JVC LT-Z32SX4B, LT-Z32SX4B/A, LT-Z32SX4B/S, LT-Z32SX4S/S Parts List

PARTS LIST

CAUTION

J The parts identified by the  symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the

safety.

J The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.

J P.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.

ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES

RESISTORS CAPACITORS

CR Carbon Resistor C CAP. Ceramic Capacitor

FR Fusible Resistor E CAP. Electrolytic Capacitor

PR Plate Resistor M CAP. Mylar Capacitor

VR Variable Resistor CH CAP. Chip Capacitor

HV R High Voltage Resistor HV CAP. High Voltage Capacitor

MF R Metal Film Resistor MF CAP. Metalized Film Capacitor

MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor

MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor

OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor

CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor

UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor

CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor

CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor

COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor

LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor

CH AL E CAP. Chip Aluminum Electrolytic Capacitor

CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor

CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor

CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor

RESISTORS

FGJ KMNRHZP

±1% ±2% ±5% ±10% ±20% ±30%

+30%

-10%

+50%

-10%

+80%

-20%

+100%

-0%

(No.YA209)3-1

CONTENTS

USING P.W. BOARD & REMOTE CONTROL UNIT .................................................................................................. 3-2

EXPLODED VIEW PARTS LIST ................................................................................................................................. 3-3

EXPLODED VIEW ....................................................................................................................................................... 3-4

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B] .......................................................................................... 3-6

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A) .......................................................... 3-6

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A) .............................................................. 3-10

FRONT CONTROL P.W. BOARD ASS'Y(LCA90351-18B) (SFL-7031A) ........................................................ 3-10

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A) ......................................................... 3-10

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A) ........................................................................ 3-10

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A) ............................................................... 3-12

DIGITAL SIGNAL P.W. BOARD ASS'Y (LCA10428-67B) (SFL-0D305A) ....................................................... 3-12

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A) ................................................................. 3-19

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/A] ..................................................................................... 3-20

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A) ........................................................ 3-20

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A) .............................................................. 3-20

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A) ....................................................... 3-20

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A) ......................................................... 3-20

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A) ........................................................................ 3-20

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A) ............................................................... 3-20

DIGITAL SIGNAL P.W. BOARD ASS'Y (LCA10428-69B) (SFL-0D307A) ...................................................... 3-20

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A) ................................................................. 3-26

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/S, LT-Z32SX4S/S] ........................................................... 3-27

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A) ........................................................ 3-27

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A) .............................................................. 3-27

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A) ....................................................... 3-27

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A) ......................................................... 3-27

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A) ........................................................................ 3-27

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A) ............................................................... 3-27

DIGITAL SIGNAL P.W. BOARD ASS'Y (LCA10428-68B) (SFL-0D306A) ...................................................... 3-27

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A) ................................................................. 3-33

REMOTE CONTROL UNIT PARTS LIST (RM-C1830-1C) ....................................................................................... 3-33

PACKING PARTS LIST ............................................................................................................................................. 3-33

PACKING ................................................................................................................................................................... 3-34

USING P.W. BOARD & REMOTE CONTROL UNIT

P.W.B ASS'Y NAME LT-Z32SX4B LT-Z32SX4B/A LT-Z32SX4B/S LT-Z32SX4S/S

ANALOG SIGNAL P.W.B LCA90350-15B (SFL-1031A)

CONNECTOR P.W.B LCA90353-14A (SFL-4031A)

FRONT CONTROL P.W.B LCA90351-18B (SFL-7031A)

FRONT SENSOR P.W.B LCA90352-18A (SFL-8031A)

POWER P.W.B LCA90348-10D (SFL-9014A)

REGULATOR P.W.B LCA90349-10B (SFL-9114A)

DIGITAL SIGNAL P.W.B LCA10428-67B (SFL-0D305A) LCA10428-69B (SFL-0D307A) LCA10428-68B (SFL-0D306A)

RECEIVER P.W.B

REMOTE CONTROL UNIT

LCA10476-51A (SFL-0F301A)

RM-C1830-1C

←←← ←←← ←←← ←←← ←←← ←←←

←

←←←

3-2(No.YA209)

EXPLODED VIEW PARTS LIST

 Ref.No. Part No. Part Name Description Local

 101 LC12040-001B-U JACK COVER (x2)  102 LC21562-003A-0L RATING LABEL LT-Z32SX4B/A  102 LC21562-002A-0L RATING LABEL LT-Z32SX4B,LT-Z32SX4B/S,LT-Z32SX4S/S  103 LC42090-002A-H LICENSE LABEL

104 LC32748-004A-H OPERATION SHEET 105 LC32749-003A-H OPERATION SHEET

 106 LC41999-002A CAUTION LABEL

 107 LC41967-001C-C STAND ASSY Inc.No.107A/107B

107A 128-023 STAND COVER 107B 128-020 CORD COVER

108 QYSPSPD5014MA SCREW M5 x 14mm(x4) 109 QYSPSPD3016ZA SCREW M3 x 16mm(x2) 110 LC42002-001B STAND SHEET LT-Z32SX4B,LT-Z32SX4B/S 110 LC42002-002B-C STAND SHEET LT-Z32SX4B/A,LT-Z32SX4S/S

 111 LC12039-001B-U REAR COVER

112 LC30599-078A STICK SHEET (x2) LT-Z32SX4B,LT-Z32SX4B/A,LT-Z32SX4B/S 112 LC32864-001A-C STICK SHEET (x2) LT-Z32SX4S/S 113 QYSBSFG4016MA TAP SCREW M4 x 16mm(x7) 114 QYSBSF3010MA TAP SCREW M3 x 10mm(x4) 115 QYSPSPD3008MA SCREW M3 x 8mm

 116 LC32760-001A-HK SERVICE COVER

117 QYSBSF3010MA TAP SCREW M3 x 10mm

 118 QMPK300-170-JC POWER CORD(EU) 1.7m BLACK LT-Z32SX4B  118 QMPG110-170-JC POWER CORD(AST) 1.7m BLACK LT-Z32SX4B/A  118 QMPN260-170-JC POWER CORD(EK) 1.7m BLACK LT-Z32SX4B/S,LT-Z32SX4S/S  119 LC21348-001D-HK POWER CORD HOLDER  120 QQR0491-001 FERRITE CORE LT-Z32SX4B/S,LT-Z32SX4S/S  121 LC21596-001B-HK TERMINAL BASE

122 QNB0036-001 HEX SCREW (x2) 123 QUQ105-5009AE FFC WIRE 50pin 9cm(x2) 124 QUQK12-1906CH FFC WIRE 19pin 6cm

 125 LC32351-011A CONTROL KNOB ASSY

126 QUQ105-4006AL FFC WIRE 40pin 6cm 127 QUQ105-3004AA FFC WIRE 30pin 4cm 128 QUQ105-5004AA FFC WIRE 50pin 4cm

 129 LC32698-002B-HK SIDE BASE  130 QQR0490-001 NOISE FILTER LT-Z32SX4B/S,LT-Z32SX4S/S  131 LC21597-003B-HK TUNER BASE  132 QUB190-12FXHM SIN TWIST WIRE  133 QLD0343-001 LCD PANEL UNIT

134 LC11633-001B SPEAKER BOX 135 QAS0142-001 SPEAKER SP01/SP02(x2) 136 LC42001-001B DUCT SHEET (x2) LT-Z32SX4B,LT-Z32SX4B/S 136 LC42001-002B-C DUCT SHEET (x2) LT-Z32SX4B/A,LT-Z32SX4S/S 137 LC21339-001A-HK DUCT BASE (x2) 138 LC21340-001B-HK DUCT COVER (x2)

 139 LC12036-005B-UK FRONT PANEL ASSY LT-Z32SX4B,LT-Z32SX4B/A  139 LC12036-005A-UK FRONT PANEL ASSY LT-Z32SX4B/S  139 LC12036-006B-UK FRONT PANEL ASSY LT-Z32SX4S/S

140 LC32747-001C-HK SENSOR WINDOW LT-Z32SX4B,LT-Z32SX4B/A,LT-Z32SX4B/S 140 LC32747-002C-HK SENSOR WINDOW LT-Z32SX4S/S 141 LC41901-001C-HK LED LENS 142 LC41852-001A JVC MARK ASSY

 201 LCA90349-10B REGULATOR PWB  202 LCA90348-10D POWER PWB  203 LCA10476-51A RECEIVER PWB  204 LCA90353-14A CONNECTOR PWB  205 LCA90350-15B ANALOG SIGNAL PWB  206 LCA90351-18B FRONT CONTROL PWB  207 LCA90352-18A FRONT SENSOR PWB  208 LCA10428-67B DIGITAL SIGNAL PWB LT-Z32SX4B  208 LCA10428-69B DIGITAL SIGNAL PWB LT-Z32SX4B/A  208 LCA10428-68B DIGITAL SIGNAL PWB LT-Z32SX4B/S,LT-Z32SX4S/S

(No.YA209)3-3

EXPLODED VIEW

113



101

104

201

103

114



115

202



a

114

102



111



120



118

113

106



203



101

116

112

FAN BRACKET

117



105

113

SHIELD COVER [LT-Z32SX4B/S, LT-Z32SX4S/S]

108

109

107A

107B

110



107



131

INSULATOR



206

205



121



125

123



207

119

123

124



122

126



204

RECEIVER PWB BRACKET

127

a

TOP SHIELD CASE [LT-Z32SX4B/S, LT-Z32SX4S/S]

128



129



130

FRONT

SIDE SHIELD CASE [LT-Z32SX4B/S, LT-Z32SX4S/S]



208

3-4(No.YA209)

TOP FRAME



133

BOTTOM FRAME

132



MAIN BASE

134

138

FRONT

141

140



139

135

142

135

136

137

138

137

136

(No.YA209)3-5

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B]



ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)



Ref No. Part No. Part Name Description Local

IC201 TA1370FG-X IC IC301 AN15852A IC IC501 CXA2069Q IC IC502 MM1510XN-X IC IC503 MM1510XN-X IC IC504 MM1510XN-X IC IC711 CXA1875AM-X IC IC801 TB1274AF IC IC802 TC90A69AF-X IC IC902 TA48M033F-X IC IC903 BA90BC0FP-X IC IC6001 NJM2777M-X IC IC6201 PQ20WZ11-X IC IC6521 NJW1137M-W IC IC6551 RC4558D-X IC IC6552 RC4558D-X IC IC6621 LM393DR-X IC IC6661 TDA8925ST/N1 IC

Q301 2SC3837K/NP/-X TRANSISTOR Q302 2SC3837K/NP/-X TRANSISTOR Q303 2SC3837K/NP/-X TRANSISTOR Q307 2SA1530A/QR/-X TRANSISTOR Q402 2SK1374-X MOS FET Q403 2SK1374-X MOS FET Q404 2SK1374-X MOS FET Q405 2SK1374-X MOS FET Q507 2SA1530A/QR/-X TRANSISTOR Q508 2SA1530A/QR/-X TRANSISTOR Q509 2SA1530A/QR/-X TRANSISTOR Q801 2SA1530A/QR/-X TRANSISTOR Q802 2SA1530A/QR/-X TRANSISTOR Q851 2SA1530A/QR/-X TRANSISTOR Q853 2SC3928A/QR/-X TRANSISTOR Q854 2SC3928A/QR/-X TRANSISTOR Q855 2SA1530A/QR/-X TRANSISTOR Q858 2SC3928A/QR/-X TRANSISTOR Q859 2SA1530A/QR/-X TRANSISTOR Q862 2SC3928A/QR/-X TRANSISTOR Q863 2SC3928A/QR/-X TRANSISTOR Q902 2SC3074/OY/-X TRANSISTOR Q2051 UN2226-X DIGI TRANSISTOR Q2052 UN2226-X DIGI TRANSISTOR Q2055 UN2110-X DIGI TRANSISTOR Q6301 2SC3928A/QR/-X TRANSISTOR Q6302 2SC3928A/QR/-X TRANSISTOR Q6421 2SC3928A/QR/-X TRANSISTOR Q6431 2SA1530A/QR/-X TRANSISTOR Q6521 2SC3928A/QR/-X TRANSISTOR Q6522 2SC3928A/QR/-X TRANSISTOR Q6523 2SA1530A/QR/-X TRANSISTOR Q6531 2SC3928A/QR/-X TRANSISTOR Q6532 2SC3928A/QR/-X TRANSISTOR Q6533 2SC3928A/QR/-X TRANSISTOR Q6534 2SA1530A/QR/-X TRANSISTOR Q6538 2SC3928A/QR/-X TRANSISTOR Q6539 2SC3928A/QR/-X TRANSISTOR Q6661 UN2112-X DIGI TRANSISTOR Q6662 2SC3928A/QR/-X TRANSISTOR Q6663 UN2212-X DIGI TRANSISTOR Q6672 2SC3928A/QR/-X TRANSISTOR Q6673 2SA1530A/QR/-X TRANSISTOR

D901 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J D903 PTZ11B-X Z DIODE D904 PTZ6.8B-X Z DIODE D2001 MA8100/M/-X Z DIODE D2002 MA8100/M/-X Z DIODE D2003 MA8100/M/-X Z DIODE D2004 MA8100/M/-X Z DIODE D2005 MA8100/M/-X Z DIODE D2006 MA8100/M/-X Z DIODE D2007 MA8100/M/-X Z DIODE D2008 MA8100/M/-X Z DIODE D2009 MA8100/M/-X Z DIODE D2010 MA8100/M/-X Z DIODE D2011 MA8100/M/-X Z DIODE D2012 MA8100/M/-X Z DIODE D2013 MA8100/M/-X Z DIODE D2014 MA8100/M/-X Z DIODE

Ref No. Part No. Part Name Description Local

D2015 MA8100/M/-X Z DIODE D2016 MA8100/M/-X Z DIODE D2017 MA8100/M/-X Z DIODE D2201 MA8100/M/-X Z DIODE D2202 MA8100/M/-X Z DIODE D2203 MA8100/M/-X Z DIODE D2204 MA8100/M/-X Z DIODE D2205 MA8100/M/-X Z DIODE D2206 MA8100/M/-X Z DIODE D2207 MA8100/M/-X Z DIODE D6001 MA111-X SI DIODE D6002 MA111-X SI DIODE D6201 MA111-X SI DIODE D6431 MA111-X SI DIODE D6432 MA111-X SI DIODE D6433 MA111-X SI DIODE D6501 MA111-X SI DIODE D6502 MA111-X SI DIODE D6503 MA111-X SI DIODE D6504 MA111-X SI DIODE D6601 MA8062/M/-X Z DIODE D6663 MA8033-X Z DIODE D6664 MA111-X SI DIODE D6671 MA8200-X Z DIODE D6672 MA8200-X Z DIODE D6673 MA8200-X Z DIODE D6674 MA8200-X Z DIODE D6681 MA111-X SI DIODE D6682 MA111-X SI DIODE D6683 MA111-X SI DIODE DB201 MA8033-X Z DIODE

C201 NCB31HK-103X C CAPACITOR 0.01uF 50V K C202 NEH71HM-225X E CAPACITOR 2.2uF 50V M C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K C204 NEZ0022-157X E CAPACITOR 150uF 10V M C205 NEH71HM-105X E CAPACITOR 1uF 50V M C206 NCB11CK-105X C CAPACITOR 1uF 16V K C207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C301 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C302 NEH71CM-476X E CAPACITOR 47uF 16V M C303 NRSA02J-221X MG RESISTOR 220Ω 1/10W J C304 NRSA02J-221X MG RESISTOR 220Ω 1/10W J C305 NRSA02J-221X MG RESISTOR 220Ω 1/10W J C306 NDC31HJ-560X C CAPACITOR 56pF 50V J C307 NDC31HJ-560X C CAPACITOR 56pF 50V J C308 NDC31HJ-560X C CAPACITOR 56pF 50V J C309 NCB31HK-103X C CAPACITOR 0.01uF 50V K C310 NCB31HK-103X C CAPACITOR 0.01uF 50V K C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K C314 NCB31HK-103X C CAPACITOR 0.01uF 50V K C315 NCB31HK-103X C CAPACITOR 0.01uF 50V K C316 NCB11CK-105X C CAPACITOR 1uF 16V K C317 NCB31HK-103X C CAPACITOR 0.01uF 50V K C318 NCB31HK-103X C CAPACITOR 0.01uF 50V K C319 NEH71CM-476X E CAPACITOR 47uF 16V M C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K C321 NEH71CM-106X E CAPACITOR 10uF 16V M C322 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C323 QETM1AM-228 E CAPACITOR 2200uF 10V M C324 NCB11CK-105X C CAPACITOR 1uF 16V K C325 NCB11CK-105X C CAPACITOR 1uF 16V K C326 NCB11CK-105X C CAPACITOR 1uF 16V K C327 NCB11CK-105X C CAPACITOR 1uF 16V K C328 NCB11CK-105X C CAPACITOR 1uF 16V K C329 NCB11CK-105X C CAPACITOR 1uF 16V K C330 NCB11CK-105X C CAPACITOR 1uF 16V K C341 NCB31HK-103X C CAPACITOR 0.01uF 50V K C342 NCB31HK-103X C CAPACITOR 0.01uF 50V K C344 NCB31HK-103X C CAPACITOR 0.01uF 50V K C345 NCB31HK-103X C CAPACITOR 0.01uF 50V K C349 NEN51EM-106X BP E CAPACITOR 10uF 25V M C372 NCB31CK-104X C CAPACITOR 0.1uF 16V K C382 NCB31CK-104X C CAPACITOR 0.1uF 16V K C392 NCB31CK-104X C CAPACITOR 0.1uF 16V K C501 NEH71CM-476X E CAPACITOR 47uF 16V M C502 NEH71CM-476X E CAPACITOR 47uF 16V M C503 NEN51EM-106X BP E CAPACITOR 10uF 25V M C505 NEN51EM-106X BP E CAPACITOR 10uF 25V M C506 NDC31HJ-270X C CAPACITOR 27pF 50V J C515 NCB11CK-105X C CAPACITOR 1uF 16V K C516 NEH71CM-106X E CAPACITOR 10uF 16V M C518 NEH71AM-107X E CAPACITOR 100uF 10V M C519 NEH71CM-106X E CAPACITOR 10uF 16V M

3-6(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C520 NCB11CK-105X C CAPACITOR 1uF 16V K C521 NEH71CM-106X E CAPACITOR 10uF 16V M C522 NEH71AM-107X E CAPACITOR 100uF 10V M C523 NEH71CM-106X E CAPACITOR 10uF 16V M C524 NCB11CK-105X C CAPACITOR 1uF 16V K C525 NEH71CM-106X E CAPACITOR 10uF 16V M C526 NEH71AM-107X E CAPACITOR 100uF 10V M C527 NEH71CM-106X E CAPACITOR 10uF 16V M C541 NCB31HK-103X C CAPACITOR 0.01uF 50V K C542 NCB31HK-103X C CAPACITOR 0.01uF 50V K C543 NCB31HK-103X C CAPACITOR 0.01uF 50V K C544 NCB31HK-103X C CAPACITOR 0.01uF 50V K C545 NCB31HK-103X C CAPACITOR 0.01uF 50V K C711 NEH71CM-106X E CAPACITOR 10uF 16V M C712 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C801 NCB31HK-104X C CAPACITOR 0.1uF 50V K C802 NCB31HK-104X C CAPACITOR 0.1uF 50V K C803 NCB31HK-104X C CAPACITOR 0.1uF 50V K C804 NEH71CM-476X E CAPACITOR 47uF 16V M C805 NCB31HK-103X C CAPACITOR 0.01uF 50V K C806 NCB31HK-103X C CAPACITOR 0.01uF 50V K C807 NEH71CM-476X E CAPACITOR 47uF 16V M C808 NCB31HK-103X C CAPACITOR 0.01uF 50V K C809 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C813 NEH71CM-476X E CAPACITOR 47uF 16V M C814 NCB31HK-103X C CAPACITOR 0.01uF 50V K C818 NEH71HM-106X E CAPACITOR 10uF 50V M C819 NDC31HJ-100X C CAPACITOR 10pF 50V J C820 NCB31AK-474X C CAPACITOR 0.47uF 10V K C821 NCB31HK-103X C CAPACITOR 0.01uF 50V K C822 NCB11CK-225X C CAPACITOR 2.2uF 16V K C823 NCB31HK-153X C CAPACITOR 0.015uF 50V K C824 NCB31HK-103X C CAPACITOR 0.01uF 50V K C825 NDC31HJ-180X C CAPACITOR 18pF 50V J C826 NEH71EM-226X E CAPACITOR 22uF 25V M C827 NEH70JM-107X E CAPACITOR 100uF 6.3V M C835 NCB31HK-103X C CAPACITOR 0.01uF 50V K C850 NDC31HJ-180X C CAPACITOR 18pF 50V J C851 NDC31HJ-560X C CAPACITOR 56pF 50V J C852 NDC31HJ-560X C CAPACITOR 56pF 50V J C853 NEH71CM-476X E CAPACITOR 47uF 16V M C854 NCB31HK-104X C CAPACITOR 0.1uF 50V K C855 NCB31HK-103X C CAPACITOR 0.01uF 50V K C856 NCB31HK-103X C CAPACITOR 0.01uF 50V K C857 NCB31HK-103X C CAPACITOR 0.01uF 50V K C858 NCB31HK-103X C CAPACITOR 0.01uF 50V K C859 NCB31AK-474X C CAPACITOR 0.47uF 10V K C860 NCB31HK-103X C CAPACITOR 0.01uF 50V K C861 NDC31HJ-681X C CAPACITOR 680pF 50V J C862 NCB31HK-104X C CAPACITOR 0.1uF 50V K C863 NCB31HK-103X C CAPACITOR 0.01uF 50V K C864 NCB31HK-103X C CAPACITOR 0.01uF 50V K C865 NDC31HJ-560X C CAPACITOR 56pF 50V J C866 NDC31HJ-560X C CAPACITOR 56pF 50V J C868 NCB31HK-104X C CAPACITOR 0.1uF 50V K C869 NDC31HJ-560X C CAPACITOR 56pF 50V J C870 NDC31HJ-560X C CAPACITOR 56pF 50V J C872 NCB31HK-104X C CAPACITOR 0.1uF 50V K C873 NDC31HJ-330X C CAPACITOR 33pF 50V J C874 NDC31HJ-150X C CAPACITOR 15pF 50V J C875 NDC31HJ-100X C CAPACITOR 10pF 50V J C876 NCB31HK-103X C CAPACITOR 0.01uF 50V K C877 NCB31HK-103X C CAPACITOR 0.01uF 50V K C878 NCB31HK-104X C CAPACITOR 0.1uF 50V K C879 NCB31HK-104X C CAPACITOR 0.1uF 50V K C880 NEH71AM-107X E CAPACITOR 100uF 10V M C881 NEH71AM-107X E CAPACITOR 100uF 10V M C882 NCB31HK-103X C CAPACITOR 0.01uF 50V K C883 NCB31HK-103X C CAPACITOR 0.01uF 50V K C884 NEH71AM-107X E CAPACITOR 100uF 10V M C885 NEH71AM-107X E CAPACITOR 100uF 10V M C886 NEH71HM-106X E CAPACITOR 10uF 50V M C887 NCB31HK-104X C CAPACITOR 0.1uF 50V K C888 NEH71AM-107X E CAPACITOR 100uF 10V M C889 NEH71HM-106X E CAPACITOR 10uF 50V M C890 NEH71HM-106X E CAPACITOR 10uF 50V M C891 NEH71CM-476X E CAPACITOR 47uF 16V M C892 NDC31HJ-180X C CAPACITOR 18pF 50V J C894 NDC31HJ-180X C CAPACITOR 18pF 50V J C895 NDC31HJ-680X C CAPACITOR 68pF 50V J C904 NCB11AK-106X C CAPACITOR 10uF 10V K C905 NEHM1CM-476X E CAPACITOR 47uF 16V M C906 NEHM1CM-476X E CAPACITOR 47uF 16V M C912 NEHM1CM-476X E CAPACITOR 47uF 16V M C913 NEX51CM-335X E CAPACITOR 3.3uF 16V M C914 NEX50JM-156X E CAPACITOR 15uF 6.3V M C915 NEHM1CM-476X E CAPACITOR 47uF 16V M

C916 NEX50JM-156X E CAPACITOR 15uF 6.3V M C2001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C2003 NCB31CK-105X C CAPACITOR 1uF 16V K C2005 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2006 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2007 NCB31HK-103X C CAPACITOR 0.01uF 50V K C2009 NCB31CK-105X C CAPACITOR 1uF 16V K C2011 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2012 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2014 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2015 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2016 NCB11AK-106X C CAPACITOR 10uF 10V K C2017 NCB11AK-106X C CAPACITOR 10uF 10V K C2018 NCB11AK-106X C CAPACITOR 10uF 10V K C2019 NCB11AK-106X C CAPACITOR 10uF 10V K C2020 NCB11AK-106X C CAPACITOR 10uF 10V K C2051 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2052 NCB11CK-225X C CAPACITOR 2.2uF 16V K C2055 NCB31CK-105X C CAPACITOR 1uF 16V K C2201 NCB31CK-105X C CAPACITOR 1uF 16V K C2202 NCB31CK-105X C CAPACITOR 1uF 16V K C2203 NCB31CK-105X C CAPACITOR 1uF 16V K C2204 NCB31CK-105X C CAPACITOR 1uF 16V K C2205 NCB31CK-105X C CAPACITOR 1uF 16V K C2206 NCB31CK-105X C CAPACITOR 1uF 16V K C2241 NCB31CK-105X C CAPACITOR 1uF 16V K C2242 NCB31CK-105X C CAPACITOR 1uF 16V K C2243 NCB31CK-105X C CAPACITOR 1uF 16V K C6001 NCF31AZ-105X C CAPACITOR 1uF 10V Z C6002 NCF31AZ-105X C CAPACITOR 1uF 10V Z C6003 NEH71AM-107X E CAPACITOR 100uF 10V M C6004 NEH71AM-107X E CAPACITOR 100uF 10V M C6005 NEH71HM-105X E CAPACITOR 1uF 50V M C6006 NEH71HM-105X E CAPACITOR 1uF 50V M C6007 QETM1CM-477 E CAPACITOR 470uF 16V M C6008 NEH71HM-106X E CAPACITOR 10uF 50V M C6009 NCF31AZ-105X C CAPACITOR 1uF 10V Z C6201 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6202 NEH71EM-336X E CAPACITOR 33uF 25V M C6203 NEH71EM-336X E CAPACITOR 33uF 25V M C6204 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6205 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6301 NEN51CM-475X BP E CAPACITOR 4.7uF 16V M C6302 NEN51CM-475X BP E CAPACITOR 4.7uF 16V M C6421 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6431 NEH71CM-476X E CAPACITOR 47uF 16V M C6505 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6510 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6517 NDC31HJ-100X C CAPACITOR 10pF 50V J C6518 NDC31HJ-100X C CAPACITOR 10pF 50V J C6521 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6522 NCB31HK-332X C CAPACITOR 3300pF 50V K C6523 NCB31HK-333X C CAPACITOR 0.033uF 50V K C6525 NCB31HK-472X C CAPACITOR 4700pF 50V K C6526 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6527 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6528 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6529 NCB31HK-332X C CAPACITOR 3300pF 50V K C6530 NCB31HK-333X C CAPACITOR 0.033uF 50V K C6532 NCB31HK-472X C CAPACITOR 4700pF 50V K C6533 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6534 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6535 NEH71HM-105X E CAPACITOR 1uF 50V M C6536 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6537 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6538 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6539 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6540 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6541 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6542 NEH71EM-475X E CAPACITOR 4.7uF 25V M C6543 NEH71CM-476X E CAPACITOR 47uF 16V M C6544 NEH71HM-105X E CAPACITOR 1uF 50V M C6545 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6546 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6551 NEH71HM-105X E CAPACITOR 1uF 50V M C6552 NEH71HM-105X E CAPACITOR 1uF 50V M C6553 NCB31CK-683X C CAPACITOR 0.068uF 16V K C6554 NCB31CK-683X C CAPACITOR 0.068uF 16V K C6555 NCB31CK-683X C CAPACITOR 0.068uF 16V K C6556 NCB31CK-683X C CAPACITOR 0.068uF 16V K C6557 NEH71CM-476X E CAPACITOR 47uF 16V M C6559 NEH71CM-476X E CAPACITOR 47uF 16V M C6561 NEH71HM-105X E CAPACITOR 1uF 50V M C6562 NEH71HM-225X E CAPACITOR 2.2uF 50V M C6563 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6564 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6567 NCB11EK-105X C CAPACITOR 1uF 25V K

(No.YA209)3-7



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C6568 NCB11EK-105X C CAPACITOR 1uF 25V K C6585 NEH71CM-106X E CAPACITOR 10uF 16V M C6586 NEH71CM-106X E CAPACITOR 10uF 16V M C6601 NDC31HJ-101X C CAPACITOR 100pF 50V J C6602 NDC31HJ-101X C CAPACITOR 100pF 50V J C6605 NEH71CM-476X E CAPACITOR 47uF 16V M C6621 NCB31HK-332X C CAPACITOR 3300pF 50V K C6622 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6623 NEH71EM-226X E CAPACITOR 22uF 25V M C6624 NCB31HK-222X C CAPACITOR 2200pF 50V K C6625 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6626 NCB31HK-222X C CAPACITOR 2200pF 50V K C6627 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6628 NEH71EM-226X E CAPACITOR 22uF 25V M C6629 NCB31HK-222X C CAPACITOR 2200pF 50V K C6630 NCB31EK-104X C CAPACITOR 0.1uF 25V K C6631 NCB31HK-222X C CAPACITOR 2200pF 50V K C6632 NCB31HK-332X C CAPACITOR 3300pF 50V K C6661 NCB11EK-105X C CAPACITOR 1uF 25V K C6662 NCB11EK-105X C CAPACITOR 1uF 25V K C6663 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6664 QETM1HM-226 E CAPACITOR 22uF 50V M C6665 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6666 QETM1HM-226 E CAPACITOR 22uF 50V M C6667 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6668 NDC31HJ-561X C CAPACITOR 560pF 50V J C6669 QFV21HJ-224 MF CAPACITOR 0.22uF 50V J C6670 QFVE1HJ-474 MF CAPACITOR 0.47uF 50V J C6671 NCB31HK-153X C CAPACITOR 0.015uF 50V K C6672 QETM1EM-477 E CAPACITOR 470uF 25V M C6673 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6674 QETM1EM-477 E CAPACITOR 470uF 25V M C6675 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6676 NDC31HJ-561X C CAPACITOR 560pF 50V J C6677 NDC31HJ-561X C CAPACITOR 560pF 50V J C6678 QFV21HJ-224 MF CAPACITOR 0.22uF 50V J C6679 QFVE1HJ-474 MF CAPACITOR 0.47uF 50V J C6680 NCB31HK-153X C CAPACITOR 0.015uF 50V K C6681 NDC31HJ-561X C CAPACITOR 560pF 50V J C6682 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6683 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6684 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6685 QETM1EM-477 E CAPACITOR 470uF 25V M C6687 QETM1EM-477 E CAPACITOR 470uF 25V M C6688 NCB31HK-104X C CAPACITOR 0.1uF 50V K C6691 NEH71HM-106X E CAPACITOR 10uF 50V M C6692 NEH71CM-106X E CAPACITOR 10uF 16V M C6693 QETM1CM-477 E CAPACITOR 470uF 16V M CB501 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB502 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB503 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB504 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB505 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB506 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB507 NCB31HK-103X C CAPACITOR 0.01uF 50V K CB508 NCB31HK-103X C CAPACITOR 0.01uF 50V K

R201 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R202 NRSA63J-0R0X MG RESISTOR 0 R203 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R204 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R207 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R208 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R210 NRSA63J-0R0X MG RESISTOR 0 R211 NRSA63J-222X MG RESISTOR 2.2k R212 NRSA63J-103X MG RESISTOR 10k R214 NRSA63J-101X MG RESISTOR 100 R216 NRSA63J-101X MG RESISTOR 100 R218 NRSA63J-0R0X MG RESISTOR 0 R219 NRSA63J-0R0X MG RESISTOR 0 R220 NRSA63J-472X MG RESISTOR 4.7k R302 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R303 NRSA63J-0R0X MG RESISTOR 0 R307 NRSA63J-0R0X MG RESISTOR 0 R308 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R316 NRSA63J-0R0X MG RESISTOR 0 R317 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R318 NRSA63J-0R0X MG RESISTOR 0 R321 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R322 NRSA63J-0R0X MG RESISTOR 0 R323 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R326 NRSA63J-0R0X MG RESISTOR 0 R327 NRSA63J-0R0X MG RESISTOR 0 R328 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R334 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R335 NRSA63J-222X MG RESISTOR 2.2k R336 NRSA63J-562X MG RESISTOR 5.6k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R372 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R374 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R375 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R382 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R384 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R385 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R392 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R394 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R395 NRSA63J-470X MG RESISTOR 47Ω 1/16W J R402 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R403 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R404 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R405 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R409 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R410 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R513 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R514 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R516 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R517 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R518 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R519 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R520 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R521 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R522 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R523 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R524 NRSA63J-221X MG RESISTOR 220 R526 NRSA63J-0R0X MG RESISTOR 0 R527 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R528 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R529 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R530 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R531 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R532 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R533 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R534 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R538 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R539 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R540 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R541 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R573 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R574 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R575 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R576 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R577 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R578 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R579 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R580 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R581 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R582 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R583 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R584 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R711 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R713 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R714 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R715 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R716 NRSA63J-101X MG RESISTOR 100 R717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R718 NRSA63J-101X MG RESISTOR 100 R719 NRSA63J-103X MG RESISTOR 10k R720 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R722 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R801 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R802 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R803 NRSA63J-332X MG RESISTOR 3.3k R804 NRSA63J-222X MG RESISTOR 2.2k R805 NRSA63J-222X MG RESISTOR 2.2k R806 NRSA63J-332X MG RESISTOR 3.3k R807 NRSA63J-752X MG RESISTOR 7.5k R808 NRSA63J-101X MG RESISTOR 100 R809 NRSA63J-101X MG RESISTOR 100 R816 NRSA63J-273X MG RESISTOR 27k R817 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R818 NRSA63J-332X MG RESISTOR 3.3k R819 NRSA63J-103X MG RESISTOR 10k R851 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R852 NRSA63J-391X MG RESISTOR 390 R853 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R854 NRSA63J-822X MG RESISTOR 8.2k R855 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R856 NRSA63J-105X MG RESISTOR 1M R859 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R860 NRSA63J-101X MG RESISTOR 100 R861 NRSA63J-101X MG RESISTOR 100 R862 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R863 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R864 NRSA63J-391X MG RESISTOR 390 R865 NRSA63J-391X MG RESISTOR 390

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-8(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R866 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R867 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R869 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R873 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R874 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R876 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R877 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R879 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R883 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R884 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R885 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J R886 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R887 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R888 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R889 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R893 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R907 NRS12BJ-0R0W MG RESISTOR 0Ω 1/2W J R908 NRS12BJ-471W MG RESISTOR 470Ω 1/2W J R2001 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2002 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2003 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2004 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R2005 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R2006 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2007 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2008 NRSA63J-750X MG RESISTOR 75 R2009 NRSA63J-224X MG RESISTOR 220k R2010 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R2011 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2012 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R2013 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R2051 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2052 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R2053 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R2054 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R2055 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R2058 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R2059 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R2060 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R2061 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R2062 NRSA63J-391X MG RESISTOR 390Ω 1/16W J R2065 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R2066 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R2069 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R2071 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J R2202 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2203 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2204 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2205 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R2207 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2208 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2209 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2241 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2242 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2243 NRSA63J-750X MG RESISTOR 75Ω 1/16W J R2245 NRSA63J-331X MG RESISTOR 330 R2246 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R6001 NRSA63J-223X MG RESISTOR 22k R6002 NRSA63J-223X MG RESISTOR 22k R6003 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6004 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R6005 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R6006 QRL039J-330 OMF RESISTOR 33Ω 3W J R6201 NRSA63J-562X MG RESISTOR 5.6k R6202 NRSA63J-182X MG RESISTOR 1.8k R6203 NRSA63J-183X MG RESISTOR 18k R6204 NRSA63J-562X MG RESISTOR 5.6k R6205 NRSA63J-473X MG RESISTOR 47k R6301 NRSA63J-0R0X MG RESISTOR 0 R6302 NRSA63J-0R0X MG RESISTOR 0 R6303 NRSA63J-103X MG RESISTOR 10k R6304 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6305 NRSA63J-102X MG RESISTOR 1k R6306 NRSA63J-101X MG RESISTOR 100 R6307 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6308 NRSA63J-103X MG RESISTOR 10k R6309 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6310 NRSA63J-101X MG RESISTOR 100 R6409 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6423 NRSA63J-332X MG RESISTOR 3.3k R6424 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6425 NRSA63J-222X MG RESISTOR 2.2k R6431 NRSA63J-563X MG RESISTOR 56k R6432 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6515 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R6516 NRSA63J-223X MG RESISTOR 22k R6517 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R6518 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R6519 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R6520 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6521 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6522 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6523 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6524 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6525 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6526 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6527 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6528 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6529 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6530 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6531 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6532 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6533 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6534 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6535 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6536 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6537 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6538 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6539 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6540 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6541 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6542 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6543 NRSA63J-222X MG RESISTOR 2.2k R6551 NRSA63J-153X MG RESISTOR 15k R6552 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R6553 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R6554 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R6555 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R6556 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R6557 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R6558 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J R6559 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R6560 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J R6563 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R6564 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6567 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J R6568 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6569 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J R6577 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R6578 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R6579 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J R6580 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R6601 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6602 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6603 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6605 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6606 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R6607 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6617 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R6621 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6622 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6623 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R6624 QRJ149J-102 UNF C RESISTOR 1k R6625 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6626 NRSA63J-152X MG RESISTOR 1.5k R6627 NRSA63J-104X MG RESISTOR 100k R6629 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R6630 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R6631 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6632 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R6633 NRSA63J-151X MG RESISTOR 150 R6634 NRSA63J-103X MG RESISTOR 10k R6661 NRSA63J-102X MG RESISTOR 1k R6662 NRSA63J-102X MG RESISTOR 1k R6663 NRSA63J-393X MG RESISTOR 39k R6664 NRSA63J-0R0X MG RESISTOR 0 R6665 NRSA63J-393X MG RESISTOR 39k R6666 QRK129J-5R6 UNF C RESISTOR 5.6 R6667 QRK129J-220 UNF C RESISTOR 22Ω 1/2W J R6668 QRK129J-5R6 UNF C RESISTOR 5.6 R6669 QRK129J-220 UNF C RESISTOR 22 R6670 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R6671 NRSA63J-103X MG RESISTOR 10k R6673 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R6674 NRSA63J-102X MG RESISTOR 1k R6675 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R6676 NRSA63J-102X MG RESISTOR 1k R6677 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6680 NRSA63J-103X MG RESISTOR 10k R6681 NRSA63J-563X MG RESISTOR 56k R6682 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R6683 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6684 NRSA63J-104X MG RESISTOR 100k R6685 NRSA63J-563X MG RESISTOR 56k

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/2W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-9



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R6686 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R6688 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6691 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J RB203 NRSA63J-271X MG RESISTOR 270Ω 1/16W J RB801 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

L201 NQL914K-101X COIL 100uH K L807 NQR0413-003X FERRITE BEADS L808 NQR0413-003X FERRITE BEADS L809 NQR0413-003X FERRITE BEADS L851 NQL092K-6R8X P COIL 6.8uH K L852 NQL092K-6R8X P COIL 6.8uH K L853 NQL092K-6R8X P COIL 6.8uH K L854 NQL092M-270X P COIL 27uH M L855 NQL904J-560X COIL 56uH J L861 NQL914K-220X COIL 22uH K L862 NQL914K-101X COIL 100uH K L863 NQL914K-101X COIL 100uH K L864 NQL914K-101X COIL 100uH K L865 NQL914K-220X COIL 22uH K L866 NQL914K-220X COIL 22uH K L867 NQL914K-220X COIL 22uH K L902 NQL52EM-220X COIL 22uH M L903 NQL52EM-220X COIL 22uH M L904 NQL52EM-220X COIL 22uH M L6661 QQL28AK-560 COIL 56uH K L6662 QQL28AK-560 COIL 56uH K

CN000H QGF1201C2-19 CONNECTOR FFC/FPC (1-19) CN0011 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN0012 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) J2001 QNZ0726-001 AV JACK INPUT-1(S/V/L/R) J2002 QNZ0693-001 D CONNECTOR J2003 QNZ0726-001 AV JACK INPUT-2(S/V/L/R) J2004 QNN0651-001 PIN JACK INPUT-3(V/L/R) J2006 QNN0650-001 PIN JACK J2007 QNZ0561-001 D CONNECTOR PC IN(RGD) J2008 QNZ0726-001 AV JACK K6601 NQR0413-002X FERRITE BEADS K6602 NQR0413-002X FERRITE BEADS K6661 NQR0413-002X FERRITE BEADS K6662 NQR0413-002X FERRITE BEADS K6663 NQR0413-002X FERRITE BEADS K6664 NQR0413-002X FERRITE BEADS TH6661 NAD0035-471X P THERMISTOR 470 X201 CSB503F30 C RESONATOR X801 NAX0621-001X CRYSTAL 16.200MHz

INPUT-1(COMPONENT)

INPUT-3(COMPONENT)

MONITOR OUT(V/L/R)

Ω

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)



Ref No. Part No. Part Name Description Local

IC4201 SN74AHC1G08V-X IC

D4201 MA8033-X Z DIODE

C4202 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

R4202 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R4203 NRSA63J-470X MG RESISTOR 47Ω 1/16W J

CN0001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN0002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30) CN000T QGF0540C1-40X CONNECTOR FFC/FPC (1-40) CN1011 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN1012 QGF0508F1-50X CONNECTOR FFC/FPC (1-50)

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)



Ref No. Part No. Part Name Description Local

Q7701 UN2212-X DIGI TRANSISTOR Q7705 UN2110-X DIGI TRANSISTOR Q7706 UN2110-X DIGI TRANSISTOR Q7709 UN2212-X DIGI TRANSISTOR

D7011 MA8062/M/-X Z DIODE

D7702 HLMPNS30J00-T16 LED POWER

C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K

R7011 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7012 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7013 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7016 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7019 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7701 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R7702 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R7703 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R7704 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R7711 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R7714 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J

L7001 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L7002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J

CN0008 QGB2542K1-08 CONNECTOR B-B (1-8) J7001 QMS3004-C01 H.P.JACK HEADPHONE K7001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J S7701 QSW0797-001 TACT SWITCH CHS7702 QSW0797-001 TACT SWITCH CH+ S7703 QSW0797-001 TACT SWITCH TV/VIDEO S7704 QSW0797-001 TACT SWITCH MENU/OK S7705 QSW0797-001 TACT SWITCH VOL+ S7706 QSW0797-001 TACT SWITCH VOLS7707 QSW0797-001 TACT SWITCH POWER

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)



Ref No. Part No. Part Name Description Local

IC8751 S9066-11 PHOTO CONDUCTOR IC8752 GP1UM281QKVF IR DETECT UNIT

C8751 NEH71HM-105X E CAPACITOR 1uF 50V M C8752 NEH71CM-476X E CAPACITOR 47uF 16V M

R8751 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J R8752 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R8753 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R8754 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J R8757 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R8759 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

CN1008 QGB2542J1-08 CONNECTOR B-B (1-8)

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)



Ref No. Part No. Part Name Description Local

IC9141 BA50BC0FP-X IC



IC9211 FA5500AN-W IC IC9501 F9222L-F219 IC



IC9541 UTCTL431-T IC IC9602 M62320FP-X IC IC9603 SI-3025B-F1 IC IC9901 MP1580HS-X IC

Q9021 UN2211-X TRANSISTOR Q9211 2SK3522-01-F1 POWER MOS FET Q9212 2SD601A/QR/-X TRANSISTOR Q9213 IMD3A-W DIGI TRANSISTOR Q9215 2SD601A/QR/-X TRANSISTOR Q9216 UN2212-X DIGI TRANSISTOR Q9251 UN2213-X DIGI TRANSISTOR Q9252 UN2212-X DIGI TRANSISTOR Q9501 2SD601A/QR/-X TRANSISTOR Q9502 2SK2071-01S-W POWER MOS FET Q9503 2SD601A/QR/-X TRANSISTOR Q9504 2SK2018-01S-W POWER MOS FET Q9506 UN2213-X DIGI TRANSISTOR

3-10(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

Q9541 UN2212-X DIGI TRANSISTOR Q9602 2SB1188/QR/-W TRANSISTOR Q9603 UN2212-X DIGI TRANSISTOR Q9901 2SD601A/QR/-X TRANSISTOR

D9021 MA111-X SI DIODE D9111 S1WB/A/60-4101 BRIDGE DIODE



D9201 D25XB60 BRIDGE DIODE D9202 MA111-X SI DIODE D9211 YG972S6R SI DIODE D9213 MA111-X SI DIODE D9214 MA111-X SI DIODE D9215 D1FL20U-X SI DIODE D9251 MA3100/M/-X Z DIODE D9252 MA111-X SI DIODE D9253 MA111-X SI DIODE D9254 D1FL20U-X SI DIODE D9501 MA8220/M/-X Z DIODE D9502 MA8110/H/-X Z DIODE D9503 D1FL20U-X SI DIODE D9504 D1FL20U-X SI DIODE D9505 MA8220/M/-X Z DIODE D9507 D1FL20U-X SI DIODE D9508 MA8056/M/-X Z DIODE D9509 SD883-04-X SB DIODE D9510 RD27E/B2/-T5 Z DIODE D9511 RD27E/B2/-T5 Z DIODE D9512 D1FS4-X SB DIODE D9542 FMB-2306 SB DIODE D9543 FMB-2306 SB DIODE D9544 FME-220A SB DIODE D9545 FME-220A SB DIODE D9546 FMB-2306 SB DIODE D9605 D1FS4-X SB DIODE D9901 EC30HA03L-X SB DIODE D9902 MA111-X SI DIODE D9905 D1FL20U-X SI DIODE D9906 PTZ11B-X Z DIODE D9907 RD16E/B/-T5 Z DIODE D9908 RD16E/B/-T5 Z DIODE D9909 D1FL20U-X SI DIODE D9910 MA111-X SI DIODE



C9001 QFZ9072-105 MM CAPACITOR 1uF AC250V K



C9002 QFZ9072-105 MM CAPACITOR 1uF AC250V K



C9011 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C9013 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C9101 QCZ9082-472Z C CAPACITOR 4700pF AC250V M



C9102 QCZ9082-472Z C CAPACITOR 4700pF AC250V M



C9103 QCZ9082-472Z C CAPACITOR 4700pF AC250V M C9111 QEZ0709-106 E CAPACITOR 10uF 450V M C9141 QECR1CM-477Z E CAPACITOR 470uF 16V M C9142 QEHR1AM-337Z E CAPACITOR 330uF 10V M C9143 QEHR1CM-107Z E CAPACITOR 100uF 16V M



C9197 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C9198 QCZ9079-102 C CAPACITOR 1000pF AC250V M



C9201 QCZ9082-222Z C CAPACITOR 2200pF AC250V M



C9203 QCZ9082-222Z C CAPACITOR 2200pF AC250V M



C9204 QCZ9082-222Z C CAPACITOR 2200pF AC250V M



C9205 QCZ9082-222Z C CAPACITOR 2200pF AC250V M C9211 QFZ0222-105 MM CAPACITOR 1uF 450V K C9212 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9213 NCB11CK-105X C CAPACITOR 1uF 16V K C9214 NDC31HJ-102X C CAPACITOR 1000pF 50V J C9215 QEHR1VM-476Z E CAPACITOR 47uF 35V M C9216 QEZ0650-227 E CAPACITOR 220uF 450V M C9218 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9221 NCB31HK-222X C CAPACITOR 2200pF 50V K C9251 QEHR1HM-107Z E CAPACITOR 100uF 50V M C9252 NCB21HK-104X C CAPACITOR 0.1uF 50V K C9501 NCB31HK-104X C CAPACITOR 0.1uF 50V K C9502 NCB31HK-104X C CAPACITOR 0.1uF 50V K C9503 NCB31HK-104X C CAPACITOR 0.1uF 50V K C9504 NCB31HK-223X C CAPACITOR 0.022uF 50V K C9505 NCB11EK-474X C CAPACITOR 0.47uF 25V K C9506 NCB31HK-332X C CAPACITOR 3300pF 50V K C9507 NCB31HK-472X C CAPACITOR 4700pF 50V K C9508 NCB11AK-335X C CAPACITOR 3.3uF 10V K C9509 QECR1VM-227Z E CAPACITOR 220uF 35V M C9510 QEHR2AM-107Z E CAPACITOR 100uF 100V M C9511 QFZ0209-393 MPP CAPACITOR 0.039uF C9541 QECQ1EM-188 E CAPACITOR 1800uF 25V M C9544 QECQ1EM-188 E CAPACITOR 1800uF 25V M C9545 QECQ1EM-188 E CAPACITOR 1800uF 25V M C9546 QECR1EM-687Z E CAPACITOR 680uF 25V M C9547 QECR1EM-687Z E CAPACITOR 680uF 25V M C9550 QEHQ1EM-228 E CAPACITOR 2200uF 25V M

C9551 NCB11EK-474X C CAPACITOR 0.47uF 25V K C9552 NCB31HK-223X C CAPACITOR 0.022uF 50V K C9606 QEHR1HM-106Z E CAPACITOR 10uF 50V M C9608 QEHR1EM-107Z E CAPACITOR 100uF 25V M C9609 NCB31HK-104X C CAPACITOR 0.1uF 50V K C9610 NDC31HJ-680X C CAPACITOR 68pF 50V J C9611 NDC31HJ-680X C CAPACITOR 68pF 50V J C9902 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9903 QECR1CM-477Z E CAPACITOR 470uF 16V M C9904 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9906 NCB31HK-222X C CAPACITOR 2200pF 50V K C9907 NCB31EK-273X C CAPACITOR 0.027uF 25V K C9908 QEHR2AM-106Z E CAPACITOR 10uF 100V M C9909 QEHR1HM-106Z E CAPACITOR 10uF 50V M C9910 QECR1VM-227Z E CAPACITOR 220uF 35V M C9911 QRK126J-151X UNF C RESISTOR 150Ω 1/2W J C9912 QEHR1CM-477Z E CAPACITOR 470uF 16V M C9913 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9914 QTNC1HM-106Z E CAPACITOR 10uF 50V M C9915 NCB11EK-104X C CAPACITOR 0.1uF 25V K C9917 NCB31HK-222X C CAPACITOR 2200pF 50V K



R9001 QRZ9046-105Z C RESISTOR 1MΩ 1/2W K R9101 QRZ0216-4R7 UNF WW RESISTOR 4.7Ω 7W K R9141 QRT01EJ-1R0X MF RESISTOR 1Ω 1W J R9142 QRT01EJ-R82X MF RESISTOR 0.82



R9199 QRZ0107-685Z C RESISTOR 6.8MΩ 1/2W K



R9202 QRZ9055-8R2 FUSI RESISTOR 8.2Ω 2W K R9203 MTZJ8.2C-T2 Z DIODE R9211 NRS12BJ-474W MG RESISTOR 470kΩ 1/2W J R9212 NRS12BJ-474W MG RESISTOR 470kΩ 1/2W J R9213 NRS12BJ-334W MG RESISTOR 330kΩ 1/2W J R9214 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R9215 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R9216 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R9217 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R9218 NRSA63D-183X MG RESISTOR 18kΩ 1/16W D R9219 NRS12BJ-223W MG RESISTOR 22kΩ 1/2W J R9220 QRM059J-R27 MP RESISTOR 0.27Ω 5W J R9221 QRM059J-R15 MP RESISTOR 0.15Ω 5W J R9222 NRS181J-824X MG RESISTOR 820kΩ 1/8W J R9223 NRS181J-824X MG RESISTOR 820kΩ 1/8W J R9224 NRS181J-824X MG RESISTOR 820kΩ 1/8W J R9225 NRS12BJ-334W MG RESISTOR 330kΩ 1/2W J R9226 NRS12BJ-334W MG RESISTOR 330kΩ 1/2W J R9227 NRS12BJ-394W MG RESISTOR 390kΩ 1/2W J R9228 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9229 NRSA63J-274X MG RESISTOR 270kΩ 1/16W J R9233 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J R9236 NRS12BJ-474W MG RESISTOR 470kΩ 1/2W J R9237 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9238 NRS12BJ-220W MG RESISTOR 22Ω 1/2W J R9239 NRS12BJ-1R0W MG RESISTOR 1Ω 1/2W J R9251 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9253 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R9254 NRSA63J-473X MG RESISTOR 47k R9255 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J R9256 NRSA63J-153X MG RESISTOR 15k R9257 NRS12BJ-102W MG RESISTOR 1k R9501 QRL03EJ-822X OMF RESISTOR 8.2kΩ 3W J R9502 QRL03EJ-822X OMF RESISTOR 8.2kΩ 3W J R9503 NRS181J-824X MG RESISTOR 820kΩ 1/8W J R9504 NRS181J-824X MG RESISTOR 820kΩ 1/8W J R9505 NRS181J-824X MG RESISTOR 820k R9506 NRSA63J-473X MG RESISTOR 47k R9507 NRSA63J-473X MG RESISTOR 47k R9508 QRT029J-R56 MF RESISTOR 0.56 R9509 QRM059J-R39 MP RESISTOR 0.39 R9510 NRSA63J-103X MG RESISTOR 10k R9511 NRSA63J-102X MG RESISTOR 1k R9512 NRSA63J-333X MG RESISTOR 33k R9513 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R9514 NRSA63J-104X MG RESISTOR 100k R9515 NRSA63J-104X MG RESISTOR 100k



R9516 QRZ9009-2R2 FUSI RESISTOR 2.2Ω 1/2W J R9517 NRS12BJ-332W MG RESISTOR 3.3k R9518 QRK126J-271X UNF C RESISTOR 270Ω 1/2W J R9519 NRSA02J-180X MG RESISTOR 18 R9520 QRE121J-105Y C RESISTOR 1MΩ 1/2W J R9521 NRSA63J-223X MG RESISTOR 22k R9525 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R9526 NRSA63J-151X MG RESISTOR 150 R9529 QRL039J-561 OMF RESISTOR 560 R9541 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9542 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R9543 NRSA63J-102X MG RESISTOR 1k R9544 NRSA63D-153X MG RESISTOR 15k

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω Ω

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

1W J

2W J 5W J

3W J

(No.YA209)3-11



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R9545 NRSA63D-221X MG RESISTOR 220Ω 1/16W D R9546 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R9548 NRSA63D-272X MG RESISTOR 2.7kΩ 1/16W D R9549 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9551 QRE141J-0R0Y C RESISTOR 0Ω 1/4W J R9552 QRE141J-0R0Y C RESISTOR 0Ω 1/4W J R9602 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9615 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R9616 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R9617 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R9618 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R9620 NRSA63D-822X MG RESISTOR 8.2kΩ 1/16W D R9622 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9623 NRSA63D-122X MG RESISTOR 1.2kΩ 1/16W D R9624 NRSA63D-331X MG RESISTOR 330Ω 1/16W D R9625 NRSA63D-222X MG RESISTOR 2.2kΩ 1/16W D R9629 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9631 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R9632 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9635 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R9636 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9638 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9640 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9643 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9645 NRS12BJ-0R0W MG RESISTOR 0Ω 1/2W J R9647 NRSA63J-333X MG RESISTOR 33k R9901 NRSA02J-0R0X MG RESISTOR 0 R9902 NRSA63D-104X MG RESISTOR 100kΩ 1/16W D R9903 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9904 NRSA63D-184X MG RESISTOR 180kΩ 1/16W D R9905 QRK126J-332X UNF C RESISTOR 3.3kΩ 1/2W J R9906 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R9907 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R9908 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9910 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R9911 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9913 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9916 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R9923 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

L9141 NQL52EN-4R7X COIL 4.7uH N L9201 QQR1399-001 CHOKE COIL L9202 QQR1513-001 CHOKE COIL L9541 NQL71EM-150X COIL 15uH M L9902 NQL80CL-100X COIL 10uH L L9903 NQL80CL-100X COIL 10uH L L9904 NQL63EM-470X COIL 47uH M



T9121 QAL0425-001 POWER TRANSF



T9501 QQS0319-001 SW TRANSF



T9502 QQS0319-001 SW TRANSF

CN0006 QGB2501J1-13 CONNECTOR B-B (1-13) CN000H QGF1201C2-19 CONNECTOR FFC/FPC (1-19) CN00E1 CE41507-001P LV CONNECTOR



CP9121 QMFZ052-2R0-E FUSE 2A AC250V



CP9211 QMFZ043-2R0Z-J1 FUSE 2A AC250V



CP9501 QMFZ034-5R0Z-J1 FUSE 5A 125V



CP9502 QMFZ034-5R0Z-J1 FUSE 5A 125V



F9001 QMF51D2-6R3-J1 FUSE 6.3A AC250V K9001 QRN143J-0R0X C RESISTOR 0Ω 1/4W J K9212 QQR0621-002Z FERRITE BEADS K9501 NQR0413-002X FERRITE BEADS K9502 NQR0413-002X FERRITE BEADS K9503 NQR0413-002X FERRITE BEADS K9504 NQR0413-002X FERRITE BEADS K9505 NQR0413-002X FERRITE BEADS K9508 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J K9541 NQR0413-003X FERRITE BEADS



LF9001 QQR1514-001 LINE FILTER



LF9002 QQR1467-001 LINE FILTER



LF9003 QQR1514-001 LINE FILTER



PC9541 PS2581AL1/QW/ PHOTO COUPLER



PC9542 PS2581AL1/QW/ PHOTO COUPLER



RY9021 QSK0119-001 RELAY



RY9201 QSK0117-001 RELAY



VA9001 QAF0060-621 VARISTOR 620V

Ω

1/16W J

Ω

1/10W J

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)



Ref No. Part No. Part Name Description Local

IC9802 MP1580HS-X IC

IC9803 MP1583DN-X IC

Q9802 2SD601A/QR/-X TRANSISTOR Q9803 2SD601A/QR/-X TRANSISTOR

D9803 SD883-04-X SB DIODE D9804 MA111-X SI DIODE D9805 MA3051/M/-X Z DIODE D9806 SD883-04-X SB DIODE D9807 PTZ6.8B-X Z DIODE D9808 MA111-X SI DIODE D9810 PTZ6.8B-X Z DIODE D9813 MA111-X SI DIODE

C9805 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9806 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9809 NEHM1HM-105X E CAPACITOR 1uF 50V M C9810 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9812 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9813 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9814 NEHM0JM-107X E CAPACITOR 100uF 6.3V M C9818 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9819 NDC31HJ-101X C CAPACITOR 100pF 50V J C9821 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9822 NDC31HJ-121X C CAPACITOR 120pF 50V J C9823 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9824 NCB11EK-104X C CAPACITOR 0.1uF 25V K C9826 NCB31HK-222X C CAPACITOR 2200pF 50V K

R9810 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9811 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9812 NRVA02D-473X CMF RESISTOR 47kΩ 1/10W D R9813 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9814 NRSA63D-124X MG RESISTOR 120kΩ 1/16W D R9815 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R9816 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R9817 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R9818 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9819 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R9820 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J R9821 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9822 NRSA63D-473X MG RESISTOR 47kΩ 1/16W D R9823 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9824 NRSA63D-124X MG RESISTOR 120kΩ 1/16W D R9825 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9826 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J R9827 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R9828 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9830 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9831 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J

L9804 NQL71EM-150X COIL 15uH M L9806 NQL71EM-150X COIL 15uH M L9807 NQL80CL-100X COIL 10uH L

CN1006 QGB2501K2-13 CONNECTOR B-B (1-13)

DIGITAL SIGNAL P.W. BOARD ASS'Y (LCA10428-67B) (SFL-0D305A)



Ref No. Part No. Part Name Description Local

IC0401 SN74AHCT1G32V-X IC IC1001 TC90A92AFG IC IC1002 MM1572FN-X IC IC1502 NJM2235V-X IC IC3001 JCC5055 IC IC3403 S-80928CLNB-W IC IC3501 K4D263238F-UC50 IC IC3502 K4D263238F-UC50 IC IC3503 LP2996MR-X IC IC4001 JCC5057 IC IC4003 AT29LV01-26D50BJ IC(MICRO C ROM) (SERVICE) IC4004 ATE256-Z32SX4B1 IC (SERVICE) IC6502 THC63LVDM83R-W IC IC7001 MN102H60KKC IC(MCU) IC7002 ATE256-Z32SX4B2 IC (SERVICE) IC7401 S-80828CLNB-W IC IC7501 SDA6000-B12 IC IC7502 S-80828CNNB-W IC IC7503 K4S641632H-UC75 IC IC7504 MBV160-Z26SX4B IC(MICRO C ROM) (SERVICE) IC7505 PQ2L3252MS-X IC

3-12(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

IC7506 CD74HC4053PW-X IC IC7602 ATE32-Z32SX4B IC (SERVICE) IC9001 MP1580HS-X IC IC9101 MP1580HS-X IC IC9201 MP1580HS-X IC

Q0101 2SC3837K/NP/-X TRANSISTOR Q0102 2SA1022/BC/-X TRANSISTOR Q0104 2SA1022/BC/-X TRANSISTOR Q0105 2SC3928A/QR/-X TRANSISTOR Q0107 2SA1530A/QR/-X TRANSISTOR Q0108 2SC3928A/QR/-X TRANSISTOR Q0109 HN1C01F/Y/-X PAIR TRANSISTOR Q0110 HN1C01F/Y/-X PAIR TRANSISTOR Q0201 2SC3837K/NP/-X TRANSISTOR Q0202 2SA1022/BC/-X TRANSISTOR Q0203 2SC3928A/QR/-X TRANSISTOR Q0204 2SA1022/BC/-X TRANSISTOR Q0205 2SC3928A/QR/-X TRANSISTOR Q0207 2SA1530A/QR/-X TRANSISTOR Q0208 2SC3928A/QR/-X TRANSISTOR Q0209 HN1C01F/Y/-X PAIR TRANSISTOR Q0210 HN1C01F/Y/-X PAIR TRANSISTOR Q0301 2SC3837K/NP/-X TRANSISTOR Q0302 2SA1022/BC/-X TRANSISTOR Q0303 2SC3928A/QR/-X TRANSISTOR Q0304 2SA1022/BC/-X TRANSISTOR Q0305 2SC3928A/QR/-X TRANSISTOR Q0307 2SA1530A/QR/-X TRANSISTOR Q0308 2SC3928A/QR/-X TRANSISTOR Q0309 HN1C01F/Y/-X PAIR TRANSISTOR Q0310 HN1C01F/Y/-X PAIR TRANSISTOR Q1001 UN2213-X DIGI TRANSISTOR Q1003 2SC3928A/QR/-X TRANSISTOR Q1004 2SA1530A/QR/-X TRANSISTOR Q1101 2SC3928A/QR/-X TRANSISTOR Q1103 2SA1530A/QR/-X TRANSISTOR Q1201 2SC3928A/QR/-X TRANSISTOR Q1203 2SA1530A/QR/-X TRANSISTOR Q1301 2SC3928A/QR/-X TRANSISTOR Q1303 2SA1530A/QR/-X TRANSISTOR Q1401 2SC3928A/QR/-X TRANSISTOR Q1403 2SA1530A/QR/-X TRANSISTOR Q3001 2SC3928A/QR/-X TRANSISTOR Q3002 2SA1530A/QR/-X TRANSISTOR Q3003 2SC3928A/QR/-X TRANSISTOR Q3004 2SA1530A/QR/-X TRANSISTOR Q6501 2SC3928A/QR/-X TRANSISTOR Q6502 2SC3928A/QR/-X TRANSISTOR Q7206 UN2213-X DIGI TRANSISTOR Q7207 DTA144EKA-X DIGI TRANSISTOR Q7501 2SA1162/YG/-X TRANSISTOR Q7508 DTC114EKA-X DIGI TRANSISTOR

D1001 EC30HA03L-X SB DIODE D1002 EC30HA03L-X SB DIODE D7001 MA111-X SI DIODE D7003 MA111-X SI DIODE D7005 MA8082/M/-X Z DIODE D7006 MA8082/M/-X Z DIODE D7007 MA8082/M/-X Z DIODE D7008 MA8082/M/-X Z DIODE D7009 MA8082/M/-X Z DIODE D7010 MA111-X SI DIODE D7203 MA111-X SI DIODE D7210 RB501V-40-X SB DIODE D7501 MA111-X SI DIODE D7502 MA111-X SI DIODE D9001 EC30HA03L-X SB DIODE D9003 PTZ3.9B-X Z DIODE D9101 EC30HA03L-X SB DIODE D9102 EC30HA03L-X SB DIODE D9103 PTZ3.9B-X Z DIODE D9104 MA111-X SI DIODE D9201 EC30HA03L-X SB DIODE D9203 PTZ3.9B-X Z DIODE D9204 MA111-X SI DIODE

C0103 NDC31HJ-330X C CAPACITOR 33pF 50V J C0105 NDC31HJ-270X C CAPACITOR 27pF 50V J C0107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0109 NCB11AK-106X C CAPACITOR 10uF 10V K C0110 NCB11AK-106X C CAPACITOR 10uF 10V K C0111 NDC31HJ-820X C CAPACITOR 82pF 50V J C0112 NDC31HJ-820X C CAPACITOR 82pF 50V J C0113 NCB11AK-106X C CAPACITOR 10uF 10V K C0114 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

C0115 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0116 NCB11AK-106X C CAPACITOR 10uF 10V K C0117 NDC31HJ-560X C CAPACITOR 56pF 50V J C0118 NDC31HJ-151X C CAPACITOR 150pF 50V J C0203 NDC31HJ-330X C CAPACITOR 33pF 50V J C0205 NDC31HJ-270X C CAPACITOR 27pF 50V J C0207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0209 NCB11AK-106X C CAPACITOR 10uF 10V K C0210 NCB11AK-106X C CAPACITOR 10uF 10V K C0211 NDC31HJ-820X C CAPACITOR 82pF 50V J C0212 NDC31HJ-820X C CAPACITOR 82pF 50V J C0213 NCB11AK-106X C CAPACITOR 10uF 10V K C0214 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0215 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0217 NDC31HJ-560X C CAPACITOR 56pF 50V J C0218 NDC31HJ-151X C CAPACITOR 150pF 50V J C0303 NDC31HJ-330X C CAPACITOR 33pF 50V J C0305 NDC31HJ-270X C CAPACITOR 27pF 50V J C0307 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0309 NCB11AK-106X C CAPACITOR 10uF 10V K C0310 NCB11AK-106X C CAPACITOR 10uF 10V K C0311 NDC31HJ-820X C CAPACITOR 82pF 50V J C0312 NDC31HJ-820X C CAPACITOR 82pF 50V J C0313 NCB11AK-106X C CAPACITOR 10uF 10V K C0314 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0315 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0317 NDC31HJ-560X C CAPACITOR 56pF 50V J C0318 NDC31HJ-151X C CAPACITOR 150pF 50V J C0401 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1005 NCB31HK-152X C CAPACITOR 1500pF 50V K C1006 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1009 NDC31HJ-220X C CAPACITOR 22pF 50V J C1010 NDC31HJ-180X C CAPACITOR 18pF 50V J C1011 NDC31HJ-102X C CAPACITOR 1000pF 50V J C1012 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1014 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1015 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1016 NCB11AK-106X C CAPACITOR 10uF 10V K C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1018 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1019 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1021 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1023 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1025 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1026 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1028 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1029 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1030 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1031 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1032 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1033 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1034 NDC31HJ-390X C CAPACITOR 39pF 50V J C1035 NDC31HJ-680X C CAPACITOR 68pF 50V J C1037 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1038 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1039 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1040 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1041 NCB10JK-106X C CAPACITOR 10uF 6.3V K C1042 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1043 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1045 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1046 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1047 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1048 NCB11CK-105X C CAPACITOR 1uF 16V K C1049 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1050 NCB11CK-105X C CAPACITOR 1uF 16V K C1051 NCB11CK-105X C CAPACITOR 1uF 16V K C1061 NDC31HJ-4R0X C CAPACITOR 4pF 50V J C1062 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1063 NCB21AK-225X C CAPACITOR 2.2uF 10V K C1064 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1065 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1066 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1102 NDC31HJ-330X C CAPACITOR 33pF 50V J C1103 NDC31HJ-330X C CAPACITOR 33pF 50V J C1104 NDC31HJ-560X C CAPACITOR 56pF 50V J C1105 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1106 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1109 NDC31HJ-151X C CAPACITOR 150pF 50V J C1202 NDC31HJ-330X C CAPACITOR 33pF 50V J C1203 NDC31HJ-330X C CAPACITOR 33pF 50V J C1204 NDC31HJ-560X C CAPACITOR 56pF 50V J C1205 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1206 NCB31HK-104X C CAPACITOR 0.1uF 50V K

(No.YA209)3-13



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C1209 NDC31HJ-151X C CAPACITOR 150pF 50V J C1302 NDC31HJ-330X C CAPACITOR 33pF 50V J C1303 NDC31HJ-330X C CAPACITOR 33pF 50V J C1304 NDC31HJ-560X C CAPACITOR 56pF 50V J C1305 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1306 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1309 NDC31HJ-151X C CAPACITOR 150pF 50V J C1402 NDC31HJ-330X C CAPACITOR 33pF 50V J C1403 NDC31HJ-330X C CAPACITOR 33pF 50V J C1404 NDC31HJ-560X C CAPACITOR 56pF 50V J C1405 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1406 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1409 NDC31HJ-151X C CAPACITOR 150pF 50V J C1502 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C1508 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1509 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1511 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J C3004 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3006 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3008 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3016 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3018 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3021 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3022 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3023 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3028 NDC31HJ-221X C CAPACITOR 220pF 50V J C3030 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3031 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3032 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3037 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3040 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3041 NDC31HJ-101X C CAPACITOR 100pF 50V J C3042 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3043 NDC31HJ-101X C CAPACITOR 100pF 50V J C3044 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3045 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3047 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3049 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3051 NCB31HK-472X C CAPACITOR 4700pF 50V K C3052 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3056 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3059 NCB31HK-223X C CAPACITOR 0.022uF 50V K C3060 NCB31HK-152X C CAPACITOR 1500pF 50V K C3063 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3065 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3066 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3067 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3068 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3069 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3070 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3071 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3072 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3074 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3076 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3097 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3101 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3105 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3126 NDC31HJ-390X C CAPACITOR 39pF 50V J C3406 NCB31HK-102X C CAPACITOR 1000pF 50V K C3501 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3503 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3506 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3507 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3508 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3509 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3511 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3516 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3517 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3518 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3519 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3524 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3527 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3531 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3532 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3533 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3535 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3539 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3540 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3542 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3543 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3548 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

C3549 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3550 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3551 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3552 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C4002 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4003 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4005 NCB31AK-105X C CAPACITOR 1uF 10V K C4006 NCB31AK-105X C CAPACITOR 1uF 10V K C4008 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4009 NCB31AK-105X C CAPACITOR 1uF 10V K C4010 NCB31AK-105X C CAPACITOR 1uF 10V K C4011 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4012 NCB31AK-105X C CAPACITOR 1uF 10V K C4013 NCB31AK-105X C CAPACITOR 1uF 10V K C4016 NCB31AK-105X C CAPACITOR 1uF 10V K C4020 NCB31AK-105X C CAPACITOR 1uF 10V K C4022 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4023 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4029 NDC31HJ-470X C CAPACITOR 47pF 50V J C4030 NDC31HJ-470X C CAPACITOR 47pF 50V J C4901 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4902 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4906 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4907 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4908 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4909 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4910 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4911 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4913 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4914 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4915 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4916 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4917 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4919 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4920 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4921 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4922 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4923 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4925 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4926 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4931 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4932 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4933 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4934 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4935 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4936 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4937 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4938 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4939 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4940 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4941 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4942 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6013 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6014 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6015 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6512 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6513 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6514 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6515 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6516 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6521 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6522 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6523 NCB11AK-106X C CAPACITOR 10uF 10V K C7001 NCB31AK-105X C CAPACITOR 1uF 10V K C7002 NCB31AK-105X C CAPACITOR 1uF 10V K C7003 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C7006 NDC31HJ-150X C CAPACITOR 15pF 50V J C7007 NCB31AK-105X C CAPACITOR 1uF 10V K C7010 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7011 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7012 NCB31CK-104X C CAPACITOR 0.1uF 16V K C7013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7017 NDC31HJ-391X C CAPACITOR 390pF 50V J C7018 NCB31AK-105X C CAPACITOR 1uF 10V K C7025 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7203 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7401 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7402 NCB31AK-105X C CAPACITOR 1uF 10V K C7501 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7502 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7503 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7504 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7505 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7506 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7507 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7508 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

3-14(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C7509 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7510 NEH71CM-106X E CAPACITOR 10uF 16V M C7511 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7512 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7513 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7514 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7516 NDC31HJ-330X C CAPACITOR 33pF 50V J C7517 NDC31HJ-270X C CAPACITOR 27pF 50V J C7518 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C7520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7521 NEH71CM-106X E CAPACITOR 10uF 16V M C7522 NEH71CM-106X E CAPACITOR 10uF 16V M C7523 NEH71CM-476X E CAPACITOR 47uF 16V M C7524 NEH71CM-476X E CAPACITOR 47uF 16V M C7525 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7526 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7527 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7528 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7529 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7531 NEH71CM-476X E CAPACITOR 47uF 16V M C7532 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7533 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7534 NCB11AK-106X C CAPACITOR 10uF 10V K C7535 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7541 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7542 NEH70GM-227X E CAPACITOR 220uF 4V M C7543 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7544 NEH70JM-107X E CAPACITOR 100uF 6.3V M C7545 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7546 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7547 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7548 NEH70GM-227X E CAPACITOR 220uF 4V M C7550 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7552 NCB31AK-105X C CAPACITOR 1uF 10V K C7553 NCB31HK-471X C CAPACITOR 470pF 50V K C7616 NCB11CK-105X C CAPACITOR 1uF 16V K C9002 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9005 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9007 NCB31HK-222X C CAPACITOR 2200pF 50V K C9008 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9010 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9012 NCB31HK-222X C CAPACITOR 2200pF 50V K C9102 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9104 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9105 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9106 NDC31HJ-121X C CAPACITOR 120pF 50V J C9107 NCB31HK-222X C CAPACITOR 2200pF 50V K C9108 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9111 NCB31HK-822X C CAPACITOR 8200pF 50V K C9112 NCB31HK-222X C CAPACITOR 2200pF 50V K C9202 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9204 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9205 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9207 NCB31HK-222X C CAPACITOR 2200pF 50V K C9209 NEZ0022-157X E CAPACITOR 150uF 10V M C9211 NCB31HK-153X C CAPACITOR 0.015uF 50V K C9212 NCB31HK-222X C CAPACITOR 2200pF 50V K

Ω

R0105 NRSA63J-101X MG RESISTOR 100 R0106 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0107 NRSA63J-471X MG RESISTOR 470 R0109 NRSA63J-151X MG RESISTOR 150 R0110 NRSA63J-101X MG RESISTOR 100 R0114 NRSA63J-472X MG RESISTOR 4.7k R0116 NRSA63J-101X MG RESISTOR 100 R0119 NRSA63J-101X MG RESISTOR 100 R0121 NRSA63J-101X MG RESISTOR 100 R0122 NRSA63J-102X MG RESISTOR 1k R0125 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0126 NRSA63J-103X MG RESISTOR 10k R0127 NRSA63J-0R0X MG RESISTOR 0 R0128 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0129 NRSA63J-103X MG RESISTOR 10k R0131 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0132 NRSA63J-472X MG RESISTOR 4.7k R0133 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0134 NRSA63J-472X MG RESISTOR 4.7k R0137 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R0138 NRSA63J-330X MG RESISTOR 33 R0140 NRSA63J-182X MG RESISTOR 1.8k R0141 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0205 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0206 NRSA63J-471X MG RESISTOR 470 R0207 NRSA63J-471X MG RESISTOR 470

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R0208 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R0209 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0210 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0211 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0214 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0216 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0219 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0221 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0222 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0225 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0226 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0227 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0228 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0229 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0231 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0232 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0233 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0234 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0237 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0238 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0240 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0241 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0305 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0306 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0307 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0308 NRSA63J-681X MG RESISTOR 680 R0309 NRSA63J-221X MG RESISTOR 220 R0310 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0311 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0314 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0316 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0319 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0321 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0322 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0325 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0326 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0327 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0328 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0329 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0331 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0332 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0333 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0334 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0337 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0338 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0340 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0341 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0501 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0504 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0506 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0508 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0516 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0517 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0520 NRSA63J-0R0X MG RESISTOR 0 R0522 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0523 NRSA63J-0R0X MG RESISTOR 0 R0524 NRSA63J-0R0X MG RESISTOR 0 R0525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0527 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1001 NRSA63J-274X MG RESISTOR 270kΩ 1/16W J R1002 NRSA63D-101X MG RESISTOR 100Ω 1/16W D R1003 NRSA63J-103X MG RESISTOR 10k R1004 NRSA63J-221X MG RESISTOR 220 R1005 NRSA63J-103X MG RESISTOR 10k R1006 NRSA63J-101X MG RESISTOR 100 R1007 NRSA63J-101X MG RESISTOR 100 R1010 NRSA63J-183X MG RESISTOR 18k R1011 NQL093K-R10X P COIL 0.1uH K R1012 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1013 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R1014 NRSA63J-101X MG RESISTOR 100 R1017 NRSA63J-101X MG RESISTOR 100 R1018 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1019 NRSA63J-0R0X MG RESISTOR 0 R1021 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1101 NRSA63J-182X MG RESISTOR 1.8k R1102 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1104 NRSA63J-332X MG RESISTOR 3.3k R1105 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1106 NRSA63J-122X MG RESISTOR 1.2k R1107 NRSA63J-331X MG RESISTOR 330 R1113 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1201 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1203 NRSA63J-101X MG RESISTOR 100 R1204 NRSA63J-332X MG RESISTOR 3.3k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-15



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R1205 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1206 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1207 NRSA63J-331X MG RESISTOR 330Ω 1/16W J R1213 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1301 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1304 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1305 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1306 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1307 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1313 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1401 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1403 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1404 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1405 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1406 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1407 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1413 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1523 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z R1524 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R1525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1584 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2010 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3001 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3004 NRSA63J-103X MG RESISTOR 10k R3006 NRSA63J-0R0X MG RESISTOR 0 R3007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3009 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3018 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3019 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3020 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3021 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3022 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R3023 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R3024 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3028 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3029 NRSA63D-392X MG RESISTOR 3.9kΩ 1/16W D R3030 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3031 NRSA63D-151X MG RESISTOR 150Ω 1/16W D R3032 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3033 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3034 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3036 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3037 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3038 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R3040 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3041 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3042 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3043 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3044 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3045 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3047 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3048 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3053 NRSA63J-272X MG RESISTOR 2.7k R3054 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3056 NRSA63J-0R0X MG RESISTOR 0 R3063 NRSA63J-101X MG RESISTOR 100 R3064 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3066 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3069 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3070 NRSA63J-0R0X MG RESISTOR 0 R3071 NRSA63J-0R0X MG RESISTOR 0 R3072 NRSA63J-0R0X MG RESISTOR 0 R3089 NRSA63J-220X MG RESISTOR 22 R3090 NRSA63J-220X MG RESISTOR 22 R3091 NRSA63J-220X MG RESISTOR 22 R3092 NRSA63J-220X MG RESISTOR 22 R3093 NRSA63J-220X MG RESISTOR 22 R3094 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3095 NRSA63J-510X MG RESISTOR 51 R3096 NRSA63J-510X MG RESISTOR 51 R3097 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3098 NRSA63J-510X MG RESISTOR 51 R3099 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3100 NRSA63J-510X MG RESISTOR 51 R3101 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3102 NRSA63J-510X MG RESISTOR 51 R3103 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3104 NRSA63J-510X MG RESISTOR 51 R3105 NRSA63J-510X MG RESISTOR 51 R3106 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3122 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3126 NRSA63J-0R0X MG RESISTOR 0 R3131 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R3132 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3151 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3152 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3153 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3155 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3157 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3160 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3161 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3163 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3164 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3165 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3166 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3167 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3168 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3169 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3170 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3171 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3178 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3181 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3207 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3502 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3503 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3505 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3507 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3509 NRSA63J-510X MG RESISTOR 51 R3511 NRSA63J-510X MG RESISTOR 51 R3514 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3516 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3518 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3520 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3522 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3524 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3525 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3527 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3529 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3531 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3533 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3536 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3538 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3540 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3542 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3544 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R4004 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4005 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4016 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4023 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4024 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4027 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4035 NRSA63J-103X MG RESISTOR 10k R4037 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4039 NRSA63J-103X MG RESISTOR 10k R4041 NRSA63J-103X MG RESISTOR 10k R4042 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4044 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4055 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4056 NRSA63J-102X MG RESISTOR 1k R4057 NRSA63J-221X MG RESISTOR 220 R4058 NRSA63J-221X MG RESISTOR 220 R4059 NRSA63J-0R0X MG RESISTOR 0 R4060 NRSA63J-470X MG RESISTOR 47 R4061 NRSA63J-0R0X MG RESISTOR 0 R4064 NRSA63J-0R0X MG RESISTOR 0 R4065 NRSA63J-0R0X MG RESISTOR 0 R4068 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4101 NRSA63J-0R0X MG RESISTOR 0 R4102 NRSA63J-0R0X MG RESISTOR 0 R4103 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4104 NRSA63J-0R0X MG RESISTOR 0 R4105 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4106 NRSA63J-101X MG RESISTOR 100 R4108 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4152 NRSA63J-0R0X MG RESISTOR 0 R6025 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6028 NRSA63J-101X MG RESISTOR 100 R6031 NRSA63J-101X MG RESISTOR 100 R6034 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6038 NRSA63J-102X MG RESISTOR 1k R6039 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-16(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R6040 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6043 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6048 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6057 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6058 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6059 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6510 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6512 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6513 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6514 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6515 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6521 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6529 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R6531 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6532 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6533 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6534 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6536 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6537 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6538 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6540 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6541 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6542 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6544 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6548 NRSA63J-102X MG RESISTOR 1k R6550 NRSA63J-103X MG RESISTOR 10k R6558 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7001 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7002 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7004 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7005 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7006 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7007 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7010 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7011 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7016 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7017 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7021 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7022 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7023 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7024 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7025 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7026 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7029 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7031 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7033 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7034 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7035 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7038 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7039 NRSA63J-473X MG RESISTOR 47k R7040 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7041 NRSA63J-0R0X MG RESISTOR 0 R7042 NRSA63J-103X MG RESISTOR 10k R7043 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7047 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7048 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7049 NRSA63J-0R0X MG RESISTOR 0 R7057 NRSA63J-103X MG RESISTOR 10k R7058 NRSA63J-102X MG RESISTOR 1k R7059 NRSA63J-333X MG RESISTOR 33k R7060 NRSA63J-473X MG RESISTOR 47k R7061 NRSA63J-104X MG RESISTOR 100k R7063 NRSA63J-154X MG RESISTOR 150k R7064 NRSA63J-0R0X MG RESISTOR 0 R7065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7066 NRSA63J-101X MG RESISTOR 100 R7067 NRSA63J-151X MG RESISTOR 150 R7068 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7069 NRSA63J-0R0X MG RESISTOR 0 R7070 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7071 NRSA63J-0R0X MG RESISTOR 0 R7072 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7077 NRSA63J-0R0X MG RESISTOR 0 R7080 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7081 NRSA63J-0R0X MG RESISTOR 0 R7082 NRSA63J-0R0X MG RESISTOR 0 R7085 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7086 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7087 NRSA63J-103X MG RESISTOR 10k R7088 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R7089 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7090 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7091 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7092 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7093 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7094 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7095 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7096 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7097 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7098 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7099 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7100 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7101 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7106 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7107 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7108 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7109 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7110 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7111 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7117 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7118 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7119 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7120 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7123 NRSA63J-103X MG RESISTOR 10k R7132 NRSA63J-101X MG RESISTOR 100 R7134 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7135 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7136 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7137 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7140 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7143 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7144 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7145 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7146 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7148 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7149 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7150 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7151 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7152 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7153 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7158 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7215 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7216 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7404 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7501 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7510 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7511 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7514 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7515 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7518 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7553 NRSA63J-0R0X MG RESISTOR 0 R7556 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7557 NRSA63J-221X MG RESISTOR 220 R7558 NRSA63J-0R0X MG RESISTOR 0 R7559 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7560 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7561 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7565 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7566 NRSA63J-222X MG RESISTOR 2.2k R7567 NRSA63J-222X MG RESISTOR 2.2k R7568 NRSA63J-222X MG RESISTOR 2.2k R7576 NRSA63J-101X MG RESISTOR 100 R7588 NRSA63J-221X MG RESISTOR 220 R7590 NRSA63J-101X MG RESISTOR 100 R7599 NRSA63J-101X MG RESISTOR 100 R7602 NRSA63J-103X MG RESISTOR 10k R7603 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7692 NRSA63J-103X MG RESISTOR 10k R7701 NRSA63J-472X MG RESISTOR 4.7k R7702 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7703 NRSA63J-101X MG RESISTOR 100 R7704 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7705 NRSA63J-101X MG RESISTOR 100 R7706 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7707 NRSA63J-101X MG RESISTOR 100 R7708 NRSA63J-820X MG RESISTOR 82Ω 1/16W J R7709 NRSA63J-103X MG RESISTOR 10k R7710 NRSA63J-103X MG RESISTOR 10k R7711 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7712 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7713 NRSA63J-101X MG RESISTOR 100 R7714 NRSA63J-101X MG RESISTOR 100

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-17



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R7715 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7716 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7717 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7718 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7719 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J R7720 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9001 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9003 NRSA63D-203X MG RESISTOR 20kΩ 1/16W D R9004 NRSA63D-124X MG RESISTOR 120kΩ 1/16W D R9005 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9008 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9103 NRSA63D-203X MG RESISTOR 20kΩ 1/16W D R9104 NRSA63D-223X MG RESISTOR 22kΩ 1/16W D R9105 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9107 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9108 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9109 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9201 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9202 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9204 NRSA63D-272X MG RESISTOR 2.7k R9205 NRSA63D-103X MG RESISTOR 10k R9206 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9207 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9208 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R9209 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9210 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RA1001 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1002 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1003 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA3002 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA3004 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA3013 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3014 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3015 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3016 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3018 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3020 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3022 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3023 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3024 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3025 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3026 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3028 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3030 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3032 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3502 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3506 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3508 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3512 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3516 NRZ0040-510X NET RESISTOR 51 RA3518 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3521 NRZ0080-510X NET RESISTOR 51 RA3523 NRZ0040-510X NET RESISTOR 51 RA3526 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3530 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3531 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3536 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3540 NRZ0040-510X NET RESISTOR 51 RA3542 NRZ0040-510X NET RESISTOR 51 RA3545 NRZ0080-510X NET RESISTOR 51 RA3547 NRZ0040-510X NET RESISTOR 51 RA4007 NRZ0034-101W NET RESISTOR 100 RA4008 NRZ0034-101W NET RESISTOR 100 RA4009 NRZ0034-101W NET RESISTOR 100 RA4010 NRZ0034-101W NET RESISTOR 100 RA4011 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4012 NRZ0034-101W NET RESISTOR 100 RA6515 NRZ0034-0R0W NET RESISTOR 0 RA7007 NRZ0040-0R0X NET RESISTOR 0Ω 1/16W J x4 RB2001 NRZ0080-0R0X NET RESISTOR 0 RB2002 NRZ0080-0R0X NET RESISTOR 0Ω 1/16W J RB2003 NRZ0080-0R0X NET RESISTOR 0

L0101 NQL092K-2R2X P COIL 2.2uH K L0102 NQL092K-1R0X P COIL 1uH K L0201 NQL092K-2R2X P COIL 2.2uH K L0202 NQL092K-1R0X P COIL 1uH K L0301 NQL092K-2R2X P COIL 2.2uH K L0302 NQL092K-1R0X P COIL 1uH K L0401 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1001 NQR0489-002X FERRITE BEADS

Ω

1/16W D

Ω

1/16W D

Ω

1/16W J x4

Ω

1/16W J

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J x4

Ω

1/16W J

Ω

1/16W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/16W J

Ω

1/16W J

L1002 NQR0489-002X FERRITE BEADS L1003 NQL092K-1R5X P COIL 1.5uH K L1004 NQR0489-002X FERRITE BEADS L1005 NQR0489-002X FERRITE BEADS L1006 NQR0489-002X FERRITE BEADS L1008 NQL79GM-220X COIL 22uH M L1010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1011 NQL79GM-470X COIL 47uH M L1101 NQL092K-6R8X P COIL 6.8uH K L1102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1103 NQL092K-1R0X P COIL 1uH K L1201 NQL092K-6R8X P COIL 6.8uH K L1203 NQL092K-1R0X P COIL 1uH K L1301 NQL092K-6R8X P COIL 6.8uH K L1303 NQL092K-1R0X P COIL 1uH K L1401 NQL092K-6R8X P COIL 6.8uH K L1403 NQL092K-1R0X P COIL 1uH K L1501 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3001 NQR0489-002X FERRITE BEADS L3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3006 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3008 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3009 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3012 NRSA02J-0R0X MG RESISTOR 0 L3501 NQR0413-003X FERRITE BEADS L4001 NQR0413-003X FERRITE BEADS L4002 NRSA02J-0R0X MG RESISTOR 0 L4003 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6501 NQR0351-001X FERRITE BEADS L6502 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6508 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6509 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6510 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L7001 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7002 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7004 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7005 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7501 NQL092K-4R7X P COIL 4.7uH K L7502 NQL092K-4R7X P COIL 4.7uH K L7503 NQL092K-4R7X P COIL 4.7uH K L7504 NQL092K-4R7X P COIL 4.7uH K L7505 NQL092K-4R7X P COIL 4.7uH K L7506 NQL914M-4R7X COIL 4.7uH M L7507 NQL092K-4R7X P COIL 4.7uH K L7508 NQL092K-4R7X P COIL 4.7uH K L7509 NQL092K-4R7X P COIL 4.7uH K L7510 NQL092K-4R7X P COIL 4.7uH K L7511 NQL092K-4R7X P COIL 4.7uH K L7512 NQL914M-4R7X COIL 4.7uH M L7513 NQL914M-4R7X COIL 4.7uH M L7514 NQL092K-4R7X P COIL 4.7uH K L9001 NQL71EM-150X COIL 15uH M L9101 NQL71EM-150X COIL 15uH M L9201 NQL71EM-150X COIL 15uH M

CN001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30) K1001 NRSA02J-0R0X MG RESISTOR 0 K1004 NQR0489-002X FERRITE BEADS K3003 NRSA63J-0R0X MG RESISTOR 0 K3006 NRSA63J-0R0X MG RESISTOR 0 K7002 NRSA02J-0R0X MG RESISTOR 0 K7501 NRSA63J-390X MG RESISTOR 39 K7502 NRSA63J-0R0X MG RESISTOR 0 K7503 NQR0389-003X FERRITE BEADS LC0102 NQR0483-005X EMI FILTER 100uF 25V Z LC0519 NQR0416-001X EMI FILTER 240pF 16V M LC0524 NQR0415-005X EMI FILTER 0.1uF 25V M

LC0525 NQR0470-003X EMI FILTER

LC6501 NQR0479-001X EMI FILTER LC7501 NQR0313-007X EMI FILTER 1000pF 50V M LC7502 NQR0431-001X EMI FILTER 0.22uF 50V Z SL7001 NAX0613-001X C RESONATOR X1001 NAX0642-001X CRYSTAL X3001 NAX0635-001X CXO X3003 NAX0668-001X CXO X4001 NAX0669-001X C RESONATOR X7501 NAX0618-001X CRYSTAL

Ω

1/10W J

Ω

1/10W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

Ω

1/16W J

100pF 50V +50%-

20%

3-18(No.YA209)

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)



Ref No. Part No. Part Name Description Local

IC3101 M62320FP-X IC IC3501 MSP3415GQGB8V3M IC IC3504 BA80BC0FP-X IC IC3601 AN5285K IC IC3651 HA17558AF-X IC

Q3001 2SC3928A/QR/-X TRANSISTOR Q3502 2SC3928A/QR/-X TRANSISTOR Q3503 UN2213-X DIGI TRANSISTOR

C3003 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3004 NEH71AM-107X E CAPACITOR 100uF 10V M C3007 NCF31AZ-105X C CAPACITOR 1uF 10V Z C3008 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3009 NEH71HM-106X E CAPACITOR 10uF 50V M C3010 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3011 NEH71HM-106X E CAPACITOR 10uF 50V M C3012 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3101 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C3501 NCB11AK-106X C CAPACITOR 10uF 10V K C3502 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3503 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3504 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3505 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J C3511 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3512 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3513 NDC31HJ-2R0X C CAPACITOR 2pF 50V J C3514 NDC31HJ-2R0X C CAPACITOR 2pF 50V J C3515 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3516 NEH71AM-107X E CAPACITOR 100uF 10V M C3517 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3518 NCB31HK-222X C CAPACITOR 2200pF 50V K C3523 NDC31HJ-102X C CAPACITOR 1000pF 50V J C3524 NDC31HJ-102X C CAPACITOR 1000pF 50V J C3525 NEH71CM-106X E CAPACITOR 10uF 16V M C3526 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3527 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3528 NEH71AM-107X E CAPACITOR 100uF 10V M C3529 NEH71CM-106X E CAPACITOR 10uF 16V M C3530 NCB11AK-106X C CAPACITOR 10uF 10V K C3531 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3532 NCF31AZ-105X C CAPACITOR 1uF 10V Z C3533 NCF31AZ-105X C CAPACITOR 1uF 10V Z C3534 NCF31AZ-105X C CAPACITOR 1uF 10V Z C3535 NCF31AZ-105X C CAPACITOR 1uF 10V Z C3536 NCB11AK-106X C CAPACITOR 10uF 10V K C3537 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3544 NCB31AK-105X C CAPACITOR 1uF 10V K C3545 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3546 NCB31AK-105X C CAPACITOR 1uF 10V K C3547 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3601 NEH71EM-475X E CAPACITOR 4.7uF 25V M C3602 NCB31AK-105X C CAPACITOR 1uF 10V K C3603 NEH71AM-107X E CAPACITOR 100uF 10V M C3604 NCB31HK-103X C CAPACITOR 0.01uF 50V K C3605 NEH71CM-106X E CAPACITOR 10uF 16V M C3607 NCB31AK-105X C CAPACITOR 1uF 10V K C3608 NEH71CM-106X E CAPACITOR 10uF 16V M C3609 NCB31AK-105X C CAPACITOR 1uF 10V K C3610 NCB31AK-105X C CAPACITOR 1uF 10V K C3651 NCB31AK-105X C CAPACITOR 1uF 10V K C3652 NCB31AK-105X C CAPACITOR 1uF 10V K C3653 NEH71CM-476X E CAPACITOR 47uF 16V M C3654 NEH71CM-476X E CAPACITOR 47uF 16V M

R3004 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3005 NRSA63J-101X MG RESISTOR 100 R3006 NRSA63J-101X MG RESISTOR 100 R3007 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3009 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R3010 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3011 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3014 NRSA63J-0R0X MG RESISTOR 0 R3015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3016 NRSA63J-101X MG RESISTOR 100 R3101 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3102 NRSA63J-103X MG RESISTOR 10k R3103 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3104 NRSA63J-101X MG RESISTOR 100 R3111 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3112 NRSA63J-0R0X MG RESISTOR 0 R3501 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J



Ref No. Part No. Part Name Description Local

R3502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3508 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3511 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3512 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3513 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3514 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3515 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3516 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3517 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3522 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3523 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3546 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3547 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R3601 NRSA63J-225X MG RESISTOR 2.2MΩ 1/16W J R3602 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R3605 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R3606 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R3607 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R3608 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J R3611 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J R3651 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3652 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R3653 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3655 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J R3656 NRSA63J-103X MG RESISTOR 10k R3657 NRSA63J-472X MG RESISTOR 4.7k R3658 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R3701 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3702 QRE141J-0R0Y C RESISTOR 0Ω 1/4W J

L3001 NQL79GM-220X COIL 22uH M L3002 NQL79GM-100X COIL 10uH M L3503 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3504 NQL79GM-4R7X COIL 4.7uH M L3506 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3507 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J

K3501 NQR0389-003X FERRITE BEADS K3502 NQR0389-003X FERRITE BEADS LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z



TU3001 QAU0390-001 TUNER X3501 QAX0773-001Z CRYSTAL 18.432000MHz

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-19

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/A]



ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)

REFER TO PARTS LIST IN PAGE 3-6 FOR THIS P.W. BOARD.

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)

REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.

DIGITAL SIGNAL P.W. BOARD ASS'Y

(LCA10428-69B) (SFL-0D307A)



Ref No. Part No. Part Name Description Local

IC0401 SN74AHCT1G32V-X IC IC1001 TC90A92AFG IC IC1002 MM1572FN-X IC IC1502 NJM2235V-X IC IC3001 JCC5055 IC IC3403 S-80928CLNB-W IC IC3501 K4D263238F-UC50 IC IC3502 K4D263238F-UC50 IC IC3503 LP2996MR-X IC IC4001 JCC5057 IC IC4003 AT29LV01-26D50BJ IC(MICRO C ROM) (SERVICE) IC4004 ATE256-Z32SX4B1 IC (SERVICE) IC6502 THC63LVDM83R-W IC IC7001 MN102H60KKC IC(MCU) IC7002 ATE256-Z32SX4B2 IC (SERVICE) IC7401 S-80828CLNB-G-W IC IC7501 SDA6000-B12 IC IC7502 S-80828CNNB-G-W IC IC7503 K4S641632H-UC75 IC IC7504 MBV160-Z26SX4B IC(MICRO C ROM) (SERVICE) IC7505 PQ2L3252MS-X IC IC7506 CD74HC4053PW-X IC IC7602 ATE32-Z32SX4B IC (SERVICE) IC9001 MP1580HS-X IC IC9101 MP1580HS-X IC IC9201 MP1580HS-X IC

Q0101 2SC3837K/NP/-X TRANSISTOR Q0102 2SA1022/BC/-X TRANSISTOR Q0104 2SA1022/BC/-X TRANSISTOR Q0105 2SC3928A/QR/-X TRANSISTOR Q0107 2SA1530A/QR/-X TRANSISTOR Q0108 2SC3928A/QR/-X TRANSISTOR Q0109 HN1C01F/Y/-X PAIR TRANSISTOR

Ref No. Part No. Part Name Description Local

Q0110 HN1C01F/Y/-X PAIR TRANSISTOR Q0201 2SC3837K/NP/-X TRANSISTOR Q0202 2SA1022/BC/-X TRANSISTOR Q0203 2SC3928A/QR/-X TRANSISTOR Q0204 2SA1022/BC/-X TRANSISTOR Q0205 2SC3928A/QR/-X TRANSISTOR Q0207 2SA1530A/QR/-X TRANSISTOR Q0208 2SC3928A/QR/-X TRANSISTOR Q0209 HN1C01F/Y/-X PAIR TRANSISTOR Q0210 HN1C01F/Y/-X PAIR TRANSISTOR Q0301 2SC3837K/NP/-X TRANSISTOR Q0302 2SA1022/BC/-X TRANSISTOR Q0303 2SC3928A/QR/-X TRANSISTOR Q0304 2SA1022/BC/-X TRANSISTOR Q0305 2SC3928A/QR/-X TRANSISTOR Q0307 2SA1530A/QR/-X TRANSISTOR Q0308 2SC3928A/QR/-X TRANSISTOR Q0309 HN1C01F/Y/-X PAIR TRANSISTOR Q0310 HN1C01F/Y/-X PAIR TRANSISTOR Q1001 UN2213-X DIGI TRANSISTOR Q1003 2SC3928A/QR/-X TRANSISTOR Q1004 2SA1530A/QR/-X TRANSISTOR Q1101 2SC3928A/QR/-X TRANSISTOR Q1103 2SA1530A/QR/-X TRANSISTOR Q1201 2SC3928A/QR/-X TRANSISTOR Q1203 2SA1530A/QR/-X TRANSISTOR Q1301 2SC3928A/QR/-X TRANSISTOR Q1303 2SA1530A/QR/-X TRANSISTOR Q1401 2SC3928A/QR/-X TRANSISTOR Q1403 2SA1530A/QR/-X TRANSISTOR Q3001 2SC3928A/QR/-X TRANSISTOR Q3002 2SA1530A/QR/-X TRANSISTOR Q3003 2SC3928A/QR/-X TRANSISTOR Q3004 2SA1530A/QR/-X TRANSISTOR Q6501 2SC3928A/QR/-X TRANSISTOR Q6502 2SC3928A/QR/-X TRANSISTOR Q7206 UN2213-X DIGI TRANSISTOR Q7207 DTA144EKA-X DIGI TRANSISTOR Q7501 2SA1162/YG/-X TRANSISTOR Q7508 DTC114EKA-X DIGI TRANSISTOR

D1001 EC30HA03L-X SB DIODE D1002 EC30HA03L-X SB DIODE D7001 MA111-X SI DIODE D7003 MA111-X SI DIODE D7005 MA8082/M/-X Z DIODE D7006 MA8082/M/-X Z DIODE D7007 MA8082/M/-X Z DIODE D7008 MA8082/M/-X Z DIODE D7009 MA8082/M/-X Z DIODE D7010 MA111-X SI DIODE D7203 MA111-X SI DIODE D7210 RB501V-40-X SB DIODE D7501 MA111-X SI DIODE D7502 MA111-X SI DIODE D9001 EC30HA03L-X SB DIODE D9003 PTZ3.9B-X Z DIODE D9101 EC30HA03L-X SB DIODE D9102 EC30HA03L-X SB DIODE D9103 PTZ3.9B-X Z DIODE D9104 MA111-X SI DIODE D9201 EC30HA03L-X SB DIODE D9203 PTZ3.9B-X Z DIODE D9204 MA111-X SI DIODE

C0103 NDC31HJ-330X C CAPACITOR 33pF 50V J C0105 NDC31HJ-270X C CAPACITOR 27pF 50V J C0107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0109 NCB11AK-106X C CAPACITOR 10uF 10V K C0110 NCB11AK-106X C CAPACITOR 10uF 10V K C0111 NDC31HJ-820X C CAPACITOR 82pF 50V J C0112 NDC31HJ-820X C CAPACITOR 82pF 50V J C0113 NCB11AK-106X C CAPACITOR 10uF 10V K C0114 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0115 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0116 NCB11AK-106X C CAPACITOR 10uF 10V K C0117 NDC31HJ-560X C CAPACITOR 56pF 50V J C0118 NDC31HJ-151X C CAPACITOR 150pF 50V J C0203 NDC31HJ-330X C CAPACITOR 33pF 50V J C0205 NDC31HJ-270X C CAPACITOR 27pF 50V J C0207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0209 NCB11AK-106X C CAPACITOR 10uF 10V K C0210 NCB11AK-106X C CAPACITOR 10uF 10V K C0211 NDC31HJ-820X C CAPACITOR 82pF 50V J

3-20(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C0212 NDC31HJ-820X C CAPACITOR 82pF 50V J C0213 NCB11AK-106X C CAPACITOR 10uF 10V K C0214 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0215 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0217 NDC31HJ-560X C CAPACITOR 56pF 50V J C0218 NDC31HJ-151X C CAPACITOR 150pF 50V J C0303 NDC31HJ-330X C CAPACITOR 33pF 50V J C0305 NDC31HJ-270X C CAPACITOR 27pF 50V J C0307 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0309 NCB11AK-106X C CAPACITOR 10uF 10V K C0310 NCB11AK-106X C CAPACITOR 10uF 10V K C0311 NDC31HJ-820X C CAPACITOR 82pF 50V J C0312 NDC31HJ-820X C CAPACITOR 82pF 50V J C0313 NCB11AK-106X C CAPACITOR 10uF 10V K C0314 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0315 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0317 NDC31HJ-560X C CAPACITOR 56pF 50V J C0318 NDC31HJ-151X C CAPACITOR 150pF 50V J C0401 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1005 NCB31HK-152X C CAPACITOR 1500pF 50V K C1006 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1009 NDC31HJ-220X C CAPACITOR 22pF 50V J C1010 NDC31HJ-180X C CAPACITOR 18pF 50V J C1011 NDC31HJ-102X C CAPACITOR 1000pF 50V J C1012 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1014 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1015 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1016 NCB11AK-106X C CAPACITOR 10uF 10V K C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1018 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1019 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1021 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1023 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1025 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1026 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1028 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1029 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1030 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1031 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1032 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1033 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1034 NDC31HJ-390X C CAPACITOR 39pF 50V J C1035 NDC31HJ-680X C CAPACITOR 68pF 50V J C1037 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1038 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1039 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1040 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1041 NCB10JK-106X C CAPACITOR 10uF 6.3V K C1042 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1043 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1045 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1046 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1047 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1048 NCB11CK-105X C CAPACITOR 1uF 16V K C1049 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1050 NCB11CK-105X C CAPACITOR 1uF 16V K C1051 NCB11CK-105X C CAPACITOR 1uF 16V K C1061 NDC31HJ-4R0X C CAPACITOR 4pF 50V J C1062 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1063 NCB21AK-225X C CAPACITOR 2.2uF 10V K C1064 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1065 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1066 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1102 NDC31HJ-330X C CAPACITOR 33pF 50V J C1103 NDC31HJ-330X C CAPACITOR 33pF 50V J C1104 NDC31HJ-560X C CAPACITOR 56pF 50V J C1105 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1106 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1109 NDC31HJ-151X C CAPACITOR 150pF 50V J C1202 NDC31HJ-330X C CAPACITOR 33pF 50V J C1203 NDC31HJ-330X C CAPACITOR 33pF 50V J C1204 NDC31HJ-560X C CAPACITOR 56pF 50V J C1205 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1206 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1209 NDC31HJ-151X C CAPACITOR 150pF 50V J C1302 NDC31HJ-330X C CAPACITOR 33pF 50V J C1303 NDC31HJ-330X C CAPACITOR 33pF 50V J C1304 NDC31HJ-560X C CAPACITOR 56pF 50V J C1305 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1306 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1309 NDC31HJ-151X C CAPACITOR 150pF 50V J C1402 NDC31HJ-330X C CAPACITOR 33pF 50V J C1403 NDC31HJ-330X C CAPACITOR 33pF 50V J C1404 NDC31HJ-560X C CAPACITOR 56pF 50V J

C1405 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1406 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1409 NDC31HJ-151X C CAPACITOR 150pF 50V J C1502 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C1508 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1509 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1511 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J C3004 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3006 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3008 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3016 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3018 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3021 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3022 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3023 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3028 NDC31HJ-221X C CAPACITOR 220pF 50V J C3030 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3031 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3032 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3037 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3040 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3041 NDC31HJ-101X C CAPACITOR 100pF 50V J C3042 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3043 NDC31HJ-101X C CAPACITOR 100pF 50V J C3044 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3045 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3047 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3049 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3051 NCB31HK-472X C CAPACITOR 4700pF 50V K C3052 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3056 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3059 NCB31HK-223X C CAPACITOR 0.022uF 50V K C3060 NCB31HK-152X C CAPACITOR 1500pF 50V K C3063 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3065 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3066 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3067 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3068 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3069 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3070 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3071 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3072 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3074 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3076 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3097 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3101 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3105 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3126 NDC31HJ-390X C CAPACITOR 39pF 50V J C3406 NCB31HK-102X C CAPACITOR 1000pF 50V K C3501 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3503 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3506 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3507 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3508 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3509 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3511 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3516 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3517 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3518 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3519 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3524 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3527 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3531 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3532 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3533 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3535 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3539 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3540 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3542 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3543 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3548 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3549 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3550 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3551 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3552 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C4002 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4003 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4005 NCB31AK-105X C CAPACITOR 1uF 10V K C4006 NCB31AK-105X C CAPACITOR 1uF 10V K C4008 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4009 NCB31AK-105X C CAPACITOR 1uF 10V K

(No.YA209)3-21



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C4010 NCB31AK-105X C CAPACITOR 1uF 10V K C4011 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4012 NCB31AK-105X C CAPACITOR 1uF 10V K C4013 NCB31AK-105X C CAPACITOR 1uF 10V K C4016 NCB31AK-105X C CAPACITOR 1uF 10V K C4020 NCB31AK-105X C CAPACITOR 1uF 10V K C4022 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4023 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4029 NDC31HJ-470X C CAPACITOR 47pF 50V J C4030 NDC31HJ-470X C CAPACITOR 47pF 50V J C4901 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4902 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4906 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4907 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4908 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4909 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4910 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4911 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4913 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4914 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4915 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4916 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4917 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4919 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4920 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4921 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4922 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4923 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4925 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4926 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4931 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4932 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4933 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4934 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4935 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4936 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4937 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4938 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4939 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4940 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4941 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4942 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6013 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6014 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6015 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6512 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6513 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6514 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6515 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6516 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6521 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6522 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6523 NCB11AK-106X C CAPACITOR 10uF 10V K C7001 NCB31AK-105X C CAPACITOR 1uF 10V K C7002 NCB31AK-105X C CAPACITOR 1uF 10V K C7003 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C7006 NDC31HJ-150X C CAPACITOR 15pF 50V J C7007 NCB31AK-105X C CAPACITOR 1uF 10V K C7010 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7011 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7012 NCB31CK-104X C CAPACITOR 0.1uF 16V K C7013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7017 NDC31HJ-391X C CAPACITOR 390pF 50V J C7018 NCB31AK-105X C CAPACITOR 1uF 10V K C7025 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7203 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7401 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7402 NCB31AK-105X C CAPACITOR 1uF 10V K C7501 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7502 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7503 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7504 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7505 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7506 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7507 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7508 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7509 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7510 NEHL1CM-106X E CAPACITOR 10uF 16V M C7511 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7512 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7513 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7514 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7516 NDC31HJ-330X C CAPACITOR 33pF 50V J C7517 NDC31HJ-270X C CAPACITOR 27pF 50V J C7518 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

C7520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7521 NEHL1CM-106X E CAPACITOR 10uF 16V M C7522 NEHL1CM-106X E CAPACITOR 10uF 16V M C7523 NEHL1CM-476X E CAPACITOR 47uF 16V M C7524 NEHL1CM-476X E CAPACITOR 47uF 16V M C7525 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7526 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7527 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7528 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7529 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7531 NEHL1CM-476X E CAPACITOR 47uF 16V M C7532 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7533 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7534 NCB11AK-106X C CAPACITOR 10uF 10V K C7535 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7541 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7542 NEHL0GM-227X E CAPACITOR 220uF 4V M C7543 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7544 NEHL0JM-107X E CAPACITOR 100uF 6.3V M C7545 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7546 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7547 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7548 NEHL0GM-227X E CAPACITOR 220uF 4V M C7550 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7552 NCB31AK-105X C CAPACITOR 1uF 10V K C7553 NCB31HK-471X C CAPACITOR 470pF 50V K C7616 NCB11CK-105X C CAPACITOR 1uF 16V K C9002 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9005 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9007 NCB31HK-222X C CAPACITOR 2200pF 50V K C9008 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9010 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9012 NCB31HK-222X C CAPACITOR 2200pF 50V K C9102 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9104 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9105 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9106 NDC31HJ-121X C CAPACITOR 120pF 50V J C9107 NCB31HK-222X C CAPACITOR 2200pF 50V K C9108 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9111 NCB31HK-822X C CAPACITOR 8200pF 50V K C9112 NCB31HK-222X C CAPACITOR 2200pF 50V K C9202 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9204 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9205 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9207 NCB31HK-222X C CAPACITOR 2200pF 50V K C9209 NEZ0022-157X E CAPACITOR 150uF 10V M C9211 NCB31HK-153X C CAPACITOR 0.015uF 50V K C9212 NCB31HK-222X C CAPACITOR 2200pF 50V K

R0105 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0106 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0107 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0109 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R0110 NRSA63J-101X MG RESISTOR 100 R0114 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0116 NRSA63J-101X MG RESISTOR 100 R0119 NRSA63J-101X MG RESISTOR 100 R0121 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0122 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0125 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0126 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0127 NRSA63J-0R0X MG RESISTOR 0 R0128 NRSA63J-102X MG RESISTOR 1k R0129 NRSA63J-103X MG RESISTOR 10k R0131 NRSA63J-472X MG RESISTOR 4.7k R0132 NRSA63J-472X MG RESISTOR 4.7k R0133 NRSA63J-0R0X MG RESISTOR 0 R0134 NRSA63J-472X MG RESISTOR 4.7k R0137 NRSA63J-151X MG RESISTOR 150 R0138 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0140 NRSA63J-182X MG RESISTOR 1.8k R0141 NRSA63J-472X MG RESISTOR 4.7k R0205 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0206 NRSA63J-471X MG RESISTOR 470 R0207 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0208 NRSA63J-681X MG RESISTOR 680 R0209 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0210 NRSA63J-101X MG RESISTOR 100 R0211 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0214 NRSA63J-472X MG RESISTOR 4.7k R0216 NRSA63J-101X MG RESISTOR 100 R0219 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0221 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0222 NRSA63J-102X MG RESISTOR 1k R0225 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-22(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R0226 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0227 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0228 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0229 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0231 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0232 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0233 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0234 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0237 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0238 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0240 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0241 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0305 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0306 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0307 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0308 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R0309 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0310 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0311 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0314 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0316 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0319 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0321 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0322 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0325 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0326 NRSA63J-472X MG RESISTOR 4.7k R0327 NRSA63J-181X MG RESISTOR 180 R0328 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0329 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0331 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0332 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0333 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0334 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0337 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0338 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0340 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0341 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0501 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0504 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0506 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0508 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0516 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0517 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0520 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0522 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0523 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0524 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0527 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1001 NRSA63J-274X MG RESISTOR 270kΩ 1/16W J R1002 NRSA63D-101X MG RESISTOR 100Ω 1/16W D R1003 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1005 NRSA63J-103X MG RESISTOR 10k R1006 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1007 NRSA63J-101X MG RESISTOR 100 R1010 NRSA63J-183X MG RESISTOR 18k R1011 NQL093K-R10X P COIL 0.1uH K R1012 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1013 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R1014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1017 NRSA63J-101X MG RESISTOR 100 R1018 NRSA63J-332X MG RESISTOR 3.3k R1019 NRSA63J-0R0X MG RESISTOR 0 R1021 NRSA63J-0R0X MG RESISTOR 0 R1101 NRSA63J-182X MG RESISTOR 1.8k R1102 NRSA63J-101X MG RESISTOR 100 R1104 NRSA63J-332X MG RESISTOR 3.3k R1105 NRSA63J-561X MG RESISTOR 560 R1106 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R1107 NRSA63J-331X MG RESISTOR 330 R1113 NRSA63J-330X MG RESISTOR 33 R1201 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1203 NRSA63J-101X MG RESISTOR 100 R1204 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1205 NRSA63J-561X MG RESISTOR 560 R1206 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1207 NRSA63J-331X MG RESISTOR 330 R1213 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1301 NRSA63J-182X MG RESISTOR 1.8k R1303 NRSA63J-101X MG RESISTOR 100 R1304 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1305 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1306 NRSA63J-471X MG RESISTOR 470 R1307 NRSA63J-561X MG RESISTOR 560

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R1313 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1401 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1403 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1404 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1405 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1406 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1407 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1413 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1523 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z R1524 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R1525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1584 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2010 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3001 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3004 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3009 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3018 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3019 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3020 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3021 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3022 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R3023 NRSA63D-332X MG RESISTOR 3.3k R3024 NRSA63J-102X MG RESISTOR 1k R3028 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3029 NRSA63D-392X MG RESISTOR 3.9kΩ 1/16W D R3030 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3031 NRSA63D-151X MG RESISTOR 150Ω 1/16W D R3032 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3033 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3034 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3036 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3037 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3038 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R3040 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3041 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3042 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3043 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3044 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3045 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3047 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3048 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3053 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R3054 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3056 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3063 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3064 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3066 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3069 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3070 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3071 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3072 NRSA63J-0R0X MG RESISTOR 0 R3089 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3090 NRSA63J-220X MG RESISTOR 22 R3091 NRSA63J-220X MG RESISTOR 22 R3092 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3093 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3094 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3095 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3096 NRSA63J-510X MG RESISTOR 51 R3097 NRSA63J-510X MG RESISTOR 51 R3098 NRSA63J-510X MG RESISTOR 51 R3099 NRSA63J-510X MG RESISTOR 51 R3100 NRSA63J-510X MG RESISTOR 51 R3101 NRSA63J-510X MG RESISTOR 51 R3102 NRSA63J-510X MG RESISTOR 51 R3103 NRSA63J-510X MG RESISTOR 51 R3104 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3105 NRSA63J-510X MG RESISTOR 51 R3106 NRS144J-0R0X MG RESISTOR 0 R3122 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3126 NRSA63J-0R0X MG RESISTOR 0 R3131 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3132 NRSA63J-0R0X MG RESISTOR 0 R3151 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3152 NRSA63J-0R0X MG RESISTOR 0 R3153 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3155 NRSA63J-0R0X MG RESISTOR 0 R3157 NRSA63J-0R0X MG RESISTOR 0 R3159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3160 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3161 NRSA63J-0R0X MG RESISTOR 0 R3163 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-23



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R3164 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3165 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3166 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3167 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3168 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3169 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3170 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3171 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3178 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3181 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3207 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3502 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3503 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3505 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3507 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3509 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3511 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3514 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3516 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3518 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3520 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3522 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3524 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3525 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3527 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3529 NRSA63J-510X MG RESISTOR 51 R3531 NRSA63J-510X MG RESISTOR 51 R3533 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3536 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3538 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3540 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3542 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3544 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R4004 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4005 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4016 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4023 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4024 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4027 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4035 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4037 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4039 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4041 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4042 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4044 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4055 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4056 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R4057 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R4058 NRSA63J-221X MG RESISTOR 220 R4059 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4060 NRSA63J-470X MG RESISTOR 47 R4061 NRSA63J-0R0X MG RESISTOR 0 R4064 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4065 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4068 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4101 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4102 NRSA63J-0R0X MG RESISTOR 0 R4103 NRSA63J-0R0X MG RESISTOR 0 R4104 NRSA63J-0R0X MG RESISTOR 0 R4105 NRSA63J-101X MG RESISTOR 100 R4106 NRSA63J-101X MG RESISTOR 100 R4108 NRSA63J-0R0X MG RESISTOR 0 R4152 NRSA63J-0R0X MG RESISTOR 0 R6025 NRSA63J-101X MG RESISTOR 100 R6028 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6031 NRSA63J-101X MG RESISTOR 100 R6034 NRSA63J-102X MG RESISTOR 1k R6036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6038 NRSA63J-102X MG RESISTOR 1k R6039 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6040 NRSA63J-0R0X MG RESISTOR 0 R6043 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6048 NRSA63J-103X MG RESISTOR 10k R6057 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6058 NRSA63J-0R0X MG RESISTOR 0 R6059 NRSA63J-0R0X MG RESISTOR 0 R6507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6510 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6512 NRSA63J-102X MG RESISTOR 1k R6513 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R6514 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6515 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6521 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6529 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R6531 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6532 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6533 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6534 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6536 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6537 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6538 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6540 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6541 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6542 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6544 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6548 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6550 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6558 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7001 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7002 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7004 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7005 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7006 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7007 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7010 NRSA63J-101X MG RESISTOR 100 R7011 NRSA63J-101X MG RESISTOR 100 R7014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7016 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7017 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7021 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7022 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7023 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7024 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7025 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7026 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7029 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7031 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7033 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7034 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7035 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7038 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7039 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7040 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7041 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7042 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7043 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7047 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7048 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7049 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7057 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7058 NRSA63J-102X MG RESISTOR 1k R7059 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7060 NRSA63J-473X MG RESISTOR 47k R7061 NRSA63J-104X MG RESISTOR 100k R7063 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J R7064 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7066 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7067 NRSA63J-151X MG RESISTOR 150 R7068 NRSA63J-101X MG RESISTOR 100 R7069 NRSA63J-0R0X MG RESISTOR 0 R7070 NRSA63J-0R0X MG RESISTOR 0 R7071 NRSA63J-0R0X MG RESISTOR 0 R7072 NRSA63J-0R0X MG RESISTOR 0 R7077 NRSA63J-0R0X MG RESISTOR 0 R7080 NRSA63J-0R0X MG RESISTOR 0 R7081 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7082 NRSA63J-0R0X MG RESISTOR 0 R7085 NRSA63J-103X MG RESISTOR 10k R7086 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7087 NRSA63J-103X MG RESISTOR 10k R7088 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7089 NRSA63J-103X MG RESISTOR 10k R7090 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7091 NRSA63J-333X MG RESISTOR 33k R7092 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7093 NRSA63J-103X MG RESISTOR 10k R7094 NRSA63J-103X MG RESISTOR 10k R7095 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7096 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7097 NRSA63J-103X MG RESISTOR 10k R7098 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-24(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R7099 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7100 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7101 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7106 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7107 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7108 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7109 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7110 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7111 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7117 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7118 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7119 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7120 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7123 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7132 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7134 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7135 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7136 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7137 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7140 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7143 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7144 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7145 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7146 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7148 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7149 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7150 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7151 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7152 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7153 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7158 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7215 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7216 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7404 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7501 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7510 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7511 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7514 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7515 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7518 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7553 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7556 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7557 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7558 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7559 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7560 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7561 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7565 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7566 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7567 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7568 NRSA63J-222X MG RESISTOR 2.2k R7576 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7588 NRSA63J-221X MG RESISTOR 220 R7590 NRSA63J-101X MG RESISTOR 100 R7599 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7602 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7603 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7692 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7701 NRSA63J-472X MG RESISTOR 4.7k R7702 NRSA63J-101X MG RESISTOR 100 R7703 NRSA63J-101X MG RESISTOR 100 R7704 NRSA63J-101X MG RESISTOR 100 R7705 NRSA63J-101X MG RESISTOR 100 R7706 NRSA63J-101X MG RESISTOR 100 R7707 NRSA63J-101X MG RESISTOR 100 R7708 NRSA63J-820X MG RESISTOR 82 R7709 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7710 NRSA63J-103X MG RESISTOR 10k R7711 NRSA63J-103X MG RESISTOR 10k R7712 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7713 NRSA63J-101X MG RESISTOR 100 R7714 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7715 NRSA63J-101X MG RESISTOR 100 R7716 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7717 NRSA63J-101X MG RESISTOR 100 R7718 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7719 NRSA63J-184X MG RESISTOR 180k R7720 NRSA63J-472X MG RESISTOR 4.7k R9001 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9003 NRSA63D-203X MG RESISTOR 20k R9004 NRSA63D-124X MG RESISTOR 120k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

R9005 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9008 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9103 NRSA63D-203X MG RESISTOR 20kΩ 1/16W D R9104 NRSA63D-223X MG RESISTOR 22kΩ 1/16W D R9105 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9107 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9108 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9109 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9201 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9202 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9204 NRSA63D-272X MG RESISTOR 2.7kΩ 1/16W D R9205 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9206 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9207 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9208 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R9209 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9210 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RA1001 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1002 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1003 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA3002 NRZ0034-103W NET RESISTOR 10k RA3004 NRZ0034-103W NET RESISTOR 10k RA3013 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3014 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3015 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3016 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3018 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3020 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3022 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3023 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3024 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3025 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3026 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3028 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3030 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3032 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3502 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3506 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3508 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3512 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3516 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3518 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3521 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3523 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3526 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3530 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3531 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3536 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3540 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3542 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3545 NRZ0080-510X NET RESISTOR 51 RA3547 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA4007 NRZ0034-101W NET RESISTOR 100 RA4008 NRZ0034-101W NET RESISTOR 100 RA4009 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4010 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4011 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4012 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA6515 NRZ0034-0R0W NET RESISTOR 0 RA7007 NRZ0040-0R0X NET RESISTOR 0 RB2001 NRZ0080-0R0X NET RESISTOR 0 RB2002 NRZ0080-0R0X NET RESISTOR 0 RB2003 NRZ0080-0R0X NET RESISTOR 0

L0101 NQL092K-2R2X P COIL 2.2uH K L0102 NQL092K-1R0X P COIL 1uH K L0201 NQL092K-2R2X P COIL 2.2uH K L0202 NQL092K-1R0X P COIL 1uH K L0301 NQL092K-2R2X P COIL 2.2uH K L0302 NQL092K-1R0X P COIL 1uH K L0401 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1001 NQR0489-002X FERRITE BEADS L1002 NQR0489-002X FERRITE BEADS L1003 NQL092K-1R5X P COIL 1.5uH K L1004 NQR0489-002X FERRITE BEADS L1005 NQR0489-002X FERRITE BEADS L1006 NQR0489-002X FERRITE BEADS L1008 NQL79GM-220X COIL 22uH M L1010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1011 NQL79GM-470X COIL 47uH M L1101 NQL092K-6R8X P COIL 6.8uH K L1102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/16W J

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/16W J x4

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-25



Ref No. Part No. Part Name Description Local

L1103 NQL092K-1R0X P COIL 1uH K L1201 NQL092K-6R8X P COIL 6.8uH K L1203 NQL092K-1R0X P COIL 1uH K L1301 NQL092K-6R8X P COIL 6.8uH K L1303 NQL092K-1R0X P COIL 1uH K L1401 NQL092K-6R8X P COIL 6.8uH K L1403 NQL092K-1R0X P COIL 1uH K L1501 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3001 NQR0489-002X FERRITE BEADS L3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3006 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3008 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3009 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3012 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3501 NQR0413-003X FERRITE BEADS L4001 NQR0413-003X FERRITE BEADS L4002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L4003 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6501 NQR0351-001X FERRITE BEADS L6502 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6508 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6509 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6510 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L7001 NRSA63J-0R0X MG RESISTOR 0 L7002 NRSA63J-0R0X MG RESISTOR 0 L7003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7004 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7005 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7501 NQL092K-4R7X P COIL 4.7uH K L7502 NQL092K-4R7X P COIL 4.7uH K L7503 NQL092K-4R7X P COIL 4.7uH K L7504 NQL092K-4R7X P COIL 4.7uH K L7505 NQL092K-4R7X P COIL 4.7uH K L7506 NQL914M-4R7X COIL 4.7uH M L7507 NQL092K-4R7X P COIL 4.7uH K L7508 NQL092K-4R7X P COIL 4.7uH K L7509 NQL092K-4R7X P COIL 4.7uH K L7510 NQL092K-4R7X P COIL 4.7uH K L7511 NQL092K-4R7X P COIL 4.7uH K L7512 NQL914M-4R7X COIL 4.7uH M L7513 NQL914M-4R7X COIL 4.7uH M L7514 NQL092K-4R7X P COIL 4.7uH K L9001 NQL71EM-150X COIL 15uH M L9101 NQL71EM-150X COIL 15uH M L9201 NQL71EM-150X COIL 15uH M

CN001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30) K1001 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J K1004 NQR0489-002X FERRITE BEADS K3003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K3006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K7002 NRSA02J-0R0X MG RESISTOR 0 K7501 NRSA63J-390X MG RESISTOR 39Ω 1/16W J K7502 NRSA63J-0R0X MG RESISTOR 0 K7503 NQR0389-003X FERRITE BEADS LC0102 NQR0483-005X EMI FILTER 100uF 25V Z LC0519 NQR0416-001X EMI FILTER 240pF 16V M LC0524 NQR0415-005X EMI FILTER 0.1uF 25V M LC0525 NQR0470-003X EMI FILTER LC6501 NQR0479-001X EMI FILTER LC7501 NQR0313-007X EMI FILTER 1000pF 50V M LC7502 NQR0431-001X EMI FILTER 0.22uF 50V Z SL7001 NAX0613-001X C RESONATOR X1001 NAX0642-001X CRYSTAL X3001 NAX0635-001X CXO X3003 NAX0668-001X CXO X4001 NAX0669-001X C RESONATOR X7501 NAX0618-001X CRYSTAL

100pF 50V +50%-20%

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)

REFER TO PARTS LIST IN PAGE 3-19 FOR THIS P.W. BOARD.

3-26(No.YA209)

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/S, LT-Z32SX4S/S]



ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)

REFER TO PARTS LIST IN PAGE 3-6 FOR THIS P.W. BOARD.

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)

REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)

REFER TO PARTS LIST IN PAGE 3-12 FOR THIS P.W. BOARD.

DIGITAL SIGNAL P.W. BOARD ASS'Y

(LCA10428-68B) (SFL-0D306A)



Ref No. Part No. Part Name Description Local

IC0401 SN74AHCT1G32V-X IC IC1001 TC90A92AFG IC IC1002 MM1572FN-X IC IC1502 NJM2235V-X IC IC3001 JCC5055 IC IC3403 S-80928CLNB-W IC IC3501 K4D263238F-UC50 IC IC3502 K4D263238F-UC50 IC IC3503 LP2996MR-X IC IC4001 JCC5057 IC IC4003 AT29LV01-26D50BJ IC(MICRO C ROM) (SERVICE) IC4004 ATE256-Z32SX4B1 IC (SERVICE) IC6502 THC63LVDM83R-W IC IC7001 MN102H60KKC IC(MCU) IC7002 ATE256-Z32SX4B2 IC (SERVICE) IC7401 S-80828CLNB-W IC IC7501 SDA6000-B12 IC IC7502 S-80828CNNB-W IC IC7503 K4S641632H-UC75 IC IC7504 MBV160-Z26SX4B IC(MICRO C ROM) (SERVICE) IC7505 PQ2L3252MS-X IC IC7506 CD74HC4053PW-X IC IC7602 ATE32-Z32SX4B IC (SERVICE) IC9001 MP1580HS-X IC IC9101 MP1580HS-X IC IC9201 MP1580HS-X IC

Q0101 2SC3837K/NP/-X TRANSISTOR Q0102 2SA1022/BC/-X TRANSISTOR Q0104 2SA1022/BC/-X TRANSISTOR Q0105 2SC3928A/QR/-X TRANSISTOR Q0107 2SA1530A/QR/-X TRANSISTOR Q0108 2SC3928A/QR/-X TRANSISTOR Q0109 HN1C01F/Y/-X PAIR TRANSISTOR

Ref No. Part No. Part Name Description Local

Q0110 HN1C01F/Y/-X PAIR TRANSISTOR Q0201 2SC3837K/NP/-X TRANSISTOR Q0202 2SA1022/BC/-X TRANSISTOR Q0203 2SC3928A/QR/-X TRANSISTOR Q0204 2SA1022/BC/-X TRANSISTOR Q0205 2SC3928A/QR/-X TRANSISTOR Q0207 2SA1530A/QR/-X TRANSISTOR Q0208 2SC3928A/QR/-X TRANSISTOR Q0209 HN1C01F/Y/-X PAIR TRANSISTOR Q0210 HN1C01F/Y/-X PAIR TRANSISTOR Q0301 2SC3837K/NP/-X TRANSISTOR Q0302 2SA1022/BC/-X TRANSISTOR Q0303 2SC3928A/QR/-X TRANSISTOR Q0304 2SA1022/BC/-X TRANSISTOR Q0305 2SC3928A/QR/-X TRANSISTOR Q0307 2SA1530A/QR/-X TRANSISTOR Q0308 2SC3928A/QR/-X TRANSISTOR Q0309 HN1C01F/Y/-X PAIR TRANSISTOR Q0310 HN1C01F/Y/-X PAIR TRANSISTOR Q1001 UN2213-X DIGI TRANSISTOR Q1003 2SC3928A/QR/-X TRANSISTOR Q1004 2SA1530A/QR/-X TRANSISTOR Q1101 2SC3928A/QR/-X TRANSISTOR Q1103 2SA1530A/QR/-X TRANSISTOR Q1201 2SC3928A/QR/-X TRANSISTOR Q1203 2SA1530A/QR/-X TRANSISTOR Q1301 2SC3928A/QR/-X TRANSISTOR Q1303 2SA1530A/QR/-X TRANSISTOR Q1401 2SC3928A/QR/-X TRANSISTOR Q1403 2SA1530A/QR/-X TRANSISTOR Q3001 2SC3928A/QR/-X TRANSISTOR Q3002 2SA1530A/QR/-X TRANSISTOR Q3003 2SC3928A/QR/-X TRANSISTOR Q3004 2SA1530A/QR/-X TRANSISTOR Q6501 2SC3928A/QR/-X TRANSISTOR Q6502 2SC3928A/QR/-X TRANSISTOR Q7206 UN2213-X DIGI TRANSISTOR Q7207 DTA144EKA-X DIGI TRANSISTOR Q7501 2SA1162/YG/-X TRANSISTOR Q7508 DTC114EKA-X DIGI TRANSISTOR

D1001 EC30HA03L-X SB DIODE D1002 EC30HA03L-X SB DIODE D7001 MA111-X SI DIODE D7003 MA111-X SI DIODE D7005 MA8082/M/-X Z DIODE D7006 MA8082/M/-X Z DIODE D7007 MA8082/M/-X Z DIODE D7008 MA8082/M/-X Z DIODE D7009 MA8082/M/-X Z DIODE D7010 MA111-X SI DIODE D7203 MA111-X SI DIODE D7210 RB501V-40-X SB DIODE D7501 MA111-X SI DIODE D7502 MA111-X SI DIODE D9001 EC30HA03L-X SB DIODE D9003 PTZ3.9B-X Z DIODE D9101 EC30HA03L-X SB DIODE D9102 EC30HA03L-X SB DIODE D9103 PTZ3.9B-X Z DIODE D9104 MA111-X SI DIODE D9201 EC30HA03L-X SB DIODE D9203 PTZ3.9B-X Z DIODE D9204 MA111-X SI DIODE

C0103 NDC31HJ-330X C CAPACITOR 33pF 50V J C0105 NDC31HJ-270X C CAPACITOR 27pF 50V J C0107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0109 NCB11AK-106X C CAPACITOR 10uF 10V K C0110 NCB11AK-106X C CAPACITOR 10uF 10V K C0111 NDC31HJ-820X C CAPACITOR 82pF 50V J C0112 NDC31HJ-820X C CAPACITOR 82pF 50V J C0113 NCB11AK-106X C CAPACITOR 10uF 10V K C0114 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0115 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0116 NCB11AK-106X C CAPACITOR 10uF 10V K C0117 NDC31HJ-560X C CAPACITOR 56pF 50V J C0118 NDC31HJ-151X C CAPACITOR 150pF 50V J C0203 NDC31HJ-330X C CAPACITOR 33pF 50V J C0205 NDC31HJ-270X C CAPACITOR 27pF 50V J C0207 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0209 NCB11AK-106X C CAPACITOR 10uF 10V K C0210 NCB11AK-106X C CAPACITOR 10uF 10V K C0211 NDC31HJ-820X C CAPACITOR 82pF 50V J

(No.YA209)3-27



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C0212 NDC31HJ-820X C CAPACITOR 82pF 50V J C0213 NCB11AK-106X C CAPACITOR 10uF 10V K C0214 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0215 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0217 NDC31HJ-560X C CAPACITOR 56pF 50V J C0218 NDC31HJ-151X C CAPACITOR 150pF 50V J C0303 NDC31HJ-330X C CAPACITOR 33pF 50V J C0305 NDC31HJ-270X C CAPACITOR 27pF 50V J C0307 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0309 NCB11AK-106X C CAPACITOR 10uF 10V K C0310 NCB11AK-106X C CAPACITOR 10uF 10V K C0311 NDC31HJ-820X C CAPACITOR 82pF 50V J C0312 NDC31HJ-820X C CAPACITOR 82pF 50V J C0313 NCB11AK-106X C CAPACITOR 10uF 10V K C0314 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0315 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C0317 NDC31HJ-560X C CAPACITOR 56pF 50V J C0318 NDC31HJ-151X C CAPACITOR 150pF 50V J C0401 NCB31CK-104X C CAPACITOR 0.1uF 16V K C1001 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1005 NCB31HK-152X C CAPACITOR 1500pF 50V K C1006 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1009 NDC31HJ-220X C CAPACITOR 22pF 50V J C1010 NDC31HJ-180X C CAPACITOR 18pF 50V J C1011 NDC31HJ-102X C CAPACITOR 1000pF 50V J C1012 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1014 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1015 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1016 NCB11AK-106X C CAPACITOR 10uF 10V K C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1018 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1019 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1021 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1023 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1025 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1026 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1028 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1029 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1030 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1031 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1032 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1033 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1034 NDC31HJ-390X C CAPACITOR 39pF 50V J C1035 NDC31HJ-680X C CAPACITOR 68pF 50V J C1037 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1038 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1039 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1040 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1041 NCB10JK-106X C CAPACITOR 10uF 6.3V K C1042 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1043 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1045 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1046 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1047 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1048 NCB11CK-105X C CAPACITOR 1uF 16V K C1049 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1050 NCB11CK-105X C CAPACITOR 1uF 16V K C1051 NCB11CK-105X C CAPACITOR 1uF 16V K C1061 NDC31HJ-4R0X C CAPACITOR 4pF 50V J C1062 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1063 NCB21AK-225X C CAPACITOR 2.2uF 10V K C1064 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1065 NCB30JK-105X C CAPACITOR 1uF 6.3V K C1066 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M C1102 NDC31HJ-330X C CAPACITOR 33pF 50V J C1103 NDC31HJ-330X C CAPACITOR 33pF 50V J C1104 NDC31HJ-560X C CAPACITOR 56pF 50V J C1105 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1106 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1109 NDC31HJ-151X C CAPACITOR 150pF 50V J C1202 NDC31HJ-330X C CAPACITOR 33pF 50V J C1203 NDC31HJ-330X C CAPACITOR 33pF 50V J C1204 NDC31HJ-560X C CAPACITOR 56pF 50V J C1205 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1206 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1209 NDC31HJ-151X C CAPACITOR 150pF 50V J C1302 NDC31HJ-330X C CAPACITOR 33pF 50V J C1303 NDC31HJ-330X C CAPACITOR 33pF 50V J C1304 NDC31HJ-560X C CAPACITOR 56pF 50V J C1305 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1306 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1309 NDC31HJ-151X C CAPACITOR 150pF 50V J C1402 NDC31HJ-330X C CAPACITOR 33pF 50V J C1403 NDC31HJ-330X C CAPACITOR 33pF 50V J C1404 NDC31HJ-560X C CAPACITOR 56pF 50V J

C1405 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1406 NCB31HK-104X C CAPACITOR 0.1uF 50V K C1409 NDC31HJ-151X C CAPACITOR 150pF 50V J C1502 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C1508 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C1509 NCB31HK-103X C CAPACITOR 0.01uF 50V K C1511 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J C3004 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3006 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3008 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3009 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3010 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3016 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3018 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3019 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3021 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3022 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3023 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3028 NDC31HJ-221X C CAPACITOR 220pF 50V J C3030 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3031 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3032 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3037 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3040 NCB31CK-104X C CAPACITOR 0.1uF 16V K C3041 NDC31HJ-101X C CAPACITOR 100pF 50V J C3042 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3043 NDC31HJ-101X C CAPACITOR 100pF 50V J C3044 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3045 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3047 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3049 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3051 NCB31HK-472X C CAPACITOR 4700pF 50V K C3052 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3056 NCB31AK-334X C CAPACITOR 0.33uF 10V K C3059 NCB31HK-223X C CAPACITOR 0.022uF 50V K C3060 NCB31HK-152X C CAPACITOR 1500pF 50V K C3063 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3065 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3066 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3067 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3068 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3069 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3070 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3071 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3072 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3074 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3076 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3097 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3101 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3105 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3111 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3126 NDC31HJ-390X C CAPACITOR 39pF 50V J C3406 NCB31HK-102X C CAPACITOR 1000pF 50V K C3501 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3503 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3506 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3507 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3508 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3509 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3511 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3516 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3517 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3518 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3519 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3524 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3527 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3531 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3532 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3533 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C3535 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3539 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3540 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3542 NCF31CZ-474X C CAPACITOR 0.47uF 16V Z C3543 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3548 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3549 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3550 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C3551 NBZ0007-107X SP E CAPACITOR 100uF 4V M C3552 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C4002 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4003 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4005 NCB31AK-105X C CAPACITOR 1uF 10V K C4006 NCB31AK-105X C CAPACITOR 1uF 10V K C4008 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4009 NCB31AK-105X C CAPACITOR 1uF 10V K

3-28(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

C4010 NCB31AK-105X C CAPACITOR 1uF 10V K C4011 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C4012 NCB31AK-105X C CAPACITOR 1uF 10V K C4013 NCB31AK-105X C CAPACITOR 1uF 10V K C4016 NCB31AK-105X C CAPACITOR 1uF 10V K C4020 NCB31AK-105X C CAPACITOR 1uF 10V K C4022 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4023 NCB31HK-104X C CAPACITOR 0.1uF 50V K C4029 NDC31HJ-470X C CAPACITOR 47pF 50V J C4030 NDC31HJ-470X C CAPACITOR 47pF 50V J C4901 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4902 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4906 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4907 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4908 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4909 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4910 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4911 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4913 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4914 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4915 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4916 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4917 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4919 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4920 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4921 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4922 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4923 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4925 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4926 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4931 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4932 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4933 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4934 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4935 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4936 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4937 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4938 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4939 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4940 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4941 NCB31HK-103X C CAPACITOR 0.01uF 50V K C4942 NCB31HK-103X C CAPACITOR 0.01uF 50V K C6013 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6014 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6015 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6512 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6513 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6514 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6515 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6516 NCB31CK-104X C CAPACITOR 0.1uF 16V K C6520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6521 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6522 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C6523 NCB11AK-106X C CAPACITOR 10uF 10V K C7001 NCB31AK-105X C CAPACITOR 1uF 10V K C7002 NCB31AK-105X C CAPACITOR 1uF 10V K C7003 NCF11CZ-475X C CAPACITOR 4.7uF 16V Z C7006 NDC31HJ-150X C CAPACITOR 15pF 50V J C7007 NCB31AK-105X C CAPACITOR 1uF 10V K C7010 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7011 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7012 NCB31CK-104X C CAPACITOR 0.1uF 16V K C7013 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7017 NDC31HJ-391X C CAPACITOR 390pF 50V J C7018 NCB31AK-105X C CAPACITOR 1uF 10V K C7025 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7203 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7401 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7402 NCB31AK-105X C CAPACITOR 1uF 10V K C7501 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7502 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7503 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7504 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7505 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7506 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7507 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7508 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7509 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7510 NEH71CM-106X E CAPACITOR 10uF 16V M C7511 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7512 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7513 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7514 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7515 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7516 NDC31HJ-330X C CAPACITOR 33pF 50V J C7517 NDC31HJ-270X C CAPACITOR 27pF 50V J C7518 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

C7520 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7521 NEH71CM-106X E CAPACITOR 10uF 16V M C7522 NEH71CM-106X E CAPACITOR 10uF 16V M C7523 NEH71CM-476X E CAPACITOR 47uF 16V M C7524 NEH71CM-476X E CAPACITOR 47uF 16V M C7525 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7526 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7527 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7528 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7529 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7530 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7531 NEH71CM-476X E CAPACITOR 47uF 16V M C7532 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7533 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7534 NCB11AK-106X C CAPACITOR 10uF 10V K C7535 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7541 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7542 NEH70GM-227X E CAPACITOR 220uF 4V M C7543 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7544 NEH70JM-107X E CAPACITOR 100uF 6.3V M C7545 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7546 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z C7547 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K C7548 NEH70GM-227X E CAPACITOR 220uF 4V M C7550 NCB31HK-103X C CAPACITOR 0.01uF 50V K C7552 NCB31AK-105X C CAPACITOR 1uF 10V K C7553 NCB31HK-471X C CAPACITOR 470pF 50V K C7616 NCB11CK-105X C CAPACITOR 1uF 16V K C9002 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9004 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9005 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9007 NCB31HK-222X C CAPACITOR 2200pF 50V K C9008 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9010 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9012 NCB31HK-222X C CAPACITOR 2200pF 50V K C9102 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9104 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9105 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9106 NDC31HJ-121X C CAPACITOR 120pF 50V J C9107 NCB31HK-222X C CAPACITOR 2200pF 50V K C9108 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9111 NCB31HK-822X C CAPACITOR 8200pF 50V K C9112 NCB31HK-222X C CAPACITOR 2200pF 50V K C9202 NCJ41EK-106X-U C CAPACITOR 10mF 25V K C9204 NCB31HK-103X C CAPACITOR 0.01uF 50V K C9205 NCJ41CK-226X-U C CAPACITOR 22mF 16V K C9207 NCB31HK-222X C CAPACITOR 2200pF 50V K C9209 NEZ0022-157X E CAPACITOR 150uF 10V M C9211 NCB31HK-153X C CAPACITOR 0.015uF 50V K C9212 NCB31HK-222X C CAPACITOR 2200pF 50V K

R0105 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0106 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0107 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0109 NRSA63J-151X MG RESISTOR 150Ω 1/16W J R0110 NRSA63J-101X MG RESISTOR 100 R0114 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0116 NRSA63J-101X MG RESISTOR 100 R0119 NRSA63J-101X MG RESISTOR 100 R0121 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0122 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0125 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0126 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0127 NRSA63J-0R0X MG RESISTOR 0 R0128 NRSA63J-102X MG RESISTOR 1k R0129 NRSA63J-103X MG RESISTOR 10k R0131 NRSA63J-472X MG RESISTOR 4.7k R0132 NRSA63J-472X MG RESISTOR 4.7k R0133 NRSA63J-0R0X MG RESISTOR 0 R0134 NRSA63J-472X MG RESISTOR 4.7k R0137 NRSA63J-151X MG RESISTOR 150 R0138 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0140 NRSA63J-182X MG RESISTOR 1.8k R0141 NRSA63J-472X MG RESISTOR 4.7k R0205 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0206 NRSA63J-471X MG RESISTOR 470 R0207 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0208 NRSA63J-681X MG RESISTOR 680 R0209 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0210 NRSA63J-101X MG RESISTOR 100 R0211 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0214 NRSA63J-472X MG RESISTOR 4.7k R0216 NRSA63J-101X MG RESISTOR 100 R0219 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0221 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0222 NRSA63J-102X MG RESISTOR 1k R0225 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-29



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R0226 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0227 NRSA63J-181X MG RESISTOR 180Ω 1/16W J R0228 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0229 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0231 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0232 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0233 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0234 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0237 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0238 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0240 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0241 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0305 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0306 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0307 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R0308 NRSA63J-681X MG RESISTOR 680Ω 1/16W J R0309 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R0310 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0311 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0314 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0316 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0319 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0321 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R0322 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0325 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R0326 NRSA63J-472X MG RESISTOR 4.7k R0327 NRSA63J-181X MG RESISTOR 180 R0328 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R0329 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R0331 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0332 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0333 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0334 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0337 NRSA63J-271X MG RESISTOR 270Ω 1/16W J R0338 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R0340 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R0341 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R0501 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0504 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0506 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0508 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0516 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0517 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0520 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0522 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0523 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0524 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R0527 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1001 NRSA63J-274X MG RESISTOR 270kΩ 1/16W J R1002 NRSA63D-101X MG RESISTOR 100Ω 1/16W D R1003 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R1004 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R1005 NRSA63J-103X MG RESISTOR 10k R1006 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1007 NRSA63J-101X MG RESISTOR 100 R1010 NRSA63J-183X MG RESISTOR 18k R1011 NQL093K-R10X P COIL 0.1uH K R1012 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J R1013 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R1014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1017 NRSA63J-101X MG RESISTOR 100 R1018 NRSA63J-332X MG RESISTOR 3.3k R1019 NRSA63J-0R0X MG RESISTOR 0 R1021 NRSA63J-0R0X MG RESISTOR 0 R1101 NRSA63J-182X MG RESISTOR 1.8k R1102 NRSA63J-101X MG RESISTOR 100 R1104 NRSA63J-332X MG RESISTOR 3.3k R1105 NRSA63J-561X MG RESISTOR 560 R1106 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J R1107 NRSA63J-331X MG RESISTOR 330 R1113 NRSA63J-330X MG RESISTOR 33 R1201 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1203 NRSA63J-101X MG RESISTOR 100 R1204 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1205 NRSA63J-561X MG RESISTOR 560 R1206 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1207 NRSA63J-331X MG RESISTOR 330 R1213 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1301 NRSA63J-182X MG RESISTOR 1.8k R1303 NRSA63J-101X MG RESISTOR 100 R1304 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1305 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1306 NRSA63J-471X MG RESISTOR 470 R1307 NRSA63J-561X MG RESISTOR 560

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R1313 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1401 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J R1403 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R1404 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J R1405 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1406 NRSA63J-471X MG RESISTOR 470Ω 1/16W J R1407 NRSA63J-561X MG RESISTOR 560Ω 1/16W J R1413 NRSA63J-330X MG RESISTOR 33Ω 1/16W J R1523 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z R1524 NRSA63J-474X MG RESISTOR 470kΩ 1/16W J R1525 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R1584 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R2010 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3001 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3004 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R3006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3008 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3009 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3018 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3019 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3020 NRSA02J-3R3X MG RESISTOR 3.3Ω 1/10W J R3021 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3022 NRSA63D-332X MG RESISTOR 3.3kΩ 1/16W D R3023 NRSA63D-332X MG RESISTOR 3.3k R3024 NRSA63J-102X MG RESISTOR 1k R3028 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3029 NRSA63D-392X MG RESISTOR 3.9kΩ 1/16W D R3030 NRSA63D-102X MG RESISTOR 1kΩ 1/16W D R3031 NRSA63D-151X MG RESISTOR 150Ω 1/16W D R3032 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3033 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3034 NRSA63J-5R6X MG RESISTOR 5.6Ω 1/16W J R3036 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3037 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3038 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R3040 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3041 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R3042 NRSA63J-201X MG RESISTOR 200Ω 1/16W J R3043 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3044 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3045 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3047 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J R3048 NRSA63J-821X MG RESISTOR 820Ω 1/16W J R3053 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J R3054 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3056 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3063 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3064 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3066 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R3069 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3070 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3071 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3072 NRSA63J-0R0X MG RESISTOR 0 R3089 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3090 NRSA63J-220X MG RESISTOR 22 R3091 NRSA63J-220X MG RESISTOR 22 R3092 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3093 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3094 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3095 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3096 NRSA63J-510X MG RESISTOR 51 R3097 NRSA63J-510X MG RESISTOR 51 R3098 NRSA63J-510X MG RESISTOR 51 R3099 NRSA63J-510X MG RESISTOR 51 R3100 NRSA63J-510X MG RESISTOR 51 R3101 NRSA63J-510X MG RESISTOR 51 R3102 NRSA63J-510X MG RESISTOR 51 R3103 NRSA63J-510X MG RESISTOR 51 R3104 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3105 NRSA63J-510X MG RESISTOR 51 R3106 NRS144J-0R0X MG RESISTOR 0 R3122 NRSA63J-220X MG RESISTOR 22Ω 1/16W J R3126 NRSA63J-0R0X MG RESISTOR 0 R3131 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3132 NRSA63J-0R0X MG RESISTOR 0 R3151 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3152 NRSA63J-0R0X MG RESISTOR 0 R3153 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3155 NRSA63J-0R0X MG RESISTOR 0 R3157 NRSA63J-0R0X MG RESISTOR 0 R3159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3160 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3161 NRSA63J-0R0X MG RESISTOR 0 R3163 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-30(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R3164 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3165 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3166 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3167 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3168 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3169 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3170 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3171 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3178 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R3181 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3207 NRS144J-0R0X MG RESISTOR 0Ω 1/4W J R3502 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3503 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3505 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3507 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3509 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3511 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3514 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3516 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3518 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3520 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3522 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3524 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3525 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3527 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3529 NRSA63J-510X MG RESISTOR 51 R3531 NRSA63J-510X MG RESISTOR 51 R3533 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3536 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3538 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3540 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3542 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R3544 NRSA63J-510X MG RESISTOR 51Ω 1/16W J R4004 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4005 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4007 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4016 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4023 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4024 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R4027 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4035 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4037 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4039 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4041 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4042 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4044 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R4055 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4056 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R4057 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R4058 NRSA63J-221X MG RESISTOR 220 R4059 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4060 NRSA63J-470X MG RESISTOR 47 R4061 NRSA63J-0R0X MG RESISTOR 0 R4064 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4065 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4068 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4101 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R4102 NRSA63J-0R0X MG RESISTOR 0 R4103 NRSA63J-0R0X MG RESISTOR 0 R4104 NRSA63J-0R0X MG RESISTOR 0 R4105 NRSA63J-101X MG RESISTOR 100 R4106 NRSA63J-101X MG RESISTOR 100 R4108 NRSA63J-0R0X MG RESISTOR 0 R4152 NRSA63J-0R0X MG RESISTOR 0 R6025 NRSA63J-101X MG RESISTOR 100 R6028 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6031 NRSA63J-101X MG RESISTOR 100 R6034 NRSA63J-102X MG RESISTOR 1k R6036 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6038 NRSA63J-102X MG RESISTOR 1k R6039 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6040 NRSA63J-0R0X MG RESISTOR 0 R6043 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6048 NRSA63J-103X MG RESISTOR 10k R6057 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6058 NRSA63J-0R0X MG RESISTOR 0 R6059 NRSA63J-0R0X MG RESISTOR 0 R6507 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6510 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6512 NRSA63J-102X MG RESISTOR 1k R6513 NRSA63J-0R0X MG RESISTOR 0

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R6514 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6515 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R6521 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6529 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R6531 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6532 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6533 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6534 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6536 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6537 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6538 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6540 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6541 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6542 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6544 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R6548 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R6550 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R6558 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R7001 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7002 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7004 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7005 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7006 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7007 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7008 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7010 NRSA63J-101X MG RESISTOR 100 R7011 NRSA63J-101X MG RESISTOR 100 R7014 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7015 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7016 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7017 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7018 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7019 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7021 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7022 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7023 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7024 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7025 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7026 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7029 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7031 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7033 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7034 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7035 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7038 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7039 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7040 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7041 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7042 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7043 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7046 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7047 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7048 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7049 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7057 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7058 NRSA63J-102X MG RESISTOR 1k R7059 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7060 NRSA63J-473X MG RESISTOR 47k R7061 NRSA63J-104X MG RESISTOR 100k R7063 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J R7064 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7065 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7066 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7067 NRSA63J-151X MG RESISTOR 150 R7068 NRSA63J-101X MG RESISTOR 100 R7069 NRSA63J-0R0X MG RESISTOR 0 R7070 NRSA63J-0R0X MG RESISTOR 0 R7071 NRSA63J-0R0X MG RESISTOR 0 R7072 NRSA63J-0R0X MG RESISTOR 0 R7077 NRSA63J-0R0X MG RESISTOR 0 R7080 NRSA63J-0R0X MG RESISTOR 0 R7081 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7082 NRSA63J-0R0X MG RESISTOR 0 R7085 NRSA63J-103X MG RESISTOR 10k R7086 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7087 NRSA63J-103X MG RESISTOR 10k R7088 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7089 NRSA63J-103X MG RESISTOR 10k R7090 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7091 NRSA63J-333X MG RESISTOR 33k R7092 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7093 NRSA63J-103X MG RESISTOR 10k R7094 NRSA63J-103X MG RESISTOR 10k R7095 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7096 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7097 NRSA63J-103X MG RESISTOR 10k R7098 NRSA63J-102X MG RESISTOR 1k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

(No.YA209)3-31



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

R7099 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7100 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7101 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J R7106 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7107 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7108 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7109 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7110 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7111 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7117 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7118 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7119 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7120 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7123 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7132 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7134 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7135 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7136 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7137 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7140 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7143 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7144 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7145 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7146 NCB30JK-105X C CAPACITOR 1uF 6.3V K R7148 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7149 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7150 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7151 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7152 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J R7153 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7158 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7159 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7215 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J R7216 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7401 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7404 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7501 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7510 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7511 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7514 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7515 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7518 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7553 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7556 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7557 NRSA63J-221X MG RESISTOR 220Ω 1/16W J R7558 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7559 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7560 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R7561 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R7565 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J R7566 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7567 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J R7568 NRSA63J-222X MG RESISTOR 2.2k R7576 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7588 NRSA63J-221X MG RESISTOR 220 R7590 NRSA63J-101X MG RESISTOR 100 R7599 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7602 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7603 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7692 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7701 NRSA63J-472X MG RESISTOR 4.7k R7702 NRSA63J-101X MG RESISTOR 100 R7703 NRSA63J-101X MG RESISTOR 100 R7704 NRSA63J-101X MG RESISTOR 100 R7705 NRSA63J-101X MG RESISTOR 100 R7706 NRSA63J-101X MG RESISTOR 100 R7707 NRSA63J-101X MG RESISTOR 100 R7708 NRSA63J-820X MG RESISTOR 82 R7709 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7710 NRSA63J-103X MG RESISTOR 10k R7711 NRSA63J-103X MG RESISTOR 10k R7712 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R7713 NRSA63J-101X MG RESISTOR 100 R7714 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7715 NRSA63J-101X MG RESISTOR 100 R7716 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7717 NRSA63J-101X MG RESISTOR 100 R7718 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R7719 NRSA63J-184X MG RESISTOR 180k R7720 NRSA63J-472X MG RESISTOR 4.7k R9001 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9003 NRSA63D-203X MG RESISTOR 20k R9004 NRSA63D-124X MG RESISTOR 120k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

R9005 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9006 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9008 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9103 NRSA63D-203X MG RESISTOR 20kΩ 1/16W D R9104 NRSA63D-223X MG RESISTOR 22kΩ 1/16W D R9105 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J R9107 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9108 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9109 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9201 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R9202 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9204 NRSA63D-272X MG RESISTOR 2.7kΩ 1/16W D R9205 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D R9206 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J R9207 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J R9208 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J R9209 NRSA63J-680X MG RESISTOR 68Ω 1/16W J R9210 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J RA1001 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1002 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA1003 NRZ0034-103W NET RESISTOR 10kΩ 1/32W J x4 RA3002 NRZ0034-103W NET RESISTOR 10k RA3004 NRZ0034-103W NET RESISTOR 10k RA3013 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3014 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3015 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3016 NRZ0034-220W NET RESISTOR 22Ω 1/32W J x4 RA3018 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3020 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3022 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3023 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3024 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3025 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3026 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3028 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3030 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3032 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3502 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3506 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3508 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3512 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3516 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3518 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3521 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3523 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3526 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3530 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3531 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3536 NRZ0080-510X NET RESISTOR 51Ω 1/16W J RA3540 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3542 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA3545 NRZ0080-510X NET RESISTOR 51 RA3547 NRZ0040-510X NET RESISTOR 51Ω 1/16W J x4 RA4007 NRZ0034-101W NET RESISTOR 100 RA4008 NRZ0034-101W NET RESISTOR 100 RA4009 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4010 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4011 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA4012 NRZ0034-101W NET RESISTOR 100Ω 1/32W J x4 RA6515 NRZ0034-0R0W NET RESISTOR 0 RA7007 NRZ0040-0R0X NET RESISTOR 0 RB2001 NRZ0080-0R0X NET RESISTOR 0 RB2002 NRZ0080-0R0X NET RESISTOR 0 RB2003 NRZ0080-0R0X NET RESISTOR 0

L0101 NQL092K-2R2X P COIL 2.2uH K L0102 NQL092K-1R0X P COIL 1uH K L0201 NQL092K-2R2X P COIL 2.2uH K L0202 NQL092K-1R0X P COIL 1uH K L0301 NQL092K-2R2X P COIL 2.2uH K L0302 NQL092K-1R0X P COIL 1uH K L0401 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1001 NQR0489-002X FERRITE BEADS L1002 NQR0489-002X FERRITE BEADS L1003 NQL092K-1R5X P COIL 1.5uH K L1004 NQR0489-002X FERRITE BEADS L1005 NQR0489-002X FERRITE BEADS L1006 NQR0489-002X FERRITE BEADS L1008 NQL79GM-220X COIL 22uH M L1010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L1011 NQL79GM-470X COIL 47uH M L1101 NQL092K-6R8X P COIL 6.8uH K L1102 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/16W J

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/32W J x4

Ω

1/16W J x4

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-32(No.YA209)



Ref No. Part No. Part Name Description Local



Ref No. Part No. Part Name Description Local

L1103 NQL092K-1R0X P COIL 1uH K L1201 NQL092K-6R8X P COIL 6.8uH K L1203 NQL092K-1R0X P COIL 1uH K L1301 NQL092K-6R8X P COIL 6.8uH K L1303 NQL092K-1R0X P COIL 1uH K L1401 NQL092K-6R8X P COIL 6.8uH K L1403 NQL092K-1R0X P COIL 1uH K L1501 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3001 NQR0489-002X FERRITE BEADS L3005 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3006 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3007 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3008 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3009 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3010 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3012 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L3501 NQR0413-003X FERRITE BEADS L4001 NQR0413-003X FERRITE BEADS L4002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L4003 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6501 NQR0351-001X FERRITE BEADS L6502 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J L6508 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6509 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L6510 NRZ0034-0R0W NET RESISTOR 0Ω 1/32W J x4 L7001 NRSA63J-0R0X MG RESISTOR 0 L7002 NRSA63J-0R0X MG RESISTOR 0 L7003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7004 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7005 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J L7501 NQL092K-4R7X P COIL 4.7uH K L7502 NQL092K-4R7X P COIL 4.7uH K L7503 NQL092K-4R7X P COIL 4.7uH K L7504 NQL092K-4R7X P COIL 4.7uH K L7505 NQL092K-4R7X P COIL 4.7uH K L7506 NQL914M-4R7X COIL 4.7uH M L7507 NQL092K-4R7X P COIL 4.7uH K L7508 NQL092K-4R7X P COIL 4.7uH K L7509 NQL092K-4R7X P COIL 4.7uH K

Ω

1/16W J

Ω

1/16W J

L7510 NQL092K-4R7X P COIL 4.7uH K L7511 NQL092K-4R7X P COIL 4.7uH K L7512 NQL914M-4R7X COIL 4.7uH M L7513 NQL914M-4R7X COIL 4.7uH M L7514 NQL092K-4R7X P COIL 4.7uH K L9001 NQL71EM-150X COIL 15uH M L9101 NQL71EM-150X COIL 15uH M L9201 NQL71EM-150X COIL 15uH M

CN001 QGF0508F1-50X CONNECTOR FFC/FPC (1-50) CN002 QGF0508F1-30X CONNECTOR FFC/FPC (1-30) K1001 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J K1004 NQR0489-002X FERRITE BEADS K3003 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K3006 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K7002 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J K7501 NRSA63J-390X MG RESISTOR 39Ω 1/16W J K7502 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J K7503 NQR0389-003X FERRITE BEADS LC0102 NQR0483-005X EMI FILTER 100uF 25V Z LC0519 NQR0416-001X EMI FILTER 240pF 16V M LC0524 NQR0415-005X EMI FILTER 0.1uF 25V M LC0525 NQR0470-003X EMI FILTER LC6501 NQR0479-001X EMI FILTER LC7501 NQR0313-007X EMI FILTER 1000pF 50V M LC7502 NQR0431-001X EMI FILTER 0.22uF 50V Z SL7001 NAX0613-001X C RESONATOR X1001 NAX0642-001X CRYSTAL X3001 NAX0635-001X CXO X3003 NAX0668-001X CXO X4001 NAX0669-001X C RESONATOR X7501 NAX0618-001X CRYSTAL

100pF 50V +50%-20%

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)

REFER TO PARTS LIST IN PAGE 3-19 FOR THIS P.W. BOARD.

REMOTE CONTROL UNIT PARTS LIST (RM-C1830-1C)



Ref No. Part No. Part Name Description Local

2AA070311 BATTERY COVER

PACKING PARTS LIST

 Ref.No. Part No. Part Name Description Local

001 LC10006-048A PACKING CASE 002 LC21688-001A CUSHION 003 LC11983-001B CUSHION ASSY 4pcs in 1set 004 QPA01002305 POLY BAG 10cm x 23cm LT-Z32SX4B,LT-Z32SX4B/A 005 LCT1516-002A CAUTION SHEET 006 GG30097-004A-H POLY BAG 007 RM-C1830-1C REMOCON UNIT Inc.POLY BAG 008 QAM0690-001 D CABLE Inc.POLY BAG 009 QPA02503505P POLY BAG 25cm x 35cm 010 ------------ WARRANTY CARD BT-56012-1 LT-Z32SX4B/A

 011 LCT1732-002A INST BOOK English  012 LCT1733-002A INST BOOK French/Russian/Traditional Chinese/Arabic/Persian LT-Z32SX4B,LT-Z32SX4B/S,LT-Z32SX4S/S

013 ------------ BATTERY R6P/AA(x2) 014 GG20025-001A-H CORNER LABEL 2pcs in 1set

(No.YA209)3-33

PACKING

007

003

006

008

002

010

013

003

009

011



012

005

014

004

001

014

003

3-34(No.YA209)

JVC LT-Z32SX4B, LT-Z32SX4B/A, LT-Z32SX4B/S, LT-Z32SX4S/S Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual

USING P.W. BOARD & REMOTE CONTROL UNIT

EXPLODED VIEW PARTS LIST

EXPLODED VIEW

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B]

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)

DIGITAL SIGNAL P.W. BOARD ASS'Y (LCA10428-67B) (SFL-0D305A)

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/A]

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)

PRINTED WIRING BOARD PARTS LIST [LT-Z32SX4B/S, LT-Z32SX4S/S]

ANALOG SIGNAL P.W. BOARD ASS'Y (LCA90350-15B) (SFL-1031A)

CONNECTOR P.W. BOARD ASS'Y (LCA90353-14A) (SFL-4031A)

FRONT CONTROL P.W. BOARD ASS'Y (LCA90351-18B) (SFL-7031A)

FRONT SENSOR P.W. BOARD ASS'Y (LCA90352-18A) (SFL-8031A)

POWER P.W. BOARD ASS'Y (LCA90348-10D) (SFL-9014A)

REGULATOR P.W. BOARD ASS'Y (LCA90349-10B) (SFL-9114A)

RECEIVER P.W. BOARD ASS'Y (LCA10476-51A) (SFL-0F301A)

REMOTE CONTROL UNIT PARTS LIST (RM-C1830-1C)

PACKING PARTS LIST

PACKING
