PARTS LIST
[ RV-NB1 ]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
B ------------------------------- U.K.
E ----------- Continental Europe
EN ------------ Northern Europe
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD mechanism assembly and parts list (Block No.MB)
Cassette mechanism assembly and parts list (Block No.MP)
Electrical parts list (Block No.01~06)
Packing materials and accessories parts list (Block No.M3)
No.MB319B
3- 2
3- 6
3- 8
3-10
3-20
3-1
Exploded view of general assembly and parts list
1
M
70
69
66
61
Block No.
127
127
M
1
M
126
135
CD servo board
143
98
142
90
LED board
18
21
10
12
71
76
74
75
79
141
m
27
b
91
53
50
c
54
146
a
51
73
52
89
92
30
f
22
33
m
20
67
13
72
51
36
68
77
53
79
51
145
14
35
49
23
65
64
63
62
B
47
48
n
f
53
144
u
t
29
58
46
45
52
g
147
55
52
Display/Control
board
51
56
53
15
13
34
37
28
78
57
48
38
58
Guitar and Mic. jack
board
n
44
46
47
48
2
A
31
31
19
127
127
48
16
17
11
32
44
v
6
16
20
44
45
g
21
21
43
r
1
129
129
128
7
k1
131
a
i1
96
113
3
3
A
B
113
104
83
h
105
95
9
9
Tuner board
Equalizer amplifier
board
4
11
3
11
11
41
11
c
b
113
11
s
24
41
40
39
Power supply
board
s
25
Key board
17
r
11
8
8
82
41
i2
140
v
o
26
o
2
21
130
1
130
3-2
111
112
6
129
129
95
9
uner board
Equalizer amplifier
board
b
0
39
41
Power supply
board
25
26
o
k1
131
c
113
82
i2
a
i1
128
96
113
3
3
A
B
113
104
h
105
83
110
125
42
138
w
97
93
120
139
106
i2
i1
103
102
x
107
121
117
122
101
99
109
99
119
94
132
9
114
109
w
124
132
60
118
9
116
59
115
137
100
116
x
131
k2
123
132
132
C
133
128
133
132
130
84
132
u
134
148
130
87
C
t
132
107
129
129
112
112
81
88
86
85
85
86
85
80
86
88
87
h
Power amplifier board
k2
k1
84
109
109
108
110
126
127
127
127
30
130
2
5
7
6
3-3
General Assembly
Symbol No. Part No. Part Name Description Local
1 VJG1500-00G FRONT CABI SA
2 LE10008-024A SPEAKER (x2)
3 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8)
4 VYH2280-002 CAP (L)
5 VYH2281-002 CAP (R)
6 VKZ4389-009 SOUND ABSOBER (x2)
7 VKZ4805-001UL SOUND ABSOBER (x2)
8 VYSH102-097 SPACER (x2)
9 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8)
10 VJD2495-061 FRONT COVER(A)
11 QYSBSF2608ZA TAP SCREW M2.6 x 8mm(x10)
12 VJK4520-001 LCD LENS
13 VYSH102-098 SPACER (x2)
14 VXP3890-031 POWER BUTTON(A)
15 VXP3891-061 FUNC. BTN(A)
16 VXL4455-002 VOL.KNOB (x2)
17 VYTS539-003 VOL.SHEET (x2)
18 VJF3007-001 FOOT
19 VJF3007-002 FOOT
20 VYSA1R6-079 SPACER (x2)
21 QYSBSF3010ZA TAP SCREW M3 x 10mm(x6)
22 VJK4516-002 LENS
23 VJD5512-001 LED LENS
24 VYTH539-002 PACKING SHEET L
25 VYTH540-002 PACKING SHEET R
26 QYSBSFG3010ZA TAP SCREW M3 x 10mm
27 PQ45130-7 JVC MARK
28 VJT2389-041 CASSETTE HOLDER
29 VJT2390-031 DOOR COVER
30 VJT4246-061 DOOR LENS
31 VKY4180-401 CASSETTE SPRING (x2)
32 VYH5601-001 GEAR
33 VXL4458-031 EJECT KNOB
34 VYH8174-001 CAM(A)
35 VKY4736-001 PLATE SPRING(A)
36 VKY4737-002 PLATE SPRING(B)
37 QYSBSF2008ZA TAP SCREW M2 x 8mm
38 VKW5309-001 DOOR SPRING
39 VKL7850-303 EJECT SAFTY(R)
40 VKW5258-003 TORSION SPRING
41 QYSBSF3014ZA TAP SCREW M3 x 14mm(x4)
42 VMA4728-003 HEAD SHIELD
43 LV34126-002A PICK COVER
44 QYSDSF2006NA TAP SCREW M2 x 6mm(x4)
45 FMYH4003-003 INSULATOR (x2)
46 FMYH4003-004 INSULATOR (x2)
47 VYH7815-001 CD MECHA HOLDER (x2)
48 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
49 E65923-009 TAPPING SCREW
50 LV10179-002A CD CASE
51 LV30226-039A SPACER (x6)
52 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
53 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
54 VYH4769-002SS GEAR
55 LV35863-001A SHIELD A
56 LV35864-001A SHIELD B
57 LV40779-001A BRACKET
58 QYSBSF3010ZA TAP SCREW M3 x 10mm(x3)
59 LV40759-001A KNOB
60 LV40760-001A MIC PLATE
61 VJT1060-061 CD DOOR
62 LV35263-001A CLAMPER
63 LV42929-001A P.C.MAGNET
64 VYH7314-001 YOKE
65 LV43667-001A CLAMPER WEIGHT
66 VXL4458-031 EJECT KNOB
67 VYH8197-001 CAM(B)
68 QYSBSF2008ZA TAP SCREW M2 x 8mm
69 VKY4736-001 PLATE SPRING(A)
70 VKY4737-002 PLATE SPRING(B)
71 VYH8178-001 SLIDER(B)
72 VKW5334-001 SWITCH SPRING
73 VYH8204-001 SWITCH LEVER
74 VYH8205-001 LOCK
Block No. [M][1][M][M]
3-4
Symbol No. Part No. Part Name Description Local
75 QYSDSF2606MA TAP SCREW M2.6 x 6mm
76 VYH8176-003 COVER
77 VKW5352-001 TENSION SPRING
78 VKW5335-002 CD DOOR SPRING
79 VKZ4794-003 SPECIAL SCREW (x3)
80 VMH3021-001 HEAT SINK
81 VYH3892-005 HEAT SINK
82 VMH4055-002 HEAT SINK
83 QYSBSF3010ZA TAP SCREW M3 x 10mm
84 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2)
85 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
86 QYSBST3008ZA TAP SCREW M3 x 8mm(x4)
87 VYH8188-002 BRACKET (x2)
88 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
89 LV35225-001A LCD HOLDER
90 LV43895-001A SHEET
91 LV43896-001A LED HOLDER
92 QYSDSF2608ZA TAP SCREW M2.6 x 8mm(x2)
93 VJG1502-062 REAR CABI
94 QZW0152-001 ROD ANTENNA
95 VYH5012-005 TERMINAL LUG
96 E65923-009 TAPPING SCREW
97 QYSDSP3012NA SCREW M3 x 12mm
98 VYSH101-009 SPACER (x2)
99 QYSBSF4012ZA TAP SCREW M4 x 12mm(x4)
100 VYSH101-028 SPACER
101 VYH8179-003 JACK HOLDER
102 VYTH543-001 SHEET(AC)
103 VYTH544-001 SHEET(DC)
104 VYSA1R6-080 SPACER
105 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2)
106 VJD2503-001 DUCT
107 VKZ4796-003 SOUND ABSOBER (x2)
108 VJD2503-002 DUCT
109 QYSBSF3010ZA TAP SCREW M3 x 10mm(x8)
110 VJD5510-001 DUCT CAP (x2)
111 VJD1230-061UL GRILLE
112 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
113 QYSBSF3010ZA TAP SCREW M3 x 10mm(x4)
114 VJE3036-061 BATT.LID
115 VYSA1R4-056 SPACER
116 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2)
117 VYH8199-061 COVER
118 VYTH542-001 SHEET(COVER)
119 VYSH101-029 SPACER
120 VYSH101-027 SPACER
121 QYSBSF3010ZA TAP SCREW M3 x 10mm
122 QYSBSF3010ZA TAP SCREW M3 x 10mm
123 VJC2603-061 BATTERY COVER
124 VYH5657-001 BATTERY SPRING
125 E65923-009 TAPPING SCREW
126 VJD1233-00GUL SIDE PROTECT.AS (x2)
127 VKZ4795-002 SPECIAL SCREW (x12)
128 LE10016-057A SPEAKER (x2)
129 QYSBSF4012ZA TAP SCREW M4 x 12mm(x4)
130 QYSBSF4012ZA TAP SCREW M4 x 12mm(x4)
131 VKH3012-073 SHAFT(E) (x2)
132 QYSBSF3035ZA TAP SCREW M3 x 35mm(x10)
133 QYSBSF3010ZA TAP SCREW M3 x 10mm(x2)
134 LV35226-004A RATING LABEL
135 LV42035-002A LASER CAUTION
137 QQT0466-001 POWER TRANSF T 1901
138 QMFZ031-8R0-J1 FUSE F1902 8A
139 QMF5AE2-6R3-J1 FUSE F1904 6.3A AC250V
140 WJJ0002-001A-E E-SI C WIRE C-C
141 QUQ412-0912CJ FFC WIRE 9pin 12cm
142 QUQ412-0916CJ FFC WIRE 9pin 16cm
143 QUQ412-1018CJ FFC WIRE 10pin 18cm
144 QUQ412-1310CJ FFC WIRE 13pin 10cm
145 QUQ412-1310CJ FFC WIRE 13pin 10cm
146 QUQ110-1712AJ FFC WIRE 17pin 12cm
147 QUQ110-1607AJ FFC WIRE 16pin 7cm
148 LV44241-001A LABEL
3-5
CD mechanism assembly and parts list
FXL-M73-2M
Grease & Bond
= JVG-31N
15
2
4
5
3
Block No.
M
M
B
M
7
6
1
6
8
9
13
10
12
11
14
3-6
The parts without symbol number are not service.
CD mechanism
Symbol No. Part No. Part Name Description Local
1 LV10723-002A CD MECHA BASE A
2 OPTIMA-73B2 CD PICK
3 E406777-002SM C.D SHAFT
4 LV31002-001A CD RACK
5 E307745-441SM C.D GEAR 3
6 QYSDSP2003N SCREW M2 x 3mm(x4)
7 E406750-442SM PINION
8 LV43119-002A T.T PACKING
9 QAR0253-001 FEED MOTOR
10 QAR0130-001 SP MOTOR
11 EMW10190-441 CIR BOARD
12 QGA2001F1-06 CONNECTOR W-B (1-6)
13 QSW0506-001 LEAF SWITCH
14 E75832-221SS SPECIAL SCREW
15 QYSDSF2006Z SCREW M2 x 6mm
Block No. [M][B][M][M]
3-7
Cassette mechanism assembly and parts list
SLC-S41M
Block No.
M
M
M
P
Grease
=EM-30L
=UD-24
=LEN-320M
=Mobil-1
33
1
26
7
2
2
9
8
3
4
12
11
22
3
5
10
6
28
B
A
23
5
Cassette switch
18
1
The lower side
board
29
24
17
21
10
20
19
16
30
25
32
31
0.1
8.7
0.15 mm
32
31
34
27
Head amplifier &
Mechanism control board
34
The parts without symbol number are not service.
3-8
Cassette mechanism
Symbol No. Part No. Part Name Description Local
1 VKS1165-00N CHASSIS B. ASSY
2 VKS2274-002 REEL GEAR (x2)
3 VKW5286-002 B.T. SPRING (x2)
4 VKS5559-001 PLAY IDLE GEAR
5 VKS5595-002 BLIND
6 LV42013-001A EARTH SPRING
7 SLC-RP1SVM HEAD MOUNT ASSY
8 VKY3149-002 CASSETTE SP.
9 VKM3906-004 PLAY SW.LEVER
10 VKS1166-003 CONTROL CAM
11 VKW5279-002 HEAD BASE SP(R)
12 VKW5280-001 HEAD BASE SP(L)
16 VKS5603-00H MAIN PULLEY ASY
17 VKS3785-001MM FR ARM
18 VKW5284-002 SWING SPRING
19 VKS2278-003 TRIGGER ARM
20 VKW5301-001 FR SPRING
21 VKW5266-001 ELEVATOR SPRING
22 WDL214035-2 SLIT WASHER
23 QYSBSF2005ZA TAP SCREW M2 x 5mm
24 VKS3786-00G CLUTCH ASSY
25 VKF3205-00B F.WHEEL ASSY(R)
26 WDL183425 SLIT WASHER
27 VKF3207-00C F.WHEEL ASSY(L)
28 WDL173525-6 SLIT WASHER
29 VKZ3174-00A DC SOLENOID
30 LV42836-001A CAPSTAN BELT
31 QAR0309-001 D.C.MOTOR
32 VKR4761-003 MOTOR PULLEY
33 QYSPSP2604ZA SCREW M2.6 x 4mm(x2)
34 QYSBSF2608ZA TAP SCREW M2.6 x 8mm(x3)
Block No. [M][P][M][M]
3-9
Electrical parts list
Main board
Symbol No.
IC2 TA2008AN IC
IC3 LC72136N IC
IC301 TA8233H IC
IC390 KIA78DL06PI IC
IC601 TA8223K IC
IC701 BA15218N IC
IC702 BA15218N IC
IC703 BA15218N IC
IC704 BA15218N IC
IC801 BA15218N IC
Q2 2SC2668/O/-T TRANSISTOR
Q3 2SC2668/O/-T TRANSISTOR
Q4 2SA1175/HFE/-T TRANSISTOR
Q5 2SC2668/O/-T TRANSISTOR
Q6 2SC2668/O/-T TRANSISTOR
Q14 KRA107M-T DIGI TRANSISTOR
Q3191 KRA110M-T TRANSISTOR
Q3192 2SA1359/OY/ TRANSISTOR
Q3193 KRA111M-T DIGI TRANSISTOR
Q3194 KTC3199/GL/-T TRANSISTOR
Q3195 KTA1267/YG/-T TRANSISTOR
Q3196 KTA1023/OY/-T TRANSISTOR
Q3197 KTC3199/GL/-T TRANSISTOR
Q3198 KRC111M-T TRANSISTOR
Q3301 KTA1267/YG/-T TRANSISTOR
Q3302 2SA1359/OY/ TRANSISTOR
Q3303 KRA114M-T TRANSISTOR
Q3304 KRC114M-T TRANSISTOR
Q3305 KTC3199/GL/-T TRANSISTOR
Q3306 KTC3199/GL/-T TRANSISTOR
Q3491 KTA1267/YG/-T TRANSISTOR
Q3492 KTA1046/Y/ TRANSISTOR
Q3493 KRA114M-T TRANSISTOR
Q3494 KRC114M-T TRANSISTOR
Q3495 KTC3199/GL/-T TRANSISTOR
Q3496 KTC3199/GL/-T TRANSISTOR
Q6101 KTC3203/OY/-T TRANSISTOR
Q6201 KTC3203/OY/-T TRANSISTOR
Q6301 2SA952/LK/-T TRANSISTOR
Q6302 KTC3199/GL/-T TRANSISTOR
Q6303 KRA102M-T DIGI TRANSISTOR
Q6304 KTC3203/OY/-T TRANSISTOR
Q6305 KRC102M-T DIGI TRANSISTOR
Q6306 KRC102M-T DIGI TRANSISTOR
Q6307 KRC102M-T DIGI TRANSISTOR
Q6308 KRC102M-T DIGI TRANSISTOR
Q7301 KTC3199/GL/-T TRANSISTOR
Q7302 KTC3199/GL/-T TRANSISTOR
Q7303 2SK301/R/-T JUNCTION FET
Q8101 KTC3199/GL/-T TRANSISTOR
Q8201 KTC3199/GL/-T TRANSISTOR
D1 SVC203SPA-JV-T VARI CAP
D2 SVC203SPA-JV-T VARI CAP
D5 1SS133-T2 SI DIODE
D6 1SS133-T2 SI DIODE
D8 SVC344-T VARI CAP
D10 SVC344-T VARI CAP
D12 1A3G-T1 SI DIODE
D3191 1SS133-T2 SI DIODE
D3192 MTZJ7.5A-T2 Z DIODE
D3193 SRT14 DIODE
D3194 MTZJ7.5A-T2 Z DIODE
D3195 1SS133-T2 SI DIODE
D3196 1SS133-T2 SI DIODE
D3301 1SS133-T2 SI DIODE
D3302 MTZJ9.1A-T2 Z DIODE
D3491 1SS133-T2 SI DIODE
D3492 MTZJ9.1A-T2 Z DIODE
D3493 1SS133-T2 SI DIODE
D3901 MTZJ8.2B-T2 Z DIODE
Part No. Part Name Description Local
Block No. [0][1]
Symbol No.
D6301 1SS133-T2 SI DIODE
D6302 1SS133-T2 SI DIODE
D6304 1SS133-T2 SI DIODE
D7301 1SS133-T2 SI DIODE
D7302 1SS133-T2 SI DIODE
D7303 1SS133-T2 SI DIODE
D7304 1SS133-T2 SI DIODE
D7305 1SS133-T2 SI DIODE
D7306 1SS133-T2 SI DIODE
D7307 MTZJ4.3B-T2 Z DIODE
D8301 MTZJ4.3B-T2 Z DIODE
C3 QCSB1HK-6R8Y C CAPACITOR 6.8pF 50V K
C6 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7 QCSB1HJ-200Y C CAPACITOR 20pF 50V J
C9 QCSB1HJ-120Y C CAPACITOR 12pF 50V J
C13 QDX31EM-223Z C CAPACITOR 0.022uF 25V M
C16 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C21 QDX11EM-473Z C CAPACITOR 0.047uF 25V M
C22 QFP31HJ-431Z PP CAPACITOR 430pF 50V J
C23 QDCB1HJ-120Y C CAPACITOR 12pF 50V J
C24 QCSB1HJ-620Y C CAPACITOR 62pF 50V J
C25 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C26 QFP31HJ-181Z PP CAPACITOR 180pF 50V J
C27 QCS31HJ-101Z C CAPACITOR 100pF 50V J
C28 QCSB1HJ-150Y C CAPACITOR 15pF 50V J
C31 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C32 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C33 QETN1AM-107Z E CAPACITOR 100uF 10V M
C35 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C36 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C37 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C40 QETN1HM-105Z E CAPACITOR 1uF 50V M
C41 QETN1CM-106Z E CAPACITOR 10uF 16V M
C42 QDX11EM-473Z C CAPACITOR 0.047uF 25V M
C44 QETN1HM-105Z E CAPACITOR 1uF 50V M
C45 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C47 QDX31EM-123Z C CAPACITOR 0.012uF 25V M
C48 QDX31EM-123Z C CAPACITOR 0.012uF 25V M
C49 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C50 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C51 QDGB1HK-681Y C CAPACITOR 680pF 50V K
C52 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C56 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C60 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C61 QETN1AM-107Z E CAPACITOR 100uF 10V M
C62 QDCB1HJ-120Y C CAPACITOR 12pF 50V J
C63 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C64 QDCB1HJ-120Y C CAPACITOR 12pF 50V J
C65 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C66 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C69 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
C70 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C71 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C77 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C3191 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C3192 QETN1EM-107Z E CAPACITOR 100uF 25V M
C3193 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C3194 QETN1EM-107Z E CAPACITOR 100uF 25V M
C3301 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C3302 NCB31HK-221X C CAPACITOR 220pF 50V K
C3303 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3491 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3492 NCB31HK-221X C CAPACITOR 220pF 50V K
C3493 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3901 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3902 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C5308 QER61HM-474Z E CAPACITOR 0.47uF 50V M
C6101 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C6102 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C6103 QETN1EM-107Z E CAPACITOR 100uF 25V M
C6104 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6105 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6106 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C6107 QTE1V06-226Z E CAPACITOR 22uF 35V
C6108 NDC31HJ-151X C CAPACITOR 150pF 50V J
Part No. Part Name Description Local
3-10
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C6201 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C6202 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C6203 QETN1EM-107Z E CAPACITOR 100uF 25V M
C6204 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6205 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6206 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C6207 QTE1V06-226Z E CAPACITOR 22uF 35V
C6208 NDC31HJ-151X C CAPACITOR 150pF 50V J
C6301 QETN1EM-227Z E CAPACITOR 220uF 25V M
C6302 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6303 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6304 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C6305 QETN1HM-105Z E CAPACITOR 1uF 50V M
C6306 QETN1AM-227Z E CAPACITOR 220uF 10V M
C6307 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6308 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C6309 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C6310 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C6311 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6312 QETN1EM-227Z E CAPACITOR 220uF 25V M
C6313 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C6314 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6315 QETM1EM-688 E CAPACITOR 6800uF 25V M
C6316 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6317 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6318 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6319 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C6320 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6321 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7301 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7302 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C7303 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C7305 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7306 QFVF1HJ-274Z MF CAPACITOR 0.27uF 50V J
C7307 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7308 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C7309 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7310 QFLC1HJ-153Z M CAPACITOR 0.015uF 50V J
C7311 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7312 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7313 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7314 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7316 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7317 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C7318 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7319 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C7320 QFLC1HJ-393Z M CAPACITOR 0.039uF 50V J
C7321 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C7322 QER61HM-105Z E CAPACITOR 1uF 50V M
C7323 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7324 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8101 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C8102 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C8103 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8105 NCB31HK-331X C CAPACITOR 330pF 50V K
C8201 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C8202 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C8203 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8205 NCB31HK-331X C CAPACITOR 330pF 50V K
C8301 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8303 QETN1HM-105Z E CAPACITOR 1uF 50V M
C8304 NCB31HK-331X C CAPACITOR 330pF 50V K
C8322 QETN1EM-476Z E CAPACITOR 47uF 25V M
TC2 QAT3725-200Z TRIM CAPACITOR 20pF
TC3 QAT3725-300Z TRIM CAPACITOR 30pF
R1 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R2 QRE141J-473Y C RESISTOR 47k
R3 QRE141J-4R7Y C RESISTOR 4.7
R7 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R9 QRE141J-102Y C RESISTOR 1k
R12 QRE141J-472Y C RESISTOR 4.7k
R13 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R14 QRE141J-103Y C RESISTOR 10k
R15 QRE141J-222Y C RESISTOR 2.2k
R16 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R17 QRE141J-104Y C RESISTOR 100k
R18 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
Ω
1/4W J
1/4W J
1/4W J
1/4W J
R19 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R20 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R21 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R28 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J
R30 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R31 QRE141J-123Y C RESISTOR 12k
R33 QRE141J-101Y C RESISTOR 100
R34 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R35 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R36 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R37 QRE141J-560Y C RESISTOR 56Ω 1/4W J
R40 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R41 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R42 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R44 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R45 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R46 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R47 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R48 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R51 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R52 QRE141J-472Y C RESISTOR 4.7k
R54 QRE141J-222Y C RESISTOR 2.2k
R55 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R56 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R57 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R59 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R60 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R61 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R64 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R3191 QRE141J-1R5Y C RESISTOR 1.5Ω 1/4W J
R3192 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J
R3193 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R3194 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R3195 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R3196 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R3197 QAD0015-153Z THERMISTOR 15k
R3198 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3199 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R3200 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
R3201 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R3202 QRE141J-152Y C RESISTOR 1.5kΩ 1/4W J
R3203 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R3204 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R3301 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R3302 QRE141J-1R0Y C RESISTOR 1Ω 1/4W J
R3303 QRE141J-1R0Y C RESISTOR 1Ω 1/4W J
R3304 QRE141J-1R0Y C RESISTOR 1Ω 1/4W J
R3305 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R3306 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J
R3307 QRE141J-102Y C RESISTOR 1k
R3308 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R3309 QRE141J-681Y C RESISTOR 680
R3310 QRE141J-681Y C RESISTOR 680
R3311 QRE141J-681Y C RESISTOR 680Ω 1/4W J
R3312 QRE141J-472Y C RESISTOR 4.7k
R3313 QRE141J-471Y C RESISTOR 470
R3314 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R3315 NRSA63J-472X MG RESISTOR 4.7k
R3316 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3491 QRE141J-471Y C RESISTOR 470
R3492 QRE141J-1R0Y C RESISTOR 1
R3493 QRE141J-1R0Y C RESISTOR 1Ω 1/4W J
R3494 QRE141J-1R0Y C RESISTOR 1
R3495 NRSA63J-222X MG RESISTOR 2.2k
R3496 QRE141J-682Y C RESISTOR 6.8kΩ 1/4W J
R3497 QRE141J-102Y C RESISTOR 1k
R3498 QRE141J-222Y C RESISTOR 2.2k
R3499 QRE141J-681Y C RESISTOR 680
R3500 QRE141J-681Y C RESISTOR 680
R3501 QRE141J-681Y C RESISTOR 680Ω 1/4W J
R3502 QRE141J-472Y C RESISTOR 4.7k
R3503 QRE141J-471Y C RESISTOR 470
R3504 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R3505 QRE141J-472Y C RESISTOR 4.7k
R3506 QRE141J-472Y C RESISTOR 4.7k
R3507 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R3508 NRSA63J-682X MG RESISTOR 6.8k
R3901 QRZ9006-4R7X F.RESISTOR 4.7
Ω
1/4W J
Ω
1/4W J
Ω
Ω
Ω
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
1/4W J
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
Ω
Ω
1/4W J
1/4W J
1/4W J
1/4W J
1/16W J
1/16W J
1/4W J
1/4W J
1/4W J
1/4W J
1/16W J
3-11
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R5107 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R5207 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R6101 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R6102 QRE141J-121Y C RESISTOR 120Ω 1/4W J
R6103 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
R6104 QRE141J-2R2Y C RESISTOR 2.2
R6105 NRSA63J-472X MG RESISTOR 4.7k
R6201 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R6202 QRE141J-121Y C RESISTOR 120Ω 1/4W J
R6203 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
R6204 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R6205 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6301 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R6302 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R6303 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R6304 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R6305 QRE141J-622Y C RESISTOR 6.2kΩ 1/4W J
R6306 QRE141J-182Y C RESISTOR 1.8kΩ 1/4W J
R6307 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R6308 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R6309 QRE141J-472Y C RESISTOR 4.7k
R6310 QRE141J-102Y C RESISTOR 1k
R6311 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R6312 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R6313 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R6314 QRE141J-391Y C RESISTOR 390Ω 1/4W J
R6315 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R6316 QRE141J-391Y C RESISTOR 390Ω 1/4W J
R6317 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R6318 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R6319 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R6320 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R6321 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R6322 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
R6325 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R7301 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R7303 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7305 QRE141J-224Y C RESISTOR 220kΩ 1/4W J
R7307 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R7308 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R7309 QRE141J-333Y C RESISTOR 33kΩ 1/4W J
R7310 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7311 QRE141J-184Y C RESISTOR 180kΩ 1/4W J
R7312 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R7313 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R7314 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R7316 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R7317 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R7318 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7319 NRSA63J-202X MG RESISTOR 2k
R7320 QRE141J-221Y C RESISTOR 220Ω 1/4W J
R7321 QRE141J-224Y C RESISTOR 220k
R7322 QRE141J-563Y C RESISTOR 56k
R7323 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7324 NRSA63J-103X MG RESISTOR 10k
R7325 QRE141J-103Y C RESISTOR 10k
R7326 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R7327 NRSA63J-105X MG RESISTOR 1M
R7328 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R7329 QRE141J-102Y C RESISTOR 1k
R7330 QRE141J-392Y C RESISTOR 3.9k
R7331 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R7332 QRE141J-101Y C RESISTOR 100
R7333 QRE141J-273Y C RESISTOR 27k
R7334 QRE141J-243Y C RESISTOR 24kΩ 1/4W J
R7336 QRE141J-243Y C RESISTOR 24k
R7338 QRE141J-823Y C RESISTOR 82k
R7339 QRE141J-222Y C RESISTOR 2.2k
R7341 QRE141J-473Y C RESISTOR 47k
R7342 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R7343 NRSA63J-103X MG RESISTOR 10k
R7344 QRE141J-104Y C RESISTOR 100k
R8101 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R8102 QRE141J-272Y C RESISTOR 2.7k
R8103 QRE141J-392Y C RESISTOR 3.9k
R8104 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R8105 QRE141J-332Y C RESISTOR 3.3k
R8107 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/16W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
R8111 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R8201 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R8202 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J
R8203 QRE141J-392Y C RESISTOR 3.9kΩ 1/4W J
R8204 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R8205 QRE141J-332Y C RESISTOR 3.3k
R8207 QRE141J-103Y C RESISTOR 10k
R8211 QRE141J-473Y C RESISTOR 47kΩ 1/4W J
R8301 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R8302 QRE141J-474Y C RESISTOR 470kΩ 1/4W J
R8321 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R8327 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
L1 QQR0772-001 OSC COIL
L2 QQR0769-001 RF COIL
L3 QQR0771-001 BAR ANTENA
L4 QQR0723-001 OSC COIL
L6 QQR0774-001 OSC COIL(LW)
L7 QQL231K-221Y COIL 220uH K
L12 QQR0756-001 COIL
L3191 QQL28AK-101 CHOKE COIL 100uH K
T2 QQR0719-001 I.F.TRANSEFORME
BP1 QQR0768-001Z BP FILTER
BS1 VYH5483-001 SPRING
BS2 VYH7199-001 BATT.SPRING
CF1 QAX0403-001 C FILTER 10.70MHz
CF3 QAX0404-001Z C FILTER 10.700MHz
CF4 QAX0778-001 CERA LOCK
CN1 QGF1205C1-09 CONNECTOR FFC/FPC (1-9)
CN601 QGF1205F1-13 CONNECTOR FFC/FPC (1-13)
CN602 QGF1205F1-13 CONNECTOR FFC/FPC (1-13)
CN603 QGB1214K1-10S CONNECTOR B-B (1-10)
CN604 QGB1214J1-10S CONNECTOR B-B (1-10)
FW601 WJK0002-001A-E E-SI C WIRE C-B
FW602 WJK0004-001A-E E-SI C WIRE C-B
FW603 WJK0003-001A-E 001A C WIRE C-B
TP1 QNZ0104-001 POST PIN
TP2 QNZ0104-001 POST PIN
X1 QAX0402-001 CRYSTAL 75.0kHz
Ω
1/4W J
Ω
1/4W J
Micon board
Block No. [0][2]
Symbol No.
IC401 NJM4565M-WE IC
IC501 BH3852S IC
IC551 PQ033ES3MX-T IC
IC603 NJM4565M-WE IC
IC751 NJM4565M-WE IC
IC752 NJM4565M-WE IC
IC831 NJM4565M-WE IC
IC901 MN101C49GNH IC(MCU)MASK
IC902 PST9131N-X IC
IC903 GP1UM281XKVF IR DETECT UNIT
IC904 BR24L02F-W-X IC
Q2501 KRA108S-X TRANSISTOR
Q2502 2SD601A/R/-X TRANSISTOR
Q2503 2SD601A/R/-X TRANSISTOR
Q2504 KRC114S-X TRANSISTOR
Q2505 KRA110S-X TRANSISTOR
Q3361 2SB709A/QR/-X TRANSISTOR
Q3362 2SD601A/R/-X TRANSISTOR
Q3571 2SB624/4/-X TRANSISTOR
Q3572 2SD601A/R/-X TRANSISTOR
Q3671 2SB624/4/-X TRANSISTOR
Q3672 KRC114S-X TRANSISTOR
Q3791 2SD601A/R/-X TRANSISTOR
Q4101 2SD596/4/-X TRANSISTOR
Q4101 or 2SD2114K/VW/-X TRANSISTOR
Q4102 2SD596/4/-X TRANSISTOR
Q4102 or 2SD2114K/VW/-X TRANSISTOR
Part No. Part Name Description Local
3-12
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
Q4201 2SD596/4/-X TRANSISTOR
Q4201 or 2SD2114K/VW/-X TRANSISTOR
Q4202 2SD596/4/-X TRANSISTOR
Q4202 or 2SD2114K/VW/-X TRANSISTOR
Q4301 2SD601A/R/-X TRANSISTOR
Q5101 2SK301/R/-T JUNCTION FET
Q5201 2SK301/R/-T JUNCTION FET
Q6150 2SD596/4/-X TRANSISTOR
Q6150 or 2SD2114K/VW/-X TRANSISTOR
Q6151 2SD596/4/-X TRANSISTOR
Q6250 2SD596/4/-X TRANSISTOR
Q6250 or 2SD2114K/VW/-X TRANSISTOR
Q6251 2SD596/4/-X TRANSISTOR
Q6350 UN2211-X TRANSISTOR
Q6351 UN2111-X TRANSISTOR
Q6401 UN2211-X TRANSISTOR
Q7351 2SD601A/R/-X TRANSISTOR
Q7352 2SD601A/R/-X TRANSISTOR
Q7353 UN2112-X DIGI TRANSISTOR
Q7354 2SD601A/R/-X TRANSISTOR
Q7355 UN2112-X DIGI TRANSISTOR
Q7356 2SD601A/R/-X TRANSISTOR
Q7357 2SD601A/R/-X TRANSISTOR
Q7358 2SD601A/R/-X TRANSISTOR
Q7359 2SB709A/QR/-X TRANSISTOR
Q7360 DTC115EKA-X DIGI TRANSISTOR
Q8351 2SB709A/QR/-X TRANSISTOR
Q8352 2SB709A/QR/-X TRANSISTOR
Q8353 2SD601A/R/-X TRANSISTOR
Q8354 UN2211-X TRANSISTOR
Q9001 KTC3195/O/-T TRANSISTOR
Q9002 KTC3195/O/-T TRANSISTOR
Q9003 2SB709A/R/-X TRANSISTOR
Q9004 2SD601A/R/-X TRANSISTOR
Q9005 2SD601A/R/-X TRANSISTOR
Q9006 2SD601A/R/-X TRANSISTOR
D2502 SLR-342VR-T15 LED
D2503 SLR-342VR-T15 LED
D2504 SLR-342MG-T15 LED
D3361 1SS133-T2 SI DIODE
D3362 MTZJ3.9B-T2 Z DIODE
D3363 1SS133-T2 SI DIODE
D3571 SELU1E54CM-P LED
D3572 SELU1E54CM-P LED
D3791 MTZJ6.2A-T2 Z DIODE
D4301 1SS133-T2 SI DIODE
D4302 1SS133-T2 SI DIODE
D5501 1SS133-T2 SI DIODE
D6303 1SS133-T2 SI DIODE
D6501 MTZJ4.7A-T2 Z DIODE
D6502 MTZJ3.6A-T2 ZENER DIODE
D6503 1SS133-T2 SI DIODE
D7351 1SS133-T2 SI DIODE
D7352 1SS133-T2 SI DIODE
D7353 1SS133-T2 SI DIODE
D7354 1SS133-T2 SI DIODE
D7355 1SS133-T2 SI DIODE
D7357 1SS133-T2 SI DIODE
D7358 1SS133-T2 SI DIODE
D7359 1SS133-T2 SI DIODE
D7360 1SS133-T2 SI DIODE
D8351 1SS133-T2 SI DIODE
D8352 1SS133-T2 SI DIODE
D8353 1SS133-T2 SI DIODE
D8354 1SS133-T2 SI DIODE
D9007 1N4003S-T5 SI DIODE
D9011 MTZJ5.1C-T2 Z DIODE
D9012 MA700A-T2 SB DIODE
D9013 1SS133-T2 SI DIODE
D9126 1SS133-T2 SI DIODE
C2501 QER61HM-105Z E CAPACITOR 1uF 50V M
C2502 QER61CM-476Z E CAPACITOR 47uF 16V M
C2503 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C2521 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2522 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2523 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2524 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3361 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C3362 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C3571 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C3791 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4142 NDC31HJ-150X C CAPACITOR 15pF 50V J
C4143 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C4144 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C4145 QTE1V06-106Z E CAPACITOR 10uF 35V
C4151 NCS31HJ-681X C CAPACITOR 680pF 50V J
C4152 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4242 NDC31HJ-150X C CAPACITOR 15pF 50V J
C4243 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C4244 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C4245 QTE1V06-106Z E CAPACITOR 10uF 35V
C4251 NCS31HJ-681X C CAPACITOR 680pF 50V J
C4252 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4341 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C4342 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C4343 NCS31HJ-151X C CAPACITOR 150pF 50V J
C4344 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C4351 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5101 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C5102 QER61EM-475Z E CAPACITOR 4.7uF 25V M
C5103 QER61EM-106Z E CAPACITOR 10uF 25V M
C5104 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C5105 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C5106 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C5107 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5201 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C5202 QER61EM-475Z E CAPACITOR 4.7uF 25V M
C5203 QER61EM-106Z E CAPACITOR 10uF 25V M
C5204 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C5205 QFLC1HJ-563Z M CAPACITOR 0.056uF 50V J
C5206 QFLC1HJ-562Z M CAPACITOR 5600pF 50V J
C5207 NCS31HJ-221X C CAPACITOR 220pF 50V J
C5301 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C5302 QER61HM-105Z E CAPACITOR 1uF 50V M
C5303 QER61HM-225Z E CAPACITOR 2.2uF 50V M
C5304 QER61HM-105Z E CAPACITOR 1uF 50V M
C5305 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C5306 QEKC1EM-475Z E CAPACITOR 4.7uF 25V M
C5307 QFLC1HJ-473Z M CAPACITOR 0.047uF 50V J
C5309 QEKC1HM-474Z E CAPACITOR 0.47uF 50V M
C5501 QER61AM-107Z E CAPACITOR 100uF 10V M
C5502 QEKC1EM-476Z E CAPACITOR 47uF 25V M
C5503 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6150 QER61HM-105Z E CAPACITOR 1uF 50V M
C6151 NCS31HJ-151X C CAPACITOR 150pF 50V J
C6152 NCS31HJ-101X C CAPACITOR 100pF 50V J
C6153 QER61AM-107Z E CAPACITOR 100uF 10V M
C6155 NCB31HK-562X C CAPACITOR 5600pF 50V K
C6156 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C6157 NCS31HJ-271X C CAPACITOR 270pF 50V J
C6250 QER61HM-105Z E CAPACITOR 1uF 50V M
C6251 NCS31HJ-151X C CAPACITOR 150pF 50V J
C6252 NCS31HJ-101X C CAPACITOR 100pF 50V J
C6253 QER61AM-107Z E CAPACITOR 100uF 10V M
C6255 NCB31HK-562X C CAPACITOR 5600pF 50V K
C6256 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C6257 NCS31HJ-271X C CAPACITOR 270pF 50V J
C6350 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C6351 QEKC1CM-476Z E CAPACITOR 47uF 16V M
C6352 QEKC1CM-226Z E CAPACITOR 22uF 16V M
C7351 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C7352 NDC31HJ-331X C CAPACITOR 330pF 50V J
C7353 QETN1HM-334Z E CAPACITOR 0.33uF 50V M
C7354 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7355 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7356 QETN1EM-476Z E CAPACITOR 47uF 25V M
C7357 NDC31HJ-680X C CAPACITOR 68pF 50V J
C7358 QETN1CM-106Z E CAPACITOR 10uF 16V M
C7359 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C7360 QETN1EM-476Z E CAPACITOR 47uF 25V M
C7361 NDC31HJ-221X C CAPACITOR 220pF 50V J
C7362 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C7363 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C7365 QETN1HM-105Z E CAPACITOR 1uF 50V M
3-13
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C7366 QETN1EM-476Z E CAPACITOR 47uF 25V M
C7367 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7368 QETN1HM-105Z E CAPACITOR 1uF 50V M
C7369 NCS31HJ-331X C CAPACITOR 330pF 50V J
C7370 QETN1HM-104Z E CAPACITOR 0.1uF 50V M
C7381 NCS31HJ-221X C CAPACITOR 220pF 50V J
C7382 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8351 NDC31HJ-680X C CAPACITOR 68pF 50V J
C8352 NDC31HJ-221X C CAPACITOR 220pF 50V J
C8353 NDC31HJ-221X C CAPACITOR 220pF 50V J
C8354 NDC31HJ-330X C CAPACITOR 33pF 50V J
C8355 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C8356 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C8357 NCS31HJ-101X C CAPACITOR 100pF 50V J
C8358 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C8359 QEKC1HM-106Z E CAPACITOR 10uF 50V M
C8360 NCB31HK-272X C CAPACITOR 2700pF 50V K
C8361 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C8362 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C8363 NCS31HJ-101X C CAPACITOR 100pF 50V J
C9001 QER61AM-107Z E CAPACITOR 100uF 10V M
C9002 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9003 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9004 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9005 NCS31HJ-390X C CAPACITOR 39pF 50V J
C9006 NCS31HJ-390X C CAPACITOR 39pF 50V J
C9007 NDC31HJ-330X C CAPACITOR 33pF 50V J
C9008 NDC31HJ-330X C CAPACITOR 33pF 50V J
C9009 NDC31HJ-220X C CAPACITOR 22pF 50V J
C9010 NDC31HJ-220X C CAPACITOR 22pF 50V J
C9011 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9012 QER61HM-226Z E CAPACITOR 22uF 50V M
C9104 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9110 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9126 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9133 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9134 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9136 QER61HM-106Z E CAPACITOR 10uF 50V M
C9137 QER61HM-106Z E CAPACITOR 10uF 50V M
C9138 QER61HM-106Z E CAPACITOR 10uF 50V M
C9142 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9145 NCS31HJ-101X C CAPACITOR 100pF 50V J
C9146 NCS31HJ-101X C CAPACITOR 100pF 50V J
C9147 NCS31HJ-101X C CAPACITOR 100pF 50V J
C9148 NCS31HJ-470X C CAPACITOR 47pF 50V J
C9149 NCS31HJ-470X C CAPACITOR 47pF 50V J
C9150 NCB21CK-105X C CAPACITOR 1uF 16V K
C9151 NCB21CK-105X C CAPACITOR 1uF 16V K
C9178 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9180 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9181 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9182 NDC31HJ-680X C CAPACITOR 68pF 50V J
C9187 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9188 NDC31HJ-680X C CAPACITOR 68pF 50V J
C9189 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9190 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9196 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9197 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9198 NCS31HJ-151X C CAPACITOR 150pF 50V J
C9247 NCS31HJ-151X C CAPACITOR 150pF 50V J
R2501 NRS181J-271X MG RESISTOR 270Ω 1/8W J
R2504 NRSA63J-101X MG RESISTOR 100
R2505 NRSA63J-101X MG RESISTOR 100
R2506 NRSA63J-121X MG RESISTOR 120Ω 1/16W J
R2507 NRSA63J-151X MG RESISTOR 150
R2508 NRSA63J-221X MG RESISTOR 220
R2509 NRSA63J-271X MG RESISTOR 270
R2510 NRSA63J-391X MG RESISTOR 390
R2511 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R2512 NRSA63J-102X MG RESISTOR 1k
R2513 NRSA63J-182X MG RESISTOR 1.8k
R2514 NRS181J-391X MG RESISTOR 390Ω 1/8W J
R2515 NRS181J-471X MG RESISTOR 470
R2516 NRSA63J-473X MG RESISTOR 47k
R2517 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2518 NRSA63J-104X MG RESISTOR 100k
R2519 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/8W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R2520 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2521 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R3361 QRE141J-390Y C RESISTOR 39Ω 1/4W J
R3362 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R3363 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3571 NRSA63J-472X MG RESISTOR 4.7k
R3572 NRSA63J-472X MG RESISTOR 4.7k
R3573 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3574 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3575 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3576 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R3577 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R3671 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R3672 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R3791 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R3792 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R3793 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R3794 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R4141 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R4142 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R4143 NRSA63J-224X MG RESISTOR 220k
R4144 NRSA63J-473X MG RESISTOR 47k
R4145 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R4149 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R4150 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R4151 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R4153 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R4155 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R4158 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R4159 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R4160 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R4161 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R4241 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R4242 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R4243 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R4244 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R4245 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R4249 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R4250 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R4251 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R4253 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R4255 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R4258 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R4259 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R4260 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R4261 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R4301 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R4341 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R4342 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R4343 QRE141J-101Y C RESISTOR 100
R4351 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R4352 NRSA63J-101X MG RESISTOR 100
R4353 NRSA63J-101X MG RESISTOR 100
R5101 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R5102 NRSA63J-153X MG RESISTOR 15k
R5104 NRSA63J-224X MG RESISTOR 220k
R5201 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R5202 NRSA63J-153X MG RESISTOR 15k
R5204 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R5301 NRSA63J-104X MG RESISTOR 100k
R5302 NRSA63J-333X MG RESISTOR 33k
R5303 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R5304 NRSA63J-104X MG RESISTOR 100k
R5305 QRE141J-101Y C RESISTOR 100
R5306 NRSA63J-475X MG RESISTOR 4.7MΩ 1/16W J
R5307 NRSA63J-475X MG RESISTOR 4.7M
R5308 NRSA63J-154X MG RESISTOR 150k
R5501 NRSA63J-153X MG RESISTOR 15k
R5502 NRSA63J-473X MG RESISTOR 47k
R6150 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R6151 NRSA63J-223X MG RESISTOR 22k
R6152 NRSA63J-102X MG RESISTOR 1k
R6153 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R6154 NRSA63J-222X MG RESISTOR 2.2k
R6155 NRSA63J-222X MG RESISTOR 2.2k
R6157 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R6158 NRSA63J-153X MG RESISTOR 15k
R6160 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-14
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R6161 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6250 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R6251 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R6252 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R6253 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R6254 NRSA63J-222X MG RESISTOR 2.2k
R6255 NRSA63J-222X MG RESISTOR 2.2k
R6257 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R6258 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R6260 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6261 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6335 QRE141J-121Y C RESISTOR 120Ω 1/4W J
R6350 QRE141J-121Y C RESISTOR 120Ω 1/4W J
R6351 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R6353 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R6354 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6401 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R7351 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R7352 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R7353 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R7354 NRSA63J-153X MG RESISTOR 15k
R7355 NRSA63J-563X MG RESISTOR 56k
R7356 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R7357 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7358 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7359 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R7360 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R7361 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7362 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R7365 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R7366 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R7367 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7368 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R7369 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R7370 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R7371 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7372 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7373 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R7374 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J
R7375 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7376 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7377 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7378 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7379 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R7380 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R7381 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7382 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R7383 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7384 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R7385 NRSA63J-473X MG RESISTOR 47k
R7386 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R7387 NRSA63J-102X MG RESISTOR 1k
R7388 NRSA63J-103X MG RESISTOR 10k
R8351 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R8352 NRSA63J-474X MG RESISTOR 470k
R8353 NRSA63J-124X MG RESISTOR 120k
R8354 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R8355 NRSA63J-474X MG RESISTOR 470k
R8356 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R8357 NRSA63J-101X MG RESISTOR 100
R8358 NRSA63J-475X MG RESISTOR 4.7M
R8359 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R8360 NRSA63J-822X MG RESISTOR 8.2k
R8361 NRSA63J-473X MG RESISTOR 47k
R8362 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R8363 QRE141J-101Y C RESISTOR 100
R8364 NRSA63J-473X MG RESISTOR 47k
R8365 NRSA63J-101X MG RESISTOR 100
R8366 NRSA63J-224X MG RESISTOR 220k
R8367 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R8368 NRSA63J-473X MG RESISTOR 47k
R8369 NRSA63J-473X MG RESISTOR 47k
R8370 NRSA02J-275X MG RESISTOR 2.7MΩ 1/10W J
R8371 NRSA63J-103X MG RESISTOR 10k
R8372 NRSA63J-103X MG RESISTOR 10k
R9001 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9002 NRSA63J-222X MG RESISTOR 2.2k
R9003 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/4W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R9004 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R9011 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R9012 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R9013 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R9014 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9015 NRSA63J-103X MG RESISTOR 10k
R9016 NRSA63J-103X MG RESISTOR 10k
R9017 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9018 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R9102 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9103 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9104 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9105 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9107 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9108 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9115 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R9116 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R9118 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9119 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9120 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9124 NRSA63J-222X MG RESISTOR 2.2k
R9125 NRSA63J-103X MG RESISTOR 10k
R9126 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R9129 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9130 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9131 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9133 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R9134 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R9135 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9136 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R9137 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9138 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9139 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9140 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9142 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9145 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9146 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9147 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9148 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9149 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9150 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R9172 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9173 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9174 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9175 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9176 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9177 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R9178 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R9180 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9181 NRSA63J-222X MG RESISTOR 2.2k
R9182 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R9184 NRSA63J-103X MG RESISTOR 10k
R9185 NRSA63J-102X MG RESISTOR 1k
R9186 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R9187 NRSA63J-222X MG RESISTOR 2.2k
R9188 NRSA63J-682X MG RESISTOR 6.8k
R9189 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R9190 NRSA63J-222X MG RESISTOR 2.2k
R9191 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R9192 NRSA63J-222X MG RESISTOR 2.2k
R9196 NRSA63J-472X MG RESISTOR 4.7k
R9197 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R9198 NRSA63J-472X MG RESISTOR 4.7k
R9199 NRSA63J-102X MG RESISTOR 1k
R9201 NRSA63F-473X MG RESISTOR 47kΩ 1/16W F
R9202 NRSA63F-154X MG RESISTOR 150k
R9203 NRSA63J-333X MG RESISTOR 33k
R9204 NRSA63J-912X MG RESISTOR 9.1k
R9207 NRSA63J-103X MG RESISTOR 10k
R9208 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R9209 NRSA63J-103X MG RESISTOR 10k
R9218 NRSA63J-432X MG RESISTOR 4.3k
R9221 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R9222 NRSA63J-104X MG RESISTOR 100k
R9223 NRSA63J-104X MG RESISTOR 100k
R9224 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R9226 NRSA63J-473X MG RESISTOR 47k
R9230 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W F
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-15
Symbol No.
R9237 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R9238 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R9239 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R9240 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R9272 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R9273 NRSA63J-473X MG RESISTOR 47k
R9274 NRSA63J-473X MG RESISTOR 47k
R9275 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R9278 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R9282 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R9285 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R9286 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
VR731 QVQ0287-B24 V RESISTOR
VR901 QSW0626-001 R ENCODER
VR902 QSW0626-001 R ENCODER
L4351 QQR0621-001Z FERRATE BEADS
L4352 QQR0621-001Z FERRATE BEADS
L4353 QQL244K-100Z COIL 10uH K
L4354 NQR0007-002X FERRITE BEADS
L4355 NQR0007-002X FERRITE BEADS
L4356 NQR0007-002X FERRITE BEADS
L6351 NQR0007-002X FERRITE BEADS
L6352 NQR0007-002X FERRITE BEADS
L6353 NQR0007-002X FERRITE BEADS
L9001 QQL244K-100Z COIL 10uH K
L9002 QQL244K-100Z COIL 10uH K
CN251 QGB1216K1-10S CONNECTOR B-B (1-10)
CN252 QGB1216K1-10S CONNECTOR B-B (1-10)
CN403 QGF1205C1-09 CONNECTOR FFC/FPC (1-9)
CN404 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
CN405 QGF1205C1-10 CONNECTOR FFC/FPC (1-10)
CN406 QGF1205C1-09 CONNECTOR FFC/FPC (1-9)
CN407 QGF1210G1-13 CONNECTOR FFC/FPC (1-13)
CN408 QGF1210G1-13 CONNECTOR FFC/FPC (1-13)
CN751 QGA2001F1-04 CONNECTOR W-B (1-4)
CN901 QGB1216J1-10S CONNECTOR B-B (1-10)
CN902 QGB1216J1-10S CONNECTOR B-B (1-10)
CN904 QGA2501C3-03Z CONNECTOR W-B (1-3)
DI901 QLD0332-002 LCD MODULE
FW251 QUM213-14Z3Z3-E PARA RIBON WIRE
FW253 QUM213-14Z3Z3-E PARA RIBON WIRE
FW256 QJK002-020602-E SIN CL C-B WIRE
FW401 QUM212-08Z3Z3-E PARA RIBON WIRE
FW403 QJK003-040704-E SIN CL C-B WIRE
J4301 QNS0186-001 JACK
J6301 QNS0072-001 HEADPHONE JACK
J7351 QNS0148-001 6.3 JACK
K5101 NQR0288-004X FERRITE BEADS
K5102 NQR0360-001X FERRITE BEADS
K5201 NQR0288-004X FERRITE BEADS
K5202 NQR0360-001X FERRITE BEADS
K7351 QQR0621-001Z FERRATE BEADS
K9001 QQR0621-001Z FERRATE BEADS
K9003 QQR0621-001Z FERRATE BEADS
K9005 NQR0007-002X FERRITE BEADS
S2501 QSW0622-001Z TACT SW
S2502 QSW0622-001Z TACT SW
S2503 QSW0622-001Z TACT SW
S2504 QSW0622-001Z TACT SW
S2505 QSW0622-001Z TACT SW
S2506 QSW0622-001Z TACT SW
S2507 QSW0622-001Z TACT SW
S2508 QSW0622-001Z TACT SW
S2509 QSW0622-001Z TACT SW
S2510 QSW0622-001Z TACT SW
S2512 QSW0622-001Z TACT SW
S2513 QSW0622-001Z TACT SW
S2521 QSW0122-001 PUSH SWITCH
X9001 QAX0401-001 CRYSTAL 32.768KHz
X9002 QAX0416-001Z C RESONATOR 8.000MHz
Part No. Part Name Description Local
Ω
1/16W J
Ω
1/16W J
Power board
Block No. [0][3]
Symbol No.
D1901 D5SBA20-S1 SI DIODE
D1902 6A10E2 SI DIODE
C1901 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1902 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1903 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C1904 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
R1901 QRJ146J-103X UNF C RESISTOR 10kΩ 1/4W J
CN191 QGA2501C1-09 CONNECTOR W-B (1-9)
CN192 QGB2501K1-04 CONNECTOR B-B (1-4)
CN193 QGA2501C1-05 CONNECTOR W-B (1-5)
CN194 QGA7901C1-02 CONNECTOR W-B (1-2)
CN195 QGA3901C1-02 CONNECTOR W-B (1-2)
J1901 QNC0042-001 AC SOCKET
J1902 QNA0016-001 DC JACK
LF191 QQR1321-001 LINE FILTER
WC1 QZW0007-001 POST PIN
Z1902 QNG0020-001Z FUSE CLIP
Z1904 QNG0020-001Z FUSE CLIP
Z1922 QNG0020-001Z FUSE CLIP
Z1944 QNG0020-001Z FUSE CLIP
Part No. Part Name Description Local
CD servo board
Block No. [0][4]
Symbol No.
IC201 BR24L08FV-W-X IC
IC251 MN101C61GNJ IC
IC601 AN22002A-W IC
IC651 MN6627934CH IC
IC671 A42L2604V-45L IC
IC681 SN74AHC1G32DC-X IC
IC682 SN74LV08APW-X IC
IC801 AN4801SB-W IC
Q231 2SC2814/4-5/-X TRANSISTOR
Q232 2SC2814/4-5/-X TRANSISTOR
Q291 2SB1424/QR/-W TRANSISTOR
Q631 2SA1037AK/RS/-X TRANSISTOR
D251 RB521S-30-X SB DIODE
D252 RB521S-30-X SB DIODE
D601 1SS355-X SI DIODE
C201 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C231 NDC31HJ-390X C CAPACITOR 39pF 50V J
C232 NDC31HJ-390X C CAPACITOR 39pF 50V J
C233 NCB31HK-102X C CAPACITOR 1000pF 50V K
C234 NCB31HK-102X C CAPACITOR 1000pF 50V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C259 NDC31HJ-101X C CAPACITOR 100pF 50V J
C291 QERF0JM-226Z E CAPACITOR 22uF 6.3V M
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NDC31HJ-391X C CAPACITOR 390pF 50V J
C606 NDC31HJ-121X C CAPACITOR 120pF 50V J
C609 NDC31HJ-470X C CAPACITOR 47pF 50V J
C610 NCB31CK-563X C CAPACITOR 0.056uF 16V K
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C615 NCB31HK-272X C CAPACITOR 2700pF 50V K
C616 NCB31HK-182X C CAPACITOR 1800pF 50V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C622 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
Part No. Part Name Description Local
3-16
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C623 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C624 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C631 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C632 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C633 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C641 NDC31HJ-101X C CAPACITOR 100pF 50V J
C651 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C652 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C653 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 NCS31HJ-681X C CAPACITOR 680pF 50V J
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C659 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C661 NCB31HK-102X C CAPACITOR 1000pF 50V K
C662 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C664 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C667 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C669 NCB31HK-182X C CAPACITOR 1800pF 50V K
C672 NCB31HK-182X C CAPACITOR 1800pF 50V K
C673 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 NDC31HJ-100X C CAPACITOR 10pF 50V J
C676 NDC31HJ-100X C CAPACITOR 10pF 50V J
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C678 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C681 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C690 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 QERF1AM-227Z E CAPACITOR 220uF 10V M
C802 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C803 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C804 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C805 NCB31HK-222X C CAPACITOR 2200pF 50V K
C806 NCB31HK-152X C CAPACITOR 1500pF 50V K
R231 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R232 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R233 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R234 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R236 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R251 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R253 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R255 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R256 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R258 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R259 NRSA63J-103X MG RESISTOR 10k
R260 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R261 NRSA63J-102X MG RESISTOR 1k
R262 NRSA63J-102X MG RESISTOR 1k
R263 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R264 NRSA63J-102X MG RESISTOR 1k
R265 NRSA63J-103X MG RESISTOR 10k
R266 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R267 NRSA63J-102X MG RESISTOR 1k
R268 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R271 NRSA63J-102X MG RESISTOR 1k
R274 NRSA63J-102X MG RESISTOR 1k
R278 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R289 NRSA63J-102X MG RESISTOR 1k
R293 NRSA63J-473X MG RESISTOR 47k
R294 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R295 NRSA63J-473X MG RESISTOR 47k
R296 NRSA63J-103X MG RESISTOR 10k
R297 NRSA63J-122X MG RESISTOR 1.2k
R298 NRSA63J-103X MG RESISTOR 10k
R601 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R602 NRSA63J-392X MG RESISTOR 3.9k
R603 NRSA63J-393X MG RESISTOR 39k
R604 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0
R606 NRSA63J-0R0X MG RESISTOR 0
R607 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R608 NRSA63J-223X MG RESISTOR 22k
R611 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R613 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R617 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R625 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R631 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R632 NRSA63J-3R9X MG RESISTOR 3.9
R634 NRSA63J-3R9X MG RESISTOR 3.9
R635 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R651 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R653 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R654 NRSA63J-753X MG RESISTOR 75kΩ 1/16W J
R655 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R656 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R657 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R658 NRSA63J-241X MG RESISTOR 240Ω 1/16W J
R659 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R661 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R662 NRSA02J-101X MG RESISTOR 100Ω 1/10W J
R664 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R665 NRSA63J-681X MG RESISTOR 680
R666 NRSA63J-561X MG RESISTOR 560
R667 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R668 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R669 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R671 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R672 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R673 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R674 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R675 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R676 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R678 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R679 NRSA63J-270X MG RESISTOR 27Ω 1/16W J
R681 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R682 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R801 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R802 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R803 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R805 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R806 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R807 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R809 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R811 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R812 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R814 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R815 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R816 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R818 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R830 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R831 NRSA63J-271X MG RESISTOR 270
R832 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R833 NRSA63J-271X MG RESISTOR 270
R834 NRSA63J-271X MG RESISTOR 270
R835 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R836 NRSA63J-271X MG RESISTOR 270
R837 NRSA63J-271X MG RESISTOR 270
R838 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R839 NRSA63J-271X MG RESISTOR 270
R840 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R841 NRSA63J-271X MG RESISTOR 270
R842 NRSA63J-271X MG RESISTOR 270
R843 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R844 NRSA63J-271X MG RESISTOR 270
R845 NRSA63J-271X MG RESISTOR 270
R846 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R847 NRSA63J-271X MG RESISTOR 270
R848 NRSA63J-271X MG RESISTOR 270
CN601 QGF1008F1-16 CONNECTOR FFC/FPC (1-16)
CN603 QGA2501F1-02 CONNECTOR W-B (1-2)
CN651 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
FW602 QJK004-060601-E SIN CL C-B WIRE
K251 NQR0007-002X FERRITE BEADS
K252 NQR0007-002X FERRITE BEADS
K254 NQR0007-002X FERRITE BEADS
K651 QQR0621-001Z FERRATE BEADS
K654 NQR0007-002X FERRITE BEADS
X251 QAX0684-001Z C RESONATOR 8.38MHz
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-17
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
X651 NAX0476-001X CRYSTAL 33.8688MHz
Head amplifier board
Block No. [0][5]
Symbol No.
IC31 BA3126N IC
IC32 AN7317 IC
IC33 BU4094BCF-X IC
Q101 DTC114TKA-X TRANSISTOR
Q102 DTC114TKA-X TRANSISTOR
Q201 DTC114TKA-X TRANSISTOR
Q202 DTC114TKA-X TRANSISTOR
Q301 DTA144EKA-X DIGI TRANSISTOR
Q302 2SC2001/K/-T TRANSISTOR
Q303 2SC2001/K/-T TRANSISTOR
Q304 2SC2001/LK/-T TRANSISTOR
Q305 2SC2001/LK/-T TRANSISTOR
Q306 2SC2412K/RS/-X TRANSISTOR
Q307 2SC2412K/RS/-X TRANSISTOR
Q308 2SC2412K/RS/-X TRANSISTOR
Q309 2SC2412K/RS/-X TRANSISTOR
Q321 DTC144EKA-X DIGI TRANSISTOR
Q323 2SC2412K/RS/-X TRANSISTOR
Q371 2SA952/LK/-T TRANSISTOR
Q372 DTC124EKA-X DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 2SC2412K/RS/-X TRANSISTOR
D301 MA152WA-X DIODE
D309 MA704A-X S.K.DIODE
D375 HZM5.1NB2-X Z DIODE
C101 NCS21HJ-821X C CAPACITOR 820pF 50V J
C102 NCS21HJ-221X C CAPACITOR 220pF 50V J
C103 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C104 NCB21HK-333X C CAPACITOR 0.033uF 50V K
C105 NCB21HK-222X C CAPACITOR 2200pF 50V K
C106 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C107 NCS21HJ-561X C CAPACITOR 560pF 50V J
C108 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 NCB21HK-682X C CAPACITOR 6800pF 50V K
C111 NCB21HK-122X C CAPACITOR 1200pF 50V K
C112 NCB21EK-683X C CAPACITOR 0.068uF 25V K
C113 NCB21HK-222X C CAPACITOR 2200pF 50V K
C121 NCS21HJ-331X C CAPACITOR 330pF 50V J
C201 NCS21HJ-821X C CAPACITOR 820pF 50V J
C202 NCS21HJ-221X C CAPACITOR 220pF 50V J
C203 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C204 NCB21HK-333X C CAPACITOR 0.033uF 50V K
C205 NCB21HK-222X C CAPACITOR 2200pF 50V K
C206 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C207 NCS21HJ-561X C CAPACITOR 560pF 50V J
C208 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 NCB21HK-682X C CAPACITOR 6800pF 50V K
C211 NCB21HK-122X C CAPACITOR 1200pF 50V K
C212 NCB21EK-683X C CAPACITOR 0.068uF 25V K
C213 NCB21HK-222X C CAPACITOR 2200pF 50V K
C221 NCS21HJ-331X C CAPACITOR 330pF 50V J
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C302 NCB21HK-393X C CAPACITOR 0.039uF 50V K
C303 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C304 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C305 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C306 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C307 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C308 NCB21HK-562X C CAPACITOR 5600pF 50V K
C309 NCB21HK-562X C CAPACITOR 5600pF 50V K
Part No. Part Name Description Local
C310 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C311 NCB21HK-682X C CAPACITOR 6800pF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C315 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C316 QFG32AJ-103Z PP CAPACITOR 0.01uF 100V J
C318 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C319 QFG32AJ-821Z PP CAPACITOR 820pF 100V J
C321 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C322 QFG32AJ-152Z PP CAPACITOR 1500pF 100V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C351 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C375 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 NCB21HK-103X C CAPACITOR 0.01uF 50V K
C391 NCB31HK-681X C CAPACITOR 680pF 50V K
R101 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R102 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R103 NRSA63J-242X MG RESISTOR 2.4k
R104 NRSA63J-122X MG RESISTOR 1.2k
R105 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R106 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R107 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R108 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R109 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R110 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R111 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R112 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R113 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R114 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R116 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R121 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R201 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R202 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R203 NRSA63J-242X MG RESISTOR 2.4kΩ 1/16W J
R204 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R205 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R206 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R207 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R208 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R209 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R210 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R211 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R212 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R213 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R214 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R216 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R221 NRSA63J-102X MG RESISTOR 1k
R301 NRS181J-221X MG RESISTOR 220Ω 1/8W J
R303 NRSA63J-393X MG RESISTOR 39k
R304 NRS181J-101X MG RESISTOR 100
R305 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R306 NRSA63J-222X MG RESISTOR 2.2k
R310 NRS181J-560X MG RESISTOR 56
R311 NRS181J-560X MG RESISTOR 56Ω 1/8W J
R313 NRSA63J-3R3X MG RESISTOR 3.3
R314 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R315 NRSA63J-100X MG RESISTOR 10
R316 NRSA63J-223X MG RESISTOR 22k
R317 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R319 NRSA63J-152X MG RESISTOR 1.5k
R322 NRSA63J-152X MG RESISTOR 1.5k
R327 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J
R332 NRSA63J-123X MG RESISTOR 12k
R333 NRSA63J-123X MG RESISTOR 12k
R335 NRSA63J-152X MG RESISTOR 1.5k
R336 NRSA63J-472X MG RESISTOR 4.7k
R337 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R338 NRSA63J-392X MG RESISTOR 3.9k
R339 NRSA63J-222X MG RESISTOR 2.2k
R340 NRS181J-391X MG RESISTOR 390Ω 1/8W J
R341 NRSA63J-123X MG RESISTOR 12k
R342 NRSA63J-203X MG RESISTOR 20k
R343 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R351 NRSA63J-683X MG RESISTOR 68k
R352 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/8W J
Ω
1/16W J
Ω
1/8W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-18
Symbol No.
R371 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R372 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R375 NRSA02J-151X MG RESISTOR 150Ω 1/10W J
R376 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
VR31 QVP0008-503Z TRIM RESISTOR 50k
VR32 QVP0008-503Z TRIM RESISTOR 50k
VR37 QVP0008-103Z TRIM RESISTOR 10k
L301 QQR0620-001 OSC COIL(BIAS)
L303 QQL01BK-100Z COIL 10uH K
CN31 QGF1201F3-06 CONNECTOR FFC/FPC (1-6)
CN32 QGB2011M1-10 CONNECTOR B-B (1-10)
CN33 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN34 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
Part No. Part Name Description Local
Ω
Ω
Ω
Cassette switch board
Block No. [0][6]
Symbol No.
IC1 SG-105F3/Z1/ PHOTO SENSER
D1 1SR139-400-T2 SI DIODE
CN1 QGB2011L1-10 CONNECTOR B-B (1-10)
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW4 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
Part No. Part Name Description Local
3-19
Packing materials and accessories parts list
No additional / supplemental order of WARRANTY CARDs are available
P6
P7
A7
Block No.
M
3
M
M
P1
P4
P2
P8
A1, A2,
A6, A8, A9
A3
A4
P5
P9
A5
P3
3-20
Packing and Accessories
Symbol No. Part No. Part Name Description Local
A 1 LVT1265-003B INST BOOK ENG B
A 1 LVT1265-004B INST BOOK GER,FRE E,EN
A 2 LVT1265-005B INST BOOK DUT E
A 2 LVT1265-006B INST BOOK SWE,FIN,DAN EN
A 3 RM-SRVNB1A REMO-CON UNIT
A 4 ----------------- BATTERY (x2)
A 5 LV35227-001A SHOULDER BELT
A 6 ----------------- WARRANTY CARD BT-54026-1
A 7 QMPP060-183-JD POWER CORD(EU) 1.83m BLACK B
A 7 QMPL060-183-JD POWER CORD(EU) 1.83m BLACK E,EN
A 8 VNA3000-204 REGISTER CARD B
A 9 LVT1265-007B INST BOOK SPA,ITA EN
P 1 LV35228-001A CARTON
P 2 VPH1721-001 BOTTOM(L)
P 3 VPH1721-002 BOTTOM(R)
P 4 VPH1721-007 UPPER (L)
P 5 VPH1721-006 UPPER (R)
P 6 VPK4343-001 CARTON SHEET
P 7 QPA01503503 POLY BAG 15cm x 35cm B
P 7 QPA01202505 POLY BAG 12cm x 25cm E,EN
P 8 QPA02503503P POLY BAG 25cm x 35cm
P 9 QPF16016015 POLY SHEET 160cm x 160cm
Block No. [M][3][M][M]
3-21
Loading...
