Kambrook KS200 User Manual

Ezy-Steam

Food Steamer

KS200 Issue 1/00

Kambrook Safety

Welcome to Kambrook and your new Ezy-Steam Food Steamer.At Kambrook we believe that the safe performance of our products is the first priority in any consumer product so that you, our valued customer, can confidently use and trust our products.We ask that any electrical appliance that you use can be operated in a sensible fashion with due care and attention placed on the following important operating instructions.

READ ALL INSTRUCTIONS THOROUGHLY BEFORE ACTIVATING THE APPLIANCE AND RETAIN THEM FOR FUTURE REFERENCE.

young children or infirm persons without supervision.

Young children should be supervised to ensure that they do not play with the appliance.

Do not leave the appliance unattended when in use.

Do not let the cord hang over the edge of a table or counter, touch hot surfaces or become knotted.

Do not place on or near a hot gas burner, electric element, or in a heated oven.

This appliance is suitable for domestic use only. Do not use this appliance for anything other than its intended use. Do not use outdoors.

Ensure that the power source to be used is the same as the voltage requirements of the product.

Always switch off at the power outlet and then unplug when not in use and before cleaning.

Allow all parts to cook before disassembling for cleaning.

Never immerse the cooking body, cord or power plug in water or any other liquid.

Do not put any food or liquid other than water into the steamer body, only the steamer baskets and rice bowl are designed to cook food.

Do not touch hot surfaces, use handles.

Lift and remove the steamer baskets/rice bowl and juice collection tray carefully to avoid scalding.

This appliance is not intended for use by

Regularly inspect the supply cord, plug and actual appliance for any damage. If found damaged in any way, immediately cease use of the appliance and return the appliance to the nearest authorised Kambrook Service Centre for examination, replacement or repair.

Please call 1800 800 634 for service centre details.

FEATURES OF YOUR KAMBROOK EZY-STEAM

1. 60 minute timer with auto off and sounding bell

2.‘On’ indicator light

3. 3-litre steamer bowl

4. 2-litre steamer bo

5. Rice/sauce cooker bowl

6. Lid

7. Juice collection tray

oir

eser

ater r

9. Element protection cover

(not shown)

Using Your Ezy-Steam Food Steamer

Before first use remove any promotional labels and wash the removable steamer bowls, rice/sauce bowl, lid, juice collection tray in warm soapy water, rinse and dry thoroughly, also wipe the inside of the water reservoir.

Do not immerse the cord or steamer body in water or any other liquid.

Remove the steamer bowls from the top of the unit and ensure that the element protection cover is in place by aligning the three holes in the element protection cover with the three protruding nubs around the element and push on until the cover is firmly in place.

➞

Pour water into the water reservoir, up to the maximum marking “HI FILL” found on the inside of the water reservoir. If you are cooking for a long period of time ensure that the water level does not fall below the minimum “LO FILL” mark.

“LO FILL”

“HI FILL

”

Note: Only use clean water in your steamer. Do not use wine, stock or other liquids.

Place the juice collection tray on top of the unit.

Place food inside of the steamer bowls and/or rice/sauce bowl and place on top of the unit and place the lid on top.

Plug the appliance into a 230/240 volt power outlet and switch on.

Turn the timer dial to the desired cooking time - this will activate the steamer and the “power” light will illuminate.Within 30 seconds steam will start to be produced. After cooking time has lapsed the unit will switch off, sounding a bell and the “power” indicator light will turn off.

Caution:Always take care when lifting the steamer bowls and juice collection tray, as the steam and water condensation can cause burns.

Note:The large (3-litre) bowl must be used if you are steaming in only one bowl and the smaller bowl can be added during the steaming process when food needs less steaming time. Heavier foods or foods that take longer to cook should be placed on the lower steamer basket as this gets a higher concentration of steam.

Switch off at the power outlet and then unplug, allow the Kambrook Ezy-Steam to cool down before cleaning.

During cooking avoid unnecessary removing of the lid and steamer baskets, as steam will escape.

Maintaining Your Ezy-Steam Food Steamer

Always turn the power off at the power outlet and unplug the steamer and allow the unit to cool down before disassembling any parts.

Wash the removable steamer bowls, rice/sauce bowl, lid, juice collection tray and element protection cover in warm soapy water, rinse and dry thoroughly.

Discard the remaining water in the water reservoir and wipe the interior with a damp cloth and dry thoroughly.

Do not place any part of the steamer including steamer and rice bowls in a dishwasher.

Do not use abrasive cleaners, steel wool or scouring pads as these can damage the surface and the element.

The steamer body can simply be wiped over with a damp cloth and then dried.

Caution: Do not immerse steamer body, power cord or plug in water or any other liquid as this may cause electrocution.

Mineral deposits may accumulate on the Heating Element. It is recommended to descale the steamer regularly to prolong the life of your appliance.

Prepare a solution of 2 cups of water, 1 tablespoon of lemon juice or white vinegar.

Pour the solution into the water reservoir and place steamer bowl and lid on top. Turn the steamer on for approximately 15 minutes. Remove the lid and clean as

repeat

usual. If excess scale has built up

the process.

Note: If food with a strong odour, such as fish has been steamed, the above procedure can be followed with steamer and rice bowls in position to ensure the odour is not transferred to the next steaming session.

KAMBROOK STEAMER

All recipes assume that the proceeding assembly instructions have been followed, eg after filling water reservoir the drip tray is placed then the steamer bowl/s.

WARM POTATO SALAD

Serves 4-6

800g new potatoes

1 medium Spanish onion, finely chopped

3/4 cup thinly sliced celery

GREEN BEANS AND MUSHROOM SALAD

Serves 4

400g baby green beans, trimmed and cut in half

150g button mushrooms

2 tablespoons balsamic vinegar

1/4 cup olive oil

2 teaspoons grain mustard

Freshly ground black pepper

150g salami, finely chopped

2 tablespoon freshly snipped chives

Dressing

3/4 cup mayonnaise

2 tablespoons sour cream

1 1/2 tablespoons lemon juice

Freshly ground black pepper

1. Fill water reservoir to “HI FILL” and place the large steamer bowl onto the unit. Place potatoes in a single layer in the steamer. Cover with lid.

2. Set steamer dial to 25 minutes and/or until potatoes are cooked.

3.Allow potatoes to cool slightly and cut in half. Combine with onion, celery, salami and chives.

4. Combine dressing ingredients.

5. Pour dressing over potatoes, season

with freshly ground black pepper. Serve.

1. Fill water reservoir to “HI FILL” and place the large steamer bowl onto the unit. Place beans in the steamer. Cover with lid.

2. Set steamer dial to 10 - 12 minutes. After 7 minutes of cooking, remove lid and place the smaller steamer bowl, filled with mushrooms, on top of the larger steamer bowl. Cover with lid and continue cooking for the remaining 3-5 minutes and/or until beans and mushrooms are cooked. Serve.

3. Combine vinegar, oil, mustard and pepper in a screw top jar. Shake well.

4. Pour dressing over prepared beans and mushrooms or toss to combine. Serve.
