Page 1
Dust Sentry
Accurate and affordable real-time
outdoor particulate monitoring
The Dust Sentry provides real time, continuous particle
measurement of TSP, PM10, PM2.5 or PM1 with
datalogging and alarm relay outputs. Numerous
integrated options including SMS and/or email
notifications, weather sensors, noise and mounting
equipment make the Dust Sentry a flexible base system
suitable for a wide range of applications.
Roadside PM surveys
Nuisance dust detection
Industrial site compliance monitoring
Construction / mining sites
Community exposure studies
Workplace monitoring
Smoke / biomass burn-off
Real time particle monitoring, Measures and
reports data in 1 minute intervals
Accurately measures TSP, PM10, PM2.5 or PM1
On board data storage for up to 15 years of data
Web-based and GSM data retrieval and alerts
Gravimetric filter
Option to integrate weather, wind, temp/RH
sensors, and sirens
Tough weatherproof enclosure with solar
shielding for hot climates
Quick installation and relocatable
Compared to reference-equivalent monitors like TEOMs and
BAMs which lack sensitivity at short sampling periods, the Dust
Sentry reports accurately at 1 minute intervals and has a much
lower total cost of ownership (up to 5x less). In addition, the
Dust Sentry is compact, re-locatable and can integrate wind and
weather sensors for maximum utility.
Page 2
Dust Sentry Specifications
Models DS 10 DS 25 DS 1
Measurement Technology
Range
Accuracy
Cut Points Available
Sample Flowrate
Inlet
Alarm
Datalogging
Reference Filter
Software
Outputs
Mounting
Wireless Communication Options
Meterological Sensor Options
Environmental Operating Range
Power Requirements
Enclosure
Near forward light scattering nephelometry
0-2000 µg/m
3
+/- (2 ug/m3 + 5% of reading)
PM 10
PM 2.5
PM 1.0
2.0 LPM
Heated
Relay and SMS (optional)
2GB SD card (>15 years data storage)
25mm GF filter
Datalogging and configuration software included
RS232 & cellular IP Gateway
Pole and wall mounting
Low power RF modem
Temperature & RH sensor, Gill WindSonic, Vaisala WXT520
-10°C to +45°C; 10 to 95% RH (NC)
Mains (100 to 260VAC) or regulated 12VDC (10W)
Lockable & weatherproof GRP cabinet IP65; 685 x 350 x 300mm
(including solar shield armour & mounting brackets)
Weight
<12kg
Specifications are subject to change without notice.
Distributed by:
20130531Rev1
Kanomax USA, Inc.
P.O. Box 372
219 US Hwy 206, Andover, NJ 07821 U.S.A.
TEL: 1-800-247-8887 (USA) / 1-973-786-6386
FAX: 1-973-786-7586
E-mail: info@kanomax-usa.com
URL: www.kanomax-usa.com
C
Copyright 2012 by KANOMAX USA, Inc.
