JVC SP-THA55C User Manual

DVD DIGITAL CINEMA SYSTEM

TH-A85

Consists of XV-THA85, SP-PWA85, SP-THA85C and SP-THA85F

TH-A55

Consists of XV-THA55, SP-PWA55, SP-THA55C, SP-THA55F and SP-THA55S

INSTRUCTIONS

LVT1025-003A

[B]

Warnings, Cautions and Others

CAUTION

IMPORTANT for the U.K.

DO NOT

plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.

BE SURE

type, as originally fitted.

If nonetheless the mains plug is cut off ensure to remove the fuse and dispose of the plug immediately, to avoid a possible shock hazard by inadvertent connection to the mains supply.

If this product is not supplied fitted with a mains plug then follow the instructions given below:

IMPORTANT.

DO NOT

marked with the letter E or by the safety earth symbol or coloured green or green-and-yellow.

The wires in the mains lead on this product are coloured in accordance with the following code:

As these colours may not correspond with the coloured markings identifying the terminals in your plug proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.

IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.

cut off the mains plug from this equipment. If the

to replace the fuse only with an identical approved

make any connection to the terminal which is

Blue: Neutral Brown: Live

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

CAUTION — F button! (XV-THA85/XV-THA55)

Disconnect the mains plug to shut the power off completely (the STANDBY lamp goes off). The F button in any position does not disconnect the mains line.

• When the system is on standby, the STANDBY lamp lights red.

• When the system is turned on, the STANDBY lamp goes off.

The power can be remote controlled.

CAUTION (SP-PWA85/SP-PWA55)

The power supply to the subwoofer is linked to the center unit. The POWER ON lamp on the subwoofer lights green when the power is turned on.

• Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

• Do not place any naked flame sources, such as lighted candles, on the apparatus.

• When discarding batteries, environmental problems must be considered and local rules or laws governing the disposal of these batteries must be followed strictly.

• Do not expose this apparatus to rain, moisture, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

IMPORTANT FOR LASER PRODUCTS

REPRODUCTION OF LABELS

CLASSIFICATION LABEL, PLACED ON EXTERIOR SURFACE

AAAA

WARNING LABEL, PLACED INSIDE THE UNIT

BBBB

1. CLASS 1 LASER PRODUCT

CAUTION

2. interlock failed or defeated. Avoid direct exposure to beam.

CAUTION

3. serviceable parts inside the Unit; leave all servicing to qualified service personnel.

: Visible and invisible laser radiation when open and

: Do not open the top cover. There are no user

G-1

Warnings, Cautions and Others

SP-PWA85/ SP-PWA55

15 cm

Wall or

obstructions

Front

Floor

Caution: Proper Ventilation

To avoid risk of electric shock and fire and to protect from damage, locate the apparatus as follows: Front: No obstructions open spacing. Sides: No obstructions in 3 cm from the sides. Top: No obstructions in 8 cm from the top. Back: No obstructions in 10 cm from the back. Bottom: No obstructions, place on the level surface. In addition, maintain the best possible air circulation as illustrated.

Spacing 10 cm or more

Wall or

obstructions

XV-THA85/ XV-THA55

Front

Stand height 15 cm or more

Floor

SAFETY INSTRUCTIONS

“SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT”

This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

Do read the operating instructions before you attempt to use the equipment.

Do ensure that all electrical connections (including the mains plug, extension leads and interconnections between pieces of equipment) are properly made and in accordance with the manufacturer’s instructions. Switch off and withdraw the mains plug when making or changing connections.

Do consult your dealer if you are ever in doubt about the installation, operation or safety of your equipment.

Do be careful with glass panels or doors on equipment.

DON’T continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way — switch off, withdraw the mains plug and consult your dealer.

DON’T remove any fixed cover as this may expose dangerous voltages.

DON’T leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or has a standby mode. Switch off using the switch on the equipment and make sure that your family know how to do this. Special arrangements may need to be made for infirm or handicapped people.

DON’T use equipment such as personal stereos or radios so that you are distracted from the requirements of traffic safety. It is illegal to watch television whilst driving.

DON’T listen to headphones at high volume as such use can permanently damage your hearing.

DON’T obstruct the ventilation of the equipment, for example with curtains or soft furnishings. Overheating will cause damage and shorten the life of the equipment.

DON’T use makeshift stands and NEVER fix legs with wood screws — to ensure complete safety always fit the manufacturer’s approved stand or legs with the fixings provided according to the instructions.

DON’T allow electrical equipment to be exposed to rain or moisture.

ABOVE ALL

— NEVER let anyone, especially children, push anything into holes, slots or any other opening in the case — this could result in a fatal

electrical shock.;

— NEVER guess or take chances with electrical equipment of any kind — it is better to be safe than sorry!

G-2

Table of contents

Introduction...................................... 2

Notes on handling..................................................................2

Supplied accessories .............................................................2

About discs ......................................3

Playable disc types ................................................................3

Disc structure ........................................................................4

Playback Control function (PBC) — VCD and SVCD only ......4

Names of parts and controls ...........5

Getting started................................. 8

Connections...........................................................................8

Using the remote control .....................................................16

Basic operations ............................19

Turning the system on/off....................................................19

Selecting the source to play.................................................20

Adjusting the volume ...........................................................20

Listening with headphones ..................................................20

Turning off the sound temporarily .......................................20

Adjusting the brightness ......................................................21

Using the Sleep Timer..........................................................21

Adjusting the output level of the subwoofer.........................22

Adjusting the bass/treble sound...........................................22

Changing the decode mode .................................................22

Playback......................................... 23

Basic playback .....................................................................23

Playback features.................................................................25

Creating realistic sound fields ......33

Using the surround mode ....................................................35

Adjusting the sound.............................................................36

Advanced operations ..................... 37

Using the on-screen bar ......................................................37

Playing from a specified position on a disc..........................38

Using the MP3 control display.............................................40

Using the JPEG control display............................................41

Selecting a view angle of DVD .............................................42

Selecting the subtitle/audio languages.................................43

Special picture playback ......................................................45

Program Playback................................................................47

Random Playback................................................................48

Repeat Playback ..................................................................48

Setting DVD preferences ...............50

Using the choice menus ......................................................50

Menu description.................................................................52

Parental Lock.......................................................................55

System setting ............................... 58

References ..................................... 59

Maintenance ........................................................................59

Trouble shooting..................................................................59

Glossary...............................................................................62

Index....................................................................................63

Specifications ......................................................................64

Tuner operations............................ 27

Manual tuning......................................................................27

Preset tuning .......................................................................27

Selecting the FM reception mode.........................................28

Reducing the noise of AM (MW) broadcast .........................28

Using the RDS (Radio Data System) when receiving

FM stations ..........................................................................29

Introduction

Notes on handling

Important cautions

Installation of the system

• Select a place which is level, dry and neither too hot nor too cold; between 5°C and 35°C.

• Leave sufficient distance between the system and the TV.

• Do not use the system in a place subject to vibration.

Power cord

• Do not handle the power cord with wet hands!

• A small amount of power (1.0 watt) is always consumed while the power cord is connected to the wall outlet (center unit only).

• When unplugging the power cord from the wall outlet, always pull on the plug, not the power cord.

To prevent malfunctions of the system

• There are no user-serviceable parts inside. If anything goes wrong, unplug the power cord and consult your dealer.

• Do not insert any metallic object into the system.

• Do not use any non-standard shape disc (like a heart, flower or credit card, etc.) available on the market, because it may damage the system.

• Do not use a disc with tape, stickers, or paste on it, because it may damage the system.

Label sticker

Safety precautions

Avoid moisture, water and dust

Do not place the system in moist or dusty places.

Avoid high temperatures

Do not expose the system to direct sunlight and do not place it near a heating device.

When you are away

When away on travel or for other reasons for an extended period of time, disconnect the power cord plug from the wall outlet.

Do not block the vents

Blocking the vents may damage the system.

Care of the cabinet

When cleaning the system, use a soft cloth and follow the relevant instructions on the use of chemically-coated cloths. Do not use benzene, thinner or other organic solvents including disinfectants. These may cause deformation or discoloring.

If water gets inside the system

Turn the system off and disconnect the power cord plug from the wall outlet, then call the store where you made your purchase. Using the system in this condition may cause fire or electrical shock.

Supplied accessories

Sticker

Paste

Note about copyright laws

Check the copyright laws in your country before recording from DVDs, Super Video CDs (SVCDs), Video CDs (VCDs) and Audio CDs. Recording of copyrighted material may infringe copyright laws.

Note about copyguard system

DVDs are protected by copyguard system. When you connect the system to your VCR directly, the copyguard system activates and the picture may not be played back correctly.

Check to be sure you have all of the supplied accessories. The number in parentheses is the quantity of the pieces supplied. If anything is missing, contact your dealer immediately.

• Remote control (1)

• Batteries (2)

•FM antenna (1)

• AM (MW) loop antenna (1)

• Power cord (1)

• System cord (1)

• Speaker cords

5 m: For satellite (front left/right) and center speakers (3)

10 m: For satellite speakers (surround left/right) (2) (Length of speaker cords is approximate.)

• Screws (with washer) (TH-A85 only) M4 x 25 mm: For satellite speakers (16)

This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

About discs

Playable disc types

This system has been designed to play back the following discs: DVD Video (DVD), Video CD (VCD), Super Video CD (SVCD), Audio CD, CD-R and CD-RW.

• This system can also play back MP3 and JPEG files recorded on CD-Rs and CD-RWs. (A pg. 23)

• This system can also play back finalized DVD-Rs recorded in DVD VIDEO format. However, some discs may not be played back because of their disc characteristics or recording conditions.

Discs you can play:

Disc Type Mark (Logo)

DVD PAL 2/ALL

VCD PAL —

SVCD PAL —

Audio CD — —

CD-R — —

CD-RW — —

* Note on Region Code

DVD players and DVDs have their own Region Code numbers. This system can only play back DVDs recorded with the color system of PAL whose Region Code number includes “2”.

Examples:

If a DVD with an improper Region Code number is loaded, “REGION CODE ERROR!” appears on the TV screen and playback cannot start.

• The following discs cannot be played back: DVD Audio, DVD-ROM, DVD-RAM, DVD-RW, CD-ROM, CD-I (CD-I Ready), Photo CD, etc. Playing back these discs will generate noise and damage the speakers.

• On some DVDs, Video CDs or SVCDs, their actual operation may be different from what is explained in this manual. This is due to the disc programming and disc structure, not a malfunction of this system.

Notes on CD-R and CD-RW

• User-edited CD-Rs (Recordable) and CD-RWs (Rewritable) can be played back only if they are already “finalized”.

• This system can play back CD-Rs or CD-RWs recorded on a personal computer if they have been recorded in the audio CD format. This system can also play back CD-Rs or CD-RWs if MP3 files or JPEG files are recorded on them. However, some discs may not be played back because of their disc characteristics, recording conditions, or damage or stain on them.

Video

Format

Region Code

Number

Especially, the configuration and characteristics of an MP3 disc or a JPEG disc are determined by the writing (encoding) software and hardware used for recording. Therefore, due to the software and hardware used, the following symptoms may occur:

• Some discs may not be played back.

• Some tracks on an MP3 disc may be skipped or may not be

played back normally.

• Some files on a JPEG disc may be played back distortedly.

• Before playing back CD-Rs or CD-RWs, read their instructions or cautions carefully.

• CD-RWs may require a longer readout time. This is caused by the fact that the reflectance of CD-RWs is lower than that of regular CDs.

About MP3 discs

MP3 is an abbreviation for Motion Picture Experts Group 1 (or MPEG-1) Audio Layer 3. MP3 is simply a compressed data file format. By using MP3 format, one CD-R or CD-RW can contain 10 times as much data as one regular CD.

About JPEG discs

A still-picture data compression system proposed by the Joint Photographic Expert Group, which features small decrease in image quality in spite of its high compression ratio.

Notes on MP3/JPEG discs

• MP3/JPEG discs (either CD-R or CD-RW) require a longer readout time. (It differs due to the complexity of the directory/file configuration.)

• When making an MP3/JPEG disc, select ISO 9660 Level 1 or Level 2 for the disc format.

• This system supports “multi-session” discs (up to 5 sessions).

• This system cannot play “packet write” discs.

• The system can only play MP3/JPEG files with the following file extensions; MP3: “.MP3”, “.Mp3”, “.mP3” and “.mp3” JPEG: “.jpg”, “.jpeg”, “.JPG”, “.JPEG” and any uppercase and

lowercase combination (such as “.Jpg”)

• If both MP3 files and JPEG files are recorded on a disc, set the MP3/JPEG setting in the PICTURE menu to the appropriate setting for the data to be read (“MP3” or “JPEG”). (A pg. 53)

• Some MP3/JPEG discs may not be played back because of their disc characteristics or recording conditions.

Notes on MP3 discs only

• ID3* tags cannot be shown on the display. * An MP3 file can contain file information called an “ID3 Tag”

where its album name, performer, track title, etc. are recorded. There are two versions, ID3v1 (ID3 Tag version 1) and ID3v2 (ID3 Tag version 2).

• We recommend to record each piece of material (song) at a sample rate of 44.1 kHz and at a data transfer rate of 128 kbps.

• Some tracks on an MP3 disc may be skipped or may not be played back normally.

Notes on JPEG discs only

• We recommend to record a file at 640 x 480 resolution. (If a file has been recorded at a resolution of more than 640 x 480, it will take a longer time to be displayed.)

• This system can only play baseline JPEG files*. Progressive JPEG files* or lossless JPEG files* cannot be played. * Baseline JPEG format: Used for digital cameras, web, etc.

Progressive JPEG format:Used for web. Lossless JPEG format: An old type and rarely used now.

• Some files on a JPEG disc may be played back distortedly.

About discs

NOTE

Submenu

Menu screen

A: Moving picture B: Still picture

Press RETURN.

IMPORTANT

Before playing a disc, make sure of the following;

• Check the connection with the TV.

• Turn on your TV and select the correct input mode on the TV to view the pictures or on-screen information on the TV screen.

• For DVD playback, you can change the initial setting to your preference. (Apg.50–57)

If B appears on the TV screen when pressing a button;

The disc cannot accept the operation you have tried to do, or the information required for that operation is not recorded on the disc.

NOTICE:

be accepted.

In some cases, without showing B, operations will not

Disc structure

DVD

A DVD consists of “titles” and each title may be divided into “chapters”. For example, if a DVD contains movies, each movie may have its own title number and may be further divided into chapters.

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2

Playback Control function (PBC) — VCD and SVCD only

The Playback Control function allows you to enjoy menu-driven operation and high-resolution still images which have a resolution four times greater than moving pictures.

High-resolution still image display

You can display high-quality images which are four times clearer than moving pictures.

Menu-driven playback

A selection menu is displayed when you start playing a Video CD or SVCD with the Playback Control feature. The selection menu shows a list of numbers for selection. Some discs may show moving pictures or a divided screen. You can interact with the screen using a menu display to select and play an entry. See example illustration below about basic features of menu-driven playback (for details about the operation through the menu, also see page 39).

Video CD/SVCD/Audio CD

A Video CD, SVCD, Audio CD consists of “tracks”. In general, each track has its own track number. (On some discs, each track may also be further divided by indexes.)

Track 1 Track 2 Track 3 Track 4 Track 5

MP3 discs

On an MP3 disc, each song is recorded as a track (file). Tracks are usually grouped into a group (folder). Groups can also include other groups, creating hierarchical group layers. This system can recognize up to 150 tracks per group and up to 99 groups per disc.

• If there is any type of file other than MP3 files in a group (folder), those files are also counted in the total number of 150.

Group 1 Group 2

Track 1 Track 2 Group 3 Group 4 Group 5

JPEG discs

On a JPEG disc, each still picture is recorded as a file. Files are usually grouped into a group (folder). Groups can also include other groups, creating hierarchical folder layers. This system can recognize up to 150 files per group and up to 99 groups per disc.

• If there is any type of file other than JPEG files in a group (folder), those files are also counted in the total number of 150.

Group 1 Group 2

• When operating a Video CD or SVCD using the menu, some functions such as Repeat Playback may not work.

File 1 File 2 Group 3 Group 4 Group 5

Names of parts and controls

The illustrations of the center unit and the subwoofer used in this manual are of TH-A85 unless otherwise noted.

Front panel (center unit)

Source button (SOURCE) Apg. 20

Volume buttons (VOLUME +/–) Apg. 20

Disc tray Apg. 23

Illumination lamp Apg. 21

Stop button (7) Apg. 23

Play button (3) Apg. 23

Pause button (8) Apg. 23

Reverse skip button (4) Apg. 26

Rear panel (center unit)

Forward skip button (¢) Apg. 26

Standby lamp (STANDBY) Apg. 19

Standby-on button (F) Apg. 19

Display window Apg.6,24

Remote sensor Apg. 16

Headphones jack (PHONES) Apg. 20

Open/close button (0) Apg. 23

System cord connector Apg. 10

Audio input jacks (AUX IN) Apg. 14

Digital input jack (DIGITAL IN) Apg. 14

AV (SCART) connector (AV) Apg. 8

Video output jacks (OUT VIDEO/S-VIDEO) Apg. 8

Antenna terminals (ANTENNA) Apg. 9

Video output signal selector (RGB-Y/C) Apg. 8

AV COMPU LINK-III jacks (for future use)

AC IN socket Apg. 15

Names of parts and controls

Display window (center unit)

A • Dolby Pro Logic II indicator (GPLII) A pg. 33

• Linear PCM indicator (LPCM) A pg. 34

• Digital signal format indicators A pg. 34

Dolby Digital (GDIGITAL), DTS (C)

B MP3 indicator A pg. 24 C Channel indicator (CH) A pg. 28 D Main display A pg. 24 E Stereo indicator (ST) A pg. 27 F Tuning indicator (TUNED) A pg. 27 G Auto muting indicator (AUTO MUTING) A pg. 28

Powered subwoofer

• Source signal indicators (abcdghi )

A pg. 34

• Subwoofer indicator (f) A pg. 34

• Sound reproducing speaker indicator ( ) A pg. 34

I Surround indicator (SURROUND) A pg. 35 J DSP indicator A pg.33–35 K Resume indicator (RESUME) A pg. 24 L Repeat mode indicators A pg. 48 M RDS reception mode indicators A pg. 29 – 32

RDS, TA, News, Info

Rear

A System cord connector A pg. 10 B Front speaker terminals (FRONT SPEAKERS) A pg. 12, 13 C Center speaker terminals (CENTER SPEAKER) A pg. 12, 13 D Surround speaker terminals (SURROUND SPEAKERS) A pg. 12, 13 E Power cord A pg. 15 F Power lamp (POWER ON) A pg. 19

Front

Names of parts and controls

Remote control

NOTE

• To use buttons L – Y and i – p, slide

down the remote control cover.

A Remote control mode selector A pg.17–58

AUDIO, TV, VCR

B Open/close button (OPEN/CLOSE) A pg. 23 C Display window button (FL DISPLAY) A pg. 24 D Dimmer button (DIMMER) A pg. 21 E Source selecting buttons A pg. 20

DVD, FM/AM, AUX, TV SOUND

F Surround buttons (SURR)

Mode (MODE), On/Off (ON/OFF) A pg. 35

G TV volume buttons (TV VOL +/–) A pg. 17 H Operating buttons

• Play button (3) A pg. 24

• Forward/reverse skip buttons (¢/4) A pg. 26

• Fast-forward/reverse playback buttons (¡/1) A pg. 26

• Stop button (7) A pg. 23

• Pause button (8) A pg. 23

• Tuning buttons (TUNING ª, TUNING ·) A pg. 27

• Memory button (MEMORY) A pg. 28

• FM reception/Beat Cut mode button (FM MODE) A pg. 28

• Enhanced Other Network operating button (TA/NEWS/INFO)

A pg. 31

• PTY selection buttons (PTY ª, PTY ·) A pg. 30

I Top menu button (TOP MENU) A pg. 38 J

• Cursor buttons (3/2///5) A pg. 38

• Enter button (ENTER) A pg. 17

• One Touch Replay button ( ) A pg. 25

• Record button (REC) A pg. 18

L Audio button (AUDIO) A pg. 43, 44 M Subtitle button (SUBTITLE) A pg. 43 N Angle button (ANGLE) A pg. 42 O Setting button (SETTING) A pg. 58 P Choice menu button (CHOICE) A pg. 50 Q Group/title button (GROUP/TITLE) A pg. 39 R Repeat button (REPEAT) A pg. 48 S A-B repeat button (A-B REPEAT) A pg. 49 T Effect button (EFFECT) A pg. 36 U Sleep button (SLEEP) A pg. 21 V Decode mode button (DECODE) A pg. 22 W Test tone button (TEST) A pg. 36 X Subwoofer adjustment buttons (S.WFR +/–) A pg. 22 Y Center speaker adjustment buttons (CENTER +/–) A pg. 36 Z Standby-on button (F AUDIO) A pg. 19 a Standby-on button (F TV) A pg. 17 b Standby-on button (F VCR) A pg. 18 c Muting button (MUTING) A pg. 20 d TV/Video mode button (TV/VIDEO) A pg. 17 e Channel buttons (CHANNEL +/–) A pg. 17 f Volume buttons (AUDIO VOL +/–) A pg. 20 g

• Menu button (MENU) A pg. 38

• PTY search button (PTY SEARCH) A pg. 30

h • On-screen button (ON SCREEN) A pg. 37

• RDS display button (RDS DISPLAY) A pg. 29

• Number buttons A pg. 17, 26, 39

• TV returning button (TV RETURN) A pg. 17

j Return button (RETURN) A pg. 4, 39 k Cancel button (CANCEL) A pg. 47 l VFP setting button A pg. 46 m Zoom button (ZOOM) A pg. 45 n Bass adjustment buttons (BASS +/–) A pg. 22 o Treble adjustment buttons (TREBLE +/–) A pg. 22 p Surround speaker adjustment buttons (SURR) A pg. 36

Left (L +/–), Right (R +/–)

Getting started

Connections

• Do not connect the AC power cord until all other connections have been made.

• Since different components often have different terminal names, carefully read the instructions supplied with the components you are going to connect.

Connecting a TV

To view pictures and on-screen displays, connect the TV to the center unit.

• Distortion of picture may occur when connecting to the TV via a VCR, or to a TV with a built-in VCR.

• You need to set “MONITOR TYPE” in the PICTURE menu correctly according to the aspect ratio of your TV. (A pg. 53)

7 To connect a TV with the SCART connector

Connect the center unit’s AV (SCART) connector with your TV’s SCART connector using a SCART cable (not supplied).

• Set the RGB-Y/C selector correctly according to your TV.

• If the TV accomodates the RGB video signal, set the RGB-Y/C selector to “RGB” so that you can enjoy better-quality pictures.

• If the TV accomodates the S-video signal, set the RGB-Y/C selector to “Y/C”.

• If the TV accomodates the composite video signal only, set the RGB-Y/C selector to “RGB”.

Center unit

RGB-Y/C selector

To AV (SCART) connector

SCART cable (not supplied)

* Some TV’s SCART connectors output audio signal. In such a case, you can enjoy the TV sound through this system.

NOTE

• No sound comes out from “AV” (SCART) connector.

To SCART

connector

7 To connect a TV through the composite or S-video jacks

Connect the TV using the composite video cord (not supplied) or an S-video cord (not supplied). If your TV has an S-video (Y/C-separation) jack, you can get better picture quality than by using composite video connection.

• Connect the S-video cord by matching the / mark on the plug to the one on the rear of the center unit.

RGB-Y/C selector

Center unit

To composite video input

To S-video input

* When connecting an S-video cord, set the RGB-Y/C selector to “Y/C”.

When connecting a composite video cord, set the RGB-Y/C selector to “RGB”.

NOTE

• When the RGB-Y/C selector is set to “RGB”, correct video signal is not output from the S-VIDEO jack on the rear panel.

• Whether the RGB-Y/C selector is set to “RGB” or “Y/C”, the composite video signal is always output from the OUT VIDEO jack.

Composite video cord

(not supplied)

S-video cord

(not supplied)

Getting started

NOTE

Outdoor single vinyl-covered wire antenna (not supplied)

AM (MW) loop antenna

Extend the supplied FM antenna horizontally.

Center unit

Outdoor FM antenna

(not supplied)

Outdoor FM antenna cord

(not supplied)

Connecting the FM and AM (MW) antennas

Make sure the antenna conductors do not touch any other terminals, connecting cords and power cords. This could cause poor reception.

AM (MW) loop antenna

Setting up supplied AM (MW) loop antenna

Attach the AM (MW) loop to its base by snapping the tabs on the loop into the slot on the base.

If the antenna cord is covered with the insulation coat, twist and pull the insulation coat off and remove.

Connecting AM (MW) loop antenna

Center unit

If reception is poor

Connect an outdoor single vinyl-covered wire antenna (not supplied) to the AM EXT terminal. (Keep the AM (MW) loop antenna connected.)

• Twist together both wires.

FM antenna

Connecting supplied FM antenna

Press and hold down the terminal clamp.

Insert the antenna cord.

Release finger from the clamp.

• Turn the loop antenna until you have the best reception.

If reception is poor

Connect an outdoor FM antenna with standard type (75 C coaxial) connector.

• Disconnect the supplied FM antenna before attaching a 75 C coaxial connector (the kind with a round wire going to an outdoor antenna).

• We recommend that you use coaxial cable for the FM antenna as it is well-shielded against interference.

Getting started

Connecting the powered subwoofer

Connect the supplied powered subwoofer (SP-PWA85/SP-PWA55) using the system cord (supplied).

• Connect the system cord by matching the 5 marks on the plugs to the ones on the center unit and powered subwoofer.

System cord (supplied)

Ensure that the 5 mark on the plug faces down.

Powered

subwoofer

Center unit

Connecting the satellite speakers

7 Speaker layout

When positioning the speakers, to obtain the best possible sound from this system you need to place all satellite speakers at the same distance from the listening position with the front of each speaker facing toward the listener.

When you cannot place them at the same distance from the listening position, you can make adjustment so that speakers operate as if they are placed at the best position. (A pg. 54)

• Normally place the powered subwoofer in front of you. (Since bass sound is non-directional, you do not need to place it at the same distance as the other speakers.)

NOTE

• Although the satellite speakers and the powered subwoofer are magnetically shielded, the TV screen may appear mottled. In this case, keep the distance between them to the TV to over 10 cm.

• For safety reasons, always ensure that there is sufficient space behind the powered subwoofer.

• When you position the satellite speakers in a relatively high place, such as the top of your bookshelf, place them on a flat and level surface.

• Speaker grilles are not removable (except SP-THA55C, SP-THA55F, and SP-THA55S). Trying to remove them by force may damage them.

• Be sure to place the powered subwoofer to the TV’s right. If you place the powered subwoofer to the TV’s left, keep sufficient distance between them to prevent the TV from appearing mottled.

TH-A85

Center speaker

Surround left

Powered subwoofer

Front rightFront left

Surround right

NOTE

Only for TH-A85

• Do not lean against the satellite speakers, as the speakers could fall down or break, possibly causing injury. Especially be careful not to let children lean against them.

TH-A55

Front rightFront left

Center

speaker

Surround left Surround right

Powered

subwoofer

Getting started

NOTE

Speaker section

Stand

Screws (4) (supplied, M4 x 25 mm)

Cushion (not supplied)

Assembling the satellite speakers (TH-A85 only)

Each speaker (except the center speaker) has been divided into two parts for shipment. Before connecting the satellite speakers, first assemble them by following the procedure below.

This page is for

Fix the stand to the speaker section.

• Be sure to tighten the screws firmly.

TH-A85

Speaker section

Before assembling —

• Prepare a Phillips screwdriver.

• Take care not to drop the stand while assembling; otherwise, it may cause damage to the floor or injury.

• Ensure enough space exists for assembly and installation.

• Spread a large, thick cloth on the floor where you assemble the speakers, so you can protect the floor and the speaker itself.

Connect the speaker connectors to the

Stand

stand connectors.

• Be sure to connect the speaker connectors by matching their sizes.

Front

Speaker connectors

Front

Repeat the procedure from step 1 to assemble the other satellite speakers.

• Use the speaker after assembly is fully and correctly done.

• It is recommended to place a cushion under the speaker section. You can tighten the screws easily by placing the speaker section horizontally.

Speaker section

Join the stand to the speaker section.

Speaker section

Rear

Stand

Getting started

This page is for

TH-A85

7 Connecting the satellite (front, center, surround) speakers (TH-A85)

Each speaker (SP-THA85F) can be used as a front or surround speaker.

CAUTION

• When you connect (larger) speakers other than the supplied ones, only use speakers with the same speaker impedance (SPEAKER IMPEDANCE) as indicated by the speaker terminals on the rear of the powered subwoofer.

• DO NOT connect more than one speaker to one speaker terminal.

Before connecting the speaker cords;

Front speakers

Twist and pull the insulation coat off and remove.

Center speaker

(SP-THA85C)

(SP-THA85F)

Press and hold the clamp.

• Connect the white cords to the red (ª) terminals and black cords to the black (·) terminals.

Insert the bare end of the speaker cord into the terminal.

Release the clamp.

Red

Black

White

Red

White

Insert the speaker cords into the speaker terminals.

Black

Surround speakers

(SP-THA85F)

Black

Powered subwoofer

Route the speaker cord as shown at right.

• Be sure to remove all slack from the cord so that the speaker cord lies flat.

Getting started

This page is for

7 Connecting the satellite (front, center, surround) speakers (TH-A55)

Be sure to identify each speaker (SP-THA55C/SP-THA55F/SP-THA55S) and connect them to the corresponding terminals of the powered subwoofer.

CAUTION

• DO NOT connect more than one speaker to one speaker terminal.

Front speakers (SP-THA55F)

Before connecting the speaker cords;

Twist and pull the insulation coat off and remove.

Center speaker

(SP-THA55C)

Press and hold the clamp.

Insert the bare end of the speaker cord into the

Release the clamp.

terminal.

• Connect the white cords to the red (ª) terminals and black cords to the black (·) terminals.

Tilt adjustment screw

Powered subwoofer

Surround speakers

(SP-THA55S)

Black

White

Red

CAUTION

When installing the satellite speakers on the wall (TH-A55 only);

• Be sure to have them installed on the wall by a qualified personnel. DO NOT install the satellite speakers on the wall by yourself to avoid unexpected damage from their falling off the wall due to incorrect installation or weakness in wall structure.

• Care must be taken in selecting a location for speaker installation on a wall. Injury to personnel or damage to equipment may result if the speakers installed interfere with daily activities.

• Before installing the satellite speakers on the wall, be sure to detach the speaker stands equipped with the satellite speakers by removing the tilt adjustment screws.

NOTE

• You can attach the satellite speakers to the separately sold TV stand instead of the stands attached to them at your purchase. For assembling the TV stand and speakers, be sure to use the screws supplied with the TV stand. Using the screws attached to the speakers may damage the speakers. For details, refer to the instructions manual supplied with the TV stand.

• You can tilt the satellite speakers and center speaker. Loosen the tilt adjustment screw, adjust the angle, then tighten the screw.

Getting started

Connecting to an analog component

You can enjoy the sound of an analog component such as a VCR, TV, or Cassette recorder with this system. Use RCA pin plug cords (not supplied) for connection.

Cassette recorder

Center unit

Red White

RCA pin plug cord

(not supplied)

To audio

output

VCR

NOTE

• If you connect a sound-enhancing device such as a graphic equalizer between the source components and this system, the sound output through this system may be distorted.

• When playing a video component such as a VCR;

•

To listen to the sound, select “AUX” as the source to play. (Apg. 20)

•

To see the picture, connect the video output jack of the component to the video input jack of the TV directly, and select the correct input mode on the TV.

Connecting to a digital component

You can enjoy the sound of a digital component such as a DBS (Direct Broadcast Satellite) tuner or MD recorder with this system. Use digital optical cord (not supplied) for connection.

Center unit

Digital optical cord (not supplied)

To digital optical output

MD recorder

Before connecting a digital optical cord, unplug the protective plug.

DBS tuner

NOTE

When playing a video component such as a DBS tuner;

• To listen to the sound, select “AUX DIGITAL” as the source to play. (Apg. 20)

• To see the picture, connect the video output jack of the component to the video input jack of the TV directly, and select the correct input mode on the TV.

Getting started

Connecting the power cord

Make sure that all connections have been completed, before plugging in the power cords of the center unit and powered subwoofer.

Firmly insert the supplied power cord into the ÓAC IN socket on the rear of the center unit.

Plug both power cords into AC outlets.

Center unit

Plug into AC outlets.

Power cord (supplied)

Power cord

CAUTION

• Disconnect the power cord before cleaning or moving the system.

• Do not touch the power cord with wet hands.

• Do not pull on the power cord to unplug the cord. When unplugging the cord, always grasp and pull the plug so as not to damage the cord.

NOTE

• Keep power cords away from other connected cords. The power cords may cause noise or screen interference.

• Preset settings, such as preset stations and surround mode adjustment, may be erased in a few days in the following cases;

•

If you unplug the power cord of the center unit.

•

If a power failure occurs.

• The speakers will not produce any sound if the power cord of the powered subwoofer is removed from the AC outlet while the center unit is turned on. In this case, press

AUDIO

again.

AUDIO

on the remote control or

on the center unit to turn the power off, plug in the powered subwoofer, then press

Powered subwoofer

Getting started

Using the remote control

The remote control makes it easy to use many of the system functions from a distance of up to 7 m away.

• You can also use the remote control supplied for this system to operate other manufacturers’ TVs (A pg. 17) and VCRs (A pg. 18).

Putting batteries in the remote control

Before using the remote control, first put in the 2 supplied batteries.

1 Remove the battery

cover on the back of the remote control.

2 Insert the batteries.

• Make sure to match polarity: (+) to (+) and (–) to (–).

Operating the system from the remote control

Aim the remote control directly at the remote sensor on the center unit.

• To control other components, aim the remote control directly at the remote sensor on each component. Refer also to their instruction manuals.

• To operate the remote control properly, do not hide the remote sensor by placing any obstructions in front of it.

Remote sensor

3 Replace the cover.

If the range or effectiveness of the remote control decreases, replace the batteries. Use two R6P (SUM-3)/AA (15F) type drycell batteries.

CAUTION

• Follow these precautions to avoid leaking or cracking batteries;

• Use the correct type of batteries. Batteries that look similar may

differ in voltage.

• Always replace both batteries at the same time.

• Do not expose batteries to heat or flame.

Getting started

Remote control

mode selector

(play button)

Number buttons

4 Press number buttons (1-9, 0) to enter

the manufacturer’s code (2 digits).

Examples: For a Hitachi TV: Press 0, then 7.

For a Toshiba TV: Press 2, then 9.

Manufacturer

JVC 01 Nordmende 13, 14, 18, 26 – 28

Akai 02, 05 Okano 09

Blaupunkt 03 Orion 15

Daewoo 10, 31, 32 Panasonic 16, 17

Fenner 04, 31, 32 Philips 10

Fisher 05 Saba 13, 14, 18, 26 – 28

Grundig 06 Samsung 10, 19, 32

Hitachi 07, 08 Sanyo 05

Inno-Hit 09 Schneider 02, 05

Irradio 02, 05 Sharp 20

Magnavox 10 Sony 21 – 25

Mitsubishi 11, 33 Telefunken 13, 14, 18, 26 – 28

Miver 03 Thomson

Nokia 12, 34 Toshiba 29

Code

Manufacturer

Code

13, 14, 18, 26–28, 30

For TV operations

You can operate your TV using the remote control supplied with this system.

• Refer also to the instruction manuals supplied with your TV.

7 To set the manufacturer’s code

You can operate a JVC TV without setting the remote control signal.

1 Slide the remote control mode selector

to TV.

2 Press and hold F TV.

Keep the button pressed until step 4 is finished.

3 Press ENTER.

5 Release F TV. 6 Try operating your TV by pressing

F TV.

When your TV turns on or off, you have entered the correct code. If there is more than one code listed for corresponding brand, try each one until you enter the correct one.

NOTE

• Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

• Set the codes again after replacing the batteries of the remote control.

7 Operation

IMPORTANT

Before using the remote control to operate a TV;

• Set the remote control mode selector to TV.

The following buttons are available:

F TV: Turns TV on and off. TV VOL +/–: Adjusts the volume. TV/VIDEO: Selects the input mode (either TV or

VIDEO).

CHANNEL +/–: Changes the channels. 1-10, 0, +10 (100+): Selects the channel. TV RETURN: Alternates between the previously selected

channel and the current channel.

Getting started

For VCR operations

You can operate your VCR using the remote control supplied with this system.

• Refer also to the instruction manuals supplied with your VCR.

7 To set the manufacturer’s code

1 Slide the remote control mode selector

to VCR.

2 Press and hold F VCR.

Keep the button pressed until step 4 is finished.

3 Press ENTER. 4 Press number buttons (1-9, 0) to enter

the manufacturer’s code (2 digits).

Examples: For a Panasonic VCR: Press 2, then 1.

For a Philips VCR: Press 0, then 5.

Manufacturer

JVC 01 Nokia 16

Aiwa 02, 20 Nordmende 17 – 19, 31

Bell+Howell 03, 16 Orion 20

Blaupunkt 04 Panasonic 21

CGM 03, 05, 16 Philips 05, 22

Daewoo 34 Phonola 05

Digtal 05 Saba 17 – 19, 23, 31

Fisher 03, 16 Samsung 24, 25

G.E. 06 Sanyo 03, 16

Grundig 07 Sharp 26, 27

Hitachi 08, 09 Siemens 07

Loewe 05, 10, 11 Sony 28 – 30, 35

Magnavox 04, 05 Telefunken 17 – 19, 31, 32

Mitsubishi 12 – 15 Toshiba 33

Code

Manufacturer

Code

7 Operation

IMPORTANT

Before using the remote control to operate a VCR;

• Set the remote control mode selector to VCR.

The following buttons are available:

F VCR: Turns VCR on and off. 3 (play button): Starts playback. 7 : Stops operation. 8 : Pauses playback. ¢: Fast forwards video tape. 4: Rewinds video tape.

REC: Press this button together with 3 (play button) to

start recording or together with 8 to pause recording.

CHANNEL +/–: Changes the TV channels on the VCR.

5 Release F VCR. 6 Try operating your VCR by pressing

F VCR.

When your VCR turns on or off, you have entered the correct code. If there is more than one cord listed for your brand, try each one until you enter the correct one.

NOTE

• Manufacturers’ codes are subject to change without notice. If they are changed, this remote control cannot operate the equipment.

• Set the codes again after replacing the batteries of the remote control.

+ 47 hidden pages
