DVD & HDD VIDEO RECORDER

DR-MH30S/ DR-MH20S

CABLE/SAT

DVDTV

STANDBY ON

OPEN/

DVD

TV AV

TV/CBL/SAT

VIDEO

HDD DVD

AUX

CANCEL

MEMO/MARK

EDIT

DUBBING

LIVE

ENTER

CLEAR

STOP/

JUMP

REC MODE

DISPLAY

ON SCREEN

SAT SET UP

VPS/PDC

AUDIO

SUBTITLE

ANGLE

LIVE CHECK

PROGRAMME

NAVIGATIONTOP MENU

RETURN

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

PAUSEREC

PROGRESSIVE

HELP

STANDBY/ON

SCAN

VIDEO

S-VIDEO VIDEO

L(MONO)-AUDIO-R

HDD DVD

DV IN

PULL - OPEN

INSTRUCTIONS

LPT0923-001A

2 EN

SAFETY FIRST

Safety Precautions

The rating plate and the safety caution are on the rear of the unit.

WARNING: DANGEROUS VOLTAGE INSIDE WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT

EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION:

A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.

WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE DISC TRAY AND OTHER OPENINGS TO LOOK INTO THE INSIDE OF THIS UNIT.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL.

CLASS 1 LASER PRODUCT REPRODUCTION OF LABELS

WARNING LABEL INSIDE OF THE UNIT

IMPORTANT:

8 Please read the various precautions on page 2 and 3 before

installing or operating the unit.

8 It should be noted that it may be unlawful to re-record pre-

recorded tapes, DVDs, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable programme and in any literary, dramatic, musical, or artistic work embodied therein.

CAUTION:

8 When you are not using the unit for a long period of time, it is

recommended that you disconnect the power cord from the mains outlet.

8 Dangerous voltage inside. Refer internal servicing to qualified

service personnel. To prevent electric shock or fire hazard, remove the power cord from the mains outlet prior to connecting or disconnecting any signal lead or aerial.

● Manufactured under licence from Dolby Laboratories. “Dolby” and double-D symbol are trademarks of Dolby Laboratories.

● “DTS” and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.

● SHOWVIEW is a registered trademark of Gemstar Development Corporation. The SHOWVIEW system is manufactured under licence from Gemstar Development Corporation.

● This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing users only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

For Italy:

“It is declared that this product, brand JVC, conforms to the Ministry Decree n. 548 of 28 Aug.’95 published in the Official Gazette of the Italian Republic n. 301 of 28 Dec.’95”

The STANDBY/ON 1 button does not completely shut off mains power from the unit, but switches operating current on and off. “`” shows electrical power standby and “

When the equipment is installed in a cabinet or a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear).

When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.

Failure to heed the following precautions may result in damage to the unit, remote control or disc.

1. DO NOT

— in an environment prone to extreme temperatures or humidity.

— in direct sunlight. — in a dusty environment. — in an environment where strong magnetic fields are

generated. — on a surface that is unstable or subject to vibration.

2. DO NOT

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

3. DO NOT

4. DO NOT or remote control.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

5. DO NOT

6. DO NOT water. Also DO NOT place any containers filled with water or

liquids (such as cosmetics or medicines, flower vases, potted plants, cups, etc.) on top of this unit.

7. DO NOT candles, on the apparatus.

8. AVOID

place the unit —

block the unit’s ventilation openings or holes.

place heavy objects on the unit or remote control. place anything which might spill on top of the unit

expose the apparatus to dripping or splashing. use this equipment in a bathroom or places with

place any naked flame sources, such as lighted

violent shocks to the unit during transport.

!” shows ON.

SAFETY FIRST

MOISTURE CONDENSATION

Moisture in the air will condense on the unit when you move it from a cold place to a warm place, or under extremely humid conditions—just as water droplets form on the surface of a glass filled with cold liquid. In conditions where condensation may occur, disconnect the unit’s power plug from the wall and keep it disconnected for a few hours to let the moisture dry, then turn on the unit.

TTENTION:

To mobile phone users:

Using a mobile phone in the vicinity of the unit may cause picture vibration on the TV screen or change the screen to a blue back display.

On placing the unit:

Some TVs or other appliances generate strong magnetic fields. Do not place such appliances on top of the unit as it may cause picture disturbance.

EN 3

4 EN

DISC INFORMATION 5

About Discs ...................................................................................5

INDEX 10

INSTALLING YOUR NEW UNIT 17

Basic Connections ......................................................................17

INITIAL SETTINGS 18

Auto Set Up .................................................................................18

Preset Download .........................................................................19

Language ....................................................................................21

Monitor Set ..................................................................................22

SAT CONTROL SET 23

Satellite Receiver Control Setting ...............................................23

BASIC OPERATIONS ON DVD DECK 25

Basic Playback ............................................................................25

Playback Features ......................................................................26

Using The On-screen Bar ...........................................................30

Parental Lock ..............................................................................34

Basic Recording ..........................................................................35

Recording Features .....................................................................36

BASIC OPERATIONS ON HDD DECK 38

Basic Recording ..........................................................................38

Recording Features .....................................................................39

Basic Playback ............................................................................40

Playback Features ......................................................................40

Live Memory Playback ................................................................41

TIMER RECORDING 44

SHOWVIEWTM Timer Programming .................................................44

Manual Timer Programming ........................................................46

Automatic Satellite Programme Recording .................................48

NAVIGATION 49

Library Database Navigation .......................................................49

Modify Original Information .........................................................50

Modify Play List Information ........................................................52

Modify Library Information ...........................................................54

Playback With MP3/JPEG Navigation .........................................55

EDITING 56

High Speed Dubbing (From HDD To DVD) ................................ 56

Just Dubbing (From HDD To DVD) ............................................ 56

Manual Dubbing (From HDD To DVD) ....................................... 57

Original Dubbing (From DVD To HDD) ...................................... 57

DV Dubbing ................................................................................ 58

Edit From A Camcorder .............................................................. 59

Edit To Or From Another Recorder ............................................ 60

Output/Input Set ......................................................................... 61

Digital Audio Dubbing ................................................................. 62

REMOTE CONTROL 63

Remote Control Functions .......................................................... 63

SYSTEM CONNECTIONS 65

Connecting To A Satellite Receiver ............................................ 65

Connecting To A Dolby Digital Decoder Or An Amplifier With

Built-in DTS ..........................................................................66

SUBSIDIARY SETTINGS 67

Mode Set .................................................................................... 67

Scan Mode Set ........................................................................... 69

HOWVIEW

Tuner Set .................................................................................... 70

Clock Set .................................................................................... 73

Format A Disc (DVD Deck Only) ................................................ 74

Finalise A Disc (DVD Deck Only) ............................................... 75

Help Function ............................................................................. 76

Tray Lock (DVD Deck Only) ....................................................... 76

System Setup ......................................................... 70

TROUBLESHOOTING 77

SPECIFICATIONS 81

APPENDIX 82

LIST OF TERMS 86

About Discs

Recordable/playable Discs

You can use discs with the following logos for recording and playback.

DVD-RAM

12 cm: 4.7 GB/9.4 GB 8 cm: 1.4 GB/2.8 GB Ver. 2.0/2x speed Ver. 2.1/1x – 2x speed

DVD- R

12 cm: 4.7 GB 8 cm: 1.4 GB Ver. 2.0/1x – 4x speed (Video mode)

● The above table is based on the information as of February 2004.

● Recording and playback may not be performed depending on the

characteristics and condition of the disc used, leading to unsatisfactory results. Using discs manufactured by JVC is recommended since they have been tested to be compatible with this unit.

DVD-RAM Discs

It is only possible to use discs which conform with DVD-RAM standard Version 2.0 or 2.1.

● It is impossible to record on DVD-RAM discs which do not conform to

this standard. If you use a disc formatted under a different standard version, format it on this unit before use.

● It may not be possible to record, play back, edit or dub a DVD-RAM

disc even if it conforms to the standard if it was recorded or edited on the devices from other manufacturers or on a PC, or if it has far too many titles, or if there is very little available capacity remaining on the disc.

● DVD-RAM discs recorded on this unit cannot be played back on an

incompatible DVD player.

● It is possible to record copy-once programmes of digital broadcasts

only onto 4.7/9.4 GB DVD-RAM discs (2.8 GB DVD-RAM discs are not compatible).

DVD-RW

12 cm: 4.7 GB/9.4 GB Ver. 1.1/1x – 2x speed (Video mode/VR mode)

DISC INFORMATION

EN 5

DVD-R/RW Discs

It is only possible to use DVD-R discs which conform with DVD-R standard Version 2.0. When a DVD-R/RW disc (Video mode) is finalised (墌 pg. 75), it can be played back on a standard DVD player as a DVD VIDEO disc. When a DVD-RW disc (VR mode) is finalised (墌 pg. 75), it can be played back on a standard DVD player compatible with the VR mode of DVD-RW discs.

Before finalising —

— it is possible to record on unrecorded areas of the disc, edit the disc title and programme titles, and delete programmes.

● It is impossible to record or edit DVD-R/RW discs recorded on other devices even if they have not been finalised.

● It is impossible to overwrite recorded areas of DVD-R discs.

● Available recording capacity does not increase even if a recorded

programme is deleted from a DVD-R disc.

After finalising —

After a DVD-R/RW disc (Video mode) has been finalised, it is possible to play back the recorded programmes (video and/or audio) on a standard DVD video player as a DVD VIDEO disc.

● Edited titles are displayed as the “DVD menu” in video mode.

● It is impossible to record, edit or delete the data either in video mode or in VR mode.

● Either in video mode or in VR mode, although the disc can be played back on DVD players from other manufacturers, sometimes it may not be possible to play back depending on the disc and recording conditions.

● It is impossible to record on CD-R/RW or DVD-R discs used for authoring.

● It is impossible to record onto DVD-R/RW (Video mode) discs broadcasts that allow you to copy once. The copy once programmes can only be recorded onto DVD-RW discs formatted in VR mode.

NOTE:

The following may result if you play back a DVD-R disc recorded on another unit.

● The disc does not play.

● A mosaic pattern (block noise) appears on the screen.

● Video or audio may be dropped out.

● The unit stops during playback.

6 EN

DISC INFORMATION

Discs For Playback Only

You can use discs with the following logos for playback only.

DVD VIDEO Video CD/Super Video CD

(example of region code indications)

Audio CD

CD-DA files

CD-RW

CD-DA/JPEG/ MP3 files

● Playback may not be performed depending on the characteristics and condition of the disc used.

● DTS Audio CDs can also be played back (An optional DTS decoder is required).

● MP3 and JPEG discs can be played back on this unit only when they have been recorded in the ISO9660 or Joliet format and finalised.

● JPEG files that can be played back on this unit must conform to JFIF/ Baseline process, and the maximum resolution of a JPEG file is 3,840 x 2,160 pixels.

● CD-R/RW discs recorded in music CD format need to be finalised to play back on this unit.

● Operation and audio quality of this unit are not guaranteed for discs that do not conform to the Compact Disc specification (CD-DA). Before you play back a CD, check for the CD logo and read the notes on the package to confirm that it conforms to the Compact Disc specification.

● Depending on the intentions of the author of the software, recording conditions of DVD discs and Video CD/SVCD discs may be restricted. Since this unit plays back discs according to the intentions of the author of the software as indicated on the disc, some functions may not operate as commanded.

● When switching from the first layer to the second layer of doublelayered DVD VIDEO discs, the image and sound may be momentarily distorted. This is not a malfunction.

● DVD-AUDIO discs compatible with DVD video players can be played.

● Super Audio CDs (SACD) compatible with conventional CD players

can be played.

CD-R

CD-DA/JPEG/ MP3 files

CD-ROM

JPEG/MP3 files

Unplayable Discs

The following types of discs cannot be played using this unit. Do not attempt to play back any kind of disc that is damaged (cracked, warped, or repaired with adhesive tape) or discs in unusual shapes (heart-shaped, octagonal, or other forms). If such discs are accidentally played back, it may cause noise that can lead to speaker damage.

● CD-ROM discs (including PHOTO-CD and CD-G)

● Discs recorded in Packet Write (UDF) format

● 1.3-GB double density CDs (DDCD)

● High density CDs (HDCD)

The following discs also cannot be played back.

● Discs of a region number other than “2”

● DVD-RAM (2.6 GB/5.2 GB)

● DVD-RAM (TYPE1)

Region Number

The world is divided into 6 regions for DVD VIDEO discs. DVDVIDEO discs are assigned a region number to indicate which region they may be played back in. A disc cannot be played back on this unit unless the region number of the disc matches that of the unit. The region number for this unit is “2”. Only discs whose region number includes “2” or “ALL” can be played back such as shown below.

Examples of DVD VIDEO labels which can be played back using this unit.

Marks of discs in this instruction manual

Allows operation with a DVD-RAM disc.

Allows operation with a DVD-R disc.

Allows operation with a DVD-RW dis c.

Allows operation with a DVDVIDEO disc.

Allows operation with a Video CD/Super Video CD (SVCD) disc.

Allows operation with an Audio CD disc.

Allows operation with a disc including MP3 files.

Allows operation with a disc including JPEG files.

Recording Medium And Format

DVD-RAM

● Recording and erasing can be performed as many times as possible on a disc.

● Editing can be performed after recording, such as deleting unwanted parts.

● While recording, it is possible not only to start playback of a programme currently being recorded, but also to watch another programme previously recorded.

DVD-RW (VR mode)

● Recording and erasing can be performed as many times as possible on a disc.

● Editing can be performed after recording, such as deleting unwanted parts.

DVD-RW (Vid eo mode)

● Can be played back on other DVD players.

● New recording can be performed by erasing all the data on a disc

once played back.

DVD-R

● Can be played back on other DVD players.

● Suitable when keeping a recorded disc for a long time.

File Structure Of Discs

DVD VIDEO

Typically, DVD VIDEO discs are made up of larger units called “titles”. Each title has a number (title number) that can be used to select desired titles. Titles are further divided into units called “chapters”. Each chapter has a number (chapter number) that can also be used to select desired chapters. Note that some discs are not divided into titles and chapters.

When you record a programme on a DVD-RAM/RW (VR mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes from monaural to stereo due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during playback. (墌 pg. 27)

When you record a programme on a DVD-R/RW (Video mode) disc

A single recording session results in a single title (a single chapter). However, chapter marks are automatically inserted when recording is paused, or audio changes due to commercial breaks, etc. It is also possible to insert chapter marks at desired locations during either recording or playback. Once the disc has been finalised, these chapter marks are deleted and new chapter marks are assigned automatically approximately every 5 minutes.

DVD-RAM, DVD-RW, DVD-R or DVD VIDEO disc

Title 1 Title 2

Chapter 1 Chapter 2

● In Video mode, even before finalising, it is impossible to perform editing operations other than changing the disc name and/or title names and deleting programmes and/or titles.

● After finalising, it is impossible to perform editing operations.

Chapter 3

Chapter 1

Chapter 2

Chapter 3

DISC INFORMATION

EN 7

Audio CD/Video CD/SVCD

Typically, Audio CD discs are divided into separate tracks each containing one song. Each track is assigned a number. For example, the third track is Track 3. The same is true for Video CD/ SVCD discs. However, some discs are not divided into tracks.

Track 1 Track 2 Track 3 Track 4

Audio CD or Video CD/SVCD

JPEG/MP3 Disc (CD-R/RW/ROM)

MP3/JPEG files put in directories nested in several levels on a disc will be organized as if they were put in single level directories (groups) by the MP3/JPEG Navigation of this unit. (墌 pg. 55)

File structure of a disc before starting the MP3/JPEG Navigation

Directory MP3 file JPEG file

File structure of the disc after starting the MP3/JPEG Navigation

Files are automatically grouped as follows and displayed on the MP3/JPEG Navigation screen. Data is displayed in the alphabetical order of file name. Files are grouped based on roots.

● This unit can recognise up to 9 hierarchies including directories and files. Also, it can recognise up to 250 files in each group, and up to 99 groups on a disc.

NOTES:

● Video CD/SVCD discs that support Playback Control (PBC)

The contents of a disc are recorded into several hierarchies, and played back according to the instructions on the screen while navigating through the hierarchies. It is also possible to playback recorded tracks consecutively without activating the PBC function even when playing a PBC-compatible disc. (

● Regarding the contents recorded on discs

Some files may not be played back depending on the file types and other factors.

墌 pg. 29)

8 EN

HDD DVD

CABLE/SAT

DVDTV

DVD

TV/CAL/SAT

STANDBY/ON

OPEN/ CLOSE

TV AV

VIDEO

DISC INFORMATION

DVD VIDEO Marks

Sometimes marks are printed on a DVD disc and/or on its packaging to indicate information regarding the contents and functions of the disc. Check the marks indicating the contents and functions of the disc. Note, however, that in some cases a disc may not include a mark even for a function it supports.

Marks related to video

Number of subtitles Number of angles

Recorded under the standard 4:3 aspect ratio

Video playback is in Wide video mode (16:9) on wide televisions, but in letter box on televisions with standard 4:3 aspect ratio.

Video playback is in Wide video mode (16:9) on wide televisions, but pan and scan is used on televisions with standard 4:3 aspect ratio (either the left or right side of the image is cut-out).

Marks related to audio

Number of audio tracks

Dolby Digital mark It has been developed by Dolby Laboratories as a digital surround system.

DTS (Digital Theater Systems) You can enjoy DTS audio if you connect an amplifier with a built-in DTS decoder to the DIGITAL OUT connector of the unit.

Screen includes black bands at the top and the bottom of image which has a standard 4:3 aspect ratio (letter box)

Placing A Disc

Opening the disc tray

Press x to open the disc tray.

L(MONO)-AUDIO-R

HDD DVD

DV IN

BY/O ND A

PULL - OPEN

O E D I V

Disc tray

D V D

D D H

PULL - OPEN

VIDEO

S-VIDEO VIDEO

● Pressing the button again closes the disc tray.

● Use the buttons to open and close the disc tray.

● Do not block the disc tray with your hand while it is opening or closing

as this may result in hardware failure.

● Do not place unplayable discs or any object other than a disc on the disc tray.

● Do not press down strongly on the disc tray or place any heavy objects on it.

Discs without cartridges

Place the disc on the disc tray with the label side facing up. Since disc size changes depending on the disc to be played back, be sure to correctly align the disc with the grooves for its size. If the disc is not in its groove, it may be scratched or otherwise damaged. To insert an 8 cm disc, place it according to the inner groove.

DVD-RAM discs contained in cartridges

Double-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the side you wish to play back or record facing down. If you insert the disc with “Side A” facing down, programmes are recorded on the side A.

Single-sided discs:

Remove the disc from the cartridge. Align the disc with the grooves on the disc tray as shown in the illustration and insert with the label side facing up.

Care And Handling Of Discs

How to handle discs

When handling a disc, do not touch the surface of the disc. Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the unit to malfunction.

Label side

Do not damage the label side, stick paper to or use any adhesives on its surface.

Recording side

Make sure that discs are not scratched and dirty on the recording side before use. Scratches and dirt on the recording side of a disc may hinder proper playback and recording. Also be careful that a DVD-RAM disc may get scratched or dirt when removed from cartridge then put back in after use.

Storage

Make sure that discs are kept in their cases. If discs are piled on top of one another without their protective cases, they can be damaged. Do not put discs in a location where they may be exposed to direct sunlight, or in a place where the humidity or temperature is high. Avoid leaving discs in your car!

DISC INFORMATION

EN 9

Maintenance of discs

If there are fingerprints or other dirt adhering to a disc, wipe with a soft dry cloth, moving from the centre outwards. If a disc is difficult to clean, wipe with a cloth moistened with water. Never use record cleaners, petrol, alcohol or any anti-static agents.

CAUTION:

Sometimes during playback, noise may appear or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the unit.

10 EN

INDEX

Front View

STANDBY ON

C D FE G H I JBA

HDD DVD

VIDEO

S-VIDEO VIDEO

L(MONO)-AUDIO-R

DV IN

A Infrared Beam Receiving Window B Front Display Panel C Disc Tray D Open/Close Button (x) E Stop Button (8) F Play Button (4) G Pause Button (9) H Record Button (7) I HDD Button J DVD Button

墌 pg. 25

墌 pg. 12

墌 pg. 8 墌 pg. 25, 40 墌 pg. 25, 40

墌 pg. 25, 40

墌 pg. 35, 38

墌 pg. 38

M POLLN

K Standby/On Button (1) L Video Lamp (VIDEO) M S-Video/Video/Audio Input Connectors (S-VIDEO/

VIDEO/AUDIO (L/R))

N DV Input connector (DV IN (i*))

* i (i.Link) refers to the IEEE1394-1995 industry specification and

extensions thereof. The i logo is used for products compliant with the i.Link standard.

O HDD Lamp 墌 pg. 38 P DVD Lamp

To access covered connectors, pull and open the connector cover.

墌 pg. 25

墌 pg. 36, 39

墌 pg. 59

墌 pg. 58

L(MONO)-AUDIO-R

HDD DVD

DV IN

PULL - OPEN

Rear View

INDEX

EN 11

AEFCDBGH

JK LI

A Antenna Connectors (ANTENNA IN/OUT) 墌 pg. 17 B Component Video Output Connectors (COMPONENT

VIDEO OUT) 墌 pg. 17

C S-video Output Connector (S-VIDEO OUT)

墌 pg. 17, 60

D Audio Output Connectors (AUDIO OUT (RIGHT/LEFT))

墌 pg. 60

E AV COMPU LINK Connector*

* Not function with this unit.

F Digital Audio Output Connectors

(DIGITAL OUT (COAXIAL/OPTICAL))

墌 pg. 62, 66

G Cooling Fan

● This prevents the temperature from rising inside the unit. Do not remove it.

● Install the unit so as not to block the area around the fan.

● The cooling fan on the rear of the unit may be activated even if

the unit is turned off in the following cases;

— In the Automatic Satellite Programme Recording standby

mode (墌 pg. 48), slightly before the starting time of VPS/PDC recording (墌 pg. 45)

— If you connect the decoder or the satellite receiver to L-2 IN/

DECODER and if “L-2 SELECT” is set to “DECODER” or “SAT VIDEO” or “SAT S-VIDEO”. (墌 pg. 61)

— when “JUST CLOCK” is set to “ON” (墌 pg. 73)

(Set “JUST CLOCK” to “OFF” if you mind the noise of the fan.)

H Mains Power Cord 墌 pg. 17 I L-1 Input/Output Connector (L-1 IN/OUT)

墌 pg. 17, 60,

61, 65, 66

J L-2 Input/Decoder Connector

(L-2 IN/DECODER)

墌 pg. 23, 60, 65, 66

K Satellite Control Connector (SAT CONTROL) L Region Number Label

墌 pg. 6

墌 pg. 23

12 EN

INDEX

Front Display Panel

ABDCGFEIHJ

A VPS/PDC Indicator 墌 pg. 45

Appears when checking if the station being received transmits a VPS/PDC signal.

Disc Type Indicator

When a disc is loaded, the type of the disc is indicated.

Disc Status Indicator

When a disc is running, the disc marks rotate. During High-Speed Search: Rotate faster than normal playback. During Slow Motion: Rotate slower than normal playback. While recording: Inner red ring lights in the same way

While paused: Disc marks blink when either

While stopped: Disc marks all light. While resume stopped: Disc marks all blink. While the disc tray opened: Disc marks all light out. No disc on the disc tray: Disc marks all light out.

B VR Mode Indicator 墌 pg. 74

Lights when a DVD-RW disc is formatted in VR mode.

C Recording Mode Indicator (XP/SP/LP/EP/FR) 墌 pg. 35

Blinks when recording mode is being set. While “FR” is blinking, the left 3 digits of the Multi Display (L M) indicate setting values ranging from “60” to “480”. After the value has been set, only “FR” lights.

D VPS/PDC Recording Indicator 墌 pg. 45

Lights when the VPS/PDC recording function is activated.

E Group/Title Indicator (GRP/TITLE)

“GRP” or “TITLE” lights depending on a disc loaded while the left 2 digits of the Multi Display (L) indicate the numbers explained below. “GRP”: Total number of groups or group number being played

back are displayed on the Multi Display.

“TITLE”: Total number of titles or title number being played back

are displayed on the Multi Display.

F Track/Chapter Indicator (TRK/CHAP)

“TRK” or “CHAP” lights depending on a disc loaded while the 3rd and 4th digits from the left of the Multi Display (M) indicate the numbers explained below. “TRK”: Total number of tracks or track number being played

back are displayed on the Multi Display.

“CHAP”: Chapter number being played back are displayed on the

Multi Display.

as normal playback. During Instant Timer Recording (ITR), inner red ring slowly blinks.

recording or playing back.

NMLKOP

G Simulated Surround Effect Indicator (3D) 墌 pg. 32

Lights when a simulated surround effect is set to “3D-ON” on the on-screen bar.

H Linear PCM Indicator (LPCM)

Lights when “XP MODE REC AUDIO” is set to “LINEAR PCM” (

墌 pg. 68) for recording with HDD, DVD-RAM, DVD-R and

DVD-RW discs, and when Linear PCM audio is played.

I Random/Programme Playback Mode Indicator (RND/

PRGM)

“RND”: Lights when Random Playback mode is set. “PRGM”: Lights when Programme Playback mode is set.

J Repeat Mode Indicator ( /1/A–B) 墌 pg. 31

Select Repeat Playback mode on the on-screen bar. “ ”: Whole disc is played back repeatedly.

“ 1”: A single title/chapter/track is played back repeatedly. “ A–B”: The selected part (A–B) is played back repeatedly. No display: Repeat Playback mode is off.

K Video Output Indicator ( ) 墌 pg. 69

No display:Indicates that interlace mode is engaged.

(Example) lights when video output mode is in progressive mode.

L Group/Title Number Display M Track/Chapter Number Display N Remaining Time/Elapsed Time Indicator 墌 pg. 28, 36

Lights when remaining time of DVD-RAM, DVD-R and DVD-RW discs is displayed, and lights out when elapsed time is displayed. The right 6 digits of the Multi Display (O) indicate elapsed or remaining time of each track. No display: Indicates elapsed time of the disc. Displayed: Indicates remaining time of the disc.

O Remaining Time/Elapsed Time Display 墌 pg. 28, 36 P Multi Display

Displays clock, received channel, elapsed time, and remaining time. Also displays status of the unit (NO DISC/OPEN/CLOSE/ READING).

墌 pg. 33

: Indicates that progressive mode is engaged.

Remote Control

CABLE/SAT

DVDTV

A B

OPEN/ CLOSE

HDD DVD

TV AV

VIDEO

TV/CBL/SAT

STANDBY ON

DVD

CANCEL

AUX

MEMO/MARK

F G

H I

LIVE

NAVIGATIONTOP MENU

ENTER

RETURN

PROGRAMME

EDIT

DUBBING

K L

NEXTPREVIOUS

SLOWSLOW PLAY/SELECT

CLEAR

PAUSEREC

STOP/

JUMP

REC MODE

DISPLAY

ON SCREEN

HELP

P Q

SAT SET UP

AUDIO

VPS/PDC

SUBTITLE

ANGLE

LIVE CHECK

PROGRESSIVE

SCAN

R S T

A Open/Close Button (x) 墌 pg. 8 B TV AV/VIDEO Button C HDD Button D Number Keys

墌 pg. 38

墌 pg. 23, 35, 38

E Auxiliary Button (AUX) F Cancel Button (& (CANCEL)) G Live Button (LIVE) H Dubbing Button (DUBBING)

TV Muting Button (TV )

I Top Menu Button (TOP MENU) J rt w e Buttons K Menu Button (MENU) L Reverse Skip Button (2)

Previous Button (PREVIOUS)

M Reverse Search Button (3)

Reverse Slow Button (SLOW –)

N Record Button (7) O Jump Button (JUMP +/–) P Recording Mode Button (REC MODE) Q Display Button (DISPLAY) R Automatic Satellite Programme Recording Button

(SAT#) 墌 pg. 48

墌 pg. 36, 39

墌 pg. 46, 70

墌 pg. 44

墌 pg. 42

墌 pg. 56

墌 pg. 63

墌 pg. 26

墌 pg. 21

墌 pg. 26

墌 pg. 26, 42, 43

墌 pg. 29

墌 pg. 26, 42

墌 pg. 27

墌 pg. 35, 38

墌 pg. 43

墌 pg. 28, 36

V W X Y

a b c d e

f g

h i j k l m n o

p q

r s

墌 pg. 35, 38

INDEX

EN 13

S VPS/PDC Recording Button (VPS/PDC#) T Audio Button (AUDIO) U Subtitle Button (SUBTITLE) V TV/CABLE/SAT/DVD switch

墌 pg. 29

墌 pg. 28 墌 pg. 21

墌 pg. 45

W DVD Standby/On Button (DVD 1) X TV/CBL/SAT Standby/On Button (TV/CBL/SAT 1)

墌 pg. 63

Y DVD Button Z TV Volume Buttons (TV%+/–) a Programme Buttons (PR +/–) b Memo Button (MEMO)

Mark Button (MARK)

c Programming Button (PROGRAMME) d Edit Button (EDIT) e Navigation Button (NAVIGATION) f Enter Button (ENTER) g Return Button (RETURN) h Forward Skip Button (6)

Next Button (NEXT)

i Forward Search Button (5)

Forward Slow Button (SLOW +)

j Play Button (4)

Select Button (SELECT)

k Pause Button (9) l Stop Button (8)

Clear Button (CLEAR)

m Skip Search Button ( ) n Help Button (?) o One Touch Replay Button ( ) p On-Screen Button (ON SCREEN) q Set Up Button (SET UP)

墌 pg. 25

墌 pg. 63

墌 pg. 35, 63

墌 pg. 50, 53

墌 pg. 27

墌 pg. 44, 46, 47

墌 pg. 50

墌 pg. 49

墌 pg. 21

墌 pg. 29, 44

墌 pg. 26, 42, 43

墌 pg. 29

墌 pg. 26, 42

墌 pg. 27

墌 pg. 25, 40

墌 pg. 25, 50

墌 pg. 25, 40

墌 pg. 31, 44

墌 pg. 27, 42

墌 pg. 76

墌 pg. 42

墌 pg. 14, 30

墌 pg. 21

r Progressive Scan Button (PROGRESSIVE SCAN)

墌 pg. 69

s Angle Button (ANGLE) (DVD deck only)

Live Check Button (LIVE CHECK)

How To Use

Before use, insert two R6 size batteries into the remote control with the polarity ( and ) matched correctly as indicated on the battery compartment or on the lid.

The remote control can operate most of your unit’s functions, as well as basic functions of TV sets and satellite receivers of JVC and other brands. (墌 pg. 63, 64)

● Point the remote control toward the receiving window.

● The maximum operating distance of the remote control is about

8m.

NOTE:

If the remote control doesn’t work properly, remove its batteries, wait a short time, replace the batteries and then try again.

墌 pg. 28

墌 pg. 42

14 EN

INDEX

On-Screen Display (DVD deck)

When “SUPERIMPOSE” is set to “AUTO” and ON SCREEN on the remote control is pressed, various operational indicators appear on the TV screen. To clear the operational indicators, press ON SCREEN twice.

When playing back a recorded title

TITLE99 CHAPTER999 T. REMAIN6:59:59

FISHING WORLD

A Playback title number B Playback chapter number C Disc remaining time D Current status (playback) E Audio mode F Current received (recording) channel position number

(On playback background)

G Bar meter H Name of title (or play list) currently being played back I Current playback point J Recorded mode K Live Memory mode (recording)

When recording

Digital

1212

When pressing REC MODE

(Appears for eight seconds.)

RAM

FR360

7: 00 XP 10: 00 SP 20: 00 LP 28: 00

36: 00

FR480

A Disc type B Current recording speed C Remaining disc time for each recording speed D Recording speed

When pressing 7 during recording

ITR 2 : 30

A Recording time for Instant Timer Recording (ITR) mode

TITLE99 CHAPTER999 T. REMAIN6:59:59

RAM

FR360

A Recording point B Current status (recording) C Current time D Recording channel number

11:35

On-Screen Display (HDD deck)

When playing back a recorded title

When recording

11:00 12:00 1:00

FR360

A Live Memory Recording point B Live Memory Recording mode

11:35

11:33

INDEX

EN 15

STEREO

0:00 1:00 2:00

004 FISHING WORLD

FR360

01:16:48

FR360

Digital

STEREO

A Title start B Current playback point C Title end D Elapsed playing time E Play mode F Current received (recording) channel position number

(On playback background)

G Recorded title (or play list) number currently being played back H Name of title currently being played back I Time scale (This title is an hour and a half long.) J Audio mode K Live Memory mode (recording)

When watching a programme on air

11:00 12:00 1:00

11:35

STEREO

ON AIR

A Possible start point from where Live Memory Playback can be

performed

B Possible start point from where Live Memory Recording can be

performed (Received channel has changed at this point.)

C Currently viewed point D Time scale E Current time F Current received channel position number

When pressing REC MODE

(Appears for eight seconds.)

FR360

7: 00 XP 10: 00 SP 20: 00 LP 28: 00

36: 00

FR480

A HDD capacity graph B Current recording speed C Remaining HDD time for each recording speed D Recording speed

When pressing 7 during recording

ITR 2 : 30

A Recording time for Instant Timer Recording (ITR) mode

When using Live Memory playback

11:00 12:00 1:00

A Time scale for Temporary Recording B Current Temporary Recording point C Current time D Current playback channel position number E Time scale for Live Memory Playback F Current playback point G Live Memory playback mode H Current playback time

11:35

STEREO

16 EN

INDEX

On-Screen Display (DV Dubbing)

When capturing images from the external DV equipment

FR360

12bit

0:00 1:00 2:00

HDD

00: 00:00. 00

JVC

GR-DV3500DV

GR-DV3500

00: 00:00. 00

L - R

SOUND1

A Recording speed B HDD capacity graph C HDD time counter D Recording time scale E HDD mode F Remote control mode G Connected DV equipment mode H Connected DV equipment model information I Input channel J Sound mode K Sound input bit-rate*

* Indicates the sound bit-rate of the connected DV equipment

L Connected DV equipment information*

* Maker name and model name, etc. may not appear depending on the

connected equipment.

M Time counter for the connected DV equipment N Sound monitor mode

DV DV

1 2

O Remote control switch P Auto capture button Q Sound monitor switch

179 :59 :59

R Elapsed recording time

Basic Connections

TV aerial cable

ANTENNA IN

COMPONENT VIDEO OUT

S-VIDEO OUT

ANTENNA

OUT

RF cable (provided)

Component video cable (not provided)

L-1 IN/OUT

21-pin SCART

cable

(provided)

AUDIO OUT

Audio cable

(not provided)

Mains outlet

Mains power cord

Back of unit

S-Video cable (not provided)

INSTALLING YOUR NEW UNIT

EN 17

8 Basic Connection To connect to a TV with 21-pin SCART input connector —

A Disconnect the TV aerial cable from the TV. B Connect the TV aerial cable to the ANTENNA IN connector on

the rear panel of the unit.

C Connect the ANTENNA OUT connector on the rear panel of the

unit and the TV’s aerial connector with the provided RF cable.

D Connect the L-1 IN/OUT connector on the rear panel of the unit

and the TV’s 21-pin SCART connector with a provided 21-pin SCART cable.

● The L-1 IN/OUT connector accepts and delivers either a composite signal (regular video signal), Y/C signal or RGB signal.

● Set your TV to the VIDEO (or AV), Y/C, or RGB mode according to the type of your TV’s SCART connector.

8 S-Video Connection To connect to TV’s S-VIDEO input and AUDIO input connectors —

A Perfor m A – C in “Basic Connection”. B Connect the unit’s S-VIDEO OUT connector to the TV’s

S-VIDEO input connector.

C Connect the unit’s AUDIO OUT connectors to the TV’s AUDIO

input connectors.

● You can obtain high-quality S-VHS pictures.

● With S-VIDEO connection, you cannot use the Preset Download

function. (

● If your TV is not stereo-capable, use the unit’s AUDIO OUT connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

墌 pg. 19)

8 Component Video Connection To connect to TV’s component video input connectors —

A Perfor m A – C in “Basic Connection”. B Connect the unit’s COMPONENT VIDEO OUT connectors to

the TV’s component video input connectors.

C Connect the unit’s AUDIO OUT connectors to the TV’s AUDIO

input connectors.

● You can obtain high-quality component video pictures.

● If your TV is not stereo-capable, use the unit’s AUDIO OUT

connectors to connect to an audio amplifier for Hi-Fi stereo sound reproduction.

● By using the component video connection, you can view the images in the progressive mode. For switching to the progressive mode, refer to “Scan Mode Set” (墌 pg. 69).

NOTE:

Select an appropriate option of “L-1 OUTPUT” as follows (墌 pg. 61):

It’s essential that your unit be properly connected.

TTENTION:

Your TV must have a 21-pin AV input connector (SCART) for the basic connection to the unit.

THESE STEPS MUST BE COMPLETED BEFORE ANY VIDEO OPERATION CAN BE PERFORMED.

1 Make sure the package contains all of the accessories listed in

“SPECIFICATIONS” on page 81.

2 Place the unit on a stable, horizontal surface. 3 Connect the unit to a TV depending on the TV and cables you

use.

When your TV’s SCART connector accepts:

Set “L-1 OUTPUT” to:

Composite signals “SCART VIDEO” Y/C signal (separated

luminance (brightness) and

“SCART S-VIDEO”

chrominance (colour) signals) RGB signal “SCART RGB” Component video signal “COMPONENT”

4 Plug the end of the mains power cord into a mains outlet.

● “LOADING” blinks on the front display panel when the AC plug of the mains power cord is connected into a mains outlet and it takes approximately 50 seconds for the unit to be turned on. This is not a malfunction.

18 EN

INITIAL SETTINGS

Auto Set Up

Auto Channel Set/Auto Clock Set/Auto Guide Program Number Set

After the 1 button on the unit (or DVD 1 on the remote control) is pressed for the first time to turn on the unit selecting your country*, the Auto Set Up function sets the tuner channels, clock** and Guide Program numbers automatically.

* If you live in Belgium (BELGIUM) or Switzerland (SUISSE), you also

need to select your language.

** If you live in Hungary (MAGYARORSZÁG), Czech Republic (ČESKÁ

REPUBLIKA), Poland (POLSKA) or other countries in Eastern Europe (OTHER EASTERN), set the clock manually.

DVD 1

ENTER

rtwe

Before starting, make sure of the following:

● The TV aerial cable should be connected to the unit.

● The unit’s mains power cord should be connected to a mains

outlet.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

, by simply

CABLE/SAT

DVDTV

3 Press rt w e to select the

language of your choice, then press ENTER. The AUTO SET/ T-V LINK display appears on the TV screen.

4 Press we to select “AUTO

SET”, then press ENTER. The AUTO SET screen will appear.

TTENTION:

“AUTO” blinks on the front display panel; do NOT press any button on

INITIAL SET UP > LANGUAGE SELECT

ENGLISH

ITALIANO

SVENSKA

DANSK

ENTER

SET UP

EXIT

SELECT

INITIAL SET UP > AUTO CH SET

AUTO SET T-V LINK

ENTER

SET UP

EXIT

SELECT

INITIAL SET UP > AUTO SET

DEUTSCH

FRANCAIS

CASTELLANO

NEDERLANDS

NORSK

SUOMI

RETURN

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

the unit or remote control until the front display panel shows “– –:––” as illustrated on page 20.

● When you have connected the unit to a TV offering T-V Link via a fully-wired 21-pin SCART cable (墌 pg. 17) and the TV is turned

SET UP

EXIT

AUTO SET

PLEASE WAIT...

CANCEL

ENTER

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

SELECT

on, the unit automatically performs the Preset Download (墌 pg. 19) even if you select “AUTO SET” for Auto Set Up function.

TTENTION:

Once you have performed Auto Set Up, even if the unit’s memory backup has expired, all the stored stations and their Guide Program numbers remain in the unit’s memory and the unit will not perform Auto Set Up again. The unit only performs Auto Clock Set when the unit is turned on. If you have moved to a different area, perform each setting as required.

● Tuner setting (墌 pg. 70)

● Clock setting (墌 pg. 73)

If a new station starts broadcasting in your area, perform tuner setting. (墌 pg. 70)

NOTES:

● In areas where no TV station transmits a PDC (Programme Delivery Control) signal, the unit can perform neither Auto Clock Set nor Auto Guide Program Number Set.

● If there is a power cut, or if you press 1 or SET UP while Auto Set Up is in progress, Auto Set Up will be interrupted; be sure to turn off the unit power once and try again from step 1.

● Auto Clock Set may not function properly depending on the reception condition.

● If no sound accompanies the picture or the audio sounds unnatural on some channels that have been stored by Auto Set Up, the TV system setting for those channels may be incorrect. Select the appropriate TV system for those channels. (墌 pg. 72, “INFORMATION”)

After “Auto Set Up” is completed, perform “Monitor Set” on page 22.

1 Press 1 on the unit or DVD 1 on the remote control to turn on

the unit. The Country Set display appears on the TV screen.

2 Press rt w e to select your

country’s name, then press ENTER. The Language Set display appears on the TV screen.

NOTES:

● If you have selected BELGIUM or SUISSE, go to step 3.

● If you have selected MAGYARORSZÁG, ČESKÁ REPUBLIKA, POLSKA or OTHER EASTERN, press ENTER. The Clock Set screen appears. Set the clock manually ( go to step 4.

● If you have selected any other country name, go to step 4.

INITIAL SET UP > AREA SELECT

BELGIUM

DEUTSCHLAND

ITALIA

NORGE

PORTUGAL

SVERIGE

ENTER

SET UP

EXIT

SELECT

DANMARK

CESKA

GREECE

ESPANA

NEDERLAND

MAGYARORSZAG

POLSKA

OSTERREICH

SUISEE

SUOMI

OTHER WESTERN

OTHER EASTERN

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

墌 pg. 73), then

RETURN

Preset Download

Auto Channel Set by Downloading from TV/Auto Clock Set/Auto Guide Program Number Set

TTENTION:

You can use this function only with a TV offering T-V Link, etc.* Be sure to use a fully-wired 21-pin SCART cable.

* Compatible with TVs offering T-V Link, EasyLink, Megalogic,

SMARTLINK, Q-Link or DATA LOGIC via a fully-wired 21-pin SCART cable. The degree of compatibility and available functions may differ by system.

CABLE/SAT

DVDTV

ENTER

INITIAL SETTINGS

EN 19

If you have connected the unit to your TV via a 21-pin SCART cable (墌 pg. 17), the unit will automatically perform Preset Download instead of the Auto Set Up in step 4 on page 18. After downloading, the unit sets the clock and Guide Program numbers automatically.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

● Perform steps 1 to 3 of “Auto Set Up” (墌 pg. 18) before continuing.

1 Press we to select “T-V LINK”

and press ENTER. The T-V LINK screen will appear.

TTENTION:

INITIAL SET UP > AUTO CH SET

AUTO SET T-V LINK

Preset positions on the front display panel increase from “PR 1”; do NOT press any button on the unit or remote control until the front display panel

SET UP

ENTER

EXIT

SELECT

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

shows clock time, “PR 1” or “– –:––” as illustrated on page 20.

● When Preset Download is completed, “COMPLETED”

INITIAL SET UP > AUTO SET

appears for about 5 seconds, then the normal screen appears.

● If you press any button on the unit or remote control while downloading is in progress, it will be interrupted.

SET UP

EXIT

AUTO SET

PLEASE WAIT...

CANCEL

ENTER

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

SELECT

NOTES:

● For details, refer to the instruction manual of your TV.

● In the area where no TV station transmits a PDC (Programme

Delivery Control) signal, the unit can perform neither Auto Clock Set nor Auto Guide Program Number Set.

● If there is a power cut, or if you press 1 or SET UP while downloading or set up is in progress, it will be interrupted; be sure to turn off the unit power once and try again from the beginning.

● Auto Clock Set may not function properly depending on the reception condition.

● On this unit, the characters available for station names (ID) are A–Z, 0–9, –, f, + and I (space). Some names of downloaded stations may differ from those of your TV. (墌 pg. 72)

After “Preset Download” is completed, perform “Monitor Set” on page 22.

20 EN

INITIAL SETTINGS

Results Of Auto Set Up/Preset Download Appearing On The Front Display Panel

If both Auto Channel Set and Auto Clock Set have been performed successfully, the correct current time is displayed.

Turn on the TV and select its AV mode, then make sure that all necessary stations have been stored in the unit’s memory by using the PR +/– button(s).

● If station names (ID – 墌 pg. 85) have also been stored in the unit’s memory, the station name will be displayed at the top right corner of the TV screen for about 5 seconds when the unit is tuned to a different station.

● If you want to set the tuner manually such as to add or skip channels, to change channel positions, or to set or change station names, see pages 71 – 72.

If Auto Channel Set has succeeded but Auto Clock Set has not, “PR 1” (channel position) is displayed. OR If both Auto Channel Set and Auto Clock Set have failed, “– –:––” is displayed.

A Turn on the TV and select its AV mode, then make sure that all

necessary stations have been stored in the unit’s memory by using the PR +/– button(s).

● If you want to set the tuner manually such as to add or skip channels, to change channel positions, or to set or change station names, see pages 71 – 72.

B Perfor m “Clock Set” on page 73.

TTENTION:

After making sure the cables are connected properly, turn off the unit’s power once, then turn the unit’s power back on again. The Country Set display appears on the TV screen; perform “Auto Set Up” on page 18 or “Preset Download” on page 19 again.

IMPORTANT:

● To check if the Guide Program numbers have been set correctly, perform the SHOWVIEW Timer Programming. (墌 pg. 44)

● In certain reception conditions, station names may not be stored correctly, and auto Guide Program Number Set may not work properly. If the Guide Program numbers are not set properly when you timer-record a TV programme using the SHOWVIEW system, the unit will record a TV programme of a different station. When programming the timer using the S check the desired channel is selected correctly. ( “SHOWVIEWTM Timer Programming”)

● Your unit memorizes all detected stations even if reception of some of them is poor. You can delete those stations with an unacceptable picture. (墌 pg. 72, “Delete A Channel”)

HOWVIEW system, be sure to

墌 pg. 44,

INFORMATION

Language for the on-screen display

Auto Set Up also selects the language automatically for the onscreen display depending on the Country setting you have made in step 2 on page 18 (unless you have selected BELGIUM or SUISSE), as shown below.

SUOMI PORTUGAL DEUTSCHLAND POLSKA NORGE SVERIGE DANMARK ÖSTERREICH

ESKÁ REPUBLIKA]ENGLISH

]

SUOMI ITALIA

]

ENGLISH MAGYARORSZÁG]ENGLISH

]

DEUTSCH ESPAÑA

]

ENGLISH NEDERLAND

]

NORSK GREECE

]

SVENSKA

]

DANSK

]

DEUTSCH

OTHER WESTERN

OTHER EASTERN

]

] ] ]

]

ITALIANO

CASTELLANO NEDERLANDS ENGLISH

ENGLISH

If you want to change the language setting manually, see “On- screen Language Set” on page 21.

Just Clock

Your unit is equipped with the Just Clock function which provides accurate time keeping through automatic adjustments at regular intervals, by reading data from a PDC signal. If you want to take advantage of this function, simply set it to “ON”. (墌 pg. 73)

T-V Link Functions

When you connect the unit to your TV via a fully-wired 21-pin SCART cable (墌 pg. 17), the following functions are available. You can use these functions only with a TV offering T-V Link, etc.* For details, refer to the instruction manual of your TV.

* Compatible with TVs offering T-V Link, EasyLink, Megalogic,

SMARTLINK, Q-Link or DATA LOGIC via a fully-wired 21-pin SCART cable. The degree of compatibility and available functions may differ by system.

TV Auto Power On

The TV will turn on and be set to its AV mode automatically whenever you start playback. For details, refer to the instruction manual of your TV.

Unit Auto Standby

You can use your TV’s remote control to turn off the unit. For details, refer to the instruction manual of your TV.

Direct Rec

You can easily start recording the programme that you are watching on your TV. When you use this function, set “DIRECT REC” to “ON”. (墌 pg. 68)

INITIAL SETTINGS

EN 21

Language

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

ENTER

rtwe

SET UP

CABLE/SAT

On-screen Language Set

This unit offers you the choice to view on-screen messages in 10 different languages.

1 Press SET UP to access the Main Menu screen. 2 Press we to select “FUNCTION SET UP”, then press t. 3 Press we to select “DISPLAY

DVDTV

SET”, then press t.

4 Press rt to select “ON

SCREEN LANGUAGE”, then press ENTER.

5 Press rt to select your

desired language, then press ENTER.

DVD VIDEO SET UP INITIAL SET UPHDD/DVD SET UP

SUPERIMPOSE

BLUE BACK

DIMMER BRIGHT

POWER SAVE OFF

ON SCREEN LANGUAGE ENGLISH

ENTER

SET UP

EXIT

SELECT

FUNCTION SET UP

DISPLAY SETREC/PLAY SET UP VIDEO IN/OUT

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

AUTO

6 Press SET UP to complete the setting.

Menu/Audio/Subtitle Language Set (DVD deck only)

Some DVD discs contain the DVD menu display, audio and subtitles in multiple languages. With these discs, you can set the default language as you like.

● The procedure shows how to set “MENU LANGUAGE” as an example.

1 Press SET UP to access the Main Menu screen. 2 Press we to select “DVD VIDEO SET UP”, then press t. 3 Press we to select

“LANGUAGE SET”, then press t.

4 Press rt to select “MENU

LANGUAGE”, then press ENTER.

5 Press rt to select your

desired language, then press ENTER.

● See “Language Code List” (墌 pg. 82).

6 Press SET UP to complete the setting.

NOTE:

When the selected language is not available on the disc, the disc’s default menu language is played back.

DVD VIDEO SET UP INITIAL SET UPHDD/DVD SET UP

LANGUAGE SET

MENU LANGUAGE

AUDIO LANGUAGE

SUBTITLE ENGLISH

ENTER

SET UP

EXIT

SELECT

FUNCTION SET UP

AUDIO OUTPUT

PARENTAL LOCK DISC SET UP

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

ENGLISH

22 EN

INITIAL SETTINGS

Monitor Set

You can select the monitor type depending on the TV used when you play back DVD VIDEO discs recorded for wide-screen TVs.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

CABLE/SAT

DVDTV

ENTER

rtwe

SET UP

1 Press SET UP to access the Main Menu screen.

● You cannot set the monitor type during recording or playback.

2 Press we to select “FUNCTION SET UP”, then press t. 3 Press we to select “VIDEO IN/

OUT”, then press t.

4 Press rt to select “MONITOR

TYPE”, then press ENTER.

5 Press rt to select the desired

option, then press ENTER.

6 Press SET UP to complete the

setting.

*The boldface settings below indicate the settings at your

purchase.

8 MONITOR TYPE — 4:3LB / 4:3PS / 16:9 AUTO / 16:9 FIX

4:3LB (Letter Box conversion): Select this when the aspect ratio of

your TV is 4:3 (conventional TV). While viewing a wide screen picture, the black bars appear on the top and the bottom of the screen.

4:3PS (Pan&Scan): Select this when the aspect ratio of your TV is

4:3 (conventional TV). While viewing a wide screen picture, the black bars do not appear; however, the left and right edges of the pictures will not be shown on the screen.

16:9 AUTO (Wide television conversion): Select this when the

aspect ratio of your TV is 16:9 (wide TV).

16:9 FIX (Wide television conversion): Select this when the aspect

ratio of your TV is fixed to 16:9 (wide TV). The unit automatically adjusts the screen width of the output signal correctly when playing back a picture whose aspect ratio is 4:3.

DVD VIDEO SET UP INITIAL SET UPHDD/DVD SET UP

MONITOR TYPE

F-1 INPUT

L-1 OUTPUT SCART VIDEO

L-2 INPUT VIDEO

L-2 SELECT VIDEO

ENTER

SET UP

EXIT

SELECT

FUNCTION SET UP

DISPLAY SETREC/PLAY SETUP VIDEO IN/OUT

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

4:3LB

VIDEO

Pan&Scan/Letter Box

In general, DVD VIDEO disc are produced for a wide-screen TV with 16:9 aspect ratio. Material with this ratio will not fit to a TV with 4:3 aspect ratio. There are two styles to display the image, “Pan&Scan” (PS) and “Letter Box” (LB).

Pan&Scan

The right and left side of the image are cut off. The image fills the screen.

● The picture will be shown in the “4:3LB” mode depending on the disc even if the “4:3PS” mode is selected.

Letter Box

Black bands appear at the top and bottom of the image. The image itself appears in 16:9 aspect ratio.

Satellite Receiver Control Setting

Satellite receiver

Satellite Controller

Your unit

Tr an s m it t e r

Satellite receiver

(provided) (suggested locations)

Satellite Controller

(provided)

SAT CONTROL SET

EN 23

The following procedure is required if you receive satellite channels through a satellite receiver. Approximately 20 seconds before the S

HOWVIEW timer programming (墌 pg. 44) or Manual Timer

programming (墌 pg. 46) starts, the unit sets its input mode to “L-2” and automatically switches the satellite receiver’s channels using the provided Satellite Controller.

Installing Satellite Controller

1 Place the Satellite Controller so that the path between its

transmitter and the satellite receiver’s remote sensor is unobstructed.

2 Fix securely using the adhesive strip attached on the back of the

Satellite Controller.

3 Be sure to connect the unit’s L-2 IN/DECODER connector to the

satellite receiver’s 21-pin SCART connector.

NOTE:

When connecting your satellite receiver, refer to its instruction manual.

4 Connect the Satellite Controller to the SAT CONTROL

connector on the rear panel.

Setting Satellite Receiver’s Brand And Channel

After installation, set the satellite receiver’s brand and channel correctly; otherwise, the Satellite Controller cannot work correctly.

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

Back of unit

21-pin SCART cable (provided)

ENTER

1 Turn on the satellite receiver’s power. 2 Press SET UP to access the Main Menu screen. 3 Press we to select “INITIAL SET UP”, then press t. 4 Press we to select “TUNER

SET”, then press t.

5 Press rt w e to select “SAT

CONTROL SET”, then press ENTER.

6 Press rt to select “BRAND”,

then press ENTER.

DVD VIDEO SET UP INITIAL SET UPFUNCTION SET UPHDD/DVD SET UP

SET UP

TUNER SET

EXIT

ENTER

SELECT

CLOCK SET

AUTO CH SET

SAT CONTROL SET

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

MANUAL CH SET

GUIDE PROG SET

7 Press rt to select the brand

code from the list on page 24, then press ENTER.

● If the unit is in playback or recording mode, you cannot set the brand code.

8 Press rt to select “PROGRAMME”, then press ENTER.

SAT CONTROLL-2 IN/DECODER

CABLE/SAT

DVDTV

rtwe

9 Press rt to select one of the channel positions on the satellite

receiver, then press ENTER.

● You can select the channel position between 1 to 999.

10 Press rt to select “TEST”,

then press ENTER. The unit enters the Test mode.

INITIAL SET UP > SAT CONTROL SET

BRAND

PROGRAMME

ENTER

SET UP

EXIT

SELECT

TEST

SELECT WITH [ ] THEN PRESS [ENTER] PRESS [SET UP] TO EXIT

SET UP

24 EN

SAT CONTROL SET

11 Check the result of the test.

If the satellite receiver’s channel number has been changed to the same one as you set in step 9

Press we to select “YES”, then press ENTER to finish the Sat Control Set mode.

If the satellite receiver’s channel number has not been changed correctly

Press we to select “NO”, then press ENTER. Then perform the procedure again from step 6.

BRAND NAME CODE

JVC AMSTRAD ASTON CANAL SATELLITE CANAL + D-BOX ECHOSTAR (VIA DIGITAL) FINLUX FORCE GALAXIS GRUNDIG HIRSCHMANN HUMAX ITT NOKIA JERROLD KATHREIN LUXOR MASCOM MASPRO NOKIA PA CE PANASONIC PHILIPS RADIX RFT SABA SAGEM SALORA SAMSUNG SIEMENS SKYMASTER TECHNISAT THOMSON TPS TRIAX WISI

73 60, 61, 62, 63, 92 97 81 81 85 82 68 89 88 64, 65, 102 64, 78, 99 88 68 75 70, 71, 96 68 93 70 87, 94 65, 67, 74, 86, 92, 97 74, 92 66, 84, 101 78 69 97 83, 90 68 83 64 69, 98 66, 100 97 83 91 64

NOTES:

● The Satellite Controller may not work with all types of satellite receiver.

● For some satellite receivers, you need to set its channel input mode to 2-digit.

● If your satellite receiver has more than two channel modes, be sure to set to “All Channel Mode”. For details, refer to the instruction manual of the satellite receiver.

● When selecting the satellite receiver’s channel ( from the remote control may interfere with signals transmitted from the Satellite Controller. In this case, move the remote control as close to the unit’s infrared beam receiving window as possible.

墌 step 9), signals

Basic Playback

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

ENTER

SELECT

DVD

CABLE/SAT

BASIC OPERATIONS ON DVD DECK

EN 25

To play back an MP3/JPEG disc, see “Playback With MP3/JPEG Navigation” (墌 pg. 55).

1 Load a disc.

● For details, refer to “Placing A Disc” (墌 pg. 8).

● Pressing 4 also closes the disc tray.

● Playback begins automatically if an auto-playback DVD disc is

loaded.

2 Press DVD so that the DVD lamp lights up on the unit. 3 Press 4 to start playback.

DVD

DVDTV

● If you load a DVD disc whose region code does not match the unit,

“REGION CODE ERROR” appears on the TV screen. For details, refer to “Region Number” (墌 pg. 6).

● If “CAN NOT PLAY BACK DISC UNDER CURRENT SETTING” appears on the TV screen, refer to “Parental Lock” (墌 pg. 34).

● With Video CD/SVCD discs with PBC control or some DVD discs, the menu display may appear on the TV screen after starting playback. In this case, select an item which you want to play back from the menu. Otherwise, the playback cannot go forward. Refer to “Playback Control (PBC) Function” (墌 pg. 29) or “Locating A Desired Scene Using The DVD Menu” (墌 pg. 26).

● The Library Database Navigation also enables you to search and select the desired titles. (墌 pg. 50)

4 Press 9 to pause playback.

● To resume normal playback, press 4.

5 Press 8 to stop playback.

● When a recordable disc is played, playback stops and a programme received with the unit’s tuner resumes on the TV screen.

● When a playback-only disc is played, playback stops and the still image at the time you press 8 remains on the TV screen. Pressing 8 again resumes a programme received with the unit’s tuner.

● If x is pressed during playback, playback stops, then the disc tray opens.

NOTE:

When the Library Database Navigation screen appears, choose a thumbnail image of the desired title on the TV screen, then press SELECT(4) or ENTER. (墌 pg. 50)

TTENTION:

● It takes approximately 30 seconds to read a disc depending on the type and condition of the disc since this unit is multi-disc compatible (DVD-RAM, DVD-RW, DVD-R). It may even take several minutes when a disc is dirty, scratched or warped.

● It may take a few seconds to start playback. This is not a malfunction.

● Forward/reverse high-speed search and other operations cannot be performed while playback is stopped.

26 EN

BASIC OPERATIONS ON DVD DECK

Playback Features

● Turn on the unit.

● Turn on the TV and select the AV mode.

● Slide the TV/CABLE/SAT/DVD switch to DVD.

● Press DVD so that the DVD lamp lights up on the unit.

CABLE/SAT

0-9

TOP MENU

ENTER

DVD

MARK

rtwe

5/SLOW + 3/SLOW 9

Locating The Start Point Of The Item Or Skip The Item

Press 2 or 6 during playback.

● Pressing 6 locates the start point of the item or skips the item for forward direction, then resumes playback.

● Pressing 2 locates the start point of the item or skips the item for

DVDTV

reverse direction, then resumes playback.

When a DVD-RAM/RW/R disc is played

Current programme

News

Reverse Forward

programme

●: marked points (墌 pg. 27)

Drama

programme

Movie

Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once. To locate the beginning of the previous item, press 2 three times.

When a DVD VIDEO, Audio CD or Video CD/SVCD disc is played

Playba ck point

Locating A Desired Scene Using The DVD Menu

DVD VIDEO/finalised DVD-R/-RW (Video mode) discs may have top menu and disc menu.

Top m e nu

DVD discs generally have their own menus which show the disc contents. These menus contain various items such as titles of a movie, names of songs, or artist information. You can locate a desired scene by using the top menu displayed on the TV screen. Press TOP MENU to access the top menu.

Disc menu

Disc menus include playback data (angle menu, subtitle menu, etc.) specific to each title. Press MENU to access the disc menu.

1 Press TOP MENU or MENU to

access the DVD menu.

2 Press rt w e to select a

desired title, then press ENTER. Playback starts.

● It may be possible to select the desired item using the number keys depending on the menu display.

NOTE:

When “X” appears on the TV screen in step 1, the disc does not have a top menu or disc menu.

Example:

Scene 2

(Chapter 2)

Tra ck 2

Reverse Forward

Scene 3

(Chapter 3)

Tra ck 3

Scene 4

(Chapter 4)

Track 4

Example:

To locate the beginning of the next item, press 6 once. To locate the beginning of the current item, press 2 once.

High-Speed Search

During playback, press 5 for forward high-speed search, or 3 for reverse high-speed search.

● Each press of the button increases the search speed for each direction.

● To resume normal playback, press 4.

Still Picture/Frame-By-Frame Playback

1 Press 9 to pause during playback. 2 Press SLOW – (3) or SLOW + (5) to activate frame-by-

frame playback.

● Each press of SLOW – (3) or SLOW + (5) advances/reverses the still picture frame by frame.

● Frame-by-frame playback for reverse direction cannot be performed with Video CD/SVCD discs.

● To resume normal playback, press 4.

Slow Motion

1 Press 9 to pause during playback. 2 Press SLOW – (3) or SLOW + (5) for 2 or more seconds.

● Each press of SLOW – (3) or SLOW + (5) increases the slow motion speed for each direction (from 1/16 to 1/2 times the normal speed).

● Slow motion for reverse direction cannot be performed with Video CD/SVCD discs.

Skip Search

During playback, press .

● Each press initiates an approximately 30-second period of fastmotion playback. Normal playback resumes automatically.

Resume Function

It is possible to memorize the position where you stop playback and resume playback from that position.

● Be sure to set “RESUME” to “ON” or “DISC RESUME”. (墌 pg. 68)

1 Press 8 during playback to memorize a resume point.

● The unit enters Resume Stop mode and memorizes the position where you have stopped playback as a resume point. (The inside of the disc status indicator on the front display panel blinks while memorising.)

● The unit retains a memory of the resume points of the last 30 discs played back, even though they have been ejected if “RESUME” is set to “DISC RESUME”. (墌 pg. 68)

● To clear the resume points: (The inside of the disc status indicator stops blinking and lights.)

When “RESUME” is set to “ON”:

• Press 1 to turn off the unit.

• Press x to take out the disc.

• Press 8 in stop mode.

• Press TOP M ENU to display the top menu, then start playback by

selecting an item, etc.

• Press MENU to display the disc menu, then start playback by selecting an item, etc.

When “RESUME” is set to “DISC RESUME”:

• Set “RESUME” to “OFF”. (墌 pg. 68)

• Press 8 in stop mode.

• Press TOP M ENU to display the top menu, then start playback by

selecting an item, etc.

• Press MENU to display the disc menu, then start playback by selecting an item, etc.

2 Press 4 in stop mode to resume playback. The unit starts

playback from the resume point.

BASIC OPERATIONS ON DVD DECK

EN 27

NOTES:

● “DISC RESUME” setting works on DVD VIDEO, VCD, SVCD and already finalised DVD-R/DVD-RW (video mode) discs. For other types of discs, the function under “ON” setting will be applied even if “RESUME” is set to “DISC RESUME”. (墌 pg. 68)

● If you stop the playback of a disc for which a resume point has already been memorized, the memory will be updated with the new resume point.

● After the unit has memorized the resume points for 30 discs, remembering a new resume point will cause the unit to delete the oldest memorized point. Stopping playback of a disc for which a resume point is already stored may change the order in which the points are stored. This may potentially change the order in which points are deleted.

● When the unit memorizes a resume point for a disc, it also remembers audio language, subtitle and angle settings.

● This function may not work for some Video CD/SVCDs.

● When “RESUME” is changed to “ON” or “OFF” (墌 pg. 68), resume

points of the discs memorized with “RESUME” set to “DISC RESUME” will be cleared.

● Resume points are memorized for each side of a double-sided disc.

Marking Positions To Play Back Again Later

It is possible to mark positions (up to 999 points) where you want to play back once again later, and start playback from a marked position. Marking onto DVD-RAM/RW/R discs when recording is helpful to locate a start point when you play back the discs later.

To mark positions:

During playback, press MARK at positions you want to mark.

● “MARK” appears on the TV screen. You can easily locate the marked positions using 2 or 6 when you play back the disc.

To delete the marked positions:

While paused, press 2 or 6 to locate a marked position you want to delete, then press MARK.

● Crossed “MARK” appears on the TV screen, and the marked position is deleted.

NOTES:

● When a monaural programme changes to a stereo programme while recording, a mark signal is automatically recorded.

● When a DVD-R/RW (Video mode) disc is finalised, marked points marked before finalising will be deleted, and programmes will be divided automatically into “chapters” approximately every 5 minutes. (墌 pg. 75)

+ 61 hidden pages

JVC LPT0923-001A User Manual

SAFETY FIRST

Safety Precautions

CONTENTS

About Discs

Recordable/playable Discs

DISC INFORMATION

Discs For Playback Only

Unplayable Discs

Region Number

Recording Medium And Format

File Structure Of Discs

DVD VIDEO Marks

Placing A Disc

Care And Handling Of Discs

INDEX

Front View

Rear View

Front Display Panel

Remote Control

On-Screen Display (DVD deck)

On-Screen Display (HDD deck)

On-Screen Display (DV Dubbing)

Basic Connections

INSTALLING YOUR NEW UNIT

INITIAL SETTINGS

Auto Set Up

Auto Channel Set/Auto Clock Set/Auto Guide Program Number Set

Preset Download

Auto Channel Set by Downloading from TV/Auto Clock Set/Auto Guide Program Number Set

Results Of Auto Set Up/Preset Download Appearing On The Front Display Panel

T-V Link Functions

Language

On-screen Language Set

Menu/Audio/Subtitle Language Set (DVD deck only)

Monitor Set

Satellite Receiver Control Setting

SAT CONTROL SET

Installing Satellite Controller

Setting Satellite Receiver’s Brand And Channel

Basic Playback

BASIC OPERATIONS ON DVD DECK

Playback Features

Locating The Start Point Of The Item Or Skip The Item

Locating A Desired Scene Using The DVD Menu

High-Speed Search

Still Picture/Frame-By-Frame Playback

Slow Motion

Skip Search

Resume Function

Marking Positions To Play Back Again Later
