DVD PLAYER & VIDEO CASSETTE RECORDER

HR-XV28S

PAL

INSTRUCTIONS

LPT1056-001A

Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOTREMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation mark within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

WARNING: Do not install this equipment in a confined space such as a book case or similar unit.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

Notes on copyrights:

It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyright material without permission. This product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

SERIALNUMBER: The serial number is found on the back of this unit. This number is unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.

Model No.

Serial No.

CAUTION: When you are not using the unit for a long period of time, it is recommended that you disconnect the power cord from the mains outlet.

The STANDBY/ON Í/I button does not completely shut off mains power from the unit, but switches operating current on and off. “Í” shows electrical power standby and “I” shows ON.

CAUTION:

This Digital Video Disc Player employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain for future reference, should the unit require maintenance, contact an authorized service location see service procedure. Use of controls, adjustments or the performance of procedures other than those specified herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM.

CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCKS DEFEATED.

CAUTION: The apparatus shall not be exposed to water, dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

This product is manufactured to comply with the radio interference requirements of EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/ EEC.

HOWVIEW is a trademark of Gemstar Development

Corporation. The S license from Gemstar Development Corporation.

HOWVIEW system is manufactured under

Important notes on controlling this unit

This unit uses one set of controls to operate both DVD and VCR. The following buttons are helpful in successfully controlling each part.

1. Í/I Button Press the Í/I button on the remote control or front panel to turn on this unit.

2. DVD Button Press DVD button on the remote control when you want to control the DVD. The DVD indicator will light on the front panel display to show that the DVD is selected.

3. VCR Button Press the VCR button on the remote control when you want to control the VCR. The VCR indicator will light on the front panel display to show that the VCR is selected.

4. DVD/VCR Button Press the DVD/VCR button on the front panel to toggle control between the DVD and the VCR.

Introduction

Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important notes on controlling this unit . . . . . . . . . 2

Table of Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

About the symbols for instructions . . . . . . . . . . . . . 3

Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5

Playable Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Remote Control Operation Range . . . . . . . . . . . . . 4

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

About Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Selecting the Viewing Source . . . . . . . . . . . . . . . . 5

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Display Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Rear Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Preparation

Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11

Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . . 10

Connecting to Optional Equipment. . . . . . . . . . . . 11

Before Operation-VCR part . . . . . . . . . . . . . . . . .12-16

Tuning in a video channel on your TV . . . . . . . . . 12

Initial preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting the clock Manually . . . . . . . . . . . . . . . . . . 13

To set the colour system . . . . . . . . . . . . . . . . . . . 13

How to use the main menu . . . . . . . . . . . . . . . . . 14

Tuning in TV Stations Automatically . . . . . . . . . . 14

Tuning in TV Stations Manually . . . . . . . . . . . . . . 15

Changing the order of TV Stations

Deleting TV Stations . . . . . . . . . . . . . . . . . . . . . . 16

Before Operation-DVD part . . . . . . . . . . . . . . . . .17-19

General Operation . . . . . . . . . . . . . . . . . . . . . . . . 17

LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Menu Language. . . . . . . . . . . . . . . . . . . . . . . 17

• Disc Audio / Subtitle / Menu. . . . . . . . . . . . . . 17

DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• TV Aspect . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Display Mode. . . . . . . . . . . . . . . . . . . . . . . . . 17

AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• Dolby Digital / DTS / MPEG. . . . . . . . . . . . . . 18

• Sample Freq. (Frequency) . . . . . . . . . . . . . . . 18

• DRC (Dynamic Range Control) . . . . . . . . . . . 18

OTHERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• PBC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• Auto Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

LOCK (Parental Control) . . . . . . . . . . . . . . . . . . . 19

• Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• Password (Security Code) . . . . . . . . . . . . . . . 19

• Area Code . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

. . . . . . . . . . . . . . 16

Operation

Operation with tape . . . . . . . . . . . . . . . . . . . . . . .20-24

Playing a tape . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

• CM (Commercial Message) Skip. . . . . . . . . . 20

• OPR (Optimum Picture Response) . . . . . . . . 20

Instant Timer Recording . . . . . . . . . . . . . . . . . . . 21

ShowView Programming . . . . . . . . . . . . . . . . . . . 22

Timer recording using On Screen Display . . . .23-24

Additional Operation - VCR part. . . . . . . . . . . . .25-27

Hi-Fi Stereo Sound System (NIC) . . . . . . . . . . . . 25

On Screen Display (F.OSD) . . . . . . . . . . . . . . . . 25

Tape Counter Memory Stop . . . . . . . . . . . . . . . . 25

Video Doctor (Self-Diagnosis) . . . . . . . . . . . . . . . 26

Wide Screen Compatibility 16:9 . . . . . . . . . . . . . .26

To set the decoder . . . . . . . . . . . . . . . . . . . . . . . .26

Recording from External Components. . . . . . . . . .27

Copying from DVD to VCR . . . . . . . . . . . . . . . . . .27

Operation with DVD and Video CD . . . . . . . . . . 28-30

Playback Setup . . . . . . . . . . . . . . . . . . . . . . . . . . .28

General Features . . . . . . . . . . . . . . . . . . . . . . . . .28

• Moving to another TITLE . . . . . . . . . . . . . . . .28

• Moving to another CHAPTER / TRACK . . . . .28

• Slow Motion . . . . . . . . . . . . . . . . . . . . . . . . . .28

• Still Picture and Frame-by-Frame Playback . .29

• Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

• Time Search . . . . . . . . . . . . . . . . . . . . . . . . . .29

• Marker Search . . . . . . . . . . . . . . . . . . . . . . . .29

• Repeat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

• Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . . .29

• Zoom. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

• Changing the Audio Channel . . . . . . . . . . . . .30

• Last Scene Memory . . . . . . . . . . . . . . . . . . . .30

• Instant Replay. . . . . . . . . . . . . . . . . . . . . . . . .30

• Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . .30

Special DVD Features . . . . . . . . . . . . . . . . . . . . .30

• Title Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

• Disc Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . .30

• Camera Angle. . . . . . . . . . . . . . . . . . . . . . . . .30

• Changing the Audio Language . . . . . . . . . . . .30

• Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Operation with Audio CD and MP3 Disc . . . . . . . . .31

On-Screen Display - DVD . . . . . . . . . . . . . . . . . . .31

Maintenance and Service . . . . . . . . . . . . . . . . . . .31

Playing an Audio CD or MP3 Disc . . . . . . . . . . . 32-34

Audio CD and MP3 Disc Features . . . . . . . . . . . .33

• Pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

• Moving to another Track . . . . . . . . . . . . . . . . .33

• Repeat Track / All / Off . . . . . . . . . . . . . . . . . .33

• Search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

• Random . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

• Repeat A-B . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Programmed Playback . . . . . . . . . . . . . . . . . . . . .34

• Repeat Programmed Tracks . . . . . . . . . . . . . .34

• Erasing a Track from “Program” List . . . . . . . .34

• Erasing the Complete Program List . . . . . . . .34

Viewing a JPEG Disc. . . . . . . . . . . . . . . . . . . . . . . . .35

Slide Show. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Still Picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Moving to another File . . . . . . . . . . . . . . . . . . . . . .35

Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

To rotate picture. . . . . . . . . . . . . . . . . . . . . . . . . . .35

Reference

Language and Area Code List . . . . . . . . . . . . . . . . .36

Language Code List. . . . . . . . . . . . . . . . . . . . . . . .36

Area Code List. . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 37-38

Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

About the symbols for instructions

Indicates hazards likely to cause harm to the unit itself or other material damage.

Note: Indicates special operating features of this unit.

Tip: Indicates tips and hints for making the task easier.

INTRODUCTION

Before Use

Playable Discs

DVD (8 cm / 12 cm disc)

Video CD (VCD) (8 cm / 12 cm disc)

Audio CD (8 cm / 12 cm disc)

In addition, this unit can play SVCD, DVD±R/RW and CD-R/RW that contains audio titles, MP3 or JPEG files.

Notes:

• Depending on the conditions of the recording equipment or the CD-R/RW (or DVD±R/RW) disc itself, some CD-R/RW (or DVD±R/RW) discs cannot be played on the unit.

• Do not attach any seal or label to either side (the labeled side or the recorded side) of a disc.

• Do not use irregular shaped CDs (e.g., heart-shaped or octagonal). It may result in malfunctions.

Notes on DVDs and Video CDs

Some playback operations of DVDs and Video CDs may be intentionally programmed by software manufacturers. This unit plays DVDs and Video CDs according to disc content designed by the software manufacturer, therefore some playback features may not be available or other functions may be added.

Track (Video CD and audio CD only)

Sections of a picture or a musical piece on a video CD or an audio CD. Each track is assigned a track number, enabling you to locate the track you want.

Scene

On a video CD with PBC (Playback control) functions, moving pictures and still pictures are divided into sections called “Scenes”. Each scene is displayed in the menu screen and assigned a scene number, enabling you to locate the scene you want. A scene is composed of one or several tracks.

Types of video CDs

There are two types of video CDs:

Video CDs equipped with PBC (Version 2.0)

PBC (Playback control) functions allow you to interact with the system via menus, search functions, or other typical computer-like operations. Moreover, still pictures of high resolution can be played if they are included in the disc.

Video CDs not equipped with PBC (Version 1.1)

Operated in the same way as audio CDs, these discs allow playback of video pictures as well as sound, but they are not equipped with PBC.

Remote Control Operation Range

Regional code of the DVD player and DVDs

This DVD player is designed and manufactured for playback of region “2” encoded DVD software. The region code on the labels of some DVD discs indicates which type of player can play those discs. This unit can play only DVD discs labeled “2” or “ALL”. If you try to play any other discs, the message “Check Regional Code” will appear on the TV screen. Some DVD discs may not have a region code label even though their playback is prohibited by area limits.

Disc-related terms

Title (DVD only)

The main film content or accompanying feature content or additional feature content, or music album. Each title is assigned a title reference number enabling you to locate it easily.

Chapter (DVD only)

Sections of a picture or a musical piece that are smaller than titles. A title is composed of one or several chapters. Each chapter is assigned a chapter number, enable you to locate the chapter you want. Depending on the disc, chapters may not be recorded.

Point the remote control at the remote sensor and press the buttons.

• Distance: About 23 ft (7 m) from the front of the remote sensor

•Angle: About 30° in each direction of the front of the remote sensor

Remote control battery installation

Detach the battery cover on the rear of the

AAA

Caution

Do not mix old and new batteries. Never mix different types of batteries (standard, alkaline, etc.).

remote control, and insert two (R03/AAA) size batteries with + and - aligned correctly.

Before Use (Continued)

Precautions

Handling the unit

When shipping the unit

The original shipping carton and packing materials come in handy. For maximum protection, re-pack the unit as it was originally packed at the factory.

When setting the unit

The picture and sound of a nearby TV or radio may be distorted during playback. In this case, position the unit away from the TV or radio, or turn off the unit after removing the disc.

To keep the surface clean

Do not use volatile liquids, such as insecticide spray, near the unit. Do not leave rubber of plastic products in contact with the unit for a long period of time. They will leave marks on the surface.

Cleaning the unit

To clean the cabinet

Use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents, such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

To obtain a clear picture

The DVD player is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn down, the picture quality will be poor. Regular inspection and maintenance are recommended after every 1,000 hours of use. (This depends on the operating environment.) For details, please contact your nearest dealer.

Cleaning discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.

About Symbols

About the symbol display

“ ” may appear on the TV screen during operation. This icon means the function explained in this owner’s manual is not permitted by the DVD+VCR or is not available on that specific DVD video disc.

About the disc symbols for instructions

A section whose title has one of the following symbol is applicable only to the disc represented by the symbol.

DVD

VCD

Video CDs.

Audio CDs.

MP3

MP3 disc.

JPEG

JPEG disc.

INTRODUCTION

Notes on Discs

Handling discs

Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints will not get on the surface. Do not stick paper or tape on the disc.

Storing discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat, or leave it in a parked car exposed to direct sunlight, as there may be a considerable temperature increase inside the car.

Selecting the Viewing Source

You must select one of your output sources (DVD or VCR) to view on the TV screen.

• If you want to view DVD deck output source:

Press DVD until DVD indicator in the display window lights and output source of DVD deck is viewed on the TV screen.

• If you want to view VCR deck output source:

Press VCR until VCR indicator in the display window lights and output source of VCR deck is viewed on the TV screen.

Notes:

• If you insert a disc while the DVD+VCR is in the VCR mode, the DVD+VCR will switch to DVD mode automatically.

• If you insert a cassette tape without prevention tab while the DVD+VCR is in the DVD mode, the DVD+VCR will switch to VCR mode automatically.

Front Panel

Disc Tray (DVD deck)

Insert a disc here.

Cassette Compartment (VCR deck)

Insert a video cassette here.

Remote Sensor

Point the DVD+VCR remote control here.

Display Windows

< OPEN/CLOSE

Opens or closes the disc tray.

;

Pause playback or recording. Press repeatedly for frame-by-frame playback.

∫

Stops playback of the disc or tape.

< EJECT

Ejects the tape in the VCR deck.

PROG. (-/+)

To scan up or down through memorized channels.

- DVD: Skip to next chapter or track. Press and hold for two seconds for a fast forward search.

- VCR: Advances the tape during the STOP mode or for fast forward picture search.

Starts playback of a disc or tape.

To record normally or to activate

One-touch Timer Recording by

repeated presses.

- DVD: Skip to beginning of current chapter or track, press twice in quick successions to go to previous chapter or track. Press and hold button for about two seconds to search backward.

- VCR: Rewinds the tape during the stop mode or for fast reverse picture search.

VCR/DVD

Select one of your output sources to view on the TV

screen between DVD and VCR.

Video IN Jack

Í/I

Switches the DVD+VCR ON and STANDBY.

Audio IN (L/R) Jacks

Display Window

The DVD deck is selected.

A disc is in the DVD deck. (Lights when a disc is in the DVD deck and Flashes when no disc.)

Indicates repeat mode.

INTRODUCTION

DVD+VCR is in timer recording or a timer recording is programmed. (VCR part only)

A cassette is in the VCR deck.

The VCR deck is selected.

Lights when TV mode is active.

DVD+VCR is Recording.

(VCR part only)

Indicates total playing time, elapsed time, remaining time or current deck status (Playback, Pause, etc).

Remote Control

Switches DVD+VCR ON and STANDBY

To view channels selected by the VCR

tuner or by the TV tuner.

TV/VCR •

DVD •

Select the DVD+VCR function mode to

DVD.

VCR •

Select the DVD+VCR function mode to

VCR.

DISPLAY

- - : - -

- Accesses On-Screen Display (DVD).

- Shows you the current time or counter (VCR).

2/1/3/4

- PR/TRK (+/-): Selects VCR channels.

Adjusts manually the tape’s picture on

- Selects menu options.

the screen.

SETUP/MENU (i)

Accesses or removes DVD Setup

menu and VCR menu.

ENTER/OK

Confirms menu selections. Displays

functions on the TV screen.

;

- Pause playback or recording.

- Press repeatedly for frame-by-frame playback.

(6) •

- For fast reverse picture search.

- Rewinds the tape during the STOP mode.

Starts playback.

(5) •

- For fast forward picture search.

- Advances the tape during the STOP mode.

0-9 numerical buttons

Selects numbered options in a menu.

REPEAT •

Repeat chapter, track, title or all.

RANDOM ( ) •

- Plays tracks in random order.

- CM SKIP

REPEAT A-B •

Repeats sequence between two points

Selects recording speed.

(A and B)

SHOWVIEW •

To display the programme menu for

ShowView programming.

OPEN/CLOSE, EJECT (<)

- Ejects the tape in the VCR deck.

- Opens and closes the disc tray.

AUX

Select input source for recording into tape.

DISC MENU

Accesses menu on a DVD disc.

SKIP (:/9)

Skip to beginning of current chapter or track, press twice in quick successions to go to previous chapter or track. Skip to next chapter or track.

RETURN

- Removes the setup menu.

- Displays the menu of a video CD with PBC.

∫

Stops playback or recording.

MNL. PROG.

Places a track on the program list.

CLEAR ( )

Removes a track number on the program menu or a mark on the MARKER SEARCH menu.

• A.MONITOR

Selects an audio language (DVD) or an audio channel (VCD).

• SUBTITLE

Selects a subtitle language.

• ANGLE

Selects a DVD camera angle, if available.

• ZOOM

•

Enlarges DVD video image.

• MARKER

Marks any point during playback.

• SEARCH

Displays Marker Search menu.

• TITLE

Displays the disc’s Title menu, if available.

• REC (¥)

Records normally or activates One touch Timer Recording with repeated presses.

•

Note: This remote control uses the same buttons for VCR and DVD functions (ex. PLAY). When using a VCR, first press the VCR button. When using a DVD, first press the DVD button.

Rear Panel

AERIAL

Connect the aerial using this jack.

DVD/VCR OUT (VIDEO/AUDIO (Left/Right))

Connect to a TV with video and audio inputs.

AUDIO OUT (Left/Right) (DVD EXCLUSIVE OUT)

Connect to an amplifier, receiver or stereo system.

EURO AV2 DECODER (VCR IN+OUT/DVD OUT)

Connect to pay-TV decoder, Set Top Box or another video recorder.

Connect to a power source.

INTRODUCTION

AC Power Cord

EURO AV1 AUDIO/VIDEO (VCR IN+OUT/DVD OUT)

Connect to your TV set or another video recorder.

COAXIAL (DVD EXCLUSIVE OUT) (Digital audio out jack)

Connect to digital (coaxial) audio equipment.

RF.OUT

Connect to your TV using this jack.

Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

Precautions

Connections

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

Failure to heed the following precautions may result in damage to the unit, remote control or disc.

1. DO NOT

— in an environment prone to extreme temperatures or

— in direct sunlight. — in a dusty environment. — in an environment where strong magnetic fields are

— on a surface that is unstable or subject to vibration.

2. DO NOT

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3. DO NOT control.

4. DO NOT unit or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

5. DO NOT

6. DO NOT with water. Also DO NOT place any containers filled with

water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

7. DO NOT candles, on the apparatus.

8. AVOID

place the unit —

humidity.

generated.

block the unit’s ventilation openings or holes.

place heavy objects on the unit or remote

place anything which might spill on top of the

expose the apparatus to dripping or splashing. use this equipment in a bathroom or places

place any naked flame sources, such as lighted

violent shocks to the unit during transport.

Tips:

• Depending on your TV and other equipment there are

various ways you can connect the player.

• Please refer to the manuals of your TV, VCR, stereo system or other devices as necessary for additional connection information.

Notes:

• The picture and sound of a nearby TV, VCR, or radio may be

distorted during playback. Position the units away from each other or turn off the unit after removing the disc.

• Make sure the DVD+VCR is connected directly to the TV and tune the TV to the correct video input channel.

• Do not connect the DVD+VCR’s AUDIO OUT jack to the phono in jack (record deck) of your audio system. Do not connect the DVD+VCR via another VCR. The DVD image could be distorted by the copy protection system.

Connecting to a TV

Make one of the following connections, depending on the capabilities of your existing equipment.

Basic connection (AV)

1. Connect the EURO AV1 AUDIO/VIDEO on the rear

panel of this unit to the SCART input socket on the TV using a SCART lead (not supplied). For TV without SCART, connect the yellow VIDEO OUT jack and DVD/VCR AUDIO OUT jacks of this unit to the TV.

2. Some TV broadcasters transmit encoded television

signals which you can only see with a purchased or rented decoder. You can connect such a decoder (descrambler) to this unit.

Basic connection (RF)

1. Connect the RF antenna cable from your indoor/

outdoor antenna to AERIAL jack on the rear panel of this unit.

2. Connect the supplied RF antenna cable from the

RF.OUT jack on the rear panel of this unit to your television’s Antenna Input.

Rear of TV

AUDIO INPUT

VIDEO INAERIAL

Rear of this unit (Basic connection)

SCART INPUT

Satellite or Set Top Box

Connections (Continued)

Connecting to Optional

Equipment

Connecting to an amplifier equipped with two channel analog stereo or Dolby Pro Logic II/Pro Logic

Connect the Left and Right DVD/VCR AUDIO OUT or AUDIO OUT (DVD EXCLUSIVE OUT) jacks on this unit

to the audio left and right in jacks on your amplifier, receiver or stereo system, using the audio cables.

Connecting to an amplifier equipped with two channel digital stereo (PCM) or to an Audio/ Video receiver equipped with a multi-channel decoder (Dolby Digital™, MPEG 2 or DTS)

1. Connect one of this unit’s DIGITAL AUDIO OUT jack (COAXIAL) to the corresponding in jack on your amplifier. Use an optional digital (coaxial) audio cable.

2. You will need to activate this unit’s digital output. (See “AUDIO” on page 18).

Digital Multi-channel sound

A digital multi-channel connection provides the best sound quality. For this you need a multi-channel Audio/ Video receiver that supports one or more of the audio formats supported by your unit (MPEG 2, Dolby Digital and DTS). Check the receiver manual and the logos on the front of the receiver.

Notes:

• If the audio format of the digital output does not match the capabilities of your receiver, the receiver will produce a strong, distorted sound or no sound at all.

• Six Channel Digital Surround Sound via digital connection can only be obtained if your receiver is equipped with a Digital Multi-channel decoder.

• To see the audio format of the current DVD in the OnScreen Display, press A.MONITOR.

PREPARATION

Warning:

Due to the DTS Licensing agreement, the digital output will be in DTS digital out when DTS audio stream is selected.

Rear of this unit

2 channel analog stereo or Dolby Surround connection.

Digital multi-channel connection

COAXIAL

DIGITAL INPUT

AUDIO INPUT

Amplifier (Receiver)

DVD exclusive out

Before Operation-VCR part

Tuning in a video channel on your TV

Notes:

• The output frequency of this DVD+VCR is set at UHF channel 36. If channel 36 is already used by another TV station, or if the picture is distorted, you can change the transmitter channel of your DVD+VCR. Stages 5 ~ 8 will show you how to change the output frequency of your DVD+VCR.

• Your TV receives signals from the DVD+VCR like another TV station. You have to select a channel number on your TV and tune it in so that you may watch video tapes. If you have used a SCART then your TV should already have a dedicated video channel built into it, usually called AV.

1. Make sure that you have correctly installed your

DVD+VCR as described earlier in this book. Press Í/I to turn on your DVD+VCR. Turn on your TV.

2. Insert a pre-recorded video tape into your DVD+VCR

and press Select a TV channel which you wish to watch video. Don’t worry if you don’t have a video-tape to play at this stage! If you switch your DVD+VCR on and continue stages 3 ~ 4, instead of seeing video playback tune your TV until you see a bright blue screen.

3. Tune this channel until the video picture is sharp and

the sound is clear. If you have used a SCART or AUDIO and VIDEO cables you will not have to tune your TV, simply select the AV channel. The AV channel is already pre-tuned for optimum video playback on your TV.

4. Store this channel on your TV.

You will need to look at the TV instruction book if you do not know how to do this.

5. Only carry out stages 5 ~ 8 if you cannot obtain

clear video playback as described in stages 1 ~

Select a TV channel which you wish to watch video. Make sure that your DVD+VCR is in standby pressing Í/I on the remote control (only the clock will be displayed).

6. Press PROG. (+/-) on the front of your DVD+VCR for

more than 4 seconds. RF36 will appear in the display window. The following picture will be displayed on the TV screen.

on the remote control.

7. Use PROG. (+/-) to select another video channel. You may select any channel number between 22 and

68.

8. Select a TV channel which you wish to watch video.

Press Í/I on the front of your DVD+VCR when you have finished. Tune this channel so that a bright blue screen appears. Store this channel on your TV.

Notes:

Make sure that you have correctly installed your DVD+VCR and successfully tuned in a dedicated video channel on your TV. If you do not tune in a dedicated video channel on your TV you will be unable to view and record video tapes!

Initial preset

For the following steps we do assume that you have just connected your video recorder for the very first time. In this case the video recorder is on after mains connection. You should not touch any buttons yet. On the connected TV you will now see.

Note: If this menu does not appear, your video recorder was programmed already.

1. Select the country according to your area with 2 and 1.

“A”: Austria, “B”: Belgium, “CH”: Switzerland, “D”: Germany, “DK”: Denmark, “E”: Spain, “F”: France, “I”: Italy, “N”: Norway, “NL”: Netherlands, “P”: Portugal, “S”: Sweden, “SF”: Finland, “OTHERS”

B D DK E F I

NNL PSSFOTHERS

Pr-12

ACMS

2. Press ENTER/OK to start the automatic storing of the channels of the TV stations in your area.

Pr-12

ACMS

3. The TV STATION TABLE will appear when tuning is completed. Press i to save your settings.

RF CHANNEL 36

SET

Before Operation-VCR part

Setting the clock Manually

The clock in your DVD+VCR controls time and date settings for your DVD+VCR.

1. Press i.

Press 2 or 1 to select SET. Press ENTER/OK. The auto adjust mode can be set to “OFF” by pressing ENTER/OK if you want to set the time manually.

HH MN DD MM YY

:..- -

- -

SET

2. Use the 3 or 4 on the remote control to alter the

HOURS, MINUTES, DAY, MONTH and YEAR. Please note your DVD+VCR uses a 24 hour clock. e.g. 1pm will be displayed as 13:00. The day of the week will appear automatically when you enter the year.

3. If you make a mistake press 2 or 1 and enter the

correct details.

- - - -

- - - - -

To set the colour system

1. Press i.

2. The main menu will appear on the TV screen.

3. Press 2 or 1 to select the SYS and press ENTER/ OK.

4. Press 3 or 4 to select according to the COLOUR system used.

AUTO

PAL

SET

SYS

MESECAM

OSD

OSD ON OFF

5. Press 2 or 1 to select the RF AUDIO. Press 3 or 4 to select according to the RF AUDIO used.

RF I/I

RF B/G

SET

SYS

RF D/K

OSD

OSD ON OFF

6. Press i to remove the menus from the TV screen.

SYS

PREPARATION

HH MN DD MM YY

:..00 1 01 05 SAT 8

SET

4. Press i to return to a TV picture.

Before Operation-VCR part

How to use the main menu

This DVD+VCR can easily be programmed by using the menus displayed on screen. The menus are controlled by the Remote Control Handset.

1. Switch on your TV set and DVD+VCR by pressing

the Í/I button.

2. Press i button. The main menu will appear on the TV screen.

SYS

ON OFF

•REC - Timer recording setting (see p. 23).

• PR SET - Manual tuning setting (see p. 15).

•ACMS - ACMS (Automatic Channel Memory

System) (see p. 14).

• SET - Date & clock setting (see p. 13).

• SYS - To set the Colour TV System (see p. 13).

• (Dr.) - To check a problem with your VCR (see

p. 26).

• F.OSD ON/OFF - To display the operational mode

of your VCR (see p. 25).

• (16:9/4:3) - To select the aspect ratio of your

TV (see p. 26).

• DECODER - To use a pay-TV decoder (or

Satellite) with your VCR (see p. 26).

• (OPR) - To improve the playback picture (see p.

20). Appear when playback only.

• NIC - To activate or deactivate the NICAM digital

sound (see p. 25).

Tip: You can change the menu language on the DVD setup menu. (See the Menu Language on page 17.)

3. Press 2 and 1 to select the desired menu. Press ENTER/OK and use 3 or 4 to select.

4. Press i to return to a TV picture.

SET

OSD

Tuning in TV Stations

Automatically

If the TV broadcast signal is weak your DVD+VCR may not detect the necessary information and will not be able to store them correctly. To overcome this problem please turn to the MANUAL TUNING section on page 15.

1. Press Í/I to turn on your DVD+VCR.

2. Press i button. The main menu will appear on the TV screen. Press 2 or 1 to select the ACMS. Press ENTER/OK.

Pr-12

ACMS

SET

OSD

ON OFF

Pr-12

ACMS

SYS

B D DK E F I

NNL PSSFOTHERS

3. Select the country according to your area with 2 or

A:Austria, B:Belgium, CH:Switzerland, D:Germany, DK:Denmark, E:Spain, F:France, I:Italy, N:Norway, NL:Netherlands, P:Portugal, S:Sweden, SF:Finland, “OTHERS”

4. Press ENTER/OK to start the automatic storing of the channels of the TV stations in your area.

5. The TV STATION TABLE will appear when tuning is completed. Press i to save your settings.

01 C01 00 - - - - -

02 C02 00 - - - - -

03 C03 00 - - - - -

04 - - - - - - - - -

05 - - - - - - - - 06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

MOVE :

Pr-12

ACMS

,DELETE :

Notes: The DVD+VCR’s clock will be set automatically when automatic tuning has finished. If the clock is wrong please see “Setting the clock Manually” on page 13.

Before Operation-VCR part

Tuning in TV Stations Manually

In certain areas of the country broadcast signals may be too weak for your DVD+VCR’s automatic tuning process to find or assign TV stations correctly. You must tune in these weaker broadcast stations manually in order for your DVD+VCR to store them.

1. Press i. The main menu will appear on the TV screen. Press 2 or 1 to select the PR SET. Press OK.

Pr-12

ACMS

SYS

SET

OSD

OSD ON OFF

PR CH MFT STATION 01 00

C03

SET

CHANNEL/CABLE : AV

2. Press i. The station table will appear.

3. Press 3 or 4 to select the programme number that you want to tune (for example, PR 04).

01 C01 00 - - - - -

02 C02 00 - - - - 03 C03 00 - - - - -

04 - - - - - - - - -

05 - - - - - - - - 06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

4. Press OK. Press AUX to select C (Standard stations) or S (Cable stations): C02 - C69, S01 - S41. Enter the channel number of station that you want to tune, use 3 or 4 to find the required station.

MOVE :

PR-03

,DELETE :

SET

PR CH STATION 04 00

SET

C04

MFT

CHANNEL/CABLE : AV

6. Press 1 to select STATION so that you may name

your TV station. Press OK.

7. Use 3 or 4 to select letters and numbers for the

station name. Use 2 or 1 to move back and forth between characters. Press OK.

PR CH MFT 04 00C04

SET

STATION

8. Press i, confirm the station placement.

PR CH MFT 04 00

C04

SET

STATION

PR-04

If you wish to manually tune other stations repeat stages 3 - 8.

01 C01 00 PR-00

02 C02 00 PR-02 03 C03 00 PR-03

04 C04 00 PR-04

05 - - - - - - - - 06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

MOVE :

,DELETE :

9. Press i again. Your new TV station has now been tuned into your DVD+VCR.

PREPARATION

PR CH STATION 04 - - - - - -

SET

MFT

C - -

CHANNEL/CABLE : AV

5. Searching will stop when it locates a stations.

Press 1 to select MFT. Control the fine tuning of the station by using 3 or

Before Operation-VCR part

Changing the order of TV Stations

After tuning TV stations into your DVD+VCR you may wish to change the order in which they are stored without having to retune them again. The instructions given on this page will show you how you can simply move them into your desired order.

1. Press i. The main menu will appear on the TV screen. Press 2 or 1 to select the PR SET. Press ENTER/OK.

PR CH MFT STATION 01 00 PR-03

Pr-12

ACMS

SYS

SET

OSD

OSD ON OFF

SET

2. Press i.

Press 3 or 4 to select the programme number you want to move (for example, PR-03). Press 1.

01 C01 00 PR-00

02 C02 00 PR-02

03 C03 00 PR-03

04 C04 00 PR-04

05 - - - - - - - - 06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

MOVE :

,DELETE :

3. Press 3 or 4 to select the programme number

you want to move to (for example, PR-05).

01 C01 00 PR-00

02 C02 00 PR-02

03 C04 00 PR-04 04 - - - - - - - - 05 C03 00 PR-03

06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

4. Press ENTER/OK. The selected programme will be moved to the new programme number. If you wish to move other TV stations repeat stages 1 - 4.

C03

SET

01 C01 00 PR-00

02 C02 00 PR-02

03 C03 00 PR-03 04 C04 00 PR-04

05 - - - - - - - - 06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

CHANNEL/CABLE : AV

Deleting TV Stations

After tuning TV stations into your DVD+VCR you may wish to delete a station. The instructions given on this page will show you how you can easily delete any unwanted TV stations.

1. Press i. The main menu will appear on the TV screen. Use 2 or 1 to select the PR SET. Press ENTER/OK.

PR CH MFT STATION 01 00 PR-03

MOVE :

C03

SET

,DELETE :

CHANNEL/CABLE : AV

Pr-12

ACMS

SYS

SET

OSD

OSD ON OFF

SET

2. Press i.

3. Press 3 or 4 to select the programme number

you want to delete. (for example, PR-00)

01 C01 00 PR-00

02 C02 00 PR-02

03 C04 00 PR-04 04 - - - - - - - - 05 C03 00 PR-03

06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

4. Press 2.

After a short while, the selected station will be deleted. If you wish to delete other TV stations repeat stages

3 - 4.

01 C01 00 PR-02

02 C02 00 PR-04

03 - - - - - - - - 04 C03 00 PR-03

- - - - - - - - -

06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

5. Press i to remove the menus from the TV screen.

01 C01 00 PR-00

02 C02 00 PR-02

03 C04 00 PR-04 04 - - - - - - - - -

05 C03 00 PR-03

06 - - - - - - - - 07 - - - - - - - - 08 - - - - - - - - -

SET

MOVE :

,DELETE :

5. Press i to remove the menus from the TV screen.

Before Operation-DVD part

By using the DVD Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 17 to 19.

To display and exit the Menu:

Press SETUP to display the menu. A second press of SETUP will take you back to initial screen.

To go to the next level:

Press 1 on the remote control.

To go back to the previous level:

Press 2 on the remote control.

General Operation

1. Press DVD on the remote control.

2. Press SETUP. The Setup menu appears.

3. Use 3/4 to select the desired option then press 1 to move to the second level. The screen shows the current setting for the selected item, as well as alternate setting(s).

4. Use 3/4 to select the second desired option then press 1 to move to the third level.

5. Use 3/4 to select the desired setting then press ENTER/OK to confirm your selection. Some items require additional steps.

6. Press SETUP or 1 exit the Setup menu.

LANGUAGE

Menu Language

Disc Audio

Disc Subtitle

Disc Menu

English

Original

Off

Original

Move

Select

Menu Language

Select a language for the VCR and DVD’s setup menu and information display.

Disc Audio / Subtitle / Menu

Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.

Original: Refers to the original language in which the disc was recorded.

Other: To select another language, press number buttons then ENTER/OK to enter the corresponding 4digit number according to the language code list in the reference chapter (see page 36). If you enter the wrong language code, press CLEAR ( ).

Off (for Disc Subtitle): Turn off Subtitle.

DVD

DISPLAY

PREPARATION

DISPLAY

16 : 9 Wide

Widescreen

Move

Select

TV Aspect

Display Mode

DVD

4:3 : Select when a standard 4:3 TV is connected.

16:9 : Select when a 16:9 wide TV is connected.

Display Mode

DVD

Display Mode setting works only when the TV Aspect mode is set to “4:3”.

Letterbox: Displays a wide picture with bands on the upper and lower portions of the screen.

Panscan: Automatically displays the wide picture on the entire screen and cuts off the portions that do not fit.

Before Operation-DVD part

AUDIO

Each DVD disc has a variety of audio output options. Set this unit’s AUDIO options according to the type of audio system you use.

AUDIO

Dolby Digital

DTS

MPEG

Sample Freq.

DRC

Dolby Digital / DTS / MPEG

Bitstream: Select “Bitstream” if you connect the

DVD+VCR’s DIGITAL AUDIO OUT jack to an amplifier or other equipment with a Dolby Digital, DTS or MPEG decoder.

PCM (for Dolby Digital / MPEG): Select when connected to a two-channel digital stereo amplifier. DVDs encoded in Dolby Digital or MPEG will be automatically downmixed to two-channel PCM audio.

Off (for DTS): If you select “Off”, the DTS signal is not output through the DIGITAL AUDIO OUT jack.

Sample Freq. (Frequency)

If your receiver or amplifier is NOT capable of handling 96 kHz signals, select 48 kHz. When this choice is made, this unit automatically converts any 96 kHz signals to 48 kHz so your system can decode them.

If your receiver or amplifier is capable of handling 96 kHz signals, select 96 kHz. When this choice is made, this unit passes each type of signal through without any further processing.

Check the documentation for your amplifier to verify its capabilities.

Bitstream

PCM

48KHz

Move

DVD

Select

OTHERS

The PBC and Auto Play settings can be changed.

OTHERS

PBC

Auto Play

VCD

PBC

Set Playback Control (PBC) to On or Off.

On: Video CDs with PBC are played according to the PBC.

Off: Video CDs with PBC are played the same way as Audio CDs.

Auto Play

DVD

You can set up the DVD+VCR so a DVD disc automatically starts playing whenever the DVD is inserted. If Auto Play mode is set to On, this DVD player will search for title that has the longest playback time and then play back the title automatically.

On: Auto Play function is active.

Off: Auto Play function is not active.

Note: The Auto Play function may not work for some DVDs.

Off

Select

Move

DRC (Dynamic Range Control)

DVD

With the DVD format, you can hear a program’s soundtrack in the most accurate and realistic presentation possible, thanks to digital audio technology. However, you may wish to compress the dynamic range of the audio output (the difference between the loudest sounds and the quietest ones). This allows you to listen to a movie at a lower volume without losing clarity of sound. Set DRC to On for this effect.

Before Operation-DVD part

LOCK (Parental Control)

LOCK

Rating

Password

Area Code

Rating

DVD

Some movies contain scenes that may not be suitable for children to view. Many of these discs contain parental control information that applies to the complete disc or to certain scenes on the disc. Movies and scenes are rated from 1 to 8, depending on the area. DVD video discs may or may not respond to the parental control setting if the Area code of the disc is set wrongly. Some discs offer more suitable scenes as an alternative. Ratings are area dependent.

The parental control feature allows you to block access to scenes below the rating you input, thereby preventing your children from being able to view material you believe is unsuitable.

1. Select “Rating” on the LOCK menu then press 1.

2. To access the Rating, Password and Area Code features, you must input the 4-digit security code you created.

If you have not yet entered a security code you are prompted to do so. Input a 4-digit code and press ENTER/OK. Enter it again and press ENTER/OK to verify. If you make a mistake before pressing ENTER/OK, press CLEAR ( ).

3. Select a rating from 1 to 8 using the 3 / 4 buttons.

1-8: Rating one (1) has the most restrictions and rating eight (8) has the least restrictive.

Unlock: If you select unlock, parental control is not active and the disc plays in full.

4. Press ENTER/OK to confirm your rating selection, then press SETUP to exit the menu.

5. Press OPEN/CLOSE (<) to activate parental control.

Unlock

New

Move

Select

Password (Security Code)

You can enter or change password.

1. Select “Password” on the LOCK menu then press 1.

2. Follow step 2 as shown left column (Rating). To change the password, select the “Change”, press ENTER/OK and input the new 4-digit code then press ENTER/OK. Input it again to verify.

3. Press SETUP to exit the menu.

If you forget your Security Code

If you forget your security code you can clear it using the following steps:

1. Press SETUP to display the Setup menu.

2. Input the 6-digit number “210499” and the

security code is cleared.

3. Enter a new code as described above.

Area Code

Enter the Area Code whose standards were used to rate the DVD video disc, based on the list in the reference chapter (see page 36).

1. Select “Area Code” on the LOCK menu then press

2. Follow step 2 as shown left (Rating).

3. Select the first character using 3/ 4 buttons.

4. Press 1 and select the second character using 3/

4 buttons.

5. Press ENTER/OK to confirm your area code selection.

DVD

PREPARATION

Note:

If you set a rating for the player, all disc scenes with the same rating or lower are played. Higher rated scenes are not played unless an alternate scene is available on the disc. The alternative must have the same rating or a lower one. If no suitable alternative is found, playback stops. You must enter the 4-digit password or change the rating level in order to play the disc.

Operation with tape

Playing a tape

You will only be able to load and eject video cassettes when your DVD+VCR is plugged into the mains. Your DVD+VCR may also playback recordings from NTSC tapes (on PAL TV).

Getting a better picture

When a cassette is inserted and playback started, the automatic tracking function works to get the best possible picture automatically. If the quality of the recording is poor, repeatedly press 3 or 4 on the remote control to manually adjust the tracking until any distortions have been removed.

1. Make sure that you have correctly connected your DVD+VCR as described earlier in this book. Turn on your TV. Press Í/I to turn on your DVD+VCR. Insert the video cassette into your DVD+VCR. The video cassette should have the window side facing up and the arrow facing away from you.

2. Press If you load a video cassette which has had its record protection tab removed, playback of the cassette will start automatically.

AUTO TRACKING

Your DVD+VCR will automatically adjust the tracking to give the best picture quality. If noise bars appear during playback, adjust the tracking manually by pressing PR/TRK (+/-).

3. Press ; to still a picture. Press ; repeatedly to advance the tape frame by frame. If you press 5, the picture will be slowed down at about 1/19 times the normal playback. Tapes can be paused for up to 5 minutes. After 5 minutes your DVD+VCR will stop the tape to prevent damaging the tape or your DVD+VCR. Still picture quality can be improved slightly by using 3 or 4.

4. Press

Double speed playback (SP mode only) Press the “1 (X2)” button during normal playback. The tape will play back at double speed and without sound. Press the “1 (X2)” button to return to playback at normal speed

Picture search: During playing back press either 6 or 5 to this will enable you to rapidly wind the tape (7 times normal playback) see where you are on the tape.

Notes:

• When playing back tapes that have been over-

recorded with new content, the original audio may be audible during auto tracking.

• The image may be distorted during special playback

in LP mode.

to start playing your tape.

to continue playing your tape.

Logic search:

During fast forwarding or rewinding press and hold 6 or 5 the picture will be played back at 7 times normal playback speed.

5. Slow motion playback,

Shuttle:

During playing back or still picture press 2 or 1. You can reach the following playback speeds. (-7xplay, -3xplay, -play, still, 1/19 slow, play, 2xplay, 7xplay) To switch off the slow motion and shuttle, press the desired function. During slow motion and shuttle, the noise bars may appear on the picture according to the status of tape. If distortions can be seen in the picture, reduce them with 3 or 4.

6. Press ∫ to end playback. Press EJECT (<).

If the end of the tape is reached, your DVD+VCR will stop playback automatically, rewind, stop, eject the tape.

CM (Commercial Message) Skip:

This feature enables you during playback of a tape to skip a commercial break in a few seconds, then resume normal playback. While tape is playing press on the remote control to skip commercial (or another programme material). Repeatedly press to skip: 1 Press 30 seconds 2 Press 60 seconds 3 Press 90 seconds 4 Press 120 seconds 5 Press 150 seconds 6 Press 180 seconds

OPR (Optimum Picture Response)

This feature automatically improves playback picture quality by adjusting your DVD+VCR to the condition of the tape. Please note that the OPR icon ( ) will only appear in play that mode when playing a tape.

1. Press i.

2. Press 2 or 1 to select (OPR).

3. Press ENTER/OK.

4. Press 3 or 4 repeatedly to select: OFF, SOFT or SHARP.

5. Press i return to screen.

OFF

SOFT

Pr-12

ACMS

SYS

SET

SHARP

OSD

OSD ON OFF

Operation with tape

Instant Timer Recording

Your DVD+VCR allows you to make recordings using a variety of simple methods:

Instant Timer Recording start recording immediately for a set period of time or until the video cassette runs out.

Your DVD+VCR incorporates Long Play (LP) which enables you to record up to twice the amount of time on a video cassette. For example an E-180 will record up to 180 minutes using Standard Play (SP); using LP you will be able to record up to 360 minutes. Please note there will be a slight loss in picture and sound quality when using LP.

1. Make sure that you have correctly connected your DVD+VCR as described earlier in this book. Press Í/I to turn on your DVD+VCR.

2. Insert a video cassette with protection tab into your DVD+VCR. The video cassette should have the window side facing up and the arrow facing away from you.

3. Press 3 or 4 to select the programme number you wish to record. You may also directly select programme number using the numbered buttons on the remote control.

4. If you wish to record directly from the SCART or RCA jacks, repeatedly press AUX until the socket you wish to record from is displayed.

AV 1 for recording from EURO AV1 SCART jacks on the rear of your unit. AV 2 for recording from EURO AV2 SCART jacks on the rear of your unit. AV 3 for recording from VIDEO IN and AUDIO IN (Left & Right) jacks on the front of your unit.

5. Press if you wish to record in Long Play or Standard Play.

SP will produce improved picture and sound quality, however LP will provide twice as much recording time as SP.

6. Press REC (¥) on the remote to start recording.

Press ¥ on your unit or press REC (¥) on the remote several times. Each successive press will increase the record time by 30 minutes until you reach a maximum of 9 hours.

7. Press ; to avoid recording unwanted scenes. Press ; to continue recording.

Tapes can be paused for up to 5 minutes; RECP will be displayed when a tape is paused. After 5 minutes your DVD+VCR will stop recording to prevent damaging the tape or your DVD+VCR.

8. Press ∫ to end recording. Press EJECT (<).

Notes:

• If you do not wish to record on a tape (this can happen

quite easily by accident!) remove the protection tab on the back edge of the video cassette.

• It is possible to record on a video cassette with the

record protection tab removed by covering the hole with self adhesive tape.

• Remember you can record one programme while

watching another by starting your instant recording, press TV/VCR to select TV mode and then selecting a different channel on your TV.

OPERATION

Operation with tape

ShowView Programming

ShowView greatly simplifies entering the date, channel, start and end times of a Timer Recording by simply entering a ShowView Code. ShowView Codes are published in most TV guide magazines; they can vary one to nine numbers in length.

HOWVIEW is a registered trademark of Gemstar

Development Corporation. The S

HOWVIEW system is manufactured under

license from Gemstar Development Corporation.

1. Make sure that TV channels have been tuned and stored in correct SHOWVIEW order. Insert a video cassette with protection tab into your DVD+VCR.

SHOWVIEW NO.

- - - - - - - - -

0~9,

DELETE :

REC

2. Press SHOWVIEW.

3. Press the numbered buttons to enter the ShowView Code of the TV programme that you wish to record. If you make a mistake press 2 then enter the revised number.

SHOWVIEW NO.

246876543

REC

4. Press ENTER/OK. If PLEASE CHECK is displayed it means that you have entered the wrong ShowView number, entered the ShowView number incorrectly. If “- -” is displayed, you have to enter the programme number of the station, you want to record from.

5. Press 2 or 1 to select the settings that you wish to

revise. (PR, DATE, TIME and SP). Press 3 or 4 to enter the correct information.

PR DATE TIME

PR-01 12

- - - -

- - - - - - - -~::

11 11 55~::

SP SP SP SP SP SP SP

6. Press 1 to select the recording speed. Press 3 or 4 to select the desired tape speed (SP, IP, or LP). IP mode determines how much tape is left and switches speed from SP to LP, if necessary, to complete recording the program. Check that the timer event details are correct. If you wish to record from AUDIO IN and VIDEO IN on the front or from either of the EURO SCART sockets on the back of VCR, press AUX to select for correct display (AV1, AV2 or AV3).

PR DATE TIME

PR-01 12

- - - -

- - - - - - - -~::

11 11 55~::

SP SP SP SP SP SP

7. If you want to make another ShowView recording repeat stages 2 - 7. Press i twice. If PLEASE CHECK is displayed, you have entered incorrect information and will need to re-enter the data. Press Í/I to switch your DVD+VCR power off mode.

will appear in the video recorder’s display while your VCR waits to make the recording. To watch a DVD during timer recording standby mode, press Í/I and DVD to switch to DVD mode.

8. Press Í/I to end recording.

PR DATE TIME

PR-01 12

- - - -

11 11 55~::

- - - - - - - -~::

SP SP SP SP SP SP SP

Operation with tape

Timer recording using On Screen

Display

You may set up to seven timer record events within one month of the current date.

Note:

Before setting the timer make sure that you have set the DVD+VCR clock correctly and you know which stations you have tuned TV stations on your DVD+VCR.

1. Insert a video cassette with protection tab into your DVD+VCR. The video cassette should have the window side facing up and the arrow facing away from you.

2. Press i. Press 2 or 1 to select REC. Press ENTER/OK.

PR DATE

- -

- - - -

- - - - SP

- -

- - - - - - - -~::

DELETE:

T I M E

5. Use the 3 or 4 to enter the date of the programme.

If you press ENTER/OK before entering the date you may select one of the following automated recording features. Press 2 or 1 to select, then press

ENTER/OK to confirm. DLY To record every day (except Saturday and

Sunday) at the same time.

SU~SA To record at the same time every week.

PR DATE PR-03 3

- - - - SP

DLY SU MO TU WE TH FR SA

T I M E

- - - - - - - -~::

6. Use 3/ 4/ 2 / 1buttons to enter the recording start

and end times of the programme that you wish to record. Please note your DVD+VCR uses a 24 hour clock. e.g. 1pm will be displayed as 13:00.

PR DATE

PR-03

- - - - SP

T I M E

41400 1530~::

- - - - - - - -~::

OPERATION

3. Press ENTER/OK to start setting the timer record event.

4. Use the 3 or 4 to enter the station that you wish to record then press 1.

PR DATE

PR-03

- - - -

- - - - SP

- -

- - - - - - - -~::

T I M E

SP SP

Note: If all timer record events are full press 3 or 4 to select the event that you wish to remove and replace. Press 2 to delete the event.

7. Press 1 to select the recording speed. Press 3 or 4 to select the desired tape speed (SP, IP, or LP). IP mode determines how much tape is left and switches speed from SP to LP, if necessary, to complete recording the program.

PR DATE

PR-03

- - - - SP

T I M E

41400 1530~::

- - - - - - - -~::

Operation with tape

Timer recording using On Screen

Display (Continued)

8. Press i to set another timer record event and follow steps 3 to 8. Check that the timer event details are correct. Press i return to screen.

If PLEASE CHECK is displayed, you have entered incorrectly and will need to re-enter the data.

9. Press Í/I to switch your DVD+VCR to Timer Standby mode.

The timer symbol ( ) will appear in the display window while your DVD+VCR waits to make the recording.

10. Press Í/I to end timer recording.

Notes:

• The DVD+VCR will automatically power off when

Timer Recording ends.

• During timer recording standby mode, the DVD and

VCR mode cannot be operated. To use the DVD+VCR, press Í/I. After you use the DVD or VCR, press Í/I again to put the VCR into timer recording standby mode.

• If at a later date you wish to delete or change any of

the settings in timer event memory you may do so without having to enter all the timer event information again. Simply display the timer event screen. Use 3 or 4 to select the event that you wish to delete or change.

Press 2 to delete the event...or Press ENTER/OK to change; then press 2 or 1 to select; Station, Date, Start and End times and recording speed. Press 3 or 4 to enter the correct information.

• If Timer record events Overlap...

Make sure that the preset times of the timer recording events do not overlap. If they do, the earlier programme will always be given priority.

Example:

Programme 1 is programmed to start at 16:00 and end at 17:00. Programme 2 is programmed to start at 16:30 and end at 17:30. (In this case, Programme 1 will be recorded in its entirety, but only the last 30 minutes of Programme 2 will be recorded.)

• To watch a DVD while performing a timer recording,

press TV/VCR to select VCR mode.

Additional Operation - VCR part

Hi-Fi Stereo Sound System (NIC)

Your DVD+VCR will record and playback Hi-Fi stereo sound. In addition it has a stereo NICAM digital stereo sound decoder. This allows you to record and playback the sound in several different ways. Video cassettes recorded on your DVD+VCR will have a normal mono audio track and two VHS Hi-Fi stereo audio tracks. These stereo tracks allow you to make audio recordings in Hi-Fi stereo or bilingual mode from a TV broadcast, stereo audio system, video disc or another Hi-Fi VCR.

1. Your DVD+VCR’s NICAM digital sound decoder allows you to enjoy broadcasts with NICAM sound, as well as standard stereo, bilingual and mono sound. The particular type of sound received or that recorded will be briefly displayed on the TV screen for a couple of seconds:

STEREO NICAM Sound is automatically recorded on the Hi-Fi stereo and mono tracks of the video tape.

BIL NICAM Both audio channels will be recorded on the Hi-Fi stereo tracks. The primary language channel (left) will be recorded on the mono track of the video tape.

MONO The sound is recorded on the Hi-Fi tracks and the mono track of the video tape without any separation.

2. Press AUDIO repeatedly until the desired audio mode appears.

3. The choice is STEREO, LEFT, RIGHT and MONO. In BIL NICAM playback the primary language is output on the left channel and the secondary channel is output simultaneously from the right channel when audio output is set to STEREO. The primary language will be output from both channels when the audio setting is MONO. Please note that when adjusting the tracking control Hi-Fi stereo sound may revert to MONO.

Note: When OFF is selected in NIC, only mono sound will be output.

On Screen Display (F.OSD)

You may easily display the current time or tape counter, amount of tape left, day, month, year, day of week, programme channel, tape speed and operational mode of your DVD+VCR on the TV screen. If a recording is taking place these On Screen Displays will not be recorded onto the tape.

1. Press DISPLAY to display. Press DISPLAY repeatedly to cycle through the display options. The tape counter and amount of tape left will appear if there is a tape loaded.

2. After 3 seconds the majority of the On Screen Displays will clear leaving only the clock or tape counter and the amount of tape left on the screen. Press DISPLAY again to remove all displays from the TV screen.

Note: It cannot display when f.OSD is OFF.

Tape Counter Memory Stop

The Digital Tape Counter can be displayed on the display window instead of the time by pressing DISPLAY on the remote control. The Digital Tape Counter indicates the relative positions of recordings on the tape.

1. Press DISPLAY. Press CLEAR ( ) to set the counter to 0:00:00.

Press

The tape counter will display the actual play time in hours, minutes and seconds.

2. Press ∫ when playback or recording is complete. Press 6.

The tape will rewind and automatically stop when the counter returns to 0:00:00.

Note:

To rewind to the beginning of the tape, press 6 again.

or start playback or recording.

OPERATION

Additional Operation - VCR part

Video Doctor (Self-Diagnosis)

This feature informs you that there is a problem with your DVD+VCR. These error messages will appear on the TV screen.

1. Press i.

Press 2 or 1 to select . Press ENTER/OK.

ANTENNA CONNECT

HEAD STATUS TAPE STATUS

Pr-12

ACMS

SYS

SET

OSD

OSD ON OFF

NO. OF TIMER PROGRAMME NEXT TIMER PROGRAMME

PLEASE CHECK

2. Press 3 or 4 to check a problem.

ANTENNA CONNECT

• PLEASE CHECK:

Connect the aerial into the jack securely.

HEAD STATUS

• PLEASE CLEAN:

Clean your video heads.

TAPE STATUS

• NOT RECORDABLE:

Insert a tape with its protection tab in place

NO. OF TIMER PROGRAMME

•2

Shows the number of timer recording.

NEXT TIMER PROGRAMME

• PR-01 26 10:00~11:00 SP

Shows the current status of timer recording.

3. Press i to remove the menus from the TV screen.

Wide Screen Compatibility 16:9

Your DVD+VCR can record and play back wide screen aspect ratio programmes (16:9). To record a wide screen format programme successfully the correct type of wide screen signal must be broadcast by the TV station.

1. Switch on your DVD+VCR. Press i. Press 2 or 1 to select . Press ENTER/OK.

2. Press 3/4 repeatedly to select: AUTO, 4:3 or 16:9.

AUTO:

Automatically plays back Wide-Screen programmes as Wide-Screen and Normal programmes as normal.

4:3:

Only for playing back and recording Normal format recordings (4:3). 16:9: Only for playing back and recording Wide-Screen format recordings (16:9).

Pr-12

ACMS

SYS

SET

AUTO

4:3

OSD

16:9

OFF

3. Press i to remove the menus from the TV screen. To enjoy Wide-Screen playback you must connect your VCR to the TV using a SCART cable.

To set the decoder

We have already described, how to connect a decoder for pay-TV station as DECODER or PREMIERE on page

10. For the recording of an encoded station you do not

have to control anything. You just select the station and wait shortly until the decoding will start.

1. Press i. The main menu will appear on the TV screen. Press 2 or 1 to select the DECODER. Press ENTER/OK.

2. Press 3 or 4 to select.

ON: When the decoder is connected to the AV2 socket.

OFF: When another VCR is connected to the AV2 socket.

Pr-12

ACMS

SYS

SET

OSD

OSD ON OFF

ON OFF

Pr-12

ACMS

SYS

SET

AUTO

4:3

OSD

16:9

Additional Operation - VCR part

Recording from External Components

You can record from an external component, such as a camcorder or VCR, connected to any of the DVD+VCR’s external inputs.

1. Make sure that the component you want to record from is connected properly to the DVD+VCR.

2. Press AUX repeatedly to select the external input to record from.

3. Load a recordable tape.

4. Set a recording mode (SP or LP) as necessary by pressing repeatedly.

5. Play the tape or disc in the external component. If you have a TV attached to your DVD+VCR, you can see the video playing.

6. Press ¥ once to start recording. The REC indicator lights in the display window.

7. Press ∫ to stop recording.

Notes:

• Before recording, confirm the recording start position.

• If your source is copy-protected using CopyGuard, you will

not be able to record it using this unit. See Copyright on page 2 for more details.

• To record for a fixed length of time, see One-touch Timer

Recording.

Copying from DVD to VCR

You can copy the contents of a DVD to a VHS tape.

1. Insert the disc you wish to copy into the DVD deck and close the disc tray.

2. Insert a blank VHS video tape into the VCR deck.

3. Find the place on the DVD from which you want to start dubbing using the functions. For best results, pause playback at the point from which you want to record.

4. Press ¥ on the Remote Control. The DVD goes into PLAY mode and the VCR goes into RECORD mode. If the DVD disc menu appears, you may need to

press

manually to begin copying.

5. When the DVD is finished playing, press ∫ to end copying.

Notes:

• If the DVD you are attempting to copy is copy protected, you

will not be able to copy the disc. It is not permitted to copy Macrovision encoded DVDs (or Discs). “LOCK” is displayed in the display window.

• You must stop the copy process manually when the DVD

movie ends, or the unit may replay and record over and over again.

• When you stop the DVD playback during copying, the

recording on VCR is stopped automatically.

, 6, 5 and ;

OPERATION

Operation with DVD and Video CD

Playback Setup

1. Turn on the TV and select the video input source connected to the DVD+VCR.

2. Turn on the audio system (if applicable) and select the input source connected to the DVD+VCR.

3. Press OPEN/CLOSE (<) to open the disc tray and load your chosen disc in the tray, with the playback side down.

4. Press OPEN/CLOSE (<) to close the tray. Playback starts automatically. If playback does not

start, press In some cases, the disc menu might appear instead.

5. To stop the playback, press ∫. The unit records the stopped point, depending on the disc. “;∫” appears on the screen briefly. Press

to resume playback (from the scene point). If

you press ∫ again or unload the disc (“∫” appears on the screen.), the unit will clear the stopped point. Press OPEN/CLOSE (<) to remove the disc. Press OPEN/CLOSE (<) to close disc tray or press Í/I, the disc tray closes automatically and unit turns off.

If a menu screen is displayed

The menu screen may be displayed first after loading a DVD or Video CD which offer a menu.

DVD

Use the 2 1 3 4 buttons to select the title/chapter you want to view, then press ENTER/OK to start. Press TITLE or DISC MENU to return to the menu screen.

VCD

Use the number buttons to select the track you want to view and press RETURN to return to the menu screen. Menu settings and operating procedures may differ. Follow the instructions on each menu screen. You also may set PBC to Off (See “PBC” on page 18).

Notes:

• If parental control is set and the disc is not within the rating

settings you must input the password. (See “LOCK” on page 19).

• DVDs may have a region code. Your player will not play discs

that have a region code different from your player. The region code for this player is 2 (two).

• In some cases, playback of discs recorded in the NTSC

system may be jerky.

General Features

Notes: Unless stated otherwise, all operations described use the remote control. Some features may also be available on the Setup menu.

Moving to another TITLE

When a disc has more than one title, you can move to another title. Press DISPLAY and select desired title by using number (0-9) or 2 / 1 then press ENTER/OK to move to another title.

Moving to another CHAPTER / TRACK

DVD VCD

When a title on a disc has more than one chapter or a disc has more than one track, you can move to another chapter/track as follows:

• Press 9 or : briefly during playback to select

the next chapter/track or to return to the beginning of the current chapter/track.

• Press : twice in quick successions to step back to

the previous chapter/track.

• To go directly to any chapter during DVD playback,

press DISPLAY and press 3 / 4 to select the chapter/track icon. Input the chapter/track number (0-

9) or use 2 / 1.

Note: On a Video CD with PBC, you must set PBC to Off on the setup menu to use this function (See “PBC” on page 18).

Slow Motion

1. Press 5 during still mode.

The DVD+VCR will now go into SLOW mode.

2. Use 5 to select the required speed: F 1/7, F 1/6, F 1/4, or F 1/2 (forward).

3. To exit Slow Motion mode, press 1.

Note: Slow motion playback in reverse is not possible.

DVD VCD

DVD

Operation with DVD and Video CD

Still Picture and Frame-by-Frame Playback

DVD VCD

1. Press ; during playback. Advance the picture frame-by-frame by pressing ; repeatedly.

2. To exit still motion mode, press 1.

1. Press 6 or 5 during playback.

2. Press 6 or 5 repeatedly to select the required

3. To exit SEARCH mode, press 1.

Time Search

To start playing at any chosen time on the disc:

1. Press DISPLAY during playback. The time search

2. Press 3/4 to select the time clock icon and

3. Input the required start time in hours, minutes, and

4. Press ENTER/OK to confirm. Playback starts from

Note:

On a Video CD with PBC, you must set PBC to Off on the setup menu to use this function (See “PBC” on page 18).

Marker Search

To enter a Marker

You can start playback from up to nine memorized points. To enter a marker, press MARKER at the desired point on the disc. The Marker icon appears on the TV screen briefly. Repeat to enter up to nine markers.

To Recall or Clear a Marked Scene

1. During disc playback, press SEARCH. The marker

2. Within 10 seconds, press 2/1 to select a marker

3. Press ENTER/OK and playback starts from the

4. You can play any marker by inputting its number on

DVD VCD

speed: DVD disc; X2, X4, X16 or X100 Video CD; X2, X4, X8

DVD VCD

box shows the elapsed playing time.

“ -:--:-- ” appears.

seconds from left to right. If you enter the wrong numbers, press CLEAR ( ) to remove the numbers you entered. Then input the correct numbers.

the selected time.

DVD VCD

1/9#5

123------

search menu appears on the screen.

number that you want to recall or clear.

marked scene. Or, Press CLEAR ( ) and the marker number is erased from the list.

the marker search menu.

Repeat

DVD VCD

You can repeat a title/chapter/all/track on a disc. Press REPEAT during playback to select a desired repeat mode.

DVD Video Discs - Repeat Chapter/Title/Off

• Chapter: repeats the current chapter.

• Title: repeats the current title.

• Off: does not play repeatedly.

Video CDs - Repeat Track/All/Off

• Track: repeats the current track

• All: repeats all the tracks on a disc.

• Off: does not play repeatedly.

Note:

• On a Video CD with PBC, you must set PBC to Off on the setup menu to use this function (See “PBC” on page 18).

• If you press 9 once during Repeat Chapter (Track) playback, the repeat playback cancels.

Repeat A-B

DVD VCD

To repeat a sequence.

1. Press REPEAT A-B at your chosen starting point.

“A- ” appears briefly on the TV screen.

2. Press REPEAT A-B again at your chosen end point.

“A- B” appears briefly on the TV screen and the repeat sequence begins.

3. Press REPEAT A-B again to cancel.

Zoom

DVD VCD

Use zoom to enlarge the video image.

1. Press ZOOM during playback or still playback to

activate the Zoom function. The square frame appears briefly in the right bottom of the picture.

2. Each press of the ZOOM button changes the TV

screen in the sequence:

100% size → 150% size → 200% size → 300% size → 400% size → 100% size.

3. Use the 2 134 buttons to move through the

zoomed picture.

4. To resume normal playback, press ZOOM

repeatedly or CLEAR ( ) button.

Note:

Zoom may not work on some DVDs.

OPERATION

Operation with DVD and Video CD

Changing the Audio Channel

Press AUDIO repeatedly during playback to hear a different audio channel (Stereo, Left, Right).

Last Scene Memory

This player memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the player or switch off the player. If you load a disc that has the scene memorized, the scene is automatically recalled.

Note:

This player does not memorize the scene of a disc if you switch off the player before commencing to play the disc.

Instant Replay

Press AUX during playback and the disc will reverse picture search through 10 seconds of playback. And then the playback will start from the point again.

DVD CD VCD

DVD

VCD

Screen Saver

The screen saver appears when you leave the DVD+VCR in Stop mode for about five minutes.

Special DVD Features

Checking the contents of DVD discs: Menus

DVDs may offer menus that allow you to access special features. To use the disc menu, press DISC MENU. Input the corresponding number or use the 2 134 buttons to highlight your selection. Then press ENTER/OK.

Title Menu

1. Press TITLE. If the current title has a menu, the

menu appears on the screen. Otherwise, the disc menu may appear.

2. The menu offers features such as camera angles,

spoken language and subtitle options, and chapters for the title.

3. Press TITLE to exit.

Disc Menu

Press DISC MENU and the disc menu is displayed. Press DISC MENU again to exit.

Camera Angle

If the disc contains scenes recorded at different camera angles, you can change to a different camera angle during playback. Press ANGLE repeatedly during playback to select a desired angle. Note that the number of the current angle appears on the display.

Tip:

The Camera Angle icon is displayed on the TV screen when alternate angles are available.

DVD

Changing the Audio Language

Press A.MONITOR repeatedly during playback to hear a different audio language or audio track.

Subtitles

Press SUBTITLE repeatedly during playback to see the different subtitle languages.

Note:

If there is no information, is displayed.

DVD

Operation with Audio CD and MP3 Disc

On-Screen Display - DVD

You can display the general playback status on the TV screen. Some items can be changed using the menu. To use the on-screen display:

1. Press DISPLAY during playback.

2. Press 3 / 4 to select an item.

The selected item is highlighted.

3. Press 2 / 1 to change the setting. You can also use

the number buttons if appropriate (e.g. inputting the title number). For some functions, press ENTER/OK to execute the setting.

Notes:

• Some discs may not provide all of the features shown below.

• If no button is pressed for 10 seconds, the on-screen display

disappears.

• If is displayed, action prohibited or not available.

Example: On-Screen Display during playing DVD Video

Items Selection Method

Title Number

Chapter Number

Time search

1 / 1

1 / 18

-:--:--

Example: On-Screen Display during playing VCD

Items Selection Method

Track Number (or PBC mode)

Time search

1 / 1

-:--:--

2 / 1, Numbers

ENTER/OK

2 / 1, Numbers

ENTER/OK

Numbers

ENTER/OK

2 / 1, Numbers

ENTER/OK

Numbers

ENTER/OK

Maintenance and Service

Refer to the information in this chapter before contacting a service technician.

Handling the Unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

• Do not use volatile liquids such as insecticide spray

near the unit.

• Do not leave rubber or plastic products in contact with the unit for a long period of time. since they leave marks on the surface.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution.

Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The DVD+VCR is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished.

Depending on the operating environment, regular inspection and maintenance are recommended after every 1,000 hours of use.

For details, please contact your nearest authorized service center.

OPERATION

Playing an Audio CD or MP3 Disc

The DVD+VCR can play MP3 formatted recordings on CD-ROM, CD-R, or CD-RW discs.

Audio CD

Once you insert an audio CD a menu appears on the TV

screen. Press 3 / 4 to select a track then press

ENTER/OK and playback starts.

AUDIO CD

0:52:07

1 / 12

Trac k1

Trac k2

Trac k3

Trac k4

Trac k5

Trac k6

Trac k7

Trac k8

List

PROGRAM

Program

Clear All

Edit

MP3

1. Press 3 / 4 to select a folder, and press ENTER/

OK to see the folder contents.

2. Press 3 / 4 to select a track then press

ENTER/OK. Playback starts.

MUSIC

0:00:00

1 / 12

1-Music1

2-Music2

3-Music3

4-Music4

5-Music5

6-Music6

7-Music7

DISPLAY

List

Info

PROGRAM

Program

Clear All

Edit

ID3 TAG

• When playing a file containing information such as track titles, you can see the information by pressing DISPLAY. [ Song, Artist, Album, Comment, Genre ]

• If there is no information, “No ID3 TAG” appear on the menu screen.

MP3 disc compatibility with this player is limited as follows:

• Sampling frequency: within 8 - 48 kHz

• Bit rate: within 32 - 320kbps

• The player cannot read an MP3 file that has a file

extension other than “.mp3”.

• CD-R physical format should be ISO 9660

• If you record MP3 files using software that cannot

create a file system (eg. Direct-CD) it is impossible to playback MP3 files. We recommend that you use Easy-CD Creator, which creates an ISO 9660 file system.

• File names should have a maximum of 8 letters and must incorporate an .mp3 extension.

• They should not contain special letters such as / ? * : “ < > l etc.

• The total number of contens on the disc should be less than 1500 files and 300 folders.

This DVD player requires discs and recordings to meet certain technical standards in order to achieve optimal playback quality. Pre-recorded DVDs are automatically set to these standards. There are many different types of recordable disc formats (including CD-R containing MP3 or WMA files) and these require certain pre-existing conditions (see above) to ensure compatible playback.

Customers should note that permission is required in order to download MP3 / WMA files and music from the Internet. Our company has no right to grant such permission. Permission should always be sought from the copyright owner.

Tips:

• If you are in a file list on the “MUSIC” menu and want to

return to the Folder list, use the 3 / 4 to highlight and press ENTER/OK.

• To go directly to any track, input the track number (0-9).

• On a CD with MP3 and JPEG you can switch MP3 and

JPEG. Press TITLE and “MUSIC” or “PHOTO” word on top of the menu is highlighted.

Playing an Audio CD or MP3 Disc

Audio CD and MP3 Disc Features

Pause

1. Press ; during playback.

2. To return to playback, press 1 or press ; again.

Moving to another Track

1. Press 9 or : briefly during playback to go to

2. Press : twice in quick successions to go back to

3. You can play any track by inputting its number.

Repeat Track / All / Off

You can play a track/all on a disc.

1. Press REPEAT when playing a disc. The repeat icon

2. Press REPEAT to select a desired repeat mode.

CD MP3

the next track or to return to the beginning of the current track.

the previous track.

CD MP3

appears.

• Track: repeats the current track.

• All: repeats all the tracks on a disc.

• Off (No display): does not play repeatedly.

Random

1. Press RANDOM during playback. Random Playback begins immediately and “Random” appears on the menu screen.

2. To return to normal playback, press RANDOM repeatedly until “Random” disappears from the menu screen.

Tip:

By pressing 9 or : during random playback, the unit selects another track and resumes random playback.

Repeat A-B

1. To repeat a sequence during disc playback press REPEAT A-B at your chosen starting point. The Repeat icon and “A -” appear on the menu screen.

2. Press REPEAT A-B again at your chosen end point. The Repeat icon and “A-B” appear on the menu screen, and the sequence begins to play repeatedly.

3. To exit the sequence and return to normal play, press REPEAT A-B again. The Repeat icon disappears from the menu screen.

CD MP3

OPERATION

Note:

If you press 9 once during Repeat Track playback, the repeat playback will be cancelled.

1. Press 6 or 5 during playback.

2. Press 6 or 5 repeatedly to select the required

speed: X2, X4 and X8 backward or forward.

3. To exit SEARCH mode, press 1.

CD MP3

Playing an Audio CD or MP3 Disc

Programmed Playback

The program function enables you to store your favourite tracks from any disc in the player memory. A program can contain 30 tracks.

1. Insert a disc. AUDIO CD or MUSIC menu appears.

2. Press MNL.PROG. The E mark will appear to the right of the word “Program” on the right side of the menu screen.

AUDIO CD

0:52:07

6 / 16

List

01-TRACK01

02-TRACK02

03-TRACK03

04-TRACK04

05-TRACK05

06-TRACK06

07-TRACK07

08-TRACK08

PROGRAM

01-TRACK01

02-TRACK02

03-TRACK04

04-TRACK06

Edit

Program

Audio CD Program Menu

MUSIC

0:00:00

4 / 4

List

03 File 03

04 File 04

05 File 05

06 File 06

07 File 07

08 File 08

09 File 09

10 File 10

MP3

DISPLAY

Info

PROGRAM

Edit

Program

03 File 03

06 File 06

08 File 08

10 File 10

MP3 Program Menu

Clear All

Repeat Programmed Tracks

1. Press REPEAT when playing a disc. The repeat icon appears.

2. Press REPEAT to select a desired repeat mode.

• Track: repeats the current track

• All: repeats all the tracks on programmed list.

• Off (No display): does not play repeatedly.

Note:

If you press 9 once during Repeat Track playback, the repeat playback will be cancelled.

Erasing a Track from “Program” List

1. During STOP mode, press MNL.PROG. and E mark will appear.

2. Use 1 / 3 / 4 to select the track that you wish to erase from the Program list.

3. Press CLEAR ( ). Repeat to erase additional tracks on the list.

Erasing the Complete Program List

1. During STOP mode, press MNL.PROG. and E mark will appear.

2. Use 1 / 3 / 4 to select “Clear All” in the “Program” list, then press ENTER/OK.

Note:

The programs are also cleared when the disc is removed.

Note:

Press MNL.PROG. again, the E mark will disappear to exit the Program Edit mode.

3. Select a track on the “List”, then press ENTER/OK to place the selected track on the “Program” list. Repeat to place additional tracks on the list.

4. Press 1. Select the track you want to start playing in the “Program” list.

5. Press

or ENTER/OK to start. Playback begins in the order in which you programmed the tracks. Playback stops after all of the tracks on the “Program” list have played once.

6. To resume normal playback from programmed playback, select a track of AUDIO CD (or MUSIC) list

and then press

or ENTER/OK.

Note:

When you play the programmed track, the E mark will disappear then the program edit mode will disable.

Viewing a JPEG Disc

Using this DVD+VCR you can view discs with JPEG files.

1. Insert a disc and close the tray. The PHOTO menu appears on the TV screen.


Folder 00

Folder 01

Folder 02

Folder 03

Folder 04

01 FILE 01

02 FILE 02

03 FILE 03

/FILE 01

List

Preview

>>>

2. Press 3 / 4 to select a folder, and press ENTER/ OK. A list of files in the folder appears. If you are in a file list and want to return to the previous Folder list, use the 3 / 4 buttons on the remote to highlight and press ENTER/OK.

3. If you want to view a particular file, press 3 / 4 to

highlight a file and press ENTER/OK or

. The selected file will appear for viewing. The on-screen messages displayed with the file can be turned off by pressing the RETURN (Hide) button on the remote control. While viewing a file, you can press ∫ to move to the previous menu (PHOTO menu).

Tips:

• Information and user guidance regarding the current image is displayed in the lower part of the screen. You can toggle this bar on and off using RETURN.

• There are three Slide Speed options : >>> (Fast), >> (Normal) and > (Slow) Use 342 1 to highlight the Speed. Then, use 2 / 1 to select the option you want to use then press ENTER/OK.

• On a disc with MP3 and JPEG you can switch MP3 and JPEG. Press TITLE and MUSIC or PHOTO word on top of the menu is highlighted.

Slide Show

JPEG

Use 342 1 to highlight the (Slide Show) then press ENTER/OK.

Still Picture

JPEG

1. Press ; during slide show.

The player will now go into PAUSE mode.

2. To return to the slide show, press 1 or press ; again.

Moving to another File

JPEG

Press 9 or : or cursor (2 or 1) once while viewing a picture to advance to the next or previous file.

Zoom

JPEG

Use zoom to enlarge the photo image. (see page 29)

To rotate picture

JPEG

Press 3 / 4 during showing a picture to rotate the picture clockwise or counter clockwise.

JPEG disc compatibility with this player is limited as follows:

• Depending upon the size and number of JPEG

files, it could take a long time for the DVD+VCR to read the disc’s contents. If you don’t see an onscreen display after several minutes, some of the files may be too large — reduce the resolution of the JPEG files to less than 5760 (Horizontal) x 4608 (Vertical) pixels and burn another disc.

• The total number of contens on the disc should be less than 1500 files and 300 folders.

• Some discs may be incompatible due to a different recording format or the condition of disc.

• Ensure that all the selected files have the “.jpg” extensions when copying into the CD layout.

• If the files have “.jpe” or “.jpeg” extensions, please rename them as “.jpg” file.

• File names without “.jpg” extension will not be able to be read by this DVD+VCR. Even though the files are shown as JPEG image files in Windows Explorer.

OPERATION

Language and Area Code List

Language Code List

Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu.

Language Code Language Code Language Code Language Code

Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian 7684 Slovak 8375 Afrikaans 6570 French 7082 Macedonian 7775 Slovenian 8376 Albanian 8381 Frisian 7089 Malagasy 7771 Somali 8379 Ameharic 6577 Galician 7176 Malay 7783 Spanish 6983 Arabic 6582 Georgian 7565 Malayalam 7776 Sudanese 8385 Armenian 7289 German 6869 Maltese 7784 Swahili 8387 Assamese 6583 Greek 6976 Maori 7773 Swedish 8386 Aymara 6588 Greenlandic 7576 Marathi 7782 Tagalog 8476 Azerbaijani 6590 Guarani 7178 Moldavian 7779 Tajik 8471 Bashkir 6665 Gujarati 7185 Mongolian 7778 Tamil 8465 Basque 6985 Hausa 7265 Nauru 7865 Tatar 8484 Bengali; Bangla 6678 Hebrew 7387 Nepali 7869 Telugu 8469 Bhutani 6890 Hindi 7273 Norwegian 7879 Thai 8472 Bihari 6672 Hungarian 7285 Oriya 7982 Tibetan 6679 Breton 6682 Icelandic 7383 Panjabi 8065 Tigrinya 8473 Bulgarian 6671 Indonesian 7378 Pashto, Pushto 8083 Tonga 8479 Burmese 7789 Interlingua 7365 Persian 7065 Turkish 8482 Byelorussian 6669 Irish 7165 Polish 8076 Turkmen 8475 Cambodian 7577 Italian 7384 Portuguese 8084 Twi 8487 Catalan 6765 Japanese 7465 Quechua 8185 Ukrainian 8575 Chinese 9072 Javanese 7487 Rhaeto-Romance 8277 Urdu 8582 Corsican 6779 Kannada 7578 Rumanian 8279 Uzbek 8590 Croatian 7282 Kashmiri 7583 Russian 8285 Vietnamese 8673 Czech 6783 Kazakh 7575 Samoan 8377 Volapük 8679 Danish 6865 Kirghiz 7589 Sanskrit 8365 Welsh 6789 Dutch 7876 Korean 7579 Scots Gaelic 7168 Wolof 8779 English 6978 Kurdish 7585 Serbian 8382 Xhosa 8872 Esperanto 6979 Laothian 7679 Serbo-Croatian 8372 Yiddish 7473 Estonian 6984 Latin 7665 Shona 8378 Yoruba 8979 Faroese 7079 Latvian, Lettish 7686 Sindhi 8368 Zulu 9085

Area Code List

Choose a area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF Ethiopia ET Malaysia MY Saudi Arabia SA Argentina AR Fiji FJ Maldives MV Senegal SN Australia AU Finland FI Mexico MX Singapore SG Austria AT France FR Monaco MC Slovak Republic SK Belgium BE Germany DE Mongolia MN Slovenia SI Bhutan BT Great Britain GB Morocco MA South Africa ZA Bolivia BO Greece GR Nepal NP South Korea KR Brazil BR Greenland GL Netherlands NL Spain ES Cambodia KH Islands HM Canada CA Hong Kong HK New Zealand NZ Sweden SE Chile CL Hungary HU Nigeria NG Switzerland CH China CN India IN Norway NO Taiwan TW Colombia CO Indonesia ID Oman OM Thailand TH Congo CG Israel IL Pakistan PK Turkey TR Costa Rica CR Italy IT Panama PA Uganda UG Croatia HR Jamaica JM Paraguay PY Ukraine UA Czech Republic CZ Japan JP Philippines PH United States US Denmark DK Kenya KE Poland PL Uruguay UY Ecuador EC Kuwait KW Portugal PT Uzbekistan UZ Egypt EG Libya LY Romania RO Vietnam VN El Salvador SV Luxembourg LU

Netherlands Antilles

Russian Federation

AN Sri Lanka LK

RU Zimbabwe ZW

Troubleshooting

Check the following guide for the possible cause of a problem before contacting service.

Symptom Cause Correction

No power. • The power cord is disconnected. • Plug the power cord into the wall outlet

securely.

The power is on, but the DVD+VCR does not work.

No picture. • The TV is not set to receive DVD+VCR

No sound. • The equipment connected with the audio

• DVD or VCR button is not switched properly.

• No disc is inserted.

• No tape is inserted.

signal output.

• The video cable is not connected securely. • Connect the video cable into the jacks

• Mismatch setting between TV and this

unit.

• Wrong connection. • Check the connection.

cable is not set to receive DVD+VCR signal output.

• The audio cables are not connected securely.

• The power of the equipment connected with the audio cable is turned off.

• Refer to page 5.

• Insert a disc or tape. (Check that the

disc or tape indicator in the display window is lit.)

• Select the appropriate video input mode on the TV so the picture from the DVD+VCR player appears on the TV screen.

securely.

• Select the correct Video Output in SETUP menu.

• Select the correct input mode of the audio receiver so you can listen to the sound from the DVD+VCR.

• Connect the audio cable into the jacks securely.

• Turn on the equipment connected with the audio cable.

REFERENCE

The playback picture is poor.

• The AUDIO options are set to the wrong position.

• The disc is dirty. • Clean the disc.

• The TV channels are not tuned in

properly.

• Tape heads are dirty. • Clean video heads.

• Tape is a rental or was recorded on

another VCR.

• Set the AUDIO options to the correct position.

• Check tuning, carry out tuning again.

• Use PR/TRK (3/4) for manual

tracking adjustment while tape is playing.

Troubleshooting (Continued)

Symptom Cause Correction

The DVD+VCR does not start playback.

Video tape cannot be inserted.

No Hi-Fi sound • Audio mode is not set properly. • Select STEREO by repeatedly pressing

No NICAM sound recording

The remote control does not work properly.

• An unplayable disc is inserted. • Insert a playable disc. (Check the disc type and Regional code.)

• The disc is placed upside down. • Place the disc with the playback side down.

• The disc is not placed within the guide. • Place the disc on the disc tray correctly inside the guide.

• The disc is dirty. • Clean the disc.

• The Rating level is set. • Cancel the Rating function or change

the rating level.

• Is the cassette compartment empty? • Eject the tape in.

AUDIO on the remote control.

• NICAM mode is not set properly. • Make sure NICAM in the menu is set to AUTO for the station to be recorded.

• There is an obstacle in the path of the

remote control and this unit.

• The batteries in the remote control are

exhausted.

• The remote control is not pointed at the

remote sensor of the DVD+VCR.

• Remove the obstacle.

• Replace the batteries with new ones.

• Point the remote control at the remote

sensor of the DVD+VCR.

Timer recording is not possible.

• The remote control is too far from the

DVD+VCR.

• This remote control use the same buttons

for VCR and DVD functions (ex.PLAY).

• Clock in DVD+VCR is not set to correct

time.

• Timer has been programmed incorrectly. • Reprogram Timer.

• indicator light does not appear after

programming timer.

• Operate the remote control within 23ft (7 m).

• When using a VCR, first press the VCR button. When using a DVD, first press the DVD button.

• Set clock to correct time.

• Reprogram Timer and turn DVD+VCR

off to enable timer.

Specification

General

Power requirements AC 200-240 V, 50 Hz Power consumption 17 W Dimensions (approx.) 430 X 78.5 X 265 mm (w/h/d) Mass (approx.) 4.2 kg Operating temperature 5°C to 35°C (41°F to 95°F) Operating humidity 5 % to 90 % Timer 24 hours display type RF Modulator UHF 22-68 (Adjustable)

System

Laser Semiconductor laser, wavelength 650 nm Video Head system Double azimuth 6 heads, helical scanning. Signal system PAL Frequency response DVD (PCM 96 kHz): 8 Hz to 44 kHz

DVD (PCM 48 kHz): 8 Hz to 22 kHz

CD: 8 Hz to 20 kHz Signal-to-noise ratio More than 100 dB (ANALOG OUT connectors only) Harmonic distortion Less than 0.008% Dynamic range More than 100 dB (DVD)

More than 95 dB (CD)

Inputs (VCR)

Audio -6.0 dBm, more than 10 kohms (SCART)

-6.0 dBm, more than 47 kohms (RCA)

Video 1.0 V (p-p), 75 ohms, unbalanced (SCART/RCA)

Outputs (DVD)

VIDEO OUT 1 Vp-p 75 ohms, sync negative Audio output (digital audio) 0.5 V (p-p), 75 ohms, RCA jack x 1 Audio output (analog audio) 2.0 Vrms (1 kHz, 0 dB), 600 ohms, RCA jack (L, R) x 1/SCART (TO TV)

REFERENCE

Outputs (VCR/DVD)

Audio -6.0 dBm, less than 1 kohms (SCART) Video 1.0 V (p-p), 75 ohms, unbalanced (SCART)

• Designs and specifications are subject to change without notice.

Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.

DTS and DTS Digital Out are trademarks of Digital Theater Systems, Inc.

HR-XV28S

Printed in Indonesia

0305MNH-AL-OT

JVC LPT1056-001A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Precautions

CAUTION

CAUTION: TO REDUCE THE RISK

OF ELECTRIC SHOCK

DO NOTREMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

Important notes on controlling this unit

1. Í/I Button Press the Í/I button on the remote control or front panel to turn on this unit.

2. DVD Button Press DVD button on the remote control when you want to control the DVD. The DVD indicator will light on the front panel display to show that the DVD is selected.

3. VCR Button Press the VCR button on the remote control when you want to control the VCR. The VCR indicator will light on the front panel display to show that the VCR is selected.

4. DVD/VCR Button Press the DVD/VCR button on the front panel to toggle control between the DVD and the VCR.

Table of Contents

About the symbols for instructions

Before Use

Playable Discs

Remote Control Operation Range

Before Use (Continued)

Precautions

About Symbols

JPEG

Notes on Discs

Selecting the Viewing Source

Front Panel

Display Window

Remote Control

Rear Panel

Precautions

Connections

Connecting to a TV

Connections (Continued)

1. Connect one of this unit’s DIGITAL AUDIO OUT jack (COAXIAL) to the corresponding in jack on your amplifier. Use an optional digital (coaxial) audio cable.

2. You will need to activate this unit’s digital output. (See “AUDIO” on page 18).

Before Operation-VCR part

Tuning in a video channel on your TV

4. Store this channel on your TV.

8. Select a TV channel which you wish to watch video.

Initial preset

1. Select the country according to your area with 2 and 1.

2. Press ENTER/OK to start the automatic storing of the channels of the TV stations in your area.

Setting the clock Manually

1. Press i.

To set the colour system

1. Press i.

2. The main menu will appear on the TV screen.

3. Press 2 or 1 to select the SYS and press ENTER/ OK.

4. Press 3 or 4 to select according to the COLOUR system used.

5. Press 2 or 1 to select the RF AUDIO. Press 3 or 4 to select according to the RF AUDIO used.

6. Press i to remove the menus from the TV screen.

4. Press i to return to a TV picture.

How to use the main menu

2. Press i button. The main menu will appear on the TV screen.

3. Press 2 and 1 to select the desired menu. Press ENTER/OK and use 3 or 4 to select.

4. Press i to return to a TV picture.

1. Press Í/I to turn on your DVD+VCR.

2. Press i button. The main menu will appear on the TV screen. Press 2 or 1 to select the ACMS. Press ENTER/OK.

4. Press ENTER/OK to start the automatic storing of the channels of the TV stations in your area.

Tuning in TV Stations Manually

1. Press i. The main menu will appear on the TV screen. Press 2 or 1 to select the PR SET. Press OK.

2. Press i. The station table will appear.

3. Press 3 or 4 to select the programme number that you want to tune (for example, PR 04).

4. Press OK. Press AUX to select C (Standard stations) or S (Cable stations): C02 - C69, S01 - S41. Enter the channel number of station that you want to tune, use 3 or 4 to find the required station.

8. Press i, confirm the station placement.

9. Press i again. Your new TV station has now been tuned into your DVD+VCR.

5. Searching will stop when it locates a stations.

Changing the order of TV Stations

1. Press i. The main menu will appear on the TV screen. Press 2 or 1 to select the PR SET. Press ENTER/OK.

2. Press i.

4. Press ENTER/OK. The selected programme will be moved to the new programme number. If you wish to move other TV stations repeat stages 1 - 4.

Deleting TV Stations

1. Press i. The main menu will appear on the TV screen. Use 2 or 1 to select the PR SET. Press ENTER/OK.

2. Press i.

4. Press 2.

5. Press i to remove the menus from the TV screen.

5. Press i to remove the menus from the TV screen.
