JVC MX-C55 User Manual
COMPACT COMPONENT SYSTEM
MX-C55
– Consists of CA-MXC55 and SP-MXC55
CD
FM/AM
USB/AUX
ECO
DISC SKIP
CD3
CD2
CD1
SP-MXC55 SP-MXC55CA-MXC55
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1541-001A
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le
coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
For U.S.A.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC
Rules.These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not approved by JVC could void the user's
authority to operate the equipment.
For U.S.A.
For the main unit:
Declaration of Conformity
Model Number: MX-C55
Trade Name: JVC
Responsible Party: JVC Americas Corp.
Address: 1700 Valley Road, Wayne
New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Caution –– STANDBY/ON button!
Disconnect the mains plug to shut the power off completely (the
STANDBY lamp goes off). When installing the apparatus, ensure
that the plug is easily accessible.
The STANDBY/ON button in any position does not disconnect
the mains line.
• When the unit is on standby, the STANDBY lamp lights red.
• When the unit is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
Attention –– Touche STANDBY/ON !
Déconnectez la fiche d’alimentation secteur pour mettre l’appareil
complètement hors tension (le témoin STANDBY est éteint). Lors
de l’installation de l’appareil, assurez-vous que la fiche soit facilement accessible.
La touche STANDBY/ON , dans n’importe quelle position, ne
déconnecte pas l'appareil du secteur.
• Quand l’appareil est en mode d’attente, le témoin STANDBY
est allumé en rouge.
• Quand l’appareil est sous tension, le témoin STANDBY est
éteint.
L’alimentation peut être télécommandée.
For Canada/pour le Canada
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Section 820-40 of the NEC which provides guidelines for
proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.
G-1
20 kg / 45 lbs.
CAUTION!
To avoid personal injury or accidentally dropping
the unit, have two persons unpack, carry, and install the
unit.
ATTENTION!
Pour éviter toute blessure personnelle ou chute
accidentelle del’appareil, faites déballer, transporter et
installer l’appareil par deux personnes.
[European Union only]
[Union européenne uniquement only]
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the Unit; leave all servicing to qualified
service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when
open. Do not view directly with optical instruments.
IMPORTANT POUR PRODUITS LASER
1. PRODUIT LASER CLASSE 1
2. ATTENTION: N’ouvrez pas le couvercle supérieur. Il n’y a aucune
pièce réparable par l’utilisateur à l’intérieur de l’appareil; confiez
toute réparation à un personnel qualifié.
3. ATTENTION: Rayonnement laser visible et/ou invisible de classe
1M une fois ouvert. Ne pas regarder directement avec des
instruments optiques.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez l’appareil de la manière suivante:
1 Avant:
Bien dégagé de tout objet.
2 Côtés/dessus/dessous:
Assurez-vous que rien ne bloque les espaces indiqués sur le schéma ci-dessous.
3 Dessous:
Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation correcte puisse se faire en le plaçant sur un support d’au
moins dix centimètres de hauteur.
Front view
Face
15 cm
15
/16 in.)
(5
15 cm
15
(5
/16 in.)
1 cm
7
(
/16 in.)
SP-MXC55 SP-MXC55
CA-MXC55
1 cm
(7/16 in.)
15 cm
(5
15
/16 in.)
Ventilateur de refroidissement*
Side view
Côté
Cooling fan*
15 cm
15
(5
/16 in.)
CA-MXC55
15 cm
(5
15
/16 in.)
10 cm
(3
15
/16 in.)
G-2
Introduction
We would like to thank you for purchasing a JVC product.
Before operating this unit, read this manual carefully and thoroughly to
obtain the best possible performance from your unit, and retain this manual
for future reference.
About This Manual
This manual is organized as follows:
• The manual mainly explains operations using the
buttons and controls on the unit. You can also use the
buttons on the remote control if they have the same or
similar names (or marks) as those on the unit.
If operation using the remote control is different from
that using the unit, it is then explained.
• Basic and common information that is the same for many
functions is grouped in one place, and is not repeated in
each procedure. For instance, we do not repeat the
information about turning on/off the unit, setting the
volume, changing the sound effects, and others, which are
explained in the section “Common Operations” on pages 9
to 11.
•The following marks are used in this manual:
Gives you warnings and cautions to prevent
damage or risk of fire/electric shock.
Also gives you information which is not good
for obtaining the best possible performance
from the unit.
Gives you information and hints you should
know.
Power sources
•When unplugging from the wall outlet, always pull the
plug, not the AC power cord.
DO NOT handle the AC power cord with wet
hands.
Moisture condensation
Moisture may condense on the lens inside the unit in the
following cases:
• After starting heating in the room
• In a damp room
• If the unit is brought directly from a cold to a warm place
Should this occur, the unit may malfunction. In this case,
leave the unit turned on for a few hours until the moisture
evaporates, unplug the AC power cord, and then plug it in
again.
Others
• Should any metallic object or liquid fall into the unit,
unplug the unit and consult your dealer before operating
any further.
• If you are not going to operate the unit for an extended
period of time, unplug the AC power cord from the wall
outlet.
Precautions
Installation
• Do not grasp the control knobs when moving or carrying
the unit.
• Install in a place which is level, dry and neither too hot nor
too cold—between 5˚C (41˚F) and 35˚C (95˚F).
• Install the unit in a location with adequate ventilation to
prevent internal heat built-up in the unit.
• Leave sufficient distance between the unit and the TV.
•Keep the speakers away from the TV to avoid interference
with TV.
DO NOT install the unit in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or vibration.
DO NOT disassemble the unit since there are no
user serviceable parts inside.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
1
Contents
Location of the Buttons and Controls....................... 3
Front Panel ................................................................. 3
Remote Control .......................................................... 5
Getting Started............................................................ 6
Unpacking .................................................................. 6
Inserting the Batteries into the Remote Control ......... 6
Connecting Antennas ................................................. 6
Connecting Speakers .................................................. 7
Canceling the Display Demonstration ....................... 8
Common Operations .................................................. 9
Turning On or Off the Power ..................................... 9
Setting the Clock ........................................................ 9
Selecting the Sources ................................................. 9
Adjusting the Volume ............................................... 10
Reinforcing the Bass Sound ..................................... 10
Enjoying the Powerful sound—SOUND TURBO ... 10
Selecting the Sound Modes ...................................... 11
Turning On or Off the Key-touch Tone (BEEP) ...... 11
Listening to the Radio .............................................. 12
Tuning in to a Station—Auto Search ....................... 12
Presetting Stations .................................................... 12
Tuning in to a Preset Station .................................... 12
Playing Back CDs ..................................................... 13
Loading CDs ............................................................ 13
Playing Back CDs—All Disc and One Disc ............ 13
Advanced CD Operations......................................... 15
Changing the MP3/WMA Playback Mode .............. 17
Turning On or Off the Resume Play for MP3/WMA
Disc ..................................................................... 17
Programming the Playing Order of the Tracks
—–Program Play ................................................ 18
Playing at Random—–Random Play ....................... 19
Repeating Tracks or CDs—–Repeat Play ................ 19
Prohibiting Disc Ejection—–Carrousel Lock .......... 19
Playing Back from the External Source ................. 20
Connecting to Your PC. ............................................ 20
Connecting the Other Audio Equipment .................. 21
Using the Timers ....................................................... 22
Using Daily Timer.................................................... 22
Using Sleep Timer.................................................... 23
Maintenance .............................................................. 24
Troubleshooting ........................................................ 25
Specifications............................................................. 26
2
Location of the Buttons and Controls
Be familiar with the buttons and controls on your unit.
Front Panel
ECO
CD
FM/AM
USB/AUX
DISC SKIP
CD3
CD2
CD1
3
Display Window
Continued
1
8 9
7
See pages in the parentheses for details.
Front Panel
1 (power) button/Sandby lamp (9)
2 ECO button (9)
3 Carrousel
4 Display window
5 CD 3 (play) button (9, 14-15, 17-18)
Pressing this button also turns on the unit.
6 FM/AM button (9, 12)
Pressing this button also turns on the unit.
7 USB/AUX button (9, 20-21)
Pressing this button also turns on the unit.
8 PRESET +/–, 4 / ¢
(reverse search/forward search) control (12, 16-17)
9 1 / ¡ (fast rewind/fast forward) buttons (12, 15)
p SURROUND MODE button (11)
q SOUND MODE button (11)
w SOUND TURBO button (10)
e VOL (volume) +/– control (10)
r PHONES jack (10)
t 0 (carrousel open/close) button (13-15, 17-19)
Pressing this button also turns on the unit.
y DISC SKIP button (13, 15, 17)
u Disc number buttons (CD1, CD2 and CD3) (14)
Pressing one of these buttons also turns on the unit.
i 8 (pause) button (15)
o 7 (stop)/BEEP button (11)
; SUBWOOFER +/– buttons (10)
a DEMO button (8)
s USB AUDIO jack (20)
d AUX jack (21)
0!@~=-
4
5 632
Display Window
1 BEEP indicator
2 Timer indicators
•DAILY (daily timer), SLEEP (sleep timer) and
(timer) indicators.
3 Main display
• Shows the source name, frequency, etc.
4 PROGRAM indicator
5 RANDOM indicator
6 REPEAT mode indicators
• REPEAT 1, REPEAT 1 DISC, REPEAT ALL DISC,
ALL DISC and 1 DISC indicators
7 TITLE indicator
8 GROUP indicator
9 TRACK indicator
0 CHAP. (chapter) indicator
- CD No. (CD number) indicators
• The corresponding CD No. lights up when a CD is
loaded on the carrousel.
• The current CD No. flashes.
= S. MODE (sound mode) indicator
~ SURR. (surround) indicator
! Tuner operation indicators
• ST (stereo) and MONO (monaural) indicators
@ Volume level, Subwoofer level, Sound Mode pattern
indicators and Level meter.
4
Remote Control
1
2
3
4
5
6
7
8
9
p
q
w
e
r
t
y
Remote Control
1 CLOCK/TIMER button (9, 22-23)
2 SLEEP button (23)
3 Number buttons (12, 16-18)
4 CANCEL button (9, 18, 23)
u
i
o
;
a
s
d
f
g
h
j
k
5 VOLUME + button (10)
6 4/1 (reverse search/fast reverse) button (9, 12, 15-
17, 19, 22-23)
7 SOUND TURBO button (10)
8 SURROUND MODE button (11)
9 SOUND MODE button (11)
p FM/AM button (9, 12)
Pressing this button also turns on the unit.
q CD 6 (play/pause) button (13-15, 17-18)
Pressing this button also turns on the unit.
w REPEAT button (13, 15, 19)
e PROGRAM button (18)
r FM MODE button (12)
t MP3/WMA MODE button (17)
y Disc number buttons (DISC1, DISC2 and DISC3) (14-15,
18-19)
u STANDBY/ON button (23)
i SET button (9, 12, 18, 22-23)
o 7 (stop) button (13-15, 18-19)
; ¢/¡ (forward search/ fast forward) button (9, 12, 15-
17, 19, 22-23)
a VOLUME – button (10)
s DISPLAY button (9)
d SUBWOOFER LEVEL +/– buttons (10)
f USB/AUX button (9, 20-21)
Pressing this button also turns on the unit.
g RESUME button (17)
h RANDOM button (19)
j BEEP button (11)
k FADE MUTING button (10)
ECO
CD
FM/AM
USB/AUX
DISC SKIP
CD3
CD2
CD1
When using the remote
control, point it at the remote
sensor on the front panel.
5
Getting Started
Continued
Unpacking
After unpacking, check if you have all the following
accessories.
The number in the parentheses indicates the quantity of the
pieces supplied.
• AM loop antenna (1)
• FM antenna (1)
• Remote control (1)
• Batteries (2)
If any is missing, consult your dealer immediately.
Inserting the Batteries into the Remote Control
Insert the batteries—R6P(SUM-3)/AA(15F)—into the remote
control, by matching the polarity (+ and –) on the batteries
with the + and – markings on the battery compartment.
When the remote control can no longer operate the unit,
replace both batteries at the same time.
1
Connecting Antennas
FM antenna
FM antenna (supplied)
1
Connect the FM antenna to the FM [75 Ω]
coaxial terminal.
2
Extend the FM antenna.
3
Fix it in the position which gives you the best
reception, on the wall, etc.
About the supplied FM antenna
The FM antenna supplied with this unit can be used as temporary
measure. If reception is poor, you can connect an outdoor FM
antenna.
To connect an outdoor FM antenna
Before connecting it, disconnect the supplied FM antenna.
2
R6P(SUM-3)/AA(15F)
Outdoor FM antenna
(not supplied)
3
• DO NOT use an old battery together with a new one.
• DO NOT use different types of batteries together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use the
remote control for an extended period of time.
Otherwise, it will be damaged from battery leakage.
A 75 Ω antenna with coaxial type connector should be
used.
6
AM antenna
Connecting Speakers
1
2
AM loop antenna
(supplied)
DO NOT carry the speaker by holding the tube
duct (on the top of the speaker).
1
Speaker cord
(blue/black)
Black
2, 3
Blue
Speaker cord
(blue/black)
Black
1
Connect the AM antenna to the AM terminal
on the rear of the unit.
2
Turn the AM loop antenna until you have the
best reception.
For better reception of both FM and AM
• Make sure the antenna conductors do not touch any other
terminals and connecting cords.
•Keep the antennas away from metallic parts of the unit,
connecting cords, and the AC power cord.
Red
Speaker cord
(red/black)
From right
main
speaker’s
terminals
1
Press and hold the clamp of the speaker
From right
subwoofer’s
terminals
From left
subwoofer’s
terminals
From left
main
speaker’s
terminals
terminal on the rear of the unit.
2
Insert the end of the speaker cord into the
terminal.
Match the colors (polarity): Blue (+) to blue (+) and black
(–) to black (–); red (+) to red (+) and black (–) to black
(–).
3
Release the finger from the clamp.
IMPORTANT:
• Use only speakers with the same speaker impedance as
indicated by the speaker terminals on the rear of the
unit.
• DO NOT connect more than one speaker to one speaker
terminal.
7
Loading...
