COMPACT COMPONENT SYSTEM
HX-Z3 — Consists of CA-HXZ3 and SP-HXZ3
COMPACT
DIGITAL AUDIO
E
M
D
N
O
U
D
O
E
S
S
E
E
R
T
P
M
U
L
O
V
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GVT0086-001A
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
ATTENTION
Afin d’éviter tout risque d’électrocution, d’incendie, etc.:
1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le
coffret de l’appareil.
2. Ne pas exposer l’appareil à la pluie ni à l’humidité.
Caution–– (standby/on) button!
Disconnect the mains plug to shut the power off completely. The
(standby/on) button in any position does not disconnect the
mains line. The power can be remote controlled.
Attention––Commutateur (attente/sous tension)!
Déconnecter la fiche de secteur pour couper complètement le
courant. Le commutateur (attente/sous tension) ne coupe
jamais complètement la ligne de secteur, quelle que soit sa
position. Le courant peut être télécommandé.
For U.S.A.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Section 820-40 of the NEC which provides
guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of
the building, as close to the point of cable entry as practical.
– G-1 –
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS
LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS
B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,”
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE
BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS
NUMIRIQUES DE CLASSE B PRESCRITES DANS LA NORME
SUR LE MATERIEL BROUILLEUR: “APPAREILS NUMERIQUES”,
NMB-003 EDICTEE PAR LE MINISTRE DES
COMMUNICATIONS.
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open and interlock failed
or defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user service-
able parts inside the Unit; leave all servicing to qualified service
personnel.
1. PRODUIT LASER CLASSE 1
2. ATTENTION: Radiation laser invisible quand l’appareil est ouvert
ou que le verrouillage est en panne ou désactivé. Eviter une
exposition directe au rayon.
3. ATTENTION: Ne pas ouvrir le couvercle du dessus. Il n’y a
aucune pièce utilisable à l’intérieur. Laisser à un personnel
qualifié le soin de réparer votre appareil.
– G-2 –
Introduction
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly to
obtain the best possible performance from your unit, and retain this manual
for future reference.
About This Manual
This manual is organized as follows:
• The manual mainly explains operations using the
buttons and controls on the unit. You can also use the
buttons on the remote control if they have the same or
similar names (or marks) as those on the unit.
If operation using the remote control is different from
that using the unit, it is then explained.
• Basic and common information that is the same for many
functions is grouped in one place, and is not repeated in
each procedure. For instance, we do not repeat the
information about turning on/off the unit, setting the
volume, changing the sound effects, and others, which are
explained in the section “Common Operations” on pages 9
to 11.
• The following marks are used in this manual:
Gives you warnings and cautions to prevent
from damage or risk of fire/electric shock.
Also gives you information which is not good
for obtaining the best possible performance
from the unit.
Gives you information and hints you had better
know.
Precautions
Power sources
• When unplugging from the wall outlet, always pull the
plug, not the AC power cord.
DO NOT handle the AC power cord with wet hands.
Moisture condensation
Moisture may condense on the lens inside the unit in the
following cases:
• After heating starts in the room
• In a damp room
• If the unit is brought directly from a cold to a warm place
Should this occur, the unit may malfunction. In this case, leave
the unit turned on for a few hours until the moisture evaporates,
unplug the AC power cord, and then plug it in again.
Internal heat
A cooling fan is mounted on the rear panel to prevent heat
buildup inside the unit.
For safety, observe the following carefully:
• Make sure there is good ventilation around the
unit. Poor ventilation could overheat and damage
the unit.
• DO NOT block the cooling fan and the ventilation
openings or holes. If they are blocked by a
newspaper or cloth, etc., the heat may not be
able to get out.
Installation
• Install in a place which is level, dry and neither too hot nor
too cold—between 5˚C (41˚F) and 35˚C (95˚F).
• Install the unit in a location with adequate ventilation to
prevent internal heat buildup in the unit.
• Leave sufficient distance between the unit and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
DO NOT install the unit in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or vibration.
Others
• Should any metallic object or liquid fall into the unit,
unplug the unit and consult your dealer before operating
any further.
• If you are not going to operate the unit for an extended
period of time, unplug the AC power cord from the wall
outlet.
DO NOT disassemble the unit since there are no
user serviceable parts inside.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
– 1 –
Contents
Location of the Buttons and Controls ....................... 3
Front Panel ................................................................. 3
Remote Control .......................................................... 5
Getting Started............................................................ 6
Supplied Accessories .................................................. 6
Putting the Batteries into the Remote Control ........... 6
Connecting Antennas ................................................. 6
Connecting Speakers .................................................. 7
Connecting Other Equipment ..................................... 8
Canceling the Demonstration ..................................... 8
Common Operations .................................................. 9
Turning On or Off the Power ..................................... 9
Saving the Power Consumption while on Standby
—Ecology Mode .................................................. 9
Setting the Clock ........................................................ 9
Selecting the Sources ................................................. 10
Adjusting the Volume ............................................... 10
Reinforcing the Bass Sound ..................................... 10
Selecting the Sound Modes ...................................... 10
Creating Your Own Sound Mode—User Mode ....... 11
Turning On or Off the Key-touch Tone .................... 11
Listening to FM and AM Broadcasts ...................... 12
Tuning in to a Station ............................................... 12
Presetting Stations .................................................... 12
Tuning in to a Preset Station .................................... 12
Playing Back Discs .................................................... 15
Loading Discs ........................................................... 15
Playing Back the Entire Discs—Continuous Play ... 15
Basic Disc Operations .............................................. 16
Programming the Playing Order of the Tracks
—Program Play .................................................. 17
Playing at Random—Random Play ......................... 18
Repeating Tracks or Discs—Repeat Play ................ 19
Prohibiting Disc Ejection—Tray Lock .................... 19
Playing Back Tapes ................................................... 20
Playing Back a Tape ................................................. 20
Locating the Beginning of a Song—Music Scan ..... 20
Recording .................................................................. 21
Recording on a Tape ................................................. 21
Synchronized Recording .......................................... 22
7 Direct Recording ............................................. 22
7 Auto Edit Recording (only for audio CDs)..... 23
Using the Timers ....................................................... 24
Using Daily Timer.................................................... 24
Using Recording Timer ............................................ 26
Using Sleep Timer.................................................... 27
Timer Priority ........................................................... 27
Maintenance .............................................................. 28
Troubleshooting ........................................................ 29
Disc Play Introduction.............................................. 13
MP3 Introduction ..................................................... 13
Specifications............................................................. 30
– 2 –
Location of the Buttons and Controls
Become familiar with the buttons and controls on your unit.
Front Panel
Front Panel
Top view of Indication-lamp panel p
COMPACT
DIGITAL AUDIO
E
M
D
O
N
D
U
E
O
S
S
E
E
R
T
P
M
U
L
O
V
– 3 –
Display Window
TITLE GROUP TRACK
See pages in the parentheses for details.
Front Panel
1 Disc trays
2 (standby/on) button and lamp (9, 25, 26)
3 ECO (Ecology) button (9)
4 Remote sensor
5 Display window
6 FM/AM button (10, 12)
Pressing this button also turns on the unit.
7 TAPE 2 3 button (10, 20, 21)
Pressing this button also turns on the unit.
8 AUX button (10)
Pressing this button also turns on the unit.
9 CLOCK/TIMER button (9, 24 – 27)
p Indication-lamp panel
Å SOUND MODE lamp (10)
ı SUBWOOFER lamp (10)
Ç REC (recording) lamp (21 – 23)
Î SEA (Sound Effect Amplifier) mode lamps (10)
• ROCK, POP, and CLASSIC lamps
‰ Surround mode lamps (10)
• DANCE, HALL, and STADIUM lamps
Ï CD ready lamps (13)
• CD1 READY, CD2 READY, and CD3 READY lamps
q SOUND MODE control (10)
w PRESET + / – control (12)
4 / ¢ (reverse skip/forward skip) control
(9, 11, 16 – 18, 22 – 26)
e SUBWOOFER LEVEL + / – buttons (10)
r Setting buttons (8, 9, 11, 12, 17, 18, 23 – 27, 29)
• CANCEL/DEMO and SET/DISPLAY buttons
t REVERSE MODE button (20 – 23)
y Cassette holder (20 – 22)
u PHONES ( ) jack (10)
i 0 (Disc tray open/close) (CD1, CD2, and CD3) buttons
(13, 15, 16, 19)
Pressing one of these buttons also turns on the unit.
o Disc number (CD1, CD2, and CD3) buttons
(15 – 18, 22, 23)
Pressing one of these buttons also turns on the unit.
Continued
MP
3
; CD 3/8 button (10, 16 – 18, 22)
Pressing this button also turns on the unit.
a VOLUME + / – control (10)
s TUNING + / – buttons (12)
1 / ¡ (reverse search/forward search) buttons (11, 16, 20)
7 (stop) button (16 – 23, 26)
d Disc play mode buttons (17 – 19)
• REPEAT and CD PLAY MODE buttons
f Recording buttons (21 – 23, 26)
• REC START/STOP, CD REC START, and EDIT buttons
g 0 EJECT button for cassette deck (20 – 22)
Display Window
1 Timer indicators
• DAILY (Daily Timer), SLEEP (Sleep Timer),
REC (Recording Timer), and (Timer) indicators
2 TITLE indicator
3 GROUP indicator
4 TRACK indicator
5 Main display
• Shows the source name, frequency, etc.
6 PRGM (program) indicator
7 Disc track number (1 – 16) indicators
8 RANDOM indicator
9 REPEAT (ALL/1/DISC) indicators
p MP3 indicator
q Audio level indicator
When one of the 6 preset sound modes is activated, these
will function as illumination display. For details, see
“Selecting the Sound Modes” on pages 10 and 11.
w Tuner operation indicators
• MONO and ST (stereo) indicators
e Tape operation indicators
• 2 3 (tape direction) and (reverse mode) indicators
– 4 –
Remote Control
Remote Control
1 Number buttons (12, 16, 17)
2 4 (1) (reverse skip/reverse search) button
(12, 16, 18, 20)
7 (stop) button (16 – 18, 20 – 23, 26)
¢ (¡) (forward skip/forward search) button
(12, 16, 18, 20)
3 Disc number (CD1, CD2, and CD3) buttons (15 – 18)
4 Disc play mode buttons (17 – 19)
• REPEAT, RANDOM, and PROGRAM buttons
5 REC START/STOP button (21, 23, 26)
6 SOUND MODE button (10)
7 SUBWOOFER LEVEL + / – buttons (10)
8 STANDBY/ON button (9)
9 SLEEP button (27)
p AUX button (10)
q FM/AM button (10, 12)
w FM MODE button (12)
e CD 3¥8 button (10, 16 – 18)
r PROGRAM CANCEL button (18)
t TAPE 2 3 button (10, 20, 21)
y BEEP ON/OFF button (8, 11)
u VOLUME + / – button (10)
i FADE MUTING button (10)
COMPACT
DIGITAL AUDIO
FM/AM
TAPE
AUX
CLOCK
/ TIMER
M
D
N
O
U
D
O
E
S
SUBWOOFER
LEVEL
P
E
R
S
E
T
CANCEL / DEMO
REVERSE
MODE
CD-R /RW PLAYBACK
EXTENDED SUPER BASS
SET/
DISPLAY
REC START
/STOP
REPEAT
CD REC
START
CD3
CD2
CD1
CD
E
M
U
L
O
V
CD PLAY
MODE
EDIT
When using the remote control, point it
at the remote sensor on the front panel.
– 5 –
Getting Started
Continued
Supplied Accessories
Make sure that you have all the following items.
The number in the parentheses indicates the quantity of the
pieces supplied.
• AM loop antenna (1)
• FM antenna (1)
• Remote control (1)
• Batteries (2)
If anything is missing, consult your dealer immediately.
Putting the Batteries into the Remote Control
Insert the batteries—R6(SUM-3)/AA(15F)—into the remote
control, by matching the polarity (+ and –) on the batteries
with the + and – markings on the battery compartment.
When the remote control can no longer operate the unit,
replace both batteries at the same time.
1
Connecting Antennas
FM antenna
ANTENNA
AM EXT
LOOP
FM 75
COAXIAL
FM antenna (supplied)
1 Attach the FM antenna to the FM 75 Ω
COAXIAL terminal.
2 Extend the FM antenna.
3 Fasten it up in the position which gives you
the best reception, then fix it on the wall, etc.
R6(SUM-3)/AA(15F)
2
3
• DO NOT use an old battery together with a new
one.
• DO NOT use different types of batteries together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use the
remote control for an extended period of time.
Otherwise, it will be damaged from battery
leakage.
About the supplied FM antenna
The FM antenna supplied with this unit can be used as temporary
measure. If reception is poor, you can connect an outdoor FM
antenna.
To connect an outdoor FM antenna
Before connecting it, disconnect the supplied FM antenna.
Outdoor FM antenna
(not supplied)
ANTENNA
AM EXT
LOOP
FM 75
COAXIAL
A 75 Ω antenna with coaxial type connector should
be used.
– 6 –
AM antenna
LEFTRIGHT
MAIN
SPEAKERS
SUBWOOFERS
CAUTION:
SPEAKER
IMPEDANCE
6 16
Connecting Speakers
1
2
ANTENNA
AM EXT
AM LOOP
FM 75
COAXIAL
Vinyl-covered wire
(not supplied)
3
AM loop antenna
(supplied)
1
If cords are covered with insulation, twist the
core of the cord at the end of each cord, then
remove the insulation.
1
2
Speaker cords
(black/blue)
From right
subwoofer
From main
right speaker
3
Speaker cords
(black/blue)
Speaker cords
(black/red)
From left
subwoofer
From main
left speaker
2 Connect the AM loop antenna to the AM LOOP
terminals as illustrated.
3 Turn the AM loop antenna until you have the
best reception.
To connect an outdoor AM antenna
When reception is poor, connect a single vinyl-covered wire
to the AM EXT terminal and extend it horizontally. The AM
loop antenna must remain connected.
For better reception of both FM and AM
• Make sure the antenna conductors do not touch any other terminals
and connecting cords.
• Keep the antennas away from metallic parts of the unit, connecting
cords, and the AC power cord.
1 If cords are covered with insulation, twist the
core of the cord at the end of each cord, then
remove the insulation.
2 Insert the end of the speaker cord into the
terminal as illustrated.
Match the same polarity: (+) to (+) and (–) to (–).
3 Close the speaker terminals.
IMPORTANT: Use only speakers with the same speaker
impedance as indicated by the speaker terminals on the
rear of the unit.
• DO NOT connect more than one speaker to each
speaker terminal.
• DO NOT push or pull the speakers as this will
damage the foot spacers at the bottom of the
speakers.
– 7 –
Connecting Other Equipment
Now, you can plug the AC power cord.
You can connect both analog and digital equipment.
• DO NOT connect any equipment while the power
is on.
• DO NOT plug in any equipment until all connections
are complete.
To connect an analog component
Be sure that the plugs of the audio cords are colored: White
plugs and jacks are for left audio signals, and red ones for
right audio signals.
AUX
RIGHT LEFT
Audio equipment
To audio output
For playing the other equipment through this unit,
connect between the audio output jacks on the other
equipment and AUX jacks by using an audio cord (not
supplied).
IMPORTANT: Be sure to check all connections to be done
before plugging the AC power cord into a wall outlet.
Canceling the Demonstration
When connecting the AC power cord into a wall outlet, the
unit automatically starts the demonstration.
To cancel the demonstration, press and hold
CANCEL/DEMO until “DEMO OFF” appears
on the display.
• To cancel only beep sounds during the
demonstration, press BEEP ON/OFF on the
remote control.
When you press other buttons
The demonstration stops temporarily. It will start automatically
again (if no operation is done for 2 minutes) unless you cancel it by
pressing CANCEL/DEMO.
To start the demonstration manually
Press and hold CANCEL/DEMO again until “DEMO START”
appears on the display.
CANCEL / DEMO
BEEP
ON/OFF
To connect audio equipment with an optical digital
input terminal
You can record audio CD sound onto the connected digital
equipment.
• If the disc played back is an MP3 disc, no sound can be
output from the unit to the connected digital equipment.
CD OPTICAL
DIGITAL
OUTPUT
To optical digital input
Before connecting the
other equipment,
remove the protective
plug from the terminal.
Audio equipment with
an optical digital input
Protective
plug
Connect an optical digital cord (not supplied) between the
optical digital input terminal on the other equipment and the
CD OPTICAL DIGITAL OUTPUT terminal.
– 8 –
Common Operations
Turning On or Off the Power
To turn on the unit, press (or
STANDBY/ON on the remote control)
so that the lamp on the button goes off.
To turn off the unit (on standby), press
(or STANDBY/ON on the remote control)
again so that the lamp on the button lights up.
• A little power is always consumed even while
the unit is on standby.
To switch off the power supply completely, unplug the AC
power cord from the AC outlet.
When you unplug the AC power cord or if a power
failure occurs
The clock is reset to “AM 12:00” right away, while the tuner preset
stations (see page 12) will be erased in a few days.
Saving the Power Consumption while on Standby
—Ecology Mode
You can save the power consumption while the unit is turned
off (on standby).
• You can set Ecology Mode whether the unit is on or off.
On the unit ONLY:
To activate the Ecology Mode, press ECO.
“ECO” appears on the display for 2 seconds (and
the demonstration is canceled temporarily if you
have pressed the button while the unit is off).
• Each time you press the button, “ECO” and “NORMAL”
appear alternately on the display.
To deactivate the Ecology Mode, press ECO again.
“NORMAL” appears (and the demonstration starts if the unit
is turned off).
ECO
Setting the Clock
You can set the clock whether the unit is on or off; however,
if Ecology Mode is activated, you cannot set the clock while
the unit is off (on standby).
If Ecology Mode is not in use while the unit is turned off (on
standby), “AM 12:00” flashes on the display until you set the
clock.
On the unit ONLY:
R
P
DISPLAY
E
SET /
S
E
CLOCK
/ TIMER
T
1
Press CLOCK/TIMER.
The hour digits start flashing on the display.
2
Tur n 4 / ¢ to adjust the
hour, then press SET/DISPLAY.
The minute digits start flashing on the
display.
If you want to correct the hour
CANCEL / DEMO
after pressing SET/DISPLAY,
press CANCEL/DEMO.
The hour digits start flashing again.
3
Tur n 4 / ¢ to adjust the minute, then
press SET/DISPLAY.
To check the clock time while playing a source
Press and hold SET/DISPLAY.
• Each time you press and hold the button, the source
indication and the clock time alternate on the display.
When you turn off the unit with Ecology Mode activated
“ECO” flashes on the display, and the clock time will not be shown
while the unit is turned off.
To adjust the clock again
If you have set the clock before, press CLOCK/TIMER
repeatedly until the clock setting mode is selected.
• Each time you press the button, the clock/timer setting
modes change as follows:
DAILY
Canceled
When you unplug the AC power cord or if a power
failure occurs
The clock loses the setting and is reset to “AM 12:00.” If this
happens, set the clock again.
TIMER
(Daily Timer setting)
Clock
setting
(The hour digits start flashing.)
(Recording Timer setting)
REC
TIMER
– 9 –
Loading...
