PARTS LIST
[XV-NA70BK,XV-NA77SL]
* All printed circuit boards and its assemblies are not available as service parts.
* (x_) in a description column shows the number of the used part.
Area Suffix (XV-NA70BK)
J -------------------------- U.S.A.
C --------------------- Canada
Area Suffix (XV-NA77SL)
J -------------------------- U.S.A.
C --------------------- Canada
UJ ------------ U.S.A Militaly
B -------------------------- U.K.
E ------ Continental Europe
EN ------- Northern Europe
EV --------- Eastern Europe
EE ---- Russian Federation
US ---------------- Singapore
UF ---------------------- China
A --------------------- Australia
UW ----- Brazil,Mexico,Peru
- Contents -
Exploded view of general assembly and parts list
DVD Traverse mechanism assembly and parts list
DVD Loading mechanism assembly and parts list
Electrical parts list
Packing materials and accessories parts list
3-2
3-4
3-6
3-8
3-16
(No.XA011)3-1
Exploded view of general assembly and parts list
52
50
51
Operation
switch board
52
14
56
25
55
35
24
32
51
f
d
e
35
f
d
e
35
35
35
12
Block No.M1MM
7
18
13
10
15
16
2
4
9
8
11
FL display board
3
17
11
1
5
6
Servo control & signal
output treminal board
44
39
40
38
43
37
45
42
20
41
"A"
23
47
53
22
46
22
22
g
Power supply &
system control board
21
g
19
20
36
"A"
29
33
3
54
33
c
a
30
29
30
b
33
28
a
27
c
34
Relay board
26
30
b
28
3-2(No.XA011)
49
48
31
General assembly
Block No. [M][1][M][M]
Symbol No. Part No. Part Name Description Local
1 GN10044-002A FRONT PANEL 70C,70J
1 GN10044-004A FRONT PANEL 77C,77J,77UJ
1 GN10044-006A FRONT PANEL
2 GN40020-001A JVC MARK 70C,70J
2 GN40020-002A JVC MARK only XV-NA77SL
3 E75896-002 FELT SPACER FRONT FOOT(x2)
4 GN20054-003A ORNAMENT(L) 70C,70J
4 GN20054-004A ORNAMENT(L) only XV-NA77SL
5 GN20055-003A ORNAMENT(R) 70C,70J
5 GN20055-004A ORNAMENT(R) only XV-NA77SL
6 GN20056-008A WINDOW SCREEN 70C,70J
6 GN20056-013A WINDOW SCREEN only Europe
6 GN20056-015A WINDOW SCREEN 77C,77J,77UJ
6 GN20056-014A WINDOW SCREEN 77A,77UF,77US,77UW
7 GN30059-002A FL SCREEN 70C,70J
7 GN30059-004A FL SCREEN only XV-NA77SL
8 GN20058-003A PUSH BUTTON BK POWER 70C,70J
8 GN20058-005A PUSH BUTTON SL POWER only Europe
8 GN20058-004A PUSH BUTTON SL POWER except Europe
9 GN30057-001A INDICATOR POWER
10 GN30058-001A LED LENS LEFT
11 QYSBSF2608Z TAPPING SCREW POWER SW.CB.(x4)
12 GN20059-003A PUSH BUTTON BK PLAY 70C,70J
12 GN20059-004A PUSH BUTTON SL PLAY only XV-NA77SL
13 GN30058-002A LED LENS RIGHT
14 QYSBSF2608Z TAPPING SCREW PLAY SW.CB.(x3)
15 QUQ210-2108BJ FFC WIRE
16 QUQ210-0916AJ FFC WIRE
17 QUQ210-2308BJ FFC WIRE
18 E3400-431 SPACER (x2)
19 GN10045-004A CHASSIS BASE 70C,70J
19 GN10045-003A CHASSIS BASE only XV-NA77SL
20 E75896-002 FELT SPACER REAR FOOT(x2)
21 GN40037-001A PROTECT SHEET
22 QYSBSGG3006E TAP SCREW MAIN CB+CHASSIS(x3)
23 QYSBSGG3006E TAP SCREW MAIN CB+CHASSIS(x2)
24 QUQ412-1708AJ FFC WIRE
25 QUQ412-1512AJ FFC WIRE only Europe
26 QUQ605-5008AF FFC WIRE MECHA+MAIN
27 ------------ TRAVERSE MECHA
28 LE40900-003A INSULATOR (x2)
29 LE40900-004A INSULATOR (x2)
30 LE40901-001A SPECIAL SCREW FOR INSULATOR(x4)
31 ------------ 1DISC LOADING B
32 GN30006-019A SPACER (x2)
33 QYSDSF2608Z SCREW FOR CONNECT CB(x4)
34 QUQ210-0518BJ FFC WIRE TRAMEK+CONNECT
35 QYSBSG3008Z TAPPING SCREW MECHA+CHASSIS(x3)
36 GN20064-064A REAR PANEL 70C,70J
36 GN20064-071A REAR PANEL 77A
36 GN20064-069A REAR PANEL 77EE
36 GN20064-068A REAR PANEL 77B,77E,77EN,77EV
36 GN20064-065A REAR PANEL 77C,77J
36 GN20064-074A REAR PANEL 77UF
36 GN20064-070A REAR PANEL 77UJ
36 GN20064-072A REAR PANEL 77US
36 GN20064-073A REAR PANEL 77UW
37 QYSBSGY3008M SPECIAL SCREW REAR+CHASSIS
38 QYSBSGY3008M SPECIAL SCREW OPT/COAXIAL
39 QYSBSGY3008M SPECIAL SCREW AUDIO OUT
40 QYSBSGY3008M SPECIAL SCREW VIDEO OUT
41 QYSBSGY3008M SPECIAL SCREW COMPU LINK
42 QYSBSGY3008M SPECIAL SCREW 21P OUT(x2) only Europe
43 QYSBSGY3008M SPECIAL SCREW COMPONENT(x2)
44 QYSBSGY3008M SPECIAL SCREW 5.1CH OUT
45 QYSBSGY3008M SPECIAL SCREW BKT
46 QMF51U1-1R6-J8 FUSE 1.6A AC125V only ver.J,C
46 QMF51E2-1R6-J1 FUSE 1.6A AC250V except ver.J,C of XV-NA77SL
47 QMPG100-244-JD POWER CORD(AST) 2.44m BLACK 77A
47 QMPN230-200-JC POWER CORD(EK) 2m BLACK 77B
47 QMPD450-200-JN POWER CORD(US/CA) 2m BLACK only ver.J,C
47 QMPR470-200-JN POWER CORD 2m BLACK 77UF
47 QMPK280-200-JN POWER CORD(EU) 2m BLACK 77E,77EE,77EN,77EV,77UJ,77US,77UW
48 QZW0004-001 WIRE CLAMP
49 GN30073-001A PROTECT SHEET(T
50 GN20063-001A/S/ METAL COVER 70C,70J
50 GN20063-002A/S/ METAL COVER only XV-NA77SL
51 QYSBSGG3006E TAP SCREW REAR(x3)
52 QYSDSG3008M SCREW BK SIDE(x2) 70C,70J
52 QYSDSG3008N TAPPING SCREW SL SIDE(x2) only XV-NA77SL
53 GN20062-004A LENS 70C,70J
53 GN20062-005A LENS only XV-NA77SL
54 GN20060-001A FITTING BASE 70C,70J
54 GN20060-002A FITTING BASE only XV-NA77SL
55 GN30082-001A SHIELD only ver.J,C
56 LE30001-031A SPACER only Europe
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
77A,77B,77E,77EE,77EN,77EV,77UF,77US,77UW
(No.XA011)3-3
DVD Traverse mechanism assembly and parts list
EXL-V76-1C
23
23
13
11
12
BACK SIDE
SIDE
Block No.M2MM
Grease
JVG-31N
PG-641
CFD-4007ZY2
9.5mm
19
18
17
65.3mm 0.2mm
16
21
20
3
BACK SIDE
12.0mm 0.2mm
15
14
10
4
5
3-4(No.XA011)
2
8
9
7
22
6
1
DVD Traverse mechanism
Symbol No. Part No. Part Name Description Local
1 LE10274-003A MECHA BASE
2 LE40896-001A BAR SPRING
3 LV41121-002A SHAFT
4 QAR0165-001 FEED MOTOR
5 LV41510-001A FEED GEAR T
6 QYSPSPU2040M SCREW 2mm x 4mm(x2)
7 LV41511-003A FEED GEAR M
8 LV41512-002A FEED GEAR E
9 LV41517-003A LEAD SCREW
10 QAL0452-001 PICK UP
11 LE20519-001A SW ACTUATOR
12 LE30886-001A LEAD SPRING
13 QYSPSFU1740Z SCREW 1.7mm x 4mm(x2)
14 LE30888-003A P.U.SPRING
15 QYSPSGU1430Z SCREW 1.4mm x 3mm
16 LV41121-002A SHAFT
17 LE40894-001A T.SPRING
18 LE40895-002A BRACKET
19 QYSDSF2005Z SCREW 2mm x 5mm
20 QAL0284-001 FPC
21 QAR0268-001 SPINDLE MOTOR
22 QYSPSPU1760Z SCREW 1.7mm x 6mm(x3)
23 LE40858-002A S.SCREW (x3)
Block No. [M][2][M][M]
(No.XA011)3-5
DVD Loading mechanism assembly and parts list
18
20
19
17
14
22
ELM-J3-1C
5
Block No.M3MM
16
3
21
Grease
JVG-31N
4
13
JVS-1003
1
12
11
a
15
7.95 0.10mm
b
Switch board
b
-
+
(All circumferences)
10
8
9
BACK SIDE
7
6
a
3-6(No.XA011)
DVD Loading mechanism
Symbol No. Part No. Part Name Description Local
1 LE10275-003A LOADER BASE
3 LE31043-001A PULLEY GEAR
4 LE31044-001A IDLE GEAR
5 LE20665-001A SLIDE CAM
6 LE20667-002A ELEVATOR
7 LE10276-002A TRAY
8 LE31045-001A BUSHING
9 LE40898-001A SHAFT
10 QYSSSF2008Z SCREW 2mm x 8mm
11 QAR0197-001 MOTOR
12 LV42087-002A MOTOR PULLEY
13 QYSPSPU1730Z SCREW FOR MOTOR(x2)
14 QYSDSF2008Z SCREW 2mm x 8mm(x2)
15 QYSDSF2006Z SCREW FOR BOARD
16 LE40897-001A BELT
17 LE31046-001A CLAMPER
18 LV42930-003A MAGNET
19 LE40899-001A YOKE
20 LE40906-001A S.SCREW
21 LE31042-001A MIDDLE GEAR
22 LE40937-001A LEAF SPRING
Block No. [M][3][M][M]
(No.XA011)3-7
Electrical parts list
Relay board
Block No. [0][1]
Symbol No.
CN1 QGF0522F1-30W CONNECTOR FFC/FPC (1-30)
CN2 QGF1016F2-05W CONNECTOR FFC/FPC (1-5)
CN3 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN4 QGF0522F1-50W CONNECTOR FFC/FPC (1-50)
SW1 NSW0127-001X SLIDE SWITCH
Servo control &
signal output terminal board
Symbol No.
IC101 AN8703FH-V IC Frontend processor for DVD
IC102
IC103
IC104 NJU7015M-W IC Ope. Amp
IC105
IC201 BA5983FM-X IC 4-channel driver
IC251 BA6679FM-X LSI
IC301 MN103S26EGB-H IC Super optical disc controller
IC302
IC401 HA17558AF-X IC Dual Operational Amp
IC402 NJM4580M-X IC Ope. Amp
IC403 HA17558AF-X IC Dual Operational Amp
IC404 NJM4580M-X IC Ope. Amp
IC405 MN35505-X IC DAC
IC406 MN35505-X IC DAC
IC501 NDV8611VWA IC Pantera
IC505 or
IC505
IC505 or HY57643220CT55 IC
IC505 or
IC505 or
IC505 or W986416DH-7 IC DRAM
IC506
IC506 or W986416DH-7 IC DRAM
IC511 LM1117MP1.8-X IC Regulator
IC520 MM1565AF-X IC Regulator
IC521
IC521
IC521
IC521
IC521
IC521
IC521
IC522 74LCX373MTC-X IC(DIGITAL) Octal D-type latch
IC522 or 74LVC373APW-X IC(DIGITAL) Octal D-type transparet latch
IC523 74LCX373MTC-X IC(DIGITAL) Octal D-type latch
IC523 or 74LVC373APW-X IC(DIGITAL) Octal D-type transparet latch
IC524
IC524
IC524
IC524
IC524
IC524
IC524
IC525 PQ3RD23 IC
IC601 JCE8046-X IC
IC602 MM1592FFBE-X IC
IC603 MM1623XF-X IC Video driver
IC604 MM1505XN-X IC only Europe
IC703 MN35505-X IC DAC
IC704 74VHCT08ASJ-X IC 2-input AND gate
IC705 NJM5532L IC
IC741 NJM5532L IC
IC802 GP1UE271XK IR DETECT UNIT
3-8(No.XA011)
Part No. Part Name Description Local
Block No. [0][2]
Part No. Part Name Description Local
SN74AHC1G66HV-X
SN74LV4053APW-X
SN74AHC2G66T-X
SN74AHC1G66HV-X
HY57V643220CT-5
K4S641632F-TC75
K4S643232E-TC60
K4S643232F-TC60
K4S641632F-TC75
SST39VF160H0B06
SST39VF160H0B83
SST39VF160H0BC3
SST39VF160H0B44
SST39VF160H0B63
SST39VF160H0BA3
SST39VF160H0BE3
SST39VF160H0B16
SST39VF160H0B93
SST39VF160H0BD3
SST39VF160H0B54
SST39VF160H0B73
SST39VF160H0BB3
SST39VF160H0BF3
IC
IC
IC
IC
IC
IC(DIGITAL) CMOS SDRAM
IC
IC
IC(DIGITAL) CMOS SDRAM
IC only ver.J,C
IC only ver.UJ
IC only ver.UW,A
IC
IC only ver.EE
IC only ver.US
IC only ver.UF
IC only ver.J,C
IC only ver.UJ
IC only ver.UW,A
IC
IC only ver.EE
IC only ver.US
IC only ver.UF
512K x 32 bit x 4 banks
synchronous DRAM
512K x 32 bit x 4 banks synchronous DRAM
512K x 32 bit x 4 banks synchronous DRAM
only ver.J,C
only ver.B,E,EN.EV
only ver.B,E,EN.EV
Symbol No.
Q101 KTA1001/Y/-X TRANSISTOR
Q102 KTA1001/Y/-X TRANSISTOR
Q103 DTA144EE-X DIGI TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 2SC4617/R/-X TRANSISTOR
Q106 2SC4617/R/-X TRANSISTOR
Q107 2SA1774/R/-X TRANSISTOR
Q108 2SC4617/R/-X TRANSISTOR
Q109 2SC4617/R/-X TRANSISTOR
Q110 2SC4617/R/-X TRANSISTOR
Q111 DTC114EE-X DIGI TRANSISTOR
Q112 KRC102S-X DIGI TRANSISTOR
Q301 DTC144EE-X DIGI TRANSISTOR
Q401 2SC3576-JVC-T TRANSISTOR
Q402 2SC3576-JVC-T TRANSISTOR
Q403 2SC3576-JVC-T TRANSISTOR
Q404 2SC3576-JVC-T TRANSISTOR
Q601 KRC102S-X DIGI TRANSISTOR
Q606 KRC102S-X DIGI TRANSISTOR only Europe
Q701 KRA121S-X DIGI TRANSISTOR
Q702 2SC2412K/RS/-X TRANSISTOR
Q703 KRC109S-X TRANSISTOR
Q704 2SC3576-JVC-T TRANSISTOR
Q705 2SC3576-JVC-T TRANSISTOR
Q706 2SC3576-JVC-T TRANSISTOR
Q707 KRA102S-X DIGI TRANSISTOR
Q708 KRA102S-X DIGI TRANSISTOR
Q743 2SC3576-JVC-T TRANSISTOR
Q821 KRA102S-X DIGI TRANSISTOR
D101 RB521S-30-X SB DIODE
D825
D827
C105 QETN1EM-476Z E CAPACITOR 47uF 25V M
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C108 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C109 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C110 NCS31HJ-221X C CAPACITOR 220pF 50V J
C111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C112 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C114 NCB31HK-392X C CAPACITOR 3900pF 50V K
C115 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C116 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C117 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C119 NCB31HK-561X C CAPACITOR 560pF 50V K
C120 NCB31HK-561X C CAPACITOR 560pF 50V K
C121 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C122 NCS31HJ-120X C CAPACITOR 12pF 50V J
C123 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C124 NCS31HJ-470X C CAPACITOR 47pF 50V J
C125 NCB31HK-271X C CAPACITOR 270pF 50V K
C126 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C127 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C128 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C129 NCB31HK-472X C CAPACITOR 4700pF 50V K
C132 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C133 NCB31CK-273X C CAPACITOR 0.027uF 16V K
C134 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C135 QETN1EM-476Z E CAPACITOR 47uF 25V M
C136 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C137 QETN1EM-476Z E CAPACITOR 47uF 25V M
C138 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C140 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C141 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C142 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C143 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C144 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C146 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C147 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C148 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C150 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C151 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
Part No. Part Name Description Local
SPR-325MVW/L/-T
204-10SUBC/A4VW
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
LED GREEN-RED
LED
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C152 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C153 NCB31HK-392X C CAPACITOR 3900pF 50V K
C154 NCS31HJ-680X C CAPACITOR 68pF 50V J
C155 NCS31HJ-680X C CAPACITOR 68pF 50V J
C156 NCS31HJ-120X C CAPACITOR 12pF 50V J
C157 NCB31HK-102X C CAPACITOR 1000pF 50V K
C158 NCS31HJ-221X C CAPACITOR 220pF 50V J
C159 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C160 NCS31HJ-820X C CAPACITOR 82pF 50V J
C161 NCS31HJ-180X C CAPACITOR 18pF 50V J
C162 NCS31HJ-181X C CAPACITOR 180pF 50V J
C203 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C204 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C205 NCS31HJ-121X C CAPACITOR 120pF 50V J
C207 NCS31HJ-391X C CAPACITOR 390pF 50V J
C208 NCS31HJ-391X C CAPACITOR 390pF 50V J
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C216 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C217 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C218 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C251 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C253 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C258 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C259 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C260 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C261 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C262 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C263 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C264 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C301 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C302 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C303 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C304 QETN1EM-476Z E CAPACITOR 47uF 25V M
C306 QETN0JM-227Z E CAPACITOR 220uF 6.3V M
C308 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C310 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C311 NCS31HJ-561X C CAPACITOR 560pF 50V J
C312 NCS31HJ-561X C CAPACITOR 560pF 50V J
C313 NCS31HJ-561X C CAPACITOR 560pF 50V J
C314 NCS31HJ-331X C CAPACITOR 330pF 50V J
C315 NCS31HJ-471X C CAPACITOR 470pF 50V J
C316 NCS31HJ-271X C CAPACITOR 270pF 50V J
C317 NCS31HJ-121X C CAPACITOR 120pF 50V J
C318 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C319 NCB31HK-102X C CAPACITOR 1000pF 50V K
C320 NCB31HK-102X C CAPACITOR 1000pF 50V K
C321 NCB31HK-102X C CAPACITOR 1000pF 50V K
C322 NCB31HK-562X C CAPACITOR 5600pF 50V K
C323 NCB31HK-102X C CAPACITOR 1000pF 50V K
C324 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C325 NCS31HJ-470X C CAPACITOR 47pF 50V J
C326 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C327 NCB31HK-102X C CAPACITOR 1000pF 50V K
C328 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C329 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C332 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31HK-102X C CAPACITOR 1000pF 50V K
C336 NCB31HK-472X C CAPACITOR 4700pF 50V K
C337 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C338 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C341 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C342 NCS31HJ-101X C CAPACITOR 100pF 50V J
C343 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C344 NCS31HJ-101X C CAPACITOR 100pF 50V J
C345 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C346 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C347 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
C349 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C350 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C353 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C360 QETN1EM-476Z E CAPACITOR 47uF 25V M
C362 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C363 QETN1EM-476Z E CAPACITOR 47uF 25V M
C402 QTE0J28-477Z E CAPACITOR 470uF 6.3V
C403 QFVJ1HJ-224Z MF CAPACITOR 0.22uF 50V J
C404 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C405 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C406 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C407 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C408 QTE0J46-477Z E CAPACITOR 470uF 6.3V
C409 NCB31HK-152X C CAPACITOR 1500pF 50V K
C410 QFLC1HJ-122Z M CAPACITOR 1200pF 50V J
C411 QFLC1HJ-122Z M CAPACITOR 1200pF 50V J
C412 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C413 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C414 QTE1E28-476Z E CAPACITOR 47uF 25V
C415 QTE1E28-476Z E CAPACITOR 47uF 25V
C416 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C417 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C418 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C419 QTE1C46-107Z E CAPACITOR 100uF 16V
C420 QTE1C46-107Z E CAPACITOR 100uF 16V
C421 QTE1C46-107Z E CAPACITOR 100uF 16V
C422 QTE1C46-107Z E CAPACITOR 100uF 16V
C423 QTE1C46-107Z E CAPACITOR 100uF 16V
C424 QTE1C46-107Z E CAPACITOR 100uF 16V
C425 QTE1C46-107Z E CAPACITOR 100uF 16V
C426 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C427 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C428 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C429 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C430 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C431 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C432 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C433 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C434 QFLC1HJ-122Z M CAPACITOR 1200pF 50V J
C435 QFLC1HJ-122Z M CAPACITOR 1200pF 50V J
C436 QTE0J46-477Z E CAPACITOR 470uF 6.3V
C437 QTE0J46-477Z E CAPACITOR 470uF 6.3V
C438 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C439 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C440 QTE0J46-477Z E CAPACITOR 470uF 6.3V
C441 QFVJ1HJ-224Z MF CAPACITOR 0.22uF 50V J
C443 QTE0J28-477Z E CAPACITOR 470uF 6.3V
C444 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C445 NCB31HK-152X C CAPACITOR 1500pF 50V K
C446 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C447 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C448 QTE1E28-476Z E CAPACITOR 47uF 25V
C449 QTE1E28-476Z E CAPACITOR 47uF 25V
C450 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C451 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C452 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C453 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C454 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C455 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C456 QTE1C46-107Z E CAPACITOR 100uF 16V
C457 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C458 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C460 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C461 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C462 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C463 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C464 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C471 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C500 NCS31HJ-471X C CAPACITOR 470pF 50V J
C501 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C502 NCS31HJ-101X C CAPACITOR 100pF 50V J
C503 NCS31HJ-101X C CAPACITOR 100pF 50V J
C504 NCS31HJ-101X C CAPACITOR 100pF 50V J
C505 NCS31HJ-101X C CAPACITOR 100pF 50V J
C506 NDC31HJ-150X C CAPACITOR 15pF 50V J
C507 NDC31HJ-180X C CAPACITOR 18pF 50V J
C508 NCS31HJ-101X C CAPACITOR 100pF 50V J
C509 NCS31HJ-101X C CAPACITOR 100pF 50V J
(No.XA011)3-9
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C510 NCS31HJ-101X C CAPACITOR 100pF 50V J
C511 NCS31HJ-101X C CAPACITOR 100pF 50V J
C512 NCS31HJ-101X C CAPACITOR 100pF 50V J
C513 NCS31HJ-101X C CAPACITOR 100pF 50V J
C514 NCS31HJ-101X C CAPACITOR 100pF 50V J
C515 NCS31HJ-101X C CAPACITOR 100pF 50V J
C516 NCS31HJ-101X C CAPACITOR 100pF 50V J
C517 NCS31HJ-101X C CAPACITOR 100pF 50V J
C518 NCS31HJ-101X C CAPACITOR 100pF 50V J
C519 NCS31HJ-101X C CAPACITOR 100pF 50V J
C520 NCS31HJ-101X C CAPACITOR 100pF 50V J
C521 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C522 NCS31HJ-101X C CAPACITOR 100pF 50V J
C523 NCS31HJ-101X C CAPACITOR 100pF 50V J
C524 QEZ0653-107Z E CAPACITOR 100uF
C525 NCS31HJ-101X C CAPACITOR 100pF 50V J
C526 NCS31HJ-101X C CAPACITOR 100pF 50V J
C527 QEZ0653-107Z E CAPACITOR 100uF
C528 NCS31HJ-101X C CAPACITOR 100pF 50V J
C529 NCS31HJ-101X C CAPACITOR 100pF 50V J
C530 NCS31HJ-101X C CAPACITOR 100pF 50V J
C531 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C532 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C533 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C534 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C535 NCS31HJ-101X C CAPACITOR 100pF 50V J
C536 NCS31HJ-101X C CAPACITOR 100pF 50V J
C537 NCS31HJ-101X C CAPACITOR 100pF 50V J
C539 NCS31HJ-101X C CAPACITOR 100pF 50V J
C540 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C541 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C542 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C543 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C544 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C545 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C547 NCS31HJ-101X C CAPACITOR 100pF 50V J
C548 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C550 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C552 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C553 QETN1EM-476Z E CAPACITOR 47uF 25V M
C554 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C555 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C556 NCS31HJ-101X C CAPACITOR 100pF 50V J
C557 NCS31HJ-101X C CAPACITOR 100pF 50V J
C558 NCS31HJ-101X C CAPACITOR 100pF 50V J
C559 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C560 NCS31HJ-101X C CAPACITOR 100pF 50V J
C562 QETN1EM-476Z E CAPACITOR 47uF 25V M
C563 QETN1EM-476Z E CAPACITOR 47uF 25V M
C565 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C567 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C568 QTE0J24-227Z E CAPACITOR 220uF 6.3V
C569 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C570 QETN1EM-476Z E CAPACITOR 47uF 25V M
C571 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C572 QETN1EM-476Z E CAPACITOR 47uF 25V M
C573 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C575 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C576 QETN1EM-476Z E CAPACITOR 47uF 25V M
C577 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C580 QETN1EM-476Z E CAPACITOR 47uF 25V M
C581 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C582 NRSA63J-0R0X MG RESISTOR 0
C586 QTE0J28-107Z E CAPACITOR 100uF 6.3V
C588 QETN1EM-476Z E CAPACITOR 47uF 25V M
C589 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C590 QETN1EM-476Z E CAPACITOR 47uF 25V M
C591 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C592 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C593 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C594 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C595 QETN1EM-476Z E CAPACITOR 47uF 25V M
C598 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C599 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C600 NCB31HK-103X C CAPACITOR 0.01uF 50V K only Europe
C601 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C604 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C606 NCB30JK-105X C CAPACITOR 1uF 6.3V K
Ω
1/16W J
3-10(No.XA011)
C608 QETN1HM-106Z E CAPACITOR 10uF 50V M only Europe
C609 QETN1EM-476Z E CAPACITOR 47uF 25V M
C610 QETN0JM-107Z E CAPACITOR 100uF 6.3V M only Europe
C611 QTE0J24-227Z E CAPACITOR 220uF 6.3V
C612 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C613 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C615 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C616 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C617 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C618 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C620 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C621 QETN1EM-226Z E CAPACITOR 22uF 25V M
C622 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C623 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C624 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C628 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C629 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C630 QFN31HJ-104Z M CAPACITOR 0.1uF 50V J
C631 QTE0J24-227Z E CAPACITOR 220uF 6.3V
C634 QETN1EM-476Z E CAPACITOR 47uF 25V M
C636 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C637 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C638 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C639 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C640 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C641 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C642 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C643 QEZ0653-107Z E CAPACITOR 100uF
C645 NCB31HK-221X C CAPACITOR 220pF 50V K
C651 QTE1A46-477Z E CAPACITOR 470uF 10V
C653 QTE1A46-477Z E CAPACITOR 470uF 10V
C655 QTE1A46-477Z E CAPACITOR 470uF 10V
C657 QTE1A46-477Z E CAPACITOR 470uF 10V
C659 QTE1A46-477Z E CAPACITOR 470uF 10V
C661 NCB31HK-221X C CAPACITOR 220pF 50V K
C662 NCS31HJ-471X C CAPACITOR 470pF 50V J
C663 NCS31HJ-121X C CAPACITOR 120pF 50V J
C664 NCS31HJ-121X C CAPACITOR 120pF 50V J
C665 NCS31HJ-121X C CAPACITOR 120pF 50V J
C666 NCS31HJ-470X C CAPACITOR 47pF 50V J
C667 NCS31HJ-101X C CAPACITOR 100pF 50V J
C668 NCS31HJ-101X C CAPACITOR 100pF 50V J
C700 QTE0J28-477Z E CAPACITOR 470uF 6.3V
C701 NCB31HK-152X C CAPACITOR 1500pF 50V K
C702 QFLC1HJ-182Z M CAPACITOR 1800pF 50V J
C703 QTE1E28-476Z E CAPACITOR 47uF 25V
C704 QTE1C46-227Z E CAPACITOR 220uF 16V
C705 QTE1C46-227Z E CAPACITOR 220uF 16V
C706 QTE1C46-227Z E CAPACITOR 220uF 16V
C707 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C708 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C709 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
C710 QTE1C46-227Z E CAPACITOR 220uF 16V
C711 QFLC1HJ-182Z M CAPACITOR 1800pF 50V J
C712 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C713 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
C714 QTE0J46-108Z E CAPACITOR 1000uF 6.3V
C715 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C716 QTE0J46-108Z E CAPACITOR 1000uF 6.3V
C717 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C718 NCB31HK-152X C CAPACITOR 1500pF 50V K
C719 NCS31HJ-151X C CAPACITOR 150pF 50V J
C720 QETN1EM-475Z E CAPACITOR 4.7uF 25V M
C721 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C722 QEZ0653-107Z E CAPACITOR 100uF
C723 QEZ0653-107Z E CAPACITOR 100uF
C724 NCS31HJ-331X C CAPACITOR 330pF 50V J
C725 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C726 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
C727 QFLC1HJ-121Z M CAPACITOR 120pF 50V J
C728 QFLC1HJ-182Z M CAPACITOR 1800pF 50V J
C729 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C730 QFVJ1HJ-224Z MF CAPACITOR 0.22uF 50V J
C731 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C732 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
C733 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C734 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C735 QFLC1HJ-182Z M CAPACITOR 1800pF 50V J
C736 QFLC1HJ-561Z M CAPACITOR 560pF 50V J
C737 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C739 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C740 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C741 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C746 QTE1E28-476Z E CAPACITOR 47uF 25V
C803 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C804 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C5001 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C5004 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C5005 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C5006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C5007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C5008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R101 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R102 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R103 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R104 NRS125J-270X MG RESISTOR 27Ω 1/2W J
R105 NRS125J-270X MG RESISTOR 27
R106 NRSA63J-273X MG RESISTOR 27k
R107 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R108 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R109 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R110 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R111 NRVA63D-243X CMF RESISTOR 24kΩ 1/16W D
R112 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R113 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R115 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R119 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R120 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R121 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R125 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R126 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R127 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R128 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R129 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R130 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R131 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R132 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R133 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R134 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R135 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R136 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R140 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R141 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R142 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R143 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R144 NRSA63J-103X MG RESISTOR 10k
R145 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R146 NRSA63J-102X MG RESISTOR 1k
R147 NRSA63J-222X MG RESISTOR 2.2k
R148 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R149 NRSA63J-223X MG RESISTOR 22k
R150 NRSA63J-223X MG RESISTOR 22k
R151 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R152 NRSA63J-103X MG RESISTOR 10k
R153 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R154 NRSA63J-122X MG RESISTOR 1.2k
R155 NRSA63J-821X MG RESISTOR 820
R156 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R157 NRSA63J-242X MG RESISTOR 2.4k
R201 NRSA63J-470X MG RESISTOR 47
R202 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R204 NRSA63J-273X MG RESISTOR 27k
R205 NRSA63J-273X MG RESISTOR 27k
R206 NRSA63J-303X MG RESISTOR 30k
R207 NRSA63J-473X MG RESISTOR 47k
R208 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R209 NRSA63J-223X MG RESISTOR 22k
R210 NRSA63J-392X MG RESISTOR 3.9k
R211 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R212 NRSA63J-103X MG RESISTOR 10k
R213 NRSA63J-103X MG RESISTOR 10k
R214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R215 NRSA63J-103X MG RESISTOR 10k
R216 NRSA63J-912X MG RESISTOR 9.1k
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R219 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R220 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R221 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R222 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R223 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R230 NRSA63J-332X MG RESISTOR 3.3k
R251 NRS125J-R47X MG RESISTOR 0.47
R252 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R254 NRSA63J-203X MG RESISTOR 20kΩ 1/16W J
R255 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R256 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R259 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R280 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R301 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R302 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R303 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R304 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R305 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R306 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R307 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R308 NRSA63J-0R0X MG RESISTOR 0
R309 NRSA63J-473X MG RESISTOR 47k
R313 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R317 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R320 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R321 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R323 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R324 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R325 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R326 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R327 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R328 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R329 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R330 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R331 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R332 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R333 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R334 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R336 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R337 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R338 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R339 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R340 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R341 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R342 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R344 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R345 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R347 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R348 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R401 NRVA63D-101X CMF RESISTOR 100
R402 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R403 NRSA63J-103X MG RESISTOR 10k
R404 NRVA63D-101X CMF RESISTOR 100
R405 NRVA63D-561X CMF RESISTOR 560Ω 1/16W D
R406 NRVA63D-561X CMF RESISTOR 560
R407 NRVA63D-273X CMF RESISTOR 27k
R408 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R409 NRVA63D-183X CMF RESISTOR 18k
R410 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R411 NRSA63J-221X MG RESISTOR 220
R412 QRE141J-102Y C RESISTOR 1k
R413 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R414 QRE141J-102Y C RESISTOR 1k
R415 NRSA63J-221X MG RESISTOR 220
R416 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R417 NRVA63D-751X CMF RESISTOR 750
R418 NRVA63D-751X CMF RESISTOR 750
R419 NRVA63D-751X CMF RESISTOR 750
R420 NRVA63D-751X CMF RESISTOR 750
R421 NRVA63D-363X CMF RESISTOR 36kΩ 1/16W D
R422 NRVA63D-162X CMF RESISTOR 1.6k
R423 NRVA63D-362X CMF RESISTOR 3.6k
R424 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R425 NRVA63D-362X CMF RESISTOR 3.6k
R426 NRVA63D-272X CMF RESISTOR 2.7k
R427 NRVA63D-162X CMF RESISTOR 1.6kΩ 1/16W D
R428 NRVA63D-363X CMF RESISTOR 36k
R429 NRVA63D-183X CMF RESISTOR 18k
Ω
1/16W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
(No.XA011)3-11
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R430 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R431 NRVA63D-303X CMF RESISTOR 30kΩ 1/16W D
R432 NRVA63D-303X CMF RESISTOR 30kΩ 1/16W D
R433 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R434 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R435 NRVA63D-303X CMF RESISTOR 30k
R436 NRVA63D-183X CMF RESISTOR 18k
R437 NRVA63D-303X CMF RESISTOR 30kΩ 1/16W D
R438 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R439 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R440 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R441 NRVA63D-332X CMF RESISTOR 3.3kΩ 1/16W D
R442 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R443 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R444 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R445 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R448 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R449 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R450 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R451 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R452 NRSA63J-100X MG RESISTOR 10
R453 NRVA63D-101X CMF RESISTOR 100
R454 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R455 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R456 NRVA63D-101X CMF RESISTOR 100Ω 1/16W D
R457 NRVA63D-561X CMF RESISTOR 560Ω 1/16W D
R458 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R459 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R460 NRVA63D-561X CMF RESISTOR 560Ω 1/16W D
R461 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R462 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R463 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R464 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R465 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R466 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R467 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R468 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R469 NRVA63D-751X CMF RESISTOR 750Ω 1/16W D
R471 NRVA63D-751X CMF RESISTOR 750Ω 1/16W D
R472 NRVA63D-751X CMF RESISTOR 750Ω 1/16W D
R473 NRVA63D-751X CMF RESISTOR 750Ω 1/16W D
R474 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R475 NRVA63D-162X CMF RESISTOR 1.6kΩ 1/16W D
R476 NRVA63D-363X CMF RESISTOR 36kΩ 1/16W D
R477 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R478 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R479 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R480 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R481 NRVA63D-303X CMF RESISTOR 30kΩ 1/16W D
R482 NRVA63D-303X CMF RESISTOR 30k
R483 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R484 NRVA63D-272X CMF RESISTOR 2.7k
R485 NRVA63D-272X CMF RESISTOR 2.7k
R486 NRVA63D-363X CMF RESISTOR 36kΩ 1/16W D
R487 NRVA63D-162X CMF RESISTOR 1.6k
R488 NRVA63D-183X CMF RESISTOR 18k
R489 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R490 NRVA63D-303X CMF RESISTOR 30k
R491 NRVA63D-303X CMF RESISTOR 30kΩ 1/16W D
R492 NRSA63J-470X MG RESISTOR 47
R493 NRSA63J-470X MG RESISTOR 47
R494 NRVA63D-332X CMF RESISTOR 3.3kΩ 1/16W D
R495 NRSA63J-220X MG RESISTOR 22
R496 NRSA63J-471X MG RESISTOR 470
R497 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R498 NRSA63J-100X MG RESISTOR 10
R499 NRSA63J-100X MG RESISTOR 10
R501 NRSA63J-470X MG RESISTOR 47
R502 NRSA63J-100X MG RESISTOR 10
R504 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R510 NRSA63J-0R0X MG RESISTOR 0
R511 NRSA63J-0R0X MG RESISTOR 0
R512 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R513 NRSA63J-0R0X MG RESISTOR 0
R515 NRSA63J-0R0X MG RESISTOR 0
R516 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R517 NRSA63J-0R0X MG RESISTOR 0
R519 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W D
Ω
1/16W D
Ω
1/16W J
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-12(No.XA011)
R527 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R529 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R533 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R563 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R564 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R565 NRSA63J-473X MG RESISTOR 47k
R566 NRVA63D-122X CMF RESISTOR 1.2k
R567 NRSA63F-820X MG RESISTOR 82Ω 1/16W F
R568 NRSA63F-750X MG RESISTOR 75Ω 1/16W F
R570 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R573 NRSA63J-162X MG RESISTOR 1.6kΩ 1/16W J
R574 NRSA63J-162X MG RESISTOR 1.6kΩ 1/16W J
R575 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R576 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R578 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R583 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R589 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R600 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R603 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R604 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R605 NRSA63J-102X MG RESISTOR 1k
R607 NRSA63J-103X MG RESISTOR 10k
R608 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R609 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R610 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R611 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R612 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R613 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R614 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R618 NRSA63F-750X MG RESISTOR 75Ω 1/16W F
R622 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R624 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J only Europe
R625 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J only Europe
R626 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J only Europe
R628 NRSA63F-101X MG RESISTOR 100Ω 1/16W F
R629 NRSA63F-101X MG RESISTOR 100Ω 1/16W F
R630 NRSA63F-750X MG RESISTOR 75Ω 1/16W F
R631 NRVA63D-272X CMF RESISTOR 2.7kΩ 1/16W D
R632 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J only Europe
R637 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J only Europe
R639 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R643 NRSA63F-820X MG RESISTOR 82Ω 1/16W F
R644 NRSA63F-620X MG RESISTOR 62Ω 1/16W F only Europe
R644 NRSA63F-680X MG RESISTOR 68Ω 1/16W F except Europe
R645 NRSA63F-620X MG RESISTOR 62Ω 1/16W F only Europe
R645 NRSA63F-680X MG RESISTOR 68Ω 1/16W F except Europe
R646 NRSA63F-750X MG RESISTOR 75Ω 1/16W F
R649 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R654 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J except Europe
R700 NRSA63J-105X MG RESISTOR 1M
R701 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R702 NRSA63J-104X MG RESISTOR 100k
R703 NRVA63D-101X CMF RESISTOR 100
R704 NRVA63D-561X CMF RESISTOR 560Ω 1/16W D
R705 NRSA63J-103X MG RESISTOR 10k
R706 NRVA63D-273X CMF RESISTOR 27k
R709 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R710 NRSA63J-473X MG RESISTOR 47k
R711 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R712 NRSA63J-473X MG RESISTOR 47k
R713 NRSA63J-221X MG RESISTOR 220
R714 QRE141J-821Y C RESISTOR 820Ω 1/4W J
R715 NRVA63D-183X CMF RESISTOR 18k
R716 NRSA63J-221X MG RESISTOR 220
R717 NRVA63D-621X CMF RESISTOR 620Ω 1/16W D
R718 NRVA63D-183X CMF RESISTOR 18k
R719 QRE141J-821Y C RESISTOR 820
R720 NRSA63J-221X MG RESISTOR 220
R721 NRSA63J-221X MG RESISTOR 220
R722 NRVA63D-621X CMF RESISTOR 620Ω 1/16W D
R723 NRVA63D-681X CMF RESISTOR 680
R724 NRVA63D-362X CMF RESISTOR 3.6k
R725 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R726 NRVA63D-273X CMF RESISTOR 27k
R727 NRSA63J-473X MG RESISTOR 47k
R728 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R729 NRVA63D-332X CMF RESISTOR 3.3k
R730 NRVA63D-362X CMF RESISTOR 3.6k
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W D
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W D
Ω
1/16W D
Ω
1/16W J
Ω
1/16W D
Ω
1/16W D
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R731 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R732 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R733 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R734 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R735 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R736 NRVA63D-273X CMF RESISTOR 27k
R737 NRSA63J-470X MG RESISTOR 47
R739 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R740 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R742 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R743 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R744 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R745 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R746 NRVA63D-332X CMF RESISTOR 3.3kΩ 1/16W D
R747 NRVA63D-362X CMF RESISTOR 3.6kΩ 1/16W D
R748 NRVA63D-681X CMF RESISTOR 680Ω 1/16W D
R749 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R750 NRVA63D-101X CMF RESISTOR 100Ω 1/16W D
R751 NRVA63D-561X CMF RESISTOR 560Ω 1/16W D
R752 NRVA63D-273X CMF RESISTOR 27kΩ 1/16W D
R753 NRSA63J-105X MG RESISTOR 1M
R754 NRVA63D-183X CMF RESISTOR 18k
R755 NRVA63D-183X CMF RESISTOR 18kΩ 1/16W D
R756 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R757 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R758 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R759 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R760 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R761 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R762 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R763 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R764 NRSA63J-621X MG RESISTOR 620Ω 1/16W J
R765 NRSA63J-621X MG RESISTOR 620Ω 1/16W J
R766 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R767 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R768 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R769 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J 77US
R769 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R771 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R772 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R773 NRVA63D-332X CMF RESISTOR 3.3kΩ 1/16W D
R774 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R775 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J only Europe
R776 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J only Europe
R821 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R822 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R953 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J except Europe
R1001 NRSA63J-0R0X MG RESISTOR 0
R2001 NRSA63J-0R0X MG RESISTOR 0
R2002 NRSA63J-0R0X MG RESISTOR 0
R4001 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R4002 NRSA63J-471X MG RESISTOR 470
R4003 NRSA63J-471X MG RESISTOR 470
R4004 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R7001 NRSA63J-0R0X MG RESISTOR 0
L501 NQL77GM-100X COIL 10uH M
L505 QQL244K-100Z COIL 10uH K
L506 QQL244K-100Z COIL 10uH K
L507 QQL244K-100Z COIL 10uH K
L508 QQL244K-100Z COIL 10uH K
L601 NQL77GM-100X COIL 10uH M
L603 NQL77GM-100X COIL 10uH M
L604 NQR0430-001X COIL
L605 NQR0429-001X LPF
L606 NQR0429-001X LPF
L701 QQL232K-1R0Z COIL 1uH K
CN101 QGF0529C1-50W CONNECTOR FFC/FPC (1-50)
CN501 QGF1201C3-17 CONNECTOR FFC/FPC (1-17)
CN601 QGF1201C3-15 CONNECTOR FFC/FPC (1-15) only Europe
CN801 QGF1016F2-23W CONNECTOR FFC/FPC (1-23)
CN802 QGF1016F3-09 CONNECTOR FFC/FPC (1-9)
CN803 QGF1016F2-21W CONNECTOR FFC/FPC (1-21)
DI801 QLF0130-001 FL TUBE
FW501 QUM106-24DGZ4 PARA RIBON WIRE
FW502 QUM103-30DGZ4 PARA RIBON WIRE
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
only ver.UF,US,UJ
77A,77UF,
77UJ,77UW
J401 QNN0583-001 PIN JACK
J602 QNN0582-001 PIN JACK
J604 QND0114-001 PIN JACK
J700 QNN0581-001 PIN JACK
J701 QNZ0656-001 PIN+OPT JACK
K101 NQR0007-002X FERRITE BEADS
K404 NQR0007-002X FERRITE BEADS
K406 NQR0007-002X FERRITE BEADS
K407 NQR0007-002X FERRITE BEADS
K409 NQR0007-002X FERRITE BEADS
K410 NQR0007-002X FERRITE BEADS
K412 NQR0007-002X FERRITE BEADS
K508 NQR0007-002X FERRITE BEADS
K509 NQR0007-002X FERRITE BEADS
K514 NQR0129-002X FERRITE BEADS
K515 NQR0129-002X FERRITE BEADS
K516 NQR0129-002X FERRITE BEADS
K517 NQR0129-002X FERRITE BEADS
K518 NQR0129-002X FERRITE BEADS
K601 NQR0007-002X FERRITE BEADS
K603 NQR0007-002X FERRITE BEADS
K604 NQR0007-002X FERRITE BEADS only Europe
K701 NQR0007-002X FERRITE BEADS
K702 NQR0227-004X FERRITE BEADS
K703 NQR0007-002X FERRITE BEADS
K704 NQR0007-002X FERRITE BEADS
K705 NQR0227-004X FERRITE BEADS
K706 NQR0227-004X FERRITE BEADS
S801 QSW0651-001Z TACT SWITCH
X301 NAX0566-001X C RESONATOR 16.934MHz
X571 NAX0550-001X CRYSTAL 27.000MHz
OT1 VPZ4011-003 SERIAL LABEL 77US
OT2 GN30006-020A SPACER 77US
OT3 GN30006-021A SPACER 77US
OT4 VPZ4011-003 SERIAL LABEL
OT5 VPZ4011-003 SERIAL LABEL except ver.US
OT6 GN30006-020A SPACER except ver.US
OT7 GN30006-021A SPACER except ver.US
(No.XA011)3-13
Power supply and system control board
Block No. [0][3]
Symbol No.
IC851 IC-PST3527N-X IC
IC901 MIP2C50MPSCF IC
IC902 MN101C35DLT IC(1-TIME)
IC904 TL431/A/-T IC
Q611 2SC3576-JVC-T TRANSISTOR only Europe
Q612 2SC3576-JVC-T TRANSISTOR only Europe
Q613 KRC102S-X DIGI TRANSISTOR only Europe
Q614 KRA102S-X DIGI TRANSISTOR only Europe
Q827 KRC107S-X DIGI TRANSISTOR
Q851 KRC107S-X DIGI TRANSISTOR
Q852 2SC1740S/RS/-T TRANSISTOR
Q951 2SC3576-JVC-T TRANSISTOR
Q952 KRA104S-X DIGI TRANSISTOR
D822 SLR343BBT3F LED
D823
D826
D851 1SS133-T2 DIODE
D852 1SS133-T2 DIODE
D901 DI106 BRIDGE DIODE
D903 SARS01-T2 SI DIODE
D904 1SS244-T2 SI DIODE
D905 RB441Q-40-T2 SI DIODE IM
D951 1F4-T2 FR DIODE
D952 1F4-T2 FR DIODE
D953 SB360-F82 SB DIODE
D954 1F4-T2 FR DIODE
D955 ER204-F33 FR DIODE
D956 1F4-T2 FR DIODE
D957 1F4-T2 FR DIODE
D960 MTZJ3.6B-T2 Z DIODE
PC901 PC123Y22FZ
C669 NCS31HJ-101X C CAPACITOR 100pF 50V J only Europe
C670 QFN31HJ-471Z M CAPACITOR 470pF 50V J only Europe
C678 QTE1A46-477Z E CAPACITOR 470uF 10V only Europe
C680 QTE1A46-477Z E CAPACITOR 470uF 10V only Europe
C681 QFN31HJ-471Z M CAPACITOR 470pF 50V J only Europe
C683 QTE1E28-476Z E CAPACITOR 47uF 25V only Europe
C684 QTE1E28-476Z E CAPACITOR 47uF 25V only Europe
C685 NCB31HK-152X C CAPACITOR 1500pF 50V K only Europe
C686 NCS31HJ-121X C CAPACITOR 120pF 50V J only Europe
C687 NCS31HJ-121X C CAPACITOR 120pF 50V J only Europe
C688 NCS31HJ-121X C CAPACITOR 120pF 50V J only Europe
C689 NCS31HJ-121X C CAPACITOR 120pF 50V J only Europe
C691 QTE1A46-477Z E CAPACITOR 470uF 10V only Europe
C693 QTE1A46-477Z E CAPACITOR 470uF 10V only Europe
C695 QTE1A46-477Z E CAPACITOR 470uF 10V only Europe
C851 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C852 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C853 QETN0JM-227Z E CAPACITOR 220uF 6.3V M
C854 NCB31HK-331X C CAPACITOR 330pF 50V K
C855 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C856 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C857 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C858 NCS31HJ-101X C CAPACITOR 100pF 50V J
C861 QETN1EM-106Z E CAPACITOR 10uF 25V M
C862 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C902 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
C904 QCZ9079-471 C CAPACITOR 470pF AC250V K
C905 QCZ9079-471 C CAPACITOR 470pF AC250V K
C906 QCZ9079-102 C CAPACITOR 1000pF AC250V M
C907 QETM2DM-107 E CAPACITOR 100uF 200V M only ver.J,C
C907 QEZ0590-686 E CAPACITOR 68uF 400V M 77US
C907 QEZ0590-686 E CAPACITOR 68uF 400V M
C908 QCZ0136-332Z C CAPACITOR 3300pF 1kV K
C913 QCZ0302-470Z C CAPACITOR 47pF 1kV J
C914 QEZ0657-226Z E CAPACITOR 22uF
C915 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C918 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
3-14(No.XA011)
Part No. Part Name Description Local
SPR-325MVW/L/-T
204-10SUBC/A4VW
LED GREEN-RED
LED
PHOTO COUPLER
Photo coupler
77A,77B,77E,77E
E,77EN,77EV,
77UF,77UJ,77UW
Symbol No.
C950 QEZ0653-107Z E CAPACITOR 100uF
C951 QETN1EM-226Z E CAPACITOR 22uF 25V M
C952 QEZ0592-108Z E CAPACITOR 1000uF
C953 QEZ0657-226Z E CAPACITOR 22uF
C954 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C955 QTE1A46-477Z E CAPACITOR 470uF 10V
C956 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C957 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C958 QEZ0654-477Z E CAPACITOR 470uF
C959 QTE1A46-477Z E CAPACITOR 470uF 10V
C960 NCS31HJ-331X C CAPACITOR 330pF 50V J
C963 QEZ0655-187Z E CAPACITOR 180uF
C964 QEZ0655-187Z E CAPACITOR 180uF
C965 QTE1C28-227Z E CAPACITOR 220uF 16V only Europe
C965 QTE1C28-107Z E CAPACITOR 100uF 16V except Europe
C966 QTE1C28-227Z E CAPACITOR 220uF 16V only Europe
C966 QTE1C28-107Z E CAPACITOR 100uF 16V except Europe
C967 QEZ0655-337Z E CAPACITOR 330uF
C969 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C980 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C981 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C982 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C988 QETN1CM-227Z E CAPACITOR 220uF 16V M
R658 QRE141J-750Y C RESISTOR 75Ω 1/4W J only Europe
R659 NRSA63J-750X MG RESISTOR 75Ω 1/16W J only Europe
R660 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J only Europe
R661 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J only Europe
R662 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J only Europe
R663 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J only Europe
R664 QRE141J-561Y C RESISTOR 560Ω 1/4W J only Europe
R665 QRE141J-561Y C RESISTOR 560Ω 1/4W J only Europe
R670 NRSA63J-101X MG RESISTOR 100Ω 1/16W J only Europe
R678 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J only Europe
R681 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R691 QRE141J-151Y C RESISTOR 150Ω 1/4W J only Europe
R692 QRE141J-750Y C RESISTOR 75Ω 1/4W J only Europe
R693 QRE141J-151Y C RESISTOR 150Ω 1/4W J only Europe
R694 QRE141J-750Y C RESISTOR 75Ω 1/4W J only Europe
R814 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R817 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R818 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R819 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R820 NRSA63J-431X MG RESISTOR 430Ω 1/16W J
R851 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R853 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R854 QRE141J-270Y C RESISTOR 27Ω 1/4W J
R856 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R858 NRSA63J-820X MG RESISTOR 82Ω 1/16W J
R862 NRSA63J-222X MG RESISTOR 2.2k
R879 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R880 NRSA63J-222X MG RESISTOR 2.2k
R881 NRSA63J-222X MG RESISTOR 2.2k
R882 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R883 NRSA63J-222X MG RESISTOR 2.2k
R884 NRSA63J-103X MG RESISTOR 10k
R885 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J except Europe
R887 NRSA63J-102X MG RESISTOR 1k
R889 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R891 NRSA63J-222X MG RESISTOR 2.2k
R893 NRSA63J-102X MG RESISTOR 1k
R894 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R895 NRSA63J-101X MG RESISTOR 100
R901 QRL01DJ-683X OMF RESISTOR 68kΩ 1W J
R902 QRL01DJ-470X OMF RESISTOR 47Ω 1W J
R903 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R904 QRL127J-470 OMF RESISTOR 47
R906 QRE141J-274Y C RESISTOR 270k
R910 QRZ9037-335
R912 QRE141J-223Y C RESISTOR 22kΩ 1/4W J
R913 NRSA63J-103X MG RESISTOR 10k
R915 QRE141J-103Y C RESISTOR 10k
R950 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R952 NRSA63J-103X MG RESISTOR 10k
R954 QRZ9005-100X FUSI RESISTOR 10
R955 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R956 NRSA63J-103X MG RESISTOR 10k
Part No. Part Name Description Local
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J only Europe
Ω
1/16W J only Europe
Ω
1/16W J
Ω
1/16W J
except ver.J,C
of XV-NA77SL
Ω
1/2W J only ver.J,C
Ω
COMP RESISTOR
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
1/4W J
3.3MΩ 1/2W K
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
Ω
1/16W J
Symbol No.
R960 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R961 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R962 NRSA63F-512X MG RESISTOR 5.1kΩ 1/16W F
R964 NRSA63F-103X MG RESISTOR 10kΩ 1/16W F
R968 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
RA1 QRB149J-104 NET RESISTOR 100k
RA2 QRB149J-104 NET RESISTOR 100k
L851 QQL231K-2R2Y COIL 2.2uH K
L901 QQR0816-001 LINE FILTER
L951 QQR1291-001Z CHOKE COIL
L952 QQR1291-001Z CHOKE COIL
L953 QQL244K-220Z COIL 22uH K
L954 QQL244K-220Z COIL 22uH K
L955 QQR1291-001Z CHOKE COIL
T901 QQS0220-001 SW TRANSF
CN651 QGF1201C3-15 CONNECTOR FFC/FPC (1-15) only Europe
CN852 QGF1016F3-09 CONNECTOR FFC/FPC (1-9)
CN861 QGF1016C1-23 CONNECTOR FFC/FPC (1-23)
CN862 QGF1016C1-21 CONNECTOR FFC/FPC (1-21)
CN901 QGD2504C1-03Z CONNECTOR (1-3)
CN902 QGD2504C1-03Z CONNECTOR (1-3)
CN903 QGD2504C1-03Z CONNECTOR (1-3)
CN904 QGF1201C3-17 CONNECTOR FFC/FPC (1-17)
CP951 ICP-N10-T IC PROTECTOR 400mA
EP951 QNZ0136-001Z EARTH PLATE
EP952 E409182-001SM GRAND TERMINAL
EP953 QNZ0136-001Z EARTH PLATE
EP954 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
J603 QNZ0610-001 RGB CONNECTOR only Europe
J851 QNS0221-001 3.5 JACK
K981 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
K982 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
K983 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
K984 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
K985 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
P901 QGA7901C1-02 CONNECTOR W-B (1-2)
S601 QSW0986-001 SLIDE SWITCH
S802 QSW0651-001Z TACT SWITCH
S803 QSW0651-001Z TACT SWITCH
S804 QSW0651-001Z TACT SWITCH
S805 QSW0651-001Z TACT SWITCH
S806 QSW0651-001Z TACT SWITCH
S807 QSW0651-001Z TACT SWITCH
S901 QSW0454-001 SW 77US
S901 QSW0454-001 SW
X851 QAX0667-001Z C RESONATOR 8.000MHz
OT1 LE40845-001A FUSE LABEL 77US
OT2 LE40845-001A FUSE LABEL
Part No. Part Name Description Local
Ω
J
Ω
J
77A,77B,77E,77
EE,77EN,77EV,
77UF,77UW
77A,77B,77E,77E
E,77EN,77EV,
77UF,77UJ,77UW
Switch board
Block No. [0][4]
Symbol No.
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
Part No. Part Name Description Local
(No.XA011)3-15
Packing materials and accessories parts list
INST BOOK SA
Block No.M4MM
INST BOOK SA
P3
P1
FRONT
P5
P4
P2
A9
MODEL
MODEL
A1
A10
A7
A10
A5
A6
A16A15
A3
Important......
A13
A10
A2
A4
A12
A8
A11A14
3-16(No.XA011)
Packing and accessories
Block No. [M][4][M][M]
Symbol No. Part No. Part Name Description Local
A 1 GNT0036-022B INST BOOK English French 70C
A 1 GNT0036-001B INST BOOK English 70J
A 1 GNT0036-002B INST BOOK English 77B
A 1 GNT0036-022B INST BOOK English French 77C
A 1 GNT0036-005B INST BOOK Dutch 77E
A 1 GNT0036-014A INST BOOK Russian 77EE
A 1 GNT0036-003B INST BOOK German 77E,77EN
A 1 GNT0036-004B INST BOOK French 77E,77EN
A 1 GNT0036-006B INST BOOK Spanish 77EN
A 1 GNT0036-007B INST BOOK Italian 77EN
A 1 GNT0036-008B INST BOOK Swedish 77EN
A 1 GNT0036-009B INST BOOK Finnish 77EN
A 1 GNT0036-010B INST BOOK Danish 77EN
A 1 GNT0036-011A INST BOOK Polish 77EV
A 1 GNT0036-012A INST BOOK Hungarian 77EV
A 1 GNT0036-013A INST BOOK Czech 77EV
A 1 GNT0036-019A INST BOOK Simplified Chinese 77UF
A 1 GNT0036-001B INST BOOK English 77J,77UJ
A 1 GNT0036-018B INST BOOK Simplified Chinese 77US
A 1 GNT0036-015B INST BOOK English 77A,77US,77UW
A 1 GNT0036-016B INST BOOK Spanish 77UW
A 1 GNT0036-017B INST BOOK Portuguese 77UW
A 2 YU20333 SAFETY INST. only ver.J,C,UJ
A 3 BT-51028-2 J=REGIST CARD 70J,77J,77UJ
A 3 BT-51034-1 J=REGIST CARD 70J,77J,77UJ
A 4 LE30964-001A NETFLIX COUPO 70J,77J
A 5 QAM0328-001 AV CORD 3P
A 6 EWP302-011W SIGNAL CORD (x2)
A 7 RM-SXV045J REMOCON UNIT 70C,70J
A 7 RM-SXV047E REMOCON UNIT only Europe
A 7 RM-SXV046J REMOCON UNIT 77C,77J
A 7 RM-SXV048U REMOCON UNIT 77A,77UF,77UJ,77US,77UW
A 8 ------------ BATTERY FOR EXP.(x2)
A 9 QPC02504015P POLY BAG FOR ACC INST
A10 BT-56012-1 WARRANTY CARD 77A
A10 BT-52006-2 WARRANTY CARD 70C,77C
A10 BT-54008-5 WARRANTY CARD 77B,77E
A10 BT-59019-1 WARRANTY CARD 77UF
A11 LE40932-005A INSERT SHEET 77UF
A12 QAM0112-002 PLUG ADAPTOR 77UJ,77US,77UW
A13 VNA3000-204 REGISTER CARD 77B
A14 BT-56002-2 SVC CENTER LIST 77A
A14 BT-59021-1 S.CENTER LIST 77UF
A15 LE40975-002A CAUTION SHEET 77EE,77EV
A16 GN30076-001A SURVEY CARD 77UF
P 1 QPC06005515P POLY BAG FOR SET
P 2 GN10046-013A PACKING CASE 70C,70J
P 2 GN10046-021A PACKING CASE 77A
P 2 GN10046-015A PACKING CASE 77B
P 2 GN10046-017A PACKING CASE 77EE
P 2 GN10046-016A PACKING CASE 77E,77EN,77EV
P 2 GN10046-024A PACKING CASE 77UF
P 2 GN10046-026A PACKING CASE 77C,77J,77UJ
P 2 GN10046-019A PACKING CASE 77US
P 2 GN10046-018A PACKING CASE 77UW
P 3 GN20069-001A PACKING PAD(L) LEFT 77UF
P 3 GN20065-001A PACKING PAD(L) LEFT only ver.J,C,UJ
P 3 GN20067-001A PACKING PAD(L) LEFT 77A,77B,77E,77EE,77EN,77EV,77US,77UW
P 4 GN20070-001A PACKING PAD(R) RIGHT 77UF
P 4 GN20066-001A PACKING PAD(R) RIGHT only ver.J,C,UJ
P 4 GN20068-001A PACKING PAD(R) RIGHT 77A,77B,77E,77EE,77EN,77EV,77US,77UW
P 5 GN30068-001A SHEET ASSY 77A,77B
<Local area>
XV-NA70BK C:70 J:70J XV-NA77SL A:77A B:77B C:77C E:77E
EE:77EE EN:77EN EV:77EV J:77J UF:77UF UJ:77UJ US:77US
(No.XA011)3-17
Loading...
