JVC SR-DVM700U User Manual

Mini DV & HDD & DVD VIDEO RECORDER

SR-DVM700U

DVDTV

STANDBY/ON

OUTPUT

VIDEO

SELECT

DV HDD DVD

PR/CH

CANCEL

MEMO/MARK

INPUTSELECT

EDIT

PROG

NAVIGATIONTOPME NU

ENTER

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY

PAUSEREC

STOP/CLEAR

DISPLAY

ONSCREEN

RECMODE/

AUDIO

SUBTITLE

REMAIN

PROGRESSIVE

SCAN

STANDBY/ON

ANGLE/

EECHECK

SETUPDUBBINGEE

S-VIDEO

INF-1

VIDEO(MONO)L -AUDIO - R

INPUT

OUTPUT

SELECT

EJECTEJECTDISPLAY

RECDVDRECHDDRECDV

DV/HDD/DVD RECMODE INSTANTREPLAY AUDIODUB. INSERT

RECPAUSEPLAY

FFREWSTOP

DVIN/ OUT

NTSC

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located on the rear of cabinet. Retain this information for future reference.

Model No.

Serial No.

LPT1135-001A

2 EN

SAFETY FIRST

Dear Customer,

Thank you for purchasing the JVC Mini DV & HDD & DVD video recorder. Before use, please read the safety information and precautions to ensure safe use of your new unit.

Cautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

CAUTION:

A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.

WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT REPRODUCTION OF LABELS

WARNING LABEL INSIDE OF THE UNIT

This unit apply to the standard AIEC60825-1:2001B for laser products.

RISQUE DE CHOC ELECTRIQUE

AVIS

- NE PAS OUVRIR.

KLASS 1 M LASERSTRÅLNING NÅR DEN ÄR ÖPPEN. TITTA INTE DIREKT PÅ DEN MED OPTISKA INSTRUMENT.

(SW)

LP41334-001A

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION:

This unit should be used with AC 120VH, 60Hz only. To prevent electric shocks and fire hazards, DO NOT use any other power source.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

CAUTION:

Changes or modifications not approved by JVC could void user’s authority to operate the equipment.

Declaration of Conformity

Model Number: SR-DVM700U Trade Name: JVC Responsible Party: JVC Americas Corp. Address: 1700 Valley Road Wayne, N.J. 07470 Telephone Number: 973-317-5000 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

IMPORTANT PRODUCT SAFETY INSTRUCTIONS

Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.

ATTENTION:

Follow and obey all warnings and instructions marked on your product and its operating instructions. For your safety, please read all the safety and operating instructions before you operate this product and keep this booklet for future reference.

INSTALLATION

1. Grounding or Polarization

(A)Your product may be equipped with a polarized alternating-

current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

(B)Your product may be equipped with a 3-wire grounding-type

plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

2. Power Sources

Operate your product only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. If your product is intended to operate from battery power, or other sources, refer to the operating instructions.

3. Overloading

Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

4. Power Cord Protection

Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

5. Ventilation

Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered.

● Do not block the openings by placing the product on a bed, sofa,

rug or other similar surface.

● Do not place the product in a built-in installation such as a

bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

6. Wall or Ceiling Mounting

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

SAFETY FIRST

ANTENNA INSTALLATION INSTRUCTIONS

1. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

2. Lightning

For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

3. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

EN 3

4 EN

SAFETY FIRST

USE

1. Accessories

To avoid personal injury:

● Do not place this product on an unstable cart, stand, tripod,

bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the product.

● Use only with a cart, stand, tripod, bracket, or table

recommended by the manufacturer or sold with the product.

● Use a mounting accessory recommended by the manufacturer

and follow the manufacturer’s instructions for any mounting of the product.

● Do not try to roll a cart with small casters across thresholds or

deep-pile carpets.

2. Product and Cart Combination

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

3. Water and Moisture

Do not use this product near water^for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.

4. Object and Liquid Entry

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or shortout parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

5. Attachments

Do not use attachments not recommended by the manufacturer of this product as they may cause hazards.

6. Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

7. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

SERVICING

1. Servicing

If your product is not operating correctly or exhibits a marked change in performance and you are unable to restore normal operation by following the detailed procedure in its operating instructions, do not attempt to service it yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

2. Damage Requiring Service

Unplug this product from the wall outlet and refer servicing to

qualified service personnel under the following conditions: a. When the power supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the product. c. If the product has been exposed to rain or water. d. If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper

adjustment of other controls may result in damage and will often

require extensive work by a qualified technician to restore the

product to its normal operation. e. If the product has been dropped or damaged in any way. f. When the product exhibits a distinct change in

performance^this indicates a need for service.

3. Replacement Parts

When replacement parts are required, be sure the service

technician has used replacement parts specified by the

manufacturer or which have the same characteristics as the

original part. Unauthorized substitutions may result in fire,

electric shock or other hazards.

4. Safety Check

Upon completion of any service or repairs to this product, ask

the service technician to perform safety checks to determine

that the product is in safe operating condition.

HOW TO USE THIS INSTRUCTION MANUAL

● All major sections and subsections are listed in the Table Of

Contents on page 6. Use this when searching for information on a specific procedure or feature.

● The Index on pages 12 - 15 illustrates the controls and

connections on the front and rear panel, the front display panel and the remote control.

● The list of terms on page 86 lists frequently-used terms, and the

number of the page on which they are used or explained in the manual.

● The A mark signals a reference to another page for instructions

or related information.

● Operation buttons necessary for the various procedures are

clearly indicated through the use of illustrations at the beginning of each major section.

BEFORE YOU INSTALL YOUR NEW UNIT . . .

. . . please read the sections/literature listed below.

● ACautionsB on page 2

● AIMPORTANT PRODUCT SAFETY INSTRUCTIONSB on

pages 3 - 4

NTSC

● Manufactured under license from Dolby Laboratories. ADolbyB

and the double-D symbol are trademarks of Dolby Laboratories.

● ADTSB and ADTS DIGITAL OUTB are trademarks of Digital

Theater Systems, Inc.

● This unit can play back and record only NTSC signals. PAL

signals can also be played back on the DVD deck.

● This product incorporates copyright protection technology that is

protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

Failure to heed the following precautions may result in damage to the unit, remote control or disc/cassette.

1. DO NOT

place the unit ^

^ in an environment prone to extreme temperatures or

humidity.

^ in direct sunlight. ^ in a dusty environment. ^ in an environment where strong magnetic fields are

generated.

^ on a surface that is unstable or subject to vibration.

2. DO NOT

block the unit’s ventilation openings or holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3. DO NOT

4. DO NOT

place heavy objects on the unit or remote control. place anything which might spill on top of the unit

or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

5. DO NOT

6. DO NOT

expose the apparatus to dripping or splashing. use this equipment in a bathroom or places with

water. Also DO NOT place any containers filled with water or

liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

7. DO NOT

place any naked flame sources, such as lighted

candles, on the apparatus.

8. AVOID

violent shocks to the unit during transport.

SAFETY FIRST

EN 5

MOISTURE CONDENSATION

Moisture in the air will condense on the unit when you move it from a cold place to a warm place, or under extremely humid conditions^just as water droplets form on the surface of a glass filled with cold liquid. In conditions where condensation may occur, disconnect the unit’s power plug from the wall and keep it disconnected for a few hours to let the moisture dry, then turn on the unit.

DISCLAIMER OF LIABILITY

JVC shall not be liable for any loss relating to the unit’s failure to properly record, store or playback any content (video, audio or otherwise) for any reason whatsoever. Any applicable warranties shall only cover replacement or repair of the effected unit, and shall not apply to recovery or replacement of lost content.

ATTENTION:

8 Using a mobile phone in the vicinity of the unit may cause

picture vibration on the TV screen or change the screen to a black back display.

8 Some TVs or other appliances generate strong magnetic

fields. Do not place such appliances on top of the unit as it may cause picture disturbance.

8 When moving the product, press A to turn off the power,

and wait at least 30 seconds before unplugging the power cord. Then, wait at least 2 minutes before moving the product.

8 If there is a power outage when using the unit, the recorded

data may be erased.

8 It is recommended to back up discs which contain important

recordings periodically (every few years). As digital signals do not deteriorate, failure to play back or record might arise due to the effects of the disc aging through the years depending on the storage environment.

8 Recorded programs and data cannot be restored once the

disc or tape is damaged.

6 EN

CONTENTS

SAFETY FIRST 2

DISC INFORMATION 7

About Discs....................................................................................7

Life Span Of Parts........................................................................11

INDEX 12

INSTALLING YOUR NEW UNIT 18

Basic Connections .......................................................................18

INITIAL SETTINGS 19

Clock Set......................................................................................19

Language .....................................................................................20

Monitor Set...................................................................................21

BASIC OPERATIONS ON DVD DECK 22

Basic Playback.............................................................................22

Playback Features .......................................................................23

Using The On-screen Bar ............................................................27

BASIC OPERATIONS ON HDD DECK 31

Basic Playback.............................................................................31

Playback Features .......................................................................31

BASIC OPERATIONS ON DV DECK 33

Basic Playback.............................................................................33

Playback Features .......................................................................34

LIVE MEMORY PLAYBACK ON HDD/DVD DECK 35

Live Memory Playback.................................................................35

NAVIGATION ON HDD/DVD DECK 38

Library Database Navigation........................................................38

Edit Original Information...............................................................39

Edit Play List Information .............................................................42

Navigate Library Information........................................................44

Playback With MP3/WMA/JPEG Navigation................................45

EDITING 46

Dubbing .......................................................................................46

DV Dubbing (HDD & DVD Deck Only) ........................................ 50

Edit From A Camcorder............................................................... 52

Edit To Or From Another Recorder ............................................. 53

Dubbing DV Format Contents To A DV Device

(HDD Deck Only) ...................................................................... 54

Digital Audio Dubbing .................................................................. 55

Audio Dubbing (DV Deck Only) ................................................... 56

Insert Editing (DV Deck Only)...................................................... 57

REMOTE CONTROL 58

Remote Control Functions........................................................... 58

SYSTEM CONNECTIONS 59

Connecting To A Dolby Digital Decoder Or

An Amplifier With Built-in DTS .................................................. 59

SUBSIDIARY SETTINGS 60

Mode Set .....................................................................................60

Format A Disc (DVD Deck Only) .................................................63

Finalize A Disc (DVD Deck Only) ................................................64

User-Customizable Background And Text Color......................... 66

Setting The Background And Text Color ..................................... 67

Scan Mode Set (HDD & DVD Deck Only) ...................................68

Tray Lock (DVD Deck Only) ........................................................ 68

Mode Lock ................................................................................... 68

Last Function Memory ................................................................. 68

TROUBLESHOOTING 69

APPENDIX 72

RS-232C INTERFACE 73

RS-232C Interface – Command Table – .....................................73

RS-232C Interface – Specifications –.......................................... 73

RS-232C Interface – Command – ...............................................74

SPECIFICATIONS 85

LIST OF TERMS 86

About Discs

Recordable/Playable Discs

You can use discs with the following logos for recording and playback.

DVD-RAM

12 cm: 4.7 GB/9.4 GB 8 cm: 1.4 GB/2.8 GB Ver. 2.0/2x speed Ver. 2.1/1x – 3x speed

DVD-R

12 cm: 4.7 GB 8 cm: 1.4 GB Ver. 2.0/1x – 4x/8x speed (Video mode/VR mode) Ver. 2.1/16x speed (Video mode/VR mode)

● The above table is based on the information as of June 2006.

● Recording and playback may not be performed depending on the

characteristics and condition of the disc used, leading to unsatisfactory results. Using discs manufactured by JVC is recommended since they have been tested to be compatible with this unit.

DVD-RAM Discs

It is only possible to use discs which conform with DVD-RAM standard Version 2.0 or 2.1.

● It is impossible to record on DVD-RAM discs which do not

conform to this standard. If you use a disc formatted under a different standard version, format it on this unit before use.

● It may not be possible to record, play back, edit or dub a

DVD-RAM disc even if it conforms to the standard if it was recorded or edited on the devices from other manufacturers or on a PC, or if it has far too many titles, or if there is very little available capacity remaining on the disc.

● DVD-RAM discs recorded on this unit cannot be played back on

an incompatible DVD player.

● It is possible to record copy-once programs of digital broadcasts

only onto 4.7/9.4 GB DVD-RAM discs (2.8 GB DVD-RAM discs are not compatible).

DVD-RW

12 cm: 4.7 GB/9.4 GB Ver. 1.1/1x – 2x speed (Video mode/VR mode) Ver. 1.2/4x speed (Video mode/VR mode)

DISC INFORMATION

EN 7

DVD-R/RW Discs

It is only possible to use DVD-R discs which conform with DVD-R standard Version 2.0. When a DVD-R/RW disc (Video mode) is finalized (A pg. 64), it can be played back on a standard DVD player as a DVD VIDEO disc. When a DVD-R/RW disc (VR mode) is finalized (A pg. 64), it can be played back on a standard DVD player compatible with the VR mode of DVD-R/RW discs.

Before finalizing ^ ^ it is possible to record on unrecorded areas of the disc, edit the

disc title and program titles, and delete programs.

● It is impossible to record or edit DVD-R/RW discs recorded on

other devices even if they have not been finalized.

● It is impossible to overwrite recorded areas of DVD-R discs.

● Available recording capacity does not increase even if a recorded

program is deleted from a DVD-R disc.

After finalizing ^

After a DVD-R/RW disc (Video mode) has been finalized, it is possible to play back the recorded programs (video and/or audio) on a standard DVD video player as a DVDVIDEO disc.

● Edited titles are displayed as the

ADVD menu B in video mode.

● It is impossible to record, edit or

delete the data either in video

mode or in VR mode.

● Either in video mode or in VR

mode, although the disc can be

HOME MOVIES DOCUMENTARIES

MTV CARTOON

TRAVELLINGCLIPS

played back on DVD players from

other manufacturers, sometimes it

may not be possible to play back depending on the disc and

recording conditions.

● It is impossible to record on CD-R/RW or DVD-R discs used for

authoring.

● It is impossible to record onto DVD-R/RW (Video mode) discs

broadcasts that allow you to copy once. The copy once programs

can only be recorded onto DVD-R/RW discs formatted in VR

mode.

NOTES:

● The following may result if you play back a DVD-R disc recorded

on another unit.

● The disc does not play.

● A mosaic pattern (block noise) appears on the screen.

● Video or audio may be dropped out.

● The unit stops during playback.

● 6x speed DVD-RW disc cannot be used on this unit.

8 EN

DISC INFORMATION

Discs For Playback Only

You can use discs with the following logos for playback only.

DVD VIDEO Video CD/Super Video CD

(example of region code indications)

Audio CD

CD-DA files

CD-RW

CD-DA/JPEG/ MP3/WMA files

● Playback may not be performed depending on the characteristics

and condition of the disc used.

● DTS Audio CDs can also be played back (An optional DTS

decoder is required).

● MP3 and JPEG discs can be played back on this unit only when

they have been recorded in the ISO9660 or Joliet format and finalized.

● JPEG files that can be played back on this unit must conform to

JFIF/Baseline process, and the maximum resolution of a JPEG file is 2,812 pixels in width and 2,112 pixels in height.

● CD-R/RW discs recorded in music CD format need to be finalized

to play back on this unit.

● Operation and audio quality of this unit are not guaranteed for

discs that do not conform to the Compact Disc specification (CD-DA). Before you play back a CD, check for the CD logo and read the notes on the package to confirm that it conforms to the Compact Disc specification.

● Depending on the intentions of the author of the software,

recording conditions of DVD discs and Video CD/SVCD discs may be restricted. Since this unit plays back discs according to the intentions of the author of the software as indicated on the disc, some functions may not operate as commanded.

● When switching from the first layer to the second layer of double-

layered DVD VIDEO discs, the image and sound may be momentarily distorted. This is not a malfunction.

● DVD-AUDIO discs compatible with DVD video players can be

played.

● Super Audio CDs (SACD) compatible with conventional CD

players can be played.

● +R/+RW discs recorded and finalized in Video mode can be

played. ADVDB will light on the front display panel.

CD-R

CD-DA/JPEG/ MP3/WMA files

CD-ROM

JPEG/MP3/ WMA files

Unplayable Discs

The following types of discs cannot be played using this unit. Do not attempt to play back any kind of disc that is damaged (cracked, warped, or repaired with adhesive tape) or discs in unusual shapes (heart-shaped, octagonal, or other forms). If such discs are accidentally played back, it may cause noise that can lead to speaker damage.

● CD-ROM discs (including PHOTO-CD and CD-G)

● Discs recorded in Packet Write (UDF) format

● 1.3-GB double density CDs (DDCD)

● High density CDs (HDCD)

The following discs also cannot be played back.

● Discs of a region number other than A1B

● DVD-RAM (2.6 GB/5.2 GB)

● DVD-RAM (TYPE1)

Caution for DualDisc playback

The Non-DVD side of a ADualDiscB does not comply with the ACompact Disc Digital AudioB standard. Therefore, the use of Non-

DVD side of a DualDisc on this product may not be recommended.

Region Number

The world is divided into 6 regions for DVD VIDEO discs. DVD VIDEO discs are assigned a region number to indicate which region they may be played back in. A disc cannot be played back on this unit unless the region number of the disc matches that of the unit. The region number for this unit is A1B. Only discs whose region number includes A1B or AALLB can be played back such as shown below.

Examples of DVD VIDEO labels which can be played back using this unit.

Marks of discs in this instruction manual

Allows operation with a DVD-RAM disc.

Allows operation with a DVD-R disc.

Allows operation with a DVD-RW disc.

Allows operation with a DVDVIDEO disc.

Allows operation with a Video CD/Super Video CD (SVCD) disc.

Allows operation with an Audio CD disc.

Allows operation with a disc including MP3 files.

Allows operation with a disc including JPEG files.

Recording Medium And Format

DVD-RAM

● Recording and erasing can be performed as many times as

possible on a disc.

● Editing can be performed after recording, such as deleting

unwanted parts.

● While recording, it is possible not only to start playback of a

program currently being recorded, but also to watch another program previously recorded.

DVD-RW (VR mode)

● Recording and erasing can be performed as many times as

possible on a disc.

● Editing can be performed after recording, such as deleting

unwanted parts.

● Recording of copy once programs are possible using a CPRM

compatible disc.

DVD-RW (Video mode)

● Can be played back on other DVD players.

● New recording can be performed by erasing all the data on a disc

once played back.

DVD-R (VR mode)

● Editing can be performed after recording, such as deleting

unwanted parts.

● Recording of copy once programs are possible using a CPRM

compatible disc.

DVD-R (Video mode)

● Can be played back on other DVD players.

● Suitable when keeping a recorded disc for a long time.

File Structure Of Discs

DVD VIDEO

Typically, DVD VIDEO discs are made up of larger units called AtitlesB. Each title has a number (title number) that can be used to select desired titles. Titles are further divided into units called AchaptersB. Each chapter has a number (chapter number) that can also be used to select desired chapters. Note that some discs are not divided into titles and chapters.

When you record a program on a DVD-RAM/R/RW (VR mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes from monaural to stereo due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during playback. (A pg. 25)

When you record a program on a DVD-R/RW (Video mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during either recording or playback. Once the disc has been finalized, these chapter marks are deleted and new chapter marks are assigned automatically approximately every 5 minutes.

DVD-RAM, DVD-RW, DVD-R or DVD VIDEO disc

Title 1 Title 2

Chapter 1 Chapter 2

● In Video mode, even before finalizing, it is impossible to perform

Chapter 3

editing operations other than changing the disc name and/or title names and deleting programs and/or titles.

● After finalizing, it is impossible to perform editing operations.

Chapter 1

Chapter 2

Chapter 3

DISC INFORMATION

EN 9

Audio CD/Video CD/SVCD

Typically, Audio CD discs are divided into separate tracks each containing one song. Each track is assigned a number. For example, the third track is Track 3. The same is true for Video CD/ SVCD discs. However, some discs are not divided into tracks.

Audio CD or Video CD/SVCD

Track 1 Track 2 Track 3 Track 4

JPEG/MP3 Disc (CD-R/RW/ROM)

MP3/JPEG files put in directories nested in several levels on a disc will be organized as if they were put in single level directories (groups) by the MP3/JPEG Navigation of this unit. (A pg. 45)

File structure of a disc before starting the MP3/JPEG Navigation

Directory MP3 file JPEG file

File structure of the disc after starting the MP3/JPEG Navigation

Files are automatically grouped as follows and displayed on the MP3/JPEG Navigation screen. Data is displayed in the alphabetical order of file name. Files are grouped based on roots.

● This unit can recognize up to 9 hierarchies including directories

and files.

Also, it can recognize up to 250 files in each group, and up to 99

groups on a disc.

NOTES:

● Video CD/SVCD discs that support Playback Control (PBC)

The contents of a disc are recorded into several hierarchies, and

played back according to the instructions on the screen while

navigating through the hierarchies. It is also possible to playback

recorded tracks consecutively without activating the PBC function

even when playing a PBC-compatible disc. (A pg. 26)

● Regarding the contents recorded on discs

Some files may not be played back depending on the file types

and other factors.

10 EN

DISC INFORMATION

DVD VIDEO Marks

Sometimes marks are printed on a DVD disc and/or on its packaging to indicate information regarding the contents and functions of the disc. Check the marks indicating the contents and functions of the disc. Note, however, that in some cases a disc may not include a mark even for a function it supports.

Marks related to video

Number of subtitles Number of angles

Recorded under the standard 4:3 aspect ratio

Video playback is in Wide video mode (16:9) on wide televisions, but in letter box on televisions with standard 4:3 aspect ratio.

Video playback is in Wide video mode (16:9) on wide televisions, but pan and scan is used on televisions with standard 4:3 aspect ratio (either the left or right side of the image is cut-out).

Marks related to audio

Number of audio tracks

Dolby Digital Stereo Creator mark Developed by Dolby Laboratories. It enables audio recording in high-quality stereo Dolby Digital.

DTS (Digital Theater Systems) You can enjoy DTS audio if you connect an amplifier with a built-in DTS decoder to the DIGITAL OUT connector of the unit.

Screen includes black bands at the top and the bottom of image which has a standard 4:3 aspect ratio (letter box)

Placing A Disc

Opening the disc tray

Press M to open the disc tray.

EJECT DV/HDD/DVD REC MODE INSTANTREPLAY AUDIODUB. INSERT

RECDVD

● Pressing the button again closes the disc tray.

● Use the button to open and close the disc tray.

● Do not block the disc tray with your hand while it is opening or

closing as this may result in hardware failure.

● Do not place unplayable discs or any object other than a disc on

the disc tray.

● Do not press down strongly on the disc tray or place any heavy

objects on it.

Discs without cartridges

E D V D

R ME I

A L P

P TO S

W E R

P C /

N E

C E R

N I

MA E R

OW L S

<> <

D O M

C E R

Place the disc on the disc tray with the label side facing up. Since disc size changes depending on the disc to be played back, be sure to correctly align the disc with the grooves for its size. If the disc is not in its groove, it may be scratched or otherwise damaged. To insert an 8 cm disc, place it according to the inner groove.

DVD-RAM discs contained in cartridges

Double-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the side you wish to play back or record facing down. If you insert the disc with ASide AB facing down, programs are recorded on the side A.

Single-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the label side facing up.

G N I B B

U D

R C V

E P

L L U

D K N I

C E R

C F F

D V

Disc tray

RECPAUSEPLAY FFREWSTOP

DVIN/ OUT

DR V

N I

DISC INFORMATION

EN 11

Care And Handling Of Discs

How to handle discs

When handling a disc, do not touch the surface of the disc. Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the unit to malfunction.

Label side

Do not damage the label side, stick paper to or use any adhesives on its surface.

Recording side

Make sure that discs are not scratched or dirty on the recording side before use. Scratches and dirt on the recording side of a disc may hinder proper playback and recording. Also be careful that a DVD-RAM disc may get scratched or dirty when removed from cartridge then put back in after use.

Storage

Make sure that discs are kept in their cases. If discs are piled on top of one another without their protective cases, they can be damaged. Do not put discs in a location where they may be exposed to direct sunlight, or in a place where the humidity or temperature is high. Avoid leaving discs in your car!

Maintenance of discs

If there are fingerprints or other dirt adhering to a disc, wipe with a soft dry cloth, moving from the centre outwards. If a disc is difficult to clean, wipe with a cloth moistened with water. Never use record cleaners, petrol, alcohol or any anti-static agents.

Life Span Of Parts

Cooling fan

Periodical inspection and maintenance are requisite to maintain the initial performance and reliability of the product. We recommend the exchange of the fan motor every three years.

HDD

The HDD is a consumable part. Please arrange for maintenance after an estimated usage of 10,000 hours (this estimation is based on usage under the environment of 25f, it may differ depending on the usage environment). Please consult your authorized dealer or nearest JVC service center on the maintenance and cost.

CAUTION:

Sometimes during playback, noise may appear or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the unit.

12 EN

INDEX

Front View

STANDBY/ON

S-VIDEO

VIDEO (MONO)L - AUDIO - R

IN F-1

INPUT

SELECT

OUTPUT SELECT

HGI

EJECTEJECTDISPLAY

RECDV DRECHDDRECDV

DV/HDD/DVD REC MODE INSTANT REPLAY AUDIODUB. INSERT

LMBA

RECPAU SEPLAY

FFREWSTOP

DV IN/ OU T

A STANDBY/ON Button (A) B Eject Button (M) (DV) A pg. 33 C Mini DV Cassette Loading Slot D DV Lamp (DV) A pg. 33

DV Recording Lamp (REC)

E HDD Lamp (HDD) A pg. 20

HDD Recording Lamp (REC)

F DVD Lamp (DVD) A pg. 20, 22

DVD Recording Lamp (REC)

G Eject Button (M) (DVD) A pg. 10 H DV/HDD/DVD Select Button (DV/HDD/DVD) A pg. 22, 31, 33

● This button will not function during navigation mode or set up

mode.

I Recording Mode Button (REC MODE) A pg. 50 J Instant Replay Button (INSTANT REPLAY) A pg. 24, 32, 34 K Disc Tray L Audio Dubbing Button (AUDIO DUB.) A pg. 56 M Insert Button (INSERT) A pg. 57 N Display Button (DISPLAY) A pg. 25 O S-video Input Connector [S-VIDEO] A pg. 52 P Video/Audio Input Connectors

[VIDEO/AUDIO ((MONO) L/R)] A pg. 52

Q Input Select Button (INPUT SELECT) A pg. 50, 52

R Output Select Button (OUTPUT SELECT)

● Switches between AALLB (DV/HDD/DVD output) and ADVB (DV

output) when pressed. When AALLB is selected, DV, HDD or DVD signals are output from the [DV/HDD/DVD OUTPUT] connectors on the rear panel depending on the deck selected. When ADVB is selected, DV signals are output regardless of the deck selected.

ATTENTION:

If ADVB is selected, ADVB and AOUTPUT DVB blink on the front display panel and TV screen respectively when EDIT or NAVIGATION is pressed while in the HDD/DVD deck mode. Press OUTPUT SELECT to stop the blinking and return to the previous display.

S Front Display Panel A pg. 14 T Infrared Beam Receiving Window U Stop Button (o) A pg. 22, 31 V Reverse Search Button (O) (HDD & DVD deck) A pg. 23,

36 Rewind Button (O) (DV deck) A pg. 33, 34

W Play Button (I) A pg. 22, 31 X Forward Search Button (N) (HDD & DVD deck) A pg. 23,

36 Fast Forward Button (N) (DV deck) A pg. 33, 34

Y Pause Button (W) A pg. 22, 31 Z Record Button (R) a DV Input/Output Connector [DV IN/OUT(A*)] A pg. 50

● This connector can also be used as a direct connection to NLE

(Non-Linear Editing) systems or to a PC for downloading, editing and archiving.

* A (i.Link) refers to the IEEE1394-1995 industry specification and

extensions thereof. The i.Link standard.

A logo is used for products compliant with the

Rear View

INDEX

EN 13

BCA

COMPONENT

VIDEO OUT

A AC Power Cord A pg. 18 B Cooling Fan

● This prevents the temperature from rising inside the unit.

Do not remove it.

● Install the unit so as not to block the area around the fan.

● The unit may become hot when it is turned off, as the cooling

fan on the rear of the unit is not activated. However, the cooling fan may be activated in the standby mode when AQUICK STARTUPB is set to AONB.

C Component Video Output Connectors [COMPONENT

VIDEO OUT (Y/P

D Serial Command Connector (D-SUB 9-PIN) [SERIAL COM.]

A pg. 73

● Use this connector when controlling this unit via a computer.

The cable to be used should be a RS-232C interface cable (straight type). For details on the RS-232C interface command, refer to page 73.

B/PR

)] (HDD & DVD deck only) A pg. 18

SERIALCOM.

HDD/DVD

DIGITAL AUDIO OUT

PCM/STREAM

COAXIAL

OPTICAL

DV/HDD/DVD

OUTPUT

HDD/DVD

VIDEO

E GF

OUTPUT

S-VIDEO

VIDEO

AUDIO

INPUT L-1

S-VIDEO

VIDEO

AUDIO

OUTPUT

DV/HDD/DVD

S-VIDEO

VIDEO

AUDIO

REMOTE IN

E S-VIDEO/VIDEO/AUDIO OUTPUT Connectors (HDD & DVD

deck only)

● These connectors only output DVD/HDD signals and can be

used to connect to a second monitor.

F S-VIDEO/VIDEO/AUDIO INPUT Connectors (L-1) A pg. 53 G S-VIDEO/VIDEO/AUDIO OUTPUT Connectors A pg. 18 H Digital Audio Output Connectors

[DIGITAL AUDIO OUTPUT (OPTICAL/COAXIAL)] (HDD & DVD deck only) A pg. 55, 59

I BNC Video Output Connector [VIDEO OUTPUT] A pg. 18 J Remote Input Connector* [REMOTE IN]

* There is currently no compatible remote control unit available.

14 EN

INDEX

Front Display Panel

AB ED

CGFH

LPCM FR XP SP LP EP +

RW VCD

RAM

A Disc Type Indicator

When a disc is loaded, the type of the disc is indicated.

Disc Status Indicator

When a disc is running, the disc marks rotate.

VR Mode Indicator (VR) A pg. 63

Lights when a DVD-R/RW disc is formatted in VR mode.

B Linear PCM Indicator (LPCM)

Lights when AXP MODE REC AUDIOB is set to ALINEAR PCMB (A pg. 61) for recording with HDD, DVD-RAM, DVD-R and DVD-RW discs, and when Linear PCM audio is played.

C Cassette Loaded Mark (u)

Indicates the present of a cassette in the DV deck. Lights when a cassette is loaded into the DV deck. It will remain lit as long as the cassette is loaded, even if the HDD or DVD deck is being selected.

D Recording Mode Indicator (XP/SP/LP/EP/FR) A pg. 51

Blinks when recording mode is being set. While AFRB is blinking, the left 3 digits of the Multi Display (L N) indicate setting values ranging from A60B to A480B. After the value has been set, only AFRB lights.

E Group/Title Indicator (GRP/TITLE)

AGRPB or ATITLEB lights depending on a disc loaded while the left 2 digits of the Multi Display (L) indicate the numbers explained below.

AGRPB: Total number of groups or group number being played

ATITLEB: Total number of titles or title number being played

F External Input Indicator

Indicates the external input selected.

G Track/Chapter Indicator (TRK/CHAP)

ATRKB or ACHAPB lights depending on a disc loaded while the 3rd and 4th digits from the left of the Multi Display (N) indicate the numbers explained below.

ATRKB: Total number of tracks or track number being played

ACHAPB: Chapter number being played back are displayed on

H Simulated Surround Effect Indicator (3D) A pg. 29

Lights when a simulated surround effect is set to A3D-ONB on the on-screen bar.

back are displayed on the Multi Display.

the Multi Display.

I Random/Program Playback Mode Indicator (RND/PRGM)

A pg. 30

ARNDB: Lights when Random Playback mode is set. APRGMB: Lights when Program Playback mode is set.

J Repeat Mode Indicator (x/1/A-B) A pg. 27

Select Repeat Playback mode on the on-screen bar.

AxB: Whole disc is played back repeatedly. Ax1B: A single title/chapter/track is played back

AxA-BB: The selected part (A-B) is played back repeatedly.

No display: Repeat Playback mode is off.

K Video Output Indicator (q) A pg. 68

No display: Indicates that interlace mode is engaged. q: Indicates that progressive mode is engaged. (Example) q lights when video output mode is in progressive

L Group/Title Number Display M Audio Dubbing/Insert Editing Indicator

AADUBB or AINSB lights up during Audio Dubbing or Insert Editing respectively.

N Track/Chapter Number Display O Remaining Time/Elapsed Time Indicator A pg. 25

Lights when remaining time of HDD, DVD-RAM, DVD-R and DVD-RW discs is displayed, and lights out when elapsed time is displayed. The right 6 digits of the Multi Display (P) indicate elapsed or remaining time of each track. No display: Indicates elapsed time of the disc. Displayed: Indicates remaining time of the disc.

P Remaining Time/Elapsed Time Display A pg. 25

Time Code Display A pg. 34

Q Multi Display

Displays clock, received channel, elapsed time, and remaining time. Also displays status of the unit (NO DISC/OPEN/CLOSE/ READING).

repeatedly.

mode.

Remote Control

A B

C D

G H

I J

N O

P Q

R S

OUTPUT SELECT

ENTER

STOP/CLEAR

ON SCREEN

AUDIO

VIDEO

MEMO/MARK

EDIT

SUBTITLE

PROGRESSIVE

SCAN

DV HDD DVD

CANCEL

DISPLAY

REC MODE/

REMAIN

STANDBY/ON

INPUT SELECT

NAVIGATIONTOP MENU

RETURN

SLOWSLOW PLAY

PAU S EREC

DVDTV

PR/CH

PROG

ANGLE/

EE CHECK

SET UPDUBBINGEE

U V

W X

a b c d

e f

h i

j k

l m

n o

p q

INDEX

EN 15

J Selection Keys (FGDE) A pg. 19 K Menu Button (MENU) A pg. 23 L Reverse Skip Button (S) A pg. 23, 36, 32

Previous Button (PREVIOUS): A pg. 26

M Reverse Search Button (O) (HDD & DVD deck) A pg. 23,

36 Rewind Button (O) (DV deck) A pg. 33 Reverse Slow Button (SLOW –) A pg. 23

N Record Button (R) O Display Button (DISPLAY) A pg. 25, 34 P On-Screen Button (ON SCREEN) A pg. 16, 27 Q Recording Mode Button (REC MODE) A pg. 50

Remain Button (REMAIN) A pg. 25

R Audio Button (AUDIO) A pg. 26 S EE Button A pg. 36 T Dubbing Button (DUBBING) A pg. 46 U TV/DVD switch A pg. 20, 58 V STANDBY/ON Button (A) W TV/VIDEO Button A pg. 58 X DVD Button* A pg. 22

* This button will not function during navigation mode or set up mode.

Y TV Volume Buttons (TV8 +/–) A pg. 58 Z TV Program Buttons (PR/CH +/–) A pg. 58

Input Select Button (INPUT SELECT +/–) A pg. 50, 52

a Memo Button (MEMO) A pg. 39, 43

Mark Button (MARK) A pg. 25

b Programming Button (PROG): Not use on this unit. c Edit Button (EDIT) A pg. 39 d Navigation Button (NAVIGATION) A pg. 38, 45 e Enter Button (ENTER) A pg. 20 f Return Button (RETURN) A pg. 26, 28 g Forward Skip Button (T) A pg. 23, 36

Next Button (NEXT): A pg. 26

h Forward Search Button (N) (HDD & DVD deck) A pg. 23,

36 Fast Forward Button (N) (DV deck) A pg. 33 Forward Slow Button (SLOW +) A pg. 23

i Play Button (I) A pg. 22, 31 j Pause Button (W) A pg. 22, 31 k Stop Button (o) A pg. 22, 31

Clear Button (CLEAR) A pg. 30

l Skip Search Button (v) A pg. 24, 31, 34, 36 m Instant Replay Button (w) A pg. 24, 32, 34, 36, 37 n Angle Button (ANGLE) (DVD deck only) A pg. 25

EE Check Button (EE CHECK) A pg. 36

o Set Up Button (SET UP) A pg. 20, 60 p Subtitle Button (SUBTITLE) A pg. 26 q Progressive Scan Button (PROGRESSIVE SCAN) A pg. 68

A Output Select Button (OUTPUT SELECT)

● Switches between AALLB (DV/HDD/DVD output) and ADVB (DV

ATTENTION:

If ADVB is selected, ADV B and AOUTPUT DVB blink on the front display panel and TV screen respectively when EDIT or NAVIGATION is pressed while in the HDD/DVD deck mode. Press OUTPUT SELECT to stop the blinking and return to the previous display.

B TV Muting Button (TV d) A pg. 58 C DV Button* A pg. 33

* This button will not function during navigation mode or set up mode.

D HDD Button* A pg. 31

* This button will not function during navigation mode or set up mode.

E Number Keys A pg. 58 F Cancel Button (CANCEL) A pg. 30 G F1 Button: A pg. 68 H F2 Button: A pg. 64, 65 I Top Menu Button (TOP MENU) A pg. 23

How To Use

Before use, insert two AA size batteries into the remote control with the polarity (F and G) matched correctly as indicated on the battery compartment or on the lid.

The remote control can operate most of your unit’s functions, as well as basic functions of TV sets of JVC and other brands. (A pg. 58)

● Point the remote control toward the receiving window.

● The maximum operating distance of the remote control is

about 8 m.

NOTE:

If the remote control doesn’t work properly, remove its batteries, wait a short time, replace the batteries and then try again.

16 EN

INDEX

On-Screen Display (HDD & DVD deck)

When ASUPERIMPOSEB is set to AONB or AAUTOB and ON SCREEN on the remote control is pressed, various operational indicators appear on the TV screen. To clear the operational indicators, press ON SCREEN twice.

When playing back a recorded title HDD

0:00 1:00 2:00

FISHING WORLD

01:16:48

FR360

Digital

L–R

When pressing REC MODE

(Appears for eight seconds.)

7: 00 XP 10: 00 SP 20: 00 LP 28: 00

36: 00

FR480

A Remaining disc time for each recording speed B Recording speed

When using Live Memory playback HDD

A Title start B Current playback point C Title end D Elapsed playing time E Play mode F Name of title currently being played back G Time scale (This title is an hour and a half long.) H Audio mode

DVD

TITLE99 CHAPTER999 REMAIN6:59:59T.

FISHING WORLD

Digital

L–R

A Playback title number B Playback chapter number C Disc remaining time D Current status (playback) E Audio mode F Bar meter G Name of title (or play list) currently being played back H Current playback point I Recorded mode*

* Depending on the recording condition, the recorded mode may not

always be displayed.

When recording HDD

11:00 12:00 13:00

FR360

11:35AM

11:33AM

DVD

TITLE99 CHAPTER999 REMAIN6:59:59T.

RAM

FR360

11:35AM

11:33AM

A Time scale for recording (HDD deck)

Bar meter for recording (DVD deck)

B Current recording point C Recording mode D Current time E Current playback channel position number F Time scale for Live Memory Playback (HDD deck)

Bar meter for Live Memory Playback (DVD deck)

G Current playback point H Live Memory playback mode I Current playback time

PR.12

11:00 12:00 13:00

FR360

DVD

TITLE99 CHAPTER999 T. REMAIN6:59:59

RAM

FR360

A Recording point B Current status (recording) C Current time D Recording channel number

11:35AM

PR.12

LIVE

PR.12

LIVE

INDEX

EN 17

On-Screen Display (DV Dubbing)

When capturing images from the external DV equipment

0:00 1:00 2:00

HDD

00: 00:00. 00

FR360

12bit

JVC

GR-DV3500DV

A Recording speed B HDD capacity graph C HDD time counter D Recording time scale E HDD mode F Remote control mode G Connected DV equipment mode H Connected DV equipment model information I Input channel J Sound mode K Sound input bit-rate*

* Indicates the sound bit-rate of the connected DV equipment

L Connected DV equipment information*

* Maker name and model name, etc. may not appear depending on the

connected equipment.

M Time counter for the connected DV equipment N Sound monitor mode

DV DV

O Remote control switch P Auto capture button Q Sound monitor switch

GR-DV3500

00:00:00.00

SOUND1

1 2

L–R

On-Screen Display (DV deck)

G F

SE CL EANI NG CASSE TTE

R000:00:00:

61BIT

A Operation Mode Indicators B Tape Speed (SP/LP) C Sound Mode Display A pg. 62 D Current Month/Day/Year/Clock Display/Time Code Display

A pg. 34

E Audio Mode Display A pg. 34 F Warning Message G Auxiliary Input Indicator (L-1, F-1 or DV) H ACassette LoadedB Mark

A B

R Elapsed recording time

179 : 59 : 59

18 EN

INSTALLING YOUR NEW UNIT

Basic Connections

Another Recorder

Audio/Video

cable

(not supplied)

AC outlet

AC power cord

Back of unit

[COMPONENT

VIDEO OUT

B/PR

(Y/P

Component video

(not supplied)

S-video cable (not supplied)

To [S-VIDEO

INPUT]

To [AUDIO/VIDEO INPUT]

)]

cable

[VIDEO

OUTPUT]

BNC video

cable

(not supplied)

Audio/Video

(not supplied)

[AUDIO/

VIDEO

OUTPUT]

Audio/Video

(supplied)

It’s essential that your unit be properly connected.

ATTENTION:

Connect the AC plug only after all connections to the TV has been completed.

● Make sure the package contains all of the accessories listed in

ASPECIFICATIONSB (A pg. 85).

● Place the unit on a stable, horizontal surface.

cable

Camcorder

S-video cable (not supplied)

To [S - VI D EO INPUT]

To [S-VIDEO OUTPUT]

S-video cable (not supplied)

THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO OPERATION CAN BE PERFORMED.

Connecting to a TV Monitor

Connect the unit to a TV depending on the TV and cables you use.

8 AV Connection To connect to a TV with AV connector ^

A Connect the [AUDIO/VIDEO OUTPUT] connectors on the rear

panel of the unit and the TV’s audio/video input connectors with the supplied Audio/Video cable.

To connect to a TV with BNC connector ^

A Connect an optional audio cable between the [AUDIO

OUTPUT] connectors on the rear panel of the unit and the TV’s audio input connectors.

B Connect an optional BNC video cable between the unit’s BNC

[VIDEO OUTPUT] connector and the TV’s BNC VIDEO input connector.

8 S-Video Connection To connect to TV’s S-VIDEO input and AUDIO input connectors ^

A Connect the unit’s [S-VIDEO OUTPUT] connector to the TV’s

S-VIDEO input connector.

B Connect the unit’s [AUDIO OUTPUT] connectors to the TV’s

AUDIO input connectors.

● If your TV is not stereo-capable, use the unit’s [AUDIO

OUTPUT] connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

8 Component Video Connection To connect to TV’s component video input connectors ^

A Connect the unit’s [COMPONENT VIDEO OUT (Y/P

B/PR

)]

connectors to the TV’s component video input connectors.

B Connect the unit’s [AUDIO OUTPUT] connectors to the TV’s

AUDIO input connectors.

● You can obtain high-quality component video pictures.

● The [COMPONENT VIDEO OUT (Y/P

B/PR

)] connectors do not

output DV signals.

● If your TV is not stereo-capable, use the unit’s [AUDIO

OUTPUT] connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

● By using the component video connection, you can view the

images in the progressive mode. For switching to the progressive mode, refer to AScan Mode Set (HDD & DVD Deck Only)B (A pg. 68).

Connecting to a DV Device

A Connect the unit’s [S-VIDEO INPUT] or [VIDEO INPUT]

connector on the front panel to the camcorder’s s-video or video output connector.

B Connect the unit’s [AUDIO INPUT] connectors on the front

panel to the camcorder’s audio output connectors.

Connecting to Another Recorder

A Connect the unit’s [S-VIDEO INPUT] or [VIDEO INPUT]

connector to another recorder’s s-video or video output connector.

B Connect the unit’s [AUDIO INPUT] connectors to another

recorder’s audio output connectors.

Plug the end of the AC power cord into an AC outlet.

● APLEASEB and AWAIT B blink alternately on the front display

panel when the AC plug of the AC power cord is connected into an AC outlet. After a short while, A32**B blinks on the front display panel and starts to count down. It takes approximately 50 seconds for the unit to be turned on. This is not a malfunction.

Clock Set

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

ENTER

Selection Keys

FGDE

INITIAL SETTINGS

EN 19

1 Press SET UP to access the Main Menu screen. 2 Press selection keys to select AINITIAL SET UPB, then press

3 Press selection keys to select

ACLOCK SETB, then press G.

4 Press selection keys to select

ATIMEB, then press ENTER.

DVDTV

Press selection keys to set the time, then press ENTER.

● Repeat the same procedure to

set the date and year.

● When you set the time, press

DVD VIDEO SET UP

MENU BACKGROUND

TIME

DATE

YEAR

D.S.T.

SET UP

EXIT

HDD/DVD SET UP FUNCTION SET UP

CLOCK SET

ENTER

SELECT WITH @ THEN PRESS [ENTER]

SELECT

PRESS [SET UP] TO EXIT

1/1 (SUN)

2006

INITIAL SET UP

--:--

and hold FG to change the time by 30-minute intervals.

● When you set the date, press and hold FG to change the date

by 15-day intervals.

5 Press selection keys to select AD.S .T.B, then press ENTER.

Press selection keys to select the desired setting, then press ENTER.

ON:

Adjustment will be made by the built-in clock itself.

OFF:

Select when Daylight Saving Time does not apply to you.

6 Press SET UP to start the clock operation.

SET UP

Daylight Saving Time

This function enables automatic adjustment of the unit’s clock at the start and end of Daylight Saving Time.

● With D.S.T. activated, ^

^ on the second Sunday of March at 2:00 AM, the clock is

adjusted to 3:00 AM.

^ on the first Sunday of November at 2:00 AM, the clock is

adjusted to 1:00 AM.

NOTE:

For the year 2006, the Daylight Saving time will end on the last Sunday of October at 2:00 AM.

20 EN

INITIAL SETTINGS

Language

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

HDD

ENTER

DVD

Selection Keys

FGDE

SET UP

On-screen Language Set

This unit offers you the choice to view on-screen messages in 3 different languages.

1 Press HDD or DVD so that the HDD or DVD lamp lights up on

the unit.

2 Press SET UP to access the Main Menu screen. 3 Press selection keys to select AFUNCTION SET UPB, then

DVDTV

press G.

4 Press selection keys to select

ADISPLAY SETB, then press

5 Press selection keys to select

AON SCREEN LANGUAGEB, then press ENTER.

6 Press selection keys to select

your desired language, then press ENTER.

DVD VIDEO SET UP HDD/DVD SET UP

REC/PLAY SET UP

DISPLAY SET

SUPERIMPOSE

DIMMER (DURING POWER ON)

DIMMER (DURING POWER OFF)

QUICK STARTUP

ON SCREEN LANGUAGE

ENTER

SET UP

SELECT WITH @ THEN PRESS [ENTER]

EXIT

SELECT

PRESS [SET UP] TO EXIT

FUNCTION SET UP

VIDEO IN/OUT

AUTO

BRIGHT

ENGLISH

INITIAL SET UP

OFF

7 Press SET UP to complete the setting.

Menu/Audio/Subtitle Language Set (DVD deck only)

Some DVD discs contain the DVD menu display, audio and subtitles in multiple languages. With these discs, you can set the default language as you like.

● The procedure shows how to set AMENU LANGUAGEB as an

example.

1 Press DVD so that the DVD lamp lights up on the unit. 2 Press SET UP to access the Main Menu screen. 3 Press selection keys to select ADVD VIDEO SET UPB, then

press G.

4 Press selection keys to select

ALANGUAGE SETB, then press G.

5 Press selection keys to select

AMENU LANGUAGEB, then press ENTER.

6 Press selection keys to select

your desired language, then press ENTER.

● See ALanguage Code ListB (A pg. 72).

7 Press SET UP to complete the setting.

NOTE:

When the selected language is not available on the disc, the disc’s default menu language is played back.

DVD VIDEO SET UP

HDD/DVD SET UP

LANGUAGE SET AUDIO OUTPUT

MENU LANGUAGE

AUDIO LANGUAGE

SUBTITLE

ENTER

SET UP

EXIT

SELECT

FUNCTION SET UP

DISC PLAY SET UP

SELECT WITH @ THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

ENGLISH

INITIAL SET UP

Monitor Set

You can select the monitor type depending on the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

DVDTV

DVD

INITIAL SETTINGS

EN 21

1 Press DVD so that the DVD lamp lights up on the unit. 2 Press SET UP to access the Main Menu screen.

● You cannot set the monitor type during recording or playback.

3 Press selection keys to select AFUNCTION SET UPB, then

press G.

4 Press selection keys to select

AVIDEO IN/OUTB, then press

5 Press selection keys to select

AMONITOR TYPEB, then

DVD VIDEO SET UP

HDD/DVD SET UP FUNCTION SET UP

REC/PLAY SET UP DISPLAY SET

MONITOR TYPE

FRONT AUX F-1

REAR AUX L-1

VIDEO IN/OUT

4:3LB

VIDEO

INITIAL SET UP

press ENTER.

6 Press selection keys to select

the desired option, then press

SET UP

SELECT WITH @ THEN PRESS [ENTER]

EXIT

SELECT

PRESS [SET UP] TO EXIT

ENTER

ENTER.

7 Press SET UP to complete the setting.

*The boldface settings below indicate the settings at your purchase.

ENTER

Selection Keys

FGDE

SET UP

8 MONITOR TYPE - 4:3LB / 4:3PS / 16:9AUTO / 16:9FIX

4:3LB (Letter Box conversion):

Select this when the aspect ratio of your TV is 4:3 (conventional TV). While viewing a wide screen picture, the black bars appear on the top and the bottom of the screen.

4:3PS (Pan&Scan):

Select this when the aspect ratio of your TV is 4:3 (conventional TV). While viewing a wide screen picture, the black bars do not appear; however, the left and right edges of the pictures will not be shown on the screen.

16:9AUTO (Wide television conversion):

Select this when the aspect ratio of your TV is 16:9 (wide TV).

16:9FIX (Wide television conversion):

Select this when the aspect ratio of your TV is fixed to 16:9 (wide TV). The unit automatically adjusts the screen width of the output signal correctly when playing back a picture whose aspect ratio is 4:3.

Pan&Scan/Letter Box

In general, DVDVIDEO disc are produced for a wide-screen TV with 16:9 aspect ratio. Material with this ratio will not fit to a TV with 4:3 aspect ratio. There are two styles to display the image, APan&ScanB (PS) and ALetter BoxB (LB).

Pan&Scan

The right and left side of the image are cut off. The image fills the screen.

● The picture will be shown in the A4:3LBB

mode depending on the disc even if the A4:3PSB mode is selected.

Letter Box

Black bands appear at the top and bottom of the image. The image itself appears in 16:9 aspect ratio.

22 EN

BASIC OPERATIONS ON DVD DECK

Basic Playback

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

DVD lamp

ENTER

DV/HDD/DVD

DVD

To play back an MP3/JPEG disc, see APlayback With MP3/WMA/ JPEG NavigationB (A pg. 45).

1 Load a disc.

● For details, refer to APlacing A DiscB (A pg. 10).

● Pressing I also closes the disc tray.

● Playback begins automatically if an auto-playback DVD disc is

loaded.

2 Press DV/HDD/DVD on the unit repeatedly or DVD on the

remote control so that the DVD lamp lights up on the unit.

3 Press I to start playback.

● If you load a DVD disc whose region code does not match the

unit, AREGION CODE ERRORB appears on the TV screen. For details, refer to ARegion NumberB (A pg. 8).

● With Video CD/SVCD discs with PBC control or some DVD

discs, the menu display may appear on the TV screen after starting playback. In this case, select an item which you want to play back from the menu. Otherwise, the playback cannot go

forward. Refer to APlayback Control (PBC) FunctionB (A pg. 26) or ALocating A Desired Scene Using The DVD MenuB (A pg. 23).

● The Library Database Navigation also enables you to search

DVDTV

and select the desired titles. (A pg. 39)

4 Press W to pause playback.

● To resume normal playback, press I.

5 Press o to stop playback.

● When a recordable disc is played, playback stops and AV input

(from external AV source) resumes on the TV screen.

● When a playback-only disc is played, playback stops and the

TV screen becomes all black when you press o. Pressing o again resumes the AV input (from external AV source).

● If M is pressed during playback, playback stops, then the disc

tray opens.

NOTES:

● When the Library Database Navigation screen appears, choose

a thumbnail image of the desired title on the TV screen, then press ENTER. (A pg. 39)

● It is not possible to playback the DVD disc recorded in 96 kHz on

DVD during recording or Live Memory Playback on HDD.

● It is possible to play back on the DV deck and the HDD/DVD deck

simultaneously. However, either DVD or HDD can be played at the same time.

ATTENTION:

● It takes approximately 30 seconds to read a disc depending on

the type and condition of the disc since this unit is multi-disc compatible (DVD-RAM, DVD-RW, DVD-R). It may even take several minutes when a disc is dirty, scratched or warped.

● It may take a few seconds to start playback. This is not a

malfunction.

● Forward/reverse high-speed search and other operations

cannot be performed while playback is stopped.

BASIC OPERATIONS ON DVD DECK

EN 23

Playback Features

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/DVD switch to DVD.

● Press DVD so that the DVD lamp lights up on the unit.

DVDTV

DVD

0-9

TOP MENU

ENTER

O/SLOW

Locating A Desired Scene Using The DVD Menu

DVDVIDEO discs may have top menu and disc menu.

Top m e n u

DVD discs generally have their own menus which show the disc contents. These menus contain various items such as titles of a movie, names of songs, or artist information. You can locate a desired scene by using the top menu displayed on the TV screen. Press TOP MENU to access the top menu.

Disc menu

Disc menus include playback data (angle menu, subtitle menu, etc.) specific to each title. Press MENU to access the disc menu.

1 Press TOP MENU or MENU to

access the DVD menu.

2 Press selection keys to select

a desired title, then press ENTER. Playback starts.

● It may be possible to select the

desired item using the number keys depending on the menu

display.

NOTE:

When A7B appears on the TV screen in step 1, the disc does not have a top menu or disc menu.

Locating The Start Point Of The Item Or Skip The Item

Press S or T during playback.

● Pressing T locates the start point or marked points of the item

or skips the item in the forward direction, then resumes playback.

● Pressing S locates the start point or marked points of the item

or skips the item in the reverse direction, then resumes playback.

Selection Keys

FGDE

T N/SLOW + W

Example:

Current playback point

program

Scene 2

(Chapter 2)

Track 2

Reverse

: marked points if any (A pg. 25) or beginning of recording

●

Drama

Scene 3

(Chapter 3)

Track 3

Next program

Scene 4

(Chapter 4)

Track 4

Forward

Movie

Scene 5

(Chapter 5)

Tra c k 5

Variable Speed Search

During playback, press N for forward variable speed search, or O for reverse variable speed search.

● Each press of the button increases the search speed for each

direction.

● To resume normal playback, press I.

For Audio CD

You can perform 4 levels of speed search with N and O. (Audio is active also during variable speed search.) You cannot perform slow motion for each direction.

Reverse

Reverse Search

4 steps

–60 –15 –5 –3 –1

Reverse

Play

Reverse Slow

Motion 3 steps

–1/2 –1/4

–1/16 1/16

Slow Motion

3 steps

1/4 1/2 1 3 5 15 60

Normal

Play

Forward

Forward Search

4 steps

NOTE:

Reverse play (–1x) is not possible with Video CD/SVCD discs.

Still Picture/Frame-By-Frame Playback

1 Press W to pause during playback. 2 Press SLOW – (O) or SLOW + (N) to activate frame-by-

frame playback.

● Each press of SLOW – (O) or SLOW + (N) advances/

reverses the still picture frame by frame.

● Frame-by-frame playback for reverse direction cannot be

performed with Video CD/SVCD discs.

● To resume normal playback, press I.

Slow Motion

1 Press W to pause during playback. 2 Press SLOW – (O) or SLOW + (N) for 2 or more seconds.

● Each press of SLOW – (O) or SLOW + (N) increases the

slow motion speed for each direction.

● Slow motion for reverse direction cannot be performed with

Video CD/SVCD discs.

24 EN

BASIC OPERATIONS ON DVD DECK

Skip Search

During playback, press v.

● Each press initiates an approximately 30-second period of fast-

motion playback. Normal playback resumes automatically.

● Skip search cannot be performed when a VCD/SVCD disc is

being played back with the PBC function.

Instant Replay

You can move back the playback position slightly. Press w on the remote control or INSTANT REPLAY on the unit.

● Each press skips back for approximately 7 seconds and resumes

playback.

● Pressing while paused skips back for approximately 7 seconds

and resumes pause.

● Instant replay cannot be performed when a VCD/SVCD disc is

being played back with the PBC function.

Jump Search

You can locate a scene ahead or behind the current one by jumping scenes according to selected time intervals (A pg. 61) during playback (or Live Memory Playback). Press S or T.

● To advance forward or back, press S or T repeatedly within 5

seconds of each press to continue jump.

● Depending on the time from where you want to start jump search,

the first press of S or T will not necessarily lead to a jump of the selected time interval. The first press will lead to a jump to the nearest quarter points of an hour (15 min/ 30 min/ 45 min/ 00 min). The subsequent jumps will then be in accordance to the selected time interval.

● When you cannot advance any further (beginning or end of

program reached), the message AUNABLE TO GO BACK ANY MOREB or AUNABLE TO GO FORWARD ANY MOREB appears on the screen. In such a case, press S, O, N, T or o.

Example:

Playback search when jump interval is set to 15 MIN jumps. Taking for instance, you want to start jump search 40 minutes after the beginning of the program. Pressing S or T will result in a jump to the scene at the 30 minutes point or 45 minutes point respectively as illustrated below. At the subsequent press, the scene will jump to the 15 minutes point or 1 hour point respectively, according to the selected time interval, which in this case is A15 MINB.

Time counter

0 min

Beginning of program

15 min

NOTES:

● Jump search cannot be performed with finalized DVD-R/DVD-RW

(video mode) discs.

● Jump search functions only when chapters (marks) are not set.

30 min

Current scene

40 min

45 min

1 h 15 min

1 h

End of program

Resume Function

It is possible to memorize the position where you stop playback and resume playback from that position.

● Be sure to set ARESUMEB to AONB or ADISC RESUMEB.

(A pg. 61)

● Resume function always works for DVD-R/DVD-RW discs that

have not been finalized and DVD-RAM regardless of the setting of ARESUMEB.

1 Press o during playback to memorize a resume point.

● The unit enters Resume Stop mode and memorizes the

position where you have stopped playback as a resume point. (The inside of the disc status indicator on the front display panel blinks while memorizing.)

● The unit retains a memory of the resume points of the last 30

discs played back, even though they have been ejected if ARESUMEB is set to ADISC RESUMEB. (A pg. 61)

● Performing the following steps would erase the resume points:

(The inside of the disc status indicator stops blinking and lights.)

When ARESUMEB is set to AONB:

• Press A to turn off the unit.

• Press

M to take out the disc.

• Press

o in stop mode.

• Press

TOP MENU to display the top menu, then start playback by

selecting an item, etc.

MENU to display the disc menu, then start playback by

• Press selecting an item, etc.

When ARESUMEB is set to ADISC RESUMEB:

•Set ARESUMEB to AOFFB. (A pg. 61)

• Press

o in stop mode.

• Press

TOP MENU to display the top menu, then start playback by

selecting an item, etc.

MENU to display the disc menu, then start playback by

• Press selecting an item, etc.

2 Press I in stop mode to resume playback. The unit starts

playback from the resume point.

NOTES:

● ADISC RESUMEB setting works on DVD VIDEO, VCD, SVCD

and already finalized DVD-R/DVD-RW (video mode) discs. For other types of discs, the function under AONB setting will be applied even if ARESUMEB is set to ADISC RESUMEB. (A pg. 61)

● If you stop the playback of a disc for which a resume point has

already been memorized, the memory will be updated with the new resume point.

● After the unit has memorized the resume points for 30 discs,

remembering a new resume point will cause the unit to delete the oldest memorized point. Stopping playback of a disc for which a resume point is already stored may change the order in which the points are stored. This may potentially change the order in which points are deleted.

● When the unit memorizes a resume point for a disc, it also

remembers audio language, subtitle and angle settings.

● This function may not work for some Video CD/SVCDs.

● When ARESUMEB is changed to AONB or AOFFB (A pg. 61),

resume points of the discs memorized with ARESUMEB set to ADISC RESUMEB will be cleared.

● Resume points are memorized for each side of a double-sided

disc.

● When you switch to HDD while playing back JPEG/MP3 files,

playback stops. The Resume Function doesn’t work when you switch to DVD thereafter to playback the disc.

BASIC OPERATIONS ON DVD DECK

EN 25

Checking The Time Information

DVDTV

DVD

0-9

MARK

ENTER

S/PREVIOUS

I o

DISPLAY

REC MODE/REMAIN

AUDIO

Selection Keys

FGDE

RETURN T/NEXT

ON SCREEN

SET UP SUBTITLE

Marking Positions To Play Back Again Later

It is possible to mark positions (up to 999 points) where you want to play back once again later, and start playback from a marked position. Marking onto DVD-RAM/R/RW (VR mode only) discs when recording is helpful to locate a start point when you play back the discs later.

To mark positions:

During playback, press MARK at positions you want to mark.

● AMARKB appears on the TV

screen. You can easily locate the marked positions using S or T when you play back the disc.

To delete the marked positions:

While paused, press S or T to locate a marked position you want to delete, then press MARK.

● Crossed AMARKB appears on the

TV screen, and the marked position is deleted.

NOTES:

● For DVD-R/RW (Video mode) discs, marks are assigned

automatically every 5 minutes.

● If MARK is pressed when playing back a disc that does not allow

marks to be inserted, A7B appears on the TV screen.

You can check time information of a disc on the front display panel and the TV screen.

8 DVD-RAM/DVD-R/DVD-RW

Each press of DISPLAY on the remote control or the unit changes the display as follows:

During recording

Clock time (front display panel only) N Current title elapsed time N Disc remaining time N (back to the beginning)

During playback

Each title elapsed time N Total remaining time N Remaining time* N (back to the beginning)

* only discs before finalizing

During recording/playback or in stop mode Press REC MODE.

● The disc remaining time according to recording modes appears

on the TV screen.

● It is possible to check disc remaining time according to recording

modes also by pressing REMAIN.

● In FR mode, it is possible to set recording time in detail. While the

recording mode and the disc remaining time are displayed by pressing REMAIN, press selection keys to select AFRB, then press DE to select the desired recording time. (A pg. 51)

● It is not possible to switch the recording mode during playback or

while recording.

8 Video CD/SVCD/Audio CD During playback or in stop mode

Current track elapsed time N Current track remaining time N Tot al elapsed time N Total remaining time N (back to the beginning)

NOTES:

● When a PBC-compatible Video CD/SVCD disc is loaded,

deactivate the PBC function. (A pg. 26)

● For pre-recorded DVD VIDEO, only the title, chapter and elapsed

time are displayed when ON SCREEN is pressed.

Angle Selection

You can enjoy a variety of scene angles if a DVD VIDEO disc contains Amulti-angleB parts, where the same scene was shot from different angles. If the disc contains Amulti-angleB parts, AyB appears on the TV screen at the beginning of the Amulti-angleB part.

1 Press ANGLE during playback.

The angle selection display appears on the TV screen.

2 Press ANGLE or selection

keys to select your desired

angle.

● Each time you press ANGLE or the selection keys, the angle

changes.

● When A7B appears on the TV screen, the current scene is not

recorded from multiple angles. In addition, some discs prohibit angle selection.

● To clear the angle selection display, press ENTER. In addition,

the angle selection display disappears automatically if no operation is done for 10 seconds.

When 3 scene angles are contained.

26 EN

BASIC OPERATIONS ON DVD DECK

Subtitle Selection

Some DVDVIDEO discs contain more than one subtitle language, from among which you can choose the desired subtitle language. AhB appears on the TV screen at the beginning of the part where more than one subtitle language are recorded.

1 Press SUBTITLE during

playback. The subtitle selection display appears on the TV screen.

● Each time you press

SUBTITLE, the subtitle display is switched on and off.

When 3 subtitle languages are contained.

ENGLISH

2 Press selection keys to select your desired language.

● To clear the subtitle selection display, press ENTER.

NOTES:

● When A7B appears on the TV screen, no subtitle language is

recorded.

● When the subtitle language won’t be changed with the procedure

above, change the subtitle on a disc menu displayed by pressing MENU.

Audio Channel Selection

When watching bilingual programs or playing discs on which you recorded bilingual or stereo programs, you can choose the desired audio channel.

● When ASUPERIMPOSEB is set to AONB or AAUTOB, you can

confirm on the TV screen the audio channel you have chosen. (A pg. 61)

● Each time you press AUDIO, the audio

channel changes.

TRACK

On-Screen Display

For stereo discs For audio of left channel For audio of right channel

NOTE:

It is not possible for DVD-R/DVD-RW (Video mode) disc playback to switch the audio channel.

When you can’t switch the audio channel of a bilingual program

When the unit is connected with a digital audio device using an optional optical cable and ADIGITAL AUDIO OUTB is set to ADOLBY DIGITAL/PCMB, it is not possible to switch the audio channel of a bilingual program recorded on a DVD-RAM or DVD-R/ RW (VR mode) disc. (A pg. 59) In this case, perform the following steps using the remote control to switch ADIGITAL AUDIO OUTB from ADOLBY DIGITAL/PCMB to APCM ONLYB.

A Press SET UP to access the Main Menu screen. B Press selection keys to select ADVD VIDEO SET UPB, then

press G.

C Press selection keys to select AAUDIO OUTPUTB, then press

D Press selection keys to select ADIGITAL AUDIO OUTB, then

press ENTER.

E Press selection keys to select APCM ONLYB, then press

ENTER. (A pg. 60)

F Press SET UP to complete the setting. G Press AUDIO to select the desired audio channel.

USE

Audio Language/Sound Selection

Some DVDVIDEO discs contain the multiple audio language or sound. You can select the desired audio language or sound. For some Video CD/SVCD discs, you can switch the audio channel to choose Karaoke either with or without the vocal.

1 Press AUDIO during playback.

The Audio Language/Sound selection display appears.

2 Press AUD IO or selection

keys to select your desired

audio language/sound.

● Each time you press AUDIO or the selection keys, the audio

language/sound changes.

● To clear the Audio Language/Sound selection display, press

ENTER.

NOTES:

● When A7B appears on the TV screen, no other audio language is

recorded.

● When the audio language won’t be changed with the procedure

above, change the audio on a disc menu displayed by pressing MENU.

● Pressing AUDIO to select the audio language/sound is only

possible during playback. It is not possible to select by pressing AUDIO in stop mode. However, you can select the desired audio language/sound from the setup menu while in stop mode.

For example: DVD VIDEO

ENGLISH

When 3 audio languages are contained.

Playback Control (PBC) Function

Some Video CD/SVCD discs support the PBC function. PBC is an abbreviation of APlay Back ControlB. A Video CD/SVCD disc recorded with PBC has its own menus, such as a list of the songs on the disc. You can locate a specific scene by using the menu.

1 Press I in stop mode. The PBC menu appears. 2 Press the number keys to enter the number of the desired

scene, then press ENTER. The unit starts playback of the selected item.

● APBCB appears on the front display panel.

● When ANEXTB or APREVIOUSB appears on the TV screen:

Pressing NEXT (T) advances to the next page. Pressing PREVIOUS (S) returns to the previous page.

● You can return to the menu by pressing RETURN.

● The method of the operation is different depending on the disc.

NOTE:

If you want to playback a PBC-compatible Video CD/SVCD disc without activating the PBC function, start playback with the PBC function, then press o to stop playback. The TV screen becomes all black. Then start playback in stop mode by using the number keys to choose the track, then press ENTER.

Using The On-screen Bar

The on-screen bar allows you to control various playback functions. Some of the functions operated on Navigation Menu can be controlled on the On-screen bar.

ATTENTION:

The on-screen bar can also be used for the HDD deck.

Be sure to clear Library Database Navigation screen by pressing NAVIGATION.

DVDTV

NAVIGATION

ENTER

Selection Keys

FGDE

RETURN

BASIC OPERATIONS ON DVD DECK

EN 27

A Disc type. B Select this for Repeat Playback. (See below) C Select this for A-B Repeat Playback. (A pg. 28) D Select this for search function. (A pg. 28) E Select this for time search function. (A pg. 29) F Select this to switch Simulated Surround Effect function.

(A pg. 29)

G Select this for Picture Control function. (A pg. 29) H Select this to switch picture source type. (A pg. 30) I Current status area for the selected item. J Select this for Program Playback. (A pg. 30) K Select this for Random Playback. (A pg. 30) L Select this to control the switching interval of the slide show.

(A pg. 30)

NOTE:

Although examples of the on-screen bar are provided here only for 3 types of discs, the on-screen bar will be displayed for whichever disc indicated in the left column.

Basic Operation On The On-screen Bar

Example: When selecting Picture Control function of DVD

During playback or while stopped

1 Press ON SCREEN twice to access the on-screen bar. The

item currently selected is highlighted and pointed by :.

CHAPTER 99 EACH 0:00TITLE 99

DVD-

VIDEO

3D-ON CINEMA AUTO

ON SCREEN

How To Access The On-screen Bar

1 Press ON SCREEN twice whenever a disc is loaded.

Contents of the on-screen bar during playback

DVD VIDEO

CHAPTER 99 EACH 0:00TITLE 99

DVD-

VIDEO

Video CD/SVCD

TRACK 99

VCD

JPEG disc

JPEG

TRACK 99GROUP 99

5sec

3D-ON CINEMA AUTO

EACH 0:00

CINEMA

2 Press selection keys to select A B, then press ENTER. The

pop-up window appears under the selected item.

CHAPTER 99 EACH 0:00TITLE 99

DVD-

VIDEO

3D-ON CINEMA AUTO

3 Press selection keys to select the desired option, then press

ENTER.

CHAPTER 99 EACH 0:00TITLE 99

DVD-

VIDEO

3D-ON CINEMA AUTO

NORMAL CINEMA SHARP SOFT

To clear the on-screen bar Press ON SCREEN.

NOTE:

See the corresponding pages for details on each menu item.

Repeat Playback

You can repeat playback as you like according to the type of disc.

1 Press ON SCREEN twice to access the on-screen bar. 2 Press selection keys to select AxB, then press ENTER. The

pop-up window appears under the selected item.

CHAPTER 99 EACH 0:00TITLE 99

DVD-

VIDEO

3D-ON CINEMA AUTO

3 Press selection keys repeatedly to select the desired Repeat

mode, then press ENTER.

+ 61 hidden pages
