PARTS LIST
[ SP-DWF10]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
J ------------------------------ U.S.A.
A -------------------------- Australia
E ------------ Continental Europe
US ---------------------- Singapore
UF ---------------------------- China
UP ---------------------------- Korea
UT --------------------------- Taiwan
UX ------------------- Saudi Arabia
UJ --------------------- U.S.Military
MB251
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01)
Packing materials and accessories parts list (Block No.M3)
3- 2
3- 6
3-10
3-1
Exploded view of general assembly and parts list
E
Block No.
M
43
M
1
M
41
47
41
53
42
J
51
45
48
49
50
16
15
46
52
J
3
7
A
B
3-2
D
Amp board
38
38
61
59 60
J
A
oard
b
1
4
6
Volume board
E
B
A
62
26
27
4
Regulator board
G
4
F
17
39
40
b
20
a
20
56
2
58
4
18
57
55
D
10
28
Power
switch board
19
29
Switch board
26
F
Terminal board
9
12
12
C
a
5
b
54
26
28
44
11
14
C
21
13
G
8
13
4
25
22
24
23
25
29
30
32
32
37
33
34
35
31
36
3-3
General Assembly
Symbol No. Part No. Part Name Description Local
Block No. [M][1][M][M]
1 LV21341-002A SHIELD DWF10J
1 LV21341-001A SHIELD
2 LV10709-002A COVER
3 LV30225-0R9A SPACER
4 LV30225-0S1A SPACER (x5)
5 LV30225-079A SPACER
6 LV30225-0E4A SPACER
7 LV30225-0R8A SPACER
8 LV30225-044A SPACER
9 QYSBSG3016E TAP SCREW M3 x 16mm(x2)
10 QYSBSF3008Z TAP SCREW M3 x 8mm(x4)
11 LV43179-002A BKT(SW)
12 LV30225-0H6A SPACER (x2)
13 LV30225-0H7A SPACER (x2)
14 QYSBSF2612M TAP SCREW M2.6 x 12mm
15 LV41148-002A CORD COVER
16 QYSBSF4012Z TAP SCREW M4 x 12mm(x2)
17 LV43178-001A BKT(CORD)
18 QZW0033-001 STRAIN RELIEF
19 QMPG150-244-JC POWER CORD(EU) 2.44m BLACK DWF10A
19 QMPD280-200-JC POWER CORD(EU) 2m BLACK DWF10J
19 QMPR480-200-JC POWER CORD(EU) 2m BLACK DWF10UF
19 QMPR310-200-JC POWER CORD(EU) 2m BLACK DWF10UP
19 QMPK190-200-JC POWER CORD(EU) 2m BLACK DWF10E,DWF10UJ,DWF10US
19 QMPR600-200-JD POWER CORD(EU) 2m BLACK DWF10UT
19 QMPR270-200-JD POWER CORD(EU) 2m BLACK DWF10UX
20 QYSBSF2612M TAP SCREW M2.6 x 12mm(x2)
21 LV33804-002A BKT(KNOB)
22 QYSBST3006Z TAP SCREW M3 x 6mm(x2)
23 E407321-002SM PUSH BUTTON
24 LV30225-0H5A SPACER
25 QYSBSF2612M TAP SCREW M2.6 x 12mm(x3)
26 LV30225-0H5A SPACER (x3)
27 LV30225-0E5A SPACER
28 LV30225-0E5A SPACER (x2)
29 LV30225-0A4A SPACER (x2)
30 LV30225-074A SPECER
31 LV21342-020A BACK PANEL DWF10A
31 LV21342-025A BACK PANEL DWF10E
31 LV21342-023A BACK PANEL DWF10J
31 LV21342-021A BACK PANEL DWF10UF
31 LV21342-024A BACK PANEL DWF10UJ
31 LV21342-019A BACK PANEL DWF10UP
31 LV21342-018A BACK PANEL DWF10US,DWF10UT
31 LV21342-022A BACK PANEL DWF10UX
32 LV30225-0H4A SPACER (x2)
33 LV30225-0H5A SPACER
34 QYSBSGY3008E TAP SCREW M3 x 8mm
35 QYSBSGY3008E TAP SCREW M3 x 8mm
36 QYSBSGY3008E TAP SCREW M3 x 8mm
37 QYSBSGY3008E TAP SCREW M3 x 8mm(x2)
38 QYSDSA4020M TAP SCREW M4 x 20mm(x11)
39 LV33803-001A HEAT SINK
40 QYSBSG3012Z TAP SCREW M3 x 12mm
41 LV30225-0G7A SPACER (x2)
42 LV30225-0G4A SPACER
43 LV43211-001A SPACER
44 QMF51E2-2R0-J1 FUSE 2A AC250V DWF10A,DWF10E
44 QMF51N2-3R0-J1 FUSE 3A AC250V DWF10J
44 QMF51E2-2R5-J1 FUSE 2.5A AC250V DWF10UF,DWF10UP
44 QMF51E2-3R15-J1 FUSE 3.15A AC250V
45 WJJ0098-001A E-SI C WIRE C-C
46 WJJ0390-001A E-SI C WIRE C-C DWF10J
46 WJN0095-001A E-SH C WIRE C-C
47 CR160063-01 CONE SPK
48 7001842004 SCREW (x6)
49 9916012101 ORNAMENT
50 9916012201 NET ASSY
51 5600006901 RUBBER FOOT (x4)
52 QQR0919-001 FERRITE CORE K 5003 DWF10J
53 LV43835-001A EMC LABEL DWF10J
54 QYSBSGY3008M TAP SCREW M3 x 8mm(x2)
DWF10A,DWF10E,DWF10UF,DWF10UJ,D
WF10UP,DWF10US,DWF10UT,DWF10UX
DWF10UJ,DWF10US,DWF10UT,DWF10U
X
DWF10A,DWF10E,DWF10UF,DWF10UJ,D
WF10UP,DWF10US,DWF10UT,DWF10UX
3-4
Symbol No. Part No. Part Name Description Local
55 QYSBSG3010Z TAP SCREW M3 x 10mm
56 LV33802-001A HEAT SINK1 HS 951
57 E70306-001 HEAT SINK HS 954
58 QYSBSG3008Z TAP SCREW M3 x 8mm
59 E70306-001 HEAT SINK HS 952
60 E70306-001 HEAT SINK HS 953
61 QYSBSG3008Z TAP SCREW M3 x 8mm(x2)
62 VYSH101-034 SPACER
3-5
Electrical parts list
Main board
Symbol No.
IC101 HA17558AF-X IC
IC102 HA17558AF-X IC
IC103 HA17558AF-X IC
IC104 HA17558AF-X IC
IC501 HA17558AF-X IC
IC502 NJM311M-XE IC
IC503 TC74HC00AF-W IC
IC504 TC74HC14AF-X IC
IC505 BU4584BF-X IC
IC506 IR2113S-X GATE DRIVER
IC571 TC74HC14AF-X IC
IC591 NJM78L05A-T IC
IC592 AN79L05-T IC
IC951 STR-F6656 IC
IC951 STR-F6676 IC
Q1001 2SC2412K/RS/-X TRANSISTOR
Q1002 2SC2412K/RS/-X TRANSISTOR
Q1003 2SC2412K/RS/-X TRANSISTOR
Q1004 2SA1037AK/RS/-X TRANSISTOR
Q1006 2SA1037AK/RS/-X TRANSISTOR
Q1007 2SC2412K/RS/-X TRANSISTOR
Q5001 2SA1037AK/RS/-X TRANSISTOR
Q5002 2SC2412K/RS/-X TRANSISTOR
Q5003 2SA1037AK/RS/-X TRANSISTOR
Q5004 2SC4452/3-4/-X TRANSISTOR
Q5005 2SA1514K/RS/-X TRANSISTOR
Q5006 IRFI540N FET
Q5007 IRFI540N FET
Q5706 2SC2412K/RS/-X TRANSISTOR
Q5707 2SA1037AK/RS/-X TRANSISTOR
Q5708 KRC104S-X TRANSISTOR
Q5709 2SC2412K/RS/-X TRANSISTOR
Q5710 2SA1037AK/RS/-X TRANSISTOR
Q5711 2SC2412K/RS/-X TRANSISTOR
Q5712 KRA104S-X DIGI TRANSISTOR
Q5713 2SK303/3-4/-X FET
Q5714 DTC115EKA-X DIGI TRANSISTOR
Q5715 KRA104S-X DIGI TRANSISTOR
Q5716 KRC104S-X TRANSISTOR
Q5717 DTC115EKA-X DIGI TRANSISTOR
Q5718 DTC115EKA-X DIGI TRANSISTOR
Q5719 KRC104S-X TRANSISTOR
Q5720 KRA104S-X DIGI TRANSISTOR
Q5721 KRC104S-X TRANSISTOR
Q5722 DTC144TKA-X TRANSISTOR
Q5723 2SK303/3-4/-X FET
Q5901 2SD2395/EF/ TRANTRANSISTOR
Q5902 2SA1037AK/RS/-X TRANSISTOR
Q5903 2SC2412K/RS/-X TRANSISTOR
Q5904 2SC2412K/RS/-X TRANSISTOR
Q5905 2SA1037AK/RS/-X TRANSISTOR
Q9504 2SC2412K/RS/-X TRANSISTOR
Q9508 2SA1514K/RS/-X TRANSISTOR
Q9509 2SA1514K/RS/-X TRANSISTOR
Q9510 2SC2412K/RS/-X TRANSISTOR
D1001 1SS133-T2 DIODE
D1002 1SS133-T2 DIODE
Part No. Part Name Description Local
Block No. [0][1]
DWF1
0J
DWF1
0A,D
WF10
E,DW
F10U
F,D W
F10UJ
,DWF
10UP,
DWF1
0US,D
WF10
UT,D
WF10
UX
Symbol No.
D1003 1SS133-T2 DIODE
D5001 1SS133-T2 DIODE
D5002 1SS133-T2 DIODE
D5003 1SS133-T2 DIODE
D5004 1SS133-T2 DIODE
D5005 1SS133-T2 DIODE
D5006 1SS133-T2 DIODE
D5007 MTZJ16B-T2 Z DIODE
D5008 M1FL20U-X FR DIODE
D5009 MTZJ18B-T2 Z DIODE
D5010 MTZJ18B-T2 Z DIODE
D5011 M1FL20U-X FR DIODE
D5012 M1FL20U-X FR DIODE
D5013 1SS355-X SI DIODE
D5703 1SS133-T2 DIODE
D5704 1SS355-X SI DIODE
D5705 1SS355-X SI DIODE
D5706 1SS355-X SI DIODE
D5707 1SS355-X SI DIODE
D5708 MA3200/H/-X Z DIODE
D5709 MA3200/H/-X Z DIODE
D5710 1SS355-X SI DIODE
D5711 1SS355-X SI DIODE
D5712 MA3300/L/-X Z DIODE
D5713 MA3300/L/-X Z DIODE
D5714 1SS355-X SI DIODE
D5715 1SS355-X SI DIODE
D5716 1SS133-T2 DIODE
D5717 1SS355-X SI DIODE
D5718 1SS355-X SI DIODE
D5901 MTZJ16B-T2 Z DIODE
D5902 MTZJ18B-T2 Z DIODE
D5903 MTZJ15A-T2 Z DIODE
D5904 MTZJ15A-T2 Z DIODE
D5905 MTZJ6.8B-T2 Z DIODE
D5906 MTZJ6.8B-T2 Z DIODE
D5907 MTZJ16B-T2 Z DIODE
D5908 MTZJ16B-T2 Z DIODE
D5909 RB160L-40-X SB DIODE
D5910 RB160L-40-X SB DIODE
D5911 1SS355-X SI DIODE
D5912 1SS355-X SI DIODE
D9001 RBV-606 BRIDGE DIODE
D9501 AW04-T2 SB DIODE
D9502 AG01Z-T2 DIODE
D9503 AG01Z-T2 DIODE
D9504 MTZJ20B-T2 Z DIODE
D9505 MTZJ20B-T2 Z DIODE
D9506 AG01Z-T2 DIODE
D9507 SARS03 SI DIODE
D9509 FML-G22S SI DIODE
D9510 FML-G22S SI DIODE
D9511 MTZJ15A-T2 Z DIODE
D9512 MTZJ15A-T2 Z DIODE
PC951 PC123Y22FZ PHOTO COUPLER
C1001 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1002 NCB31HK-102X C CAPACITOR 1000pF 50V K
C1003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1004 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1005 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1008 QERF1CM-107Z E CAPACITOR 100uF 16V M
C1009 QERF1CM-107Z E CAPACITOR 100uF 16V M
C1010 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C1011 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C1012 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1013 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1014 QFN31HJ-823Z M CAPACITOR 0.082uF 50V J
C1015 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C1016 QETN1HM-106Z E CAPACITOR 10uF 50V M
C1020 NCB31HK-222X C CAPACITOR 2200pF 50V K
C1021 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1022 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C1023 QERF1HM-105Z E CAPACITOR 1uF 50V M
C1027 NCB31HK-103X C CAPACITOR 0.01uF 50V K
Part No. Part Name Description Local
3-6
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C1028 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C1029 NCS31HJ-470X C CAPACITOR 47pF 50V J
C1030 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
C1031 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1032 QETN1CM-477Z E CAPACITOR 470uF 16V M
C1033 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C1034 QEKC1CM-106Z E CAPACITOR 10uF 16V M
C5001 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5002 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5003 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5004 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5005 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5006 QERF1CM-107Z E CAPACITOR 100uF 16V M
C5007 NCS31HJ-471X C CAPACITOR 470pF 50V J
C5008 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C5009 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5010 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5011 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C5012 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5013 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C5014 NCS31HJ-681X C CAPACITOR 680pF 50V J
C5015 NCS31HJ-470X C CAPACITOR 47pF 50V J
C5016 NCS31HJ-560X C CAPACITOR 56pF 50V J
C5017 NCS31HJ-560X C CAPACITOR 56pF 50V J
C5018 NCB11EK-224X C CAPACITOR 0.22uF 25V K
C5019 NCB11EK-684X C CAPACITOR 0.68uF 25V K
C5020 QER61HM-106Z E CAPACITOR 10uF 50V M
C5021 QFV72AJ-224Z MF CAPACITOR 0.22uF 100V J
C5022 QFG32AJ-392Z PP CAPACITOR 3900pF 100V J
C5023 QENC1HM-225Z BP E CAPACITOR 2.2uF 50V M
C5024 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C5025 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C5026 QETN2AM-475Z E CAPACITOR 4.7uF 100V M
C5027 NCS31HJ-271X C CAPACITOR 270pF 50V J
C5028 NCS31HJ-271X C CAPACITOR 270pF 50V J
C5702 QETN1VM-227Z E CAPACITOR 220uF 35V M
C5703 QER61CM-476Z E CAPACITOR 47uF 16V M
C5704 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5705 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5706 NCB11AK-335X C CAPACITOR 3.3uF 10V K
C5707 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5708 NCB11AK-335X C CAPACITOR 3.3uF 10V K
C5709 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5710 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C5711 NCB11EK-224X C CAPACITOR 0.22uF 25V K
C5901 QFV72AJ-103Z MF CAPACITOR 0.01uF 100V J
C5901 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C5902 QFV72AJ-103Z MF CAPACITOR 0.01uF 100V J
DWF1
0J,D
WF10
UT
DWF1
0J,D
WF10
UT
DWF1
0A,D
WF10
E,DW
F10J
DWF1
0UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
DWF1
0A,D
WF10
E,DW
F10J
C5902 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C5903 QEHR1HM-227Z E CAPACITOR 220uF 50V M
C5904 QEHR1HM-227Z E CAPACITOR 220uF 50V M
C5905 QER61EM-475Z E CAPACITOR 4.7uF 25V M
C5906 QER61EM-476Z E CAPACITOR 47uF 25V M
C5907 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5908 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5909 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C5910 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C5911 QEHR1EM-107Z E CAPACITOR 100uF 25V M
C5912 QEHR1EM-107Z E CAPACITOR 100uF 25V M
C5913 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5914 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5915 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5916 QERF1CM-106Z E CAPACITOR 10uF 16V M
C5917 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C5917 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C5918 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C5918 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C9001 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
C9002 QFZ9075-104 MPP CAPACITOR 0.1uF AC275V M
C9003 QCZ9079-102 C CAPACITOR 1000pF AC250V M
C9004 QCZ9079-102 C CAPACITOR 1000pF AC250V M
C9005 QFZ9075-103 MPP CAPACITOR 0.01uF AC275V M
C9501 QEZ0602-477 E CAPACITOR 470uF
C9501 QEZ0603-227 E CAPACITOR 220uF
C9501 QEZ0603-477 E CAPACITOR 470uF
DWF1
0UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
DWF1
0A,D
WF10
E
DWF1
0J,D
WF10
UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
DWF1
0A,D
WF10
E
DWF1
0J,D
WF10
UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
DWF1
0J
DWF1
0A,D
WF10
E,DW
F10U
F, DW
F10U
P
DWF1
0UJ,D
WF10
US,D
WF10
UT,D
WF10
UX
3-7
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C9502 QCZ0366-102 C CAPACITOR 1000pF
C9503 NCB31HK-471X C CAPACITOR 470pF 50V K
C9504 QETN1VM-107Z E CAPACITOR 100uF 35V M
C9505 NCB31HK-471X C CAPACITOR 470pF 50V K
C9506 QFKB2JK-103 MM CAPACITOR 0.01uF 630V K
C9507 QCZ0213-472 C CAPACITOR 4700pF 1kV K
C9508 QCZ0213-472 C CAPACITOR 4700pF 1kV K
C9509 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C9509 QFV72AJ-104Z MF CAPACITOR 0.1uF 100V J
C9510 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C9510 QFV72AJ-104Z MF CAPACITOR 0.1uF 100V J
C9511 QEHQ1HM-228 E CAPACITOR 2200uF 50V M
C9512 QEHQ1HM-228 E CAPACITOR 2200uF 50V M
C9513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9514 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9515 QCZ9079-332 C CAPACITOR 3300pF AC250V M
R1001 NRSA63J-474X MG RESISTOR 470k
R1002 NRSA63J-474X MG RESISTOR 470k
R1003 NRSA63J-563X MG RESISTOR 56k
R1004 NRSA63J-563X MG RESISTOR 56k
R1005 NRSA63J-223X MG RESISTOR 22k
R1015 QRE141J-470Y C RESISTOR 47
R1016 NRSA63J-153X MG RESISTOR 15k
R1017 QRE141J-470Y C RESISTOR 47
R1020 NRSA63J-392X MG RESISTOR 3.9k
R1021 NRSA63J-472X MG RESISTOR 4.7k
R1022 NRSA63J-123X MG RESISTOR 12k
R1023 NRSA63J-683X MG RESISTOR 68k
R1025 QRE141J-470Y C RESISTOR 47
R1028 QRE141J-470Y C RESISTOR 47
R1030 NRSA63J-752X MG RESISTOR 7.5k
R1031 NRSA63J-752X MG RESISTOR 7.5k
R1032 NRSA63J-684X MG RESISTOR 680k
R1039 NRSA63J-223X MG RESISTOR 22k
R1040 NRSA63J-683X MG RESISTOR 68k
R1041 QRE141J-470Y C RESISTOR 47
R1044 QRE141J-470Y C RESISTOR 47
R1046 NRSA63J-473X MG RESISTOR 47k
R1047 NRSA63J-104X MG RESISTOR 100k
R1048 NRSA63J-102X MG RESISTOR 1k
R1049 NRSA63J-222X MG RESISTOR 2.2k
R1050 NRSA63J-473X MG RESISTOR 47k
R1051 NRSA63J-105X MG RESISTOR 1M
R1052 NRSA63J-122X MG RESISTOR 1.2k
R1053 NRSA63J-472X MG RESISTOR 4.7k
R1054 NRSA63J-560X MG RESISTOR 56
R1055 NRSA63J-152X MG RESISTOR 1.5k
R1056 NRSA63J-103X MG RESISTOR 10k
R1057 NRSA63J-154X MG RESISTOR 150k
R1059 NRSA63J-104X MG RESISTOR 100k
R1060 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
DWF1
0A,D
WF10
E,DW
F10J
DWF1
0UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
DWF1
0A,D
WF10
E,DW
F10J
DWF1
0UF,D
WF10
UJ,D
WF10
UP,D
WF10
US,D
WF10
UT,D
WF10
UX
R1061 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R1062 QRE141J-470Y C RESISTOR 47
R1064 QRE141J-470Y C RESISTOR 47
R1065 QRE141J-101Y C RESISTOR 100
R1066 NRSA63J-473X MG RESISTOR 47k
R1067 NRSA63J-560X MG RESISTOR 56
R1068 QRE141J-101Y C RESISTOR 100
R5001 NRSA63J-153X MG RESISTOR 15k
R5002 NRSA63J-103X MG RESISTOR 10k
R5003 NRSA63J-103X MG RESISTOR 10k
R5004 NRSA63J-103X MG RESISTOR 10k
R5005 NRSA63J-103X MG RESISTOR 10k
R5006 NRSA63J-752X MG RESISTOR 7.5k
R5007 NRSA63J-133X MG RESISTOR 13k
R5008 NRSA63J-103X MG RESISTOR 10k
R5009 NRSA63J-103X MG RESISTOR 10k
R5010 NRSA63J-103X MG RESISTOR 10k
R5011 NRSA63J-103X MG RESISTOR 10k
R5012 NRSA63J-103X MG RESISTOR 10k
R5013 NRSA63J-472X MG RESISTOR 4.7k
R5014 NRSA63J-472X MG RESISTOR 4.7k
R5015 NRSA63J-222X MG RESISTOR 2.2k
R5016 QRE141J-222Y C RESISTOR 2.2k
R5017 NRSA63J-102X MG RESISTOR 1k
R5018 NRSA63J-102X MG RESISTOR 1k
R5019 NRSA63J-4R7X MG RESISTOR 4.7
R5020 NRSA63J-4R7X MG RESISTOR 4.7
R5021 NRSA63J-4R7X MG RESISTOR 4.7
R5022 NRSA63J-4R7X MG RESISTOR 4.7
R5023 NRSA63J-101X MG RESISTOR 100
R5024 NRSA63J-0R0X MG RESISTOR 0
R5025 NRSA63J-4R7X MG RESISTOR 4.7
R5026 NRSA63J-4R7X MG RESISTOR 4.7
R5027 NRSA63J-2R2X MG RESISTOR 2.2
R5028 NRSA63J-102X MG RESISTOR 1k
R5029 NRSA63J-682X MG RESISTOR 6.8k
R5030 NRSA63J-682X MG RESISTOR 6.8k
R5031 NRSA63J-472X MG RESISTOR 4.7k
R5032 NRSA63J-222X MG RESISTOR 2.2k
R5033 NRSA63J-2R2X MG RESISTOR 2.2
R5034 NRSA63J-2R2X MG RESISTOR 2.2
R5035 NRSA63J-2R2X MG RESISTOR 2.2
R5036 NRSA63J-103X MG RESISTOR 10k
R5037 NRSA63J-123X MG RESISTOR 12k
R5038 NRSA63J-222X MG RESISTOR 2.2k
R5039 NRSA63J-103X MG RESISTOR 10k
R5040 NRSA63J-102X MG RESISTOR 1k
R5041 NRSA63J-562X MG RESISTOR 5.6k
R5042 NRSA63J-102X MG RESISTOR 1k
R5043 NRSA63J-332X MG RESISTOR 3.3k
R5044 NRSA63J-561X MG RESISTOR 560
R5045 NRSA63J-822X MG RESISTOR 8.2k
R5046 NRSA63J-822X MG RESISTOR 8.2k
R5048 NRSA63J-103X MG RESISTOR 10k
R5049 QRZ9038-220X FUSI RESISTOR 22
R5050 QRZ9015-2R2X FUSI RESISTOR 2.2
R5051 QRZ9015-100X FUSI RESISTOR 10
R5052 QRZ9015-220X FUSI RESISTOR 22
R5053 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R5054 NRSA63J-105X MG RESISTOR 1M
R5055 QRT01DJ-6R8X MF RESISTOR 6.8
R5056 QRT01DJ-6R8X MF RESISTOR 6.8
R5057 NRSA63J-223X MG RESISTOR 22k
R5058 NRSA63J-184X MG RESISTOR 180k
R5059 NRSA63J-113X MG RESISTOR 11k
R5060 NRSA02J-150X MG RESISTOR 15
R5061 NRSA02J-150X MG RESISTOR 15
R5062 NRSA02J-150X MG RESISTOR 15
Ω
1/4W J
Ω
1/4W J
Ω
Ω
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1W J
Ω
1W J
Ω
Ω
Ω
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
1/4W J
1/16W J
1/4W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/4W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
DWF1
0J,D
WF10
UT
DWF1
0J,D
WF10
UT
DWF1
0J,D
WF10
UT
3-8
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R5063 NRSA02J-150X MG RESISTOR 15Ω 1/10W J
Ω
R5701 QRE141J-102Y C RESISTOR 1k
R5702 NRSA63J-103X MG RESISTOR 10k
R5713 NRSA63J-153X MG RESISTOR 15k
R5714 NRSA63J-473X MG RESISTOR 47k
R5715 NRSA63J-472X MG RESISTOR 4.7k
R5716 NRSA63J-224X MG RESISTOR 220k
R5717 NRSA63J-104X MG RESISTOR 100k
R5718 NRSA63J-473X MG RESISTOR 47k
R5719 NRSA63J-473X MG RESISTOR 47k
R5720 NRSA63J-222X MG RESISTOR 2.2k
R5721 NRSA63J-473X MG RESISTOR 47k
R5722 NRSA63J-473X MG RESISTOR 47k
R5723 NRSA63J-224X MG RESISTOR 220k
R5724 NRSA63J-393X MG RESISTOR 39k
R5725 NRSA63J-683X MG RESISTOR 68k
R5726 NRSA63J-104X MG RESISTOR 100k
R5727 NRSA63J-104X MG RESISTOR 100k
R5728 NRSA63J-333X MG RESISTOR 33k
R5729 NRSA63J-683X MG RESISTOR 68k
R5730 NRSA63J-104X MG RESISTOR 100k
R5731 NRSA63J-103X MG RESISTOR 10k
R5732 NRSA63J-104X MG RESISTOR 100k
R5733 NRSA63J-103X MG RESISTOR 10k
R5734 NRSA63J-474X MG RESISTOR 470k
R5735 NRSA63J-103X MG RESISTOR 10k
R5736 NRSA63J-474X MG RESISTOR 470k
R5737 NRSA63J-103X MG RESISTOR 10k
R5738 NRSA63J-104X MG RESISTOR 100k
R5739 NRSA63J-103X MG RESISTOR 10k
R5740 NRSA63J-473X MG RESISTOR 47k
R5741 NRSA63J-0R0X MG RESISTOR 0
R5742 NRSA63J-2R2X MG RESISTOR 2.2
R5743 NRSA63J-222X MG RESISTOR 2.2k
R5744 NRSA63J-391X MG RESISTOR 390
R5745 NRSA63J-223X MG RESISTOR 22k
R5746 NRSA63J-104X MG RESISTOR 100k
R5747 NRSA63J-104X MG RESISTOR 100k
R5748 NRSA63J-104X MG RESISTOR 100k
R5749 NRSA63J-104X MG RESISTOR 100k
R5750 NRSA63J-224X MG RESISTOR 220k
R5901 QRZ9005-100X FUSI RESISTOR 10
R5902 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R5905 NRSA63J-473X MG RESISTOR 47k
R5906 NRSA63J-473X MG RESISTOR 47k
R5909 QRE141J-102Y C RESISTOR 1k
R5910 QRE141J-102Y C RESISTOR 1k
R5911 NRSA63J-123X MG RESISTOR 12k
R5912 NRSA63J-123X MG RESISTOR 12k
R5913 NRSA63J-331X MG RESISTOR 330
R5914 NRSA63J-331X MG RESISTOR 330
R5915 QRZ9038-220X FUSI RESISTOR 22
R5916 QRZ9038-220X FUSI RESISTOR 22
R9001 QRL027J-104 OMF RESISTOR 100kΩ 2W J
R9002 QRZ9037-335 COMP RESISTOR 3.3MΩ 1/2W K
R9501 QRT017J-R33 MF RESISTOR 0.33
R9502 QRT017J-R33 MF RESISTOR 0.33
R9503 QRZ9005-681X FUSI RESISTOR 680
R9504 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R9505 NRSA63J-222X MG RESISTOR 2.2k
R9506 NRSA63J-103X MG RESISTOR 10k
R9508 QRL01DJ-220X OMF RESISTOR 22
R9510 QRE141J-753Y C RESISTOR 75k
R9516 NRSA63J-133X MG RESISTOR 13k
R9517 NRSA63J-103X MG RESISTOR 10k
R9518 NRSA63J-103X MG RESISTOR 10k
R9519 NRSA63J-103X MG RESISTOR 10k
R9520 NRSA63J-133X MG RESISTOR 13k
R9521 NRSA63J-103X MG RESISTOR 10k
R9522 NRSA63J-103X MG RESISTOR 10k
R9523 NRSA63J-102X MG RESISTOR 1k
R9524 NRSA63J-472X MG RESISTOR 4.7k
R9525 NRSA63J-102X MG RESISTOR 1k
R9526 NRSA63J-103X MG RESISTOR 10k
R9527 NRSA63J-222X MG RESISTOR 2.2k
R9528 QRE141J-753Y C RESISTOR 75k
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
Ω
Ω
Ω
Ω
Ω
1/16W J
Ω
1W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/4W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1/16W J
1W J
1W J
1/16W J
1/16W J
1/16W J
DWF1
0J,D
WF10
UT
R9529 QRE141J-753Y C RESISTOR 75kΩ 1/4W J
VR501 QVP0008-502Z TRIM RESISTOR 5k
VR502 QVP0008-203Z TRIM RESISTOR 20k
L5001 QQR1361-001 TOROIDAL COIL
L5901 NQL114K-471X COIL 470uH K
L5902 NQL114K-471X COIL 470uH K
L5903 NQL114K-471X COIL 470uH K
L5904 NQL114K-471X COIL 470uH K
T9501 QQS0172-001 SW TRANSF
BK501 LV33818-001A BKT(FET)
CN101 QGB2016K1-08 CONNECTOR B-B (1-8)
CN102 QGA2501C1-02 CONNECTOR W-B (1-2)
CN103 QGB2016J1-05 CONNECTOR B-B (1-5)
CN501 QGB2016J1-08 CONNECTOR B-B (1-8)
CN502 QGB2510K1-10 CONNECTOR B-B (1-10)
CN503 QGA3901C1-02 CONNECTOR W-B (1-2)
CN504 QGB2016J1-11 CONNECTOR B-B (1-11)
CN505 QGB2016K1-11 CONNECTOR B-B (1-11)
CN901 QGA7901F2-02 CONNECTOR W-B (1-2)
CN951 QGB2510J1-10 CONNECTOR B-B (1-10)
CN952 QGB2016K1-05 CONNECTOR B-B (1-5)
EP951 QNZ0136-001Z EARTH PLATE
EP952 QNZ0136-001Z EARTH PLATE
J1001 QNN0090-001 PIN JACK
K1001 NQR0129-003X FERRITE BESDA
K5001 QQR1183-001Z FERRITE BEADS
K5002 QQR1183-001Z FERRITE BEADS
K9501 QQR0779-001Z COIL
LF901 QQR1360-001 LINE FILTER
LF902 QQR1360-001 LINE FILTER
RY502 QSK0149-001 RELAY
S1001 QSW0834-001 PUSH SW
S9001 QSW1001-001 POWER SW
TH501 QAD0015-153Z THERMISTOR 15k
TH591 NAD0032-330X P THERMISTOR 33
TH592 NAD0032-330X P THERMISTOR 33
TH593 NAD0032-330X P THERMISTOR 33
TH594 NAD0032-330X P THERMISTOR 33
TH901 QAD0143-5R1 THERMISTOR 5.1
TH901 QAD0141-6R0 THERMISTOR 6
Z9001 QNG0003-001Z FUSE CLIP
Z9002 QNG0003-001Z FUSE CLIP
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
Ω
DWF1
0J
DWF1
0A,D
WF10
E,DW
F10U
F, DW
F10UJ
,DWF
10UP,
DWF1
0US,D
WF10
UT,D
WF10
UX
3-9
Packing materials and accessories parts list
Block No.
P2
A1A3 A6
US, UJ
M
3
M
M
P7
P2
A1A2 A3
P5
A, E, UP,
A
P3
A4
P2
A1A3
A11A12
J
P6
P2
A1A3 A5
UT, UX
P2
A1A2 A3
A7
A8 A9
A10
UF
3-10
P4
P1
Packing and Accessories
Block No. [M][3][M][M]
Symbol No. Part No. Part Name Description Local
A 1 LVT1145-007A INST BOOK ENG DWF10A
A 1 LVT1145-002C INST BOOK GER FRE DUT SPA ITA SWE FIN DAN DWF10E
A 1 LVT1145-010A INST BOOK ENG DWF10J
A 1 LVT1145-009A INST BOOK CHI(PEKIN) DWF10UF
A 1 LVT1145-006A INST BOOK ENG SPA CHI(PEKIN) POR ARA DWF10UP
A 1 LVT1145-004A INST BOOK KOR DWF10UJ,DWF10US
A 1 LVT1145-008A INST BOOK CHI(TAIWAN) DWF10UT
A 1 LVT1145-005A INST BOOK ENG ARA PER DWF10UX
A 2 BT-56012-1 WARRANTY CARD DWF10A
A 2 BT-54008-6 WARRANTY CARD DWF10E
A 2 BT-59019-1 WARRANTY CARD DWF10UF
A 2 BT-56013-1 WARRANTY CARD DWF10UP
A 3 QAM0570-001 PIN CABLE
A 4 SPDWF10E-SPBOX SPK WITH BOX
A 5 QAM0027-002 CONVERSION PLUG DWF10UT,DWF10UX
A 6 QAM0112-002 PLUG ADAPTOR DWF10UJ,DWF10US
A 7 BT-59020-1 SEAL DWF10UF
A 8 BT-59021-2 SVC CENTER LIST DWF10UF
A 9 E310162-001 CERTIFICATE TAG DWF10UF
A 10 GN30020-003A SURVEY CARD DWF10UF
A 11 YU20333 SAFETY INST. DWF10J
A 12 BT-51034-2 J=REGIST CARD DWF10J
P 1 LV31492-060A CARTON DWF10A
P 1 LV31492-070A CARTON DWF10E
P 1 LV35232-003A CARTON DWF10UF
P 1 LV31492-090A CARTON DWF10J,DWF10UJ
P 1 LV31492-058A CARTON DWF10UP,DWF10US,DWF10UT
P 1 LV31492-059A CARTON DWF10UX
P 2 QPA02503503P POLY BAG 25cm x 35cm
P 3 QPA07007505P POLY BAG 70cm x 75cm
P 3 LV34587-001A POLY BAG DWF10US,DWF10UT,DWF10UX
P 4 8500051801 MIRROR MAT
P 5 8000055101 TOP CUSHION
P 6 8000055111 BOTTOM CUSHION
P 7 LV33489-010A CARTON SHEET DWF10A
DWF10A,DWF10E,DWF10J,DWF10UF,DW
F10UJ,DWF10UP
3-11
Loading...
