JVC KDDV-5202-EU, KDDV-5205-UT, KDDV-5205-U, KDDV-5201-EU, KDDV-5206-U Service manual

SERVICE MANUAL

DVD/CD RECEIVER

MA26420065

KD-DV5201EU,KD-DV5202EU,

KD-DV5205U,KD-DV5205UT,
KD-DV5206U,KD-DV5206UT,
KD-DV6205U,KD-DV6205UT,

KD-DV6205A,KD-DV6206U,

KD-DV6206UT,KD-DV6206A

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

TABLE OF CONTENTS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

COPYRIGHT © 2006 Victor Company of Japan, Limited

No.MA264

2006/5

SPECIFICATION

KD-DV5202/KD-DV5201

AUDIO AMPLIFIER SECTION

Maximum Power Output Front 50 W per channel

Rear 50 W per channel

Continuous Power
Output (RMS)

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range Frequencies 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz, 15 kHz

Signal-to-Noise Ratio 70 dB

Audio Output Level Analog (2nd AUDIO OUT) 6 mW (at 16 Ω)

Subwoofer-Out Level/Impedance 2.0 V/20 kΩ load (full scale)

Color System PAL

Video Output (composite) 1 Vp-p/75 Ω

Other Terminals LINE IN, CD changer

Frequency Range FM 87.5 MHz to 108.0 MHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

MW Tuner Sensitivity 20 µV

LW Tuner Sensitivity 50 µV

Signal Detection System Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz/96 kHz 16 Hz to 22 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 (MPEG Audio Layer 3) Max. Bit Rate : 320 kbps

WMA (Windows Media® Audio) Max. Bit Rate : 192 kbps

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Mass (approx.) 1.7 kg (excluding accessories)

Front 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than

0.8% total harmonic distortion.

Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than

0.8% total harmonic distortion.

Level ±10 dB

Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 5.0 V/20 kΩ load (full scale)

Output Impedance : 1 kΩ

TUNER SECTION

AM (MW) 522 kHz to 1 620 kHz

(LW) 144 kHz to 279 kHz

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 Db

Selectivity 35 dB

DVD/CD PLAYER SECTION

VCD, CD, MP3, WMA 16 Hz to 20 000 Hz

GENERAL

Panel Size (approx.) 188 mm × 58 mm × 11 mm

1-2 (No.MA264)

KD-DV6206/KD-DV6205/KD-DV5206/KD-DV5205

AUDIO AMPLIFIER SECTION

Maximum Power Output Front 50 W per channel

Rear 50 W per channel

Continuous Power
Output (RMS)

Load Impedance 4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range Frequencies 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.4 kHz, 6 kHz, 15 kHz

Signal-to-Noise Ratio 70 dB

Audio Output Level KD-DV6206/KD-DV6205 Analog (2nd AUDIO OUT)

Subwoofer-Out Level/Impedance 2.0 V/20 kΩ load (full scale) (KD-DV6206/KD-DV6205)

Color System PAL/NTSC

Video Output (composite) 1 Vp-p/75 Ω

Other Terminals LINE IN, CD changer

Frequency Range FM 87.5 MHz to 108.0 MHz

FM Tuner Usable Sensitivity 11.3 dBf (1.0 µV/75 Ω)

AM Tuner Sensitivity 20 µV

Signal Detection System: Non-contact optical pickup (semiconductor laser)

Number of Channels 2 channels (stereo)

Frequency Response DVD, fs=48 kHz/96 kHz 16 Hz to 22 000 Hz

Dynamic Range 96 dB

Signal-to-Noise Ratio 98 dB

Wow and Flutter Less than measurable limit

MP3 (MPEG Audio Layer 3) Max. Bit Rate : 320 kbps

WMA (Windows Media® Audio) Max. Bit Rate : 192 kbps

Power Requirement Operating Voltage DC 14.4 V (11 V to 16 V allowance)

Grounding System Negative ground

Allowable Operating Temperature 0°C to +40°C
Dimensions (W × H × D) Installation Size (approx.) 182 mm × 52 mm × 158 mm

Mass (approx.) 1.7 kg (excluding accessories)

Front 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than

0.8% total harmonic distortion.

Rear 19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than

0.8% total harmonic distortion.

Level ±10 dB

6 mW (at 16 Ω)

Digital (DIGITAL OUT: Optical) Signal wave length : 660 nm

Output level : -21 dBm to -15 dBm

Line-Out Level/Impedance 5.0 V/20 kΩ load (full scale) (KD-DV6206/KD-DV6205)

2.5 V/20 kΩ load (full scale) (KD-DV5206/KD-DV5205)
Output Impedance : 1 kΩ

TUNER SECTION

AM 531 kHz to 1 602 kHz

50 dB Quieting Sensitivity 16.3 dBf (1.8 µV/75 Ω)

Alternate Channel Selectivity (400 kHz) 65 dB

Frequency Response 40 Hz to 15 000 Hz

Stereo Separation 30 dB

Selectivity 35 dB

DVD/CD PLAYER SECTION

VCD, CD, MP3, WMA 16 Hz to 20 000 Hz

GENERAL

Panel Size (approx.) 188 mm × 58 mm × 11 mm

Design and specifications are subject to change without notice.

(No.MA264)1-3

SECTION 5

TROUBLESHOOTING

5.1 16 PIN CORD DIAGRAM (for KD-DV5201EU, KD-DV5202EU)

8

GN/BK

7

6

5

4

BL/WH

3

2

1

2 RD

16 YL

1 BK

3 BL/WH

13 BR

15 OR/WH

6 GN

7 GN/BK

5 VI

GN

VI/BK

VI

NC

RD

BK

WH

WH/BK

GY/BK

GY

BR

YG

OR/WH

YL

10

11

12

13

14

15

16

9

ACC

MEMORY

GND

REMOTE

TEL

ILL

RL+

RL-

RR+

BK

RD

BL

WH

BR

YG

Black

Red

Blue

White

Brown

Yellow Green

GN

VI

GY

YL

OR

TEL MUTING

ILLUMINATION
CONTROL

Green

Violet

Gray

Yellow

Orange

RD

1

3

5

7

RD 7

YL 4

NC

NC

BL/WH

RD

8

5

2

6

7

8

1

BR

YL

OR/WH

BK

2

4

6

8

6 VI/BK

9 WH

10 WH/BK

12 GY

11 GY/BK

14 YG

RR

FR

FL

RL

RR-

FL+

FL-

FR+

FR-

PARKING

Rear Right

Front Right

Front Left

Rear Left

ANT

ACC

TEL

GND

Auto Antenna

ACC Line

Telephone Muting

Ground

2

5

6

3

4

PARKING
BRAKE

VI/BK

GY/BK

WH/BK

GN/BK

2

4

6

8

VI

1

3

GY

5

WH

GN

7

REMOTE

ILL

Remote

Illuminations Control

MEMORY

PARKING

Memory Backup Battery+

Parking Brake

(No.MA264)1-5

5.2 16 PIN CORD DIAGRAM (except KD-DV5201EU, KD-DV5202EU)

8

7

6

5

4

3

2

1

GN

GN/BK

VI/BK

VI

BL

BL/WH

RD

BK

WH

WH/BK

GY/BK

GY

BR

YG

OR/WH

YL

10

11

12

13

14

15

16

9

BK

RD

BL

WH

BR

YG

Black

Red

Blue

White

Brown

Yellow Green

GN

VI

GY

YL

OR

Green

Violet

Gray

Yellow

Orange

1 BK

16 YL

2 RD

15 OR/WH

9 WH

10 WH/BK

12 GY

11 GY/BK

8 GN

7 GN/BK

5 VI

6 VI/BK

3 BL/WH

GND

MEMORY

ACC

ILL

FL+

FL-

FR+

FR-

RL+

RL-

RR+

RR-

REMOTE

ILLUMINATION
CONTROL

GND

13 BR

4 BL

14 YG

RR

FR

FL

RL

REMOTE

ILL

1-6 (No.MA264)

TEL

ANT

PARKING

Rear Right

Front Right

Front Left

Rear Left

Remote

Illuminations Control

REMOTE OUT

TEL MUTING

POWER ANTENNA

ANT

ACC

TEL

GND

MEMORY

PARKING

Auto Antenna

ACC Line

Telephone Muting

Ground

Memory Backup Battery+

Parking Brake

PARKING
BRAKE

Block diagram

FOCUS

&

TRACKING

COIL

PICK UP

LOAD&FEED
MOTOR

SPINDLE
MOTOR

SW1 to SW3

M

M

AUX IN

DVD section

Q101
Q102

Q103
Q104

IC201

DRIVER

IC251

DRIVER

IC399

SDRAM

SW4TRVSW

A,B,C,D,E,F
RF+/-,LPC1,LPC2
CD/DVD,HAGUP

LPCO1
DVDLDCUR

LPCO2
CDLDCUR

LDIN

MA0 to MA11
MDQ0 to MDQ15
DQM0,DQM1
BA0,BA1,MCK
NWE,NCSM
NCAS,NRAS

CN101

FLM+/-

H1+/­H2+/-

CN201

H3+/­SM1 to SM3

CN202

SW2,SW3
SW1

DVD LD

CD LD

F+/­T+/-

SP MOTOR

SW4,SW5

LCD & Key switch section

S1 to S52
COM1 to COM3

AUX.L

J601

AUX.R

Used for
KD-DV5201
KD-DV5202
KD-DV6205
KD-DV6206

LCD1

LCD DISPLAY

/DRVMUTE
TRDRV
FODRV
TRSDRV
DRVCONT

LM

Q231

SPDRV
/SPMUTE
FG

SW1,SW4

D601 to D619

D645,D646

LIGHTING

DISPLAY

IC301
DV2.1

IC601

LCD DRIVER

LCDDA
LCDCL
LCDCE

EPDI
EPDO
EPSK
EPCS

AOUT3
BCK
LRCLK
PCMCLK
DACPDN
DACOCS
DCLK
DDATA

IC481

EPROM

IC401

D/A

IC411

AMP

DAC4OUT,TX
LRMUTE,UCS,SCS
SCLK,U2SDT,S2UDT

EXADT0 to EXADT15
EXADR16 to EXADR20
EXDAT0 to EXDAT15
NEXOE,NEXCE
NEXWE

FLASH ROM

/FL_RST

NRST

SDATA, SCLK

EN601

ENCODER

ENC1
ENC2

DIM_OUT

Q640,Q641

DIMMER

CONT

AOUTL+/­AOUTR+/-

IC398

IC304

RESET

D1.2V

IC302

D1.2V REG.

D3.3V

L-CH
R-CH

CPURST

IC602

REMOCON

CN403

CN402

CHANGER

REMOCON

KEY0
KEY1
KEY2

S601 to S614

S616,S617

KEY MATRIX

ANT

Used for
KD-DV5201
KD-DV5202

LINE IN

CN962

CN963

CN601

Main amplifier section

W21

Q9,Q81,Q91

CN141

LINE-L, LINE-R

CN961

Used for
KD-DV5205
KD-DV5206

J801

AUXINL

CN701

AUXINR

3.3V REG.

TU21

FM/AM TUNER

MUX

RDSDA
RDSSCK

IC71
RDS

TU MUTE

CHL
CHR

CHL
CHR

IC162

Q161,Q162

AUX/CH
SWITCH

AUX.L
AUX.R

IC101

AUX AMP

D3.3V
S3.3V

IC921

M5V

SQ
AFCK

5V REG.

LRMUTE
UCS,SCS,SCLK
U2SDT,S2UDT
CPURST

IC922

S.METER
IFCCONT,SD/ST

SEEK, MONO
FM/AM
FM/AM OSC
FM Vt,AM Vt

Tu.L
Tu.R

E.VOLUME

DVDL
DVDR

IN2L
IN2R

SCK
SI/SO

AUX/CH

Used for
KD-DV5201
KD-DV5202
KD-DV6205
KD-DV6206

D5V
M5V
S5V

VDD

PANEL DETACH

IC31

PLL

IC161

IC961

IC962
LEVEL
CONV.

IC801

JVC BUS

S701,S702

PANEL OPEN

SWITCH

IC722

EPROM

Q701,D719

LED

PLLDI
PLLDO
PLLCE
PLLCK

VOLDA, VOLCK
VOLMUTE
SACLK, SAOUT

SW1,SW4

LRMUTE
UCS,SCS,SCLK
U2SDT,S2UDT
CPURST

BUSSO
BUSSCK
BUSINT
I/O,SI/SO

KEY0 to KEY2
DIMOUT
LCDCL
LCDDA
LCDCE
ENC1,ENC2
REMOCON

POPEN
PDETACH

EPDAI
EPDAO
EPCLK

LED

IC721

CPU

DVDL
DVDR

MUTE

OUTLR
OUTRR

OUTLF
OUTRF

PON, ANT

HEADPHONE

E.VOLUME

IC371,IC381

5V LINE AMP

Q303
Q781

MUTE

Q304

VMUTE

DOUTMUTE

FAN

RESET

OUTSW

IC431

HPDATA
HPCK
HPSTB

Used for
KD-DV5205
KD-DV5206

MUTE

STBYAMPKILL

VDD,ACC5V,SW5V
CD8V,9V,10V

EACH BLOCK

IC901

REGULATOR

ANT

D851

POWER ANT

PBRK

DIMMER

TELMUTE

COMPOSITE

TX

IC723

RESET

RESET SW

Q191,Q192

SW MUTE

W-MUTE

IC421,Q421,Q422
Q431,Q432,Q782

HEADPHONE

AMP. / MUTE

HPMUTE

Q324,Q334

FL,FR

LINE OUT

MUTE

RL,RR

Q344,Q354

LINE OUT

IC301

MUTE

FRONT L+/­FRONT R+/­REAR L+/­REAR R+/-

RL,RR

POWER

AMP

ACC
REMOTE

Used for
KD-DV5205
KD-DV5206
KD-DV6205
KD-DV6206

AUTO ANT

PAR K

Q885

ILL

Q881

Q891

TEL

TEL MUTE

IC411

VIDEO AMP.

IC401

DIGITAL OUT

MUTING

Q821 to Q823

FAN CONTROL

Used for
KD-DV5201
KD-DV5202

HNDLEREM

S723

VOUT

CN191 CN421

SUBWOOFER
OUT

2nd
AUDIO OUT

LINE OUT(FRONT)

Used for

J331

KD-DV5201, KD-DV5202
KD-DV6205, KD-DV6206

LINE OUT(REAR)

CN901

SPEAKER
&
BATTERY

CN411

VIDEO
OUT

IC402

DIGITAL
OUT

CN821 CN831

M

FAN
MOTOR

OE
REMOTE

2-1

Standard schematic diagrams

Main section

(for KD-DV5201EU,KD-DV5202EU)

TU21

!

QAU0313-001

L1

4.7

PLLCE

PLLDO

PLLCK

PLLDI

SEEK

MONO

FM/AM

CN962

QGF0534F3-45X

R44

10k

10K

R43

CN963

QGB2027L9-30X

10K

R42

RA31

NRZ0065-222X

4.7k

NI

R41

R40

C28C29

47P

C48

QGB2027M3-30S

CN961

W21

QAM0105-003

100

C99

22/16

0.047

DVDL

DVDR

0.047

C969

UDZW5.1B-X

UDZW5.1B-X

C968

NI

10

R38

NQL114K-470X

C965

220/10

D713

D715

R33

0

R32

C33

0.001

39k

R35

10k

R34

10P

0.01

C38

C30

C41

C37

0.0027

10/16

C35

0.047

C42

C34

0.01

0.047

C31

0.01
C32

0.01

R37

470

C39

C40

47P

C44

R9

Q31

10

RT1N141C-X

220/10

C43

NI

C49

L31

SCS

SN74LVC32APW-X

0.1/16

C966

SW1

SW4

R921

0

0

L922
NQL56CK-220X

R969

0

R961

0

L921
NQL79GM-100X

R968

0

R967

BA33BC0FP-X

IC921

D921

1A3G-T1

C921

C922

100/10

220/10

AUXINL

AUXINR

AUXING

UDZW6.2B-X

0

0

0

D703

R701

R703

R702

D712

UDZW5.1B-X

C703

100P

C704

0.47

C705

100P

D714

UDZW5.1B-X

R36

100P

C925

220/10

UDZW6.2B-X

D702

C36

0.001

220

RT1N141C-X

IC961

UDZW6.2B-X

D701

R14

Q14

L924

10k

IFCCONT

C963

220/10

NQL56CK-220X

C926

47/10

KEY1

KEY0

22

22

R4

47K

R2

R3

R5

Q5

RT1N141C-X

0
R8

FM/AM

S2UDT

CPURST

R973

10K

R974

10K

R975

10K

C962

C911

220/10

0.001

0

L927

B922

NQLB7GM-100X

L925

NQL71EM-330X

0.1

C927

470/25

C928

KEY2

ENC1

ENC2

LCDCL

LCDCE

LCDDA

270

270

R706

R705

R704

X31
QAX0616-001Z

7P10P

IC31

TB2118F-X

!

R39

6.2k

C47

0.01
NI

NI

C46

C45

C50

100P

C961

220/10

R962

TX

100

VGND

COMPOSITE

C964

220/10

100/16

C909

C914

C915

NI

NI

Q4

4.7K

10K

2SB624/4/-X

SQ

C967

0.1/16

R923

39K

RB051L-40-X

D922

REMOCON

R7

R6

3.3K

C55

0.47/50

D906

390k

R926

10K

R707

CN701

QNZ0605-001

Q7

2SA1530A/R/-X

47K

D3

MC2838-X

15k

R58

470

R59

Q53

2SC3928A/R/-X

UCS

LRMUTE

R914

220

UDZW5.1B-X

RT1N141C-X

C929

R925

0.1

C930

D704

D705

D706

D707

D709

D710

C701

C702

D711

1SS355W-X

D2

R57

SN74HCT32APW-X

R910

Q904

4700P

150K

10K

R924

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

0.01

0.1

UDZW6.2B-X

1SS355W-X

D1

47/16

0.047

C6

C5

2SC3928A/R/-X

C54

0.1

10K

C53

0.0047

IC962

Q903

2SA1530A/R/-X

R909

2.2K

IC922

BD9781HFP-W

C931

C428

4.7/25

DVDR

DVDL

C438

4.7/25

0.0015

0.0015

0.0015

Q781
RT1P141C-X

C781

HPDATA

HPCK

HPSTB

R452

22k

C451

22k22k1047/6.3

R451R441

47/6.3

C441

R442

22k

33K

0.0015

33K

33K

33K

R171

2.2k

R461

IC371

100/10100/10

C379C389

C380

100/10

IC381

C390

100/10

NI

B102

CHR

2.2/50
C187

CHL

0.01

C169

R173

0

C170

10/16

R891
47K

MUTE

R976

56k

TELMUTE

Q891
RT1N141C-X

10/16

C903

Q892

TELCONT

0.1

C904

R892
1K

NI

100/10

C905

R977

18k

R893
NI

D891
MC2836-X

0.1

C906

C461

22/16

4.7/25

C356

47k

R353

47k

C326

4.7/25

R343

C346

4.7/25

NI

0

NI

0

B103

B105

B104

B106

R337

0

0

R357

R347

0

R327

0

R304

D302

1SS355W-X

47k

R308

2.2k

10

R307

22/16

C315

Q304

RT1N141C-X

AMPKILL

ILL

TEL

R882

10K

R885

R881

47k

47k

C891

C892

NI

0.1

C881

Q881

22/16

DIMMER

220/10

0.01

C907

C908

ANT

PON

R802

47K

C802

22P

2SC3928A/R/-X

L902

NQL56CK-220X

SI/SO

100k

22K

PBRK

!

IC901

R2S25400DS-E

R905

10k

5.6K

Q901
UN2111-X

R906

Q912
UN2211-X

1K

R907

I/O

BUSSO

R804

R803

R801

100

HD74HC126FP-X

CN141

QGA2006C1-04

C155

0.47

47K47K

R141R151

NINI

R1

47k

KTD1304-X

NI

0.01

C72

47k

R743

SD/ST

18K

0.0012

C94

R92

Q81

KTD1304-X

RDSDA

2.2/50

C77

C76

0.022

R75

2.2k

SAA6579T-X

IC71

R73

R74

2.2k

2.2k

RDSSCK

X71

47/6.3

NI

QAX0263-001Z

C71

0

R72

R71

47P

82P

C73

C74

VOLDA

VOLCK

HPSTB

SACLK

HPDATA

W-MUTE

2.2k

2.2k

2.2k

2.2k

R722

R721

R784

R730

10k

10k

R763

R765

L721

SW1

SW4

ENC1

ENC2

47k

47k

47k

47k

NI

R748

R747

R749

R750

R742

470P

220/10

C726

C725

C724

18K

0.0012

R82

C84

HPCK

NRZ0065-222X

RA721

820

R744

NQL38DK-330X

X721

8P

C727

RDSDA

2.2k

R845

R745

R746

QAX0617-001Z

27P

27P

C728

Tu.L

Tu.R

C166

10/16

C171

C181

C172

DVDL

C182

DVDR

LINE-L

LINE-G

LINE-R

AUXINL

AUXING

AUXINR

47k

47k

AFCK

R844

R843

SD/ST

1K

1k

R720

R719

10k

R718

2.2k

10M

2.2k

R740

R753

UCS

47K

RESET

33k

X722C729

QAX0401-001

R751

BUSINT

22P

C83

1/50

1/50

0.01
220/10

C4

C3

0.1/50

KTD1304-X

D5

IC721

UPD784217AGC329

VOLMUTE

R726

R735

AMPKILL

R727

R728

R729

NI

2.2k

10K

NI

2.2K

2.2K

VPP

4.7K

4.7K

220K

220K

R708

330

SLR-56VC3F

C93

R93

4.7K

4.7K

0

R13

Q9

1SS355W-X

AFCK

R723

R724

!

10K

0

5.6k

4.7k

0

1k

R710

2SA1530A/R/-X

11K

R83

RT1P141C-X

NI

NI

Q701

R81
11K

R91

Q91

Q13

C13

0.1

C75

560P

R709

5.6k

47

R31

NI

0.001

C2

C1

22/16

0.01

0.01

C7

C9

C8

47K

R55

10K

R56

Q52

C52

0.01

47k

R54

R53

2.2K

SCLK

U2SDT

47K

R927

0

R928

47k

R929

NI

NI

0.001

0.001

0.012

0.012

C91

C81

C82

C92

C12

Q11

RT1N141C-X

NI

R10

NI NI

S.METER

47K

Q12

4.7k

R11

RT1P141C-X

Q10

47K

R51

Q51

RT1N141C-X

D4

MONO

SEEK

C999

C997

0.01

100P

HPMUTE

DOUTMUTE

VMUTE

MUTE

DIMMER

PBRK

ANT

PON

DIMOUT

TELMUTE

R731

R732

TELCONT

R733

R734

FAN

R736

R737

R738

R739

R758

R759

D719

R12

27K

330P

C51

R52

R725

C721

0.047
C722

220/10

C723
470P

LRMUTE

SCS

CPURST

C141C151

LINE-G

LINE-R

LINE-L

100/10

C161

C162

0.047

C164
1

2.2/50

2.2/50

2.2/50

2.2/50

C175

470P

C185

470P

C102

22/16

C101
10/16

47k47k

R101R111

C111
10/16

C112

22/16 0

47k

47k

R842

R841

PLLDI

PLLCK

2.2k

R754

REMOCON

R755

10k

VDD

GND

22k

R752

HNDLEREM

PLLDO

C163
1

C174

C168

C184

R113

PLLCE

2.2/50

2.2/50

2.2/50

R103

10k

10k

R112

10k 10k

10k

R717

RESET

S723

QSW1049-001Z

C165

1

R114

AUX/CH

R715

R716

TD

RD

R104R102

10k10k

270

270

C156

0.047

470

R155

47K

R162

R163

R105

10k

R115

10k

C109

0.022

C733

SCK

R711

R780

R779

R799

R778

R777

R776

R775

R774

R773

R772

R771

R770

R769

R768

R767

R766

RA723

NRZ0065-103X

IC723

R756

2.2k

RT1P441C-X

47K

IC101

NJM4565V-X

BR24L32F-W-X

470P

R713

2.2k

2.2k

2.2k

NI

1k

4.7k

4.7k

4.7k

3.9k

3.9k

3.9k

1k

47k

10K

10K

NI

IC-PST3433U-X

C730

47/6.3

QGA2501C3-03Z

KTD1304-X

Q192

C191

47/6.3

D192

1SS355W-X

0

R161

R106

C110
47/16

IC722

10k

10k

TH721

NAD0028-103X

4.7K

4.7K

R760

R761

CN191

R193

Q191

100

R192
820

R191

4.7k

22K

R375

W-MUTE

R371

C373

4.7/25

1k

R373
100K

47/6.3

R372

C374

4.7/25

47K

R165

47K

R164

C267

10/16

220

R166

SAOUT

R167

2.2K

VOLMUTE

R168

2.2K

SACLK

2.2K

R169

VOLCK

R170

2.2K

VOLDA

IC161

TDA7416

C103

R107

10k

10k

47/6.3

10k

10k

R117

R116

C113

47/6.3

R110

100k

R714

R712

100k

SCLK

S2UDT

U2SDT

I/O

BUSSCK

BUSSO

SI/SO
LCDCL

LCDDA

C732

LCDCE

IFCCONT

S.METER

SQ

KEY2

KEY1

KEY0

4.7K

R762

RDSSCK

D731

47k

0.01

1SS355W-X

C731

R757

1k

R374
100K

R376

R384
100K

R382

C384

4.7/25

1k

R383
100K

R381

C383

4.7/25

1k

C176

2.2/50

AUX.L

NI

B101

C177

2.2/50

C186

Q161

2.2/50
RT1N141C-X

AUX.R

Q162

RT1N141C-X

AUX/CH

SAOUT

D782

MC2836-X

Q783

RT1P141C-X

220/10

C783 D783

UDZS9.1B-X

POPEN

PDETACH

UDZW6.2B-X

QSW0451-001

D716

S701

220/10

L722

NQL114K-470X

C734
NI

C375 C377

0.1

C391

C376

0.1

22K

22K

R386

0.1

C386

C392

47/6.3

C385

0.1

R385

22K

IC162

CD4066BPW-X

R172

2.2k

R782

470

R781

470

Q782

RT1P141C-X

D781

MC2836-X

C782

47/6.3

HPMUTE

UDZW6.2B-X

QSW0451-001

D717

S702

D903

1SS355W-X

C910

0.001

BATT

Q976

RT1N441C-X

R377

NJM2160BV-X

C378

R378

R388

C388

NJM2160BV-X

C387

R387

2SA1530A/R/-X

47/6.3

Q977

4.7/25

IC801

C336

47K

R358

47K

R328

R306

1SS355W-X

RT1N141C-X

DIMOUT

R805

10k

R462

R333

R323
47k

47K47K

R338R348

27k

RT1N141C-X

R886

4.7k

Q885

100K100K

R439

C437

R438

4.7K

4.7/25

IC431

LC75344M-X

C426 C436

C427

4.7/25
R428

4.7K

100/10

0.1

R429

10

C462

C463

R335

1K

47k

R325

1K

IC301

TB2906HQ

C338

R339

1/16

51k

R359

C358

51k

1/16

100P

100P

C359

C339

100P

100P

C348

R349

C349

C329

1/16

51k

R329

C328

51k

1/16

R303

0

R305

10k

Q303

PARK

D885

R888
0

R887
10k

C885

10/16

0.047
22/16

C912

C913

R807

330

R809

100

R810

C803

47K

0.047

R436
18K

6.8K
R437

IC421

NJM4580V-X

220P 220P

C425

100P

R427

R355

D354

D334

D324

D344

R345

R340

1k

R360

1k

R350

1k

R330

1k

C330

0.1

R302
0

C314

2.2/50

R903

BUSINT

BUSSCK

R806

100K

R808
22k

C804

22P

C435

6.8K

1K

1SS355W-X

1SS355W-X

1SS355W-X

1SS355W-X

1K

470p

C303

R902

4.7K

SCK

C433

C434

R434

39 22

150P

220/10

100P

C424

150P

R426

18K

10

R463

C465

R354

2.2k

R334

2.2k

R324

2.2k

R344

2.2k

0.01

C313

CRS03-W

470p

470p

CRS03-W

C304

C305

D304

D303

D981

CRS03-W

D982

CRS03-W

9.1K

10V

VMUTE

0.01

1k

R435

C432

1k

R425

C422

0.01

C423

R424

220/10

D431

0.1
C464

100/10

Q354
KTD1304-X

Q334
KTD1304-X

Q324
KTD1304-X

Q344
KTD1304-X

C311

4.7/16

C312

47/16

C350

0.1

D305

D308

CRS03-W

CRS03-W

CRS03-W

470p

CRS03-W

470p

C306

D306

C307

D307

R981

C981

0.1

NI

D851

D852

NI

RT1N141C-X

FAN

HNDLEREM

SN74AHCT1G08V-X

R401

DOUTMUTE

470

TX

R413

10

NQL114K-470X

COMPOSITE

6.8K

R412

R411

0

VGND

1SS355W-X

C360

0.1

R821

Q821

L411

IC411

C413

R417

R433

1k

R423

1K

D421

1SS355W-X

C340

0.1

470p

C308

C851

2SD1994A/RS/-T

10

C823

0.01

D821

MM1510XN-X

1.5

180

KTD1304-X

KTD1304-X

KTD1304-X

KTD1304-X

R431

Q432

Q422

R356

100

R336

100

R326
100

R346

0.01

C316

CRS03-W

470p

470p

D309

C310

C309

R982

2.2K2.2k

NI

UDZS12B-X

270

IC401

CRS03-W

D310

R851

C821

R432

1K

R422

1k

100

NI

Q823

Q822

10/16

NQR0007-002X

UDZW6.2B-X

R421

2239

100P

C335

100P

C325

RT1N441C-X

RT1P141C-X

R822

470

0.01

22p

C402

C401

K831

D831

Q431

Q421

Q301

0.01
C302

C902

2.2/50

C822
10/16

0.01

C403

220/10

C411

C415
100P

100P

C355

100P

C345

Q302

RT1P441C-X

C801

NI

CRS03-W

10

R402

K401

NQR0007-002X

D401

CRS03-W

L401

NQR0007-002X

NQR0007-002X

330/6.3

0.047

C412

C416

0.01

470P470P

C431C421

D301

UDZS11B-X

R901

TEL

PARK

ILL

NI

C889

CHR

R403

470

K402

C414

B921

NQR0201-004X

C301

47/16

1k

R889

R883

R404

K922

0.022

C331

C901

QEZ0722-338

CHL

D801

QGA2006F1-02

C831
100P

1

C404

100/6.3

R414
1K

0

NQR0007-002X

NQR0007-002X

NQR0007-002X

NI

C430

R894

0

0

100k

QQR1378-002

D901

1N5401-F64

!

J801

QNZ0095-001

QGA2001C1-02

IC402

TOTX177L

22p

C405

VOUT

75

R416

0

NQR0201-004X

L431

L430

L421

QNN0489-001

L901

SI/SO

R831

0

0.01

C406

R415

K411

SCK

CN821

CN831R832

QGA2501C3-03Z

CN421

J331

CN901

QNZ0607-001

CN411

QGA2501F1-02

!

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-2

LCD and Key control section

(for KD-DV5201EU,KD-DV5202EU)

IC602
RPM7338-V4

0.022

C681

C682

0.022

3.9K

3.9K

R606

R612

ENC1

S607S614

ENC2

R605

2.7K

S606

S613

EN601

QSW1115-002

S605

S612

S604

S611

0.012

10K

D643

R691

S1S2S3

S4

S5S6S7S8S9

S10

S11

S12

S13

S14

S15

S16

S17

S18

S19

S20

S21

S23

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

S39

S40

R635

S41

R634

D615

D616

D617

LCD1

COM1

COM2

S601

S608

KEY2

KEY1

KEY0

COM3

R649

R648

D601

D602

D603

R647

R646

D604

D605

S22

470

R645

R644

D606

D607

D608

470

R643

R642

200

D640
MA152WK-X

330

R640

SML310BA1T-X

SML310BA1T-X

R641

120

330

D609

R650

R639

R638

D610

D611

470

R636

R637

D612

D613

D614

QLD0420-001

R602R603R604

R601

8201.2K1.8K

820

S602

S603

R607R608R611 R610 R609

8208202.7K 1.8K 1.2K

S610

S609

R614

R613

820

820

S617

S616

S42

R633

S47

S48

S49

S50

S51

R631

R630

D619

S52

S50

S51

390

R661

D646

NSPW310BS/B2RST

390

R660

D645

NSPW310BS/B2RST

Q641

RT1N141C-X

R672

470

R671

470

Q640

2SB624/4/-X

R674

S52

S49

COM1

COM2

COM3

R651

2.2k

R652

2.2k

R653

10k

R658
180k

D642

R673

47k

1SS355W-X

1k

C601

10/6.3

D641

UDZW5.1B-X

0.022

C603

DIM_CON

680p

C602

51k

R657

10k

R654

10k

R655

LCDCE

10k

R656

LCDCL

LCDDA

S44

S45

S46

S47

S48

S3

S4S5S6

S2

S46

S45

S44

S43

R632

D618

C611

UDZW6.2B-X

S36

S37

S38

S39

S40

S41

S42

S43

S7S8S9

S10

S11S1S12

C612

S35

S13

470

R692

4.7/6.3

CN601

0

R624

470

R621

C620

0

R623
47k

QNS0245-001

R670

0.047

DIM_CON

S33

S34

IC601

PT6523LQ-L

S32

S31

S30

S29

S28

S27

S26

S25

S24

S23

S22

S21

S20

S19

S18

S17

S14

S15

S16

0

R620

R622
47k

J601

DIMOUT

REMOCON

ENC1

ENC2
LCDCE
LCDDA
LCDCL

KEY2

KEY1

KEY0

AUX.R

AUX.GND

AUX.L

GND

NNZ0085-001

10V

2-3

Main section

(except KD-DV5201EU,KD-DV5202EU)

W21

QAM0105-003

CN962

QGF0534F3-45X

X31
QAX0616-001Z

7P10P

C28C29

IC31

4.7k

R40

C48

47P

CN961

QGB2027M3-30S

C914

0.1

TB2118F-X

!

R39

6.2k

NI

NI

22/16

C47

C46

C45

0.01

C50

100P

C961

220/10

R962

TX

100

VGND

0.047

COMPOSITE

C969

C964

220/10

100/16

C909

C915
100P

R44

10k

RA31

NRZ0065-222X

PLLCE

PLLDO

PLLCK

PLLDI

SEEK

MONO

FM/AM

10K

10K

10K

R42

R43

R41

CN963

QGB2027L9-30X

C99

C968

0.047

DVDL

DVDR

UDZW5.1B-X

UDZW5.1B-X

R38

C965

220/10

10P

C30

NI

C44

R9

10

L31

NQL114K-470X

0

R961

D713

D715

C41

10/16

C42

0.047

10

SW1

SW4

0

R967

220/10

C38

0.01

220/10

C43

C49

L922
NQL56CK-220X

L921
NQL79GM-100X

BA33BC0FP-X

C921

100P

0.47

100P

R701

R35

AUXINL

0

R33

C33

C35

0.01

0.01

0.1/16

C966

IC921

100

0.001

39k

0.047

C31

C32

C40

NI

AUXING

0

R702

UDZW5.1B-X

R37

470

47P

RT1N141C-X

R921

0

0

0

UDZW5.1B-X

C703

C704

C705

R32

0

R34

10k

0.0027

C37

C34

0.01

C39

100P

Q31

SCS

SN74LVC32APW-X

R969

R968

D921

1A3G-T1

C922

100/10

C925

220/10

AUXINR

UDZW6.2B-X

0

D703

R703

D712

D714

C36

R36

IC961

UDZW6.2B-X

D702

0.001

220

RT1N141C-X

L924

UDZW6.2B-X

D701

R14

Q14

22

R2

10k

IFCCONT

C963

220/10

NQL56CK-220X

C926

47/10

KEY1

KEY0

KEY2

22

R4

47K

R3

R5

4.7K

RT1N141C-X

0

R8

FM/AM

S2UDT

CPURST

R973

10K

R974

10K

R975

10K

220/10

C911

0.001

0

L927

B922

NQLB7GM-100X

L925

NQL71EM-330X

0.1

C927

470/25

C928

ENC1

ENC2

LCDCL

LCDCE

LCDDA

270

270

R705

R706

R704

TU21

QAU0312-002

Q4

2SA1365/F/-X

Q5

C967

C962

RB051L-40-X

D922

REMOCON

10K

SQ

0.1/16

R923

39K

2SA1530A/R/-X

R7

R6

3.3K

470
R59

C55

0.47/50

D906

390k

R926

R707

10K

CN701

QNZ0605-001

!

4.7

Q7

47K

D3

MC2838-X

R58

15k

Q53

2SD601A/R/-X

UCS

LRMUTE

R914

220

UDZW5.1B-X

RT1N141C-X

R925

0.1

C930

D704

D705

D706

D707

D709

D710

C701

C702

D711

L1

1SS355W-X

D2

R57

SN74HCT32APW-X

R910

Q904

C929

4700P

150K

10K

R924

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

UDZW6.2B-X

0.01

0.1

UDZW6.2B-X

1SS355W-X

D1

47/16

C5

2SD601A/R/-X

C54

0.1

10K

C53

0.0047

IC962

Q903

2SA1530A/R/-X

R909

2.2K

IC922

BD9781HFP-W

C931

C428

4.7/25

DVDR

DVDL

C438

4.7/25

C781

33K

0.0015

0.0015

33K

33K

0.0015

0.0015

33K

R171

2.2k

R173

Q781
RT1P141C-X

HPDATA

HPCK

HPSTB

R452

22k

C451

47/6.3

22k22k

R451R441

47/6.3

C441

R442

22k

10

R461

IC371

C379

100/10

C380

100/10

IC381

C390

100/10

C389

100/10

0

B102

CHR

2.2/50
C187

CHL

C169

0.01

0

C170

10/16

R891
47K

Q891
RT1N141C-X

Q892

UN2211-X

TELCONT

TELMUTE

MUTE

0.1

10/16

100/10

C905

C903

C904

R977

R976

18k

56k

C461
22/16

4.7/25

C356

47k

R353

47k

R343

C346

4.7/25

0

0

0

0

B105

B104

B106

B103

1SS355W-X

AMPKILL

R892
1K

D891
MC2836-X

R893

3.3k

C891

0.1

0.1

C892

0.1

0.01

C907

C906

ANT

D302

TEL

220/10

C908

R881
47k

Q881

DIMMER

2SC3928A/R/-X

PON

R802

47K

C802

22P

L902

NQL56CK-220X

SI/SO

R304

47k

R308

2.2k

Q304

RT1N141C-X

5.6K

R906

R907

R804

100k

R803

22K

R801

100

R882

C881
22/16

1K

10K

BUSSO

R307

IC901

R2S25400DS-E

R905

I/O

R337

R357

R347

R327

10

ILL

10k

HD74HC126FP-X

CN141

QGA2006C1-04

C155

0.47

47K47K

R141R151

0.00470.0047

2.2/50

2.2/50

2.2/50

2.2/50

C175

470P

C185

470P

R101R111

47k

47k

R841

R842

REMOCON

R755

10k

VDD

GND

HNDLEREM

C141C151

LINE-G

LINE-R

LINE-L

100/10

C161

C162

0.047

C164
1

C102

22/16

C101

10/16

47k47k

C111

10/16

C112

22/16

PLLDI

PLLCK

2.2k

R754

22k

R752

C165

1

C163
1

2.2/50

C174

2.2/50

C168

2.2/50

C184

R104R102

10k

10k

10k

R103

R113

10k

R114

10k

10k

R112

AUX/CH

PLLDO

PLLCE

10k

R717

R715

270

270

R716

TD

RD

RESET

S723

QSW1049-001Z

R1
47k

C83

1/50

R81

0.01
220/10

C4

C3

0.1/50

KTD1304-X

D5

IC721

UPD784217AGC334

VOLMUTE

R726

R735

AMPKILL

R727

R728

R729

2.2K

2.2K

VPP

4.7K

4.7K

220K

220K

R708

330

SLR-56VC3F

C93

1/50

0MA111-X

AFCK

R723

!

10K

0

5.6k

4.7k

0

2.2k

2.2k

10K

47K

R710

2SA1530A/R/-X

15K

R91

15K

R93

4.7K

KTD1304-X

Q91

R83

4.7K

R13

Q13

UN2111-X

C13

0.1

C75

560P

Q9

UN2111-X

47K

47K

R724

R709

1k

5.6k

Q701

47

R31

NI

0.001

0.012

0.012

0.01

C2

C1

22/16

0.01

0.047

C7

C6

C8

R56

R55

10K

Q52

C52

0.01

R54

2.2K

47K

R927

0

R928

47k

R929

47k

0.1

0.01

C91

C81

C82

C92

C12

Q11

RT1N141C-X

0.01
0

C9

R12

47K

27K

R53

47k

C51

330P

R52

S.METER

SCLK

U2SDT

R725

47K

C721

0.047
C722

220/10

C723
470P

LRMUTE

SCS

CPURST

Q12

4.7k

R11

Q10

UN2111-X

47K

R51

Q51

UN2211-X

D4

R10

27K

1SS355W-X

MONO

SEEK

C997

C999

100P

0.01

HPMUTE

DOUTMUTE

VMUTE

MUTE

DIMMER

PBRK

ANT

PON

DIMOUT

TELMUTE

R731

TELCONT

R732

R733

R734

FAN

R736

R737

R738

R739

R758

R759

D719

SD/ST

27K

0.0012

C94

R92

Q81

KTD1304-X

RDSDA

C77

2.2/50

C76

R75

2.2k

0.022

SAA6579T-X

IC71

R73

R74

2.2k

2.2k

RDSSCK

X71

47/6.3

0.01

C72

47k

R743

NI

QAX0263-001Z

C71

0

R72

R71

C73

C74

47P

82P

SACLK

HPSTB

VOLDA

VOLCK

HPDATA

W-MUTE

2.2k

2.2k

2.2k

2.2k

R730

R721

R722

R784

10k

10k

R763

R765

L721

ENC1

ENC2

SW1

SW4

47k

47k

47k

47k

47k

R747

R749

R748

R750

R742

220/10

470P

C726

C724

C725

27K

0.0012

C84

R82

HPCK

NRZ0065-222X

RA721

820

R744

NQL38DK-330X

X721

8P

C727

RDSDA

2.2k

R845

R745

R746

QAX0617-001Z

27P

27P

C728

Tu.L

Tu.R

C166

10/16

C171

C181

C172

DVDL

C182

DVDR

LINE-L

LINE-G

LINE-R

AUXINL

AUXING

AUXINR

47k

47k

AFCK

R843

R844

SD/ST

1K

1k

R719

R720

10k

R718

2.2k

10M

R740

2.2k
R753

UCS

47K

RESET

X722C729

33k

QAX0401-001

R751

BUSINT

22P

R155

470

C156

0.047

47K

R162

C109

0.022

C733

SCK

R779

R799
R778

R777

R776

R775

R774

R773

R772

R771

R770

R769

R768

R767

R766

RA723

NRZ0065-103X

IC723

R756

2.2k

R163
47K

R105

10k

R115

10k

BR24L16F-W-X

470P

R713

R711

R780

C730

47/6.3

QGA2501C3-03Z

RT1P441C-X

Q192

1SS355W-X

IC101

NJM4565V-X

IC722

10k

10k

2.2k

2.2k

2.2k
47K

1k

4.7k

4.7k

4.7k

3.9k

3.9k

3.9k

1k

47k

10K

10K

47K

R760

IC-PST3433U-X

KTD1304-X

C191

47/6.3

D192

0

R161

C110
47/16

100k

NAD0028-103X

4.7K

CN191

R193
100

Q191

R192

R191

820

4.7k

R375

R377

R374
100K

R384
100K

0

2.2/50

R373
100K

R383
100K

PDETACH

C375 C377

C373

4.7/25

47/6.3

C374

4.7/25

C376

R376

R386

C386

C384

4.7/25

47/6.3

C383

4.7/25

C385

R385

AUX/CH

D782

MC2836-X

RT1P141C-X

UDZW6.2B-X

QSW0451-001

D716

S702

C391

C392

CD4066BPW-X

R172

2.2k

R782

R781

Q782

C782

47/6.3

HPMUTE

D903

1SS355W-X

Q976

RT1N441C-X

22K

0.1

NJM2160BV-X

C378

0.1

R378

22K

R388

22K

C388

0.1

NJM2160BV-X

0.1

C387

22K

R387

IC162

470

470

D781

MC2836-X

47/6.3

UDZW6.2B-X

D717

C910

0.001

BATT

Q977

2SA1530A/R/-X

W-MUTE

R371

1k

R372

C176

2.2/50

AUX.L

C186

2.2/50

AUX.R

SAOUT

1k

R382

1k

R381

1k

B101

C177

Q161

RT1N141C-X

Q162

RT1N141C-X

Q783

RT1P141C-X

C783 D783
47/16 UDZS11B-X

POPEN

QSW0451-001

S701

L722

NQL114K-470X

C734

0.1

47K

R165

47K

R164

C267

10/16

220

R166

SAOUT

2.2K

R167

VOLMUTE

2.2K

R168

SACLK

2.2K

R169

VOLCK

R170

2.2K

VOLDA

IC161

TDA7416

C103

47/6.3

R107

10k

10k

R106

C113

R117

R116

10k

10k

47/6.3

R110

0

100k

R714

R712

SCLK

S2UDT

U2SDT

I/O

BUSSCK

BUSSO

SI/SO

LCDCL

LCDDA

C732

220/10

LCDCE

IFCCONT

S.METER

SQ

TH721

KEY2

KEY1

KEY0

4.7K

4.7K

R761

R762

RDSSCK

D731

47k

0.01

1SS355W-X

C731

R757

0

0

0

0

C315

!

4.7/25

22/16

Q901
UN2111-X

Q912
UN2211-X

R439

100K100K

C437

R438

4.7K

4.7/25

IC431

LC75344M-X

C426 C436

C427

4.7/25
R428

4.7K

100/10

0.1

R429

10

R462

C462

C463

R335

C336

1K

4.7/25

C326

R358

R306

R885

47k

PBRK

IC801

47K

47K47K

R338R348

47K

R328

27k

1SS355W-X

Q885

RT1N141C-X

DIMOUT

R805

10k

R333

47k

R323
47k

C338
1/16

C358

1/16

C348

1/16

C328
1/16

RT1N141C-X

D885

R886

4.7k

TB2906HQ

Q303

0.047

C913

1SS355W-X

1SS355W-X

1SS355W-X

1SS355W-X

R325

1K

IC301

R339

51k

R359

51k

100P

100P

C359

C339

100P

100P

C349

C329

R349

51k

R329

51k

R303

0

R305

10k

PARK

R888
0

R887
10k

C885

10/16

22/16

C912

R807

330

R809

100

R810

47K

C803

0.047

R436
18K

6.8K
R437

IC421

NJM4580V-X

220P 220P

C425

100P

R427

R355

D354

D334

D324

D344

R345

R340

1k

R360

1k

R350

1k

R330

1k

C330

0.1
R302
0

C314

2.2/50

R903

BUSINT

BUSSCK

R806

100K

R808
22k

C804

22P

C433

C435

C434

R434

39 22

150P

220/10

100P

C423

C424

150P

220/10

R426

18K

6.8K
R463

0.1

10

100/10

C464

C465

1K

R354

2.2k

R334

2.2k

R324

2.2k

R344

2.2k

1K

0.01

C313

C312

C350

0.1

470p

470p

470p

470p

CRS03-W

CRS03-W

CRS03-W

C303

C304

C305

C306

D303

D304

D306

D981

CRS03-W

D982

C981

CRS03-W

D851

R902

9.1K

FAN

10V

HNDLEREM

4.7K

DOUTMUTE

SCK

VMUTE

R435

1k

R425

KTD1304-X

KTD1304-X

Q344

KTD1304-X

47/16

D305

CRS03-W

0.1

CRS03-W

TX

COMPOSITE

VGND

1k

C422

R424

Q354
KTD1304-X

D852

CRS03-W

R413

10

R411

0

0.01

C432

0.01

Q334

Q324

C311

4.7/16

D308

CRS03-W

470p

C307

R981

SN74AHCT1G08V-X

R401

470

NQL114K-470X

R412

D431

1SS355W-X

CRS03-W

D307

R821

Q821

RT1N141C-X

L411

6.8K

C360

IC411

R417

D421

0.1

10

C413

1.5

R433

R423

1SS355W-X

470p

C308

C851

MM1510XN-X

180

1k

1K

C316

C340

0.1

470p

C309

2SD1994A/RS/-T

C823

0.01

D821

270

IC401

Q432

0.01

CRS03-W

D309

0.1

Q422

R356

R336

R346

R982

2.2K2.2k

UDZS12B-X

KTD1304-X

KTD1304-X
KTD1304-X

KTD1304-X

R431

470P470P

Q431

R432

1K

C431C421

R422

1k

Q421

R421

2239

100

100

100P

100P

C335

C355

100P

100P

R326

C345

C325

100

100

Q301

RT1N441C-X

Q302

RT1P441C-X

UDZS11B-X

D301

0.01

C302

C902

2.2/50

R901

1k

TEL

PARK

Q823

Q822

RT1P141C-X

R822

470

10/16

NQR0007-002X

MA8062/M/-X

0.01

22p

C402

C401

K831

D831

C822
10/16

0.01

C403

220/10

C411

C415
100P

C801

NI

CRS03-W

10

R402

K401

NQR0007-002X

D401

CRS03-W

L401

NQR0007-002X

NQR0007-002X

330/6.3

0.047

C412

C416

0.01

ILL

NI

C889

CHR

R403

470

K402

C414

B921

NQR0201-004X

R889

R883

K922

470p

CRS03-W

C310

D310

4.7K

R851

C821

0.022

C331

C301

47/16

C901

QEZ0722-338

D801

QGA2006F1-02

R404

1

C404

100/6.3

R414
1K

0

NQR0007-002X

NQR0007-002X

NQR0007-002X

0.022

C430

R894

0

0

100k

QQR1378-002

D901

CHL

QNZ0095-001

QGA2001C1-02

C831
100P

TOTX177L

C405

75

L431

L430

L421

L901

1N5401-F64

!

J801

SI/SO

R831
0

IC402

22p

C406

0.01

VOUT

R415

R416

0

K411

NQR0201-004X

SCK

CN821

CN831R832

J331

QGA2501C3-03Z

CN421

CN901

QNZ0607-001

CN411

QGA2501F1-02

!

Parts are safety assurance parts.
When replacing those parts make
sure to use the specified one.

2-4

LCD and Key control section

(except KD-DV5201EU,KD-DV5202EU)

IC602

RPM7338-V4

0.022

C681

C682

0.022

3.9K

3.9K

R606

R612

ENC1

S607S614

ENC2

R605

2.7K

S606

S613

EN601

QSW1115-002

S605

S612

S604

S611

0.012

10K

R691

D643

C611

UDZW6.2B-X

S1S2S3

S4

S5S6S7S8S9

S10

S11

S12

S13

S14

LCD1

COM1

COM2

S601

S608

KEY2

KEY1

KEY0

COM3

R649

R648

D601

D602

D603

270

R647

R646

D604

D605

QLD0420-001

R602R603R604

R601

820

8201.2K1.8K

S602

S603

R607R608R611 R610 R609

8208202.7K 1.8K 1.2K

S610

S609

R614

R613

820

820

S617

S616

S15

470

470

R645

R644

D606

D607

D608

S21

S16

S17

S18

S19

S20

S24

S25

S26

S27

S28

S29

S30

S31

S32

S33

S34

S35

S36

S37

S38

S39

S40

S41

270

270

R635

R634

D615

D616

D617

R643

R642

S23

S22

390

390

R641

D640

MA152WK-X

330

330

R640

D609

R650

R639

R638

D610

D611

470

R637

R636

D612

D613

D614

S47

S48

S49

S50

S42

S45

S44

S43

1.2K
R632

R633

D618

S51

S46

1.2K
R631

1.2K
R630

D619

1.2K

S52

S36

S37

S39

S41

390

R661

D646

NSPW310BS/B2RST

R660

390

D645

NSPW310BS/B2RST

Q641

UN2211-X

R672

470

R671

470

Q640

2SB624/4/-X

R674

S45

S44

S47

S48

S49

S50

S51

S52

COM1

COM2

COM3

R651

2.2k

R652

2.2k

R653

10k

R658
180k

D642

R673

47k

1SS355W-X

1k

C601

10/6.3

D641

UDZW5.1B-X

0.022

C603

DIM_CON

680p

C602

51k

R657

10k

R654

10k

R655

LCDCE

10k

R656

LCDCL

LCDDA

S46

S2

S3

S4

S5

S38

S40

S42

S43

S7

S8

S6

S9

S10

S11S1S12

S13

C612

S35

470

R692

4.7/6.3

CN601

0

R624

470

R621

C620

0

R623
47k

QNS0245-001

R670

0.047

J601

DIM_CON

S34

S33

IC601

PT6523LQ-L

S32

S31

S30
S29

S28
S27

S26

S25

S24

S23

S22
S21

S20

S19
S18

S17

S14

S16

S15

0

R620

R622
47k

DIMOUT
REMOCON

10V

ENC1

ENC2

LCDCE

LCDDA

LCDCL

KEY2
KEY1
KEY0
AUX.R

AUX.GND

AUX.L

GND

NNZ0085-001

2-5

DVD section

(common)

CN101

QGF0501F8-30X

TP201

TP202

CN201

QGF1038F2-11X

C113

0.1/16

C104

TP1

0.1/16

C103

TP3

TP2

TP51

TP52

TP31

TP41

CN202

QGF0523F2-05W

SW4SW5

NSW0184-001XNSW0183-001X

TP25

K101

NQR0007-002X

0.1/16

TP4

TP32

TP40

SW1

P3.3V

K399

NQR0502-001X

IC398

SG32M90TFIR3

EXADT15

EXADT14

EXADT13

EXADT12

EXADT11

EXADT10

EXADT9

EXADT8

EXADR19

EXADR20

NEXWE

/FL_RST

NI

R398

R396

47k

EXADR18

EXADR17

EXADT7

EXADT6

EXADT5

EXADT4

EXADT3

EXADT2

TP22

TP24

C112

TP6

TP5

TP33

TP34

TP39

TP38

SW2

SWGND

TP23

TP21

TP20

TP16

TP17

TP18

TP19

0.1/16

0

TP9

TP7

TP8

TP11

TP12

TP10

TP36

TP35

TP37

SW3

B201

NI

B202

NI

B203

NI

B204

NI

B205

NI

DGND

L-END

REST

EXADT1 EXADT0

TP14

TP15

VREFH

HAGUP

LPC2

RF+

LPC1

RF-

E

F

C

D

A

B

CD/DVD

K102

NQR0007-002X

R101

T+

10k

F-

T-

F+

TRVSW

SM3

SM2

SM1

H3-

H3+

VH

H1+

H1-

H2+

H2-

SW1

SW2

SW3

SW4

Q107

2SC4617/R/-X 2SK3019-X2SK3019-X

D5V

0

R233

47

R260

NI

C269

R122

0

R119

0

R129

100k

R128R130

10k

M5V

1

R201

C201

100/16

M8V

C211

C209

R231

2.7k

R235 R234

6.8k 390k

DTC114EE-X

MGND

C254

10/10

SBRK

SBRK

SPDRV

M8V

C252

C255

100/16

MGND

R124

F+T-T+

NI

C207

NI

Q231

C253

C396

0.1/16

NI

NI

NI

R121

C109

C110

R123

0

R120

0

91

R126

R127

Q105Q106

NI

C208

C202

0.1/16

IC201

BA5835FM-X

C212

100/16

0.1/16

R232

15k

0.047

0.1/16

0.1/16
C265

C256

C266

0.1/16

IC251

BD6671FM-X

R259

10k

R252

0

R257

10k

C267

0.01

0.1/16

/SPMUTE

SPDRV

/SPMUTE

C397

22/6.3

EXADR16

R399

0

EXDAT15

EXDAT7

EXDAT14

EXDAT6

EXDAT13

EXDAT5

EXDAT12

EXDAT4

EXDAT11

EXDAT3

EXDAT10

EXDAT2

EXDAT9

EXDAT1

EXDAT8

EXDAT0

NEXOE

R397

NI

NEXCE

DGND

DVDLDCUR

NI

C106

12

R105

R104

2.2

R106

3k 3k

R107

1k 1k

Q101

2SB1424/R/-W 2SB1424/R/-W

91

Q102

2SC4617/R/-X

2.4k
C102

R103

0.1/16
R109

C203 C204

270p 150p

R203

R202

30k

47k

R221

10k

MGND

C221

0.022

H3-

H3+

H2-

H2+

0

R253

0.001

C257

C258

0.47

R251

C251

0.1/16

MDQ0

0.1/16
MDQ1

MDQ2

MDQ3

MDQ4

0.1/16
MDQ5

MDQ6

MDQ7

DQM0

NWE

NCAS

NRAS

NCSM

BA0

BA1

MA10

MA0

MA1

MA2

LPCO1

R110

470

R108

47/10

330

R219

R220

C213

TRSDRV

R222

10k

H1+

H1-

0.001

0.001

C259

R254

10k

20k

R255

IC399

C399

0.1/16

C392

C391

C398

0.1/16

C395

0.1/16

CDLDCUR

0

R112

2.4k

R111

R205

27k

R204

27k

15k

18k

0.1/16

R223

0

R256

47

C260

C264

0.01

K4S281632F-UC75

MDQ15

MDQ14

MDQ13

C393

MDQ12

0.1/16

MDQ11

MDQ10

MDQ9

C394

MDQ8

NI

C384

DQM1

0.1/16

MCK

MA11

MA9

MA8

MA7

MA6

MA5

MA4

MA3

S5V

LPCO2

0

1

R125

R118

ADS5V

C108

470

R116

47/10

12

R113

2.2

R114

R115

Q103

Q104

2SC4617/R/-X

C111

0.1/16

TDRV

R207

0

FDRV

R206

0

VHALF2

VH

SM1

SM2

SM3

NI

NI

NI

C261

C262

NI

C263

C105

47/10

330

R117

DGND

/DRVMUTE

TRDRV

FODRV

VHALF

R210

NI

R211

0

TRSDRV

1k1k

DRVCONT

R384R385

C371

1/16

LM

FG

FG

/FL_RST

EXADR20

NEXWE

EXADT0

EXADT4

EXADT8

EXADT12

EXADR16

EXADR18

EXADT14

EXADT10

EXADT6

EXADT2

NEXCE

EXADT1

EXADT5

EXADT9

EXADT13

EXADR17

EXADR19

EXADT15

EXADT11

EXADT7

EXADT3

NEXOE

MDQ9

MDQ5

MDQ10

MDQ4

MDQ11

MDQ3

MDQ12

MDQ2

MDQ13

MDQ1

MDQ14

MDQ0

MDQ15

DACPDN

DACOCS

DCLK

DDATA

P3.3V

C1

0.1/16

C2

0.1/16

C307

0.1/16 0.1/16

R321

0

C3

0.1/16

C4

0.1/16

C5

0.1/16

0.1/16

C6

C7

0.1/16

R322

0

R372

330

R373

EPCS

EPSK

EPDO

R389R390

330

R304

NI

C8

0.1/16

NI

DGND

R387

NI

1k

0.1/16

C380

R310

R388

NI10k

IC304

S-80827CNNB-G-W

100k

R323

R309

0

EJREQ

10k

C481

0.1/16

R481

EPCS

EPSK

BR93L66F-W-X

MDQ7

MDQ8

MDQ6

DQM1

C21

0.1/16

100

0

100

R386

R354

R353

NI

TUBUYAKI

10k

R381

R370

NI

C310

IC481

R320

R324

1000p

SCLK

S2UDT

U2SDT

SACK

SCS

EPDO

EPDI

EPDI

DACPDN

DACOCS

DCLK

DDATA

MCK

NWE

DQM0

C20

C222

0.01

NI

1k

R371

R380

FG

CPURST

PCMCLK

BCK

AOUT3

LRCLK

10k

R224

TRSDRV

NCSM

NRAS

NCAS

27

R303

C19

0.1/16

10k

R258

NININI

C268

0.015

R376

R377

22k

R308

NI

R374

HAGUP

CD/DVD

SPDRV

/SPMUTE

TRVSW

PCMCLK

BCK

AOUT3

LRCLK

47k

DCLK

R404

DDATA

MA8

MA9

BA0

BA1

MA11

C18

0.1/16

0.1/16

TP313

C308

C309

0.1/16

0.1/16

NI

NI

NI

NI

R378

R379

R382

R383

100

100

47k

NI

R329

R328

R349

R331

DRVCONTLM/DRVMUTE

Q302

SW3

SW4

330p

C403

IC401

AK4385ET-X

R403

DGND

MA1

MA6

MA0

MA7

MA10

C17

C16

0.1/16

0.1/16

IC301

MN2DS0003AA-H

TP312

TP302

TP303

TP309

TP308

TP307

P3.3V

NI

100

100

47k

47k

47k

R327

R326

R348

R347

R346

R330

Q301

SW2

SW1

DTC144EE-XDTC144EE-X

10

R401

C402

47/10

C401

0.1/16

4.7

R402

0

C404

C405

NI

0.047

MA3

MA4

MA2

MA5

C14

C15

0.1/16

0.1/16

C335

0.1/16

TP306

C331

0

R314

UCS

C330

C333

22k22k

R533

NJM4580V-X

R433

0.1/16

C332

0.1/16

0.1/16

C337

0.018

C334

C338

0.1/16

0.0056
R313

DGND

C531

0.0033

470p

R532

C532

4.7k

IC411

R432

C432

470p

4.7k

R434

C431

0.0033

0.033

R535

4.7k

R531 R534

4.7k 200

R431

4.7k 200

R435

4.7k 4.7k

EXDAT0

C13

0.1/16

TP314

TP315

0.1/16

0.1/16

C320

C321

0.1/16

0.1/16

C348

C350

0

5p

5p

C359

C358

150

150

R363

R364

RF+

RF-

R538

22k

R537

4.7k

R536

200

C433

R436

470p

200

R437

R438

22k

EXDAT11

EXDAT5

EXDAT10

EXDAT6

EXDAT9F-EXDAT7

C12

0.1/16

0.1/16

C322

C323

C533
470p

C412

47/10

C11

0.1/16

0.1/16

C349

0.1/16

C314

R312

C411

0.1/16

0.1/16

0.1/16

VHALF

1/16

0.1/16

0.1/16

C319

C347

0

LPC1

C522

47/10

C521

0.1/16

C421

0.1/16

C422

47/10

0.1/16

1/16

C340

C324

VREFH

VHALF

LPCO2

LPC2

LPCO1

LRMUTE

A5V

L-CH

R522 R521

AGND

R422

1k 1.2k 1.2k 1k

R421

R411

A9V

10

R-CH

EXDAT4

EXDAT12

EXDAT3

EXDAT13

EXDAT2

EXDAT14

EXDAT1

EXDAT15

P3.3V

C305

C10

EXDAT8

C315

R392

C311

R305

NI

C9

0.1/16

NQL093K-1R8X

C313

C339

R325

180

C341

R340

R350

R359

R360

R208

R209

C356

C317

C316

TP325

100

NQL093K-1R8X

L306

L307

NQL093K-1R8X

L305

0.1/16

0.1/16

1/16

30k

180

180

180

20k

22k

1/16

0.1/16

0.1/16

1k

1k

R306

R307

R369

R362

R344

C342

NI

C318

R342

C312

1/16

C336

R333

R335

R334

R337

R336

R338

R339

R394

R393

C492

0.1/16

5.1k

C343

C344

C345

C346

0.1/16

D1.2V

1.6k

C302

C369

22k

R319

R352

C205

C491

0.1/16

NI

NI

NI

NI

NQR0502-001X

47/6.3

47/6.3

22k

R317

NI

K425

K427

K428

K429

R357

R351

1M

0

NI

0.1/16

NI

C206
560p

680p

0.1/16

150

150

150

150

0

0

0

0

R493

TH491
NAD0025-103X

R300

IC303

0

R301

NI

0

K301

NINI

C361

C362

IC302

NI

C367

TP320

NI

NQL093K-1R8X

R361

R358

0

C325

X351
NAX0730-001X

C326

0

R315

0

R316

0

3.3k

R491R492

10k

BA00HC5WF-X

1/16

R332

1k

C366

TP319

TP317

TP316

TP318

AOUT3

0

BCK

LRCLK

10p

10p

PCMCLK

L302

FODRV

TRDRV

ADS5V

DVDLDCUR

CDLDCUR

B

A

D

C

F

E

S3.3V

NI NI

L301

C301

220/6.3

DGND

NI

9102k

R365R366

C368

R367

NQL093K-1R8X

NI

NI

NI

1k

R345

VGND

K311

NQR0129-002X

R341
NI

L303

NQL044K-100X

R318

22k

TP491

EJREQ

UCS

SCS

SACK

SCLK

U2SDT

S2UDT

CPURST

LRMUTE

A5V

A9V

L-CH

AGND

R-CH

R302

NI

C360

C365

C364

0.1/16

K401

K402

K403

K404

K405

K406

K407

K441

K442

K443

K444

R441

K445

R442

SW4

K451

SW1EPDI

K452

K601

NI

00

R606R605

C602

NI

L601 L602

C601

R603

R601

NI

C303

47/6.3

TP321

D3.3V

D3.3V

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

NQR0022-005X

0

NQR0022-005X

0

NQR0022-005X

NQR0022-005X

VGND

B601

R604

NQR0022-005X

NI

R602

NI

C603

NI

NI

NI

NI

NI

D3.3V

0

0

R356

R355

NI

D3.3V

NI

NINININI

MGND

FG1

C22

C23

R23

R24

FG2

K420

K421

K422

K423

K424

K434

K426

K430

K431

K432

K433

C453

0.1/16

DGND

L451

NQL044K-100X

C451

0.1/16

C452

0.1/16

DGND

R21

NI

R22

NI

CN402

QGF0522F3-06W

NI

NI

NI

NI

CN403

QGF0534F3-45X

TP417

TP416

0.1/16

TP420

TP422

TP425

TP426

TP427

TP428

TP429

TP430

TP431

TP432

TP433

TP434

TP435

TP436

TP437

TP438

TP439

TP440

TP441

TP442

TP444

TP446

TP448

TP452

TP453

TP455

TP457

TP322

TP323

TP324

NI

NI

NI

NI

NI

NI

C454

S3.3V

S5V

0

DGND

D5V

M5V

M8V

2-6

Printed circuit boards

Main board

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

(Main board) (Main board)

S702

B922

L927

C964

R707

R706

C927

R704 R705

R929
R927

R928

L925

C931

R923

R924

R925

C929

C930

R926

C926

D922

IC922

D921

CN701

R701

R702

R703

C921

D719

R710

C725

Q701

C101

C111

C109
R116

C112

R112

R113

R114

C113

C110

IC101

R115

R105

R106

R107

R117

C102

R102

R103

IC723

X722

R104

C731

D731

R757

C103

C176

C330

C302

C186

X71

S723

C71

D716

S701

C909

C965

C912

L921

R921

L924

C922

X721

R744

R752

R756

R760

C730

C350

C75

C72
R72

C303

C304

C305

C306

R71

IC71

C77

C4

IC721

L721

R746

R745

R755

R761

R762

R766

TH721

Q9

Q51

R59

C55

C76

R55

R56

Q12

R10

C12

R44

D4

C925

IC411

C412

CN411

C722

Q10

L902

C911

C349

C413

L411

C732

D5

C93

R11

R751

R753

C359

C329

C339

R329 R330

R349 R350

C328

C348

C411

R348

R358

R328

R338

C414

R327

R347

R758

R759

R747

R748

R749

R750

R742

R743

R909

R910

L722

R726
R725

R723

R724

R784

R717

C733

R844

R714

R712

Q13

C13

R13

R83

R93

Q91

Q81

C49
C50

R41

C94

C47

R92

C46

C84

R38

C45

R91

R82

R81

L31

C83

Q11

R754

R767

RA723

R768

R769

R770

R771

R772

R773

R774

forward side reverse side

R905

R906

R765

Q904

IC301

Q901

IC901

R961

R340

R360

IC962

C967

R339

R359

C338

C358

R973

R337

R738

R808

R39

R775

IC961

R357

C966

R974

R975

R739

R728

R729

R731

R732

R763

R733

R734

R736

R737

C962

D906

Q903

R914

R58

R1

R57

Q53

C53
R54

Q52

C54

R51
R53

C52

IC722

R809

IC801

R806 R807

R805

R810

C804

C803

X31

IC31

RA31

C48

R711

R713

R776

R777

R778

R907

Q912

Q301

CN961

C905

D903

R727

C963

C181

C171

R722
R721
R730

RA721

R720
R719
R716
R718
R715
R842
R841
R843

IC162

Q162

B101
B102

C802

R802

R801

R804

R803

C41

C42

Q302
D301

C301

L922

C908

C961

C903

R901

R305
R303

R976

R302

R304

R977

C906

C902

Q977
Q976

C182

IC161

R169

R170

C169
R171

C170

R172

C187

C177

C43

R903

R902

Q431

Q421
Q422

Q432

R433

R423

R432

D431

D421

C172

C166

C164

R164

R166

R167

R168

C161

C267

R373
R374

R384
R383

C384

R173

Q161

C383

C38

R35

C37

C34

R32R34

R14

C44

C39

C40

C36

C376

R36R37

C386

C392

C35

C8

C99

C314

R422

C162

D1

IC371

IC381

C311

C312

C315

R306

Q303

R307

R308

Q304

D302

R889
C889
R888

D885

R886
R885

R161

R441
R442

R427

C385

D2

C783

R887

Q885

R881

Q881
R882
R883

C885

R141

C141C151

C185

R151

C175

C881

C438

C163

C165

C462

IC431

C463

R439
R437

R438

C435

C436

C434

C461

C426

R436

C174

IC421

R428

C465

C425

R429

C424

R192

R426

C373C374

C391

C191

CN831

C379

C377

C375

C380

C378
C388

C390

C387

C389

C5

TU21

L1

D308

C340

C360

D305

C310

C309

C308

C307

CN901

C901

A

C451

C437

C428

C427

C441

C168

Q192

C404

R401

C336

C326

C356

W21

D901
L901

PP2

Q823

CN821

C782

C781

R461

C822

R451

R452

C433

Q191

C184

C464

R191

D401

IC402

K401

R333

L401

IC401

C401

R323

C402
C403
R402

R334
Q334
R324

D334

Q324
D324
D354
R354
Q354
R344

D344

Q344

R353

R343

C346

PP3

D801

J801

CN421

C821

(Main sub board) (Main sub board)

C423

CN141

PP1

CN191

R992

R991

C993
C992

CN963

CN962

J331

C991

R993
C994
C995

CN421

L421

D901

D982
C981

R851
C851
D852

Q822

L901

Q821

R822

R434

L431

L430

R431

C432

C422

R424

R421

PP1

CN141

C155

R155

C313

C901

CN901

PP2

D851

Q823

C781

CN821

R821

C822

C821

C823

C433

D821

R435

R425

R463

C423

C464

C184

CN191

IC402

J331

J801

R193

C156

K402

R404

C405

C406

R403

C331

PP3

C801

C891
R893
C892
D891
Q891
R981
R982

C316

IC301

C312

Q892

R894

C315

R891 R892

D981

A

B901

R781
D782
R782
D781

C783

C885

C782

C438

C881

C451

C437

C427

C191

C404

C462

C428

R462

C441

C461

C168

C174

C379

R831

C336

C380

C326

C390

C356

C389

C346

W21

TU21

C161

B106

D192

B105

R832

R371

K831

D831

C831

C374

CN831

R377

R378

R376

R375

R385

R386

R335

R387

R388

R336
R325
R326

R355
R356
R345
R346

C5

C6

C7

R6

D783
Q783
Q782
Q781

IC901

CN961

C916

C917

C301

C314

C908

R901

C166

R163

R162

R372

C391

C1

R165

R381

C267

R382

B103 B104

C373

C384

C187

C383

C392

C43

R9

R8

R2

R3

C35

C8

C99

C2

Q4

R4

R7

Q7

D3

C968

R962

C970

C961

C903

C905

C902

C182

C172

C963

C181

C171

C170

C177

X31

C28

C41

R33

C33

Q14

Q31

C3

C9

Q5

R31

C31

C32

R5

C915

C904

B402

B401

C416

C415

C962

C998

C29

C30

R40

R42
R43

C81

C82

C914

C909

C910

C999

C907

R411

R412

C411

R414

R415R416

C414

K411

D921

CN411

R413

C722

R735

VPP

R779

R799

R780

R845

C734

C721

C93

C83

C91

C92

C51

R52

C969

R417

C413

C925

R968

K922
B921

C926

C723

C922

R709

GND

R740

RESET

C732

C55

R12

C4

C12

S702

C965

C913

C912

D717

D711

D710

C964

C927

C702

C701

D709

C928

R967

R969

IC921

C726

X722

C77

D707

D706

D705

D704

D703

D702

D701

D712

C703

D713

C704

CN701

C705
D714
D715

C921

R783

D719

VDD

C725

C724

X721

C727

C728

C729

C706

C730

C997

C103

C996

C176

C73
R73
C74

R75

R74

X71

C71

S701

R708

R101

R111

C101

C111

C102

C112

C113

R110

C186

C110

S723

Switch board

forward side reverse side

S610

S616

D601

D602

S611

D605

S613

D607

D603

S612

R610

D604

S614

D606

R612

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

S601

601

N

E

D608

CP602

R601

CP601

LCD1

D646

D609

D645

S608

D611

S617

D610

R602 R603

S602

D612

S603

D613

R604

R605

S605

S604

D614

S606

D615

S609

D617

D616

Q640

R646

R670

R642

CN601

R647

R648

R609
R608
R607

R614

R649

R611R613

R644

R645

R673R674

R671

D619

IC602

IC602

J601

R692

R691

J601

R606

S607

D618

R622

R623

R621

C620
R624

C611

C612

R620

R632

R630

R631

R633

R634

R635

D643

IC601

D641

C601

R658

R653

D642

R657

C602

R656

R655

R654

R651

C603

R652

D646

R661

R660

D645

R636
R637
R638
R639

E

R672

N

601

C681

C682

Q641

R650

R641

R640

D640

R643

2-7

Front end board

Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

forward side reverse side

IC303

C264

R255

R251

R302

K301

C361

R386

C263

R233

C366

C360

C213

R300

C260C261

C262

R232

R231

R310

IC304

R235

R438
C433

R437

C532

R301

R253

C254

R234

R534

R535

R387

R388

C380

R315

R316

C253

R532

R533

R379

C252

Q231

C211

C201

C431

R436

R434

C432

C521

R522

R531

C451

L451

C313

C339

R432

C301

R378

R377

C452

R376

L301

R330

R348

R344

R341

R201

R442

R347

R327

R328

C317
C491

C340

R21

K445

C533

R441

K452

R349

R342

R491

R492
C492

K444

K451

K406

R331

R329

Q301

C9

C318

TH491

R538

K404

K407

R346

R326

R325

R362

R359

R350

R340

R360

R493

R116
R114

R115

Q103

R537

K405

K401

R117

K102

C531

R536

K402

R305

R361

R118

IC411

C453

K441

K403

R312

R110

Q104

C108

R113

R355
R356

L307

R313

Q102

R435

C454

C302

C305

L306

C349

R108
R107

R109

R106

R433

K431

R390

C330

R105

R431

C421

R422

IC401

K426

R389

L305

C337

C338

K430

R112

SW4

R358

R357

C15

C332

R364
R363

C333

C334

Q101

B204

K433

C18

R314

C331

C359
C358

C106

R104

R111

C111

R345

C335

C105

R303

R354

R380

C102
R103

R353

R125

C20

C2

R322

C21

R321

K399

SW5

C397

C398

C22C23

C384

R23

IC398

EPDI

C481

R24

C393

IC481

C394

R481

R323

R396

R398

R324

R309

TP201 TP202

C310

R397

R101

REST

R308

C395

C396

TP5

C103

C104

B205

IC399

C307

C391

TP6

C1

IC301

C3

C4

C5

C392

C399

C7

R399

C8

R304

C308

TUBUYAKI

R258

TP7

R224

R374

C222

C112

CN101

TP3

C6

R372

C268

C113

R370

R373

C309

R383
R382

TP21

TP8

R381

R393

TP1

TP2

R394

TP24

TP4

R320

TP312

C323

C343

R335

R130

R371

TP303

C320

R334

R126

TP302

C346

R337

R127

Q105

C345

R336

R128

Q106

TP309

C321

R129

K101

Q107

SWGND

DCLK DDATA

BCK

AOUT3

PCMCLK

CN403

CN401

C17C19

C322

C344

R338

R339

TP16

TP25

TP18

LRCLK

TP313

LRMUTE

R120

R121

R119

L-END

C402

TP323

C16

C109C110

R124

R122

C404
C403
R404

K420

R123

TP23

R421

C522

TP416

TP417

K421

TP324

TP19

R403
C405
R402

C401

K422

C422

R521

R401

K423

K424

TP322

C13C14

TP9

TP422

C350

TP10

TP420

K427

K442

C348

TP11

TP425

K428

K429

C412

C11C12

TP321

TP12

TP426

TP427

K432

TP433

TP14

TP428

K425

R411

K443

C314

TP15

TP22

TP429

Q302

C411

R392

TP325

TP491

C347

C319

TP17

TP306

TP308

TP430

TP435

TP434

K434

C315

C311

C316

C371

R385

R204

R206

R207

TP315

TP307

TP432

TP431

TP439

TP436

C10

TP317

C341
C312

R384

C204

TP440

TP320

TP319

R367

R211

R202

TP437

TP441

R319

R351

C356

C324

R333

R210

R205

TDRV

TP314

TP444

R317

R208
R209

R220

TP20

R369

L303

FDRV

C207

R22

TP446

TP448

TP442

K601

B601

C325

C336

TP455

TP41

TP40

X351

R318

C206
C205

C203

R203

B201
B202

B203

L601

R306

R307

R352

C342

L302

TP34

SBRK

C202

C208

TP452

R604

R602

L602

C602
R601
C601
R603

C326

K311

TP38

TP37

TP35

C266

C256

R219

SW1

TP438

TP453

C603

CN201

C258

C257

C265

TP52

SW2
SW3

C365

TP457

C259

TP51

C364

C367

R260

TP39

C369

R606R605

C269

TP316

TP318

C221

R221

R223
R222

IC302

C368

R332

C255

C209

CN202

R366R365

C362

CN402

TP36

TP33

IC251

R252

C212

TP32

R259

TRSDR

C267

TP31

FG

R256

V

C303

R254

C251

/SPMUTE

SPDRV

R257

2-8

Exploded view of general assembly and parts list

7

38

13

20

12

32

44

24

46

34

21

47

26

39

51

37

23

31

C

13

Switch board

30

88

22

25

33

28

36

29

54

48

Block No.

1

35

27

54

54

M

M

1

M

89

B

15

41

42

50

40

59

55

43

65

45

58

49

56

52

66

53

Main sub board

57

17

16

4

4

5

6

19

5

18

67

3-2

70

72

90

89

2

68

H

14

69

71

91

10

E

F

8

A

11

K

G

93

74

76

75

78

78

79

10

82

81

80

J

D

73

77

83

A

10

85

86

C

8

D

E

F

G

B

3

H

K

J

19

5

67

9

84

Main board

87

9

61

4

60

6

64

62

63

18

7

6

7

92

3-3

General Assembly

Block No. [M][1][M][M]



Symbol No. Part No. Part Name Description Local

1 LV10774-008A TOP CHASSIS
2 LV40848-044A SPACER(P)
3 LV34061-001A SIDE HEAT SINK
4 QYSDST2003ZA TAP SCREW M2 x 3mm(x2)
5 QYSDST2606ZA TAP SCREW M2.6 x 6mm(x2)
6 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
7 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x2)
8 GE40235-001A SCREW (x2)
9 GE40235-004A SCREW (x3)
10 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3)
11 LV41200-005A SCREW (x3)
12 QYSDSF2006ZA TAP SCREW M2 x 6mm(x2)
13 QYSDST2004ZA TAP SCREW M2 x 4mm(x2)
14 QYSDST2604ZA TAP SCREW M2.6 x 4mm
15 LV34460-001A INSULATOR
16 GE40255-001A SUPPORT BRACKET
17 GE20180-001A DUST COVER
18 GE40218-034A SHEET
19 GE40278-001A SHEET
20 LV34065-004A F.CHASSIS ASSY
21 FSYH4036-098 SHEET
22 GE30827-002A OPEN LEVER
23 GE30824-002A LOCK LEVER(O.L)
24 GE31245-002A RELEASE LEVER
25 GE30829-001A LOCK LEVER(TOP)
26 GE31607-001A LOCK LEVER(L)
27 GE31608-001A LOCK LEVER(R)
28 GE40154-001A GEAR
29 QZW0108-002 OIL DAMPER
30 GE40153-001A T.SPRING
31 GE40157-001A T.SPRING
32 VKW5264-005 T.SPRING
33 FSKW4012-002 T.SPRING
34 LV43392-001A T.SPRING
35 GE40155-001A T.SPRING
36 QYSDSF2006ZA TAP SCREW M2 x 6mm
37 GE40156-001A BLIND
38 LV40848-042A SPACER(P)
39 LV40848-043A SPACER(P)
40 GE31590-035A FRONT PANEL ASSY DV5201EU
40 GE31590-036A FRONT PANEL ASSY DV5202EU
40 GE31590-037A FRONT PANEL ASSY DV5205U,DV5205UT
40 GE31590-038A FRONT PANEL ASSY DV5206U,DV5206UT
40 GE31590-039A FRONT PANEL ASSY DV6205A,DV6205U,DV6205UT
40 GE31590-040A FRONT PANEL ASSY DV6206A,DV6206U,DV6206UT
41 GE31591-033A FINDER ASSY DV5201EU
41 GE31591-034A FINDER ASSY DV5202EU
41 GE31592-014A FINDER ASSY DV5205U,DV5205UT
41 GE31592-015A FINDER ASSY DV5206U,DV5206UT
41 GE31591-035A FINDER ASSY DV6205A,DV6205U,DV6205UT
41 GE31591-036A FINDER ASSY DV6206A,DV6206U,DV6206UT
42 GE40298-001A VOLUME KNOB ASS DV5201EU,DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
42 GE40298-002A VOLUME KNOB ASS DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
43 GE31599-002A RIM LENS DV5201EU,DV5202EU

43 GE31599-001A RIM LENS

44 GE31593-006A D.FUNC BTN DV5201EU
44 GE31593-013A D.FUNC BTN DV5202EU
44 GE31593-008A D.FUNC BTN DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
44 GE31593-001A D.FUNC BTN DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
45 GE20175-009A PRESET BUTTON DV5201EU
45 GE20175-007A PRESET BUTTON DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
45 GE20175-010A PRESET BUTTON DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
46 GE31594-004A UP/DOWN BTN DV5201EU
46 GE31594-002A UP/DOWN BTN DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
46 GE31594-001A UP/DOWN BTN DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
47 GE31595-004A SEARCH BTN DV5201EU
47 GE31595-002A SEARCH BTN DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
47 GE31595-001A SEARCH BTN DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
48 VKZ4777-010 MINI SCREW
49 GE31601-003A EJECT BUTTON DV5201EU
49 GE31601-002A EJECT BUTTON DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
49 GE31601-005A EJECT BUTTON DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
50 GE31598-001A RIM COVER DV5201EU,DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT

DV5205U,DV5205UT,DV5206U,DV5206UT,
DV6205A,DV6205U,DV6205UT,DV6206A,DV6206U,DV6206UT

3-4



Symbol No. Part No. Part Name Description Local

50 GE31598-002A RIM COVER DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
51 FSKW3002-012 COMP.SPRING
52 GE40202-012A COMPRESSION SPRING
53 GE10107-002A REAR COVER
54 VKZ4777-010 MINI SCREW (x4)
55 GE31603-001A LCD CASE
56 GE31604-001A LCD LENS
57 GE31605-001A LENS CASE
58 GE40251-002A LIGHTING SHEET
59 GE40218-032A SHEET
60 LV34058-002A BOTTOM COVER
61 GE31663-001A INSULATOR
62 GE32196-001A NAME PLATE DV5201EU
62 GE32199-001A NAME PLATE DV5202EU
62 GE32210-001A NAME PLATE DV5205U,DV5205UT
62 GE32213-001A NAME PLATE DV5206U,DV5206UT
62 GE32202-001A NAME PLATE DV6205A,DV6205U,DV6205UT
62 GE32206-001A NAME PLATE DV6206A,DV6206U,DV6206UT
63 LV41843-002A LASER CAUTION
64 GE31683-010A LABEL (DVD) DV5201EU,DV5202EU

64 GE31683-011A LABEL (DVD)

64 GE31683-012A LABEL (DVD) DV6205A,DV6206A
65 QLD0420-001 LCD MODULE
66 QNZ0772-001 RUBBER CONN
67 QUQP05-4510BB-E FFC WIRE 45pin 10cm

68 QAM0680-001 HP CABLE

69 QAM0685-001 LINE IN CABLE
70 QAM0683-001 COMPOSITE CABLE

71 QAM0684-001 SUBWOOFER CABLE

72 VYTA500-001 PIN CAP (x2)



73 QMFZ039-150-T FUSE 15A
74 QAR0294-001 FAN MOTOR

75 GE31609-021A REAR BRACKET

75 GE31609-023A REAR BRACKET DV5205U,DV5205UT,DV5206U,DV5206UT
76 GE40252-002A FAN BRACKET
77 GE40253-001A WIRE HOLDER
78 QYSDST2604ZA TAP SCREW M2.6 x 4mm(x2)
79 QYSDST2604ZA TAP SCREW M2.6 x 4mm
80 QYSDST2606ZA TAP SCREW M2.6 x 6mm
81 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
82 QYSDSF2606ZA TAP SCREW M2.6 x 6mm
83 QYSDST2604ZA TAP SCREW M2.6 x 4mm
84 GE40270-001A SHIELD COVER
85 LV43349-002A POWER IC BKT
86 LV43373-002A REGULATOR BKT
87 VMA4652-001SS EARTH PLATE
88 GE30854-001A LED HOLDER
89 GE31574-037A UT LABEL DV5205UT
89 GE31574-038A UT LABEL DV5206UT
89 GE31574-039A UT LABEL DV6205UT
89 GE31574-040A UT LABEL DV6206UT

90 VYTA500-001 PIN CAP (x2)

91 QYSDST2604ZA TAP SCREW M2.6 x 4mm DV5201EU,DV5202EU
92 LV44385-001A RECYCLE LABEL DV5201EU,DV5202EU
93 QAM0686-001 STEERING REMOTE DV5201EU,DV5202EU

DV5205U,DV5205UT,DV5206U,DV5206UT,
DV6205U,DV6205UT,DV6206U,DV6206UT

DV5201EU,DV5202EU,DV6205A,DV6205U,DV6205UT,
DV6206A,DV6206U,DV6206UT

DV5201EU,DV5202EU,DV6205A,DV6205U,DV6205UT,
DV6206A,DV6206U,DV6206UT

DV5201EU,DV5202EU,DV6205A,DV6205U,DV6205UT,
DV6206A,DV6206U,DV6206UT

DV5201EU,DV5202EU,DV6205A,DV6205U,DV6205UT,
DV6206A,DV6206U,DV6206UT

3-5

DVD mechanism assembly and parts list

Grease

=

JVS-1003

=

MOBIL-1

=

JVG-31N

=

JC-803B

=

1401C

= FG-87HS

93

30

29

FMU-JD5-2D

97

94

96

95

92

14

15

18

87

Block No.

18

A

M

J

M

M

62

17

34

10

16

13

53

32

55

56

36

91

28

27

B

29

31

90

88

INSIDE

89

c

34

OUTSIDE

37

64

35

33

48

51

49

45

47

F

44

46

50

54

H

G

K

23

3

60

61

52

63

BACK SIDE

6

7

75

24

C

57

58

G

59

H

K

20

21

AFTER SET PICK UP SA.
APPLY GREASE

74

40

43

39

41

B

22

19

38

43

c

65

42

E

D

J

26

F

73

72

25

76

79

3

71

70

83

86

80

67

12

10

11

5

8

D

9

77

78

12

8

5

A

10

4

INSIDE

69

68

b

66

86

a

85

E

81

84

86

J

82

1

a

17

16

1

2

3-6

The parts without symbol number are not service.

DVD mechanism



Symbol No. Part No. Part Name Description Local

1 VKZ4539-056 MINI SCREW (x2)
2 QYSPSFT2040ZA TAP SCREW M2 x 4mm
3 LV43481-001A COOLING RUBBER (x2)
4 LV10674-001A CHASSIS FRAME
5 LV30225-0J6A SPACER (x2)
6 VKZ4539-056 MINI SCREW
7 VYSA1R4-056 SPACER
8 LV35272-001A DAMPER(F) (x2)
9 LV35273-001A DAMPER(R)
10 QYSDST2005ZA TAP SCREW M2 x 5mm(x3)
11 LV43039-001A DAMPER SP.(R)
12 LV43849-001A DAMPER SP(F2) (x2)
13 LV43041-001A FLOATING SPRING (x2)
14 LV10675-001A TOP COVER
15 LV30225-0J5A SPACER
16 VKZ4539-056 MINI SCREW (x2)
17 LV33669-001A STOPPER (x2)
18 VKZ4539-056 MINI SCREW (x2)
19 LV21297-004A CHAS. BASE ASSY
20 LV33608-002A GEAR HOLDER
21 VKZ4539-056 MINI SCREW
22 LV43561-002A ABSORBER
23 LV30225-0J5A SPACER
24 LV36831-001A SLIDE CAM ASSY2
25 LV33610-002A FLOATING ARM
26 LV33611-001A CONNECT ARM
27 LV33678-003A LOADING A. ASSY
28 LV43049-001A LOADING SHAFT
29 LV43052-003A ROLLER (x2)
30 LV33612-001A LOADING GEAR
31 QYWFM124013 WASHER 4mm/1.2mm x 0.13mm
32 LV43053-002A ROD(L)
33 LV43054-003A ROD(R)
34 LV43001-001A COLLAR (x2)
35 LV21285-003A PROTECTOR
36 LV43055-001A PROTECTOR SP.
37 QAR0373-001 MOTOR
38 LV43002-002A WORM GEAR
39 QYSPSPT2025MA SCREW M2 x 2.5mm(x2)
40 LV33679-001A MOTOR H. ASSY
41 LV33614-003A WORM WHEEL
42 QYWDL1230250 SLIT WASHER 3mm/1.2mm x 0.25mm
43 VKZ4539-056 MINI SCREW (x2)
44 LV33615-001A GEAR 2
45 LV43057-004A IDLER ARM ASSY
46 QYWDL1635252 SLIT WASHER 3.5mm/1.6mm x 0.25mm
47 LV21286-001A CONTROL CAM
48 QYWDL1230196 SLIT WASHER 3mm/1.2mm x 0.19mm
49 LV33616-002A LOAD.LOCK LEVER
50 LV43060-001A CAM SPRING
51 LV43005-001A GEAR 4
52 LV43006-002A GEAR 5
53 LV33617-002A GEAR 6
54 LV33618-002A LOADING G. ARM
55 QYWDL1635252 SLIT WASHER 3.5mm/1.6mm x 0.25mm
56 LV43007-002A GEAR 7
57 LV33619-002A GEAR 8
58 LV42132-001A E RING
59 QYWFM215013 WASHER 5mm/2.1mm x 0.13mm
60 LV33620-001A GEAR 9
61 LV43008-001A GEAR10
62 LV43061-001A LOAD SPRING
63 LV33621-001A FEED GEAR
64 LV33622-002A TRIGGER ARM
65 LV43062-001A FEED TRI.SPRING
66 QAR0240-002 SPINDLE MOTOR
67 LV21287-002A SPINDLE BASE
68 LV44169-001A SPECIAL SCREW (x2)
69 VKZ4539-056 MINI SCREW (x2)
70 QAL0742-001 DVD PICK UP
71 LV34583-002A CD RACK PLATE
72 LV34579-001A CD RACK SPRING
73 LV43903-002A MINI TAP SCREW
74 LV43037-001A LEAD SCREW

Block No. [M][J][M][M]

3-7



Symbol No. Part No. Part Name Description Local

75 LV43010-001A L.S.GEAR
76 LV43063-001A L.S.COLLAR
77 LV43011-001A THRUST SPRING
78 QYSPSFT2040ZA TAP SCREW M2 x 4mm
79 LV33624-001A HOLDER(M)
80 VKZ4539-056 MINI SCREW (x2)
81 LV22130-001A HOLDER(S) 2
82 VKZ4539-056 MINI SCREW (x2)
83 LV43064-001A ROD(M)
84 LV43065-001A ROD(S)
85 LV43066-001A SUB SHAFT
86 VKZ4730-002 SPECIAL SCREW (x3)
87 LV21298-007A CLAMPER UNIT
88 LV43070-001A CLAMPER SPRING
89 LV43355-001A CLAMPER2 SPRING
90 LV30225-0J6A SPACER
91 LV22185-001A FRONT UNIT (C)
92 VKZ4539-056 MINI SCREW
93 LVB30012-002A SW FPC
94 NSW0187-001 SWITCH S1
95 NSW0187-001 SWITCH S1
96 NSW0187-001 SWITCH S1
97 VKZ4539-055 MINI SCREW (x2)

3-8

Electrical parts list

Main board
(KD-DV5201EU,KD-DV5202EU)

Block No. [0][1]



Symbol No.



IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC101 NJM4565V-X IC
IC161 TDA7416 IC
IC162 CD4066BPW-X IC
IC301 TB2906HQ IC
IC371 NJM2160BV-X IC
IC381 NJM2160BV-X IC
IC401 SN74AHCT1G08V-X IC
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC
IC421 NJM4580V-X IC
IC431 LC75344M-X IC



IC721 UPD784217AGC329 IC
IC722 BR24L32F-W-X IC(DIGITAL)
IC723 S-80833CNNB-G-W IC
IC801 HD74HC126FP-X IC



IC901 R2S25400DS-E IC
IC921 BA33BC0FP-X IC
IC922 BD9781HFP-W IC
IC961 SN74LVC32APW-X IC
IC962 SN74HCT32APW-X IC

Q4 2SA1365/F/-X TRANSISTOR
Q5 RT1N141C-X DIGI TRANSISTOR
Q7 2SA1530A/R/-X TRANSISTOR
Q9 RT1P141C-X DIGI TRANSISTOR
Q10 RT1P141C-X DIGI TRANSISTOR
Q11 RT1N141C-X DIGI TRANSISTOR
Q12 KTD1304-X TRANSISTOR
Q14 RT1N141C-X DIGI TRANSISTOR
Q31 RT1N141C-X DIGI TRANSISTOR
Q51 RT1N141C-X DIGI TRANSISTOR
Q52 2SC3928A/R/-X TRANSISTOR
Q53 2SC3928A/R/-X TRANSISTOR
Q81 KTD1304-X TRANSISTOR
Q91 KTD1304-X TRANSISTOR
Q161 RT1N141C-X DIGI TRANSISTOR
Q162 RT1N141C-X DIGI TRANSISTOR
Q191 KTD1304-X TRANSISTOR
Q192 RT1P441C-X DIGI TRANSISTOR
Q301 RT1N441C-X TRANSISTOR
Q302 RT1P441C-X DIGI TRANSISTOR
Q303 RT1N141C-X DIGI TRANSISTOR
Q304 RT1N141C-X DIGI TRANSISTOR
Q324 KTD1304-X TRANSISTOR
Q334 KTD1304-X TRANSISTOR
Q344 KTD1304-X TRANSISTOR
Q354 KTD1304-X TRANSISTOR
Q421 KTD1304-X TRANSISTOR
Q422 KTD1304-X TRANSISTOR
Q431 KTD1304-X TRANSISTOR
Q432 KTD1304-X TRANSISTOR
Q701 2SA1530A/R/-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q782 RT1P141C-X DIGI TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q821 RT1N141C-X DIGI TRANSISTOR
Q822 RT1P141C-X DIGI TRANSISTOR
Q823 2SD1994A/RS/-T TRANSISTOR
Q881 2SC3928A/R/-X TRANSISTOR
Q885 RT1N141C-X DIGI TRANSISTOR
Q891 RT1N141C-X DIGI TRANSISTOR
Q903 2SA1530A/R/-X TRANSISTOR
Q904 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N441C-X TRANSISTOR
Q977 2SA1530A/R/-X TRANSISTOR

D1 1SS355W-X DIODE
D2 1SS355W-X DIODE

Part No. Part Name Description Local



Symbol No.

D3 MC2838-X DIODE
D5 1SS355W-X DIODE
D192 1SS355W-X DIODE
D301 UDZS11B-X Z DIODE
D302 1SS355W-X DIODE
D305 CRS03-W SB DIODE
D308 CRS03-W SB DIODE
D324 1SS355W-X DIODE
D334 1SS355W-X DIODE
D344 1SS355W-X DIODE
D354 1SS355W-X DIODE
D401 CRS03-W SB DIODE
D421 1SS355W-X DIODE
D431 1SS355W-X DIODE
D701 UDZW6.2B-X Z DIODE
D702 UDZW6.2B-X Z DIODE
D703 UDZW6.2B-X Z DIODE
D704 UDZW6.2B-X Z DIODE
D705 UDZW6.2B-X Z DIODE
D706 UDZW6.2B-X Z DIODE
D707 UDZW6.2B-X Z DIODE
D709 UDZW6.2B-X Z DIODE
D710 UDZW6.2B-X Z DIODE
D711 UDZW6.2B-X Z DIODE
D712 UDZW5.1B-X SB DIODE
D713 UDZW5.1B-X SB DIODE
D714 UDZW5.1B-X SB DIODE
D715 UDZW5.1B-X SB DIODE
D716 UDZW6.2B-X Z DIODE
D717 UDZW6.2B-X Z DIODE
D719 SLR-56VC3F DIODE C.M
D731 1SS355W-X DIODE
D781 MC2836-X DIODE
D782 MC2836-X DIODE
D783 UDZS9.1B-X Z DIODE
D801 CRS03-W SB DIODE
D821 UDZS12B-X Z DIODE
D831 UDZW6.2B-X Z DIODE
D885 1SS355W-X DIODE
D891 MC2836-X DIODE



D901 1N5401-F64 SI DIODE
D903 1SS355W-X DIODE
D906 UDZW5.1B-X SB DIODE
D921 1A3G-T1 SI DIODE
D922 RB051L-40-X SB DIODE
D981 CRS03-W SB DIODE
D982 CRS03-W SB DIODE

C2 NCB31HK-102X C CAPACITOR 1000pF 50V K
C3 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C6 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C7 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C9 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C12 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C13 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C28 NCS31HJ-7R0X C CAPACITOR 7pF 50V J
C29 NDC31HJ-100X C CAPACITOR 10pF 50V J
C30 NDC31HJ-100X C CAPACITOR 10pF 50V J
C31 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C32 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C33 NCB31HK-102X C CAPACITOR 1000pF 50V K
C34 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C35 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C36 NCB31HK-102X C CAPACITOR 1000pF 50V K
C37 NCB31HK-272X C CAPACITOR 2700pF 50V K
C38 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C39 NCS31HJ-101X C CAPACITOR 100pF 50V J
C40 NDC31HJ-470X C CAPACITOR 47pF 50V J
C41 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C42 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C43 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCS31HJ-470X C CAPACITOR 47pF 50V J

Part No. Part Name Description Local

3-9



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C50 NCS31HJ-101X C CAPACITOR 100pF 50V J
C51 NCS31HJ-331X C CAPACITOR 330pF 50V J
C52 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C53 NCB31HK-472X C CAPACITOR 4700pF 50V K
C54 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C55 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C71 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C72 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C73 NCS31HJ-470X C CAPACITOR 47pF 50V J
C74 NCS31HJ-820X C CAPACITOR 82pF 50V J
C75 NCS31HJ-561X C CAPACITOR 560pF 50V J
C76 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C77 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C81 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C82 NCB31HK-102X C CAPACITOR 1000pF 50V K
C83 QTE1H57-105Z E CAPACITOR 1uF 50V
C84 NCB31HK-122X C CAPACITOR 1200pF 50V K
C91 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C92 NCB31HK-102X C CAPACITOR 1000pF 50V K
C93 QTE1H57-105Z E CAPACITOR 1uF 50V
C94 NCB31HK-122X C CAPACITOR 1200pF 50V K
C99 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C101 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C102 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C103 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C109 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C110 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C111 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C112 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C113 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C155 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C156 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C161 QTE1A57-107Z E CAPACITOR 100uF 10V
C162 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C163 NFV81CM-105X MF CAPACITOR 1uF 16V M
C164 NFV81CM-105X MF CAPACITOR 1uF 16V M
C165 NFV81CM-105X MF CAPACITOR 1uF 16V M
C166 QTE1C57-106Z E CAPACITOR 10uF 16V
C168 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C170 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C171 QTE1H57-225Z E CAPACITOR 2.2uF 50V
C172 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C174 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C175 NCB31HK-471X C CAPACITOR 470pF 50V K
C176 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C181 QTE1H57-225Z E CAPACITOR 2.2uF 50V
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C184 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C185 NCB31HK-471X C CAPACITOR 470pF 50V K
C186 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C191 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C267 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C301 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 NBE21CM-475X TA E CAPACITOR 4.7uF 16V M
C312 QTE1C57-476Z E CAPACITOR 47uF 16V
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C315 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C326 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C328 NFV81CM-105X MF CAPACITOR 1uF 16V M
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C336 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C338 NFV81CM-105X MF CAPACITOR 1uF 16V M
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 NFV81CM-105X MF CAPACITOR 1uF 16V M
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 NFV81CM-105X MF CAPACITOR 1uF 16V M
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J
C373 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C375 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C376 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C377 NCB31HK-152X C CAPACITOR 1500pF 50V K
C378 NCB31HK-152X C CAPACITOR 1500pF 50V K
C379 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C380 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C383 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C384 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C385 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C386 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C387 NCB31HK-152X C CAPACITOR 1500pF 50V K
C388 NCB31HK-152X C CAPACITOR 1500pF 50V K
C389 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C390 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C391 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C392 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C423 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C424 NCS31HJ-151X C CAPACITOR 150pF 50V J
C425 NCS31HJ-101X C CAPACITOR 100pF 50V J
C426 NCS31HJ-221X C CAPACITOR 220pF 50V J
C427 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C428 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C432 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C433 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C434 NCS31HJ-151X C CAPACITOR 150pF 50V J
C435 NCS31HJ-101X C CAPACITOR 100pF 50V J
C436 NCS31HJ-221X C CAPACITOR 220pF 50V J
C437 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C438 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C441 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C451 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C461 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C462 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C463 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C464 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C465 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C701 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C703 NDC31HJ-101X C CAPACITOR 100pF 50V J
C704 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C705 NDC31HJ-101X C CAPACITOR 100pF 50V J
C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C782 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C831 NCS31HJ-101X C CAPACITOR 100pF 50V J
C881 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

3-10



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C892 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C908 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C910 NCB31HK-102X C CAPACITOR 1000pF 50V K
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXF1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C961 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C964 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C965 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C997 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J

R1 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R2 NRS181J-220X MG RESISTOR 22Ω 1/8W J
R3 NRS181J-220X MG RESISTOR 22Ω 1/8W J
R4 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R5 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R6 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R7 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R8 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R9 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R11 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R13 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R14 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R31 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R32 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R33 NRSA63J-101X MG RESISTOR 100
R34 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R35 NRSA63J-393X MG RESISTOR 39k
R36 NRSA63J-221X MG RESISTOR 220
R37 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R38 NRSA63J-100X MG RESISTOR 10
R39 NRSA63J-622X MG RESISTOR 6.2k
R40 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R42 NRSA63J-103X MG RESISTOR 10k
R43 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R44 NRSA63J-103X MG RESISTOR 10k
R51 NRSA63J-473X MG RESISTOR 47k
R52 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R53 NRSA63J-473X MG RESISTOR 47k
R54 NRSA63J-222X MG RESISTOR 2.2k
R55 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R56 NRSA63J-103X MG RESISTOR 10k
R57 NRSA63J-103X MG RESISTOR 10k
R58 NRSA63J-153X MG RESISTOR 15k
R59 NRSA63J-471X MG RESISTOR 470
R72 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R73 NRSA63J-222X MG RESISTOR 2.2k
R74 NRSA63J-222X MG RESISTOR 2.2k
R75 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R81 NRSA63J-113X MG RESISTOR 11k
R82 NRSA63J-183X MG RESISTOR 18k
R83 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R91 NRSA63J-113X MG RESISTOR 11k
R92 NRSA63J-183X MG RESISTOR 18k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R93 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R102 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R103 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R104 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R105 NRSA63J-103X MG RESISTOR 10k
R106 NRSA63J-103X MG RESISTOR 10k
R107 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R111 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R113 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R114 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R115 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R116 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R117 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R141 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R151 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R155 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R161 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R162 NRSA63J-473X MG RESISTOR 47k
R163 NRSA63J-473X MG RESISTOR 47k
R164 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R165 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R166 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R167 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R168 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R169 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R170 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R171 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R172 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R173 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R191 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R192 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R193 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R302 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R303 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R304 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R305 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R306 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R307 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R308 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R323 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R324 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R325 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R326 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R327 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R328 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R329 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R330 NRSA63J-102X MG RESISTOR 1k
R333 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R334 NRSA63J-222X MG RESISTOR 2.2k
R335 NRSA63J-102X MG RESISTOR 1k
R336 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R337 NRSA63J-0R0X MG RESISTOR 0
R338 NRSA63J-473X MG RESISTOR 47k
R339 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R340 NRSA63J-102X MG RESISTOR 1k
R343 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R344 NRSA63J-222X MG RESISTOR 2.2k
R345 NRSA63J-102X MG RESISTOR 1k
R346 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R347 NRSA63J-0R0X MG RESISTOR 0
R348 NRSA63J-473X MG RESISTOR 47k
R349 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R350 NRSA63J-102X MG RESISTOR 1k
R353 NRSA63J-473X MG RESISTOR 47k
R354 NRSA63J-222X MG RESISTOR 2.2k
R355 NRSA63J-102X MG RESISTOR 1k
R356 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R357 NRSA63J-0R0X MG RESISTOR 0
R358 NRSA63J-473X MG RESISTOR 47k
R359 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R360 NRSA63J-102X MG RESISTOR 1k
R371 NRSA63J-102X MG RESISTOR 1k
R372 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R373 NRSA63J-104X MG RESISTOR 100k
R374 NRSA63J-104X MG RESISTOR 100k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

3-11



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R375 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R376 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R377 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R378 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R381 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R382 NRSA63J-102X MG RESISTOR 1k
R383 NRSA63J-104X MG RESISTOR 100k
R384 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R385 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R386 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R387 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R388 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R401 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R402 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R403 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R404 NRSA63J-1R0X MG RESISTOR 1Ω 1/16W J
R411 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R412 NRSA63D-682X MG RESISTOR 6.8kΩ 1/16W D
R413 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R414 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R415 NRSA63J-750X MG RESISTOR 75
R416 NRSA63J-0R0X MG RESISTOR 0
R417 NRSA63D-181X MG RESISTOR 180Ω 1/16W D
R421 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R422 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R423 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R424 NRSA63J-390X MG RESISTOR 39Ω 1/16W J
R425 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R426 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R427 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R428 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R429 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R431 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R432 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R433 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R434 NRSA63J-390X MG RESISTOR 39Ω 1/16W J
R435 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R436 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R437 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R438 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R439 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R441 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R442 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R451 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R452 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R461 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R462 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R463 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R701 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R702 NRSA63J-0R0X MG RESISTOR 0
R703 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R704 NRSA63J-271X MG RESISTOR 270
R705 NRSA63J-271X MG RESISTOR 270
R706 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R707 NRSA63J-103X MG RESISTOR 10k
R708 NRS181J-331X MG RESISTOR 330
R709 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R710 NRSA63J-102X MG RESISTOR 1k
R711 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R712 NRSA63J-104X MG RESISTOR 100k
R713 NRSA63J-103X MG RESISTOR 10k
R714 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R715 NRSA63J-271X MG RESISTOR 270
R716 NRSA63J-271X MG RESISTOR 270
R717 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R718 NRSA63J-103X MG RESISTOR 10k
R719 NRSA63J-102X MG RESISTOR 1k
R720 NRSA63J-102X MG RESISTOR 1k
R721 NRSA63J-222X MG RESISTOR 2.2k
R722 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R725 NRSA63J-473X MG RESISTOR 47k
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R728 NRSA63J-472X MG RESISTOR 4.7k
R729 NRSA63J-0R0X MG RESISTOR 0
R730 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R732 NRSA63J-222X MG RESISTOR 2.2k
R733 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R735 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R737 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R739 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R740 NRSA63J-222X MG RESISTOR 2.2k
R743 NRSA63J-473X MG RESISTOR 47k
R744 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R745 NRSA63J-106X MG RESISTOR 10MΩ 1/16W J
R746 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R747 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R750 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R751 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R752 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R753 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R754 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R755 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R756 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R757 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R758 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R759 NRSA63J-224X MG RESISTOR 220k
R760 NRSA63J-472X MG RESISTOR 4.7k
R761 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R762 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R763 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R765 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R767 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R768 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R769 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R770 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R771 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R772 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R773 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R774 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R775 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R776 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R777 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R779 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R780 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R781 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R782 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R799 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R801 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R802 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R803 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R804 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R805 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R806 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R807 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R808 NRSA63J-223X MG RESISTOR 22k
R809 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R810 NRSA63J-473X MG RESISTOR 47k
R821 NRSA63J-100X MG RESISTOR 10
R822 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R831 NRSA63J-0R0X MG RESISTOR 0
R832 NRSA63J-271X MG RESISTOR 270
R841 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R842 NRSA63J-473X MG RESISTOR 47k
R845 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R881 NRSA63J-473X MG RESISTOR 47k
R882 NRSA63J-103X MG RESISTOR 10k
R883 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R885 NRSA63J-473X MG RESISTOR 47k
R886 NRSA63J-472X MG RESISTOR 4.7k
R887 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R888 NRSA63J-0R0X MG RESISTOR 0
R889 NRSA63J-0R0X MG RESISTOR 0
R891 NRSA63J-473X MG RESISTOR 47k
R892 NRSA63J-102X MG RESISTOR 1k
R894 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R901 QRE142J-102X C RESISTOR 1k
R902 NRSA63J-912X MG RESISTOR 9.1k
R903 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R909 NRSA63J-473X MG RESISTOR 47k
R910 NRSA63J-222X MG RESISTOR 2.2k
R914 NRS181J-221X MG RESISTOR 220Ω 1/8W J
R921 NRS181J-0R0X MG RESISTOR 0
R923 NRSA63J-393X MG RESISTOR 39k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/4W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

3-12



Symbol No.

R924 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R925 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R926 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R927 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R928 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R961 NRS181J-0R0X MG RESISTOR 0
R962 NRSA63J-101X MG RESISTOR 100
R967 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R968 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R969 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R973 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R974 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R975 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R976 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R977 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R981 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
R982 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
RA31 NRZ0065-222X NET RESISTOR 2.2k
RA721 NRZ0065-222X NET RESISTOR 2.2k
RA723 NRZ0065-103X NET RESISTOR 10kΩ 1/16W J

L1 NQL334J-4R7X COIL 4.7uH J
L31 NQL114K-470X INDUCTOR 47uH K
L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K
L421 NQR0007-002X FERRITE BEADS
L430 NQR0007-002X FERRITE BEADS
L431 NQR0007-002X FERRITE BEADS
L721 NQL38DK-330X COIL 33uH K
L722 NQL114K-470X INDUCTOR 47uH K
L901 QQR1378-002 COIL
L902 NQL56CK-220X COIL 22uH K
L924 NQL56CK-220X COIL 22uH K
L925 NQL71EM-330X COIL 33uH M
L927 NQLB7GM-100X COIL 10uH M

CN141 QGA2006C1-04 CONNECTOR W-B (1-4)
CN191 QGA2501C3-03Z CONNECTOR W-B (1-3)
CN411 QGA2501F1-02 CONNECTOR W-B (1-2)
CN421 QGA2501C3-03Z CONNECTOR W-B (1-3)
CN701 QNZ0605-001 CAR CONNECTOR
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN831 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2027M3-30S CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L9-30X CONNECTOR B-B (1-30)
J331 QNN0489-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
K831 NQR0007-002X FERRITE BEADS
K922 NQR0201-004X FERRITE BEADS
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
PP3 QZW0010-001 STYLE PIN
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k



TU21 QAU0313-001 TUNER
W21 QAM0105-003 CAR CABLE
X31 QAX0616-001Z CRYSTAL 10.250MHz
X71 QAX0263-001Z CRYSTAL 4.332MHz
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz

Part No. Part Name Description Local

Ω

1/8W J

Ω

1/16W J

Ω
Ω

Ω

Switch board
(KD-DV5201EU,KD-DV5202EU)

Block No. [0][2]



Symbol No.

IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER

Q640 2SA1365/F/-X TRANSISTOR
Q641 RT1N141C-X DIGI TRANSISTOR

D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 SML310BA1T/HJ-X LED
D609 SML310BA1T/HJ-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MC2838-X DIODE
D641 UDZW5.1B-X SB DIODE
D642 1SS355W-X DIODE
D643 UDZW6.2B-X Z DIODE
D645 NSPW310BS/B2RST LED
D646 NSPW310BS/B2RST LED

C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C620 NCB31HK-473X C CAPACITOR 0.047uF 50V K

R601 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
R606 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R607 NRSA63J-821X MG RESISTOR 820
R608 NRSA63J-821X MG RESISTOR 820
R609 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k
R611 NRSA63J-272X MG RESISTOR 2.7k
R612 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R613 NRSA63J-821X MG RESISTOR 820
R614 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0
R621 NRSA63J-0R0X MG RESISTOR 0
R622 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R623 NRSA63J-473X MG RESISTOR 47k
R624 NRSA63J-471X MG RESISTOR 470
R630 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J DV5201EU
R630 NRSA63J-122X MG RESISTOR 1.2k
R631 NRSA63J-122X MG RESISTOR 1.2k
R632 NRSA63J-821X MG RESISTOR 820
R632 NRSA63J-122X MG RESISTOR 1.2k
R633 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J DV5202EU
R634 NRSA63J-331X MG RESISTOR 330
R634 NRSA63J-271X MG RESISTOR 270
R636 NRSA63J-331X MG RESISTOR 330Ω 1/16W J DV5201EU
R636 NRSA63J-271X MG RESISTOR 270
R638 NRSA63J-471X MG RESISTOR 470
R640 NRSA02J-331X MG RESISTOR 330Ω 1/10W J
R641 NRSA02J-121X MG RESISTOR 120
R642 NRSA02J-331X MG RESISTOR 330

Part No. Part Name Description Local

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J DV5202EU

Ω

1/16W J DV5202EU

Ω

1/16W J DV5201EU

Ω

1/16W J DV5202EU

Ω

1/16W J DV5201EU

Ω

1/16W J DV5202EU

Ω

1/16W J DV5202EU

Ω

1/16W J

Ω

1/10W J

Ω

1/10W J

3-13



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R643 NRSA02J-201X MG RESISTOR 200Ω 1/10W J
R644 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R646 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R648 NRSA63J-331X MG RESISTOR 330Ω 1/16W J DV5201EU
R648 NRSA63J-271X MG RESISTOR 270Ω 1/16W J DV5202EU
R651 NRSA63J-222X MG RESISTOR 2.2k
R652 NRSA63J-222X MG RESISTOR 2.2k
R653 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R655 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R656 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R657 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R658 NRSA63J-184X MG RESISTOR 180kΩ 1/16W J
R660 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R661 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R672 NRSA02J-471X MG RESISTOR 470Ω 1/10W J
R673 NRSA02J-473X MG RESISTOR 47kΩ 1/10W J
R674 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R691 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R692 NRSA63J-471X MG RESISTOR 470

CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
J601 QNS0245-001 AUX JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Main board
(KD-DV5205U,KD-DV5205UT,
KD-DV5206U,KD-DV5206UT,
KD-DV6205U,KD-DV6205UT,
KD-DV6205A,KD-DV6206U,
KD-DV6206UT,KD-DV6206A)

Block No. [0][3]



Symbol No.



IC31 TB2118F-X PLL IC

IC101 NJM4565V-X IC

IC161 TDA7416 IC

IC162 CD4066BPW-X IC

IC301 TB2906HQ IC

IC371 NJM2160BV-X IC

IC381 NJM2160BV-X IC

IC401
IC402 TOTX177L OPTICAL JACK
IC411 MM1510XN-X IC

IC421 NJM4580V-X IC

IC431 LC75344M-X IC

Part No. Part Name Description Local

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,

SN74AHCT1G08V-X

IC

DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

IC721
IC722 BR24L16F-W-X IC(DIGITAL)
IC723 S-80833CNNB-G-W IC
IC801 HD74HC126FP-X IC



IC901 R2S25400DS-E IC
IC921 BA33BC0FP-X IC
IC922 BD9781HFP-W IC
IC961 SN74LVC32APW-X IC
IC962 SN74HCT32APW-X IC

Q4 2SA1365/F/-X TRANSISTOR
Q5 RT1N141C-X DIGI TRANSISTOR
Q7 2SA1530A/R/-X TRANSISTOR
Q11 RT1N141C-X DIGI TRANSISTOR
Q14 RT1N141C-X DIGI TRANSISTOR
Q31 RT1N141C-X DIGI TRANSISTOR

Q161 RT1N141C-X DIGI TRANSISTOR

Q162 RT1N141C-X DIGI TRANSISTOR

Q191 KTD1304-X TRANSISTOR

Q192 RT1P441C-X DIGI TRANSISTOR

Q301 RT1N441C-X TRANSISTOR
Q302 RT1P441C-X DIGI TRANSISTOR
Q303 RT1N141C-X DIGI TRANSISTOR
Q304 RT1N141C-X DIGI TRANSISTOR

Q324 KTD1304-X TRANSISTOR

Q334 KTD1304-X TRANSISTOR

Q344 KTD1304-X TRANSISTOR
Q354 KTD1304-X TRANSISTOR

Q421 KTD1304-X TRANSISTOR

Q422 KTD1304-X TRANSISTOR

Q431 KTD1304-X TRANSISTOR

Q432 KTD1304-X TRANSISTOR

Q701 2SA1530A/R/-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR

Q782 RT1P141C-X DIGI TRANSISTOR

Q783 RT1P141C-X DIGI TRANSISTOR
Q821 RT1N141C-X DIGI TRANSISTOR
Q822 RT1P141C-X DIGI TRANSISTOR
Q823 2SD1994A/RS/-T TRANSISTOR
Q881 2SC3928A/R/-X TRANSISTOR
Q885 RT1N141C-X DIGI TRANSISTOR
Q891 RT1N141C-X DIGI TRANSISTOR
Q903 2SA1530A/R/-X TRANSISTOR
Q904 RT1N141C-X DIGI TRANSISTOR
Q976 RT1N441C-X TRANSISTOR
Q977 2SA1530A/R/-X TRANSISTOR

D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D3 MC2838-X DIODE
D4 MA111-X SI DIODE

D192 MA111-X SI DIODE

D301 UDZS11B-X Z DIODE
D302 MA111-X SI DIODE
D305 CRS03-W SB DIODE
D308 CRS03-W SB DIODE

D324 MA111-X SI DIODE

D334 MA111-X SI DIODE

D344 MA111-X SI DIODE
D354 MA111-X SI DIODE
D401 CRS03-W SB DIODE

D421 MA111-X SI DIODE

D431 MA111-X SI DIODE

D701 MA8062/M/-X Z DIODE

UPD784217AGC334

IC

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

3-14



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D710 MA8062/M/-X Z DIODE
D711 MA8062/M/-X Z DIODE

D712 UDZW5.1B-X SB DIODE

D713 UDZW5.1B-X SB DIODE

D714 UDZW5.1B-X SB DIODE

D715 UDZW5.1B-X SB DIODE

D716 MA8062/M/-X Z DIODE
D717 MA8062/M/-X Z DIODE
D719 SLR-56VC3F DIODE C.M
D731 MA111-X SI DIODE
D781 MC2836-X DIODE
D782 MC2836-X DIODE

D783 UDZS11B-X Z DIODE

D783 UDZS9.1B-X Z DIODE

D801 CRS03-W SB DIODE
D821 UDZS12B-X Z DIODE
D851 CRS03-W SB DIODE
D852 CRS03-W SB DIODE
D885 MA111-X SI DIODE
D891 MC2836-X DIODE



D901 1N5401-F64 SI DIODE
D903 MA111-X SI DIODE
D906 UDZW5.1B-X SB DIODE
D921 1A3G-T1 SI DIODE
D922 RB051L-40-X SB DIODE
D981 CRS03-W SB DIODE
D982 CRS03-W SB DIODE

C2 NCB31HK-102X C CAPACITOR 1000pF 50V K
C3 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C6 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C7 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C9 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C12 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C28 NCS31HJ-7R0X C CAPACITOR 7pF 50V J
C29 NDC31HJ-100X C CAPACITOR 10pF 50V J
C30 NDC31HJ-100X C CAPACITOR 10pF 50V J
C31 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C32 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C33 NCB31HK-102X C CAPACITOR 1000pF 50V K
C34 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C35 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C36 NCB31HK-102X C CAPACITOR 1000pF 50V K
C37 NCB31HK-272X C CAPACITOR 2700pF 50V K
C38 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C39 NCS31HJ-101X C CAPACITOR 100pF 50V J
C40 NDC31HJ-470X C CAPACITOR 47pF 50V J
C41 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C42 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C43 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCS31HJ-470X C CAPACITOR 47pF 50V J
C50 NCS31HJ-101X C CAPACITOR 100pF 50V J
C51 NCS31HJ-331X C CAPACITOR 330pF 50V J
C82 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C83 QTE1H57-105Z E CAPACITOR 1uF 50V
C84 NCB31HK-122X C CAPACITOR 1200pF 50V K
C92 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C93 QTE1H57-105Z E CAPACITOR 1uF 50V
C94 NCB31HK-122X C CAPACITOR 1200pF 50V K
C99 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C101 QEKJ1CM-106Z E CAPACITOR 10uF 16V M

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

C102 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C103 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C109 NCB31EK-223X C CAPACITOR

C110 QEKJ1CM-476Z E CAPACITOR 47uF 16V M

C111 QEKJ1CM-106Z E CAPACITOR 10uF 16V M

C112 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C113 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C155 NCB31AK-474X C CAPACITOR 0.47uF 10V K

C156 NCB31EK-473X C CAPACITOR

C161 QTE1A57-107Z E CAPACITOR 100uF 10V
C162 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C163 NFV81CM-105X MF CAPACITOR 1uF 16V M
C164 NFV81CM-105X MF CAPACITOR 1uF 16V M
C165 NFV81CM-105X MF CAPACITOR 1uF 16V M
C166 QTE1C57-106Z E CAPACITOR 10uF 16V
C168 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M

C169 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C170 QEKJ1CM-106Z E CAPACITOR 10uF 16V M

C171 QTE1H57-225Z E CAPACITOR 2.2uF 50V
C172 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C174 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C175 NCB31HK-471X C CAPACITOR 470pF 50V K

C176 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M

C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C181 QTE1H57-225Z E CAPACITOR 2.2uF 50V
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C184 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C185 NCB31HK-471X C CAPACITOR 470pF 50V K

C186 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M

C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M

C191 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C267 QEKJ1CM-106Z E CAPACITOR 10uF 16V M

C301 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 NBE21CM-475X
C312 QTE1C57-476Z E CAPACITOR 47uF 16V
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C315 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C326 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C328 NFV81CM-105X MF CAPACITOR 1uF 16V M
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K

C336 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C338 NFV81CM-105X MF CAPACITOR 1uF 16V M
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 NFV81CM-105X MF CAPACITOR 1uF 16V M
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 NFV81CM-105X MF CAPACITOR 1uF 16V M
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J

C373 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C374 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C375 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C376 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C377 NCB31HK-152X C CAPACITOR 1500pF 50V K

C378 NCB31HK-152X C CAPACITOR 1500pF 50V K

TA E CAPAC ITO R

0.022uF 25V K

0.047uF 25V K

4.7uF 16V M

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

3-15



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C379 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C380 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C383 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C384 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C385 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C386 NCB31EK-104X C CAPACITOR 0.1uF 25V K

C387 NCB31HK-152X C CAPACITOR 1500pF 50V K

C388 NCB31HK-152X C CAPACITOR 1500pF 50V K

C389 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C390 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C391 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C392 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K

C422 NCB31EK-103X C CAPACITOR 0.01uF 25V K

C423 QEKJ1AM-227Z E CAPACITOR 220uF 10V M

C424 NCS31HJ-151X C CAPACITOR 150pF 50V J

C425 NCS31HJ-101X C CAPACITOR 100pF 50V J

C426 NCS31HJ-221X C CAPACITOR 220pF 50V J

C427 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C428 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C432 NCB31EK-103X C CAPACITOR 0.01uF 25V K

C433 QEKJ1AM-227Z E CAPACITOR 220uF 10V M

C434 NCS31HJ-151X C CAPACITOR 150pF 50V J

C435 NCS31HJ-101X C CAPACITOR 100pF 50V J

C436 NCS31HJ-221X C CAPACITOR 220pF 50V J

C437 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C438 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M

C441 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C451 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C461 QEKJ1CM-226Z E CAPACITOR 22uF 16V M

C462 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C463 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

C464 QEKJ1AM-107Z E CAPACITOR 100uF 10V M

C465 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z

C701 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K

C703 NDC31HJ-101X C CAPACITOR 100pF 50V J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

C704 NCB31AK-474X C CAPACITOR 0.47uF 10V K

C705 NDC31HJ-101X C CAPACITOR 100pF 50V J

C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C782 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M

C783 QEKJ1CM-476Z E CAPACITOR 47uF 16V M

C783 QEKJ1AM-227Z E CAPACITOR 220uF 10V M

C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C851 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C881 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C892 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C904 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C908 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C910 NCB31HK-102X C CAPACITOR 1000pF 50V K
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXF1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C961 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C964 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C965 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C997 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J

R1 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R2 NRS181J-220X MG RESISTOR 22
R3 NRS181J-220X MG RESISTOR 22
R4 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R5 NRSA63J-472X MG RESISTOR 4.7k
R6 NRSA63J-332X MG RESISTOR 3.3k
R7 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R8 NRS181J-0R0X MG RESISTOR 0
R9 NRSA63J-100X MG RESISTOR 10
R10 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R12 NRSA63J-0R0X MG RESISTOR 0

Ω

1/8W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

Ω

1/8W J

Ω

1/16W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

3-16



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R14 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R31 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R32 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R33 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R34 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R35 NRSA63J-393X MG RESISTOR 39k
R36 NRSA63J-221X MG RESISTOR 220
R37 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R38 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R39 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J
R40 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R42 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R43 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R44 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R81 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R82 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R91 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R92 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J

R101 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R102 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R103 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R104 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R105 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R106 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R107 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R111 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R112 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R113 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R114 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R115 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R116 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R117 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J

R141 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R151 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R155 NRSA63J-471X MG RESISTOR 470
R161 NRSA63J-0R0X MG RESISTOR 0
R162 NRSA63J-473X MG RESISTOR 47k
R163 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R164 NRSA63J-473X MG RESISTOR 47k

R165 NRSA63J-473X MG RESISTOR 47k

R166 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R167 NRSA63J-222X MG RESISTOR 2.2k
R168 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R169 NRSA63J-222X MG RESISTOR 2.2k
R170 NRSA63J-222X MG RESISTOR 2.2k

R171 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R172 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R173 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R191 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J

R192 NRSA63J-821X MG RESISTOR 820Ω 1/16W J

R193 NRSA63J-101X MG RESISTOR 100Ω 1/16W J

R302 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R303 NRSA63J-0R0X MG RESISTOR 0
R304 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R305 NRSA63J-103X MG RESISTOR 10k
R306 NRSA63J-273X MG RESISTOR 27k
R307 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R308 NRSA63J-222X MG RESISTOR 2.2k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

R323 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R324 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R325 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R326 NRSA63J-101X MG RESISTOR 100Ω 1/16W J

R327 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R328 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R329 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R330 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R333 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R334 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R335 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R336 NRSA63J-101X MG RESISTOR 100Ω 1/16W J

R337 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R338 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R339 NRSA63J-513X MG RESISTOR 51k
R340 NRSA63J-102X MG RESISTOR 1k
R343 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R344 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R345 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R346 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R347 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R348 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R349 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R350 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R353 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R354 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R355 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R356 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R357 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R358 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R359 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R360 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R371 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R372 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R373 NRSA63J-104X MG RESISTOR

R374 NRSA63J-104X MG RESISTOR

R375 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R376 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R377 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J

R378 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J

R381 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R382 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R383 NRSA63J-104X MG RESISTOR

R384 NRSA63J-104X MG RESISTOR

R385 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R386 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R387 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J

R388 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J

R401 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R402 NRSA63J-100X MG RESISTOR 10
R403 NRSA63J-471X MG RESISTOR 470
R404 NRSA63J-1R0X MG RESISTOR 1Ω 1/16W J
R411 NRSA63J-0R0X MG RESISTOR 0
R412 NRSA63D-682X MG RESISTOR 6.8k
R413 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R414 NRSA63J-102X MG RESISTOR 1k
R415 NRSA63J-750X MG RESISTOR 75

Ω

1/16W J

Ω

1/16W J

100kΩ 1/16W J

100kΩ 1/16W J

100kΩ 1/16W J

100kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

3-17



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R416 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R417 NRSA63D-181X MG RESISTOR 180Ω 1/16W D

R421 NRSA63J-220X MG RESISTOR 22Ω 1/16W J

R422 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R423 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R424 NRSA63J-390X MG RESISTOR 39Ω 1/16W J

R425 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R426 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J

R427 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J

R428 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J

R429 NRSA63J-104X MG RESISTOR

R431 NRSA63J-220X MG RESISTOR 22Ω 1/16W J

R432 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R433 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R434 NRSA63J-390X MG RESISTOR 39Ω 1/16W J

R435 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R436 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J

R437 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J

R438 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J

R439 NRSA63J-104X MG RESISTOR

R441 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R442 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R451 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R452 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J

R461 NRSA63J-100X MG RESISTOR 10Ω 1/16W J

R462 NRSA63J-100X MG RESISTOR 10Ω 1/16W J

R463 NRSA63J-100X MG RESISTOR 10Ω 1/16W J

R701 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R702 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R703 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R704 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R705 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R706 NRSA63J-103X MG RESISTOR 10k
R707 NRSA63J-103X MG RESISTOR 10k
R708 NRS181J-331X MG RESISTOR 330Ω 1/8W J
R709 NRSA63J-562X MG RESISTOR 5.6k
R710 NRSA63J-102X MG RESISTOR 1k
R711 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R712 NRSA63J-104X MG RESISTOR 100k
R713 NRSA63J-103X MG RESISTOR 10k
R714 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R715 NRSA63J-271X MG RESISTOR 270
R716 NRSA63J-271X MG RESISTOR 270

R717 NRSA63J-103X MG RESISTOR 10k

R718 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R719 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R721 NRSA63J-222X MG RESISTOR 2.2k
R722 NRSA63J-222X MG RESISTOR 2.2k
R725 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R726 NRSA63J-103X MG RESISTOR 10k
R727 NRSA63J-562X MG RESISTOR 5.6k
R728 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R729 NRSA63J-0R0X MG RESISTOR 0

100kΩ 1/16W J

100kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

R730 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R732 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R733 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R735 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R737 NRSA63J-222X MG RESISTOR 2.2k
R738 NRSA63J-472X MG RESISTOR 4.7k
R739 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R740 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R743 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R744 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R745 NRSA63J-106X MG RESISTOR 10MΩ 1/16W J
R746 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R747 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R749 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R750 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R751 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R755 NRSA63J-103X MG RESISTOR 10k
R756 NRSA63J-222X MG RESISTOR 2.2k
R757 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R758 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R759 NRSA63J-224X MG RESISTOR 220kΩ 1/16W J
R760 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R761 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R762 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R763 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R765 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R766 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R768 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R769 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R770 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R771 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R772 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R773 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R774 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R775 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R776 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R777 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R779 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R780 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R781 NRSA63J-471X MG RESISTOR 470Ω 1/16W J

R782 NRSA63J-471X MG RESISTOR 470Ω 1/16W J

R784 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J

R799 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R801 NRSA63J-101X MG RESISTOR 100
R802 NRSA63J-473X MG RESISTOR 47k
R803 NRSA63J-223X MG RESISTOR 22k
R804 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R805 NRSA63J-103X MG RESISTOR 10k
R806 NRSA63J-104X MG RESISTOR 100k
R807 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R808 NRSA63J-223X MG RESISTOR 22k
R809 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R810 NRSA63J-473X MG RESISTOR 47k
R821 NRSA63J-100X MG RESISTOR 10
R822 NRSA63J-471X MG RESISTOR 470Ω 1/16W J

R841 NRSA63J-473X MG RESISTOR 47k

R842 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R843 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R844 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R851 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R881 NRSA63J-473X MG RESISTOR 47k
R882 NRSA63J-103X MG RESISTOR 10k
R883 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R885 NRSA63J-473X MG RESISTOR 47k
R886 NRSA63J-472X MG RESISTOR 4.7k
R887 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R888 NRSA63J-0R0X MG RESISTOR 0
R889 NRSA63J-0R0X MG RESISTOR 0
R891 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205A,DV6206A
DV5205U,DV5205UT,DV5206U,

DV5206UT,DV6205U,DV6205UT,
DV6206U,DV6206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT

DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6205U,DV6205UT,
DV6206U,DV6206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205A,DV6206A
DV5205U,DV5205UT,DV5206U,
DV5206UT

3-18



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R892 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R894 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R901 QRE142J-102X C RESISTOR 1kΩ 1/4W J
R902 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R903 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R909 NRSA63J-473X MG RESISTOR 47k
R910 NRSA63J-222X MG RESISTOR 2.2k
R914 NRS181J-221X MG RESISTOR 220Ω 1/8W J
R921 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R923 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R924 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R925 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R926 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R927 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R928 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R961 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R962 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R967 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R968 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R969 NRS181J-0R0X MG RESISTOR 0Ω 1/8W J
R973 NRSA63J-103X MG RESISTOR 10k
R974 NRSA63J-103X MG RESISTOR 10k
R975 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R976 NRSA63J-563X MG RESISTOR 56kΩ 1/16W J
R977 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R981 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
R982 NRS181J-222X MG RESISTOR 2.2kΩ 1/8W J
RA31 NRZ0065-222X NET RESISTOR 2.2k

RA721 NRZ0065-222X NET RESISTOR 2.2k

RA723 NRZ0065-103X NET RESISTOR 10kΩ 1/16W J

L1 NQL334J-4R7X COIL 4.7uH J
L31 NQL114K-470X INDUCTOR 47uH K
L401 NQR0007-002X FERRITE BEADS
L411 NQL114K-470X INDUCTOR 47uH K

L421 NQR0007-002X FERRITE BEADS

L430 NQR0007-002X FERRITE BEADS

L431 NQR0007-002X FERRITE BEADS

L721 NQL38DK-330X COIL 33uH K
L722 NQL114K-470X INDUCTOR 47uH K
L901 QQR1378-002 COIL
L902 NQL56CK-220X COIL 22uH K
L924 NQL56CK-220X COIL 22uH K
L925 NQL71EM-330X COIL 33uH M
L927 NQLB7GM-100X COIL 10uH M

CN141 QGA2006C1-04 CONNECTOR W-B (1-4)

CN191 QGA2501C3-03Z CONNECTOR W-B (1-3)

CN411 QGA2501F1-02 CONNECTOR W-B (1-2)

CN421 QGA2501C3-03Z CONNECTOR W-B (1-3)

CN701 QNZ0605-001 CAR CONNECTOR
CN821 QGA2001C1-02 CONNECTOR W-B (1-2)
CN901 QNZ0607-001 CAR CONNECTOR
CN961 QGB2027M3-30S CONNECTOR B-B (1-30)
CN962 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
CN963 QGB2027L9-30X CONNECTOR B-B (1-30)

J331 QNN0519-001 PIN JACK

J331 QNN0489-001 PIN JACK

J801 QNZ0095-001 CONNECTOR
K401 NQR0007-002X FERRITE BEADS
K402 NQR0007-002X FERRITE BEADS
K411 NQR0201-004X FERRITE BEADS
K922 NQR0201-004X FERRITE BEADS

PP1 QZW0010-001 STYLE PIN

PP2 QZW0010-001 STYLE PIN
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S723 QSW1049-001Z TACT SW
TH721 NAD0028-103X N THERMISTOR 10k
TU21 QAU0312-002 TUNER PACK

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω
Ω

Ω

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

W21 QAM0105-003 CAR CABLE
X31 QAX0616-001Z CRYSTAL 10.250MHz
X721 QAX0617-001Z CRYSTAL 12.500MHz
X722 QAX0401-001 CRYSTAL 32.768KHz

Switch board
(KD-DV5205U,KD-DV5205UT,
KD-DV5206U,KD-DV5206UT,
KD-DV6205U,KD-DV6205UT,
KD-DV6205A,KD-DV6206U,
KD-DV6206UT,KD-DV6206A)



Symbol No.

IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER

Q640 2SA1365/F/-X TRANSISTOR
Q641 RT1N141C-X DIGI TRANSISTOR

D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED

D608 SML-310VT/JK/-X LED

D608

D609 SML-310VT/JK/-X LED

D609

D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MC2838-X DIODE
D641 UDZW5.1B-X SB DIODE
D642 MA111-X SI DIODE
D643 MA8062/M/-X Z DIODE
D645
D646

C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M

C620 NCB31HK-473X C CAPACITOR

R601 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820Ω 1/16W J

R603 NRSA63J-122X MG RESISTOR

R604 NRSA63J-182X MG RESISTOR

R605 NRSA63J-272X MG RESISTOR

R606 NRSA63J-392X MG RESISTOR 3.9k

Part No. Part Name Description Local

SML310BA1T/HJ-X

SML310BA1T/HJ-X

NSPW310BS/B2RST
NSPW310BS/B2RST

LED

LED

LED
LED

0.047uF 50V K

Ω

1/16W

1.2k
J

1.8k

Ω

1/16W

J

2.7kΩ 1/16W
J

Ω

1/16W J

Block No. [0][4]

DV5205U,DV5205UT,DV5206U,
DV5206UT
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

3-19



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R607 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R608 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8kΩ 1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k
R613 NRSA63J-821X MG RESISTOR 820
R614 NRSA63J-821X MG RESISTOR 820Ω 1/16W J

R620 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R621 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

R622 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R623 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J

R624 NRSA63J-471X MG RESISTOR 470Ω 1/16W J

R630 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J

R630 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J

R631 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J

R632 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J

R632 NRSA63J-821X MG RESISTOR 820Ω 1/16W J

R633 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J

R634 NRSA63J-271X MG RESISTOR 270Ω 1/16W J

R634 NRSA63J-331X MG RESISTOR 330Ω 1/16W J

R636 NRSA63J-271X MG RESISTOR 270Ω 1/16W J

R636 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R638 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R640 NRSA02J-331X MG RESISTOR 330Ω 1/10W J

R641 NRSA02J-391X MG RESISTOR 390Ω 1/10W J

R641 NRSA02J-121X MG RESISTOR 120Ω 1/10W J

R642 NRSA02J-331X MG RESISTOR 330Ω 1/10W J

R643 NRSA02J-391X MG RESISTOR 390Ω 1/10W J

R643 NRSA02J-201X MG RESISTOR 200Ω 1/10W J

R644 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R646 NRSA63J-471X MG RESISTOR 470

R648 NRSA63J-271X MG RESISTOR 270Ω 1/16W J

R648 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
R654 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
R656 NRSA63J-103X MG RESISTOR 10k
R657 NRSA63J-513X MG RESISTOR 51kΩ 1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
R660 NRSA02J-391X MG RESISTOR 390
R661 NRSA02J-391X MG RESISTOR 390Ω 1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0
R672 NRSA02J-471X MG RESISTOR 470
R673 NRSA02J-473X MG RESISTOR 47kΩ 1/10W J
R674 NRSA02J-102X MG RESISTOR 1kΩ 1/10W J
R691 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R692 NRSA63J-471X MG RESISTOR 470

CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER

J601 QNS0245-001 AUX JACK

S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

Ω

1/10W J

Ω

1/16W J

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A
DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6206U,DV6206UT,
DV6206A

DV6205U,DV6205UT,DV6205A
DV5205U,DV5205UT,DV5206U,

DV5206UT,DV6206U,DV6206UT,
DV6206A
DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6206U,DV6206UT,
DV6206A

DV6205U,DV6205UT,DV6205A
DV5205U,DV5205UT,DV5206U,

DV5206UT,DV6206U,DV6206UT,
DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6206U,DV6206UT,
DV6206A
DV6205U,DV6205UT,DV6205A

DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6206U,DV6206UT,
DV6206A

DV6205U,DV6205UT,DV6205A

DV5205U,DV5205UT,DV5206U,
DV5206UT
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT
DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

DV5205U,DV5205UT,DV5206U,
DV5206UT,DV6206U,DV6206UT,
DV6206A

DV6205U,DV6205UT,DV6205A

DV6205U,DV6205UT,DV6205A,
DV6206U,DV6206UT,DV6206A

S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH

Front end board

Block No. [0][5]



Symbol No.

IC201 BA5835FM-X IC
IC251 BD6671FM-X IC
IC301 MN2DS0003AA-H IC
IC302 BA00HC5WF-X IC
IC304 S-80827CNNB-G-W IC
IC398 SG32M90TFIR31G IC(PROGRAMED)
IC399 K4S281632F-UC75 IC(DIGITAL)
IC399 or EDS1216AATA-75 IC(DIGITAL)
IC401 AK4385ET-X IC
IC411 NJM4580V-X IC
IC481 BR93L66F-W-X IC(DIGITAL)

Q101 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 2SK3019-X MOS FET
Q106 2SK3019-X MOS FET
Q107 2SC4617/R/-X TRANSISTOR
Q231 DTC114EE-X DIGI TRANSISTOR
Q301 DTC144EE-X DIGI TRANSISTOR
Q302 DTC144EE-X DIGI TRANSISTOR

C1 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C3 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C4 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C9 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C10 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C11 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C12 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C13 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C14 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C15 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C16 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C17 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C18 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C19 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C20 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C21 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C106 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C108 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C112 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C113 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C201 NEAF1CM-107X E CAPACITOR 100uF 16V M
C202 NCB31CK-104X C CAPACITOR 0.1uF 16V K

Part No. Part Name Description Local

3-20



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

C203 NCS31HJ-271X C CAPACITOR 270pF 50V J
C204 NDC31HJ-151X C CAPACITOR 150pF 50V J
C205 NCB31HK-681X C CAPACITOR 680pF 50V K
C206 NCB31HK-561X C CAPACITOR 560pF 50V K
C211 NEAF1CM-107X E CAPACITOR 100uF 16V M
C212 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C213 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C221 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C222 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 NEAF1CM-107X E CAPACITOR 100uF 16V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C254 NBE21AM-106X TA E CAPACITOR 10uF 10V M
C255 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C256 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C257 NCB31HK-102X C CAPACITOR 1000pF 50V K
C258 NCB31HK-102X C CAPACITOR 1000pF 50V K
C259 NCB31HK-102X C CAPACITOR 1000pF 50V K
C264 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C265 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C266 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C267 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C268 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C301 NEAF0JM-227X E CAPACITOR 220uF 6.3V M
C302 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB31HK-102X C CAPACITOR 1000pF 50V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB21CK-105X C CAPACITOR 1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB21CK-105X C CAPACITOR 1uF 16V K
C325 NDC31HJ-100X C CAPACITOR 10pF 50V J
C326 NDC31HJ-100X C CAPACITOR 10pF 50V J
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C336 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31HK-183X C CAPACITOR 0.018uF 50V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB21CK-105X C CAPACITOR 1uF 16V K
C341 NCB21CK-105X C CAPACITOR 1uF 16V K
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C356 NCB21CK-105X C CAPACITOR 1uF 16V K
C358 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C359 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C364 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M
C365 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C366 NCB21CK-105X C CAPACITOR 1uF 16V K
C369 NBE40JM-476X TA E CAPACITOR 47uF 6.3V M
C371 NCB21CK-105X C CAPACITOR 1uF 16V K
C380 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C384 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C391 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C392 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C393 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C395 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C396 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C397 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M

C398 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C399 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C401 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C402 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C403 NCB31HK-331X C CAPACITOR 330pF 50V K
C404 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C411 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C412 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C421 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C422 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C431 NCB31HK-332X C CAPACITOR 3300pF 50V K
C432 NCS31HJ-471X C CAPACITOR 470pF 50V J
C433 NCS31HJ-471X C CAPACITOR 470pF 50V J
C451 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C452 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C453 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C454 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C481 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C491 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C492 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C521 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C522 NBE41AM-476X TA E CAPACITOR 47uF 10V M
C531 NCB31HK-332X C CAPACITOR 3300pF 50V K
C532 NCS31HJ-471X C CAPACITOR 470pF 50V J
C533 NCS31HJ-471X C CAPACITOR 470pF 50V J

R101 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R103 NRSA63D-242X MG RESISTOR 2.4kΩ 1/16W D
R104 NRSA63D-302X MG RESISTOR 3kΩ 1/16W D
R105 NRS125J-120X MG RESISTOR 12Ω 1/2W J
R106 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R107 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R108 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R109 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R111 NRSA63D-242X MG RESISTOR 2.4kΩ 1/16W D
R112 NRSA63D-302X MG RESISTOR 3kΩ 1/16W D
R113 NRS125J-120X MG RESISTOR 12Ω 1/2W J
R114 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R115 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R116 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R117 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R118 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R120 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R122 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R123 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R125 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R126 NRSA63J-910X MG RESISTOR 91Ω 1/16W J
R127 NRSA63J-910X MG RESISTOR 91
R128 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R129 NRSA63J-104X MG RESISTOR 100k
R130 NRSA63J-103X MG RESISTOR 10k
R201 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R202 NRSA63J-473X MG RESISTOR 47k
R203 NRSA63J-303X MG RESISTOR 30k
R204 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R205 NRSA63J-273X MG RESISTOR 27k
R206 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R207 NRSA63J-0R0X MG RESISTOR 0
R208 NRSA63J-203X MG RESISTOR 20k
R209 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R211 NRSA63J-0R0X MG RESISTOR 0
R219 NRSA63J-153X MG RESISTOR 15k
R220 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R221 NRSA63J-103X MG RESISTOR 10k
R222 NRSA63J-103X MG RESISTOR 10k
R223 NRSA63J-0R0X MG RESISTOR 0
R224 NRSA63J-103X MG RESISTOR 10k
R231 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R232 NRSA63J-153X MG RESISTOR 15k
R233 NRSA63J-0R0X MG RESISTOR 0
R234 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R235 NRSA63J-682X MG RESISTOR 6.8k
R251 NRS125J-R47X MG RESISTOR 0.47
R252 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R253 NRSA63J-0R0X MG RESISTOR 0
R254 NRSA63J-103X MG RESISTOR 10k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/2W J

Ω

1/16W J

Ω

1/16W J

3-21



Symbol No.

Part No. Part Name Description Local



Symbol No.

Part No. Part Name Description Local

R255 NRSA63J-203X MG RESISTOR 20kΩ 1/16W J
R256 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R257 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R258 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R259 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R260 NRSA63J-470X MG RESISTOR 47
R300 NRSA63J-0R0X MG RESISTOR 0
R301 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R303 NRSA63J-270X MG RESISTOR 27Ω 1/16W J
R306 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R307 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R308 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R309 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R310 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R312 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R313 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R314 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R315 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R316 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R317 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R318 NRSA63D-332X MG RESISTOR 3.3k
R319 NRSA63J-223X MG RESISTOR 22k
R321 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R322 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R323 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R325 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R326 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R327 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R328 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R329 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R332 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R333 NRSA63D-162X MG RESISTOR 1.6kΩ 1/16W D
R334 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R335 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R336 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R337 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30kΩ 1/16W D
R345 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R346 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R347 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R348 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R349 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R350 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R351 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R352 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R353 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R354 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R355 NRSA63J-0R0X MG RESISTOR 0
R356 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R357 NRSA63J-0R0X MG RESISTOR 0
R358 NRSA63J-0R0X MG RESISTOR 0
R359 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R360 NRSA63J-181X MG RESISTOR 180
R361 NQL093K-1R8X COIL 1.8uH K
R362 NRSA63J-0R0X MG RESISTOR 0
R363 NRSA63J-151X MG RESISTOR 150
R364 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R365 NRSA63D-911X MG RESISTOR 910
R366 NRSA63D-202X MG RESISTOR 2k
R370 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R372 NRSA63J-331X MG RESISTOR 330
R373 NRSA63J-331X MG RESISTOR 330
R380 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k
R385 NRSA63J-102X MG RESISTOR 1k
R386 NRSA63J-0R0X MG RESISTOR 0
R390 NRSA63J-103X MG RESISTOR 10k
R392 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R393 NRSA63J-0R0X MG RESISTOR 0
R394 NRSA63J-0R0X MG RESISTOR 0
R396 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R399 NRSA63J-0R0X MG RESISTOR 0
R401 NRSA63J-100X MG RESISTOR 10
R402 NRSA63J-4R7X MG RESISTOR 4.7Ω 1/16W J
R403 NRSA63J-0R0X MG RESISTOR 0
R404 NRSA63J-473X MG RESISTOR 47k

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W D

Ω

1/16W D

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

R411 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R421 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R422 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R431 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R432 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R433 NRSA63J-223X MG RESISTOR 22k
R434 NRSA63J-201X MG RESISTOR 200
R435 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R436 NRSA63J-201X MG RESISTOR 200Ω 1/16W J
R437 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R438 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R441 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R442 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R481 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R491 NRSA63D-103X MG RESISTOR 10kΩ 1/16W D
R492 NRSA63D-512X MG RESISTOR 5.1kΩ 1/16W D
R493 NRSA63D-223X MG RESISTOR 22kΩ 1/16W D
R521 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R522 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R531 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R532 NRSA63J-472X MG RESISTOR 4.7k
R533 NRSA63J-223X MG RESISTOR 22k
R534 NRSA63J-201X MG RESISTOR 200Ω 1/16W J
R535 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R536 NRSA63J-201X MG RESISTOR 200Ω 1/16W J
R537 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R538 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R606 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J

L303 NQL044K-100X COIL 0.26Ω 10uH K
L305 NQL093K-1R8X COIL 1.8uH K
L306 NQL093K-1R8X COIL 1.8uH K
L307 NQL093K-1R8X COIL 1.8uH K
L451 NQL044K-100X COIL 0.26Ω 10uH K

CN101 QGF0501F8-30X CONNECTOR FFC/FPC (1-30)
CN201 QGF1038F2-11X CONNECTOR FFC/FPC (1-11)
CN202 QGF0523F2-05W CONNECTOR FFC/FPC (1-5)
CN402 QGF0522F3-06W CONNECTOR FFC/FPC (1-6)
CN403 QGF0534F3-45X CONNECTOR FFC/FPC (1-45)
K101 NQR0007-002X FERRITE BEADS
K102 NQR0007-002X FERRITE BEADS
K301 NQR0502-001X FERRITE BEADS
K311 NQR0129-002X FERRITE BEADS
K399 NQR0502-001X FERRITE BEADS
K401 NQR0022-005X FERRITE BEADS
K402 NQR0022-005X FERRITE BEADS
K403 NQR0022-005X FERRITE BEADS
K404 NQR0022-005X FERRITE BEADS
K405 NQR0022-005X FERRITE BEADS
K406 NQR0022-005X FERRITE BEADS
K407 NQR0022-005X FERRITE BEADS
K425 NQL093K-1R8X COIL 1.8uH K
K441 NQR0022-005X FERRITE BEADS
K442 NQR0022-005X FERRITE BEADS
K443 NQR0022-005X FERRITE BEADS
K444 NQR0022-005X FERRITE BEADS
K445 NQR0022-005X FERRITE BEADS
K451 NQR0022-005X FERRITE BEADS
K452 NQR0022-005X FERRITE BEADS
K601 NQR0022-005X FERRITE BEADS
SW4 NSW0184-001X DETECT SW
SW5 NSW0183-001X DETECT SW
TH491 NAD0025-103X N THERMISTOR 10k
X351 NAX0730-001X CRYSTAL 27.000MHz

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

1/16W J

Ω

3-22

Packing materials and accessories parts list

Block No.

M

3

M

M

P1

P2

A18

A16

A17

A12

P7

A1,A3,A4,
A19,

P9

A2

A20, A21

P3

A12

P6

A13

A14

P5

A5,A6,A7,

KIT:

A8,A9,A10

P8

A15

P4

A11

3-24

Packing and Accessories

Block No. [M][3][M][M]



Symbol No. Part No. Part Name Description Local

A 1 GET0382-001A INST BOOK ENG FRE DV5201EU,DV5202EU
A 1 GET0383-001A INST BOOK ENG CHI(TAIWAN) DV5205U,DV5206U,DV6205U,DV6206U
A 1 GET0383-003A INST BOOK ENG CHI(TAIWAN) DV5205UT,DV5206UT,DV6205UT,DV6206UT
A 1 GET0383-004A INST BOOK ENG DV6205A,DV6206A
A 2 GET0382-002A INST BOOK SPA TUR PER DV5201EU,DV5202EU
A 2 GET0383-002A INST BOOK KOR THA ARA PER DV5205U,DV5206U,DV6205U,DV6206U

A 3 GET0383-005A INSTALL MANUAL ENG CHI(TAIWAN)

A 3 GET0383-007A INSTALL MANUAL ENG DV6205A,DV6206A
A 4 GET0383-006A INSTALL MANUAL KOR THA ARA PER DV5205U,DV5206U,DV6205U,DV6206U
A 5 VKZ4027-202 PLUG NUT
A 6 VKH4871-003 MOUNT BOLT
A 7 VKZ4328-003 LOCK NUT
A 8 QYWWS53A008ZA WASHER 0mm/5.3mm x
A 9 GE40130-002A HOOK (x2)
A 10 LV41478-002A CORD CONNECTOR
A 11 FSJB3002-30C HARD CASE
A 12 LV43644-001A LABEL (x2) DV5205U,DV5206U,DV6205U,DV6206U
A 13 RM-RK230 REMOCON UNIT
A 14 -------------- BATTERY



A 15 QAM0450-002 POWER CORD DV5201EU,DV5202EU



A 15 QAM0455-002 POWER CORD

A 16 GE20137-003A MOUNTING SLEEVE
A 17 GE20149-013A TRIM PLATE DV5201EU
A 17 GE20149-010A TRIM PLATE DV5202EU,DV5206U,DV5206UT,DV6206A,DV6206U,DV6206UT
A 17 GE20149-007A TRIM PLATE DV5205U,DV5205UT,DV6205A,DV6205U,DV6205UT
A 18 GE31574-037A UT LABEL DV5205UT
A 18 GE31574-038A UT LABEL DV5206UT
A 18 GE31574-039A UT LABEL DV6205UT
A 18 GE31574-040A UT LABEL DV6206UT
A 19 LVT1435-001A INST SHEET DV5201EU,DV5202EU
A 20 GET0382-003A INSTALL MANUAL ENG FRE DV5201EU,DV5202EU
A 21 GET0382-004A INSTALL MANUAL SPA TUR PER DV5201EU,DV5202EU
KIT SRW-ADV6160J SCREW PART KIT A5 A6 A7 A8 A9 A10
P 1 GE32197-001A CARTON DV5201EU
P 1 GE32200-001A CARTON DV5202EU
P 1 GE32211-001A CARTON DV5205U,DV5205UT
P 1 GE32214-001A CARTON DV5206U,DV5206UT
P 1 GE32205-001A CARTON DV6205A
P 1 GE32203-001A CARTON DV6205U,DV6205UT
P 1 GE32209-001A CARTON DV6206A
P 1 GE32207-001A CARTON DV6206U,DV6206UT
P 2 LV10777-003A PAPER CUSHION
P 3 LV10778-003A PAPER CUSHION
P 4 FSYH4036-068 SHEET
P 5 QPA01003003 POLY BAG 10cm x 30cm
P 6 QPC03004315P POLY BAG 30cm x 43cm
P 7 FSPG4002-001 POLY BAG
P 8 QPA00801205 POLY BAG 8cm x 12cm
P 9 FSPG4002-001 POLY BAG DV5201EU,DV5202EU,DV5205U,DV5206U,DV6205U,DV6206U

DV5205U,DV5205UT,DV5206U,DV5206UT,
DV6205U,DV6205UT,DV6206U,DV6206UT

DV5205U,DV5205UT,DV5206U,DV5206UT,
DV6205A,DV6205U,DV6205UT,DV6206A,DV6206U,DV6206UT

3-25
