COMPACT COMPONENT SYSTEM
NX-PS1
—Consists of CA-NXPS1, SP-NXPS1F and SP-NXPS1W
INSTRUCTIONS
COMPACT COMPONENT SYSTEM
STANDBY
CA-NXPS1 SP-NXPS1F SP-NXPS1WSP-NXPS1F
NX-PS1
VOLUME
FUNCTION
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1633-001A
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
(For U.S.A.)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
(For U.S.A.)
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
(For U.S.A.)
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
G-1
(For U.S.A.)
CAUTION
Changes or modifications not approved by JVC
could void the user’s authority to operate the
equipment.
(For U.S.A.)
For the main unit:
Declaration of Conformity
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED
THE CLASS B LIMITS FOR RADIO NOISE
EMISSIONS FROM DIGITAL APPARATUS AS
Model Number: NX-PS1
Trade Name: JVC
Responsible Party: JVC Americas Corp.
Address: 1700 Valley Road, Wayne
New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL
APPARATUS,” ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES
LIMITES DE BRUITS RADIOELECTRIQUES
APPLICABLES AUX APPAREILS NUMIRIQUES
DE CLASSE B PRESCRITES DANS LA NORME
SUR LE MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
received, including interference that may cause
undesired operation.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10
cm (3-
15
/16") or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez l’appareil de la manière
suivante:
1. Avant: Bien dégagé de tout objet.
2. Côtés/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiqués sur le schéma ci-dessous.
3. Dessous: Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation correcte puisse se faire en
le plaçant sur un support d’au moins dix centimètres de hauteur.
Front
Face
15 cm
15
(5- ")
/
16
2 cm
13
(")
/
16
2 cm
13
(")
/
16
2 cm
13
(")
/
16
15 cm
15
/
(5- ")
16
15 cm
15
(5- ")
/
16
Side
Côté
15 cm
15
(5- ")
/
16
15 cm
15
(5- ")
/
16
10 cm
15
(3- ")
/
16
G-2
Contents
Introduction .....................................................2
Precautions ...................................................................... 2
Getting Started ................................................3
Connection ...................................................................... 4
Basic Operations .............................................5
Unit .................................................................................5
Remote Control ............................................................... 6
Setting the Clock and Daily Timer ................ 7
Setting the Clock ............................................................7
Setting the Daily Timer ..................................................7
Playing Back from iPod ..................................8
To Connect iPod ............................................................. 8
Basic Operations .............................................................8
Playing Back from USB mass storage class
device .............................................................9
To connect the USB mass storage class device .............. 9
Basic Operations .............................................................9
Playing Back from the PC ............................10
How to install the USB drivers ..................................... 10
To playback sounds on the PC ..................................... 10
Playing Back from Other Equipment ......... 11
To connect other equipment .........................................11
Troubleshooting ............................................11
Specifications .................................................12
1
Introduction
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible
performance from the unit.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor
too cold–between 5°C and 35°C (41°F and 95°F).
• Install the System in a location with adequate ventilation to
prevent internal heat buildup inside the System.
DO NOT install the System in a location near
heat sources, or in a place subject to direct
sunlight, excessive dust or vibration.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
Power sources
• When unplugging the System from the wall outlet, always
pull on the plug, not the AC adaptor.
DO NOT handle the AC adaptor with wet
hands.
Internal heat
For safety, observe the following carefully:
• Make sure there is good ventilation the main
unit. Poor ventilation could overheat and
damage the System.
• DO NOT block the ventilation openings or
holes. If they are blocked by a newspaper or
cloth, etc., the heat may not be able to get
out.
Others
• Should any metallic object or liquid fall into the System,
unplug the AC adaptor and consult your dealer before
operating any further.
DO NOT disassemble the System since there
are no user serviceable parts inside.
• If you are not going to operate the System for an extended
period of time, unplug the AC adaptor from the wall outlet.
If anything goes wrong, unplug the AC adaptor and consult
your dealer.
2
Getting Started
Supplied Accessories
After unpacking, check to be sure that you have all the following items. The number in parentheses indicates the quantity of
each piece supplied.
• Remote control (1)
• Lithium coin battery CR2025 (1) (The battery has been installed when shipped from the factory.)
• Speaker cords 1.5m (2)
• Speaker cord 2.5m (1)
• AC power cord (1)
• AC adaptor (AA-R2401) (1)
• iPod connection cable (Audio) (1)
• iPod stand (1)
If anything is missing, consult your dealer immediately.
CAUTION:
To avoid risk of fire, and to prevent damage.
• Do not use AC adaptors except the supplied AC adaptor.
• Do not use the supplied AC adaptor for other equipment.
Prepare the Remote Control
When you use the remote control
for the first time, pull out the
insulation sheet.
Insulation sheet
(Front side)
Replacing the Battery in the Remote Control
Insert the battery into the remote control by
matching the polarity (+ and -) correctly.
Lithium coin battery
(product number: CR2025)
(Rear side)
Warning
• Store the battery in a place where children cannot reach. If a child accidentally swallows the battery, consult
a doctor immediately.
• Do not recharge, short, disassemble or heat the battery or dispose of it in a fire. Doing any of these things
may cause the battery to give off heat, crack, or start a fire.
• Do not leave the battery with other metallic materials. Doing this may cause the battery to give off heat, crack,
or start a fire.
• When throwing away or saving the battery, wrap it in tape and insulate; otherwise, the battery may start to
give off heat, crack, or start a fire.
• Do not poke the battery with tweezers or similar tools. Doing this may cause the battery to give off heat,
crack, or start a fire.
• Dispose of battery in the proper manner, according to federal, state, and local regulations.
For USA-California Only
This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material – special handling
may apply.
See http://www.dtsc.ca.gov/hazardouswaste/perchlorate
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
3
Connection
Do not connect the AC power cord until all other connections have been made.
Subwoofer
To a wall outlet
Plug the AC power cord
only after all connections
are complete.
Unit
USB AUDIO
AC power
cord
iPod terminal
AC adaptor
AC adaptor
Main speaker
terminal
USB
AUDIO
i Pod
DC IN
23V 2.5A
DC IN
RIGHT LEFT WOOFER
6-16‰ 8-16‰
SPEAKERS
23V 2.5A
Speaker cord (1.5m) Speaker cord (1.5m)
To connect the speaker cords
Make sure the unit, main speakers, and subwoofer are
connected correctly and firmly.
When connecting the speaker cords, match the polarity of
the speaker terminals: white cord to (+) and white cord with
black stripe to (-).
NOTES
• DO NOT connect more than one speaker to each terminal.
• DO NOT allow the conductor of the speaker cords to be
in touch with the metallic parts of the System.
RIGHT LEFT WOOFER
6-16‰ 8-16‰
SPEAKERS
e.g. Speaker
1 Hold
e.g. Unit
2 Insert
INPUT
Speaker cord (2.5m)
Speaker cord
Main speaker
3 Release
1 Unlock
2 Insert
3 Lock
4
Unit
Basic Operations
COMPACT COMPONENT SYSTEM
Display
STANDBY lamp
Remote control
sensor
Operation
buttons
4
Operating on the Unit
Buttons Functions
Adjusts the volume level VOLUME MIN /
1 to 29 / VOLUME MAX.
1
VOLUME
STANDBY
AUX jack
NX-PS1
FUNCTION
USB
MEMORY
AUX PHONES
VOLUME
Opening the front panel cover
Adjust the volume
1
Select a source
2
3
STANDBY/ON button
USB MEMORY terminal
PHONES jack
Using Headphones
Be sure to turn down the volume before
connecting or wearing the headphones.
• Connecting the headphones will
deactivate the speakers.
Buttons Functions
Turns on or off (standby) the power.
3
STANDBY
FUNCTION
USB
MEMORY
AUX
PHONES
Selects a source.
iPod USB MEMORY
AUX USB AUDIO
FUNCTION
2
See “Playing Back from iPod” (P.8).
See “Playing Back from USB mass storage class
device” (P.9).
See “Playing Back from the PC” (P. 10).
See “Playing Back from Other Equipment” (P. 11).
Display Information
Symbols Description
RND
1/ ALL/ GR Lights when Repeat mode is activated. (P.10)
FLAT/ROCK/POP/
JAZZ/CLAS(CLASSIC)
SLEEP
“Random” and “Repeat” can only be set in USB MEMORY mode.
Lights when Random Play mode is activated. (P.10)
Displays an selected EQ setting. (P.6)
Lights when the USB mass storage class
device is connected and the USB MEMORY
mode is selected.
Lights when the Sleep Timer is activated. (P.6)
Lights when Daily Timer is set. (P.7)
Operates music.
4
See “Playing Back from iPod” (P.8).
See “Playing Back from USB” (P.9).
While selecting iPod / USB AUDIO:
Volume level
Source name
Current status
While selecting USB MEMORY:
Volume level
Elapsed playing time
Current track number
Current group number
File information ⇔ Clock display
While selecting AUX:
Volume level
Source name
No display ⇔ Clock display
⇔
Clock display
5
Remote Control
Sleep timer
8
Adjust the tone
FADE MUTING
button
6
7
10
5
1
2
3
9
Dimmer/ECO mode
4
Operating on the Remote Control
Buttons Functions
1
2
3
4
Turns on or off (standby) the power
Changes the display information.
USB MEMORY mode : Clock display ⇔ File information
Other mode : Clock display ⇔ Source information
Changes source to iPod.
See “Playing Back from iPod” (P.8).
Changes source to USB MEMORY.
See “Playing Back from USB mass storage class
device” (P.9).
Changes source to USB audio and AUX.
See “Playing Back from the PC” (P.10).
See “Playing Back from Other Equipment” (P.11).
Adjusts the volume level VOLUME MIN / 1 to 29 /
VOLUME MAX.
STANDBY/ON
button
Change the display
information
Select a source
Adjust the volume
To dim the display—DIMMER
Press while the System is turned on.
“DIMMER ON” appears.
• To cancel this function, press DIMMER/ECO again.
“DIMMER OFF” appears.
To set the ECO mode.
In ECO mode, the dispaly goes off and the least power is
consumed.
Press While the System is turned off.
“ECO ON” appears and then nothing is displayed.
• To cancel this function, press DIMMER/ECO again.
“ECO OFF” appears and then the clock is displayed.
To turn off the System after a certain period
of time—Sleep Timer
1
2
• To check the time remaining before the shut-off time, press
SLEEP once.
If you press the button repeatedly, you can change the shutoff time
Press repeatedly to specify the time (in minutes) as
follows:
10 20 30 60 90 120
OFF (Canceled)
Wait until the set time goes off.
To adjust the tone
Drops the volume in a moment.
5
To restore the volume, press again, or adjust the
volume level.
Others
Buttons Reference pages
6
7
8
9
10
CLOCK/TIMER set (P.7)
CLOCK/TIMER set (P.7)
USB MEMORY (P.9)
AUX (P.11)
CLOCK/TIMER set (P.7)
USB MEMORY (P.9)
CLOCK/TIMER set (P.7)
iPod (P.8)
USB MEMORY (P.9)
USB MEMORY (P.9)
1
2
ROCK Boosts low and high frequency. Good for acoustic
POP Good for vocal music.
JAZZ Good for jazz music.
CLASSIC Good for classical music.
FLAT Normal sound.
When the bass or treble level is adjusted, EQ is not effective and
EQ symbol disappears.
BASS/TREBLE adjustment will not work at the same time as the
EQ. The last setting made will become effective.
Selects an item as follows :
EQ BASS TREBLE
• Adjust the bass and treble level with
VOLUME +/- from -5 to +5.
• Select a EQ setting as follows with VOLUME +/-:
FLAT
music.
ROCK POP
ROCK
CLASSIC JAZZ
6
Setting the Clock and Daily Timer
Setting the Clock
1
2
• To go back to the previous step, press CANCEL.
• If there is a power failure, the clock loses the setting and is reset to “AM 12:00”. You need to set the clock again.
or
Activate the clock setting mode (“Clock Adjust” appears).
The hour digit of the time indication blinks on the display.
• If you have already adjusted the clock before, press the button repeatedly until “Clock Adjust” appears.
Current timer settings
If the clock has not been adjusted, “Clock Adjust” appears first.
1 Adjust the hour. The minute digits of the time indication blink on the display.
2 Adjust the minute. The built-in clock starts working.
Timer setting Clock Adjust
Canceled
Setting the Daily Timer
Without setting the built-in clock, you cannot use Daily Timer.
Using Daily Timer, you can wake up with music, etc.
Connect the iPod or USB mass storage device, or other equipment, to the Unit beforehand. (P.8, P.9, P.11)
1
2
(Twice)
or
Select the timer setting mode.
Current timer settings
Canceled
1 Adjust the hour then the minute for Daily Timer on-time.
2 Adjust the hour then the minute for Daily Timer off-time.
• The on-time and off-time of the Daily Timer cannot be set to the same time.
3 Select the playback source—“iPod,” “USB MEMORY,” or “AUX.”
• If “USB MEMORY” is selected, select the GROUP number (“001” to “500” and “---”) and then
select the TRACK number (“001” to “999” and “---”).
If you select “---,” TRACK1 in GROUP1 is set.
4 Select the volume level (“VOLUME MIN / 1 to 29 / VOLUME MAX”).
“SET OK” appears briefly followed by setting information, then the icon appears on the display.
Timer setting
Clock Adjust
3
• To exit from the timer setting, press CLOCK/TIMER as required.
• To correct a misentry during the process, press CANCEL. You can return to the previous step.
Turn off the System (on standby).
To cancel the Daily Timer
1
2
Select the current timer settings mode.
icon disappears.
To turn on the Daily Timer again (Turn on a timer setting you have made beforehand.)
1
2
Select the current timer settings mode.
icon appears on the display.
7
Playing Back from iPod
This system is equipped with an iPod terminal on the rear panel. You can connect your iPod to this terminal and enjoy the
sound from your iPod.
Compatible iPod types:
iPod nano 1G/2G/4G
iPod mini
iPod (4th Generation) 20G/40G
iPod photo (4th Generation) 20G/30G/40G/60G
iPod video (5th Generation) 30G/60G
If the iPod does not play correctly, please update your iPod
software to the latest version.
• For details about updating your iPod, check on the Apple
web site <http://www.apple.com>.
iPod is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
To Connect iPod
Connect the iPod to the System using the supplied cable.
Make sure the System is turned off when you connect it.
Connect the arrow of iPod terminal and the arrow of the
connector facing each other.
USB
AUDIO
RIGHT
2
You can place the iPod on
the supplied iPod stand.
1
LEFT
WOOFER
i Pod
DC IN
23V
2.5A
8-16‰
SPEAKERS
Basic Operations
Button
On the
Unit
On the
remote
Start playback / Pause
Press and hold : The iPod is in sleep mode
Increase the track numbers
Press and hold : Fast forward search
Decrease the track numbers
Press and hold : Fast reverse search
NOTES
• The iPod battery is charged while the System is turned on.
See the iPod instruction manual about battery charging.
• If you connect an iPod to the iPod terminal and a USB mass
storage class device to the USB MEMORY terminal at the
same time, the system might be overloaded.
• Sound distortion may occur when playing back audio
sources with high recording levels. When distortion
occurs, it is recommended to turn off the equalizer of the
iPod. For information on operating the iPod, see the iPod
instruction manual.
• JVC is not responsible for any loss of or damage to iPod
that might result from the use of this product.
• When you connect your iPod to the cable, make sure it
connects all the way in.
• Do not carry the System with iPod connected. You might
drop it down or it might cause damages to the connector
part.
• Do not touch or hit the iPod terminal pins or the connector
pins directly. It might cause damages to the connector part.
• Remove the iPod from the cable when you do not use.
• Always set volume to the minimum level when connecting
or disconnecting the other equipment.
Function
When disconnecting the iPod, make sure that the System is
turned off.
To remove the connector from
your iPod, squeeze the buttons
on the sides and pull.
8
Playing Back from USB mass storage class device
This System is equipped with a USB MEMORY terminal on the front panel. You can connect a USB mass storage class
device such as a USB flash memory device, Digital Audio Player (DAP), etc. to this System.
This System cannot recognize a USB mass storage class device whose rating exceeds 5V/500mA.
To connect the USB mass storage class device
MP3/WMA groups/tracks configuration
When connecting a USB mass storage class device, refer
also to its manual.
VOLUME
FUNCTION
STANDBY
USB
MEMORY
AUX
PHONES
or
DAP
• When disconnecting the USB mass storage class device,
make sure that the System is in the stop condition.
Basic Operations
This System plays back MP3/WMA tracks as follows.
01
02
Hierarchy
1
2
03 04
3
4
5
6
05
9
10
7
8
11
12
Level 1 Level 2 Level 3 Level 4 Level 5
ROOT
Group with its play order
01
1
MP3/WMA track with its play order
Button
On the
Unit
On the
remote
Starts playback / Pauses
Stops playback
Increases the track/group* numbers.
Decreases the track/group* numbers.
Function
* For details about the group selection, see “For MP3/WMA
playback” on this page.
For MP3/WMA playback
1
2
3
• To exit from the Number select mode, press CANCEL.
Set Number select mode.
or
Group number
Start playback.
Input the Group number, then
input the Track number.
Track number
NOTES
• You cannot send any data to your USB mass storage class device
from this System.
• Always set volume to the minimum level when connecting or
disconnecting the other equipment.
• Connect the USB mass storage class device directly to the system.
Using a USB hub may result in malfunction.
• Coded or encrypted tracks in a special method cannot be played
on the unit.
• The USB mass storage device's battery is charged while the
System is turned on.
• An iPod does not play on the USB MEMORY terminal.
“RESTRICT” appears on the display when an iPod is connected
to the USB MEMORY terminal while USB MEMORY is
selected for the source.
• This System may not playback some USB mass storage devices
and does not support DRM (Digital Rights Management).
• Some MP3/WMA files cannot be played back and will be
skipped.
This result from their recording processes and conditions.
• This System can play back MP3/WMA files with the extension
code <.mp3> or <.wma> (regardless of the letter case–upper/
lower).
• Some characters or symbols will not be shown correctly on the
display.
The maximum character number shown on the display is 32
(without the extension code) for files, and 30 for ID3 tag.
• It is recommended that you make each MP3 file at a sampling rate
of 44.1 kHz and at a bit rate of 128 kbps. Similarly each WMA
file at a sampling rate of 44.1 kHz and at a bit rate of 96 kbps.
• Playback order of MP3/WMA tracks may be different from the
one you have intended while recording. If a folder does not
include MP3/WMA tracks, they are ignored.
9
Repeat Play Random Play
1
2
Press repeatedly before you start playback to specify
the repeat mode as follows:
1 Repeats the current track.
ALL Repeats all tracks.
GR Repeats all tracks in the current group.
Cancel
Start playback.
1
2
RND appears on the display before you start
playback.
• To cancel, press again.
Playback starts in random order.
Random Play ends when all tracks are played.
• To repeat random play, press REPEAT.
Playing Back from the PC
This System is equipped with a USB AUDIO terminal on the rear panel. You can connect your PC to this terminal and enjoy
the sound from your PC. When you connect your PC for the first time, follow the procedure below.
How to install the USB drivers
1
2
3
4
Turn on your PC and start running Windows ® 98SE,
Windows
XP.
• If the PC has been turned on, close all the
Select USB AUDIO for the source.
• USB AUDIO can be selected also by the
Connect the System to the PC using a USB cable (not
supplied).
• Use “USB series A plug to B plug” cable.
The USB drivers are installed automatically.
®
Me, Windows ® 2000, or Windows ®
applications running.
USB AUDIO
AUX
FUNCTION button on the unit.
(rear panel)
USB cable
(not supplied)
PC
To playback sounds on the PC
Refer to the manuals supplied with the media player
application installed on the PC.
* Microsoft
Windows ® 2000 and Windows ® XP
are registered trademarks of Microsoft corporation.
NOTES
• You cannot send any signal or data to your PC from this
System.
• DO NOT turn off the unit or disconnect the USB cable
while installing the drivers and for several seconds while
your PC is recognizing the receiver.
• Use a full speed USB cable (version 1.1).
Recommended cord length is shorter than approximately 2
m.
• If your PC does not recognize the unit, disconnect the USB
cable and connect it again. If it does not work yet, restart
Windows.
• The installed drivers can be recognized only when the USB
cable is connected between the unit and your PC.
• The sound may not be played back correctly— interrupted
or degraded—due to your PC settings and PC
specifications.
®
, Windows ® 98SE, Windows ® Me,
NOTE
• Always set volume to the minimum level when connecting
or disconnecting the other equipment.
10
Playing Back from Other Equipment
To connect other equipment
By using a stereo mini plug cord (not supplied), you can
connect other equipment with analog audio output jacks,
such as Digital Audio Player, a TV, etc.
Stereo mini plug cord (not supplied)
AUX
(front panel)
• Refer to the manuals supplied with the other equipment.
NOTE
• Always set volume to the minimum level when connecting
or disconnecting the other equipment.
Portable audio
device, Game
machine, etc.
To select other equipment for the source
Select AUX for the source.
USB AUDIO
AUX
• AUX can be selected also by the FUNCTION
button on the unit.
To adjust the sound input level from other
equipment
You can adjust the sound input level from the connected
equipment, if the incoming signal is too small or too large.
1
2
LEVEL 1:
Decreased input level. Suitable for equipment with high output
level (such as a DVD player).
LEVEL 2:
Ordinary input level (factory setting).
Suitable for equipment with low output level (such as a portable
audio device).
Select AUX for the source.
Press and hold until the indicator appears on the
display. Then press and hold until setting is changed.
LEVEL 1
LEVEL 2
Troubleshooting
If you are having a problem with your System, check this list for a possible solution before calling for service.
General:
Power does not come on.
Power plug is not inserted securely. Plug in securely.
Adjustments or settings are suddenly canceled
before you finish.
There is a time limit. Repeat the procedure again.
Operations are disabled.
The built-in microprocessor may malfunction due to
external electrical interference. Unplug the AC power
cord and then plug it back in.
Unable to operate the System from the remote
control.
The path between the remote control and the remote
sensor on the System is blocked.
Point it at the remote sensor on the font panel.
Signals cannot reach the remote sensor.
More closer to the System.
The batteries are exhausted.
No sound is heard from the speakers.
Speaker connections are incorrect or loose (P.4).
Headphones are connected (P.5).
Sound from PC connected with a USB cable has
some noise. (P.10)
PC is subjected to excessive load due to using other
applications. Close the applications you do not use.
PC is connected via USB Hub. Connect the PC directly
to the main unit with a USB cable.
iPod/USB mass storage class device Operations:
The iPod doesn’t playback although the display
indicates CONNECT.
The battery is empty. Let stand for more than
approximately ten minutes on the connecting condition.
Timer Operations:
Daily Timer does not work.
The System has been turned on when the ontime comes.
Timer starts working only when the System is turned
off.
There might have been a power failure.
Set the clock first, then the timer again.
11
Specifications
Amplifier
Output Power
Main Speaker 10 W per channel, min. RMS, driven
into 6Ω at 1kHz, with no more than
10% total harmonic distortion
Subwoofer 30W, min. RMS, driven into 8Ω at
100Hz, with no more than 10% total
harmonic distortion
Terminals
Input Sensitivity/Impedance (1 kHz)
AUX IN LEVEL1 500 mV/47 kΩ
LEVEL2 125 mV/47 kΩ
USB AUDIO Ver. 1.1
USB MEMORY Ver. 1.1
Compatible device Mass Storage Class
Compatible file system FAT16, FAT32
Bus power supply Max. 5V/500 mA
iPod
Compatible iPod types See Page 8
Bus power supply Max. 5V/500 mA
Speaker terminals Main speaker 6Ω-16Ω
Subwoofer 8Ω-16Ω
PHONES 32Ω - 1 kΩ
15 mW/ch output into 32Ω
Frequency Range 35 Hz - 150Hz
Sound pressure level 80 dB/W • m
Dimensions 221mm × 221mm × 222mm
(8-3/4" × 8-3/4" × 8-3/4")
(W/H/D)
Mass Approx. 3.5kg (7.8lbs)
Accessories
See page 3
Power Specifications
NX-PS1 (System)
Power Requirements AC 110V-240V 50Hz/60Hz
Power Consumption 19 W (power on mode)
12 W (in Standby mode)
1 W (in ECO mode)
AC Adaptor (AA-R2401)
INPUT
OUTPUT DC 23V 2.5A, 57.5VA
CA-NXPS1 (Main Unit)
Power Requirements DC IN 23V 2.5A
Design and specifications are subject to change without notice.
AC 110V-240V 50Hz/60Hz 1.5A
Unit
Dimensions 90mm × 96mm × 137mm
Mass Approx. 0.5kg (1.1lbs)
9
/16" × 3-13/16" × 5-7/16")
(3(W/H/D)
Speaker Specifications
Main speaker SP-NXPS1F (each unit)
Type Full range bass-reflex type
Speaker Unit 7.5 cm (3") cone × 1
Power handling Capacity
Impedance 6Ω
Frequency Range 150 Hz - 20 kHz
Sound pressure level 83 dB/W • m
Dimensions 90mm × 96mm × ×90mm
Mass Approx. 0.63kg (1.4lbs)
Subwoofer SP-NXPS1W
Type Bass Reflex Type
Speaker Unit 16 cm (6-
Power handling Capacity
Impedance 8Ω
10 W
9
/16" × 3-13/16" × 3-9/16")
(3(W/H/D)
5
/16") cone × 1
30 W
12
TO OUR VALUED CUSTOMER
THANK YOU FOR PURCHASING THIS JVC PRODUCT.
WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE.
NEED HELP ON HOW TO HOOK UP?
NEED ASSISTANCE ON HOW TO OPERATE?
NEED TO LOCATE A JVC SERVICE CENTER?
LIKE TO PURCHASE ACCESSORIES?
IS HERE TO HELP!
TOLL FREE: 1(800)252-5722
http://www.jvc.com
Remember to retain your Bill of Sale for Warranty Service.
Do not attempt to service the product yourself
Caution
To prevent electrical shock, do not open the cabinet.
There are no user serviceable parts inside.
Please refer to qualified service personnel for repairs.
BT-51018-5
(
)
0306
LIMITED WARRANTY
1-1
USA ONLY
ONLY FOR PRODUCT PURCHASED IN U.S.A.
JVC Americas Corp. (JVC) warrants this product and all parts thereof, except as set forth below ONLY TO THE
ORIGINAL RETAIL PURCHASER
original purchase for the period shown below. ("The Warranty Period")
to be
FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date
PARTS LABOR
of
1 YR 1 YR
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND
IN THE COMMONWEALTH OF PUERTO RICO.
WHAT WE WILL DO:
If this product is found to be defective within the warranty period, JVC will repair or replace defective parts with new or
rebuilt equivalents at no charge to the original owner. Such repair and replacement services shall be rendered by JVC
during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the
remainder of the Warranty Period. All products may be brought to a JVC authorized service center on a carry-in basis.
Color televisions with a screen size of 27" or greater qualify for in-home service. In such cases, a technician will come
to your home and either repair the TV there or remove and return it if it cannot be repaired in your home.
WHAT YOU MUST DO FOR WARRANTY SERVICE:
Please do not return your product to the retailer
Instead, return your product to the JVC authorized service center nearest you. If shipping the product to the service
center, please be sure to package it carefully, preferably in the original packaging, and include a brief description of
the problem(s). Please call 1-800-252-5722 to locate the nearest JVC authorized service center. Service locations
can also be obtained from our website http://www.jvc.com. If your product qualifies for in-home service, the service
representative will require clear access to the product.
If you have any questions concerning your JVC Product, please contact our Customer Care Center at
WHAT IS NOT COVERED:
This limited warranty provided by JVC does not cover:
1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty
installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by
JVC to render such service, or if affixed to any attachment not provided with the products, or if the model or serial
number has been altered, tampered with, defaced or removed;
2. Initial installation, installation and removal from cabinets or mounting systems.
3. Operational adjustments covered in the Owner's Manual, normal maintenance, video and audio head cleaning;
4. Damage that occurs in shipment, due to act of God, and cosmetic damage;
5. Signal reception problems and failures due to line power surge;
6.
User Removal Memory Devices/Video Pick-up Tubes/CCD Image Sensors are covered for 90 days from the date of purchase;
7. Accessories;
8. Batteries (except that Rechargeable Batteries are covered for 90 days from the date of purchase);
9. Products used for commercial purposes, including, but not limited to rental.
10. Loss of data resultant from malfunction of hard drive or other data storage device;
There are no express warranties except as listed above.
THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS
LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.
JVC SHALL NOT BE LIABLE FOR ANY LOSS OF USE OF THE PRODUCT, INCONVIENCE, OR ANY OTHER
DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTAL (INCLUDING, WITHOUT LIMITATION,
DAMAGE TO TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE
WARRANTY PERIOD SET FORTH ABOVE.
Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an
implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty gives you specific
legal rights and you may also have other rights which vary from state to state.
800-252-5722
REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAIL
OF
REFURBISHED PRODUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY
INFORMATION
For customer use:
Enter below the Model No. and Serial No. which is located either on the rear, bottom or side of the cabinet.
Retain this information
Model No. :
Purchase date :
PACKAGED WITH EACH REFURBISHED PRODUCT.
for future reference.
1700 Valley Road,
JVC AMERICAS CORP.
http://www.jvc.com
Wayne, New Jersey 07470
Serial No. :
Name of dealer :
NX-PS1 COMPACT COMPONENT SYSTEM
EN
© 2006 Victor Company of Japan, Limited
0806NSMCREBET
COMPACT COMPONENT SYSTEM
SYSTEME DE COMPOSANTS COMPACT
NX-PS1
—Consists of CA-NXPS1, SP-NXPS1F and SP-NXPS1W
—Composée du CA-NXPS1, SP-NXPS1F et du SP-NXPS1W
MANUEL D’INSTRUCTIONS
COMPACT COMPONENT SYSTEM
NX-PS1
VOLUME
FUNCTION
STANDBY
CA-NXPS1 SP-NXPS1F SP-NXPS1WSP-NXPS1F
INSTRUCTIONS
LVT1633-002A
[C]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
(For U.S.A.)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
(For U.S.A.)
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
G-1
G-2
(For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
(For U.S.A.)
CAUTION
Changes or modifications not approved by JVC could void the user’s authority to
operate the equipment.
(For U.S.A.)
For the main unit:
Declaration of Conformity
Model Number: NX-PS1
Trade Name: JVC
Responsible Party: JVC Americas Corp.
Address: 1700 Valley Road, Wayne New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO
NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE
INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL
APPARATUS,” ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS
RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMIRIQUES DE CLASSE
B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.
G-3
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a
stand with a height of 10 cm or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration,
installez l’appareil de la manière suivante:
1. Avant: Bien dégagé de tout objet.
2. Côtés/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiqués sur le schéma cidessous.
3. Dessous: Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation
correcte puisse se faire en le plaçant sur un support d’au moins dix centimètres de hauteur.
Front
Face
15 cm
2 cm 2 cm
2 cm
15 cm
15 cm
10 cm
Side
Côté
15 cm
15 cm
G-4
Contents
Introduction ............................................. 2
Precautions ..............................................................2
Getting Started ........................................ 3
Connection ..............................................................5
Basic Operations ...................................... 7
Unit .........................................................................7
Remote Control .......................................................9
Setting the Clock and Daily Timer ...... 11
Setting the Clock ...................................................11
Setting the Daily Timer .........................................11
Playing Back from iPod ........................ 13
To Connect iPod ...................................................13
Basic Operations ...................................................14
Playing Back from USB mass storage class
device ................................................... 15
To connect the USB mass storage class device ....15
Basic Operations ...................................................15
Playing Back from the PC .................... 17
How to install the USB drivers .............................17
To playback sounds on the PC ..............................18
Playing Back from Other Equipment .. 19
To connect other equipment .................................19
Troubleshooting ..................................... 20
Specifications ......................................... 21
1
Introduction
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and
to obtain the best possible performance from the unit.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor too cold–between 5°C and 35°C.
• Install the System in a location with adequate ventilation to prevent internal heat buildup inside
the System.
DO NOT install the System in a location near heat sources, or in a place subject to
direct sunlight, excessive dust or vibration.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid interference with TV.
Power sources
• When unplugging the System from the wall outlet, always pull on the plug, not the AC adaptor.
DO NOT handle the AC adaptor with wet hands.
Internal heat
For safety, observe the following carefully:
• Make sure there is good ventilation the main unit. Poor ventilation could overheat
and damage the System.
• DO NOT block the ventilation openings or holes. If they are blocked by a newspaper
or cloth, etc., the heat may not be able to get out.
Others
• Should any metallic object or liquid fall into the System, unplug the AC adaptor and consult your
dealer before operating any further.
DO NOT disassemble the System since there are no user serviceable parts inside.
• If you are not going to operate the System for an extended period of time, unplug the AC adaptor
from the wall outlet.
If anything goes wrong, unplug the AC adaptor and consult your dealer.
2
Getting Started
Supplied Accessories
After unpacking, check to be sure that you have all the following items. The number in parentheses
indicates the quantity of each piece supplied.
• Remote control (1)
• Lithium coin battery CR2025 (1) (The battery has been installed when shipped from the factory.)
• Speaker cords 1.5m (2)
• Speaker cord 2.5m (1)
• AC power cord (1)
• AC adaptor (AA-R2401) (1)
• iPod connection cable (Audio) (1)
• iPod stand (1)
If anything is missing, consult your dealer immediately.
CAUTION:
To avoid risk of fire, and to prevent damage.
• Do not use AC adaptors except the supplied AC adaptor.
• Do not use the supplied AC adaptor for other equipment.
Prepare the Remote Control
When you use the remote control for the first time, pull out the insulation sheet.
Insulation sheet
(Front side)
Replacing the Battery in the Remote Control
Insert the battery into the remote control by matching the polarity (+ and -) correctly.
Lithium coin battery
(product number: CR2025)
(Rear side)
3
Warning
• Store the battery in a place where children cannot reach. If a child accidentally
swallows the battery, consult a doctor immediately.
• Do not recharge, short, disassemble or heat the battery or dispose of it in a fire. Doing
any of these things may cause the battery to give off heat, crack, or start a fire.
• Do not leave the battery with other metallic materials. Doing this may cause the
battery to give off heat, crack, or start a fire.
• When throwing away or saving the battery, wrap it in tape and insulate; otherwise, the
battery may start to give off heat, crack, or start a fire.
• Do not poke the battery with tweezers or similar tools. Doing this may cause the
battery to give off heat, crack, or start a fire.
• Dispose of battery in the proper manner, according to federal, state, and local
regulations.
CAUTION:
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
4
Connection
Do not connect the AC power cord until all other connections have been made.
Subwoofer
To a wall outlet
Plug the AC power cord
only after all connections
are complete.
USB AUDIO
AC power
cord
AC adaptor
AC adaptor
iPod terminal
Main speaker
terminal
USB
AUDIO
i Pod
DC IN
23V 2.5A
DC IN
23V 2.5A
Unit
RIGHT LEFT WOOFER
6-16Ω 8-16Ω
SPEAKERS
RIGHT LEFT WOOFER
6-16Ω 8-16Ω
SPEAKERS
INPUT
Speaker cord (2.5m)
Main speaker
5
Speaker cord (1.5m) Speaker cord (1.5m)
To connect the speaker cords
Make sure the unit, main speakers, and subwoofer are connected correctly and firmly.
When connecting the speaker cords, match the polarity of the speaker terminals: white cord to
(+) and white cord with black stripe to (-).
NOTES
• DO NOT connect more than one speaker to each terminal.
• DO NOT allow the conductor of the speaker cords to be in touch with the metallic parts of the
System.
e.g. Speaker
2 Insert
3 Release
1 Hold
e.g. Unit
1 Unlock
2 Insert
3 Lock
6
Unit
Basic Operations
Display
STANDBY lamp
Remote control
sensor
Operation
buttons
4
Opening the front panel cover
STANDBY
FUNCTION
USB
MEMORY
AUX
PHONES
COMPACT COMPONENT SYSTEM
STANDBY
NX-PS1
AUX PHONES
AUX jack
VOLUME
FUNCTION
USB
MEMORY
Adjust the volume
1
Select a source
2
3
STANDBY/ON button
USB MEMORY terminal
PHONES jack
Using Headphones
Be sure to turn down the volume before
connecting or wearing the headphones.
• Connecting the headphones will
deactivate the speakers.
Operating on the Unit
Buttons Functions
Adjusts the volume level VOLUME MIN / 1 to 29 / VOLUME MAX.
1
VOLUME
Selects a source. See “Playing Back from iPod” (P.13).
2
FUNCTION
iPod USB MEMORY
AUX USB AUDIO
See “Playing Back from USB mass storage class
device” (P.15).
See “Playing Back from the PC” (P. 17).
See “Playing Back from Other Equipment” (P. 19).
Turns on or off (standby) the power.
3
Operates music.
4
See “Playing Back from iPod” (P.13).
See “Playing Back from USB mass storage class device” (P.15).
7
Display Information
While selecting iPod / USB AUDIO:
Volume level
Source name
Current status
While selecting USB MEMORY:
Volume level
Elapsed playing time
Current track number
Current group number
File information ⇔ Clock display
While selecting AUX:
Volume level
Source name
No display ⇔ Clock display
Symbols Description
RND Lights when Random Play mode is activated in USB Memory mode. (P.17)
1/ ALL/ GR Lights when Repeat mode is activated in USB Memory mode. (P.17)
FLAT/ROCK/POP/
JAZZ/CLAS(CLASSIC)
SLEEP Lights when the Sleep Timer is activated. (P.10)
Displays an selected EQ setting. (P.10)
Lights when the USB mass storage class device is connected and the USB
MEMORY mode is selected.
Lights when Daily Timer is set. (P.11)
⇔
Clock display
8
Remote Control
Sleep timer
6
8
7
10
Adjust the tone
FADE MUTING button
5
Operating on the Remote Control
Buttons Functions
1
2
3
Turns on or off (standby) the power
Changes the display information.
USB MEMORY mode : Clock display ⇔ File information
Other mode : Clock display ⇔ Source information
Changes source to iPod.
See “Playing Back from iPod” (P.13).
Changes source to USB MEMORY.
See “Playing Back from USB mass storage class device” (P.15).
Changes source to USB audio and AUX.
See “Playing Back from the PC” (P.17).
See “Playing Back from Other Equipment” (P.19).
1
2
3
9
Dimmer/ECO mode
4
STANDBY/ON button
Change the display information
Select a source
Adjust the volume
4
5
Adjusts the volume level VOLUME MIN / 1 to 29 / VOLUME MAX.
Drops the volume in a moment.
To restore the volume, press again, or adjust the volume level.
Others
Buttons Reference pages
6
7
8
CLOCK/TIMER set (P.11)
CLOCK/TIMER set (P.11)
USB MEMORY (P.15)
AUX (P.19)
CLOCK/TIMER set (P.11)
USB MEMORY (P.15)
9
Buttons Reference pages
CLOCK/TIMER set (P.11)
9
10
iPod (P.13)
USB MEMORY (P.15)
USB MEMORY (P.15)
To dim the display—DIMMER
Press while the System is turned on. “DIMMER ON” appears.
• To cancel this function, press DIMMER/ECO again. “DIMMER OFF” appears.
To set the ECO mode.
In ECO mode, the dispaly goes off and the least power is consumed.
Press While the System is turned off. “ECO ON” appears and then nothing is displayed.
• To cancel this function, press DIMMER/ECO again.
“ECO OFF” appears and then the clock is displayed.
To turn off the System after a certain period of time—Sleep Timer
Press repeatedly to specify the time (in minutes) as follows:
1
10 20 30 60 90 120
OFF (Canceled)
2
• To check the time remaining before the shut-off time, press SLEEP once.
If you press the button repeatedly, you can change the shut-off time
Wait until the set time goes off.
To adjust the tone
Selects an item as follows :
1
• Adjust the bass and treble level with VOLUME +/- from -5 to +5.
2
ROCK Boosts low and high frequency. Good for acoustic music.
POP Good for vocal music.
JAZZ Good for jazz music.
CLAS
(CLASSIC)
FLAT Normal sound.
• Select a EQ setting as follows with VOLUME +/-:
Good for classical music.
EQ BASS TREBLE
FLAT
ROCK POP
ROCK
CLAS JAZZ
When the bass or treble level is adjusted, EQ is not effective and EQ symbol disappears.
BASS/TREBLE adjustment will not work at the same time as the EQ. The last setting made will become
effective.
10
Setting the Clock and Daily Timer
Setting the Clock
1
Activate the clock setting mode (“Clock Adjust” appears).
The hour digit of the time indication blinks on the display.
• If you have already adjusted the clock before, press the button repeatedly
until “Clock Adjust” appears.
Current timer settings
If the clock has not been adjusted, “Clock Adjust” appears first.
Timer setting Clock Adjust
Canceled
2
• To go back to the previous step, press CANCEL.
• If there is a power failure, the clock loses the setting and is reset to “AM12:00”. You need to set
the clock again.
or
1 Adjust the hour. The minute digits of the time indication blink
on the display.
2 Adjust the minute. The built-in clock starts working.
Setting the Daily Timer
Without setting the built-in clock, you cannot use Daily Timer.
Using Daily Timer, you can wake up with music, etc.
Connect the iPod or USB mass storage device, or other equipment, to the Unit beforehand. (P.13,
P.15, P.19)
Select the timer setting mode.
Current timer settings
Canceled
1 Adjust the hour then the minute for Daily Timer on-time.
2 Adjust the hour then the minute for Daily Timer off-time.
• The on-time and off-time of the Daily Timer cannot be set to the same time.
3 Select the playback source—“iPod,” “USB MEMORY,” or “AUX.”
• If “USB MEMORY” is selected, select the GROUP number (“001” to
“500” and “---”) and then select the TRACK number (“001” to “999”
and “---”).
If you select “---,” TRACK1 in GROUP1 is set.
4 Select the volume level (“VOLUME MIN / 1 to 29 / VOLUME MAX”).
Timer setting
Clock Adjust
1
2
(Twice)
or
3
• To exit from the timer setting, press CLOCK/TIMER as required.
• To correct a misentry during the process, press CANCEL. You can return to the previous step.
Turn off the System (on standby).
11
“SET OK” appears briefly followed by setting information, then the
icon appears on the display.
To cancel the Daily Timer
1
2
To turn on the Daily Timer again (Turn on a timer setting you have made
beforehand.)
1
2
Select the current timer settings mode.
icon disappears.
Select the current timer settings mode.
icon appears on the display.
12
Playing Back from iPod
This system is equipped with an iPod terminal on the rear panel. You can connect your iPod to this
terminal and enjoy the sound from your iPod.
Compatible iPod types:
iPod nano 1G/2G/4G
iPod mini
iPod (4th Generation) 20G/40G
iPod photo (4th Generation) 20G/30G/40G/60G
iPod video (5th Generation) 30G/60G
If the iPod does not play correctly, please update your iPod software to the latest version.
• For details about updating your iPod, check on the Apple web site <http://www.apple.com>.
iPod is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
To Connect iPod
Connect the iPod to the System using the supplied cable.
Make sure the System is turned off when you connect it.
Connect the arrow of iPod terminal and the arrow of the connector facing each other.
USB
AUDIO
RIGHT
2
1
LEFT
WOOFER
i Pod
DC IN
23V
2.5A
8-16Ω
SPEAKERS
You can place the iPod on
the supplied iPod stand.
13
When disconnecting the iPod, make sure that the System is turned off.
To remove the connector from
your iPod, squeeze the buttons
on the sides and pull.
Basic Operations
Button
On the Unit On the remote
Start playback / Pause
Press and hold : The iPod is in sleep mode
Increase the track numbers
Press and hold : Fast forward search
Decrease the track numbers
Press and hold : Fast reverse search
(Press this button during playback to jump back to the beginning of
the track.)
Function
NOTES
• The iPod battery is charged while the System is turned on or on standby (except in ECO mode).
See the iPod instruction manual about battery charging.
• If you connect an iPod to the iPod terminal and a USB mass storage class device to the USB
MEMORY terminal at the same time, the system might be overloaded.
• Sound distortion may occur when playing back audio sources with high recording levels. When
distortion occurs, it is recommended to turn off the equalizer of the iPod. For information on
operating the iPod, see the iPod instruction manual.
• JVC is not responsible for any loss of or damage to iPod that might result from the use of this
product.
• When you connect your iPod to the cable, make sure it connects all the way in.
• Do not carry the System with iPod connected. You might drop it down or it might cause damages
to the connector part.
• Do not touch or hit the iPod terminal pins or the connector pins directly. It might cause damages
to the connector part.
• Remove the iPod from the cable when you do not use.
• Always set volume to the minimum level when connecting or disconnecting the other equipment.
14
Playing Back from USB mass storage class device
This System is equipped with a USB MEMORY terminal on the front panel. You can connect a
USB mass storage class device such as a USB flash memory device, Digital Audio Player (DAP),
etc. to this System.
This System cannot recognize a USB mass storage class device whose rating exceeds 5V/500mA.
To connect the USB mass storage class device
When connecting a USB mass storage class device, refer also to its manual.
FUNCTION
STANDBY
or
DAP
• When disconnecting the USB mass storage class device, make sure that the System is in the stop condition.
USB
MEMORY
AUX
PHONES
Basic Operations
Button
On the Unit On the remote
For MP3/WMA playback
1
Set Number select mode.
Function
Starts playback / Pauses
Stops playback
Increases the track numbers.
Press and hold : Fast forward search
Decreases the track numbers.
Press and hold : Fast reverse search
(Press this button during playback to jump back to the beginning of
the track.)
Input the Group number, then
input the Track number.
2
or
15
Track number
Group number
3
• To exit from the Number select mode, press CANCEL.
NOTES
• You cannot send any data to your USB mass storage class device from this System.
• Always set volume to the minimum level when connecting or disconnecting the other equipment.
• Connect the USB mass storage class device directly to the system. Using a USB hub may result in
malfunction.
• Coded or encrypted tracks in a special method cannot be played on the unit.
• The USB mass storage device's battery is charged while the System is turned on or on standby (except
in ECO mode).
• An iPod does not play on the USB MEMORY terminal. “RESTRICT” appears on the display when an
iPod is connected to the USB MEMORY terminal while USB MEMORY is selected for the source.
• This System may not playback some USB mass storage devices and does not support DRM (Digital
Rights Management).
• Some MP3/WMA files cannot be played back and will be skipped.
This result from their recording processes and conditions.
• This System can play back MP3/WMA files with the extension code <.mp3> or <.wma> (regardless of
the letter case–upper/lower).
• Some characters or symbols will not be shown correctly on the display.
The maximum character number shown on the display is 32 (without the extension code) for files, and
30 for ID3 tag.
• It is recommended that you make each MP3 file at a sampling rate of 44.1 kHz and at a bit rate of 128
kbps. Similarly each WMA file at a sampling rate of 44.1 kHz and at a bit rate of 96 kbps.
• Playback order of MP3/WMA tracks may be different from the one you have intended while recording.
If a folder does not include MP3/WMA tracks, they are ignored.
Start playback.
16
Repeat Play
Press repeatedly before you start playback to specify the repeat mode as follows:
1 Repeats the current track.
1
Cancel
2
Random Play
1
2
Start playback.
RND appears on the display before you start playback.
• To cancel, press again.
Playback starts in random order.
Random Play ends when all tracks are played.
• To repeat random play, press REPEAT.
ALL Repeats all tracks.
GR Repeats all tracks in the current group.
Playing Back from the PC
This System is equipped with a USB AUDIO terminal on the rear panel. You can connect your PC
to this terminal and enjoy the sound from your PC. When you connect your PC for the first time,
follow the procedure below.
How to install the USB drivers
1
2
Turn on your PC and start running Windows ® 98SE, Windows ® Me, Windows ® 2000, or
Windows
• If the PC has been turned on, close all the applications running.
Select USB AUDIO for the source.
• USB AUDIO can be selected also by the FUNCTION button on the unit.
®
XP.
USB AUDIO
AUX
17
Connect the System to the PC using a USB cable (not supplied).
(rear panel)
3
• Use “USB series A plug to B plug” cable.
4
NOTE
• Always set volume to the minimum level when connecting or disconnecting the other equipment.
The USB drivers are installed automatically.
USB cable
(not supplied)
PC
To playback sounds on the PC
Refer to the manuals supplied with the media player application installed on the PC.
* Microsoft ®, Windows ® 98SE, Windows ® Me, Windows ® 2000 and Windows ® XP are
registered trademarks of Microsoft corporation.
NOTES
• You cannot send any signal or data to your PC from this System.
• DO NOT turn off the unit or disconnect the USB cable while installing the drivers and for several
seconds while your PC is recognizing the receiver.
• Use a full speed USB cable (version 1.1).
Recommended cord length is shorter than approximately 2 m.
• If your PC does not recognize the unit, disconnect the USB cable and connect it again. If it does
not work yet, restart Windows.
• The installed drivers can be recognized only when the USB cable is connected between the unit
and your PC.
• The sound may not be played back correctly— interrupted or degraded—due to your PC settings
and PC specifications.
18
Playing Back from Other Equipment
To connect other equipment
By using a stereo mini plug cord (not supplied), you can connect other equipment with analog audio
output jacks, such as Digital Audio Player, a TV, etc.
Stereo mini plug cord (not supplied)
AUX
(front panel)
• Refer to the manuals supplied with the other equipment.
NOTE
• Always set volume to the minimum level when connecting or disconnecting the other equipment.
Portable audio
device, Game
machine, etc.
To select other equipment for the source
Select AUX for the source.
USB AUDIO
AUX
• AUX can be selected also by the FUNCTION button on the unit.
To adjust the sound input level from other equipment
You can adjust the sound input level from the connected equipment, if the incoming signal is too
small or too large.
1
Select AUX for the source.
Press and hold until the indicator appears on the display. Then press and hold until setting is
2
LEVEL 1:
Decreased input level. Suitable for equipment with high output level (such as a DVD player).
LEVEL 2:
Ordinary input level (factory setting). Suitable for equipment with low output level (such as a portable audio
device).
changed.
19
LEVEL 1
LEVEL 2
Troubleshooting
If you are having a problem with your System, check this list for a possible solution before calling
for service.
General:
Power does not come on.
Power plug is not inserted securely. Plug in securely.
Adjustments or settings are suddenly canceled before you finish.
There is a time limit. Repeat the procedure again.
Operations are disabled.
The built-in microprocessor may malfunction due to external electrical interference. Unplug
the AC power cord and then plug it back in.
Unable to operate the System from the remote control.
The path between the remote control and the remote sensor on the System is blocked.
Point it at the remote sensor on the font panel.
Signals cannot reach the remote sensor.
More closer to the System.
The batteries are exhausted.
No sound is heard from the speakers.
Speaker connections are incorrect or loose (P.5).
Headphones are connected (P.7).
Sound from PC connected with a USB cable has some noise (P.17).
PC is subjected to excessive load due to using other applications. Close the applications you do
not use.
PC is connected via USB Hub. Connect the PC directly to the main unit with a USB cable.
iPod/USB mass storage class device Operations:
The iPod doesn’t playback although the display indicates CONNECT.
The battery is empty. Let stand for more than approximately ten minutes on the connecting
condition.
Timer Operations:
Daily Timer does not work.
The System has been turned on when the ontime comes.
Timer starts working only when the System is turned off.
There might have been a power failure.
Set the clock first, then the timer again.
20
Specifications
Amplifier
Output Power
Main Speaker 10 W per channel, min. RMS,
driven into 6Ω at 1kHz, with
no more than 10% total
harmonic distortion
Subwoofer 30W, min. RMS, driven into
8Ω at 100Hz, with no more
than 10% total harmonic
distortion
Terminals
Input Sensitivity/Impedance (1 kHz)
AUX IN LEVEL1 500 mV/47 kΩ
LEVEL2 125 mV/47 kΩ
USB AUDIO Ver. 1.1
USB MEMORY Ver. 1.1
Compatible device Mass Storage Class
Compatible file system FAT16, FAT32
Bus power supply Max. 5V/500 mA
iPod
Compatible iPod types See Page 13
Bus power supply Max. 5V/500 mA
Speaker terminals Main speaker 6Ω-16Ω
Subwoofer 8Ω-16Ω
PHONES 32Ω - 1 kΩ
15 mW/ch output into 32Ω
Unit
Dimensions 90mm × 96mm × 137mm
(W/H/D)
Mass Approx. 0.5kg
Speaker Specifications
Main speaker SP-NXPS1F (each unit)
Type Full range bass-reflex type
Speaker Unit 7.5 cm cone × 1
Power handling Capacity
Impedance 6Ω
Frequency Range 150 Hz - 20 kHz
Sound pressure level 83 dB/W • m
10 W
Dimensions 90mm × 96mm × ×90mm
(W/H/D)
Mass Approx. 0.63kg
Subwoofer SP-NXPS1W
Type Bass Reflex Type
Speaker Unit 16 cm cone × 1
Power handling Capacity
Impedance 8Ω
Frequency Range 35 Hz - 150Hz
Sound pressure level 80 dB/W • m
Dimensions 221mm × 221mm × 222mm
Mass Approx. 3.5kg
30 W
(W/H/D)
Accessories
See page 3
Power Specifications
NX-PS1 (System)
Power Requirements
Power Consumption 19 W (power on mode)
AC Adaptor (AA-R2401)
INPUT AC 110V-240V
OUTPUT DC 23V 2.5A, 57.5VA
CA-NXPS1 (Main Unit)
Power Requirements DC IN 23V 2.5A
Design and specifications are subject to change without notice.
AC 110V-240V 50Hz/60Hz
12 W (in Standby mode)
1 W (in ECO mode)
50Hz/60Hz 1.5A
21
NX-PS1 COMPACT COMPONENT SYSTEM
EN, FR
© 2006 Victor Company of Japan, Limited
0906NSMCREBET
Loading...
