JVC LT-42X899, LT-47X899 User Guide

LCD Television Users Guide

LT-42X899
LT-47X899

1080p HDTV

MODE

V1 V2 V3 V4 V5

TV STB VCR DVD AUDIO

INPUT

123

456

789

TUNE

0

– CH + – VOL +

LIGHT MUTING

U

N

OK

E

M

F

A

V

O

R

I

T

E

A

DVR

STATUS

VIDEO

SOUND

SUB CH C.C. DISPLAY

SUB T.

TV/VCR

TWIN SLEEP ML/MTS

SWAP

SELECT

RM-C1430

TV

POWER

+

RETURN

TV

B

A

C

K

T

C

E

P

S

GUIDE

Important Note:

In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user’s guide in a convenient place for future reference. Keep the carton
and original packaging for future use.

Serial Number:

Model Number:

LCT2403-001A-A

0508TSH-II-IM

Table of Contents

Warnings . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . 7

Remote Control . . . . . . . . . . . . . 10

TV Basic Controls . . . . . . . . . . . 12

Key Features . . . . . . . . . . . . . . . 17

Setup . . . . . . . . . . . . . . . . . . . 18

Interactive Plug-In Menu . . . . . . . . . . 18

Remote Control Functions . . . . . 20

Return+ TV . . . . . . . . . . . . . . . . 20

Favorite . . . . . . . . . . . . . . . . . . . 20

Aspect . . . . . . . . . . . . . . . . 20

Sound . . . . . . . . . . . . . . . . 21

Video . . . . . . . . . . . . . . . . 21

Guide . . . . . . . . . . . . . . . . 21

SUB CH . . . . . . . . . . . . . . . . 21

C.C. . . . . . . . . . . . . . . . . . . . 22

TWIN . . . . . . . . . . . . . . . . . . . 22

Sleep . . . . . . . . . . . . . . . . . . . 23

ML/MTS . . . . . . . . . . . . . . . . 23

SWAP . . . . . . . . . . . . . . . . . . . 23

SELECT . . . . . . . . . . . . . . . . . . . 23

Customizing your TV . . . . . . 24

Initial Setup . . . . . . . . . . . . . . 25

Language . . . . . . . . . . . . . . . . 25

Tuner Setup . . . . . . . . . . . . . . . . 25

Set Clock . . . . . . . . . . . . . . . . 26

Set Lock Code . . . . . . . . . . . . . . . . 27

Interactive Plug-in Menu . . . . . . . . . . . 27

Software Version . . . . . . . . . . . . . . . . 27

Auto Demo . . . . . . . . . . . . . . . . . 27

V-Chip . . . . . . . . . . . . . . . . 28

V-Chip . . . . . . . . . . . . . . . . . . 29

Set US TV Ratings . . . . . . . . . . . . . . 29

Set Movie Ratings . . . . . . . . . . . . . . 30

Set Canadian Ratings English . . . . . . . 31

Set Canadian Ratings French . . . . . . . 31

Unrated . . . . . . . . . . . . . . . . . 31

Closed Caption . . . . . . . . . . 32

Closed Caption . . . . . . . . . . 32

Reset . . . . . . . . . . . . . . . . . 32

On/Off Timer . . . . . . . . . . . . . 33

Mode . . . . . . . . . . . . . . . . 33

On Time . . . . . . . . . . . . . . . . . . . 33

Off Time . . . . . . . . . . . . . . . . 33

Channel . . . . . . . . . . . . . . . . 33

On Volume . . . . . . . . . . . . . . . . 33

Picture Adjust . . . . . . . . . . . 34

Video Status . . . . . . . . . . . . . . . . 34

Natural Cinema . . . . . . . . . . . . 35

Theater Pro II . . . . . . . . . . . . . . . . 35

x.v.Color . . . . . . . . . . . . . . . . 35

Color Temp . . . . . . . . . . . . . . . . 35

Color Management . . . . . . . . . . . 36

Dynamic Gamma . . . . . . . . . . . . 36

Smart Picture . . . . . . . . . . . . . . . 36

Digital VNR . . . . . . . . . . . . . . . 36

MPEG NR . . . . . . . . . . . . . . . 36

Smart Sensor . . . . . . . . . . . . 36

Reset . . . . . . . . . . . . . . . . . 36

Sound Adjust . . . . . . . . . . . . 37

Balance . . . . . . . . . . . . . . . . 37

Turn On Volume . . . . . . . . . . . . . . 37

Volume Limit . . . . . . . . . . . . . . . . 37

Optical Out . . . . . . . . . . . . . . . . 38

Reset . . . . . . . . . . . . . . . . 38

Features . . . . . . . . . . . 39

Video-5 Input . . . . . . . . . . . . . . . 39

Noise Muting . . . . . . . . . . . . . 39

Front Panel Lock . . . . . . . . . . . . . 39

Auto Shut Off . . . . . . . . . . . . . . . 39

Quick Start-up . . . . . . . . . . . . . . . 39

Aspect . . . . . . . . . . . . . . . . . . . 40

Position Adjustment . . . . . . . . . . . . 41

Illumination . . . . . . . . . . . . 41

Power indicator . . . . . . . . . . . . 41

HDMI Size . . . . . . . . . . . . . . . . 41

Control with HDMI . . . . . . . . . . . 42

Video-1 Audio . . . . . . . . . . . . 42

Video Input Label . . . . . . . . . . . 42

Key Items . . . . . . . . . . . 43

Favorite . . . . . . . . . . . . . . . 43

Guide . . . . . . . . . . . . . . . . 43

Display . . . . . . . . . . . . . . . 43

Sleep Timer . . . . . . . . . . . . . . . 43

Multi Language/MTS . . . . . . . . . . . . 44

Photo Viewer . . . . . . . . . . . 45

Connecting Your Devices . . . . . 48

Programming Your Remote . . . . 55

Troubleshooting . . . . . . . . . . 62

Specifi cations . . . . . . . . . . . . 64

Warranty . . . . . . . . . . . . 65

Notes . . . . . . . . . . . . . . . . . . 67

2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Warnings

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service
personnel.

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair
it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

• As an “ENERGY STAR®” partner,
JVC has determined that this
product or product model meets the
“ENERGY STAR
efficiency.

®

” guidelines for energy

3

Warnings

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal

of these materials may be regulated in your community due to

environmental considerations. For disposal or recycling information,

please contact your local authorities or for USA, the Electronic Industries

Alliance: http://www.eiae.org

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

4

Warnings

16) Place the television on a stable, flat surface. Failure to do so can result in the television
falling, causing injury.

17) DO NOT allow young children to play around or on the television. Do not hang from the
TV. Failure to do so can result in the television falling, causing injury.

18) DO NOT allow young children to play with the plastic bag that came with the television
when you unpacked it. Failure to do so can result in suffocation, causing injury.

19) Avoid improper installation and never position the unit where good ventilation is impossible.
When installing this TV, distance recommendations must be maintained between the set
and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the
minimum distance guidelines shown for safe operation.

150 mm

5 7/8 in

200 mm

7 7/8 in

150 mm

5 7/8 in

200 mm

7 7/8 in

50 mm

2 in

20) Cautions for installation

— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way.
— The TV will generate a slight amount of heat during operation. Ensure that

sufficient space is available around the TV to allow satisfactory cooling.

— Have two people remove the TV from the box with the screen facing away

from you. It's possible your clothing, (such as a belt buckle or button) may
scratch the front of the TV. Do the same when moving the TV to another
location.

21) When attaching to a wall, use the optional JVC wall mounting unit.

For LT-42X899: JVC-XUF-2637 LCD FLAT WALL MOUNT
For LT-47X899: JVCPCM-MS2 TILT/FLAT WALL MOUNT
Caution
— Consult qualified installers.
— See the included manual on mounting procedures.
— JVC is not responsible for damages or injuries due to improper mounting.
— Use with other wall mounting unit is capable of resulting in instability or causing possible

injury.

22) Make enough room for inserting and removing the power plug. Place the TV as close
to the outlet as possible. The main power supply for this TV is controlled by inserting or
removing the power plug.

23) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

24) When this TV is connected to the wall outlet, it is always on standby even when all the LED

lamps are not lit. To shut down the TV, unplug the TV from the wall outlet.

5

Warnings

FCC Notice:

Caution: Changes or modifi cations not expressly approved by party responsible for

compliance could void the user's authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

– Consult the dealer or an experienced radio/TV technician for help.

We have an important note for customers who subscribe to basic cable services (do not have
a separate cable box) and plan to use their JVC TV remote control to select channels.

Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is
receiving through the RF input), every channel number available from your cable company
will appear in your television’s Channel Summary and they will all be marked as available for
scanning. Even though every channel is detected and appears as available, you will only be
able to view those that you specifi cally subscribe to from your cable company. This will likely
mean there are blank channels between those channels you wish to scan or “surf”.

We apologize for any inconvenience this may cause but it is important to note that this is
not a malfunction of your television. If you want to sequentially scan those channels you
subscribe to without blank ones in between, you can contact your cable company for their
cable box and remote, or manually deselect them using the edit / skip feature on page 25.

6

Precautions

Avoiding Temporary Burn-in

Displaying fi xed images for extended periods of time can leave a subtle but temporary burn-in
image on your screen. To avoid this, mix your viewing pattern.

Examples include, but are not limited to the following:

• Stock-market report bars

• Shopping channel logos and pricing

displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style

images

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or

digital television tuners/converters

TV on

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly
moistened with water. You can add a few drops of mild liquid detergent to the water to help
remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

For example...

TV off

XYZ XYZ

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a
soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner
and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen.
These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image
distortions.

7

Precautions

Tidying the cables

A cable holder which keeps your connection cables
tidy is attached to the back of the stand.

Install your TV

To prevent the TV from falling, thread the belt
through the hole on the back of the standand
secure it to the TV rack.

Disconnecting the stand

1) Place the TV face down on a soft cloth on a table.

2) Remove the five screws from the back of the TV.

3) Pull out the stand from the TV.

Hole

Belt and screw (not included)

Note:

• To re-install the stand, reverse the procedure from 3) to 1).

8

Package Contents

Make sure you have the following.

Precautions

Television x 1

Remote Control x 1

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

123

456

789

RETURN

TUNE

0

– CH + – VOL +

LIGHT MUTING

U

N

OK

E

M

F

A

V

O

R

P

I

T

S

E

A

DVR

STATUS

VIDEO

SOUND

SUB CH C.C. DISPLAY

SUB T.

TV/VCR

TWIN SLEEP ML/MTS

SWAP

SELECT

RM-C1430

TV

How to clean the frame and stand

Your TV has a glossy frame and stand which
have protection sheets attached to them. Peel
them off before use, but only after the TV has
been properly placed. Take care with handling
the glossy frame and stand because these
surfaces are delicate. If the glossy frame or
stand becomes dirty, first dust it off, then wipe it
softly with a cleaning cloth. If you wipe without
dusting off, you may damage it.

Insert the batteries

Use two “AA” batteries (included).

Place the "–" end in the unit first, making sure the "+" and
"–" markings are correct. Place the "–" end in the unit
first.

AA Batteries x 2

+

POWER

+

TV

B

A

C

K

T

C

E

GUIDE

AA Alkaline

–

+

AA Alkaline

–

Frame

Stand

If this symbol is shown, it is only valid
in the European Union

9

Remote Control

30

R

S

US

V

O

GUIDE

S

SUB CHC.C.

DIS

SOUND

F

A

V

O

R

I

T

E

S

S

P

ML/MTS

S

CT

The following pages gives you a brief description of each button’s function. For more detailed
information on the remote control buttons, see pages 20 - 23. This remote can also control up
to four other devices. See page 55 - 61.

POWER

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

123

456

789

TUNE

0

Lets you decide the input channel and select

TUNE

RETURN

TV

+

it. After pressing the remote 0 - 9 buttons,

Lets you go back to the previously selected

– CH +

– VOL +

LIGHT

MUTING

U

N

E

M

All remote control buttons are illuminated,

Turns the TV volume to 0. Press again to

Used to access the TV’s onscreen menus.

Turns the TV on or off.

Switch between “TV / STB /

VCR / DVD / AUDIO devices.

See page 55.

Switch between devices

connected to Video-1, 2, 3,

4 and 5.

Change channels. Input

remote codes. See page 55.

+

RETURN

TV

press TUNE.

channel. See page 20.

Move sequentially through the channels.

Raise or lower the volume.

except for the LIGHT button.

restore the volume.

See page 24.

POWER

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

123

456

789

TUNE

RETURN

TV

0

– CH + – VOL +

LIGHT MUTING

U

N

OK

E

M

F

A

V

O

R

I

T

E

DVR

DV

STATUS

TAT

VIDEO

SOUND

SUB CH C.C. DISPLAY

SUB T.

TV/VCR

TV/VCR

TWIN SLEEP ML/MTS

SWAP

SELECT

WAP

RM-C1430

RM-C14

ELE

IDE

UB T.

LEE

T

C

E

P

S

A

GUIDE

PLAY

TV

+

B

A

C

K

OK

B

A

C

K

Used to navigate through the TV’s

onscreen menus.

Go back to a previous onscreen menu or to

correct a mistake.

10

STAT

Remote Control

R

A

T

4

TU

T

T

–

M

B

A

C

K

V3

V5

30

F

A

V

O

R

I

T

E

Save your favorite channels. See page 20.

S

A

SOUND

VIDEO

GUIDE

SUB CH

TV/VCR

C.C.

SUB T.

DISPLAY

TWIN

SLEEP

T

C

E

P

Change the aspect ratio of the image on your

TV screen. See page 20.

Change the sound mode of the MaxxAudio

function. See page 21.

TV STB VCR DVD AUDIO

MODE

DE

INPUT

INPU

TBVC

POWER

POWER

UDIO

V1 V2 V3 V4 V5

Choose different display settings according to

personal preferences. See page 21.

Programming information. (Digital channels

only). See page 21.

Used to select sub channels.

(Digital channels only). See page 21.

Use the C.C. (Closed Caption) button to

select the mode of closed caption. See page

22.

View current channel information.

Activate the split screen option.

Choose how long the TV will stay on before

turning off. See page 23.

123

456

789

TUNE

NE

– CH + – VOL +

CH + – VOL +

LIGHT MUTING

LIGH

U

N

E

M

F

A

V

O

R

I

DVR

STATUS

SOUND

SUB CH C.C. DISPLAY

TV/VCR

TWIN SLEEP ML/MTS

SWAP

T

E

SELECT

0

0

OK

OK

VIDEO

SUB T.

S

A

RETURN

TV

UTING

T

C

E

P

GUIDE

V

+

B

A

C

K

ML/MTS

Listen to a program in stereo, mono or

another language (SAP). (Depending on

availability in the program). See page 23.

SWAP

Exchange the channel (or input) displayed in

the split screen window for the main screen

image.

SELECT

Select the picture (channel) while viewing split

screen.

* See page 56 for buttons that control your external devices.

RM-C1430

RM-C14

TV

11

TV Basic Controls

Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television. Some of the
connection terminals are color coded for easy connection with the proper cables.

Front Panel

Illumination

POWER LED

Side Panel

INPUT MENU C H VOL

OK BACK

POWER

Rear Panel

• For governing the use of

the IR IN terminal, consult
your dealer.

12

Input

Change the input

MENU

Used to access the TV’s onscreen menus.

+CH–

Move sequentially through the channels.

+VOL–

Raises or lowers the volume.

POWER

Turn the TV on or off.

Antenna / Cable

IR IN

75 Ω

(VHF/UHF)

F

VIDEO

R – AUDIO – L

Y

P

R PR

VIDEO

R – AUDIO – L

Y

P

R PR

VIDEO

R – AUDIO – L

S-VIDEO

R – AUDIO – L

R – AUDIO – L

RS-232CINPUT 5INPUT 4INPUT 3FOR HDMI 1AUDIO OUT

INPUT 5 INPUT 2 INPUT 1

DIGITAL AUDIO
OPTICAL OUT

PC IN

(D-SUB)

VIEWER

TV Basic Controls

I

Digital Camera

A

J

A, BA

Audio System

RS-232CINPUT 5INPUT 4INPUT 3FOR HDMI 1AUDIO OUT

VIDEO

R – AUDIO – L

Y

P

R PR

VIDEO

R – AUDIO – L

Y

P

R PR

VIDEO

S-VIDEO

R – AUDIO – L

R – AUDIO – L

R – AUDIO – L

DIGITAL AUDIO


OPTICAL OUT

VIEWER

INPUT 5 INPUT 2 INPUT 1

PC IN
(D-SUB)

G

PC

DVD Player

• For more detailed information, see
pages 48 - 54.

• For governing the usage of the
RS-232C terminal, consult your
dealer.

STB (Digital Cable,

E

satellite) Tuner Box

* This is used when you are using

A, B, C, D, E, F, G, H, I, J: Types of connections.

C, E

Video Camera

C, D, E

a DVI device.

Game Console

H

Audio System

13

TV Basic Controls

Device Side With Cables TV Side

A

HDMI HDMI Cable INPUT 1, 2 or 5

B

Good Best

C

VIDEO and AUDIO

D

E

F

G

AUDIO

DVI + Audio

Component

Video + Audio

S-Video + Audio

Composite

Video + Audio

Antenna / Cable

(VHF / UHF) RF Cable

OPTICAL INPUT

DVI – HDMI Cable,

Audio Cable

Component

Video + Audio INPUT 3 or 4

S-Video Cable,

Audio Cable

Composite

Video + Audio INPUT 3, 4 or 5

OPTICAL AUDIO

Cable

INPUT 1 +

HDMI ANALOG AUDIO

INPUT 3 +

AUDIO Input

75Ω

(VHF / UHF)

DIGITAL AUDIO

OPTICAL OUT

H

Good Best

14

AUDIO INPUT

(L / R) Audio Cable

AUDIO OUT

(L / R)

Compatible Signal Notes

Input

• HDMI (Digital)
SD: 480i, 480p
HD: 1080/60p / 1080/30p / 1080/24p / 1080i / 720p
Audio L/R (Digital)

Input

• DVI (Digital)
SD: 480i, 480p
HD: 1080/60p / 1080i / 720p

• Audio L/R (Analog)

Input

• Component (Analog)
SD: 480i, 480p
HD: 1080i, 720p

• Audio L/R (Analog)

Input

• S-Video (Analog)

• Audio L/R (Analog)

TV Basic Controls

See page 52.

See page 51.

See page 49.

Input

• Composite (Analog)

• Audio L/R (Analog)

ATSC (Digital)
NTSC (Analog)
Clear QAM (Digital)

Output

• Audio L/R (Digital)
(PCM or Dolby Digital)

Output

• Audio L/R (Analog)
(Fixed)

See page 49.

See page 48.

See page 50.

See page 50.

15

TV Basic Controls

PC

Device Side With Cables TV Side

I

PC IN

(D-SUB)

(3.5 mm stereo mini jack)

USB

Device Side With Cables TV Side

J

D-SUB

+ Audio

USB

D-sub (15 pin) Cable

+ Audio Cable

USB Cable

PC IN (D-SUB)

+ INPUT 5 AUDIO Input

VIEWER

16

Key Features

Your JVC TV is equipped with many features. Here are some key features
highlighted in detail.

1 Stunning picture quality via 1920x1080 Full HD panel.

Dynamic Gamma and Color Management give further
fi ne tuned picture reproduction. Smart Picture adjusts the
best possible picture quality automatically scene by scene
based on the incoming signal from any source!

2 “120Hz Clear Motion Drive III technology displays

120 frames per second (120Hz) in the same time a
conventional LCD TV displayes 60 frames (60Hz). You
will be able to reduce blurring or image trails when there is
rapid or complex movement across the screen.

OffOn

i-clear Motion NR – Provides 3D noise reduction for moving images by applying the

Real 12bit Driver – JVC’s new bit extention technology takes 8-bit images and turns them into

high-precision motion prediction techniques.

images with 12-bit precision. It produces smooth, natural signal gradations
without sacrafi cing the original HD signal.

3 JVC exclusive twin oblique cone speakers provide excellent TV sound quality. MaxxAudio

sound provides you with 4 different settings based on the program you are watching. The
equalizer will fi ne tune your listening preferences.

4 Full connectivity with 3 HDMI, 2 Component, 1 S-video and others. The variety of

connections are explained on pages 47 to 51.

x 3 x 2

HDMI CEC (see page 42)

x 1

5 Aspect mode will show every pixel you are getting in High Defi nition. The Native mode will

show 100% of 1080p. Full – with slight overscan. Panorama and Cinema will fi ll the screen
with various aspect settings. See page 40.

6 Photo Viewer allows you to enjoy your digital pictures stored on your USB Mass Storage

Class devices. See page 45.

17

Setup

TV

CR

A

O

UT

4

TUNE

T

T

G

–

30

US

V

R

M

A

V

O

T

A

B

A

C

K

1

V2

V5

P

S

CT

Interactive Plug-In Menu

When you turn on your TV for the first time, the Interactive Plug-In Menu appears automatically.
These menus will help you setup your TV with basic information for Language, Time and

Tuner Setup.

POWER

TV STB VCR DVD AUDIO

MODE

V1 V2 V3 V4 V5

V

TB V

DE

INPUT

INP

V3V4

123

456

789

TUNE

– CH + – VOL +

CH + – VOL +

LIGHT MUTING

LIGH

U

N

E

M

F

A

V

O

R

I

DVR

STATUS

TAT

SOUND

UND

SUB CH C.C. DISPLAY

UB CH C.C.DISPLAY

TV/VCR

TV/VC

TWIN SLEEP ML/MTS

SWAP

WA

0

OK

T

E

VIDEO

IDEO

UB T.

SUB T.

LEEPML/MT

SELECT

ELE

RM-C1430

RM-C14

A

RETURN

P

S

GUIDE

TV

V

TIN

T

C

E

UIDE

TV

UDI

+

B

A

C

K

1) Turn on the TV

2) Set the language

Interactive Plug-In Menu

> Language/Langue/Idioma

Language/Langue/Idioma

Select

Set

Operate Exit

English

MENU

3) Set time attribute

Interactive Plug-In Menu

> Set Clock

Mode

Channel

Time

Time Zone

D.S.T

Select

Start Clock

Manual

– –

– – : – – – –

Pacific

Off

Operate Exit

Back

BACK

MENU

POWER

1 Select a language

OK

2 Select “Set”

OK

3 Move to next menu

1 Change settings

OK

2 Select an item
3 Select “Start

Clock”

OK

4 Move to next menu

Mode Auto (Analog), Auto (Digital), Manual

Channel Only can select when Mode is in Auto (Digital)

Time Only can select when Mode is in Manual

Time Zone Choose the time zone you live in.

D.S.T. Changes the clock automatically for daylight saving time. On / Off

18

Interactive Plug-In Menu (Continued)

G

– VO

30

R

US

O

E

R

.

CH.C.IS

D

M

A

V

O

T

B

A

C

K

S

CT

Setup

– CH + – VOL +

– CH +

LIGHT MUTING

LIGHT

U

N

E

M

F

A

V

O

R

I

T

E

DVR

V

STATUS

TAT

SOUND

N

SUB CH C.C. DISPLAY

B

TV/VCR

TV/VC

TWIN SLEEP ML/MTS

SWAP

SELECT

WAP

OK

VIDEO

VIDE

SUB T.

UB T

LEEP

ELE

RM-C1430

M-C14

UTIN

T

C

E

P

S

A

GUIDE

PLAY

L/MT

TV

L +

ID

4) Set TV attribute

Interactive Plug-In Menu

> Auto Tuner Setup

Tuner Mode

Scan Mode

B

A

C

K

Select

Start

Operate Exit

Cable

Auto

Back

MENU

BACK

Tuner Mode Choose Air (antenna), Cable or Skip

Scan Mode Auto, STD, HRC, IRC

* If you use a set top box (satellite or cable box), press “Exit” to

skip this step.

Cable Users: After your auto tuner setup is complete, you may,
(depending on the type of hookup), have only 1 channel, usually
2, 3 or 4 in the auto tuner memory. This is normal.

1 Change settings

OK

2 Select an item

3 Select “Start”

OK

4 Start scanning

channels

“Thank you! Setup is now complete”

19

Remote Control Functions

+

RETURN

TV

Has three functions.

Return – Returns to the channel viewed just before the channel currently onscreen.

Return+ – Lets you program a specific channel to return to while scanning through the

TV – Returns to the TV mode as you are watching a video, DVD, etc.

Note:

• Press the RETURN+ TV and hold for three seconds. This will memorize the current channel
to return to while you scan through the other channels. To cancel, press and hold the
RETURN+ TV button for three seconds.

F

A

V

O

R

Allows you to save channels you like so you can view them easily. First you must register the
channels you like.

Notes:

• Go to the channel you want to register and press the FAVORITE button for three seconds.

• To view your favorite channels, press FAVORITE. Move π† to select your channel and

press OK.

• To erase your favorite channels, press FAVORITE. Move π† to select your channel and

press ®.

• Both analog and digital channels can be registered.

• The newest channel you registered will appear at the top of the list.

RETURN+ TV

channels using the – CH + button as you memorize the channel.

FAVORITE

I

T

E

T

C

ASPECT

E

P

S

A

Allows you to adjust the way the image appears on your TV based on the format that is being
received.

Panorama / Cinema / Full / Panorama Zoom / Cinema Zoom / Full Native / Regular / Slim

See page 40.

Note:

• You can select the aspect mode by pressing the ASPECT button.

20

Remote Control Functions

U

DVR

STAT

SOUND

Change the sound mode of the MaxxAudio function. High / Mid / Low / Off

Notes:

• You can choose the different sound modes by pressing the SOUND button.

SOUND

ATUS

VIDEO

VIDEO

Allows you to choose different picture settings according to personal preferences. You can
access this feature for each input (TV, V1, V2, V3, V4, V5).

Standard / Dynamic / Theater / Game / Memory-1 / Memory-2

Note:

• You can select Video Status by pressing the VIDEO button. See page 34.

GUIDE

DISPLAY

GUIDE

You can view program information for Digital Channels.

Note:

• When the program information is not being broadcast, the correct information will not be
displayed.

• The GUIDE will not show the correct time and date depending on the Time Zone and D.S.T.

settings. See page 43.

SUB CH

TV/VCR

SUB CH

Digital broadcast sometimes offers sub channels. By using the SUB CH button, you can select
a sub channel easily.

For example, to move to sub channel 123-45:

1) Press 1, 2 and 3 in order

2) Press the SUB CH button

3) Press 4 and 5 in order

4) Press the TUNE button

21

Remote Control Functions

C.C.

SUB T.

C.C. (Closed Caption)

Use the C.C. (Closed Caption) button to select the mode of closed caption. At first, select TV,
STB or VCR mode to use the closed caption function.

Notes:

• You can change the mode by pressing the π† buttons and press OK.

• Smart Caption will appear when you press the MUTING button only on channels where the
broadcast contains closed captioning.

• When you select On, it will be the mode selected in the Closed Caption Menu.

• See page 32 when you set the caption/text mode.

• If you are in PC mode or use HDMI, C.C. cannot be used.

TWIN

TWIN

Activate the split-screen option by pressing TWIN
on the remote control. The channel (or input) you

TV

Video-1

were watching before pressing TWIN will appear on
the left, the new channel will appear on the right. To
turn split-screen off and return to normal television

MAIN SCREEN


SPLIT SCREEN


viewing, press TWIN again or press the BACK
button. At first, select TV mode to use the TWIN
function.

Notes:

• You can enter the TWIN mode when you are in a single screen.

• Split screen functions will not work when you are receiving a 1080/30p and 1080/24p signal.

• Split screen functions will not work with locked channels or channels blocked by V-Chip
ratings limits. A black screen will display instead.

• The aspect of Main Screen Picture becomes 16:9 when you input the picture of 480p, 720p,
1080i and 1080p from the component terminal, HDMI terminal and digital channels.

• When you are in TWIN mode, you cannot change the aspect ratio.

• When you press the MENU button in TWIN mode, the menu screen will not appear.

• When you are in PC mode, TWIN, SWAP and SELECT cannot be used.

22

Remote Control Functions

S

SLEEP

SLEEP

Allows you to choose how long the TV will stay on before turning off.

Notes:

• You can change the interval by pressing the

π†

buttons and press OK.

• You can set the interval at 0, 15, 30, 45, 60, 90, 120 and 180 minutes.

• 60 seconds before the TV turns off, a message will appear and it will count the remaining
time. If you want to extend the time, press the SLEEP button and you can change the
interval. If you don’t press the SLEEP button, within 60 seconds the TV will turn off.

ML/MTS

ML/MTS

Allows you to listen to a program in stereo, mono sound or another language (SAP) if available.
First you must set the MODE to TV on your remote.

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the
language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo
mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• MTS is unavailable if your television’s Input source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using HDMI or an external input.

SWAP

SWAP

You can exchange the channel (or input) displayed in the split screen window for the main
screen image by pressing the SWAP button. At first, select TV mode to use the SWAP
function.

Notes:

• It will only work in TWIN mode.

SELECT

SELECT

With SELECT, you can select the picture (channel) while viewing split screen. When you press
SELECT button, the channel banner on the top will be highlighted. Each press of SELECT will
shift the channel. The sound outputs from the screen you have selected.

23

Customizing your TV

TV

CR

A

O

UT

4

TUNE

T

T

G

–

1

V2

3V4V5

30

US

V

R

A

V

O

T

A

P

S

CT

POWER

OWER

TV STB VCR DVD AUDIO

MODE

V1 V2 V3 V4 V5

V

TB V

DE

INPUT

INP

V

123

456

789

TUNE

– CH + – VOL +

CH + – VOL +

LIGHT MUTING

LIGH

U

N

E

M

F

A

V

O

R

I

DVR

STATUS

TAT

SOUND

UND

SUB CH C.C. DISPLAY

UB CH C.C.DISPLAY

TV/VC

TV/VCR

TWIN SLEEP ML/MTS

SWAP

WA

0

OK

T

E

VIDEO

IDEO

UB T.

SUB T.

LEEPML/MT

SELECT

ELE

A

RETURN

P

S

GUIDE

TV

V

TIN

T

C

E

UIDE

1) Display the menu bar

U

N

UDI

E

M

2) Display the desired menu

Aa

Initial Setup

Language

+

B

A

C

K

Tuner Setup

Set Clock

Set Lock Code

Interactive Plug-in Menu

Software Version

Auto Demo

3) Change or adjust the setting

Language

Tuner Setup

Set Clock

Set Lock Code

Interactive Plug-in Menu

Software Version

Auto Demo

Select

Select

Initial Setup

English

Operate Back Exit

BACK MENU

Aa

English

Operate Back Exit

BACK MENU

■ Change or adjust the setting using the pop-up menu.

Select

Enter

Select

OK OK

Enter

Select

OKOK

Change / Adjust

RM-C1430

RM-C14

TV

Note:

• Depending on the situation
(analog channels, digital
channels, video signal
format, external inputs,
etc.), some items will be
displayed in gray and can
not be selected.

24

OKOK

(Example: Language)

■ To enter an item’s sub menu

Select

Enter

OKOK

(Example: Set Clock)

4) Close the menu

U

N

E

M

English

English

French

Spanish

■ To the previous screen

> Set Clock

Mode

Auto (Digital)

Channel

– –

Time

– – : – – – –

Time Zone

Pacific

D.S.T

Off

Start Clock

B

A

C

K

Initial setup

Customizing your TV

Aa

English

Operate Back Exit

BACK MENU

Language

Tuner Setup

Set Clock

Set Lock Code

Interactive Plug-in Menu

Software Version

Auto Demo

Initial Setup

Select

Language

Allows you to change the TV’s onscreen menu languages to English, French or Spanish.

Tuner Setup

Auto Tuner Setup

If you skipped this step in the initial setup or your setup has changed, you can redo your setup
in this menu. Air / Cable

Channel Summary

>> Channel Summary

Ch No.

2

3-1

3-2

3-3

4

5

Select

Scan

Station

CH-1

CH-2

CH-3

Operate Exit

Back

BACK

Channel summary allows you to customize
the line-up of channels received by your TV.
Regarding analog channels, you can add or
delete channels from the line-up or prevent
any unauthorized viewers from watching
any or all 181 channels. Regarding digital
channels, the only channels that will appear
are the ones that are broadcasting.

The Channel summary screen will now be
displayed with the channels set to scan
marked with an “√”. Regarding analog
channels, you can delete channels from the

MENU

scan by removing the “√”. If any channels
were missed during auto tuner setup and
you wish to add them, you may by placing an
“√” next to the channel number.

Note:

• The number of a digital channel may change, depending on the time of some broadcastings.
If this channel existed and now has disappeared, the lock channel or scanned channel mark
by the channel summary for that channel will be cancelled.

25

Customizing your TV

Initial setup (Continued)

Channel Summary (Continued)

>> Station

Channel

Set

Select

Reset

Operate Exit

Back

BACK

You can set the channel label by selecting the
Station column.

MENU

Notes:

• You can use characters for: Alphabet, numbers, marks and spaces.

3-1

3-2

3-3

Please enter lock code

4

by 10 key pad.

CH-1

CH-2

CH-3

You can block access to a channel by
activating the channel lock. Select the
column.

Find Channel

Allows you to add channels by pressing the 10 key pad.

Digital Antenna Level

This is a bar graph displaying the state of the Digital Antenna Level.

Tuner Diagnostic

(Service Use Only)

Set Clock

The set clock function is described on page 18 as the Interactive Plug In Menu. You can choose
to set the clock automatically or manually.

26

Customizing your TV

Initial setup (Continued)

Set Lock Code

Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes
preset with a lock code of “0000”. You may change the code to any four-digit number you wish.

Notes:

• After a power interruption you must reset the lock code.

• Write your lock code number down and keep it hidden from potential viewers.

• If you forget the lock code, a new code may be set using the steps listed above.

Interactive Plug-In Menu

If you skipped this step in the initial setup or your setup has changed, you can redo your setup
in this menu. The Interactive Plug-in Menu is described on page 18.

Software Version

You can confirm the TV’s software version.

Auto Demo

Auto Demo explains this TV’s features to you.

Notes:

• Please complete the Initial Setup menu first. The Auto Demo mode will start
automatically when the Interactive Plug-In Menu is completed.

• If you press any button on the television or remote, with the exception of
POWER or MENU, the Auto Demo mode will stop for 30 seconds. After 30 seconds
have passed with no operation, the Auto Demo mode will start again.

• If you want to turn off the Auto Demo, press the MENU button.

27

Customizing your TV

g

V-Chip

Aa

Select

V-Chip

Operate Back Exit

Off

View

BACK MENU

V-CHIP

Set US TV Ratings

Set Movie Ratings

Set Canadian Ratings English

Set Canadian Ratings French

Unrated

Notes:

• V-CHIP will not work with video signals from VCRs, DVD players, Blu-ray or camcorders
connected to the TV.

• (For Canadian viewers only): V-CHIP is designed specifically for the US and may not work
properly in Canada.

• “Advanced V-Chip Rating” and “Advanced Canadian Rating” menus may be displayed
sometimes. This depends on the broadcast you are receiving.

– When entering the password –

When you try and access the V-Chip menu, “Please input password” will appear. Press the “0”
button four times on your remote to access the V-Chip menu for the first time.

Set Movie Ratings

Set Canadian Ratings English

Set Canadian Ratings French

Unrated

Please enter lock code

by 10 key pad.

View

123

456

789

0

– When you lock or unlock channels –

You can lock or unlock ratings as shown below.

> Set US TV RATINGS

TVMATV14TVPGTV

TVY7TV

G

Y

V/FV

S

L

D

Note:

• Once a channel has been unlocked, it will remain unlocked until the television is turned off.

28

1 Select

OK

2 Lock / Unlock

Customizing your TV

V-Chip (continued)

V-Chip

Allows you to block channels or content that you deem inappropriate for children. On / Off

Set US TV Ratings

This setting is based on the US ratings system.

TV Y – Appropriate for all children.
Intended for all children 2 - 6 years old.

TV Y7 – Appropriate for older children.
Intended for children 7 years or older.

TV G – General Audience.
Suitable for all ages.

TV PG – Parental Guidance Suggested.
Suitable for all ages with parental guidance.

TV 14 – Parents Strongly Cautioned.
Intended for viewers 14 years or older.

TV MA – Mature Audiences Only.
Intended for viewers 18 years or older.

Viewing Guidelines:
In addition to the above ratings, you can also block or allow more specifi c content. (Except for
unrated programming).

A program can contain any or all of the following:

V/FV – VIOLENCE/FANTASY VIOLENCE
S – SEXUAL CONTENT
L – Strong LANGUAGE
D – Suggestive DIALOG

29

Customizing your TV

V-Chip (continued)

Set Movie Ratings

This setting is based on the US Motion Picture Association of America (MPAA) ratings system.

NR – Not Rated.
Any type of programming that does not contain a rating.

G – General Audience.
Suitable for all ages.

PG – Parental Guidance Suggested.
Suitable for all ages with parental guidance.

PG 13 – Parents Strongly Cautioned.
Intended for viewers 13 years or older.

R – Restricted.
Not recommended for viewers 17 years without parental guidance.

NC-17 – No One Under 17.
Not intended for viewers 17 years or younger.

X – No One Under 18.
Not intended for viewers 18 years or younger.

30

Customizing your TV

V-Chip (continued)

Set Canadian Ratings English

This setting is based on the Canada rating system.

E – Exempt.
Any type of programming that does not contain a rating.

C – Intended for children.
Suitable for all ages.

C8+ – Intended for children over 8 years old.
Suitable for all ages over 8 years.

G – General Audience.
May contain material not suited for younger viewers.

PG – Parental Guidance.
May contain material not suited for younger viewers. Parents may consider some content not
appropriate for children 8 - 13 years old.

14+ – 14 Years or Older.
Parents strongly urged to use their discretion in allowing viewing by persons under 14.

18+ – Adult.
Intended for viewers 18 years or older.

Set Canadian Ratings French

For instructions on “Set Canadian Ratings French”, please see page 31 in the French user’s
guide.

Unrated

You can block programs that are not rated.

Unrated programming refers to any programming which does not contain a rating signal.
Programming on television stations which do not broadcast rating signals will be placed in the
“Unrated Programming” category.

Examples of Unrated programs:

• Emergency Bulletins • Locally Originated Programming

• News • Political Programs

• Public Service Announcements • Religious Programs

• Sports • Weather

• Some Commercials

Note:

• TV programs or movies that do not have rating signals will be blocked if the unrated category
is set to Block.

31

Customizing your TV

Closed Caption

Aa

Closed Caption

Closed Caption

Type

Analog Service

Digital Service

Appearance Mode

Font Size

Font Style

Select

Closed Caption

Allows you to select the mode of the closed caption. First you must set the MODE to either TV,
STB or VCR on your remote. On / Smart Caption / Off

– Smart Caption –

Will display closed captioning when you press the MUTING button only on channels where the
broadcast contains closed captioning.

Type
Auto: Shows closed caption a priority for digital channels over analog channels. It is set

automatically.

Advanced: Shows only the digital closed caption.
Basic: Shows only the analog closed caption.

Analog Service

Choose the feature that you like for analog Closed Captioning.

Digital Service

Choose the feature that you like for digital Closed Captioning.

Appearance Mode
Auto / Manual

Font Size

Choose how big the text appears in Closed Captioning.

Font Style

Choose the style of the font in Closed Captioning.

Text / Edge Opacity

Choose how translucent the text appears in Closed Captioning.

Background Opacity
Choose how translucent the background box color for the Closed Captioning text.

Text Color

Choose the color of the text in Closed Captioning.

Edge Color

Choose the color of the border of the background box color for the Closed Captioning text.

Background Color

Choose the background box color for the Closed Captioning text.

Page 1/2

Off

Auto

CC1

1

Auto

Auto

Auto

Operate Back Exit

BACK MENU

Reset

Resets all adjustments except for Closed Caption at once to the default settings.

32

Customizing your TV

On/Off Timer

Aa

On/Off Timer

Mode

On Time

Off Time

Channel

On Volume

Select

Notes:

• In order for the On/Off Timer to work, the clock must be set.

• After a power interruption, the timer settings must be reset.

• If your clock is not set, "PLEASE SET CLOCK FIRST !" will appear on the screen.

Mode

You can select timer frequency. No / Once / Everyday

On Time

You can set the time you want the television to turn itself on.

7 : 00 AM

10 : 00 AM

Current

Set

Operate Back Exit

No

2

BACK MENU

Off Time

You can set the time you want the television to turn itself off.

Channel

You can set the channel of when On Timer is on.

Note:
The On/Off Timer cannot be set to locked or guarded channels.

On Volume

You can set the volume level when On Timer is on.
0 - 50: Volume level
Current: Start with current volume level.

Set

Set all settings of On/Off Timer menu.

Note:

• If you are out from On/Off Timer menu without pressing Set, all settings go back to previous
setting.

33

Customizing your TV

Picture Adjust

Aa

Picture Adjust

0

0

0

0

0

-5

Operate Back Exit

Page 1/2

Standard

Auto

BACK MENU

Bright, Detail, Energy Saver Mode)

Video Status

Natural Cinema

Tint

Color


Bright

Detail

Energy Saver mode

II

Theater Pro

Select

Video Status

Choose different display settings according to personal preferences. You can use this feature
with TV, V1, V2, V3, V4 and V5.

Standard – Resets the picture display to the factory settings.

Dynamic – Gives a vivid picture with better contrast when viewing in a brightly lit room.

Theater – Gives a rich, film-like look to video when viewing in a dimly lit room.

Game – Used for when you are playing video games connected to your TV.

Memory-1 / Memory 2 – You can memorize your favorite picture settings (Tint, Color, Picture,

Notes:

• Each mode is memorized for each input (TV, V1, V2, V3, V4, V5) connected to the TV.

• Each video status setting has a separate memory for HD (1080i/1080p/720p) and SD
(480p/480i) video signal. Each video status can be chosen along with your favorite picture
settings (Tint, Color, Picture, Bright, Detail and Energy Saver Mode).

– When an HD or SD signal is displayed, your HD or SD settings are recalled for the video

status you are using.

■ Allows you to change and adjust the way the picture appears on your television.

Tint

Allows you to adjust the levels of red and green on your TV.

Color

Allows you to make all the colors on your TV appear more vivid or subtle.


Allows you to adjust the level of black and white on your TV giving you a darker or brighter
picture overall.

Bright

Allows you to adjust the overall brightness of the TV.

Detail

Allows you to adjust the level of fine detail on your TV.

Energy Saver Mode

Allows you to adjust the brightness of the internal lamp which effects the overall brightness of
the TV.

34

Customizing your TV

Picture Adjust

Natural Cinema

Allows you to compensate for image blurring when the original video you are watching was
shot at 24 frames/sec, and is broadcast at 30 frames/sec. This conversion error is known as
“TELECINE”. Auto / On / Off

Notes:

• When you are receiving a 480p, 720p, 1080p signal, or in PC mode, Natural Cinema cannot
be selected.

• Natural Cinema is only applied for SD 480i and HD 1080i signals.

Theater Pro II

It is possible to use Theater Pro II menu only when the Video Status mode is set to Theater,
Memory-1 or Memory 2. It adjusts the detailed picture settings.

Theater Pro II Menu Settings

DSD Detail
H.Sharp
V.Sharp
DSD Noise Control
Color Temp.
(High, Low)
Color Balance
*Color Mngmt.
(Red, Yellow, Green, Cyan) Axis
*Color Mngmt.
(Red, Yellow, Green, Cyan) Tint
*Color Mngmt.
(Red, Yellow, Green, Cyan) Color
*Color:Bright Area
*Color:Dark Area

* These Theater Pro II menus cannot be selected when Color Management is OFF. See page 36.

Emphasizes the edge of the picture horizontally

Adjusts the color of (red, yellow, green or cyan)

Shows the edge of the picture clearly

Emphasizes the edge of the picture vertically

Reduces picture noise

Adjusts the screen (red, blue or green) color

Adjust the blue color naturally

Select a corrected color

Adjusts the tints of (red, yellow, green or cyan)

Adjusts the picture color of the bright areas

Adjusts the picture color of the dark areas

– Reset

Resets all Theater Pro II menu picture adjustments.

x.v.Color

This makes full use of the display’s capabilities to produce the perception of depth-of-field and
texture. Auto / On / Off

x.v.Color and are trademarks.

Color Temp

Allows you to change how strong or dull the colors appear.

High - Bluish picture
Low - Reddish picture

35

Customizing your TV

Picture Adjust (continued)

Color Management

Allows you to compensate for dull colors to ensure dull colors are reproduced with natural hues.

On / Off

Dynamic Gamma

Allows you see more detail in very dark or bright areas so these areas don’t appear “muddied”.
Normally, this feature should be left On for optimum picture quality. On / Off

Smart Picture

Allows you to adjust the brightness level automatically to a level suitable for what you are
watching. On / Off

Digital VNR

This function can be selected to change the effect of Digital VNR (Video Noise Reduction).

Auto / Max / Min / Off

MPEG NR

This function effects the block noise removal and mosquito NR (Noise Reduction)
simultaneously. Max / Min / Off

Note:

• When you are receiving digital channels, block noise removal will have no effect.

Smart Sensor

This function automatically adjusts the brightness on your TV according to the amount of light
in the room. Display / On / Off

– Display –

“Leaf” icon will appear on your TV screen when Smart Sensor brightness adjustment occurs.
The leaf icon will appear a maximum of 6 leaves.

Reset

Resets all picture adjustments at once to the default settings, except for Video Status and
Natural Cinema.

36

Sound Adjust

Customizing your TV

Aa

MaxxAudio

MaxxBass

MaxxTreble

MaxxStereo

MaxxVolume

Balance

Select

Sound Adjust

+1

+3

0

0

Page 1/2

Low

Off

Operate Back Exit

BACK MENU

MaxxAudio improves sound performance with four sound features (MaxxBass, MaxxTreble,
MaxxStereo and MaxxVolume). High / Mid / Low / Off

■ Allows you to change and adjust the four sound features on your television.

MaxxBass –

MaxxTreble –

MaxxStereo –

MaxxVolume –

Compensates for low frequencies and widens the frequency band.

Compensates for high frequencies and widens the frequency band.

Expands the stereo sound naturally.

Maintains a uniform sound volume even if the sound becomes too loud all of

the sudden (during commercial breaks, etc.). On / Off

Note:

• Adjustment made to the four sound features (MaxxBass, MaxxTreble, MaxxStereo and
MaxxVolume) will be stored in the selected “MaxxAudio” setting.

MaxxAudio is a registered trademark of Waves Audio Ltd. in the
USA, Japan and other countries.

Balance

Adjust the level of sound between the TV’s left and right speakers with the balance setting.

Turn On Volume

Turn On Volume allows you to set the volume level when you turn the TV on.

Volume Limit

Volume Limit allows you to set the maximum volume level.

37

Customizing your TV

Sound Adjust (continued)

Optical Out

You can select the optical digital sound output as PCM or DOLBY DIGITAL when your TV is
connected to an amplifier that has a DOLBY DIGITAL decoder. If you select DOLBY DIGITAL,
you can enjoy listening to 5.1ch sound when watching digital broadcasts. This only applies to
digital channels.

Notes:

• Optical Out can be used for both digital and analog channels.

• If your amplifier does not have DOLBY DIGITAL decoder, select PCM. If you don’t
select PCM, it cannot output the sound from the speakers.

• For connecting an amplifier using the optical output, see page 50.

Manufactured under license from Dolby Laboratories. "Dolby", and
the double-D symbol are trademarks of Dolby Laboratories.

Reset

Resets all sound adjustments at once to the default settings, except for MaxxAudio.

38

Features

Customizing your TV

Aa

Video-5 Input

Noise Muting

Front Panel Lock

Auto Shut Off

Quick Start-up

Aspect

Position Adjustment

Select

Features

Operate Back Exit

HDMI

On

Off

Off

On

Full

Page 1/2

BACK MENU

Video-5 Input

Allows you to choose the signal type you wish to receive that you have connected to Video-5
Input. HDMI / D-sub / Composite

Noise Muting

This feature inserts a blank black screen over channels which are not broadcasting or are too
weak to be received clearly. On / Off

Front Panel Lock

This allows you to lock the keys on the side of the TV. On / Off

Auto Shut Off

“Auto Shut Off” will work when there is no signal and there is no TV operation for 10 minutes.
“Auto Shut Off” will not work while you are receiving a signal, even though there is no TV
operation for 10 minutes. On / Off

Note:

• If the channel that you have on does not receive a signal for more than one minute, the
blinking text “No Program or Weak Signal Auto shut off in 9 min.” appears on the screen,
and starts the countdown. If no signal is being received within 10 minutes, the TV shuts itself
off.

Quick Start-up

This allows you to quickly start the TV by skipping over the JVC logo on the TV screen when
you press the Power button. On / Off

39

Customizing your TV

Features (continued)

Aspect

Allows you to adjust the way the image appears on your TV based on the format that is being
received.

Panorama - When watching a 4:3 aspect picture it is stretched to fit the dimensions of the 16:9
aspect screen.

Cinema - This ratio “zooms in” on the center part of a 4:3 aspect picture, blowing it up
proportionally to fill the 16:9 screen.

Full - When watching a 4:3 aspect picture, it is stretched to fit the dimensions of the TV. When
watching a 16:9 aspect picture, it displays 95% of the ratio.

Panorama Zoom - When watching a High-Definition 16:9 aspect picture it is stretched to
eliminate the black side bars.

Cinema Zoom - This ratio “zooms in” on the center part of a High-Definition 16:9 aspect image
to eliminate the black surrounding bars.

Full Native - This ratio displays 100% of the ratio. Normally, all aspects except for Full Native
display about 95%.

Regular - When watching a 4:3 aspect picture without modifying the original picture to fit the
dimensions of your 16:9 screen. Black bars will appear along the picture’s sides. The picture
will be centered within the boundaries of the 16:9 screen.

Slim - This aspect mode shrinks the screen of a 16:9 broadcast to 4:3. There are some
programming that is already stretched by mistake at broadcasting companies, so this mode
corrects it. Black side bars will appear.

Notes:

• Depending on the signal format, some aspect modes are unavailable.

• Slim can only be displayed when the signal is ATSC (720p, 1080i) or HD (720p, 1080i,
1080p).

• Full Native can only be displayed when the signal is ATSC (1080i) or HD (1080i, 1080p).

• If the television receives a 16:9 signal from your HDMI device, the aspect mode will turn to
Full automatically. If the television receives a 4:3 signal from your HDMI device when you are
in Full aspect mode, it will return to aspect mode you chose. If you change the aspect mode
after the television changed it to Full automatically, the television will change to the aspect
mode you choose. It also turns to Full automatically when the TV receives an HD (1080p,
1080i or 720p) signal.

• You can access the aspect modes using the buttons on the side of the TV, by using the

MENU button, then – CH + button.

• You can select Regular or Full in PC mode.

40

Customizing your TV

Features (continued)

Position Adjustment

Position adjustment allows you to adjust the position of the picture on the screen vertically when
the aspect is set to panorama or cinema.

> Position Adjustment

Operate Back Exit

Select

Notes:

• To reset the adjustment to the center, press the OK button.

• When the arrow disappears, while you are adjusting the position, the position is at its
maximum limit.

• If you select Regular, Slim, Full or Full Native size with aspect or Multi Screen, position
adjustment option is not selected.

• When you change the screen size, perform the position adjustment again.

• Position adjustment allows you to adjust the screen position vertically and horizontally when
the aspect is set Panorama Zoom or Cinema Zoom for 1080p, 1080i and 720p signals, or
when PC mode is set.

• It is also possible to use Position Adjustment when you are in PC Mode.

BACK MENU

Illumination

Allows you adjust the brightness of the illumination on the front of the TV.

High / Low / Off

Power Indicator

Allows you adjust the brightness of the POWER LED on the front of the TV.

High / Low / Off

HDMI Size

The HDMI Size menu can only be selected when an HDMI 480p picture signal is being input
to the HDMI terminal. This option adjusts the position when an HDMI or DVI 480p picture
signal is being displayed on the screen. There are two types of HDMI 480p picture signals:
640x480 and 720x480. If the displayed picture is slightly shifted, the position can be adjusted
by selecting Auto, Size1 or Size2.

Note:

• You can select Auto only when the signal is 480p for HDMI. When you select Auto, the
television will select "Size1" or "Size2" automatically.

41

Customizing your TV

Features (continued)

Control with HDMI

If you use a HDMI CEC compatible device, set this setting to “On”.

HDMI CEC (Consumer Electronics Control) allows the TV to connect and control multiple HDMI
CEC enabled devices with a single remote. CEC (Consumer Electronics Control) is an optional
protocol used in HDMI.

• HDMI CEC on this TV is compliant with “High-Definition Multimedia Interface Specification”.

• The TV does not support HDMI CEC functions that are not listed below.

• The TV does not guarantee to support use of all HDMI CEC enabled devices.

• Devices that are not enabled to HDMI CEC cannot be controlled with this TV.

– Control the TV using the HDMI CEC enabled device –

• Turn the TV on and switch to the video source of the operating device.

• Switch to the video source of the operating device.

• Turn the TV off with the HDMI CEC enabled device you are viewing.

• For operating instructions of the device, refer to the device’s manual.

– Control the HDMI CEC enabled device using the TV –

• Turn off the operating device by turning off the TV.

• Some device may not support this function. For more details refer to the device’s manual.

– Send status of the TV to the HDMI CEC enabled device –

• When switching the TV’s external input or channel.

• When switching the TV’s menu language.

• Information regarding behavior of the device when status is received, refer to the external
device’s manual.

If “HDMI CEC” does not work correctly:

• When HDMI CEC enabled device is connected to INPUT1, INPUT2 or INPUT5 with an HDMI
cable, you may not be able to control TV’s external input. To solve the problem set “HDMI

CEC” to “Off”.

Video-1 Audio

Set to “Digital” or “Auto” for HDMI devices, or “Analog” or “Auto” for DVI devices for INPUT1.
(Not available for INPUT2 and INPUT5)

Video Input Label

Allows you to label all the devices you have connected to the TV that use the VIDEO-1, 2, 3, 4
and 5 inputs.

VCR / DVD / Blu-ray Disc / PVR / D-VHS / STB / SAT / AMP / GAME / CAM / DISC

– Reset

Resets all Video Input Label settings.

42

Key Items

Customizing your TV

Aa

Favorite

Guide

Display

Sleep Timer

Multi Language/MTS

Select

Key Items

Operate Back Exit

0 min.

Off

BACK MENU

Favorite

The Favorite button allows you to select your favorite channels easily. First, you must register
the channels that you like. See page 20.

Guide

You can view program information.

Notes:

• The GUIDE function will work when you are receiving digital program only.

• The GUIDE will not show the correct time and date if you have not performed the set clock
function on your television.

• When the program information is not being broadcasted, it will not show the correct
information.

Display

Change display of channel banner, clock etc..

Banner/Clock / Clock / Short Banner / Off

Sleep Timer

Allows you to choose how long the TV will stay on before turning off. First set the MODE to TV.

0 min. / 15 min. / 30 min. / 45 min. / 60 min. / 90 min. / 120 min. / 180 min.

Note:

• 60 seconds before the TV turns off, a message will appear and it will count the remaining
time. If you want to extend the time, press the SLEEP button and you can change the
interval. If you don’t press the SLEEP button, within 60 seconds the TV will turn off.

43

Customizing your TV

Key Items (continued)

Multi Language/MTS

Allows you to listen to a program in stereo, mono sound or another language (SAP).

(Depending if available in the program). First you must set the MODE to TV on your remote.

Notes:

• When you are receiving a digital broadcast, if there are other languages, you can change the
language by pressing the ML/MTS button.

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo
mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• MTS unavailable if your television’s input source is (V1, V2, V3, V4, V5).

• ML/MTS will not work when you are using the HDMI and external input.

44

Photo Viewer

Customizing your TV

Aa

Photo Viewer

Select

Photo Viewer

Operate Back Exit

BACK MENU

Connect your USB Mass Storage Class device to the Photo Viewer terminal on the TV. Photo
Viewer allows you to enjoy your digital pictures stored on your USB Mass Storage Class
devices. You can view them on the TV in high quality.

Notes:

• Gently pull out your USB device from the Photo Viewer terminal after fi nishing the “Photo

Viewer” menu.

• Device can only be selected when you have two or more USB devices connected to the TV.

• Photo Viewer cannot be guaranteed to work with all USB Mass Storage Devices. It may take

some time to display or it may not display correctly.

• Please refer to the Customer Support website at www.jvc.com/support for information and

notes regarding your devices you wish to connect.

• Supported fi le formats are “.jpg” or “.JPG”.

• All your stored data should be backed up fi rst as a precaution before connecting to the TV.

• Depending on your stored fi le size, it can take extra time to display “Photo Viewer” page.

Device

Select your devices such as USB memory or digital camera.

Note:

• By using the USB hub, you can connect several devices. Choices are different depending on
your connected devices.

Multi Screen

Display digital pictures stored on your USB Mass Storage Class devices in thumbnail view.

1 Select

> Multi Screen

Photo Viewer

Page Jump

Date:

. . .

D

Select

Dimensions:

Page: 1/1

OK

Back Exit

Operate

BACK MENU

2 Display

45

Customizing your TV

Photo Viewer (continued)

Multi Screen (continued)

Choose thumbnail view by pressing π† or √ ® and press the OK button. It will now be
shown on the screen. To move to the next picture, press the √ ® buttons.

• To go to the next page, select the right end image and press the ► button. To go back to

the previous page, select the left end image and press the ◄ button.

• Press 1 - 9 buttons to display the page you want in Multi Screen.

• By pressing DISPLAY button, you can display control help screen and detailed information
of the picture when you are viewing a single image. Change the screen of control help and
detailed information by pressing DISPLAY button several times.

Preview Guide

You can display control help screen when you watch the picture. On / Off

VOL +: 90º right-handed rotation

- VOL : 90º left-handed rotation

123456789 : Move to display area in each direction (only
when zoomed in)

VOLUME

+

DISPLAY

BACK

MENU

– Reset

+

NextPrev.

–

ROTATE

–

Guide

Back

Exit

5 : Resets to default condition

π: Zoom in †: Zoom back

BACK: Back to Multi screen

MENU: Back to TV

Notes:

• Rotation settings are also memorized for Slide Show. But if you disconnected the USB

Mass Storage Class device or you turn TV off, rotation settings are reset to default settings.

• Zoom in, Zoom back or position settings are only valid in current display.

Slide Show

Display your picture image one after another automatically. Display pattern depends on Slide
Show Transition (Page 47) and interval depends on Interval Time(sec.) (Page 47).

46

Customizing your TV

Photo Viewer (continued)

Slide Show Transition

Allows you to choose display pattern of Slide Show.

Fade / Slide / Wipe / Zoom / Blind / Shuffle

– Shuffle –
Will display the pictures in 5 patterns randomly of Fade, Slide, Wipe, Zoom and Blind.

Interval Time(sec.)

Allows you to change Slide Show interval. 1-10 / 15 / 20 / 30 / 45 / 60 / 90 / 120 / Manual

– Manual –

You can slide the picture by pressing the √ ® buttons.

Note:

• Slide Show may take extra time more than what you set in the Interval Time. This depends
on how large the file size is of the picture.

47

Connecting Your Devices

Notes:

• The following connection diagrams are examples on connecting some of the most common

devices to your TV. Please refer to your device’s instruction manual on other connection
methods or for devices not shown here in this instruction book.

• When you are finished connecting your devices, turn on your TV and devices.

Connect an Antenna or Basic Cable

Cable or Antenna

Output

IR IN

75 Ω

(VHF/UHF)

TV Rear Panel

Notes:

• If you are able to receive ATSC (Digital terrestrial) signal, High Definition (HD) broadcasting
can be watched.

• All digital broadcasting is not necessary High Definition. Check by pressing the DISPLAY

button.

• Digital broadcasting is not available in all areas.

Connect a Cable Box

Cable or Antenna

Output

Note:

• To view channels on your cable box, make sure your TV’s channel is set to 2, 3 or 4

(depending on the area you live in).

CABLE BOX

IN OUT

IR IN

TV Rear Panel

75 Ω

(VHF/UHF)

48

Connecting Your Devices

Connect a DVD Player

V

I

D

EO

TV Rear Panel

INPUT 5

R

-

A

U

D

IO

-

L

(INPUT 4)

Y

P

R

P

B

INPUT 4

V

I

DEO

R

-

AU

D

I

O

-

L

Y

Green

P

B

Y

P

R

P

B

INPUT 3

S

-

VID

EO

V

IDEO

R

-

AU

D

I

O

-

DVD Player

AUDIO OUT

R L

OUT

Notes:

• Green, blue and red are the most common colors for Component Cables. Some models may
vary in color.

• To watch your DVD player, make sure your TV is displaying INPUT 3 or INPUT 4 by pressing

the V3 or V4 button on your remote control.

PR

Blue

Red

Connect a Camcorder

TV Rear Panel

INPUT 5

R

-

A

U

D

I

O

-

L

(INPUT 4)

Camcorder

Note:

• To watch video from your camcorder, make sure your TV is displaying INPUT 3, INPUT 4 or

INPUT 5 by pressing the V3, V4 or V5 button on your remote control.

Y

P

R

P

B

INPUT 4

V

I

DEO

R

-

AU

D

I

O

-

L

49

Connecting Your Devices

Connect an Amplifier or Home Theater System

AUDIO INPUT

R

L

TV Rear Panel

FOR HDMI 1

UDIO OUT

AUDIO OUT

UDIO OUT

R

-

AU

(AUDIO OUT)

D

I

O

-

L

Amplifier

or

Home Theater System

SpeakerSpeaker

Note:

• Refer to your amplifier’s or Home Theater System’s manual for more information.

Connect an Amplifier using the DIGITAL AUDIO OPTICAL OUT

TV Rear Panel

(DIGITAL AUDIO OPTICAL OUT)

(with DIGITAL AUDIO OPTICAL INPUT)

Amplifier

SpeakerSpeaker

Notes:

• Refer to your amplifier’s manual for more information.

• This terminal can only output digital audio (PCM or DOLBY DIGITAL).

• In order to use the optical output connection, select PCM or DOLBY DIGITAL. See page 38.

50

DIGITAL AUDIO

OPTICAL OUT

PC IN
(D-SUB)

VIEWER

INPUT 5 INPUT 2 INPUT 1

Connecting Your Devices

Connect a Digital TV Device

P

R

P

B

TV Rear Panel

INPUT 3

S

-
VID

EO

FOR HDMI 1

V

ID

EO

HDMI ANALOG

R

-
AU

D

I
O

-
L

AUDIO

FOR HDMI 1

UDIO OUT

AUDIO OUT

UDIO OUT

AUDIO INP

UT

R

L

R

-
AU

D

I
O

-
L

DIGITAL AUDIO

PC IN

(D-SUB)

Digital TV Device

LR

AUDIO OUT

After the connections have been made,

tighten the screw to secure the cables.

DIGITAL OUT

Notes:

• To watch your Digital TV device, make sure your TV is displaying INPUT 1 by pressing the V1
button on your remote control.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

TV Rear Panel (INPUT 1)

OPTICAL OUT


VIEWER

INPUT 5 INPUT 2 INPUT1

Connect a IR IN Device

OutIn

IR Device (set career to “Off”)

Note:

• Refer to your IR Device’s manual for more information.

IR IN

TV Rear Panel

75 Ω

(VHF/UHF)

51

Connecting Your Devices

Connect a Blu-ray or HDMI Device

TV Rear Panel (INPUT 2)

Blu-ray / HDMI Compatible Device

DIGITAL AUDIO
OPTICAL OUT

PC IN

(D-SUB)


VIEWER

INPUT 5 INPUT 2 INPUT 1

Notes:

• To watch your Blu-ray or HDMI device, make sure your TV is displaying INPUT 1, INPUT 2 or
INPUT 5 by pressing the V1, V2 or V5 button on your remote control.

• Some decoders may not respond depending on the equipment that is connected to the HDMI.

• This TV can accept 480i, 480p, 720p, 1080i and 1080p signals via HDMI.

• This JVC television can accept a variety of HD signals, including 1080/60p, 1080/60i,

1080/30p, 1080/24p and 720/60p.

• Please use a High Speed HDMI™ Cable. High Speed HDMI™ Cables are tested to carry an

HD signal up to 1080p and higher.

• Some HDMI Output Devices may fail to detect this TV as a 1080p device. If this occurs,

manually select 1080p on the HDMI Output Device.

HDMI™ (V.1.3, with Deep Color, with x.v.Color™)

HDMI, the HDMI Logo and High-Defi nition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.

52

Connecting Your Devices

Connect an AV Receiver using SMART INPUT (INPUT 3)

INPUT 3

S

-

FOR HDMI 1

UDIO OUT

P

R

VIDE

R

-

AUDIO INPUT

R

Y

P

B

O

V

I

DEO

AU

D

I

O

-

L

L

AV Receiver

MONITOR

OUT

TV Rear Panel

P

R

PB

Y

R

-

AU

D

IO

-

MONITOR OUT

AUDIO OUT

UDIO OUT

L

Your TV is equipped with a SMART INPUT (INPUT 3). This allows you to watch many different
devices connected to your AV Receiver without having to change or use other input connections
on your TV. This allows you to free up the other input connections so you can connect more
devices to your TV.

Notes:

• Refer to your AV Receiver’s manual for more information on connecting your speakers and
other devices.

• Use your AV Receiver’s remote to switch to the different devices you have connected.

• Some AV Receivers may not respond when the V3 Smart Input function is turned on.

• Your AV Receiver’s signal priority in order is Component, S-VIDEO and Composite.

53

Connecting Your Devices

Connect a Computer

Computer

PC IN

(D-SUB)

TV Rear Panel
(INPUT 5)

DIGITAL AUDIO

OPTICAL OUT

VIEWER

INPUT 5 INPUT2 INPUT 1

RS-232C

V

I

D

EO

INPUT 5

R

-

A

U

D

I

O

-

L

Y

P

R

P

B

INPUT 4

VI

D

EO

R

-

AU

D

I

O

-

L

Notes:

• Make sure your TV is displaying INPUT 5 by pressing the V5 button on your remote control.

• When you do the above connection, set “Video-5 Input” in the Features menu to “D-Sub”.
See page 39.

• Use a D-SUB cable with ferrite cores and no longer than 3 Meters to avoid electromagnetic
disturbances.

• Refer to your computer’s manual for more information.

Resolution

640 x 480
(VGA)

800 x 600
(SVGA)

1024 x 768
(XGA)

Vertical
Frequency
(Hz)

60

60

60

Horizontal
Frequency
(kHz)

31.5

37.9

48.4

Notes:

• Depending on signal quality, some pictures may not be displayed correctly.

• Computers that cannot set the refresh rate to 60 Hz, cannot be used with this TV.

• If you are inputting a PC signal that is invalid, “Invalid Signal” will appear on the TV screen. It

appears when the input is PC and it is a single screen.

54

Programming Your Remote

You can program your remote control to operate your external devices, using the instructions
and codes on pages 55 - 61.

How to set the codes

1) Manually turn on the device.

2) Change the remote control mode according to the device by pressing the MODE button.

Refer to the following list for which mode to use.

3) Find the remote control code for your device. See pages 57 - 61.

4) Set the remote code.

123

TUNE

5) Point the remote at the device and press power. If your device did not turn off or respond, try

another code.

Notes:

• If your device doesn’t respond to any of the codes listed or is not listed, see page 55.

• Some codes may have only limited functions. Try other codes that may have more functions.

456

789

0

Enter the four digit numberPress and hold

The mode indicator goes
out for a second, then it
lights.

Search Code Function

This function searches for codes one by one if none of the codes listed for your device has
worked.

1) Manually turn on the device.

2) Change the remote control mode according to the device. Press MODE to select the correct

mode.

3) Activate the search code function. Press and hold POWER and RETURN+/TV until the mode

indicator blinks.

4) Point the remote at the device and press POWER. If no response, try the next code by

pressing ® and POWER until the device turns off.

5) Press RETURN+/TV to register and set the code. Then the MODE indicator light goes out.

Notes:

• If your remote still doesn’t work with the “Search Code Function”, use the remote that came
with your device. Your TV remote can not be guaranteed to work with all devices, modes or
operations.

55

Programming Your Remote

F

TWIN SLEEP ML/MTS

C.C.

S

Device Applied for these devices

JVC brand only

TV

STB

Cable Set Top Boxes, Cable/PVR Combinations, Satellite Set Top Box, DBS/PVR Combination

VCR, DBS/PVR Combination, PVR, DVD/PVR Combination

VCR

DVD Player, DVD Recorder, Home Theater in a Box, Receiver

DVD

AUDIO

Remote Control Functions

Amplifier, Home Theater in a Box, Receiver

POWER

MODE

Turns the selected device off

TV STB VCR DVD AUDIO

INPUT

V1 V2 V3 V4 V5

– CH +

– VOL +

Channel Up / Down

Volume Up / Down

Operates menus

Select

Display
menu

U

N

E

M

OK

Changes the remote control mode

Audio Input
Selection

SUB T.

Displays Subtitles

Open / Close

Playback / Record, etc.

Rewind

Back to

B

A

C

K

previous
menu

Record Stop Pause

SWAP

Play

Forward

SELECT

OK

Note:

• If your external devices has a TV/VCR function, refer to it’s manual.

56

Programming Codes

STB mode

Cable Set Top Box

ABC
Americast
Bell South
Digeo
Director
General Instrument

GoldStar
Hamlin
Jerrold

Memorex
Motorola

Pace
Panasonic
Paragon
Philips
Pioneer

Pulsar
Quasar
Regal
Runco
Samsung
Scientific Atlanta

Sony
Starcom
Supercable
Torx
Toshiba
Zenith

Cable/PVR Combination

Americast
Digeo
General Instrument
Jerrold
Motorola
Pace
Pioneer
Scientific Atlanta
Sony
Supercable
Zenith

0003, 0008
0899
0899
118 7
0476
0476, 0810, 0276,
0003
0144
0009, 0273
0476, 0810, 0276,
0003
0000
1376, 0476, 0810,
0276, 1187
1877, 0237, 0008
0000, 0008, 0107
0000
1305, 0317, 0025
1877, 0877, 0144,
0533
0000
0000
0279, 0273
0000
0000, 0144
1877, 0877, 0477,
0008
1006
0003
0276
0003
0000
0000, 0525, 0899

0899
118 7
0810
0810
1376, 0810, 1187
1877, 0237
1877, 0877
1877, 0877
1006
0276
0899

Programming Your Remote

Satellite Set Top Box

AlphaStar
Chaparral
Coolsat
Crossdigital
DirecTV

Dish Network System

Dishpro

Echostar

Expressvu
GE
General Instrument
GOI
Hisense
Hitachi
HTS
Hughes Network Systems

Humax
iLo
JVC
LG
Magnavox
Memorex
Mitsubishi
Motorola
Next Level
Panasonic
Pansat
Paysat
Philips

Proscan
Proton
RadioShack
RCA

0772
0216
1806
110 9
1377, 0392, 0566,
0639, 1639, 1142,
0247, 0749, 1749,
0724, 0819, 1856,
1076, 1108, 0099,
1109, 1414, 1442,
1609, 1392, 1640
1505, 1005, 0775,
1170, 1775
1505, 1005, 0775,
1775
1505, 1005, 0775,
1170, 1775
0775, 1775
0566
0869
0775, 1775
1535
0819
0775, 1775
1142, 0749, 1749,
1442
1790
1535
0775, 1170, 1775
1414
0724, 0722
0724
0749
0869
0869
0247, 0701
1807
0724
1142, 0749, 1749,
0724, 1076, 0722,
0099, 1442
0392, 0566
1535
0869
0566, 0855, 0143,
1392

Satellite Set Top Box

Samsung

SKY
Sony
Star Choice
Tivo
Toshiba

UltimateTV
Ultrasat
Uniden
US Digital
USDTV
Voom
Zenith

DBS/PVR Combination

DirecTV

Dish Network System
Dishpro
Echostar
Expressvu
Hughes Network Systems
JVC
Motorola
Philips
Proscan
RCA
Samsung
Sony
Star Choice

1377, 1276, 1108,
1109, 1442, 1609
0856
0639, 1639, 1640
0869
1142, 1442
0749, 1749, 0790,
1285
1392, 1640
1806
0724, 0722
1535
1535
0869
0856, 1856

1377, 0392, 0639,
1142, 1076, 0099,
1392, 1442, 1640
1505, 0775
1505, 0775
1505, 0775, 1170
0775
1142, 1442
117 0
0869
1142, 0099, 1442
0392
1392
1442
0639, 1640
0869

57

Programming Your Remote

VCR mode

ABS
Admiral
Adventura
Aiko
Aiwa

Akai
Alienware
America Action
American High
Asha
Audiovox
Beaumark
Bell & Howell
Broksonic

Calix
Canon
Capehart
Carver
CCE
Citizen
Colt
Craig

Curtis Mathes

Cybernex
CyberPower
Daewoo

Daytron
Dell
Denon
DirecTV
Durabrand
Dynatech
Electrohome
Electrophonic
Emerex
Emerson

VCR

1972
0048, 0209
0000
0278
0037, 0000, 0307,
0479
0041, 0061, 0106
1972
0278
0035
0240
0037, 0278
0240
0104
0184, 0121, 0209,
0002, 0479, 1479
0037
0035
0020
0081
0072, 0278
0037, 0278, 1278
0072
0037, 0047, 0240,
0072, 0271
0060, 0035, 0162,
0041, 0760, 1035
0240
1972
0045, 0104, 0278,
0020, 0046, 0561,
1278
0020
1972
0042
0739
0039, 0038
0000
0037
0037
0032
0035, 0037, 0184,
0240, 0045, 0000,
0121, 0043, 0209,
0002, 0278, 1593,
1479, 1278, 0593,
0561, 0479, 0208,
0061

Fisher
Fuji
Funai
Garrard
Gateway
GE

Go Video
GoldStar

Gradiente
Harley Davidson
Harman/Kardon
Harwood
Headquarter
Hewlett Packard
HI-Q
Hitachi

Howard Computers
HP
Hughes Network Systems
Humax
Hush
iBUYPOWER
Jensen
JVC

KEC
Kenwood
KLH
Kodak
LG

Linksys
Lloyd's
Logik
LXI
Magnasonic
Magnavox

Magnin
Marantz

VCR

0047, 0104, 0046
0035, 0033
0000, 0593, 1593
0000
1972
0060, 0035, 0240,
0202, 0760, 0761,
0807, 1035, 1060
0432, 0526
0037, 0209, 0038,
0225, 1237
0000
0000
0081, 0038
0072
0046
1972
0047
0037, 0240, 0000,
0042, 0041, 0105,
1037
1972
1972
0042, 0739
0739
1972
1972
0041
0045, 0067, 0041,
0008, 0366, 1707,
1945, 1774, 1775,
1776, 1777
0037, 0278
0067, 0041, 0038
0072
0035, 0037
0037, 0045, 0042,
0209, 0038, 1037
1972
0000, 0208
0240, 0072
0037
0593, 1278
0035, 0039, 0081,
0000, 0149, 0563,
0593, 1593, 1781
0240
0035, 0081

Marta
Matsushita

Media Center PC
MEI
Memorex

MGA
MGN Technology
Microsoft
Mind
Minolta
Mitsubishi

Motorola
MTC
Multitech
NEC

Nikko
Niveus Media
Noblex
Northgate
Olympus
Optimus

Orion

Panasonic

Penney

Pentax
Philco

VCR

0037
0035, 0162, 0227,
116 2
1972
0035
0035, 0162, 0037,
0048, 0039, 0047,
0240, 0000, 0104,
0209, 0046, 0307,
0479, 1037, 1048,
1162, 1237, 1262
0240, 0043, 0061
0240
1972
1972
0042, 0105
0081, 0067, 0043,
0041, 0061, 0173,
0807
0035, 0048
0240, 0000
0000, 0072
0035, 0037, 0048,
0104, 0067, 0041,
0038, 0008
0037
1972
0240
1972
0035
1062, 0162, 0037,
0048, 0104, 0432,
0593, 1048, 1162,
1262
0184, 0121, 0209,
0002, 0208, 0479,
1479
1062, 0035, 0162,
0225, 0227, 0616,
1035, 1162, 1262
0035, 0037, 0240,
0042, 0038, 1035,
1237
0042, 0105
0035, 0000, 0038

58

Programming Your Remote

VCR mode

Philips

Pilot
Pioneer
Polk Audio
Portland
Presidian
Profitronic
Proscan

Protec
Pulsar
Quarter
Quartz
Quasar

RadioShack
Radix
Randex
RCA

Realistic

ReplayTV
Ricavision
Runco
Samsung

Sanky
Sansui

Sanyo

Scott

Sears

Sharp

Shintom
Shogun
Singer
Sonic Blue
Sony

Stack 9
STS
Sylvania

VCR VCR

0035, 0081, 0000,
0563, 0593, 0618,
0739, 1081, 1181,
1266
0037
0081, 0042, 0067
0081
0020
1593
0240
0060, 0202, 0760,
0761, 1060
0072
0039
0046
0046
0035, 0162, 1035,
116 2
0000, 1037
0037
0037
0060, 0035, 0240,
0000, 0042, 0149,
0105, 0106, 0202,
0760, 0761, 0807,
0880, 1035, 1060
0035, 0037, 0048,
0047, 0000, 0104,
0046
0614, 0616
1972
0039
0240, 0045, 0432,
0739, 0760, 1014
0048, 0039
0000, 0067, 0209,
0041, 0271, 0479,
1479
0047, 0240, 0104,
0046
0184, 0045, 0121,
0043
0035, 0037, 0047,
0000, 0042, 0104,
0046, 0057, 0105,
1237
0048, 0209, 0807,
0848, 1048
0104, 0072
0240
0045, 0072
0614, 0616
0035, 0032, 0033,
0000, 0034, 0636,
0639, 0640, 1032,
1232, 1972
1972
0042
0035, 0081, 0000,
0043, 0593, 1593,
1781

Symphonic
Systemax
Tagar Systems
Tatung

Tea c
Technics
Teknika
Thomas
Tivo

TMK
Toshiba

Totevision
Tou c h
Unitech
Vector
Vector Research
Video Concepts
Videomagic
Videosonic
Viewsonic
Villain
Voodoo
Wards

White Westinghouse
XR-1000
Yamaha
Zenith

ZT Group

DBS/PVR Combination

Echostar
Hughes Network Systems
JVC
Philips
Samsung

ABS
Alienware
CyberPower
Dell
DirecTV
Dish Network System
Echostar
Gateway
Hewlett Packard

PVR

0000, 0593, 1593
1972
1972
0081, 0045, 0000,
0067, 0041, 0008,
0366
0000, 0041
0035, 0162
0035, 0037, 0000
0000
0618, 0636, 0739,
1996
0240, 0208
0081, 0045, 0042,
0067, 0043, 0041,
0008, 0057, 0366,
0845, 1008, 1145,
1972, 1996
0037, 0240
1972
0240
0045
0038
0045, 0061
0037
0240
1972
0000
1972
0060, 0035, 0048,
0047, 0081, 0240,
0000, 0042, 0072,
0149, 0760
0209, 0072
0035, 0000, 0072
0041, 0038
0039, 0033, 0000,
0209, 0034, 0479,
1139, 1479
1972

1945
0739
1945
0739
0739

1972
1972
1972
1972
0739
1945
1945
1972
1972

Howard Computers
HP
Hughes Network Systems
Humax
Hush
iBUYPOWER
JVC
Linksys
Media Center PC
Microsoft
Mind
Niveus Media
Northgate
Panasonic
Philips
RCA
ReplayTV
Samsung
Sonic Blue
Sony
Stack 9
Systemax
Tagar Systems
Tivo
Toshiba
Tou c h
Viewsonic
Voodoo
ZT Group

DVD/PVR Combination

Emerson

PVR

1972
1972
0739
0739
1972
1972
1945
1972
1972
1972
1972
1972
1972
0616, 1777
0618, 0739
0880
0614, 0616
0739
0614, 0616
0636, 1972
1972
1972
1972
0618, 0636, 0739
1008, 1972, 1996
1972
1972
1972
1972

0000

59

Programming Your Remote

DVD mode

Accurian
Advent
Aiwa
Akai
Alco
Allegro
Apex Digital

Arrgo
Aspire Digital
Audiovox
Blaupunkt
Blue Parade
Broksonic
Cinea
Cine Vision
Citizen
Coby
Craig
Curtis Mathes
CyberHome

Daewoo

Denon
Disney
Durabrand
DVD2000
Emerson

Enterprise
ESA
Fisher
Funai
Gateway
GE
Go Video

GoldStar
Greenhill
Harman/Kardon
Hitachi
Hiteker
Humax
iLo
Initial
Insignia
Integra
JBL
Jensen
JVC

Kawasaki
Kenwood
KLH
Koss
Lasonic
Lenoxx
LG
LiteOn

DVD DVD

1416
1016
0641
0695, 0770, 0899
0790
0869
0672, 0717, 0755,
0830, 1056, 1061
1023
116 8
0790
0717
0571
0695
0831
0876, 0833, 0869
1277
0778, 1107
0831
1087
0816, 0874, 1023,
1024, 1117, 1129
0784, 0705, 0770,
0833, 0869, 1169,
117 2
0490, 0634
0675, 1270
112 7
0521
0591, 0675, 0821,
1268
0591
0821, 1268
0670
0675, 1268, 1334
115 8
0522, 0815, 0717
0744, 0715, 0741,
0783, 0833, 0869,
1044, 1075, 1099,
1158, 1304, 1730
0741
0717
0582, 0702
0573, 0664, 1247
0672
1500, 1588
1348
0717
1268
0627
0702
1016
0558, 0623, 0867,
1164, 1602, 1770,
1771, 1772, 1773
0790
0490, 0534
0717, 0790, 1149
0651
0798
112 7
0591, 0741, 0869
1058, 1158, 1416,
1440

Magnavox

Marantz
Memorex
Microsoft
Mintek
Mitsubishi
NAD
NEC
Nesa
NexxTech
Norcent
Onkyo
Oritron
Panasonic

Philips

Pioneer
Polaroid
Polk Audio
Portland
Presidian
Prima
Proscan
Pro Vision
Qwestar
RCA

Rio
Rotel
Sampo
Samsung

Sansui
Sanyo
Sensory Science
Sharp

Sharper Image
Sherwood
Shinsonic
Sonic Blue
Sony

Superscan
Sylvania
Symphonic
Tea c
Technics
Theta Digital
Tivo
Toshiba

Urban Concepts
US Logic
Venturer
Xbox
Yamaha
Zenith

0503, 0539, 0646,
0675, 0821, 1268
0539
0695, 0831, 1270
0522, 1708
0839, 0717
1521, 0521
0741
0785
0717
1402
1003, 1107
0503, 0627
0651
0490, 0703, 1362,
1462, 1490, 1762
0503, 0539, 0646,
0675, 0854, 1158,
1260, 1267, 1354
0525, 0571, 0631
1061
0539
0770
0675
1016
0522
0778
0651
0522, 0571, 0717,
0790, 0822, 1022,
113 2
0869
0623
0752
0490, 0573, 0744,
0820, 0899, 1044,
1075, 1470
0695
0670, 0695, 0873
115 8
0630, 0675, 0752,
1256
1117
0770
0533, 0839
0869, 1099
0533, 1533, 0864,
1033, 1431, 1536
0821
0675, 0821, 1268
0675, 0821
0717, 0790
0490, 0703
0571
1503
0503, 0695, 1045,
1154, 1503, 1515,
1588
0503
0839
0790
0522, 1708
0490, 0539, 0545
0503, 0591, 0741,
0869

Accurian
Apex Digital
Aspire Digital
CyberHome
Denon
Funai
Gateway
Go Video

iLo
JVC
LG
LiteOn
Magnavox
Panasonic
Philips
Pioneer
RCA
Samsung
Sensory Science
Sharp
Sony
Sylvania
Zenith

Home Theater in Box

Aiwa
Audiovox
JVC

KLH
Koss
Oritron
Polk Audio
RCA
Rio
Sonic Blue
Tea c
Venturer

DVD Recorder

1416
1056
116 8
112 9
0490
0675, 1334
115 8
0741, 1158, 1304,
1730
1348
116 4
0741
1158, 1416, 1440
0646, 0675
0490
0646, 1158
0631
0522
0490, 1470
115 8
0630, 0675
1033, 1431
0675
0741

0641
0790
1770, 1771, 1772,
1773
0790
0651
0651
0539
0790
0869
0869
0790
0790

60

Audio mode

Amstrad
Bose
Curtis Mathes
Durabrand
GE
Harman/Kardon
JVC
Left Coast
Lenoxx
Linn
Marantz
NEC
Optimus
Philips
Pioneer
Polk Audio
RCA
Shure
Sony
Soundesign
Victor
Wards
Yamaha

ADC
Aiwa

Akai
Alco
Amphion Media Works
AMW
Anam
Apex Digital
Audiotronic
Audiovox
Bose

Brix
Cambridge Soundworks
Capetronic
Carver
Classic
Coby
Criterion
Daewoo
Delphi
Denon

Garrard
Gateway
Go Video
Harman/Kardon

Initial
Insignia
Integra
JBL
JVC

Kenwood
KLH

Amplifier

Receiver

0078
0674
0300
1561
0078
0892
0331
0892
1561
0269, 0282, 0829
0892, 0269
0264
0300, 0823
0892, 0269
0013, 0300, 0823
0892, 0269
0300, 0823
0264
0689, 0815, 1126
0078
0331
0078, 0013
0354, 0133

0531
1405, 0121, 1243,
1388, 1641
1512
1390
1563, 1615
1563, 1615
1609, 1074
1257, 1430
118 9
1390
1229, 0639, 1841,
1933
1602
1370
0531
118 9
1352
1389
1420
1250
1414
1360, 0771, 1142,
1660, 2832
0463
1517
1532
0110, 0891, 1304,
1306
1426
1751
0135, 1298, 1320
0110, 1306
0531, 1374, 1495,
1560, 1676, 1871,
1894
1313, 1570, 1569
1390, 1412

Programming Your Remote

Koss
Lasonic
Lenoxx
LG
Liquid Video
Magnavox

Marantz

Mitsubishi
NexxTech
Norcent
Nova
Onkyo

Optimus
Oritron
Panasonic

Philips

Pioneer

Polaroid
Polk Audio
Proscan
RCA

Regent
Rio
Saba
Samsung
Sansui
Sanyo
Sharp
Sharper Image
Sherwood
Shinsonic
Sirius
Sonic Blue
Sony

Stereophonics
Sunfire
Teac

Technics
Thorens
Toshiba
Venturer
Wards
XM
Yamaha

Zenith

Receiver

1366, 1497
1798
1437
1293, 1869
1497
1189, 1269, 0531,
1514
1189, 1269, 0891,
1289
1393
1751
1389, 1751
1389
0135, 0842, 1298,
1320, 1531
1023, 0531, 1074
1366, 1497
1308, 1518, 0367,
1288, 1316, 1548,
1633, 1763, 1764
1189, 1269, 0891,
1266, 1289, 1673
1023, 0014, 0150,
0531, 0630, 1123,
1384, 1823
1508
1289, 1414
1254
1023, 1609, 1254,
0531, 1074, 1123,
1390, 1511
1437
1869
0531, 1519
1295, 1500
1764
1251, 1469
0771, 1286
1556
1517, 1653
1426
1602
1532, 1869
1058, 1441, 1258,
1759, 1622, 0474,
1406, 1558, 1658,
1758, 1858, 1958
1023
1313
0463, 1074, 1390,
1528
1308, 1518, 1384
1189
1788
1390
0014
1406, 1414
0176, 1176, 1276,
1331, 1375, 1476
0857, 1293

Home Theater in Box

Aiwa
Amphion Media Works
AMW
Anam
Apex Digital
Audiovox
Bose
Cambridge Soundworks
Classic
Coby
Criterion
Daewoo
Denon
Durabrand
Gateway
Go Video
Initial
Insignia
Integra
JBL
JVC

KLH
Koss
Lasonic
Lenoxx
LG
Liquid Video
Magnavox
NexxTech
Norcent
Nova
Onkyo
Oritron
Panasonic

Philips
Pioneer
Polaroid
Polk Audio
RCA
Regent
Rio
Saba
Samsung
Sanyo
Sharper Image
Sherwood
Shinsonic
Sonic Blue
Sony

Teac
Toshiba
Venturer
Yamaha
Zenith

1388, 1641
1563, 1615
1563, 1615
1609
1257, 1430
1390
1229, 1933
1370
1352
1389
1420
1250
2832
1561
1517
1532
1426
1751
1298
1306
1374, 1495, 1676,
1871
1390, 1412
1366, 1497
1798
1561
1293, 1869
1497
1514
1751
1389, 1751
1389
1298, 1531
1366, 1497
1288, 1316, 1548,
1633, 1763, 1764
1266, 1673
1384
1508
1289
1609, 1390, 1511
1437
1869
1519
1295, 1500
1469
1556
1517
1426
1532, 1869
0689, 1622, 1558,
1658, 1758, 1858,
1958
1390, 1528
1788
1390
1331, 1375
1293

61

Troubleshooting

Refer to the table below to check the condition. If you think that there is a problem, contact the
JVC Service Center where you purchased the television.

PROBLEMS CHECK

There is no power

• See if the power cord became unplugged.

• Check for a blown fuse or circuit breaker or a power outage.

There is no picture
or sound

Remote control is not
operating properly or
at all

The power turns off
by itself

It does not operate
correctly

The color quality
is poor

There are lines
across the picture

The picture is spotted

There are double
pictures (ghosts)

• The antenna could be disconnected.

• The tuner could be set improperly. See page 25.

• The TV station may be having difficulties. Check to see if other stations are working.

• Use the HDMI cable with HDMI logo . See page 52.

• You cannot output audio using the DIGITAL AUDIO OPTICAL OUTPUT when you
have digital sound from an HDMI device connected to the INPUT-1, INPUT-2 or
INPUT-5 connection on the back of the TV.

• This TV can accept 480i (Composite / S / HDMI / Component), 480p, 720p, 1080i
and 1080p signals. Please check your settings.

• Check to see that the batteries are still working and properly installed.

• Make sure the remote has a clear sight path to the TV.

• You may be too far from the TV. You must be within 23 feet (7 meters).

• Make sure nothing is connected to the IR IN terminal except for an IR device.

• Make sure the set did not become unplugged.

• Perhaps the Auto Shut Off is set. See page 33.

• Check to see if the Sleep Timer was set. See page 43.

• This television is operated by a microprocessor. It is possible that external noise or
interference is causing the problem. If the television does not function correctly,
remove the electrical plug from the wall outlet and wait a while before inserting it
into the wall outlet again and operating the television.

• Tint and Color may be improperly adjusted. See page 34.

• The Video Status mode may be turned to the wrong setting. See page 34.

• There could be interference from another electrical appliance, such as a computer,
another TV or VCR. Move any such appliances further away from the TV.

• There could be interference from a high-wattage appliance, like a hairdryer or
vacuum, operating nearby. Move the antenna away from the appliance or change
to a coaxial cable connection which is less prone to interference.

• A building or passing airplane can reflect the original signal and produce a second,
slightly delayed one. Adjust your antenna position.

Picture is snowy
(image noise)

62

• Your antenna may be damaged, disconnected or turned. Check the antenna
connection. If the antenna is damaged, replace it.

PROBLEMS CHECK

Troubleshooting

Screen is 80% black

Stereo or bilingual
programs can't be
heard

Static electricity

You hear occasional
crackling sounds

The screen
disappears except for
the menu screen

My HDMI device
doesn’t work or
doesn’t work properly

“Weak Signal”
appears

“No Program”
appears

• The Closed Caption Text mode is on. Turn it off in the Closed Caption Menu,
page 32.

• Make sure the MTS settings are correct. See page 23.

• It is normal to feel static electricity if you brush or touch the screen.

• It is normal for the TV to make crackling sounds when first turned on or off. Unless
the sound or picture become abnormal, this is fine.

• This occurs when you select a digital menu when your input source is from the
HDMI connection. Press the menu button.

• Please use a High Speed HDMI™ Cable. High Speed HDMI™ Cables are tested
to carry an HD signal up to 1080p and higher.

• This OSD appears when the digital channel that you have selected is too weak to
receive or no signal is being detected for that channel.

• It appears when that channel is not receiving a signal and you have the Noise
Muting function OFF and you have a single screen. It moves automatically every
two seconds to prevent the screen from burn-in.

• Even if "NO PROGRAM" appears on the screen, your timer functions and auto
shut off functions that you set, are still active.

• If you are watching an analog channel, NO PROGRAM does not appear.

The following are not malfunctions.

• The television may make a creaking sound if the temperature of the room or the temperature
of the inside of the television changes. If there is no problem with the screen or sound, then
there is no need to worry.

• The picture may be temporarily disturbed and noise may be seen on the screen if the power
is turned on immediately after it has been turned off. This is not a malfunction.

63

Specifi cations

Model

Reception Format

Reception Range

Power Source

Power Consumption

Screen Size

Audio Output 10W + 10W

Speakers

Antenna Terminal

(VHF/UHF,

ATSC/DIGITAL

CABLE IN)

Input 3, 4, 5 Terminal

(Composite Terminal)

Input 3, 4 Terminal

(Component Terminal)

Input 1, 2, 5 Terminal

(HDMI Input Terminal)

LT-42X899

LCD Flat TelevisionType

NTSC, BTSC System (Multi-Channel Sound) ATSC Terrestrial, Digital Cable

CATV 135 Sub, Mid, Super, Hyper and Ultra bands at Digital Cable

VHF 2 to 13, UHF 14 to 69 CATV 135 Sub, Mid, Super, Hyper and Ultra bands

• Reception of channel A-5 ("95" of the TV set's on-screen cable channel numbers)

229W

42 inch / 106.7 cm

measured diagonally,

16:9 ratio

480i
S (Input 4)
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance

1080i / 720p / 480p / 480i
Y: 1 Vp-p positive, 75 ohms (negative sync provided)
P

B/PR: 0.7 Vp-p 75 ohms

Video: 1080/60p / 1080/30p / 1080/24p / 1080i / 720p / 480p / 480i
Audio: 2ch PCM, 32 / 44.1 / 48 KHz 16 / 20 / 24 bit

VHF 2 to 13, UHF 14 to 69 at ATSC,

(191 channel frequency synthesizer system) at Analog

is not recommended for your TV set.

AC 120V, 60 Hz

4.5 x 16cm Twin Oblique Cone x 2

75 ohms (VHF/UHF)(F-type connector)

LT-47X899

299W

47 inch / 119.4 cm

measured diagonally,

16:9 ratio

PC Input Jacks

Audio Output Jacks

(FIX)

Optical Output

Digital Audio

Dimensions (inch/mm)

W X H X D

Weight (lbs / kg)

39 3/4 x 27 7/8 x 11 3/4

(with stand)

1007 x 707.2 x 296

(with stand)

39 3/4 x 26 x 5 1/8

(without stand)

1007 x 660 x 129.1

(without stand)

59.4 / 27 (with stand)

44 / 25 (without stand)

Analog RGB D-SUB (15 pin) x 1

FIX : 500mVrms (-4dBs), Low Impedance

Specifications subject to change without notice.

64

Digital Out (optical) x 1

44 1/4 x 30 1/2 x 11 3/4

(with stand)

1121 x 773.7 x 296

(with stand)

44 1/4 x 28 5/8 x 5 1/8

(without stand)

1121 x 726.5 x 129.8

(without stand)

74.8 / 34 (with stand)

66 / 30 (without stand)

Warranty

LIMITED WARRANTY

ONLY FOR PRODUCT PURCHASED IN U.S.A.

2-2

USA ONLY

2 YRS 2 YRS

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND
IN THE COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Please do not return your product to the retailer

Instead, return your product to the JVC authorized service center nearest you. If shipping the product to the service
center, please be sure to package it carefully, preferably in the original packaging, and include a brief description of
the problem(s). Please call 1-800-252-5722 to locate the nearest JVC authorized service center. Service locations
can also be obtained from our website http://www.jvc.com. If your product qualifies for in-home service, the service
representative will require clear access to the product.

WHAT IS NOT COVERED:

For customer use:

JVC AMERICAS CORP.

65

Warranty

TO OUR VALUED CUSTOMER

THANK YOU FOR PURCHASING THIS JVC PRODUCT.

WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE.

NEED HELP ON HOW TO HOOK UP?

NEED ASSISTANCE ON HOW TO OPERATE?

NEED TO LOCATE A JVC SERVICE CENTER?

LIKE TO PURCHASE ACCESSORIES?

IS HERE TO HELP!

TOLL FREE: 1(800)252-5722

http://www.jvc.com

Remember to retain your Bill of Sale for Warranty Service.

Do not attempt to service the product yourself

Caution

To prevent electrical shock, do not open the cabinet.
There are no user serviceable parts inside.
Please refer to qualified service personnel for repairs.

BT-51029-4Q
(

)

0807

66

Notes

67

JVC Loves the Earth

Digital Television Transition Notice:

This device contains a digital television tuner, so it should receive digital over the air TV
programming, with a suitable antenna, after the end of full-power analog TV broadcasting in the
United States on February 17, 2009.

Some older television receivers, if they rely on a TV antenna, will need a TV Converter to receive
over the air digital programming, but should continue to work as before for other
purposes (e.g., for watching low-power TV stations still broadcasting in analog, watching
pre-recorded movies, or playing video games).

For more information, see http://www.DTV.gov or call 1-888-CALL-FCC. For converter box
information, see http://www.dtv2009.gov or call the NTIA at 1-888-DTV-2009.

JVC COMPANY OF AMERICA

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square
Scarborough, Ontario

Canada, M1X 1A7
