KAM KSD2 Instruction Manual

I N S T R U C T I O N M A N U A L

Kam KSD2

Twin SD card / USB stick mixer

www.kam.co.uk

Due to continuous product development, specifications and appearance are subject to change.

If this product is ever no longer functional please it take to a recycling plant for environmentally friendly disposal.

Kam KSD2 Twin SD card / USB stick mixer

To reduce the risk of electric shock, always remove the mains power cable before carrying out any
servicing or maintenance. Do not remove any covers. There are no serviceable parts inside. Please refer all
servicing to qualified service personnel.

The lighting flash symbol on the rear of the unit is intended to alert the user to the presence of an un insulated
dangerous voltage within the product enclosure that may be of sufficient magnitude to constitute a risk of electric
shock. The exclamation point is intended to alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.

WARNING:

To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture. This unit is for indoor
use only. Electrical equipment should NEVER be kept or stored in damp environments.

This product is not compatible with HCSD cards or MP3 display sticks. Two SD cards or USB inputs are required

for mixing tracks. This unit requires one SD card / USB stick input per side.

KAM KSD2 UNIT FEATURES

1. POWER SWITCH

Press the power switch to turn the unit on. To switch the power off press the switch again.

2. MAINS POWER LEAD

Use this cable to connect the AC mains power to the unit 220/240V.

3. GROUND TERMINAL CONNECTOR

Connect the GND terminal to the turntable ground.

4. FUSE

Under normal operation the fuses should not blow. A blown fuse usually indicates an overload or fault condition. To
change the fuse, remove the fuse by unscrewing the fuse holder cap using a small flathead screwdriver. Refer to
the specification for fuse current ratings. ALWAYS REPLACE THE FUSE WITH THE CORRECT VALUE FOR THIS UNIT.

5. INPUT

Plug in a line level or phono level device such as turntable or additional CD player here. Ensure that the correct line
level is selected using the line level switch.

6. LINE/PHONO INPUT LEVEL SWITCH

Use this swich to allow either line level or phono level equipment to be plugged into your channel inputs. If a
turntable is used, the switch must be switched to Phono. When using CD players and other line level units, the
swich must be in the the Line position. Failure to do this may cause damage to your unit.

7. STEREO MAIN OUTPUT AND RECORD OUTPUTS

The unbalanced AMP RCA connectors are controlled by the master fader, these should be connected to your
amplifier. The REC RCA connectors are to connect a recording device such as tape player etc.

8. HEADPHONE JACK

Use this to connect headphones for audio monitoring.

9. CUE LEVEL CONTROL

This adjusts CUE (headphone) level output.

10. CUE CROSSFADER

This is used for monitoring between the two input channels. For the headphones output, hard left selects channel
one, hard right selects channel two.

2

11. MICROPHONE BASS CONTROL

10

9

8

7

6

5

4

3

2

1

10

9

8

7

6

5

4

3

2

1

+3

0

dB

-3

-8

-

10

-13

TREBLE

-12dB +12dB

CH1 GAIN

MIN MAX

MASTER

L

EVEL

MIN MAX

MIC LEVEL

MIN MAX

CUE LEVEL

MIN MAX

CH2 GAIN

MIN MAX

MIDDLE

-

12dB +12dB

BASS

-12dB +12dB

TREBLE

-12dB +12dB

MIDDLE

-

12dB +12dB

BASS

-12dB +12dB

C

H A N N E L 1

C H A N N E L 1

C H A N N E L 1 C H A N N E L 2

C H A N N E L 2

SD1

USB1

PHONO1
LINE1

C

H A N N E L 2

SD2

USB2

PHONO2
LINE2

C R O S S F A D E R

C U E F A D E R

FOLDER TRACK FOLDER TRACK

S

D/USB

S

CRATCH SCRATCH

SINGLE/CONT.

ROBO

S

D/USB

SINGLE/CONT.

ROBO

TREBLE

-12dB +12dB

BASS

-12dB +12dB

MICROPHONE HEADPHONES

POWER

G R O U N D

AC~220V-240V/ 50Hz / 20 Watts

P O W E R

O N

O

F F

PHONO2

L

INE2

PHONO1

L

INE1

250mAL250V

REPLACEFUSE AS MARKED

L

R

L

R

L

R

L

R

C

H A N N E L 2CH A N N E L 1

A U D I O I N P U T

R

E CAM P

A U D I O O U T P U T

P

GM

REPEAT REPEAT

PITCH PITCH

TIME

P

GM

TIME

djusts microphone bass equalization.

A

12. MICROPHONE TREBLE CONTROL

Adjusts microphone treble equalization.

13. MICROPHONE LEVEL

Adjusts microphone volume level.

4. MICROPHONE INPUT JACK

1

Plug in a microphone equiped with a 1/4 inch microphone jack plug or adaptor.

q

w

e

r

y y

t

u

1^

1%

1&

2)

2$

2&

2%

2^

2* 2( 3) 3!

3# 3$ 3%

3@

3*

4@

3(4) 4!

3^3&

1(

1*

2!

4#

2@

2#

4$

4%

1$

1#

1@

s

a

o

i

3
