JVC XV-NA7SL Parts List

XV-NA7SL

PARTS LIST

[XV-NA7SL]

* All printed circuit boards and its assemblies are not available as service parts.

A ------ Australia B ------ U.K. E ------ Continental Europe EN ---- Northern Europe US ---- Singapore UW --- Brazil, Mexico, Peru

- Contents -

Exploded view of general assembly and parts list DVD Traverse mechanism assembly and parts list DVD Loading mechanism assembly and parts list Electrical parts list Packing materials and accessories parts list

Area Suffix

3-2 3-5 3-7 3-9 3-20

3-1

XV-NA7SL

Exploded view of general assembly and parts list

Block No.

MMM1

BACK SIDE

ain

oard

Grease JVS-1003

3-2

XV-NA7SL

Parts list (General assembly) 1/2

Item

1 LE10272-006A

2 E75896-001

3 LE20638-014A WINDOW SCREEN 1

4 LE20639-004A

5 QYSBSF2608Z

6 LE20640-002A PUSH BUTTON 1

7 LE20641-001A

8 LE31030-002A

9 QYSBSF2608Z

10 LE20646-001A

11 LE20662-001A

12 QYSBSF2608Z

13 QYSDSG3008N T.SCREW 1

14 QUQ110-1336AJ

15 QUQ110-2711AJ

16 QUQ412-1514CJ

17 E3400-431

18 LE10273-002A

19 LE30001-033A

20 E75896-001 FELT SPACER 2

21 QUQ810-1713AJ

22 QQR1349-001

23 QQR1350-001

24 QQR1351-001

25 LV30225-090A

26 QYSBSGG3008E

27 QYSBSGG3008E T.SCREW 1

28 QYSBSGG3008E

29 QYSBSGG3008E

30 -------------------- DVD TRAVERSE ME 1

31 LV41659-201A

32 LV41424-001A

33 --------------------

34 LV10582-001A

35 LV20913-002A

36 LV32417-001A

37 LV42089-002A YOKE 1

38 LV42930-003A

39 LV41741-001A

40 QYSBSF2008Z

41 QUQ110-0610AJ

42 QYSBST3010E

43 LE40874-002A

44 QYSBST3008E T.SCREW 2

45 LE20647-025A

Parts number Parts name Area

FRONT PANEL

LE10272-005A

LE20647-022A

LE20647-023A

FRONT PANEL

FELT SPACER

PUSH BUTTON

T.SCREW

PUSH BUTTON

LED LENS

T.SCREW

BKT

INDICATOR

T.SCREW

FFC WIRE

SPACER

CHASSIS BASE

SPACER

FFC WIRE

FERRITE CORE

SPACER

T.SCREW

INSULATOR

SPECIAL SCREW

1DISC LAODING B

TRAY LONG TYPE

CLAMPER BASE

CLAMPER

MAGNET

SPECIAL SCREW

SCREW

FFC WIRE

T.SCREW

THRUST SPRING

REAR PANEL

Q'ty

Block No. M1MM

Description

A,US,UW

B,E,EN

3-3

XV-NA7SL

Parts list (General assembly) 2/2

Item

45 LE20647-024A

46 QYSBSGY3008M

47 QYSBSGY3008M

48 QYSBSGY3008M SPECIAL SCREW 1

49 QYSBSGY3008M

50 QYSBSGY3008M

51 QYSBSGY3008M SPECIAL SCREW 2

52 QYSBSGY3008M

53 QYSBSGY3008M

54 QYSBSGY3008M

55 QYSBSGY3008M

56 QYSBSGY3008M

57 QMF51E2-1R6-J1

58 QHS3771-108 CORD STOPPER 1

59 QMPG070-244-JC

A A A

60 QZW0004-001

61 LE20645-001A

62 QYSBSGG3008E

63 QYSDSG3008N T.SCREW 2

64 LE31040-001A

65 LE20663-001A

66 LV41843-001A

67 LE31028-001A

Parts number Parts name Area

REAR PANEL

SPECIAL SCREW

FUSE

POWER CORD

QMPN160-200-JD

QMPK190-200-JC

QYSBSE3008Z SCREW

POWER CORD

WIRE CLAMP

METAL COVER

T.SCREW

ORNAMENT

FITTING BASE

LASER CAUTION

LCD LENS

Q'ty

Block No. M1MM

Description

B,E,EN

E,EN,US,UW

3-4

DVD Traverse mechanism assembly and parts list

XV-NA7SL

Grease

EBS0006-013B

PG-641

CFD-4007ZY2

Block No. M M M2

12.0mm 0.2mm

0.2

65.2mm mm

3-5

XV-NA7SL

Parts list (DVD Traverse mechanism assembly)

Item

1 LE20520-002A MECHA BASE 1

2 LE20516-001A SPINDLE BASE 1

3 QYSDST2605M TAPPING SCREW 3

4 LE30909-001A HOLDER 1

5 QAR0165-001 FEED MOTOR 1

6 LV41510-001A FEED GEAR 1

7 QYSPSPU2040M SCREW 2

8 LV41512-001A FEED GEAR 1

9 LV41517-003A LEAD SCREW 1

10 LV41511-002A FEED GEAR 1

11 LE40742-001A TORSION SPRING 1

12 QYSDSF2005Z SCREW 1

13 QYSDST2605M TAPPING SCREW 2

14 LE20517-001A HOLDER 1

15 LE40744-001A SPRING 1

16 LV41121-002A SLIDE SHAFT 2

17 QYSDST2605M TAPPING SCREW 1

18 QAL0342-001 OPTICAL PICK-UP 1

19 LE20519-001A ACTUATOR 1

20 LE30886-001A SPRING 1

21 QYSPSFU1740Z SCREW 2

22 LE30888-003A SPRING 1

23 QYSPSGU1430Z SCREW 1

24 LE40743-001A SPRING 1

25 LE40774-001A PLATE 1

26 QYSDST2606Z SCREW 1

27 QAL0284-001 F.P.C.WIRE ASSY 1

28 QAR0162-001 SPINDLE MOTOR 1

29 QYSPSPU1760Z SCREW 3

30 QYYASPF2608N SCREW 3

Parts number Parts name Area

Q'ty

Block No. M2MM

Description

3-6

DVD Loading mechanism assembly and parts list

Block No. M M M3

Grease

UD-24H2

EM-30L

CFD-4007ZY2

XV-NA7SL

To G of Servo control & A/V output terminal board.

6.85mm 0.1mm

To F of Servo control & A/V output terminal board.

3-7

XV-NA7SL

Parts list (DVD Loading mechanism assembly)

Item

1 LV10454-007A LOADING BASE 1

2 QAR0164-001 MOTOR 1

3 LV42087-001A MOTOR PULLEY 1

4 QYSPSPU1730Z SCREW 1

5 VKZ4777-003 MINI SCREW 1

6 LV42209-001A BELT 1

7 LV42084-002A PULLEY GEAR 1

8 LV42085-002A MIDDLE GEAR 1

9 LV42086-001A IDLE GEAR 1

10 LV32514-002A SLIDE CAM 1

11 LV42348-001A GEAR BRACKET 1

12 VKZ4777-003 MINI SCREW 1

13 LV20912-002A ELEVATOR 1

14 QUQ110-0610AJ FFC WIRE 1

Electrical parts list (Loading motor board)

Item

CN 1

Parts number Parts name Area

QGF1016F3-06

QSW0910-002

S 1

QSW0910-002

S 2

Parts number Parts name Area

Remarks

CONNECTOR

SWITCH

Block No. 04

Q'ty

Block No. M3MM

Description

3-8

XV-NA7SL

Electrical parts list (Servo control board)

Item

C 105 NEA70JM-476X E.CAPACITOR

C 106 NEA70JM-476X E.CAPACITOR

C 109 NCB31CK-104X C CAPACITOR

C 110 NCS31HJ-221X C.CAPA. C.M

C 111 NCB31CK-104X C CAPACITOR

C 112 NCB31CK-104X C CAPACITOR

C 113 NEA70JM-226X E CAPACITOR

C 115 NCB31CK-104X C CAPACITOR

C 116 NCB31CK-104X C CAPACITOR

C 117 NCB31CK-473X C CAPACITOR

C 118 NCB31CK-273X C CAPACITOR

C 119 NCB31HK-561X C CAPACITOR

C 120 NCB31HK-561X C CAPACITOR

C 121 NCB31CK-104X C CAPACITOR

C 122 NCS31HJ-120X C.CAPA. C.M

C 123 NCB31CK-104X C CAPACITOR

C 124 NCS31HJ-470X C.CAPA. C.M

C 125 NCB31HK-271X C CAPACITOR

C 126 NCB31CK-104X C CAPACITOR

C 127 NCB31CK-104X C CAPACITOR

C 128 NCB31CK-104X C CAPACITOR

C 129 NCB31HK-472X C CAPACITOR

C 135 NEA70JM-476X E.CAPACITOR

C 137 NEA70GM-476X E.CAPA. C.M.

C 138 NCB31CK-104X C CAPACITOR

C 139 NCB31CK-104X C CAPACITOR

C 141 NCB31CK-104X C CAPACITOR

C 142 NCB31CK-104X C CAPACITOR

C 143 NCB31CK-104X C CAPACITOR

C 144 NCB31CK-103X C CAPACITOR

C 146 NCB31CK-104X C CAPACITOR

C 201 NEA70JM-226X E CAPACITOR

C 203 NCB31CK-104X C CAPACITOR

C 204 NCB31CK-104X C CAPACITOR

C 205 NCS31HJ-121X C CAPACITOR

C 207 NCB31HK-391X C CAPACITOR

C 208 NCB31HK-391X C CAPACITOR

C 211 NCB31HK-223X C CAPACITOR

C 212 NCB31CK-103X C CAPACITOR

C 216 NCB30JK-105X C CAPACITOR

C 217 NCB31CK-104X C CAPACITOR

C 218 NCB30JK-105X C CAPACITOR

C 251 NCB31CK-104X C CAPACITOR

C 252 NEA71AM-336X E CAPACITOR

C 253 NCB31CK-104X C CAPACITOR

C 255 NCB31CK-153X C CAPACITOR

C 256 NCB31CK-104X C CAPACITOR

C 257 NCB31CK-104X C CAPACITOR

C 258 NCB31CK-104X C CAPACITOR

C 259 NCB31CK-104X C CAPACITOR

C 260 NCB31CK-104X C CAPACITOR

C 261 NCB31CK-104X C CAPACITOR

C 262 NCB31CK-104X C CAPACITOR

C 263 NCB31CK-104X C CAPACITOR

C 264 NCB31CK-103X C CAPACITOR

C 301 NCB31CK-104X C CAPACITOR

C 302 NCB31CK-104X C CAPACITOR

C 303 NCB31CK-104X C CAPACITOR

C 304 NEA70GM-107X E CAPACITOR

C 306 NEA70GM-107X E CAPACITOR

C 308 NEA70GM-107X E CAPACITOR

C 310 NCB31CK-104X C CAPACITOR

C 311 NCB31HK-561X C CAPACITOR

C 312 NCB31HK-561X C CAPACITOR

C 313 NCB31HK-561X C CAPACITOR

C 314 NCB31HK-331X C CAPACITOR

Parts numbe

Parts name Area

Block No. 01

Remarks

Item

C 315 NCB31HK-471X C CAPACITOR

C 316 NCB31HK-271X C CAPACITOR

C 317 NCS31HJ-121X C CAPACITOR

C 318 NCB31CK-104X C CAPACITOR

C 319 NCB31HK-102X C CAPACITOR

C 320 NCB31HK-102X C CAPACITOR

C 321 NCB31HK-102X C CAPACITOR

C 322 NCB31HK-562X C CAPACITOR

C 323 NCB31HK-102X C CAPACITOR

C 324 NCB31CK-104X C CAPACITOR

C 325 NCS31HJ-470X C.CAPA. C.M

C 326 NCB31CK-183X C CAPACITOR

C 327 NCB31CK-102X C.CAPA. C.M

C 328 NCB31CK-104X C CAPACITOR

C 329 NCB31CK-103X C CAPACITOR

C 330 NCB31CK-104X C CAPACITOR

C 331 NCB31CK-103X C CAPACITOR

C 332 NCB21CK-105X C CAPACITOR

C 333 NCB31CK-104X C CAPACITOR

C 334 NCB31CK-104X C CAPACITOR

C 337 NCB31CK-104X C CAPACITOR

C 338 NCB31CK-104X C CAPACITOR

C 339 NCB31CK-104X C CAPACITOR

C 340 NCB31CK-104X C CAPACITOR

C 341 NCB31CK-104X C CAPACITOR

C 342 NCB31CK-104X C CAPACITOR

C 343 NCB31CK-104X C CAPACITOR

C 344 NCB31CK-104X C CAPACITOR

C 345 NCB31CK-104X C CAPACITOR

C 346 NCB31CK-104X C CAPACITOR

C 347 NCB31CK-104X C CAPACITOR

C 348 NCB31CK-104X C CAPACITOR

C 349 NCB31CK-104X C CAPACITOR

C 350 NCB31CK-104X C CAPACITOR

C 401 NEA70GM-476X E.CAPA. C.M.

C 402 NCB31CK-104X C CAPACITOR

C 403 NCB31CK-104X C CAPACITOR

C 404 NCB31CK-104X C CAPACITOR

C 405 NCB31CK-104X C CAPACITOR

C 406 NCB31CK-104X C CAPACITOR

C 407 NCB31CK-104X C CAPACITOR

C 450 NCB31CK-104X C CAPACITOR

C 500 NEA70JM-476X E.CAPACITOR

C 501 NCB31CK-104X C CAPACITOR

C 502 NEA70JM-476X E.CAPACITOR

C 503 NEA71AM-336X E CAPACITOR

C 504 NEA70JM-476X E.CAPACITOR

C 505 NEA70JM-476X E.CAPACITOR

C 506 NDC31HJ-150X C CAPACITOR

C 507 NDC31HJ-180X C.CAPACITOR

C 508 NEA70JM-476X E.CAPACITOR

C 511 NEA70GM-476X E.CAPA. C.M.

C 512 NCB31CK-104X C CAPACITOR

C 514 NCB31CK-104X C CAPACITOR

C 515 NCB31CK-104X C CAPACITOR

C 516 NCB31CK-104X C CAPACITOR

C 517 NCB31CK-104X C CAPACITOR

C 518 NCB31CK-104X C CAPACITOR

C 519 NCB31CK-104X C CAPACITOR

C 520 NCB31CK-104X C CAPACITOR

C 521 NCB31CK-104X C CAPACITOR

C 523 NCB31CK-104X C CAPACITOR

C 524 NEA70GM-476X E.CAPA. C.M.

C 527 NEA70GM-476X E.CAPA. C.M.

C 528 NCB31CK-104X C CAPACITOR

C 529 NCB31CK-104X C CAPACITOR

Parts numbe

Parts name Area

Remarks

3-9

XV-NA7SL

Electrical parts list (Servo control board)

Item

Parts numbe

C 531 NCB31CK-104X C CAPACITOR

C 532 NCB31CK-104X C CAPACITOR

C 533 NCB31CK-104X C CAPACITOR

C 534 NCB31CK-104X C CAPACITOR

C 535 NCB31CK-104X C CAPACITOR

C 536 NCB31CK-104X C CAPACITOR

C 539 NCB31CK-104X C CAPACITOR

C 540 NCB31CK-104X C CAPACITOR

C 541 NCB31CK-104X C CAPACITOR

C 542 NCB31CK-104X C CAPACITOR

C 543 NCB31CK-104X C CAPACITOR

C 544 NCB31CK-104X C CAPACITOR

C 545 NCB31CK-104X C CAPACITOR

C 547 NCB31CK-104X C CAPACITOR

C 548 NCB31CK-104X C CAPACITOR

C 549 NEA70GM-476X E CAPACITOR

C 550 NCB31CK-104X C CAPACITOR

C 551 NCB31CK-103X C CAPACITOR

C 554 NCB31CK-104X C CAPACITOR

C 557 NCB31CK-104X C CAPACITOR

C 569 NCB31CK-104X C CAPACITOR

C 571 NEA70GM-476X E CAPACITOR

C 572 NCB31CK-104X C CAPACITOR

C 573 NEA70GM-227X E CAPACITOR

C 578 NCB31CK-104X C CAPACITOR

C 580 NEA70GM-476X E CAPACITOR

C 581 NEA70GM-227X E CAPACITOR

C 582 NEA70GM-476X E CAPACITOR

C 590 NCB31CK-104X C CAPACITOR

C 591 NCB31CK-104X C CAPACITOR

C 592 NCB31CK-104X C CAPACITOR

C 593 NCB31CK-104X C CAPACITOR

C 594 NCB31CK-104X C CAPACITOR

C 595 NCB31CK-104X C CAPACITOR

C 601 NEA70GM-476X E CAPACITOR

C 602 NEA70GM-476X E CAPACITOR

C 619 NCB31CK-104X C CAPACITOR

C 700 QEXT0JM-157Z E CAPACITOR 150MF 20% 6.3V

C 701 NCB31HK-152X C CAPACITOR

C 705 NCB31CK-104X C CAPACITOR

C 707 QETN1AM-107Z E CAPACITOR

C 710 NCS31HJ-102X C CAPACITOR

C 711 QCZ0202-155Z ML C CAPACITOR

C 714 QTE1A28-477Z E CAPACITOR

C 716 QTE1A28-477Z E CAPACITOR

C 717 QCZ0202-155Z ML C CAPACITOR

C 730 QFV21HJ-224Z MF CAPACITOR .22MF 5% 50V

C 731 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 735 NCB31CK-104X C CAPACITOR

C 740 QFLC1HJ-561Z M CAPACITOR

C 741 QFP31HJ-121Z PP CAPACITOR

C 742 QFLC1HJ-182Z M CAPACITOR

C 743 QFLC1HJ-272Z M CAPACITOR

C 744 QFLC1HJ-561Z M CAPACITOR

C 745 QFLC1HJ-103Z M CAPACITOR

C 746 QTE1A48-476Z E CAPACITOR

C 747 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 748 QFLC1HJ-561Z M CAPACITOR 560PF 5% 50V

C 749 QFLC1HJ-561Z M CAPACITOR 560PF 5% 50V

C 750 QFLC1HJ-561Z M CAPACITOR

C 751 QFP31HJ-121Z PP CAPACITOR

C 752 QFLC1HJ-182Z M CAPACITOR

C 753 QFLC1HJ-272Z M CAPACITOR

C 754 QFLC1HJ-561Z M CAPACITOR

C 755 QFLC1HJ-103Z M CAPACITOR

C 756 QTE1A48-476Z E CAPACITOR

Parts name Area

Block No. 01

100MF 20% 10V

1.5MF

560PF 5% 50V

120PF 5% 50V

1800PF 5% 50V

2700PF 5% 50V

560PF 5% 50V

.010MF 5% 50V

560PF 5% 50V

120PF 5% 50V

1800PF 5% 50V

2700PF 5% 50V

560PF 5% 50V

.010MF 5% 50V

Remarks

Item

Parts numbe

C 757 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V

C 761 QTE1C28-107Z E CAPACITOR

C 762 QTE1C28-107Z E CAPACITOR

C 771 QTE1C28-107Z E CAPACITOR

C 772 QTE1C28-107Z E CAPACITOR

C 797 NCB31HK-152X C CAPACITOR

C 801 NCS31HJ-680X C CAPACITOR

C 802 NCS31HJ-680X C CAPACITOR

C 803 NCS31HJ-120X C CAPACITOR C

C 804 NCS31HJ-681X C CAPACITOR C

C 805 NCS31HJ-560X C CAPACITOR C

C 806 NCS31HJ-151X C CAPACITOR

C 807 NCS31HJ-120X C CAPACITOR

C 808 NCS31HJ-121X C CAPACITOR

C 809 NCB31HK-272X C CAPACITOR

C 810 NCB31HK-123X C CAPACITOR

C 811 NCB31CK-104X C CAPACITOR

C 812 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 813 QETN0JM-227Z E CAPACITOR 220MF 20% 6.3V

C 814 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 815 QETN0JM-227Z E CAPACITOR 220MF 20% 6.3V

C 816 QETN1AM-226Z E CAPACITOR

C 817 QETN1AM-226Z E CAPACITOR

C 818 NCB21CK-105X C CAPACITOR

C 819 QETN1AM-226Z E CAPACITOR

C 831 NCB21CK-105X C CAPACITOR

C 832 NCB21CK-105X C CAPACITOR

C 833 NCB31HK-103X C CAPACITOR

C 834 NCB31CK-104X C CAPACITOR

C 835 NCB31CK-104X C CAPACITOR

C 836 NCB31CK-103X C CAPACITOR

C 851 QETN1AM-107Z E CAPACITOR

C 853 NCB31CK-104X C CAPACITOR

C 856 QETN0JM-227Z E CAPACITOR

C 858 QETN0JM-227Z E CAPACITOR

C 859 QETN1AM-226Z E CAPACITOR

C 860 QETN0JM-227Z E CAPACITOR 220MF 20% 6.3V

C 865 NCB31CK-103X C CAPACITOR

C 992 NCB31CK-104X C CAPACITOR

C 993 NCB31CK-104X C CAPACITOR

C 994 NCB31CK-104X C CAPACITOR

C 995 NCB31CK-104X C CAPACITOR

C 996 NCB31CK-104X C CAPACITOR

C 997 NCB31CK-104X C CAPACITOR

C 998 NCB31CK-104X C CAPACITOR

C1701 QETN1EM-476Z E CAPACITOR

C1702 QETN1EM-475Z E CAPACITOR 4.7MF 20% 25V

C1703 NCS31HJ-151X C CAPACITOR

C1704 NCS31HJ-331X C CAPACITOR

C1706 NCB31CK-104X C CAPACITOR

CN101 QGF0523F1-30W FFC/FPC CONNE

CN201 QGF1037F1-15W CONNECTOR

CN202 QGF1037F1-06W W TO B CONNE

CN511 QGF1016C1-27 CONNECTOR

CN704 QGF1016C2-17W CONNECTOR

CN801 QGF1205C1-15 CONNECTOR B,E,ENE

D 101 RB521S-30 MG RESISTOR

FW901 QUM138-08DGZ4 PARA RIBON WI RE

FW903 QUM134-08DGZ4 PARA RIBON WI RE

IC101 AN8703FH-V IC

IC201 BA5983FM-X IC

IC251 BA6664FM-X LSI

IC301 MN103S26EGA IC

IC401 MN102L62GLF3 IC

IC451 S-93C66AFJ-X IC

IC501 NDV8611VWA IC

Parts name Area

22MF 20% 10V

100MF 20% 10V

220MF 20% 6.3V

22MF 20% 10V

47MF 20% 25V

SP&STP

LOADER

REAR/CNTR/SW

Remarks

3-10

XV-NA7SL

Electrical parts list (Servo control board)

Item

Parts numbe

IC505 K4S643232E-TC60 IC

IC509 SST39VF160-9CEK IC (FLASH)

IC510 S-93C66AFJ-X IC

IC511 LM1117MP1.8-X IC

IC512 74LCX373MTC-X IC(DIGITAL)

IC513 74LCX373MTC-X IC(DIGITAL)

IC522 74LCX32MTC-X IC(DIGITAL)

IC523 NC7SZ125P5-X IC(DIGITAL)

IC703 MN35505-X IC C M

IC704 TC74HC08AF-X IC

IC741 NJM5532L IC

IC751 NJM5532L IC

IC801 MM1568CJ-X IC

J 700 QNN0513-001 PIN JACK

J 701 QNN0458-001 PIN JACK

J 703 GP1FA351TZ OPT TRANSMITTER

J 801 QNN0395-001 PIN JACK

J 802 QNN0454-001 PIN JACK S/COMP. ALL

K 101 NQR0007-002X FERRITE BEADS

K 301 NQR0007-002X FERRITE BEADS

K 302 NQR0007-002X FERRITE BEADS

K 303 NQR0007-002X FERRITE BEADS

K 304 NQR0007-002X FERRITE BEADS

K 401 NQR0007-002X FERRITE BEADS

K 501 NQR0007-002X FERRITE BEADS

K 502 NRSA02J-0R0X MG RESISTOR

K 503 NRSA02J-0R0X MG RESISTOR

K 504 NQR0007-002X FERRITE BEADS

K 507 NQR0007-002X FERRITE BEADS

K 508 NQR0007-002X FERRITE BEADS

K 509 NQR0007-002X FERRITE BEADS

K 510 NQR0007-002X FERRITE BEADS

K 513 NQR0007-002X FERRITE BEADS

K 515 NQR0007-002X FERRITE BEADS

K 518 NQR0007-002X FERRITE BEADS

K 519 NQR0007-002X FERRITE BEADS

K 520 NQR0007-002X FERRITE BEADS

K 556 NQR0007-002X FERRITE BEADS

K 557 NQR0007-002X FERRITE BEADS

K 558 NQR0007-002X FERRITE BEADS

K 559 NQR0007-002X FERRITE BEADS

K 560 NQR0007-002X FERRITE BEADS

K 561 NQR0007-002X FERRITE BEADS

K 563 NQR0007-002X FERRITE BEADS

K 564 NQR0007-002X FERRITE BEADS

K 566 NQR0007-002X FERRITE BEADS

K 567 NQR0007-002X FERRITE BEADS

K 569 NQR0007-002X FERRITE BEADS

K 570 NQR0007-002X FERRITE BEADS

K 571 NQR0007-002X FERRITE BEADS

K 572 NQR0007-002X FERRITE BEADS

K 573 NQR0007-002X FERRITE BEADS

K 574 NQR0007-002X FERRITE BEADS

K 575 NQR0007-002X FERRITE BEADS

K 576 NQR0007-002X FERRITE BEADS

K 577 NQR0007-002X FERRITE BEADS

K 579 NQR0007-002X FERRITE BEADS

K 582 NQR0007-002X FERRITE BEADS

K 586 NQR0007-002X FERRITE BEADS

K 701 NQR0007-002X FERRITE BEADS

K 702 NQR0007-002X FERRITE BEADS

K 703 NQR0007-002X FERRITE BEADS

K 704 NQR0007-002X FERRITE BEADS

K 705 NQR0227-004X FERRITE BEADS

K 706 NQR0227-004X FERRITE BEADS

K 711 NQR0007-002X FERRITE BEADS

Parts name Area

FRONT L/R

COAXIAL

OPT DIGITAL OUT

COMPONENT ALL

Block No. 01

Remarks

Item

Parts numbe

K 801 NQR0007-002X FERRITE BEADS

K 802 NQR0007-002X FERRITE BEADS

K1701 NQR0227-004X FERRITE BEADS

L 501 NQL044K-100X INDUCTOR

L 502 NQL044K-100X INDUCTOR

L 503 NQL044K-100X INDUCTOR

L 801 QQR1089-001 LPF

L 802 QQR1088-001 LPF

L 803 QQR1088-001 LPF

L 804 QQR1088-001 LPF

L1701 QQL231K-1R0Y INDUCTOR

Q 101 KTA1001/Y/-X TRANSISTOR

Q 102 KTA1001/Y/-X TRANSISTOR

Q 103 DTA144EE-X DIGI TRANSISTOR

Q 704 KRC109S-X TRANSISTOR

Q 705 KRA102S-X DIGITAL.TR

Q 706 KRA102S-X DIGITAL.TR

Q 743 2SC3576-JVC-T TRANSISTOR I/M LR MUTE

Q 753 2SC3576-JVC-T TRANSISTOR I/M LR MUTE

Q 755 2SC3576-JVC-T TRANSISTOR I/M NA7 ONL

Q 756 2SC3576-JVC-T TRANSISTOR I/M NA7 ONL

Q 791 2SC2412K/RS/-X CHIP TRANSISTOR

Q 801 2SC4617/R/-X TRANSISTOR

Q 802 2SA1774/R/-X TRANSISTOR

Q 803 2SC4617/R/-X TRANSISTOR

Q 804 2SC4617/R/-X TRANSISTOR

Q 805 2SC4617/R/-X TRANSISTOR

Q 806 2SC4617/R/-X TRANSISTOR C

Q 807 DTC114EE-X RANSISTOR C

Q 808 2SC4617/R/-X TRANSISTOR C

Q 821 KRC102S-X DIGITAL.TR

Q 822 KRC102S-X DIGITAL.TR

Q 825 DTA114EK-X TRANSISTOR

Q 826 DTC114EKA-X TRANSISTOR

Q 828 KRA121S-X DIGITAL.TR

R 101 NRSA63J-333X MG RESISTOR

R 102 NRSA63J-223X MG RESISTOR

R 103 NRSA63J-223X MG RESISTOR

R 104 NRS125J-270X MG RESISTOR

R 105 NRS125J-270X MG RESISTOR

R 106 NRSA63J-273X MG RESISTOR

R 107 NRSA63J-273X MG RESISTOR

R 108 NRSA63J-222X MG RESISTOR

R 109 NRSA63J-182X MG RESISTOR

R 110 NRSA63J-333X MG RESISTOR

R 111 NRVA63D-243X RES. C.M

R 112 NRSA63J-822X MG RESISTOR

R 113 NRSA63J-103X MG RESISTOR

R 114 NRSA63J-0R0X MG RESISTOR

R 115 NRSA63J-0R0X MG RESISTOR

R 116 NRSA63J-0R0X MG RESISTOR

R 117 NRSA63J-0R0X MG RESISTOR

R 119 NRSA63J-2R2X MG RESISTOR

R 120 NRSA63J-2R2X MG RESISTOR

R 121 NRSA63J-472X MG RESISTOR

R 125 NRSA63J-105X MG RESISTOR

R 126 NRSA63J-105X MG RESISTOR

R 127 NRSA63J-222X MG RESISTOR

R 128 NRS125J-1R0X MG RESISTOR

R 129 NRS125J-1R0X MG RESISTOR

R 130 NRSA63J-182X MG RESISTOR

R 201 NRSA63J-470X MG RESISTOR

R 202 NRS125J-1R0X MG RESISTOR

R 203 NRSA63J-0R0X MG RESISTOR

R 204 NRSA63J-273X MG RESISTOR

R 205 NRSA63J-273X MG RESISTOR

Parts name Area

Remarks

NA7 ONL

A,US,UW

B,E,EN

3-11

XV-NA7SL

Electrical parts list (Servo control board)

Item

R 206 NRSA63J-303X MG RESISTOR

R 207 NRSA63J-473X MG RESISTOR

R 208 NRSA63J-223X MG RESISTOR

R 209 NRSA63J-223X MG RESISTOR

R 210 NRSA63J-242X MG RESISTOR

R 211 NRSA63J-242X MG RESISTOR

R 212 NRSA63J-103X MG RESISTOR

R 213 NRSA63J-103X MG RESISTOR

R 214 NRSA63J-103X MG RESISTOR

R 215 NRSA63J-103X MG RESISTOR

R 216 NRSA63J-912X MG RESISTOR

R 219 NRSA63J-183X MG RESISTOR

R 220 NRSA63J-243X MG RESISTOR

R 221 NRSA63J-682X MG RESISTOR

R 222 NRSA63J-103X MG RESISTOR

R 223 NRSA63J-912X MG RESISTOR

R 224 NRSA63J-103X MG RESISTOR

R 251 NRS125J-R47X MG RESISTOR

R 252 NRSA63J-2R2X MG RESISTOR

R 253 NRSA63J-0R0X MG RESISTOR

R 254 NRSA63J-203X MG RESISTOR

R 255 NRSA63J-103X MG RESISTOR

R 256 NRSA63J-470X MG RESISTOR

R 258 NRSA63J-0R0X MG RESISTOR

R 259 NRSA63J-103X MG RESISTOR

R 301 NRSA63J-473X MG RESISTOR

R 302 NRSA63J-473X MG RESISTOR

R 303 NRSA63J-473X MG RESISTOR

R 304 NRSA63J-473X MG RESISTOR

R 305 NRSA63J-473X MG RESISTOR

R 306 NRSA63J-473X MG RESISTOR

R 307 NRSA63J-473X MG RESISTOR

R 308 NRSA63J-0R0X MG RESISTOR

R 309 NRSA63J-473X MG RESISTOR

R 313 NRSA63J-473X MG RESISTOR

R 317 NRSA63J-473X MG RESISTOR

R 319 NRSA63J-473X MG RESISTOR

R 320 NRSA63J-105X MG RESISTOR C

R 321 NRSA63J-473X MG RESISTOR

R 323 NRSA63J-473X MG RESISTOR

R 324 NRSA63J-473X MG RESISTOR

R 325 NRSA63J-123X MG RESISTOR

R 326 NRSA63J-473X MG RESISTOR

R 327 NRSA63J-105X MG RESISTOR

R 328 NRSA63J-183X MG RESISTOR

R 329 NRSA63J-473X MG RESISTOR

R 332 NRSA63J-102X MG RESISTOR

R 333 NRSA63J-183X MG RESISTOR

R 334 NRSA63J-102X MG RESISTOR

R 336 NRSA63J-273X MG RESISTOR

R 337 NRSA63J-273X MG RESISTOR

R 338 NRSA63J-472X MG RESISTOR

R 339 NRSA63J-472X MG RESISTOR

R 340 NRSA63J-103X MG RESISTOR

R 341 NRSA63J-562X MG RESISTOR

R 350 NRSA63J-0R0X MG RESISTOR

R 402 NRSA63J-472X MG RESISTOR

R 403 NRSA63J-0R0X MG RESISTOR C

R 405 NRSA63J-0R0X MG RESISTOR C

R 411 NRSA63J-472X MG RESISTOR

R 413 NRSA63J-472X MG RESISTOR

R 414 NRSA63J-472X MG RESISTOR

R 421 NRSA63J-0R0X MG RESISTOR

R 422 NRSA63J-472X MG RESISTOR

R 423 NRSA63J-472X MG RESISTOR

R 424 NRSA63J-472X MG RESISTOR

Parts numbe

Parts name Area

Block No. 01

Remarks

Item

R 427 NRSA63J-102X MG RESISTOR

R 428 NRSA63J-472X MG RESISTOR

R 501 NRSA63J-470X MG RESISTOR

R 510 NRSA63J-0R0X MG RESISTOR

R 511 NRSA63J-0R0X MG RESISTOR

R 512 NRSA63J-332X MG RESISTOR

R 519 NRSA63J-0R0X MG RESISTOR

R 520 NRSA63J-0R0X MG RESISTOR

R 521 NRSA63J-103X MG RESISTOR

R 541 NRSA63J-0R0X MG RESISTOR

R 543 NRSA63J-0R0X MG RESISTOR

R 544 NRSA63J-471X MG RESISTOR

R 545 NRSA63J-0R0X MG RESISTOR

R 546 NRSA63J-0R0X MG RESISTOR

R 547 NRSA63J-0R0X MG RESISTOR

R 548 NRSA63J-471X MG RESISTOR

R 549 NRSA63J-471X MG RESISTOR

R 550 NRSA63J-471X MG RESISTOR

R 551 NRSA63J-0R0X MG RESISTOR

R 552 NRSA63J-0R0X MG RESISTOR

R 553 NRSA63J-0R0X MG RESISTOR

R 565 NRVA63D-622X CMF RESISTOR

R 566 NRVA63D-132X MG RESISTOR

R 567 NRVA63D-750X RES. C.M

R 568 NRVA63D-750X RES. C.M

R 569 NRVA63D-750X RES. C.M

R 570 NRSA63J-100X MG RESISTOR

R 572 NRVA63D-750X RES. C.M

R 573 NRSA63J-162X MG RESISTOR

R 574 NRSA63J-162X MG RESISTOR

R 575 NRSA63J-151X MG RESISTOR

R 576 NRSA63J-151X MG RESISTOR

R 578 NRSA63J-151X MG RESISTOR

R 579 NRSA63J-151X MG RESISTOR

R 580 NRSA63J-151X MG RESISTOR

R 583 NRSA63J-101X MG RESISTOR

R 584 NRSA63J-332X MG RESISTOR

R 589 NRSA63J-0R0X MG RESISTOR

R 655 NRSA63J-0R0X MG RESISTOR

R 700 NRSA63J-105X MG RESISTOR

R 701 NRSA63J-103X MG RESISTOR

R 702 NRSA63J-105X MG RESISTOR

R 703 NRSA63J-103X MG RESISTOR

R 704 NRSA63J-0R0X MG RESISTOR

R 706 NRSA63J-104X MG RESISTOR

R 711 NRSA63J-100X MG RESISTOR

R 712 NRSA63J-100X MG RESISTOR

R 713 NRSA63J-470X MG RESISTOR

R 715 NRSA63J-470X MG RESISTOR

R 721 NRSA63J-471X MG RESISTOR

R 723 NRSA63J-471X MG RESISTOR

R 724 NRSA63J-471X MG RESISTOR

R 725 NRSA63J-471X MG RESISTOR

R 726 NRSA63J-220X MG RESISTOR

R 728 NRSA63J-471X MG RESISTOR

R 729 NRSA63J-471X MG RESISTOR

R 731 NRSA63J-332X MG RESISTOR

R 738 NRSA63J-152X MG RESISTOR

R 739 NRSA63J-0R0X MG RESISTOR

R 740 NRSA63J-0R0X MG RESISTOR

R 742 QRA14CF-1802Y MF RESISTOR

R 743 QRA14CF-1802Y MF RESISTOR

R 744 NRSA63J-362X MG RESISTOR

R 746 QRA14CF-3301Y MF RESISTOR

R 747 NRSA63J-362X MG RESISTOR

R 748 NRSA63J-621X MG RESISTOR

Parts numbe

Parts name Area

Remarks

B,E,EN

A,US,UW

18 1/4W

33 1/4W

3-12

XV-NA7SL

Electrical parts list (Servo control board)

Item

Parts numbe

R 750 NRSA63J-273X MG RESISTOR

R 751 NRSA63J-273X MG RESISTOR

R 752 QRA14CF-1802Y MF RESISTOR

R 753 QRA14CF-1802Y MF RESISTOR

R 754 NRSA63J-362X MG RESISTOR

R 756 QRA14CF-3301Y MF RESISTOR

R 757 NRSA63J-362X MG RESISTOR

R 758 NRSA63J-621X MG RESISTOR

R 761 NRSA63J-621X MG RESISTOR

R 762 QRE141J-821Y C RESISTOR 820 5% 1/4W

R 763 NRSA63J-362X MG RESISTOR

R 764 NRSA63J-183X MG RESISTOR

R 765 NRSA63J-561X MG RESISTOR

R 766 NRSA63J-273X MG RESISTOR

R 767 NRSA63J-101X MG RESISTOR

R 768 NRSA63J-103X MG RESISTOR

R 771 NRSA63J-621X MG RESISTOR

R 772 QRE141J-821Y C RESISTOR 820 5% 1/4W

R 773 NRSA63J-362X MG RESISTOR

R 774 NRSA63J-183X MG RESISTOR

R 775 NRSA63J-561X MG RESISTOR

R 776 NRSA63J-273X MG RESISTOR

R 777 NRSA63J-101X MG RESISTOR

R 778 NRSA63J-103X MG RESISTOR

R 779 NRSA63J-0R0X MG RESISTOR

R 780 NRSA63J-273X MG RESISTOR

R 781 NRSA63J-273X MG RESISTOR

R 782 NRSA63J-221X MG RESISTOR

R 783 NRSA63J-221X MG RESISTOR

R 785 NRSA63J-0R0X MG RESISTOR

R 789 NRSA63J-104X MG RESISTOR

R 792 NRSA63J-221X MG RESISTOR

R 793 NRSA63J-221X MG RESISTOR

R 794 NRSA63J-473X MG RESISTOR

R 795 NRSA63J-473X MG RESISTOR

R 796 NRSA63J-103X MG RESISTOR

R 797 NRSA63J-473X MG RESISTOR

R 798 NRSA63J-473X MG RESISTOR

R 800 NRSA63J-750X MG RESISTOR

R 801 NRSA63J-822X MG RESISTOR C

R 802 NRSA63J-153X MG RESISTOR

R 803 NRSA63J-122X MG RESISTOR

R 804 NRSA63J-821X MG RESISTOR

R 805 NRSA63J-242X MG RESISTOR

R 806 NRSA63J-821X MG RESISTOR

R 807 NRSA63J-152X MG RESISTOR

R 808 NRSA63J-102X MG RESISTOR C

R 809 NRSA63J-123X MG RESISTOR C

R 810 NRSA63J-152X MG RESISTOR C

R 811 NRSA63J-103X MG RESISTOR

R 812 NRSA63J-103X MG RESISTOR

R 813 NRSA63J-103X MG RESISTOR

R 814 NRSA63J-103X MG RESISTOR

R 815 NRSA63J-821X MG RESISTOR

R 816 NRSA63J-820X MG RESISTOR

R 817 NRSA63J-102X MG RESISTOR C

R 818 NRSA63J-102X MG RESISTOR C

R 825 NRSA63J-750X MG RESISTOR A,US,UWD

R 827 NRSA63J-0R0X MG RESISTOR

R 828 NRSA63J-750X MG RESISTOR

R 829 NRSA63J-750X MG RESISTOR

R 831 NRSA63J-0R0X MG RESISTOR

R 832 NRSA63J-0R0X MG RESISTOR

R 833 NRSA63J-0R0X MG RESISTOR

R 836 NRSA63J-0R0X MG RESISTOR

R 837 NRSA63J-0R0X MG RESISTOR A,US,UWU

Parts name Area

18 1/4W

33 1/4W

Block No. 01

Remarks

A,US,UW

B,E,EN

A,US,UW

Item

Parts numbe

R 838 NRSA63J-750X MG RESISTOR

R 839 NRSA63J-750X MG RESISTOR

R 843 NRSA63J-750X MG RESISTOR

R 844 NRSA63J-222X MG RESISTOR

R 845 NRSA63J-0R0X MG RESISTOR

R 846 NRSA63J-0R0X MG RESISTOR

R 847 NRSA63J-0R0X MG RESISTOR

R 850 NRSA63J-0R0X MG RESISTOR

R 851 NRSA63J-223X MG RESISTOR

R 852 NRSA63J-223X MG RESISTOR

R 853 NRSA63J-0R0X MG RESISTOR B,E,ENE

R 854 NRSA63J-0R0X MG RESISTOR

R 855 NRSA63J-104X MG RESISTOR

R 856 NRSA63J-102X MG RESISTOR

R 857 NRSA63J-102X MG RESISTOR

R 858 NRSA63J-0R0X MG RESISTOR

R 859 NRSA63J-0R0X MG RESISTOR

R 861 NRSA63J-0R0X MG RESISTOR

R 862 NRSA63J-332X MG RESISTOR B,E,ENE

R 863 NRSA63J-102X MG RESISTOR E/U

R 866 NRSA63J-0R0X MG RESISTOR

R 872 NRSA63J-820X MG RESISTOR

R 874 NRSA63J-102X MG RESISTOR

R 875 NRSA63J-750X MG RESISTOR

R 877 NRSA63J-102X MG RESISTOR

R 878 NRSA63J-750X MG RESISTOR

R 880 NRSA63J-102X MG RESISTOR

R 881 NRSA63J-750X MG RESISTOR

R 882 NRSA63J-0R0X MG RESISTOR B,E,EN E

R 883 NRSA63J-0R0X MG RESISTOR A,US,UW D/U

R 884 NRSA63J-0R0X MG RESISTOR

R 887 NRSA63J-0R0X MG RESISTOR

R 888 NRSA63J-0R0X MG RESISTOR

R 890 NRSA63J-0R0X MG RESISTOR

R 991 NRSA63J-220X MG RESISTOR

R 996 NRSA63J-0R0X MG RESISTOR

R 997 NRSA63J-0R0X MG RESISTOR

R 998 NRSA63J-0R0X MG RESISTOR B,E,EN

R1500 QRA14CF-1802Y MF RESISTOR 18 1/4W

R1501 QRA14CF-1802Y MF RESISTOR 18 1/4W

R1502 NRSA63J-100X MG RESISTOR

R1503 NRSA63J-100X MG RESISTOR

R1504 NRSA63J-100X MG RESISTOR

R1505 NRSA63J-100X MG RESISTOR

R1506 NRSA63J-100X MG RESISTOR

R1507 NRSA63J-100X MG RESISTOR

R1508 NRSA63J-100X MG RESISTOR

R1509 NRSA63J-100X MG RESISTOR

R1510 NRSA63J-100X MG RESISTOR

R1511 NRSA63J-100X MG RESISTOR

R1512 NRSA63J-100X MG RESISTOR

R1513 NRSA63J-100X MG RESISTOR

R1514 NRSA63J-100X MG RESISTOR

R1515 NRSA63J-100X MG RESISTOR

R1516 NRSA63J-100X MG RESISTOR

R1517 NRSA63J-100X MG RESISTOR

R1518 NRSA63J-100X MG RESISTOR

R1519 NRSA63J-100X MG RESISTOR

R1520 NRSA63J-100X MG RESISTOR

R1521 NRSA63J-100X MG RESISTOR

R1522 NRSA63J-100X MG RESISTOR

R1523 NRSA63J-100X MG RESISTOR

R1524 NRSA63J-100X MG RESISTOR

R1525 NRSA63J-100X MG RESISTOR

R1526 NRSA63J-100X MG RESISTOR

R1527 NRSA63J-100X MG RESISTOR

Parts name Area

Remarks

D/U

B,E,EN

A,US,UW

B,E,EN

A,US,UW

3-13

XV-NA7SL

Electrical parts list (Servo control board)

Item

Parts numbe

R1528 NRSA63J-100X MG RESISTOR

R1529 NRSA63J-100X MG RESISTOR

R1530 NRSA63J-100X MG RESISTOR

R1531 NRSA63J-100X MG RESISTOR

R1532 NRSA63J-100X MG RESISTOR

R1533 NRSA63J-100X MG RESISTOR

R1534 NRSA63J-100X MG RESISTOR

R1535 NRSA63J-100X MG RESISTOR

R1536 NRSA63J-100X MG RESISTOR

R1537 NRSA63J-100X MG RESISTOR

R1538 NRSA63J-100X MG RESISTOR

R1539 NRSA63J-100X MG RESISTOR

R1540 NRSA63J-100X MG RESISTOR

R1541 NRSA63J-100X MG RESISTOR

R1550 NRSA63J-100X MG RESISTOR

R1551 NRSA63J-100X MG RESISTOR

R1552 NRSA63J-100X MG RESISTOR

R1553 NRSA63J-100X MG RESISTOR

R1554 NRSA63J-100X MG RESISTOR

R1555 NRSA63J-100X MG RESISTOR

R1556 NRSA63J-100X MG RESISTOR

R1557 NRSA63J-100X MG RESISTOR

R1558 NRSA63J-100X MG RESISTOR

R1559 NRSA63J-100X MG RESISTOR

R1560 NRSA63J-100X MG RESISTOR

R1561 NRSA63J-100X MG RESISTOR

R1562 NRSA63J-100X MG RESISTOR

R1570 NRSA63J-100X MG RESISTOR

R1571 NRSA63J-100X MG RESISTOR

R1721 NRSA63J-100X MG RESISTOR

R1722 NRSA63J-301X MG RESISTOR

R1725 NRSA63J-301X MG RESISTOR

R1727 NRSA63J-820X MG RESISTOR

R1728 NRSA63J-100X MG RESISTOR

R1730 NRSA63J-100X MG RESISTOR

S 801 QSW0454-001 SWITCH

S 802 QSW0986-001 SLIDE SWITCH PRG/INT/RM U

WC801 QZW0038-001 WIRE CLAMP B,E,EN

X 301 NAX0542-001X C RESONATOR

X 401 NAX0543-001X C RESONATOR

X 571 NAX0513-001X CRYSTAL

Parts name Area

Block No. 01

Remarks

PAL/NT U

3-14

XV-NA7SL

Electrical parts list (Main board)

Item

Parts numbe

BK901 E409182-001SM GRAND TERMINAL

C 1 NCS31HJ-331X C RESISTOR

C 2 NCB31CK-103X C CAPACITOR

C 3 NCB31CK-104X C CAPACITOR

C 4 NCB31CK-104X C CAPACITOR

C 5 NCB31CK-104X C CAPACITOR

C 6 NCB31CK-104X C CAPACITOR

C 8 QEKC1CM-106Z E CAPACITOR

C 9 QEKC1AM-476Z E CAPACITOR 47MF 20% 10V

C 10 NCB21CK-105X C CAPACITOR

C 11 QEKC0JM-227Z E CAPACITOR 220MF 20% 6.3V

C 12 NCB31CK-104X C CAPACITOR

C 13 QEKC1CM-106Z E CAPACITOR

C 14 NCB31CK-104X C CAPACITOR

C 15 NCB31CK-104X C CAPACITOR

C 16 QEKC1CM-106Z E CAPACITOR

C 17 NCB31CK-223X C CAPACITOR

C 902 QFZ9075-104 M CAPACITOR

C 903 QFZ9075-104 M CAPACITOR

C 905 QCZ9079-102 C CAPACITOR

C 907 QEZ0590-686 E CAPACITOR

C 910 QETN1EM-226Z E CAPACITOR

C 911 QETN1EM-226Z E CAPACITOR

C 913 QCZ0136-101Z C CAPACITOR

C 914 QEZ0532-396Z E CAPACITOR

C 915 NCB31HK-471X C CAPACITOR

C 921 QCZ9079-102 C CAPACITOR

C 922 QCZ0136-332Z C CAPACITOR 3300PF

C 928 NCB31CK-223X C CAPACITOR C

C 965 QEZ0528-108 E CAPACITOR 1000MF

C 966 QETN1AM-477Z E CAPACITOR

C 968 NCB21CK-105X C CAPACITOR

C 969 QETN0JM-227Z E CAPACITOR

C 972 NCS31HJ-471X C CAPACITOR

C 975 QEZ0528-108 E CAPACITOR

C 976 QETN0JM-477Z E CAPACITOR

C 978 QETN0JM-227Z E CAPACITOR 220MF 20% 6.3V

C 979 QEZ0528-108 E CAPACITOR 1000MF

C 980 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 981 NCB21CK-105X C CAPACITOR

C 982 QEZ0532-187Z E CAPACITOR

C 983 NCB21CK-105X C CAPACITOR

C 984 QETN1CM-477Z E CAPACITOR

C 985 QETN0JM-227Z E CAPACITOR

C 986 NCB21CK-334X C RESISTOR

C 987 QEZ0532-187Z E CAPACITOR

C 989 QETN1CM-477Z E CAPACITOR -12V

C 990 NCB21CK-334X C RESISTOR

C 991 NCS31HJ-101X C RESISTOR

CN 1 QGF1016C1-27 CONNECTOR

CN 2 QGF1016C1-13 CONNECTOR

CN 3 QGD2501C1-03Z SOCKET

CN 4 QGA2001C1-02 2P PLUG ASSY

CN 5 QGA2001C1-02 2P PLUG ASSY

CN 6 QGA2001C1-02 2P PLUG ASSY

CN 7 QGF1016F3-13 CONNECTOR

CN 8 QGD2504C1-04Z SOCKET I.M

CN 9 QJK018-021202 SIN CR C-B WIRE

CN 10 QJK018-021202 SIN CR C-B WIRE

CN 11 QJK018-021202 SIN CR C-B WIRE

CN902 QGF1205C1-15 CONNECTOR

D 1 1SS355-X DIODE C.M

D 2 SPR-39MVWF LED

D 3 SPR-325MVW/L/-T LED

D 4 SELU2E10C LED

D 5 SELU2E10C LED DVD AUDIO

Parts name Area

10MF 20% 16V

.10MF

1000PF

U/A

100PF

39MF

1000PF

470MF 20% 10V

220MF 20% 6.3V

1000MF

470MF 20% 6.3V

+12V

220MF 20% 6.3V

-12V

PERICONE E

PROGRESSIVE

STANDB

EDGE LIGHT

Block No. 02

Remarks

B,E,EN

Item

Parts numbe

D 6 SELU2E10C LED TRA

D 9 NSPW300BS/BRS/ LED BACK LIGHT

D 10 NSPW300BS/BRS/ LED

D 11 SELU2E10C LED

D 12 1SS355-X DIODE

D 13 1SS355-X DIODE

D 15 1SS355-X DIODE

D 901 S1WB/A/60-4101 BRIDGE DIODE

D 902 SARS01-T2 FR DIODE

D 904 F1T4-T2 FR DIODE

D 905 F1T4-T2 FR DIODE

D 908 EK16-F1 FR DIODE(FOMING

D 954 F1T4-T2 FR DIODE

D 956 F1T4-T2 FR DIODE

D 957 F1T4-T2 FR DIODE

D 981 RK34-LFB2 SB DIODE

D 991 HZS3CLL-T2 Z DIODE

D 998 11ES2-T4 DIODE I.M

DI 1 QLD0239-001 LCD MODULE

EP901 QNZ0136-001Z EARTH PLATE PRIMAR

FC901 QNG0003-001Z FUSE CLIP

FC902 QNG0003-001Z FUSE CLIP

FW 3 QUM137-10DGZ4 PARA RIBON WIRE

HL 1 LE20644-001A LCD HOLDER

HL 2 LE31029-001A LED HOLDER

HS901 E70306-006 HEAT SINK

IC 1 MN101C57DLR IC

IC 2 XC61FN2712M-X IC

IC 3 GP1UD271XK RM RECIVER

IC901 STR-G6551R-F8 IC(HYBRID)

IC951 MM1565AF-X IC

IC952 PQ3RD23 IC

J 901 QNS0089-001 3.5 JACK

J 902 QNZ0516-001 RGB CONNECTOR

JT911 QGD2501C1-04Z SOCKET

JT912 QGD2504C1-04Z SOCKET

JT913 QGD2504C1-04Z SOCKET FW903

K 902 QQR1183-001Z FERRITE BEADS

K 904 QQR1183-001Z FERRITE BEADS

K 905 QQR1183-001Z FERRITE BEADS

K 906 QQR1183-001Z FERRITE BEADS

L 901 QQR1105-001 LINE FILTER

L 909 QQL231K-2R2Y INDUCTOR

L 952 QQR1291-001Z CHOKE COIL

L 955 QQR1291-001Z CHOKE COIL

L 957 QQL244K-100Z INDUCTOR

L 959 QQL244K-100Z INDUCTOR

L 960 QQR1291-001Z CHOKE COIL

P 901 QGA7901C1-02 CONNECTOR

PC901 PC123Y02 IC(PHOTO COUPLE

Q 1 KRC107S-X DIGITAL.TR

Q 2 KRA103S-X DIGITAL.TR

Q 4 2SC1740S/RS/-T TRANSISTOR

Q 5 KRC107S-X DIGITAL.TR

Q 6 KRC107S-X DIGITAL.TR

Q 7 KRC107S-X DIGITAL.TR

Q 8 KRA102S-X DIGITAL.TR

Q 9 KRA102S-X DIGITAL.TR

Q 10 2SC1740S/RS/-T TRANSISTOR

Q 13 2SC1740S/RS/-T TRANSISTOR

Q 910 2SC3576-JVC-T TRANSISTOR

Q 911 2SC3576-JVC-T TRANSISTOR

Q 991 KTC3199/Y/-T TRANSISTOR

R 1 NRSA63J-472X MG RESISTOR

R 2 NRSA63J-102X MG RESISTOR

R 3 NRSA63J-472X MG RESISTOR

Parts name Area

BACK LIGHT

EDGE LIGHT

SYSCOM MASK

AV COMPULINK

PERICONE E

FW901

E MUTE

Remarks

B,E,EN

3-15

XV-NA7SL

Electrical parts list (Main board)

Item

Parts numbe

R 4 NRSA63J-222X MG RESISTOR

R 5 NRSA63J-222X MG RESISTOR

R 6 NRSA63J-104X MG RESISTOR

R 7 NRSA63J-103X MG RESISTOR

R 9 NRSA63J-103X MG RESISTOR

R 10 NRSA63J-103X MG RESISTOR

R 11 NRSA63J-152X MG RESISTOR

R 12 NRSA63J-102X MG RESISTOR

R 13 NRSA63J-103X MG RESISTOR

R 14 NRSA63J-222X MG RESISTOR

R 15 NRSA63J-103X MG RESISTOR

R 16 NRSA63J-103X MG RESISTOR

R 17 NRSA63J-103X MG RESISTOR

R 18 NRSA63J-270X MG RESISTOR

R 19 NRSA63J-392X MG RESISTOR

R 20 NRSA63J-332X MG RESISTOR

R 21 NRSA63J-0R0X MG RESISTOR

R 22 NRSA63J-0R0X MG RESISTOR

R 23 NRSA63J-151X MG RESISTOR

R 24 NRSA63J-750X MG RESISTOR

R 25 NRSA63J-331X MG RESISTOR

R 26 NRSA63J-331X MG RESISTOR

R 27 NRSA63J-222X MG RESISTOR

R 28 NRSA63J-222X MG RESISTOR

R 29 NRSA63J-431X MG RESISTOR

R 30 NRSA63J-681X MG RESISTOR

R 31 NRSA63J-0R0X MG RESISTOR

R 32 NRSA63J-182X MG RESISTOR

R 33 NRSA63J-270X MG RESISTOR

R 34 NRSA63J-105X MG RESISTOR

R 35 NRSA63J-270X MG RESISTOR

R 36 NRSA63J-222X MG RESISTOR

R 37 NRSA63J-222X MG RESISTOR

R 38 NRSA63J-750X MG RESISTOR

R 40 NRSA63J-182X MG RESISTOR

R 41 NRSA63J-182X MG RESISTOR

R 42 NRSA63J-392X MG RESISTOR

R 43 NRSA63J-103X MG RESISTOR

R 44 NRSA63J-102X MG RESISTOR D/E

R 46 NRSA63J-472X MG RESISTOR

R 50 NRSA63J-0R0X MG RESISTOR

R 51 NRSA63J-0R0X MG RESISTOR

R 53 NRSA63J-0R0X MG RESISTOR

R 56 NRSA63J-392X MG RESISTOR

R 901 QRL01DJ-683X OMF RESISTOR

R 902 NRSA63J-390X MG RESISTOR

R 903 QRE141J-560Y C RESISTOR 56 5% 1/4W

R 905 QRL027J-683 OMF RESISTOR 68K 5% 1/2W

R 906 QRE141J-681Y C RESISTOR 680 5% 1/4W

R 907 QRT022J-R47 OMF RESISTOR

R 908 QRE141J-332Y C RESISTOR

R 909 QRE141J-151Y C RESISTOR

R 910 NRSA63J-562X MG RESISTOR

R 911 NRSA63J-562X MG RESISTOR

R 912 NRSA63J-561X MG RESISTOR

R 913 NRSA63J-561X MG RESISTOR B,E,ENE MUTE

R 914 NRSA63J-103X MG RESISTOR B,E,ENE MUTE

R 915 NRSA63J-103X MG RESISTOR B,E,ENE MUTE

R 916 NRSA63J-151X MG RESISTOR B,E,ENE MUTE

R 917 NRSA63J-151X MG RESISTOR

R 918 NRSA63J-101X MG RESISTOR

R 920 QRZ9037-335 F RESISTOR

R 921 QRL01DJ-470X OMF RESISTOR

R 924 NRSA63J-101X MG RESISTOR

R 951 NRSA63J-750X MG RESISTOR

R 952 NRSA63J-750X MG RESISTOR B,E,ENE

Parts name Area

68K 5% 1/1W

5% 1/2W

3.3K 5% 1/4W

E MUTE

3.3M 1/0W

47 5% 1/1W

Block No. 02

Remarks

A,US,UW

B,E,EN

A,US,UW

B,E,EN

Item

Parts numbe

R 953 NRSA63J-750X MG RESISTOR B,E,ENE

R 954 NRSA63J-750X MG RESISTOR B,E,EN

R 958 NRSA63J-0R0X MG RESISTOR

R 960 NRSA63J-390X MG RESISTOR

R 961 NRSA63J-681X MG RESISTOR

R 962 NRSA63J-151X MG RESISTOR

R 964 NRSA63J-104X MG RESISTOR

R 969 NRSA63J-271X MG RESISTOR

S 1 QSW0651-001Z TACT SWITCH POWER SW

S 2 QSW0651-001Z TACT SWITCH OPEN/CLOSE

S 3 QSW0651-001Z TACT SWITCH STOP

S 4 QSW0651-001Z TACT SWITCH

S 5 QSW0651-001Z TACT SWITCH

S 6 QSW0651-001Z TACT SWITCH

S 7 QSW0651-001Z TACT SWITCH

T 901 QQS0159-001 SW TRANSF

X 1 QAX0667-001Z RESONATOR I.M

Parts name

Remarks

PLA

PAUSE

BW SKIP

FW SKIP

rea

3-16

XV-NA7SL

Electrical parts list (Surround audio board)

Item

Parts numbe

BK811 E409182-001SM GRAND TERMINAL

C 409 NCB31HK-152X C CAPACITOR

C 410 NCB31HK-152X C CAPACITOR

C 411 QFLC1HJ-122Z M CAPACITOR

C 412 QFLC1HJ-122Z M CAPACITOR

C 413 QFLC1HJ-472Z M CAPACITOR

C 414 QFLC1HJ-472Z M CAPACITOR

C 415 QFLC1HJ-121Z M CAPACITOR

C 416 QFLC1HJ-121Z M CAPACITOR 120PF 5% 50V

C 417 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V

C 418 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V

C 419 QFLC1HJ-102Z M CAPACITOR

C 420 QFLC1HJ-102Z M CAPACITOR

C 421 QFLC1HJ-102Z M CAPACITOR

C 422 QFLC1HJ-102Z M CAPACITOR

C 423 QTE1A48-476Z E CAPACITOR

C 424 QTE1A48-476Z E CAPACITOR

C 425 QTE1C28-107Z E CAPACITOR

C 426 QTE1C28-107Z E CAPACITOR

C 427 QTE1C28-107Z E CAPACITOR

C 428 QTE1C28-107Z E CAPACITOR

C 429 QTE0J28-227Z E CAPACITOR

C 430 NCB21AK-105X C CAPACITOR

C 431 QFLC1HJ-103Z M CAPACITOR

C 432 QFVJ1HJ-224Z MF CAPACITOR

C 433 QTE0J28-477Z E CAPACITOR

C 434 QTE0J28-477Z E CAPACITOR

C 435 NCB21AK-105X C CAPACITOR

C 441 NCB31HK-102X C CAPACITOR

C 442 NCB31HK-102X C CAPACITOR

C 451 QFLC1HJ-122Z M CAPACITOR

C 452 QFLC1HJ-122Z M CAPACITOR

C 453 QFLC1HJ-472Z M CAPACITOR

C 454 QFLC1HJ-472Z M CAPACITOR

C 455 QFLC1HJ-121Z M CAPACITOR

C 456 QFLC1HJ-121Z M CAPACITOR

C 457 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V

C 458 QFLC1HJ-123Z M CAPACITOR .012MF 5% 50V

C 459 QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V

C 460 QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V

C 461 QFLC1HJ-102Z M CAPACITOR

C 462 QFLC1HJ-102Z M CAPACITOR

C 463 QTE1A48-476Z E CAPACITOR

C 464 QTE1A48-476Z E CAPACITOR

C 465 QTE1C28-107Z E CAPACITOR

C 466 QTE1C28-107Z E CAPACITOR

C 467 QTE1C28-107Z E CAPACITOR

C 468 QTE1C28-107Z E CAPACITOR

C 469 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V

C 470 NCB21AK-105X C CAPACITOR

C 473 QTE0J28-477Z E CAPACITOR

C 474 QTE0J28-477Z E CAPACITOR

C 475 NCB21AK-105X C CAPACITOR

C1425 QFLC1HJ-222Z M CAPACITOR

C1426 QFLC1HJ-222Z M CAPACITOR

C1465 QFLC1HJ-222Z M CAPACITOR 2200PF 5% 50V

C1466 QFLC1HJ-222Z M CAPACITOR 2200PF 5% 50V

C1467 QTE0J28-227Z E CAPACITOR

C1468 QFVJ1HJ-224Z MF CAPACITOR .22MF 5% 50V

CN401 QGF1016C1-17 CONNECTOR

IC411 MN35505-X IC

IC412 MN35505-X IC

IC811 NJM4580M-X IC

IC812 NJM4580M-X IC

IC821 NJM4580M-X IC

IC822 NJM4580M-X IC

Parts name Area

1200PF 5% 50V

4700PF 5% 50V

120PF 5% 50V

1000PF 5% 50V

.010MF 5% 50V

.22MF 5% 50V

1200PF 5% 50V

4700PF 5% 50V

120PF 5% 50V

1000PF 5% 50V

2200PF 5% 50V

Block No. 03

Remarks

Item

Parts numbe

J 401 QNN0514-001 PIN JACK

K 411 NQR0007-002X FERRITE BEADS

K 412 NQR0007-002X FERRITE BEADS

K 413 NQR0007-002X FERRITE BEADS

K 414 NQR0007-002X FERRITE BEADS

K 415 NQR0007-002X FERRITE BEADS

K 416 NQR0007-002X FERRITE BEADS

K 417 NRSA63J-0R0X MG RESISTOR

K 418 NRSA63J-0R0X MG RESISTOR

K 419 NRSA63J-0R0X MG RESISTOR

K 420 NRSA63J-0R0X MG RESISTOR

K 421 NQR0007-002X FERRITE BEADS

K 422 NQR0007-002X FERRITE BEADS

Q 401 2SD2144S/VW/-T TRANSISTOR

Q 402 2SD2144S/VW/-T TRANSISTOR

Q 403 2SC3576-JVC-T TRANSISTOR

Q 404 2SC3576-JVC-T TRANSISTOR

R 350 NRSA63J-561X MG RESISTOR

R 351 NRSA63J-101X MG RESISTOR

R 352 NRSA63J-101X MG RESISTOR

R 353 NRSA63J-103X MG RESISTOR

R 354 NRSA63J-103X MG RESISTOR

R 355 NRSA63J-221X MG RESISTOR

R 356 NRSA63J-221X MG RESISTOR

R 357 NRSA63J-221X MG RESISTOR

R 358 NRSA63J-221X MG RESISTOR

R 359 NRSA63J-470X MG RESISTOR

R 360 NRSA63J-470X MG RESISTOR

R 361 NRSA63J-220X MG RESISTOR

R 362 NRSA63J-470X MG RESISTOR

R 363 NRSA63J-332X MG RESISTOR

R 364 NRSA63J-332X MG RESISTOR

R 365 NRSA63J-100X MG RESISTOR

R 366 NRSA63J-100X MG RESISTOR

R 367 NRSA63J-471X MG RESISTOR

R 368 NRSA63J-471X MG RESISTOR

R 369 NRSA63J-471X MG RESISTOR

R 370 NRSA63J-471X MG RESISTOR

R 371 NRSA63J-471X MG RESISTOR

R 372 NRSA63J-471X MG RESISTOR

R 373 NRSA63J-470X MG RESISTOR

R 374 NRSA63J-471X MG RESISTOR

R 375 NRSA63J-470X MG RESISTOR

R 376 NRSA63J-471X MG RESISTOR

R 377 NRSA63J-470X MG RESISTOR

R 378 NRSA63J-471X MG RESISTOR

R 389 NRSA63J-100X MG RESISTOR

R 390 NRSA63J-100X MG RESISTOR

R 431 QRA14CF-1802Y MF CAPACITOR 18 1/4W

R 432 QRA14CF-1802Y MF CAPACITOR

R 433 QRA14CF-1802Y MF CAPACITOR

R 434 QRA14CF-1802Y MF CAPACITOR

R 435 QRA14CF-3602Y MF CAPACITOR

R 436 QRA14CF-3602Y MF CAPACITOR

R 437 QRA14CF-1601Y MF CAPACITOR

R 438 QRA14CF-1601Y MF CAPACITOR 16 1/4W

R 439 NRSA63J-303X MG RESISTOR

R 440 NRSA63J-303X MG RESISTOR

R 441 NRSA63J-303X MG RESISTOR

R 442 NRSA63J-303X MG RESISTOR

R 443 NRSA63J-272X MG RESISTOR

R 444 NRSA63J-272X MG RESISTOR

R 445 NRSA63J-272X MG RESISTOR

R 446 NRSA63J-272X MG RESISTOR

R 447 NRSA63J-362X MG RESISTOR

R 448 NRSA63J-362X MG RESISTOR

Parts name Area

Remarks

18 1/4W

36 1/4W

16 1/4W

3-17

XV-NA7SL

Electrical parts list (Surround audio board)

Item

Parts numbe

R 449 NRSA63J-751X MG RESISTOR

R 450 NRSA63J-751X MG RESISTOR

R 451 NRSA63J-751X MG RESISTOR

R 452 NRSA63J-751X MG RESISTOR

R 453 QRE141J-102Y C RESISTOR

R 454 QRE141J-102Y C RESISTOR

R 455 NRSA63J-183X MG RESISTOR

R 456 NRSA63J-183X MG RESISTOR

R 457 NRSA63J-273X MG RESISTOR

R 458 NRSA63J-273X MG RESISTOR

R 459 NRSA63J-561X MG RESISTOR

R 460 NRSA63J-561X MG RESISTOR

R 461 NRSA63J-101X MG RESISTOR

R 462 NRSA63J-101X MG RESISTOR

R 463 NRSA63J-103X MG RESISTOR

R 464 NRSA63J-103X MG RESISTOR

R 465 NRSA63J-221X MG RESISTOR

R 466 NRSA63J-221X MG RESISTOR

R 467 NRSA63J-221X MG RESISTOR

R 468 NRSA63J-221X MG RESISTOR

R 469 NRSA63J-470X MG RESISTOR

R 470 NRSA63J-470X MG RESISTOR

R 471 QRA14CF-1802Y MF RESISTOR

R 472 QRA14CF-1802Y MF RESISTOR

R 473 QRA14CF-1802Y MF RESISTOR

R 474 QRA14CF-1802Y MF RESISTOR

R 475 QRA14CF-3602Y MF RESISTOR

R 476 QRA14CF-3602Y MF RESISTOR 36 1/4W

R 477 QRA14CF-1601Y MF RESISTOR 16 1/4W

R 478 QRA14CF-1601Y MF RESISTOR 16 1/4W

R 479 NRSA63J-303X MG RESISTOR

R 480 NRSA63J-303X MG RESISTOR

R 481 NRSA63J-303X MG RESISTOR

R 482 NRSA63J-303X MG RESISTOR

R 483 NRSA63J-272X MG RESISTOR

R 484 NRSA63J-272X MG RESISTOR

R 485 NRSA63J-272X MG RESISTOR

R 486 NRSA63J-272X MG RESISTOR

R 487 NRSA63J-362X MG RESISTOR

R 488 NRSA63J-362X MG RESISTOR

R 489 NRSA63J-751X MG RESISTOR

R 490 NRSA63J-751X MG RESISTOR

R 491 NRSA63J-751X MG RESISTOR

R 492 NRSA63J-751X MG RESISTOR

R 493 QRE141J-102Y C RESISTOR

R 494 QRE141J-102Y C RESISTOR

R 495 NRSA63J-183X MG RESISTOR

R 496 NRSA63J-183X MG RESISTOR

R 497 NRSA63J-273X MG RESISTOR

R 498 NRSA63J-273X MG RESISTOR

R 499 NRSA63J-561X MG RESISTOR

Parts name Area

Block No. 03

Remarks

1.0K 5% 1/4W

18 1/4W

36 1/4W

1.0K 5% 1/4W

3-18

< MEMO >

XV-NA7SL

3-19

XV-NA7SL

Packing materials and accessories parts list

A12

A3,A6,A7,A11

Block No. M4MM Block No. M5MM

EXCEPT EN

EN ONLY

A12

A1~ A11

A13

3-20

XV-NA7SL

Packing parts list

Item

P 1 LE31032-017A

P 2 LE20648-001A

P 3 LE20649-001A PACKING PAD(R) 1

P 4 LE30920-003A

P 5 QPC06005515P

Parts number Parts name Area

PACKING CASE

LE31032-014A

LE31032-022A

LE31032-015A PACKING CASE US1

LE31032-016A

PACKING CASE

PACKING PAD(L)

SHEET ASSY

POLY BAG

Accessories parts list

Item

A 1 LET0212-010A

A 2

A 3

A 4 BT-56002-2

A 5 VNA3000-204

A 6 QAM0328-001

A 7 EWP302-011W

A 8 QAM0005-002

A 9 QAM0326-001

A 10 RM-SXV013U

A 11 -------------------

A 12 QPC02504015P

A 13 LE40912-001A

Parts number Parts name Area

INST BOOK

LET0212-004A

LET0212-005A

LET0212-007A INST BOOK EN1

LET0212-006A

LET0204-012A INST BOOK US1

LET0212-015A

QAM0112-001

BT-56001-2

BT-54008-4

RM-SXV012E

QPC02504015P

INST BOOK

AC PLUG ADAPTER

WARRANTY CARD

SVC CENTER LIST

REGIST.CARD

AV CORD 3P

SIGNAL CORD

S-VIDEO CORD

1P PLUG CORD(JE

REMOCON UNIT

BATTERY

POLY BAG

CAUTION SHEET

Q'ty

LEFT

RIGHT

FOR SET

Q'ty

English

German,French,Dutch

Swedish,Finnish,Danish

German,French,Spanish,Italian

English,Chinese(Beujing)

English,Spanish,Porutguese

FOR EXP.

FOR ACC,INST

Description

Block No. M4MM

E,EN

A,B

Block No. M5MM

US,UW

B,E,EN

A,US,UW

B,E,EN

A,B,E,US,UW

B,E,EN

3-21

JVC XV-NA7SL Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual

Exploded view of general assembly and parts list

Parts list (General assembly) 1/2

Parts list (General assembly) 2/2

DVD Traverse mechanism assembly and parts list

Parts list (DVD Traverse mechanism assembly)

DVD Loading mechanism assembly and parts list

Parts list (DVD Loading mechanism assembly)

Electrical parts list (Loading motor board)

Electrical parts list (Servo control board)

Electrical parts list (Main board)

Electrical parts list (Surround audio board)

Packing materials and accessories parts list

Packing parts list

Accessories parts list
