WIDE LCD PANEL TV
INSTRUCTIONS
LT - 42E10
GGT0372-001A-H
Safety precautions ...................................2
Remote control buttons and functions ..... 3
Set up and connections ........................... 4
Initial settings ...........................................6
Registering / Editing channels ................. 7
Channel Summary ...................................7
Operating the menus ............................... 8
PREPARATION
Picture setting ..........................................9
Sound setting......................................... 11
Useful functions ..................................... 13
Viewing Teletext ..................................... 15
Viewing Closed Caption ........................15
Watching Video or DVDs .......................16
Technical information ............................. 16
Troubleshooting ..................................... 18
CH/CC List ............................................. 19
Specifi cation ..........................................20
FUNCTIONS
REFERENCE
Contents
ENGLISH
GGT0372-001A-H-EN.indd 1GGT0372-001A-H-EN.indd 1 13/07/2010 16:53:1113/07/2010 16:53:11
2
Thank you for buying this JVC LCD panel television.
To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.
10
10
Plane
Follow this manual regarding setup!
•
Connect only to a 110-240 V, 50/60Hz AC outlet.
-
Make enough room for inserting and removing the power plug!
•
Place the TV as close to the outlet as possible!
•
The main power supply for this TV is controlled by inserting or removing the power plug.
-
Never cut or damage the power cord!
•
If the AC plug is not the right shape, or the power cord is not long enough, use an
-
appropriate plug adapter or extension cable. (Consult your retailer)
Unplug the power cord when going out!
•
The power buttons on the remote control and the TV unit cannot completely turn off the
-
TV. (Make appropriate arrangements for bedridden people.)
Do not allow the TV to fall!
•
Do not rest your elbows on, or allow children to hang from the TV.
-
There is a risk that the TV will fall and cause injuries.
-
Make use of the hole on the back of the stand to prevent the TV from falling easily.
-
If the TV is damaged or behaving strangely, stop using it at once!
•
Unplug the power cord and contact your retailer.
-
Never place anything on the TV!
•
Placing liquid, naked fl ames, cloths, paper, etc. on the TV may cause a fi re.
-
Never expose to rain or moisture!
•
To prevent fi re or electric shock, never allow liquids to enter the unit.
-
Never insert objects into the cabinet openings!
•
It may cause a fatal electric shock.
-
Take care when children are near.
-
Hold the TV so as not to scratch the screen!
•
Do not touch the screen when carrying the TV.
-
Do not carry the TV on your own!
•
In order to prevent accidents, ensure that the TV is carried by
-
two or more people.
Never insert the power cord by wet hand!
•
It may cause a fatal electric shock.
-
Keep the TV set away from direct sunlight!
•
TV set can be damaged.
-
Place the TV set in a neat and dry place. Do not place the product close to
•
source of steam, heat, moisture or oil. Because it may cause a fi re hazard
or electric shock hazard!
Don’t touch an external metal part of the TV set!
•
It may cause an electrocuted.
-
For keep a distance from potential ignition sources to the
•
components or part in side TV set, customer should install
TV set with a stand within ± 10 perpendicularly degree.
Never dismantle the rear panel!
•
It may cause an electric shock.
-
Never obstruct the ventilation holes!
•
It may cause overheating or a fi re.
-
Handle LCD panel with care!
•
Use a soft, dry cloth when cleaning.
-
Never try repair the TV yourself!
•
If the problem cannot be solved in “Troubleshooting” unplug the power cord and contact
-
your retailer.
If a television is not positioned in a suffi ciently stable location, it can be
•
potentially hazardous due to falling. Many injuries, particularly to children,
can be avoided by talking simple precautions such as:
Using cabinets or stands recommended by the manufacturer of the television.
-
Only using furniture that can safely support the television.
-
Ensuring the television is not overhanging the edge of the supporting furniture.
-
Not placing the television on tall furniture (for example, cupboards or bookcases) without
-
anchoring both the furniture and the television to a suitable support.
Not standing the television on cloth or other materials placed between the television and
-
supporting furniture.
Educating children about the dangers of climbing on furniture to reach the television or
-
its controls.
To prevent accidents, fi rmly attach the TV stands to the TV shelf before •
using microphone.
Make sure that the subwoofer is in good condition before installing it on •
the TV.
If the subwoofer has leakage current, it may damage the TV or cause electric shock. -
For more details on installation, usage and safety • Consult your retailer.
WARNING:
To prevent the spread of fi re, keep candles or other open fl ames away from this
product at all times.
Safety precautions
GGT0372-001A-H-EN.indd 2GGT0372-001A-H-EN.indd 2 13/07/2010 16:53:1613/07/2010 16:53:16
3
RM-C2022
LCD
DISPLAY BACK
CH
VOL
MODE
ZOOM
ECO
MENU
TV/VIDEO
RETURN
+
Clear SD
1
3
2
4
6
5
7
9
8
0
KARAOKE
OK
20
19
18
17
21
16
15
14
1
2
3
4
5
6
7
8
9
10
11
12
13
DISPLAY
Zoom
Auto Panoramic
Regular
Panoramic
14:9 Zoom
16:9 Zoom
16:9 Zoom Subtitle
Full
Jan 2010
09 : 08
Su Mo Tu We Th Fr Sa
1 2
3456789
10 11 12 13 14 15 16
17 18 19 20 21 22 23
24 25 26 27 28 29 30
31
16:9 Zoom
PR List
AV
01
02 – – – – – –
03 – – – – – –
04 – – – – – –
05 – – – – – –
06 – – – – – –
07 – – – – – –
08 – – – – – –
09 – – – – – –
01
OK
1. Select
2. Set
Remote control buttons and functions
1
Power On / Off
8
Display on-screen menu
15
Change channel / Page / Hyper Scan
2
Colour buttons
9
Operate the menu
16
Channel information
3
Turn on “Clear SD”
10
To previous screen
17
Switch between TV / Video input
4
Turn on “Zoom”
11
Turn on “Sound Meister”
18
Return Plus / Return function
5
Turn on “Eco Mode”
12
Volume control / Turn off muting
19
Change channel / page
6
Turn on “Karaoke”
13
Function for viewing Teletext
20
Turn the volume off / on
7
Favourite channel setting
14
To Teletext
21
Turn on "Freeze"
Zoom : Change the aspect ratio.
Return Plus : Return to the frequently viewed channel
Return : Return to the previously viewed channel.
Favourite channel setting.
1. Register the favourite channel 2. Recall the favourite channel
Press
number
button
(1-4 only)
Press
number
button
(1-4 only)
Press and hold Press
WARNING:
Batteries shall not be exposed to excessive
heat such as direct sunshine, fi re or the like.
If this symbol is shown, it is only
valid in the European Union.
“AAA/R03” Batteries
If the favourite channel has not been registed
•
then “ No memory “ will be displayed.
Return Plus Programmed by select the frequently viewed channel then
press and hold
RETURN+
.
Return Plus Canceled by press and hold
RETURN+
.
Press and hold
CH
. PR changes without changing the picture screen.
Once you release the button, the picture of the selected PR will appear.
Move the picture with
or
while this bar is displayed.
V-Scroll
Hyper Scan :
Channel information
No Indication
PR List Calendar
Set 1-4 ? Favourite 1-4 ?
Programmed! will be displayed.
Insert the batteries
•
Use two “AAA/R03” dry cell batteries.
Insert the batteries from the end,
making sure the and polarities are
correct.
GGT0372-001A-H-EN.indd 3GGT0372-001A-H-EN.indd 3 13/07/2010 16:53:1913/07/2010 16:53:19
4
CHANNEL
VOLUME
MENU/OK
TV/VIDEO
VIDEO-2
R
L
V
2
3
4
5
6
1
Set up and connections
Care when setting
Hole for
belt
Belt (not
provided)
200 mm
150 mm150 mm 50 mm 50 mm
Screw (not provided)
Switch between TV / VIDEO
devices
Display on-screen menu / set
Change channel / Page /
Hyper Scan Function (P. 3)
Volume / Adjust
Power On / Off
Microphone
Power requirements
■
Connect the power cord only to a •
110-240V, 50/60Hz AC outlet.
When attaching the TV to the ■
wall, use the optional JVC wall
mounting unit.
Consult a qualifi ed technician.•
JVC assumes no responsibility for •
damage due to improper mounting.
400 mm x 200 mm mount which •
conforms to VESA standards.
Installation requirements ■
To avoid overheating, ensure the •
unit has ample room.
After all the connections
•
have been made, insert
the plug into an AC
outlet.
Connect an aerial and VCR / DVD Player
AERIAL
OR
VCR (DVD Player)
Stand Assembly
To prevent the TV from falling •
thread the belt through the hole
on the back of the stand and
secure it to the TV rack.
If the microphone is installed, •
should be lock it’s cable follow
picture.
Power lamp
ON : Lit (Blue)
OFF : Unlit
Power lamp lights while
the TV is on.
“Power Lamp” (P. 14)
•
Remote control sensor
GGT0372-001A-H-EN.indd 4GGT0372-001A-H-EN.indd 4 13/07/2010 16:53:2513/07/2010 16:53:25
5
HDMI-1
DVI ANALOG AUDIO
VIDEO-1
SUBWOOFER
OUTPUT
VIDEO-2
PC
V
L
R
L
R
V
L
R
PC AUDIO
(
(
PC IN
D-SUB
(
(
Pb Y
Pr
L
R
J
VC
VIDEO-1
R
L
V
Pr
Pb
Y
VIDEO-1
R
L
V
Pr
Pb
Y
J
V
C
(L) (R)
HDMI-1 HDMI-3HDMI-2
DIGITAL VIDEO/AUDIO
You can connect many different devices to the rear panel of the TV.
Please read the user manuals of each device before setup.
(Connecting cables are not supplied with this TV.)
Component input
Game
consoles
Video
camera
PC
VIDEO-1 Watching videos
Output Input
Composite signal / •
Component signal
(P. 20)
Sound L / R•
Use Component signal “Video - 1 •
Setting” (P. 16)
VIDEO-2 Watching videos
Output Input
Composite signal•
Sound L / R•
HDMI-1
HDMI-2
Connecting HDMI devices
HDMI-3
Output Input
HDMI signal (P. 20)•
“HDMI Setting” (P. 16)•
HDMI-2 and HDMI-3 inputs do not •
support analogue sound.
Connect a “DVI” device to •
“HDMI-1” (P.16)
Please use a High Speed HDMI•
TM
Cable. High Speed HDMI
TM
Cables
are tested to carry an HD signal up
to 1080p and higher.
OUTPUT
Subwoofer and sound signal of a
TV channel you are viewing outputs
from this terminal
Output
Subwoofer signal•
Sound L / R•
Composite input
Game Video
VCR
PC input line in
HDMI
TM
Connector.
DVD Player
Amplifi er
Subwoofer
(not provided)
DVD player
(HDMI compatible)
Microphone
DVD player
(HDMI compatible)
HD Video camera
Set up and connections (continued)
To “HDMI-1” To “HDMI-3”
To “HDMI-2”
Check for PC compatibility.•
“PC signals that can be displayed” (P. 17)
To Video-2
GGT0372-001A-H-EN.indd 5GGT0372-001A-H-EN.indd 5 13/07/2010 16:54:0213/07/2010 16:54:02
6
OK
OK
OK
OK
OK
OK
1. Select
2. Set
OK
1. Select
2. Set
OK
1. Select
2. Set
OK
Select
1
MENU
> Edit
PR
ID CH/CC
01 CH 02
02 CH 03
03 CH 07
04 CH 76
05 CH 12
06 CH 09
07 CH 05
08 CH 02
09 CH 15
10 CH 28
Set Up
> Channel Summary
CH/CC
ID Skip
CH 02
CH 03
CH 04
CH 05
CH 06
CH 07
CH 08
CH 09
CH 10
CH 11
Set Up
Set Up
> Teletext Language
Group-1
Group-2
Group-3
Group-4
Group-5
Group-6
Set Up
> Auto Program
Air
Cable
Set Up
> Country Area
Area - 1
Area - 2
> Language
English
Укрaїнcькa
ﻲﺑ ﺭﻋ Castellano
Français Melayu
Pуccкий ﻰﺴ ﺮ ﻔ
中文
Português
ไทย
Tiếng Việt
Set Up
Set Up
> Auto Program
50%
CH 40
Set Up
>> Auto Program
50%
CH 40
If you want to edit channel, see •
“Registering / Editing channels” (P. 7)
If you want to set undesired channels •
to be skiped, see “Channel Summary”
(P. 7)
See “Language group for Teletext” (P. 17).
•
Initial Settings
Show only when powering on for the fi rst time.•
The power on the unit can also be used.•
The select the new Country Area after Initial Setting has completed.•
Area-1 : Asia, Middle East, Europe, Oceania, Africa
Area-2 : South America, Philippines
(While the cursor is pointing to Picture menu and hold
for 3 seconds.)
1 Turn on the TV.
4 Select the Teletext language group. 4 Select Air or Cable.
2 Select a language. 3 Select Country Area.
5 Automatically register channels (Auto Program).
5 Searching for the channels (Auto Program).
6 Check what was registered.
6 Check what was registered.
JVC logo appears
If you select Country Area to “Area-1” If you select Country Area to “Area-2”
GGT0372-001A-H-EN.indd 6GGT0372-001A-H-EN.indd 6 13/07/2010 16:54:1313/07/2010 16:54:13
Loading...
