Contents

Enjoy rich multi-media with JVC

VHF / UHF / DVB-T broadcasting

Digital camera

Video camera

Game console

Personal

Audio components

VCR DVD player

DVD recorder

computer

* In this manual,

ATV : analogue terrestrial broadcasting (VHF / UHF) DTV : digital terrestrial broadcasting (DVB-T)

First things first!

Warning ············································ 4

Getting started

Names of all the parts ······················ 6



Basic connections ···························· 8



Connecting external devices ·········· 10



Initial settings ································· 12



Editing DTV channels ·····················14



Editing ATV channels ····················· 16



Let’s try it out

Enjoying your new TV! ··················· 18



· TV / Teletext / EPG / Video / Menu

Watching TV ···································20



Using EPG ····································· 22



Viewing teletext ······························ 24



Watching videos / DVDs ················ 26



Try the advanced features

Useful functions ······························28



· Multi-picture / Favourite channel

· Sleep timer / Child lock

Useful functions ······························30



Operate JVC recorders and other devices



··· 32

Just the way you like it

Customising your TV ······················ 34



Using DTV ······································ 36



Advanced picture adjustment ········· 42



· Reduce noise / Watch a more natural picture

· Set the aspect ratio, etc.

When you have trouble

Troubleshooting ····························· 44



CH/CC List ····································· 47



Technical information ····················· 48



Specifications ································· 49



First things ﬁrst!

IMPORTANT! PREPARE USE

SETTINGS

TROUBLE?

Warning

Follow this manual regarding setup!

 Connect only to a 220-240V, 50Hz AC

outlet.

Make enough room for inserting and removing the power plug!

Place the TV as close to the outlet as possible!

 The main power supply for this TV is

controlled by inserting or removing the power plug.

Never cut or damage the power cord!

 If the AC plug is not the

right shape, or the power cord is not long enough, use an appropriate plug adapter or extension cable. (Consult your retailer.)



If you have cut or damaged the power cord.

 “Technical information” (P. 48)

 To change the fuse in UK plugs

 “Technical information” (P. 48)

Please follow all the guidelines below

Do not allow the TV to fall!

 Do not rest your elbows on, or allow

children to hang from the TV. There is a risk that the TV will fall and cause injuries.

Never try to repair the TV yourself!

 If the problem cannot be solved in

“Troubleshooting” (P. 44), unplug the power cord and contact your retailer.

On disposal of the TV!

 Follow the instruction in

“Information for Users on Disposal of Old Equipment” (P. 1).

If the TV is damaged or behaving strangely, stop using it at once!

 Unplug the power cord and contact

your retailer.

Never place anything on the TV!

 Placing liquids, naked

flames, cloths, paper, etc. on the TV may cause a fire.

Never expose to rain or moisture!

 To prevent fire or electric

shock, never allow liquids to enter the unit.

Never insert objects into the cabinet openings!

 It may cause a fatal

electric shock. Take care when children are near.

Never listen to headphones at high volume!

 It may damage your hearing.

Unplug the power cord when going out!

 The power buttons on

the remote control and the TV unit cannot completely turn off the TV. (Make appropriate arrangements for bedridden people.)

 For more details on installation, usage and safety

When attaching the TV to the wall, use the optional JVC wall mounting unit!

 Consult a qualified technician.  See the included manual on mounting

procedures.

 JVC assumes no responsibility for

damage due to improper mounting.

 Consult your retailer

Never dismantle the rear panel!

 It may cause an electric shock.

Never obstruct the ventilation holes!

 It may cause overheating or a fire.

Handle LCD panel with care!

 Use a soft, dry cloth when cleaning.

Hold the TV so as not to scratch the screen!

 Do not touch the screen when carrying the

TV.

Do not carry the TV on your own!

 In order to prevent accidents,

ensure that the TV is carried by two or more people.

Getting

TV/AV

/OK

IMPORTANT! PREPARE USE

SETTINGS

TROUBLE?

started

Names of all the parts

ON: Lit (Green) OFF: Unlit

 Power lamp lights while

the TV is on.

 “Power Lamp” (P. 35)

Remove the terminal cover

Remote control sensorPower lamp

LT-37DR7BJ/SJ

Press to remove.

Cable cover

 If the cover cannot be closed due to the cables being in the way

 Do not force the cover to close (leave it open).

 Connecting terminals on the back of the TV  Connecting External devices  To remove the cable cover, refer to the included sheet.

Press to

remove.

LT-32DR7BJ/SJ

Switch between TV / AV devices

Display on-screen menu / set

Change channel / page

Volume

Power On / Off

To headphones

LT-26DR7BJ/SJ

Press to remove.

(P. 10)

Channel information

(P. 20)

Colour buttons

To ATV / DTV

Volume

To teletext

 When watching TV / Video

Change the aspect ratio

Turn on “3D Cinema Sound” (P. 20)

(P. 20)

Mute

(P. 24)

Power On / Off

Change channel / page

Watch video, etc.

(P. 26)

Switch between “TV / VCR / DVR / DVD / HC”

Display on-screen menu

Select and confirm settings in menus

Change channel / page To previous channel

 When watching DTV

View subtitles

 When watching ATV

when viewing teletext

(P. 20)

View the electronic programme guide (EPG)

(P. 16)

(P. 24)

(P. 21)

(P. 34)

(P. 22

)

Direction of TV

LT37DR7BJ/SJ

 For LT-32DR7BJ/SJ and

LT-26DR7BJ/SJ, the direction of the TV is fixed.

Tidying the cables

LT37DR7BJ/SJ LT32DR7BJ/SJ, LT26DR7BJ/SJ

Cable cover

 To remove the cable cover,

refer to the included sheet.

Take a snapshot of the screen

View in multi-picture mode

(P. 20)

(P. 28)

Check accessories

Remote control

(RM-C1905S)

 LT-26DR7BJ/SJ

To attach the stand, refer to the included sheet.

AAA/R03 Batteries

For confirming the TV works

 When choosing a favourite

channel

(P. 29)

 When operating a JVC VCR

or DVD

(P. 26)

Insert the batteries

Use two “AAA/R03” dry cell batteries. Insert the batteries from the - end, making sure the + and - polarities are correct.

CAM

IMPORTANT! PREPARE USE

SETTINGS

TROUBLE?

Basic connections

Please read the user manuals of each device carefully before setup. It is necessary to connect an aerial to watch TV.

 Connect with other devices  “Connecting external devices” (P. 10)

Connect the aerial

AERIAL

 After all the connections have been made, insert the plug into an AC outlet.

Connect a VCR / DVD recorder

EXT-2

EXT-1

VCR / DVD recorder

 After all the connections have been made, insert the plug into an AC outlet.  Connect “T-V LINK” compatible recording device to “EXT-2”.  “T-V LINK”  “What is “T-V LINK”?” (P. 12)

AERIAL

 Power requirements

 Connect the power cord only to a 220-240V, 50Hz

AC outlet.

 When attaching the TV to the wall, use the

optional JVC wall mounting unit

 Consult a qualified technician.  See the included manual on mounting procedures.  JVC assumes no responsibility for damage due to

improper mounting.

 200mm × 200mm mount which conforms to VESA

standards.

Care when setting Watch pay-per-view

 Installation requirements

 To avoid overheating, ensure the unit has ample

room.

200mm

50mm150mm 150mm 50mm

Contract with a broadcasting company beforehand.

1 Unplug the power cord 2 Insert the Viewing Card into the CAM. 3 Insert the CAM. 4 Plug the power cord, and turn the power on.

 Set pay-per-view  (P. 40)

 The CAM and Viewing Card will be sent by the broadcasting

company after contracting with them.

Conditional Access Module

Viewing Card

IMPORTANT! PREPARE USE

SETTINGS

TROUBLE?

Connecting external devices

VCR / DVD / other devices

You can connect many different devices to the rear panel of the TV. Please read the user manuals of each device before setting up. (Connecting cables are not supplied with this TV.)

To “EXT-3” R/L (PC IN)

 Check for PC compatibility

 “Technical information” (P. 48)

Game consoles

Video camera

VCR / DVD recorder

(“T-V LINK” compatible)

Satellite broadcast tuner

Headphone

DVD player

Amplifier

(L) (R)

 Audio signals received from

EXT-5 cannot be sent to the “AUDIO OUT” terminal.

Headphones

PC IN

(R)

(L)

EXT-3

EXT-2

(T-V LINK)

EXT-1

(Y)

(Pr)

(Pb)

(R)

(L)

(R)

(L)

EXT-4

AUDIO

OUT

: signal direction

AERIAL

EXT-5

(HDMI)

CAM slot

(“Watch pay-per-view” P.9)

(HDMI compatible)

DVD player

Not available.

(For service adjustments)

 Connect “DVI” devices

 (P. 48)

 “T-V LINK”  (P. 12)

EXT-1

Output  Input 

· Composite signal

· Sound L / R

 Use S-VIDEO  “S-IN” (P. 27)

EXT-2

Output  Input 

· Composite signal

· S-VIDEO (only for DTV)

· Sound L / R

· T-V LINK

 Use S-VIDEO  “S-IN” (P. 27)  Use DTV S-OUT  “S-OUT” (P. 27)  Select dubbing sources

 “DUBBING” (P. 27)

 Connect a decoder

 “Decoder (EXT-2)” (P. 35)

EXT-3

Output  Input 

EXT-4

Output  Input 



“Component Auto Select”  (P. 35)

EXT-5

Output  Input 

 “HDMI Setting”  (P. 35)

AUDIO OUT

Listening to the TV on external speakers

Output 

· Sound L / R

Watching videos

Composite signal / RGB / S-VIDEO

· Sound L / R

Dubbing videos Using “T-V LINK”

Composite signal / RGB / S-VIDEO

· Sound L / R

Watching videos

· Composite signal / S-VIDEO

· Sound L / R

Watching DVDs

Component signal (P. 49)

· Sound L / R

Connecting HDMI devices

· HDMI signal (P. 49)

Installation > Automatic Search

Channels:

100%

BBC ONE BBC TWO BBC THREE BBC NEWS 24 BBCi CBBC Channel

UHF CH:68

1 BBC ONE

Select Delete Edit Name Lock Favourites

EDIT PR LIST

1. BBC ONE

2. BBC TWO

7. BBC THREE

30. CBBC Channel

40. BBC NEWS 24

51. BBCi

CH 28

>> Auto Program

14%

> Auto Program

United Kingdom

Country

Ireland

02 03 04 05 06 07 08 09

ID CH/CC

BBC1 CH

CC CC

>Edit

Download TV Recording Device

T-V LINK

IMPORTANT! PREPARE USE

SETTINGS

TROUBLE?

Initial settings

Register DTV / ATV channels on TV. These channels can be edited later. (In this manual, digital broadcasting is indicated as DTV, and analogue broadcasting as ATV.)

 To the previous screen

 Exit

 If the “JVC” logo does not appear or

if you wish to make changes later

 DTV : “Automatic Search” (P. 40)

ATV : “Auto Program” (P. 35)

What is “T-V LINK”?

Connecting the TV to a “T-V LINK” compatible device allows :

 ATV channels on the TV to be

instantly registered on the device.

 The “DIRECT REC” function to be

used.

 “Technical information”

 “T-V LINK” variations

“T-V LINK” (JVC) “Q-LINK” (Panasonic) “Megalogic” (Grundig) “Data Logic” (Metz) “SMARTLINK” (Sony) “Easy Link” (Philips)

Begin

 The remote control

doesn’t work

 Shown only when powering on for the first time.  The power on the unit can also be used.

Automatically register DTV channels

 Confirm the mode is set to

“TV”.

Check what was registered

 Edit DTV channels

 @ in “Editing DTV

channels” (P. 14)

 Confirm

Automatically register ATV channels



TV/DTV



BACK

Check what was registered

Finish

select



If “ACI Start” appears, select and start settings. (This will set up cable television channels.)

 “What is ACI (Automatic Channel

Installation)?” (P. 48)

 Edit ATV channels

 @ in “Editing ATV

channels” (P. 16)

 When using T-V LINK

 Confirm



When not using T-V LINK

(P. 48)

 If “Feature Not

Available” appears :



Is a T-V LINK compatible device connected to EXT-2?

 Is the device turned on?

+ 18 hidden pages
