JVC HR-VP48U User Manual

VIDEO CASSETTE RECORDER
HR-VP48U
TV operation n Press and hold TV button, then press POWER, TV CH+s–, VOO+ / –VTV / VCR
POWER
TV
TV/VCR
DISPLAY
A. MONITOR
1
2 3
2
4 5 6
DAILY(M-F)
WEEKLY
89
7
C. RESET
AUX
4
CANCEL
TIMER
0
STOP DATE
CH
START
EXPRESS PROGRAMMING
SKIP
PROG.
PROG.
SEARCH
SP/EP
CHECK
1
PLAY
F
F
REW
STOP
PAUS
REC
E
E
N
T
E
R
/
O
S
D
3
U
OK
N
E
M
H
C
V
+
T
SHUTTLE
T
V
PLUS
+
V
O
L
L
O
V
V
T
T
H
V
C
LP20878-001
VCR/TV
POWER
VIDEO AUDIO
REW
MENU
OK
SP EP
VCR
REC PAUSESTOP/EJECT
CH
SP/EP
PLAY
FF
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No. which are located on the rear of cabinet. Retain this information for future reference.
Model No. Serial No.
LPT0340-001A
2
EN
Dear Customer,
Thank you for purchasing the JVC VHS video cassette recorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of your new VCR.
CAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTION:
This video cassette recorder should be used with AC 120V`, 60Hz only. To prevent electric shocks and fire hazards, DO NOT use any other power source.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Declaration of Conformity Model Number :HR-VP48U Trade Name :JVC Responsible Party :JVC Americas Corp. Address :1700 Valley Road Wayne,
N.J. 07470
Telephone Number :973-315-5000
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Failure to heed the following precautions may result in damage to the VCR, Remote or video cassette.
1. DO NOT place the VCR . . .
... in an environment prone to extreme temperatures or
humidity. ... in direct sunlight. ... in a dusty environment. ... in an environment where strong magnetic fields are
generated. ... on a surface that is unstable or subject to vibration.
2. DO NOT block the VCR’s ventilation openings.
3. DO NOT place heavy objects on the VCR or on the Remote.
4. DO NOT place anything which might spill on the top of the VCR or on the Remote.
5. AVOID violent shocks to the VCR during transport.
VCR Plus+ and PlusCode are registered trademarks of Gemstar Development Corporation. The VCR Plus+ system is manufactured under license from Gemstar Development Corporation.
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
CAUTION:
Changes or modifications not approved by JVC could void user’s authority to operate the equipment.
Cassettes marked “VHS” (or “S-VHS”) can be used with this
video cassette recorder. However, S-VHS recording is not possible with this model.
This model is equipped with SQPB (S-VHS QUASI
PLAYBACK) that makes it possible to play back S-VHS recordings with regular VHS resolution.
HQ VHS is compatible with existing VHS equipment.As an ENERGY STA R® Partner, JVC has determined that this
product or product model meets the ENERGY STAR® guidelines for energy efficiency.
EN
3
IMPORTANT PRODUCT SAFETY INSTRUCTIONS
Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.
ATTENTION:
Follow and obey all warnings and instructions marked on your product and its operating instructions. For your safety, please read all the safety and operating instructions before you operate this product and keep this booklet for future reference.
INSTALLATION
1. Grounding or Polarization
(A) Your product may be equipped with a polarized alternating-
current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
(B) Your product may be equipped with a 3-wire grounding-type
plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
2. Power Sources
Operate your product only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. If your product is intended to operate from battery power, or other sources, refer to the operating instructions.
5. Ventilation
Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered.
• Do not block the openings by placing the product on a bed,
sofa, rug or other similar surface.
• Do not place the product in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.
6. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
ANTENNA INSTALLATION INSTRUCTIONS
1. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
2. Lightning
For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.
3. Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
3. Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.
4. Power Cord Protection
Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT (NEC SECTION
ELECTRIC SERVICE EQUIPMENT
POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H)
NEC – NATIONAL ELECTRICAL CODE
810-20)
GROUNDING CONDUCTORS (NEC SECTION 810-21)
GROUND CLAMPS
4
EN
USE
1. Accessories
To avoid personal injury:
• Do not place this product on an unstable cart, stand, tripod, bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the product.
• Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.
• Use a mounting accessory recommended by the manufacturer and follow the manufacturer’s instructions for any mounting of the product.
• Do not try to roll a cart with small casters across thresholds or deep-pile carpets.
2. Product and Cart Combination
A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.
3. Water and Moisture
Do not use this product near water—for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.
4. Object and Liquid Entry
Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short­out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
5. Attachments
Do not use attachments not recommended by the manufacturer of this product as they may cause hazards.
6. Cleaning
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
7. Heat
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
PORTABLE CART WARNING (Symbol provided by RETAC)
SERVICING
1. Servicing
If your product is not operating correctly or exhibits a marked change in performance and you are unable to restore normal operation by following the detailed procedure in its operating instructions, do not attempt to service it yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
2. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a.When the power supply cord or plug is damaged. b.If liquid has been spilled, or objects have fallen into the
product. c.If the product has been exposed to rain or water. d.If the product does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation. e.If the product has been dropped or damaged in any way. f. When the product exhibits a distinct change in
performance—this indicates a need for service.
3. Replacement Parts
When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.
4. Safety Check
Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in safe operating condition.
HOW TO USE THIS INSTRUCTION MANUAL
The Index on pages 39 – 42 lists frequently-used terms, and
the number of the page on which they are used or explained
in the manual. This section also illustrates the controls and
connections on the front and rear panel, the front display
panel and the Remote.
The mark signals a reference to another page for
instructions or related information.
Operation buttons necessary for the various procedures are
clearly indicated through the use of illustrations at the
beginning of each major section.
BEFORE YOU INSTALL YOUR NEW VCR . . .
. . . please read the sections/literature listed below.
”CAUTIONS” on page 2
”IMPORTANT PRODUCT SAFETY INSTRUCTIONS” on the
previous pages
CONTENTS
NSTALLING YOUR NEW VCR 6
I
Basic Connections .................................. 6
NITIAL SETTINGS 8
I
Plug & Play Setting ....................................... 8
Language Setting .......................................... 9
Clock Setting............................................... 10
Preparations.............................................................10
Setting clock semiautomatically
— Semiauto Clock Set .......................................... 11
Setting clock manually — Manual Clock Set ...........12
Tuner Setting .............................................. 13
Setting channels automatically
— Auto Channel Set .............................................13
Setting channels manually
— Manual Channel Set ........................................ 14
ASIC PLAYBACK AND
B
RECORDING 15
Basic Playback ........................................... 15
Basic Playback Features ............................. 16
Changing display information ..................................16
Checking tape position ............................................16
Playing back tape repeatedly — Repeat Play ........... 16
Adjusting tracking condition
— Tracking Adjustments .......................................17
Automatic operations after rewinding
— Next Function Memory ....................................17
Locating beginning of recordings — Index Search ... 18 Locating beginning of timer recordings
— Instant Review .................................................18
Basic Recording .......................................... 19
Basic Recording Features ............................ 20
Changing display information ..................................20
Specifying recording length
— Instant Timer Recording (ITR)...........................20
Watching one program while recording another ...... 20
Showing on-screen display ......................................21
PECIAL EFFECT PLAYBACK 22
S
Special Effect Playback ............................... 22
Locating particular scene rapidly — Picture Search....22
• High-Speed Picture Search ................................ 22
• Variable-Speed Picture Search ...........................22
Viewing still picture — Still Picture Playback...........23
Skipping unwanted portions — Skip Search .............23
Viewing still picture frame by frame
— Frame-by-Frame Playback ............................... 23
Viewing slow motion picture
— Slow Motion Playback .....................................23
EN
5
IMER RECORDING 24
T
VCR Plus+ Timer Programing ...................... 24
VCR Plus+ Setup ......................................... 26
Express Timer Programing .......................... 28
Checking program settings ....................................... 30
Canceling or changing program settings .................. 30
When programs overlap each other .........................31
THER USEFUL FUNCTIONS 32
O
Useful Function Settings .............................. 32
7 AUTO PICTURE...................................................33
7 PICTURE CONTROL............................................33
7 AUTO TIMER.......................................................33
7 SUPERIMPOSE.....................................................33
7 AUTO SP=EP TIMER .......................................... 34
7 VIDEO STABILIZER..............................................34
7 BLUE BACK .........................................................34
DITING 35
E
Edit To Or From Another VCR ...................... 35
ROUBLESHOOTING 36
T
Questions and answers ............................................38
NDEX 39
I
List of terms .............................................................39
Front panel ..............................................................40
Front display panel ..................................................40
Rear panel ...............................................................41
On-screen display....................................................41
Remote ....................................................................42
PECIFICATIONS 43
S
OR SERVICING (Only in U.S.A.) 44
F W
ARRANTY (Only in U.S.A.) 45
6
EN
Basic Connections
Antenna or cable
Matching transformer
AC Power Cord
VIDEO OUT
AUDIO OUT
(not supplied)
INSTALLING YOUR NEW VCR
ANTENNA IN (Antenna or cable input)
Coaxial cable
Flat feeder
ANT. IN
OUT
CH3 CH4
AUDIO
VIDEO
RF OUT
AC Outlet
Back of VCR
RF OUT
Audio/video cable (not supplied)
To Audio/video input connectors
RF cable (supplied)
To 75 ohm terminal
TV
EN
7
Check contents
1
Make sure the package contains all of the accessories listed in “SPECIFICATIONS” ( pg.
43).
Situate VCR
2
Place the VCR on a stable, horizontal surface.
Connect VCR to TV
3
The following connections are required.
RF Connection
1 Disconnect the TV antenna from the TV. 2 Connect the TV antenna cable to the ANT. IN
terminal on the rear of the VCR.
3 Connect the supplied RF cable between the RF
OUT terminal on the rear of the VCR and the TV’s antenna input terminal.
AV Connection (improves picture quality during tape playback.)
If your TV is equipped with audio/video input connectors
1 Connect the antenna, VCR and TV as shown in
the illustration.
2 Connect an audio/video cable between the
AUDIO/VIDEO OUT connectors on the rear of the VCR and the audio/video input connectors on the TV.
Connect VCR to power source
4
Connect the AC power plug to an AC outlet.
The clock and tuner channels will automatically be set when the antenna is connected and when the AC power cord is first connected to an AC power outlet ( pg. 8). (If “Auto” or “CH” is displayed on the front display panel before the VCR is turned on, the clock and tuner channels are being set automatically. Wait until the clock time is displayed on the front display panel before turning on the VCR.)
Final preparation for use
5
Turn on the VCR and set the CH3-CH4 switch on the rear (shown below) to either CH3 or CH4 correctly.
The CH3–CH4 switch is preset to the CH3 position. Set to CH4 if CH3 is used for broadcasting in your area. (To view the picture from this VCR through this channel, select the same channel on the TV with the CH3–CH4 switch setting on the VCR.)
You can now perform basic playback ( pg.
15) or basic recording ( pg. 19).
ANT. IN
OUT
CH3 CH4
CH3 CH4
AUDIO
VIDEO
RF OUT
Back of VCR
NOTES:
The VCR channel is the channel on which you can watch the picture from the VCR on the TV when only using the RF connection. The VCR’s CH3-CH4 switch, on the back of the VCR, sets the VCR channel to CH3 or CH4.
Even if you are using audio/video cables to connect your VCR to your TV, you must also connect it using the RF cable. This will ensure that you can record one show while watching another (墌 pg. 20).
For full identification of the VCR’s rear panel, refer to the Index ( 墌 pg. 41).
8
EN
Plug & Play Setting
Auto Clock Set/Auto Tuner Set
ATTENTION
If you use a cable box, Plug & Play will not function; set the clock and tuner channels separately. ( pg.10 – 14)
It takes several minutes for the VCR to complete the Plug & Play setting.
Do not press any buttons on the front panel or on the Remote while Plug & Play is in progress.
SP EP
VCR
INITIAL SETTINGS
This VCR sets the clock and tuner channels automatically when AC power cord is first connected to an AC outlet. The antenna cable must be connected for the Plug & Play setting. The time and date can be set automatically by the clock setting data transmitted from one of the regular TV broadcast channels. We call this TV channel the “host channel” and it is a PBS channel in your area.
Perform Plug & Play setup
1
Connect the antenna cable to the VCR ( pg.
6). Then connect the AC power cord to an AC outlet. Do not turn on the VCR.
The clock and tuner channels will be set automatically.
NOTES:
Auto Clock Set is performed first. “Auto” blinks on the front display panel during Auto Clock Set.
Auto Channel Set is performed next. Auto Channel Set scans all the channels that are receivable by your VCR. During Auto Channel Set, the channel numbers are displayed as they are scanned and set.
When Plug & Play setting has been complete successfully, the correct clock time is displayed. If you perform Plug & Play setting successfully, there is no need to perform the clock (墌 pg. 10) and tuner (墌 pg.
13) settings. If, however, you want to add or delete channels, refer to Manual Channel Set on page 14.
During Initial Auto Clock Set
“Auto” blinks.
* If an incorrect clock time or “– –:– –” appears on the display panel, see “What to do if Plug & Play setting failed”
below.
During Auto Channel Set
The channel numbers are displayed as they are scanned and set.
Plug & Play Completed
The current time (including AM/PM) is displayed.
INFORMATION
If “AUTO CLOCK” is set to “ON” on the Clock Set screen on page 11, the clock will be adjusted automatically by the host channel every hour (except 11:00 PM, midnight, 1:00 AM and 2:00 AM) using the incoming PBS channel clock setting data. (This automatic clock adjustment can only be performed when the VCR is turned off. The clock will be adjusted just on these hours — on the time displayed on the front panel display, not on the actual real time.) The default setting of “AUTO CLOCK” is “ON”.
If the memory backup fails, because a power outage occurs or because the AC power cord is unplugged, Plug & Play will be performed when power is restored to the VCR.
Poor antenna or cable signal may prevent the VCR from receiving the Auto clock setting data from the PBS channel. If this function is taking a considerable amount of time, it may be necessary to perform the Semiauto or Manual Clock Set procedure.
What to do if Plug & Play setting failed
If an incorrect time is displayed on the front display panel, you may be receiving the clock setting data of a PBS channel from an adjacent time zone, or an incorrect PBS channel from a cable TV system. In this case, perform the Semiauto ( pg. 11) or Manual Clock Set ( pg. 12) procedure.
If “- -:- -” appears on the front display panel, your antenna cable may not be connected to the VCR or there may not be a Host PBS signal available in your area. Ensure that the antenna cable is connected correctly. Then turn on and off the VCR; the Plug & Play setting will be automatically reactivated. If Plug & Play setting is not performed though the antenna cable is connected correctly, perform Manual Clock Set (墌 pg. 12) and Auto Channel Set or Manual Channel Set ( pg. 13 or 14).
Language Setting
EN
9
This VCR offers you the language choice to view menus and some messages (excluding the on-screen display superimposed on the TV screen) — in English, Spanish or French. Select the desired language using the following procedure. The default setting is “ENGLISH”.
Turn on the VCR and the TV, and select the VCR channel 3 or 4 (or AV mode) on the TV.
1 4
2 3
SP EP
VCR
2 3
1
2 3
4 5 6
89
7
0
2
4
Access Main Menu screen
1
Press MENU.
Access Initial Set screen
2
On the front panel:
Press CH5∞ to move the highlight bar (arrow) to “INITIAL SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “INITIAL SET”, then press OK or SHUTTLE PLUS
FUNCTION SET TUNER SET
=
INITIAL SET
PRESS (5,∞), THEN (OK) PRESS (MENU) TO END
Select language
3
On the front panel:
Press CH5∞ to move the highlight bar (arrow) to “LANGUAGE”, then press OK repeatedly until the desired language is selected.
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar (arrow) to “LANGUAGE”, then press OK or
3
SHUTTLE PLUS language is selected.
repeatedly until the desired
CLOCK SET
=
LANGUAGE ENGLISH
GUIDE CHANNEL SET
SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END
Return to normal screen
4
Press MENU.
MAIN MENU
INITIAL SET
3
.
1 4
1
3
2 3
2 3
10
EN
Clock Setting
Turn on the VCR and the TV, and select the VCR channel 3 or 4 (or AV mode) on the TV.
INITIAL SETTINGS (cont.)
Perform clock setting only if the clock has not been set correctly by the Plug & Play setting or if you use a cable box. Access the Clock Set screen to perform the Semiauto or Manual Clock Set. Each procedure starts from step 4 after preparation steps below are finished. If you use a cable box, set the clock manually. ( pg. 12)
1 8 2 – 7
1
2 3
4 5 6
89
7
0
1
Preparations
Access Main Menu screen
1
Press MENU.
Access Initial Set screen
2
On the front panel: Press CH5∞ to move
SP EP
VCR
2 7
the highlight bar (arrow) to “INITIAL SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “INITIAL SET”, then press OK or SHUTTLE PLUS
Select clock set
3
On the front panel: Press CH5∞ to move
2
4
the highlight bar (arrow) to “CLOCK SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “CLOCK SET”, then press OK or SHUTTLE PLUS
“CABLE BOX USERS SET CLOCK MANUALLY” appears on the screen for about 5 seconds, then the Clock Set screen appears.
MAIN MENU
FUNCTION SET TUNER SET
=
INITIAL SET
PRESS (5,∞), THEN (OK) PRESS (MENU) TO END
3
.
INITIAL SET
=
CLOCK SET
LANGUAGE ENGLISH GUIDE CHANNEL SET
SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END
3
.
1 8
3
2 – 7
2 – 7
EN
11
Setting clock semiautomatically
— Semiauto Clock Set
You can change the host channel/D.S.T. /time zone setting manually. First follow steps 1 to 3 on page 10, then go to the following steps.
Set Auto Clock to ON
4
On the front panel:
Press CH5∞ to move the highlight bar to “AUTO CLOCK”, then press OK so that “ON” is selected.
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar to “AUTO CLOCK”, then press OK or
3
SHUTTLE PLUS Then; To select the host channel — go to step 5. To select the D.S.T. mode — go to step 6. To select the time zone — go to step 7.
so that “ON” is selected.
NOTE:
The time that has been set previously will be erased when “AUTO CLOCK”, “HOST CH”, “D.S.T.” or “TIME ZONE” setting is changed.
Select host channel
5
You can either select “AUTO” or enter a PBS channel number.
On the front panel:
Press CH5∞ to move the highlight bar to “HOST CH”, then press OK repeatedly until “AUTO” or the desired PBS channel number is selected.
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar to “HOST CH”, then press OK or SHUTTLE
3
until “AUTO” or the desired PBS channel
PLUS number is selected.
NOTE:
Some PBS channels do not transmit clock setting data.
CLOCK SET
TIME DATE YEAR
1:00PM 12/24 00 SAT
AUTO CLOCK : ON
HOST CH : AUTO (CATV) D.S.T. : AUTO TIME ZONE : AUTO PRESS (5,∞), THEN (OK) PRESS (MENU) TO END
Select D.S.T. mode
6
You have three choices: AUTO– Select if you want to adjust your VCR’s
clock automatically by the incoming signal from the host channel. (Auto Daylight Saving Time*)
ON Adjustment will be made by the clock
itself.
OFF Select when Daylight Saving Time does
not apply to you.
On the front panel:
Press CH5∞ to move the highlight bar to “D.S.T.”, then press OK repeatedly until the desired setting is selected.
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar to “D.S.T.”, then press OK or SHUTTLE PLUS
3
repeatedly until the desired setting is selected.
Select time zone
7
You can select the time zone automatically or manually.
On the front panel:
Press CH5∞ to move the highlight bar to “TIME ZONE”, then press OK repeatedly until “AUTO” or the desired time zone is selected. Each time you press the button, the time zone changes as follows:
= AUTO= ATLANTIC= HAWAII= EASTERN = ALASKA = CENTRAL PACIFIC = MOUNTAIN = (back to the beginning)
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar to “TIME ZONE”, press OK or SHUTTLE
3
repeatedly until “AUTO” or the desired
PLUS time zone is selected (see above).
NOTE:
If an incorrect clock time is displayed by the Plug & Play setting, you may be receiving the clock setting data of a PBS channel from an adjacent time zone or from an incorrect PBS channel from a cable TV system. If you selected "AUTO" for the host channel in step 6, be sure to select the correct time zone manually.
* Auto Daylight Saving Time
This function enables automatic adjustment of the VCR’s clock at the start and end of Daylight Saving Time. With Auto DST activated, . . . . . . on the first Sunday of April at 2:00 AM, the clock is adjusted to 3:00 AM. . . . on the last Sunday of October at 2:00 AM, the clock is adjusted to 1:00 AM.
Return to normal screen
8
Press MENU.
IMPORTANT
Turn off the VCR after performing Semiauto Clock Set. ”Auto” will appear on the front display panel while the clock is being set. The current clock time will appear automatically when the clock setting is complete.
12
EN
INITIAL SETTINGS (cont.)
8
8 4 – 7
SP EP
VCR
4 – 7
1
Set date
5
On the front panel:
Press CH5∞ until the desired date appears, then press OK.
On the Remote:
Press SHUTTLE PLUS 5∞ until the desired date appears, then press OK or SHUTTLE PLUS
● Holding CH 5∞ or SHUTTLE PLUS 5∞ changes the date in 15-day intervals.
Set year
6
On the front panel:
Press CH5∞ until the desired year appears, then press OK twice.
On the Remote:
Press SHUTTLE PLUS 5∞ until the desired year appears, then press OK or SHUTTLE PLUS
3
.
3
twice.
Select D.S.T. mode
7
You can select either “ON” or “OFF”. ON Adjustment will be made by the built-in
3
2 – 7
2 – 7
clock itself.
OFF– Select when Daylight Saving Time does
not apply to you.
On the front panel: Press CH5∞ to select the desired setting.
On the Remote:
Press SHUTTLE PLUS 5∞ to select the desired setting.
Setting clock manually
— Manual Clock Set
First follow steps 1 to 3 on page 10, then go to the following steps.
Set time
4
On the front panel:
Press CH5∞ until the desired time appears, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ until the desired time appears, then press OK or SHUTTLE PLUS
● Holding CH 5∞ or SHUTTLE PLUS 5∞ changes the time in 30-minute intervals.
When the time is entered manually, “AUTO CLOCK” is automatically set to “OFF”, and “HOST CH” and “TIME ZONE” disappear.
CLOCK SET
TIME DATE YEAR
– –:– –AM 1/ 1 00
AUTO CLOCK : ON HOST CH : AUTO (CATV) D.S.T. : AUTO TIME ZONE : AUTO PRESS (5,∞), THEN (OK) PRESS (MENU) TO END
Start clock
8
Press MENU and normal screen appears.
To make corrections any time during the process
Press OK or SHUTTLE PLUS 3 repeatedly until the item you want to change blinks, then press CH 5∞ or
SHUTTLE PLUS 5∞.
3
.
Tuner Setting
Turn on the VCR and the TV, and select the VCR channel 3 or 4 (or AV mode) on the TV.
1 4
EN
13
Setting channels automatically — Auto Channel Set
Use Auto Channel Set only if channels have not been set correctly by the Plug & Play setting or if you use a cable box. If you want to add or delete channels, use Manual Channel Set ( pg. 14).
Access Main Menu screen
1
Press MENU.
2 3
SP EP
VCR
1
2 3
4 5 6
89
7
0
1
2
4
2 3
Access Tuner Set screen
2
On the front panel:
Press CH5∞ to move the highlight bar (arrow) to “TUNER SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “TUNER SET”, then press OK or SHUTTLE PLUS
FUNCTION SET
=
TUNER SET
INITIAL SET
PRESS (5,∞), THEN (OK) PRESS (MENU) TO END
Perform Auto Channel Set
3
You can automatically set the receivable channels in your area in the order of their frequencies.
On the front panel:
Press CH5∞ to move the highlight bar (arrow) to “AUTO CHANNEL SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “AUTO CHANNEL SET”, then press OK or SHUTTLE PLUS
BAND CATV
=
AUTO CHANNEL SET
MANUAL CHANNEL SET
SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END
AUTO CHANNEL SET
PRESS (MENU) TO END
MAIN MENU
3
TUNER SET
SCANNING...
3
.
.
1 4
NOTES:
When Auto Channel Set is complete, “SCAN
3
2 3
2 3
4
COMPLETED” appears on screen.
If the scan was unsuccessful, “SCAN COMPLETED– NO SIGNAL” appears on screen. Check the connections and start again.
Return to normal screen
Press MENU.
INFORMATION
The VCR selects the correct band (TV or CATV) automatically during Auto Channel Set. The selected band will be displayed on the right side of “BAND” on the Tuner Set screen.
14
EN
INITIAL SETTINGS (cont.)
1 5
1 5 2 – 4
SP EP
VCR
1
2 3
4 5 6
89
7
0
1
Access Tuner Set screen
2
On the front panel:
Press CH5∞ to move the highlight bar (arrow) to “TUNER SET”, then press OK.
On the Remote:
Press SHUTTLE PLUS 5∞ to move the highlight bar (arrow) to “TUNER SET”, then press OK or SHUTTLE PLUS 3.
Access Manual Channel Set screen
3
2 – 4
2
4
4
3
2 – 4
2 – 4
On the front panel:
Press CH5∞ move the highlight bar (arrow) to “MANUAL CHANNEL SET”, then press OK.
On the Remote: Press SHUTTLE PLUS
5∞ to move the highlight bar (arrow) to “MANUAL CHANNEL SET”, then press OK or
3
SHUTTLE PLUS
.
Add or skip desired channels
4
To add channels
On the Remote ONLY:
1 Press the Number
keys to input a channel number you want to add.
2 Press OK or
3
SHUTTLE PLUS set to “ADD”.
3 Repeat 1 and 2 to add other channels.
To skip channels
On the front panel:
1 Press CH5∞ to select a channel number you
want to skip.
2 Press OK to set to “SKIP”. 3 Repeat 1 and 2 to skip other channels.
On the Remote:
1 Press the Number keys or SHUTTLE PLUS 5∞
to input a channel number you want to skip.
2 Press OK or SHUTTLE PLUS 3 to set to “SKIP”. 3 Repeat 1 and 2 to skip other channels.
to
TUNER SET
BAND CATV AUTO CHANNEL SET
=
MANUAL CHANNEL SET
SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END
MANUAL CHANNEL SET
(CATV)
CH 45 ADD
PRESS NUMBER KEY (0–9)
OR (5,∞), THEN (OK)
PRESS (MENU) TO END
Setting channels manually
— Manual Channel Set
You can add the channels you want or delete the channels you do not want manually.
Access Main Menu screen
1
Press MENU.
Return to normal screen
5
Press MENU.
BASIC PLAYBACK AND RECORDING
Basic Playback
Turn on the VCR and the TV, and select the VCR channel 3 or 4 (or AV mode) on the TV.
Load a cassette
1
Make sure the window side is up, the rear label side is facing you and the arrow on the front of the cassette is pointing towards the VCR. Do not apply too much pressure when inserting.
The VCR turns on automatically.
The counter is automatically reset to “0:00:00”.
If the cassette’s record safety tab has been
removed, playback begins automatically.
EN
15
POWER
SP EP
VCR
REW (1 )
1
2 3
4 5 6
89
7
0
2
2
4
FF ( ¡ )
STOP/EJECT
( 7 / 0 )
POWER
2
1
REW ( 1 )
3
Clean the video heads using a dry cleaning cassette — TCL-2UX — when:
• Rough, poor picture appears while a tape is played back.
• The picture is unclear or no picture appears.
• “USE CLEANING CASSETTE” appears on the screen (only with “SUPERIMPOSE” set to “ON”: pg. 33.)
FF ( ¡ )
STOP ( 7 )
Start playback
2
Press PLAY ( 3 ).
Tape speed (SP or EP) is automatically detected.
To stop playback
Press STOP ( 7 ) on the Remote or STOP/EJECT ( 7 / 0 ) on the front panel.
To rewind the tape
Press REW ( 1 ).
To fast-forward the tape
Press FF ( ¡ ).
To eject the tape
Press STOP/EJECT ( 7 / 0 ) on the front panel when the tape is not running.
You can also eject the cassette with the VCR turned off.
To turn off the VCR
Press POWER.
INFORMATION
This VCR is equipped with SQPB (S-VHS QUASI PLAYBACK) that lets you watch tapes recorded in the S­VHS format with regular VHS resolution.
SQPB does not deliver Super VHS resolution.
S-VHS recording is not possible with this VCR.
Usable cassettes
Full-Size VHS T-30 (ST-30**) T-60 (ST-60**) T-90 T-120 (ST-120**) T-160 (ST-160**) ST-210**
Compact VHS* TC-20 (ST-C20**) TC-30 (ST-C30**) TC-40 (ST-C40**)
* Compact VHS camcorder recordings can be
played on this VCR. Simply place the recorded cassette into a VHS Cassette Adapter and it can be used just like any full-sized VHS cassette.
** This VCR can record on regular VHS and Super
VHS cassettes. However, it will record regular VHS signals only.
Loading...
+ 33 hidden pages
