Page 1
PD-42DV2
ENGLISH
DEUTSCH
FRANÇAIS
NEDERLANDS
CASTELLANO
ITALIANO
PORTUGUÊS
PDP COLOUR TELEVISION
INSTRUCTIONS
1
LCT1445-001A
Page 2
2
Page 3
Thank you for buying this JVC colour television.
To make sure you understand how to use your new TV, please read this manual thoroughly before you begin.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
WARNING
Always use the power cords which are supplied with the TV and receiver.
Some power cords are supplied with this TV. Use the power cord which best suits the area in which you live, and insert it into a correctly
earthed outlet.
Failure to use the supplied power cord or to insert it into a correctly earthed outlet may result in electric shocks.
WARNING FOR TABLE TOP STAND:
To ensure safety in an emergency such as an earthquake, and to prevent accidents, ensure that measures are taken to prevent the TV
dropping or falling over.
• Use the supplied screws to firmly attach the supplied hooks to the back of the TV, and use commercially available cord to fix the TV
to rigid components such as walls and columns.
Supplied hooks
CAUTION:
• Operate only from the power source specified (AC 110 – 240 V,
50/60 Hz) on the unit.
• Avoid damaging the AC plug and power cord.
• When you are not using this unit for a long period of time, it is
recommended that you disconnect the power cord from the
main outlet.
• The ambient temperature for using this unit is 0° to 40°C (32°
to 104°F). Using the unit outside of this range may lead to it not
working correctly or being broken.
ENGLISH
Distance recommendations
Avoid improper installation and never position the unit where good
ventilation is impossible.
When installing this TV, distance recommendations must be maintained
between the set and the wall, as well as inside a tightly enclosed area or
piece of furniture.
Keep to the minimum distance guidelines shown for safe operation.
100 mm
100 mm
200 mm
50 mm
100 mm
150 mm150 mm
200 mm
50 mm
100 mm
100 mm
1
Page 4
Burn-in
A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay
on the screen (this is called phosphor burn-in).
Avoid burn-in as follows.
Use the PICTURE SHIFT function. In order to prevent burn-in, the picture displayed on the screen is shifted up,
down and to the left and right at regular intervals. Refer to page 28 for details.
• Even if the PICTURE SHIFT function is turned off, the picture may shift to the left or right when the channel or input is changed.
The PICTURE MODE function is initially set to BRIGHT. Unless the TV is being watched in an extremely bright
room, it is recommended to change the PICTURE MODE setting to either STANDARD or SOFT. Doing so will
reduce the chance of PDP burn-in and extend the life of the PDP. See “PICTURE MODE” on page 21.
Do not display static images or characters for long periods of time.
ENGLISH
While an image is displayed With power OFF
19:03
Burn-in example
19:03
• Reduce CONTRAST and BRIGHT on the PICTURE SETTING menu (page 21) when viewing.
Do not view for long periods of time in the REGULAR mode (page 15).
Screen size is normally chosen to ensure that the picture is displayed on the entire screen. After viewing in the REGULAR mode in
which black bands may occur at the left and right of the screen, it is recommended to change to the PANORAMIC mode to display
the picture on the entire screen.
While an image is displayed With power OFF
Burn-in example
Do not view for long periods of time using the PIP function (page 16) or MULTI-PICTURE function (page 17).
If Burn-in has occurred
If burn-in occurs, try the REFRESH function (page 28). If burn-in is minimal it may gradually become less noticeable.
Note:Once burn-in occurs it will never disappear completely.
2
Page 5
Point defects
PDPs use collections of fine pixels to display images. While there is no problem with more than 99.99% of these pixels, please
understand that a very small number of pixels may not light or may light all the time.
Do not install the TV near electronic equipment that is susceptible to electromagnetic waves
It may cause interference in images, sound, etc. In particular, keep video equipment away from this product.
Effect on infrared devices
There may be interference while using infrared devices such as infrared cordless headphones.
Failure to take the following precautions may cause damage to the television or remote control.
DO NOT block the TV’s ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)
DO NOT place anything on top of the TV.
(such as cosmetics or medicines, flower vases, potted plants, cups, etc.)
DO NOT allow objects or liquid into the cabinet openings.
(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)
DO NOT place any naked flame sources, such as lighted candles, on the TV.
The surface of the TV screen is easily damaged. Be very careful with it when handling the TV.
Should the TV screen become soiled, wipe it with a soft dry cloth. Never rub it forcefully.
Never use any cleaner or detergent on it.
As both sides of speaker panel can be easily scratched, cleaning should be done
carefully. If the speaker panel is dirty, please wipe with a soft cleaning cloth
(such as the cloth used to clean a compact disc).
ENGLISH
Speaker panels
If there is a fault, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover.
D.I.S.T. demonstration
To start the D.I.S.T. demonstration:
Press the a button to display the MENU (main menu). Then press the yellow button.
A picture split in two (D.I.S.T. turned on and D.I.S.T. turned off) will appear on the screen.
To quit the D.I.S.T. demonstration:
Press the yellow button, b button, P p buttons or any of the number buttons.
3
Page 6
CONTENTS
Checking contents of packages............5
Setting up your TV..................................6
Installation..........................................................6
Putting the batteries into the Remote control .....6
Connections............................................7
Connection diagram...........................................7
ENGLISH
Connecting the TV and receiver ........................8
Connecting the aerial and VCR .........................8
Connecting the power cord to the AC outlet ......9
Initial settings .......................................10
TV buttons and functions ....................12
Turn the TV on from standby mode .................12
Choose a TV channel ......................................12
Watch images from external devices ...............12
Adjust the volume ............................................12
Using the headphone.......................................12
Using the Menu................................................12
Remote control buttons and
functions............................................13
Turn the TV on or off from standby mode ........13
Choose a TV channel ......................................13
Adjust the volume ............................................14
Watch images from external devices ...............14
ZOOM function.................................................15
CINEMA SURROUND function........................15
Displaying the current time ..............................16
Return to TV channel instantly.........................16
Using the FREEZE function .............................16
Using the PIP function .....................................16
Using the MULTI-PICTURE function ...............17
Operating a JVC brand VCR or DVD player
Teletext function...................................18
Basic operation ................................................18
Using the List Mode .........................................18
Hold..................................................................18
Sub-page .........................................................19
Reveal..............................................................19
Size ..................................................................19
Index ................................................................19
Cancel..............................................................19
......17
PICTURE FEATURES........................... 22
DIGITAL VNR.................................................. 22
Super DigiPure................................................ 22
COLOUR SYSTEM ......................................... 23
PULL DOWN................................................... 23
4:3 AUTO ASPECT......................................... 23
COLOUR MANAGEMENT .............................. 23
PIP .................................................................. 23
SOUND SETTING ................................. 24
STEREO / I • II ................................................ 24
Sound Adjustment........................................... 24
SPEAKER ....................................................... 24
BBE ................................................................. 24
CINEMA SURROUND .................................... 24
A.H.B. (Active Hyper Bass) ............................. 24
HEADPHONE ................................................. 25
VIDEO SETTING ................................... 26
ID LIST ............................................................ 26
FEATURES............................................ 27
SLEEP TIMER ................................................ 27
BLUE BACK .................................................... 27
CHANNEL GUARD ......................................... 27
REFRESH ....................................................... 28
PICTURE SHIFT ............................................. 28
INSTALL................................................ 29
LANGUAGE .................................................... 29
AUTO PROGRAM........................................... 29
EDIT/MANUAL ................................................ 29
Changing the TELETEXT LANGUAGE setting
... 32
Additional preparation......................... 33
Connecting the external devices ..................... 33
CH/CC numbers ...................................35
Troubleshooting................................... 36
Specifications....................................... 38
Using the TV’s menu............................20
Basic operation ................................................20
PICTURE SETTING ...............................21
PICTURE MODE .............................................21
Picture Adjustment...........................................21
WHITE BALANCE............................................21
4
Page 7
Checking contents of packages
Check that all components are present. Contact your retailer immediately if any components are missing.
Receiver
TV
ENGLISH
Remote control
Mounting screw × 2
AA/R6-size batteries
(used to check operation)
Hook × 2
System cable
Power cord
• The power cord from those below which is suitable to the area in which you live will be included with your TV.
5
Page 8
Setting up your TV
Ensure to lift up the TV with more than 2 people. TV is too heavy to lift up by yourself and TV fall causes
injuries and damage.
Installation
Depending on the model, the TV may come with a Wall Mounting Unit or Table Top Stand. In these
cases, a separate instruction manual is provided in addition to this manual. Read that instruction
manual and install the TV correctly.
• For models which are supplied without a Wall Mounting Unit or Table Top Stand, and for when using another unit to install the TV,
ENGLISH
only use JVC units which were designed for this TV.
WARNING FOR WALL MOUNTING UNIT:
• Consult authorized service personnel for the installation of your TV in order to prevent accidents. Do not try to install your TV by
yourself.
• We are selling this product with the understanding that it will be assembled and installed by qualified service personnel.
• Please read the instruction manual of Wall Mounting Unit before starting installation in order to prevent accidents.
• We are not liable for any damage caused by faulty assembly, faulty wall mounting, insecure wall mounting, misuse, alterations, or
natural disasters.
Cautions for installation
• Do not tilt the TV towards the left or right, or towards the back.
• Install the TV in a corner on a wall or on the floor so as to keep cords out of the way.
• The TV will generate a slight amount of heat during operation. Ensure that sufficient space is available around the TV to allow
satisfactory cooling. See “Distance recommendations” on page 1.
Putting the batteries into the Remote control
Use two AA/R6 dry cell batteries.
Insert the batteries from the - end, making sure the + and - polarities are correct.
• Follow the warnings printed on the batteries.
• Battery life is about six months to one year, depending on your frequency of use.
• The batteries we supply are only for setting up and testing your TV, please replace them as soon as necessary.
• If the remote control does not work properly, replace the batteries.
6
Page 9
Connections
Caution
• Turn off all equipment (including the TV) before connecting anything.
Connection diagram
TV (back)
DISPLAY INPUT
CONNECT TO SYSTEM CABLE
Supplied system cable
AC INPUT
110-240V
Cable supplied with TV
• Refer to page 9 for connection
details.
ENGLISH
Connecting antenna and other equipment
• Refer to page 8 for connection details.
AUDIO
VIDEOS-VIDEO
L/MONO
R
VIDEO-1
L
R
VIDEO-2
LR
VIDEO-3
Receiver (back)
OUTIN
AUDIO
L
R
COMPONENT(VIDEO-4)
Pr
Pb Y
R-AUDIO-L
VIDEO
DISPLAY OUT
L
R
AUDIO
OUT
AC IN
-
240V
110
Cable supplied with receiver
• Refer to page 9 for connection details.
7
Page 10
Connections
A
O
T
P
Connecting the TV and receiver
Use the supplied system cable to connect the TV to the
receiver.
The two connectors are of different shapes.
Ensure that the pins on connector 1 are oriented correctly,
press the connector into the socket, and tighten the screws at
left and right to lock it in place.
Press connector 2 firmly into place until it is locked.
ENGLISH
1
Disconnecting the system cable
Release connector 1 by unscrewing the screws at left and
right and removing it from the socket.
Release connector 2 by removing it from the socket while
pressing the release bottoms on either side.
If connecting a VCR (see fig.B):
1 Connect the aerial cable to the aerial input
socket on the VCR, and connect the VCR and
receiver with another aerial cable
2 Connect the VCR’s VIDEO OUT (video output)
terminal and the receiver’s VIDEO terminal with
a video cable
To connect a VCR to the receiver with an S-VIDEO
cable:
Connect the VCR’s S-VIDEO OUT (S-VIDEO output)
terminal and receiver’s S-VIDEO terminal with an
S-VIDEO cable A, instead of connecting with a video
cable.
Note that the connection with a video cable will be
ignored in case you connect a VCR to the receiver with
both video cable and S-VIDEO cable.
2
3 Connect the VCR’s VIDEO OUT (audio L/R
output) terminals and the receiver’s AUDIO
terminals (L/MONO and R) with an audio cable
• If the VCR’s audio output is in mono, connect the
VCR’s AUDIO OUT (audio output) terminal and the
receiver’s AUDIO L/MONO terminal with an audio
cable.
• To connect additional external devices, please see
“Connecting the external devices” on page 33.
Fig.B
Back of the receiver
1
2
Connecting the aerial and VCR
• Aerial cable is not supplied. Use a good quality 75-ohm
coaxial cable.
• Read the manual that came with the VCR before
connecting.
If not connecting a VCR (see fig.A):
Connect an aerial cable to the aerial socket on this
receiver.
Fig.A
Back of the receiver
R
VIDEO-1
R
VIDEO-2
R
VIDEO-3
IN
VIDEOS-VIDEO
AUDIO
L/MONO
R
VIDEO-1
R
L
VIDEO-2
LR
VIDEO-3
1
A
AUDIO
R
COMPONEN
Pr
R-AUDIO-L
23
1
8
Page 11
Connecting the power cord to the AC
outlet
Insert the AC plugs on the power cords from the TV and
receiver into AC outlets.
Caution
• Operate only from the power source specified (AC 110
– 240 V, 50/60 Hz) on the unit.
• Failure to use the supplied power cord or to insert it
into a correctly earthed outlet may result in electric
shocks.
Use the supplied power cord which best suits the area in
which you live.
Connections
ENGLISH
Back of the TV
AC INLET
Power cord
AC INLET
AC110-240V
Power cord
Back of the receiver
Insert the AC plug into a correctly earthed outlet.
The receiver power lamp lights red, and the receiver is in
the standby mode, when the AC plug on the power cord is
connected to an AC outlet.
• Remove the AC plug from the outlet to completely
disconnect the TV from the power supply.
Receiver rear
OUTIN
AUDIO
VIDEO-1
VIDEO-2
VIDEO-3
VIDEOS-VIDEO
AUDIO
L/MONO
R
R
L
LR
L
R
COMPONENT(VIDEO-4)
Pr
Pb Y
R-AUDIO-L
VIDEO
DISPLAY OUT
L
R
AUDIO
OUT
1 Aerial socket (page 8)
2 VIDEO terminals (pages 8, 26, 33)
VIDEO-1 terminal, VIDEO-2 terminal, VIDEO-3
terminal, COMPONENT (VIDEO-4) terminal
3 OUT terminal (page 34)
4 AUDIO OUT terminal (page 34)
5 DISPLAY OUT terminal (page 8)
6 AC INLET (page 9)
AC IN
-
240V
110
9
Page 12
Initial settings
ENGLISH
When the TV is first turned on, it enters the initial setting
mode, and the JVC logo is displayed. Follow the
instructions on the on-screen display to make the initial
settings.
VCR/TV/DVD
Switch
Yellow button
Blue button
1 Make sure to set the VCR/TV/DVD switch to the
TV position.
• You cannot turn the TV on when the VCR/TV/DVD
switch is set to the VCR or DVD position.
2 Press the #### button on the remote control
The receiver power lamp changes from red to green.
After a short interval the TV power lamp lights green
and the JVC logo is displayed.
• Check that the AC plugs on the power cords from the
TV and receiver are connected to AC outlets.
TV (front)
• If the power lamp stays red and does not change to
green:
Your TV is in the standby mode. Press the #
(Standby) button again to turn your TV on.
• The JVC logo does not appear when your TV has
been turned on once. In this case, use the
“LANGUAGE” and “AUTO PROGRAM” functions
to make the initial settings. For details, see
“INSTALL” on page 29.
3Press the aaaa button
The LANGUAGE menu appears.
LANGUAGE
BACK
TV OK
D0002(E)-EN
4Press the 5555 and 6666 buttons to choose
ENGLISH. Then press the aaaa button
English is set for the on-screen display description. The
TELETEXT LANGUAGE menu appears as a sub-menu
of the AUTO PROGRAM function.
TELETEXT LANGUAGE
GROUP-1
GROUP-2
GROUP-3
GROUP-4
BACK
TV OK
D1003-EN
5Press the 6666 buttons to choose the teletext
language group that corresponds to language
of teletext programme that you want to watch
Group Languages
GROUP-1 Turkish, Hungarian, English, German,
French, Italian, Spanish, Portuguese,
Greek, Swedish, Finnish
10
Receiver (front)
Remote control
sensor
Power lamp
Power lampA button
GROUP-2 Polish, Serbian, Croatian, Slovenian,
Czech, Slovak, Rumanian, Hungarian,
German, French, Italian, Swedish,
Finnish
GROUP-3 Russian, Bulgarian, Lettish, Lithuanian,
Estonian, Ukrainian, Serbian, Croatian,
Slovenian, Czech, Slovak, English,
German
GROUP-4 Arabic, Czech, Slovak. Hungarian,
English, German, French, Italian,
Spanish, Portuguese, Swedish, Finnish
Page 13
6 Press the blue button to start the AUTO
PROGRAM function
The AUTO PROGRAM menu appears and received TV
channels are automatically registered in the Programme
numbers (PR).
• To cancel the AUTO PROGRAM function:
Press the b button.
AUTO PROGRAM
20%
BACK
TV OK
D0004-EN
CH 10
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
BACK
MOVE
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
ID
INSERT
DELETE
MANUAL
After the TV channels have been registered in
the Programme numbers (PR), the EDIT menu
appears
• You can proceed to edit the Programme numbers
(PR) using the EDIT/MANUAL function. For details,
see “EDIT/MANUAL” on page 29.
• If you do not need to use the EDIT/MANUAL
function, go to the next step.
7 Press the aaaa button
Initial settings
ENGLISH
11
Page 14
TV buttons and functions
ENGLISH
TV (front)
TV (back)
Receiver (front)
How to open the cover
AUDIO
S VIDEO
R
L
IN(VIDEO-5)
Refer to the pages in parentheses for details.
1 Headphone jack (mini jack) (page 33)
2 VIDEO-5 terminal (pages 26, 33)
3 A (Stand by) button (page 12)
4 Power lamp (page 10)
Turn the TV on from standby mode
Press the AAAA button or P pppp buttons to turn the TV
on from standby mode
• Check that the AC plugs on the power cords from the TV
and receiver are connected to correctly AC outlets.
Refer to the pages in parentheses for details.
1 Remote control sensor
2 Power lamp (page 10)
3 MENU/OK button (pages 12, 20)
4 TV/AV button (page 12)
5 r (Volume) q buttons (page 12)
6 P p buttons (page 12)
7 A (Stand by) button (page 12)
Choose a TV channel
Press the P pppp buttons to choose a programme
number (PR) or a VIDEO terminal
Watch images from external devices
Press the TV/AV button to choose a VIDEO
terminal
TV mode VIDEO modes
Last
Programme
number
VIDEO-1
V1
VIDEO-5
or
V5 V4S5
VIDEO-2
V2
VIDEO-3
V3
VIDEO-4
S2
or
S3
or
• The leading character is changed from V to S (e.g. V2 is
changed to S2) when VIDEO-2, VIDEO-3, or VIDEO-5
are connected to the S terminal.
Adjust the volume
Press the qqqq buttons
The volume level indicator appears.
12
Using the headphone
• The headphone volume is adjusted with the
“HEADPHONE” menu (see page 25).
Using the Menu
Use the MENU/OK button.
Refer to“Using the TV’s menu” (see page 20) for details of
using the menu.
Page 15
Remote control buttons and functions
1 Muting button
2 Number buttons
3 Information button
4 c button
5 3 sound button
6 b button
7 5 buttons
8 g (Text) button
9 p p buttons
0 VCR/DVD/Teletext control buttons
- p buttons
= Standby button
~ VCR/TV/DVD switch
! R button
@ Colour buttons
# a button
$ D button
% 6 buttons
^ f button
& r q buttons
* X button
( g button
Turn the TV on or off from standby
mode
ENGLISH
1 Make sure to set the VCR/TV/DVD switch to the
TV position.
• You cannot turn the TV on or off when the VCR/TV/
DVD switch is set to the VCR or DVD position.
2Press the #### (Standby) button to turn the TV on
or off.
When the TV is turned on, the power lamp changes from
red to green.
• The power can be turned on by pressing the b
button, p p buttons or Number buttons.
• Check that the AC plugs on the power cords from the
TV and receiver are connected to AC outlets.
Choose a TV channel
Use the number buttons:
Enter the programme number (PR) of the
channel using the number buttons.
Example:
•PR 6 → press 6
• PR 12 → press 1 and 2
Use the pppp
Press the pppp
programme number (PR) you want.
buttons:
pppp
buttons to choose the
pppp
13
Page 16
Remote control buttons and functions
Use the PR LIST:
1 Press the
PR LIST
Pressing the h (Information) button changes the display
as follows:
PR LIST
PR ID
AV
01
02
03
ENGLISH
04
05
06
07
08
09
TV OK
D0011-EN
2 Press the 5555 and 6666 buttons to choose a
Programme number (PR). Then press the aaaa
button
• For Programme numbers (PR) with the CHANNEL
GUARD function set, the n (CHANNEL GUARD)
mark is displayed next to the Programme number
(PR) in the PR LIST.
• You cannot use the 6 buttons to choose a
Programme number (PR) with the CHANNEL
GUARD function set.
• Even if you try to choose a Programme number (PR)
with the CHANNEL GUARD function set, the n
(CHANNEL GUARD) mark will appear, and you
cannot watch the TV channel. To watch the TV
channel, see “CHANNEL GUARD” on page 27.
• If you do not have a clear picture or no colour
appears, follow the operation procedure “COLOUR
SYSTEM” (see page 23).
• The sound system is chosen automatically. However,
if you cannot hear the sound normally even when the
picture appears normally, choose the sound system
manually. Refer to the MANUAL on the “INSTALL”
menu (see page 29) for details of choosing the sound
system.
Adjust the volume
Press the rrrr qqqq buttons to adjust the volume.
The Volume indicator appears and the volume changes as
you press the r q buttons.
• The headphone volume is adjusted with the
“HEADPHONE” menu (see page 25).
Muting the sound
Press the
sound.
Pressing the l (muting) button again restores the previous
volume level.
(Information) button to display the
hhhh
12 : 00
No indication
+10-10
(muting) button to turn off the
llll
Watch images from external devices
Use the o
Press the o
terminal.
• The leading character is changed from V to S (eg V2 is
Use the pppp
Press the pppp
terminal.
Use the PR LIST:
1Press the
2Press the 5555 and 6666 buttons to choose a
To return to a TV channel:
Press the bbbb button or the Number buttons.
To use the Programme number PR 0 (AV):
When the TV and VCR are connected only by the Aerial
cable, choosing the Programme number PR 0 (AV) allows
you to view images from the VCR. Set the VCR RF channel
to the Programme number PR 0 (AV) manually. For details,
see “EDIT/MANUAL” on page 29.
Pressing the o button changes the choice as follows:
• The VCR RF channel is sent as the RF signal from the
• Also refer to your VCR instruction manual.
o button:
oo
o button to choose a VIDEO
oo
TV mode VIDEO modes
Programme
numbers
PR 1 – PR 99
VIDEO-1
V1
VIDEO-5
or
V5 V4S5
VIDEO-2
V2
VIDEO-3
V3
VIDEO-4
S2
or
S3
or
changed to S2) when VIDEO-2, VIDEO-3, or VIDEO-5
are connected to the S terminal.
buttons:
pppp
buttons to choose a VIDEO
pppp
(Information) button to display the
hhhh
PR LIST
VIDEO terminal. Then press the aaaa button
• The VIDEO terminals are registered after the
Programme number PR 99.
• If you do not have a clear picture or no colour
appears, change the colour system manually. See
“COLOUR SYSTEM” on page 23.
TV mode
Programme
numbers
PR 1 – PR 99
PR 0
VIDEO modes
VIDEO-1
V1
VIDEO-5
or
V5 V4S5
VIDEO-2
V2
VIDEO-3
V3
VIDEO-4
or
S2
or
S3
VCR.
14
Page 17
Remote control buttons and functions
ZOOM function
You can change the screen size according to the picture
aspect ratio. Choose the optimum one from the following
ZOOM modes.
AUTO:
When a WSS (Wide Screen Signalling) signal, which shows
the aspect ratio of the picture, is included in the broadcast
signal or the signal from an external device, the TV
automatically changes the ZOOM mode to 16:9 ZOOM
mode or FULL mode according to the WSS signal.
If a WSS signal is not included, the picture is displayed in
accordance with the ZOOM mode set with the 4:3 AUTO
ASPECT function.
• For details of the 4:3 AUTO ASPECT function, see “4:3
AUTO ASPECT” on page 23.
• When the AUTO (WSS) mode does not function
correctly due to poor WSS signal quality or when you
want to change the ZOOM mode, press the c
button and change to another ZOOM mode.
REGULAR:
Use to view a normal picture (4:3 aspect ratio) as its
original size is.
PANORAMIC:
This mode stretches the left and right sides of a normal
picture (4:3 Aspect Ratio) to fill the screen, without making
the picture appear unnatural.
• The top and bottom of the picture are slightly cut off.
14:9 ZOOM:
This mode zooms up the Wide Picture (14:9 Aspect Ratio)
to the upper and lower limits of the screen.
Choose the ZOOM mode
1Press the c
menu
ZOOM
AUTO
REGULAR
PANORAMIC
14:9 ZOOM
16:9 ZOOM
16:9 Z OOM SUBTITLE
FULL
TV OK
D0009-EN
• The c button does not work in the twin
pictures mode.
2Press the 6666 buttons to choose a ZOOM mode.
Then press the aaaa button
The picture expands and the chosen ZOOM mode is
displayed in about 5 seconds.
c button to display the ZOOM
cc
BACK
Adjusting the visible area of the picture
If subtitles or the top (or bottom) of the picture are cut off,
adjust the visible area of the picture manually.
1Press the c
c button
cc
The ZOOM menu appears.
2Press the aaaa button to display the ZOOM mode
indication
Indicator is displayed.
16 : 9 ZOOM
D0010-EN
3 While it is displayed, press the 6666 buttons to
adjust the visible area vertically
• You cannot adjust the visible area in REGULAR or
FULL mode.
CINEMA SURROUND function
You can enjoy sounds with a wider ambience.
ENGLISH
16:9 ZOOM:
This mode zooms up the Wide Picture (16:9 Aspect Ratio)
to the full screen.
16:9 ZOOM SUBTITLE:
This mode zooms up the Wide Picture (16:9 Aspect Ratio)
with subtitles to the full screen.
FULL:
This mode uniformly stretches the left and right sides of a
normal picture (4:3 aspect ratio) to fill the wide TV screen.
Use for pictures with a 16:9 aspect ratio that have been
squeezed into a normal picture (4:3 aspect ratio), you can
restore their original dimensions.
Press the 3333 button to turn the CINEMA
SURROUND function on or off
• The CINEMA SURROUND function does not work
properly with mono sound.
• The CINEMA SURROUND function can be also turned
on or off by using the SOUND SETTING menu. For
details, see “CINEMA SURROUND” on page 24.
15
Page 18
Remote control buttons and functions
Displaying the current time
You can display the Current Time on the screen.
Press the
(Information) button to display the
hhhh
current time
Pressing the h (Information) button changes the display as
follows:
PR LIST
ENGLISH
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
D0011-EN
12 : 00
No indication
+10-10
• This TV uses teletext data to set the current time. If the
TV has not received a TV channel that has teletext
programmes since it was turned on, the time display is
blank. To view the current time, choose a TV channel
that has teletext programmes.
• When watching videos, an incorrect current time is
sometimes displayed.
Return to TV channel instantly
You can return to a TV channel instantly.
Press the bbbb button
The TV returns to the TV mode and a TV channel appears.
Using the FREEZE function
You can view the current programme as a still picture.
1 Press the ffff button
The still picture of the current picture will appear.
current
programme
D0056
To cancel the FREEZE function:
Press the f button, the p p buttons or the number
buttons.
• The FREEZE function does not work while a subpicture is displayed.
• The still picture cannot be output from the TV.
• The FREEZE function is cleared if no operation is
performed for approximately one minute.
still picture
Using the PIP function
You can view two pictures (Main-picture and sub-picture).
A TV programme and a video programme from an external
device can be watched at the same time.
1Press the RRRR button
Pressing the RRRR button changes the PIP mode as follows:
Twin pictures mode
Main-
Picture in picture mode
Main-
Cancel the PIP function
Main-
D0057
Subpicture
Subpicture
2Press the pppp buttons to change the sub-
picture to the picture from another TV channel
or another VIDEO terminal
Listening to the sound of the sub-picture:
You can listen to the sound of the sub-picture with the
headphones while listening to the sound of the mainpicture from the TV speakers.
For details, see “HEADPHONE” on page 25.
• The sub-picture sound is monaural.
Changing the position of the sub-picture:
You can choose one of four positions.
For details, see “PIP” on page 23.
Swapping the main-picture and sub-picture:
Press the g button.
The main-picture and sub-picture will be swapped.
A B
16
D0051
A
B
Page 19
Remote control buttons and functions
Cancelling the PIP function:
Press the RRRR button or b button.
• If the main-picture signal is poor, the quality of the
sub-picture may also be poor.
• If the pictures have different standards, the top and
bottom of one of them may be missing.
• If an external device is operated, the sub-picture may
disappear. If this happens, press the RRRR button again
to redisplay the sub-picture.
• You cannot view a scrambled channel in the subpicture. If the g button is pressed when viewing a
scrambled channel in the main-picture using an
external decoder, the channel you have been viewing
in the sub-picture will appear in both the main-picture
and sub-picture.
• The ZOOM function does not work in the twinpicture mode.
• Do not press the g button while you are recording
the TV output on the VCR. If you do, the TV output
signal will change.
• The BLUE BACK function does not work in the twin
picture mode or the picture-in-picture mode.
• A progressive-scanning picture cannot be displayed
as the sub-picture.
Pay attention to the following.
- When the VIDEO-4 picture is a progressive-
scanning picture, you cannot choose VIDEO-4
with the p buttons.
- When the VIDEO-4 picture signal is changed to a
progressive-scanning picture while the VIDEO-4
picture is displayed as the sub-picture, the PIP
function is cancelled.
- The pictures cannot be swapped when a
progressive-scanning picture from VIDEO-4 is
being displayed as the main picture.
• The sub-picture cannot be output from the TV.
Using the MULTI-PICTURE function
You can display multi-pictures that enable you to easily find
a program you want to view.
1 Press the XXXX button to display multi-pictures
The channels are displayed in the channel number order.
The multi-pictures will appear in multi-picture mode.
12-pictures multi:
Still pictures
Moving picture
D0058-EN
2 Press the pppp buttons to choose the screen you
want to see
The chosen picture changes to a moving picture.
3Press the aaaa button
The multi-pictures disappear and the chosen picture
appears.
Cancelling the multi-pictures:
Press the b button, the number buttons or the a
button.
• Pictures from external devices cannot be displayed in
the 12-pictures multi mode.
Operating a JVC brand VCR or DVD
player
You can operate a JVC brand VCR or DVD player.
Pressing the button having the same appearance as the
original remote control button of a device makes the
function work in the same way as the original remote
control.
1 Set the VCR/TV/DVD Switch to the VCR or DVD
position
VCR:
When you are operating the VCR, set the switch to the
VCR position. You can turn the VCR on or off with the
# (Standby) button.
DVD:
When you are operating the DVD player, set the switch
to the DVD position. You can turn the DVD player on or
off with the # (Standby) button.
2 Press the VCR/DVD Control Button to control
your VCR or DVD player
• If your device is not made by JVC, these buttons
cannot be used.
• Even if your device is made by JVC, some of these
buttons or any one of the buttons may not work,
depending on the device.
• You can use the p buttons to choose a TV channel.
The VCR will receive or choose the chapter the DVD
player plays back.
• Some DVD player models use the p buttons for
both operating of Fast forward/backward functions
and choosing the chapter. In this case, the 253
buttons do not work.
• Set the VCR/TV/DVD switch to the TV position
when you turn the TV on or off.
To use D
Some DVDs allow you to select the disc contents using the
menu. When you playback these DVDs, you can select the
subtitle language and sound-track language, etc. by using
the DVD menu.
1Press D
D button
DD
D button during play back
DD
The DVD menu appears on the screen.
•Press D button again to resume playback
at the scene when you pressed the button.
ENGLISH
2Press 6666 or 5555 buttons to select the desired
item
3Press aaaa button
The menu continues to another screen.
Repeat steps 2 and 3 to set additional items if any.
17
Page 20
Teletext function
Basic operation
1 Choose a TV channel with a teletext broadcast
2 Make sure to set the VCR/TV/DVD switch to the
TV position.
ENGLISH
3 Press gggg (Text) button to display the teletext
Pressing g (Text) button changes the mode as follows:
D1043
4 Choose a teletext page by pressing the pppp pppp
buttons, Number buttons or Colour buttons
To return to the TV mode:
Press the b button or g (Text) button.
• If you have trouble receiving teletext broadcasts,
• The ZOOM function will not operate in the TV and
• No menu operations are possible when viewing a
• Language display depends on the country which was
TEXT
---
TEXT
---
TV mode TV and text mode
TEXT
---
TEXT
---
Text mode
consult your local dealer or the teletext station.
text mode or Text mode.
teletext programme.
set on the TELETEXT LANGUAGE menu. If
characters on a Teletext programme do not appear
properly, change the TELETEXT LANGUAGE
Setting to other country’s. For detail, “Changing the
TELETEXT LANGUAGE setting” on page 32.
Using the List Mode
You can store the numbers of your favourite teletext pages
in memory and call them up quickly using the colour
buttons.
To store the page numbers:
1Press B
2 Press a Colour button to choose a position.
3 Press and hold down AAAA (Store) button
B button to engage the List mode
BB
The stored page numbers are displayed at the bottom of
the screen.
Then press the Number buttons to enter the
page number
The four page numbers blink white to indicate that they
are stored in memory.
To call up a stored page:
1Press the B
2 Press a colour button to which a page has been
assigned
To exit the List mode:
Press the B button again.
B button to engage the List mode
BB
Hold
You can hold a teletext page on the screen for as long as
you want, even while several other teletext pages are being
received.
Press the CCCC (Hold) button
18
When viewing a teletext programme, the text
periodically moves a little at a time towards either the
top or bottom of the screen. This is to prevent burn-in
and is not a malfunction.
Hold indication
To cancel the Hold function:
Press C (Hold) button again.
• The Hold function is cleared if no operation is performed
for approximately one minute.
Page 21
Sub-page
Some teletext pages include sub-pages that are
automatically displayed.
1 Choose a teletext page that includes sub-pages
Sub-page numbers that can be viewed are automatically
displayed at the top of the screen.
Teletext function
2 Press the 5555 buttons to choose a sub-page
number
Reveal
Some teletext pages include hidden text (such as answers to
a quiz).
You can display the hidden text.
Each time you press the EEEE (Reveal) button, text is
hidden or revealed
Size
You can double the height of the teletext display.
Press the FFFF (Size) button.
ENGLISH
Index
You can return to the index page instantly.
Press GGGG (Index) button
Returns to page 100 or a previously specified page.
Cancel
You can search for a teletext page while watching TV.
1 Press the Number button to enter a page
number, or press a Colour button
The TV searches for a teletext page.
2 Press HHHH (Cancel) button
The TV programme appears. When the TV finds the
teletext page, its page number appears in the upper left
of the screen.
3 Press HHHH (Cancel) button to return to a teletext
page when the page number is on the screen
• The TV mode cannot be resumed even by pressing
the H (Cancel) button. A TV programme is
temporarily displayed instead of the teletext
programme.
19
Page 22
Using the TV’s menu
ENGLISH
This TV has a number of functions you can operate using
menus. To fully utilize all your TV’s functions, you need to
understand the basic menu operating techniques fully.
3Press the 6666 buttons to choose a function
• For details of the functions in the menus, see the
following pages.
4Press the 5555 buttons to choose the setting of
that function
• If you want to operate a function which appears only
with its name, follow the descriptions of that function
on the following pages.
• The display appearing at the bottom of a menu shows
you a button on the remote control that you can use
when you operate a chosen function.
5Press the aaaa button to complete the setting
The menu disappears.
• When watching the television with the NTSC system,
the menus are displayed at about half of their normal
vertical size.
• The menu will be disappear if you press the p p
buttons while the menu is displayed.
Operation with the buttons on the TV
You can also operate the menus using the buttons on the
front panel of the TV.
Basic operation
1 Press the aaaa button to display the MENU (main
menu)
MENU
PICTURE SETTING
PICTURE FEATURES
SOUND SETTING
VIDEO SETTING
BACK
TV OK
D0013-EN
•Press the a button twice while watching the
MULTI-PICTURE mode.
• The display appearing at the bottom of a menu
indicates buttons on the remote control you can use
when you operate a chosen function.
(Information) button
h
2 Press the 5555 and 6666 buttons to choose a
menu title, and press the aaaa button
The menu appears.
To return to the previous menu:
Press the h (information) button.
To exit a menu instantly:
Press the b button.
TV OK
b button
FEATURES
INSTALL
BACK
a button
MENU/OK button
TV/AV button
6 buttons
5 buttons
The menu will disappear if no operation is performed for
approximately one minute.
20
Page 23
PICTURE SETTING
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
PICTURE SETTING
PICTURE MODE
CONTRAST
BRIGHT
SHARP
COLOUR
TINT
WHITE BALANCE
TV
D0014-EN
BACK
OK
BRIGHT
MID
RESET
PICTURE MODE
You can choose one of three PICTURE MODEs to adjust
the picture settings automatically.
BRIGHT:
Heightens contrast and sharpness.
STANDARD:
Standardizes picture adjustment.
SOFT:
Softens contrast and sharpness.
Picture Adjustment
You can change the picture settings of each PICTURE
MODE mode as you like.
CONTRAST:
You can adjust the picture contrast.
2 :lower
3 : higher
BRIGHT:
You can adjust the picture brightness.
2 :darker
3 : brighter
SHARP:
You can adjust the picture sharpness.
2 :softer
3 :sharper
COLOUR:
You can adjust the picture colour.
2 : lighter
3 : deeper
TINT:
You can adjust the picture tint.
2 :reddish
3 :greenish
WHITE BALANCE
You can select one of three WHITE BALANCE modes
(three tones of white) to adjust the white balance of the
picture. Since white is the colour which is used as a
reference for all the other colours, changing the WHITE
BALANCE mode affects the appearance of all the other
colours on the screen.
COOL:
A bluish white. Using this mode when watching bright
pictures allows you to enjoy a more vivid and bright picture.
MID:
The normal white colour.
WARM:
A reddish white. Using this mode when watching films
allows you to enjoy colours that are characteristic of films.
ENGLISH
• You can change the TINT setting (picture hue) when the
colour system is NTSC 3.58, NTSC 4.43 or a signal
from the VIDEO-4 terminal.
However, operation is not possible when the PIP
function main picture is set to VIDEO-4.
To return to the default settings in each PICTURE
MODE:
Press the blue button.
• This returns the picture settings in the PICTURE MODE
mode you have chosen to the default settings, and stores
them in the PICTURE MODE mode.
21
Page 24
PICTURE FEATURES
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
ENGLISH
D1015-EN
DIGITAL VNR
The DIGITAL VNR function cuts down the amount of
noise in the original picture.
You can choose from the three DIGITAL VNR function
settings of AUTO, MIN and MAX.
AUTO:
The TV will automatically adjust the level of the DIGITAL
VNR effect to match the amount of noise in the picture,
giving you the best possible picture.
• If you set the DIGITAL VNR effect too high it can make
• AUTO cannot be chosen when you are watching the
MIN:
The level of the DIGITAL VNR effect is set to the
minimum. If you set the DIGITAL VNR function to AUTO
but feel that the sharpness of the original picture has not
been reproduced fully, change the setting from AUTO to
MIN.
• The MIN setting is not suitable for low-quality pictures
MAX:
The level of the DIGITAL VNR effect is set to the
maximum. If you set the DIGITAL VNR function to AUTO
but still notice some noise, change the setting from AUTO
to MAX.
• The MAX setting is not suitable for high-quality pictures
• When a progressive-scanning picture is being displayed,
PICTURE FEATURES
DIGITAL VNR
Super DigiPure
COLOUR SYSTEM
PULL DOWN
4:3 AUTO ASPECT
COLOUR MANAGEMENT
PIP
BACK
OK
TV
AUTO
AUTO
AUTO
ON
the picture less sharp. It is recommended to use the
AUTO setting if you can.
VIDEO-4 picture.
which contain a lot of noise.
which contain very little noise.
the AUTO setting cannot be chosen with the DIGITAL
VNR function.
Super DigiPure
The Super DigiPure function uses the latest in digital
technology to give you a natural-looking picture. The Super
DigiPure function includes the following two functions.
DigiPure function:
This function helps to create a natural-looking picture by
eliminating unnecessary edges from high-contrast and crisp
images. For images with low-contrast, edges are added to
produce a sharper, more detailed picture.
You can choose from the three DigiPure function settings of
AUTO, MIN and MAX.
• If you set the DigiPure effect too high on a low-quality
picture that contains a lot of noise, this may actually
make the noise worse. We recommend you use the
AUTO setting if you can.
Picture motion compensation function:
This function displays fast-moving pictures (for example,
the players or ball in a football game) more smoothly and
naturally on the screen.
• The effect level of the picture motion compensation
function cannot be changed. The effect level is the same
no matter which of the AUTO, MIN or MAX settings is
used.
1 Choose Super DigiPure
2Press the 5555 buttons to choose a setting.
Then press the aaaa button
AUTO:
The TV will automatically adjust the level of the DigiPure
effect to match the amount of noise in the picture, giving the
best possible picture.
• AUTO cannot be chosen when you are watching the
VIDEO-4 picture.
MIN:
The level of DigiPure effect is set to the minimum. When
you set the Super DigiPure function to AUTO and notice
some noise, change the setting from AUTO to MIN.
• The MIN setting is not suitable for high-quality pictures
which contain very little noise.
MAX:
The level of DigiPure effect is set to the maximum. If you
set the Super DigiPure function to AUTO but feel that the
original picture quality has not been reproduced fully,
change the setting from AUTO to MAX.
• The MAX setting is not suitable for low-quality pictures
which contain a lot of noise.
OFF:
The Super DigiPure function is turned off.
22
Page 25
PICTURE FEATURES
COLOUR SYSTEM
The colour system is chosen automatically. However, if the
picture is not clear or no colour appears, choose the colour
system manually.
1 Choose COLOUR SYSTEM. Then press the aaaa
button
The sub-menu of the COLOUR SYSTEM function
appears.
COLOUR SYSTEM
MAIN SUB
PAL
BACK
TV OK
D0016-EN
2 Press the 5555 buttons to choose MAIN or SUB
MAIN:
You can change the colour system of the main-picture.
SUB:
You can change the colour system of the sub-picture.
• Choose MAIN when a sub-picture is not displayed.
3 Press the 6666 buttons to choose the
appropriate colour system. Then press the aaaa
button
AUTO:
This function detects a colour system from the input
signal. You can only use this when you are viewing a
picture from programme number PR 0 (AV), or a
VIDEO terminal.
Refer to the following table for the various international
colour systems.
Colour system
Area Country or region System
Bahrain, Kuwait, Oman, Qatar, United
Arab Emirates, Yemen, etc.
Indonesia, Malaysia, Singapore,
Thailand, India, etc.
Asia,
Middle
East
China, Vietnam, etc PAL
Hong Kong, etc PAL
Islamic Republic of Iran, Lebanon,
Saudi Arabia, etc.
Philippines, Taiwan, Myanmar, etc NTSC
Russia, etc SECAM
Europe
Czech Republic, Poland, etc PAL
Germany, Holland, Belgium, etc PAL
UK, etc PAL
Oceania Australia, New Zealand, etc PAL
Republic of South Africa, etc PAL
Africa
Nigeria, etc PAL
Egypt, Morocco, etc SECAM
• The AUTO function may not function properly if you
have poor signal quality. If the picture is abnormal in the
AUTO function, choose another colour system
manually.
AUTO
PAL
SECAM
PULL DOWN
The PULL DOWN function displays a cinema film picture
more smoothly and naturally on the screen.
AUTO:
The television automatically recognizes the type of signal
and turns the function on and off.
ON:
This function is turned on.
OFF:
This function is turned off.
• The motion may appear unnatural when viewing images
with the NTSC colour system. When the PULL DOWN
function is set to AUTO or ON, the motion may appear
unnatural when viewing images with the NTSC colour
system.
• You cannot select this function in the twin pictures mode
or the picture in picture mode.
4:3 AUTO ASPECT
You can choose one of three ZOOM modes, REGULAR,
PANORAMIC or 14:9 ZOOM, as the ZOOM mode for the
normal picture (4:3 aspect ratio).
1 Choose 4:3 AUTO ASPECT then press the aaaa
button
4:3 AUTO ASPECT
PANORAMIC
REGULAR
14:9 ZOOM
BACK
TV OK
D0017-EN
2Press the 6666 buttons to choose a ZOOM mode.
Then press the aaaa button
COLOUR MANAGEMENT
This TV supports the COLOUR MANAGEMENT function
to ensure dull colours are compensated to produce natural
hues.
The COLOUR MANAGEMENT function is on by default.
ON:
COLOUR MANAGEMENT function is turned on.
OFF:
COLOUR MANAGEMENT function is turned off.
• Set this function to ON under normal conditions.
PIP
You can choose one of four positions for the sub-picture.
1Press the 6666 buttons to choose PIP. Then
press the aaaa button
The PIP menu appears.
PIP
BACK
TV OK
D0061-EN
ENGLISH
2Press the 5555 buttons to choose the position.
Then press the aaaa button
23
Page 26
SOUND SETTING
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
SOUND SETTING
STEREO/
BASS
TREBLE
BALANCE
SPEAKER
BBE
CINEMA SURROUND
A.H.B.
HEADPHONE
BACK
TV OK
ENGLISH
D0019-EN
STEREO / I • II
When you are viewing a bilingual broadcast programme,
you can choose the sound from Bilingual I (Sub I) or
Bilingual II (Sub II). When the stereo broadcasting is
received poorly, you can change from stereo to mono sound
so that you can hear the broadcast more clearly and easily.
s: Stereo sound
v : mono sound
t : Bilingual I (sub I)
u : Bilingual II (sub II)
• The sound mode you can choose differs depending on
the TV programme.
• This function does not work in the VIDEO modes. And
this function does not appear in the SOUND SETTING
menu.
Sound Adjustment
You can adjust the sound to your liking.
BASS:
You can adjust the low tone of the sound.
2 : weaker
3 : strong
TREBLE:
You can adjust the high tone of the sound.
2 : weaker
3 : strong
BALANCE:
You can adjust the volume balance between the left and
right speaker.
2 : turn the left speaker’s volume level up.
3 : turn the right speaker’s volume level up.
ON OFF
ON OFF
ON OFF
ON OFF
SPEAKER
You can turn off the sound from the TV speakers; but you
should only do this if an audio system is connected to the
TV as a substitute for the TV speakers.
ON:
The TV speakers issue sound.
OFF:
The TV speakers does not issue sound.
BBE
You can use the BBE function to enjoy easy-to-listen sound
that is faithful to the original sound recorded.
ON:
This function is turned on.
OFF:
This function is turned off.
• Licensed by BBE Sound, Inc. BBE is a registered
trademark of BBE Sound, Inc.
CINEMA SURROUND
You can enjoy Surround sound with a “live” effect by using
the CINEMA SURROUND function.
ON:
CINEMA SURROUND function is turned on.
OFF:
CINEMA SURROUND function is turned off.
A.H.B. (Active Hyper Bass)
Used when you want to emphasize the bass sound.
ON:
This function is turned on.
OFF:
This function is turned off.
24
Page 27
HEADPHONE
You need to use the HEADPHONE menu to adjust the
volume of the headphones.
The HEADPHONE menu can also be used to set whether or
not sound comes from the TV speakers when the
headphones are being used and to perform the settings for
the sound coming from the headphones.
1 Press the 6666 buttons to choose HEADPHONE.
Then press the aaaa button
The sub-menu of the HEADPHONE function appears.
D0044-EN
2 Press the 6666 buttons to choose a function.
Then press the 5555 buttons to change the
setting
VOLUME:
You can change the volume of the headphones.
TV SPEAKER:
You can turn the TV’s speakers on or off.
ON:
The sound comes from the TV’s speakers when using
the headphones.
OFF:
The sound does not come from the TV’s speakers
when using the headphones.
OUTPUT:
You can choose the sound output to the headphones.
MAIN:
You can listen to the sound of the main-picture with
your headphones.
SUB:
You can listen to the sound of the sub-picture with
your headphones.
• When the sub-picture is a television programme,
the sound becomes monaural.
SOUND SETTING
ENGLISH
3 Press the aaaa button
Hint:
When a sub-picture is displayed, the sound of the subpicture can be listened to with the headphones while
listening to the sound of the main-picture with the TV
speakers. To do this, set TV SPEAKER to ON and
OUTPUT to SUB.
• Headphones do not work with sound adjusted for BASS
and TREBLE, BBE effect sound, A.H.B. effect sound,
and CINEMA SURROUND effect sound.
25
Page 28
VIDEO SETTING
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
VIDEO SETTING
VIDEO-1
VIDEO-3
VIDEO-5
TV
BACK
TV OK
ENGLISH
D0020-EN
ID LIST
You can have a name corresponding to the devices
connected for each VIDEO terminal. Giving a name to a
VIDEO terminal makes the VIDEO terminal number appear
on the screen, together with the name.
1 Choose a VIDEO terminal
The image from the chosen external equipment is
displayed in the background on the menu. The image on
the TV is displayed if the TV is chosen.
2 Press the blue button to display the name list
(ID LIST)
VIDEO SETTING
VIDEO-1
VIDEO-3
VIDEO-5
TV
BACK
TV OK
D0021-EN
VIDEO-2
VIDEO-4
ID LIST
VIDEO-2
VIDEO-4
ID LIST
VHS
S-VHS
DVC
SAT
STB
GAME
LD
DVD
8mm
Hi-8
3 Press the 6666 buttons to choose a name. Then
press the aaaa button
The ID LIST disappears and the name is assigned to the
VIDEO terminal.
• You cannot assign a VIDEO terminal name not found
in the name list (ID LIST).
To erase a name assigned to the VIDEO
terminal:
Choose a blank space.
4 Press the aaaa button to complete the setting
26
Page 29
FEATURES
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
FEATURES
SLEEP TIMER
BLUE BACK
CHANNEL GUARD
REFRESH
PICTURE SHIFT
TV OK
D0023-EN
BACK
OFF ON
OFF
SLEEP TIMER
You can set the TV to automatically turn off after a
specified period of time.
1 Choose SLEEP TIMER, then press the aaaa
button
A Sub-menu of the SLEEP TIMER function appears.
SLEEP TIMER
0120
OFF
BACK
TV OK
D0024-EN
2 Press the 5555 buttons to set the period of time.
Then press the aaaa button
You can set the period of time a maximum of 120
minutes (2 hours) in 10 minute increments.
• One minute before the SLEEP TIMER function turns
off the TV, “GOOD NIGHT!” appears.
• The SLEEP TIMER function cannot be used to turn
off the TV’s main power.
• When the SLEEP TIMER function is on, you can
display the Sub-menu of the SLEEP TIMER function
again to confirm and/or change the remaining period
of time of the SLEEP TIMER function. Press the a
button to exit the menu after confirming and / or
changing the remaining time.
To cancel the SLEEP TIMER function:
Press the 2 button to set a period of time to “OFF”.
BLUE BACK
You can set the TV to automatically change to a blue screen
and mute the sound if the signal is weak or absent, or when
there is no input from an external device.
ON:
This function is turned on.
OFF:
This function is turned off.
CHANNEL GUARD
When there is a TV channel you wish your children not to
watch, you can use the CHANNEL GUARD function to
lock out the TV channel. Even when a child chooses a
Programme number (PR) in which a locked TV channel has
been registered, the screen will change to blue and displays
n (CHANNEL GUARD) so the TV channel cannot be
viewed. Unless you enter a pre-set ID number by a special
operation, the lock cannot be released and the child cannot
view the TV channel programmes.
To set the CHANNEL GUARD function
1 Choose CHANNEL GUARD, then press the
o
o button
oo
“SET ID NO.” (ID number setting screen) appears.
SET ID NO.
0 000
BACK
TV OK
D0025-EN
2 Set the ID number to your liking
1 Press the 6666 buttons to choose a number.
2 Press the 5555 buttons to move the cursor.
3Press the aaaa button
The Sub-menu of CHANNEL GUARD appears.
CHANNEL GUARD
PR ID
AV
01
02
03
04
05
06
07
08
09
BACK
TV OK
D0026-EN
BBC1
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
LOCK
4Press the 6666 buttons to choose a TV channel
Every time you press the 6 buttons, the Programme
number (PR) changes, and the picture of the TV channel
registered in the Programme number (PR) is displayed
on the screen.
5 Press the blue button and set the CHANNEL
GUARD function.
Then press the aaaa button
n (CHANNEL GUARD) appears and the TV channel is
locked.
To reset the CHANNEL GUARD function:
Press the blue button again.
n (CHANNEL GUARD) disappears.
To disable easy resetting of the CHANNEL GUARD
function, the menu disappears by choosing the
CHANNEL GUARD function and pressing the a
button as in the ordinary menu operation.
To view a locked TV channel
1 Choose a Programme number (PR) in which a
TV channel locked with the Number buttons or
PR LIST
The screen changes to blue and the n (CHANNEL
GUARD) appears. You cannot view the TV channel.
5
D0027-EN
2Press the
NO.” (ID NO. input screen)
5
ID NO . :
D0028-EN
(Information) button to display “ID
hhhh
ENGLISH
27
Page 30
FEATURES
3 Press the Number buttons to enter the ID
number
The lock is temporarily released so you can view the TV
channel.
If you have forgotten the ID number:
Perform step 1 of “To set the CHANNEL GUARD
function”. After confirming the ID number, press the
b button to exit the menu.
ENGLISH
REFRESH
• Even if you reset the lock temporarily, it does not
mean that the CHANNEL GUARD function set for
the TV channel is cancelled. The next time anyone
attempts to view the TV channel, it will be locked
again.
• When you would like to cancel the CHANNEL
GUARD function, you must perform the operation
“To set the CHANNEL GUARD function” again.
• To disable easy choosing of a Programme number
(PR) in which a locked TV channel has been
registered, the Programme number (PR) has been set
that it cannot be chosen by the 6 buttons or the
operation buttons at the TV.
• To disable easy resetting of the lock, “ID NO.” (ID
NO. input screen) is set so that it cannot appear unless
you press the h (Information) button.
When burn-in is minimal, burn-in and residual images may
be softened with the REFRESH function.
1 Choose REFRESH
2 Press the aaaa button
Snow appears on the screen. Leave the TV in this
condition for a few hours.
3 After a few hours, press the TV, number
buttons, or #### button
Press the A button for the TV.
The REFRESH function has no effect if used only for a
short time.
PICTURE SHIFT
The picture displayed on the screen is shifted up, down and
to the left and right at regular intervals. In order to prevent
burn-in, set this function to FAST or SLOW.
1 Choose PICTURE SHIFT
2 Press the 5555 buttons to choose a mode
OFF:
PICTURE SHIFT is turned off.
SLOW:
The picture is shifted every 30 minutes.
FAST:
The picture is shifted every 10 minutes.
3 Press the aaaa button
The menu disappears
28
Page 31
INSTALL
Refer to “Using the TV’s menu” (see page 20) for details of
displaying the menu.
INSTALL
LANGUAGE
AUTO PROGRAM
EDIT / MANUAL
BACK
TV OK
D0029-EN
LANGUAGE
You can choose the language you want to use for the onscreen display from the language list in a menu.
1 Choose LANGUAGE, then press the aaaa button
A sub-menu of the LANGUAGE function appears.
LANGUAGE
BACK
TV OK
D0002(E)-EN
2 Press the 5555 and 6666 buttons to choose a
language. Then press the aaaa button
AUTO PROGRAM
You can automatically register the TV channels which can
be received well at your residence in the TV’s Programme
numbers (PR) by performing the following.
1 Choose AUTO PROGRAM. Then press the aaaa
button
The TELETEXT LANGUAGE menu appears as a submenu of the AUTO PROGRAM function.
TELETEXT LANGUAGE
GROUP-1
GROUP-2
GROUP-3
GROUP-4
BACK
TV OK
D1003-EN
2 Press the 6666 buttons to choose the teletext
language group that corresponds to the
language of teletext programme that you want
to watch
Group Languages
GROUP-1 Turkish, Hungarian, English, German,
GROUP-2 Polish, Serbian, Croatian, Slovenian,
GROUP-3 Russian, Bulgarian, Lettish, Lithuanian,
GROUP-4 Arabic, Czech, Slovak, Hungarian,
French, Italian, Spanish, Portuguese,
Greek, Swedish, Finnish
Czech, Slovak, Rumanian, Hungarian,
German, French, Italian, Swedish,
Finnish
Estonian, Ukrainian, Serbian, Croatian,
Slovenian, Czech, Slovak, English,
German
English, German, French, Italian,
Spanish, Portuguese, Swedish, Finnish
3Press the aaaa button to start the AUTO
PROGRAM function
The AUTO PROGRAM menu appears and received TV
channels are automatically registered in the Programme
numbers (PR).
• To cancel the AUTO PROGRAM function, press the
b button.
AUTO PROGRAM
20%
BACK
TV OK
D0004-EN
CH 10
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
BACK
MOVE
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
ID
INSERT
DELETE
MANUAL
After the TV channels have been registered in
the Programme numbers (PR), the EDIT menu
appears.
• You can proceed to edit the Programme numbers
(PR) using the EDIT/MANUAL function. For details,
see “EDIT/MANUAL” on page 29.
• If you do not need to use the EDIT/MANUAL
function, go to the next step.
4Press the aaaa button
EDIT/MANUAL
The EDIT/MANUAL functions are divided into two types:
editing of the current Programme numbers (PR) (EDIT
functions) and manual registration of a TV channel you
want to view to the Programme number (PR) (MANUAL
function). The details about these functions are as follows:
Caution
• Using the MOVE, DELETE or INSERT function
rewrites the current Programme numbers (PR) list.
Resultingly, the Programme number (PR) of some of
the TV channels will change.
• Using the MANUAL function for a TV channel for which
the CHANNEL GUARD function has been set cancels
the CHANNEL GUARD function for the TV channel.
• When a TV channel has already been registered in PR
99, using the INSERT function deletes the TV channel.
1 Choose EDIT/MANUAL, then press the aaaa
button
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
BACK
TV OK
MOVE
D0038-EN
• For Programme number PR 0, “AV” appears in the
Programme numbers (PR) list.
• A VIDEO terminal number does not appear in the
Programme numbers (PR) list.
• The CH/CC number is a number unique to the TV
and corresponding to the Channel number of a TV
channel. For the relationship of a Channel number
and a CH/CC number, see “CH/CC numbers” on
page 35.
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
ID
INSERT
DELETE
MANUAL
ENGLISH
29
Page 32
INSTALL
ENGLISH
MOVE
ID
2 Follow the operation description of a function
you want to use and operate the function
MOVE:
This function changes a Programme number (PR) of a
TV channel.
ID:
This function registers a Channel name (ID) to a TV
channel.
INSERT:
This function adds a new TV channel in the current
Programme numbers (PR) list by using the CH/CC
number.
• You cannot use the INSERT function if you do not
know a Channel number of a TV channel. Use the
MANUAL function to register a TV channel in the
Programme number (PR).
DELETE:
This function deletes an unnecessary TV channel.
MANUAL:
This function manually registers a new TV channel in a
Programme number (PR).
3 Press the aaaa button
1 Press the 6666 buttons to choose a TV channel
Every time you press the 6 buttons, the Programme
number (PR) is changed over, and the picture of the TV
channel registered in the Programme number (PR)
appears on the screen.
2 Press the 3333 button to start the MOVE function
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
D0030-EN
BACK
STORE
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
21
22
23
24
25
26
02
03
CC 01
3 Press the 6666 buttons to choose a new
Programme number (PR)
To cancel the MOVE function:
Press the h (Information) button.
4 Press the 2222 button to change the Programme
number (PR) of a TV channel to a new
Programme number (PR)
1 Press the 6666 buttons to choose a TV channel
Every time you press the 6 buttons, the Programme
number (PR) is changed over, and the picture of the TV
channel registered in the Programme number (PR)
appears on the screen.
2 Press the red button to start the ID function
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
D0031-EN
BACK
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
ID LIST
3 Enter a channel name (ID).
Press the 6666 buttons to choose a character.
Press the 5555 buttons to move the cursor.
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
D0032-EN
BACK
CH / CC
CH
21
CH
22
CH
23
CH
24
CH
25
CH
26
CC
M
01
CC
02
CC
03
ID LIST
To cancel the ID function:
Press the h (Information) button.
4Press the aaaa button to register a Channel name
(ID) to a TV channel
INSERT
Preparation:
• A CH/CC number unique to this TV and corresponding
to the Channel number of a TV channel is required. Find
the corresponding CH/CC number from a table “CH/CC
numbers” on page 35 based on the Channel number of
the TV channel.
1Press the 6666 buttons to choose a Programme
number (PR) for which you will register a new
TV channel
2 Press the green button and start the INSERT
function
EDIT
PR ID
AV
01
02
03
04
05
06
07
08
09
TV OK
CH / CC
D0034-EN
3Press the 6666 buttons to choose “CC” or “CH”
according to the CH/CC number of the TV
channel
To cancel the INSERT function:
Press the h (Information) button.
BACK
0 9
CH / CC
CH
CH
CH
CH
CH
CH
CH
CC
CC
21
22
23
24
25
26
02
03
30
Page 33
INSTALL
4 Press the Number buttons to enter the
remaining CH/CC number
The TV shifts to registration mode.
When the registration is completed, the picture of the TV
channel appears on the screen.
• The CH/CC number is a number indicating the
broadcast frequency to the TV. If the TV cannot
detect the TV channel corresponding to the broadcast
frequency indicated by the CH/CC number, a picture
in the no-signal state appears.
DELETE
1 Press the 6666 buttons to choose a TV channel
Every time you press the 6 buttons, the Programme
number (PR) is changed over, and the picture of the TV
channel registered in the Programme number (PR)
appears on the screen.
2 Press the yellow button to delete the TV
channel
The TV channel is deleted from the Programme numbers
(PR) list.
MANUAL
1 Press the 6666 buttons to choose a Programme
number (PR) to which you want to register a
new TV channel
2 Press the blue button to activate the MANUAL
function
At the right side following the CH/CC number, the
SYSTEM (broadcasting system) of the TV channel
appears.
MANUAL
PR ID
AV
01
02
03
04
05
06
07
08
09
BACK
TV OK
SYSTEM
D0035-EN
To cancel the MANUAL function:
Press the h (Information) button.
CH / CC
CH
CH
CH
CH
CH
CH
CC
CC
CC
21
22
23
24
25
26
01
02
03
(
B / G
SEARCH
SEARCH
+
FINE
-
FINE
)
+
-
Sound system
Area Country or region System
Bahrain, Kuwait, Oman, Qatar, United
Arab Emirates, Yemen, etc.
Indonesia, Malaysia, Singapore,
B/G
Thailand, India, etc.
Asia,
Middle
East
China, Vietnam, etc. D/K
Hong Kong, etc. I
Islamic Republic of Iran, Lebanon,
Saudi Arabia, etc.
B/G
Philippines, Taiwan, Myanmar, etc M
Russia, etc. D/K
Europe
Czech Republic, Poland, etc. D/K
Germany, Holland, Belgium, etc. B/G
UK, etc. I
Oceania Australia, New Zealand, etc. B/G
Republic of South Africa, etc. I
Africa
Nigeria, etc. B/G
Egypt, Morocco, etc. B/G
4 Press the green or red button to search for a TV
channel
Scanning stops when the TV finds a TV channel. Then
the TV channel is displayed.
5 Press the green or red button repeatedly until
the TV channel you want appears
If the TV channel reception is poor:
Press the blue or yellow button to fine-tune the TV
channel.
If you cannot hear the normal sound even when
the picture of the TV channel appears normally:
The SYSTEM setting is wrong. Press the 3 button and
choose a SYSTEM that has normal sound.
6Press the aaaa button and register the TV
channel to a Programme number (PR)
The normal EDIT menu is resumed.
ENGLISH
3 Press the 3333 button to choose the SYSTEM
(sound system) for a TV channel you want to
register
Refer to the following table for the various international
sound systems.
31
Page 34
INSTALL
Changing the TELETEXT LANGUAGE
setting
After the AUTO PROGRAM function is completed, you
can change the country you have already set by using the
AUTO PROGRAM function.
1 Display the INSTALL menu
When the EDIT menu is currently being
ENGLISH
displayed:
Press the h (Information) to return to the INSTALL
menu.
2 Press the 6666 buttons to choose AUTO
PROGRAM. Then press the aaaa button
A TELETEXT LANGUAGE menu appears as a submenu of the AUTO PROGRAM function.
TELETEXT LANGUAGE
GROUP-1
GROUP-2
GROUP-3
GROUP-4
BACK
TV OK
D1003-EN
Group Languages
GROUP-1 Turkish, Hungarian, English, German,
French, Italian, Spanish, Portuguese,
Greek, Swedish, Finnish
GROUP-2 Polish, Serbian, Croatian, Slovenian,
Czech, Slovak, Rumanian, Hungarian,
German, French, Italian, Swedish,
Finnish
GROUP-3 Russian, Bulgarian, Lettish, Lithuanian,
Estonian, Ukrainian, Serbian, Croatian,
Slovenian, Czech, Slovak, English,
German
GROUP-4 Arabic, Czech, Slovak, Hungarian,
English, German, French, Italian,
Spanish, Portuguese, Swedish, Finnish
3 Press the 6666 buttons to choose a group
4 Press the bbbb button to complete the setting
The menu disappears.
32
Page 35
Additional preparation
Connecting the external devices
Connect the devices to the TV, paying attention to the
following connection diagram.
Before connecting anything:
• Read the manuals provided with the devices. Depending
on the devices, the connection method may differ from
the figure. In addition, the device settings may be
changed depending on the connection method to secure
proper operation.
• Turn off all the devices including the TV.
• The “Specifications” on page 38 contains the details of
the VIDEO terminals. If you are connecting a device not
listed in the following connection diagram, see the table
to choose the best VIDEO terminal.
• Note that connecting cables are not supplied.
1 VCR (composite signal)
2 VCR (S-VIDEO signal; Y/C)
3 VCR for recording (composite signal)
4 DVD player (composite signal)
5 DVD player (S-VIDEO signal; Y/C)
6 DVD player (component video signals; Pr/Pb/Y)
7 TV game (composite signal/S-VIDEO signal; Y/C)
8 Headphones
9 Camcorder (composite signal/S-VIDEO signal; Y/C)
0 Audio/Video cable
- Video cable
= Audio cable
~ S-VIDEO cable
! Component cable
OUT IN
ENGLISH
Front of the receiver
AUDIO
S VIDEO
R
L
IN(VIDEO-5)
AUDIOS
VIDEO
RL
IN(VIDEO-5)
Back of the receiver
OUTIN
AUDIO
VIDEO
L
R
Pr
Pb Y
VIDEO-1
VIDEO-2
VIDEO-3
AUDIO
R
R
L/MONO
L
LR
VIDEO S-VIDEO
COMPONENT(VIDEO-4)
R-AUDIO-L
OUT OUT
L
R
AUDIO
OUT
33
Page 36
Additional preparation
D
Connecting devices to the OUT terminal
The signals of the images and sound you are currently
viewing with this TV are output through the OUT terminal.
By connecting a VCR to the OUT terminal, you can record
the currently shown image and sound to that VCR. To do
this, connect the VCR and OUT terminal following the
steps below.
1 Connect the VIDEO in the OUT terminals and
the VCR’s VIDEO IN (video input) terminal with
ENGLISH
a video cable
2 Connect the AUDIO (L and R) in the OUT
terminals and the VCR’s AUDIO IN (audio L/R
input) terminals with an audio cable
• When you turn off the TV, the signals from the OUT
terminal are also turned off.
• No signal is output when VIDEO-4 is chosen.
Connecting headphones
Connect the headphones with a stereo mini-jack (of 3.5 mm
in diameter) to the headphone jack at the receiver.
• The headphone volume is adjusted with the
“HEADPHONE” menu (see page 25).
Connecting Speakers/Amplifier
See the Audio equipment connection diagram, then connect
the audio equipment you desire to the TV.
You can use external front speakers to listen to the TV
sound instead of the TV speakers.
Before connecting anything:
• Read the manuals provided with the amplifier and
speakers.
• Turn the TV and amplifier off.
• To prevent magnetism from the speakers adversely
affecting the TV screen, use magnetically-shielded
speakers for the front speakers.
• Note that connecting cables are not supplied.
Back of the receiver
L
R
VIDEO
EO-4)
L
R
AUDIO
Y
OUT
1 Amplifier
2 External speakers (Magnetic-shielded type)
• The output from the AUDIO OUT terminal is not
interrupted by headphone connection to the TV. You
cannot cut the sound from the front speaker even if you
connect a headphone to the TV.
• Adjust the volume of the external speakers with the
amplifier.
34
Page 37
CH/CC numbers
When you want to use the INSERT function on page 30, find the CH/CC number corresponding to the Channel number of the TV
channel from this table.
US: The US channel numbers are the channel numbers used in the United States, Philippines, etc.
CCIR: The CCIR channel numbers are the channel numbers used in the Middle East, Southeast Asia, etc.
OIRT: The OIRT channel numbers are the channel numbers used in Eastern Europe, Russia, Vietnam, etc.
AUSTRALIA: The AUSTRALIA channel numbers are the channel numbers used in Australia, etc.
CH
CH02 US-2 E2 R1 AU-0
CH03 US-3 E3 AU-1
CH04 US-4 E4 R2 AU-2
CH05 US-5 E5 R6 AU-6
CH06 US-6 E6 R7 AU-7
CH07 US-7 E7 R8 AU-8
CH08 US-8 E8 R9 AU-9
CH09 US-9 E9
CH10 US-10 E10 R10 AU-10
CH11 US-11 E11 R11 AU-11
CH12 US-12 E12 R12
CH13 US-13
CH14 US-14, W+29
CH15 US-15, W+30
CH16 US-16, W+31
CH17 US-17, W+32
CH18 US-18, W+33
CH19 US-19, W+34
CH20 US-20, W+35
CH21 US-21, W+36 E21
CH22 US-22, W+37 E22
CH23 US-23, W+38 E23
CH24 US-24, W+39 E24
CH25 US-25, W+40 E25
CH26 US-26, W+41 E26
CH27 US-27, W+42 E27
CH28 US-28, W+43 E28
CH29 US-29, W+44 E29
CH30 US-30, W+45 E30
CH31 US-31, W+46 E31
CH32 US-32, W+47 E32
CH33 US-33, W+48 E33
CH34 US-34, W+49 E34
CH35 US-35, W+50 E35
CH36 US-36, W+51 E36
CH37 US-37, W+52 E37
CH38 US-38, W+53 E38
CH39 US-39, W+54 E39
CH40 US-40, W+55 E40
CH41 US-41, W+56 E41
CH42 US-42, W+57 E42
CH43 US-43, W+58 E43
CH44 US-44, W+59 E44
CH45 US-45, W+60 E45
CH46 US-46, W+61 E46
CH47 US-47, W+62 E47
CH48 US-48, W+63 E48
CH49 US-49, W+64 E49
CH50 US-50, W+65 E50
CH51 US-51, W+66 E51
CH52 US-52, W+67 E52
CH53 US-53, W+68 E53
CH54 US-54, W+69 E54
CH55 US-55, W+70 E55
CH56 US-56, W+71 E56
CH57 US-57, W+72 E57
CH58 US-58, W+73 E58
CH59 US-59, W+74 E59
CH60 US-60, W+75 E60
CH61 US-61, W+76 E61
CH62 US-62, W+77 E62
CH63 US-63, W+78 E63
CH64 US-64, W+79 E64
CH65 US-65, W+80 E65
CH66 US-66, W+81 E66
CH67 US-67, W+82 E67
CH68 US-68, W+83 E68
CH69 US-69, W+84 E69
US CCIR OIRT AUSTRALIA
Channel
CC
CC01 S-1 AU-5
CC02 S-2
CC03 S-3
CC04 S-4
CC05 S-5
CC06 S-6 AU-5A
CC07 S-7
CC08 S-8
CC09 S-9
CC10 S-10
CC11 S-11
CC12 S-12
CC13 S-13
CC14 A S-14
CC15 B S-15
CC16 C S-16
CC17 D S-17
CC18 E S-18
CC19 F S-19
CC20 G S-20
CC21 H S-21
CC22 I S-22
CC23 J S-23
CC24 K S-24
CC25 L S-25
CC26 M S-26
CC27 N S-27
CC28 O S-28
CC29 P S-29
CC30 Q S-30
CC31 R S-31
CC32 S S-32
CC33 T S-33
CC34 U S-34
CC35 V S-35
CC36 W S- 36
CC37 W+1 S-37
CC38 W+2 S-38
CC39 W+3 S-39
CC40 W+4 S-40
CC41 W+5 S-41
CC42 W+6
CC43 W+7
CC44 W+8
CC45 W+9
CC46 W+10
CC47 W+11
CC48 W+12
CC49 W+13
CC50 W+14
CC51 W+15
CC52 W+16
CC53 W+17
CC54 W+18
CC55 W+19
CC56 W+20
CC57 W+21
CC58 W+22
CC59 W+23
CC60 W+24
CC61 W+25
CC62 W+26
CC63 W+27
CC64 W+28
CC75 X
CC76 Y R3
CC77 Z R4 AU-3
CC78 Z+1 R5
CC79 Z+2 AU-4
CC95 A-5
CC96 A-4
CC97 A-3
CC98 A-2
CC99 A-1
US CCIR OIRT AUSTRALIA
Channel
ENGLISH
35
Page 38
Troubleshooting
If a problem arises while you are using the TV, please read this “Troubleshooting” well before you request having the TV repaired.
You may be able to fix it easily by yourself. For example, if the AC plug is disconnected from the AC outlet, or the TV aerial has
problems, you may think there is a problem with the TV itself.
Important:
• This Troubleshooting guide only covers problems whose cause are not easy to determine. If a question arise when you are
operating a function, read the page(s) corresponding to the operation of the function well, not this Troubleshooting guide.
• After you have followed the Troubleshooting description or the operating description of the functions concerned without any
success, remove the AC plug from the AC outlet and request a repair of your TV. Do not attempt to repair the TV by yourself or
remove the rear cover of the TV.
ENGLISH
If you cannot turn on the TV
• Are the AC plugs on the power cords from the TV and
receiver connected to AC outlets?
• Make sure to set the VCR/TV/DVD switch to the TV
position. You cannot turn the TV on when the VCR/TV/
DVD switch is set to the VCR or DVD position.
If you cannot turn off the TV
• Make sure to set the VCR/TV/DVD switch to the TV
position. You cannot turn the TV off when the VCR/TV/
DVD switch is set to the VCR or DVD position.
No picture/No sound
• Have you chosen a TV channel whose reception is
extremely bad? In this case, the BLUE BACK function
will be activated, the entire screen becomes blue, and the
sound is muted. In spite of this, if you want to view the
TV channel, follow the description “BLUE BACK” on
page 27 to try to change the BLUE BACK function
setting to OFF.
• Have you set the SPEAKER function to OFF? Follow
the description “SPEAKER” on page 24 to confirm the
SPEAKER function setting to try to solve the problem.
• If the SYSTEM setting for a TV channel is incorrect, it
may prevent the sound from being issued. Follow the
description “EDIT/MANUAL” on page 29 to use the
MANUAL function to try to change the SYSTEM
setting.
Poor picture
• If noise totally obscures the picture (snow), the aerial or
aerial cable may have trouble. Check the following to try
to solve the trouble:
Has the TV and aerial been connected properly?
Has the aerial cable been damaged?
Is the aerial pointed to the right direction?
Is the aerial itself faulty?
• If the TV or aerial receives interference from the other
devices, stripes or noise may appear in the picture. Move
such devices as an amplifier, personal computer, or a
hair drier that can cause interference away from your
TV, or try changing its location. If the aerial suffers
interference from a radio tower or high-voltage wire,
please contact your local dealer.
• If the TV receives interference from signal reflecting
from mountains or building, double-pictures (ghosting)
will occur. Try to change the aerial’s direction or replace
the antenna with the one with better directionality.
• Are your COLOUR SYSTEM settings for the TV
channels correct? Follow the description “COLOUR
SYSTEM” on page 23 to try to solve the trouble.
• Has COLOUR or BRIGHT been controlled properly?
Follow the description “Picture Adjustment” on page 21
to try to adjust them properly.
• Videotaping teletext is not recommended because it may
not record correctly.
• When viewing images from commercially available
video software products, or videos from videotapes
which have been recorded improperly, the top of the
image may be distorted. This is due to the condition of
the video signal, and not because of malfunction.
Poor sound
• Have you adjusted BASS or TREBLE properly? If not,
follow the description “Sound Adjustment” on page 24
to try to adjust them properly.
• When the TV channel reception is poor, it can be hard to
hear the stereo or bilingual sound. In this case, follow the
description “STEREO / I • II” on page 24 to hear the
sound more easily by changing it to a mono sound.
Operation disabled
• Have the batteries of the remote control become
exhausted? Follow the description “Putting the batteries
into the Remote control” on page 6 and replace them
with new batteries to try to solve the problem.
• Have you attempted to use the remote control at the sides
or rear of the TV or at a location more than seven meters
apart from the TV location? Operate the remote control
in the front of your TV or a location less than seven
meters from your TV to try to solve the problem.
• When you are viewing a teletext programme, you cannot
operate the menus. Press the b button to return the
teletext programme to the ordinary TV programme to try
operating the menus.
• If the TV suddenly stops responding, disconnect the
power cords of the TV and receiver from the AC outlets.
Connect them to the AC outlets again to turn on the TV.
If the TV returns to a normal state, it is not a failure.
36
Page 39
Other concerns
• When the SLEEP TIMER function operates, the TV is
automatically turned off. If the TV is turned off
suddenly, try to press the # (Standby) button to turn on
the TV once again. At this time, if the TV resumes a
normal state, there is no problem.
• When a WSS signal is included in the broadcast signal or
the signal from an external device, or when the TV is
receiving a control signal from an external device, the
ZOOM mode will change automatically. When you want
to return to the previous ZOOM mode, press the c
button to choose the ZOOM mode again.
• It takes a short period of time from the time an operation
such as changing channels is performed until an image is
displayed. This is not a malfunction. This is the time
required for the image to stabilize before it can be
displayed.
• The TV may emit a crackling sound due to a sudden
change in temperature. It does not matter if a picture or
sound does not show any abnormality. If you hear
crackling sounds frequently while you are viewing the
TV, other causes may be assumed. For precautionary
purposes, request your service technician to inspect it.
• In the twin pictures mode the sub-picture may disappear
when the external device is operated. If this happens,
press the R button and display the sub-picture again.
• The headphone volume is adjusted with the
“HEADPHONE” menu. It cannot be adjusted with the
r (volume) q buttons.
• When TV SPEAKER in the “HEADPHONE” menu is
ON, even if the headphones are connected, sound is
emitted from the TV speaker. When you do not want to
emit sound from the TV speaker, turn the setting OFF.
• Even if the PICTURE SHIFT function is turned off, the
picture may shift to the left or right when the channel or
input is changed. This is to prevent burn-in and is not a
malfunction.
Troubleshooting
ENGLISH
37
Page 40
Specifications
Item
Model
Broadcasting systems B, G, I, D, K, K1, M
Colour systems PAL, SECAM, NTSC 3.58/4.43 MHz
Channels and frequencies VHF low channel (VL) =46.25 to 168.25 MHz
Sound-multiplex systems A2 (B/G, D/K), NICAM (B/G, I, D/K) system
ENGLISH
Teletext systems FLOF (Fastext), TOP, WST (World Standard System)
Languages displayed by teletext Please see the table in the description “Changing the TELETEXT LANGUAGE setting” on page 32.
Power requirements AC 110 to 240 V, 50/60 Hz
Power consumption TV:
Screen size Viewable area 107.5 cm (measured diagonally)
Audio output Rated Power output: 18 W + 18 W
Speakers (3 cm × 10 cm) oval × 2
VIDEO-1 terminal RCA connectors × 3
VIDEO-2 terminal RCA connectors × 3, S-VIDEO connector × 1
VIDEO-3 terminal RCA connectors × 3, S-VIDEO connector × 1
VIDEO-4 terminal RCA connectors × 5
VIDEO-5 terminal RCA connectors × 3, S-VIDEO connector × 1
OUT terminal RCA connectors × 3
AUDIO OUT terminal RCA connectors × 2
Headphone jack Stereo mini-jack (3.5 mm in diameter)
Dimensions (W × H × D) TV: 1160 mm × 731 mm × 108 mm (TV only)
Weight TV: 38 kg (TV only)
Accessories Refer to “Checking contents of packages” on page 5.
VHF high channel (VH) =175.25 to 463.25 MHz
UHF channel (U) =471.25 to 855.25 MHz
• Receives cable channels in mid band (X to Z+2, S1 to S10), super band (S11 to S20) and hyper band (S21 to
S41).
330 W, Standby: 1.5 W
Receiver:
30 W, Standby: 2.4 W
(6.5 cm × 13 cm) oval × 2
• Video input and Audio L/R inputs are available.
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Component video (Pr, Pb, Y) inputs and Audio L/R inputs are available.
• progressive-scanning signals (625p or 525p) are available.
• Video input, S-VIDEO (Y/C) input and Audio L/R inputs are available.
• Video output and Audio L/R outputs are available.
• Audio L/R outputs are available.
Receiver: 435 mm × 99 mm × 382 mm
Receiver: 5.3 kg
PD-42DV2
38
Design and specifications subject to change without notice.
Pictures displayed on the screen using this TV’s ZOOM functions should not be shown for any commercial or demonstration purpose
in public places (cafes, hotels, etc.) without the consent of the owners of copyright of the original picture sources, as this constitutes an
infringement of copyright.
Page 41
Page 42
Page 43
Page 44
6
© 2003 VICTOR COMPANY OF JAPAN, LIMITED
1003-MK-CR-VP
Loading...
