (157.8) 511.8 (150) 486.2 (142.5) 462.0 (135.4) 439.8 (128.9) 420.2 (123.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

The dew point is a saturation point and is the condition (pressure and temperature) at

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 12 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD020L6-A

Compressor

Model

3DS3F46KE

KVD030L6-A

Compressor

Model

4DL3F63KE

KVD044L6-A

Compressor

Model

4DT3F76KE

KVD054L6-A

Compressor

Model

6DL3F93KE

KVD060L6-A

Compressor

Model

6DT3F11ME

KVD080L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 178.2 (52.2) 171.2 (50.2) 164.2 (48.1) 157.2 (46.1) 150.2 (44) 143.4 (42)

-5 (-20.6) 161.2 (47.2) 154.8 (45.4) 148.4 (43.5) 142.2 (41.7) 136.0 (39.9) 129.8 (38)

-10 (-23.3) 145.0 (42.5) 139.4 (40.9) 133.6 (39.2) 128.0 (37.5) 122.2 (35.8) 116.6 (34.2)

-15 (-26.1) 129.8 (38) 124.6 (36.5) 119.6 (35.1) 114.4 (33.5) 109.2 (32) 104.2 (30.5)

-20 (-28.9) 115.4 (33.8) 110.8 (32.5) 106.2 (31.1) 101.6 (29.8) 96.8 (28.4) 92.2 (27)

-25 (-31.7) 101.8 (29.8) 97.8 (28.7) 93.6 (27.4) 89.4 (26.2) 85.2 (25) 81.0 (23.7)

-30 (-34.4) 89.4 (26.2) 85.8 (25.1) 82.0 (24) 78.2 (22.9) 74.2 (21.7) 70.4 (20.6)

-35 (-37.2) 78.0 (22.9) 74.6 (21.9) 71.2 (20.9) 67.6 (19.8) 64.0 (18.8) 60.4 (17.7)

-40 (-40) 67.4 (19.8) 64.4 (18.9) 61.2 (17.9) 57.8 (16.9) 54.4 (15.9) 51.0 (14.9)
0 (-17.8) 234.8 (68.8) 226.0 (66.2) 217.2 (63.7) 208.4 (61.1) 199.4 (58.4) 190.0 (55.7)

-5 (-20.6) 212.6 (62.3) 204.4 (59.9) 196.4 (57.6) 188.4 (55.2) 180.2 (52.8) 171.4 (50.2)

-10 (-23.3) 192.0 (56.3) 184.6 (54.1) 177.4 (52) 170.0 (49.8) 162.6 (47.7) 154.6 (45.3)

-15 (-26.1) 172.8 (50.6) 166.2 (48.7) 159.6 (46.8) 153.2 (44.9) 146.2 (42.8) 139.0 (40.7)

-20 (-28.9) 155.0 (45.4) 149.0 (43.7) 143.2 (42) 137.2 (40.2) 131.0 (38.4) 124.4 (36.5)

-25 (-31.7) 138.2 (40.5) 132.8 (38.9) 127.6 (37.4) 122.2 (35.8) 116.6 (34.2) 110.4 (32.4)

-30 (-34.4) 122.2 (35.8) 117.4 (34.4) 112.6 (33) 107.8 (31.6) 102.6 (30.1) 97.0 (28.4)

-35 (-37.2) 106.4 (31.2) 102.2 (30) 98.0 (28.7) 93.6 (27.4) 88.8 (26) 83.6 (24.5)

-40 (-40) 91.0 (26.7) 87.0 (25.5) 83.2 (24.4) 79.2 (23.2) 74.8 (21.9) 70.0 (20.5)
0 (-17.8) 288.2 (84.5) 275.4 (80.7) 263.2 (77.1) 251.6 (73.7) 240.6 (70.5) 230.2 (67.5)

-5 (-20.6) 262.0 (76.8) 250.4 (73.4) 239.2 (70.1) 228.6 (67) 218.4 (64) 208.6 (61.1)

-10 (-23.3) 237.2 (69.5) 226.6 (66.4) 216.4 (63.4) 206.6 (60.5) 197.2 (57.8) 188.2 (55.2)

-15 (-26.1) 213.6 (62.6) 204.0 (59.8) 194.8 (57.1) 185.8 (54.5) 177.0 (51.9) 168.4 (49.4)

-20 (-28.9) 191.2 (56) 182.6 (53.5) 174.2 (51.1) 165.8 (48.6) 157.6 (46.2) 149.6 (43.8)

-25 (-31.7) 169.8 (49.8) 162.0 (47.5) 154.4 (45.3) 146.6 (43) 139.0 (40.7) 131.4 (38.5)

-30 (-34.4) 149.2 (43.7) 142.4 (41.7) 135.2 (39.6) 128.2 (37.6) 120.8 (35.4) 113.4 (33.2)

-35 (-37.2) 129.6 (38) 123.4 (36.2) 116.8 (34.2) 110.2 (32.3) 103.2 (30.2) 96.0 (28.1)

-40 (-40) 110.6 (32.4) 105.0 (30.8) 98.8 (29) 92.6 (27.1) 85.8 (25.1) 78.6 (23)
0 (-17.8) 366.0 (107.3) 351.4 (103) 337.0 (98.8) 322.8 (94.6) 308.6 (90.4) 294.2 (86.2)

-5 (-20.6) 331.8 (97.2) 318.6 (93.4) 305.6 (89.6) 292.6 (85.8) 279.6 (81.9) 266.4 (78.1)

-10 (-23.3) 298.6 (87.5) 286.6 (84) 275.0 (80.6) 263.2 (77.1) 251.4 (73.7) 239.4 (70.2)

-15 (-26.1) 266.8 (78.2) 256.0 (75) 245.4 (71.9) 234.8 (68.8) 224.0 (65.6) 213.0 (62.4)

-20 (-28.9) 236.6 (69.3) 226.8 (66.5) 217.2 (63.7) 207.6 (60.8) 197.8 (58) 187.4 (54.9)

-25 (-31.7) 208.0 (61) 199.2 (58.4) 190.6 (55.9) 181.8 (53.3) 172.8 (50.6) 163.2 (47.8)

-30 (-34.4) 181.6 (53.2) 173.6 (50.9) 165.8 (48.6) 157.6 (46.2) 149.2 (43.7) 140.2 (41.1)

-35 (-37.2) 157.4 (46.1) 150.2 (44) 142.8 (41.9) 135.2 (39.6) 127.4 (37.3) 118.8 (34.8)

-40 (-40) 135.6 (39.7) 128.8 (37.7) 122.0 (35.8) 114.8 (33.6) 107.2 (31.4) 99.0 (29)
0 (-17.8) 401.6 (1

-5 (-20.6) 363.8 (106.6) 347.8 (101.9) 332.2 (97.4) 316.6 (92.8) 301.6 (88.4) 286.8 (84.1)

-10 (-23.3) 327.6 (96) 313.4 (91.8) 299.2 (87.7) 285.2 (83.6) 271.6 (79.6) 258.2 (75.7)

-15 (-26.1) 293.4 (86) 280.6 (82.2) 268.0 (78.5) 255.4 (74.9) 243.0 (71.2) 230.8 (67.6)

-20 (-28.9) 261.2 (76.5) 249.8 (73.2) 238.2 (69.8) 226.8 (66.5) 215.6 (63.2) 204.6 (60)

-25 (-31.7) 231.0 (67.7) 220.6 (64.7) 210.2 (61.6) 199.8 (58.6) 189.6 (55.6) 179.4 (52.6)

-30 (-34.4) 202.8 (59.4) 193.4 (56.7) 184.0 (53.9) 174.4 (51.1) 164.8 (48.3) 155.4 (45.5)

-35 (-37.2) 176.6 (51.8) 168.0 (49.2) 159.4 (46.7) 150.4 (44.1) 141.4 (41.4) 132.4 (38.8)

-40 (-40) 152.6 (44.7) 144.6 (42.4) 136.4 (40) 127.8 (37.5) 119.2 (34.9) 110.4 (32.4)
0 (-17.8) 492.8 (144.4) 471.6 (138.2) 451.0 (132.2) 431.4 (126.4) 413.0 (121) --- ---

-5 (-20.6) 445.8 (130.7) 425.4 (124.7) 405.8 (118.9) 386.6 (113.3) 368.6 (108) 351.6 (103)

-10 (-23.3) 403.6 (118.3) 384.4 (112.7) 365.6 (107.1) 347.4 (101.8) 329.8 (96.7) 313.2 (91.8)

-15 (-26.1) 365.4 (107.1) 347.4 (101.8) 329.6 (96.6) 312.2 (91.5) 295.6 (86.6) 279.6 (81.9)

-20 (-28.9) 329.6 (96.6) 313.0 (91.7) 296.4 (86.9) 280.2 (82.1) 264.4 (77.5) 249.4 (73.1)

-25 (-31.7) 295.4 (86.6) 280.2 (82.1) 265.2 (77.7) 250.0 (73.3) 235.4 (69) 221.2 (64.8)

-30 (-34.4) 261.6 (76.7) 248.0 (72.7) 234.2 (68.6) 220.6 (64.7) 207.0 (60.7) 193.8 (56.8)

-35 (-37.2) 226.8 (66.5) 214.8 (63) 202.8 (59.4) 190.4 (55.8) 178.2 (52.2) 166.2 (48.7)

-40 (-40) 189.6 (55.6) 179.8 (52.7) 169.2 (49.6) 158.6 (46.5) 147.8 (43.3) 137.0 (40.2)

CAPACITY MBH (KW)

17.7) 384.0 (112.5) 366.6 (107.4) 349.4 (102.4) 332.8 (97.5) --- ---

R404A

R507

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 13 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS015H8-B

Compressor

Model

4C2067SH

KVS020H8-B

Compressor

Model

4C2397SH

KVS025H8-B

Compressor

Model

4B3139PH

KVS030H8-B

Compressor

Model

4B3604PH

KVS035H8-B

Compressor

Model

6B4709PH

KVS040H8-B

Compressor

Model

6B5406PH

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C
55 (12.8) 225.1 (66) 216.5 (63.4) 208.0 (61) 199.5 (58.5) 191.2 (56) 182.9 (53.6)
50 (10) 206.4 (60.5) 198.5 (58.2) 190.6 (55.9) 182.8 (53.6) 175.1 (51.3) 167.5 (49.1)
45 (7.2) 188.7 (55.3) 181.3 (53.1) 174.1 (51) 166.9 (48.9) 159.8 (46.8) 152.9 (44.8)
40 (4.4) 171.8 (50.3) 165.1 (48.4) 158.4 (46.4) 151.9 (44.5) 145.4 (42.6) 139.0 (40.7)
35 (1.7) 155.9 (45.7) 149.7 (43.9) 143.7 (42.1) 137.7 (40.4) 131.8 (38.6) 126.0 (36.9)
55 (12.8) 264.5 (77.5) 254.5 (74.6) 244.6 (71.7) 234.6 (68.8) 224.8 (65.9) 215.0 (63)
50 (10) 242.4 (71) 233.1 (68.3) 223.9 (65.6) 214.7 (62.9) 205.6 (60.3) 196.6 (57.6)
45 (7.2) 221.3 (64.9) 212.8 (62.4) 204.3 (59.9) 195.9 (57.4) 187.5 (55) 179.3 (52.5)
40 (4.4) 201.4 (59) 193.5 (56.7) 185.8 (54.5) 178.0 (52.2) 170.4 (49.9) 162.9 (47.7)
35 (1.7) 182.6 (53.5) 175.4 (51.4) 168.3 (49.3) 161.3 (47.3) 154.3 (45.2) 147.4 (43.2)
55 (12.8) 323.6 (94.8) 312.0 (91.4) 300.5 (88.1) 288.9 (84.7) 277.4 (81.3) 265.8 (77.9)
50 (10) 297.7 (87.2) 286.9 (84.1) 276.1 (80.9) 265.4 (77.8) 254.7 (74.6) 244.0 (71.5)
45 (7.2) 272.8 (79.9) 262.8 (77) 252.9 (74.1) 242.9 (71.2) 233.0 (68.3) 223.1 (65.4)
40 (4.4) 249.1 (73) 239.9 (70.3) 230.7 (67.6) 221.5 (64.9) 212.4 (62.2) 203.3 (59.6)
35 (1.7) 226.7 (66.4) 218.2 (63.9) 209.7 (61.5) 201.3 (59) 192.9 (56.5) 184.6 (54.1)
55 (12.8) 370.1 (108.5) 356.2 (104.4) 342.2 (100.3) 328.2 (96.2) 314.1 (92.1) 300.0 (87.9)
50 (10) 340.1 (99.7) 327.2 (95.9) 314.2 (92.1) 301.2 (88.3) 288.1 (84.4) 275.0 (80.6)
45 (7.2) 311.5 (91.3) 299.5 (87.8) 287.5 (84.3) 275.4 (80.7) 263.2 (77.1) 251.1 (73.6)
40 (4.4) 284.1 (83.3) 273.1 (80) 262.0 (76.8) 250.9 (73.5) 239.7 (70.2) 228.5 (67)
35 (1.7) 258.2 (75.7) 248.1 (72.7) 237.9 (69.7) 227.7 (66.7) 217.4 (63.7) 207.2 (60.7)
55 (12.8) 486.1 (142.5) 468.6 (137.3) 451.2 (132.2) 433.8 (127.1) 416.3 (122) 398.9 (116.9)
50 (10) 447.1 (131) 430.9 (126.3) 414.6 (121.5) 398.4 (116.8) 382.2 (112) 366.1 (107.3)
45 (7.2) 409.7 (120.1) 394.7 (115.7) 379.6 (111.2) 364.6 (106.9) 349.7 (102.5) 334.7 (98.1)
40 (4.4) 374.1 (109.6) 360.2 (105.6) 346.4 (101.5) 332.5 (97.4) 318.8 (93.4) 305.0 (89.4)
35 (1.7) 340.3 (99.7) 327.5 (96) 314.8 (92.3) 302.2 (88.6) 289.5 (84.8) 276.9 (81.2)
55 (12.8) 557.9 (163.5) 537.0 (157.4) 516.0 (151.2) 494.9 (145) 473.7 (138.8) 452.4 (132.6)
50 (10) 512.5 (150.2) 493.1 (144.5) 473.5 (138.8) 453.9 (133) 434.2 (127.3) 414.5 (121.5)
45 (7.2) 469.1 (137.5) 451.1 (132.2) 433.0 (126.9) 414.9 (121.6) 396.6 (116.2) 378.4 (110.9)
40 (4.4) 427.8 (125.4) 411.2 (120.5) 394.5 (1
35 (1.7) 388.7 (113.9) 373.5 (109.5) 358.2 (105) 342.8 (100.5) 327.4 (96) 312.0 (91.4)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

15.6) 377.8 (110.7) 361.0 (105.8) 344.2 (100.9)

BITZER

CONDENSING

UNIT

MODEL

KVS015H8-B

Compressor

4C2067SH

KVS020H8-B

Compressor

4C2397SH

KVS025H8-B

Compressor

4B3139PH

KVS030H8-B

Compressor

4B3604PH

KVS035H8-B

Compressor

6B4709PH

KVS040H8-B

Compressor

6B5406PH

CAPACITY DATA -

R404A

R507

60HzKVS-B

HIGH TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C
45 (7.2) 215.4 (63.1) 205.9 (60.3) 196.5 (57.6) 187.0 (54.8) 177.5 (52) 167.9 (49.2)
40 (4.4) 198.7 (58.2) 189.9 (55.7) 181.1 (53.1) 172.3 (50.5) 163.5 (47.9) 154.6 (45.3)
35 (1.7) 182.6 (53.5) 174.5 (51.1) 166.4 (48.8) 158.3 (46.4) 150.1 (44) 141.9 (41.6)
45 (7.2) 253.9 (74.4) 243.3 (71.3) 232.7 (68.2) 222.1 (65.1) 211.6 (62) 201.0 (58.9)
40 (4.4) 233.7 (68.5) 223.8 (65.6) 213.9 (62.7) 204.1 (59.8) 194.2 (56.9) 184.3 (54)
35 (1.7) 214.4 (62.8) 205.2 (60.1) 196.0 (57.4) 186.8 (54.7) 177.7 (52.1) 168.5 (49.4)
45 (7.2) 306.4 (89.8) 293.8 (86.1) 281.4 (82.5) 269.0 (78.8) 256.8 (75.3) 244.6 (71.7)
40 (4.4) 283.3 (83) 271.6 (79.6) 260.1 (76.2) 248.6 (72.9) 237.2 (69.5) 225.8 (66.2)
35 (1.7) 261.1 (76.5) 250.3 (73.4) 239.6 (70.2) 228.9 (67.1) 218.3 (64) 207.8 (60.9)
45 (7.2) 352.7 (103.4) 338.3 (99.1) 323.9 (94.9) 309.6 (90.7) 295.3 (86.5) 281.1 (82.4)
40 (4.4) 326.3 (95.6) 312.9 (91.7) 299.6 (87.8) 286.3 (83.9) 273.0 (80) 259.8 (76.1)
35 (1.7) 300.9 (88.2) 288.6 (84.6) 276.2 (80.9) 263.9 (77.3) 251.6 (73.7) 239.3 (70.1)
45 (7.2) 459.8 (134.8) 441.0 (129.2) 422.2 (123.7) 403.6 (118.3) 385.2 (112.9) 366.8 (107.5)
40 (4.4) 425.2 (124.6) 407.6 (119.5) 390.2 (114.4) 372.8 (109.3) 355.7 (104.2) 338.6 (99.2)
35 (1.7) 391.9 (114.9) 375.6 (110.1) 359.4 (105.3) 343.3 (100.6) 327.4 (96) 311.6 (91.3)
45 (7.2) 529.6 (155.2) 507.9 (148.9) 486.2 (142.5) 464.6 (136.2) 443.1 (129.9) 421.6 (123.6)
40 (4.4) 490.1 (143.6) 469.9 (137.7) 449.7 (131.8) 429.6 (125.9) 409.6 (120) 389.7 (114.2)
35 (1.7) 452.1 (132.5) 433.3 (127) 414.7 (121.5) 396.1 (116.1) 377.6 (110.7) 359.1 (105.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 14 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS015M8-B

Compressor

Model

4C2067SH

KVS020M8-B

Compressor

Model

4C2397SH

KVS025M8-B

Compressor

Model

4B3139PH

KVS030M8-B

Compressor

Model

4B3604PH

KVS035M8-B

Compressor

Model

6B4709PH

KVS040M8-B

Compressor

Model

6B5406PH

KVS050M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 167.3 (49) 159.8 (46.8) 152.3 (44.6) 144.8 (42.4) 137.3 (40.2) 129.7 (38)
25 (-3.9) 152.6 (44.7) 145.8 (42.7) 138.9 (40.7) 132.0 (38.7) 125.1 (36.7) 118.1 (34.6)
20 (-6.7) 138.6 (40.6) 132.4 (38.8) 126.1 (37) 119.8 (35.1) 113.5 (33.3) 107.1 (31.4)
15 (-9.4) 125.3 (36.7) 119.7 (35.1) 114.0 (33.4) 108.3 (31.7) 102.5 (30) 96.7 (28.3)
10 (-12.2) 112.8 (33.1) 107.7 (31.6) 102.6 (30.1) 97.4 (28.5) 92.1 (27) 86.9 (25.5)

5 (-15) 101.0 (29.6) 96.4 (28.3) 91.8 (26.9) 87.1 (25.5) 82.4 (24.1) 77.6 (22.7)

0 (-17.8) 89.9 (26.3) 85.8 (25.1) 81.6 (23.9) 77.4 (22.7) 73.2 (21.5) 68.9 (20.2)
30 (-1.1) 196.0 (57.4) 187.5 (55) 179.0 (52.5) 170.5 (50) 162.0 (47.5) 153.5 (45)
25 (-3.9) 178.6 (52.3) 170.7 (50) 162.9 (47.7) 155.0 (45.4) 147.2 (43.1) 139.3 (40.8)
20 (-6.7) 162.0 (47.5) 154.8 (45.4) 147.6 (43.3) 140.4 (41.1) 133.1 (39) 125.9 (36.9)
15 (-9.4) 146.4 (42.9) 139.8 (41) 133.2 (39) 126.6 (37.1) 119.9 (35.1) 113.3 (33.2)
10 (-12.2) 131.6 (38.6) 125.6 (36.8) 119.6 (35.1) 113.6 (33.3) 107.5 (31.5) 101.5 (29.7)

5 (-15) 117.8 (34.5) 112.3 (32.9) 106.9 (31.3) 101.4 (29.7) 95.9 (28.1) 90.4 (26.5)

0 (-17.8) 104.9 (30.7) 99.9 (29.3) 95.0 (27.8) 90.0 (26.4) 85.1 (24.9) 80.1 (23.5)
30 (-1.1) 239.9 (70.3) 229.9 (67.4) 220.0 (64.5) 210.1 (61.6) 200.4 (58.7) 190.7 (55.9)
25 (-3.9) 219.5 (64.3) 210.3 (61.6) 201.2 (59) 192.2 (56.3) 183.2 (53.7) 174.3 (51.1)
20 (-6.7) 200.1 (58.6) 191.7 (56.2) 183.4 (53.7) 175.1 (51.3) 166.9 (48.9) 158.8 (46.5)
15 (-9.4) 181.6 (53.2) 174.0 (51) 166.4 (48.8) 158.9 (46.6) 151.4 (44.4) 144.0 (42.2)
10 (-12.2) 164.1 (48.1) 157.2 (46.1) 150.3 (44) 143.5 (42.1) 136.7 (40.1) 130.0 (38.1)

5 (-15) 147.6 (43.3) 141.3 (41.4) 135.1 (39.6) 129.0 (37.8) 122.9 (36) 116.8 (34.2)

0 (-17.8) 132.0 (38.7) 126.4 (37) 120.9 (35.4) 115.3 (33.8) 109.9 (32.2) 104.4 (30.6)
30 (-1.1) 276.6 (81.1) 265.2 (77.7) 253.8 (74.4) 242.4 (71) 231.1 (67.7) 219.8 (64.4)
25 (-3.9) 253.3 (74.2) 242.8 (71.2) 232.3 (68.1) 221.9 (65) 211.5 (62) 201.1 (58.9)
20 (-6.7) 231.0 (67.7) 221.5 (64.9) 211.9 (62.1) 202.4 (59.3) 192.8 (56.5) 183.3 (53.7)
15 (-9.4) 209.9 (61.5) 201.2 (59) 192.5 (56.4) 183.8 (53.9) 175.1 (51.3) 166.5 (48.8)
10 (-12.2) 189.8 (55.6) 181.9 (53.3) 174.0 (51) 166.1 (48.7) 158.3 (46.4) 150.5 (44.1)

5 (-15) 170.9

0 (-17.8) 153.0 (44.8) 146.6 (43) 140.2 (41.1) 133.8 (39.2) 127.4 (37.3) 121.1 (35.5)
30 (-1.1) 360.0 (105.5) 344.9 (101.1) 329.9 (96.7) 315.1 (92.3) 300.4 (88) 285.8 (83.8)
25 (-3.9) 329.4 (96.5) 315.5 (92.5) 301.8 (88.4) 288.1 (84.4) 274.6 (80.5) 261.2 (76.5)
20 (-6.7) 300.3 (88) 287.6 (84.3) 275.0 (80.6) 262.5 (76.9) 250.1 (73.3) 237.9 (69.7)
15 (-9.4) 272.5 (79.9) 261.0 (76.5) 249.5 (73.1) 238.1 (69.8) 226.9 (66.5) 215.7 (63.2)
10 (-12.2) 246.3 (72.2) 235.8 (69.1) 225.4 (66.1) 215.1 (63) 204.9 (60.1) 194.8 (57.1)

5 (-15) 221.5 (64.9) 212.0 (62.1) 202.6 (59.4) 193.3 (56.7) 184.1 (54) 175.0 (51.3)

0 (-17.8) 198.1 (58.1) 189.6 (55.6) 181.1 (53.1) 172.8 (50.6) 164.5 (48.2) 156.4 (45.8)
30 (-1.1) 415.5 (121.8) 398.3 (116.7) 381.1 (111.7) 363.9 (106.6) 346.9 (101.7) 329.8 (96.7)
25 (-3.9) 380.5 (1
20 (-6.7) 347.1 (101.7) 332.7 (97.5) 318.3 (93.3) 303.9 (89.1) 289.6 (84.9) 275.3 (80.7)
15 (-9.4) 315.3 (92.4) 302.2 (88.6) 289.1 (84.7) 276.0 (80.9) 263.0 (77.1) 250.0 (73.3)
10 (-12.2) 285.2 (83.6) 273.3 (80.1) 261.4 (76.6) 249.6 (73.2) 237.8 (69.7) 226.1 (66.3)

5 (-15) 256.7 (75.2) 246.0 (72.1) 235.3 (69) 224.7 (65.9) 214.0 (62.7) 203.5 (59.6)

0 (-17.8) 229.9 (67.4) 220.3 (64.6) 210.7 (61.7) 201.1 (58.9) 191.6 (56.2) 182.1 (53.4)
30 (-1.1) 473.8 (138.9) 453.5 (132.9) 433.1 (126.9) 412.9 (121) 392.6 (115.1) --- --­25 (-3.9) 435.5 (127.6) 416.7 (122.1) 398.0 (116.6) 379.3 (111.2) 360.7 (105.7) --- ---
20 (-6.7) 398.7 (116.8) 381.5 (111.8) 364.3 (106.8) 347.2 (101.8) 330.1 (96.7) 313.1 (91.8)
15 (-9.4) 363.5 (106.5) 347.8 (101.9) 332.2 (97.4) 316.5 (92.8) 301.0 (88.2) 285.4 (83.6)
10 (-12.2) 330.0 (96.7) 315.8 (92.6) 301.5 (88.4) 287.3 (84.2) 273.2 (80.1) 259.0 (75.9)

5 (-15) 298.3 (87.4) 285.4 (83.6) 272.5 (79.9) 259.6 (76.1) 246.8 (72.3) 234.0 (68.6)

0 (-17.8) 268.3 (78.6) 256.6 (75.2) 245.0 (71.8) 233.4 (68.4) 221.8 (65) 210.3 (61.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(50.1) 163.7 (48) 156.6 (45.9) 149.5 (43.8) 142.4 (41.7) 135.3 (39.7)

11.5) 364.7 (106.9) 348.9 (102.3) 333.2 (97.7) 317.5 (93) 301.9 (88.5)

R404A R507

AMBIENT TEMPERATURE °F (°C)

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 15 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS015M8-B

Compressor

Model

4C2067SH

KVS020M8-B

Compressor

Model

4C2397SH

KVS025M8-B

Compressor

Model

4B3139PH

KVS030M8-B

Compressor

Model

4B3604PH

KVS035M8-B

Compressor

Model

6B4709PH

KVS040M8-B

Compressor

Model

6B5406PH

KVS050M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C
30 (-1.1) 140.9 (41.3) 135.3 (39.7) 129.7 (38) 124.3 (36.4) 119.0 (34.9) 113.7 (33.3)
25 (-3.9) 126.8 (37.2) 121.7 (35.7) 116.7 (34.2) 111.8 (32.8) 106.9 (31.3) 102.2 (30)
20 (-6.7) 113.6 (33.3) 109.0 (31.9) 104.5 (30.6) 100.0 (29.3) 95.7 (28) 91.4 (26.8)
15 (-9.4) 101.3 (29.7) 97.1 (28.5) 93.1 (27.3) 89.1 (26.1) 85.2 (25) 81.4 (23.9)
10 (-12.2) 89.8 (26.3) 86.1 (25.2) 82.4 (24.1) 78.8 (23.1) 75.3 (22.1) 72.0 (21.1)
30 (-1.1) 164.9 (48.3) 158.3 (46.4) 151.9 (44.5) 145.5 (42.6) 139.1 (40.8) 132.9 (38.9)
25 (-3.9) 148.3 (43.5) 142.4 (41.7) 136.5 (40) 130.7 (38.3) 124.9 (36.6) 119.3 (35)
20 (-6.7) 132.8 (38.9) 127.4 (37.3) 122.1 (35.8) 116.8 (34.2) 111.7 (32.7) 106.6 (31.2)
15 (-9.4) 118.4 (34.7) 113.5 (33.3) 108.7 (31.9) 103.9 (30.4) 99.3 (29.1) 94.7 (27.8)
10 (-12.2) 104.9 (30.7) 100.5 (29.5) 96.2 (28.2) 91.9 (26.9) 87.7 (25.7) 83.6 (24.5)
30 (-1.1) 205.4 (60.2) 197.7 (57.9) 189.9 (55.7) 182.2 (53.4) 174.6 (51.2) 166.9 (48.9)
25 (-3.9) 185.5 (54.4) 178.4 (52.3) 171.3 (50.2) 164.3 (48.2) 157.3 (46.1) 150.4 (44.1)
20 (-6.7) 166.7 (48.9) 160.3 (47) 153.9 (45.1) 147.5 (43.2) 141.1 (41.4) 134.8 (39.5)
15 (-9.4) 149.2 (43.7) 143.4 (42) 137.5 (40.3) 131.7 (38.6) 126.0 (36.9) 120.2 (35.2)
10 (-12.2) 132.9 (38.9) 127.6 (37.4) 122.3 (35.8) 117.0 (34.3) 111.8 (32.8) 106.6 (31.2)
30 (-1.1) 233.8 (68.5) 224.5 (65.8) 215.2 (63.1) 205.8 (60.3) 196.5 (57.6) 187.1 (54.8)
25 (-3.9) 210.8 (61.8) 202.4 (59.3) 193.9 (56.8) 185.3 (54.3) 176.8 (51.8) 168.3 (49.3)
20 (-6.7) 189.3 (55.5) 181.6 (53.2) 173.9 (51) 166.2 (48.7) 158.4 (46.4) 150.7 (44.2)
15 (-9.4) 169.2 (49.6) 162.3 (47.6) 155.3 (45.5) 148.3 (43.5) 141.2 (41.4) 134.2 (39.3)
10 (-12.2) 150.6 (44.1) 144.3 (42.3) 137.9 (40.4) 131.6 (38.6) 125.2 (36.7) 118.9 (34.8)
30 (-1.1) 308.4 (90.4) 296.7 (87) 285.1 (83.6) 273.5 (80.2) 261.9 (76.8) 250.5 (73.4)
25 (-3.9) 278.4 (81.6) 267.7 (78.5) 257.1 (75.3) 246.6 (72.3) 236.0 (69.2) 225.6 (66.1)
20 (-6.7) 250.3 (73.4) 240.6 (70.5) 230.9 (67.7) 221.3 (64.9) 211.7 (62) 202.2 (59.3)
15 (-9.4) 224.0 (65.6) 215.2 (63.1) 206.4 (60.5) 197.7 (57.9) 189.0 (55.4) 180.4 (52.9)
10 (-12.2) 199.5 (58.5) 191.5 (56.1) 183.5 (53.8) 175.6 (51.5) 167.8 (49.2) 160.0 (46.9)
30 (-1.1) 351.8 (103.1) 337.9 (99) 323.9 (94.9) 309.9 (90.8) 295.8 (86.7) 281.7 (82.6)
25 (-3.9) 317.2 (93) 304.5 (89.2) 291.7 (85.5) 278.9 (81.7) 266.1 (78) 253.3 (74.2)
20 (-6.7) 284.8 (83.5) 273.2 (80.1) 261.6 (76.7) 250.0 (73.3) 238.4 (69.9) 226.7 (66.4)
15 (-9.4) 254.6 (74.6) 244.1 (71.5) 233.6 (68.5) 223.0 (65.4) 212.5 (62.3) 201.9 (59.2)
10 (-12.2) 226.5 (66.4) 217.0 (63.6) 207.4 (60.8) 197.9 (58) 188.4 (55.2) 178.8 (52.4)
30 (-1.1) 411.6 (120.6) 396.8 (116.3) 381.9 (11
25 (-3.9) 372.5 (109.2) 358.9 (105.2) 345.4 (101.2) 331.8 (97.2) 318.4 (93.3) 304.9 (89.4)
20 (-6.7) 335.6 (98.4) 323.3 (94.7) 311.0 (91.1) 298.7 (87.5) 286.5 (84) 274.2 (80.4)
15 (-9.4) 301.1 (88.2) 289.9 (85) 278.7 (81.7) 267.6 (78.4) 256.5 (75.2) 245.5 (71.9)
10 (-12.2) 268.8 (78.8) 258.7 (75.8) 248.5 (72.8) 238.5 (69.9) 228.4 (66.9) 218.5 (64)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

1.9) 367.1 (107.6) 352.2 (103.2) 337.4 (98.9)

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

BITZER

04/17/13

K40-KV-PDS-17

- 16 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS012L6-B

Compressor

Model

4C2397SL

KVS015L6-B

Compressor

Model

4B3139PL

KVS020L6-B

Compressor

Model

4B3604PL

KVS025L6-B

Compressor

Model

6B4709PL

KVS030L6-B

Compressor

Model

6B5406PL

KVS040L6-B

Compressor

Model

6B6462PL

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 93.4 (27.4) 88.9 (26.1) 84.5 (24.8) 80.0 (23.4) 75.6 (22.2) 71.2 (20.9)

-5 (-20.6) 83.5 (24.5) 79.5 (23.3) 75.4 (22.1) 71.4 (20.9) 67.4 (19.8) 63.4 (18.6)

-10 (-23.3) 74.3 (21.8) 70.6 (20.7) 67.0 (19.6) 63.3 (18.6) 59.7 (17.5) 56.1 (16.4)

-15 (-26.1) 65.7 (19.3) 62.3 (18.3) 59.0 (17.3) 55.7 (16.3) 52.4 (15.4) 49.2 (14.4)

-20 (-28.9) 57.6 (16.9) 54.6 (16) 51.6 (15.1) 48.6 (14.2) 45.7 (13.4) 42.7 (12.5)

-25 (-31.7) 50.1 (14.7) 47.4 (13.9) 44.7 (13.1) 42.0 (12.3) 39.3 (11.5) 36.7 (10.8)

-30 (-34.4) 43.2 (12.7) 40.7 (11.9) 38.3 (11.2) 35.9 (10.5) 33.5 (9.8) 31.1 (9.1)

-35 (-37.2) 36.7 (10.8) 34.5 (10.1) 32.3 (9.5) 30.1 (8.8) 28.0 (8.2) 25.8 (7.6)

-40 (-40) 30.8 (9) 28.8 (8.4) 26.8 (7.9) 24.8 (7.3) 22.9 (6.7) 20.9 (6.1)
0 (-17.8) 123.0 (36) 117.5 (34.4) 112.0 (32.8) 106.5 (31.2) 101.1 (29.6) 95.7 (28)

-5 (-20.6) 110.8 (32.5) 105.8 (31) 100.8 (29.5) 95.8 (28.1) 90.8 (26.6) 85.9 (25.2)

-10 (-23.3) 99.3 (29.1) 94.7 (27.8) 90.2 (26.4) 85.6 (25.1) 81.1 (23.8) 76.6 (22.4)

-15 (-26.1) 88.5 (25.9) 84.3 (24.7) 80.2 (23.5) 76.1 (22.3) 72.0 (21.1) 67.9 (19.9)

-20 (-28.9) 78.4 (23) 74.6 (21.9) 70.9 (20.8) 67.1 (19.7) 63.4 (18.6) 59.7 (17.5)

-25 (-31.7) 68.9 (20.2) 65.5 (19.2) 62.1 (18.2) 58.8 (17.2) 55.4 (16.2) 52.1 (15.3)

-30 (-34.4) 60.1 (17.6) 57.0 (16.7) 54.0 (15.8) 50.9 (14.9) 47.9 (14) 44.9 (13.2)

-35 (-37.2) 52.0 (15.2) 49.2 (14.4) 46.4 (13.6) 43.7 (12.8) 40.9 (12) 38.1 (11.2)

-40 (-40) 44.4 (13) 41.9 (12.3) 39.4 (11.5) 36.9 (10.8) 34.3 (10.1) 31.8 (9.3)
0 (-17.8) 146.6 (43) 140.1 (41.1) 133.6 (39.2) 127.0 (37.2) 120.4 (35.3) 113.6 (33.3)

-5 (-20.6) 131.7 (38.6) 125.9 (36.9) 120.1 (35.2) 114.2 (33.5) 108.2 (31.7) 102.1 (29.9)

-10 (-23.3) 117.6 (34.5) 112.5 (33) 107.2 (31.4) 102.0 (29.9) 96.7 (28.3) 91.2 (26.7)

-15 (-26.1) 104.4 (30.6) 99.8 (29.2) 95.2 (27.9) 90.5 (26.5) 85.8 (25.1) 80.9 (23.7)

-20 (-28.9) 92.1 (27) 88.0 (25.8) 83.9 (24.6) 79.7 (23.4) 75.5 (22.1) 71.2 (20.9)

-25 (-31.7) 80.6 (23.6) 76.9 (22.5) 73.3 (21.5) 69.6 (20.4) 65.9 (19.3) 62.1 (18.2)

-30 (-34.4) 69.9 (20.5) 66.7 (19.5) 63.4 (18.6) 60.1 (17.6) 56.8 (16.6) 53.4 (15.6)

-35 (-37.2) 60.1 (17.6) 57.1 (16.7) 54.2 (15.9) 51.3 (15) 48.3 (14.2) 45.3 (13.3)

-40 (-40) 51.0 (14.9) 48.3 (14.2) 45.7 (13.4) 43.0 (12.6) 40.3 (11.8) 37.6 (11)
0 (-17.8) 188.7 (55.3) 180.3 (52.8) 171.9 (50.4) 163.6 (47.9) 155.2 (45.5) 146.8 (43)

-5 (-20.6) 169.4 (49.6) 161.9 (47.4) 154.3 (45.2) 146.8 (43) 139.3 (40.8) 131.7 (38.6)

-10 (-23.3) 151.2 (44.3) 144.5 (42.3) 137.7 (40.4) 131.0 (38.4) 124.3 (36.4) 117.5 (34.4)

-15 (-26.1) 134.2 (39.3) 128.1 (37.5) 122.1 (35.8) 1

-20 (-28.9) 118.2 (34.6) 112.8 (33.1) 107.4 (31.5) 102.1 (29.9) 96.8 (28.4) 91.4 (26.8)

-25 (-31.7) 103.3 (30.3) 98.5 (28.9) 93.8 (27.5) 89.0 (26.1) 84.3 (24.7) 79.5 (23.3)

-30 (-34.4) 89.6 (26.3) 85.3 (25) 81.0 (23.7) 76.8 (22.5) 72.6 (21.3) 68.4 (20)

-35 (-37.2) 76.9 (22.5) 73.0 (21.4) 69.2 (20.3) 65.4 (19.2) 61.7 (18.1) 57.9 (17)

-40 (-40) 65.3 (19.1) 61.7 (18.1) 58.3 (17.1) 54.8 (16.1) 51.4 (15.1) 48.0 (14.1)
0 (-17.8) 208.2 (61) 199.3 (58.4) 190.4 (55.8) 181.5 (53.2) 172.5 (50.6) 163.4 (47.9)

-5 (-20.6) 187.1 (54.8) 179.1 (52.5) 171.2 (50.2) 163.1 (47.8) 155.0 (45.4) 146.8 (43)

-10 (-23.3) 167.2 (49) 160.1 (46.9) 152.9 (44.8) 145.7 (42.7) 138.4 (40.6) 131.0 (38.4)

-15 (-26.1) 148.5 (43.5) 142.1 (41.6) 135.7 (39.8) 129.3 (37.9) 122.8 (36) 116.1 (34)

-20 (-28.9) 131.0 (38.4) 125.2 (36.7) 119.5 (35) 113.8 (33.4) 108.0 (31.7) 102.1 (29.9)

-25 (-31.7) 114.6 (33.6) 109.5 (32.1) 104.4 (30.6) 99.3 (29.1) 94.1 (27.6) 88.9 (26.1)

-30 (-34.4) 99.4 (29.1) 94.8 (27.8) 90.3 (26.5) 85.7 (25.1) 81.1 (23.8) 76.4 (22.4)

-35 (-37.2) 85.3 (25) 81.2 (23.8) 77.1 (22.6) 73.0 (21.4) 68.9 (20.2) 64.6 (18.9)

-40 (-40) 72.4 (21.2) 68.6 (20.1) 64.9 (19) 61.2 (17.9) 57.4 (16.8) 53.6 (15.7)
0 (-17.8) 246.0 (72.1) 234.8 (68.8) 223.7 (65.6) 212.7 (62.3) 201.8 (59.1) 191.0 (56)

-5 (-20.6) 221.2 (64.8) 211.0 (61.8) 200.8 (58.8) 190.8 (55.9) 180.9 (53) 171.0 (50.1)

-10 (-23.3) 197.7 (57.9) 188.4 (55.2) 179.2 (52.5) 170.1 (49.9) 161.1 (47.2) 152.2 (44.6)

-15 (-26.1) 175.6 (51.5) 167.2 (49) 158.9 (46.6) 150.7 (44.2) 142.5 (41.8) 134.4 (39.4)

-20 (-28.9) 154.9 (45.4) 147.3 (43.2) 139.8 (41) 132.4 (38.8) 125.0 (36.6) 117.7 (34.5)

-25 (-31.7) 135.5 (39.7) 128.7 (37.7) 121.9 (35.7) 115.2 (33.8) 108.6 (31.8) 102.0 (29.9)

-30 (-34.4) 117.5 (34.4) 111.3 (32.6) 105.2 (30.8) 99.2 (29.1) 93.2 (27.3) 87.3 (25.6)

-35 (-37.2) 100.8 (29.5) 95.2 (27.9) 89.7 (26.3) 84.2 (24.7) 78.8 (23.1) 73.4 (21.5)

-40 (-40) 85.3 (25) 80.2 (23.5) 75.2 (22) 70.3 (20.6) 65.3 (19.1) 60.4 (17.7)

CAPACITY MBH (KW)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

16.1 (34) 110.1 (32.3) 104.1 (30.5)

BITZER

04/17/13

K40-KV-PDS-17

- 17 -

CAPACITY DATA -

R404A

R507

EXTENDED LOW TEMPERATURE

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS008V6-B

Compressor

Model

S4N-8.2Y

KVS012V6-B

Compressor

Model

S4G-12.2Y

KVS016V6-B

Compressor

Model

S6J-16.2Y

KVS020V6-B

Compressor

Model

S6H-20.2Y

KVS025V6-B

Compressor

Model

S6G-25.2Y

KVS030V6-B

Compressor

Model

S6F-30.2Y

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

-25 (-31.7) 39.1 (11.5) 38.6 (11.3) 38.0 (11.1) 37.5 (11) 36.9 (10.8) 36.3 (10.6)

-30 (-34.4) 34.9 (10.2) 34.4 (10.1) 33.9 (9.9) 33.4 (9.8) 32.8 (9.6) 32.3 (9.5)

-35 (-37.2) 31.0 (9.1) 30.5 (8.9) 30.1 (8.8) 29.6 (8.7) 29.1 (8.5) 28.5 (8.4)

-40 (-40) 27.4 (8) 27.0 (7.9) 26.6 (7.8) 26.1 (7.6) 25.6 (7.5) 25.1 (7.4)

-45 (-42.8) 24.2 (7.1) 23.8 (7) 23.4 (6.9) 23.0 (6.7) 22.5 (6.6) 22.0 (6.4)

-50 (-45.6) 21.2 (6.2) 20.9 (6.1) 20.5 (6) 20.1 (5.9) 19.7 (5.8) 19.2 (5.6)

-55 (-48.3) 18.5 (5.4) 18.2 (5.3) 17.8 (5.2) 17.5 (5.1) 17.1 (5) 16.7 (4.9)

-60 (-51.1) 16.0 (4.7) 15.7 (4.6) 15.4 (4.5) 15.1 (4.4) 14.8 (4.3) 14.4 (4.2)

-25 (-31.7) 60.7 (17.8) 59.8 (17.5) 58.9 (17.3) 57.9 (17) 56.9 (16.7) 55.9 (16.4)

-30 (-34.4) 54.9 (16.1) 54.0 (15.8) 53.1 (15.6) 52.2 (15.3) 51.2 (15) 50.1 (14.7)

-35 (-37.2) 49.3 (14.4) 48.5 (14.2) 47.6 (14) 46.7 (13.7) 45.8 (13.4) 44.8 (13.1)

-40 (-40) 44.1 (12.9) 43.3 (12.7) 42.5 (12.5) 41.6 (12.2) 40.7 (11.9) 39.8 (11.7)

-45 (-42.8) 39.1 (11.5) 38.4 (11.3) 37.6 (11) 36.8 (10.8) 36.0 (10.6) 35.1 (10.3)

-50 (-45.6) 34.5 (10.1) 33.9 (9.9) 33.1 (9.7) 32.4 (9.5) 31.6 (9.3) 30.9 (9.1)

-55 (-48.3) 30.2 (8.9) 29.6 (8.7) 29.0 (8.5) 28.3 (8.3) 27.6 (8.1) 27.0 (7.9)

-60 (-51.1) 26.2 (7.7) 25.7 (7.5) 25.1 (7.4) 24.5 (7.2) 24.0 (7) 23.4 (6.9)

-25 (-31.7) 84.1 (24.6) 82.8 (24.3) 81.5 (23.9) 80.2 (23.5) 78.9 (23.1) 77.7 (22.8)

-30 (-34.4) 76.1 (22.3) 74.8 (21.9) 73.6 (21.6) 72.3 (21.2) 71.0 (20.8) 69.8 (20.5)

-35 (-37.2) 68.5 (20.1) 67.3 (19.7) 66.1 (19.4) 64.9 (19) 63.7 (18.7) 62.4 (18.3)

-40 (-40) 61.4 (18) 60.3 (17.7) 59.1 (17.3) 58.0 (17) 56.8 (16.6) 55.6 (16.3)

-45 (-42.8) 54.7 (16) 53.7 (15.7) 52.6 (15.4) 51.5 (15.1) 50.4 (14.8) 49.3 (14.4)

-50 (-45.6) 48.5 (14.2) 47.5 (13.9) 46.5 (13.6) 45.5 (13.3) 44.5 (13) 43.5 (12.7)

-55 (-48.3) 42.7 (12.5) 41.8 (12.3) 40.9 (12) 40.0 (11.7) 39.0 (11.4) 38.1 (11.2)

-60 (-51.1) 37.3 (10.9) 36.5 (10.7) 35.7 (10.5) 34.9 (10.2) 34.1 (10) 33.2 (9.7)

-25 (-31.7) 98.8 (29) 97.4 (28.5) 95.9 (28.1) 94.4 (27.7) 92.8 (27.2) 91.2 (26.7)

-30 (-34.4) 89.5 (26.2) 88.1 (25.8) 86.6 (25.4) 85.1 (24.9) 83.6 (24.5) 82.0 (24)

-35 (-37.2)

-40 (-40) 72.2 (21.2) 70.9 (20.8) 69.6 (20.4) 68.2 (20) 66.8 (19.6) 65.4 (19.2)

-45 (-42.8) 64.3 (18.8) 63.1 (18.5) 61.9 (18.1) 60.6 (17.8) 59.3 (17.4) 57.9 (17)

-50 (-45.6) 56.9 (16.7) 55.8 (16.4) 54.7 (16) 53.5 (15.7) 52.3 (15.3) 51.1 (15)

-55 (-48.3) 50.0 (14.7) 49.0 (14.4) 48.0 (14.1) 46.9 (13.7) 45.8 (13.4) 44.7 (13.1)

-60 (-51.1) 43.7 (12.8) 42.8 (12.5) 41.8 (12.3) 40.9 (12) 39.9 (11.7) 39.0 (11.4)

-25 (-31.7) 112.2 (32.9) 1

-30 (-34.4) 101.6 (29.8) 100.0 (29.3) 98.4 (28.8) 96.6 (28.3) 94.8 (27.8) 93.0 (27.3)

-35 (-37.2) 91.6 (26.8) 90.1 (26.4) 88.5 (25.9) 86.8 (25.4) 85.1 (24.9) 83.3 (24.4)

-40 (-40) 82.1 (24.1) 80.7 (23.7) 79.1 (23.2) 77.5 (22.7) 75.9 (22.2) 74.3 (21.8)

-45 (-42.8) 73.2 (21.5) 71.9 (21.1) 70.4 (20.6) 68.9 (20.2) 67.4 (19.8) 65.9 (19.3)

-50 (-45.6) 64.9 (19) 63.6 (18.6) 62.3 (18.3) 60.9 (17.8) 59.5 (17.4) 58.1 (17)

-55 (-48.3) 57.1 (16.7) 55.9 (16.4) 54.7 (16) 53.4 (15.6) 52.2 (15.3) 50.9 (14.9)

-60 (-51.1) 49.8 (14.6) 48.8 (14.3) 47.7 (14) 46.6 (13.7) 45.5 (13.3) 44.4 (13)

-25 (-31.7) 133.3 (39.1) 131.1 (38.4) 128.9 (37.8) 126.6 (37.1) 124.3 (36.4) 122.0 (35.8)

-30 (-34.4) 120.7 (35.4) 118.7 (34.8) 116.5 (34.1) 114.3 (33.5) 112.1 (32.9) 109.8 (32.2)

-35 (-37.2) 108.8 (31.9) 106.9 (31.3) 104.8 (30.7) 102.7 (30.1) 100.6 (29.5) 98.5 (28.9)

-40 (-40) 97.6 (28.6) 95.7 (28) 93.8 (27.5) 91.8 (26.9) 89.8 (26.3) 87.8 (25.7)

-45 (-42.8) 87.0 (25.5) 85.3 (25) 83.5 (24.5) 81.7 (23.9) 79.8 (23.4) 78.0 (22.9)

-50 (-45.6) 77.1 (22.6) 75.5 (22.1) 73.9 (21.7) 72.2 (21.2) 70.5 (20.7) 68.9 (20.2)

-55 (-48.3) 67.9 (19.9) 66.5 (19.5) 65.0 (19) 63.5 (18.6) 62.0 (18.2) 60.5 (17.7)

-60 (-51.1) 59.3 (17.4) 58.1 (17) 56.8 (16.6) 55.4 (16.2) 54.1 (15.9) 52.8 (15.5)

80.6 (23.6) 79.3 (23.2) 77.8 (22.8) 76.4 (22.4) 74.9 (22) 73.4 (21.5)

CAPACITY MBH (KW)

10.6 (32.4) 108.9 (31.9) 107.1 (31.4) 105.2 (30.8) 103.4 (30.3)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 18 -

CAPACITY DATA -

HIGH TEMPERATURE

R407C

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD030H8-B

Compressor

Model

4C2067SH

KVD040H8-B

Compressor

Model

4C2397SH

KVD050H8-B

Compressor

Model

4B3139PH

KVD060H8-B

Compressor

Model

4B3604PH

KVD070H8-B

Compressor

Model

6B4709PH

KVD080H8-B

Compressor

Model

6B5406PH

NOTE: The capacities shown above are rated at dew point.

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 450.2 (131.9) 433.0 (126.9) 416.0 (121.9) 399.0 (116.9) 382.4 (112.1) 365.8 (107.2)
50 (10) 412.8 (121) 397.0 (116.3) 381.2 (111.7) 365.6 (107.1) 350.2 (102.6) 335.0 (98.2)
45 (7.2) 377.4 (110.6) 362.6 (106.3) 348.2 (102) 333.8 (97.8) 319.6 (93.7) 305.8 (89.6)
40 (4.4) 343.6 (100.7) 330.2 (96.8) 316.8 (92.8) 303.8 (89) 290.8 (85.2) 278.0 (81.5)
35 (1.7) 311.8 (91.4) 299.4 (87.7) 287.4 (84.2) 275.4 (80.7) 263.6 (77.3) 252.0 (73.9)
55 (12.8) 529.0 (155) 509.0 (149.2) 489.2 (143.4) 469.2 (137.5) 449.6 (131.8) 430.0 (126)
50 (10) 484.8 (142.1) 466.2 (136.6) 447.8 (131.2) 429.4 (125.8) 411.2 (120.5) 393.2 (115.2)
45 (7.2) 442.6 (129.7) 425.6 (124.7) 408.6 (119.7) 391.8 (114.8) 375.0 (109.9) 358.6 (105.1)
40 (4.4) 402.8 (118) 387.0 (113.4) 371.6 (108.9) 356.0 (104.3) 340.8 (99.9) 325.8 (95.5)
35 (1.7) 365.2 (107) 350.8 (102.8) 336.6 (98.6) 322.6 (94.5) 308.6 (90.4) 294.8 (86.4)
55 (12.8) 647.2 (189.7) 624.0 (182.9) 601.0 (176.1) 577.8 (169.3) 554.8 (162.6) 531.6 (155.8)
50 (10) 595.4 (174.5) 573.8 (168.2) 552.2 (161.8) 530.8 (155.6) 509.4 (149.3) 488.0 (143)
45 (7.2) 545.6 (159.9) 525.6 (154) 505.8 (148.2) 485.8 (142.4) 466.0 (136.6) 446.2 (130.8)
40 (4.4) 498.2 (146) 479.8 (140.6) 461.4 (135.2) 443.0 (129.8) 424.8 (124.5) 406.6 (119.2)
35 (1.7) 453.4 (132.9) 436.4 (127.9) 419.4 (122.9) 402.6 (118) 385.8 (113.1) 369.2 (108.2)
55 (12.8) 740.2 (216.9) 712.4 (208.8) 684.4 (200.6) 656.4 (192.4) 628.2 (184.1) 600.0 (175.8)
50 (10) 680.2 (199.3) 654.4 (191.8) 628.4 (184.2) 602.4 (176.5) 576.2 (168.9) 550.0 (161.2)
45 (7.2) 623.0 (182.6) 599.0 (175.5) 575.0 (168.5) 550.8 (161.4) 526.4 (154.3) 502.2 (147.2)
40 (4.4) 568.2 (166.5) 546.2 (160.1) 524.0 (153.6) 501.8 (147.1) 479.4 (140.5) 457.0 (133.9)
35 (1.7) 516.4 (151.3) 496.2 (145.4) 475.8 (139.4) 455.4 (133.5) 434.8 (127.4) 414.4 (121.4)
55 (12.8) 972.2 (284.9) 937.2 (274.7) 902.4 (264.5) 867.6 (254.3) 832.6 (244) 797.8 (233.8)
50 (10) 894.2 (262.1) 861.8 (252.6) 829.2 (243) 796.8 (233.5) 764.4 (224) 732.2 (214.6)
45 (7.2) 819.4 (240.1) 789.4 (231.3) 759.2 (222.5) 729.2 (213.7) 699.4 (205) 669.4 (196.2)
40 (4.4) 748.2 (219.3) 720.4 (211.1) 692.8 (203) 665.0 (194.9) 637.6 (186.9) 610.0 (178.8)
35 (1.7) 680.6 (199.5) 655.0 (192) 629.6 (184.5) 604.4 (177.1) 579.0 (169.7) 553.8 (162.3)
55 (12.8) 1115.8 (327) 1074.0 (314.8) 1032.0 (302.4) 989.8 (290.1) 947.4 (277.7) 904.8 (265.2)
50 (10) 1025.0 (300.4) 986.2 (289) 947.0 (277.5) 907.8 (266) 868.4 (254.5) 829.0 (243)
45 (7.2) 938.2 (275) 902.2 (264.4) 866.0 (253.8) 829.8 (243.2) 793.2 (232.5) 756.8 (221.8)
40 (4.4) 855.6 (250.8) 822.4 (241) 789.0 (231.2) 755.6 (221.4) 722.0 (211.6) 688.4 (201.7)
35 (1.7) 777.4 (227.8) 747.0 (218.9) 716.4 (210) 685.6 (200.9) 654.8 (191.9) 624.0 (182.9)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

The dew point is a saturation point and is the condition (pressure and temperature) at

R407C

AMBIENT TEMPERATURE °F (°C)

BITZER

CONDENSING

UNIT

MODEL

KVD030H8-B

Compressor

4C2067SH

KVD040H8-B

Compressor

4C2397SH

KVD050H8-B

Compressor

4B3139PH

KVD060H8-B

Compressor

4B3604PH

KVD070H8-B

Compressor

6B4709PH

KVD080H8-B

Compressor

6B5406PH

CAPACITY DATA -

R404A

R507

60HzKVD-B

HIGH TEMPERATURE

SATURATED

SUCTION

TEMPERATURE

° F ° C
45 (7.2) 430.8 (126.3) 411.8 (120.7) 393.0 (115.2) 374.0 (109.6) 355.0 (104) 335.8 (98.4)
40 (4.4) 397.4 (116.5) 379.8 (111.3) 362.2 (106.1) 344.6 (101) 327.0 (95.8) 309.2 (90.6)
35 (1.7) 365.2 (107) 349.0 (102.3) 332.8 (97.5) 316.6 (92.8) 300.2 (88) 283.8 (83.2)
45 (7.2) 507.8 (148.8) 486.6 (142.6) 465.4 (136.4) 444.2 (130.2) 423.2 (124) 402.0 (117.8)
40 (4.4) 467.4 (137) 447.6 (131.2) 427.8 (125.4) 408.2 (119.6) 388.4 (113.8) 368.6 (108)
35 (1.7) 428.8 (125.7) 410.4 (120.3) 392.0 (114.9) 373.6 (109.5) 355.4 (104.2) 337.0 (98.8)
45 (7.2) 612.8 (179.6) 587.6 (172.2) 562.8 (164.9) 538.0 (157.7) 513.6 (150.5) 489.2 (143.4)
40 (4.4) 566.6 (166.1) 543.2 (159.2) 520.2 (152.5) 497.2 (145.7) 474.4 (139) 451.6 (132.4)
35 (1.7) 522.2 (153) 500.6 (146.7) 479.2 (140.4) 457.8 (134.2) 436.6 (128) 415.6 (121.8)
45 (7.2) 705.4 (206.7) 676.6 (198.3) 647.8 (189.9) 619.2 (181.5) 590.6 (173.1) 562.2 (164.8)
40 (4.4) 652.6 (191.3) 625.8 (183.4) 599.2 (175.6) 572.6 (167.8) 546.0 (160) 519.6 (152.3)
35 (1.7) 601.8 (176.4) 577.2 (169.2) 552.4 (161.9) 527.8 (154.7) 503.2 (147.5) 478.6 (140.3)
45 (7.2) 919.6 (269.5) 882.0 (258.5) 844.4 (247.5) 807.2 (236.6) 770.4 (225.8) 733.6 (215)
40 (4.4) 850.4 (249.2) 815.2 (238.9) 780.4 (228.7) 745.6 (218.5) 711.4 (208.5) 677.2 (198.5)
35 (1.7) 783.8 (229.7) 751.2 (220.2) 718.8 (210.7) 686.6 (201.2) 654.8 (191.9) 623.2 (182.6)
45 (7.2) 1059.2 (310.4) 1015.8 (297.7) 972.4 (285) 929.2 (272.3) 886.2 (259.7) 843.2 (247.1)
40 (4.4) 980.2 (287.3) 939.8 (275.4) 899.4 (263.6) 859.2 (251.8) 819.2 (240.1) 779.4 (228.4)
35 (1.7) 904.2 (265) 866.6 (254) 829.4 (243.1) 792.2 (232.2) 755.2 (221.3) 718.2 (210.5)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 19 -

CAPACITY DATA -

MEDIUM TEMPERATURE

R404A

R507

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD030M8-B

Compressor

Model

4C2067SH

KVD040M8-B

Compressor

Model

4C2397SH

KVD050M8-B

Compressor

Model

4B3139PH

KVD060M8-B

Compressor

Model

4B3604PH

KVD070M8-B

Compressor

Model

6B4709PH

KVD080M8-B

Compressor

Model

6B5406PH

KVD100M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C
30 (-1.1) 334.6 (98.1) 319.6 (93.7) 304.6 (89.3) 289.6 (84.9) 274.6 (80.5) 259.4 (76)
25 (-3.9) 305.2 (89.4) 291.6 (85.5) 277.8 (81.4) 264.0 (77.4) 250.2 (73.3) 236.2 (69.2)
20 (-6.7) 277.2 (81.2) 264.8 (77.6) 252.2 (73.9) 239.6 (70.2) 227.0 (66.5) 214.2 (62.8)
15 (-9.4) 250.6 (73.4) 239.4 (70.2) 228.0 (66.8) 216.6 (63.5) 205.0 (60.1) 193.4 (56.7)
10 (-12.2) 225.6 (66.1) 215.4 (63.1) 205.2 (60.1) 194.8 (57.1) 184.2 (54) 173.8 (50.9)

5 (-15) 202.0 (59.2) 192.8 (56.5) 183.6 (53.8) 174.2 (51.1) 164.8 (48.3) 155.2 (45.5)

0 (-17.8) 179.8 (52.7) 171.6 (50.3) 163.2 (47.8) 154.8 (45.4) 146.4 (42.9) 137.8 (40.4)
30 (-1.1) 392.0 (114.9) 375.0 (109.9) 358.0 (104.9) 341.0 (99.9) 324.0 (95) 307.0 (90)
25 (-3.9) 357.2 (104.7) 341.4 (100.1) 325.8 (95.5) 310.0 (90.9) 294.4 (86.3) 278.6 (81.6)
20 (-6.7) 324.0 (95) 309.6 (90.7) 295.2 (86.5) 280.8 (82.3) 266.2 (78) 251.8 (73.8)
15 (-9.4) 292.8 (85.8) 279.6 (81.9) 266.4 (78.1) 253.2 (74.2) 239.8 (70.3) 226.6 (66.4)
10 (-12.2) 263.2 (77.1) 251.2 (73.6) 239.2 (70.1) 227.2 (66.6) 215.0 (63) 203.0 (59.5)

5 (-15) 235.6 (69) 224.6 (65.8) 213.8 (62.7) 202.8 (59.4) 191.8 (56.2) 180.8 (53)

0 (-17.8) 209.8 (61.5) 199.8 (58.6) 190.0 (55.7) 180.0 (52.8) 170.2 (49.9) 160.2 (46.9)
30 (-1.1) 479.8 (140.6) 459.8 (134.8) 440.0 (129) 420.2 (123.1) 400.8 (117.5) 381.4 (111.8)
25 (-3.9) 439.0 (128.7) 420.6 (123.3) 402.4 (117.9) 384.4 (112.7) 366.4 (107.4) 348.6 (102.2)
20 (-6.7) 400.2 (117.3) 383.4 (112.4) 366.8 (107.5) 350.2 (102.6) 333.8 (97.8) 317.6 (93.1)
15 (-9.4) 363.2 (106.4) 348.0 (102) 332.8 (97.5) 317.8 (93.1) 302.8 (88.7) 288.0 (84.4)
10 (-12.2) 328.2 (96.2) 314.4 (92.1) 300.6 (88.1) 287.0 (84.1) 273.4 (80.1) 260.0 (76.2)

5 (-15) 295.2 (86.5) 282.6 (82.8) 270.2 (79.2) 258.0 (75.6) 245.8 (72) 233.6 (68.5)

0 (-17.8) 264.0 (77.4) 252.8 (74.1) 241.8 (70.9) 230.6 (67.6) 219.8 (64.4) 208.8 (61.2)
30 (-1.1) 553.2 (162.1) 530.4 (155.4) 507.6 (148.8) 484.8 (142.1) 462.2 (135.5) 439.6 (128.8)
25 (-3.9) 506.6 (148.5) 485.6 (142.3) 464.6 (136.2) 443.8 (130.1) 423.0 (124) 402.2 (117.9)
20 (-6.7) 462.0 (135.4) 443.0 (129.8) 423.8 (124.2) 404.8 (118.6) 385.6 (113) 366.6 (107.4)
15 (-9.4) 419.8 (123) 402.4 (117.9) 385.0 (112.8) 367.6 (107.7) 350.2 (102.6) 333.0 (97.6)
10 (-12.2) 379.6 (111.2) 363.8 (106.6) 348.0 (102) 332.2 (97.4) 316.6 (92.8) 301.0 (88.2)

5 (-15) 341.8

0 (-17.8) 306.0 (89.7) 293.2 (85.9) 280.4 (82.2) 267.6 (78.4) 254.8 (74.7) 242.2 (71)
30 (-1.1) 720.0 (211) 689.8 (202.2) 659.8 (193.4) 630.2 (184.7) 600.8 (176.1) 571.6 (167.5)
25 (-3.9) 658.8 (193.1) 631.0 (184.9) 603.6 (176.9) 576.2 (168.9) 549.2 (161) 522.4 (153.1)
20 (-6.7) 600.6 (176) 575.2 (168.6) 550.0 (161.2) 525.0 (153.9) 500.2 (146.6) 475.8 (139.4)
15 (-9.4) 545.0 (159.7) 522.0 (153) 499.0 (146.2) 476.2 (139.6) 453.8 (133) 431.4 (126.4)
10 (-12.2) 492.6 (144.4) 471.6 (138.2) 450.8 (132.1) 430.2 (126.1) 409.8 (120.1) 389.6 (114.2)

5 (-15) 443.0 (129.8) 424.0 (124.3) 405.2 (118.8) 386.6 (1

0 (-17.8) 396.2 (116.1) 379.2 (111.1) 362.2 (106.1) 345.6 (101.3) 329.0 (96.4) 312.8 (91.7)
30 (-1.1) 831.0 (243.5) 796.6 (233.5) 762.2 (223.4) 727.8 (213.3) 693.8 (203.3) 659.6 (193.3)
25 (-3.9) 761.0 (223) 729.4 (213.8) 697.8 (204.5) 666.4 (195.3) 635.0 (186.1) 603.8 (177)
20 (-6.7) 694.2 (203.4) 665.4 (195) 636.6 (186.6) 607.8 (178.1) 579.2 (169.7) 550.6 (161.4)
15 (-9.4) 630.6 (184.8) 604.4 (177.1) 578.2 (169.5) 552.0 (161.8) 526.0 (154.2) 500.0 (146.5)
10 (-12.2) 570.4 (167.2) 546.6 (160.2) 522.8 (153.2) 499.2 (146.3) 475.6 (139.4) 452.2 (132.5)

5 (-15) 513.4 (150.5) 492.0 (144.2) 470.6 (137.9) 449.4 (131.7) 428.0 (125.4) 407.0 (119.3)

0 (-17.8) 459.8 (134.8) 440.6 (129.1) 421.4 (123.5) 402.2 (117.9) 383.2 (112.3) 364.2 (106.7)
30 (-1.1) 947.6 (277.7) 907.0 (265.8) 866.2 (253.9) 825.8 (242) 785.2 (230.1) --- --­25 (-3.9) 871.0 (255.3) 833.4 (244.2) 796.0 (233.3) 758.6 (222.3) 721.4 (211.4) --- --­20 (-6.7) 797.4 (233.7) 763.0 (223.6) 728.6 (213.5) 694.4 (203.5) 660.2 (193.5) 626.2 (183.5)
15 (-9.4) 727.0 (213.1) 695.6 (203.9) 664.4 (194.7) 633.0 (185.5) 602.0 (176.4) 570.8 (167.3)
10 (-12.2) 660.0 (193.4) 631.6 (185.1) 603.0 (176.7) 574.6 (168.4) 546.4 (160.1) 518.0 (151.8)

5 (-15) 596.6 (174.8) 570.8 (167.3) 545.0 (159.7) 519.2 (152.2) 493.6 (144.7) 468.0 (137.2)

0 (-17.8) 536.6 (157.3) 513.2 (150.4) 490.0 (143.6) 466.8 (136.8) 443.6 (130) 420.6 (123.3)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

(100.2) 327.4 (96) 313.2 (91.8) 299.0 (87.6) 284.8 (83.5) 270.6 (79.3)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

13.3) 368.2 (107.9) 350.0 (102.6)

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 20 -

CAPACITY DATA -

R407C

MEDIUM TEMPERATURE

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD030M8-B

Compressor

Model

4C2067SH

KVD040M8-B

Compressor

Model

4C2397SH

KVD050M8-B

Compressor

Model

4B3139PH

KVD060M8-B

Compressor

Model

4B3604PH

KVD070M8-B

Compressor

Model

6B4709PH

KVD080M8-B

Compressor

Model

6B5406PH

KVD100M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 281.8 (82.6) 270.6 (79.3) 259.4 (76) 248.6 (72.9) 238.0 (69.8) 227.4 (66.6)
25 (-3.9) 253.6 (74.3) 243.4 (71.3) 233.4 (68.4) 223.6 (65.5) 213.8 (62.7) 204.4 (59.9)
20 (-6.7) 227.2 (66.6) 218.0 (63.9) 209.0 (61.3) 200.0 (58.6) 191.4 (56.1) 182.8 (53.6)
15 (-9.4) 202.6 (59.4) 194.2 (56.9) 186.2 (54.6) 178.2 (52.2) 170.4 (49.9) 162.8 (47.7)
10 (-12.2) 179.6 (52.6) 172.2 (50.5) 164.8 (48.3) 157.6 (46.2) 150.6 (44.1) 144.0 (42.2)

30 (-1.1) 329.8 (96.7) 316.6 (92.8) 303.8 (89) 291.0 (85.3) 278.2 (81.5) 265.8 (77.9)
25 (-3.9) 296.6 (86.9) 284.8 (83.5) 273.0 (80) 261.4 (76.6) 249.8 (73.2) 238.6 (69.9)
20 (-6.7) 265.6 (77.8) 254.8 (74.7) 244.2 (71.6) 233.6 (68.5) 223.4 (65.5) 213.2 (62.5)
15 (-9.4) 236.8 (69.4) 227.0 (66.5) 217.4 (63.7) 207.8 (60.9) 198.6 (58.2) 189.4 (55.5)
10 (-12.2) 209.8 (61.5) 201.0 (58.9) 192.4 (56.4) 183.8 (53.9) 175.4 (51.4) 167.2 (49)
30 (-1.1) 410.8 (120.4) 395.4 (115.9) 379.8 (111.3) 364.4 (106.8) 349.2 (102.3) 333.8 (97.8)
25 (-3.9) 371.0 (108.7) 356.8 (104.6) 342.6 (100.4) 328.6 (96.3) 314.6 (92.2) 300.8 (88.2)
20 (-6.7) 333.4 (97.7) 320.6 (94) 307.8 (90.2) 295.0 (86.5) 282.2 (82.7) 269.6 (79)
15 (-9.4) 298.4 (87.5) 286.8 (84.1) 275.0 (80.6) 263.4 (77.2) 252.0 (73.9) 240.4 (70.5)
10 (-12.2) 265.8 (77.9) 255.2 (74.8) 244.6 (71.7) 234.0 (68.6) 223.6 (65.5) 213.2 (62.5)
30 (-1.1) 467.6 (137) 449.0 (131.6) 430.4 (126.1) 411.6 (120.6) 393.0 (115.2) 374.2 (109.7)
25 (-3.9) 421.6 (123.6) 404.8 (118.6) 387.8 (113.7) 370.6 (108.6) 353.6 (103.6) 336.6 (98.6)
20 (-6.7) 378.6 (111) 363.2 (106.4) 347.8 (101.9) 332.4 (97.4) 316.8 (92.8) 301.4 (88.3)
15 (-9.4) 338.4 (99.2) 324.6 (95.1) 310.6 (91) 296.6 (86.9) 282.4 (82.8) 268.4 (78.7)
10 (-12.2) 301.2 (88.3) 288.6 (84.6) 275.8 (80.8) 263.2 (77.1) 250.4 (73.4) 237.8 (69.7)
30 (-1.1) 616.8 (180.8) 593.4 (173.9) 570.2 (167.1) 547.0 (160.3) 523.8 (153.5) 501.0 (146.8)
25 (-3.9) 556.8 (163.2) 535.4 (156.9) 514.2 (150.7) 493.2 (144.5) 472.0 (138.3) 451.2 (132.2)
20 (-6.7) 500.6 (146.7) 481.2 (141) 461.8 (135.3) 442.6 (129.7) 423.4 (124.1) 404.4 (118.5)
15 (-9.4) 448.0 (131.3) 430.4 (126.1) 412.8 (121) 395.4 (115.9) 378.0 (110.8) 360.8 (105.7)
10 (-12.2) 399.0 (116.9) 383.0 (112.2) 367.0 (107.6) 351.2 (102.9) 335.6 (98.4) 320.0 (93.8)
30 (-1.1) 703.6 (206.2) 675.8 (198.1) 647.8 (189.9) 619.8 (181.6) 591.6 (173.4) 563.4 (165.1)
25 (-3.9) 634.4 (185.9) 609.0 (178.5) 583.4 (171) 557.8 (163.5) 532.2 (156) 506.6 (148.5)
20 (-6.7) 569.6 (166.9) 546.4 (160.1) 523.2 (153.3) 500.0 (146.5) 476.8 (139.7) 453.4 (132.9)
15 (-9.4) 509.2 (149.2) 488.2 (143.1) 467.2 (136.9) 446.0 (130.7) 425.0 (124.6) 403.8 (118.3)
10 (-12.2) 453.0 (132.8) 434.0 (127.2) 414.8 (121.6) 395.8 (116) 376.8 (110.4) 357.6 (104.8)
30 (-1.1) 823.2 (241.3) 793.6 (232.6) 763.8 (223.8) 734.2 (215.2) 704.4 (206.4) 674.8 (197.8)
25 (-3.9) 745.0 (218.3) 717.8 (210.4) 690.8 (202.5) 663.6 (194.5) 636.8 (186.6) 609.8 (178.7)
20 (-6.7) 671.2 (196.7) 646.6 (189.5) 622.0 (182.3) 597.4 (175.1) 573.0 (167.9) 548.4 (160.7)
15 (-9.4) 602.2 (176.5) 579.8 (169.9) 557.4 (163.4) 535.2 (156.9) 513.0 (150.3) 491.0 (143.9)
10 (-12.2) 537.6 (157.6) 517.4 (151.6) 497.0 (145.7) 477.0 (139.8) 456.8 (133.9) 437.0 (128.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

NOTE:

The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

BITZER

04/17/13

K40-KV-PDS-17

- 21 -

CAPACITY DATA -

LOW TEMPERATURE

R404A

R507

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD0242L6-B

Compressor

Model

4C2397SL

KVD030L6-B

Compressor

Model

4B3139PL

KVD040L6-B

Compressor

Model

4B3604PL

KVD050L6-B

Compressor

Model

6B4709PL

KVD060L6-B

Compressor

Model

6B5406PL

KVD080L6-B

Compressor

Model

6B6462PL

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

0 (-17.8) 186.8 (54.7) 177.8 (52.1) 169.0 (49.5) 160.0 (46.9) 151.2 (44.3) 142.4 (41.7)

-5 (-20.6) 167.0 (48.9) 159.0 (46.6) 150.8 (44.2) 142.8 (41.9) 134.8 (39.5) 126.8 (37.2)

-10 (-23.3) 148.6 (43.6) 141.2 (41.4) 134.0 (39.3) 126.6 (37.1) 119.4 (35) 112.2 (32.9)

-15 (-26.1) 131.4 (38.5) 124.6 (36.5) 118.0 (34.6) 111.4 (32.6) 104.8 (30.7) 98.4 (28.8)

-20 (-28.9) 115.2 (33.8) 109.2 (32) 103.2 (30.2) 97.2 (28.5) 91.4 (26.8) 85.4 (25)

-25 (-31.7) 100.2 (29.4) 94.8 (27.8) 89.4 (26.2) 84.0 (24.6) 78.6 (23) 73.4 (21.5)

-30 (-34.4) 86.4 (25.3) 81.4 (23.9) 76.6 (22.4) 71.8 (21) 67.0 (19.6) 62.2 (18.2)

-35 (-37.2) 73.4 (21.5) 69.0 (20.2) 64.6 (18.9) 60.2 (17.6) 56.0 (16.4) 51.6 (15.1)

-40 (-40) 61.6 (18.1) 57.6 (16.9) 53.6 (15.7) 49.6 (14.5) 45.8 (13.4) 41.8 (12.3)
0 (-17.8) 246.0 (72.1) 235.0 (68.9) 224.0 (65.6) 213.0 (62.4) 202.2 (59.3) 191.4 (56.1)

-5 (-20.6) 221.6 (64.9) 211.6 (62) 201.6 (59.1) 191.6 (56.2) 181.6 (53.2) 171.8 (50.3)

-10 (-23.3) 198.6 (58.2) 189.4 (55.5) 180.4 (52.9) 171.2 (50.2) 162.2 (47.5) 153.2 (44.9)

-15 (-26.1) 177.0 (51.9) 168.6 (49.4) 160.4 (47) 152.2 (44.6) 144.0 (42.2) 135.8 (39.8)

-20 (-28.9) 156.8 (46) 149.2 (43.7) 141.8 (41.6) 134.2 (39.3) 126.8 (37.2) 119.4 (35)

-25 (-31.7) 137.8 (40.4) 131.0 (38.4) 124.2 (36.4) 117.6 (34.5) 110.8 (32.5) 104.2 (30.5)

-30 (-34.4) 120.2 (35.2) 114.0 (33.4) 108.0 (31.7) 101.8 (29.8) 95.8 (28.1) 89.8 (26.3)

-35 (-37.2) 104.0 (30.5) 98.4 (28.8) 92.8 (27.2) 87.4 (25.6) 81.8 (24) 76.2 (22.3)

-40 (-40) 88.8 (26) 83.8 (24.6) 78.8 (23.1) 73.8 (21.6) 68.6 (20.1) 63.6 (18.6)
0 (-17.8) 293.2 (85.9) 280.2 (82.1) 267.2 (78.3) 254.0 (74.4) 240.8 (70.6) 227.2 (66.6)

-5 (-20.6) 263.4 (77.2) 251.8 (73.8) 240.2 (70.4) 228.4 (66.9) 216.4 (63.4) 204.2 (59.8)

-10 (-23.3) 235.2 (68.9) 225.0 (65.9) 214.4 (62.8) 204.0 (59.8) 193.4 (56.7) 182.4 (53.5)

-15 (-26.1) 208.8 (61.2) 199.6 (58.5) 190.4 (55.8) 181.0 (53) 171.6 (50.3) 161.8 (47.4)

-20 (-28.9) 184.2 (54) 176.0 (51.6) 167.8 (49.2) 159.4 (46.7) 151.0 (44.3) 142.4 (41.7)

-25 (-31.7) 161.2 (47.2) 153.8 (45.1) 146.6 (43) 139.2 (40.8) 131.8 (38.6) 124.2 (36.4)

-30 (-34.4) 139.8 (41) 133.4 (39.1) 126.8 (37.2) 120.2 (35.2) 113.6 (33.3) 106.8 (31.3)

-35 (-37.2) 120.2 (35.2) 114.2 (33.5) 108.4 (31.8) 102.6 (30.1) 96.6 (28.3) 90.6 (26.6)

-40 (-40) 102.0 (29.9) 96.6 (28.3) 91.4 (26.8) 86.0 (25.2) 80.6 (23.6) 75.2 (22)
0 (-17.8) 377.4 (110.6) 360.6 (105.7) 343.8 (100.8) 327.2 (95.9) 310.4 (91) 293.6 (86)

-5 (-20.6) 338.8 (99.3) 323.8 (94.9) 308.6 (90.4) 293.6 (86) 278.6 (81.6) 263.4 (77.2)

-10 (-23.3) 302.4 (88.6) 289.0 (84.7) 275.4 (80.7) 262.0 (76.8) 248.6 (72.9) 235.0 (68.9)

-15 (-26.1) 268.4 (78.7) 256.2 (75.1) 244.2 (71.6) 232.2 (68.1) 220.2 (64.5) 208.2 (61)

-20 (-28.9) 236.4 (69.3) 225.6 (66.1) 214.8 (63) 204.2 (59.8) 193.6 (56.7) 182.8 (53.6)

-25 (-31.7) 206.6 (60.5) 197.0 (57.7) 187.6 (55) 178.0 (52.2) 168.6 (49.4) 159.0 (46.6)

-30 (-34.4) 179.2 (52.5) 170.6 (50) 162.0 (47.5) 153.6 (45) 145.2 (42.6) 136.8 (40.1)

-35 (-37.2) 153.8 (45.1) 146.0 (42.8) 138.4 (40.6) 130.8 (38.3) 123.4 (36.2) 115.8 (33.9)

-40 (-40) 130.6 (38.3) 123.4 (36.2) 116.6 (34.2) 109.6 (32.1) 102.8 (30.1) 96.0 (28.1)
0 (-17.8) 416.4 (122) 398.6 (1

-5 (-20.6) 374.2 (109.7) 358.2 (105) 342.4 (100.3) 326.2 (95.6) 310.0 (90.9) 293.6 (86)

-10 (-23.3) 334.4 (98) 320.2 (93.8) 305.8 (89.6) 291.4 (85.4) 276.8 (81.1) 262.0 (76.8)

-15 (-26.1) 297.0 (87) 284.2 (83.3) 271.4 (79.5) 258.6 (75.8) 245.6 (72) 232.2 (68.1)

-20 (-28.9) 262.0 (76.8) 250.4 (73.4) 239.0 (70) 227.6 (66.7) 216.0 (63.3) 204.2 (59.8)

-25 (-31.7) 229.2 (67.2) 219.0 (64.2) 208.8 (61.2) 198.6 (58.2) 188.2 (55.2) 177.8 (52.1)

-30 (-34.4) 198.8 (58.3) 189.6 (55.6) 180.6 (52.9) 171.4 (50.2) 162.2 (47.5) 152.8 (44.8)

-35 (-37.2) 170.6 (50) 162.4 (47.6) 154.2 (45.2) 146.0 (42.8) 137.8 (40.4) 129.2 (37.9)

-40 (-40) 144.8 (42.4) 137.2 (40.2) 129.8 (38) 122.4 (35.9) 114.8 (33.6) 107.2 (31.4)
0 (-17.8) 492.0 (144.2) 469.6 (137.6) 447.4 (131.1) 425.4 (124.7) 403.6 (118.3) 382.0 (112)

-5 (-20.6) 442.4 (129.7) 422.0 (123.7) 401.6 (117.7) 381.6 (111.8) 361.8 (106) 342.0 (100.2)

-10 (-23.3) 395.4 (115.9) 376.8 (110.4) 358.4 (105) 340.2 (99.7) 322.2 (94.4) 304.4 (89.2)

-15 (-26.1) 351.2 (102.9) 334.4 (98) 317.8 (93.1) 301.4 (88.3) 285.0 (83.5) 268.8 (78.8)

-20 (-28.9) 309.8 (90.8) 294.6 (86.3) 279.6 (81.9) 264.8 (77.6) 250.0 (73.3) 235.4 (69)

-25 (-31.7) 271.0 (79.4) 257.4 (75.4) 243.8 (71.5) 230.4 (67.5) 217.2 (63.7) 204.0 (59.8)

-30 (-34.4) 235.0 (68.9) 222.6 (65.2) 210.4 (61.7) 198.4 (58.1) 186.4 (54.6) 174.6 (51.2)

-35 (-37.2) 201.6 (59.1) 190.4 (55.8) 179.4 (52.6) 168.4 (49.4) 157.6 (46.2) 146.8 (43)

-40 (-40) 170.6 (50) 160.4 (47) 150.4 (44.1) 140.6 (41.2) 130.6 (38.3) 120.8 (35.4)

CAPACITY MBH (KW)

16.8) 380.8 (111.6) 363.0 (106.4) 345.0 (101.1) 326.8 (95.8)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 22 -

CAPACITY DATA -

R404A

R507

EXTENDED LOW TEMPERATURE

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD016V6-B

Compressor

Model

S4N-8.2Y

KVD024V6-B

Compressor

Model

S4G-12.2Y

KVD032V6-B

Compressor

Model

S6J-16.2Y

KVD040V6-B

Compressor

Model

S6H-20.2Y

KVD050V6-B

Compressor

Model

S6G-25.2Y

KVD060V6-B

Compressor

Model

S6F-30.2Y

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3)

-25 (-31.7) 78.2 (22.9) 77.2 (22.6) 76.0 (22.3) 75.0 (22) 73.8 (21.6) 72.6 (21.3)

-30 (-34.4) 69.8 (20.5) 68.8 (20.2) 67.8 (19.9) 66.8 (19.6) 65.6 (19.2) 64.6 (18.9)

-35 (-37.2) 62.0 (18.2) 61.0 (17.9) 60.2 (17.6) 59.2 (17.3) 58.2 (17.1) 57.0 (16.7)

-40 (-40) 54.8 (16.1) 54.0 (15.8) 53.2 (15.6) 52.2 (15.3) 51.2 (15) 50.2 (14.7)

-45 (-42.8) 48.4 (14.2) 47.6 (14) 46.8 (13.7) 46.0 (13.5) 45.0 (13.2) 44.0 (12.9)

-50 (-45.6) 42.4 (12.4) 41.8 (12.3) 41.0 (12) 40.2 (11.8) 39.4 (11.5) 38.4 (11.3)

-55 (-48.3) 37.0 (10.8) 36.4 (10.7) 35.6 (10.4) 35.0 (10.3) 34.2 (10) 33.4 (9.8)

-60 (-51.1) 32.0 (9.4) 31.4 (9.2) 30.8 (9) 30.2 (8.9) 29.6 (8.7) 28.8 (8.4)

-25 (-31.7) 121.4 (35.6) 119.6 (35.1) 117.8 (34.5) 115.8 (33.9) 113.8 (33.4) 111.8 (32.8)

-30 (-34.4) 109.8 (32.2) 108.0 (31.7) 106.2 (31.1) 104.4 (30.6) 102.4 (30) 100.2 (29.4)

-35 (-37.2) 98.6 (28.9) 97.0 (28.4) 95.2 (27.9) 93.4 (27.4) 91.6 (26.8) 89.6 (26.3)

-40 (-40) 88.2 (25.8) 86.6 (25.4) 85.0 (24.9) 83.2 (24.4) 81.4 (23.9) 79.6 (23.3)

-45 (-42.8) 78.2 (22.9) 76.8 (22.5) 75.2 (22) 73.6 (21.6) 72.0 (21.1) 70.2 (20.6)

-50 (-45.6) 69.0 (20.2) 67.8 (19.9) 66.2 (19.4) 64.8 (19) 63.2 (18.5) 61.8 (18.1)

-55 (-48.3) 60.4 (17.7) 59.2 (17.3) 58.0 (17) 56.6 (16.6) 55.2 (16.2) 54.0 (15.8)

-60 (-51.1) 52.4 (15.4) 51.4 (15.1) 50.2 (14.7) 49.0 (14.4) 48.0 (14.1) 46.8 (13.7)

-25 (-31.7) 168.2 (49.3) 165.6 (48.5) 163.0 (47.8) 160.4 (47) 157.8 (46.2) 155.4 (45.5)

-30 (-34.4) 152.2 (44.6) 149.6 (43.8) 147.2 (43.1) 144.6 (42.4) 142.0 (41.6) 139.6 (40.9)

-35 (-37.2) 137.0 (40.2) 134.6 (39.4) 132.2 (38.7) 129.8 (38) 127.4 (37.3) 124.8 (36.6)

-40 (-40) 122.8 (36) 120.6 (35.3) 118.2 (34.6) 116.0 (34) 113.6 (33.3) 111.2 (32.6)

-45 (-42.8) 109.4 (32.1) 107.4 (31.5) 105.2 (30.8) 103.0 (30.2) 100.8 (29.5) 98.6 (28.9)

-50 (-45.6) 97.0 (28.4) 95.0 (27.8) 93.0 (27.3) 91.0 (26.7) 89.0 (26.1) 87.0 (25.5)

-55 (-48.3) 85.4 (25) 83.6 (24.5) 81.8 (24) 80.0 (23.4) 78.0 (22.9) 76.2 (22.3)

-60 (-51.1) 74.6 (21.9) 73.0 (21.4) 71.4 (20.9) 69.8 (20.5) 68.2 (20) 66.4 (19.5)

-25 (-31.7) 197.6 (57.9) 194.8 (57.1) 191.8 (56.2) 188.8 (55.3) 185.6 (54.4) 182.4 (53.5)

-30 (-34.4) 179.0 (52.5) 176.2 (51.6) 173.2 (50.8) 170.2 (49.9) 167.2 (49) 164.0 (48.1)

-35 (-37.2)

-40 (-40) 144.4 (42.3) 141.8 (41.6) 139.2 (40.8) 136.4 (40) 133.6 (39.2) 130.8 (38.3)

-45 (-42.8) 128.6 (37.7) 126.2 (37) 123.8 (36.3) 121.2 (35.5) 118.6 (34.8) 115.8 (33.9)

-50 (-45.6) 113.8 (33.4) 111

-55 (-48.3) 100.0 (29.3) 98.0 (28.7) 96.0 (28.1) 93.8 (27.5) 91.6 (26.8) 89.4 (26.2)

-60 (-51.1) 87.4 (25.6) 85.6 (25.1) 83.6 (24.5) 81.8 (24) 79.8 (23.4) 78.0 (22.9)

-25 (-31.7) 224.4 (65.8) 221.2 (64.8) 217.8 (63.8) 214.2 (62.8) 210.4 (61.7) 206.8 (60.6)

-30 (-34.4) 203.2 (59.6) 200.0 (58.6) 196.8 (57.7) 193.2 (56.6) 189.6 (55.6) 186.0 (54.5)

-35 (-37.2) 183.2 (53.7) 180.2 (52.8) 177.0 (51.9) 173.6 (50.9) 170.2 (49.9) 166.6 (48.8)

-40 (-40) 164.2 (48.1) 161.4 (47.3) 158.2 (46.4) 155.0 (45.4) 151.8 (44.5) 148.6 (43.6)

-45 (-42.8) 146.4 (42.9) 143.8 (42.1) 140.8 (41.3) 137.8 (40.4) 134.8 (39.5) 131.8 (38.6)

-50 (-45.6) 129.8 (38) 127.2 (37.3) 124.6 (36.5) 121.8 (35.7) 119.0 (34.9) 116.2 (34.1)

-55 (-48.3) 114.2 (33.5) 111.8 (32.8) 109.4 (32.1) 106.8 (31.3) 104.4 (30.6) 101.8 (29.8)

-60 (-51.1) 99.6 (29.2) 97.6 (28.6) 95.4 (28) 93.2 (27.3) 91.0 (26.7) 88.8 (26)

-25 (-31.7) 266.6 (78.1) 262.2 (76.8) 257.8 (75.6) 253.2 (74.2) 248.6 (72.9) 244.0 (71.5)

-30 (-34.4) 241.4 (70.7) 237.4 (69.6) 233.0 (68.3) 228.6 (67) 224.2 (65.7) 219.6 (64.4)

-35 (-37.2) 217.6 (63.8) 213.8 (62.7) 209.6 (61.4) 205.4 (60.2) 201.2 (59) 197.0 (57.7)

-40 (-40) 195.2 (57.2) 191.4 (56.1) 187.6 (55) 183.6 (53.8) 179.6 (52.6) 175.6 (51.5)

-45 (-42.8) 174.0 (51) 170.6 (50) 167.0 (48.9) 163.4 (47.9) 159.6 (46.8) 156.0 (45.7)

-50 (-45.6) 154.2 (45.2) 151.0 (44.3) 147.8 (43.3) 144.4 (42.3) 141.0 (41.3) 137.8 (40.4)

-55 (-48.3) 135.8 (39.8) 133.0 (39) 130.0 (38.1) 127.0 (37.2) 124.0 (36.3) 121.0 (35.5)

-60 (-51.1) 118.6 (34.8) 116.2 (34.1) 113.6 (33.3) 110.8 (32.5) 108.2 (31.7) 105.6 (30.9)

161.2 (47.2) 158.6 (46.5) 155.6 (45.6) 152.8 (44.8) 149.8 (43.9) 146.8 (43)

CAPACITY MBH (KW)

.6 (32.7) 109.4 (32.1) 107.0 (31.4) 104.6 (30.7) 102.2 (30)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

NOTES

04/17/13

K40-KV-PDS-17

- 23 -

ELECTRICAL DATA -

04/17/13

K40-KV-PDS-17

- 24 -

60HzKVS-A

COPELAND

CONDENSING UNIT

MODEL

KVS015H8-

KVS025H8-

KVS030H8-

KVS035H8-

KVS040H8-

KVS015M8-

KVS025M8-

KVS030M8-

KVS035M8-

KVS040M8­KVS050M8- HT4B -A 6DUNR49ME-AWD 460/3/60 84.2 482 3 2 9.3 114.6 175

KVS010L6-

KVS015L6-

KVS022L6-

KVS027L6-

KVS030L6­KVS040L6- HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 2 2 6.2 86.1 125

* 6DJ only available in 230V

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 2 13.2 87.7 125
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 2 6.2 42.5 70
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 2 2 5.0 34.5 50
HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 2 2 13.2 147.1 250
HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 2 2 6.2 73.2 125
HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 2 2 5.0 53.5 90
HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 2 2 13.2 156.1 250
HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 2 2 6.2 77.6 125
HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 2 2 5.0 66.6 110
HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 3 2 19.8 196.6 300
HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 3 2 9.3 97.7 150
HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 3 2 7.5 74.5 125
HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 3 2 19.8 218.1 350
HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 3 2 9.3 108.4 175
HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 3 2 7.5 88.8 150
HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 2 13.2 87.7 125
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 2 6.2 42.5 70
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 2 2 5.0 34.5 50
HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 2 2 13.2 115.8 175
HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 2 2 6.2 57.6 90
HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 2 2 5.0 48.0 80
HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 2 2 13.2 145.0 250
HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 2 2 6.2 72.1 120
HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 2 2 5.0 60.2 100
HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 3 2 19.8 176.2 300
HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 3 2 9.3 87.5 150
HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 3 2 7.5 61.4 100
HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 3 2 19.8 198.4 300
HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 3 2 9.3 98.6 150
HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 3 2 7.5 72.6 120

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 2 6.6 58.4 90
HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 2 3.1 26.4 40
HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 2
HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 1 2 6.6 72.4 120
HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 1 2 3.1 36.0 60
HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 113 1 2 2.5
HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 2 13.2 93.6 150
HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 2 6.2 46.3 70
HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 2 5.0 41.4 70
HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 2 13.2 114.1 175
HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 2 6.2 56.7 90
HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 2 5.0 45.6 70
HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 2 13.2 132.7 225
HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 2 6.2 66.0 110
HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 2 5.0 54.5 90

SINGLE COMPESSOR MODELS

COMPRESSOR

MODEL NO.

POWER
SUPPLY

COMPRESSOR
RLA LRA QTY HP FLA MCA MOP

CONDENSER

FAN MOTOR

2.5 22.8 35

28.6 45

UNIT

ELECTRICAL DATA -

04/17/13

K40-KV-PDS-17

- 25 -

60HzKVD-A

COPELAND

CONDENSING UNIT

MODEL

KVD030H8-

KVD050H8-

KVD060H8-

KVD070H8-

KVD080H8-

KVD030M8-

KVD050M8-

KVD060M8-

KVD070M8-

KVD080M8-

KVS100M8- HT4B -A 6DUNR49ME-AWD 460/3/60 84.2 482 6 2 18.6 208.1 250

KVD020L6-

KVD030L6-

KVD044L6-

KVD054L6-

KVD060L6-

KVS080L6- HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 4 2 12.4 156.2 200

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 2 26.4 160.5 200
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 2 12.4 77.7 100
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 4 2 10.0 63.1 80
HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 4 2 26.4 267.4 350
HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 4 2 12.4 133.0 175
HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 4 2 10.0 97.3 125
HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 4 2 26.4 283.6 350
HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 4 2 12.4 140.9 175
HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 4 2 10.0 120.9 150
HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 6 2 39.6 357.8 400
HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 6 2 18.6 177.7 225
HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 6 2 15.0 135.6 175
HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 6 2 39.6 396.5 500
HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 6 2 18.6 197.0 250
HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 6 2 15.0 161.3 225
HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 2 26.4 160.5 200
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 2 12.4 77.7 100
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 4 2 10.0 63.1 80
HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 4 2 26.4 211.1 250
HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 4 2 12.4 104.9 125
HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 4 2 10.0 87.4 120
HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 4 2 26.4 263.6 350
HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 4 2 12.4 131.0 175
HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 4 2 10.0 109.3 150
HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 6 2 39.6 321.2 400
HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 6 2 18.6 159.4 200
HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 6 2 15.0 112.0 150
HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 6 2 39.6 361.0 500
HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 6 2 18.6 179.3 250
HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 6 2 15.0 132.2 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 2 2 13.2 106.4 125
HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 2 2 6.2 48.1 60
HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 2 2
HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 2 2 13.2 131.6 175
HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 2 2 6.2 65.4 90
HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 113 2 2 5.0
HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 4 2 26.4 171.1 225
HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 4 2 12.4 84.6 110
HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 4 2 10.0 75.5 100
HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 4 2 26.4 208.0 250
HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 4 2 12.4 103.3 125
HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 4 2 10.0 83.1 110
HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 4 2 26.4 241.5 300
HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 4 2 12.4 120.0 150
HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 4 2 10.0 99.1 125

DOUBLE COMPESSOR MODELS

COMPRESSOR

MODEL NO.

POWER
SUPPLY

COMPRESSOR
RLA LRA QTY HP FLA MCA MOP

CONDENSER

FAN MOTOR

UNIT

5.0 41.5 55

52.0 70

* 6DJ only available in 230V

BITZER

04/17/13

K40-KV-PDS-17

- 26 -

CONDENSING UNIT

MODEL

KVS015H8-

KVS020H8-

KVS025H8-

KVS030H8-

KVS035H8-

KVS040H8-

KVS015M8-

KVS020M8-

KVS025M8-

KVS030M8-

KVS035M8-

KVS040M8-

KVS050M8-

KVS012L6-

KVS015L6-

KVS020L6-

KVS025L6-

KVS030L6-

KVS040L6-

KVS008V6-

KVS012V6-

KVS016V6-

KVS020V6-

KVS025V6-

KVS030V6-

ELECTRICAL DATA -

60HzKVS-B

SINGLE COMPESSOR MODELS

COMPRESSOR

HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 2 2 13.2 81.1 125
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 2 2 6.2 40.1 60
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 2 2 5.0 32.3 50
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 2 2 5.0 37.9 60
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 2 2 13.2 118.6 200
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 2 2 6.2 58.8 100
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 2 2 5.0 47.0 80
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 2 2 13.2 138.2 225
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 2 2 6.2 68.7 110
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 2 2 5.0 55.0 90
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 3 2 19.8 166.2 275
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 3 2 9.3 82.6 125
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 3 2 7.5 65.5 110
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 3 2 19.8 216.2 350
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 3 2 9.3 107.6 175
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 3 2 7.5 86.1 125
HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 2 2 13.2 81.1 125
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 2 2 6.2 40.1 60
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 2 2 5.0 32.3 50
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 2 2 5.0 37.9 60
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 2 2 13.2 118.6 200
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 2 2 6.2 58.8 100
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 2 2 5.0 47.0 80
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 2 2 13.2 138.2 225
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 2 2 6.2 68.7 110
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 2 2 5.0 55.0 90
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 3 2 19.8 166.2 275
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 3 2 9.3 82.6 125
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 3 2 7.5 65.5 110
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 3 2 19.8 216.2 350
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 3 2 9.3 107.6 175
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 3 2 7.5 86.1 125
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 3 2 19.8 219.8 350
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 3 2 9.3 109.3 175
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 3 2 7.5 87.0 150
HT3B -B 4C2397SL-2NU-Y 208-230/3/60 44.3 252 1 2 6.6 62.0 100
HT4B -B 4C2397SL-2NU-Y 460/3/60 22.1 126 1 2 3.1 30.7 50
HT5B -B 4C2397SL-5PU-Y 575/3//60 17.7 101 1 2 2.5 24.6 40
HT3B -B 4B3139PL-2NU-Y 208-230/3/60 51.4 294 1 2 6.6 70.9 120
HT4B -B 4B3139PL-2NU-Y 460/3/60 25.7 147 1 2 3.1 35.2 60
HT5B -B 4B3139PL-5PU-Y 575/3//60 31.1 117 1 2 2.5
HT3B -B 4B3604PL-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4B3604PL-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4B3604PL-5PU-Y 575/3//60 25.7 140 2 2 5.0 37.1 60
HT3B -B 6B4709PL-2NU-Y 208-230/3/60 77.1 436 2 2 13.2 109.6 175
HT4B -B 6B4709PL-2NU-Y 460/3/60 38.6 218 2 2 6.2 54.5 90
HT5B -B 6B4709PL-5PU-Y 575/3//60 30.7 174 2 2 5.0 43.4 70
HT3B -B 6B5406PL-2NU-Y 208-230/3/60 94.3 490 2 2 13.2 131.1 225
HT4B -B 6B5406PL-2NU-Y 460/3/60 47.1 245 2 2 6.2 65.1 110
HT5B -B 6B5406PL-5PU-Y 575/3//60 37.1 196 2 2 5.0 51.4 80
HT3B -B 6B6462PL-2NU-Y 208-230/3/60 108.6 700 2 2 13.2 149.0 250
HT4B -B 6B6462PL-2NU-Y 460/3/60 54.3 350 2 2 6.2 74.1 125
HT5B -B 6B6462PL-5PU-Y 575/3//60 43.6 280 2 2 5.0 59.5 100
HT3B -B S4N-8.2Y-2NU 208-230/3/60 28.0 180 1 2 6.6 41.6 60
HT4B -B S4N-8.2Y-2NU 460/3/60 14.7 90 1 2 3.1 21.5 35
HT5B -B S4N-8.2Y-5PU 575/3//60 11.2 72 1 2 2.5 16.5 25
HT3B -B S4G-12.2Y-2NU 208-230/3/60 40.0 252 1 2 6.6 56.6 90
HT4B -B S4G-12.2Y-2NU 460/3/60 21.0 126 1 2 3.1 29.4 50
HT5B -B S4G-12.2Y-5PU 575/3//60 16.0 101 1 2 2.5 22.5 35
HT3B -B S6J-16.2Y-2NU 208-230/3/60 60.0 294 1 2 6.6 81.6 125
HT4B -B S6J-16.2Y-2NU 460/3/60 31.5 147 1 2 3.1 42.5 70
HT5B -B S6J-16.2Y-5PU 575/3//60 24.0 117 1 2 2.5 32.5 50
HT3B -B S6H-20.2Y-2NU 208-230/3/60 68.0 352 2 2 13.2 98.2 150
HT4B -B S6H-20.2Y-2NU 460/3/60 35.7 176 2 2 6.2 50.8 80
HT5B -B S6H-20.2Y-5PU 575/3//60 27.1 140 2 2 5.0 38.9 60
HT3B

-B S6G-25.2Y-2NU 208-230/3/60 82.9
HT4B -B S6G-25.2Y-2NU 460/3/60 43.1 218 2 2 6.2 60.1 100
HT5B -B S6G-25.2Y-5PU 575/3//60 33.1 174 2 2 5.0 46.4 70
HT3B -B S6F-30.2Y-2NU 208-230/3/60 96.0 490 2 2 13.2 133.2 225
HT4B -B S6F-30.2Y-2NU 460/3/60 50.4 245 2 2 6.2 69.2 110
HT5B -B S6F-30.2Y-5PU 575/3//60 38.2 196 2 2 5.0 52.8 90

MODEL NO.

POWER
SUPPLY

COMPRESSOR CONDENSER FAN MTR. UNIT
RLA LRA QTY HP FLA MCA MOP

41.4 70

436 2 2 13.2 116.8 175

BITZER

04/17/13

K40-KV-PDS-17

- 27 -

CONDENSING UNIT

MODEL

KVD030H8-

KVD040H8-

KVD050H8-

KVD060H8-

KVD070H8-

KVD080H8-

KVD030M8-

KVD040M8-

KVD050M8-

KVD060M8-

KVD070M8-

KVD080M8-

KVD100M8-

KVD024L6-

KVD030L6-

KVD040L6-

KVD050L6-

KVD060L6-

KVD080L6-

KVD016V6-

KVD024V6-

KVD032V6-

KVD040V6-

KVD050V6-

KVD060V6-

ELECTRICAL DATA -

60HzKVD-B

DOUBLE COMPESSOR MODELS

COMPRESSOR

HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 4 2 26.4 148.6 200
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 4 2 12.4 73.4 100
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 4 2 10.0 59.1 80
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 4 2 10.0 69.2 90
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 4 2 26.4 216.1 300
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 4 2 12.4 107.1 125
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 4 2 10.0 85.6 110
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 4 2 26.4 251.4 350
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 4 2 12.4 124.9 150
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 4 2 10.0 100.0 125
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 6 2 39.6 303.1 400
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 6 2 18.6 150.5 200
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 6 2 15.0 119.4 150
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 6 2 39.6 393.1 500
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 6 2 18.6 195.5 250
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 6 2 15.0 156.5 200
HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 4 2 26.4 148.6 200
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 4 2 12.4 73.4 100
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 4 2 10.0 59.1 80
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 4 2 10.0 69.2 90
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 4 2 26.4 216.1 300
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 4 2 12.4 107.1 125
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 4 2 10.0 85.6 110
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 4 2 26.4 251.4 350
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 4 2 12.4 124.9 150
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 4 2 10.0 100.0 125
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 6 2 39.6 303.1 400
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 6 2 18.6 150.5 200
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 6 2 15.0 119.4 150
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 6 2 39.6 393.1 500
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 6 2 18.6 195.5 250
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 6 2 15.0 156.5 200
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 6 2 39.6 399.6 500
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 6 2 18.6 198.6 250
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 6 2 15.0 158.1 200
HT3B -B 4C2397SL-2NU-Y 208-230/3/60 44.3 252 2 2 13.2 112.9 150
HT4B -B 4C2397SL-2NU-Y
HT5B -B 4C2397SL-5PU-Y 575/3//60 17.7 101 2 2 5.0 44.8 60
HT3B -B 4B3139PL-2NU-Y 208-230/3/60 51.4 294 2 2 13.2 128.9 175
HT4B -B 4B3139PL-2NU-Y 460/3/60 25.7 147 2 2 6.2 64.0 80
HT5B -B 4B3139PL-5PU-Y 575/3//60 31.1 117 2 2 5.0 75.0 100

HT3B -B 4B3604PL-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4B3604PL-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4B3604PL-5PU-Y 575/3//60 25.7 140 4 2 10.0 67.8 90
HT3B -B 6B4709PL-2NU-Y 208-230/3/60 77.1 436 4 2 26.4 199.9 250
HT4B -B 6B4709PL-2NU-Y 460/3/60 38.6 218 4 2 12.4 99.3 125
HT5B -B 6B4709PL-5PU-Y 575/3//60 30.7 174 4 2 10.0 79.1 100
HT3B -B 6B5406PL-2NU-Y 208-230/3/60 94.3 490 4 2 26.4 238.6 300
HT4B -B 6B5406PL-2NU-Y 460/3/60 47.1 245 4 2 12.4 118.4 150
HT5B -B 6B5406PL-5PU-Y 575/3//60 37.1 196 4 2 10.0 93.5 125
HT3B -B 6B6462PL-2NU-Y 208-230/3/60 108.6 700 4 2 26.4 270.8 350
HT4B -B 6B6462PL-2NU-Y 460/3/60 54.3 350 4 2 12.4 134.6 175
HT5B -B 6B6462PL-5PU-Y 575/3//60 43.6 280 4 2 10.0 108.1 150
HT3B -B S4N-8.2Y-2NU 208-230/3/60 28.0 180 2 2 13.2 76.2 100
HT4B -B S4N-8.2Y-2NU 460/3/60 14.7 90 2 2 6.2 39.3 50
HT5B -B S4N-8.2Y-5PU 575/3//60 11.2 72 2 2 5.0 30.2 40
HT3B -B S4G-12.2Y-2NU 208-230/3/60 40.0 252 2 2 13.2 103.2 125
HT4B -B S4G-12.2Y-2NU 460/3/60 21.0 126 2 2 6.2 53.5 70
HT5B -B S4G-12.2Y-5PU 575/3//60 16.0 101 2 2 5.0 41.0 50
HT3B -B S6J-16.2Y-2NU 208-230/3/60 60.0 294 2 2 13.2 148.2 200
HT4B -B S6J-16.2Y-2NU 460/3/60 31.5 147 2 2 6.2 77.1 100
HT5B -B S6J-16.2Y-5PU 575/3//60 24.0 117 2 2 5.0 59.0 80
HT3B -B S6H-20.2Y-2NU 208-230/3/60 68.0 352 4 2 26.4 179.4 225
HT4B -B S6H-20.2Y-2NU 460/3/60 35.7 176 4 2 12.4 92.7 110
HT5B -B S6H-20.2Y-5PU 575/3//60 27.1 140 4 2 10.0 71.0 90
HT3B

-B S6G-25.2Y-2NU 208-230/3/60 82.9
HT4B -B S6G-25.2Y-2NU 460/3/60 43.1 218 4 2 12.4 109.4 150
HT5B -B S6G-25.2Y-5PU 575/3//60 33.1 174 4 2 10.0 84.5 110
HT3B -B S6F-30.2Y-2NU 208-230/3/60 96.0 490 4 2 26.4 242.4 300
HT4B -B S6F-30.2Y-2NU 460/3/60 50.4 245 4 2 12.4 125.8 175
HT5B -B S6F-30.2Y-5PU 575/3//60 38.2 196 4 2 10.0 96.0 125

MODEL NO.

POWER
SUPPLY

460/3/60 22.1 126 2 2 6.2 55.9 70

COMPRESSOR CONDENSER FAN MTR. UNIT
RLA LRA QTY HP FLA MCA MOP

436 4 2 26.4 212.9 250

KVS

04/17/13

K40-KV-PDS-17

- 28 -

SINGLE COMPESSOR MODELS

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

REMOVEABLE
ROOF SECTION

DIMENSIONAL DATA -

TOP VIEW

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

53 5/8

1361

HINGED SERVICE DOOR HINGED SERVICE DOOR

56 1/4
1429

69 1/8
1757

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

SIDE VIEW

23 3/8
593

BASE FRAME LENGTH

(SEE OPPOSITE PAGE)

222 3/8

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD )
( REPLACEABLE CORE )

28 1/2

724

55

1397

20

508

5

127

REMOVEABLE
ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD )
( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

69 1/8
1757

23 3/8
593

53 5/8

1361

56 1/4
1429

222 3/8

KVS

04/17/13

K40-KV-PDS-17

- 29 -

DIMENSIONAL DATA -

SINGLE COMPESSOR MODELS

COMPRESSOR-END VIEW

HINGED SERVICE DOOR

ELECTRICAL
K'OUTS

44 3/4
1137

KVS-A

COPELAND

CONDENSING

UNIT

MODEL

KVS010L6-H**B-A 112 3/8 2854
KVS015L6-H**B-A 112 3/8 2854
KVS022L6-H**B-A 167 3/8 4251
KVS027L6-H**B-A 167 3/8 4251
KVS030L6-H**B-A 167 3/8 4251

KVS040L6-H**B-A 167 3/8 4251
KVS015M8-H**B-A 167 3/8 4251
KVS025M8-H**B-A 167 3/8 4251
KVS030M8-H**B-A 167 3/8 4251
KVS035M8-H**B-A 222 3/8 5648
KVS040M8-H**B-A 222 3/8 5648
KVS050M8-H**B-A 222 3/8 5648
KVS015H8-H**B-A 167 3/8 4251
KVS020H8-H**B-A 167 3/8 4251
KVS025H8-H**B-A 167 3/8 4251
KVS030H8-H**B-A 167 3/8 4251
KVS035H8-H**B-A 222 3/8 5648
KVS040H8-H**B-A 222 3/8 5648

BASE FRAME

LENGTH

inches mm

KVS-B

BITZER

CONDENSING

UNIT

MODEL

KVS012L6-H**B-B 112 3/8 2854
KVS015L6-H**B-B 112 3/8 2854
KVS020L6-H**B-B 167 3/8 4251
KVS025L6-H**B-B 167 3/8 4251
KVS030L6-H**B-B 167 3/8 4251

KVS040L6-H**B-B 167 3/8 4251
KVS015M8-H**B-B 167 3/8 4251
KVS020M8-H**B-B 167 3/8 4251
KVS025M8-H**B-B 167 3/8 4251
KVS030M8-H**B-B 167 3/8 4251
KVS035M8-H**B-B 222 3/8 5648
KVS040M8-H**B-B 222 3/8 5648
KVS050M8-H**B-B 222 3/8 5648
KVS015H8-H**B-B 167 3/8 4251
KVS020H8-H**B-B 167 3/8 4251
KVS025H8-H**B-B 167 3/8 4251
KVS030H8-H**B-B 167 3/8 4251
KVS035H8-H**B-B 222 3/8 5648
KVS040H8-H**B-B 222 3/8 5648

KVS008V6-H**B-B 112 3/8 2854

KVS012V6-H**B-B 112 3/8 2854

KVS016V6-H**B-B 112 3/8 2854

KVS020V6-H**B-B 167 3/8 4251

KVS025V6-H**B-B 167 3/8 4251

KVS030V6-H**B-B 167 3/8 4251

inches mm

BASE FRAME

LENGTH

KVD

04/17/13

K40-KV-PDS-17

- 30 -

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

COMPRESSOR #1
REMOVEABLE
ROOF SECTION

DIMENSIONAL DATA -

DOUBLE COMPESSOR MODELS

TOP VIEW

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

COMPRESSOR #2
REMOVEABLE
ROOF SECTION

HINGED SERVICE DOOR HINGED SERVICE DOOR

CONDENSER FAN #1R

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD )
REPLACEABLE CORE

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2R

CONDENSER FAN #3R

28 1/2

724

55

1397

20

508

69 1/8
1757

23 3/8
593

222 3/8

BASE FRAME LENGTH

(SEE OPPOSITE PAGE)

5

127

69 1/8
1757

23 3/8
593

222 3/8

LIQUID FILTER DRIER ( STANDARD )
REPLACEABLE CORE

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

COMPRESSOR #1
REMOVEABLE
ROOF SECTION

COMPRESSOR #2
REMOVEABLE
ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #1R

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

KVD

04/17/13

K40-KV-PDS-17

- 31 -

DIMENSIONAL DATA -

DOUBLE COMPESSOR MODELS

COMPRESSOR-END VIEW

ELECTRICAL
K'OUTS

HINGED SERVICE DOOR
COMPRESSOR #1

KVD-A

COPELAND

CONDENSING

UNIT

MODEL

KVD020L6-H**B-A 112 3/8 2854
KVD030L6-H**B-A 112 3/8 2854
KVD044L6-H**B-A 167 3/8 4251
KVD054L6-H**B-A 167 3/8 4251
KVD060L6-H**B-A 167 3/8 4251

KVD080L6-H**B-A 167 3/8 4251
KVD030M8-H**B-A 167 3/8 4251
KVD040M8-H**B-A 167 3/8 4251
KVD050M8-H**B-A 167 3/8 4251
KVD060M8-H**B-A 167 3/8 4251
KVD070M8-H**B-A 222 3/8 5648
KVD080M8-H**B-A 222 3/8 5648
KVD100M8-H**B-A 222 3/8 5648
KVD030H8-H**B-A 167 3/8 4251
KVD040H8-H**B-A 167 3/8 4251
KVD050H8-H**B-A 167 3/8 4251
KVD060H8-H**B-A 167 3/8 4251
KVD070H8-H**B-A 222 3/8 5648
KVD080H8-H**B-A 222 3/8 5648

BASE FRAME

LENGTH

inches mm

86 3/4
2203

HINGED SERVICE DOOR
COMPRESSOR #2

KVD-B

BITZER

CONDENSING

MODEL

KVD024L6-H**B-B 112 3/8 2854
KVD030L6-H**B-B 112 3/8 2854
KVD040L6-H**B-B 167 3/8 4251
KVD050L6-H**B-B 167 3/8 4251
KVD060L6-H**B-B 167 3/8 4251

KVD080L6-H**B-B 167 3/8 4251
KVD030M8-H**B-B 167 3/8 4251
KVD040M8-H**B-B 167 3/8 4251
KVD050M8-H**B-B 167 3/8 4251
KVD060M8-H**B-B 167 3/8 4251
KVD070M8-H**B-B 222 3/8 5648
KVD080M8-H**B-B 222 3/8 5648
KVD100M8-H**B-B 222 3/8 5648

KVD030H8-H**B-B 167 3/8 4251

KVD040H8-H**B-B 167 3/8 4251

KVD050H8-H**B-B 167 3/8 4251

KVD060H8-H**B-B 167 3/8 4251

KVD070H8-H**B-B 222 3/8 5648

KVD080H8-H**B-B 222 3/8 5648

KVD016V6-H**B-B 112 3/8 2854

KVD024V6-H**B-B 112 3/8 2854

KVD032V6-H**B-B 112 3/8 2854

KVD040V6-H**B-B 167 3/8 4251

KVD050V6-H**B-B 167 3/8 4251

KVD060V6-H**B-B 167 3/8 4251

UNIT

BASE FRAME

inches mm

LENGTH

SPECIFICATIONS -

04/17/13

K40-KV-PDS-17

- 32 -

60HzKVS-A

COPELAND

CONDENSING

UNIT

MODEL

KVS015H8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 2155 979
KVS025H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091
KVS030H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2500 1136
KVS035H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379

KVS040H8-H**B-A 3 2 1/8 54 1 3/8 35 189 85.8 3165 1438
KVS015M8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 2160 982
KVS025M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2405 1093
KVS030M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2510 1141
KVS035M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379
KVS040M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3165 1438
KVS050M8-H**B-A 3 2 1/8 54 1 1/8 29 254 115.3 3285 1493

KVS010L6-H**B-A 1 1 3/8 35 5/8 16 70 31.8 1675 761

KVS015L6-H**B-A 1 1 5/8 41 7/8 22 82 37.2 1800 818

KVS022L6-H**B-A 2 2 1/8 54 7/8 22 103 46.7 2285 1039

KVS027L6-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2510 1141

KVS030L6-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 2515 1143

KVS040L6-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 2645 1202

CONDENSER

FANS

SINGLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

APPROX.

SHIPPING WEIGHT

SPECIFICATIONS -

60HzKVD-A

COPELAND

CONDENSING

UNIT

MODEL

KVD030H8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 3865 1757

KVD050H8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4345 1975

KVD060H8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4540 2063

KVD070H8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5510 2504

KVD080H8-H**B-A 3 2 1/8 54 1 3/8 35 189 85.8 5760 2618
KVD030M8-H**B-A 2 1 5/8 41 7/8 22 103 46.7 3875 1761
KVD050M8-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4355 1979
KVD060M8-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4555 2070
KVD070M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5515 2506
KVD080M8-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5760 2618
KVD100M8-H**B-A 3 2 1/8 54 1 1/8 29 254 115.3 6005 2729

KVD020L6-H**B-A 1 1 3/8 35 5/8 16 70 31.8 2975 1352

KVD030L6-H**B-A 1 1 5/8 41 7/8 22 82 37.2 3225 1466

KVD044L6-H**B-A 2 2 1/8 54 7/8 22 103 46.7 4120 1872

KVD054L6-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4570 2077

KVD060L6-H**B-A 2 2 1/8 54 1 1/8 29 124 56.3 4580 2082

KVD080L6-H**B-A 2 2 1/8 54 1 1/8 29 157 71.2 4830 2195

CONDENSER

FANS

DOUBLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER

CAPACITY

90% FULL *

APPROX.

SHIPPING WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407C

1.10 1.15 1.00

R404A

R404A

R22

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

SPECIFICATIONS -

04/17/13

K40-KV-PDS-17

- 33 -

BITZER

CONDENSING

UNIT

MODEL

KVS015H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2085 948
KVS020H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2175 989
KVS025H8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091
KVS030H8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2505 1138
KVS035H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 2990 1359
KVS040H8-H**B-B 3 2 1/8 54 1 3/8 35 189 85.8 3120 1418
KVS015M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2090 950
KVS020M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 2170 986
KVS025M8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2400 1091
KVS030M8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2515 1143
KVS035M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 2995 1361
KVS040M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3115 1416
KVS050M8-H**B-B 3 2 1/8 54 1 1/8 29 254 115.3 3230 1468

KVS012L6-H**B-B 1 1 3/8 35 5/8 16 70 31.8 1580 718
KVS015L6-H**B-B 1 1 5/8 41 7/8 22 82 37.2 1750 795
KVS020L6-H**B-B 2 2 1/8 54 7/8 22 103 46.7 2250 1023
KVS025L6-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2445 1111
KVS030L6-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 2470 1123

KVS040L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2600 1182
KVS008V6-H**B-B 1 1 1/8 29 1/2 13 70 31.8 1585 720
KVS012V6-H**B-B 1 1 3/8 35 5/8 16 82 37.2 1705 775
KVS016V6-H**B-B 1 1 5/8 41 5/8 16 82 37.2 1860 845
KVS020V6-H**B-B 2 2 1/8 54 5/8 16 124 56.3 2435 1107
KVS025V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 2470 1123
KVS030V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 2545 1157

CONDENSER

FANS

SINGLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

60HzKVS-B

APPROX.

SHIPPING WEIGHT

SPECIFICATIONS -

BITZER

CONDENSING

UNIT

MODEL

KVD030H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3725 1693
KVD040H8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3895 1770
KVD050H8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4340 1972
KVD060H8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4550 2068
KVD070H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5425 2466
KVD080H8-H**B-B 3 2 1/8 54 1 3/8 35 189 85.8 5670 2577
KVD030M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3735 1698
KVD040M8-H**B-B 2 1 5/8 41 7/8 22 103 46.7 3880 1763
KVD050M8-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4350 1977
KVD060M8-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4565 2075
KVD070M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5430 2468
KVD080M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5665 2575
KVD100M8-H**B-B 3 2 1/8 54 1 1/8 29 254 115.3 5895 2679

KVD024L6-H**B-B 1 1 3/8 35 5/8 16 70 31.8 2790 1268
KVD030L6-H**B-B 1 1 5/8 41 7/8 22 82 37.2 3120 1418
KVD040L6-H**B-B 2 2 1/8 54 7/8 22 103 46.7 4055 1843
KVD050L6-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4440 2018
KVD060L6-H**B-B 2 2 1/8 54 1 1/8 29 124 56.3 4480 2036

KVD080L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4745 2157
KVD016V6-H**B-B 1 1 1/8 29 1/2 13 70 31.8 2795 1270
KVD024V6-H**B-B 1 1 3/8 35 5/8 16 82 37.2 3030 1377
KVD032V6-H**B-B 1 1 5/8 41 5/8 16 82 37.2 3345 1520
KVD040V6-H**B-B 2 2 1/8 54 5/8 16 124 56.3 4415 2007
KVD050V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 4485 2038
KVD060V6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 4630 2104

CONDENSER

FANS

DOUBLE COMPESSOR MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

APPROX. SHIPPING

60HzKVD-B

WEIGHT

ON MODELS USING “8” AS REFRIGERANT CODE. FOR ALERNATE REFRIGERANTS,

* PUBLISHED RECEIVER CAPACITY IS BASED ON

MULTIPLY

* NOTE ON ALTERNATE REFRIGERANTS:

R404A

VALUE BY THE APPROPRIATE VALUE AT RIGHT:

R404A

R407C

1.10 1.15 1.00

R22

R507

KVS/D

04/17/13

K40-KV-PDS-17

- 34 -

CONDENSING UNIT WIRING DIAGRAM -

COMPRESSOR #1

KVS/D

04/17/13

K40-KV-PDS-17

- 35 -

CONDENSING UNIT WIRING DIAGRAM -

COMPRESSOR #2

KVS/D

04/17/13

K40-KV-PDS-17

- 36 -

AIR DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #1

KVS/D

04/17/13

K40-KV-PDS-17

- 37 -

AIR DEFROST EVAP. WIRING DIAGRAM -

COMPRESSOR #2

KVS/D

04/17/13

K40-KV-PDS-17

- 38 -

ELECTRIC DEFROST EV AP. WIRING DIAGRAM -

COMPRESSOR #1

KVS/D

04/17/13

K40-KV-PDS-17

- 39 -

ELECTRIC DEFROST EV AP. WIRING DIAGRAM -

COMPRESSOR #2

COPELAND

04/17/13

K40-KV-PDS-17

- 40 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS016H8-A

Compressor

Model

3DS3R17ME

KVS026H8-A

Compressor

Model

4DHNR22ME

HIGH EFFICIENCY MODELS

KVS031H8-A

Compressor

Model

4DJNR28ME

KVS036H8-A

Compressor

Model

6DHNR35ME

KVS041H8-A

Compressor

Model

6DJNR40ME

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 245.9 (72.1) 236.6 (69.3) 227.5 (66.7) 218.8 (64.1) 210.3 (61.6) 202.0 (59.2) 194.0 (56.9)
50 (10) 225.7 (66.1) 217.4 (63.7) 209.3 (61.3) 201.4 (59) 193.8 (56.8) 186.4 (54.6) 179.1 (52.5)
45 (7.2) 206.5 (60.5) 199.1 (58.4) 191.9 (56.2) 184.9 (54.2) 178.1 (52.2) 171.5 (50.3) 164.9 (48.3)
40 (4.4) 188.3 (55.2) 181.7 (53.3) 175.4 (51.4) 169.2 (49.6) 163.1 (47.8) 157.2 (46.1) 151.3 (44.3)
35 (1.7) 171.1 (50.1) 165.3 (48.4) 159.7 (46.8) 154.3 (45.2) 148.9 (43.6) 143.5 (42.1) 138.2 (40.5)
55 (12.8) 375.4 (110) 355.8 (104.3) 336.6 (98.6) 317.7 (93.1) 299.3 (87.7) 281.4 (82.5) 264.1 (77.4)
50 (10) 342.8 (100.5) 325.2 (95.3) 308.0 (90.3) 291.2 (85.3) 274.8 (80.5) 258.9 (75.9) 243.6 (71.4)
45 (7.2) 311.5 (91.3) 295.9 (86.7) 280.7 (82.3) 265.8 (77.9) 251.4 (73.7) 237.4 (69.6) 224.1 (65.7)
40 (4.4) 281.7 (82.6) 268.1 (78.6) 254.8 (74.7) 241.7 (70.8) 229.1 (67.1) 217.0 (63.6) 205.5 (60.2)
35 (1.7) 253.7 (74.4) 241.8 (70.9) 230.3 (67.5) 219.0 (64.2) 208.1 (61) 197.6 (57.9) 187.7 (55)
55 (12.8) 445.5 (130.6) 422.7 (123.9) 400.4 (117.3) 378.6 (111) 357.2 (104.7) 336.3 (98.6) 316.0 (92.6)
50 (10) 404.1 (118.4) 383.7 (112.5) 363.8 (106.6) 344.4 (100.9) 325.5 (95.4) 307.1 (90) 289.2 (84.8)
45 (7.2) 365.2 (107) 347.2 (101.8) 329.7 (96.6) 312.6 (91.6) 296.1 (86.8) 280.0 (82.1) 264.5 (77.5)
40 (4.4) 329.0 (96.4) 313.3 (91.8) 298.0 (87.3) 283.2 (83) 268.9 (78.8) 255.0 (74.7) 241.7 (70.8)
35 (1.7) 295.4 (86.6) 281.9 (82.6) 268.7 (78.7) 256.0 (75) 243.8 (71.5) 232.0 (68) 220.7 (64.7)
55 (12.8) 549.2 (161) 527.9 (154.7) 506.5 (148.4) 485.0 (142.1) 463.5 (135.8) 441.8 (129.5) 420.1 (123.1)

50 (10) 491.4 (144) 472.6 (138.5) 453.7 (133) 434.7 (127.4) 415.6 (121.8) 396.4 (116.2) 377.0 (110.5)
45 (7.2) 439.3 (128.7) 422.8 (123.9) 406.2 (119) 389.5 (114.2) 372.7 (109.2) 355.7 (104.2) 338.5 (99.2)
40 (4.4) 392.5 (115) 378.2 (110.8) 363.7 (106.6) 349.1 (102.3) 334.4 (98) 319.5 (93.6) 304.4 (89.2)
35 (1.7) 350.7 (102.8) 338.4 (99.2) 325.9 (95.5) 313.2 (91.8) 300.4 (88) 287.4 (84.2) 274.1 (80.3)
55 (12.8) 765.3 (224.3) 733.4 (214.9) 699.1 (204.9) 662.7 (194.2) 624.3 (183) 584.2 (171.2) 542.7 (159)
50 (10) 671.5 (196.8) 643.2 (188.5) 612.4 (179.5) 579.5 (169.8) 544.8 (159.7) 508.5 (149) 470.8 (138)

45 (7.2) 588.3 (172.4) 563.2 (165.1) 535.8 (157) 506.3 (148.4) 475.1 (139.2) 442.4 (129.7) 408.4 (119.7)
40 (4.4) 515.7 (151.1) 493.4 (144.6) 469.0 (137.4) 442.6 (129.7) 414.7 (121.5) 385.5 (113) 355.2 (104.1)
35 (1.7) 452.9 (132.7) 433.2 (127) 411.5 (120.6) 388.1 (1

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

13.7) 363.3 (106.5) 337.4 (98.9) 310.6 (91)

COPELAND

CONDENSING

UNIT

MODEL

KVS016H8-A

Compressor

3DS3R17ME

KVS026H8-A

Compressor

4DHNR22ME

KVS031H8-A

Compressor

4DJNR28ME

KVS036H8-A

Compressor

6DHNR35ME

KVS041H8-A

Compressor

6DJNR40ME

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 231.5 (67.8) 221.6 (64.9) 211.7 (62) 202.0 (59.2) 192.4 (56.4) 182.9 (53.6) 173.5 (50.8)
40 (4.4) 212.9 (62.4) 203.8 (59.7) 194.8 (57.1) 185.9 (54.5) 177.2 (51.9) 168.5 (49.4) 159.9 (46.9)
35 (1.7) 195.3 (57.2) 187.0 (54.8) 178.8 (52.4) 170.7 (50) 162.7 (47.7) 154.8 (45.4) 147.0 (43.1)
45 (7.2) 310.7 (91.1) 297.1 (87.1) 283.9 (83.2) 271.1 (79.5) 258.7 (75.8) 246.6 (72.3) 234.7 (68.8)
40 (4.4) 288.9 (84.7) 276.3 (81) 264.0 (77.4) 252.1 (73.9) 240.5 (70.5) 229.2 (67.2) 218.2 (63.9)
35 (1.7) 267.2 (78.3) 255.5 (74.9) 244.1 (71.5) 233.0 (68.3) 222.3 (65.1) 211.8 (62.1) 201.6 (59.1)
45 (7.2) 381.3 (111.7) 365.0 (107) 348.9 (102.3) 332.9 (97.6) 317.0 (92.9) 301.1 (88.2) 285.3 (83.6)
40 (4.4) 351.3 (103) 336.2 (98.5) 321.3 (94.2) 306.5 (89.8) 291.8 (85.5) 277.1 (81.2) 262.5 (76.9)
35 (1.7) 322.5 (94.5) 308.6 (90.4) 294.9 (86.4) 281.3 (82.4) 267.7 (78.5) 254.3 (74.5) 240.8 (70.6)
45 (7.2) 487.6 (142.9) 467.3 (137) 447.0 (131) 426.7 (125.1) 406.2 (119) 385.7 (113) 365.1 (107)
40 (4.4) 447.0 (131) 428.5 (125.6) 409.9 (120.1) 391.3 (114.7) 372.6 (109.2) 353.8 (103.7) 335.0 (98.2)
35 (1.7) 408.7 (119.8) 391.8 (114.8) 374.9 (109.9) 357.9 (104.9) 340.9 (99.9) 323.7 (94.9) 306.6 (89.9)
45 (7.2) 551.9 (161.7) 529.9 (155.3) 508.0 (148.9) 486.1 (142.5) 464.0 (136) 441.8 (129.5) 419.2 (122.9)
40 (4.4) 509.9 (149.4) 489.5 (143.5) 469.2 (137.5) 448.9 (131.6) 428.6 (125.6) 408.1 (119.6) 387.3 (113.5)
35 (1.7) 469.5 (137.6) 450.7 (132.1) 432.0 (126.6) 413.3 (121.1) 394.5 (115.6) 375.6 (110.1) 356.5 (104.5)

CAPACITY DATA -

R404A

R507

HIGH TEMP. HIGH EFFICIENCY MODELS

CAPACITY MBH (KW)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

R404A R507

AMBIENT TEMPERATURE °F (°C)

60HzKVS-A

COPELAND

04/17/13

K40-KV-PDS-17

- 41 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS016M8-A

Compressor

Model

3DS3R17ME

KVS026M8-A

Compressor

Model

4DHNR22ME

KVS031M8-A

Compressor

Model

4DJNR28ME

KVS036M8-A

Compressor

Model

6DHNR35ME

KVS041M8-A

Compressor

Model

6DJNR40ME

KVS051M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C
30 (-1.1) 178.5 (52.3) 171.0 (50.1) 163.6 (47.9) 156.3 (45.8) 149.1 (43.7) 141.9 (41.6) 134.9 (39.5)
25 (-3.9) 162.7 (47.7) 156.0 (45.7) 149.3 (43.8) 142.7 (41.8) 136.2 (39.9) 129.7 (38) 123.4 (36.2)
20 (-6.7) 147.8 (43.3) 141.8 (41.6) 135.8 (39.8) 129.9 (38.1) 124.0 (36.3) 118.3 (34.7) 112.6 (33)
15 (-9.4) 133.9 (39.2) 128.5 (37.7) 123.1 (36.1) 117.8 (34.5) 112.6 (33) 107.5 (31.5) 102.4 (30)
10 (-12.2) 120.9 (35.4) 116.0 (34) 111.3 (32.6) 106.6 (31.2) 101.9 (29.9) 97.3 (28.5) 92.8 (27.2)

5 (-15) 108.8 (31.9) 104.5 (30.6) 100.2 (29.4) 96.0 (28.1) 91.9 (26.9) 87.8 (25.7) 83.8 (24.6)

0 (-17.8) 97.5 (28.6) 93.7 (27.5) 89.9 (26.3) 86.2 (25.3) 82.5 (24.2) 78.9 (23.1) 75.3 (22.1)
30 (-1.1) 245.7 (72) 234.9 (68.8) 224.4 (65.8) 214.2 (62.8) 204.2 (59.8) 194.6 (57) 185.1 (54.2)
25 (-3.9) 224.7 (65.9) 214.7 (62.9) 205.0 (60.1) 195.7 (57.4) 186.5 (54.7) 177.6 (52) 168.9 (49.5)
20 (-6.7) 204.2 (59.8) 195.1 (57.2) 186.3 (54.6) 177.7 (52.1) 169.4 (49.6) 161.2 (47.2) 153.2 (44.9)
15 (-9.4) 184.5 (54.1) 176.2 (51.6) 168.2 (49.3) 160.5 (47) 152.9 (44.8) 145.5 (42.6) 138.2 (40.5)
10 (-12.2) 165.8 (48.6) 158.4 (46.4) 151.2 (44.3) 144.2 (42.3) 137.4 (40.3) 130.7 (38.3) 124.1 (36.4)

5 (-15) 148.4 (43.5) 141.8 (41.6) 135.4 (39.7) 129.2 (37.9) 123.1 (36.1) 117.0 (34.3) 111.0 (32.5)

0 (-17.8) 132.3 (38.8) 126.5 (37.1) 120.9 (35.4) 115.4 (33.8) 110.1 (32.3) 104.7 (30.7) 99.3 (29.1)
30 (-1.1) 295.0 (86.5) 282.2 (82.7) 269.6 (79) 257.2 (75.4) 244.8 (71.7) 232.5 (68.1) 220.2 (64.5)
25 (-3.9) 268.7 (78.7) 257.1 (75.3) 245.6 (72) 234.2 (68.6) 223.0 (65.4) 211.8 (62.1) 200.6 (58.8)
20 (-6.7) 243.8 (71.5) 233.2 (68.3) 222.8 (65.3) 212.5 (62.3) 202.3 (59.3) 192.2 (56.3) 182.1 (53.4)
15 (-9.4) 220.2 (64.5) 210.7 (61.7) 201.3 (59) 192.0 (56.3) 182.8 (53.6) 173.7 (50.9) 164.7 (48.3)
10 (-12.2) 198.0 (58) 189.4 (55.5) 181.0 (53) 172.7 (50.6) 164.5 (48.2) 156.4 (45.8) 148.3 (43.5)

5 (-15) 177.2 (51.9) 169.6 (49.7) 162.1 (47.5) 154.7 (45.3) 147.4 (43.2) 140.3 (41.1) 133.1 (39)

0 (-17.8) 157.9 (46.3) 151.1 (44.3) 144.4 (42.3) 137.9 (40.4) 131.6 (38.6) 125.3 (36.7) 119.0 (34.9)
30 (-1.1) 372.6 (109.2) 357.3 (104.7) 341.9 (100.2) 326.4 (95.7) 311.0 (91.1) 295.4 (86.6) 279.8 (82)
25 (-3.9) 338.7 (99.3) 324.8 (95.2) 310.9 (91.1) 296.9 (87) 282.9 (82.9) 268.8
20 (-6.7) 307.1 (90) 294.5 (86.3) 281.9 (82.6) 269.2 (78.9) 256.5 (75.2) 243.8 (71.5) 231.1 (67.7)
15 (-9.4) 277.6 (81.4) 266.2 (78) 254.8 (74.7) 243.4 (71.3) 231.9 (68) 220.5 (64.6) 209.0 (61.3)
10 (-12.2) 250.2 (73.3) 239.9 (70.3) 229.6 (67.3) 219.3 (64.3) 208.9 (61.2) 198.6 (58.2) 188.3 (55.2)

5 (-15) 224.9 (65.9) 215.6 (63.2) 206.2 (60.4) 196.8 (57.7) 187.5 (55) 178.2 (52.2) 168.9 (49.5)

0 (-17.8) 201.7 (59.1) 193.1 (56.6) 184.5 (54.1) 176.0 (51.6) 167.6 (49.1) 159.1 (46.6) 150.7 (44.2)
30 (-1.1) 430.8 (126.3) 413.5 (121.2) 396.2 (116.1) 379.1 (111.1) 361.9 (106.1) 344.6 (101) 327.1 (95.9)
25 (-3.9) 393.9 (1
20 (-6.7) 358.8 (105.2) 344.2 (100.9) 329.8 (96.7) 315.4 (92.4) 301.2 (88.3) 286.8 (84.1) 272.3 (79.8)
15 (-9.4) 325.7 (95.5) 312.3 (91.5) 299.1 (87.7) 286.1 (83.8) 273.2 (80.1) 260.2 (76.3) 247.0 (72.4)
10 (-12.2) 294.6 (86.3) 282.3 (82.7) 270.3 (79.2) 258.5 (75.8) 246.8 (72.3) 235.1 (68.9) 223.2 (65.4)

5 (-15) 265.4 (77.8) 254.2 (74.5) 243.3 (71.3) 232.6 (68.2) 222.1 (65.1) 211.6 (62) 201.0 (58.9)

0 (-17.8) 238.4 (69.9) 228.1 (66.8) 218.2 (63.9) 208.6 (61.1) 199.1 (58.4) 189.7 (55.6) 180.2 (52.8)
30 (-1.1) 506.6 (148.5) 487.3 (142.8) 467.7 (137.1) 447.9 (131.3) 427.9 (125.4) 407.8 (119.5) 387.5 (113.6)
25 (-3.9) 464.2 (136) 446.5 (130.9) 428.4 (125.6) 410.2 (120.2) 391.8 (114.8) 373.2 (109.4) 354.5 (103.9)
20 (-6.7) 423.2 (124) 406.9 (119.3) 390.3 (114.4) 373.6 (109.5) 356.6 (104.5) 339.5 (99.5) 322.3 (94.5)
15 (-9.4) 383.9 (112.5) 369.0 (108.1) 353.8 (103.7) 338.5 (99.2) 322.9 (94.6) 307.3 (90.1) 291.5 (85.4)
10 (-12.2) 346.8 (101.6) 333.3 (97.7) 319.4 (93.6) 305.4 (89.5) 291.2 (85.3) 276.9 (81.2) 262.5 (76.9)

5 (-15) 312.6 (91.6) 300.2 (88) 287.6 (84.3) 274.8 (80.5) 261.9 (76.8) 248.8 (72.9) 235.7 (69.1)

0 (-17.8) 281.6 (82.5) 270.3 (79.2) 258.9 (75.9) 247.2 (72.4) 235.5 (69) 223.6 (65.5) 211.7 (62)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

15.4) 377.9 (110.8) 362.2 (106.1) 346.5 (101.5) 330.8 (96.9) 315.0 (92.3) 299.0 (87.6)

R404A R507

AMBIENT TEMPERATURE °F (°C)

(78.8) 254.7 (74.6)

HIGH EFFICIENCY MODELS

COPELAND

04/17/13

K40-KV-PDS-17

- 42 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS016M8-A

Compressor

Model

3DS3R17ME

KVS026M8-A

Compressor

Model

4DHNR22ME

HIGH EFFICIENCY MODELS

KVS031M8-A

Compressor

Model

4DJNR28ME

KVS036M8-A

Compressor

Model

6DHNR35ME

KVS041M8-A

Compressor

Model

6DJNR40ME

KVS051M8-A

Compressor

Model

6DUNR49ME

The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

NOTE:

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 155.0 (45.4) 149.9 (43.9) 145.0 (42.5) 140.2 (41.1) 135.3 (39.7) 130.5 (38.2) 125.6 (36.8)
25 (-3.9) 139.8 (41) 135.4 (39.7) 131.1 (38.4) 126.8 (37.2) 122.5 (35.9) 118.1 (34.6) 113.5 (33.3)
20 (-6.7) 125.8 (36.9) 121.9 (35.7) 118.1 (34.6) 114.2 (33.5) 110.3 (32.3) 106.2 (31.1) 101.9 (29.9)
15 (-9.4) 112.7 (33) 109.3 (32) 105.9 (31) 102.4 (30) 98.7 (28.9) 94.8 (27.8) 90.7 (26.6)
10 (-12.2) 100.6 (29.5) 97.6 (28.6) 94.5 (27.7) 91.2 (26.7) 87.7 (25.7) 84.0 (24.6) 79.9 (23.4)
30 (-1.1) 227.4 (66.6) 217.2 (63.7) 207.3 (60.8) 197.6 (57.9) 188.2 (55.2) 179.3 (52.5) 170.9 (50.1)
25 (-3.9) 202.9 (59.5) 194.3 (56.9) 185.8 (54.5) 177.5 (52) 169.6 (49.7) 162.0 (47.5) 154.9 (45.4)
20 (-6.7) 180.4 (52.9) 173.1 (50.7) 165.9 (48.6) 158.9 (46.6) 152.1 (44.6) 145.7 (42.7) 139.7 (40.9)
15 (-9.4) 159.8 (46.8) 153.7 (45) 147.6 (43.3) 141.6 (41.5) 135.8 (39.8) 130.3 (38.2) 125.2 (36.7)
10 (-12.2) 141.3 (41.4) 136.1 (39.9) 130.9 (38.4) 125.7 (36.8) 120.7 (35.4) 115.9 (34) 111.4 (32.6)
30 (-1.1) 264.6 (77.5) 253.0 (74.1) 241.9 (70.9) 231.1 (67.7) 220.7 (64.7) 210.8 (61.8) 201.3 (59)
25 (-3.9) 236.4 (69.3) 226.6 (66.4) 217.2 (63.7) 208.1 (61) 199.5 (58.5) 191.2 (56) 183.3 (53.7)
20 (-6.7) 210.8 (61.8) 202.6 (59.4) 194.7 (57.1) 187.1 (54.8) 179.9 (52.7) 173.0 (50.7) 166.4 (48.8)
15 (-9.4) 187.6 (55) 180.7 (53) 174.1 (51) 167.8 (49.2) 161.7 (47.4) 155.9 (45.7) 150.5 (44.1)
10 (-12.2) 166.6 (48.8) 160.8 (47.1) 155.2 (45.5) 149.8 (43.9) 144.7 (42.4) 139.8 (41) 135.2 (39.6)
30 (-1.1) 313.6 (91.9) 303.0 (88.8) 292.3 (85.7) 281.3 (82.4) 270.2 (79.2) 258.8 (75.8) 247.1 (72.4)
25 (-3.9) 280.6 (82.2) 271.6 (79.6) 262.4 (76.9) 252.9 (74.1) 243.2 (71.3) 233.2 (68.3) 222.9 (65.3)
20 (-6.7) 251.3 (73.6) 243.6 (71.4) 235.6 (69) 227.4 (66.6) 218.8 (64.1) 210.0 (61.5) 200.8 (58.8)
15 (-9.4) 225.1 (66) 218.4 (64) 211.4 (62) 204.1 (59.8) 196.5 (57.6) 188.6 (55.3) 180.3 (52.8)
10 (-12.2) 201.4 (59) 195.4 (57.3) 189.2 (55.4) 182.6 (53.5) 175.6 (51.5) 168.3 (49.3) 160.6 (47.1)
30 (-1.1) 399.2 (117) 381.7 (111.9) 362.5 (106.2) 341.7 (100.1) 319.9 (93.8) 297.2 (87.1) 273.9 (80.3)
25 (-3.9) 353.5 (103.6) 337.9 (99) 320.9 (94) 302.7 (88.7) 283.6 (83.1) 264.0 (77.4) 244.2 (71.6)
20 (-6.7) 314.5 (92.2) 300.6 (88.1) 285.5 (83.7) 269.7 (79) 253.3 (74.2) 236.8 (69.4) 220.3 (64.6)
15 (-9.4) 280.8 (82.3) 268.4 (78.7) 255.2 (74.8) 241.6 (70.8) 227.8 (66.8) 214.3 (62.8) 201.3 (59)
10 (-12.2) 250.9 (73.5) 239.8 (70.3) 228.3 (66.9) 216.9 (63.6) 205.7 (60.3) 195.2 (57.2) 185.7 (54.4)
30 (-1.1) 466.3 (136.7) 444.6 (130.3) 421.8 (123.6) 398.2 (116.7) 374.0 (109.6) 349.5 (102.4) 325.0 (95.2)
25 (-3.9) 413.5 (121.2) 393.8 (115.4) 373.3 (109.4) 352.3 (103.2) 330.9 (97) 309.5 (90.7) 288.4 (84.5)
20 (-6.7) 365.7 (107.2) 348.0 (102) 329.8 (96.7) 311.3 (91.2) 292.8 (85.8) 274.6 (80.5) 257.0 (75.3)
15 (-9.4) 322.8 (94.6) 307.1 (90) 291.1 (85.3) 275.3 (80.7) 259.7 (76.1) 244.8 (71.7) 230.9 (67.7)
10 (-12.2) 284.5 (83.4) 270.8 (79.4) 257.2 (75.4) 244.0 (71.5) 231.6 (67.9) 220.2 (64.5) 210.2 (61.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 43 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzKVS-A

CONDENSING

UNIT

MODEL

KVS011L6-A

Compressor

Model

3DS3F46KE

KVS016L6-A

Compressor

Model

4DHNF63KE

KVS023L6-A

Compressor

Model

4DJNF76KE

KVS028L6-A

Compressor

Model

6DHNF93KE

KVS031L6-A

Compressor

Model

6DJNF11ME

KVS041L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 91.1 (26.7) 87.5 (25.6) 84.0 (24.6) 80.4 (23.6) 76.9 (22.5) 73.5 (21.5) 70.1 (20.5)

-5 (-20.6) 82.2 (24.1) 79.0 (23.2) 75.8 (22.2) 72.6 (21.3) 69.4 (20.3) 66.3 (19.4) 63.3 (18.6)

-10 (-23.3) 73.8 (21.6) 71.0 (20.8) 68.1 (20) 65.2 (19.1) 62.4 (18.3) 59.5 (17.4) 56.8 (16.6)

-15 (-26.1) 65.9 (19.3) 63.4 (18.6) 60.8 (17.8) 58.2 (17.1) 55.6 (16.3) 53.1 (15.6) 50.5 (14.8)

-20 (-28.9) 58.5 (17.1) 56.3 (16.5) 54.0 (15.8) 51.6 (15.1) 49.3 (14.4) 46.9 (13.7) 44.6 (13.1)

-25 (-31.7) 51.6 (15.1) 49.6 (14.5) 47.6 (14) 45.4 (13.3) 43.3 (12.7) 41.1 (12) 39.1 (11.5)

-30 (-34.4) 45.3 (13.3) 43.5 (12.7) 41.6 (12.2) 39.6 (11.6) 37.7 (11) 35.7 (10.5) 33.8 (9.9)

-35 (-37.2) 39.4 (11.5) 37.8 (11.1) 36.0 (10.6) 34.2 (10) 32.4 (9.5) 30.6 (9) 28.8 (8.4)

-40 (-40) 34.1 (10) 32.6 (9.6) 30.9 (9.1) 29.3 (8.6) 27.6 (8.1) 25.8 (7.6) 24.1 (7.1)
0 (-17.8) 126.4 (37) 121.4 (35.6) 116.7 (34.2) 112.1 (32.9) 107.5 (31.5) 102.9 (30.2) 98.2 (28.8)

-5 (-20.6) 113.8 (33.4) 109.2 (32) 104.9 (30.7) 100.8 (29.5) 96.7 (28.3) 92.5 (27.1) 88.1 (25.8)

-10 (-23.3) 102.2 (30) 98.1 (28.8) 94.2 (27.6) 90.5 (26.5) 86.8 (25.4) 83.0 (24.3) 78.9 (23.1)

-15 (-26.1) 91.6 (26.8) 87.9 (25.8) 84.4 (24.7) 81.0 (23.7) 77.7 (22.8) 74.2 (21.7) 70.5 (20.7)

-20 (-28.9) 81.7 (23.9) 78.4 (23) 75.3 (22.1) 72.3 (21.2) 69.3 (20.3) 66.2 (19.4) 62.7 (18.4)

-25 (-31.7) 72.6 (21.3) 69.6 (20.4) 66.8 (19.6) 64.1 (18.8) 61.4 (18) 58.5 (17.1) 55.4 (16.2)

-30 (-34.4) 63.8 (18.7) 61.2 (17.9) 58.7 (17.2) 56.3 (16.5) 53.9 (15.8) 51.2 (15) 48.3 (14.2)

-35 (-37.2) 55.5 (16.3) 53.1 (15.6) 50.9 (14.9) 48.7 (14.3) 46.5 (13.6) 44.0 (12.9) 41.3 (12.1)

-40 (-40) 47.2 (13.8) 45.1 (13.2) 43.1 (12.6) 41.2 (12.1) 39.1 (11.5) 36.8 (10.8) 34.2 (10)
0 (-17.8) 149.5 (43.8) 142.7 (41.8) 136.3 (39.9) 130.2 (38.2) 124.3 (36.4) 118.8 (34.8) 113.6 (33.3)

-5 (-20.6) 135.5 (39.7) 129.4 (37.9) 123.6 (36.2) 118.0 (34.6) 112.6 (33) 107.5 (31.5) 102.7 (30.1)

-10 (-23.3) 122.3 (35.8) 116.8 (34.2) 111.5 (32.7) 106.4 (31.2) 101.5 (29.7) 96.8 (28.4) 92.3 (27.1)

-15 (-26.1) 109.9 (32.2) 104.9 (30.7) 100.1 (29.3) 95.5 (28) 91.0 (26.7) 86.6 (25.4) 82.3 (24.1)

-20 (-28.9) 98.1 (28.8) 93.7 (27.5) 89.3 (26.2) 85.1 (24.9) 80.9 (23.7) 76.8 (22.5) 72.7 (21.3)

-25 (-31.7) 86.9 (25.5) 82.9 (24.3) 79.0 (23.2) 75.1 (22) 71.3 (20.9) 67.4 (19.8) 63.5 (18.6)

-30 (-34.4) 76.2 (22.3) 72.7 (21.3) 69.2 (20.3) 65.6 (19.2) 61.9 (18.1) 58.2 (17.1) 54.4 (15.9)

-35 (-37.2) 66.1 (19.4) 62.9 (18.4) 59.7 (17.5) 56.3 (16.5) 52.8 (15.5) 49.2 (14.4) 45.5 (13.3)

-40 (-40) 56.3 (16.5) 53.5 (15.7) 50.5 (14.8) 47.3 (13.9) 43.9 (12.9) 40.4 (11.8) 36.6 (10.7)
0 (-17.8) 187.0 (54.8) 179.5 (52.6) 172.2 (50.5) 165.0 (48.4) 157.8 (46.2) 150.6 (44.1) - -

-5 (-20.6) 169.2 (49.6) 162.4 (47.6) 155.8 (45.7) 149.3 (43.8) 142.8 (41.9) 136.2 (39.9) 129.4 (37.9)

-10 (-23.3) 152.0 (44.5) 145.9 (42.8) 140.0 (41) 134.1 (39.3) 128.1 (37.5) 122.1 (35.8) 115.8 (33.9)

-15 (-26.1) 135.6 (39.7) 130.1 (38.1) 124.8 (36.6) 119.4 (35) 1

-20 (-28.9) 120.1 (35.2) 115.1 (33.7) 110.3 (32.3) 105.5 (30.9) 100.5 (29.5) 95.4 (28) 90.1 (26.4)

-25 (-31.7) 105.5 (30.9) 101.0 (29.6) 96.7 (28.3) 92.3 (27.1) 87.7 (25.7) 83.0 (24.3) 78.0 (22.9)

-30 (-34.4) 92.0 (27) 88.0 (25.8) 84.0 (24.6) 79.9 (23.4) 75.7 (22.2) 71.3 (20.9) 66.5 (19.5)

-35 (-37.2) 79.7 (23.4) 76.0 (22.3) 72.3 (21.2) 68.5 (20.1) 64.6 (18.9) 60.4 (17.7) 55.8 (16.4)

-40 (-40) 68.6 (20.1) 65.2 (19.1) 61.7 (18.1) 58.2 (17.1) 54.4 (15.9) 50.3 (14.7) 45.8 (13.4)
0 (-17.8) 206.3 (60.5) 197.2 (57.8) 188.3 (55.2) 179.6 (52.6) 171.0 (50.1) 162.6 (47.7) --- ---

-5 (-20.6) 186.4 (54.6) 178.3 (52.3) 170.2 (49.9) 162.3 (47.6) 154.6 (45.3) 147.0 (43.1) --- ---

-10 (-23.3) 167.5 (49.1) 160.2 (46.9) 153.1 (44.9) 145.9 (42.8) 139.0 (40.7) 132.1 (38.7) 125.5 (36.8)

-15 (-26.1) 149.7 (43.9) 143.2 (42) 136.8 (40.1) 130.4 (38.2) 124.1 (36.4) 117.9 (34.6) 111.9 (32.8)

-20 (-28.9) 133.0 (39) 127.2 (37.3) 121.4 (35.6) 115.7 (33.9) 109.9 (32.2) 104.3 (30.6) 98.8 (29)

-25 (-31.7) 117.4 (34.4) 112.2 (32.9) 107.0 (31.4) 101.8 (29.8) 96.5 (28.3) 91.4 (26.8) 86.3 (25.3)

-30 (-34.4) 102.9 (30.2) 98.3 (28.8) 93.5 (27.4) 88.7 (26) 83.9 (24.6) 79.1 (23.2) 74.3 (21.8)

-35 (-37.2) 89.6 (26.3) 85.3 (25) 80.9 (23.7) 76.4 (22.4) 71.9 (21.1) 67.4 (19.8) 62.8 (18.4)

-40 (-40) 77.3 (22.7) 73.4 (21.5) 69.2 (20.3) 64.9 (19) 60.6 (17.8) 56.2 (16.5) 51.8 (15.2)
0 (-17.8) 259.0 (75.9) 247.8 (72.6) 236.9 (69.4) 226.3 (66.3) 216.2 (63.4) 206.7 (60.6) - -

-5 (-20.6) 233.9 (68.5) 223.2 (65.4) 212.8 (62.4) 202.7 (59.4) 193.0 (56.6) 183.7 (53.8) - -

-10 (-23.3) 211.3 (61.9) 201.3 (59) 191.5 (56.1) 181.9 (53.3) 172.6 (50.6) 163.7 (48) 155.2 (45.5)

-15 (-26.1) 190.7 (55.9) 181.4 (53.2) 172.2 (50.5) 163.2 (47.8) 154.4 (45.3) 145.9 (42.8) 137.9 (40.4)

-20 (-28.9) 171.5 (50.3) 163.0 (47.8) 154.5 (45.3) 146.1 (42.8) 137.9 (40.4) 129.9 (38.1) 122.3 (35.8)

-25 (-31.7) 153.2 (44.9) 145.5 (42.6) 137.8 (40.4) 130.0 (38.1) 122.4 (35.9) 115.0 (33.7) 107.8 (31.6)

-30 (-34.4) 135.1 (39.6) 128.3 (37.6) 121.4 (35.6) 114.4 (33.5) 107.4 (31.5) 100.6 (29.5) 93.9 (27.5)

-35 (-37.2) 116.7 (34.2) 110.8 (32.5) 104.7 (30.7) 98.5 (28.9) 92.2 (27) 86.0 (25.2) 79.9 (23.4)

-40 (-40) 97.2 (28.5) 92.3 (27.1) 87.1 (25.5) 81.7 (23.9) 76.2 (22.3) 70.7 (20.7) 65.2 (19.1)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

14.0 (33.4) 108.5 (31.8) 102.7 (30.1)

HIGH EFFICIENCY MODELS

--- Outside Operating Range

COPELAND

04/17/13

K40-KV-PDS-17

- 44 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD031H8-A

Compressor

Model

3DS3R17ME

KVD051H8-A

Compressor

Model

4DHNR22ME

HIGH EFFICIENCY MODELS

KVD061H8-A

Compressor

Model

4DJNR28ME

KVD071H8-A

Compressor

Model

6DHNR35ME

KVD081H8-A

Compressor

Model

6DJNR40ME

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 491.8 (144.1) 473.2 (138.7) 455.0 (133.3) 437.6 (128.2) 420.6 (123.3) 404.0 (118.4) 388.0 (113.7)
50 (10) 451.4 (132.3) 434.8 (127.4) 418.6 (122.7) 402.8 (118) 387.6 (113.6) 372.8 (109.3) 358.2 (105)
45 (7.2) 413.0 (121) 398.2 (116.7) 383.8 (112.5) 369.8 (108.4) 356.2 (104.4) 343.0 (100.5) 329.8 (96.7)
40 (4.4) 376.6 (110.4) 363.4 (106.5) 350.8 (102.8) 338.4 (99.2) 326.2 (95.6) 314.4 (92.1) 302.6 (88.7)
35 (1.7) 342.2 (100.3) 330.6 (96.9) 319.4 (93.6) 308.6 (90.4) 297.8 (87.3) 287.0 (84.1) 276.4 (81)

55 (12.8) 750.8 (220) 711.6 (208.5) 673.2 (197.3) 635.4 (186.2) 598.6 (175.4) 562.8 (164.9) 528.2 (154.8)
50 (10) 685.6 (200.9) 650.4 (190.6) 616.0 (180.5) 582.4 (170.7) 549.6 (161.1) 517.8 (151.8) 487.2 (142.8)
45 (7.2) 623.0 (182.6) 591.8 (173.4) 561.4 (164.5) 531.6 (155.8) 502.8 (147.4) 474.8 (139.1) 448.2 (131.4)
40 (4.4) 563.4 (165.1) 536.2 (157.1) 509.6 (149.3) 483.4 (141.7) 458.2 (134.3) 434.0 (127.2) 411.0 (120.5)
35 (1.7) 507.4 (148.7) 483.6 (141.7) 460.6 (135) 438.0 (128.4) 416.2 (122) 395.2 (115.8) 375.4 (110)
55 (12.8) 891.0 (261.1) 845.4 (247.8) 800.8 (234.7) 757.2 (221.9) 714.4 (209.4) 672.6 (197.1) 632.0 (185.2)
50 (10) 808.2 (236.9) 767.4 (224.9) 727.6 (213.2) 688.8 (201.9) 651.0 (190.8) 614.2 (180) 578.4 (169.5)
45 (7.2) 730.4 (214.1) 694.4 (203.5) 659.4 (193.3) 625.2 (183.2) 592.2 (173.6) 560.0 (164.1) 529.0 (155)
40 (4.4) 658.0 (192.8) 626.6 (183.6) 596.0 (174.7) 566.4 (166) 537.8 (157.6) 510.0 (149.5) 483.4 (141.7)
35 (1.7) 590.8 (173.1) 563.8 (165.2) 537.4 (157.5) 512.0 (150.1) 487.6 (142.9) 464.0 (136) 441.4 (129.4)
55 (12.8) 1098.4 (321.9) 1055.8 (309.4) 1013.0 (296.9) 970.0 (284.3) 927.0 (271.7) 883.6 (259) 840.2 (246.2)
50 (10) 982.8 (288) 945.2 (277) 907.4 (265.9) 869.4 (254.8) 831.2 (243.6) 792.8 (232.3) 754.0 (221)
45 (7.2) 878.6 (257.5) 845.6 (247.8) 812.4 (238.1) 779.0 (228.3) 745.4 (218.5) 711.4 (208.5) 677.0 (198.4)
40 (4.4) 785.0 (230.1) 756.4 (221.7) 727.4 (213.2) 698.2 (204.6) 668.8 (196) 639.0 (187.3) 608.8 (178.4)
35 (1.7) 701.4 (205.6) 676.8 (198.3) 651.8 (191) 626.4 (183.6) 600.8 (176.1) 574.8 (168.5) 548.2 (160.7)
55 (12.8) 1530.6 (448.6) 1466.8 (429.9) 1398.2 (409.8) 1325.4 (388.4) 1248.6 (365.9) 1168.4 (342.4) 1085.4 (318.1)
50 (10) 1343.0 (393.6) 1286.4 (377) 1224.8 (359) 1159.0 (339.7) 1089.6 (319.3) 1017.0 (298.1) 941.6 (276)

45 (7.2) 1176.6 (344.8) 1126.4 (330.1) 1071.6 (314.1) 1012.6 (296.8) 950.2 (278.5) 884.8 (259.3) 816.8 (239.4)
40 (4.4) 1031.4 (302.3) 986.8 (289.2) 938.0 (274.9) 885.2 (259.4) 829.4 (243.1) 771.0 (226) 710.4 (208.2)
35 (1.7) 905.8 (265.5) 866.4 (253.9) 823.0 (241.2) 776.2 (227.5) 726.6 (212.9) 674.8 (197.8) 621.2 (182.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

CONDENSING

UNIT

MODEL

KVD031H8-A

Compressor

3DS3R17ME

KVD051H8-A

Compressor

4DHNR22ME

KVD061H8-A

Compressor

4DJNR28ME

KVD071H8-A

Compressor

6DHNR35ME

KVD081H8-A

Compressor

6DJNR40ME

TEMPERATURE

CAPACITY DATA -

R404A

R507

60HzKVD-A

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

° F ° C

45 (7.2) 463.0 (135.7) 443.2 (129.9) 423.4 (124.1) 404.0 (118.4) 384.8 (112.8) 365.8 (107.2) 347.0 (101.7)
40 (4.4) 425.8 (124.8) 407.6 (119.5) 389.6 (114.2) 371.8 (109) 354.4 (103.9) 337.0 (98.8) 319.8 (93.7)
35 (1.7) 390.6 (114.5) 374.0 (109.6) 357.6 (104.8) 341.4 (100.1) 325.4 (95.4) 309.6 (90.7) 294.0 (86.2)
45 (7.2) 621.4 (182.1) 594.2 (174.1) 567.8 (166.4) 542.2 (158.9) 517.4 (151.6) 493.2 (144.5) 469.4 (137.6)
40 (4.4) 577.8 (169.3) 552.6 (162) 528.0 (154.7) 504.2 (147.8) 481.0 (141) 458.4 (134.3) 436.4 (127.9)
35 (1.7) 534.4 (156.6) 511.0 (149.8) 488.2 (143.1) 466.0 (136.6) 444.6 (130.3) 423.6 (124.1) 403.2 (118.2)
45 (7.2) 762.6 (223.5) 730.0 (213.9) 697.8 (204.5) 665.8 (195.1) 634.0 (185.8) 602.2 (176.5) 570.6 (167.2)
40 (4.4) 702.6 (205.9) 672.4 (197.1) 642.6 (188.3) 613.0 (179.7) 583.6 (171) 554.2 (162.4) 525.0 (153.9)
35 (1.7) 645.0 (189) 617.2 (180.9) 589.8 (172.9) 562.6 (164.9) 535.4 (156.9) 508.6 (149.1) 481.6 (141.1)
45 (7.2) 975.2 (285.8) 934.6 (273.9) 894.0 (262) 853.4 (250.1) 812.4 (238.1) 771.4 (226.1) 730.2 (214)
40 (4.4) 894.0 (262) 857.0 (251.2) 819.8 (240.3) 782.6 (229.4) 745.2 (218.4) 707.6 (207.4) 670.0 (196.4)
35 (1.7) 817.4 (239.6) 783.6 (229.6) 749.8 (219.7) 715.8 (209.8) 681.8 (199.8) 647.4 (189.7) 613.2 (179.7)
45 (7.2) 1103.8 (323.5) 1059.8 (310.6) 1016.0 (297.8) 972.2 (284.9) 928.0 (272) 883.6 (259) 838.4 (245.7)
40 (4.4) 1019.8 (298.9) 979.0 (286.9) 938.4 (275) 897.8 (263.1) 857.2 (251.2) 816.2 (239.2) 774.6 (227)
35 (1.7) 939.0 (275.2) 901.4 (264.2) 864.0 (253.2) 826.6 (242.3) 789.0 (231.2) 751.2 (220.2) 713.0 (209)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 45 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD031M8-A

Compressor

Model

3DS3R17ME

KVD051M8-A

Compressor

Model

4DHNR22ME

KVD061M8-A

Compressor

Model

4DJNR28ME

KVD071M8-A

Compressor

Model

6DHNR35ME

KVD081M8-A

Compressor

Model

6DJNR40ME

KVD101M8-A

Compressor

Model

6DUNR49ME

SATURATED

SUCTION

TEMPERATURE

° F ° C
30 (-1.1) 357.0 (104.6) 342.0 (100.2) 327.2 (95.9) 312.6 (91.6) 298.2 (87.4) 283.8 (83.2) 269.8 (79.1)
25 (-3.9) 325.4 (95.4) 312.0 (91.4) 298.6 (87.5) 285.4 (83.6) 272.4 (79.8) 259.4 (76) 246.8 (72.3)
20 (-6.7) 295.6 (86.6) 283.6 (83.1) 271.6 (79.6) 259.8 (76.1) 248.0 (72.7) 236.6 (69.3) 225.2 (66)
15 (-9.4) 267.8 (78.5) 257.0 (75.3) 246.2 (72.2) 235.6 (69) 225.2 (66) 215.0 (63) 204.8 (60)
10 (-12.2) 241.8 (70.9) 232.0 (68) 222.6 (65.2) 213.2 (62.5) 203.8 (59.7) 194.6 (57) 185.6 (54.4)

5 (-15) 217.6 (63.8) 209.0 (61.3) 200.4 (58.7) 192.0 (56.3) 183.8 (53.9) 175.6 (51.5) 167.6 (49.1)

0 (-17.8) 195.0 (57.1) 187.4 (54.9) 179.8 (52.7) 172.4 (50.5) 165.0 (48.4) 157.8 (46.2) 150.6 (44.1)
30 (-1.1) 491.4 (144) 469.8 (137.7) 448.8 (131.5) 428.4 (125.6) 408.4 (119.7) 389.2 (114.1) 370.2 (108.5)
25 (-3.9) 449.4 (131.7) 429.4 (125.8) 410.0 (120.2) 391.4 (114.7) 373.0 (109.3) 355.2 (104.1) 337.8 (99)
20 (-6.7) 408.4 (119.7) 390.2 (114.4) 372.6 (109.2) 355.4 (104.2) 338.8 (99.3) 322.4 (94.5) 306.4 (89.8)
15 (-9.4) 369.0 (108.1) 352.4 (103.3) 336.4 (98.6) 321.0 (94.1) 305.8 (89.6) 291.0 (85.3) 276.4 (81)
10 (-12.2) 331.6 (97.2) 316.8 (92.8) 302.4 (88.6) 288.4 (84.5) 274.8 (80.5) 261.4 (76.6) 248.2 (72.7)

5 (-15) 296.8 (87) 283.6 (83.1) 270.8 (79.4) 258.4 (75.7) 246.2 (72.2) 234.0 (68.6) 222.0 (65.1)

0 (-17.8) 264.6 (77.5) 253.0 (74.1) 241.8 (70.9) 230.8 (67.6) 220.2 (64.5) 209.4 (61.4) 198.6 (58.2)
30 (-1.1) 590.0 (172.9) 564.4 (165.4) 539.2 (158) 514.4 (150.8) 489.6 (143.5) 465.0 (136.3) 440.4 (129.1)
25 (-3.9) 537.4 (157.5) 514.2 (150.7) 491.2 (144) 468.4 (137.3) 446.0 (130.7) 423.6 (124.1) 401.2 (117.6)
20 (-6.7) 487.6 (142.9) 466.4 (136.7) 445.6 (130.6) 425.0 (124.6) 404.6 (118.6) 384.4 (112.7) 364.2 (106.7)
15 (-9.4) 440.4 (129.1) 421.4 (123.5) 402.6 (118) 384.0 (112.5) 365.6 (107.1) 347.4 (101.8) 329.4 (96.5)
10 (-12.2) 396.0 (116.1) 378.8 (111) 362.0 (106.1) 345.4 (101.2) 329.0 (96.4) 312.8 (91.7) 296.6 (86.9)

5 (-15) 354.4 (103.9) 339.2 (99.4) 324.2 (95) 309.4 (90.7) 294.8 (86.4) 280.6 (82.2) 266.2 (78)

0 (-17.8) 315.8 (92.6) 302.2 (88.6) 288.8 (84.6) 275.8 (80.8) 263.2 (77.1) 250.6 (73.4) 238.0 (69.8)
30 (-1.1) 745.2 (218.4) 714.6 (209.4) 683.8 (200.4) 652.8 (191.3) 622.0 (182.3) 590.8 (173.1) 559.6 (164)
25 (-3.9) 677.4 (198.5) 649.6 (190.4) 621.8 (182.2) 593.8 (174) 565.8 (165.8) 537.6
20 (-6.7) 614.2 (180) 589.0 (172.6) 563.8 (165.2) 538.4 (157.8) 513.0 (150.3) 487.6 (142.9) 462.2 (135.5)
15 (-9.4) 555.2 (162.7) 532.4 (156) 509.6 (149.3) 486.8 (142.7) 463.8 (135.9) 441.0 (129.2) 418.0 (122.5)
10 (-12.2) 500.4 (146.7) 479.8 (140.6) 459.2 (134.6) 438.6 (128.5) 417.8 (122.4) 397.2 (116.4) 376.6 (110.4)

5 (-15) 449.8 (131.8) 431.2 (126.4) 412.4 (120.9) 393.6 (115.4) 375.0 (109.9) 356.4 (104.5) 337.8 (99)

0 (-17.8) 403.4 (1
30 (-1.1) 861.6 (252.5) 827.0 (242.4) 792.4 (232.2) 758.2 (222.2) 723.8 (212.1) 689.2 (202) 654.2 (191.7)
25 (-3.9) 787.8 (230.9) 755.8 (221.5) 724.4 (212.3) 693.0 (203.1) 661.6 (193.9) 630.0 (184.6) 598.0 (175.3)
20 (-6.7) 717.6 (210.3) 688.4 (201.7) 659.6 (193.3) 630.8 (184.9) 602.4 (176.5) 573.6 (168.1) 544.6 (159.6)
15 (-9.4) 651.4 (190.9) 624.6 (183.1) 598.2 (175.3) 572.2 (167.7) 546.4 (160.1) 520.4 (152.5) 494.0 (144.8)
10 (-12.2) 589.2 (172.7) 564.6 (165.5) 540.6 (158.4) 517.0 (151.5) 493.6 (144.7) 470.2 (137.8) 446.4 (130.8)

5 (-15) 530.8 (155.6) 508.4 (149) 486.6 (142.6) 465.2 (136.3) 444.2 (130.2) 423.2 (124) 402.0 (117.8)

0 (-17.8) 476.8 (139.7) 456.2 (133.7) 436.4 (127.9) 417.2 (122.3) 398.2 (116.7) 379.4 (111.2) 360.4 (105.6)
30 (-1.1) 1013.2 (296.9) 974.6 (285.6) 935.4 (274.1) 895.8 (262.5) 855.8 (250.8) 815.6 (239) 775.0 (227.1)
25 (-3.9) 928.4 (272.1) 893.0 (261.7) 856.8 (251.1) 820.4 (240.4) 783.6 (229.6) 746.4 (218.7) 709.0 (207.8)
20 (-6.7) 846.4 (248.1) 813.8 (238.5) 780.6 (228.8) 747.2 (219) 713.2 (209) 679.0 (199) 644.6 (188.9)
15 (-9.4) 767.8 (225) 738.0 (216.3) 707.6 (207.4) 677.0 (198.4) 645.8 (189.3) 614.6 (180.1) 583.0 (170.9)
10 (-12.2) 693.6 (203.3) 666.6 (195.4) 638.8 (187.2) 610.8 (179) 582.4 (170.7) 553.8 (162.3) 525.0 (153.9)

5 (-15) 625.2 (183.2) 600.4 (176) 575.2 (168.6) 549.6 (161.1) 523.8 (153.5) 497.6 (145.8) 471.4 (138.2)

0 (-17.8) 563.2 (165.1) 540.6 (158.4) 517.8 (151.8) 494.4 (144.9) 471.0 (138) 447.2 (131.1) 423.4 (124.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

18.2) 386.2 (113.2) 369.0 (108.1) 352.0 (103.2) 335.2 (98.2) 318.2 (93.3) 301.4 (88.3)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

(157.6) 509.4 (149.3)

HIGH EFFICIENCY MODELS

COPELAND

04/17/13

K40-KV-PDS-17

- 46 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD031M8-A

Compressor

Model

3DS3R17ME

KVD051M8-A

Compressor

Model

4DHNR22ME

HIGH EFFICIENCY MODELS

KVD061M8-A

Compressor

Model

4DJNR28ME

KVD071M8-A

Compressor

Model

6DHNR35ME

KVD081M8-A

Compressor

Model

6DJNR40ME

KVD101M8-A

Compressor

Model

6DUNR49ME

The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

NOTE:

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 310.0 (90.9) 299.8 (87.9) 290.0 (85) 280.4 (82.2) 270.6 (79.3) 261.0 (76.5) 251.2 (73.6)
25 (-3.9) 279.6 (81.9) 270.8 (79.4) 262.2 (76.8) 253.6 (74.3) 245.0 (71.8) 236.2 (69.2) 227.0 (66.5)
20 (-6.7) 251.6 (73.7) 243.8 (71.5) 236.2 (69.2) 228.4 (66.9) 220.6 (64.7) 212.4 (62.2) 203.8 (59.7)
15 (-9.4) 225.4 (66.1) 218.6 (64.1) 211.8 (62.1) 204.8 (60) 197.4 (57.9) 189.6 (55.6) 181.4 (53.2)
10 (-12.2) 201.2 (59) 195.2 (57.2) 189.0 (55.4) 182.4 (53.5) 175.4 (51.4) 168.0 (49.2) 159.8 (46.8)
30 (-1.1) 454.8 (133.3) 434.4 (127.3) 414.6 (121.5) 395.2 (115.8) 376.4 (110.3) 358.6 (105.1) 341.8 (100.2)
25 (-3.9) 405.8 (118.9) 388.6 (113.9) 371.6 (108.9) 355.0 (104) 339.2 (99.4) 324.0 (95) 309.8 (90.8)
20 (-6.7) 360.8 (105.7) 346.2 (101.5) 331.8 (97.2) 317.8 (93.1) 304.2 (89.2) 291.4 (85.4) 279.4 (81.9)
15 (-9.4) 319.6 (93.7) 307.4 (90.1) 295.2 (86.5) 283.2 (83) 271.6 (79.6) 260.6 (76.4) 250.4 (73.4)
10 (-12.2) 282.6 (82.8) 272.2 (79.8) 261.8 (76.7) 251.4 (73.7) 241.4 (70.7) 231.8 (67.9) 222.8 (65.3)
30 (-1.1) 529.2 (155.1) 506.0 (148.3) 483.8 (141.8) 462.2 (135.5) 441.4 (129.4) 421.6 (123.6) 402.6 (118)
25 (-3.9) 472.8 (138.6) 453.2 (132.8) 434.4 (127.3) 416.2 (122) 399.0 (116.9) 382.4 (112.1) 366.6 (107.4)
20 (-6.7) 421.6 (123.6) 405.2 (118.8) 389.4 (114.1) 374.2 (109.7) 359.8 (105.4) 346.0 (101.4) 332.8 (97.5)
15 (-9.4) 375.2 (110) 361.4 (105.9) 348.2 (102) 335.6 (98.4) 323.4 (94.8) 311.8 (91.4) 301.0 (88.2)
10 (-12.2) 333.2 (97.7) 321.6 (94.3) 310.4 (91) 299.6 (87.8) 289.4 (84.8) 279.6 (81.9) 270.4 (79.2)
30 (-1.1) 627.2 (183.8) 606.0 (177.6) 584.6 (171.3) 562.6 (164.9) 540.4 (158.4) 517.6 (151.7) 494.2 (144.8)
25 (-3.9) 561.2 (164.5) 543.2 (159.2) 524.8 (153.8) 505.8 (148.2) 486.4 (142.5) 466.4 (136.7) 445.8 (130.7)
20 (-6.7) 502.6 (147.3) 487.2 (142.8) 471.2 (138.1) 454.8 (133.3) 437.6 (128.2) 420.0 (123.1) 401.6 (117.7)
15 (-9.4) 450.2 (131.9) 436.8 (128) 422.8 (123.9) 408.2 (119.6) 393.0 (115.2) 377.2 (110.5) 360.6 (105.7)
10 (-12.2) 402.8 (118) 390.8 (114.5) 378.4 (110.9) 365.2 (107) 351.2 (102.9) 336.6 (98.6) 321.2 (94.1)
30 (-1.1) 798.4 (234) 763.4 (223.7) 725.0 (212.5) 683.4 (200.3) 639.8 (187.5) 594.4 (174.2) 547.8 (160.5)
25 (-3.9) 707.0 (207.2) 675.8 (198.1) 641.8 (188.1) 605.4 (177.4) 567.2 (166.2) 528.0 (154.7) 488.4 (143.1)
20 (-6.7) 629.0 (184.3) 601.2 (176.2) 571.0 (167.3) 539.4 (158.1) 506.6 (148.5) 473.6 (138.8) 440.6 (129.1)
15 (-9.4) 561.6 (164.6) 536.8 (157.3) 510.4 (149.6) 483.2 (141.6) 455.6 (133.5) 428.6 (125.6) 402.6 (118)
10 (-12.2) 501.8 (147.1) 479.6 (140.6) 456.6 (133.8) 433.8 (127.1) 411.4 (120.6) 390.4 (114.4) 371.4 (108.8)
30 (-1.1) 932.6 (273.3) 889.2 (260.6) 843.6 (247.2) 796.4 (233.4) 748.0 (219.2) 699.0 (204.9) 650.0 (190.5)
25 (-3.9) 827.0 (242.4) 787.6 (230.8) 746.6 (218.8) 704.6 (206.5) 661.8 (194) 619.0 (181.4) 576.8 (169)
20 (-6.7) 731.4 (214.4) 696.0 (204) 659.6 (193.3) 622.6 (182.5) 585.6 (171.6) 549.2 (161) 514.0 (150.6)
15 (-9.4) 645.6 (189.2) 614.2 (180) 582.2 (170.6) 550.6 (161.4) 519.4 (152.2) 489.6 (143.5) 461.8 (135.3)
10 (-12.2) 569.0 (166.8) 541.6 (158.7) 514.4 (150.8) 488.0 (143) 463.2 (135.8) 440.4 (129.1) 420.4 (123.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

COPELAND

04/17/13

K40-KV-PDS-17

- 47 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzKVD-A

CONDENSING

UNIT

MODEL

KVD021L6-A

Compressor

Model

3DS3F46KE

KVD031L6-A

Compressor

Model

4DHNF63KE

KVD045L6-A

Compressor

Model

4DJNF76KE

KVD055L6-A

Compressor

Model

6DHNF93KE

KVD061L6-A

Compressor

Model

6DJNF11ME

KVD081L6-A

Compressor

Model

6DUNF13ME

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 182.2 (53.4) 175.0 (51.3) 168.0 (49.2) 160.8 (47.1) 153.8 (45.1) 147.0 (43.1) 140.2 (41.1)

-5 (-20.6) 164.4 (48.2) 158.0 (46.3) 151.6 (44.4) 145.2 (42.6) 138.8 (40.7) 132.6 (38.9) 126.6 (37.1)

-10 (-23.3) 147.6 (43.3) 142.0 (41.6) 136.2 (39.9) 130.4 (38.2) 124.8 (36.6) 119.0 (34.9) 113.6 (33.3)

-15 (-26.1) 131.8 (38.6) 126.8 (37.2) 121.6 (35.6) 116.4 (34.1) 111.2 (32.6) 106.2 (31.1) 101.0 (29.6)

-20 (-28.9) 117.0 (34.3) 112.6 (33) 108.0 (31.7) 103.2 (30.2) 98.6 (28.9) 93.8 (27.5) 89.2 (26.1)

-25 (-31.7) 103.2 (30.2) 99.2 (29.1) 95.2 (27.9) 90.8 (26.6) 86.6 (25.4) 82.2 (24.1) 78.2 (22.9)

-30 (-34.4) 90.6 (26.6) 87.0 (25.5) 83.2 (24.4) 79.2 (23.2) 75.4 (22.1) 71.4 (20.9) 67.6 (19.8)

-35 (-37.2) 78.8 (23.1) 75.6 (22.2) 72.0 (21.1) 68.4 (20) 64.8 (19) 61.2 (17.9) 57.6 (16.9)

-40 (-40) 68.2 (20) 65.2 (19.1) 61.8 (18.1) 58.6 (17.2) 55.2 (16.2) 51.6 (15.1) 48.2 (14.1)
0 (-17.8) 252.8 (74.1) 242.8 (71.2) 233.4 (68.4) 224.2 (65.7) 215.0 (63) 205.8 (60.3) 196.4 (57.6)

-5 (-20.6) 227.6 (66.7) 218.4 (64) 209.8 (61.5) 201.6 (59.1) 193.4 (56.7) 185.0 (54.2) 176.2 (51.6)

-10 (-23.3) 204.4 (59.9) 196.2 (57.5) 188.4 (55.2) 181.0 (53) 173.6 (50.9) 166.0 (48.6) 157.8 (46.2)

-15 (-26.1) 183.2 (53.7) 175.8 (51.5) 168.8 (49.5) 162.0 (47.5) 155.4 (45.5) 148.4 (43.5) 141.0 (41.3)

-20 (-28.9) 163.4 (47.9) 156.8 (46) 150.6 (44.1) 144.6 (42.4) 138.6 (40.6) 132.4 (38.8) 125.4 (36.8)

-25 (-31.7) 145.2 (42.6) 139.2 (40.8) 133.6 (39.2) 128.2 (37.6) 122.8 (36) 117.0 (34.3) 110.8 (32.5)

-30 (-34.4) 127.6 (37.4) 122.4 (35.9) 117.4 (34.4) 112.6 (33) 107.8 (31.6) 102.4 (30) 96.6 (28.3)

-35 (-37.2) 111.0 (32.5) 106.2 (31.1) 101.8 (29.8) 97.4 (28.5) 93.0 (27.3) 88.0 (25.8) 82.6 (24.2)

-40 (-40) 94.4 (27.7) 90.2 (26.4) 86.2 (25.3) 82.4 (24.1) 78.2 (22.9) 73.6 (21.6) 68.4 (20)
0 (-17.8) 299.0 (87.6) 285.4 (83.6) 272.6 (79.9) 260.4 (76.3) 248.6 (72.9) 237.6 (69.6) 227.2 (66.6)

-5 (-20.6) 271.0 (79.4) 258.8 (75.8) 247.2 (72.4) 236.0 (69.2) 225.2 (66) 215.0 (63) 205.4 (60.2)

-10 (-23.3) 244.6 (71.7) 233.6 (68.5) 223.0 (65.4) 212.8 (62.4) 203.0 (59.5) 193.6 (56.7) 184.6 (54.1)

-15 (-26.1) 219.8 (64.4) 209.8 (61.5) 200.2 (58.7) 191.0 (56) 182.0 (53.3) 173.2 (50.8) 164.6 (48.2)

-20 (-28.9) 196.2 (57.5) 187.4 (54.9) 178.6 (52.3) 170.2 (49.9) 161.8 (47.4) 153.6 (45) 145.4 (42.6)

-25 (-31.7) 173.8 (50.9) 165.8 (48.6) 158.0 (46.3) 150.2 (44) 142.6 (41.8) 134.8 (39.5) 127.0 (37.2)

-30 (-34.4) 152.4 (44.7) 145.4 (42.6) 138.4 (40.6) 131.2 (38.5) 123.8 (36.3) 116.4 (34.1) 108.8 (31.9)

-35 (-37.2) 132.2 (38.7) 125.8 (36.9) 119.4 (35) 112.6 (33) 105.6 (30.9) 98.4 (28.8) 91.0 (26.7)

-40 (-40) 1
0 (-17.8) 374.0 (109.6) 359.0 (105.2) 344.4 (100.9) 330.0 (96.7) 315.6 (92.5) 301.2 (88.3) --- ---

-5 (-20.6) 338.4 (99.2) 324.8 (95.2) 311.6 (91.3) 298.6 (87.5) 285.6 (83.7) 272.4 (79.8) 258.8 (75.8)

-10 (-23.3) 304.0 (89.1) 291.8 (85.5) 280.0 (82.1) 268.2 (78.6) 256.2 (75.1) 244.2 (71.6) 231.6 (67.9)

-15 (-26.1) 271.2 (79.5) 260.2 (76.3) 249.6 (73.2) 238.8 (70) 228.0 (66.8) 217.0 (63.6) 205.4 (60.2)

-20 (-28.9) 240.2 (70.4) 230.2 (67.5) 220.6 (64.7) 211.0 (61.8) 201.0 (58.9) 190.8 (55.9) 180.2 (52.8)

-25 (-31.7) 211.0 (61.8) 202.0 (59.2) 193.4 (56.7) 184.6 (54.1) 175.4 (51.4) 166.0 (48.6) 156.0 (45.7)

-30 (-34.4) 184.0 (53.9) 176.0 (51.6) 168.0 (49.2) 159.8 (46.8) 151.4 (44.4) 142.6 (41.8) 133.0 (39)

-35 (-37.2) 159.4 (46.7) 152.0 (44.5) 144.6 (42.4) 137.0 (40.2) 129.2 (37.9) 120.8 (35.4) 111.6 (32.7)

-40 (-40) 137.2 (40.2) 130.4 (38.2) 123.4 (36.2) 116.4 (34.1) 108.8 (31.9) 100.6 (29.5) 91.6 (26.8)
0 (-17.8) 412.6 (120.9) 394.4 (115.6) 376.6 (110.4) 359.2 (105.3) 342.0 (100.2) 325.2 (95.3) --- ---

-5 (-20.6) 372.8 (109.3) 356.6 (104.5) 340.4 (99.8) 324.6 (95.1) 309.2 (90.6) 294.0 (86.2) --- ---

-10 (-23.3) 335.0 (98.2) 320.4 (93.9) 306.2 (89.7) 291.8 (85.5) 278.0 (81.5) 264.2 (77.4) 251.0 (73.6)

-15 (-26.1) 299.4 (87.7) 286.4 (83.9) 273.6 (80.2) 260.8 (76.4) 248.2 (72.7) 235.8 (69.1) 223.8 (65.6)

-20 (-28.9) 266.0 (78) 254.4 (74.6) 242.8 (71.2) 231.4 (67.8) 219.8 (64.4) 208.6 (61.1) 197.6 (57.9)

-25 (-31.7) 234.8 (68.8) 224.4 (65.8) 214.0 (62.7) 203.6 (59.7) 193.0 (56.6) 182.8 (53.6) 172.6 (50.6)

-30 (-34.4) 205.8 (60.3) 196.6 (57.6) 187.0 (54.8) 177.4 (52) 167.8 (49.2) 158.2 (46.4) 148.6 (43.6)

-35 (-37.2) 179.2 (52.5) 170.6 (50) 161.8 (47.4) 152.8 (44.8) 143.8 (42.1) 134.8 (39.5) 125.6 (36.8)

-40 (-40) 154.6 (45.3) 146.8 (43) 138.4 (40.6) 129.8 (38) 121.2 (35.5) 112.4 (32.9) 103.6 (30.4)
0 (-17.8) 518.0 (151.8) 495.6 (145.2) 473.8 (138.9) 452.6 (132.6) 432.4 (126.7) 413.4 (121.2) --- ---

-5 (-20.6) 467.8 (137.1) 446.4 (130.8) 425.6 (124.7) 405.4 (118.8) 386.0 (113.1) 367.4 (107.7) --- ---

-10 (-23.3) 422.6 (123.9) 402.6 (118) 383.0 (112.2) 363.8 (106.6) 345.2 (101.2) 327.4 (96) 310.4 (91)

-15 (-26.1) 381.4 (111.8) 362.8 (106.3) 344.4 (100.9) 326.4 (95.7) 308.8 (90.5) 291.8 (85.5) 275.8 (80.8)

-20 (-28.9) 343.0 (100.5) 326.0 (95.5) 309.0 (90.6) 292.2 (85.6) 275.8 (80.8) 259.8 (76.1) 244.6 (71.7)

-25 (-31.7) 306.4 (89.8) 291.0 (85.3) 275.6 (80.8) 260.0 (76.2) 244.8 (71.7) 230.0 (67.4) 215.6 (63.2)

-30 (-34.4) 270.2 (79.2) 256.6 (75.2) 242.8 (71.2) 228.8 (67.1) 214.8 (63) 201.2 (59) 187.8 (55)

-35 (-37.2) 233.4 (68.4) 221.6 (64.9) 209.4 (61.4) 197.0 (57.7) 184.4 (54) 172.0 (50.4) 159.8 (46.8)

-40 (-40) 194.4 (57) 184.6 (54.1) 174.2 (51.1) 163.4 (47.9) 152.4 (44.7) 141.4 (41.4) 130.4 (38.2)

12.6 (33) 107.0 (31.4) 101.0 (29.6) 94.6 (27.7) 87.8 (25.7) 80.8 (23.7) 73.2 (21.5)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 48 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS016H8-B

Compressor

Model

4C2067SH

KVS021H8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4C2397SH

KVS026H8-B

Compressor

Model

4B3139PH

KVS031H8-B

Compressor

Model

4B3604PH

KVS036H8-B

Compressor

Model

6B4709PH

KVS041H8-B

Compressor

Model

6B5406PH

KVS051H8-B

Compressor

Model

6B6462PH

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 234.3 (68.7) 225.4 (66.1) 216.6 (63.5) 207.8 (60.9) 199.2 (58.4) 190.6 (55.9) 182.2 (53.4)
50 (10) 214.3 (62.8) 206.1 (60.4) 197.9 (58) 189.9 (55.7) 181.9 (53.3) 174.0 (51) 166.3 (48.7)
45 (7.2) 195.3 (57.2) 187.8 (55) 180.3 (52.8) 172.9 (50.7) 165.6 (48.5) 158.4 (46.4) 151.3 (44.3)
40 (4.4) 177.4 (52) 170.5 (50) 163.7 (48) 156.9 (46) 150.3 (44) 143.7 (42.1) 137.3 (40.2)
35 (1.7) 160.6 (47.1) 154.3 (45.2) 148.1 (43.4) 141.9 (41.6) 135.9 (39.8) 129.9 (38.1) 124.1 (36.4)
55 (12.8) 271.1 (79.5) 260.9 (76.5) 250.7 (73.5) 240.6 (70.5) 230.5 (67.6) 220.6 (64.7) 210.7 (61.7)
50 (10) 247.9 (72.7) 238.5 (69.9) 229.1 (67.1) 219.8 (64.4) 210.6 (61.7) 201.4 (59) 192.3 (56.4)
45 (7.2) 226.0 (66.2) 217.4 (63.7) 208.8 (61.2) 200.2 (58.7) 191.7 (56.2) 183.3 (53.7) 175.0 (51.3)
40 (4.4) 205.4 (60.2) 197.4 (57.9) 189.6 (55.6) 181.7 (53.3) 174.0 (51) 166.3 (48.7) 158.7 (46.5)
35 (1.7) 185.9 (54.5) 178.7 (52.4) 171.5 (50.3) 164.4 (48.2) 157.3 (46.1) 150.3 (44) 143.4 (42)
55 (12.8) 348.9 (102.3) 336.6 (98.6) 324.3 (95) 312.1 (91.5) 299.9 (87.9) 287.7 (84.3) 275.6 (80.8)
50 (10) 319.1 (93.5) 307.7 (90.2) 296.4 (86.9) 285.1 (83.6) 273.8 (80.2) 262.6 (77) 251.4 (73.7)
45 (7.2) 290.9 (85.3) 280.4 (82.2) 270.0 (79.1) 259.6 (76.1) 249.3 (73.1) 238.9 (70) 228.7 (67)
40 (4.4) 264.4 (77.5) 254.8 (74.7) 245.3 (71.9) 235.7 (69.1) 226.2 (66.3) 216.8 (63.5) 207.3 (60.8)
35 (1.7) 239.6 (70.2) 230.8 (67.6) 222.0 (65.1) 213.3 (62.5) 204.6 (60) 196.0 (57.4) 187.4 (54.9)
55 (12.8) 400.9 (117.5) 386.4 (113.2) 371.7 (108.9) 357.0 (104.6) 342.2 (100.3) 327.4 (96) 312.5 (91.6)
50 (10) 366.2 (107.3) 352.8 (103.4) 339.3 (99.4) 325.7 (95.5) 312.0 (91.4) 298.3 (87.4) 284.6 (83.4)
45 (7.2) 333.5 (97.7) 321.2 (94.1) 308.7 (90.5) 296.2 (86.8) 283.6 (83.1) 271.0 (79.4) 258.4 (75.7)
40 (4.4) 302.8 (88.7) 291.4 (85.4) 280.0 (82.1) 268.5 (78.7) 257.0 (75.3) 245.4 (71.9) 233.8 (68.5)
35 (1.7) 274.0 (80.3) 263.6 (77.3) 253.2 (74.2) 242.7 (71.1) 232.1 (68) 221.5 (64.9) 210.9 (61.8)
55 (12.8) 525.3 (153.9) 506.8 (148.5) 488.3 (143.1) 469.9 (137.7) 451.5 (132.3) 433.2 (127) 414.9 (121.6)
50 (10) 480.3 (140.8) 463.2 (135.8) 446.1 (130.7) 429.1 (125.8) 412.2 (120.8) 395.2 (115.8) 378.4 (110.9)
45 (7.2) 437.8 (128.3) 422.1 (123.7) 406.4 (119.1) 390.7 (114.5) 375.1 (109.9) 359.6 (105.4) 344.1 (100.8)
40 (4.4) 397.9 (116.6) 383.4 (112.4) 369.0 (108.1) 354.7 (104) 340.4 (99.8) 326.1 (95.6) 311.9 (91.4)
35 (1.7) 360.4 (105.6) 347.2 (101.8) 334.0 (97.9) 320.9 (94) 307.8 (90.2) 294.8 (86.4) 281.8 (82.6)
55 (12.8) 601.4 (176.3) 579.6 (169.9) 557.7 (163.4) 535.6 (157) 513.4 (150.5) 491.1 (143.9) 468.8 (137.4)
50 (10) 549.4 (161) 529.2 (155.1) 509.0 (149.2) 488.6 (143.2) 468.1 (137.2) 447.5 (131.1) 426.9 (125.1)
45 (7.2) 500.3 (146.6) 481.8 (141.2) 463.1 (135.7) 444.4 (130.2) 425.5 (124.7) 406.6 (1
40 (4.4) 454.2 (133.1) 437.2 (128.1) 420.1 (123.1) 402.9 (118.1) 385.5 (113) 368.2 (107.9) 350.8 (102.8)
35 (1.7) 411.0 (120.5) 395.4 (115.9) 379.8 (111.3) 364.0 (106.7) 348.2 (102) 332.3 (97.4) 316.4 (92.7)
55 (12.8) 696.5 (204.1) 672.9 (197.2) 649.3 (190.3) 625.7 (183.4) 602.1 (176.5) 578.4 (169.5) 554.8 (162.6)
50 (10) 638.1 (187) 616.3 (180.6) 594.5 (174.2) 572.7 (167.8) 550.9 (161.5) 529.1 (155.1) 507.3 (148.7)
45 (7.2) 582.8 (170.8) 562.7 (164.9) 542.6 (159) 522.6 (153.2) 502.5 (147.3) 482.5 (141.4) 462.4 (135.5)
40 (4.4) 530.6 (155.5) 512.1 (150.1) 493.7 (144.7) 475.4 (139.3) 457.0 (133.9) 438.6 (128.5) 420.3 (123.2)
35 (1.7) 481.5 (141.1) 464.6 (136.2) 447.8 (131.2) 431.0 (126.3) 414.2 (121.4) 397.5 (116.5) 380.7 (111.6)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

19.2) 387.6 (113.6)

BITZER

CONDENSING

UNIT

MODEL

KVS016H8-B

Compressor

4C2067SH

KVS021H8-B

Compressor

4C2397SH

KVS026H8-B

Compressor

4B3139PH

KVS031H8-B

Compressor

4B3604PH

KVS036H8-B

Compressor

6B4709PH

KVS041H8-B

Compressor

6B5406PH

KVS051H8-B

Compressor

6B6462PH

CAPACITY DATA -

R404A

R507

60HzKVS-B

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

TEMPERATURE

° F ° C

45 (7.2) 225.3 (66) 215.6 (63.2) 205.9 (60.3) 196.1 (57.5) 186.3 (54.6) 176.5 (51.7) 166.6 (48.8)
40 (4.4) 207.2 (60.7) 198.2 (58.1) 189.2 (55.4) 180.2 (52.8) 171.1 (50.1) 162.0 (47.5) 152.8 (44.8)
35 (1.7) 190.0 (55.7) 181.7 (53.3) 173.3 (50.8) 165.0 (48.4) 156.6 (45.9) 148.2 (43.4) 139.7 (40.9)
45 (7.2) 260.8 (76.4) 250.0 (73.3) 239.1 (70.1) 228.4 (66.9) 217.6 (63.8) 206.8 (60.6) 196.0 (57.4)
40 (4.4) 239.6 (70.2) 229.6 (67.3) 219.5 (64.3) 209.4 (61.4) 199.4 (58.4) 189.4 (55.5) 179.3 (52.5)
35 (1.7) 219.5 (64.3) 210.2 (61.6) 200.8 (58.8) 191.5 (56.1) 182.2 (53.4) 172.8 (50.6) 163.5 (47.9)
45 (7.2) 332.7 (97.5) 319.3 (93.6) 306.0 (89.7) 292.8 (85.8) 279.7 (82) 266.7 (78.2) 253.8 (74.4)
40 (4.4) 306.1 (89.7) 293.6 (86) 281.3 (82.4) 269.1 (78.9) 256.9 (75.3) 244.9 (71.8) 233.0 (68.3)
35 (1.7) 280.7 (82.3) 269.2 (78.9) 257.8 (75.6) 246.6 (72.3) 235.4 (69) 224.3 (65.7) 213.2 (62.5)
45 (7.2) 384.0 (112.5) 368.7 (108.1) 353.4 (103.6) 338.2 (99.1) 323.1 (94.7) 308.0 (90.3) 292.9 (85.8)
40 (4.4) 353.4 (103.6) 339.2 (99.4) 325.1 (95.3) 311.0 (91.1) 297.0 (87) 283.0 (82.9) 269.0 (78.8)
35 (1.7) 324.2 (95) 311.1 (91.2) 298.1 (87.4) 285.1 (83.6) 272.2 (79.8) 259.3 (76) 246.4 (72.2)
45 (7.2) 501.0 (146.8) 480.8 (140.9) 460.7 (135) 440.7 (129.2) 420.9 (123.4) 401.2 (117.6) 381.7 (111.9)
40 (4.4) 460.9 (135.1) 442.1 (129.6) 423.5 (124.1) 404.9 (118.7) 386.6 (113.3) 368.4 (108) 350.3 (102.7)
35 (1.7) 422.5 (123.8) 405.2 (118.8) 388.0 (113.7) 370.9 (108.7) 354.0 (103.7) 337.2 (98.8) 320.5 (93.9)
45 (7.2) 574.4 (168.3) 551.2 (161.5) 528.1 (154.8) 505.1 (148) 482.3 (141.3) 459.5 (134.7) 436.8 (128)
40 (4.4) 528.7 (154.9) 507.3 (148.7) 486.0 (142.4) 464.7 (136.2) 443.5 (130) 422.5 (123.8) 401.4 (117.6)
35 (1.7) 485.2 (142.2) 465.5 (136.4) 445.8 (130.7) 426.2 (124.9) 406.7 (119.2) 387.3 (113.5) 367.9 (107.8)
45 (7.2) 658.6 (193) 631.5 (185.1) 604.3 (177.1) 577.3 (169.2) 550.3 (161.3) 523.4 (153.4) 496.4 (145.5)
40 (4.4) 607.8 (178.1) 582.6 (170.7) 557.5 (163.4) 532.4 (156) 507.3 (148.7) 482.3 (141.3) 457.4 (134.1)
35 (1.7) 559.1 (163.9) 535.9 (157.1) 512.7 (150.3) 489.5 (143.5) 466.3 (136.7) 443.2 (129.9) 420.1 (123.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 49 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS016M8-B

Compressor

Model

4C2067SH

KVS021M8-B

Compressor

Model

4C2397SH

KVS026M8-B

Compressor

Model

4B3139PH

KVS031M8-B

Compressor

Model

4B3604PH

KVS036M8-B

Compressor

Model

6B4709PH

KVS041M8-B

Compressor

Model

6B5406PH

KVS051M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 173.5 (50.8) 165.9 (48.6) 158.2 (46.4) 150.6 (44.1) 142.8 (41.9) 135.1 (39.6) 127.3 (37.3)
25 (-3.9) 157.8 (46.2) 150.9 (44.2) 143.9 (42.2) 136.9 (40.1) 129.8 (38) 122.7 (36) 115.5 (33.8)
20 (-6.7) 143.0 (41.9) 136.7 (40.1) 130.3 (38.2) 123.9 (36.3) 117.4 (34.4) 110.9 (32.5) 104.4 (30.6)
15 (-9.4) 129.0 (37.8) 123.2 (36.1) 117.5 (34.4) 111.7 (32.7) 105.8 (31) 99.9 (29.3) 93.9 (27.5)
10 (-12.2) 115.8 (33.9) 110.6 (32.4) 105.4 (30.9) 100.2 (29.4) 94.9 (27.8) 89.5 (26.2) 84.1 (24.6)

5 (-15) 103.4 (30.3) 98.8 (29) 94.1 (27.6) 89.4 (26.2) 84.6 (24.8) 79.8 (23.4) 74.9 (22)

0 (-17.8) 91.8 (26.9) 87.7 (25.7) 83.5 (24.5) 79.3 (23.2) 75.0 (22) 70.7 (20.7) 66.3 (19.4)
30 (-1.1) 200.4 (58.7) 191.7 (56.2) 183.1 (53.7) 174.5 (51.1) 165.8 (48.6) 157.2 (46.1) 148.5 (43.5)
25 (-3.9) 182.2 (53.4) 174.3 (51.1) 166.3 (48.7) 158.4 (46.4) 150.4 (44.1) 142.4 (41.7) 134.4 (39.4)
20 (-6.7) 165.1 (48.4) 157.8 (46.2) 150.5 (44.1) 143.2 (42) 135.9 (39.8) 128.6 (37.7) 121.2 (35.5)
15 (-9.4) 149.0 (43.7) 142.3 (41.7) 135.6 (39.7) 128.9 (37.8) 122.2 (35.8) 115.5 (33.8) 108.8 (31.9)
10 (-12.2) 133.8 (39.2) 127.7 (37.4) 121.6 (35.6) 115.5 (33.8) 109.4 (32.1) 103.3 (30.3) 97.2 (28.5)

5 (-15) 119.6 (35.1) 114.1 (33.4) 108.6 (31.8) 103.0 (30.2) 97.5 (28.6) 91.9 (26.9) 86.4 (25.3)

0 (-17.8) 106.3 (31.2) 101.3 (29.7) 96.4 (28.3) 91.4 (26.8) 86.3 (25.3) 81.3 (23.8) 76.3 (22.4)
30 (-1.1) 256.5 (75.2) 246.0 (72.1) 235.5 (69) 225.2 (66) 214.9 (63) 204.7 (60) 194.6 (57)
25 (-3.9) 233.6 (68.5) 224.0 (65.6) 214.4 (62.8) 204.9 (60.1) 195.5 (57.3) 186.2 (54.6) 176.9 (51.8)
20 (-6.7) 212.0 (62.1) 203.2 (59.6) 194.5 (57) 185.8 (54.5) 177.2 (51.9) 168.7 (49.4) 160.3 (47)
15 (-9.4) 191.5 (56.1) 183.5 (53.8) 175.6 (51.5) 167.8 (49.2) 160.0 (46.9) 152.3 (44.6) 144.7 (42.4)
10 (-12.2) 172.3 (50.5) 165.1 (48.4) 158.0 (46.3) 150.9 (44.2) 143.9 (42.2) 136.9 (40.1) 130.0 (38.1)

5 (-15) 154.3 (45.2) 147.8 (43.3) 141.4 (41.4) 135.0 (39.6) 128.7 (37.7) 122.5 (35.9) 116.3 (34.1)

0 (-17.8) 137.5 (40.3) 131.7 (38.6) 126.0 (36.9) 120.3 (35.3) 114.6 (33.6) 109.0 (31.9) 103.4 (30.3)
30 (-1.1) 296.4 (86.9) 284.4 (83.3) 272.5 (79.9) 260.6 (76.4) 248.7 (72.9) 236.8 (69.4) 225.0 (65.9)
25 (-3.9) 270.0 (79.1) 259.1 (75.9) 248.2 (72.7) 237.3 (69.5) 226.4 (66.4) 215.5
20 (-6.7) 245.1 (71.8) 235.1 (68.9) 225.2 (66) 215.3 (63.1) 205.4 (60.2) 195.5 (57.3) 185.6 (54.4)
15 (-9.4) 221.6 (64.9) 212.5 (62.3) 203.5 (59.6) 194.5 (57) 185.5 (54.4) 176.6 (51.8) 167.6 (49.1)
10 (-12.2) 199.5 (58.5) 191.3 (56.1) 183.2 (53.7) 175.0 (51.3) 166.9 (48.9) 158.8 (46.5) 150.7 (44.2)

5 (-15) 178.8 (52.4) 171.5 (50.3) 164.1 (48.1) 156.8 (46) 149.5 (43.8) 142.2 (41.7) 134.9 (39.5)

0 (-17.8) 159.5 (46.7) 152.9 (44.8) 146.3 (42.9) 139.8 (41) 133.2 (39) 126.7 (37.1) 120.1 (35.2)
30 (-1.1) 386.1 (113.2) 370.2 (108.5) 354.4 (103.9) 338.7 (99.3) 323.1 (94.7) 307.6 (90.1) 292.3 (85.7)
25 (-3.9) 351.6 (103) 337.0 (98.8) 322.5 (94.5) 308.1 (90.3) 293.9 (86.1) 279.7 (82) 265.7 (77.9)
20 (-6.7) 318.9 (93.5) 305.6 (89.6) 292.4 (85.7) 279.3 (81.9) 266.3 (78) 253.4 (74.3) 240.7 (70.5)
15 (-9.4) 288.1 (84.4) 276.0 (80.9) 264.0 (77.4) 252.1 (73.9) 240.4 (70.5) 228.7 (67) 217.1 (63.6)
10 (-12.2) 259.1 (75.9) 248.2 (72.7) 237.4 (69.6) 226.6 (66.4) 216.0 (63.3) 205.5 (60.2) 195.1 (57.2)

5 (-15) 232.0 (68) 222.2 (65.1) 212.5 (62.3) 202.8 (59.4) 193.2 (56.6) 183.8 (53.9) 174.4 (51.1)

0 (-17.8) 206.7 (60.6) 197.9 (58) 189.2 (55.4) 180.5 (52.9) 172.0 (50.4) 163.5 (47.9) 155.2 (45.5)
30 (-1.1) 443.7 (130) 425.6 (124.7) 407.6 (119.5) 389.6 (114.2) 371.7 (108.9) 353.9 (103.7) 336.1 (98.5)
25 (-3.9) 404.4 (1
20 (-6.7) 367.1 (107.6) 352.1 (103.2) 337.1 (98.8) 322.2 (94.4) 307.3 (90.1) 292.4 (85.7) 277.6 (81.4)
15 (-9.4) 332.0 (97.3) 318.4 (93.3) 304.8 (89.3) 291.3 (85.4) 277.8 (81.4) 264.3 (77.5) 250.9 (73.5)
10 (-12.2) 298.9 (87.6) 286.7 (84) 274.4 (80.4) 262.2 (76.8) 250.1 (73.3) 237.9 (69.7) 225.8 (66.2)

5 (-15) 268.0 (78.5) 257.0 (75.3) 246.0 (72.1) 235.0 (68.9) 224.1 (65.7) 213.2 (62.5) 202.3 (59.3)

0 (-17.8) 239.1 (70.1) 229.2 (67.2) 219.4 (64.3) 209.6 (61.4) 199.8 (58.6) 190.0 (55.7) 180.3 (52.8)
30 (-1.1) 512.7 (150.3) 491.3 (144) 469.9 (137.7) 448.6 (131.5) 427.3 (125.2) 406.0 (119) --- --­25 (-3.9) 468.5 (137.3) 448.9 (131.6) 429.3 (125.8) 409.7 (120.1) 390.2 (114.4) 370.7 (108.6) 351.2 (102.9)
20 (-6.7) 426.5 (125) 408.7 (119.8) 390.8 (114.5) 372.9 (109.3) 355.0 (104) 337.2 (98.8) 319.4 (93.6)
15 (-9.4) 386.9 (113.4) 370.6 (108.6) 354.3 (103.8) 338.1 (99.1) 321.8 (94.3) 305.6 (89.6) 289.4 (84.8)
10 (-12.2) 349.4 (102.4) 334.7 (98.1) 320.0 (93.8) 305.2 (89.4) 290.5 (85.1) 275.8 (80.8) 261.2 (76.5)

5 (-15) 314.3 (92.1) 301.0 (88.2) 287.7 (84.3) 274.4 (80.4) 261.1 (76.5) 247.9 (72.7) 234.7 (68.8)

0 (-17.8) 281.4 (82.5) 269.4 (79) 257.5 (75.5) 245.5 (71.9) 233.6 (68.5) 221.7 (65) 209.8 (61.5)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

18.5) 387.8 (113.7) 371.4 (108.8) 354.9 (104) 338.6 (99.2) 322.3 (94.5) 306.0 (89.7)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

(63.2) 204.7 (60)

HIGH EFFICIENCY MODELS

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 50 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS016M8-B

Compressor

Model

4C2067SH

KVS021M8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4C2397SH

KVS026M8-B

Compressor

Model

4B3139PH

KVS031M8-B

Compressor

Model

4B3604PH

KVS036M8-B

Compressor

Model

6B4709PH

KVS041M8-B

Compressor

Model

6B5406PH

KVS051M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 144.8 (42.4) 139.1 (40.8) 133.5 (39.1) 127.9 (37.5) 122.4 (35.9) 117.0 (34.3) 111.8 (32.8)
25 (-3.9) 130.1 (38.1) 124.9 (36.6) 119.8 (35.1) 114.8 (33.6) 109.8 (32.2) 105.0 (30.8) 100.3 (29.4)
20 (-6.7) 116.4 (34.1) 111.7 (32.7) 107.1 (31.4) 102.5 (30) 98.1 (28.8) 93.7 (27.5) 89.5 (26.2)
15 (-9.4) 103.6 (30.4) 99.4 (29.1) 95.2 (27.9) 91.1 (26.7) 87.1 (25.5) 83.3 (24.4) 79.5 (23.3)
10 (-12.2) 91.8 (26.9) 88.0 (25.8) 84.2 (24.7) 80.6 (23.6) 77.0 (22.6) 73.5 (21.5) 70.2 (20.6)

30 (-1.1) 167.7 (49.1) 161.1 (47.2) 154.6 (45.3) 148.1 (43.4) 141.7 (41.5) 135.3 (39.7) 129.1 (37.8)
25 (-3.9) 150.7 (44.2) 144.7 (42.4) 138.7 (40.6) 132.9 (38.9) 127.0 (37.2) 121.3 (35.5) 115.7 (33.9)
20 (-6.7) 134.8 (39.5) 129.4 (37.9) 124.0 (36.3) 118.7 (34.8) 113.4 (33.2) 108.3 (31.7) 103.3 (30.3)
15 (-9.4) 120.0 (35.2) 115.1 (33.7) 110.2 (32.3) 105.4 (30.9) 100.7 (29.5) 96.1 (28.2) 91.6 (26.8)
10 (-12.2) 106.3 (31.2) 101.9 (29.9) 97.5 (28.6) 93.1 (27.3) 88.9 (26.1) 84.7 (24.8) 80.7 (23.7)

30 (-1.1) 216.3 (63.4) 208.3 (61) 200.3 (58.7) 192.4 (56.4) 184.5 (54.1) 176.6 (51.8) 168.7 (49.4)
25 (-3.9) 194.6 (57) 187.3 (54.9) 180.1 (52.8) 172.8 (50.6) 165.6 (48.5) 158.5 (46.5) 151.3 (44.3)
20 (-6.7) 174.4 (51.1) 167.8 (49.2) 161.2 (47.2) 154.6 (45.3) 148.1 (43.4) 141.6 (41.5) 135.2 (39.6)
15 (-9.4) 155.7 (45.6) 149.7 (43.9) 143.7 (42.1) 137.8 (40.4) 131.8 (38.6) 126.0 (36.9) 120.1 (35.2)
10 (-12.2) 138.4 (40.6) 132.9 (38.9) 127.5 (37.4) 122.1 (35.8) 116.7 (34.2) 111.4 (32.6) 106.1 (31.1)
30 (-1.1) 247.0 (72.4) 237.6 (69.6) 228.1 (66.8) 218.5 (64) 208.9 (61.2) 199.2 (58.4) 189.6 (55.6)
25 (-3.9) 222.0 (65.1) 213.4 (62.5) 204.7 (60) 196.0 (57.4) 187.3 (54.9) 178.5 (52.3) 169.7 (49.7)
20 (-6.7) 198.7 (58.2) 190.9 (55.9) 183.0 (53.6) 175.1 (51.3) 167.2 (49) 159.2 (46.7) 151.3 (44.3)
15 (-9.4) 177.1 (51.9) 170.0 (49.8) 162.9 (47.7) 155.7 (45.6) 148.6 (43.6) 141.4 (41.4) 134.2 (39.3)
10 (-12.2) 157.1 (46) 150.7 (44.2) 144.3 (42.3) 137.8 (40.4) 131.3 (38.5) 124.8 (36.6) 118.4 (34.7)
30 (-1.1) 325.4 (95.4) 313.3 (91.8) 301.3 (88.3) 289.3 (84.8) 277.4 (81.3) 265.6 (77.8) 253.7 (74.4)
25 (-3.9) 292.7 (85.8) 281.7 (82.6) 270.8 (79.4) 259.9 (76.2) 249.1 (73) 238.3 (69.8) 227.6 (66.7)

20 (-6.7) 262.3 (76.9) 252.3 (73.9) 242.4 (71) 232.5 (68.1) 222.7 (65.3) 212.9 (62.4) 203.2 (59.6)
15 (-9.4) 234.1 (68.6) 225.0 (65.9) 216.0 (63.3) 207.1 (60.7) 198.2 (58.1) 189.3 (55.5) 180.5 (52.9)
10 (-12.2) 208.0 (61) 199.8 (58.6) 191.6 (56.2) 183.5 (53.8) 175.4 (51.4) 167.4 (49.1) 159.5 (46.7)
30 (-1.1) 370.6 (108.6) 356.4 (104.5) 342.1 (100.3) 327.8 (96.1) 313.4 (91.8) 298.9 (87.6) 284.4 (83.3)
25 (-3.9) 333.0 (97.6) 320.1 (93.8) 307.1 (90) 294.0 (86.2) 280.9 (82.3) 267.8 (78.5) 254.6 (74.6)
20 (-6.7) 298.0 (87.3) 286.3 (83.9) 274.5 (80.4) 262.7 (77) 250.8 (73.5) 238.9 (70) 227.0 (66.5)
15 (-9.4) 265.6 (77.8) 255.1 (74.8) 244.4 (71.6) 233.7 (68.5) 222.9 (65.3) 212.1 (62.2) 201.3 (59)
10 (-12.2) 235.7 (69.1) 226.1 (66.3) 216.5 (63.4) 206.8 (60.6) 197.0 (57.7) 187.3 (54.9) 177.6 (52)
30 (-1.1) 435.4 (127.6) 420.1 (123.1) 404.8 (118.6) 389.4 (114.1) 374.2 (109.7) 358.9 (105.2) 343.7 (100.7)

25 (-3.9) 392.4 (115) 378.4 (1

20 (-6.7) 352.3 (103.2) 339.6 (99.5) 327.0 (95.8) 314.4 (92.1) 301.8 (88.4) 289.3 (84.8) 276.8 (81.1)

15 (-9.4) 315.0 (92.3) 303.5 (88.9) 292.1 (85.6) 280.7 (82.3) 269.3 (78.9) 258.0 (75.6) 246.7 (72.3)

10 (-12.2) 280.4 (82.2) 270.1 (79.2) 259.7 (76.1) 249.4 (73.1) 239.1 (70.1) 228.9 (67.1) 218.7 (64.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

10.9) 364.5 (106.8) 350.6 (102.8) 336.7 (98.7) 322.9 (94.6) 309.1 (90.6)

R407C

AMBIENT TEMPERATURE °F (°C)

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

BITZER

04/17/13

K40-KV-PDS-17

- 51 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzKVS-B

CONDENSING

UNIT

MODEL

KVS013L6-B

Compressor

Model

4C2397SL

KVS016L6-B

Compressor

Model

4B3139PL

KVS021L6-B

Compressor

Model

4B3604PL

KVS026L6-B

Compressor

Model

6B4709PL

KVS031L6-B

Compressor

Model

6B5406PL

KVS041L6-B

Compressor

Model

6B6462PL

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 96.1 (28.2) 91.5 (26.8) 87.0 (25.5) 82.5 (24.2) 78.0 (22.9) 73.5 (21.5) 69.1 (20.3)

-5 (-20.6) 85.8 (25.1) 81.7 (23.9) 77.5 (22.7) 73.4 (21.5) 69.3 (20.3) 65.3 (19.1) 61.2 (17.9)

-10 (-23.3) 76.1 (22.3) 72.4 (21.2) 68.7 (20.1) 65.0 (19) 61.2 (17.9) 57.6 (16.9) 53.9 (15.8)

-15 (-26.1) 67.1 (19.7) 63.8 (18.7) 60.4 (17.7) 57.0 (16.7) 53.7 (15.7) 50.4 (14.8) 47.1 (13.8)

-20 (-28.9) 58.8 (17.2) 55.7 (16.3) 52.7 (15.4) 49.7 (14.6) 46.7 (13.7) 43.7 (12.8) 40.7 (11.9)

-25 (-31.7) 51.0 (14.9) 48.3 (14.2) 45.6 (13.4) 42.8 (12.5) 40.1 (11.8) 37.5 (11) 34.8 (10.2)

-30 (-34.4) 43.9 (12.9) 41.4 (12.1) 39.0 (11.4) 36.5 (10.7) 34.1 (10) 31.7 (9.3) 29.3 (8.6)

-35 (-37.2) 37.3 (10.9) 35.1 (10.3) 32.9 (9.6) 30.6 (9) 28.5 (8.4) 26.3 (7.7) 24.1 (7.1)

-40 (-40) 31.3 (9.2) 29.3 (8.6) 27.2 (8) 25.2 (7.4) 23.2 (6.8) 21.3 (6.2) 19.3 (5.7)
0 (-17.8) 134.6 (39.4) 128.6 (37.7) 122.8 (36) 116.9 (34.3) 111.1 (32.6) 105.4 (30.9) 99.7 (29.2)

-5 (-20.6) 120.3 (35.3) 115.0 (33.7) 109.7 (32.1) 104.4 (30.6) 99.1 (29) 93.9 (27.5) 88.7 (26)

-10 (-23.3) 107.1 (31.4) 102.3 (30) 97.5 (28.6) 92.7 (27.2) 87.9 (25.8) 83.2 (24.4) 78.5 (23)

-15 (-26.1) 94.8 (27.8) 90.5 (26.5) 86.1 (25.2) 81.8 (24) 77.5 (22.7) 73.3 (21.5) 69.0 (20.2)

-20 (-28.9) 83.5 (24.5) 79.6 (23.3) 75.6 (22.2) 71.8 (21) 67.9 (19.9) 64.0 (18.8) 60.2 (17.6)

-25 (-31.7) 73.0 (21.4) 69.5 (20.4) 66.0 (19.3) 62.5 (18.3) 59.0 (17.3) 55.5 (16.3) 52.1 (15.3)

-30 (-34.4) 63.4 (18.6) 60.2 (17.6) 57.1 (16.7) 53.9 (15.8) 50.8 (14.9) 47.6 (14) 44.5 (13)

-35 (-37.2) 54.6 (16) 51.7 (15.2) 48.9 (14.3) 46.0 (13.5) 43.2 (12.7) 40.3 (11.8) 37.5 (11)

-40 (-40) 46.5 (13.6) 43.9 (12.9) 41.3 (12.1) 38.7 (11.3) 36.1 (10.6) 33.5 (9.8) 30.9 (9.1)
0 (-17.8) 151.9 (44.5) 145.4 (42.6) 138.8 (40.7) 132.1 (38.7) 125.4 (36.8) 118.6 (34.8) 111.6 (32.7)

-5 (-20.6) 136.0 (39.9) 130.2 (38.2) 124.3 (36.4) 118.3 (34.7) 112.3 (32.9) 106.2 (31.1) 99.9 (29.3)

-10 (-23.3) 121.1 (35.5) 115.9 (34) 110.6 (32.4) 105.3 (30.9) 100.0 (29.3) 94.5 (27.7) 88.9 (26.1)

-15 (-26.1) 107.3 (31.4) 102.6 (30.1) 97.9 (28.7) 93.2 (27.3) 88.4 (25.9) 83.5 (24.5) 78.6 (23)

-20 (-28.9) 94.3 (27.6) 90.2 (26.4) 86.0 (25.2) 81.8 (24) 77.6 (22.7) 73.3 (21.5) 68.9 (20.2)

-25 (-31.7) 82.4 (24.1) 78.7 (23.1) 75.0 (22) 71.3 (20.9) 67.5 (19.8) 63.7 (18.7) 59.8 (17.5)

-30 (-34.4) 71.4 (20.9) 68.0 (19.9) 64.7 (19) 61.4 (18) 58.1 (17) 54.7 (16) 51.2 (15)

-35 (-37.2) 61.2 (17.9) 58.2 (17.1) 55.3 (16.2) 52.3 (15.3) 49.3 (14.4) 46.3 (13.6) 43.2 (12.7)

-40 (-40) 51.9 (15.2) 49.2 (14.4) 46.5 (13.6) 43.8 (12.8) 41.1 (12) 38.4 (11.3) 35.6 (10.4)
0 (-17.8) 193.5 (56.7) 185.0 (54.2) 176.4 (51.7) 167.9 (49.2) 159.5 (46.7) 150.9 (44.2) 142.4 (41.7)

-5 (-20.6) 173.3 (50.8) 165.6 (48.5) 158.0 (46.3) 150.4 (44.1) 142.7 (41.8) 135.1 (39.6) 127.4 (37.3)

-10 (-23.3) 154.4 (45.3) 147.5 (43.2) 140.7 (41.2) 133.9 (39.2) 127.0 (37.2) 120.2 (35.2) 113.4 (33.2)

-15 (-26.1) 136.7 (40.1) 130.5 (38.2) 124.5 (36.5) 118.4 (34.7) 1

-20 (-28.9) 120.2 (35.2) 114.7 (33.6) 109.3 (32) 103.9 (30.4) 98.5 (28.9) 93.1 (27.3) 87.7 (25.7)

-25 (-31.7) 104.9 (30.7) 100.1 (29.3) 95.2 (27.9) 90.5 (26.5) 85.7 (25.1) 80.9 (23.7) 76.1 (22.3)

-30 (-34.4) 90.8 (26.6) 86.5 (25.4) 82.2 (24.1) 77.9 (22.8) 73.7 (21.6) 69.4 (20.3) 65.1 (19.1)

-35 (-37.2) 77.9 (22.8) 74.0 (21.7) 70.1 (20.5) 66.3 (19.4) 62.5 (18.3) 58.7 (17.2) 54.9 (16.1)

-40 (-40) 66.0 (19.3) 62.5 (18.3) 59.0 (17.3) 55.5 (16.3) 52.1 (15.3) 48.7 (14.3) 45.2 (13.2)
0 (-17.8) 213.8 (62.7) 204.7 (60) 195.8 (57.4) 186.7 (54.7) 177.7 (52.1) 168.5 (49.4) --- ---

-5 (-20.6) 191.7 (56.2) 183.6 (53.8) 175.5 (51.4) 167.4 (49.1) 159.2 (46.7) 150.9 (44.2) 142.5 (41.8)

-10 (-23.3) 171.0 (50.1) 163.7 (48) 156.4 (45.8) 149.2 (43.7) 141.9 (41.6) 134.4 (39.4) 126.8 (37.2)

-15 (-26.1) 151.5 (44.4) 145.0 (42.5) 138.5 (40.6) 132.1 (38.7) 125.5 (36.8) 118.9 (34.8) 112.0 (32.8)

-20 (-28.9) 133.4 (39.1) 127.6 (37.4) 121.8 (35.7) 116.0 (34) 110.2 (32.3) 104.3 (30.6) 98.1 (28.8)

-25 (-31.7) 116.5 (34.1) 111.3 (32.6) 106.2 (31.1) 101.0 (29.6) 95.9 (28.1) 90.6 (26.6) 85.1 (24.9)

-30 (-34.4) 100.9 (29.6) 96.3 (28.2) 91.7 (26.9) 87.1 (25.5) 82.5 (24.2) 77.7 (22.8) 72.8 (21.3)

-35 (-37.2) 86.5 (25.4) 82.3 (24.1) 78.2 (22.9) 74.1 (21.7) 69.9 (20.5) 65.7 (19.3) 61.3 (18)

-40 (-40) 73.3 (21.5) 69.5 (20.4) 65.7 (19.3) 62.0 (18.2) 58.2 (17.1) 54.4 (15.9) 50.3 (14.7)
0 (-17.8) 258.9 (75.9) 247.2 (72.4) 235.7 (69.1) 224.2 (65.7) 212.9 (62.4) 201.7 (59.1) 190.5 (55.8)

-5 (-20.6) 231.8 (67.9) 221.2 (64.8) 210.7 (61.7) 200.3 (58.7) 190.0 (55.7) 179.8 (52.7) 169.7 (49.7)

-10 (-23.3) 206.4 (60.5) 196.8 (57.7) 187.3 (54.9) 177.9 (52.1) 168.6 (49.4) 159.4 (46.7) 150.2 (44)

-15 (-26.1) 182.7 (53.5) 174.0 (51) 165.4 (48.5) 157.0 (46) 148.6 (43.6) 140.2 (41.1) 132.0 (38.7)

-20 (-28.9) 160.6 (47.1) 152.8 (44.8) 145.1 (42.5) 137.4 (40.3) 129.9 (38.1) 122.4 (35.9) 114.9 (33.7)

-25 (-31.7) 140.0 (41) 133.0 (39) 126.1 (37) 119.3 (35) 112.5 (33) 105.7 (31) 99.0 (29)

-30 (-34.4) 121.1 (35.5) 1

-35 (-37.2) 103.6 (30.4) 97.9 (28.7) 92.3 (27.1) 86.7 (25.4) 81.2 (23.8) 75.7 (22.2) 70.2 (20.6)

-40 (-40) 87.5 (25.6) 82.4 (24.1) 77.3 (22.7) 72.2 (21.2) 67.2 (19.7) 62.2 (18.2) 57.2 (16.8)

CAPACITY MBH (KW)

14.8 (33.6) 108.6 (31.8) 102.4 (30) 96.3 (28.2) 90.2 (26.4) 84.1 (24.6)

R404A

AMBIENT TEMPERATURE °F (°C)

R507

12.3 (32.9) 106.2 (31.1) 100.1 (29.3)

HIGH EFFICIENCY MODELS

BITZER

04/17/13

K40-KV-PDS-17

- 52 -

CAPACITY DATA -

R407C

HIGH TEMP. HIGH EFFICIENCY MODELS

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD031H8-B

Compressor

Model

4C2067SH

KVD041H8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4C2397SH

KVD051H8-B

Compressor

Model

4B3139PH

KVD061H8-B

Compressor

Model

4B3604PH

KVD071H8-B

Compressor

Model

6B4709PH

KVD081H8-B

Compressor

Model

6B5406PH

KVD101H8-B

Compressor

Model

6B6462PH

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

SATURATED

SUCTION

TEMPERATURE

° F ° C

55 (12.8) 468.6 (137.3) 450.8 (132.1) 433.2 (127) 415.6 (121.8) 398.4 (116.8) 381.2 (111.7) 364.4 (106.8)
50 (10) 428.6 (125.6) 412.2 (120.8) 395.8 (116) 379.8 (111.3) 363.8 (106.6) 348.0 (102) 332.6 (97.5)
45 (7.2) 390.6 (114.5) 375.6 (110.1) 360.6 (105.7) 345.8 (101.3) 331.2 (97.1) 316.8 (92.8) 302.6 (88.7)
40 (4.4) 354.8 (104) 341.0 (99.9) 327.4 (96) 313.8 (92) 300.6 (88.1) 287.4 (84.2) 274.6 (80.5)
35 (1.7) 321.2 (94.1) 308.6 (90.4) 296.2 (86.8) 283.8 (83.2) 271.8 (79.7) 259.8 (76.1) 248.2 (72.7)
55 (12.8) 542.2 (158.9) 521.8 (152.9) 501.4 (146.9) 481.2 (141) 461.0 (135.1) 441.2 (129.3) 421.4 (123.5)
50 (10) 495.8 (145.3) 477.0 (139.8) 458.2 (134.3) 439.6 (128.8) 421.2 (123.4) 402.8 (118) 384.6 (112.7)
45 (7.2) 452.0 (132.5) 434.8 (127.4) 417.6 (122.4) 400.4 (117.3) 383.4 (112.4) 366.6 (107.4) 350.0 (102.6)
40 (4.4) 410.8 (120.4) 394.8 (115.7) 379.2 (111.1) 363.4 (106.5) 348.0 (102) 332.6 (97.5) 317.4 (93)
35 (1.7) 371.8 (109) 357.4 (104.7) 343.0 (100.5) 328.8 (96.4) 314.6 (92.2) 300.6 (88.1) 286.8 (84.1)
55 (12.8) 697.8 (204.5) 673.2 (197.3) 648.6 (190.1) 624.2 (182.9) 599.8 (175.8) 575.4 (168.6) 551.2 (161.5)
50 (10) 638.2 (187) 615.4 (180.4) 592.8 (173.7) 570.2 (167.1) 547.6 (160.5) 525.2 (153.9) 502.8 (147.4)

45 (7.2) 581.8 (170.5) 560.8 (164.4) 540.0 (158.3) 519.2 (152.2) 498.6 (146.1) 477.8 (140) 457.4 (134.1)
40 (4.4) 528.8 (155) 509.6 (149.3) 490.6 (143.8) 471.4 (138.2) 452.4 (132.6) 433.6 (127.1) 414.6 (121.5)
35 (1.7) 479.2 (140.4) 461.6 (135.3) 444.0 (130.1) 426.6 (125) 409.2 (119.9) 392.0 (114.9) 374.8 (109.8)
55 (12.8) 801.8 (235) 772.8 (226.5) 743.4 (217.9) 714.0 (209.3) 684.4 (200.6) 654.8 (191.9) 625.0 (183.2)
50 (10) 732.4 (214.6) 705.6 (206.8) 678.6 (198.9) 651.4 (190.9) 624.0 (182.9) 596.6 (174.8) 569.2 (166.8)
45 (7.2) 667.0 (195.5) 642.4 (188.3) 617.4 (180.9) 592.4 (173.6) 567.2 (166.2) 542.0 (158.8) 516.8 (151.5)
40 (4.4) 605.6 (177.5) 582.8 (170.8) 560.0 (164.1) 537.0 (157.4) 514.0 (150.6) 490.8 (143.8) 467.6 (137)
35 (1.7) 548.0 (160.6) 527.2 (154.5) 506.4 (148.4) 485.4 (142.3) 464.2 (136) 443.0 (129.8) 421.8 (123.6)
55 (12.8) 1050.6 (307.9) 1013.6 (297.1) 976.6 (286.2) 939.8 (275.4) 903.0 (264.6) 866.4 (253.9) 829.8 (243.2)
50 (10) 960.6 (281.5) 926.4 (271.5) 892.2 (261.5) 858.2 (251.5) 824.4 (241.6) 790.4 (231.6) 756.8 (221.8)
45 (7.2) 875.6 (256.6) 844.2 (247.4) 812.8 (238.2) 781.4 (229) 750.2 (219.9) 719.2 (210.8) 688.2 (201.7)

40 (4.4) 795.8 (233.2) 766.8 (224.7) 738.0 (216.3) 709.4 (207.9) 680.8 (199.5) 652.2 (191.1) 623.8 (182.8)

35 (1.7) 720.8 (211.2) 694.4 (203.5) 668.0 (195.8) 641.8 (188.1) 615.6 (180.4) 589.6 (172.8) 563.6 (165.2)

55 (12.8) 1202.8 (352.5) 1159.2 (339.7) 11

50 (10) 1098.8 (322) 1058.4 (310.2) 1018.0 (298.3) 977.2 (286.4) 936.2 (274.4) 895.0 (262.3) 853.8 (250.2)

45 (7.2) 1000.6 (293.2) 963.6 (282.4) 926.2 (271.4) 888.8 (260.5) 851.0 (249.4) 813.2 (238.3) 775.2 (227.2)

40 (4.4) 908.4 (266.2) 874.4 (256.3) 840.2 (246.2) 805.8 (236.2) 771.0 (226) 736.4 (215.8) 701.6 (205.6)

35 (1.7) 822.0 (240.9) 790.8 (231.8) 759.6 (222.6) 728.0 (213.4) 696.4 (204.1) 664.6 (194.8) 632.8 (185.5)

55 (12.8) 1393.0 (408.2) 1345.8 (394.4) 1298.6 (380.6) 1251.4 (366.7) 1204.2 (352.9) 1156.8 (339) 1109.6 (325.2)

50 (10) 1276.2 (374) 1232.6 (361.2) 1189.0 (348.5) 1145.4 (335.7) 1101.8 (322.9) 1058.2 (310.1) 1014.6 (297.3)

45 (7.2) 1165.6 (341.6) 1125.4 (329.8) 1085.2 (318) 1045.2 (306.3) 1005.0 (294.5) 965.0 (282.8) 924.8 (271)

40 (4.4) 1061.2 (311) 1024.2 (300.2) 987.4 (289.4) 950.8 (278.7) 914.0 (267.9) 877.2 (257.1) 840.6 (246.4)

35 (1.7) 963.0 (282.2) 929.2 (272.3) 895.6 (262.5) 862.0 (252.6) 828.4 (242.8) 795.0 (233) 761.4 (223.1)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

15.4 (326.9) 1071.2 (313.9) 1026.8 (300.9) 982.2 (287.9) 937.6 (274.8)

R407C

AMBIENT TEMPERATURE °F (°C)

BITZER

CONDENSING

UNIT

MODEL

KVD031H8-B

Compressor

4C2067SH

KVD041H8-B

Compressor

4C2397SH

KVD051H8-B

Compressor

4B3139PH

KVD061H8-B

Compressor

4B3604PH

KVD071H8-B

Compressor

6B4709PH

KVD081H8-B

Compressor

6B5406PH

KVD101H8-B

Compressor

6B6462PH

CAPACITY DATA -

R404A

R507

60HzKVD-B

HIGH TEMP. HIGH EFFICIENCY MODELS

SATURATED

SUCTION

TEMPERATURE

° F ° C
45 (7.2) 450.6 (132.1) 431.2 (126.4) 411.8 (120.7) 392.2 (114.9) 372.6 (109.2) 353.0 (103.5) 333.2 (97.7)
40 (4.4) 414.4 (121.4) 396.4 (116.2) 378.4 (110.9) 360.4 (105.6) 342.2 (100.3) 324.0 (95) 305.6 (89.6)
35 (1.7) 380.0 (111.4) 363.4 (106.5) 346.6 (101.6) 330.0 (96.7) 313.2 (91.8) 296.4 (86.9) 279.4 (81.9)
45 (7.2) 521.6 (152.9) 500.0 (146.5) 478.2 (140.1) 456.8 (133.9) 435.2 (127.5) 413.6 (121.2) 392.0 (114.9)
40 (4.4) 479.2 (140.4) 459.2 (134.6) 439.0 (128.7) 418.8 (122.7) 398.8 (116.9) 378.8 (111) 358.6 (105.1)
35 (1.7) 439.0 (128.7) 420.4 (123.2) 401.6 (117.7) 383.0 (112.2) 364.4 (106.8) 345.6 (101.3) 327.0 (95.8)
45 (7.2) 665.4 (195) 638.6 (187.2) 612.0 (179.4) 585.6 (171.6) 559.4 (163.9) 533.4 (156.3) 507.6 (148.8)
40 (4.4) 612.2 (179.4) 587.2 (172.1) 562.6 (164.9) 538.2 (157.7) 513.8 (150.6) 489.8 (143.5) 466.0 (136.6)
35 (1.7) 561.4 (164.5) 538.4 (157.8) 515.6 (151.1) 493.2 (144.5) 470.8 (138) 448.6 (131.5) 426.4 (125)
45 (7.2) 768.0 (225.1) 737.4 (216.1) 706.8 (207.1) 676.4 (198.2) 646.2 (189.4) 616.0 (180.5) 585.8 (171.7)
40 (4.4) 706.8 (207.1) 678.4 (198.8) 650.2 (190.6) 622.0 (182.3) 594.0 (174.1) 566.0 (165.9) 538.0 (157.7)
35 (1.7) 648.4 (190) 622.2 (182.3) 596.2 (174.7) 570.2 (167.1) 544.4 (159.5) 518.6 (152) 492.8 (144.4)
45 (7.2) 1002.0 (293.7) 961.6 (281.8) 921.4 (270) 881.4 (258.3) 841.8 (246.7) 802.4 (235.2) 763.4 (223.7)
40 (4.4) 921.8 (270.2) 884.2 (259.1) 847.0 (248.2) 809.8 (237.3) 773.2 (226.6) 736.8 (215.9) 700.6 (205.3)
35 (1.7) 845.0 (247.6) 810.4 (237.5) 776.0 (227.4) 741.8 (217.4) 708.0 (207.5) 674.4 (197.6) 641.0 (187.9)
45 (7.2) 1148.8 (336.7) 1102.4 (323.1) 1056.2 (309.5) 1010.2 (296.1) 964.6 (282.7) 919.0 (269.3) 873.6 (256)
40 (4.4) 1057.4 (309.9) 1014.6 (297.3) 972.0 (284.9) 929.4 (272.4) 887.0 (260) 845.0 (247.6) 802.8 (235.3)
35 (1.7) 970.4 (284.4) 931.0 (272.8) 891.6 (261.3) 852.4 (249.8) 813.4 (238.4) 774.6 (227) 735.8 (215.6)
45 (7.2) 1317.2 (386) 1263.0 (370.1) 1208.6 (354.2) 1154.6 (338.4) 1100.6 (322.6) 1046.8 (306.8) 992.8 (291)
40 (4.4) 1215.6 (356.3) 1165.2 (341.5) 1115.0 (326.8) 1064.8 (312.1) 1014.6 (297.3) 964.6 (282.7) 914.8 (268.1)
35 (1.7) 1118.2 (327.7) 1071.8 (314.1) 1025.4 (300.5) 979.0 (286.9) 932.6 (273.3) 886.4 (259.8) 840.2 (246.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R404A R507

AMBIENT TEMPERATURE °F (°C)

BITZER

04/17/13

K40-KV-PDS-17

- 53 -

CAPACITY DATA -

R404A

R507

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD031M8-B

Compressor

Model

4C2067SH

KVD041M8-B

Compressor

Model

4C2397SH

KVD051M8-B

Compressor

Model

4B3139PH

KVD061M8-B

Compressor

Model

4B3604PH

KVD071M8-B

Compressor

Model

6B4709PH

KVD081M8-B

Compressor

Model

6B5406PH

KVD101M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 347.0 (101.7) 331.8 (97.2) 316.4 (92.7) 301.2 (88.3) 285.6 (83.7) 270.2 (79.2) 254.6 (74.6)
25 (-3.9) 315.6 (92.5) 301.8 (88.4) 287.8 (84.3) 273.8 (80.2) 259.6 (76.1) 245.4 (71.9) 231.0 (67.7)
20 (-6.7) 286.0 (83.8) 273.4 (80.1) 260.6 (76.4) 247.8 (72.6) 234.8 (68.8) 221.8 (65) 208.8 (61.2)
15 (-9.4) 258.0 (75.6) 246.4 (72.2) 235.0 (68.9) 223.4 (65.5) 211.6 (62) 199.8 (58.6) 187.8 (55)
10 (-12.2) 231.6 (67.9) 221.2 (64.8) 210.8 (61.8) 200.4 (58.7) 189.8 (55.6) 179.0 (52.5) 168.2 (49.3)

5 (-15) 206.8 (60.6) 197.6 (57.9) 188.2 (55.2) 178.8 (52.4) 169.2 (49.6) 159.6 (46.8) 149.8 (43.9)

0 (-17.8) 183.6 (53.8) 175.4 (51.4) 167.0 (48.9) 158.6 (46.5) 150.0 (44) 141.4 (41.4) 132.6 (38.9)
30 (-1.1) 400.8 (117.5) 383.4 (112.4) 366.2 (107.3) 349.0 (102.3) 331.6 (97.2) 314.4 (92.1) 297.0 (87)
25 (-3.9) 364.4 (106.8) 348.6 (102.2) 332.6 (97.5) 316.8 (92.8) 300.8 (88.2) 284.8 (83.5) 268.8 (78.8)
20 (-6.7) 330.2 (96.8) 315.6 (92.5) 301.0 (88.2) 286.4 (83.9) 271.8 (79.7) 257.2 (75.4) 242.4 (71)
15 (-9.4) 298.0 (87.3) 284.6 (83.4) 271.2 (79.5) 257.8 (75.6) 244.4 (71.6) 231.0 (67.7) 217.6 (63.8)
10 (-12.2) 267.6 (78.4) 255.4 (74.9) 243.2 (71.3) 231.0 (67.7) 218.8 (64.1) 206.6 (60.5) 194.4 (57)

5 (-15) 239.2 (70.1) 228.2 (66.9) 217.2 (63.7) 206.0 (60.4) 195.0 (57.1) 183.8 (53.9) 172.8 (50.6)

0 (-17.8) 212.6 (62.3) 202.6 (59.4) 192.8 (56.5) 182.8 (53.6) 172.6 (50.6) 162.6 (47.7) 152.6 (44.7)
30 (-1.1) 513.0 (150.3) 492.0 (144.2) 471.0 (138) 450.4 (132) 429.8 (126) 409.4 (120) 389.2 (114.1)
25 (-3.9) 467.2 (136.9) 448.0 (131.3) 428.8 (125.7) 409.8 (120.1) 391.0 (114.6) 372.4 (109.1) 353.8 (103.7)
20 (-6.7) 424.0 (124.3) 406.4 (119.1) 389.0 (114) 371.6 (108.9) 354.4 (103.9) 337.4 (98.9) 320.6 (94)
15 (-9.4) 383.0 (112.2) 367.0 (107.6) 351.2 (102.9) 335.6 (98.4) 320.0 (93.8) 304.6 (89.3) 289.4 (84.8)
10 (-12.2) 344.6 (101) 330.2 (96.8) 316.0 (92.6) 301.8 (88.4) 287.8 (84.3) 273.8 (80.2) 260.0 (76.2)

5 (-15) 308.6 (90.4) 295.6 (86.6) 282.8 (82.9) 270.0 (79.1) 257.4 (75.4) 245.0 (71.8) 232.6 (68.2)

0 (-17.8) 275.0 (80.6) 263.4 (77.2) 252.0 (73.9) 240.6 (70.5) 229.2 (67.2) 218.0 (63.9) 206.8 (60.6)
30 (-1.1) 592.8 (173.7) 568.8 (166.7) 545.0 (159.7) 521.2 (152.7) 497.4 (145.8) 473.6 (138.8) 450.0 (131.9)
25 (-3.9) 540.0 (158.3) 518.2 (151.9) 496.4 (145.5) 474.6 (139.1) 452.8 (132.7) 431.0
20 (-6.7) 490.2 (143.7) 470.2 (137.8) 450.4 (132) 430.6 (126.2) 410.8 (120.4) 391.0 (114.6) 371.2 (108.8)
15 (-9.4) 443.2 (129.9) 425.0 (124.6) 407.0 (119.3) 389.0 (114) 371.0 (108.7) 353.2 (103.5) 335.2 (98.2)
10 (-12.2) 399.0 (1

5 (-15) 357.6 (104.8) 343.0 (100.5) 328.2 (96.2) 313.6 (91.9) 299.0 (87.6) 284.4 (83.3) 269.8 (79.1)

0 (-17.8) 319.0 (93.5) 305.8 (89.6) 292.6 (85.8) 279.6 (81.9) 266.4 (78.1) 253.4 (74.3) 240.2 (70.4)
30 (-1.1) 772.2 (226.3) 740.4 (217) 708.8 (207.7) 677.4 (198.5) 646.2 (189.4) 615.2 (180.3) 584.6 (171.3)
25 (-3.9) 703.2 (206.1) 674.0 (197.5) 645.0 (189) 616.2 (180.6) 587.8 (172.3) 559.4 (163.9) 531.4 (155.7)
20 (-6.7) 637.8 (186.9) 611.2 (179.1) 584.8 (171.4) 558.6 (163.7) 532.6 (156.1) 506.8 (148.5) 481.4 (141.1)
15 (-9.4) 576.2 (168.9) 552.0 (161.8) 528.0 (154.7) 504.2 (147.8) 480.8 (140.9) 457.4 (134.1) 434.2 (127.3)
10 (-12.2) 518.2 (151.9) 496.4 (145.5) 474.8 (139.1) 453.2 (132.8) 432.0 (126.6) 411.0 (120.5) 390.2 (114.4)

5 (-15) 464.0 (136) 444.4 (130.2) 425.0 (124.6) 405.6 (118.9) 386.4 (113.2) 367.6 (107.7) 348.8 (102.2)

0 (-17.8) 413.4 (121.2) 395.8 (116) 378.4 (110.9) 361.0 (105.8) 344.0 (100.8) 327.0 (95.8) 310.4 (91)
30 (-1.1) 887.4 (260.1) 851.2 (249.5) 815.2 (238.9) 779.2 (228.4) 743.4 (217.9) 707.8 (207.4) 672.2 (197)
25 (-3.9) 808.8 (237) 775.6 (227.3) 742.8 (217.7) 709.8 (208) 677.2 (198.5) 644.6 (188.9) 612.0 (179.4)
20 (-6.7) 734.2 (215.2) 704.2 (206.4) 674.2 (197.6) 644.4 (188.9) 614.6 (180.1) 584.8 (171.4) 555.2 (162.7)
15 (-9.4) 664.0 (194.6) 636.8 (186.6) 609.6 (178.7) 582.6 (170.7) 555.6 (162.8) 528.6 (154.9) 501.8 (147.1)
10 (-12.2) 597.8 (175.2) 573.4 (168) 548.8 (160.8) 524.4 (153.7) 500.2 (146.6) 475.8 (139.4) 451.6 (132.4)

5 (-15) 536.0 (157.1) 514.0 (150.6) 492.0 (144.2) 470.0 (137.7) 448.2 (131.4) 426.4 (125) 404.6 (118.6)

0 (-17.8) 478.2 (140.1) 458.4 (134.3) 438.8 (128.6) 419.2 (122.9) 399.6 (117.1) 380.0 (111.4) 360.6 (105.7)
30 (-1.1) 1025.4 (300.5) 982.6 (288) 939.8 (275.4) 897.2 (262.9) 854.6 (250.5) 812.0 (238) --- --­25 (-3.9) 937.0 (274.6) 897.8 (263.1) 858.6 (251.6) 819.4 (240.1) 780.4 (228.7) 741.4 (217.3) 702.4 (205.9)
20 (-6.7) 853.0 (250) 817.4 (239.6) 781.6 (229.1) 745.8 (218.6) 710.0 (208.1) 674.4 (197.6) 638.8 (187.2)

15 (-9.4) 773.8 (226.8) 741.2 (217.2) 708.6 (207.7) 676.2 (198.2) 643.6 (188.6) 611.2 (179.1) 578.8 (169.6)
10 (-12.2) 698.8 (204.8) 669.4 (196.2) 640.0 (187.6) 610.4 (178.9) 581.0 (170.3) 551.6 (161.7) 522.4 (153.1)

5 (-15) 628.6 (184.2) 602.0 (176.4) 575.4 (168.6) 548.8 (160.8) 522.2 (153) 495.8 (145.3) 469.4 (137.6)

0 (-17.8) 562.8 (164.9) 538.8 (157.9) 515.0 (150.9) 491.0 (143.9) 467.2 (136.9) 443.4 (129.9) 419.6 (123)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

16.9) 382.6 (112.1) 366.4 (107.4) 350.0 (102.6) 333.8 (97.8) 317.6 (93.1) 301.4 (88.3)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

(126.3) 409.4 (120)

HIGH EFFICIENCY MODELS

--- Outside Operating Range

BITZER

04/17/13

K40-KV-PDS-17

- 54 -

CAPACITY DATA -

R407C

MEDIUM TEMP. HIGH EFFICIENCY MODELS

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD031M8-B

Compressor

Model

4C2067SH

KVD041M8-B

Compressor

Model

HIGH EFFICIENCY MODELS

4C2397SH

KVD051M8-B

Compressor

Model

4B3139PH

KVD061M8-B

Compressor

Model

4B3604PH

KVD071M8-B

Compressor

Model

6B4709PH

KVD081M8-B

Compressor

Model

6B5406PH

KVD101M8-B

Compressor

Model

6B6462PH

SATURATED

SUCTION

TEMPERATURE

° F ° C

30 (-1.1) 289.6 (84.9) 278.2 (81.5) 267.0 (78.2) 255.8 (75) 244.8 (71.7) 234.0 (68.6) 223.6 (65.5)
25 (-3.9) 260.2 (76.3) 249.8 (73.2) 239.6 (70.2) 229.6 (67.3) 219.6 (64.4) 210.0 (61.5) 200.6 (58.8)
20 (-6.7) 232.8 (68.2) 223.4 (65.5) 214.2 (62.8) 205.0 (60.1) 196.2 (57.5) 187.4 (54.9) 179.0 (52.5)
15 (-9.4) 207.2 (60.7) 198.8 (58.3) 190.4 (55.8) 182.2 (53.4) 174.2 (51.1) 166.6 (48.8) 159.0 (46.6)
10 (-12.2) 183.6 (53.8) 176.0 (51.6) 168.4 (49.4) 161.2 (47.2) 154.0 (45.1) 147.0 (43.1) 140.4 (41.1)

30 (-1.1) 335.4 (98.3) 322.2 (94.4) 309.2 (90.6) 296.2 (86.8) 283.4 (83.1) 270.6 (79.3) 258.2 (75.7)
25 (-3.9) 301.4 (88.3) 289.4 (84.8) 277.4 (81.3) 265.8 (77.9) 254.0 (74.4) 242.6 (71.1) 231.4 (67.8)
20 (-6.7) 269.6 (79) 258.8 (75.8) 248.0 (72.7) 237.4 (69.6) 226.8 (66.5) 216.6 (63.5) 206.6 (60.5)
15 (-9.4) 240.0 (70.3) 230.2 (67.5) 220.4 (64.6) 210.8 (61.8) 201.4 (59) 192.2 (56.3) 183.2 (53.7)
10 (-12.2) 212.6 (62.3) 203.8 (59.7) 195.0 (57.1) 186.2 (54.6) 177.8 (52.1) 169.4 (49.6) 161.4 (47.3)
30 (-1.1) 432.6 (126.8) 416.6 (122.1) 400.6 (117.4) 384.8 (112.8) 369.0 (108.1) 353.2 (103.5) 337.4 (98.9)
25 (-3.9) 389.2 (114.1) 374.6 (109.8) 360.2 (105.6) 345.6 (101.3) 331.2 (97.1) 317.0 (92.9) 302.6 (88.7)
20 (-6.7) 348.8 (102.2) 335.6 (98.4) 322.4 (94.5) 309.2 (90.6) 296.2 (86.8) 283.2 (83) 270.4 (79.2)
15 (-9.4) 311.4 (91.3) 299.4 (87.7) 287.4 (84.2) 275.6 (80.8) 263.6 (77.3) 252.0 (73.9) 240.2 (70.4)
10 (-12.2) 276.8 (81.1) 265.8 (77.9) 255.0 (74.7) 244.2 (71.6) 233.4 (68.4) 222.8 (65.3) 212.2 (62.2)
30 (-1.1) 494.0 (144.8) 475.2 (139.3) 456.2 (133.7) 437.0 (128.1) 417.8 (122.4) 398.4 (116.8) 379.2 (111.1)

25 (-3.9) 444.0 (130.1) 426.8 (125.1) 409.4 (120) 392.0 (114.9) 374.6 (109.8) 357.0 (104.6) 339.4 (99.5)
20 (-6.7) 397.4 (116.5) 381.8 (111.9) 366.0 (107.3) 350.2 (102.6) 334.4 (98) 318.4 (93.3) 302.6 (88.7)
15 (-9.4) 354.2 (103.8) 340.0 (99.6) 325.8 (95.5) 311.4 (91.3) 297.2 (87.1) 282.8 (82.9) 268.4 (78.7)
10 (-12.2) 314.2 (92.1) 301.4 (88.3) 288.6 (84.6) 275.6 (80.8) 262.6 (77) 249.6 (73.2) 236.8 (69.4)
30 (-1.1) 650.8 (190.7) 626.6 (183.6) 602.6 (176.6) 578.6 (169.6) 554.8 (162.6) 531.2 (155.7) 507.4 (148.7)
25 (-3.9) 585.4 (171.6) 563.4 (165.1) 541.6 (158.7) 519.8 (152.3) 498.2 (146) 476.6 (139.7) 455.2 (133.4)

20 (-6.7) 524.6 (153.7) 504.6 (147.9) 484.8 (142.1) 465.0 (136.3) 445.4 (130.5) 425.8 (124.8) 406.4 (119.1)
15 (-9.4) 468.2 (137.2) 450.0 (131.9) 432.0 (126.6) 414.2 (121.4) 396.4 (116.2) 378.6 (111
10 (-12.2) 416.0 (121.9) 399.6 (117.1) 383.2 (112.3) 367.0 (107.6) 350.8 (102.8) 334.8 (98.1) 319.0 (93.5)
30 (-1.1) 741.2 (217.2) 712.8 (208.9) 684.2 (200.5) 655.6 (192.1) 626.8 (183.7) 597.8 (175.2) 568.8 (166.7)
25 (-3.9) 666.0 (195.2) 640.2 (187.6) 614.2 (180) 588.0 (172.3) 561.8 (164.6) 535.6 (157) 509.2 (149.2)
20 (-6.7) 596.0 (174.7) 572.6 (167.8) 549.0 (160.9) 525.4 (154) 501.6 (147) 477.8 (140) 454.0 (133.1)
15 (-9.4) 531.2 (155.7) 510.2 (149.5) 488.8 (143.3) 467.4 (137) 445.8 (130.7) 424.2 (124.3) 402.6 (118)
10 (-12.2) 471.4 (138.2) 452.2 (132.5) 433.0 (126.9) 413.6 (121.2) 394.0 (115.5) 374.6 (109.8) 355.2 (104.1)
30 (-1.1) 870.8 (255.2) 840.2 (246.2) 809.6 (237.3) 778.8 (228.2) 748.4 (219.3) 717.8 (210.4) 687.4 (201.5)
25 (-3.9) 784.8 (230) 756.8 (221.8) 729.0 (213.6) 701.2 (205.5) 673.4 (197.4) 645.8 (189.3) 618.2 (181.2)
20 (-6.7) 704.6 (206.5) 679.2 (199.1) 654.0 (191.7) 628.8 (184.3) 603.6 (176.9) 578.6 (169.6) 553.6 (162.2)
15 (-9.4) 630.0 (184.6) 607.0 (177.9) 584.2 (171.2) 561.4 (164.5) 538.6 (157.8) 516.0 (151.2) 493.4 (144.6)
10 (-12.2) 560.8 (164.4) 540.2 (158.3) 519.4 (152.2) 498.8 (146.2) 478.2 (140.1) 457.8 (134.2) 437.4 (128.2)

85 (29.4) 90 (32.2) 95 (35.0) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

CAPACITY MBH (KW)

R407C

AMBIENT TEMPERATURE °F (°C)

) 361.0 (105.8)

NOTE: The capacities shown above are rated at dew point. The dew point is a saturation point and is the condition (pressure and temperature) at

which a gas begins to condense. Since R407C has signicant glide, the saturated gas and saturated liquid temperatures are not the same.
It is important that all components of a system are selected correctly

BITZER

04/17/13

K40-KV-PDS-17

- 55 -

CAPACITY DATA -

R404A

R507

LOW TEMP. HIGH EFFICIENCY MODELS

60HzKVD-B

CONDENSING

UNIT

MODEL

KVD025L6-B

Compressor

Model

4C2397SL

KVD031L6-B

Compressor

Model

4B3139PL

KVD041L6-B

Compressor

Model

4B3604PL

KVD051L6-B

Compressor

Model

6B4709PL

KVD061L6-B

Compressor

Model

6B5406PL

KVD081L6-B

Compressor

Model

6B6462PL

--- Outside Operating Range

SATURATED

SUCTION

TEMPERATURE

° F ° C 85 (29.4) 90 (32.2) 95 (35) 100 (37.8) 105 (40.6) 110 (43.3) 115 (46.1)

0 (-17.8) 192.2 (56.3) 183.0 (53.6) 174.0 (51) 165.0 (48.4) 156.0 (45.7) 147.0 (43.1) 138.2 (40.5)

-5 (-20.6) 171.6 (50.3) 163.4 (47.9) 155.0 (45.4) 146.8 (43) 138.6 (40.6) 130.6 (38.3) 122.4 (35.9)

-10 (-23.3) 152.2 (44.6) 144.8 (42.4) 137.4 (40.3) 130.0 (38.1) 122.4 (35.9) 115.2 (33.8) 107.8 (31.6)

-15 (-26.1) 134.2 (39.3) 127.6 (37.4) 120.8 (35.4) 114.0 (33.4) 107.4 (31.5) 100.8 (29.5) 94.2 (27.6)

-20 (-28.9) 117.6 (34.5) 111.4 (32.6) 105.4 (30.9) 99.4 (29.1) 93.4 (27.4) 87.4 (25.6) 81.4 (23.9)

-25 (-31.7) 102.0 (29.9) 96.6 (28.3) 91.2 (26.7) 85.6 (25.1) 80.2 (23.5) 75.0 (22) 69.6 (20.4)

-30 (-34.4) 87.8 (25.7) 82.8 (24.3) 78.0 (22.9) 73.0 (21.4) 68.2 (20) 63.4 (18.6) 58.6 (17.2)

-35 (-37.2) 74.6 (21.9) 70.2 (20.6) 65.8 (19.3) 61.2 (17.9) 57.0 (16.7) 52.6 (15.4) 48.2 (14.1)

-40 (-40) 62.6 (18.3) 58.6 (17.2) 54.4 (15.9) 50.4 (14.8) 46.4 (13.6) 42.6 (12.5) 38.6 (11.3)
0 (-17.8) 269.2 (78.9) 257.2 (75.4) 245.6 (72) 233.8 (68.5) 222.2 (65.1) 210.8 (61.8) 199.4 (58.4)

-5 (-20.6) 240.6 (70.5) 230.0 (67.4) 219.4 (64.3) 208.8 (61.2) 198.2 (58.1) 187.8 (55) 177.4 (52)

-10 (-23.3) 214.2 (62.8) 204.6 (60) 195.0 (57.1) 185.4 (54.3) 175.8 (51.5) 166.4 (48.8) 157.0 (46)

-15 (-26.1) 189.6 (55.6) 181.0 (53) 172.2 (50.5) 163.6 (47.9) 155.0 (45.4) 146.6 (43) 138.0 (40.4)

-20 (-28.9) 167.0 (48.9) 159.2 (46.7) 151.2 (44.3) 143.6 (42.1) 135.8 (39.8) 128.0 (37.5) 120.4 (35.3)

-25 (-31.7) 146.0 (42.8) 139.0 (40.7) 132.0 (38.7) 125.0 (36.6) 118.0 (34.6) 111.0 (32.5) 104.2 (30.5)

-30 (-34.4) 126.8 (37.2) 120.4 (35.3) 114.2 (33.5) 107.8 (31.6) 101.6 (29.8) 95.2 (27.9) 89.0 (26.1)

-35 (-37.2) 109.2 (32) 103.4 (30.3) 97.8 (28.7) 92.0 (27) 86.4 (25.3) 80.6 (23.6) 75.0 (22)

-40 (-40) 93.0 (27.3) 87.8 (25.7) 82.6 (24.2) 77.4 (22.7) 72.2 (21.2) 67.0 (19.6) 61.8 (18.1)
0 (-17.8) 303.8 (89) 290.8 (85.2) 277.6 (81.4) 264.2 (77.4) 250.8 (73.5) 237.2 (69.5) 223.2 (65.4)

-5 (-20.6) 272.0 (79.7) 260.4 (76.3) 248.6 (72.9) 236.6 (69.3) 224.6 (65.8) 212.4 (62.2) 199.8 (58.6)

-10 (-23.3) 242.2 (71) 231.8 (67.9) 221.2 (64.8) 210.6 (61.7) 200.0 (58.6) 189.0 (55.4) 177.8 (52.1)

-15 (-26.1) 214.6 (62.9) 205.2 (60.1) 195.8 (57.4) 186.4 (54.6) 176.8 (51.8) 167.0 (48.9) 157.2 (46.1)

-20 (-28.9) 188.6 (55.3) 180.4 (52.9) 172.0 (50.4) 163.6 (47.9) 155.2 (45.5) 146.6 (43) 137.8 (40.4)

-25 (-31.7) 164.8 (48.3) 157.4 (46.1) 150.0 (44) 142.6 (41.8) 135.0 (39.6) 127.4 (37.3) 119.6 (35.1)

-30 (-34.4) 142.8 (41.9) 136.0 (39.9) 129.4 (37.9) 122.8 (36) 116.2 (34.1) 109.4 (32.1) 102.4 (30)

-35 (-37.2) 122.4 (35.9) 116.4 (34.1) 1

-40 (-40) 103.8 (30.4) 98.4 (28.8) 93.0 (27.3) 87.6 (25.7) 82.2 (24.1) 76.8 (22.5) 71.2 (20.9)
0 (-17.8) 387.0 (113.4) 370.0 (108.4) 352.8 (103.4) 335.8 (98.4) 319.0 (93.5) 301.8 (88.4) 284.8 (83.5)

-5 (-20.6) 346.6 (101.6) 331.2 (97.1) 316.0 (92.6) 300.8 (88.2) 285.4 (83.6) 270.2 (79.2) 254.8 (74.7)

-10 (-23.3) 308.8 (90.5) 295.0 (86.5) 281.4 (82.5) 267.8 (78.5) 254.0 (74.4) 240.4 (70.5) 226.8 (66.5)

-15 (-26.1) 273.4 (80.1) 261.0 (76.5) 249.0 (73) 236.8 (69.4) 224.6 (65.8) 212.4 (62.2) 200.2 (58.7)

-20 (-28.9) 240.4 (70.5) 229.4 (67.2) 218.6 (64.1) 207.8 (60.9) 197.0 (57.7) 186.2 (54.6) 175.4 (51.4)

-25 (-31.7) 209.8 (61.5) 200.2 (58.7) 190.4 (55.8) 181.0 (53) 171.4 (50.2) 161.8 (47.4) 152.2 (44.6)

-30 (-34.4) 181.6 (53.2) 173.0 (50.7) 164.4 (48.2) 155.8 (45.7) 147.4 (43.2) 138.8 (40.7) 130.2 (38.2)

-35 (-37.2) 155.8 (45.7) 148.0 (43.4) 140.2 (41.1) 132.6 (38.9) 125.0 (36.6) 117.4 (34.4) 109.8 (32.2)

-40 (-40) 132.0 (38.7) 125.0 (36.6) 118.0 (34.6) 111.0 (32.5) 104.2 (30.5) 97.4 (28.5) 90.4 (26.5)
0 (-17.8) 427.6 (125.3) 409.4 (120) 391.6 (114.8) 373.4 (109.4) 355.4 (104.2) 337.0 (98.8) --- ---

-5 (-20.6) 383.4 (112.4) 367.2 (107.6) 351.0 (102.9) 334.8 (98.1) 318.4 (93.3) 301.8 (88.4) 285.0 (83.5)

-10 (-23.3) 342.0 (100.2) 327.4 (96) 312.8 (91.7) 298.4 (87.5) 283.8 (83.2) 268.8 (78.8) 253.6 (74.3)

-15 (-26.1) 303.0 (88.8) 290.0 (85) 277.0 (81.2) 264.2 (77.4) 251.0 (73.6) 237.8 (69.7) 224.0 (65.6)

-20 (-28.9) 266.8 (78.2) 255.2 (74.8) 243.6 (71.4) 232.0 (68) 220.4 (64.6) 208.6 (61.1) 196.2 (57.5)

-25 (-31.7) 233.0 (68.3) 222.6 (65.2) 212.4 (62.2) 202.0 (59.2) 191.8 (56.2) 181.2 (53.1) 170.2 (49.9)

-30 (-34.4) 201.8 (59.1) 192.6 (56.4) 183.4 (53.7) 174.2 (51.1) 165.0 (48.4) 155.4 (45.5) 145.6 (42.7)

-35 (-37.2) 173.0 (50.7) 164.6 (48.2) 156.4 (45.8) 148.2 (43.4) 139.8 (41) 131.4 (38.5) 122.6 (35.9)

-40 (-40) 146.6 (43) 139.0 (40.7) 131.4 (38.5) 124.0 (36.3) 116.4 (34.1) 108.8 (31.9) 100.6 (29.5)
0 (-17.8) 517.8 (151.8) 494.4 (144.9) 471.4 (138.2) 448.4 (131.4) 425.8 (124.8) 403.4 (118.2) 381.0 (111.7)

-5 (-20.6) 463.6 (135.9) 442.4 (129.7) 421.4 (123.5) 400.6 (117.4) 380.0 (111.4) 359.6 (105.4) 339.4 (99.5)

-10 (-23.3) 412.8 (121) 393.6 (115.4) 374.6 (109.8) 355.8 (104.3) 337.2 (98.8) 318.8 (93.4) 300.4 (88)

-15 (-26.1) 365.4 (107.1) 348.0 (102) 330.8 (96.9) 314.0 (92) 297.2 (87.1) 280.4 (82.2) 264.0 (77.4)

-20 (-28.9) 321.2 (94.1) 305.6 (89.6) 290.2 (85) 274.8 (80.5) 259.8 (76.1) 244.8 (71.7) 229.8 (67.3)

-25 (-31.7) 280.0 (82.1) 266.0 (78) 252.2 (73.9) 238.6 (69.9) 225.0 (65.9) 211.4 (62) 198.0 (58)

-30 (-34.4) 242.2 (71) 229.6 (67.3) 217.2 (63.7) 204.8 (60) 192.6 (56.4) 180.4 (52.9) 168.2 (49.3)

-35 (-37.2) 207.2 (60.7) 195.8 (57.4) 184.6 (54.1) 173.4 (50.8) 162.4 (47.6) 151.4 (44.4) 140.4 (41.1)

-40 (-40) 175.0 (51.3) 164.8 (48.3) 154.6 (45.3) 144.4 (42.3) 134.4 (39.4) 124.4 (36.5) 114.4 (33.5)

CAPACITY MBH (KW)

10.6 (32.4) 104.6 (30.7) 98.6 (28.9) 92.6 (27.1) 86.4 (25.3)

R404A

R507

AMBIENT TEMPERATURE °F (°C)

HIGH EFFICIENCY MODELS

ELECTRICAL DAT A - SINGLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 56 -

COPELAND

CONDENSING UNIT

MODEL

KVS016H8-

KVS026H8-

KVS031H8-

KVS036H8-

HIGH EFFICIENCY MODELS

KVS041H8-

KVS016M8-

KVS026M8-

KVS031M8-

KVS036M8-

KVS041M8­KVS051M8- HT4B -A 6DUNR49ME-AWD 460/3/60 84.2 482 4 2 12.4 117.7 200

KVS011L6-

KVS016L6-

KVS023L6-

KVS028L6-

KVS031L6­KVS041L6- HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 3 2 9.3 89.2 150

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 2 13.2 87.7 125
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 2 6.2 42.5 70
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 2 2 5.0 34.5 50
HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 3 2 19.8 153.7 250
HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 3 2 9.3 76.3 125
HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 3 2 7.5 56.0 90
HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 3 2 19.8 162.7 275
HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 3 2 9.3 80.7 125
HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 3 2 7.5 69.1 110
HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 4 2 26.4 203.2 300
HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 4 2 12.4 100.8 150
HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 4 2 10.0 77.0 125
HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 4 2 26.4 224.7 350
HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 4 2 12.4 111.5 175
HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 4 2 10.0 91.3 150
HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 2 2 13.2 87.7 125
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 2 2 6.2 42.5 70
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 2 2 5.0 34.5 50
HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 3 2 19.8 122.4 200
HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 3 2 9.3 60.7 100
HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 3 2 7.5 50.5 80
HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 3 2 19.8 151.6 250
HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 3 2 9.3 75.2 125
HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 3 2 7.5 62.7 100
HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 4 2 26.4 182.8 300
HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 4 2 12.4 90.6 150
HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 4 2 10.0 63.9 100
HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 4 2 26.4 205.0 300
HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 4 2 12.4 101.7 150
HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 4 2 10.0 75.1 125

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 1 2 6.6 58.4 90
HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 1 2 3.1 26.4 40
HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 1 2
HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 2 2 13.2 79.0 125
HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 2 2 6.2 39.1 60
HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 113 2 2 5.0
HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 2 2 13.2 93.6 150
HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 2 2 6.2 46.3 70
HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 2 2 5.0 41.4 70
HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 2 2 13.2 114.1 175
HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 2 2 6.2 56.7 90
HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 2 2 5.0 45.6 70
HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 2 2 13.2 132.7 225
HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 2 2 6.2 66.0 110
HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 2 2 5.0 54.5 90

COMPRESSOR

MODEL NO.

HIGH EFFICIENCY MODELS

POWER

SUPPLY

COMPRESSOR

RLA LRA QTY HP FLA MCA MOP

CONDENSER

FAN MOTOR

2.5 22.8 35

60HzKVS-A

UNIT

31.1 50

* 6DJ only available in 230V

ELECTRICAL DAT A - DOUBLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 57 -

60HzKVD-A

COPELAND

CONDENSING UNIT

MODEL

KVD031H8-

KVD051H8-

KVD061H8-

KVD071H8-

KVD081H8-

KVD031M8-

KVD051M8-

KVD061M8-

KVD071M8-

KVD081M8­KVS101M8- HT4B -A 6DUNR49ME-AWD 460/3/60 84.2 482 8 2 24.8 214.3 250

KVD021L6-

KVD031L6-

KVD045L6-

KVD055L6-

KVD061L6­KVS081L6- HT4B -A 6DUNF13ME-AWD 460/3/60 63.9 367 6 2 18.6 162.4 225

HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 2 26.4 160.5 200
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 2 12.4 77.7 100
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 4 2 10.0 63.1 80
HT3B -A 4DHNR22ME-TSK 208-230/3/60 107.1 428 6 2 39.6 280.6 350
HT4B -A 4DHNR22ME-TSK 460/3/60 53.6 214 6 2 18.6 139.2 175
HT5B -A 4DHNR22ME-TSE 575/3//60 38.8 172 6 2 15.0 102.3 125
HT3B -A 4DJNR28ME-TSK 208-230/3/60 114.3 470 6 2 39.6 296.8 400
HT4B -A 4DJNR28ME-TSK 460/3/60 57.1 235 6 2 18.6 147.1 200
HT5B -A 4DJNR28ME-TSE 575/3//60 49.3 200 6 2 15.0 125.9 175
HT3B -A 6DHNR35ME-TSK 208-230/3/60 141.4 565 8 2 52.8 371.0 500
HT4B -A 6DHNR35ME-TSK 460/3/60 70.7 283 8 2 24.8 183.9 250
HT5B -A 6DHNR35ME-TSE 575/3//60 53.6 230 8 2 20.0 140.6 175
HT3B -A 6DJNR40ME-TSN* 230/3/60 158.6 594 8 2 52.8 409.7 500
HT4B -A 6DJNR40ME-TSN 460/3/60 79.3 297 8 2 24.8 203.2 250
HT5B -A 6DJNR40ME-TSE 575/3//60 65.0 245 8 2 20.0 166.3 225
HT3B -A 3DS3R17ME-TFC 208-230/3/60 59.6 275 4 2 26.4 160.5 200
HT4B -A 3DS3R17ME-TFD 460/3/60 29.0 138 4 2 12.4 77.7 100
HT5B -A 3DS3R17ME-TFE 575/3//60 23.6 110 4 2 10.0 63.1 80
HT3B -A 4DHNR22ME-TSK 208-230/3/60 82.1 428 6 2 39.6 224.3 300
HT4B -A 4DHNR22ME-TSK 460/3/60 41.1 214 6 2 18.6 111.1 150
HT5B -A 4DHNR22ME-TSE 575/3//60 34.4 172 6 2 15.0 92.4 125
HT3B -A 4DJNR28ME-TSK 208-230/3/60 105.4 470 6 2 39.6 276.8 350
HT4B -A 4DJNR28ME-TSK 460/3/60 52.7 235 6 2 18.6 137.2 175
HT5B -A 4DJNR28ME-TSE 575/3//60 44.1 200 6 2 15.0 114.3 150

HT3B -A 6DHNR35ME-TSK 208-230/3/60 125.1 565 8 2 52.8 334.4 400
HT4B -A 6DHNR35ME-TSK 460/3/60 62.6 283 8 2 24.8 165.6 225
HT5B -A 6DHNR35ME-TSE 575/3//60 43.1 230 8 2 20.0 117.0 150
HT3B -A 6DJNR40ME-TSN* 230/3/60 142.9 594 8 2 52.8 374.2 500
HT4B -A 6DJNR40ME-TSN 460/3/60 71.4 297 8 2 24.8 185.5 250
HT5B -A 6DJNR40ME-TSE 575/3//60 52.1 245 8 2 20.0 137.2 175

HT3B -A 3DS3F46KE-TFC 208-230/3/60 41.4 215 2 2 13.2 106.4 125
HT4B -A 3DS3F46KE-TFD 460/3/60 18.6 106 2 2 6.2 48.1 60

HT5B -A 3DS3F46KE-TFE 575/3//60 16.2 84 2 2
HT3B -A 4DHNF63KE-TSK 208-230/3/60 52.6 278 4 2 26.4 144.8 175
HT4B -A 4DHNF63KE-TSK 460/3/60 26.3 139 4 2 12.4 71.6 90
HT5B -A 4DHNF63KE-TSE 575/3//60 20.9 113 4 2 10.0
HT3B -A 4DJNF76KE-TSK 208-230/3/60 64.3 374 4 2 26.4 171.1 225
HT4B -A 4DJNF76KE-TSK 460/3/60 32.1 187 4 2 12.4 84.6 110
HT5B -A 4DJNF76KE-TSE 575/3//60 29.1 135 4 2 10.0 75.5 100
HT3B -A 6DHNF93KE-TSK 208-230/3/60 80.7 450 4 2 26.4 208.0 250
HT4B -A 6DHNF93KE-TSK 460/3/60 40.4 225 4 2 12.4 103.3 125
HT5B -A 6DHNF93KE-TSE 575/3//60 32.5 172 4 2 10.0 83.1 110
HT3B -A 6DJNF11ME-TSK 208-230/3/60 95.6 470 4 2 26.4 241.5 300
HT4B -A 6DJNF11ME-TSK 460/3/60 47.8 235 4 2 12.4 120.0 150
HT5B -A 6DJNF11ME-TSE 575/3//60 39.6 200 4 2 10.0 99.1 125

COMPRESSOR

HIGH EFFICIENCY MODELS

COMPRESSOR
RLA LRA QTY HP FLA MCA MOP

MODEL NO.

POWER

SUPPLY

CONDENSER

FAN MOTOR

5.0 41.5 55

57.0 70

UNIT

HIGH EFFICIENCY MODELS

* 6DJ only available in 230V

ELECTRICAL DAT A - SINGLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 58 -

BITZER

CONDENSING UNIT

MODEL

KVS016H8-

KVS021H8-

KVS026H8-

KVS031H8-

KVS036H8-

HIGH EFFICIENCY MODELS

KVS041H8-

KVS051H8-

KVS016M8-

KVS021M8-

KVS026M8-

KVS031M8-

KVS036M8-

KVS041M8-

KVS051M8-

KVS013L6-

KVS016L6-

KVS021L6-

KVS026L6-

KVS031L6-

KVS041L6-

HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 2 2 13.2 81.1 125
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 2 2 6.2 40.1 60
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 2 2 5.0 32.3 50
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 2 2 5.0 37.9 60
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 3 2 19.8 125.2 200
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 3 2 9.3 61.9 100
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 3 2 7.5 49.5 80
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 3 2 19.8 144.8 225
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 3 2 9.3 71.8 120
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 3 2 7.5 57.5 90
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 4 2 26.4 172.8 275
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 4 2 12.4 85.7 125
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 4 2 10.0 68.0 110
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 4 2 26.4 222.8 350
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 4 2 12.4 110.7 175
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 4 2 10.0 88.6 150
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 4 2 26.4 226.4 350
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 4 2 12.4 112.4 175
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 4 2 10.0 89.5 150
HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 2 2 13.2 81.1 125
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 2 2 6.2 40.1 60
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 2 2 5.0 32.3 50
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 2 2 5.0 37.9 60
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 3 2 19.8 125.2 200
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 3 2 9.3 61.9 100
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 3 2 7.5 49.5 80
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 3 2 19.8 144.8 225
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 3 2 9.3 71.8 120
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 3 2 7.5 57.5 90
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 4 2 26.4 172.8 275
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 4 2 12.4 85.7 125
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 4 2 10.0 68.0 110
HT3B -B 6B5406PH-2NU-Y 208-230/3/60
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 4 2 12.4 110.7 175
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 4 2 10.0 88.6 150
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 4 2 26.4 226.4 350
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 4 2 12.4 112.4 175
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 4 2 10.0 89.5 150
HT3B -B 4C2397SL-2NU-Y 208-230/3/60 44.3 252 1 2 6.6 62.0 100
HT4B -B 4C2397SL-2NU-Y 460/3/60 22.1 126 1 2 3.1 30.7 50
HT5B -B 4C2397SL-5PU-Y 575/3//60 17.7 101 1 2 2.5 24.6 40
HT3B -B 4B3139PL-2NU-Y 208-230/3/60 51.4 294 2 2 13.2 77.5 125
HT4B -B 4B3139PL-2NU-Y 460/3/60 25.7 147 2 2 6.2 38.3 60
HT5B -B 4B3139PL-5PU-Y 575/3//60 31.1 117 2 2 5.0 43.9 70
HT3B -B 4B3604PL-2NU-Y 208-230/3/60 64.3 352 2 2 13.2 93.6 150
HT4B -B 4B3604PL-2NU-Y 460/3/60 32.1 176 2 2 6.2 46.3 70
HT5B -B 4B3604PL-5PU-Y 575/3//60 25.7 140 2 2 5.0 37.1 60
HT3B -B 6B4709PL-2NU-Y 208-230/3/60 77.1 436 2 2 13.2 109.6 175
HT4B -B 6B4709PL-2NU-Y 460/3/60 38.6 218 2 2 6.2 54.5 90
HT5B -B 6B4709PL-5PU-Y 575/3//60 30.7 174 2 2 5.0 43.4 70
HT3B -B 6B5406PL-2NU-Y 208-230/3/60 94.3 490 2 2 13.2 131.1 225
HT4B -B 6B5406PL-2NU-Y 460/3/60 47.1 245 2 2 6.2 65.1 110
HT5B -B 6B5406PL-5PU-Y 575/3//60 37.1 196 2 2 5.0 51.4 80
HT3B -B 6B6462PL-2NU-Y 208-230/3/60 108.6 700 3 2 19.8 155.6 250
HT4B -B 6B6462PL-2NU-Y 460/3/60 54.3 350 3 2 9.3 77.2 125
HT5B -B 6B6462PL-5PU-Y 575/3//60 43.6 280 3 2 7.5 62.0 100

COMPRESSOR

HIGH EFFICIENCY MODELS

MODEL NO.

POWER
SUPPLY

60HzKVS-B

COMPRESSOR CONDENSER FAN MTR. UNIT
RLA LRA QTY HP FLA MCA MOP

157.1 700 4 2 26.4 222.8 350

BITZER

04/17/13

K40-KV-PDS-17

- 59 -

CONDENSING UNIT

MODEL

KVD031H8-

KVD041H8-

KVD051H8-

KVD061H8-

KVD071H8-

KVD081H8-

KVD101H8-

KVD031M8-

KVD041M8-

KVD051M8-

KVD061M8-

KVD071M8-

KVD081M8-

KVD101M8-

KVD025L6-

KVD031L6-

KVD041L6-

KVD051L6-

KVD061L6-

KVD081L6-

ELECTRICAL DAT A - DOUBLE COMPRESSOR

60HzKVD-B

HIGH EFFICIENCY MODELS

COMPRESSOR

HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 4 2 26.4 148.6 200
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 4 2 12.4 73.4 100
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 4 2 10.0 59.1 80
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 4 2 10.0 69.2 90
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 6 2 39.6 229.3 300
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 6 2 18.6 113.3 150
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 6 2 15.0 90.6 120
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 6 2 39.6 264.6 350
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 6 2 18.6 131.1 175
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 6 2 15.0 105.0 125
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 8 2 52.8 316.3 400
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 8 2 24.8 156.7 200
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 8 2 20.0 124.4 150
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 8 2 52.8 406.3 500
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 8 2 24.8 201.7 250
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 8 2 20.0 161.5 200
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 8 2 52.8 412.8 500
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 8 2 24.8 204.8 250
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 8 2 20.0 163.1 225
HT3B -B 4C2067SH-2NU-Y 208-230/3/60 54.3 294 4 2 26.4 148.6 200
HT4B -B 4C2067SH-2NU-Y 460/3/60 27.1 147 4 2 12.4 73.4 100
HT5B -B 4C2067SH-5PU-Y 575/3//60 21.8 117 4 2 10.0 59.1 80
HT3B -B 4C2397SH-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4C2397SH-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4C2397SH-5PU-Y 575/3//60 26.3 140 4 2 10.0 69.2 90
HT3B -B 4B3139PH-2NU-Y 208-230/3/60 84.3 436 6 2 39.6 229.3 300
HT4B -B 4B3139PH-2NU-Y 460/3/60 42.1 218 6 2 18.6 113.3 150
HT5B -B 4B3139PH-5PU-Y 575/3//60 33.6 174 6 2 15.0 90.6 120
HT3B -B 4B3604PH-2NU-Y 208-230/3/60 100.0 490 6 2 39.6 264.6 350
HT4B -B 4B3604PH-2NU-Y 460/3/60 50.0 245 6 2 18.6 131.1 175
HT5B -B 4B3604PH-5PU-Y 575/3//60 40.0 196 6 2 15.0 105.0 125
HT3B -B 6B4709PH-2NU-Y 208-230/3/60 117.1 550 8 2 52.8 316.3 400
HT4B -B 6B4709PH-2NU-Y 460/3/60 58.6 275 8 2 24.8 156.7 200
HT5B -B 6B4709PH-5PU-Y 575/3//60 46.4 220 8 2 20.0 124.4 150
HT3B -B 6B5406PH-2NU-Y 208-230/3/60 157.1 700 8 2 52.8 406.3 500
HT4B -B 6B5406PH-2NU-Y 460/3/60 78.6 350 8 2 24.8 201.7 250
HT5B -B 6B5406PH-5PU-Y 575/3//60 62.9 280 8 2 20.0 161.5 200
HT3B -B 6B6462PH-2NU-Y 208-230/3/60 160.0 950 8 2 52.8 412.8 500
HT4B -B 6B6462PH-2NU-Y 460/3/60 80.0 425 8 2 24.8 204.8 250
HT5B -B 6B6462PH-5PU-Y 575/3//60 63.6 340 8 2 20.0 163.1 225
HT3B -B 4C2397SL-2NU-Y 208-230/3/60 44.3 252 2 2 13.2 112.9 150
HT4B -B 4C2397SL-2NU-Y
HT5B -B 4C2397SL-5PU-Y 575/3//60 17.7 101 2 2 5.0 44.8 60
HT3B -B 4B3139PL-2NU-Y 208-230/3/60 51.4 294 4 2 26.4 142.1 175
HT4B -B 4B3139PL-2NU-Y 460/3/60 25.7 147 4 2 12.4 70.2 90
HT5B -B 4B3139PL-5PU-Y 575/3//60 31.1 117 4 2 10.0 80.0 110

HT3B -B 4B3604PL-2NU-Y 208-230/3/60 64.3 352 4 2 26.4 171.1 225
HT4B -B 4B3604PL-2NU-Y 460/3/60 32.1 176 4 2 12.4 84.6 110
HT5B -B 4B3604PL-5PU-Y 575/3//60 25.7 140 4 2 10.0 67.8 90
HT3B -B 6B4709PL-2NU-Y 208-230/3/60 77.1 436 4 2 26.4 199.9 250
HT4B -B 6B4709PL-2NU-Y 460/3/60 38.6 218 4 2 12.4 99.3 125
HT5B -B 6B4709PL-5PU-Y 575/3//60 30.7 174 4 2 10.0 79.1 100
HT3B -B 6B5406PL-2NU-Y 208-230/3/60 94.3 490 4 2 26.4 238.6 300
HT4B -B 6B5406PL-2NU-Y 460/3/60 47.1 245 4 2 12.4 118.4 150
HT5B -B 6B5406PL-5PU-Y 575/3//60 37.1 196 4 2 10.0 93.5 125
HT3B -B 6B6462PL-2NU-Y 208-230/3/60 108.6 700 6 2 39.6 284.0 350
HT4B -B 6B6462PL-2NU-Y 460/3/60 54.3 350 6 2 18.6 140.8 175
HT5B -B 6B6462PL-5PU-Y 575/3//60 43.6 280 6 2 15.0 113.1 150

MODEL NO.

POWER
SUPPLY

460/3/60 22.1 126 2 2 6.2 55.9 70

COMPRESSOR CONDENSER FAN MTR. UNIT
RLA LRA QTY HP FLA MCA MOP

HIGH EFFICIENCY MODELS

KVS

04/17/13

K40-KV-PDS-17

- 60 -

DIMENSIONAL DAT A - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

HIGH EFFICIENCY MODELS

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

REMOVEABLE
ROOF SECTION

56 1/4
1429

CONDENSER FAN #1

TOP VIEW

LIQUID FILTER DRIER ( STANDARD )
( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2

LIQUID LINE SIGHT GLASS ( STANDARD )

CONDENSER FAN #3

53 5/8

1361

HINGED SERVICE DOOR HINGED SERVICE DOOR

69 1/8
1757

23 3/8
593

BASE FRAME LENGTH

222 3/8

(SEE OPPOSITE PAGE)

28 1/2

724

55

1397

20

508

5

127

REMOVEABLE
ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #2

CONDENSER FAN #3

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD )
( REPLACEABLE CORE )

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

69 1/8
1757

23 3/8
593

53 5/8

1361

56 1/4
1429

222 3/8

KVS

04/17/13

K40-KV-PDS-17

- 61 -

DIMENSIONAL DAT A - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

COMPRESSOR-END VIEW

KVS-A

COPELAND

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

KVS011L6-H**B-A 112 3/8 2854
KVS016L6-H**B-A 167 3/8 4251
KVS023L6-H**B-A 167 3/8 4251
KVS028L6-H**B-A 167 3/8 4251
KVS031L6-H**B-A 167 3/8 4251
KVS041L6-H**B-A 222 3/8 5648
KVS016M8-H**B-A 167 3/8 4251
KVS026M8-H**B-A 222 3/8 5648
KVS031M8-H**B-A 222 3/8 5648
KVS036M8-H**B-A 277 3/8 7045
KVS041M8-H**B-A 277 3/8 7045
KVS051M8-H**B-A 277 3/8 7045
KVS016H8-H**B-A 167 3/8 4251
KVS026H8-H**B-A 222 3/8 5648
KVS031H8-H**B-A 222 3/8 5648
KVS036H8-H**B-A 277 3/8 7045
KVS041H8-H**B-A 277 3/8 7045

BASE FRAME

LENGTH

inches mm

HINGED SERVICE DOOR

ELECTRICAL
K'OUTS

44 3/4
1137

KVS-B

BITZER

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

KVS013L6-H**B-B 112 3/8 2854
KVS016L6-H**B-B 167 3/8 4251
KVS021L6-H**B-B 167 3/8 4251
KVS026L6-H**B-B 167 3/8 4251
KVS031L6-H**B-B 167 3/8 4251

KVS041L6-H**B-B 222 3/8 5648
KVS016M8-H**B-B 167 3/8 4251
KVS021M8-H**B-B 167 3/8 4251
KVS026M8-H**B-B 222 3/8 5648
KVS031M8-H**B-B 222 3/8 5648
KVS036M8-H**B-B 277 3/8 7045
KVS041M8-H**B-B 277 3/8 7045
KVS051M8-H**B-B 277 3/8 7045
KVS016H8-H**B-B 167 3/8 4251
KVS021H8-H**B-B 167 3/8 4251
KVS026H8-H**B-B 222 3/8 5648
KVS031H8-H**B-B 222 3/8 5648
KVS036H8-H**B-B 277 3/8 7045
KVS041H8-H**B-B 277 3/8 7045
KVS051H8-H**B-B 277 3/8 7045

BASE FRAME

inches mm

LENGTH

HIGH EFFICIENCY MODELS

DIMENSIONAL DAT A - SINGLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 62 -

KVD

HIGH EFFICIENCY MODELS

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HIGH EFFICIENCY MODELS

COMPRESSOR #1
REMOVEABLE
ROOF SECTION

CONDENSER FAN #1

TOP VIEW

CONDENSER FAN #2

CONDENSER FAN #3

COMPRESSOR #2
REMOVEABLE
ROOF SECTION

HINGED SERVICE DOOR HINGED SERVICE DOOR

CONDENSER FAN #1R

LIQUID LINE SIGHT GLASS ( STANDARD )

LIQUID FILTER DRIER ( STANDARD )
REPLACEABLE CORE

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

SIDE VIEW

CONDENSER FAN #2R

CONDENSER FAN #3R

28 1/2

724

55

1397

20

508

69 1/8
1757

23 3/8
593

222 3/8

BASE FRAME LENGTH

(SEE OPPOSITE PAGE)

5

127

69 1/8
1757

23 3/8
593

222 3/8

LIQUID FILTER DRIER ( STANDARD )
REPLACEABLE CORE

END CAPPED PIPE ( STANDARD )
SUCTION FILTER ( OPTIONAL )
( REPLACEABLE CORE )

COMPRESSOR #1
REMOVEABLE
ROOF SECTION

COMPRESSOR #2
REMOVEABLE
ROOF SECTION

CONDENSER FAN #1

CONDENSER FAN #1R

ELECTRICAL COMPARTMENTS ( WITH HINGED DOOR )

HINGED SERVICE DOOR HINGED SERVICE DOOR

SIDE VIEW

TOP VIEW

KVD

04/17/13

K40-KV-PDS-17

- 63 -

DIMENSIONAL DAT A - SINGLE COMPRESSOR

HIGH EFFICIENCY MODELS

COMPRESSOR-END VIEW

HIGH EFFICIENCY MODELS

ELECTRICAL
K'OUTS

HINGED SERVICE DOOR
COMPRESSOR #1

KVD-A

COPELAND

HIGH EFFICIENCY MODELS

CONDENSING

UNIT

MODEL

KVD021L6-H**B-A 112 3/8 2854
KVD031L6-H**B-A 167 3/8 4251
KVD045L6-H**B-A 167 3/8 4251
KVD055L6-H**B-A 167 3/8 4251
KVD061L6-H**B-A 167 3/8 4251

KVD081L6-H**B-A 222 3/8 5648
KVD031M8-H**B-A 167 3/8 4251
KVD051M8-H**B-A 222 3/8 5648
KVD061M8-H**B-A 222 3/8 5648
KVD071M8-H**B-A 277 3/8 7045
KVD081M8-H**B-A 277 3/8 7045
KVD101M8-H**B-A 277 3/8 7045

KVD031H8-H**B-A 167 3/8 4251
KVD051H8-H**B-A 222 3/8 5648
KVD061H8-H**B-A 222 3/8 5648
KVD071H8-H**B-A 277 3/8 7045
KVD081H8-H**B-A 277 3/8 7045

BASE FRAME

LENGTH

inches mm

86 3/4
2203

HINGED SERVICE DOOR
COMPRESSOR #2

KVD-B

BITZER

HIGH EFFICIENCY MODELS

CONDENSING

MODEL

KVD025L6-H**B-B 112 3/8 2854
KVD031L6-H**B-B 167 3/8 4251
KVD041L6-H**B-B 167 3/8 4251
KVD051L6-H**B-B 167 3/8 4251
KVD061L6-H**B-B 167 3/8 4251
KVD081L6-H**B-B 222 3/8 5648
KVD031M8-H**B-B 167 3/8 4251
KVD041M8-H**B-B 167 3/8 4251
KVD051M8-H**B-B 222 3/8 5648
KVD061M8-H**B-B 222 3/8 5648
KVD071M8-H**B-B 277 3/8 7045
KVD081M8-H**B-B 277 3/8 7045
KVD101M8-H**B-B 277 3/8 7045
KVD031H8-H**B-B 167 3/8 4251
KVD041H8-H**B-B 167 3/8 4251
KVD051H8-H**B-B 222 3/8 5648
KVD061H8-H**B-B 222 3/8 5648
KVD071H8-H**B-B 277 3/8 7045
KVD081H8-H**B-B 277 3/8 7045
KVD101H8-H**B-B 277 3/8 7045

UNIT

BASE FRAME

LENGTH

inches mm

SPECIFICATIONS - SINGLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 64 -

COPELAND

CONDENSING

UNIT

MODEL

KVS016H8-H**B-A 2 1 5/8 41 0.88 22 124 56.3 2260 1027
KVS026H8-H**B-A 3 2 1/8 54 1.13 29 157 71.2 2870 1304
KVS031H8-H**B-A 3 2 1/8 54 1.13 29 189 85.8 3020 1373
KVS036H8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 3660 1663
KVS041H8-H**B-A 4 2 1/8 54 1.38 35 254 115.3 3820 1736
KVS016M8-H**B-A 2 1 5/8 41 0.88 22 124 56.3 2265 1029
KVS026M8-H**B-A 3 2 1/8 54 1.13 29 157 71.2 2875 1307

HIGH EFFICIENCY MODELS

KVS031M8-H**B-A 3 2 1/8 54 1.13 29 189 85.8 3030 1377
KVS036M8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 3660 1663
KVS041M8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 3815 1734
KVS051M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 3835 1743

KVS011L6-H**B-A 1 1 3/8 35 0.63 16 124 56.3 1785 811
KVS016L6-H**B-A 2 1 5/8 41 0.88 22 124 56.3 2335 1061
KVS023L6-H**B-A 2 2 1/8 54 0.88 22 124 56.3 2385 1084
KVS028L6-H**B-A 2 2 1/8 54 1.13 29 157 71.2 2610 1186
KVS031L6-H**B-A 2 2 1/8 54 1.13 29 157 71.2 2625 1193
KVS041L6-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 3045 1384

CONDENSER

FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

SHIPPING WEIGHT

60HzKVS-A

APPROX.

SPECIFICATIONS - DOUBLE COMPRESSOR

KVD-A

COPELAND

CONDENSING

UNIT

MODEL

KVD031H8-H**B-A 2 1 5/8 41 0.88 22 124 56.3 4065 1847
KVD051H8-H**B-A 3 2 1/8 54 1.13 29 157 71.2 5185 2357
KVD061H8-H**B-A 3 2 1/8 54 1.13 29 189 85.8 5475 2488
KVD071H8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 6615 3006
KVD081H8-H**B-A 4 2 1/8 54 1.38 35 254 115.3 6920 3145
KVD031M8-H**B-A 2 1 5/8 41 0.88 22 124 56.3 4075 1852
KVD051M8-H**B-A 3 2 1/8 54 1.13 29 157 71.2 5195 2361
KVD061M8-H**B-A 3 2 1/8 54 1.13 29 189 85.8 5490 2495
KVD071M8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 6620 3009
KVD081M8-H**B-A 4 2 1/8 54 1.13 29 254 115.3 6915 3143
KVD101M8-H**B-A 4 2 1/8 54 1 1/8 29 254 115.3 6960 3163

KVD021L6-H**B-A 1 1 3/8 35 0.63 16 124 56.3 3195 1452
KVD031L6-H**B-A 2 1 5/8 41 0.88 22 124 56.3 4220 1918
KVD045L6-H**B-A 2 2 1/8 54 0.88 22 124 56.3 4315 1961
KVD055L6-H**B-A 2 2 1/8 54 1.13 29 157 71.2 4760 2163
KVD061L6-H**B-A 2 2 1/8 54 1.13 29 157 71.2 4795 2179
KVD081L6-H**B-A 3 2 1/8 54 1 1/8 29 189 85.8 5535 2516

CONDENSER

FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

60Hz

APPROX.

SHIPPING WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407C

1.10 1.15 1.00

R404A

R404A

R22

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

SPECIFICATIONS - SINGLE COMPRESSOR

04/17/13

K40-KV-PDS-17

- 65 -

BITZER

CONDENSING

UNIT

MODEL

KVS016H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2190 995
KVS021H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2275 1034
KVS026H8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 2870 1304
KVS031H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3025 1375
KVS036H8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3615 1643
KVS041H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 3810 1732
KVS051H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 3815 1734
KVS016M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2195 998
KVS021M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2270 1032
KVS026M8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 2875 1307
KVS031M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3035 1379
KVS036M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3615 1643
KVS041M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3770 1713
KVS051M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 3780 1718

KVS013L6-H**B-B 1 1 3/8 35 5/8 16 124 56.3 1695 770
KVS016L6-H**B-B 2 1 5/8 41 7/8 22 124 56.3 2285 1039
KVS021L6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 2355 1070
KVS026L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2545 1157
KVS031L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 2565 1166
KVS041L6-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 3000 1363

CONDENSER

FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER

CAPACITY

90% FULL *

60HzKVS-B

APPROX.

SHIPPING WEIGHT

HIGH EFFICIENCY MODELS

SPECIFICATIONS - DOUBLE COMPRESSOR

60HzKVD-B

BITZER

CONDENSING

UNIT

MODEL

KVD031H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 3925 1784
KVD041H8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 4095 1861
KVD051H8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 5185 2357
KVD061H8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5485 2493
KVD071H8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6530 2968
KVD081H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 6900 3136
KVD101H8-H**B-B 4 2 1/8 54 1 3/8 35 254 115.3 6920 3145
KVD031M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 3935 1788
KVD041M8-H**B-B 2 1 5/8 41 7/8 22 124 56.3 4080 1854
KVD051M8-H**B-B 3 2 1/8 54 1 1/8 29 157 71.2 5190 2359
KVD061M8-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5500 2500
KVD071M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6535 2970
KVD081M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6825 3102
KVD101M8-H**B-B 4 2 1/8 54 1 1/8 29 254 115.3 6845 3111

KVD025L6-H**B-B 1 1 3/8 35 5/8 16 124 56.3 3010 1368
KVD031L6-H**B-B 2 1 5/8 41 7/8 22 124 56.3 4115 1870
KVD041L6-H**B-B 2 2 1/8 54 7/8 22 124 56.3 4255 1934
KVD051L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4635 2107
KVD061L6-H**B-B 2 2 1/8 54 1 1/8 29 157 71.2 4675 2125
KVD081L6-H**B-B 3 2 1/8 54 1 1/8 29 189 85.8 5445 2475

CONDENS-

ER FANS

HIGH EFFICIENCY MODELS

UNIT CONNECTIONS

SUCTION (OD) LIQUID (OD)

Inches mm Inches mm Lbs. Kgs Lbs. Kgs

RECEIVER
CAPACITY

90% FULL *

APPROX. SHIPPING

WEIGHT

* NOTE ON ALTERNATE REFRIGERANTS:

* PUBLISHED RECEIVER CAPACITY IS BASED ON

FOR ALERNATE REFRIGERANTS, MULTIPLY

R407C

1.10 1.15 1.00

R404A

R404A

R22

ON MODELS USING “8” AS REFRIGERANT CODE.

VALUE BY THE APPROPRIATE VALUE BELOW:

R507

KVS/D

04/17/13

K40-KV-PDS-17

- 66 -

FOR HIGH EFFICIENCY MODELS,

HIGH EFFICIENCY MODELS

VISIT www.k-rp.com/serv_parts.htm

WIRING DIAGRAMS

FOR WIRING DIAGRAMS

REFER TO PAGES 34-39

FOR SERVICE PARTS,

Finished Goods Warranty

04/17/13

K40-KV-PDS-17

- 67 -

The terms and conditions as described below in the General Warranty Policy cover all products

manufactured by National Refrigeration.

GeneraL Warranty PoLiCy

Subject to the terms and conditions hereof, the Company warrants all Products, including Service

Parts, manufactured by the Company to be free of defects in material or workmanship, under nor-

mal use and application for a period of one (1) year from the original date of installation, or eighteen
(18) months from the date of shipment from the Company, whichever occurs rst. Any replacement
part(s) so supplied will be warranted for the balance of the product’s original warranty. The part(s) to

be replaced must be made available in exchange for the replacement part(s) and reasonable proof
of the original installation date of the product must be presented in order to establish the effective

date of the warranty, failing which, the effective date will be based upon the date of manufacture plus
thirty (30) days. Any labour, material, refrigerant, transportation, freight or other charges incurred in

connection with the performance of this warranty will be the responsibility of the owner at the cur-

rent rates and prices then in effect. This warranty may be transferred to a subsequent owner of the

product.

this Warranty does not CoVer

(a) Damages caused by accident, abuse, negligence, misuse, riot, re, ood, or Acts of God (b) damages
caused by operating the product in a corrosive atmosphere (c) damages caused by any unauthorized
alteration or repair of the system affecting the product’s reliability or performance (d) damages caused
by improper matching or application of the product or the product’s components (e) damages caused by

failing to provide routine and proper maintenance or service to the product (f) expenses incurred for the
erecting, disconnecting, or dismantling the product (g) parts used in connection with normal maintenance,

such as lters or belts (h) products no longer at the site of the original installation (i) products installed

or operated other than in accordance with the printed instructions, with the local installation or building
codes and with good trade practices (j) products lost or stolen.

No one is authorized to change this WARRANTY or to create for or on behalf of the Company any

other obligation or liability in connection with the Product(s). There is no other representation, warranty
or condition in any respect, expressed or implied, made by or binding upon the Company other than
the above or as provided by provincial or state law and which cannot be limited or excluded by such
law, nor will we be liable in any way for incidental, consequential, or special damages however caused.

The provisions of this additional written warranty are in addition to and not a modication of or subtraction
from the statutory warranties and other rights and remedies provided by Federal, Provincial or State laws.

PROJECT INFORMATION

System

Model Number Date of Start-Up
Serial Number Service Contractor
Refrigerant Phone
Electrical Supply Fax

NATIONAL REFRIGERATION &

04/17/13

AIR CONDITIONING CANADA CORP.

CANADA

159 ROY BLVD., BRANTFORD, ONTARIO, CANADA N3R 7K1

PHONE: [phone] [phone] FAX [phone]

Due to National Refrigeration’s policy of continuous product improvement, we reserve the right to make changes without notice.

USA

985 WHEELER WAY, LANGHORNE, PA. 19047 USA

PHONE: 1-888-KEEPUS1 OR 1-888-533-7871
