DVD VIDEO RECORDER

DR-MH220SE

INSTRUCTIONS

LPT1132-001A

This product is manufactured to comply with the radio interference requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC.

CAUTION

Dear Customer,

This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety.

European representative of Victor Company of Japan Limited. is: JVC Technology Centre Europe GmbH P.O. Box 10 05 52 61145 Friedberg Germany

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL

This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

CAUTION:

Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings should be never be blocked by placing the product on a bed, sofa, rug or other similar surface.This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer's instruction have been adhered to.

CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects filled with liquids, such as vases, should be placed on the apparatus.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a dedicated circuit;

That is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.

Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.

To disconnect power from the mains, pull out the mains cord plug. When installing the product, ensure that the plug is easily accessible.

CAUTION:

CLASS 2M VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.

CAUTION:

This product employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Should the unit require maintenance, contact an authorized service center. Performing controls, adjustments, or carrying out procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-9

Symbol Used in this Manual . . . . . . . . . . . . . . . .4

Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . .4

Recordable and Playable Discs . . . . . . . . . . . . .5

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . .6

Regional Code . . . . . . . . . . . . . . . . . . . . . . . . . .6

Availability of copying or moving feature . . . . . . .6

About the internal hard disk drive . . . . . . . . . . . .7

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . .9

Remote Control Operation . . . . . . . . . . . . . . . . .9

Recording . . . . . . . . . . . . . . . . . . . . . . . . . . . .34-41

About DVD recording . . . . . . . . . . . . . . . . . . . .34

About HDD recording . . . . . . . . . . . . . . . . . . . .34

Timeshift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Basic Recording from a TV . . . . . . . . . . . . . . . .36

Instant Timer Recording . . . . . . . . . . . . . . . . . .36

Timer Recording . . . . . . . . . . . . . . . . . . . . . . . .37

Timer Recording with S

HOWVIEW

System . . . . .38

Checking Timer Recording Details . . . . . . . . . .39

Recording from an External Input . . . . . . . . . . .39

Recording from DV Input . . . . . . . . . . . . . . . . .40

Simultaneous recording and playback . . . . . . . .41

Playback another title during recording . . . .41

Time Slip . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Introduction

Hookup and Settings . . . . . . . . . . . . . . . . . . .10-22

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Connecting to the Aerial . . . . . . . . . . . . . . . . . .10

Connections to Your TV . . . . . . . . . . . . . . . . . .11

Connecting to an Amplifier . . . . . . . . . . . . . . . .12

Accessory Audio/Video (A/V) Connections . .13-14

Using the Home Menu . . . . . . . . . . . . . . . . . . .15

Initial Settings . . . . . . . . . . . . . . . . . . . . . . . . . .15

General Operation . . . . . . . . . . . . . . . . . . . .15

General Settings . . . . . . . . . . . . . . . . . . . . .15-18

Auto Programming . . . . . . . . . . . . . . . . . . .15

Program Edit . . . . . . . . . . . . . . . . . . . . . . . .16

Auto Clock Set / Manual Clock Set . . . . . . .17

TV Aspect / Display Mode . . . . . . . . . . . . . .17

Progressive Scan . . . . . . . . . . . . . . . . . . . .17

AV2 Connection / Power Save Mode . . . . . .17

Initialization . . . . . . . . . . . . . . . . . . . . . . . . .18

Language Settings . . . . . . . . . . . . . . . . . . . . . .18

Audio Settings . . . . . . . . . . . . . . . . . . . . . . . . .18

Dolby Digital / DTS / MPEG . . . . . . . . . . . .18

Sampling Frequency . . . . . . . . . . . . . . . . . .18

DRC (Dynamic Range Control) . . . . . . . . . .18

Vocal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Lock Settings . . . . . . . . . . . . . . . . . . . . . . . . . .19

DivX Registration Code . . . . . . . . . . . . . . .19

Recording Settings . . . . . . . . . . . . . . . . . . . . . .19

Record Mode Set / Record Aspect . . . . . . . .19

DV Recording Audio / TV Recording Audio .19

Auto Chapter / AV2 Recording . . . . . . . . . . .19

Disc Settings . . . . . . . . . . . . . . . . . . . . . . . .20-21

Disc Format / Finalize . . . . . . . . . . . . . . . . .20

Disc Label / Disc Protect / PBC . . . . . . . . . .21

General Explanation of On-Screen Display . . . .22

Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23-33

General Playback Features . . . . . . . . . . . . .23-26

Playing a DivX Movie File . . . . . . . . . . . . . . . . .27

Playing an Audio CD or MP3/WMA file . . . . . . .28

Program Playback with Audio CD and

MP3/WMA file . . . . . . . . . . . . . . . . . . . . . . . . . .29

Viewing a JPEG File . . . . . . . . . . . . . . . . . .30-31

Editing a MP3/WMA, JPEG, DivX file . . . . . .32-33

Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42-49

Title List and Chapter List Menu Overview . . . .42

HDD, VR Mode: Original and Playlist Editing . . .43

Adding Chapter Markers . . . . . . . . . . . . . . . . .43

Changing Title Thumbnails . . . . . . . . . . . . . . . .43

Making a New Playlist . . . . . . . . . . . . . . . . . . . .44

Adding Additional Title/Chapters to the Playlist .44 Deleting an Original or Playlist Title/Chapter . . .45

Deleting a Part . . . . . . . . . . . . . . . . . . . . . . . . .45

Naming a Title . . . . . . . . . . . . . . . . . . . . . . . . .46

Time Search . . . . . . . . . . . . . . . . . . . . . . . . . .46

Sort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Undoing/Redoing the Last Deletion . . . . . . . . . .47

Combining Two Titles Into One . . . . . . . . . . . . .47

Divide One Titles Into Two . . . . . . . . . . . . . . . .48

Combining Two Chapters Into One . . . . . . . . . .48

Moving a Playlist Chapter . . . . . . . . . . . . . . . . .49

Hide a Chapter/Title . . . . . . . . . . . . . . . . . . . . .49

Protect a Title . . . . . . . . . . . . . . . . . . . . . . . . . .49

Dubbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50-52

Before Dubbing . . . . . . . . . . . . . . . . . . . . . . . . .50

Dubbing from HDD to DVD . . . . . . . . . . . . . . .51

Dubbing from DVD to HDD . . . . . . . . . . . . . . . .51

One Touch Copy (HDD to DVD) . . . . . . . . . . . .52

One Touch Copy (DVD to HDD) . . . . . . . . . . . .52

Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . .53-57

Additional Information . . . . . . . . . . . . . . . . . . . .53

Overwriting Recording . . . . . . . . . . . . . . . . .53

Viewing Title List menu displayed on other

DVD Recorders or Players . . . . . . . . . . . . .53

Playing Your Recordings on Other DVD

Players (Finalizing a Disc) . . . . . . . . . . . . . .53

Language Codes . . . . . . . . . . . . . . . . . . . . . . .54

Troubleshooting . . . . . . . . . . . . . . . . . . . . . .55-56

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . .57

Introduction

Notes on Discs

To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference.

This manual provides information on the operation and maintenance of your recorder. Should the unit require service, contact an authorized service location.

About the Symbol Display

“ ” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specific media.

Symbol Used in this Manual

Note:

Indicates special notes and operating features.

Tip:

Indicates tips and hints for making the task easier.

A section whose title has one of the following symbols are applicable only to the disc represented by the symbol.

Handling Discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center out.

Titles recorded on the HDD

HDD

DVD ALL

-RW

-RW +RW

-R

DVD VCD ACD DivX

MP3 WMA JPEG

All DVD discs listed below.

DVD-RW with VR recording mode

Video

DVD-RW with Video recording mode DVD+RW disc DVD-R disc DVD+R disc DVD-Video disc

Video CDs Audio CDs DivX files MP3 files WMA files JPEG files

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

Moisture Condensation

Never operate this product immediately after moving it from a cold location to a warm location. Leave it for two or three hours without operating it. If you use this product in such a situation, it may damage discs and internal parts.

Recordable and Playable Discs

DVD-RW (Digital Video Disc - ReWritable):

 DVD-RW discs can be formatted for VR mode recording or Video mode recording.  These Discs can be recorded on repeatedly. Recordings can be erased, then you can record again

on the same Disc.

[VR mode]

 Recordings can be extensively edited  Playable only on VR mode compatible players (after finalization)

[Video mode]

 Playable on regular DVD players (after finalization)  Limited editing features

DVD-R (Digital Video Disc - Recordable)

 These Discs can be recorded only once. After you finalize a DVD-R, you cannot record on it or edit it.  DVD-R discs can be only formatted to Video mode.  Playable on regular DVD players (after finalization)  Limited editing features

DVD+RW (Digital Video Disc + ReWritable)

 These Discs can be recorded on repeatedly. Recordings can be erased, then you can record again

on the same Disc.

 Playable on DVD+RW compatible players (automatically finalization)  The edited contents are playable on DVD+RW compatible players only after finalization  Recordings can be edited the title/chapter

DVD+R (Digital Video Disc + Recordable)

 These Discs can be recorded only once. After you finalize a DVD+R, you cannot record on it or edit

it any more.

 Playable on DVD+R compatible players (after finalization)  Any edited contents are not be compatible on DVD+R compatible players. (Hide, chapter combine,

added chapter mark, etc.)

 Limited title/chapter editing features.

Introduction

Recommended recordable DVD discs

DVD-R DVD+R DVD-RW DVD+RW

Mitsubishi (8x, 16x) Mitsubishi (8x, 16x) Mitsubishi (4x) Mitsubishi (4x)

That’s (8x, 16x) Ricoh (8x, 16x) Verbatim (4x) SONY (4x)

Verbatim (8x) Verbatim (8x) JVC (4x) Imation (4x)

--Victor (4x) Maxell (4x)

--Maxell (4x) Ricoh (4x)

Note: If a DVD-RW/DVD+RW discs is recorded using a personal computer or other DVD recorder, you cannot format the disc using this recorder. So if you want to use the disc on this recorder, you must format the disc using the original recorder.

Playable Discs

DVD (8 cm / 12 cm disc)

Discs such as movies that can be purchased or rented

Video CD (VCD) (8 cm / 12 cm disc)

VIDEO CDs or CD-Rs/CD-RWs in VIDEO CD/Super VIDEO CD format

Audio CD (8 cm / 12 cm disc)

Music CDs or CD-Rs/CD-RWs in music CD format that can be purchased

CD-R/CD-RW (8 cm / 12 cm disc)

CD-R/CD-RW discs that contain audio titles, DivX, MP3, WMA, or JPEG files.

Notes:

 Depending on the conditions of the recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some

CD-R/RW (or DVD±R/RW) discs cannot be played on the unit.

 Do not attach any seal or label to either side (the labeled side or the recorded side) of a disc.  Do not use irregularly shaped CDs (e.g., heart-shaped or octagonal). Doing so may result in malfunctions.  Depending on the recording software & the finalization, some recorded discs (CD-R/RW or DVD±R/RW) may

not be playable.

 DVD-R/RW, DVD+R/RW and CD-R/RW discs recorded using a personal computer or a DVD or CD Recorder

may not play if the disc is damaged or dirty, or if there is dirt or condensation on the Recorder’s lens.

 If you record a disc using a personal computer, even if it is recorded in a compatible format, there are cases

in which it may not play because of the settings of the application software used to create the disc. (Check with the software publisher for more detailed information.)

 This recorder requires discs and recordings to meet certain technical standards in order to achieve optimal

playback quality. Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 or WMA files) and these require certain preexisting conditions (see above) to ensure compatible playback.

 Customers should note that permission is required in order to download MP3 / WMA files and music from the

Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner.

Regional Code

This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labeled same as the rear of the unit or “ALL”.

Notes on Regional Codes



Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your unit’s regional code or the disc cannot play.



If you try to play a DVD with a different regional code from the unit, the message “Incorrect region code. Can’t play back” appears on the TV screen.

Availability of copying or moving feature

From To MP3/WMA JPEG DivX Audio CD Video CD Title*

HDD DISC No No No No No Yes

DISC HDD Yes Yes Yes No No Yes

*1 The title is recorded from this unit.

About the internal hard disk drive

The internal hard disk drive (HDD) is a fragile piece of equipment. Please use the recorder following the guidelines below to protect against possible HDD failure. We recommend that you back up your important recordings onto DVD discs in order to protect against accidental loss.

 Do not move the recorder while it is on.

 Install and use the recorder on a stable, level

surface.

 Do not block the rear vent/cooling fan.

 Do not use the recorder in excessively hot or humid

places, or in places that may be subject to sudden changes in temperature. Sudden changes in temperature can cause condensation to form inside the recorder. This can be a cause of HDD failure.

 While the recorder is switched on, do not unplug

from the wall socket or switch the electricity off from the breaker switch.

 Do not move the recorder immediately after

switching it off. If you need to move the recorder, please follow the steps below:

1. After the message POWER OFF is shown in the display, wait at least two minutes.

2. Unplug from the wall socket.

3. Move the recorder.

 If there’s a power failure while the recorder is on

there is a chance that some data on the HDD will be lost.

 The HDD is very delicate. If used improperly or in

an unsuitable environment, it is possible that the HDD will fail after a few years of use. Signs of problems include playback unexpectedly freezing and noticeable block noise (mosaic) in the picture. However, sometimes there will be no warning signs of HDD failure.

If the HDD fails, no playback of recorded material will be possible. In this case it will be necessary to replace the HDD unit.

Introduction

Front Panel

ab c defghi

jklm

a STANDBY/ON button

Switches the recorder ON or OFF.

b Display window

Shows the current status of the recorder.

T/S: Indicates the timeshifting mode.

REC: The recorder is recording.

HDD: The recorder is HDD mode.

DVD: The recorder is DVD mode.

HDD bBDVD: The recorder is dubbing. TV: Indicates when the recorder is in TV tuner

mode.

: Indicates when the recorder is in timer

recording or a timer recording is programmed.

: Indicates clock, total playing

time, elapsed time, title number, chapter/track number, channel, etc.

c Disc Tray

Insert a disc here.

d OPEN/CLOSE (Z)

Opens or closes the disc tray.

e DVD/HDD

Set the recorder’s mode to HDD or DVD.

f PR (+/-)

Scans up or down through memorized channels.

g z (REC)

Starts recording. Press repeatedly to set the recording time.

h N / X (PLAY / PAUSE)

Starts playback. Pause playback or recording temporarily, press again to exit pause mode.

i x (STOP)

Stops playback or recording.

j Remote Sensor

Point the recorder remote control here.

k DV IN

Connect the DV output of a digital camcorder.

l AV IN 4 (S-VIDEO IN)

Connect the S-Video output of an external source (TV/ Monitor, VCR, Camcorder, etc.).

m AV IN 4 (VIDEO IN/AUDIO IN (Left/Right))

Connect the audio/video output of an external source (Audio system, TV/ Monitor, VCR, Camcorder, etc.).

Remote Control

• The recorder’s remote control code is set to C code.

• The other JVC devices may be operated by this remote control without your purpose. In this case, you should change the remote control code of the other device to prevent confusion.

    

STANDBY/ON: Switches the

recorder ON or OFF.

OPEN/CLOSE (Z): Opens and closes the disc tray.

DVD: Selects the unit’s function mode to DVD.

HDD: Selects the unit’s function mode to HDD.

AV INPUT: Changes the input to use for recording (Tuner, AV1-4, or DV IN).

0-9 numerical buttons: Selects numbered options in a menu.

DUBBING: Copies DVD to HDD (or HDD to DVD).

JVC TV Control Buttons

-STANDBY/ON: Turns the TV on or off.

-AV INPUT: Selects the TV’s source.

- PR +/–: Selects TV’s channel.

- VOL +/–: Adjusts TV’s volume.

- %: Temporarily turns TV sound OFF, press again to restore.

    

AUDIO: Selects an audio language or audio channel.

SUBTITLE: Selects a subtitle language.

CLEAR: Removes a track number on the Program List or a mark on the Marker Search menu.

REC (z): Starts recording. REC MODE: Selects the recording

mode. TIMER REC: Displays Timer

Record menu.

    

m / M: Search backward or forward.

. / >: Go to next or previous chapter or track.

PAUSE (X): Pause playback or recording temporarily.

PLAY (N): Starts playback. STOP (x): Stops playback or

recording.

    

HOME: Accesses or removes the HOME menu.

MENU/LIST: Accesses menu on a DVD disc. Switches between Title List-Original and Title List-Playlist menu.

b / B / v / V (left/right/up/down):

Selects an option in the menu.

ENTER ( )

- Acknowledges menu selection.

- Displays information while viewing a TV program.

PR (+/-): Scans up or down through memorized channels.

DISPLAY: Accesses On-Screen Display.

RETURN (O): Removes the menu.

    

TIMESHIFT: Activates pause live TV/playback (timeshift) for a live TV program.

MARKER: Marks any point during playback.

SEARCH: Displays Marker Search menu.

SETUP: Accesses or removes the Setup menu.

PIP: Selects PIP function on or off. ZOOM: Enlarges video image. TITLE: Displays the disc’s Title

menu, if available. CHP. ADD: Inserts a chapter

marker when playing/recording. I.SKIP (INSTANT SKIP): Skips 14

seconds forward during playback. REPEAT: Repeat chapter, track,

title, all.

A-B: Repeat sequence. THUMBNAIL: Selects a thumbnail

picture. TV/VIDEO: To view channels

selected by the recorder tuner or by the TV tuner.

HOWVIEW : To display the

program menu for S

HOWVIEW

System programming.

Introduction

Remote Control Operation

Point the Remote Control at the remote sensor and press the buttons.

Caution

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

Remote Control Battery Installation

Remove the battery cover on the rear of the Remote Control, and insert two R03 (size AAA) batteries with and matched correctly.

Hookup and Settings

Rear Panel

abcdef g

hijk

a AERIAL

Connect the aerial to this terminal.

b EURO AV 2 DECODER

Connect the audio/video output of an external source (Pay-TV decoder, Set Top Box, VCR, etc.).

c AV OUT 3 (VIDEO / AUDIO OUT (Left/Right))

Connect to a TV with video/audio inputs.

d AV IN 3 (VIDEO IN/AUDIO IN (Left/Right))

Connect the audio/video output of an external source (Audio system, TV/ Monitor, VCR, Camcorder, etc.).

e COAXIAL (Digital audio out jack)

Connect to digital (coaxial) audio equipment.

f Cooling fan

g AC Power Cord

Plug into the power source.

Connecting to the Aerial

Remove the aerial cable plug from your TV set and insert it into the aerial socket at the back of the recorder. Plug one end of the aerial cable into the TV socket on the recorder and the other end into the aerial input socket on your TV set.

h RF. OUT

Passes the signal from the AERIAL to your TV/monitor

i EURO AV 1 AUDIO/VIDEO

Connect to a TV with SCART jack.

j VIDEO OUT SELECT Switch

Select either COMPONENT or RGB signal of EURO AV1 AUDIO/VIDEO terminal depending on how you connect the recorder to the TV.

k COMPONENT/PROGRESSIVE SCAN VIDEO

OUT (Y Pb Pr)

Connect to a TV with Y Pb Pr inputs.

Aerial

ANTENNA

INPUT

SCART INPUT

Rear of TV

AUDIO INPUT

VIDEO INPUT

RF coaxial connection

Connect the RF. OUT jack on the recorder to the aerial input jack on the TV using the 75-ohm Coaxial Cable supplied (R). The RF. OUT jack passes the signal through from the AERIAL jack.

Rear of the recorder

Connections to Your TV



Make one of the following connections, depending on the capabilities of your existing equipment.



When using the COMPONENT/PROGRESSIVE SCAN VIDEO OUT jacks, set the VIDEO OUT SELECT switch to COMPONENT. When using the SCART jack, set the VIDEO OUT SELECT switch to RGB.

Tips



Depending on your TV and other equipment you wish to connect, there are various ways you could connect the recorder. Use only one of the connections described below.



Please refer to the manuals of your TV, VCR, Stereo System or other devices as necessary to make the best connections.

Caution

– Make sure the recorder is connected directly to the

TV. Tune the TV to the correct video input channel.

– Do not connect the recorder’s AUDIO OUT jack to

the phono in jack (record deck) of your audio system.

– Do not connect your recorder via your VCR. The

DVD image could be distorted by the copy protection system.

SCART connection

Connect the EURO AV1 AUDIO/VIDEO scart jack on the recorder to the corresponding in jacks on the TV using the scart cable (T).

Video connection

Connect the VIDEO OUT jack on the recorder to the video in jack on the TV using the video cable (V).

Audio (Left/Right) Connection

Connect the left and right AUDIO OUT jacks of the recorder to the audio left and right IN jacks on the TV using the audio cables (A). Do not connect the recorder’s AUDIO OUT jack to the phono in jack (record deck) of your audio system.

Component Video connection

Connect the COMPONENT / PROGRESSIVE SCAN VIDEO OUT jacks on the recorder to the corresponding input jacks on the TV using an Y Pb Pr cable (C).

If your television is a high-definition or “digital ready” television, you may take advantage of the recorder’s progressive scan output for the highest video resolution possible. If your TV does not accept the Progressive Scan format, the picture will appear scrambled if you try Progressive Scan on the recorder.



Set the [Progressive Scan] option to [ON] on the setup menu for progressive signal, see page 17.

Settings

Hookup and

Rear of TV

SCART INPUT

Rear of the recorder

COMPONENT VIDEO INPUT

Note:

VIDEO

AUDIO INPUT

INPUT

Progressive scan does not work with the analog video connections (yellow VIDEO OUT jack).

Caution

Once the setting for Progressive Scan output is entered, an image will only be visible on a Progressive Scan compatible TV or monitor. If you set Progressive Scan to [ON] in error, you must reset the

recorder. First, remove the disc in the recorder. Next, press STOP (x) and hold it for five seconds before

releasing it. The video output will be restored to the standard setting, and a picture will once again be visible on a conventional analog TV or monitor.

Connecting to an Amplifier

Connecting to an amplifier equipped with two channel analog stereo or Dolby Pro Logic ll/ Pro Logic

Connect the Left and Right AUDIO OUT jacks on the recorder to the audio left and right in jacks on your amplifier, receiver, or stereo system, using the audio cables (A).

Connecting to an amplifier equipped with two channel digital stereo (PCM) or to an Audio/ Video receiver equipped with a multi-channel decoder (Dolby Digital™, MPEG 2, or DTS)

1. Connect one of the recorder’s DIGITAL AUDIO

OUT jacks (COAXIAL X) to the corresponding in jack on your amplifier. Use an optional digital (coaxial X) audio cable.

2. You will need to activate the recorder’s digital output. (See “Audio Settings” on page 18).

Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this you need a multi-channel Audio/Video receiver that supports one or more of the audio formats supported by your recorder (MPEG 2, Dolby Digital and DTS). Check the receiver manual and the logos on the front of the receiver.

Caution:

Due to the DTS Licensing agreement, the digital output will be in DTS digital out when DTS audio stream is selected.

Rear of the recorder

A X

AUDIO INPUT DIGITAL INPUT

COAXIAL

Amplifier (Receiver)

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the doubleD symbol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

Notes:

– If the audio format of the digital output does not

match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

– Six Channel Digital Surround Sound via digital

connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

–To see the audio format of the current DVD in the

on-screen display, press AUDIO.

– This recorder does not perform internal (2 channel)

decoding of a DTS sound track. To enjoy DTS multi channel surround, you must connect this recorder to a DTS compatible receiver via one of this recorder’s digital audio outputs.

Accessory Audio/Video (A/V)

VCR RECORDER

Line input 1

Line input 2

Connections

Connecting a PAY-TV/Canal Plus Decoder

You can watch or record PAY-TV/Canal Plus programmes if you connect a decoder (not supplied) to the recorder. Disconnect the recorder’s mains lead from the mains when connecting the decoder.

To watch or record PAY-TV/Canal Plus programmes, set [AV2 Connection] option to [Decoder] (see page

17) and set the program’s [Decoder On/Off] option to [On] on the Setup menu (page 16).

Tip:

You do not need to turn on the recorder to view the signals from the connected tuner on your TV.

Note:

If you disconnect the recorder’s mains lead, you will not be able to view the signals from the connected decoder.

VCR, Cable Box, or

Satellite Tuner, etc.

Settings

Hookup and

Rear of the recorder

PAY-TV/Canal Plus Decorder

SCART AV

Rear of the recorder

Connecting to the EURO AV2 DECODER jack

Connect a VCR or similar recording device to the EURO AV2 DECODER jack of this recorder.

To watch or record the source from EURO AV2 DECODER jack, set [AV2 Connection] option to [Others] (see page 17) and set [AV2 Record] option to [Auto], [CVBS] or [RGB] as required (see page 19).

Tip:

You do not need to turn on the recorder to view the signals from the connected tuner on your TV.

Notes:

 Pictures containing copy protection signals that

prohibit any copying cannot be recorded.

 If you pass the recorder signals via the VCR, you

may not receive a clear image on your TV screen. Be sure to connect your VCR to the recorder and your TV in the order shown below. To watch video tapes, watch the tapes through a second line input on your TV.

 When you record to a VCR from this recorder, do

not switch the input source to TV by pressing the TV/VIDEO button on the remote.

 If you are using a B Sky B tuner, be sure to connect

the tuner’s VCR SCART jack to the EURO AV2 DECODER jack.

 If you disconnect the recorder’s mains lead, you will

not be able to view the signals from the connected VCR or tuner.

Connecting to the AV IN 3 or AV IN 4 Jacks

Connect the input jacks (AV IN 3, AV IN 4) on the recorder to the audio/video out jacks on your accessory component, using audio/video cables.

Note:

If you use the S-VIDEO IN jack on the front panel, the VIDEO IN jack on the front panel is not available.

Jack panel of Accessory Component

(VCR, Camcorder, etc.)

AUDIO

OUTPUT

Connecting a Digital Camcorder

Using the front panel DV IN jack, it is possible to connect a DV digital camcorder and digitally transfer DV tapes to DVD.

Use a DV cable (not supplied) to connect the DV in/out jack of your DV camcorder to the front panel DV IN jack of this recorder.

Note:

This jack is for connection to DV digital camcorder only. It is not compatible with digital satellite tuners or D-VHS video decks.

Rear of the recorder

VIDEO

OUTPUT

S-VIDEO

OUTPUT

DV Digital Camcorder

IN/OUT

Front of

the recorder

Front of the recorder

Using the Home Menu

From the Home Menu screen you can access all the Media for playback and recording of the recorder.

1. Press HOME to display the Home Menu screen.

2. Use the b / B buttons to select a main option you

want. Sub options appears.

3. Use the v / V and ENTER buttons to select the

sub option you want.

4. To exit the HOME menu, press HOME.

General Operation

1. Press SETUP and the Setup menu appears.

2. Use v / V to select the desired option.

3. While the desired item is selected, press B to

move to the second level.

4. Use v / V to select the second desired option.

5. Press B to move to the third level.

6. Use v / V to select the desired setting then press

ENTER to confirm your selection. Some items require additional steps.

7. Press SETUP to exit the Setup menu.

Note:

Press b to go back to the previous level.

Settings

Hookup and



TV HDD: Returns to live TV viewing for HDD recording.



TV DVD: Returns to live TV viewing for DVD recording.

MOVIE



HDD: Displays the Title List menu for HDD. (page 42)



HDD DivX: Displays the [Movie List] menu for HDD. (page 27)



DISC:

Displays Title List menu for recordable disc (page 42)

- Displays [Movie List] menu for DivX disc. (page 27)

- Plays back Video CD or DVD-Video disc (page 23-26).

PHOTO (See page 30)



HDD: Displays [Photo List] menu for HDD.



DISC: Displays [Photo List] menu for disc.

MUSIC (See page 28)



HDD: Displays [Music List] menu for HDD.



DISC: Displays [Music List] (or Audio CD) menu for disc.

SETUP (See page 15)



Start: Displays Setup menu.

Initial Settings

In this menu system, there are several ways to customize the settings provided. Most menus consist of three levels to set up the options, but some require greater depth for the variety of settings.

General Settings

Auto Programming

This recorder is equipped with a frequency synthesized tuner capable of receiving up to 88 TV channels.

Preparation:

 Connect the recorder to the desired type of aerial,

as shown in Connecting to the Aerial on page 10.

1. Select the [Auto Programming] option.

2. Press B to move to the third level.

[Country] option is highlighted.

3. Use v / V to select a country then press B.

[Start] icon is highlighted. If your country is not listed, select [Others]

4. Press ENTER to begin the channel search. The tuner will automatically cycle through all available channels in the area and place them in the tuner’s memory.

Note:

After you have connected your recorder for the very first time. If you press SETUP for initial setting, you can only set the [Auto Programming] option. Then you can set the other options.

General Settings (Continued)

Program Edit

You can edit a channel manually (add, delete, name, move, etc.).

1. Select [Program Edit] option then press B.

2. Press ENTER while [Edit] is selected. The Program List menu appears.

3. Use v / V to select a PR number then press ENTER.

4. Use v / V to select the program option then press ENTER.

 [Program Edit] Sets the channel manually. See

“Program Edit” on the right.

 [Station Rename] Changes the station name.

The display for entering characters appears. To enter characters, see page 46. Names can be up to 5 characters long.

 [Move] Sorts the programme positions on the

Program List. Press v / V to move the selected programme position to a new location.

 [Delete] Disables a programme position you do

not need.

 [Decoder On/Off] Sets the channels for the

decoder. You need this setting to watch or record PAY-TV/Canal Plus programmes. Press ENTER so [Decoder] appears on the display. Press ENTER again to turn off the setting.

 [NICAM Auto/off] Sets the channels for the

NICAM broadcast. Normally, [NICAM] is lit on the display. If the sound from NICAM broadcast is not clear, press ENTER so [NICAM] disappears.

5. Press RETURN (O) repeatedly to exit Program List menu.

Program Edit

You can perform a search to select and store TV channels manually. When you select [Program Edit] in step 4 above, the display for setting channels appears.

1. Use b / B to select the item and press v / V to

change the setting.

 [PR] indicates the selected programme position.

 [Seek] Searches for a channel automatically.

Searching stops when the recorder tunes in a channel.

 [Ch.] Changes the channel number.

 [MFT] Fine tunes the channel to obtain a clearer

picture.

2. Choose OK then press ENTER to confirm the setting and returns to the Program List menu.

AV1 Decoder

Sets the EURO AV1 AUDIO/VIDEO jack for inputting encoded video signals.

1. Press AV INPUT while the Program List menu

appears.

2. Press ENTER so [Canal+] appears on the display.

Press ENTER again to turn off the setting.

 Off: Inputs the signals from the EURO AV1

AUDIO/VIDEO jack. Normally select this.

 On: The encoded video signal input from the

EURO AV1 AUDIO/VIDEO jack is output to the EURO AV2 DECODER jack for decoding. The decoded signal is then input back through the EURO AV2 DECODER jack so you can record or view PAY-TV/Canal Plus programmes.

General Settings (Continued)

Auto Clock Set

When Channel auto search is completed the actual Time and Date are also set automatically. If the time in the recorder display is not correct, the clock must be set manually.

1. Select [Clock set] option then press B.

2. Use v / V to select [Auto] option then press

ENTER.

Note:

There are cases where the TV station does not send, or sends wrong date and/or time information and the recorder sets the incorrect time. If this happens, we recommend that you set the clock manually.

Manual Clock Set

1. Select [Clock set] option then press B.

2. Use v / V to select [Manual] option then press

ENTER.

3. Enter the necessary information for date and time.

b / B (left/right): Moves the cursor to the previous or next column.

v / V (up/down): Changes the setting at the current cursor position.

4. Press ENTER to confirm your setting.

TV Aspect

Selects the aspect ratio of the connected TV (4:3 standard or wide).

 [4:3] Select this when connecting to a 4:3 screen

TV. When you select [4:3], set [Display Mode] below.

 [16:9] Select this when connecting to a wide-screen

TV or TV with a wide mode function.

Display Mode

Selects how to display a wide picture on the screen when [4:3] is selected in [TV Aspect].

 [Letter Box] Displays a wide picture with bands on

the upper and lower portions of the screen.

 [Pan Scan] Automatically displays a wide picture on

the entire screen and cuts off the portions that do not fit.

Progressive Scan

Progressive Scan Video provides the highest quality pictures with less flickering. If you are using the COMPONENT/PROGRESSIVE SCAN VIDEO OUT jacks, but are connecting the recorder to a standard (analog) television, set Progressive Scan to [OFF]. If you are using the COMPONENT/PROGRESSIVE SCAN VIDEO OUT jacks for connection to a TV or monitor that is compatible with a progressive scan signal, set Progressive Scan to [ON].

Note:

Progressive Scan will be disable in the setup menu when the VIDEO OUT SELECT switch on the rear panel is set to RGB position.

Caution

Once the setting for Progressive Scan output is entered, an image will only be visible on a Progressive Scan compatible TV or monitor. If you set Progressive Scan to [ON] in error, you must reset the recorder. First, remove the disc in the recorder. Next, press STOP (x) and hold it for five seconds before releasing it. The video output will be restored to the standard setting, and a picture will once again be visible on a conventional analog TV or monitor.

AV2 Connection

You can connect a decoder or other device to the EURO AV2 DECODER socket on the back.

 [Decoder] Select [Decoder] if you connect the

recorder’s EURO AV2 DECODER jack to a PAY-TV or Canal Plus decoder.

 [Others] Select [Others] if you connect the

recorder’s EURO AV2 DECODER jack to a VCR or similar recording device.

Power Save Mode

You can set up the unit into an economic power save mode. Nothing is displayed in the display window when the unit is turned off.

 [OFF] Power Save Mode is not active.

 [ON] Power Save Mode is active.

Notes:

 The encoded television signals (CANAL+ or

PREMIERE) are not decoded in the Power Save Mode.

 The Power Save Mode is not available in the

standby mode for the timer recording and when power off of the unit after receiving the encoded television signals (CANAL+ or PREMIERE).

Settings

Hookup and

General Settings (Continued)

Audio Settings

Initialization

You can reset the recorder to its original factory settings and initialize the HDD.

 [Factory Set] If you need to, you can reset the

recorder to all its factory settings.

 [HDD format] Initializes the HDD (Hard Disk Drive):

everything recorded on the HDD will be erased.

1. Select [Initialize] option then press B.

2. Press v / V to select the desired option then press

ENTER. The confirm message will appear.

3. Use b / B to select [Yes] or [No] then press

ENTER.

Language Settings

Each DVD disc has a variety of audio output options. Set the recorder’s Audio Output according to the type of audio system you use.

Dolby Digital / DTS / MPEG

 [Bitstream]: Select “Bitstream” if you connect the

recorder’s DIGITAL AUDIO OUT jack to an amplifier or other equipment with a Dolby Digital, DTS or MPEG decoder.

 [PCM] (for Dolby Digital / MPEG): Select when

connected to a two-channel digital stereo amplifier. DVDs encoded in Dolby Digital or MPEG will be automatically downmixed to two-channel PCM audio.

 [Off] (for DTS): If you select “Off”, the DTS signal is

not output through the DIGITAL AUDIO OUT jack.

Display Menu

Select a language for the Setup menu and on-screen display.

Disc Menu/Audio/Subtitle

 [Original]Refers to the original language in which

the disc was recorded.

 [Other] To select another language, press number

buttons then ENTER to enter the corresponding 4-digit number according to the language code list in the reference chapter (see page 54). If you enter the wrong language code, press CLEAR.

 [Off](for Disc Subtitle) : Turn off Subtitle.

Sampling Frequency

If your receiver or amplifier is NOT capable of handling 96 kHz signals, select [48 kHz]. When this choice is made, this unit will automatically convert any 96 kHz signals to 48 kHz so your system can decode them. If your receiver or amplifier is capable of handling 96 kHz signals, select [96 kHz]. When this choice is made, this unit will pass each type of signal through without any further processing.

DRC (Dynamic Range Control)

With the DVD format, you can hear a program’s soundtrack in the most accurate and realistic presentation possible, thanks to digital audio technology. However, you may wish to compress the dynamic range of the audio output (the difference between the loudest sounds and the quietest ones). Then, you may listen to a movie at a lower volume without losing clarity of sound. Set DRC to [ON] for this effect.

Vocal

Set Vocal to [ON] only when a multi-channel karaoke DVD is playing. The karaoke channels on the disc will mix into normal stereo sound.

Note:

Set the [Dolby Digital] option to [PCM] for the vocal function if using the digital audio out jack.

Lock Settings

DV Recording Audio

You need to set this if you have a camcorder using 32kHz/12-bit sound connected to the front panel DV IN jack. Some digital camcorders have two stereo tracks for audio. One is recorded at the time of shooting; the other is for overdubbing after shooting. On the Audio 1 setting, the sound that was recorded while shooting is used. On the Audio 2 setting, the overdubbed sound is used.

DivX Registration Code

We provide you the DivX® VOD (Video On Demand) registration code that allows you to rent and purchase videos using the DivX® VOD service. For more information, visit www.divx.com/vod.

1. Select [DivX Reg. Code] option then press B.

2. Press ENTER while [View] is selected and the registration code will appear.

3. Use the registration code to purchase or rent the videos from DivX® VOD service at www.divx.com/vod. Follow the instructions and download the video onto a disc for playback on this unit.

Note:

All the downloaded videos from DivX® VOD can only be played back on this unit.

DivX

Recording Settings

TV Recording Audio

When TV recording with bilingual, you can choose audio channel to record. [Main+Sub] Main language and Sub language [Main] Main language only [Sub] Sub language only

Auto Chapter

When recording in Video mode, chapter markers are put in specified setting. You can change this interval to 5 minutes, 10 minutes or 15 minutes. If you select [None], switch off automatic chapter marking altogether with the [None] setting.

AV2 Recording

You can select the type of the signal when recording video input signal from the device connected to the EURO AV2 DECODER socket. [Auto] The video input signal will automatically follow the video signal received. [CVBS] Only for recording CVBS input signal. [RGB] Only for recording RGB input signal.

Settings

Hookup and

Record Mode Set

You can set the picture quality for recording; XP (High Quality), SP (Standard Quality), LP (Low Quality), EP (Extend Quality).

Record Aspect

When DVD recording, you can set the recording aspect ratio to suit the material you’re recording (16:9 or 4:3).

Disc Settings

Disc Format

If you load a completely blank disc, the recorder will initialize the disc.

DVD-R: The recorder initialize the disc to Video mode. The recording mode will always be Video mode. DVD-RW/DVD+RW/DVD+R: The Initialize menu will appears. Select [OK] then press ENTER.

DVD-RW disc is initialized to VR mode. Also, you can reformat the DVD-RW/DVD+RW from the Setup menu as below.

Finalize

Finalizing ‘fixes’ the recordings in place so that the disc can be played on a regular DVD player or computer equipped with a suitable DVD-ROM drive. Finalizing a Video mode disc creates a menu screen for navigating the disc. This is accessed by pressing MENU/LIST or TITLE.

Caution

Once you have finalized a DVD-R and DVD+R disc, you cannot edit or record anything else on that disc except DVD+RW. However, you can record and edit a DVD-RW disc by choosing [Unfinalize] option.

1. Select [Disc Format] option then press B.

2. Press ENTER while [Start] is selected.

Format Disc menu appears.

3. Use b / B to select a desired mode (VR Mode or

Video Mode) then press ENTER. Confirm message will appear. For DVD+RWs, go to step 4.

4. Use b / B to select [OK] then press ENTER.

It takes a few moments to initialize the disc.

Caution If you want to change the disc format, everything recorded on the disc will be erased.

Note:

If a DVD-RW/DVD+RW discs is recorded using a personal computer or other DVD recorder, you cannot format the disc using this recorder. So if you want to use the disc on this recorder, you must format the disc using the original recorder.

1. Select [Finalize] option then press B.

2. Press ENTER while [Finalize] is selected. Finalize menu appears.

3. Select [OK] then press ENTER. The recorder starts finalizing the disc.

Note:



How long finalization takes depends on the type of disc, how much is recorded on the disc, and the number of titles on the disc.

Tips

 If you load a DVD-RW that has already been

finalized, you can ‘Unfinalize’ it by choosing Unfinalize from the Finalize menu. After doing this, you can edit and re-record onto the disc.

 You cannot unfinalize a DVD-R and DVD+R disc.

 If [Disc Protect] option is set to [ON], the finalize is

not available. To finalize, set [Disc Protect] option to [OFF].

Disc Settings (Continued)

Disc Label

Use this to enter a name for the disc. This name appears when you load the disc and when you display disc information on-screen.

 The disc name can be up to 32 characters long.  For discs formatted on a different recorder, you will

see only a limited character set.

1. Select [Disc Label] option then press B.

2. Press ENTER while [Edit] is selected. Keyboard menu appears. To e nter characters, see page 46.

Disc Protect

When recording in DVD+RW / +R disc or VR mode formatted DVD-RW disc, set to [ON] to prevent accidental recording, editing or deleting of the disc loaded. If you need to unlock the disc to make edits, select [OFF].

PBC

PBC stands for Playback Control and refers to special menus and navigation features that are available on some Video CDs.

 [ON] Video CDs are played according to the PBC, if

available.

 [OFF] Video CDs are played the same way as Audio

CDs.

Settings

Hookup and

General Explanation of On-Screen Display

This manual gives basic instructions for operating the recorder. Some DVDs require specific operation or allow only limited operation during playback. When this occurs, the symbol appears on the TV screen, indicating that the operation is not permitted by the recorder or is not available on the disc.

Displaying Information While Watching TV

During viewing the TV, press ENTER or DISPLAY to display/remove the information displayed on-screen.

Indicates channel number, station name, and

audio signal (STEREO, MONO) received by

the tuner.

Indicates the record mode,

free space, and elapsed

time progress bar.

Indicates disc name and format.

Displaying Disc Information on-screen

You can display various information about the disc loaded on-screen.

1. Press DISPLAY once to show current status.

2. Press DISPLAY once again to show various playback information. The items displayed differ depending on the disc type or playing status.

3. You can select an item by pressing v / V and change or select the setting by pressing b / B. For details about each item, see the pages in parentheses.



[Title]: Current title (or track) number/total number of titles (or tracks) (page 23, 25)



[Chapter]: Current chapter number/total number of chapters (page 23)



[Time]: Elapsed playing time (page 25)



[Audio]: Selected audio language (DVD VIDEO only) or audio channel (page 24)



[Subtitle]: Selected subtitle (page 24)



[Angle]: Selected angle/total number of angles (page 25)



[Sound]: Selected sound mode (page 26)

Indicates current date and time.

Note:

If no button is pressed for 10 seconds, the on-screen display disappears.

Playback

General Playback Features

1. Load your chosen disc in the tray, with the playback side down.

2. Starts playback using HOME menu (see page 15).

3. To stop the playback, press STOP (x). The unit records the stopped point, depending on the disc. “Xx” appears on the screen briefly. Press PLAY (N) to resume playback (from the scene point). If you press STOP (x) again or unload the disc (“x” appears on the screen.), the unit will clear the stopped point.

Note:

The resume point may be cleared when a button is pressed (for example; TIMER REC, HOME, MENU/LIST, etc).

4. Press OPEN/CLOSE (Z) to remove the disc. Press OPEN/CLOSE (Z) to close disc tray or press STANDBY/ON, the disc tray closes automatically and unit turns off.

Note:

When using a DVD+R/RW, the recorder will execute the Menu-making operation to update the new title and editing when removing the disc from the recorder or turn off the recorder. So you must remove the disc after selecting the recorder’s operation mode to DVD mode.

Playback

Buttons Operations

OPEN / CLOSE (Z) Opens or closes the disc tray.

PAUSE (X) During playback, press PAUSE (X) to pause playback.

Press PAUSE (X) repeatedly to play Frame-by-Frame.

Tip:

You can advance or back up the picture frame-by-frame by pressing b / B repeatedly during PAUSE mode. The picture frame-by-frame in reverse is not available for Video CD.

. / > During playback, press . or > to go to the next

chapter/track or to return to the beginning of the current chapter/track. Press . twice briefly to step back to the previous chapter/track.

Tips:



To go directly to any chapter during DVD playback, press DISPLAY twice and press v / V to select the chapter icon. Then, input the chapter number or use b / B.



On an Audio CD, to go directly to any track, enter the track number using the numbered buttons (0-9) during playback.

m / M During playback, press m or M repeatedly to select the

required scan speed. HDD, DVD; 5 steps DivX; 4 steps Video CD, Audio CD; 3 steps

While the playback is paused, press m or M repeatedly to play in slow motion. HDD, DVD; 4 steps Video CD; 3 steps (Forward only)

Discs

All Discs

VCDDVD ALLHDD

MP3ACDDivX

WMA

VCDDVD ALLHDD

ACDDivX

VCDDVD ALLHDD

General Playback Features (Continued)

Buttons Operations

ZOOM During playback or pause mode, press ZOOM to enlarge

the video image. (x1 size → x2 size → x4 size → x1 size (normal size) You can move through the zoomed picture using bBvV buttons.

REPEAT During playback, press REPEAT repeatedly to select a

desired repeat mode. HDD (Title/Off), DVD (Chapter/Title/Off) VR mode DVD-RW (Chapter/Title/All/Off) Video CD, Audio CD (Track/All/Off) MP3/WMA (Track/Folder/Off)

Notes:



On a Video CD with PBC, you must set PBC to [OFF] in the Setup menu to use the Repeat function. See page 21.



If you press > once during Repeat Chapter (Track) playback, the repeat playback cancels.

A-B During playback, each press of A-B button to select point A

and point B and repeats a sequence from point A (Starting point) to point B (End point).

Note:

During HDD playback, you cannot select a sequence less than 5 seconds.

TITLE If the current DVD title has a menu, the title menu appears

on the screen. Otherwise, the disc menu may appears.

MENU/LIST The disc menu appears on the screen.

SUBTITLE During playback, press SUBTITLE then press b / B

repeatedly to select a desired subtitle language.

AUDIO Press AUDIO then press b / B repeatedly to hear a

different audio language or audio track.

Note:

Some discs feature both Dolby Digital and DTS soundtracks. There is no analog audio output when DTS is selected. To listen to the DTS soundtrack, connect this recorder to a DTS decoder via one of the digital outputs. See page 12 for connection details.

Press AUDIO then press b / B repeatedly during playback to hear a different audio channel (STEREO, LEFT or RIGHT).

With DVD-RW discs recorded in VR mode and HDD that have both a main and a Bilingual audio channel, you can switch among Main (L), Sub (R), or Main+sub (L+R).

Press AUDIO repeatedly during playback to hear a different audio channel (STEREO, LEFT or RIGHT).

I.SKIP Press I.SKIP repeatedly during playback to skip forward

14 seconds. In HDD playback or Timeshift mode, each press b / B

skips forward or reverse 5 minutes.

Discs

ACD

DVD

HDD

-RW

DivXVCD

DVD ALLHDD

WMAMP3ACD

-RW

+R-R+RW

VCDDVD ALLHDD

Video

If a menu screen is displayed

VCDDVD

The menu screen may be displayed first after loading a DVD or Video CD which contains a menu.

DVD

Use the b / B / v / V buttons to select the title/chapter you want to view, then press ENTER to start playback. Press TITLE or MENU/LIST to return to the menu screen.

VCD



Use the number buttons to select the track you want to view. Press RETURN (O) to return to the menu screen.



Menu setting and the exact operating procedures for using the menu may differ depending on the disc. Follow the instructions on the each menu screen. You may also set PBC to [OFF] under Setup menu (see page 21).

Moving to another TITLE

Video

HDD

-RW

DivXDVD+R-R+RW-RW

When a disc has more than one title, you can move to another title as follows:



Press DISPLAY twice during playback then use v / V to select the title icon. Then, press the appropriate numbered button (0-9) or b / B to

select a title number.

Marker Search

HDD

-RW

VCDDVD

To enter a Marker

You can start playback from up to six memorized points. To enter a marker, press MARKER at the desired point on the disc. The Marker icon appears on the TV screen briefly. Repeat to enter up to six markers.

To Recall or Clear a Marked Scene

1. During disc playback, press SEARCH. The marker search menu appears on the screen.

2. Use b / B / v / V to select a marked scene that you want to recall or clear.

3. Press ENTER and playback starts from the marked scene. Or, press CLEAR and the marked scene is erased from the marker search menu.

Video

+R-R+RW-RW

Playback

Time Search

HDD

-RW

Video

+RW-RW

DivXDVD+R-R

To start playing at any chosen time on the disc:

1. Press DISPLAY twice during playback. The time search box shows the elapsed playing time.

2. Press v / V to select the time clock icon and “0:00:00” appears.

3. Input the required start time in hours, minutes, and seconds from left to right.

If you enter the wrong numbers, press b

B to

move the under bar (_) to the wrong number. Then enter the correct numbers.

4. Press ENTER to confirm. Playback starts from the selected time.

Camera Angle

DVD

If the disc contains scenes recorded at different camera angles, you can change to a different camera angle during playback.

1. Press DISPLAY during playback. The On-Screen Display appears on the TV screen.

2. Use v / V to select the Angle icon in the OnScreen Display.

3. Use b / B to select a desired angle. The number of the current angle appears on the TV screen.

Tip:

The ANGLE indicator will blink on the TV screen at scenes recorded at different angles to indicate that angle switching is possible.

3D Surround

-RW

Video

-R+RW-RW

DivXVCDDVD+R

PIP (Picture in Picture)

Video

HDD

-RW

VCDDVD+R-R+RW-RW

This unit can produce a 3D Surround effect, which simulates multi-channel audio playback from two conventional stereo speakers, instead of the five or more speakers normally required to listen to multichannel audio from a home theater system.

1. Press DISPLAY during playback. The On-Screen Display appears on the TV screen.

2. Use v / V to select the Sound icon in the OnScreen Display.

3. Use b / B to select “3D SUR”. To turn off the 3D Surround effect, select “NORMAL”.

Last Condition Memory

DVD

This recorder memorizes the user settings for the last disc that you have viewed. Settings remain in memory even if you remove the disc from the recorder or switch off the recorder. If you load a disc that had its settings memorized, the latest stop position is automatically recalled.

Notes:

– Settings are stored in memory for use any time. – This recorder does not memorize settings of a disc

if you switch off the recorder before commencing to play it.

This function enables you to view the stored stations in sub picture during playback.

On and off

Press PIP to switch on the sub picture, press this button again to switch it off.

Input mode selection for sub picture

Press AV INPUT to select the input mode for the sub picture. Each time this button is pressed, each input mode for the sub picture is displayed as shown below.

→

Tuner

AV1→AV2→AV3→AV4

Program selection for sub picture

Use PR (+/-) to change the program when sub picture’s input is set to tuner. The selected program number is displayed on the TV screen. You can view the selected program by pressing STOP (x).

Sub picture position change

Press b / B repeatedly until desired position is achieved. The sub picture moves clockwise or counterclockwise.

Zoom Sub picture

Press ZOOM repeatedly to enlarge the sub picture, the magnification level increases up to three steps.

Playing a DivX Movie File

The recorder can play Divx files. Before playing DivX files, read “DivX file requirement” on right.

1. Press HOME then select [MOVIE] option.

2. Select a media that contains DivX file(s) then press ENTER. The [Movie List] menu appears on the TV screen.

3. Press v / V to select a folder, and press ENTER. A list of files in the folder appears. If you are in a file list and want to return to the Folder list, use the

v / V buttons on the remote to highlight and press ENTER.

4. If you want to view a particular file, press v / V to highlight a file and press PLAY (N). You can use variable playback functions. Refer to pages 23-26.

5. Press STOP to stop the playback. The [Movie List] menu appears.

 To exit the menu screen, press HOME and

select [TV DVD] or [TV HDD] option then press ENTER.

Notice for displaying the DivX subtitle

If the subtitle does not display properly, please follow the steps below.

1. Press PAUSE (X) when the subtitle appears.

2. Press and hold SUBTITLE about 3 seconds. The language code will appear.

3. Press b / B to select another language code until the subtitle is displayed properly.

4. Press PLAY (N) to continue playback.

Movie List menu options

1. Press v / V to select a folder/file on the [Movie

List] menu then press ENTER. [Movie List] menu options appear. The menu options displayed differ depending on the selected media.

2. Press v / V / b / B to select an option, and press

ENTER.

 [Play] Start playback the selected title.  [Open] Opens the folder and a list of files in the

folder appears.

 [Delete] Deletes the file(s) or folder(s) from the

media.

 [Rename] Edits the file name.(page 32)  [Move] Moves the file(s) to another folder or

media. (page 33)

 [Copy] Copies the file(s) to another folder or

media. (page 33)

DivX file requirement

Available resolution size: 720x576 (W x H) pixel DivX file extensions: “.avi”, “.divx” Playable DivX subtitle: “.smi”, “.srt”,

“.sub (Micro DVD format only)”, “.txt (Micro DVD format only)”

Playable Codec format: “DIV3”, “MP43”, “DIVX”, “XVID”, “DX50”

Playable Audio format: “AC3”, “PCM”, “MP2”, “MP3”, “WMA”

 Sampling frequency:

within 8 - 48 kHz (MP3), within 32 - 48kHz (WMA)

 Bit rate:

within 8 - 320kbps (MP3), within 32 - 192kbps (WMA)

CD-R Format: ISO 9660 and JOLIET. DVD±R/RW Format: ISO 9660 (UDF Bridge format) Maximum Files/Disc: Less than 1999 (total number

of files and folders)

Notes on DivX format

 If the number of the screen frame is over 29.97

frames per second, this unit may not operate normally.

 If the video and audio structure of recorded file is

not interleaved, returns to the menu screen.

 If the file is recorded with GMC, the unit supports

only 1-point of the record level.

GMC?

* GMC is the acronym for Global Motion

Compensation. It is an encoding tool specified in MPEG4 standard. Some MPEG4 encoders, like DivX or Xvid, have this option. There are different levels of GMC encoding, usually called 1-point, 2-point, or 3-point GMC.

Playback

Playing an Audio CD or MP3/WMA file

The recorder can play audio CDs and MP3/WMA files. Before playing MP3/WMA files, read “MP3/WMA audio file requirement” on right.

1. Press HOME. The HOME menu appears.

2. Select [MUSIC] option.

3. Select a media that contains MP3/WMA or audio title then press ENTER. The [Music List] menu appears on the TV screen.

4. Use v/V to select a track then press PLAY (N). Playback starts. You can use variable playback functions. Refer to pages 23-26.

Tips:

 Press DISPLAY to view ID3-Tag information for

the MP3 file. If ID3-Tag information is not present, [ID3-Tag: None] will appear. If you select a folder, the number of subfolders and number of MP3/WMA files in the folder are displayed. Press DISPLAY again to remove the information screen.

 If you want to move to the upper directory, use

the v / V to highlight and press ENTER.

 You also display HOME menu to select another

media by pressing HOME.

 To exit the menu screen, press HOME and

select [TV DVD] or [TV HDD] option then press ENTER.

5. To stop playback at any time, press STOP.

Tip:

You can create new folder. Select [New Album] option on the Music-HDD menu then press ENTER. “NONAME##” folder is created.

Audio CD and Music menu options

1. Press v / V to select a folder/file on the Audio CD

or Music menu then press ENTER. The menu options appear. The menu options displayed differ depending on the selected media.

2. Press v / V / b / B to select an option, and press

ENTER.

 [Play] Start playback the selected title.

 [Random] Start or stop random playback.

 [Open] Opens the folder and a list of files in the

folder appears

 [Delete] Deletes the file(s) from the media.

 [Rename] Edits the file name. (page 32)

 [Move] Moves the file(s) to another folder or

media. (page 33)

 [Copy] Copies the file(s) to another folder or

media. (page 33)

 [Program Add] Adds the track(s) to Program List.

(page 29)

Random

1. Press v / V to select a file then press ENTER.

The menu options appear.

2. Press v / V to select [Random] option then press

ENTER. The unit automatically begins random playback and “RANDOM” appears on the menu screen.

3. To return to normal playback, select [Random] option again then press ENTER.

Tip:

By pressing > during Random playback, the unit selects another track and resumes Random playback.

MP3/WMA audio file requirement

File extensions

“.mp3”, “.wma”.

 The WMA files with DRM are not supported.

Sampling frequency:

within 8 - 48 kHz (MP3), within 32 - 48kHz (WMA)

Bit rate:

within 8 - 320kbps (MP3), within 32 - 192kbps (WMA)

CD-R Format:

ISO 9660 and JOLIET.

DVD±R/RW Format:

ISO 9660 (UDF Bridge format)

Maximum Files/Disc:

Less than 1999 (total number of files and folders)

Program Playback with Audio CD and MP3/WMA file

Program Playback enables you to make custom playlists of Audio CD or MP3/WMA tracks. Programs can contain up to 99 Audio CD tracks or 256 MP3/WMA files.

1. Use v / V to select a track/file (or folder) on the

Audio CD or Music menu. You can select all MP3/WMA files and folders on the Music menu by pressing CLEAR button. To cancel the selections, press CLEAR again.

Selecting multiple files/tracks (folders)

1. Press MARKER. A check mark appears on the file/track or folder. Press MARKER again to cancel the marked file/track or folder.

2. Repeat step 1 to mark additional file/track (folders).

2. Press ENTER. The options appear on the left side of the menu.

3. Use v / V to select the [Program Add] option then press ENTER.

4. Repeat steps 1-3 to mark additional tracks.

Note:

If you select a folder for Programmed Playback, all tracks/files in the folder are added to the Program List.

Program List menu options

1. Press v / V to select a track/file on the Program

List then press ENTER. The menu options appear.

2. Use v / V to select an option then press ENTER

to confirm your selection.

 [Play] Playback begins in the order in which you

programmed the tracks from the selected track.

 [Random] Start or stop random playback.

 [Delete] Deletes the track(s) from the Program

List menu.

 [Move] Moves the track(s) to change the

program order.

 [Save] Memorizes the program list. (HDD only)

Repeat Programmed Tracks

Press REPEAT to select the desired Repeat mode.

 [TRACK] Repeats the current track.  [ALL] Repeats all tracks on the Program List.  [OFF] Cancels Repeat mode (no display).

Playback

5. Use B to move to the Program list. The programmed track you selected last is highlighted on the program list.

6. Use v / V to select the track you want to start playing.

7. Press PLAY (N) to start. Playback stops after playing the last programmed track in the program list.

8. To exit Program Playback and resume normal playback, select a track on the List and press PLAY (N).

Tip:

You can access or remove the Program List screen by pressing MENU/LIST.

Erasing a Track from the Program List

1. Select the track you wish to erase from the Program List. Use MARKER button to select multiple tracks.

2. Press ENTER. The menu options appears

3. Select [Delete] option then press ENTER.

Changing Track Order in the Program List

1. Select the track you wish to move on the Program List. Use MARKER button to select multiple tracks.

2. Press ENTER. The menu options appears

3. Select [Move] option then press ENTER.

4. Use v / V to move the yellow bar to the desired location, then press ENTER.

Save Your Program List (HDD only)

This recorder memorizes the user program list that you have programmed.

1. Select a track on the Program List. The menu options appear.

2. Select [Save] option then press ENTER. The Program List is saved in the HDD’s PROGRAM folder.

Viewing a JPEG File

The recorder can play JPEG files. Before playing JPEG recordings, read “Photo file requirement” on right.

1. Press HOME. The HOME menu appears.

2. Select [PHOTO] option.

3. Select a media that contains JPEG file then press ENTER. The [Photo List] menu appears on the TV screen.

4. Use b / B / v / V to select a file, then press ENTER. The menu options appear on the left side of the menu.

Tips:

 If you want to move to the upper directory, use the

v / V to highlight and press ENTER.

 You can also display HOME menu to select another

media by pressing HOME.

5. Use v / V to select [Full Screen] then press ENTER. The selected image is displayed in full screen. Depending upon the size and number of JPEG files, it could take a long time for the recorder to read the files.

Photo List menu options

1. Press v / V to select a file on the [Photo List]

menu then press ENTER. The menu options appear. The menu options displayed differ depending on the selected media. You can select all files and folders on the menu by pressing CLEAR button. To cancel the selections, press CLEAR again.

Selecting multiple files (folders)

1. Press MARKER. A check mark appears on the file or folder. Press MARKER again to cancel the marked file or folder.

2. Repeat step 1 to mark additional file (folders).

2. Use v / V to select an option then press ENTER

to confirm your selection.

 [Open] Opens the folder and a list of files in the

folder appears

 [Full Screen] Shows the selected file as full

screen.

 [Delete] Deletes the selected file from the media.

 [Slide Show] Displays Slide Show menu.

 [Rename] Edits the file name. (page 32)

 [Move] Moves the file(s) to another folder

(album) or media. (page 33)

 [Copy] Copies the file(s) to another folder or

media. (page 33)

Tip:

You can create new folder in the HDD. Select [New Album] option then press ENTER. “NONAME##” folder is created.

Press ENTER to appear or disappear this menu during viewing the full screen.

6. To stop viewing at any time, press STOP. The [Photo List] menu appears.

 To exit the menu screen, press HOME and

select [TV DVD] or [TV HDD] option then press ENTER.

Photo file requirement

File extensions

“.jpg”

Photo size:

Less than 4MB recommended

CD-R Format:

ISO 9660 and JOLIET.

DVD±R/RW Format:

ISO 9660 (UDF Bridge format)

Maximum Files/Disc:

Less than 1999 (total number of files and folders)

Notes on JPEG file

Progressive and lossless compression JPEG image files are not supported.

Skip Images

While viewing a picture, press .or > once to advance to the next file or return to the previous file.

Rotate Images

Use v / V while viewing a picture to flip the picture clockwise or counterclockwise.

View Slide Shows

1. Select [Slide Show] option on the [Photo List] menu (Refer to “Photo List menu options” on page 30).

2. Press ENTER. The Slide Show menu appears.

3. Use b / B / v / V to set the options. [Object] option:

 [Selected] Views slide show only selected files.

Use the MARKER button to select multiple files.

 [All] Views slide show all files.

[Speed] option: Sets the Slide Show speed to [Slow], [Normal], or [Fast].

4. Select the [Start] option then press ENTER to start the Slide Show.

5. Press STOP to stop the Slide Show and returns to the [Photo List] menu.

To listen to music while slide show simultaneously

You can display photo files while listening to MP3/WMA music files recorded on HDD.

1. Select [Slide Show] option on the [Photo List] menu (Refer to “Photo List menu options” on page 30).

2. Press ENTER. The Slide Show menu appears.

3. Select [Simultaneous Music play] option on the

Slide Show menu

4. Press ENTER.

Simultaneous Music play menu appears.

5. Press MARKER to select multiple files.

 Select [Select All] option to select all tracks then

press ENTER.

 Select [Deselect All] option to deselect all

selected tracks then press ENTER.

 Select [Cancel] option to exit this menu then

press ENTER.

6. Use b / B / v / V to highlight [Start] option then

press ENTER.

Playback

To Pause the Slide Show

1. Press PAUSE (X) to pause slide show.

2. When you want to continue slide show, press

PLAY (N).

7. Press STOP to stop the Slide Show and return to

the [Photo List] menu.

Editing a MP3/WMA, JPEG, DivX file

These descriptions are MP3 file’s operation for example, other kind’s files are operated same way.

Erasing a file(s)/folder(s) from the HDD

You can erase MP3/WMA, JPEG or DivX file(s)/ folder(s) on the HDD.

1. Select a file you wish to erase on the menu. You can select all files and folders on the menu by pressing CLEAR button. To cancel the selections, press CLEAR again.

Selecting multiple files (folders)

1. Press MARKER.

A check mark appears on the file or folder. Press MARKER again to cancel the marked file or folder.

2. Repeat step 1 to mark additional file (folders).

2. Press ENTER. The menu options appear on the menu.

Naming a file on the HDD

You can name MP3/WMA files on the HDD independently. Names can be up to 32 characters long.

1. Select a file you wish to rename on the menu.

2. Press ENTER. The menu options appear on the menu.

3. Select [Edit] option then press ENTER. Edit options appears.

4. Select [Rename] option then press ENTER. Keyboard menu appears. To enter characters, see page 46.

3. Select [Delete] option then press ENTER. The selected file(s) is deleted.

Copying a file(s) to a folder on HDD

You can copy a file(s)/folder(s) to a folder on HDD.

1. Select a file you wish to copy on the menu. You can select all files and folders on the menu by pressing CLEAR button. To cancel the selections, press CLEAR again.

Selecting multiple files (folders)

1. Press MARKER.

A check mark appears on the file or folder. Press MARKER again to cancel the marked file or folder.

2. Repeat step 1 to mark additional file (folders).

2. Press ENTER. The menu options appear on the menu.

3. Select [Edit] option then press ENTER. Edit options appears.

4. Select [Copy] option then press ENTER. Copy menu appears.

Moving a file(s) to a folder on HDD

You can move a file(s)/folder(s) to a folder on HDD. After moving, the file(s)/folder(s) are deleted from the current location.

1. Follow steps 1-3 as shown left.

2. Press ENTER. The options appear on the left side of the menu.

3. Select [Edit] option then press ENTER. Edit options appears.

4. Select [Move] option then press ENTER. Move menu will appear.

5. You can select a album (folder) to copy.

1. After selecting a media then press ENTER. The album (folder) list appears.

2. Select a folder. Also, you can create new album (folder). Select [New Album] option on the Copy menu then press ENTER. “NONAME##” folder is created.

6. Select [Copy] option then press ENTER to begin copying.

5. You can select a album (folder) to move.

1. After selecting a media then press ENTER. The album (folder) list appears.

2. Select a folder. Also, you can create new album (folder). Select [New Album] option on the Move menu then press ENTER. “NONAME##” folder is created.

6. Select [Move] option then press ENTER to begin moving.

Playback

Note:

If a folder’s depth is more than 5 level, the copy is not available.

Recording

About DVD recording

Notes:

 This recorder cannot make recordings on CD-R or

CD-RW discs.

 Our company takes no responsibility for recording

failure due to power outages, defective discs, or damage to the Recorder.

 Fingerprints and small scratches on a disc can

affect playback and/or recording performance. Please take proper care of your discs.

Disc types and recording formats, modes, and settings

This recorder can play five different kinds of DVD discs: pre-recorded DVD-Video discs, DVD-RW, DVD-R, DVD+RW and DVD+R discs. The disc format for DVD-R, DVD+R, DVD+RW discs is always “Video format”—the same as pre-recorded DVD-Video discs. This means that once finalized, you can play a DVDR, DVD+R, or DVD+RW in a regular DVD player. By default, the DVD-RW disc format is Video Recording (VR) format, though you can change this to Video format, if required. (Reinitializing the disc will erase the contents of the disc.) The recording mode is closely related to the disc format. If the disc format is Video Recording format, then the recording mode is VR mode; if the disc format is Video mode, then the recording mode is Video mode (except for DVD-Video, which is not recordable, and so does not have a recording mode). Within the recording modes (which are fixed for them whole disc) are the record settings. These can be changed as required for each recording and determine the picture quality and how much space the recording will take up on the disc.

About HDD recording

Recording to the internal hard disk drive (HDD) is basically similar to recording to a VR mode DVD-RW disc. You have the full choice of recording quality options, including the manual mode, and of course you can record, erase and re-record as many times as you like. The capacity of the hard disk drive means that you can store many hours of video on it, even in the higher quality recording modes. To help you organize the contents, the HDD is divided into ten genre. You can name and use these genres as you like—for example, you might have a genre for movies, another for TV shows, and one for camcorder recordings.

Note:

 The maximum number of titles that can be recorded

on the HDD is 255.

 Using the HDD allows you to record a maximum of

12 hours continuously.

Notes for recording

 The recording times shown are not exact because

the recorder uses variable bit-rate video compression. This means that the exact recording time will depend on the material being recorded.

 When recording a TV broadcast, if the reception is

poor or the picture contains interference, the recording times may be shorter.

 If you record still pictures or audio only, the

recording time may be longer.

 The displayed times for recording and time

remaining may not always add up to exactly the length of the disc.

 The recording time available may decrease if you

heavily edit a disc.

 If using a DVD-RW disc, make sure you change the

recording format (Video mode or VR mode) before you record anything on the disc. See page 20 (Disc Format) for how to do this.

 When using a DVD-R or DVD+R disc, you can keep

recording until the disc is full, or until you finalize the disc. Before you start a recording session, check the amount of recording time left on the disc.

 When using a DVD-RW disc in Video mode,

recording time available will only increase if you erase the last title recorded on the disc.

 The Delete Title option in the Title List (Original)

menu only hides the title, it does not actually erase the title from the disc and increase the recording time available (except for the last recorded title on a DVD-RW disc in Video mode).

 Overwrite recording is available using DVD+RW

discs.



Recording time and picture quality

There are four preset recording quality modes:

 XP – Highest quality setting, gives about

1 hour of recording time on a DVD (4.7GB).

 SP –

 LP – Slightly lower video quality, gives about 4 hour

 EP – Lowest video quality, gives about 6 hour of

Default quality, sufficient for most applications,

gives about 2 hours of recording time on a DVD (4.7GB).

of recording time on a DVD disc (4.7GB).

recording time on a DVD (4.7GB). You may see a fragmented picture during playing back the contents recorded in EP mode .

Timeshift

HDD

Do not miss a scene from a live broadcast. If the telephone rings while you are watching your favorite live broadcast, just press “TIMESHIFT” and “PAUSE (X)” before answering the phone. The timeshift function will be activated and the broadcast is then recorded for later viewing. After the phone call or viewing interruption, press “PLAY” or “m / M” to watch the program. Press “STOP” to return to the live broadcast.

Timeshift (Pause, Live TV/Playback) Operation

You can store a program in the HDD storage cache temporarily.

Press TIMESHIFT while watching a TV program.

The Progress Bar display appears on the screen as shown below. The Progress Bar changes to timeshift icon after 5 seconds.

34 5

1. Indicates playback mode.

2. Indicates current Timeshift position.

3. Indicates Timeshift start time.

4. Indicates Timeshift elapsed time.

5. Indicates the time that is one hour from Timeshift start time.

Tips:

 You can use trick play functions (Slow, Scan, etc.)

during timeshift. Refer to Playback Operation on pages 23-26.

 You can edit the cached clip during Timeshift to

retain the program on the HDD. Refer to Clip Record on the right.

Notes:

 There is not free space on the HDD, the oldest

timeshift section of the cache will be incrementally deleted.

 If no button is pressed for 6 hours, the Timeshift will

stop automatically.

HDD

Marker Search in Timeshift mode

You can mark one in Timeshift mode. Press MARKER at the desired point during Timeshift. Press SEARCH to recall the marked scene.

Clip Record

HDD

You can edit during Timeshift to store the program on the HDD (Hard Disk Drive).

1. During Timeshift, use pause step, search and slow-motion to find the starting point.

2. Press REC at the starting point of the section you want to record. Progress of the edit is indicated in red on the Progress Bar.

3. Use pause step, search and slow-motion to find the ending point.

4. Press REC at the ending point of the section you want to record. Normal playback continues.

5. Repeat steps 1 and 4 to make several Clip Records of a program.

6. Press STOP to stop Timeshift. Confirm message will appear.

7. Use b / B to select [Yes] then press ENTER. Or, press STOP again. The current broadcast is displayed on the screen.

Notes:

 Selected sections are recorded on the HDD.  If you want to stop Clip recording, press the STOP

button. If you press STANDBY/ON to stop Clip recording, the program may not be recorded on the HDD.

 Clip records cannot be made for sections lasting

less than 5 seconds.

Jump to Start or End during Timeshift

1. Press ENTER during timeshift. The menu will appear.

2. Press b and playback starts from the very beginning of the timeshift.

Press B and jumps to the very end of the timeshift then goes to pause mode.

To Exit the Timeshift

1. Press STOP to exit Timeshift function. Confirm message will appear.

2. Use b / B to select [Yes] then press ENTER. The current broadcast is displayed on the screen.

Recording

Basic Recording from a TV

Follow the instructions below to record a TV program. Recording starts immediately and continues until the disc is full or you stop the recording.

Note:

You must load a recordable disc for DVD recording.

1. Press HOME. The HOME menu appears.

2. Select [TV] option.

3. Select [TV HDD] or [TV DVD] option then press ENTER. Also make sure that the TV input is set to this recorder. If you load a completely blank disc, the recorder takes a short while to initialize the disc.

4. Set a recording mode as necessary by pressing REC MODE repeatedly. (XP, SP, LP, EP)

5. Use PR (+/-) buttons to select the TV channel to record.

Changing TV Audio Channel

You can select the audio channel (language) to listen by pressing AUDIO during viewing TV program. The current audio channel is displayed on-screen.

Stereo or mono broadcast: Stereo → Left → Right → Mono

Bilingual broadcast: Main → Sub → Main+Sub

 For TV recording with bilingual, set audio channel

from the [TV Rec Audio] in sub-menu of the Setup menu (see page 19).

 If the sound is of poor quality when set to Stereo,

you can often improve it by changing to Mono (Left or Right).

 This recorder can record either NICAM or regular

audio. If the NICAM setting (page 16) is set to Auto, then if the broadcast is NICAM, the audio automatically changes to NICAM and you can record the NICAM audio. If the broadcast is nonNICAM, the regular audio is always recorded. If NICAM sound distortion occurs, due to poor reception, you can switch off NICAM setting of the program.

6. Press REC (z) once. Recording will start. (The REC indicator lights in the display window.)



Recording continues until you press STOP (x) or the disc or HDD is full.



To record for a fixed length of time, see Instant Timer Recording on right.

To Pause the Recording

1. Press PAUSE (X) to pause recording.

2. When you want to continue recording, press

PAUSE (X).

To record one TV program while watching another

1. Press TV/VIDEO to select the TV mode during recording. The TV indicator appears.

2. Using the TV, select the channel to be viewed.

Instant Timer Recording

Instant Timer Recording allows you to make a recording easily of a preset length without using the program timer.

1. Follow steps 1-5 as shown left (Basic Recording from a TV).

2. Press REC (z) repeatedly to select the recording time length.

Recording starts after the first press. Each subsequent press increases the recording time within free space (maximum 240 minutes). The recording time is displayed on the TV screen. At the end of the recording, the recorder will stop recording and shut off.

Checking the Recording Time

Press REC (z) once to check the recording time. The recalled setting will automatically return to the TV screen for a moment. Also, remaining time of recording is shown in the display window.

To Extend the Recording Time

The recording time can be extended anytime by pressing REC (z).

Each subsequent press increases the recording time within free space (maximum 240 minutes).

Caution

If the recorder is unplugged (or there is a power failure) while the recorder is recording, the recording will be lost.

7. Press STOP (x) to stop recording.

Timer Recording

This recorder can be programmed to record up to 16 programs within a period of 1 month. For unattended recording, the timer needs to know the channels to be recorded, the starting and ending time.

Note:

If you use a completely blank disc for timer recording, you must format the disc before starting timer recording. (Refer to “Disc Format” on page 20.)

1. Press TIMER REC. The Timer Record menu will appear.

 [Media] Choose a media to record (HDD or

DVD).

 [PR] Choose a memorized program number, or

one of the external inputs from which to record. (You cannot select DV input.)

 [Date] Choose a date up to

 [Start Time] Set the start time.

 [End Time] Set the end time.

 [Repeat] Choose a desired repeat (Once,

Daily (Monday - Friday), or Weekly).

 [VPS/PDC] The VPS/PDC system automatically

adjusts the recording time so that even if a program is not running to schedule, you won’t miss it. For VPS/PDC to work properly, you must input the correct announced time and date of the program you want to record. Note that VPS/PDC may not work with every station.

Notes:

 Stations that use VPS/PDC typically include

VPS/PDC information in the teletext TV guide pages. Please refer to these pages when setting a timer recording.

 When using VPS/PDC, there may be

instances where the beginning of the program is not recorded.

2. Enter the necessary information for your timer recording(s).

 b / B (left/right) – move the cursor left/right  v / V (up/down) – change the setting at the

current cursor position

 Press RETURN (O) to exit the Timer Record

menu.

 Press ENTER after filling in all the program

information.

 Press TIMER REC to display Timer Record List.

1 month

in advance.

3. Set a recording mode as necessary by pressing REC MODE repeatedly. (XP, SP, LP, EP)

4. Press ENTER, the program will be memorized by the recorder. To check the programming, the Timer Record List will appear. Check field’s “Rec. OK” on the Timer Record List indicates that the timer recording is programmed correctly.

5. Press RETURN (O) to exit the Timer Record List.

6. Make sure that you load a recordable disc for DVD recording and press STANDBY/ON to switch your unit to Standby.

Notes:

 Timer recordings cannot be made if the recorder is

turned on.

 Even if the timer is set and if the recorder is turned

on, the caution message appears on the TV screen before 10, 5, and 1 mimutes from starting time.

 The timer indicator lights in the display window

when the recorder is in standby with the timer active. (Nothing is displayed while the [Power Save Mode] is ON.)

 For TV recording with bilingual, set audio channel

from the [TV Rec Audio] in sub-menu of the Setup menu (see page 19).

 If you set a timer recording to record to DVD but

there isn’t a recordable DVD loaded at the time of the recording, the Recovery Recording feature will automatically record the program to the HDD for you.

 You cannot change the operation mode to DVD

from HDD (to HDD from DVD) in timer recording.

 You cannot use the Timeshift function in timer

recording.

 TV channels cannot be changed in timer recording.  You can stop a timer recording in progress.

Press STOP and the confirm message will appear. Press ENTER to stop the recording or press RETURN (O) to continue the recording.

 When the end time of one recording and start time

of another are the same, the other recording’s start portion will be cut off. So, set the end time of the previous program to a few minutes early.

Recording

Timer Recording with

HOW

VIEW

This system makes programming timer recordings very simple. Most TV guides publish SHOWVIEW programming numbers with their program details.If you want to make a timer recording of a program, you just input the corresponding SHOWV number. The date, start, stop and channel settings are made automatically. All you have to do is tell the recorder the recording mode, and whether it’s a onceonly recording, or a regular recording. Up to 16 timer programs can be stored in the recorder.

HOWVIEW is a registered trademarks of Gemstar

S Development Corporation.

HOWVIEW System is manufactured under license

The S from Gemstar Development Corporation.

1. Press S The SHOW Press S

 [Number] Enter the SHOWVIEW programming

number.

2. Use the number buttons then press ENTER to enter the S To check the programming, the Timer Record menu will appear.

 If you make a mistake before pressing ENTER,

press CLEAR repeatedly to delete number one by one then correct it.

System

IEW programming

HOWVIEW button.

VIEW menu will appear.

HOWVIEW button again to exit the menu.

HOW

VIEW programming number.

3. You can change the information as required using

b / B / v / V (Media, VPS/PDC, etc.) Refer to “Timer Recording” on previous page.

4. Choose a record mode (XP, SP, LP, or EP).

5. Press ENTER, the program will be memorized by the recorder. To check the programming, the Timer Record List will appear. Check field’s “Rec. OK” on the Timer Record List indicates that the timer recording is programmed correctly.

6. Press RETURN (O) to exit the Timer Record menu.

7. Make sure that you load a recordable disc for DVD recording and press STANDBY/ON to switch your unit to Standby.

Notes:

 Timer recordings cannot be made if the recorder is

turned on.

 Even if the timer is set and if the recorder is turned

on, the caution message appears on the TV screen before 10, 5, and 1 mimutes from starting time.

 You cannot change the operation mode to DVD

from HDD (to HDD from DVD) in timer recording.

 You cannot use the Timeshift function in timer

recording.

 TV channels cannot be changed in timer recording.  You can stop a timer recording in progress.

Press STOP and the confirm message will appear. Press ENTER to stop the recording or press RETURN (O) to continue the recording.

 When the end time of one recording and start time

of another are the same, the other recording’s start portion will be cut off. So, set the end time of the first program to a few minutes early.

Checking Timer Recording Details

Programming can be checked whenever the recorder is turned on. Press TIMER REC twice.

 Use v / V to select a timer recording.  Press ENTER to edit the selected program.

Timer Record menu appears.

 Press CLEAR to delete the selected program

from the Timer Record List.

Canceling a Timer Recording

You can clear a timer setting anytime before the recording actually starts.



Use v / V to select a program you want to erase on the Timer Recorder List. If you want to erase the program, press CLEAR.

Stopping a Timer Recording in Progress

After a timer recording has started, you can still cancel the program.



Press STOP and the confirm message will appear. Press ENTER to stop the recording or press RETURN (O) to continue the recording.

Timer Recording Troubleshooting

Even though the timer is set, the recorder will not record when:

 There is no disc loaded and there is not free space

on the HDD.

 A non-recordable disc is loaded and there is not

free space on the HDD.

 [Disc Protect] option is set to [ON] in the Setup

menu and there is not free space on the HDD. (see page 21).

 Power is turned on.  There are already 99 titles (DVD-RW, DVD-R), 49

titles (DVD+R, DVD+RW) recorded on the disc and there are already 255 titles recorded on the HDD.

You cannot enter a timer program when:

 A recording is already underway.  The time you’re trying to set has already passed.  There are already 16 timer programs set.

If two or more timer programs overlap:

 The earlier program takes priority.  When the earlier program finishes, the later

program starts.

 If two programs are set to start at exactly the same

time, the program entered first takes priority.

If the disc is damaged, the recording may not complete successfully. In this case even though the Check field shows “Rec. OK”, it may not be.

Recording from an External Input

Recording from External Components

You can record from an external component, such as a camcorder or VCR, connected to any of the recorder’s external inputs.

1. Make sure that the component you want to record from is connected properly to the recorder. See page 13-14.

2. Choose a media (TV HDD or TV DVD) to record using HOME menu. (see page 15).

3. Press AV INPUT repeatedly to select the external input to record from.

 Tuner: Built-in tuner  AV1: EURO AV1 AUDIO VIDEO mounted on

back panel

 AV2: EURO A/V2 DECODER mounted on back

panel

 AV3: AV IN 3 mounted on back panel  AV4: AV IN 4 (VIDEO, AUDIO (L/R), S-VIDEO

IN) mounted on front panel

 DV: DV IN mounted on front panel

4. Select the recording mode as necessary by pressing REC MODE repeatedly. (XP, SP, LP, or EP)

5. Press REC (z) once. Recording will start. (The REC indicator lights in the display window.)

 Recording continues until you press STOP (x)

or the disc is full.

 To record for a fixed length of time, see “Instant

Timer Recording” on page 36.

6. Press STOP (x) to stop recording.

Note:

If your source is copy-protected using CopyGuard, you will not be able to record it using this recorder. See Copyright on page 50 for more details.

Recording

Recording from DV Input

Before DV dubbing

You can connect a DV-equipped camcorder to this recorder using a single DV cable for input and output of audio, video, data and control signals.

 This recorder is only compatible with DV-format

(DVC-SD, DV25) camcorders. Digital satellite tuners and Digital VHS video recorders are not compatible.

 You cannot connect more than one DV camcorder

at a time to this recorder.

 You cannot control this recorder from external

equipment connected via the DV IN jack (including two recorders).

 It may not always be possible to control the

connected camcorder via the DV IN jack.

 Digital camcorders can usually record audio as

stereo 16-bit/48kHz, or twin stereo tracks of 12bit/32kHz. This recorder can only record one stereo audio track. Set [DV Rec Audio] option to [Audio 1] (original audio) or [Audio 2] (overdubbed audio). as required (see page 19).

 Audio input to the DV IN jack should be 32 or

48kHz (not 44.1kHz).

 Picture disturbance on the recording may occur if

the source component pauses playback or plays an unrecorded section of tape, or if the power fails in the source component, or the DV cable becomes disconnected.

Recording from a Digital Camcorder

You can record from a digital camcorder connected to the DV IN jack on the front panel of this recorder. Using the recorder’s remote, you can control both the camcorder and this recorder. Before recording, make sure that the audio input for the DV IN jack is set up (see page 19).

4. Find the place on the camcorder tape that you want to the recording to start from. For best results, pause playback at the point from which you want to record.

 Depending on your camcorder, you can use this

recorder’s remote to control the camcorder using the STOP, PLAY and PAUSE functions.

5. Press REC (z) once to start recording.

 Recording is automatically stopped if the

recorder detects no signal.

 You can pause or stop the recording by

pressing PAUSE (X) or STOP (x). You cannot control the camcorder from this remote control during recording.

 In Video mode, the final frame of the recording

may remain displayed on screen for a while after recording stops.

Troubleshooting

If you cannot get a picture and/or audio through the DV IN jack, check the bullet points:

 Make sure the DV cable is properly connected.  Try switching off the connected equipment then

switch back on.

 Try switching the audio input.

Note:

Depending on the connected camcorder, you may not be able to control it using the remote control supplied with this recorder.

General Explanation of On-Screen Display when DV input is selected

Tips:

 The source signal must be DVC-SD format.  Some camcorders cannot be controlled using this

recorder’s remote.

 If you connect a second recorder using a DV cable,

you cannot control the second DVD from this one.

 You cannot control this unit remotely from a

component connected to the DV IN jack.

 You cannot record date and time information from a

DV cassette.

1. Make sure your digital camcorder is connected to the front panel DV IN jack. See page 14.

2. Select [TV HDD] or [TV DVD] option on the HOME menu then press ENTER. (see page 15).

3. Press AV INPUT repeatedly to select the DV input. DV appears in the display window and on the TV screen.

1. Indicates a camera is connected to the recorder.

2. Indicates a camera’s operation mode. The operations as shown below are available when the camera is playing back. [N] the camcorder is in normal playback. [m] the camcorder is in backward scan mode. [M] the camcorder is in forward scan mode. [X] the playback is paused. [x] the playback is stopped.

3. Indicates recorder’s operation mode. [z] when the recordable disc is inserted. [a] when the non-recordable disc is inserted. [X][x] Pause or Stop operation is available on the

recorder

4. Indicates the DV input mode and the selected media to dub. (HDD, DVD-RW, etc)

Simultaneous recording and playback

Playback another title during recording

Playback and recording for both DVD and built in hard disk drive (HDD) are completely independent. For example, you can record to either the DVD or HDD source and play back video from the other source at the same time.

1. Start recording.

2. Press HOME to display the Home Menu screen.

3. Use the v / V / b / B and ENTER buttons to

select a different media type that you want to play back.

4. Start Playback. The recording will continue while playing back the media from the other mode.

Notes:

 You can’t use simultaneous playback and

recording while copying.

 You cannot edit programs during simultaneous

recording and playback.

Time Slip

You can play back the current title in recording simultaneously.

1. Start HDD recording.

2. Press PLAY (N). The playback starts and the recording will continue while playing back.

 You can use PAUSE (X) and m / M buttons

for pause, scan, slow-motion during playback.

3. Press STOP (x). The playback will stop then returns to the current recording position.

Notes:

 Playback cannot be started until 15 seconds

after recording starts.

 This function does not work in DVD recording

mode.

HDD

Recording

Editing

Title List and Chapter List Menu Overview

Using the Title List menu you can edit video content. The editing features available in the Title List menu depend on whether you are editing video on DVD, or the HDD, and whether you’re editing Original content, or a Playlist.

There are two ways to edit VR mode DVD-RW discs. You can directly edit the Original content of the disc, or you can create and edit a Playlist. The Playlist doesn’t actually change any of the content on the disc, but just controls how the content is played back.

Editing material recorded on the HDD is similar to editing the Original content of a VR mode DVD-RW, with similar commands for erasing and naming titles, as well as fine control over the content of chapters within titles for DVD disc.

Note:

During recording, if you display the Title List menu for the HDD, some of the titles may appear with a mark. These titles were recorded with a Line Input setting different to the current setting of the recorder. During recording, these titles cannot be played.

1. Press MENU/LIST to display the Title List menu. Playback should be stopped when you do this.

 You can also access it using HOME menu,

select [MOVIE] option then select [HDD] or [DVD] option and press ENTER.

 When selecting titles, use the v / V buttons to

display the previous/next page if there are more than six titles.

 If you are editing a VR mode disc, press

MENU/LIST to switch between Original and Playlist menu.

On the left side of the screen are the menu options. The main part of the screen shows thumbnails of the titles (or chapter) on the DVD or HDD. You can change these thumbnails using the THUMBNAIL button—see Changing Title Thumbnails on page 43.

Press DISPLAY to display the information of selected title on the Title List menu.

After selecting a title or chapter on the Title List or Chapter List menu, then press ENTER. The menu options appears on the left side of the menu. Use v / V to select a option then press ENTER to confirm your selection.

2. To exit the Title List menu, press RETURN (O) repeatedly.

123 4 5 6 7

1. Menu options: To display menu option, select a title or chapter then press ENTER. The options displayed differ depending on the disc type.

 [Combine] Combines two titles or chapters into one

(page 47, 48).

 [Delete] Deletes the title or chapter. (page 45)  [Delete Part] Deletes a part of the Title (page 45).  [Divide] Divides a title into two (page 48).  [Dubbing] Copies the title to another media. (page 51)  [Full Play] Starts playback of the selected title

including the hidden chapters.

 [Hide (Show)] Hides (or Shows) the selected title or

chapter. (page 49)

 [Move] Moves a chapter on the Chapter List-Playlist

menu to a position on the menu. (page 49)

 [Play] Start playback of the selected title or chapter.

The hidden titles and chapters on the DVD+R/RW cannot be play back.

 [Playlist Add] Adds the title or chapter to the Playlist.

(page 44)

 [Protect] Protects accidental recording, editing or

deleting of the title. (page 49)

 [Rename (Title Name)] Edits the title name. (page 46)  [Search]

- [Chapter]; Displays Chapter List of the Title.

- [Time]; Search time for you want start point of the title. (page 46)

 [Sort] Lists the programs on the Title List menu by

Date, Title, or Category. (page 47)

 [Title] Displays Title List of the chapter.

 [Undo]/[Redo] Un-do/Re-do the last deletion/ action.

(page 47)

2. Indicates the record mode, free space, and elapsed time progress bar.

3. Current media

4. Currently selected title.

5. Thumbnail

6. Shows the selected title number and total number of titles.

7. Shows the title name, recorded date, and recording length.

HDD, VR Mode: Original and Playlist Editing

Adding Chapter Markers

Titles, Chapters and Parts

Titles in the disc’s original content contain one or more chapters. When you insert a disc’s title into the Playlist, all the chapters within that title also appear. In other words, chapters in the Playlist behave exactly as chapters on a DVD-Video disc do. Parts are sections of Original or Playlist titles. From the Original and Playlist menu you can add or delete parts. Adding a chapter or title to the Playlist creates a new title made up of a section (ie., chapter) of an Original title. Deleting a part removes part of a title from the Original or Playlist menu.

Caution

 When editing using the Delete, Add and Move

functions, the start and end frames may not be exactly as set in the start and end point display.

 During Playlist playback, you may notice a

momentary pause between edits. This is not a malfunction.

Is editing a DVD like editing a video tape?

No. When you edit a video tape you need one video deck to play the original tape and another to record the edits. With DVD, you edit by making a ‘Playlist’ of what to play and when to play it. On playback, the Recorder plays the disc according to the Playlist.

About word ‘Original’ and ‘Playlist’

Throughout this manual, you will often see the words Original and Playlist to refer to the actual content and the edited version.

 Original: content refers to what’s actually recorded

on the disc.

 Playlist: content refers to the edited version of the

disc — how the Original content is to be played.

-RW

HDD

You can create chapters within a title by inserting chapter marks at the desired points.

Note:

Chapter markers are inserted at regular intervals automatically. You can change this interval from the Initial Setup menu (see “Auto Chapter” on page 19).

During recording or playing back, at the point you want to start a new chapter, press CHP ADD. A chapter marker icon appears on the TV screen.

+R+RW-RW

Changing Title Thumbnails

-RW

HDD

Each title displayed in the Title List menu is represented by a thumbnail picture taken from the start of that title or chapter. If you prefer, select a different still picture from within a title. Press THUMBNAIL to make the currently displayed picture the one that appears in the Title List menu. The still picture that you choose appears in both the Original or Playlist menu.

Tip

You can also change the thumbnail picture of the title on the Chapter List menu. Select a chapter on the Chapter List menu then press THUMBNAIL. The thumbnail picture of the title that includes the chapter is changed.

+R+RW-RW

Editing

Making a New Playlist

-RW

Use this function to add an Original title or chapter to the Playlist. When you do this, the whole title is put into the Playlist (you can delete bits you don’t need later — see Deleting an Original or Playlist title/chapter on page 45).

The title appears in the Playlist complete with the chapter markers that appear in the Original. However, if you add more chapter markers to the Original later, these are not automatically copied over into the Playlist title.

You can add up to 999 chapters to one disc . If you only want to add a chapter of a title, use the Adding a title/chapter to the Playlist on this page.

1. Choose a title or chapter on the Title List-Original menu or Chapter List-Original menu to put into the Playlist, then press ENTER. The menu options appears on the left side of the menu.

Adding Additional Title/Chapters

to the Playlist

You can add an Original title or chapter to add to a Playlist title even if it is already registered.

1. Choose a title or chapter on the Title List-Original menu or Chapter List-Original menu to put into the Playlist, then press ENTER. The menu options appears on the left side of the screen.

2. Use v / V to select [Playlist Add] from menu options then press ENTER.

-RW

2. Use v / V to select [Playlist Add] option then press

ENTER.

3. Select [New Playlist] then press ENTER. The new title appears in the updated Playlist. All chapters of the title are added to the Playlist.

3. Choose a Title List-Playlist that is already registered to insert a title or chapter, then press ENTER.

4. Repeat steps 1-3 to add additional title or chapter on the Playlist. You can view the added chapters on the Chapter List-Playlist menu.

5. Press RETURN (O) to exit, or MENU/LIST to go back to the Title List-Original menu.

Deleting an Original or Playlist Title/Chapter

When you erase a title or chapter from the Playlist menu, you only remove it from the Playlist; the title/chapter remains in the Original menu.

If you choose to delete a title or chapter from the Original (title/chapter) menu, the title or chapter is actually deleted from the disc and the remaining time available for recording increases. Titles/chapters deleted from the Original are also removed from the Playlist.

Note:

It may not be possible to delete chapters that are less than 5 seconds long.

1. Use b / B / v / V to choose a chapter or title you

want to delete on the Title List or Chapter List menu then press ENTER. The menu options appears on the left side of the screen.

2. Select [Delete] option from the options on the menu.

Example: Title List (HDD)

3. Press ENTER to confirm. The confirm message for deleting will appear.

4. Use b / B to select [Yes] then press ENTER. The selected chapter or title is deleted. After pressing ENTER, the new, updated menu is displayed.

5. Repeat steps 1 - 4 to continue to delete from the menu.

6. Press RETURN (O) repeatedly to exit the menu.

Notes:

 When DVD+RW recording, the deleted title’s name

is changed to ‘Deleted Title’.

 If more than two titles are repeatedly deleted, the

titles are combined into one.

 When you are deleting a title or chapter, only the

last one on DVD+RW increases remaining recording time.

Deleting a Part

You can delete a part which you do not want in the title.

1. Use b / B / v / V to choose a title you want to

delete on the Title List menu then press ENTER. The options appears on the left side of the menu.

2. Select [Delete Part] option then press ENTER. Edit (Delete Part) menu appears on the TV screen. [Start Point] icon is highlighted.

Example: Edit (Delete Part) (HDD)

3. Starts playback and use pause step, search and slow-motion to find the starting point.

4. Press ENTER at the starting point of the section you want to delete. ‘End Point’ icon is highlighted. The part is indicated on the Progress Bar.

5. Use pause step, search and slow-motion to find the ending point.

6. Press ENTER at the ending point of the section you want to delete. You can cancel the selected point, use v / V to select [Cancel] icon then press ENTER.

Tip:

With HDD recordings, you can delete additional part. Select [Next Part] icon on the menu then press ENTER, then repeat steps 3-6.

7. If you finish to edit, select [Done] icon then press ENTER. The confirm message for deleting will appear. Use b / B to select [Yes] then press ENTER. The selected part is deleted from the title and Title List menu appears.

Note:

This function may not work correctly if the selected part is less than 3 seconds. So you must select a part that is more than 3 seconds.

HDD

-RW

Editing

Naming a Title

You can name Original and Playlist titles independently. Names can be up to 32 characters long.

1. Choose the title you want to name on the Title List menu, then press ENTER. The menu options appears on the left side of the menu.

2. Use v/V to select [Rename (Title Name)] option then press ENTER. Keyboard menu appears.

3. Enter a name for the title. Use b / B / v / V to select a character then press ENTER to confirm your selection.

 Use MENU/LIST button to change keyboard

type.



OK: Select to finish.



Cancel: Cancels all entered characters.



Space: Inserts a space at the cursor position.



Delete: Deletes the previous character at the cursor position.



b / B: Moves cursor to left or right.

Tip:

Remote control buttons for entering a name PLAY (N): Inserts a space at the cursor position.

PAUSE (X): Deletes the after character at the

cursor position.

STOP (x), CLEAR: Deletes the previous

character at the cursor position.

. / >: Moves cursor to left or right. Numbers (0-9): Enters the corresponding

character at the cursor position.

Tip:

You can add the genre only for HDD title name.

4. Choose OK then press ENTER to fix the name and return to the previous menu screen.

5. Press RETURN (O) repeatedly to exit the menu.

Notes:

 Names can be up to 32 characters long.  For discs formatted on a different recorder, you will

see only a limited character set.

 When recording on DVD-R, DVD+R or DVD+RW

discs, the entered name is displayed on the DVD player only after finalization.

Time Search

HDD

-RW

Video

+R-R+RW

You can select start point of the title.

1. Use b / B / v / V to choose a title on the Title List

menu then press ENTER. The options appears on the left side of the menu.

2. Select [Time] option then press ENTER.

[Search] menu appears on the TV screen.

Example: Title List (HDD)

Current picture

End time

Start time

Selected time

Selected point

3. Use b / B to find the point you want to start.

The point increase 1 minute step. If you press and hold b / B then the point increase

5 minute step.

4. Press ENTER to start selected point.

Sort

HDD

Combining Two Titles Into One

This function allows you to access show listings organized by Date, Title, or Category on the Title ListHDD menu. So you can find title you want to watch easily.

1. Choose any title on the Title List-HDD menu, then press ENTER. The menu options appears on the left side of the menu.

2. Use v/V to select [Sort] option then press ENTER. Sort options appears.

3. Use v/V to select [Date], [Title] or [Category] option then press ENTER. After pressing ENTER, the sorted menu is displayed.

HDD

Use this function to combine two adjacent OriginalHDD titles into one.

Notes:

 This function is not available if there is only one

titles within the HDD.

 If there are more than 60 titles on the HDD, you

cannot combine the titles.

1. On the Title List-HDD menu, select the first title of the two titles you want to combine then press ENTER. The menu options appears on the left side of the screen.

2. Select [Combine] option then press ENTER.

Undoing/Redoing the Last

Deletion

If you make a mistake while deleting, you can undo it. There is one level of undo (in other words, you can undo the last one deletion you made).

Use v / V to select [Undo] option then press ENTER. It doesn’t matter whether you are currently in the menu screen; the last deletion is undone.

Notes:

 You can’t undo a recording.



You can’t undo anything after ejecting the disc from the recorder or switching the recorder into standby mode.

 You can still undo a deletion even after exiting the

menu display.

Tip:

You can redo the last undo action using the [Redo] option.

-RW

3. Select the second title of the two titles you want to combine then press ENTER. Confirm message appears.

4. Use b / B to select [Yes] then press ENTER. After pressing ENTER, the updated menu is displayed.

Editing

Divide One Titles Into Two

Use this command to split a title up into two new titles.

1. On the Title List menu, select a title you want to divide then press ENTER. The menu options appears on the left side of the screen.

2. Select [Divide] option.

Example: Title List (HDD)

3. Press ENTER. Edit (Divide) menu appears. [Divide] option is highlighted.

Current picture

Combining Two Chapters Into One

Use this function to combine two adjacent Playlist or Original chapters into one.

Note:

This function is not available if there is only one chapter within the title.

1. On the Chapter List menu, select the second

2. Use v / V to select [Combine] option.

3. Press ENTER.

HDD+RWHDD

chapter of the two chapters you want to combine then press ENTER The menu options appears on the left side of the screen.

The combine indicator appears between the two chapters you want to combine.

+R+RW-RW

The first title’s thumbnail

The second title’s thumbnail

4. Use play, pause step, search and slow-motion to find the point you want to divide the title.

5. Select [Divide] option then press ENTER at the point. To reset the point, select [Cancel] option then press ENTER. Repeat from step 3.

6. Choose [Done] option then press ENTER to fix the dividing point. The title is divided into two new titles. It take up to 4 minutes to divide.

Note:

You cannot select dividing point less than 3 seconds.

Moving a Playlist Chapter

Use this function to re-arrange the playing order of Playlist chapters on the Title List-Playlist menu.

Note:

This function is not available if there is only one chapter.

1. Select a chapter on the Chapter List-Playlist menu.

2. Press ENTER. The menu options appears on the left side of the menu.

3. Use v / V to select [Move] option from Playlist options then press ENTER.

4. Use b / B / v / V to choose the place you want to move the chapter to then press ENTER. After pressing ENTER, the updated menu is displayed.

Hide a Chapter/Title

You can skip playing chapters or titles without deleting from the disc.

1. Use vVbBto choose a chapter or title you want to hide on the Title List or Chapter List menu, then press ENTER. Options appear on the left side of the screen.

2. Select [Hide] option.

Example: Title List (DVD+RW)

-RW

+R+RW

Tip

If you select a hidden chapter or title on the Title List or Chapter List menu, you can ‘show’ it by choosing [Show] option on the menu. After doing that, you are able to see the chapter or title.

Protect a Title

-RW

+R+RW

Use this function to protect against accidental recording, editing or deleting of the title.

1. Press MENU/LIST to display the Title List menu.

2. Use vVbBto choose a title you want to protect

then press ENTER. Options appear on the left side of the screen.

3. Select [Protect] from the options.

4. Press ENTER to confirm. The lock mark will appears on the title’s thumbnail.

Tip

If you select a title that has already been protected on the Title List menu, you can ‘unprotect’ it by choosing [Protect] option from the Title List menu options. After doing that, you can edit and delete the title.

Editing

3. Press ENTER to confirm. The chapter’s or title’s thumbnail will dim.

Dubbing

Before Dubbing

Use the copying features of this recorder to:

 Back up important recordings stored on the HDD to

a DVD.

 Make a DVD copy of a recording on the HDD to

play in another player.

 Transfer video from a DVD to the HDD for editing.  Transfer edited video from the HDD to DVD.

The simplest method of copying is to use the One Touch Copy feature. Using this you can very simply copy the title that’s currently playing from HDD to DVD, or the other way around.

Note:

If the title’s length is less than 5 seconds, the dubbing is not available. (from HDD to DVD)

Restrictions on copying

Some video material is copy-once protected: Such material cannot be copied to HDD or DVD.

You can identify copy-once protected material during playback by displaying disc information on-screen.

 NTSC format signals from the analog or the DV

inputs is not recorded correctly with this recorder.

 Video signals in SECAM format (from the built-in TV

tuner or from the analog inputs) are recorded in PAL format.

What is ‘CPRM’?

CPRM is a copy protection system (with scramble system) only allowing the recording of ‘copy once’ broadcast programs. CPRM stands for Content Protection for Recordable Media. CPRM recordings can only be made on DVD-RW discs formatted in VR mode or discs, and CPRM recordings can only be played on players that are specifically compatible with CPRM.

 Recording equipment should be used only for lawful

copying and you are advised to check carefully what is lawful copying in the area in which you are making a copy. Copying of copyright material such as films or music is unlawful unless permitted by a legal exception or consented to by the rights owner.

 This product incorporates copyright protection

technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only, unless otherwise

authorized by Macrovision corporation. Reverse engineering or disassembly is prohibited.

 CONSUMERS SHOULD NOTE THAT NOT ALL

HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 625 PROGRESSIVE SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 625p HDD/DVD RECORDER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.

Fast copying (Maximum 12x)

Copying between DVD and HDD is a completely digital process and therefore involves no loss of quality in the audio or video. This means that you can transfer back and forth without having to worry about the quality getting worse with each copy ‘generation’. It also means that copying can be carried out at the maximum speed possible. When copying from HDD to DVD, the speed of copying depends on the recording mode and the kind of DVD disc you’re using.

Minimum fast copying times

The table below shows the minimum HDD to DVD copying time for 2 hours of video recorded with SP mode.

Disc Disc Copying Time Type Speed (Record Speed)

DVD-R / DVD+R 16x 6.5 min. (12x)

DVD-R / DVD+R / DVD+RW 8x 8 min. (8x)

DVD-RW 6x 12 min. (6x)

DVD-R / DVD+R 4x 13 min. (4x) DVD-RW / DVD+RW

DVD+R / DVD+RW 2.4x 21 min. (2.4x)

DVD-R / DVD-RW 2x 25 min. (2x)

Notes:

 All times in the above table are approximate.  Actual copy speed varies with the part of the disc

being recorded.

 There may be cases where even 4x/6x/8x/16x

compatible discs do not copy at full speed.

 Fast copying may not be possible when using disc

initialized on another recorder.

Dubbing from HDD to DVD

Dubbing from DVD to HDD

1. On the Title List-HDD menu, select a title you want to dub then press ENTER. The menu options appears on the left side of the screen.

2. Use v / V to select [Dubbing] option then press ENTER. Dubbing menu appears.

3. Use b / B to select record mode (XP, SP, LP, EP, AUTO, or Fast), then press V. ‘Start’ icon is highlighted. AUTO: This mode determines how much DVD disc time is available and the record mode is set to appropriate mode, to complete dubbing the title. Fast: See page 50 for more information on Fast copying.

4. When [Start] icon is highlighted, press ENTER. Dubbing starts.

5. To stop dubbing at any other time, press STOP (x).

Notes:

 The recording time of [Fast] mode could be varied

depending on data size of source.

 Stopping dubbing in [Fast] mode partway through

will cancel the recording and any data recorded up to that point will be lost.

 If the remaining space on the disc is insufficient, the

[Fast] mode is not available.

 The [Fast] mode is not available for edited HDD title

and Clip Recording title.

 If the free space of the DVD disc is not sufficient for

the selected record mode, you cannot dub the whole title.

1. On the Title List menu, select a title you want to dub then press ENTER. Menu options appears on the left side of the screen.

2. Use v / V to select [Dubbing] option then press ENTER. Dubbing menu appears.

3. Use b / B to select record mode (XP, SP, LP, EP, AUTO, or Fast), then press V. ‘Start’ icon is highlighted. AUTO: This mode determines how much HDD time is available and the record mode is set to appropriate mode, to complete dubbing the title. Fast: Only available when copying VR mode disc to HDD. (See page 50 for more information on Fast copying.)

4. When [Start] icon is highlighted, press ENTER. Dubbing starts.

5. To stop dubbing at any other time, press STOP (x).

Notes:

 Depending on the conditions of the recording

equipment or the disc itself, the dubbing may not be capable.

 Stopping dubbing in [Fast] mode partway through

will cancel the recording and any data recorded up to that point will be lost.

 The recording time of [Fast] mode can take up to 19

minutes.

 The [Fast] mode is not available for edited title on

the DVD-RW with VR recording mode.

Dubbing

One Touch Copy (HDD to DVD)

The One Touch Copy feature copies the currently playing title from the HDD to DVD. The whole title is copied, regardless of where in the title you start copying. The recorder copies at the maximum speed possible.

For One Touch Copy to work, make sure that a recordable DVD disc is loaded.

During HDD playback, press DUBBING to copy the current title to DVD.

The on-screen display indicates that the title is being copied. Playback continues while copying.

 You cannot use the One Touch Copy function to

copy a title if any part of the title is copy-once protected.

One Touch Copy (DVD to HDD)

One Touch Copy from DVD to HDD copies a single title to the HDD in real time. When you start copying, playback jumps back to the start of the title, then continues through to the end of the title, when recording automatically stops. The copy will be made in the recording mode (XP, SP, LP, EP) that is currently set.

During DVD playback, press DUBBING to copy the current title to HDD.

Playback starts again from the beginning of the current title. The on-screen display indicates that the title is being copied.

Notes:

 Video CD cannot be copied to HDD.

 The copying stops when then recorder detects a

badly scratched or copy protected part.

 If some part of the title being copied is copy-

protected, copying will start, but the copy-protected portions will not be copied.

 During Playlist title’s playback, One Touch Copy is

not available.

Tip:

To stop dubbing at any other time, press STOP (x).

Reference

Additional Information

Overwriting Recording

To overwrite a new video recording on a previously recorded title, follow these steps. This feature is not available for DVD+Rs, that always record at the end of the Disc.

1. Select input source you want to record (TV channel, AV1-4, DV).

2. Press MENU/LIST to display the Title List menu.

3. Use vVbBto choose a title you want to overwrite.

4. Press REC (z) to start overwrite recording. Overwrite recording starts from the start point of the title.

5. Press STOP (x) to stop the overwrite recording. The new title is created and updated menu is displayed.

Notes:

 This function is not available for a protected title.  If the overwrite is longer than the recording

length of the current title, the next title is overwritten. But if next title is protected, the overwriting stops at the starting point of the title.

 If the selected title’s recording length is less than 10

seconds, the next title is overwritten. But if the next title is protected, overwriting stops.

Viewing Title List menu displayed on other DVD Recorders or Players

+R+RW

You can view the Title List menu displayed on the other DVD player that is capable of playing DVD+RW or DVD+R discs.

1. Insert DVD+R or DVD+RW disc recorded already.

+RW

2. Press TITLE in play or stop mode. Title List menu will appear as shown below.

Tip

You can remove the Title List menu by pressing STOP (x).

3. To play back a title, select the title you want then press ENTER or PLAY (N).

Playing Your Recordings on Other DVD Players (Finalizing a Disc)

Most regular DVD players can play finalized discs recorded in Video mode, finalized DVD+R or DVD+RWs. A small number of players can also play DVD-RW discs recorded in VR mode, finalized or not. Check the manual that came with the other player to check what formats of discs it will play.

Finalizing ‘fixes’ the recordings and editings in place so that the disc can be played on a regular DVD player or computer equipped with a suitable DVDROM drive. Finalizing a Video mode disc creates a menu screen for navigating the disc. The menu can be accessed by pressing MENU/LIST or TITLE. To finalize a disc, refer to “Finalize” on page 20.

Notes:

 When using a DVD+R/RW, the recorder will execute

the Menu-making operation to update the new title and editing when removing the disc from the recorder or turn off the recorder. So you must remove the disc after selecting the recorder’s operation mode to DVD mode.

 Unfinalized DVD+RW is playable on regular DVD

players.

 The edited contents of a DVD+RW disc is

compatible on regular DVD players only after finalization.

 Any edited contents of the DVD+R disc are not

compatible on regular DVD players. (Hide, chapter combine, added chapter mark, etc.)



How long finalization takes depends on the type of disc, how much is recorded on the disc, and the number of titles on the disc.

Dubbing

Language Codes

Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu.

Language Code

Abkhazian 6566 Afar 6565 Afrikaans 6570 Albanian 8381 Ameharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Aymara 6588 Azerbaijani 6590 Bashkir 6665 Basque 6985 Bengali; Bangla 6678 Bhutani 6890 Bihari 6672 Breton 6682 Bulgarian 6671 Burmese 7789 Byelorussian 6669 Cambodian 7577 Catalan 6765 Chinese 9072 Corsican 6779 Croatian 7282 Czech 6783 Danish 6865 Dutch 7876 English 6978 Esperanto 6979 Estonian 6984 Faroese 7079

Language Code

Fiji 7074 Finnish 7073 French 7082 Frisian 7089 Galician 7176 Georgian 7565 German 6869 Greek 6976 Greenlandic 7576 Guarani 7178 Gujarati 7185 Hausa 7265 Hebrew 7387 Hindi 7273 Hungarian 7285 Icelandic 7383 Indonesian 7378 Interlingua 7365 Irish 7165 Italian 7384 Japanese 7465 Javanese 7487 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kirghiz 7589 Korean 7579 Kurdish 7585 Laothian 7679 Latin 7665 Latvian, Lettish 7686

Language Code

Lingala 7678 Lithuanian 7684 Macedonian 7775 Malagasy 7771 Malay 7783 Malayalam 7776 Maltese 7784 Maori 7773 Marathi 7782 Moldavian 7779 Mongolian 7778 Nauru 7865 Nepali 7869 Norwegian 7879 Oriya 7982 Panjabi 8065 Pashto, Pushto 8083 Persian 7065 Polish 8076 Portuguese 8084 Quechua 8185 Rhaeto-Romance 8277 Rumanian 8279 Russian 8285 Samoan 8377 Sanskrit 8365 Scots Gaelic 7168 Serbian 8382 Serbo-Croatian 8372 Shona 8378 Sindhi 8368

Language Code

Singhalese 8373 Slovak 8375 Slovenian 8376 Somali 8379 Spanish 6983 Sudanese 8385 Swahili 8387 Swedish 8386 Tagalog 8476 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 Tonga 8479 Turkish 8482 Turkmen 8475 Twi 8487 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapük 8679 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 7473 Yoruba 8979 Zulu 9085

Troubleshooting

Check the following guide for the possible cause of a problem before contacting service.

Symptom

No power.

No picture.

No sound.

The playback picture is poor.

The recorder does not start playback.

The picture from the external input is distorted

Some channels are skipped over when using PR (+/-).

The picture or sound of broadcasting channel is weak or missing.

Camcorder image is not shown.

Camcorder image via A/V input or DV IN to recorder is not shown on TV screen.

Cause

 The power cord is disconnected.

 TV/VIDEO mode for the recorder is

set to TV.

 The TV is not set to receive recorder

signal output.

 The video cable is not connected

securely.

 The connected TV power is turned off.

 The equipment connected with the

audio cable is not set to receive recorder signal output.

 The audio cables are not connected

securely.

 The power of the equipment connected

with the audio cable is turned off.



The audio connecting cord is damaged.

 The disc is dirty.

 No disc is inserted.

 An unplayable disc is inserted.

 The disc is placed upside down.

 The disc is not placed within the

guide.

 The disc is dirty.

 The video signal from the external

component is copy-protected.

 Those channels are not stored in the

recorder.

 Aerial or cables are loose.

 Camcorder is off.

 The recorder’s source is incorrect.

Solution

 Plug the power cord into the wall

outlet securely.

 Press TV/VIDEO on the remote

control repeatedly to choose DVD mode. TV indicator disappears in the display window.



Select the appropriate video input mode on the TV so the picture from the recorder appears on the TV screen.

 Connect the video cable securely.

 Turn on the TV.

 Select the correct input mode on the

audio receiver so you can listen to the sound from the recorder.

 Connect the audio cable securely.

 Turn on the equipment connected

with the audio cable.

 Replace it with new one.

 Clean the disc.

 Insert a disc. (Check that the disc

indicator in the display window is lit.)



Insert a playable disc. (Check the disc type, color system, and regional code.)

 Place the disc with the playback side

down.

 Place the disc on the disc tray

correctly inside the guide.

 Clean the disc.

 Yo u cannot connect via this recorder.

Connect the component directly to your TV.

 Restore channels. See “Program Edit”

on page 16.

 Tighten connections or replace cable.

 Turn camcorder on and operate

properly.

 Use AV INPUT to select input channel

(AV1, AV2, DV, etc.)

Reference

Symptom

Cannot play a disc recorded using this recorder on another player.

Cannot record or did not record successfully.

Timer recording is not possible.

Stereo Audio Record and/or Playback is not present.

The remote control does not work properly.

Cause



The disc was recorded in Video mode.

 Some players will not play even a

finalized disc recorded in Video mode.

 The disc was recorded in VR mode,



Discs recorded with copy-once material cannot be played on other players.

 The remaining blank space on the

disc is insufficient.

 The source you are trying to record is

copy protected.



When setting the recording channel, the channel is tuned on the TV’s own tuner.

 When recording to a Video mode disc,

programs that are copy-once protected cannot be recorded.

 Clock in recorder is not set to correct

time.

 Timer has been programmed

incorrectly.

 Timer record indicator light does not

appear after programming timer.

 TV is not Stereo-compatible.

 Broadcast program is not in stereo

format.

 The recorder A/V Out jacks are not

connected to TV A/V In jacks.

 The recorder Audio/Video Out is not

selected for viewing at the TV.

 The recorder’s TV audio channel is

set to mono.

 The remote control is not pointed at

the remote sensor of the recorder.

 The remote control is too far from the

recorder.

 There is an obstacle in the path of the

remote control and the recorder.

 The batteries in the remote control

are exhausted.

 The remote control’s code does not

match the code of other JVC device you want to operate.

Solution

 Finalize the disc. (page 20)

 No solution.

 The other player must be RW

compatible in order to play it.

 No solution.

 Use another disc.

 You cannot record the source.

 Select the channel on the recorder’s

built-in TV tuner.

 Use a VR mode formatted disc for

copy-once material.

 Set clock to correct time. See “Auto

Clock Set” or “Manual Clock Set” on page 17.

 Reprogram Timer. See “Timer

Recording” on page 37.

 Reprogram Timer.

 No solution.

 Make A/V connections. Stereo is

available only via A/V output from the recorder.

 Select AUX or A/V source as TV

input.

 Set TV audio channel mode to Stereo.

See “Changing TV audio channel” on page 36.

 Point the remote control at the remote

sensor of the recorder.

 Operate the remote control within

7 m.

 Remove the obstacle.

 Replace the batteries with new ones.

 Change the remote control code of

the device to C code.

Resetting the recorder

If you observe any of the following symptoms...



The unit is plugged in, but the power will not turn on or off.



The front panel display is not working.



The recorder is not operating normally.

...you can reset the recorder as follows:



Press and hold the STANDBY/ON button for at least five seconds. This will force the unit to power off then turn the unit back on.



Unplug the power cord, wait at least five seconds, and then plug it in again.

Specifications

General

Power requirements AC 220-240V, 50/60 Hz

Power consumption 35W

Dimensions (approx.) 430 X 54 X 275 mm (w x h x d) without foot

Mass (approx.) 4.1 kg

Operating temperature 5˚C to 35˚C

Operating humidity 5 % to 90 %

Television system PAL I, B/G, I/I, SECAM D/K, K1 color system

Recording format PAL

Recording

Recording format DVD Video Recording, DVD-VIDEO

Recordable media HDD (160GB), DVD-ReWritable, DVD-Recordable, DVD+ReWritable,

Recordable time DVD (4.7GB): Approx. 1 hour (XP mode), 2 hours (SP mode),

Video recording format

Sampling frequency 27MHz

Compression format MPEG 2 (VBR support)

Audio recording format

Sampling frequency 48kHz

Compression format Dolby Digital

Playback

Frequency response DVD (PCM 48 kHz): 8 Hz to 22 kHz, CD: 8 Hz to 20 kHz

Signal-to-noise ratio More than 100 dB (AUDIO OUT connector)

Harmonic distortion Less than 0.008% (AUDIO OUT connector)

Dynamic range More than 95 dB (AUDIO OUT connector)

DVD+Recordable

4 hours (LP mode), 6 hours (EP mode)

HDD (160GB): Approx. 42 hours (XP mode), 82 hours (SP mode),

152 hours (LP mode), 226 hours (EP mode)

DVD (PCM 96 kHz): 8 Hz to 44 kHz

Inputs

AERIAL IN Aerial input, 75 ohms

VIDEO IN 1.0 Vp-p 75 ohms, sync negative, RCA jack x 2 / SCART x 2

AUDIO IN 2.0 Vrms more than 47 kohms, RCA jack (L, R) x 2 / SCART x 2

S-VIDEO IN (Y) 1.0 V (p-p), 75 Ω, sync negative, Mini DIN 4-pin x 1

DV IN 4 pin (IEEE 1394 standard)

Outputs

VIDEO OUT 1 Vp-p 75 Ω, sync negative, RCA jack x 1 / SCART x 2

COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

Audio output (digital audio) 0.5 V (p-p), 75 Ω, RCA jack x 1

Audio output (analog audio) 2.0 Vrms (1 KHz, 0 dB), 600 Ω, RCA jack (L, R) x 1 / SCART x 2

Accessory:

Scart cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 RF Coaxial Cable . . . . . . . . . . . . . . . .1

Remote control . . . . . . . . . . . . . . . . . . . . . . . . . .1 Batteries . . . . . . . . . . . . . . . . . . . . . . .2



Design and specifications are subject to change without notice.

Reference

DR-MH220SE

Printed in Indonesia

0406MNH-LG-LG

P/NO : MFL30384212

JVC LPT1132-001A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Introduction

Recordable and Playable Discs

Playable Discs

Regional Code

Availability of copying or moving feature

About the internal hard disk drive

Front Panel

Remote Control

Hookup and Settings

Rear Panel

Connecting to the Aerial

Connections to Your TV

Connecting to an Amplifier

Using the Home Menu

Initial Settings

General Settings

Audio Settings

Lock Settings

Recording Settings

Disc Settings

General Explanation of On-Screen Display

Playback

General Playback Features

Playing a DivX Movie File

Playing an Audio CD or MP3/WMA file

Program Playback with Audio CD and MP3/WMA file

Viewing a JPEG File

Editing a MP3/WMA, JPEG, DivX file

Recording

About DVD recording

Timeshift

Basic Recording from a TV

Instant Timer Recording

Timer Recording

Checking Timer Recording Details

Recording from an External Input

Recording from DV Input

Simultaneous recording and playback

Editing

Title List and Chapter List Menu Overview

HDD, VR Mode: Original and Playlist Editing

Adding Chapter Markers

Changing Title Thumbnails

Making a New Playlist

Deleting an Original or Playlist Title/Chapter

Deleting a Part

Naming a Title

Time Search

Sort

Combining Two Titles Into One

Divide One Titles Into Two

Combining Two Chapters Into One

Moving a Playlist Chapter

Hide a Chapter/Title

Protect a Title

Dubbing

Before Dubbing

Dubbing from HDD to DVD

Dubbing from DVD to HDD

One Touch Copy (HDD to DVD)

One Touch Copy (DVD to HDD)

Reference

Additional Information

Language Codes

Troubleshooting

Specifications
