Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
DVD DIGITAL CINEMA SYSTEM
DIGITAL
SURROUND
DIGITAL
STANDBY
AUDIO/FM MODE
DSP
VOLUMESOURCE
DVD DIGITAL CINEMA SYSTEM TH-A30R
STANDBY/ON
DISPLAY
TV/VIDEO
TOP MENU
AUDIO
TUNING
ENTER
RDS
VCR CHANNEL
TUNER PRESET
DVD FM/AM AUX
MUTING
STANDBY/ON
VCR
VCR
CONTROL
MENU
TV
AUDIO/
FM MODE
SUBTITLE
RETURN
STEP
TV VOLUME
TV CHANNEL
VOLUME
B.SEARCHF.SEARCH
DOWNUP
REW
FF
RM-STHA30R
DVD CINEMA SYSTEM
DISPLAY
TH-A30R
Consists of XV-THA30R, SP-XA30, SP-XSA30 and SP-WA30
INSTRUCTIONS
LVT0945-010B
[B]
Warnings, Cautions and Others
IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If the plug
fitted is not suitable for the power points in your home or the
cable is too short to reach a power point, then obtain an
appropriate safety approved extension lead or consult your
dealer.
BE SURE to replace the fuse only with an identical approved
type, as originally fitted.
If nonetheless the mains plug is cut off ensure to remove the
fuse and dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the mains supply.
If this product is not supplied fitted with a mains plug then follow
the instructions given below:
IMPORTANT.
DO NOT make any connection to the terminal which is marked
with the letter E or by the safety earth symbol or coloured green
or green-and-yellow.
The wires in the mains lead on this product are coloured in
accordance with the following code:
Blue : Neutral
Brown : Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed as
follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1.Do not remove screws, covers or cabinet.
2.Do not expose this appliance to rain or moisture.
Caution ––STANDBY/ON switch!
Disconnect the mains plug to shut the power off completely.
The STANDBY/ON button in any position does not
disconnect the mains line.
The power can be remote controlled.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)
• Do not place any naked flame sources, such as lighted
candles, on the apparatus.
• When discarding batteries, environmental problems must be
considered and local rules or laws governing the disposal of
these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping or
splashing and that no objects filled with liquids, such as vases,
shall be placed on the apparatus.
G-1
IMPORTANT FOR LASER PRODUCTS
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LASER CLASE 1
REPRODUCTION OF LABELS
1 CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE
2 WARNING LABEL, PLACED INSIDE THE UNIT
1. CLASS 1 LASER PRODUCT
2. CAUTION: Invisible laser radiation when open and interlock
failed or defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to
qualified service personnel.
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front:No obstructions open spacing.
Sides:No obstructions in 10 cm from the sides.
Top:No obstructions in 10 cm from the top.
Back:No obstructions in 15 cm from the back
Bottom:No obstructions, place on the level surface.
In addition, maintain the best possible air circulation as illustrated.
Spacing 15 cm or more
Wall or obstructions
XV-THA30R
Front
Stand height 15 cm or more
Floor
G-2
SAFETY INSTRUCTIONS
“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”
This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be
taken if you are to obtain the best results and safety is to be assured.
Do read the operating instructions before you attempt to use the equipment.
Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment) are
properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing
connections.
Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.
Do be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way–switch off, withdraw
the mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose dangerous voltages.
DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has
a standby mode.
Switch off using the switch on the equipment and make sure that your family know how to do this.
Special arrangements may need to be made for infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is illegal to watch
television whilst driving.
DON’T listen to headphones at high volume as such use can permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings.
Overheating will cause damage and shorten the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s approved
stand or legs with the fixings provided according to the instructions.
DON’T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
— NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case -this could result in a fatal
electrical shock.;
— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!
G-3
Table of Contents
Parts Identification ...................................... 2
Center Unit ................................................................................. 2
Remote Control .......................................................................... 3
Getting Started ........................................... 4
Before Installation ...................................................................... 4
Checking the Supplied Accessories ........................................... 4
Putting Batteries in the Remote Control .................................... 4
Connecting the FM and AM Antennas ....................................... 5
• Pressing one of these buttons also turns on the power.
9 4, 7, 3/
8
, and ¢ buttons
TUNER PRESET UP and DOWN buttons (45)
FF (Fast-forward) and REW (Rewind) buttons
p VCR CHANNEL + and – buttons (54)
TUNING + and – buttons (14, 44)
¡ F. (Forward) SEARCH and 1 B. (Back) SEARCH
buttons
q Menu operation buttons
• 3, 2, 5, and ∞ buttons
• ENTER button
w VOLUME + and – buttons (10, 12, 14)
e TOP MENU button (29)
r MENU button (29, 35)
t TV/VIDEO button (10, 12, 54, 55)
y RDS DISPLAY button (46)
u TV CHANNEL + and – buttons (54, 55)
i TV VOLUME + and – buttons (54, 55)
o VCR CONTROL buttons (54)
IMPORTANT:
If you press VCR CONTROL, this remote control will work ONLY
for the JVC’s VCR. When you want to operate the system again,
press DVD or FM/AM.
w SETUP button (51 – 53)
e TEST button (19)
r D.R.C button (21)
t DSP MODE button
(11, 13, 20, 23)
y PROGRAM button
(31, 32, 37, 45)
u SLEEP button (15)
i REMAIN button (29, 34)
3
Getting Started
Before Installation
General Precautions
• DO NOT insert any metal object into the center unit.
• DO NOT disassemble the center unit or remove screws, covers, or
cabinet.
• DO NOT expose the center unit to rain or moisture.
Locations
• Install the center unit in a location that is level and protected from
moisture.
• The temperature around the center unit must be between 5˚C and
35˚C (41˚F and 95˚F).
• Make sure there is good ventilation around the center unit. Poor
ventilation could cause overheating and damage the center unit.
Handling the center unit
• DO NOT touch the power cord with wet hands.
• DO NOT pull on the power cord to unplug the cord. When
unplugging the cord, always grasp the plug so as not to damage
the cord.
• Keep the power cord away from the connecting cords and the
antenna. The power cord may cause noise or screen interference. It
is recommended to use a coaxial cable for antenna connection,
since it is well-shielded against interference.
• When a power failure occurs, or when you unplug the power cord,
the preset settings such as preset FM/AM channels and sound
adjustments may be erased in a few days.
Putting Batteries in the Remote Control
Before using the remote control, put two supplied batteries first.
• When using the remote control, aim the remote control directly at
the remote sensor on the center unit.
1. On the back of the remote control, remove the
battery cover.
2. Insert batteries. Make sure to match the polarity:
(+) to (+) and (–) to (–).
3. Replace the cover.
Checking the Supplied Accessories
Check to be sure you have all of the following supplied accessories.
The number in the parentheses indicates the quantity of the pieces
supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
• Video cord (1)
If anything is missing, contact your dealer immediately.
If the range or effectiveness of the remote control decreases, replace
the batteries. Use two UM-4“AAA”/IEC “R03” type dry-cell
batteries.
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
• Place batteries in the remote control so they match the polarity: (+)
to (+) and (–) to (–).
• Use the correct type of batteries. Batteries that look similar may
differ in voltage.
• Always replace both batteries at the same time.
• Do not expose batteries to heat or flame.
4
Y/C
COMP.
1
2
3
MINMIN MINMIN
Connecting the FM and AM Antennas
If FM reception is poor, connect
outdoor FM antenna (not supplied).
If AM reception is poor, connect single vinyl-covered
wire (not supplied).
AM Loop Antenna
(supplied)
FM Antenna (supplied)
Cooling fan
(See “About the cooling fan” below.)
FM antenna connection
Connect the supplied FM antenna to the FM 75 Ω COAXIAL
terminal as temporary measure.
Extend the supplied FM antenna horizontally.
• If reception is poor, connect an outdoor antenna. Before attaching
a 75 Ω coaxial cable (with a standard type connector), disconnect
the supplied FM antenna.
Snap the tabs on the loop into
the slots of the base to
assemble the AM loop antenna.
Center unit
AM antenna connection
Connect the supplied AM loop antenna to the AM and H terminals.
Turn the loop until you have the best reception.
• If reception is poor, connect an outdoor single vinyl-covered wire
to the AM terminal. (Keep the AM loop antenna connected.)
Note:
If the AM loop antenna wire is covered with vinyl, remove
the vinyl by twisting it as shown in the diagram.
About the cooling fan
A cooling fan is mounted on the rear panel of the center unit to
prevent abnormal temperature inside the center unit, thus assuring
normal operation of the unit. The cooling fan automatically starts
rotating to supply external cool air to the inside of the center unit
when the internal temperature goes up.
For safety, observe the following carefully.
• Make sure there is good ventilation around the center unit. Poor
ventilation could overheat and damage the center unit.
• DO NOT block the cooling fan and the ventilation openings or
holes. (If they are blocked by a newspaper or cloth, etc., the
heat may not be able to get out.)
• DO NOT touch the speaker cords to the cooling fan.
5
Getting Started
Subwoofer
Left rear
speaker
Right front
speaker
Right rear
speaker
To center speaker
To left front speaker
To right front speaker
To left rear
speaker
To right rear
speaker
To subwoofer
Left front
speaker
DIGITAL
SURROUND
DIGITAL
COMPACT
DIGITAL VIDEO
STANDBY
AUDIO/FM MODE
DSP
VOLUME SOURCE
DVD DIGITAL CINEMA SYSTEM TH-A30R
STANDBY/ON
Center unit
Y/C
COMP.
Center speaker
MINMINMIN
MIN
Speaker Layout Diagram
6
Connecting the Speakers
Left front
speaker
Right front
speaker
Right rear
speaker
Subwoofer
Left rear
speaker
Center speaker
132
Connect the satellite speakers, center speaker, and subwoofer to the
terminals on the rear panel using speaker cords supplied.
Labels are attached to the speaker cords to indicate the terminals to
be connected.
• Connect the red cord to the red (+) terminal, and the black cord to
the black (–) terminal respectively.
CAUTION:
Use speakers with the SPEAKER IMPEDANCE indicated by the
speaker terminals.
Connecting speaker cords to the terminals
1
Press and hold the terminal clamp.
When setting the speakers
To obtain the best possible sound from this system, you need to
place all the speakers except the subwoofer at the same distance
from the listening position with each front faced toward the listener.
Since bass sound is non-directional, you can place a subwoofer
wherever you like. Normally place it in front of you.
If your speakers cannot be placed at the same distance from the
listening position
You can adjust the delay time of the center speaker and rear
speakers. For in-depth information about adjusting the delay time,
see “Setting the Delay Time” on page 16 and 17.
2
Insert the speaker cord.
3
Release the finger from the clamp.
Notes:
• If the speaker cord is covered with vinyl, remove the
vinyl by twisting it as shown in the diagram.
• Make sure the core wire of speaker cords do not
expose to out of the terminals. This could cause
short-circuit.
Note:
You can change the phase of subwoofer sounds by connecting the
speaker cords to the terminals inversely—the red cord to the black
terminal, and the black cord to the red terminal. You may get the more
effective bass sounds by changing the phase.
CAUTION:
• When attaching the satellite speakers on the wall, have them
attached to the wall by a qualified person.
DO NOT attach the satellite speakers on the wall by yourself to
avoid an unexpected damage of their falling from the wall, caused
by incorrect attachment or weakness in the wall.
• Care is required in selecting a location for attaching speakers to the
wall. Injury to personnel, or damage to equipment, may result if the
speakers are attached in a location which interferes with daily
activities.
7
Getting Started
Y/C
COMP.
DBS Tuner
Center unit
MD Recorder
Cassette Deck
OUT
LEFT
RIGHT
AUDIO
VCR
TV
MIN
Connecting Audio/Video Component
Turn the power off to all components before connections.
Audio component connection
Connect the other component to the center unit with the
audio cord.
Use the cord supplied with the other component or
purchase it at an electric appliance store.
Audio cord (not supplied)
Illustrations of the input/output terminals below are typical
examples.
When you connect the other component, refer also to its
manuals since the terminal name actually printed on the rear
vary among the components.
If you connect a sound-enhancing device such as a
graphic equalizer between the source component and
the center unit, the sound output through this system
may be distorted.
8
Y/C
COMP.
Y/C
COMP.
MINMIN
MIN
MIN
1
TV
A
B
C
4
Y/C
COMP.
Y/C
COMP.
A
B
C
TV connection
The S-video cord and the SCART cable are not supplied with this system.
Use the cords or cables supplied with the other component or purchase them at an electric appliance store.
Video cord (supplied)SCART cable (not supplied)
S-video cord (not supplied)
You can select one of three connection types—A, B, and C.
For using the composite video cord or S-video cord
• If your TV has S-video (Y/C-separation) jack, connect it using an
S-video cord (not supplied)B.
By using this jack, you can get a better picture quality than using
composite video cord connection A.
Illustrations below are
typical examples.
When you connect the TV,
refer also to its manual since
the terminal names actually
printed on the rear vary
among the components.
For using the SCART cable ( C)
• If S-Video (Y/C-separation) is equipped for your
TV, set Y/C–COMP. selector of the center unit to
Y/C. You can get a better picture quality by using
S-Video (Y/C-separation) setting.
• If S-Video (Y/C-separation) is not equipped for
your TV, set Y/C–COMP. selector to COMP.
Y/C–COMP. selector
Note:
On the rear panel SCART cable is indicated as “AV OUT.” However,
this terminal is designed as video output. So, no sound comes out.
Now, you can plug the power cord of the center unit into the AC outlet.
Note:
Keep the power cord away from the connecting cords and the antenna
cables. The power cord may cause noise or screen interference.
9
Basic DVD Operations
STANDBY/ON
AUDIO
TOP MENU MENU RETURN MUTING
VOLUME
TUNER PRESET
DISPLAY
B.SEARCH
DOWN
REW
UP
FF
F.SEARCH
RETURN
STEP
TV/VIDEO
TV VOLUME
TV CHANNEL
SUBTITLE
TOP MENU
TV
STANDBY/ON
AUDIO
VCR
VCR
CONTROL
TUNER PRESET
ENTER
VOLUME
MENU
AUDIO/
FM MODE
VCR CHANNEL
TUNING
DVD FM/AM AUX
MUTING
123
45
6
78
9
0
REMAIN
PROGRAM
D.R.CZOOM
SETUP
DSP MODE
SLEEP
TEST
PRO LOGIC
SETTING
SOUND
CLEAR
REPEAT
ANGLE
SLOW
SEARCH
A-B REPEAT
PTY –PTY +PTY SEARCH
RDS
DISPLAY
DVD
This manual mainly explains operations using the buttons on
the remote control. You can also use the buttons on the center
unit if they have the similar names (or marks) as those on the
remote control.
If operations using the center unit are different from those
using the remote control, they are then explained.
1
STANDBY/ON
AUDIO
TV
2 DVD
7
7
TV/VIDEO
4
3/8
2
Select the Source
Press DVD.
The source changes to DVD.
3
Load a DVD
On the front panel ONLY:
Press 0 to open the disc tray, then place a DVD correctly
with its label side up.
CORRECTINCORRECT
5
5
VOLUME –
VOLUME +
MUTING
6
DSP MODE
For in-depth information about DVD operations, see
pages 25 to 33.
1
Turn On the Power
Before turning on the system, turn on your TV and select the correct
video input. (See the manual supplied with your TV.)
• When you use a JVC’s TV, you can turn on your TV by pressing
TV
pressing TV/VIDEO. (If your TV is not a JVC’s, see “Operating
on the remote control, and select the video input by
Other Manufacturers’ TV” on page 55.)
• For changing the OSD messages—the information on the TV
screen—into the desired language, see “Setting the Initial
Languages” on pages 50 and 51.
4
Start Playback
Press 3/8.
The disc tray closes. “LOADING” appears for a
while.
• You can also start playback by closing the
disc tray using 0 on the front panel.
5
Adjust the Volume
To increase the volume, press and hold VOLUME +.
To decrease the volume, press and hold VOLUME –.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing VOLUME + or – repeatedly, you can adjust the volume
level step by step.
• The volume level can be adjusted within 51 steps—
“MIN (minimum),” 01 to 49, and “MAX (maximum).”
To turn off the sounds temporarily
From the remote control ONLY:
Press MUTING.
Press STANDBY/ON
STANDBY/ON
The STANDBY lamp goes off and the illumination
lamp on the center unit lights up. The source
indication selected previously appears on the display.
10
AUDIO (or
on the front panel).
To restore the sound, press
MUTING again.
• Pressing VOLUME + or – also restores the sound.
6
STANDBY/ON
AUDIO
HALLTHEATER
Normal
indication
(canceled)
LIVE CLUB
DANCE CLUB
DSP MODE
TUNER PRESET
Activate Surround or DSP Mode
7
Stop Playback
You can enjoy two kinds of surround—Digital Multichannel
Surround (Dolby Digital and DTS Digital Surround) and DSP
modes.
Digital Multichannel Surround—Dolby Digital
and DTS Digital Surround
Dolby Digital or DTS Digital Surround takes effect only when you
enjoy a disc encoded with its signals—the DOLBY DIGITAL or
DTS indicator lights up on the display.
Sound signal
indicators on the
display
To activate Dolby Digital or DTS Digital Surround
When a disc encoded with the Dolby Digital or DTS Digital
Surround is loaded, the system detects it and starts playing the disc
automatically with Multichannel Surround activated.
– For in-depth information about surround modes, see “Creating
Realistic Sound Fields” on pages 18 and 21.
DSP modes—THEATER, HALL, LIVE CLUB,
DANCE CLUB
DSP modes take effect only when you enjoy a disc recorded using
Linear PCM—the LINEAR PCM indicator lights up on the display.
Press 7 twice.
Playback stops completely and “DVD” appears
on the display. (The DVD player goes on
working for 3 minutes after playback stops.)
• This system can memorize the end point even when you press 7
once. When you start playback again by pressing 3/8, playback
begins from where it has been stopped—Resume play.
To remove the loaded disc
Press 0.
“OPEN” appears on the display and the disc tray comes out.
To close the disc tray, press 0 again.
• If you do not press the button, the disc tray closes
automatically after 3 minutes.
To turn off the power (into standby)
Press STANDBY/ON AUDIO (or
STANDBY/ON
The illumination lamp goes off and the STANDBY
lamp lights up.
• If you press STANDBY/ON
STANDBY/ON
open, the disc tray closes automatically, then the system is turned
off.
• A small amount of power is consumed even in standby mode. To
turn the power off completely, unplug the AC power cord.
on the front panel).
AUDIO (or
on the front panel) while the disc tray is kept
Sound signal
indicators on the
display
To activate DSP modes
Press DSP MODE (or DSP on the front panel).
The DSP indicator lights up and the current DSP mode
appears on the display for a while.
• Each time you press the button, DSP mode changes as follows:
– For in-depth information about DSP modes, see “Creating
Realistic Sound Fields” on pages 19, 23, and 24.
Note:
Before activating the Surround or DSP mode, adjust the speaker
setting to bring out the best performance from this system.
For in-depth information about adjusting the speaker setting, see
“Speaker Settings” on pages 16 and 17.
11
Basic VCD/CD Operations
STANDBY/ON
AUDIO
VOLUME
TUNER PRESET
DISPLAY
B.SEARCH
DOWN
REW
UP
FF
F.SEARCH
RETURN
STEP
TV/VIDEO
TV VOLUME
TV CHANNEL
SUBTITLE
TOP MENU
TV
STANDBY/ON
AUDIO
VCR
VCR
CONTROL
TUNER PRESET
ENTER
VOLUME
MENU
AUDIO/
FM MODE
VCR CHANNEL
TUNING
DVD FM/AM AUX
MUTING
123
45
6
78
9
0
REMAIN
PROGRAM
D.R.CZOOM
SETUP
DSP MODE
SLEEP
TEST
PRO LOGIC
SETTING
SOUND
CLEAR
REPEAT
ANGLE
SLOW
SEARCH
A-B REPEAT
PTY –PTY +PTY SEARCH
RDS
DISPLAY
DVD
1
STANDBY/ON
AUDIO
2
Select the Source
Press DVD.
TV
TV/VIDEO
2 DVD
7
7
5
VOLUME –
5
VOLUME +
MUTING
6
DSP MODE
• SVCD can be operated by using the VCD operation
procedure.
• For in-depth information about VCD/CD operations,
see pages 25, 26, and 34 to 39.
4
3/8
3
Load a VCD/CD
On the front panel ONLY:
Press 0 to open the disc tray, then place a disc correctly
with its label side up.
CORRECTINCORRECT
• When using a CD single (8 cm), place it on the inner circle of the
disc tray.
• Continued use of irregular shape CDs (heart-shape, octagonal,
etc.) can damage the center unit.
4
Start Playback
Press 3/8.
The disc tray closes. “LOADING” appears for
a while.
• You can also start playback by closing the
disc tray using 0 on the front panel.
1
Turn On the Power
Before turning on the system, turn on your TV if necessary and
select the correct video input. (See the manual supplied with your
TV.)
• When you use a JVC’s TV, you can turn on your TV by pressing
TV
pressing TV/VIDEO. (If your TV is not a JVC’s, see “Operating
Other Manufacturers’ TV” on page 55.)
• For changing the OSD messages—the information on the TV
screen—into the desired language, see “Setting the Initial
on the remote control, and select the video input by
Languages” on pages 50 and 51.
Press STANDBY/ON
STANDBY/ON
The STANDBY lamp goes off and the illumination
lamp on the center unit lights up. The source
AUDIO (or
on the front panel).
indication selected previously appears on the display.
12
5
Adjust the Volume
To increase the volume, press and hold VOLUME +.
To decrease the volume, press and hold VOLUME –.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing VOLUME + or – repeatedly, you can adjust the volume
level step by step.
• The volume level can be adjusted within 51 steps—
“MIN (minimum),” 01 to 49, and “MAX (maximum).”
To turn off the sounds temporarily
STANDBY/ON
AUDIO
TOP MENU MENU RETURN MUTING
HALLTHEATER
Normal
indication
(canceled)
LIVE CLUB
DANCE CLUB
DSP MODE
TUNER PRESET
From the remote control ONLY:
Press MUTING.
To restore the sound, press
MUTING again.
• Pressing VOLUME + or – also
restores the sound.
7
Stop Playback
Press 7 twice.
Playback stops completely and “VCD” or “CD”
appears on the display. (The DVD player goes
on working for 3 minutes after playback stops.)
• This system can memorize the end point even
when you press 7 once. When you start playback again by
pressing 3/8, playback begins from where it has been stopped—
Resume play.
6
Activate DSP Mode
You can enjoy DSP modes.
DSP modes—THEATER, HALL, LIVE CLUB,
DANCE CLUB
DSP modes take effect only when you enjoy a disc recorded using
Linear PCM—the LINEAR PCM indicator lights up on the display.
Sound signal
indicators on the
display
To activate DSP modes
Press DSP MODE (or DSP on the front panel).
The DSP indicator lights up and the current DSP mode
appears on the display for a while.
• Each time you press the button, DSP mode changes as
follows:
To remove the loaded disc
Press 0.
“OPEN” appears on the display and the disc tray comes out.
To close the disc tray, press 0 again.
• If you do not press the button, the disc tray closes
automatically after 3 minutes.
To turn off the power (into standby)
Press STANDBY/ON AUDIO (or
STANDBY/ON
The illumination lamp goes off and the STANDBY
lamp lights up.
• If you press STANDBY/ON
STANDBY/ON
open, the disc tray closes automatically, then the system is turned
off.
• A small amount of power is consumed even in standby mode. To
turn the power off completely, unplug the AC power cord.
on the front panel).
AUDIO (or
on the front panel) while the disc tray is kept
– For in-depth information about DSP modes, see “Creating
Realistic Sound Fields” on pages 19, 23, and 24.
Note:
Before activating the DSP mode, adjust the speaker setting to bring
out the best performance from this system.
For in-depth information about adjusting the speaker setting, see
“Speaker Settings” on pages 16 and 17.
13
Basic Tuner Operations
STANDBY/ON
AUDIO
FM/AM
DVD player*AUX IN
FMAM
SOURCE
B.SEARCHF.SEARCH
VCR CHANNEL
TUNING
STANDBY/ON
AUDIO
VOLUME
DISPLAY
B.SEARCH
DOWN
REW
UP
FF
F.SEARCH
RETURN
STEP
TV/VIDEO
TV VOLUME
TV CHANNEL
SUBTITLE
TOP MENU
TV
STANDBY/ON
AUDIO
VCR
VCR
CONTROL
TUNER PRESET
ENTER
VOLUME
MENU
AUDIO/
FM MODE
VCR CHANNEL
TUNING
DVD FM/AM AUX
MUTING
RDS
DISPLAY
1
STANDBY/ON
AUDIO
3
Adjust the Volume
To increase the volume, press and hold VOLUME +.
To decrease the volume, press and hold VOLUME –.
2
FM/AM
4
TUNING –
3
VOLUME –
4
TUNING +
3
VOLUME +
MUTING
For in-depth information about tuner operations, see
“Tuner Operations” on pages 44 to 49.
1
Turn On the Power
Press STANDBY/ON AUDIO (or
STANDBY/ON
on the front panel).
The STANDBY lamp goes off and the
illumination lamp lights up on the center unit.
The source indication selected previously appears
on the display.
2
Select the Band
From the remote control:
Press FM/AM.
The last received station of the selected band is tuned into.
• Each time you press the button, the band alternates
between FM and AM.
On the front panel:
Press SOURCE repeatedly until the desired band (FM
or AM) appears on the display.
The last received station of the selected band is tuned into.
• Each time you press the button, the source changes as
follows:
* “WAIT” appears on the display.
CAUTION:
Always set the volume to the minimum before starting any source. If
the volume is set at its high level, the sudden blast of sound energy
can permanently damage your hearing and/or ruin your speakers.
Notes:
• By pressing VOLUME + or – repeatedly, you can adjust the volume
level step by step.
• The volume level can be adjusted within 51 steps—
“MIN (minimum),” 01 to 49, and “MAX (maximum).”
• You can turn off the sounds temporarily by pressing MUTING.
4
Tune into a Station
From the remote control:
Press and hold TUNING + or – until the station frequency starts
changing continuously on
the display.
The system starts searching
for a station.
On the front panel:
1) Press 7 so that “MANUAL” appears on the display.
2) Press and hold ¢ or 4 until the station frequency starts
changing continuously on the display.
The system starts searching for a station.
Notes:
• When a station of sufficient signal strength is tuned in, the system
stops searching, and the indicator lights up on the display.
• When an FM stereo program is received, the indicator also
lights up.
• When you press the button repeatedly, the frequency changes step
by step.
To turn off the power (into standby)
Press STANDBY/ON AUDIO (or
STANDBY/ON
The illumination lamp goes off and the STANDBY
lamp lights up.
• A small amount of power is consumed even in
standby mode. To turn the power off completely, unplug the AC
power cord.
on the front panel) again.
14
Other Basic Operations
10203060
15012090
OFF
(Canceled)
SLEEP
DVD player*AUX IN
FMAM
AUX
SOURCE
SLEEP
SLEEP
DISPLAY
B.SEARCH
DOWN
REW
UP
FF
F.SEARCH
RETURN
STEP
TV/VIDEO
TV VOLUME
TV CHANNEL
SUBTITLE
TOP MENU
TV
STANDBY/ON
AUDIO
VCR
VCR
CONTROL
TUNER PRESET
ENTER
VOLUME
MENU
AUDIO/
FM MODE
VCR CHANNEL
TUNING
DVD FM/AM AUX
MUTING
123
45
6
78
9
0
REMAIN
PROGRAM
D.R.CZOOM
SETUP
DSP MODE
SLEEP
TEST
PRO LOGIC
SETTING
SOUND
CLEAR
REPEAT
ANGLE
SLOW
SEARCH
A-B REPEAT
PTY –PTY +PTY SEARCH
RDS
DISPLAY
PRO LOGIC
3 STEREO
STEREO
(canceled)
PRO LOGIC
AUX
2
Start playback on the external component.
• For in-depth information about the external component, see
the manual supplied for it.
3
Press PRO LOGIC to activate Dolby
Surround.
• Each time you press the button, Dolby Surround
mode changes as follows:
• When Dolby Surround activates, the PRO LOGIC indicator
lights up on the display.
– For in-depth information about Pro Logic modes, see “Creating
Realistic Sound Fields” on pages 18 and 22.
Turning Off the Power with the Timer
PRO LOGIC
SLEEP
Enjoying Sounds from the External
Component
You can enjoy sounds from the external component connected to the
AUX IN jacks on the rear panel of the center unit.
• When you listen to sounds encoded with Dolby Surround, you can
1
enjoy Dolby Surround.
Select AUX as the source.
From the remote control:
Press AUX.
You can fall asleep while listening to music—Sleep Timer.
From the remote control ONLY:
Press SLEEP.
• Each time you press the button, the shut-off time
changes as follows:
When the shut-off time comes, the system turns off automatically.
To check or change the time remaining until the
shut-off time
Press SLEEP once.
The remaining time (in minutes) appears on the display.
• By pressing SLEEP, you can change the shut-off time.
To cancel the Sleep Timer
Press SLEEP repeatedly until “OFF” appears on the
display.
• Turning off the power also cancels the Sleep Timer.
On the front panel:
Press SOURCE repeatedly until “AUX IN”
appears on the display.
• Each time you press the button, the source changes
as follows:
* “WAIT” appears on the display.
15
Speaker Settings
DISPLAY
B.SEARCH
DOWN
REW
UP
FF
F.SEARCH
RETURN
STEP
TV/VIDEO
TV VOLUME
TV CHANNEL
SUBTITLE
TOP MENU
TV
STANDBY/ON
AUDIO
VCR
VCR
CONTROL
TUNER PRESET
ENTER
VOLUME
MENU
AUDIO/
FM MODE
VCR CHANNEL
TUNING
DVD FM/AM AUX
MUTING
123
45
6
78
9
0
REMAIN
PROGRAM
D.R.CZOOM
SETUP
DSP MODE
SLEEP
TEST
PRO LOGIC
SETTING
SOUND
CLEAR
REPEAT
ANGLE
SLOW
SEARCH
A-B REPEAT
RDS
DISPLAY
PTY –PTY +PTY SEARCH
R–DLYC–DLY
Normal indication
(canceled)
ENTER
SETTING
23
Setting the Delay Time
Adjust the delay time of the sounds from the center speaker and the
rear speakers, comparing to that of the sounds from the front
speakers. If the distance to the center speaker* and/or the rear
speakers** from your listening point is almost the same as from the
front speakers, select “00 MS (msec).”
* You can adjust the delay time only when the DOLBY DIGITAL
or DTS indicator is lit on the display.
** You can adjust the delay time only when the DOLBY DIGITAL,
DTS, or PRO LOGIC indicator is lit on the display.
For Dolby Digital or DTS Digital Surround:
Before you start, remember...
There is a time limit in doing the following steps. If the setting is
1
canceled before you finish, start from step
1
Select and play a DVD encoded with Dolby
again.
Digital or DTS Digital Surround.
16
2
SETTING
Press SETTING repeatedly until one of
delay time indications (with the current
PRO LOGIC
setting*) appears on the display.
• Each time you press the button, the indication in the main
display changes as follows:
C–DLY (Center delay) : To register delay time for center
speaker—from 0 msec to 5 msec
R–DLY (Rear delay): To register delay time for rear
speakers—from 0 msec to 15 msec
* The initial setting for the center speaker is “00 MS.”
The initial setting for the rear speakers is “00 MS.”
If you have already changed the setting, a different value will
be shown.
3
Press 3 or 2 to adjust delay
time.
• 3 : Increases delay time.
• 2 : Decreases delay time.
• 1 msec increase (or decrease) in delay
time corresponds to 30 cm increase (or
decrease) in distance.
4
Repeat steps 2 and 3 to adjust the
other delay time.
Loading...
+ 44 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
