JVC MP-XV841US User Manual
Mobile Mini Note PC
MP-XV841US
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No. which is located on the bottom
of the Mobile Mini Note PC. Retain this information for future reference.
Model No.
Serial No.
LET0248-006A
2 EN
Dear Customer,
Thank you for purchasing this Mobile Mini Note PC. Before use, please read the safety information
and precautions contained in the following pages to ensure safe use of this product.
Using This Instruction Manual
It is recommended that you...
... . read thoroughly the Safety Precautions and Safety Instructions that follow. They contain extremely
important information regarding the safe use of this product.
You are recommended to carefully read the cautions on pages 4 through 6 before use.
SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
NOTES:
●
The rating plate (serial number plate) and
safety caution are on the bottom and/or the
back of the main unit.
●
The rating plate (serial number plate) of the
AC Power Adapter is on its bottom.
CAUTIONS:
● Use the JVC BN-LL23 battery pack and, to
recharge it, the provided multi-voltage AC Power
Adapter.
When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all
sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)
No naked flame sources, such as lighted candles, should be placed on the apparatus.
When discarding batteries, environmental problems must be considered and the local rules or laws
governing the disposal of these batteries must be followed strictly.
The apparatus shall not be exposed to dripping or splashing.
Do not use this equipment in a bathroom or places with water.
Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower
vases, potted plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)
This product has a fluorescent lamp that contains a small amount of mercury. It also contains lead in
some components. Disposal of these materials may be regulated in your community due to
environmental considerations.
For disposal or recycling information please contact your local authorities, or the Electronics Industries
Alliance:
<http://www.eiae.org>
When using the AC Power Adapter in areas other than the USA
The provided AC Power Adapter features automatic voltage selection in the AC range from 110 V to
240 V.
EN3
When using the wireless LAN
WARNING
Please heed the warning below.
• Do not turn on the PC’s power in trains, aircraft, hospitals or other places where the use of wireless
LANs is restricted or prohibited. Use in such places may have an adverse effect on the electronic
devices or medical equipment and cause accidents. At present, the policy of airline companies is to
prohibit the use of electronic devices in aircraft at certain stages of a flight (take-off and landing).
This PC is classified as an “electronic device.” For further details, contact the airline companies.
Radio waves emitted from wireless LANs
WARNING
Please heed the warning below.
• Do not use the wireless LAN in trains full of passengers and other crowded locations. Wireless LANs
emit radio waves which can adversely affect pacemakers and other medical devices.
• Do not use the wireless LAN if you are bringing this PC on board an aircraft or into a hospital.
Wireless LANs emit radio waves which may adversely affect measuring instruments and medical
equipment.
• Stop using the wireless LAN in this PC if other equipment is being adversely affected by the wireless
LAN. Wireless LANs emit radio waves which may adversely affect other equipment and cause
accidents triggered by equipment malfunctioning.
4 EN
Battery Packs
The supplied battery pack is
a lithium-ion battery. Before
using the supplied battery
pack or an optional battery
pack, be sure to read the
following cautions:
1. To avoid hazards . . .
.... do not burn.
.... do not short-circuit the terminals.
.... do not modify or disassemble.
.... do not expose the battery to temperatures
exceeding 60°C (140°F), as this may cause the
battery to overheat, explode or catch fire.
.... use only specified chargers.
2. To prevent damage and prolong service life . . .
.... do not subject to unnecessary shock.
.... charge in an environment where temperatures
are within the tolerances shown in the chart
below. This is a chemical reaction type
battery—cooler temperatures impede chemical
reaction, while warmer temperatures can
prevent complete charging.
.... store in a cool, dry place. Extended exposure
to high temperatures will increase natural
discharge and shorten service life.
.... fully charge and then fully discharge the
battery every 6 months when storing the
battery pack over a long period of time.
.... remove from charger or power unit when not
in use, as some machines use current even
when switched off.
NOTES:
●
It is normal for the battery pack to be warm after
charging, or after use.
Temperature Range Specifications
Charging ............. 10°C to 35°C (50°F to 95°F)
Operation ........... 5°C to 35°C (41°F to 95°F)
Storage ............... –20°C to 50°C (–4°F to 122°F)
●
Recharging time is based on room temperature of
20°C (68°F).
●
The lower the temperature, the longer recharging
takes.
Terminals
LCD Screen
1. To prevent damage to the LCD screen,
DO NOT...
.... push it strongly or apply any shocks.
.... place a thing on the LCD screen.
2. To prolong service life...
.... avoid rubbing it with coarse cloth.
3. Be aware of the following phenomena for LCD
screen use.
These are not malfunctions:
•While using the Mobile Mini Note PC, the
surface around the LCD screen and/or the
back of the LCD screen may heat up.
•If you leave power on for a long time, the
surface around the LCD screen becomes hot.
Main Unit
1. For safety, DO NOT...,
.... open the Mobile Mini Note PC’s chassis.
.... disassemble or modify the unit.
.... short-circuit the terminals of the battery pack.
Keep it away from metallic objects when not
in use.
.... allow inflammables, water or metallic objects
to enter the unit.
.... remove the battery pack or disconnect the
power supply while the power is on.
.... leave the battery pack attached when the
Mobile Mini Note PC is not in use.
2. Avoid using the unit...,
.... in places subject to excessive humidity or
dust.
.... in places subject to soot or steam such as
near a cooking stove.
.... in places subject to excessive shock or
vibration.
.... near a television set.
.... near appliances generating strong magnetic
or electric fields (speakers, broadcasting
antennas, etc.).
.... in places subject to extremely high (over
35°C or 95°F) or extremely low (under 5°C or
41°F) temperatures.
3. DO NOT leave the unit...,
.... in places of over 50°C (122°F).
.... in places where humidity is extremely low
(below 35%) or extremely high (above 80%).
.... in direct sunlight.
.... in a closed car in summer.
.... near a heater.
4. To protect the unit, DO NOT...,
.... allow it to become wet.
.... drop the unit or strike it against hard objects.
.... subject it to shock or excessive vibration
during transportation.
.... carry it by holding the LCD screen.
.... swing it excessively when using the hand
strap or the grip.
.... swing the soft case excessively when the
Mobile Mini Note PC is inside it.
How To Handle CD-ROMs
•Take care not to soil or scratch the mirror surface
(opposite to the printed surface). Do not write
anything or put a sticker on either the front or
back surface. If the CD-ROM gets dirty, gently
wipe it with a soft cloth outward from the center
hole using a circular motion.
• Do not use conventional disc cleaners or
cleaning spray.
• Do not bend the CD-ROM or touch its mirror
surface.
• Do not store your CD-ROM in a dusty, hot or
humid environment. Keep it away from direct
sunlight.
EN5
About moisture condensation...
● You have observed that pouring a cold liquid
into a glass will cause drops of water to form on
the glass’ outer surface. This same phenomenon
occurs on the HDD disk and/or the DVD pickup Lense when it is moved from a cool place to
a warm place, after heating a cold room, under
extremely humid conditions or in a place
directly subjected to the cool air from an air
conditioner.
● Moisture on the HDD disk and/or the DVD
pick-up Lense can cause severe damage, and
can lead to internal damage to the Mobile Mini
Note PC itself.
Serious malfunctioning
If malfunctioning occurs, stop using the unit
immediately and consult your local JVC dealer.
The Mobile Mini Note PC is a microcomputercontrolled device. External noise and
interference (from a TV, a radio, etc.) might
prevent it from functioning properly. In such
cases, first disconnect its power supply unit
(battery pack, AC Power Adapter, etc.) and wait
a few minutes and then re-connect it and
proceed as usual from the beginning.
6 EN
Declaration of Conformity
Model Number : MP-XV841US
Tr ade Name : JVC
Responsible party : JVC AMERICAS CORP.
Address : 1700 Valley Road Wayne, N. J. 07470
Telephone Number : 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Change or modifications not approved by the party responsible for compliance could void the user’s
authority to operate the equipment. This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
EN7
CHECKING INVENTORY
Before using your Mobile Mini Note PC (hereinafter Mobile PC), make sure that all of the
following system components have been included in the container.
If you have found any shortage or problem, contact the sales shop.
* The illustrations provided in these instructions may differ in part from the actual products.
•Mobile Mini Note PC
•Modem cable (1.8 meters long)
Lithium-ion battery pack
•BN-LL23E
•AC power adapter
• Telephone adapter •External display cable
•Three Application CD-ROMs
•Dedicated AC cable
•Instruction manual (this book)
•Warranty card
•Two stick caps
•Start Here manual
8 EN
JVC Software License Agreement
Important:
Thank you for purchasing JVC Mobile Mini Note PC (“Product”).
Please carefully read this End-User License Agreement (“Agreement”) before installing or using
JVC original software accompanied with or pre-installed into the Product (“Software”). The right
to use the Software is granted by Victor Company of Japan, Limited (“JVC”) to You only on the
condition that You agree to the following Agreement. If You do not agree to the terms of the
Agreement, you may not use the Software any more. Then, please give the Software with the
Product back to the dealer from whom you bought the Product. HOWEVER, USING THE
PRODUCT OR UNPACKING THE PACKAGED MEDIA CONTAINING THE SOFTWARE INDICATES
YOUR ACCEPTANCE OF THESE TERMS AND CONDITIONS.
END-USER LICENSE AGREEMENT
1. Copyright; Ownership
You acknowledge that all copyrights and other intellectual property rights in the Software as
well as associated materials such as instruction manual and other documents (“Associated
Materials”) are owned by JVC and its licensor, and remain vested in JVC and such licensor.
The Software is protected under the copyright law of Japan and other countries, and related
Conventions.
2. Grant of License
(1) Subject to the conditions of this Agreement, JVC grants to You a non-exclusive right to use
the Software.
(2) You may install and/or use the Software on an HDD or other storage devices incorporated
in the Product only.
(3) You may make a single copy of the Software for the back-up and storage purpose, if a back-
up copy of the Software has not been included with the Product on physical media such as
CD-ROM. You may use such back-up copy solely for the archival purpose.
(4) The terms of this Agreement will apply to any updated Software provided by JVC to You at
JVC’s sole option. Such update will be also deemed as the Software.
3. Restriction
(1) You may not reverse engineer, decompile or disassemble (except to the extent as permitted
by the applicable laws) the Software in any manner.
(2) You may not modify, copy or otherwise dispose of the Software, in whole or in part, other
than as expressly specified in this Agreement.
(3) You have no right to grant a license to use the Software, and may not sell, lease or rent the
Software to any other person for any purpose.
4. Transfer of the Software
Subject to the fulfillment of the following conditions, You may assign the license granted
under this Agreement to other person.
(1) You assign and transfer such other person the Product including the Software, any copy of
the Software contained in the packaged media as well as any Associated Materials, and
then will not possess them.
(2) Such other person as assignee agrees to the Agreement.
5. Limited Warranty
(1) THE SOFTWARE IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND. SHOULD
THERE BE ANY PROBLEM ARISING FROM OR CAUSED BY THE SOFTWARE, YOU
SHOULD SETTLE ALL SUCH PROBLEM AT YOUR OWN COSTS AND RESPONSIBILITIES.
(2) THIS SECTION PROVIDES JVC’S EXCLUSIVE WARRANTY REGARDING THE SOFTWARE.
JVC DOES NOT MAKE ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.
6. Limitation of Liability
JVC WILL HAVE NO LIABILITY WITH RESPECT TO ITS OBLIGATIONS UNDER THIS
AGREEMENT OR OTHERWISE FOR CONSEQUENTIAL, EXEMPLARY, INCIDENTAL OR
PUNITIVE DAMAGES EVEN IF IT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. YOU WILL INDEMNIFY AND HOLD HARMLESS JVC FROM ANY LOSS,
LIABILITY OR COSTS ARISING OUT OF OR IN ANY WAY CONNECTED TO CLAIMS FROM
ANY OTHER PERSONS RELATING TO THE USE OF THE SOFTWARE.
7. Term
This Agreement will become effective on the date when You start to use the Product or You
unpack the packaged media containing the Software, whichever is earlier, and continue to
be in effect until termination under Section 8 below.
8. Termination
(1) Should You breach any provision of this Agreement, JVC may terminate this Agreement
without giving any notice to You. In this event, JVC may claim against You any damages
caused by Your breach.
(2) Should this Agreement be terminated, You should immediately destroy the Software
including any copy (including erasure from any memory in the Product) and any associated
Materials, and then will not possess them.
EN9
9. Export Control
You agree that You will not ship, transfer or export the Software or underlying information
and technology to any countries to which Japan and other relevant countries have embargoed
goods.
10.General
(1) No modification, change, addition, deletion or other alteration of or to the Agreement
will be valid unless reduced to writing and signed by an authorized representative of JVC.
(2) Even if any part of the Agreement is held invalid by or in conflict with any law having
jurisdiction over this Agreement, the remaining provisions will remain in full force and
effect.
(3) To the maximum extent permitted by the applicable law where the Software was acquired,
any conditions or warranties imposed or implied by law are hereby excluded. You may
nevertheless have the benefit of certain rights or remedies pursuant to the applicable law
in respect of which liability may not be excluded. In any case, however, JVC's entire
liability will be limited to those which apply to the Product.
(4) The Agreement shall be governed by and interpreted under the laws of Japan. The Tokyo
District Court has jurisdiction over all disputes which may arise with respect to the
execution, interpretation and performance of this Agreement.
10 EN
END-USER LICENSE AGREEMENT
Important:
Please carefully read this End-User License Agreement (“Agreement”) before installing or using
the G.726 Decoder (“Software”) on your PC. The right to use the Software is granted by Victor
Company of Japan, Limited (“JVC”) to You only on the condition that You agree to the following
Agreement. If You do not agree to the terms of the Agreement, you may not install the Software
any more. HOWEVER, INSTALLING OR USING THE SOFTWARE INDICATES YOUR
ACCEPTANCE OF THESE TERMS AND CONDITIONS. The Software also includes the associated
materials, and any modification, upgrade and update of the Software granted to You by JVC.
1. Copyright; Ownership
You acknowledge that all copyrights and other intellectual property rights in the Software is
owned by, and remain vested in Sharp Corporation, a Japanese corporation, and JVC is the
authorized licensee of Sharp Corporation to duplicate, use and distribute the Software. The
Software is protected under the copyright law of Japan and other countries, and related
Conventions. You must use the Software in the same manner as You use any other copyrighted
work in compliance with these laws and conventions and other regulations.
2. Grant of License
(1) Subject to the conditions of the Agreement, JVC grants to You a non-exclusive right to use
the Software.
(2) You may install and use the Software in Your PC.
(3) You may make a copy of the Software in whole or in part for the back-up and storage
purposes.
3. Restriction
(1) You may not modify, reverse engineer, decompile or disassemble (except to the extent as
permitted by the applicable laws) the Software in any manner.
(2) You may not copy or use the Software, in whole or in part, other than as expressly specified
in this Agreement.
(3) You may not remove the copyright and/or other proprietary rights notice from the Software.
You may make copies of the Software hereunder, provided that each such copy contains
copyright and/or other proprietary rights notice in the same manner as appeared originally
on this Agreement and the Software.
(4) You have no right to grant a license to use the Software, and may not sell, lease or rent the
Software to any other person for any purpose.
4. Transfer of the Software
You may not transfer or assign the Software (either stored in the recording media or not) to any
other person, unless such other person as the transferee or assignee agrees to this Agreement.
Such assignee or transferee will be bound by the same conditions as provided for in this
Agreement, and the license originally granted to You hereunder will then be null and void.
5. Limited Warranty
THE SOFTWARE IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND. JVC DOES
NOT MAKE ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. SHOULD THERE BE ANY PROBLEM ARISING FROM OR CAUSED BY THE
SOFTWARE, YOU SHOULD SETTLE ALL SUCH PROBLEMS AT YOUR OWN COST AND
RESPONSIBILITY.
EN11
6. Limitation of Liability
JVC WILL HAVE NO LIABILITY WITH RESPECT TO ITS OBLIGATIONS UNDER THIS
AGREEMENT OR OTHERWISE FOR CONSEQUENTIAL, EXEMPLARY, INCIDENTAL OR
PUNITIVE DAMAGES EVEN IF IT HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. YOU WILL INDEMNIFY AND HOLD HARMLESS JVC FROM ANY LOSS, LIABILITY
OR COSTS ARISING OUT OF OR IN ANY WAY CONNECTED TO CLAIMS FROM ANY OTHER
PERSONS RELATING TO THE USE OF THE SOFTWARE.
7. Term
This Agreement will become effective on the date when You download and/or install the
Software onto Your machine, and continue to be in effect until termination under the reasons
as below:
Should You breach any provision of this Agreement, JVC may terminate this Agreement without
giving any notice to You. In this event, JVC may claim against You any damages caused by
Your breach. Should this Agreement be terminated, You should immediately destroy the
Software stored in Your machine (including erasure from any memory in Your PC), and then
will not possess such Software.
8. Export Control
You agree that You will not ship, transfer or export the Software or underlying information and
technology to any countries to which Japan and other relevant countries have embargoed
goods.
9. Restricted Rights Legend
The Software including related documentation has been developed at private expense of Sharp
Corporation, and is commercially available.
If the Software is acquired by You under a United States Department of Defense contract, the
use, duplication or disclosure by the Government is subject to the restrictions as set forth in
subparagraph (c)(i)(ii) of the Rights in Technical Data and Computer Software clause at DFARS
252.227-7013. Contractor: Victor Company of Japan, Limited, 12, 3-chome, Moriya-cho,
Kanagawa-ku, Yokohama, Kanagawa 221-8528 Japan.
If the Software is acquired by You as any other agency of the U.S. Government, the use,
duplication, or disclosure by the Government is subject to the restriction as set forth in
subparagraph (g)(3) of FAR 52.227-14 or FAR 52.227-19, as applicable.
10. General
(1) No modification, change, addition, deletion or other alteration of or to the Agreement will
be valid unless reduced to writing and signed by an authorized representative of JVC.
(2) To the maximum extent permitted by the applicable law where the Software was acquired,
any conditions or warranties imposed or implied by law are hereby excluded. You may
nevertheless have the benefit of certain rights or remedies pursuant to the applicable law
in respect of which liability may not be excluded. In any case, however, JVC’s entire
liability will be limited to those which apply to your Mobile Mini Note PC.
(3) Even if any part of the Agreement is held invalid by or in conflict with any law having
jurisdiction over this Agreement, the remaining provisions will remain in full force and
effect.
(4) The Agreement shall be governed by and interpreted under the laws of Japan. The Tokyo
District Court has jurisdiction over all disputes which may arise with respect to the
execution, interpretation and performance of this Agreement.
12 EN
Table of Contents
SAFETY PRECAUTIONS ....................................... 2
SOME DO’S AND DON‘TS ON THE SAFE
USE OF EQUIPMENT .......................................... 3
When using the wireless LAN .............................. 5
Radio waves emitted from
wireless LANs ...................................................... 5
CAUTIONS ......................................................... 6
CHECKING INVENTORY ..................................... 7
JVC Software License Agreement.......................... 8
END-USER LICENSE AGREEMENT ..................... 10
PARTS AND COMPONENT NAMES .................. 13
SETTING UP
SETTING UP ...................................................... 16
TURN-ON ......................................................... 19
Turning (On/Off) Key On ....................... 19
Initial Setup of Microsoft Windows ............... 20
Turn-Off ........................................................ 22
JVC ORIGINAL SOFTWARE AND
SYSTEM APPLICATIONS
JVC ORIGINAL SOFTWARE ............................... 24
Setup of JVC Original Software ...................... 24
CC Converter .................................................. 26
PD-TS decoder ............................................... 28
Easy Network Changer .................................... 29
STANDARD APPLICATION ................................ 31
To Set Up the Standard Applications
Again .............................................................. 33
To Uninstall a Standard Application ................ 33
NAVIGATE IN THE INTERNET WORLD!
TO CONNECT TO THE INTERNET .................... 36
Contracting with the Internet
Service Provider .............................................. 36
Connection of Telephone Line and
Modem Setup ................................................. 37
The Internet Connection Setup ........................ 39
Connecting to the Internet .............................. 44
Disconnection from the Internet ..................... 45
Accessing a Web Page .................................... 46
E-MAILING ........................................................ 47
Setting Up E-Mail Software ............................. 47
Sending and Receiving E-mails ....................... 50
OPERATIONS
Using the Pointing Device ................................. 54
Using Keyboard ................................................. 56
Using the center keys ......................................... 58
Using the DVD/CD function keys ...................... 59
HARDWARE
Using the DVD-ROM & CD-R/RW drive ............ 62
Using the SD Memory Card Slot ........................ 64
Using an External Monitor ................................. 65
Connecting to a Network ................................... 66
Network Connections Using a Wireless LAN ..... 70
Checking the Battery Level ................................. 79
Power-saving Mode ........................................... 80
Increasing the (Optional) Memory Capacity ....... 82
Using the UltraPOST self-diagnosis tool ............. 86
PC RECOVERY (REPEATED PC SETUP)
Setting Up Your PC Again ................................... 88
System Recovery Procedure ............................... 89
TROUBLESHOOTING
Q&A .................................................................. 92
Power ............................................................. 92
Startup and Operation of Windows ................. 93
Display ........................................................... 95
Using the Internet ........................................... 96
Wireless LAN .................................................. 99
Battery .......................................................... 100
DVD-ROM & CD-R/RW drive....................... 101
SD memory cards ......................................... 104
Miscellaneous ............................................... 105
APPENDIX
List of Support Centers .................................. 108
Trademark Notice ......................................... 109
Maintenance .................................................. 110
How to Disposal ............................................ 111
Specification ..................................................112
Wireless LAN Specifications .......................... 113
Options (separately available) ........................114
PARTS AND COMPONENT NAMES
Your Mobile PC has the following parts and components.
Stick
Internal microphone
(used for network meetings, etc.)
Left button
EN13
Speakers
Scroll button
Right button
PC card eject button
Center keys
Wireless LAN
ON/OFF switch
Volume control
Docking port/External
monitor output
Buckle
PC card slot
Eject button
Eject hole
DVD-ROM & CD-R/RW drive
Display panel
(On/Off) Key
Keyboard
DC Input connector (
i-Link connector
DVD/CD function keys
)
LAN connector
USB connectors
Modem jack
14 EN
Built-in lithium-ion
battery pack (BN-LL23E)
Wireless LAN antenna
Ventilation slots
Reset button
SD memory
card slot
Microphone input
Headphone output
1
SETTING UP
EN15
16 EN
SETTING UP
SETTING UP
When you first use your-Mobile PC, always plug the AC power cord into the DC Input connector.
First, install the lithium-ion battery pack in the PC by following the steps below. Proceed with
the setup while the battery pack is charging. To avoid data loss due to power failure or any other
cause, check the points for battery recharging in Page 18.
1. Mounting/Dismounting the Lithium-Ion Battery Pack
• Mounting Battery Pack • Dismounting Battery Pack
Lock lever A
Lock lever B
1 Slide lock lever A in the direction of the arrow
).
(
2 Mount and lock the battery pack until it clicks.
3 Slide lock lever A in the direction of the arrow
).
(
2. Open the display panel
Buckle
1 Slightly pull up the buckle of the Note PC,
and the display panel will be unlocked.
1 Slide lock lever A in the direction of the arrow
(
).
2 Slide and hold lock lever B in the direction of
the arrow (
battery pack in direction 3 as shown.
2 Carefully open the display panel to the desired
angle. You can open the display panel to 180
degrees.
), and pull out and dismount the
EN17
3. Recharge the battery pack by plugging the AC cord into DC Input connector
When recharging the battery pack:
1 Plug the AC power cord into the AC adapter.
2 Plug the DC cord of the adapter into the DC Input connector (
3 Plug the AC cord of the AC adapter into the power receptacle.
1
3
DC cord
) of the Mobile PC.
2
Continue to next page
18 EN
SETTING UP
4. Make sure that the battery pack is fully recharged
To avoid an interruption of your operation due to power failure, check the battery voltage when
you start to use your PC in the field. See “Checking the Battery Level” (see Page 79) to check the
battery voltage level.
• Make sure that the battery pack is fully recharged
When you are using the AC adapter and when the battery indicator (
battery pack is fully (100%) recharged. When it lights in orange, the battery pack is being recharged.
Battery indicator
) lights in green, the
If you have unplugged the DC cable of the AC adapter and if you drive your PC with the lithiumion battery pack, the battery indicator (
Approximate recharging times:
Recharging time
(When the PC’s power is off)
Lithium-ion
battery pack (BN-LL23E)
Cautions
• If the battery pack discharges quickly even after recharging, the battery service life has expired.
Replace it with a new one. (The built-in CMOS backup cells are service parts.)
• The standard recharging times listed above are typical values in an ambient temperature of
20°C to 25°C (68°F to 77°F).
Approximately 180 minutes
) goes out.
Recharging time
(When the PC’s power is on)
Approximately 290 minutes
1 A
TURN-ON
Turning (On/Off) Key On
Press the (On/Off) key.
The PC will turn on and the Windows logo will appear.
Caution
• Tu r n Off the PC (On/Off) key in areas such as hospitals where use of the PC is prohibited.
Otherwise, your PC may influence the electronic and medical equipment and may cause a serious
problem.
At present, most airlines prohibit the use of electronic devices in an airplane according to the flight
condition (taking off and landing) of the aircraft and others. This machine is also grouped in these
electronic devices. Consult each airline for details.
EN19
(On/Off) Key
• Status indicators
Num Lock lamp
1
Caps Lock lamp
A
Scroll Lock lamp
Stand By lamp
DVD-ROM &
CD-R/RW access lamp
SD access lamp
HDD access lamp
Wireless LAN access lamp
When the Num Lock key is active
When the Caps Lock key is active
When the Scroll Lock key is active
When the PC is turned on
When the disc is accessed
When the SD card is accessed
When the HDD is accessed
When wireless LAN is accessed
Caution
Disconnect all peripheral devices (such as a telephone or printer) before pressing the
Off) key for the first time. Otherwise, your PC setup may fail.
Lights up green.
Lights up green.
Lights up green.
Lights up green.
Lights up green.
Lights up green.
Lights up green.
Lights up orange.
(On/
20 EN
SETTING UP
Initial Setup of Microsoft Windows
When using your PC for first time, you must prepare the PC to use Microsoft Windows.
Once you have finished the initial Windows setup, you can use the software and various PC
functions. Use the following procedure to initially set up Microsoft Windows.
For pointing device and keyboard operations, see Pages 54 to 57.
1. When the “Welcome to Microsoft Windows” screen appears, click [Next] at the
right lower corner of the screen.
The “The End User License Agreement” screen will appear.
2. Read the “The End User License Agreement” information and click “Yes, I accept”
option if you accept the agreement. Then, click [Next].
The “What’s your computer’s name?” screen will appear.
Note
If you select the “No, I don’t accept” option, the initial Windows setup is canceled. You
cannot use the Microsoft Windows or the PC software.
3. Rename your computer and click [Next].
The “An Internet connection could not be chosen” or “How will this computer connect to
the Internet?” screen appears.
Tips
A unique computer name is required so that your PC is distinguished from other computers
if you connect your PC to the network. Although the PC is named automatically and shown
in the “Computer name” column, you can change it to a name which is easy to remember.
4. Click [Next].
The “Ready to register with Microsoft?” screen appears.
5. Click “No, not at this time” option, and click [Next].
The “Who will use this computer?” screen may appear.
Tips
If you select “Yes, I’d like to register with Microsoft now” option, you can start online user
registration. For Internet connection setup, see Page 36 “TO CONNECT TO THE INTERNET”
section.
6. Enter the user name and click [Next].
The “Thank you!” screen will appear.
Tips
The name you have entered is shown on the “welcome” screen that appears when you turn
the PC power switch on after initial Windows setup. To start up Microsoft Windows, click
the user name shown on the screen.
7. Click [Finish].
The initial Windows setup has completed.
Cautions
• No guarantees are made for operation if an operating system other than the one already
installed in your PC is installed.
• When a week has passed after initial startup of the Microsoft Windows, a confirmation
screen asking for the deletion of desktop icons appears.
This is the Desktop Cleanup program that can delete icons that you have not used for a
certain period from the desktop screen. The software is not deleted even if you have
cleared its icon from the desktop screen.
• Use the following procedure to change the Windows date and time.
1. Double-click the time display in the task tray at the lower right of the desktop. The
“Date and Time Properties” dialog box appears.
EN21
2. Click the “Time Zone” tab and select your time zone from the list box.
3. Click the “Date & Time” tab and enter the correct date and time.
4. Click “OK” to save your change.
22 EN
SETTING UP
Turn-Off
Cautions
• Check the battery level before turning off the power to ensure that the charge caution screen
will not appear while you are using the PC on the move, interrupting your work. To check the
battery level, refer to "Checking the Battery Level" on page 79.
• Always use this procedure to turn off the PC. Otherwise, your PC may fail.
1. Click [start].
The “start” menu will appear.
2. Click [Turn Off computer].
The “Turn off computer” screen will appear.
3. Click [Turn Off].
The PC will be turned off automatically, and (Stand By) lamp will go out.
Before closing the LCD panel, make sure that
Tips
To restart Windows without turning off the power, click [Restart] on the “Turn off computer”
screen. Alternatively, press the [Shift] button on the keyboard while “Turn off computer”
screen is displayed. The screen below will appear and the PC can be put into [Hibernate].
For details on the [Stand By] and [Hibernate] modes, refer to pages 80 and 81.
(Stand By) lamp has turned off.
2
JVC ORIGINAL SOFTWARE
AND SYSTEM APPLICATIONS
EN 23
24 EN
JVC ORIGINAL SOFTWARE AND SYSTEM APPLICATIONS
JVC ORIGINAL SOFTWARE
To use the JVC original software, you must set it up in the “Setup of JVC Original Software” given
below. You can setup the following software program.
Setup software
• CC converter (See Page 26.)
Tips
• When connecting this PC to a digital video camera (DVC) made by JVC, the USB drivers
must be set up from the CD-ROM that is provided with the DVC.
• For DVC connection and operations, see its instruction manual.
Setup of JVC Original Software
Before starting the software setup, quit and save the currently active application if any. Otherwise,
your working data will be lost.
1. Click [start] and click [Run first] at the right lower end of the Menu.
The “Preparing to Install
2. Read the License Agreement when displayed.
If you accept the Agreement, click [Yes]
...
” screen will appear, and the software setup will start up.
3. During setup, the “Sound, video and game controllers has not passed Windows
Logo testing to verify its compatibility with Windows XP.” message may be displayed.
Ignore it as it does not affect the system operation. Click [Continue Anyway] to
continue software setup.
EN 25
4. When the software has been set up, a prompt for PC restarting appears. Click
[Finish] to restart the PC.
26 EN
JVC ORIGINAL SOFTWARE AND SYSTEM APPLICATIONS
CC Converter
This is a data-band expansion system JVC has developed for audio applications. It reproduces
the timbre of the original sound from high-quality and compressed music data as well.
The CC converter operates as a system filter so that it takes effect regardless of the playback
application.
To make the effect valid or invalid or to change the effect level:
1. Open a shortcut of (CC Converter) icon in the task tray (by clicking the right
mouse button).
About the expansion effect modes
(see next page for details)
About the intensity
(see next page for details)
2. When the menu above appears, click on the desired option.
Cautions
• If you have disabled the effect, the CC Converter icon is shown in monochrome color in the
task tray.
• The actual sound playback may slightly be delayed due to processing of playback data.
Explanation of menu options
• Enable
Makes the CC converter processing valid.
• Disable
Makes the CC converter processing invalid.
EN 27
The following menu options are effective only when you have checked the “Enable”
option.
About the expansion effect modes
One of the following three effect modes can be selected.
Each has its own special characteristics as described below depending on the frequency band
pattern which is to be expanded.
• Harmonic Expansion
Expanding the harmonic components contained in music accentuates the lingering tones
and gives the sound an added brilliance. This mode is particularly suited to vocals and
music made by acoustic instruments. It can have an effect on almost all genres of music,
and it is the mode which is normally used.
• High tone Expansion
Expanding the high-tone components enhances the feeling of the sound’s resolution. It is
particularly suited to hard-sounding types of music made by electronic instruments. With
rock or pop music, you can enjoy a more lively sound.
• All range Expansion
This provides an expansion effect over all the range contained in the music. Since there is
no focus on a particular point to be expanded, the CC converter can have an effect with all
types of music.
About the intensity
One of three menu options can be selected as the intensity level of the effect to be exerted by
the CC converter. It is recommended that you select the level of intensity that matches the size
of the speakers that will reproduce the sound, the performance of the headphones and type of
sound data (compressed or non-compressed).
• More presence
The CC converter functions to have the maximum effect.
The “More presence” level is suited to playing back compressed music data through the
PC’s built-in speakers or other small-sized speakers. With some types of music, the noise
may be accentuated in which case the “Standard” or “More natural” option should be
selected.
• Standard
With the “Standard” level, the CC converter exerts an effect which is suited to listening to
compressed music data through headphones or mini audio components. This is the setting
which is normally used.
• More natural
The CC converter functions to reproduce the original sound with the highest possible fidelity.
The “More natural” level is suited to listening to non-compressed high-quality data through
large-sized speakers.
Set to this mode if the level of noise is so high that it interferes with your listening pleasure
while using headphones
• About CC converter
Shows the CC converter version and other information.
Click [OK] to close the displayed subwindow.
Continue to next page
28 EN
• Exit
Quits the CC converter. The CC converter status you have set at this point is held. If you
wish to restart the CC converter, you can start up the program from the Start menu.
*To change the CC converter setting and save the new status, you must click [Exit]. To restart
the CC converter, click [Start] [ [All Programs] [ [CC Converter] [ [CC Converter].
Tips
•Do not change the sound playback device when you are playing back the sound data (such
as an audio file).
• If you have changed the sound playback device, wait five (5) or more seconds before
playing back the data.
• The CC converter can process two-channel PCM data only. There are cases where the
DVD sound is to be output to an external sound source or where multi-channel data or
data in a non-PCM format is to be sent by a sound device: in these cases, the CC converter
cannot process the data.
• If you play back data having a high noise level, the noise may be emphasized.
• Users other than the computer administrator (even if they have the Administrator’s authority)
may not change the CC converter setup.
JVC ORIGINAL SOFTWARE AND SYSTEM APPLICATIONS
PD-TS decoder
This decoder is designed to capture, using a separate personal computer (Pentium 4, 2 GHz or
faster recommended), the data which has been shot in the GR-PD1 HI-RES. mode or PS50 mode
and play the data using the Windows Media Player 9 of this unit (MP-XV841GB) in a simplified
format, and it is pre-installed.
To uninstall the decoder, select [Add/Remove Programs] and delete it.
•
The installer is included on the application CD-ROM so use the provided CD-ROM if you
•
need to re-install the decoder.
EN 29
Easy Network Changer
The Easy Network Changer is a network setting utility which enables network settings to be
changed easily.
This utility makes it possible to register a multiple number of profiles that define the network
settings for use at home, in the office or other connection locations. When InterLink has been
moved to a different network environment, it allows easy connection to a network by selecting
the corresponding profile.
To start the utility
Double-click the Easy Network Changer
The profile management screen now appears. To register a profile, click [New] and follow the
instructions given by the Wizard. Once a profile has been registered, it can be selected from the
profile management screen and the network settings can be changed. An easy way to change the
network is to click the icon on the task tray and select the profile from the menu which is
then displayed.
icon on the desktop.
The registered profiles are displayed, and the
network is connected by selecting one of these
profiles. (The check mark indicates the profile
which is being used.)
This is used to disconnect the network.
This is used to show the main menu.
This is used to display the help information.
This is used to display the version information.
This is used to exit the Easy Network Changer.
For details on how to use the utility, refer to the utility’s help information.
30 EN
You can create the removable recovery CDs using Bootable CD Creator (BCDC).
1. Click [Start] [ [All Programs] [ [BCDC SE] to start BCDC.
2. Select the writing speed, and press the “Create Recovery Disc” button.
3. The “Once you have successfully created Restore Disc, Create Restore Disc function
is no longer available. Continue?” message now appears. Select “Yes.”
4. The number of CD-R discs required is displayed. When the CD-R discs have been
readied, click “OK.”
5. When the “Please insert a blank disc in the drive.” message appears, insert one of
the CD-R discs into the drive, and press OK.
(The screen on which the blank CD automatic execution is selected may appear. If it
does, cancel it.)
6. Data writing starts, and when the “Please insert a blank disc in the drive.” message
appears from then on, replace the disk.
7. When “Disk creation now completed.” message appears, click “OK.”
JVC ORIGINAL SOFTWARE AND SYSTEM APPLICATIONS
Tip
When a recovery CD which was created by a bootable CD creator is used to initiate recovery, the
recovery area inside the hard drive will be erased.
Loading...
