Kanomax 6332, 6332D Specifications

Page 1

Airow Transducer

Models 6332 / 6332D

The airow transducer model 6332/D is designed for xed installation. The units can be wired with local electric for power and can be connected to any device that can accept analog output. Transducers are a good choice if you need to simultaneously measure airow at multiple xed points that may not be in proximity to other points. The relatively low cost of this solution makes it a good choice for facility management and integration into other equipment such as dataloggers, alarms or controllers.

Features & Benets

• 10 interchangeable probe options

• Probes quickly and easily attach/detach

• Digital Display Option (model 6332D)

• Selectable Output (Output can be set to either voltage (0 to 5V) or current (4 to 20mA))

Applications

• Product Line Quality Control

• PCB Temperature Monitoring

• Air Velocity Monitor for Local Exhaust Ventilation and FFU (Fan Filter Unit)

• Residential Air Ventilation Monitoring

0963-00

0965-00 (80mm long w/horn)

0965-01 & -09 (80mm long)

0965-10 (400 mm long)

0965-03 0965-04 0965-07 0965-08

0962-00

Page 2

Main Unit Specications

Model 6332 / 6332D

Measuring Object Clean air and compatible, non-combustible gases

Measuring Range Maximum range 0.1 ~ 50 m/s (Range dependant on probe type*)

Temperature Compensation Range

Selectable Output Option

Selectable Range Option

Display Resolution (Model 6332D only)

Power Supply DC 12~24V

Power Consumption (Reference Value)

Connection Wire Size 0.5 ~ 1.5 mm2

Operating Temperature Range 5 ~ 40°C

Storage Temperature Range -10 ~ 50°C

Dimensions Approx. 128(W)×78(D)×30(H) mm

Weight Approx. 320g (11oz.)

Standard Accessory Operation Manual : 1, Main Unit Case: 1

Optional Accessory

5~40°C ±0.25 m/s ±0.50 m/s ±1.25 m/s ±2.50 m/s

40~80°C ±0.35 m/s ±0.70 m/s ±1.75 m/s ±3.50 m/s

Approx. 2.0W (Under the following conditions - power supply: 12V, air velocity: approx.

Power consumption rate is subject to change according to conditions such as air veloci-

Probe Cable (10m, 20m, 30m), Display Unit (Supplied with a case with a display window

0.1-4.99 m/s 5.00-9.99 m/s 10.0-24.9 m/s 25.0-50.0 m/s

(Set via onboard DIPswitch)

Current output: DC 4~20mA (Max. load resistance: 250Ω)

Voltage output: DC 0~5V

(Rotary Switch selectable)

0~2, 0~5, 0~10, 0~25, or 0~50 m/s

Velocity Range: 0~2, 0~5, 0~10 m/s : Display Resolution: 0.01m/s

Velocity Range: 0~25, 0~50 m/s : Display Resolution: 0.1m/s

10m/s, using a unit with a display with probe model 0965-03.)

ty, probe type and use of display.

and 2 installation screws.), Dedicated AC Adapter (DC12V)

Probe Specications

Model

0962-00 Uni-Directional

0963-00 Uni-Directional

0965-00 Omni-Directional

0965-01 Omni-Directional

0965-03 Omni-Directional

0965-04 Omni-Directional

0965-07 Omni-Directional

0965-08 Omni-Directional

0965-09 Omni-Directional

0965-10 Omni-Directional

Kanomax USA, Inc. P.O. Box 372 219 US Hwy 206, Andover, NJ 07821 U.S.A. TEL: 1-800-247-8887 (USA) / 1-973-786-6386 FAX: 1-973-786-7586 E-mail: [email protected] URL: www.kanomax-usa.com

20141107rev1

Probe

Type

Velocity

Range

20-9840 fpm (0.10-50.0 m/s)

20-4920 fpm (0.10-25.0 m/s)

20-4920 fpm (0.10-25.0 m/s) miniature i-shaped probe, with independent temperature compensation

20-4920 fpm (0.10-25.0 m/s) miniature L-shaped probe, with independent temperature compensation

20-9840 fpm (0.10-50.0 m/s)

tip is designed so it can easily be mounted in place

spherical-tip probe with horn

spherical-tip probe (no horn)

spherical-tip probe, 80mm long

spherical-tip probe, 400 mm long

Primary Feature

basic probe

miniature i-shaped probe

miniature L-shaped probe
