Jwin i177 User Manual

Stereo Audio System for Your iPod
Instruction Manual
Model: i177
Please read this manual carefully before operating and save it for future reference.
Have a question? Please visit http://www.i-Luv.com
USER SAFETY GUIDE
INSTRUCTIONS ON ENVIRONMENT PROTECTION
Do not dispose of this product in the usual household garbage at the end of its life cycle; bring it to a collection point for the recycling of electrical and electronic appliances. This symbol on the product means the instructions for use or the packing will inform about the methods for disposal. The materials are recyclable as mentioned in its marking. By recycling, material recycling, or other forms of re-utilization of old appliances, you make an important contribution to protect the environment. Please inquire at your local community administration for the authorized disposal location.
FCC RULES This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.
Do not make changes or modify the device in any way. Changes or modifications not expressly appro ved by the party responsible for compliance could void the user’s authority to operate the equipment.
IMPORTANT SAFETY WARNINGS
1. Before using the player, please ensure that your local AC voltage is suitable for this unit.
2. To prevent fire or electric shock, do not expose the unit to rain or moisture.
3. Never attempt to open the cabinet. Always refer servicing to a qualified technician.
IMPORTANT SAFETY INSTRUCTIONS
1. READ INSTRUCTIONS – All the safety and operating instructions should be read before the appliance is operated.
2. RETAIN INSTRUCTIONS – The safety and operating instructions should be retained in a secure place for future reference.
3. HEED WARNINGS – All warnings on the appliance and in the operating instructions should be observed.
4. FOLLOW INSTRUCTIONS – All operating and use instructions should be followed.
5. WATER AND MOISTURE – The appliance should not be used near water. For example: near a bathtub, kitchen sink, laundry tub, and/or swimming pool.
6. HEAT – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.
- 1 -
www.i-Luv.com
USER SAFETY GUIDE
IMPORTANT SAFETY INSTRUCTIONS – CONTINUED
7. POWER SOURCES – The appliance should be connected to a power supply only of the type described in the operating instructions or as marked on the appliance itself.
8. CLEANING – The appliance should be cleaned with a dry cloth.
9. OBJECT AND LIQUID ENTRY – Care should be taken so that objects do not fall and liquids are not spilled into the device’s openings.
10. CARTS AND STANDS – The appliance should be used only with a cart or stand that is recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.
11. DAMAGE REQUIRING SERVICE – The appliance should be serviced by qualified service professional when:
a. The power supply cord or plug has been damaged. b. Objects have fallen into, or liquid has been spilled into the appliance’s apertures. c. The appliance has been exposed to rain. d. The appliance has been dropped and suffered damage. e. The appliance does not appear to operate normally or exhibits a change in performance.
12. SERVICING – The user should not attempt to service the appliance beyond what is described in the user's operating instructions. All other servicing should be referred to qualified service professional.
13. BATTERY USAGE – To prevent battery leakage, which may result in bodily injury, property damage or damage to the unit, follow these instructions:
a. Install all batteries correctly according to the polarity (+/-) as marked on the unit. b. Do not mix old and new batteries, carbon and alkaline, etc. c. Remove batteries from the unit when the device will not be used for an extended period of time.
14. LEAD AND MERCURY – This product may contain lead and/or mercury. Disposal of these materials may be regulated by your local authorities due to environmental considerations. For more detailed disposal or recycling information, please contact your local authorities or the EIA (Electronic Industries Alliance) – http://www.eiae.org
- 2 -
www.i-Luv.com
USER SAFETY GUIDE
FCC NOTICE (USA)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help.
- 3 -
www.i-Luv.com
TABLE OF CONTENTS
Getting Started
General features ……………………………………………………………………………………………………………………………………………...… 5 Installing the AC adapter…………….……………………………………………………………..…………………… …………………………………..… 6 Installing the backup battery for clock and alarm settings ………………..……………………….………………………………………………………. 6
Installing the remote control battery ….....………………………………………………………………………………………………………….………… 7
Installing the AM loop antenna ………………………………………………………………………………………………………………………….…….. 7 Installing the dock adapter …………………………………………………………………………………………………………………………………….. 7 Location of controls on the main unit ……………………………………………………………………………………………………………….…...…… 8 Location of controls on the remote control …………………………………………………………………………………………………………………... 9 Location of indications on the LCD screen …...…………………………………………………………………………………………………………….. 10
Setting the clock time …….....…………….…………...………………………………………………………………………………………………………. 11
Setting the alarm time ………………………………………………………………………………………………………………………………………..… 11
Operational Instructions
Listening to your favorite songs on iPod …………………………………………………………………………………………………………………….. 12 Charging your iPod ……………………………………………………………………………………………………………………………………………. 12 Listening to other audio devices ……………………………………………………………………………………………………………………………… 13 Listening to your favorite radio stations ……………………………………………………………………………………………………………………… 13 Using the alarm function ………………………………………………………………………………………………………………………………………. 14 Adjusting the brightness of LCD screen ………...…………………………………………………………………………………………………………… 14 Setting the sleep time ………………………………………………………………………………………………………………………………………….. 15
Maintenance & Troubleshooting Guide …………………………………………… ………… ……… ………… ……… ………… ……… ………..… ……… .. 16
- 4 -
www.i-Luv.com
GETTING STARTED
Congratulations on your purchase of the new iLuv i177 for your iPod. Uniquely designed to work with your iPod, this iLuv stereo audio system with built-in universal dock provides advanced audio and radio performance that brings out the best in your music. Remember to keep this manual for future reference.
Enhance Your Enjoyment of the Music Stored on Your iPod
Enhance the richness of your iPod sound with jAura  Powerful built-in speakers allow you to hear music with depth and clarity  Digital clock display with dual alarm  Fall asleep or wake up to your iPod, AM/FM radio, or buzzer  Charges your iPod  Integrated universal dock for your iPod  Supports iPod shuffle  Auxiliary line input for 1
st
and 2nd generations of the iPod and other audio devices
AM/FM radio with PLL digital tuning technology  External loop antenna provides better AM reception  Liquid crystal display with white backlight  Remote control included
What’s included?
Stereo audio system  Remote control (Battery included)
Dock adapters  AC adapter
* Made for iPod with video (30GB, 60GB), iPod nano, iPod shuffle, iPod mini, iPod 4G, and iPod 3G only.
with iLuvTM Stereo Audio System
acoustic speaker technology
TM
AM loop antenna  Instruction manual
Warranty card
- 5 -
www.i-Luv.com
