Jwin JD TV108 User Manual

PORTABLE DVD PLAYER

• Before attempting to connect, operate or adjust this product, please save and read the User Guide completely.

• The style of the product shown in the User Guide may be different from the actual unit due to various models.

User Guide

Playable Format: DVD/DVD R/DVD RW/Audio CD/Kodak Picture CD/JPEG Picture CD/MPEG 4/DviX

JD-TV108

JDTV108V10M10EN04072005

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

PORTABLE DVD PLAYER USER GUIDE

Contents

FCC and Safety Information .................... 1

Important Safety Instruction .................. 2

Precautions .............................................. 3

Selecting the Type of Disc for the Type

of TV Connected ................................. 4

About This User Guide ........................... 5

1-1 Getting Started .............................. 6

Front View .................................................. 6

Top View .................................................. 6

Right Side View ............................................ 6

Battery Installation for the Remote Control ...... 6

Remote Control .............................................. 7

Connect to External Equipment .................... 8

Input from External Equipment ..................... 9

USB Flash Drive and SD/MMC Card Operation

... 9

Receiving Antenna TV Signal ......................... 10

Receiving TV Signal from Cable ................... 10

How to Use TV Tuner ................................. 10

To Select Preferred Available Channels ..... 11

To Select a SPecic Channel ...................... 11

To Recall Between the Current Channel and

the Previous Channel .................................. 11

2-1 DVD Operation .............................. 12

Basic Playback ....................................... 12

Returning to the Menu Screen .................... 12

Stopping Playback .................................... 12

Pausing Playback ...................................... 12

Frame Advance (Step) ................................. 12

Muting the Player ................................... 12

Using Volume Function .............................. 12

Fast Forward and Backward ..................... 13

Skipping a Chapter Ahead or Back ............ 13

Repeating Viewing .................................... 13

Repeating Sections Between Two Specific

Points (A-B Repeats) .................................. 13

Displaying Scene Information .................. 13

Changing Audio Soundtrack Language ...... 14

3D Audio Output Adjustment ...................... 14

Changing Subtitle Languages ...................... 15

Viewing from Different Angles ................... 15

Zooming a Scene During Playback ......... 15

Using a DVD Menu ................................... 15

Searching Scenes During Playback ........ 16

Programming DVD Playback .................. 16

2-2 Audio CD Operation ..................... 17

Basic Playback ........................................... 17

Stopping Playback ................................. 18

Pausing Playback ............................... 18

Muting the Player .................................. 18

Using Volume Function ....................... 18

Displaying Track Information ................. 18

Fast Forward and Backward ................ 18

Skipping a Track Ahead or Back ............ 18

Rep eating Pla yback ... ...... ...... ...... . 18

PORTABLE DVD PLAYER USER GUIDE

Contents

3-2 Audio Setup .................................... 27

Digital Out ................................................. 27

Downmix .................................................. 27

Night Mode ............................................. 28

3-3 Video Setup .................................... 29

Video Output ............................................... 29

TV Aspect ......................................... 29

Brightness ............................................... 30

Contrast .................................................. 31

Hue ............................................................ 31

Saturation .................................................... 32

TV System ............................................. 32

3-4 System Setup .................................... 33

Screen Saver .............................................. 33

Angle Mark ................................................. 33

Default ........................................................... 34

4-1 LCD Setting .................................... 35

Panel Setting ............................................. 35

Invert Setting ............................................ 35

Color Setting ............................................. 36

Bright Setting ............................................. 36

5-1 Troubleshooting ........................... 37

5-2 Disc Handling and Maintenance

............................................................. 39

Repeating Sections Between Two Specific

Times (A-B Repeat) ............................... 19

2 Channel Audio Output Adjustment ........ 19

3D Audio Output Adjustment ................ 19

Searching Music During Playback ........... 20

Programming Music Playback .................. 20

2-3 Koda k an d JP EG Picture CDs

Operation .............................................. 21

Basic Playback ......................................... 21

Stopping Playback ................................. 22

Pausing Playback ...................................... 22

Zooming Pictures .................................... 22

Displaying Picture Information ................ 22

Skipping a Picture Ahead or Back .......... 22

Repeating Playback ................................. 22

Programming Pictures in Title Menu ............ 22

Changing Slideshow Display ................. 23

3 Initial OSD Setting ............................. 24

Major OSD Settings ............................ 24

3-1 Language Setup ............................. 25

OSD Language .......................................... 25

Audio Language ....................................... 25

Subtitle Language .................................. 26

Menu Language .......................................... 26

PORTABLE DVD PLAYER USER GUIDE

CAUTION:

This unit employs a laser. Due to possible eye injury, only qualied service personnel should remove the cover or attempt to service this device. Use of controls, adjustments, or the performance of procedures other than those specied herein may result in hazardous radiation exposure.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment

and receiver.

–

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV

technician for help.

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

For the DVD Player with Progressive scan output: ‘Consumers should note that not all high denition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of Progressive scan picture problems, it is recommended that the user switch the connection to the “Standard Denition” output. If there are questions regarding our TV set compatibility with this model DVD Player, Please contact our customer service center.’

Since it is usual for DVD movies to be released at different

times in different regions of the world, all players have region

codes and disc can have an optional region code. If you load

a disc of a different region code to your player, you will see

the region code notice on the screen. The disc will not play,

and should be unloaded.

(Possible region codes:)

There are 6 regions (also called “locals”). Each DVD player

and disc will be played in one region ONLY.

1: Canada, U.S., U.S. Territories

2: Japan, Europe, South Africa, Middle East (including

Egypt)

3: Southeast Asia, East Asia (including Hong Kong)

4: Australia, New Zealand, Pacic Islands, Central America,

Mexico, South America, Caribbean

5: Former Soviet Union, Indian Subcontinent, Africa (also

North Korea, Mongolia)

6: China

Never make or change connections with the power switched on.

CAUTION

VISIBLE AND INVISIBLE LASER RADIA-

TION WHEN OPEN AVOID EXPOSURE

TO BEAM (WARNING LOCATION: INSIDE

ON LASER COVER SHIELD)

FCC and Safety Information

PORTABLE DVD PLAYER USER GUIDE

Important Safety Instruction

1. Read and keep these instructions.

2. Pay attention to all warnings.

3. Follow all instructions.

4. Do not use this apparatus near water.

5. Clean only with a damp cloth.

6. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

ampliers) that produce heat.

8. Do not defeat the safety purpose of the polarized-type plug. A polarized plug has two blades with one

wider than the other. The wide blade is provided for your safety. When the provided plug does not t into

your outlet, consult an electrician for replacement of the obsolete outlet.

9. Protect the power cord from being walked on or pinched particularly at plug, convenience receptacles,

and the point where they exit from the apparatus.

10. Only use attachments/accessories specied by the manufacturer.

11. Unplug this apparatus during lighting storms or when unused for long periods of time.

12. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been

damaged in any way; such as when the power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

13. Ambient Temperature 0~40°C.

WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. The

apparatus shall not be exposed to dripping or splashing and that not objects lled with liquids, such as vases,

shall be placed on the apparatus.

PORTABLE DVD PLAYER USER GUIDE

Please read these precautions before operating the unit.

n Power cord protection

To avoid any malfunctions of the unit, and to protect against electric shock, re or personal injury, please

observe the following.

l Hold the plug rmly when connecting or disconnecting the AC power cord. l Keep the AC power cord away from heating appliances. l Never put any heavy object on the AC power cord.

n Placement

Avoid placing the unit in areas of:

l Direct sunlight or heating radiators, or closed automobiles l High temperature (over 35 C) or high humidity (over 90%)

n Non-use periods

When the unit is not being used, turn it off. When left unused for a long period of time, the unit should be

unplugged from the household AC outlet.

n No ngers or other objects inside

l Touching internal parts of the unit is dangerous, and may cause serious damage to the unit. Do not

attempt to disassemble the unit.

l Do not put any foreign object on the disc tray.

n Keep away from water/magnet

l Never bring a magnet or magnetized object near the unit.

n Stacking

l Place the unit in a horizontal position, and do not place anything heavy on it.

n Condensation

l Immediately after a heater has been turned on l In a steamy or very humid room

unit, it may not operate properly. In this case, turn on the power and wait about one hour for the moisture

to evaporate.

Precautions

l Do not attempt to repair or modify the AC power cord in any way.

l Excessive dust, as the internal parts may be seriously damaged.

l Keep the unit away from vases, tubs, sinks, etc. If liquids are spilled into the unit, serious damage

could occur.

Moisture may form on the internal lens under the following conditions:

l When the unit is suddenly moved from a cold environment to a warm one. If moisture forms inside the

n If there is noise or interference on the TV while a broadcast is being received

Depending on the reception condition of your TV (not the JD-TV108), interference may appear on the TV monitor while watching a TV broadcast when the JD-TV108 is left on. This is not a malfunction of the unit or the TV. To watch a TV broadcast without such interference, turn off the unit.

PORTABLE DVD PLAYER USER GUIDE

n Connecting to the PAL TV

Selecting the Type of Disc for the Type of TV Connected

To View NTSC DVDs on a Multi-TV System Monitor:

1. In the VIDEO SETUP menu (see page 32), be sure the "TV SYSTEM" entry is set for NTSC (the default).

2. Be sure the Multi-TV System (external) Monitor is set to receive NTSC video signals.

3. The video content being played will appear on both the JD-TV108's LCD and on the external monitor.

To View PAL DVDs on a Multi-TV System Monitor:

1. In the VIDEO SETUP menu (see page 32), be sure the "TV SYSTEM" entry is set for PAL.

2. Be sure the Multi-TV System (external) Monitor is set to receive PAL video signals.

3. The video content being played will appear on both the JD-TV108's LCD and on the external monitor, but because the unit's LCD cannot display PAL video directly, it will appear without color content. The external monitor will display the PAL content in color. See the NOTE below.

To View NTSC DVDs on an NTSC TV Monitor:

1. In the VIDEO SETUP menu (see page 32), be sure the "TV SYSTEM" entry is set for NTSC (the default).

2. Be sure the NTSC Monitor is ready to receive NTSC video signals.

3. The video content being played will appear on both the JD-TV108's LCD and on the external monitor.

To View PAL DVDs on a PAL TV Monitor:

1. In the VIDEO SETUP menu (see page 32), be sure the "TV SYSTEM" entry is set for PAL.

2. Be sure the PAL Monitor is set to receive PAL video signals.

3. The video content being played will appear without color on JD-TV108's LCD. The external monitor will display the PAL content in color. See the NOTE below.

NOTE:

When viewing a PAL DVD on the unit's LCD display (without an external monitor), you must set the VIDEO SETUP menu's "TV SYSTEM" entry to NTSC (not PAL; see page 32). In order for PAL video content to appear in color on the unit's LCD display, it must first be converted to NTSC. As already stated, PAL signals can appear in color on a PAL external monitor when the "TV SYSTEM" is set to PAL, but the same content will then appear in "black and white" on the LCD.

Your JD-TV108 is capable of playing DVD discs and having their content viewed on the unit's LCD display, as well as on an external TV. While your JD-TV108 is primarily intended to play NTSC DVDs, it can also play PAL DVDs (NTSC and PAL are video formats); refer to the Quick Guide and to the following information:

n Connecting to a Multi-TV System (external) monitor (capable of viewing NTSC and PAL)

n Connecting to an NTSC TV

PORTABLE DVD PLAYER USER GUIDE

About This User Guide

this User Guide completely.

Thank you for buying the Portable DVD Player. Instructions in this User Guide describe mainly

the use of the remote control. Buttons with the same or similar marking on your Portable DVD Player

To switch the player to Stand-by mode, press

Power

. To resume to Play mode,

press

Power

again.

When turning on the DVD Player, the unit directly enters DVD mode.

If a disc is already placed on the disc tray, the recorder will start to load the disc right after

power is turned on.

When pressing

Stop once during DVD playback, the player turns to a pre-stop status and

memorizes the position where the playback is stopped. To start play from where the playback

has been stopped, press

Play.

Press

Stop twice to completely stop playback.

Note: Before attempting to connect, operate or adjust this product, please read and save

itself, have the same functions as those of the remote control. For introduction to the display (Portable DVD Player), buttons (Remote Control), and various connections, please refer to the Quick Guide.

The section below covers signicant information about the unit’s general behavior. Please read carefully. If you wish, you can use the same functions on the remote control.

To turn on the DVD player, press

Power on the top panel of the player.

To switch to other modes, do the following:

If there is no disc placed in the recorder, press

If there is a disc placed in the recorder, press

Press

If an “INVALID KEY” appears on the left top corner of the screen, it indicates that the action

is prohibited or not available.

Mode to toggle through different modes.

Stop twice to completely stop DVD playback.

Mode to toggle through different modes.

PORTABLE DVD PLAYER USER GUIDE

1-1

Getting Started

Front View

1.2.3. 4. 5.6.7.

8. 9.10.11.

VOLUME(-) Button

CHANNEL(+) Button

VOLUME(+) Button

POWER Button

PREVIOUS Button

PLAY Button

NEXT Button

CHANNEL(-) Button

TV/DVD Button

10.

EJECT Button

11.

STOP Button

Top View

P-SCAN Output Jack

PHONES Jack

AV OUT Jack

AV IN Jack

COAXIAL Output Jack

USB Port

SD/MMC Card Slot

DC IN Jack

CABLE IN Jack

CR2025

OPEN

PUSH

Right Side View

Battery Installation for the

Remote Control

Insert the battery and match the (+) and (-) on battery to the marks inside the battery compartment.

First-time use:

REAR OF

REMOTE

CONTROL

1. LCD Screen

2. Speakers

3. Power Indicator

4. Remote Sensor

5. Remote Control Carrier

6. Base

Remember to remove the insulating mylar strip from the battery.

PORTABLE DVD PLAYER USER GUIDE

1-1 Getting Started - continued

29.

30.

31.

1. Setup Button

2. Power Button

3. Subtitle Button

4. Zoom Button

5. Cursor Button (

)

6. Menu Button

7. OK Button

8. Cursor Button (

)

9. Cursor Button (

)

10. Return Button

Service life of battery:

1. The battery normally lasts about

one year although this depends on how often and for what operations the remote control is used.

2. If the remote control unit fails to work

even when it is operated near the player, replace the battery.

3. Use a 3V lithium battery (No. CR2025).

Remote Control

11.

13.

15.

16.2.

17.

18.4.

19.

20.6.

21.

22.8.

23.

24.10.

25.

26.12.

27.

28.14.

11. Pause Button

12. Play Button

13. Fast Forward Button

14. Fast Backward Button

15. LCD Button

16. Mode Button

17. Angle Button

18. Audio Button

19. Title Button

20. Volume(+) Button

21. Cursor Button ( )

22. Volume(-) Button

23. Search Button

24. Mute Button

25. Stop Button

26. TV Source/Info. Button

27. Channel(-)/Previous Button

28. Channel(+)/Next Button

29. Program Button

30. Repeat Button

31. Number Buttons

PORTABLE DVD PLAYER USER GUIDE

GreenBlue Red

(Green)(Blue)(Red)

(Yellow)

Y Pb Pr Input

Input

(White) (Red)

Audio Input

(White) (Red)

Audio Input

OR OR

Yellow WhiteRed

Orange

1-1 Getting Started - continued

POWER

EJECT

Connect to External Equipment

1 Connect the Portable DVD Player to

a source of power.

onnect the supplied AC adapter to

the DC IN jack on the right side of the unit.

2 Connect the unit to external equipment

and/or to earphones.

If you want to enjoy better listening and viewing quality, you can connect the Portable DVD Player to external equipment, such as a TV or an ampli er.

3 Press Power button on the top panel

of the unit to turn on the DVD Player.

4 Press Eject button on the top panel of

the unit to open the disc cover. Pull the cover forward, if necessary.

5 Gently hold the edge of the disc, then

put it in the disc frame with the printed side down.

Note:

• Before connecting, make sure to turn off the

power on the Portable DVD Player and the external equipment.

• Make sure the external equipment supports

inputs from the JD-TV108. See the Quick Guide.

Note:

• This player doesn’t support the 8cm (3.15 in.)

disc playback.

6 Close the disc cover. 7 Press Play button on the top panel

of the unit or Play on the remote control to play the disc.

PORTABLE DVD PLAYER USER GUIDE

1-1 Getting Started - continued

Input from External Equipment

You could input images and sounds from external equipment by connecting the portable DVD player to external equipment with the audio or video cable.

Yellow White Red

Audio Output

Output

(White) (Red)

(Yellow)

Note:

• Make sure the external equipment you wish to

use has output connections available for the inputs in the JD-TV108.

USB Flash Drive and SD/MMC

AV IN

White Red

Audio Output

(White) (Red)

Card Operation

1 Insert a USB Flash Drive to the USB

port or a SD/MMC card to the card slot on the right panel of the DVD player.

2 Press the Mode button on the remote

control to select USB Mode or SD/MMC Card Mode.

Insert a USB Flash Drive

Insert a SD/MMC Card

3 A  le list appears on the screen, press

Up / Down on the remote control

to select a preferred JPEG or MP3  le.

4 Press OK or Play to play the

selected  le.

For Picture File Playback Only

• Press Right to rotate the picture

clockwise by 90°.

• Press Left to rotate the picture anti-

clockwise by 90°.

Note:

• Press Mode a number of times. You can

toggle through different modes, including

“DVD Mode”, “USB”, “CARD”, “AV IN” and

“TV TUNER”.

Note:

• Playable formats for the SD/MMC memory card

operation include JPEG and MP3.

• If the JPEG  le size is over 1.0MB, it may take
