MP-C33DE-BU
Exploded view, Final part assembly list
32
35
36
29
28
33
34
C
62
37
E
27
31
33
34
B
71
24
8
7
Block No.
17
23
M
16
9
M
12
13
15
2
4
64
64
79
6
9
20
77
3
19
18
20
4
10
73
11
14
15
1
26
22
21
78
A
M
1
67
57
55
C
51
55
57
25
24
8
72
55
55
57
ED
55
59
60
52
54
30
57
55
A
55
57
B
58
53
54
54
25
7
5
9
9
50
56
47
76
65
70
63
61
40
D
65
70
65
70
69
69
39
66
74
63
68
43
45
70
63
46
44
42
41
75
38
65
49
48
3-23-1
MP-C33DE-BU
< MEMO >
MP-C33DE-BU
3-1
MP-C33DE-BU
Final assembly (1/2)
A
Item Parts number Parts name DescriptionPrice(Yen)
1 LE10239-002A LCD PANEL 2560
2 LE40708-001A CAP (BACK) 168
3 QLD0165-001 LCD - *
4 WJZ0069-003A WIRE ASSY
5 QAL0273-001 TOUCH PANEL - *
6 QAL0273-001ASSY
7 LE40739-001A SPACER 168
8 LE40739-003A SPACER 168
9 QYSDSP2004Z SCREW 8
10 LE30862-003A BUCKLE ASSY 392
11 LE40740-001A SPRING 168
12 LE40770-001A SPRING (L) 168
13 LE40723-001A PLATE (L) 168
14 LE40738-001A PLATE (R) 168
15 QYSSSPT2035Z SCREW 8
16 QAL0272-001 INVERTER BOARD 1920
17 QYSSSPT2050N SCREW 8
18 LE40735-001A HINGE ASSY 448
19 LE30863-001A HINGE COVER (1) 168
20 QYSPSPG2005Z SCREW 8
21 LE30864-001A HINGE COVER (2) 168
22 QYSPSPG2005Z SCREW 8
23 LE10238-005A LCD FRONT PANEL 1360
24 LE40737-001A CUSHION 168
25 QYSSSPT2035Z SCREW 8
26 LE40724-001A RING 168
27 LE10241-006A FUNCTION PANEL 672
28 LE30852-001A INDICATOR 168
29 LE30866-001A MIC CAP 168
30 QAN0040-001A MICROPHONE 392
31 LE30877-001A HINGE COVER (R) 168
32 LE30880-001A HINGE COVER (L) 168
33 LE40800-001A SPACER 168
34 QAS0075-001 SPEAKER 392
35 LE30849-001A SHUTTER (PC) 168
36 LE40711-001A SPRING 168
37 LE30850-002A SHUTTER (CF) 168
38 LE10240-002A BOTTOM CASE 2560
39 LE40767-001A SHEET 168
40 LE30878-001A COVER (L) 168
41 LE30879-001A COVER (R) 168
42 QYSSSPT2050N SCREW 8
43 LE30854-001A LOCK LEVER 168
44 LE40718-002A SPRING 168
45 LE30855-001A SLIDE KNOB 168
46 QYSPSGT2040M SCREW 8
47 LE40714-001A SCREEN 168
48 LE40712-001A CAP (USB) 168
49 LE40713-001A CAP
50 LE40710-001A CAP (MODEM) 168
51 QAL0368-001 MOTHER BOARD 20000
LCD-TOUCH PANEL ASSY
(extension connector)
Block No. M1MM
20000
168
The parts that are marked * are not supplied by JVC.
3-2
MP-C33DE-BU
Final assembly (2/2)
A
Item Parts number Parts name Description
52 QAL0367-001 ROM BOARD 7000
53 QAL0373-001 RAM BOARD 3920
54 QYSPSP2003M SCREW 8
55 QYSDSP2004Z SCREW 8
56 QAB0032-001 BATTERY 504
57 LE40777-003A SPACER 168
58 LE40776-001A SPACER 168
59 LE40777-002A SPACER 168
60 LE40777-001A SPACER 168
61 LE40772-001A JACK HOLDER 168
62 QSW0953-001 KEY BOARD ASSY 2560
63 QYSPSP2004N SCREW 8
64 QYSPSPG2005Z SCREW 8
65 QYSPSF2005N SCREW 8
66 QYSSSGT2040N SCREW 8
67 LE30903-002A SHEET 168
68 LE30858-001A ROM COVER 168
69 QYSSSPT2050N SCREW 8
70 LE40715-001A FOOT 168
71 LE30847-003A SIDE FITTING (L) 168
72 LE30848-003A SIDE FITTING (R) 168
73 LE40697-003A PEN ASSY 224
74 LE40781-002A LABEL 168
75 LE40840-002A GASKET 168
76 LE40840-003A GASKET ...
77 LE40840-005A GASKET ...
78 LE40840-004A GASKET ...
79 LE40870-001A COPPER TAPE ...
Block No. M1MM
Price(Yen)
The parts that are marked * are not supplied by JVC.
3-3
MP-C33DE-BU
Packing materials and accessories parts list
21
3
3
6
4
19
17
20
18
13
16
9
12
10
11
15
Block No.
TKK
1
M
2
5
M
78
M
2
14
Accessories parts list
A
Item Parts number Parts name Description
Price(Yen)
1 HQ300185-003 Parts Case 2 QAM0152-001 Line Cord 168
3 QQR0491-001 Noise Filter 392
4 QAM0152-001ASSY
Line cord-Noise Filter Assy
560 Telefon-Anschlusskable
A 5 QAL0364-001 AC Adapter 3480 Netzadapter
6 QAM0388-001 Adapter Plug 392 Telefonadapter
7 QAM0320-001 PC Cord - *
8 QQR1288-001 Ferrite Core - *
9 QAM0320-001ASSY
PC Cord-Ferrite Core Assy 2480 Serielles Kadel
10 QAB0047-001 Battery - *
11 LE40734-001A Foot - *
12 QAB0047-001ASSY Battery-Foot Assy 6930
13 LE31004-002A Microsoft CD 20000
Akku (Spezifischer Lithiumionen-Akku)
Aicrosft ActiveSync3.1CD-ROM
14 LE30826-008A Packing Case - *
15 LE30883-001A Bottom Case Assy - *
16 LE30882-001A Upper Cover - *
17 HQ300182-001A Envelope - *
18 LET0197-001A Inst Book 448 Bedienungsanleitung
19 LE31016-001A Caution Label - *
20 LE40866-001A Envelope - *
21 LE31019-001A EC Sheet -
Block No. M2MM
The parts that are marked * are not supplied by JVC.
3-4
MP-C33DE-BU
Other servicing parts
Parts number Image Parts name Description
QAM0325-001 External display connection
cable (VGA Cable)
Price(Yen)
3920
LCD Touch Panel Ass'y
The LCD-Touch Panel Ass'y is composed of two component parts, the LCD and the Touch Panel. This service
part is supplied as a combination of the two component parts. The LCD and the Touch Panel are not supplied
as individual parts. The assembly of these component parts requires the use of a clean dust-proof room and
special tools such as a dust removal roller. The JVC IT Network Division possesses these facilities and
equipment but does not supply these special tools to the users. Although the cost of the LCD-Touch Panel
Ass'y is usually very high, this assembly is priced at a special low price.
Provided Accessory "Serielles Kabel"
The "Serielles Kabel" provided with the unit is composed of two component parts, PC Code and a Ferrite
Core. Please assemble these parts as described below.
(CAUTION)
How to wind the cable around the ferrite core
The cable should be wound at the side of
on the socket.
PC cord
QAM0320-001
TKK
95±3mm
Ferrite Core
QQR1288-001
The Provided Accessory "Telefon Anschlusskabel"
The "Telefon Anschlusskabel" provided with the unit is composed of two component parts, a Line Cord and a
Noise Filter. Please assemble these parts as described below.
Line cord
QAM0152-001
Noise Filter
QQR0491-001
20mm
Mother Board Ass'y
When ordering a new Mother Board Ass'y, please also forward the defective board to the JVC IT Network
Division. The IT Network Division will repair and recycle the board in order to supply this originally very highcost part at a special low price.
3-5
MP-C33DE-BU
Inquiries
For inquiries about technical questions or those regarding servicing parts supply,
please consult the following:
QUALITY ASSURANCE GRP.
IT NETWORK DIVISION
AV & MULTIMEDIA COMPANY
VICTOR COMPANY OF JAPAN, LIMITED
Telephone: 81-46-278-1889
Facsimile: 81-46-278-2018
Address: 1644, Shimotsuruma, Yamato, Kanagawa 242-8514, Japan
:
3-6
