JVC HR-S5950EU, HR-S5955EK, HR-S5955MS Parts List

SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSOR Y ASSEMBLY <M1> The instruction manual to be provided with this product will differ according to the destination.

307

306

ADHESIVE TAPE

312

308

306A

(HR-S5955MS)

SPEC OF BARCODE

317 310

302

MODEL MARK HR-S5950EU A HR-S5955EK B HR-S5955MS C

FINAL ASSY <M2>

303

311

302

(HR-S5955EK)

SPEC OF BARCODE

317 310 319

(HR-S5950EU)

SPEC OF BARCODE

316 310

315 (HR-S5955MS)

301

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PAR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

P ACKING AND ACCESSOR Y ASSEMBLY <M1>

301 LP30855-004A PACKING CASE 302 LP30909-001C CUSHION ASSY 303 PQM30021-93 POL Y BAG 306 LP20878-014A REMOTE CONTROLLER 306A LP40610-003A COVER(BATTER Y) 307 – BATTERY,X2(“R6”TYPE) 308 QPC02202230P POLY BAG

310 LPT0649-001B INST.BOOK(EN),A

! ! ! ! !

LPT0649-002B INST.BOOK(GE),A LPT0649-003A INST.BOOK(FR),A LPT0649-004A INST.BOOK(DU),A LPT0649-005A INST.BOOK(SP),A LPT0649-006A INST.BOOK(IT),A

SPEC OF BARCODE

! ! ! ! ! ! ! ! ! ! !

LPT0649-007A INST.BOOK(DA),A LPT0649-008A INST.BOOK(FI),A LPT0649-009A INST.BOOK(SW),A LPT0649-010A INST.BOOK(NO),A LPT0649-011A INST.BOOK(PT),A LPT0649-012A INST.BOOK(GR),A LPT0649-013A INST.BOOK(CZ),A LPT0649-014A INST.BOOK(PO),A LPT0649-015A INST.BOOK(HU),A LPT0653-001A INST.BOOK(EN),B

LPT0657-001A INST.BOOK(FR),C 311 QPC02503530P POLY BAG 312 PEAC0300-02 RF CABLE 315 QAM0238-003 PERI CABLE,C 316 BT-54013-2 WARRANTY CARD,A 317 BT-54008-2 GUARANTY CARD,B,C 319 LYT0194-001B Q.CARD(JUK),B

5-1

5.2 FINAL ASSEMBLY <M2>

NOTE) INERTIA PLATE should be attached so as to ser small

diameter of central round hole above.

501

522 521

519

501A

520

519A

NOTE) When attaching ROLLER ARM ASS'Y,

attach the hook(L3c) before the spring(P3a).

NOTE) After attached ROLLER ARM ASS'Y, tighten screw(S3g) with slit washer(W3a).

BEWARE OF BOGUS PARTS

Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine JVC parts be used.

532

515

510

533

505

516

515

MECHANISM ASSY<M4>

510

503

502

510

517

533

5001

511

Insert the bushing of POWER CORD so as not to twist the cord.

JS3001

<Phase alignment> Accord the position of V gap on R. Encoder and PWB silk " ". Accord the position of Boss on R. Encoder and PWB silk " ".

523

For the prevention of the DRUM FPC damage. When you attach the MECHA UNIT on B. CHASSIS. Attach the MECHA UNIT after the positioning boss "z" of the B. CHASSIS is matched to the positioning hole of the MECHA UNIT.

REAR SIDE

"Z"

S/P CONVERTER BOARD ASSY<87>

516

MAIN BOARD ASSY<03>

503

504

536

534 (HR-S5955EK)

5-2

ONLY USED FOR HR-S5955MS

WR9

501B

536

ONLY USED FOR HR-S5955MS

512

from CAPSTAN MDA right side

CN1601

CN513

CN7102

CN7105

DRUM

right side

A/C HEAD

CN2001

CN5001

NOTE

1. Insert direction of FCC WIRE as follows.

Right side Back side

electrode side

2. FFC WIRE and DRUM FPC WIRE should be insert as follows.

3. Insert direction of POWER CORD.

U/U(C)/JPN

WHITE LINE

NEUTRAL

CN CN

NEUTRAL

CN5001

supporting side

Except U/U(C)/JPN

BLUE

CN5001

DETAIL"A"

CN7001

for JOG

NOT USED

bend

back side

CN1601

bend

ONLY USED FOR

bend

CN513

back side

bend

HR-S5955MS

S-SUB

S-P CONV.

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

FINAL ASSEMBLY <M2>

501 LP10434-007E FRONT PANEL ASSY,A

! !

501A LP20961-015D CASSETTE DOOR 501B PQ46448 TORSION SPRING

502 LP10013-051B TOP COVER 503 QYTDSF3010R SCREW,X4,TOP COVER(SIDE) 504 QYTDSF3010M SCREW ,TOP COVER(REAR) 505 PDV2544A DRUM ASSY 510 QYSPSPD3008Z SCREW,X3,DRUM

511 LP10108-001H BOTT OM CHASSIS

512 LP10014-002C BOTTOM COVER 515 QYTDSF4012Z SCREW,X2,MECHA 516 QYSPSFG3010Z SCREW,X2,MECHA

517 QMP4A10-170 POWER CORD,A,C

519 LP40370-001F ROLLER ARM ASSY 519A PDM4311A-1 ROLLER ASSY 520 PQ45160 INERTIA PLATE 521 PQM30017-51 SLIT W ASHER 522 QYSLSF2060D SCREW 523 QYTDSF3010M SCREW ,T.BOARD 532 QYTDSF3010Z SCREW,MAIN 533 DPSF3010Z SCREW,X3,MAIN 534 LP30871-003B CAP(JACK),B 536 QYTDSF3008Z SCREW,X2,P/S CONV.,C WR9 QUQ112-1 1 15CG FFC WIRE,P/S CONV .CN513,C

LP10434-008F FRONT PANEL ASSY,B LP10434-009E FRONT PANEL ASSY,C

QMP51K0-170-K POWER CORD,B

5-3

5.3 MECHANISM ASSEMBL Y <M4>

112

124

127

128

138

126

110

118

122

130

121

105

131

137

138

151

123

125

126

119

120

31 30

111

117

115

113

112

116

114

A/C HEAD BOARD ASSY <12>

WR2

5-4

107

134

Classification drawing

Part No.

102

Symbol in

Grease KYODO-SH-JB AA Oil COSMO-HV56 BB

105

107

18B

18A

20 LOADING MOTOR

BOARD ASSY <55>

23B

23A

WR3

WR1

62 59

NOTE:The section marked in AA and BB

indicate lubrication and greasing areas.

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

1 LP21039-001R MAIN DECK ASSY 3 LP40097-002D GUIDE POLE CAP 4 QAH0082-001 FULL ERASE HEAD 15 LP30958-001B LOAD.GEAR BASE 16 QYTPST2620Z SCREW,X2 18 LP40798-001A LOAD.GEAR(SUPPLY)ASSY 18A LP21040-001A LOAD.GEAR(SUPPLY) 18B LP40799-001A LOAD.ARM(SUPPL Y)ASSY 19 LP40837-001A TORSION SPRING(SUPPL Y) 20 LP40903-001A FIXING PLATE 21 LP40806-001D POLE BASE ASSY(SUPPLY) 22 LP30959-002A LOAD GEAR 23 LP40802-001B LOAD.GEAR(TAKE UP)ASSY 23A LP21041-001B LOAD.GEAR(T AKE UP) 23B LP40803-001A LOAD.ARM(T AKE UP)ASSY 24 LP40838-001A TORSION SPRING(T AKE UP) 26 LP40808-001E POLE BASE ASSY(TAKE UP) 30 LP31020-004A ARM BASE 31 QYTDST2606Z SCREW 36 LP21055-001E TU LEVER 37 LP40943-001A TENSION SPRING 38 LP40859-001D T -UP HEAD 39 LP30961-001C LID GUIDE 40 LP30002-0B7A SPACER 42 LP40810-001A PINCH ROLLER ARM ASSY 44 LP40840-001D TORSION SPRING 46 LP30963-001B PRESS LEVER 47 PQM30017-24 SLIT WASHER 48 LP40930-002E S-SWITCH 49 LP40813-001D GUIDE ARM ASSY 50 LP40841-001A TORSION SPRING 51 LP30002-090A SP ACER 52 QAH0081-001 AC HEAD 53 LP30965-001A HEAD BASE 55 LP40842-001A COMPRESSION SPRING 57 QYTSST2010Z SCREW,X3 58 QYTDST2606Z SCREW,X2 59 QAR0023-001 LOADING MOTOR 60 QYTPSP3003Z SCREW,X2 61 LP21056-002G MOTOR BRACKET 62 QYTPST2620Z SCREW 63 LP40814-001B WORM BEARING 64 LP21044-001D CONTROL CAM 65 PQM30017-24 SLIT WASHER 66 LP40815-001A WORM GEAR 67 LP40816-001B HELICAL GEAR 68 LP40817-001A CONNECT GEAR 69 LP10400-001H CONTROL PLATE 70 LP40843-001A TORSION SPRING 71 LP40818-001B TENSION ARM ASSY 72 LP40844-001D TENSION SPRING 73 LP21045-001D TENSION ARM BASE 74 LP40821-001A TENSION BAND ASSY 75 LP30967-001B BAND HOLDER-1 76 LP30968-001C BAND HOLDER-2 77 LP40822-002B ADJUST PIN 78 LP31000-005E TENSION ARM LEVER 79 LP21046-001C MAIN BRAKE(TAKE UP) 80 LP40824-001A BAND BRAKE ASSY

MECHANISM ASSEMBLY <M4>

81 LP30969-002A BRAKE LEVER 82 LP30003-033B TENSION SPRING 83 LP30003-035B TENSION SPRING 84 LP40825-001B CAPSTNAN BRAKE ASSY

85 QAR0204-002 CAPSTAN MOTOR 86 QYTDSF2606M SCREW ,X3 87 LP30005-010A BELT,CAPST AN MOT OR 88 LP30970-001A IDLER ARM 89 LP40828-004A IDLER GEAR 1,X2 90 LP40829-001B IDLER GEAR 2,X2 91 LP31014-001A WIRE HOLDER 93 LP40934-001B CLUTCH UNIT 94 PQM30017-47 SLIT WASHER 95 LP30973-001A DIRECT GEAR 96 LP40939-001A COMP . SPRING 102 LP30974-001B CHANGE LEVER 105 LP21049-001A REEL DISK,X2 107 LP30017-004A SPACER,X2 110 LP10401-001F SIDE FRAME(L) 111 LP10402-001G SIDE FRAME(R) 112 QYTDST2606Z SCREW,X2 113 LP40917-001D TORSION SPRING 114 LP30976-001E SIDE PLATE 115 LP30977-002D LIMIT PLATE 116 LP40846-001C LIMIT SPRING 117 LP31100-001B DRIVE LEVER 118 LP30978-001B DRIVE ARM(L) 119 LP30979-001H DRIVE ARM(R) 120 LP40847-001B TORSION SPRING 121 LP30980-001B CONNECT PLA TE 122 LP10403-001C SIDE HOLDER(L) 123 LP10404-001E SIDE HOLDER(R) 124 LP30983-001A LOCK LEVER(L) 125 LP30984-001A LOCK LEVER(R) 126 LP40924-001D TENSION SPRING,X2 127 LP40856-001B EARTH SPRING(1) 128 LP40857-001B EARTH SPRING(2) 130 LP30981-001F CASETTE HOLDER ASSY 131 LP31135-001A C.H STOPPER 134 LP21051-002C REC.SAFETY LEVER 137 LP21052-001H TOP FRAME 138 LP30002-0A7A SPACER,X2 151 LP30985-001G DOOR OPENER WR1 WJT0059-001D E-CARD WIRE,DRUM WR2 WJT0067-001B E-CARD WIRE,A/C HEAD CN2001 WR3 WJS0022-001A E-FL/RB WIRE,LOADING MOTOR

5-5

MODEL MARK

5.4 ELECTRICAL PARTS LIST

# REF No. PART No. P ART NAME, DESCRIPTION # REF No. P AR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

MAIN BOARD ASSEMBLY <03>

PW1 MAIN BOARD ASS’Y<03> includes the parts shown in the following. PW1 S-SUB BOARD ASS’Y<15>

PW1 LPA10160-07E MAIN BOARD ASSY,A

LPA10160-08E MAIN BOARD ASSY,B

LPA10160-09E MAIN BOARD ASSY,C IC1 JCP8051-MSA IC IC251 LC74793 IC IC301 LA7358 IC,C IC2201 AN3651FBP IC IC3001 HD6432199RA44F IC,A

HD6432199RA46F IC,B

HD6432199RA48F IC,C

or HD64F2199RFA44 IC,A or HD64F2199RFA46 IC,B

or HD64F2199RFA48 IC,C IC3002 IC-PST3427U-X IC IC3003 LPN0722-004A-01 IC(EEPROM),A

LPN0738-003A-01 IC(EEPROM),B LPN0752-002A-02 IC(EEPROM),C

IC6701 MSP3417D IC

or MSP3417DG3 IC

or MSP3417G IC IC7002 GP1U291Q IR DETECT UNIT

or PNA4652M00YC IR DETECT UNIT IC7102 MM1508XN IC,A,C IC7103 MM1508XN IC,A,C IC7104 MM1503XN IC,A,C

MM1507XN IC,B IC7105 MM1506XN IC Q1 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q3 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q4 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q7 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q8 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q9 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q10 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q14 2SC4081/QRS/-X TRANSISTOR,C

or 2SD1819A/QRS/-X TRANSISTOR,C or 2PC4081/R/-X TRANSISTOR,C

Q15 DTC144WU DIGI TRANSISTOR,C

or PDTC144WU DIGI TRANSISTOR,C or RN1309 DIGI TRANSISTOR,C or UN521E DIGI TRANSISTOR,C

HR-S5950EU A HR-S5955EK B HR-S5955MS C

Q16 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q21 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q24 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q34 2SA1576A/QR/-X TRANSISTOR,C

or 2PA1576/R/-X TRANSISTOR,C or 2SB1218A/QR/-X TRANSISTOR,C

Q38 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q41 DTC144WU DIGI TRANSISTOR,A,C

or PDTC144WU DIGI TRANSISTOR,A,C or RN1309 DIGI TRANSISTOR,A,C or UN521E DIGI TRANSISTOR,A,C

Q50 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR or RN2309 TRANSISTOR or UN511E DIGI TRANSISTOR

Q201 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q202 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q301 2SB1218A/QR/-X TRANSISTOR,C

or 2PA1576/R/-X TRANSISTOR,C or 2SA1576A/QR/-X TRANSISTOR,C

Q302 UN511E DIGI TRANSISTOR,C

or RN2309 TRANSISTOR,C or DTA144WU DIGI TRANSISTOR,C or PDTA144WU DIGI TRANSISTOR,C

Q2001 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2002 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q2003 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR or RN2309 TRANSISTOR or UN511E DIGI TRANSISTOR

Q2051 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2052 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q2053 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q2054 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q2055 DTC144WU DIGI TRANSISTOR

5-6

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q2201 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR or UN511E DIGI TRANSISTOR or RN2309 TRANSISTOR

Q2202 DTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR or PDTC144WU DIGI TRANSISTOR

Q2203 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q2204 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q2251 DTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR or PDTC144WU DIGI TRANSISTOR

Q2252 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR

Q2253 DTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR or UN521E DIGI TRANSISTOR or PDTC144WU DIGI TRANSISTOR

Q2254 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR or RN1302 DIGI TRANSISTOR or UN5211 DIGI TRANSISTOR

Q2255 DTC114EU DIGI TRANSISTOR,A,C

or PDTC114EU DIGI TRANSISTOR,A,C or RN1302 DIGI TRANSISTOR,A,C

or UN5211 DIGI TRANSISTOR,A,C Q3003 PTZ-NV16A PHOTO TRANSISTOR Q3004 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q3005 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q4001 UN5211 DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or DTC114EU DIGI TRANSIST OR

or RN1302 DIGI TRANSISTOR Q5101 2SK2632-CB14 POWER MOS FET

or 2SK2129-LT POWER MOS FET

or 2SK2129 POWER MOS FET

or 2SK2632 POWER MOS FET Q5102 2SD2144S/UV/-T TRANSISTOR Q5301 2SC1740S/RS/-T TRANSISTOR

or 2SC3199/YG/-T TRANSISTOR Q5303 2SC5739/QP/ TRANSISTOR

Q5304 2SD2144S/UV/-T TRANSISTOR Q5305 DTA1 14EU DIGI TRANSISTOR

or PDTA1 14EU DIGI TRANSISTOR

or RN2302 TRANSISTOR

or UN5111 DIGI TRANSISTOR

Q5306 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR or UN5211 DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR Q5307 2SD2144S/UV/-T TRANSISTOR Q6030 2SB1218A/RS/-X TRANSISTOR Q6031 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR Q6032 DTC114EU DIGI TRANSISTOR

or PDTC114EU DIGI TRANSISTOR

or UN5211 DIGI TRANSISTOR

or RN1302 DIGI TRANSISTOR Q7001 DTA143TU DIGI TRANSIST OR Q7002 DTA143TU DIGI TRANSIST OR Q7003 DTA143TU DIGI TRANSIST OR Q7004 DTA143TU DIGI TRANSIST OR Q7005 DTA143TU DIGI TRANSIST OR Q7006 DTC143TU DIGI TRANSISTOR Q7007 DTC143TU DIGI TRANSISTOR Q7008 DTC143TU DIGI TRANSISTOR Q7009 DTC143TU DIGI TRANSISTOR Q7010 DTC143TU DIGI TRANSISTOR Q7011 DTC143TU DIGI TRANSISTOR Q7012 DTC143TU DIGI TRANSISTOR Q7101 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q7102 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR Q7103 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7104 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR Q7106 2SB1218A/QR/-X TRANSISTOR,A,C

or 2SA1576A/QR/-X TRANSISTOR,A,C

or 2PA1576/R/-X TRANSISTOR,A,C Q7107 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR D201 1SS133 DIODE D2251 1SS133 DIODE

or 1SS270A DIODE D3001 LNB2301L01VI LE DIODE D3002 1SS133 DIODE

or 1SS270A DIODE D3003 RD39ES/B3/-T2 ZENER DIODE

or MTZJ39C ZENER DIODE D3004 11ES2 DIODE

or 1A3G DIODE

D3005 11ES2 DIODE

or 1A3G DIODE D5001 S1WB/A/60-4102 BRIDGE DIODE

or S1WB/A/60-X BRIDGE DIODE

or S1WB(A)60F4072X BRIDGE DIODE

5-7

# REF No. PART No. P ART NAME, DESCRIPTION # REF No. P AR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

D5101 AU01 DIODE

or ERA18-04-T2 FR DIODE or 1SR153-400-T2 FR DIODE or 10ELS4 FR DIODE

D5102 AU01 DIODE

or ERA18-04-T2 FR DIODE or 1SR153-400-T2 FR DIODE or 10ELS4 FR DIODE

D5103 1SS133 DIODE

or 1SS270A DIODE

D5105 1SS133 DIODE

or 1SS270A DIODE

D5203 AU01Z FR DIODE

or 10ELS2 FR DIODE

D5204 AU01Z FR DIODE

or 10ELS2 FR DIODE

D5207 AK04 SB DIODE

or SBO40 SB DIODE or 11EQS04 SB DIODE or 1S4 SB DIODE

D5209 AK04 SB DIODE

or SBO40 SB DIODE or 1S4 SB DIODE or 11EQS04 SB DIODE

D5210 AU01Z FR DIODE

or PG104RS FR DIODE or 10ELS2 FR DIODE or ERA18-02-T2 FR DIODE or 1SR153-400-T2 FR DIODE

D5301 MTZJ15C ZENER DIODE

or RD15ES/B3/-T2 ZENER DIODE

D5302 MTZJ11C ZENER DIODE

or RD11ES/B3/-T2 ZENER DIODE

D5303 MTZJ5.6A ZENER DIODE

or RD5.6ES/B1/-T2 ZENER DIODE

D5305 MTZJ5.6C ZENER DIODE

or RD5.6ES/B3/-T2 ZENER DIODE

D6002 HZ30-2L-T2 ZENER DIODE

or HZ30-2LTD Z DIODE (M) D6701 1SS133 DIODE R1 NRSA02J-622X MG RESISTOR 6.2kØ,1/10W R2 QRE141J-152Y RESISTOR 1.5kØ,1/4W R3 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7 NRSA02J-681X MG RESISTOR 680Ø,1/10W R21 NRSA02J-102X MG RESISTOR 1kØ,1/10W R22 NRSA02J-102X MG RESISTOR 1kØ,1/10W R23 NRSA02J-222X MG RESISTOR,C 2.2kØ,1/10W R24 NRSA02J-0R0X MG RESIST OR 0Ø,1/10W R25 NRSA02J-103X MG RESISTOR 10kØ,1/10W R26 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R27 NRSA02J-221X MG RESISTOR 220Ø,1/10W R28 NRSA02J-221X MG RESISTOR 220Ø,1/10W R29 NRSA02J-561X MG RESISTOR 560Ø,1/10W R31 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R32 NRSA02J-471X MG RESISTOR 470Ø,1/10W R35 NRSA02J-153X MG RESISTOR 15kØ,1/10W R36 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R38 NRSA02J-102X MG RESISTOR 1kØ,1/10W R40 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W

R41 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R42 NRSA02J-681X MG RESISTOR 680Ø,1/10W R46 NRSA02J-331X MG RESISTOR 330Ø,1/10W R47 NRSA02J-821X MG RESISTOR,C 820Ø,1/10W R48 NRSA02J-102X MG RESISTOR 1kØ,1/10W R51 NRSA02J-471X MG RESISTOR 470Ø,1/10W R65 NRSA02J-102X MG RESISTOR,C 1kØ,1/10W R68 NRSA02J-222X MG RESISTOR,C 2.2kØ,1/10W R77 NRSA02J-103X MG RESISTOR 10kØ,1/10W R80 NRSA02J-102X MG RESISTOR,C 1kØ,1/10W R82 NRSA02J-102X MG RESISTOR 1kØ,1/10W R88 NRSA02J-0R0X MG RESIST OR 0Ø,1/10W R90 NRSA02J-391X MG RESISTOR 390Ø,1/10W R92 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R93 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R104 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R118 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R201 NRSA02J-471X MG RESISTOR 470Ø,1/10W R202 NRSA02J-103X MG RESISTOR 10kØ,1/10W R203 NRSA02J-103X MG RESISTOR 10kØ,1/10W R204 NRSA02J-474X MG RESISTOR 470kØ,1/10W R205 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R206 NRSA02J-474X MG RESISTOR 470kØ,1/10W R207 NRSA02J-102X MG RESISTOR 1kØ,1/10W R208 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R209 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R210 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R211 NRSA02J-471X MG RESISTOR 470Ø,1/10W R212 NRSA02J-101X MG RESISTOR 100Ø,1/10W R251 NRSA02J-103X MG RESISTOR 10kØ,1/10W R252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R254 NRSA02J-103X MG RESISTOR 10kØ,1/10W R255 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R256 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R258 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R259 NRSA02J-103X MG RESISTOR 10kØ,1/10W R301 NRSA02J-273X MG RESISTOR,C 27kØ,1/10W R302 NRSA02J-124X MG RESISTOR,C 120kØ,1/10W R303 NRSA02J-273X MG RESISTOR,C 27kØ,1/10W R304 NRSA02J-682X MG RESISTOR,C 6.8kØ,1/10W R305 NRSA02J-473X MG RESISTOR,C 47kØ,1/10W R306 NRSA02J-273X MG RESISTOR,C 27kØ,1/10W R307 NRSA02J-222X MG RESISTOR,C 2.2kØ,1/10W R308 NRSA02J-222X MG RESISTOR,C 2.2kØ,1/10W R309 NRSA02J-0R0X MG RESISTOR,C 0Ø,1/10W R310 NRSA02J-223X MG RESISTOR,C 22kØ,1/10W R311 NRSA02J-472X MG RESISTOR,C 4.7kØ,1/10W R312 NRSA02J-272X MG RESISTOR,C 2.7kØ,1/10W R313 NRSA02J-223X MG RESISTOR,C 22kØ,1/10W R314 NR VA02D-243X CMF RESIST OR,C 24kØ,1/10W R315 NRSA02J-564X MG RESISTOR,C 560kØ,1/10W R316 NRSA02J-124X MG RESISTOR,C 120kØ,1/10W R329 NRSA02J-0R0X MG RESISTOR,C 0Ø,1/10W R2003 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2005 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2007 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2008 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2010 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2013 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2014 NRSA02J-224X MG RESISTOR 220kØ,1/10W R2015 NRSA02J-181X MG RESISTOR 180Ø,1/10W

5-8

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R2016 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2017 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2019 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2053 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R2054 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2055 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W R2056 NRSA02J-820X MG RESISTOR 82Ø,1/10W R2057 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2058 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2059 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2060 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2201 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2202 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2203 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2204 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2205 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2206 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2207 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2208 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2209 NRSA02J-681X MG RESISTOR 680Ø,1/10W R2210 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2211 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R2212 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R2213 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2214 NRSA02J-681X MG RESISTOR 680Ø,1/10W R2215 NRSA02J-181X MG RESISTOR 180Ø,1/10W R2216 NRSA02J-122X MG RESISTOR,A,B 1.2kØ,1/10W R2217 NRSA02J-472X MG RESISTOR,A,B 4.7kØ,1/10W R2218 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R2219 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R2220 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2223 NRSA02J-511X MG RESISTOR 510Ø,1/10W R2224 NRSA02J-511X MG RESISTOR 510Ø,1/10W R2225 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2226 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2227 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2228 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2229 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2230 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2231 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2232 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2233 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2234 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2235 NRSA02J-681X MG RESISTOR,A,C 680Ø,1/10W R2236 NRSA02J-272X MG RESISTOR,A,C 2.7kØ,1/10W R2237 NRSA02J-681X MG RESISTOR,A,C 680Ø,1/10W R2238 NRSA02J-272X MG RESISTOR,A,C 2.7kØ,1/10W R2251 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2252 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2253 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2254 QRE141J-103Y RESISTOR 10kØ,1/4W R2255 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2256 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3024 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3025 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3026 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3027 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R3028 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3030 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

R3031 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3032 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3033 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3034 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3035 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3037 QUY160-100Y IM BUS WIRE R3038 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3039 QUY160-100Y IM BUS WIRE R3040 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3041 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3042 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3043 NRSA02J-0R0X MG RESISTOR,C 0Ø,1/10W R3045 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3046 QUY160-100Y IM BUS WIRE R3047 QUY160-100Y IM BUS WIRE R3048 QUY160-100Y IM BUS WIRE R3049 QUY160-100Y IM BUS WIRE R3050 QUY160-100Y IM BUS WIRE R3051 QUY160-100Y IM BUS WIRE R3052 QUY160-100Y IM BUS WIRE R3053 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3054 QRE141J-102Y RESISTOR 1kØ,1/4W R3055 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3058 QUY160-100Y IM BUS WIRE R3059 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3060 NRSA02J-331X MG RESISTOR 330Ø,1/10W R3061 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3062 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3063 QRE141J-271Y RESISTOR 270Ø,1/4W R3064 QRE141J-271Y RESISTOR 270Ø,1/4W R3065 QRE141J-271Y RESISTOR 270Ø,1/4W R3066 QRE141J-271Y RESISTOR 270Ø,1/4W R3067 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3068 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3069 QUY160-100Y IM BUS WIRE R3070 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3071 QUY160-100Y IM BUS WIRE R3072 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3073 QUY153-050Y IM BUS WIRE R3074 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3077 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3080 NRSA02J-101X MG RESISTOR 100Ø,1/10W R3082 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3083 QRE141J-102Y RESISTOR,A,C 1kØ,1/4W

QUY160-100Y IM BUS WIRE,B R3084 QUY153-050Y IM BUS WIRE R3085 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3086 QUY160-100Y IM BUS WIRE R3087 NRSA02J-0R0X MG RESISTOR,B 0Ø,1/10W

NRSA02J-102X MG RESISTOR,A,C 1kØ,1/10W R3088 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3089 NRSA02J-0R0X MG RESISTOR,C 0Ø,1/10W R3090 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3091 QUY153-050Y IM BUS WIRE R3092 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3093 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3094 QUY160-100Y IM BUS WIRE R3095 QUY160-100Y IM BUS WIRE R3096 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3097 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3098 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

5-9

# REF No. PART No. P ART NAME, DESCRIPTION # REF No. P AR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R3099 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3100 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3101 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3102 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3205 QRE141J-181Y RESISTOR 180Ø,1/4W R3207 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3208 NRSA02J-121X MG RESISTOR 120Ø,1/10W R3209 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3210 NRSA02J-121X MG RESISTOR 120Ø,1/10W R3211 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3212 NRSA02J-474X MG RESISTOR 470kØ,1/10W R3213 NRSA02J-334X MG RESISTOR 330kØ,1/10W R3214 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3215 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3216 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3217 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3218 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3219 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3220 NRSA02J-104X MG RESISTOR 100kØ,1/10W R3221 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3222 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3223 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3224 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3225 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3229 NRSA02J-105X MG RESISTOR 1MØ,1/10W R3232 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3235 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3236 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R3244 NRSA02J-333X MG RESISTOR 33kØ,1/10W R3246 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3248 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3252 NRSA02J-153X MG RESISTOR 15kØ,1/10W R3253 QRE141J-103Y RESISTOR 10kØ,1/4W R4003 NRSA02J-561X MG RESISTOR 560Ø,1/10W R4004 NRSA02J-561X MG RESISTOR 560Ø,1/10W R4005 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R4007 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4009 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4011 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R4012 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R4015 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R4017 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5101 QRE141J-224Y RESISTOR 220kØ,1/4W R5102 QRE141J-224Y RESISTOR 220kØ,1/4W R5103 QRE141J-683Y RESISTOR 68kØ,1/4W R5104 QRG02GJ-683 OMF RESISTOR 68kØ,2W R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W R5107 QRE121J-331Y RESISTOR 330Ø,1/2W R5108 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R5109 QRE141J-561Y RESISTOR 560Ø,1/4W R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W R5111 NRSA02J-391X MG RESISTOR 390Ø,1/10W R5112 NRSA02J-221X MG RESISTOR 220Ø,1/10W R5302 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5303 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R5304 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5306 NRSA02J-181X MG RESISTOR 180Ø,1/10W R5310 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5312 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5313 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5319 NRSA02J-221X MG RESISTOR 220Ø,1/10W

R5332 QRL02DJ-391X OMF RESISTOR 390Ø,2W R6020 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6021 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6030 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6031 NRSA02J-271X MG RESISTOR 270Ø,1/10W R6032 NRSA02J-472X MG RESISTOR,A,B 4.7kØ,1/10W

NRSA02J-183X MG RESISTOR,C 18kØ,1/10W

R6033 NRSA02J-183X MG RESISTOR,C 18kØ,1/10W

NRSA02J-182X MG RESISTOR,A,B 1.8kØ,1/10W R6050 NRSA02J-101X MG RESISTOR,A,B 100Ø,1/10W R6051 QRE141J-101Y RESISTOR,A,B 100Ø,1/4W R6052 NRSA02J-101X MG RESISTOR,A,B 100Ø,1/10W R6056 NRSA02J-101X MG RESISTOR,A,B 100Ø,1/10W R6080 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6707 NRSA02J-330X MG RESISTOR 33Ø,1/10W R6708 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6709 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6710 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6711 NRSA02J-474X MG RESISTOR 470kØ,1/10W R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6713 NRSA02J-123X MG RESISTOR 12kØ,1/10W R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6715 NRSA02J-123X MG RESISTOR 12kØ,1/10W R6716 NRSA02J-470X MG RESISTOR 47Ø,1/10W R6719 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6720 QRE141J-562Y RESISTOR 5.6kØ,1/4W R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R7001 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7002 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7003 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7004 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7005 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7006 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7007 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7015 QRE141J-102Y RESISTOR 1kØ,1/4W R7020 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7021 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R7022 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R7023 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R7024 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R7025 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7030 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7031 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R7032 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R7033 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R7101 NRSA02J-473X MG RESISTOR 47kØ,1/10W R7102 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7103 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7105 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7107 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7108 NRSA02J-750X MG RESISTOR,A,C 75Ø,1/10W R7110 NRSA02J-221X MG RESISTOR,A,C 220Ø,1/10W R7111 NRSA02J-221X MG RESISTOR,A,C 220Ø,1/10W R7112 QRE141J-331Y RESISTOR 330Ø,1/4W R7113 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7114 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7116 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7117 QRE141J-750Y RESISTOR 75Ø,1/4W R7119 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7120 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7122 NQL402M-4R7X COIL 4.7µH

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R7124 NQL402M-4R7X COIL 4.7µH R7131 NRSA02J-101X MG RESISTOR,A,C 100Ø,1/10W R7133 QRE141J-471Y RESISTOR,A,C 470Ø,1/4W R7134 NRSA02J-471X MG RESISTOR,A,C 470Ø,1/10W R7138 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7139 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7140 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7141 NRSA02J-820X MG RESISTOR 82Ø,1/10W R7142 NRSA02J-0R0X MG RESISTOR,A,C 0Ø,1/10W R7143 NRSA02J-0R0X MG RESISTOR,A,C 0Ø,1/10W R7144 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7145 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R7146 NRSA02J-393X MG RESISTOR 39kØ,1/10W R7147 NRSA02J-223X MG RESISTOR 22kØ,1/10W R7148 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7160 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7161 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7162 NRSA02J-331X MG RESISTOR 330Ø,1/10W R7163 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7184 NRSA02J-105X MG RESISTOR,A,C 1MØ,1/10W R7185 NRSA02J-105X MG RESISTOR,B 1MØ,1/10W R7186 NRSA02J-105X MG RESISTOR,B 1MØ,1/10W VR2251 QVP0039-223Z TRIM RESISTOR,REC FM ADJ B5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B28 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B61 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B62 NRSA02J-0R0X MG RESISTOR,A,B 0Ø,1/10W B203 QRE141J-0R0Y RESISTOR 0Ø,1/4W B301 NRSA02J-0R0X MG RESISTOR,C 0Ø,1/10W B2051 QUY153-050Y IM BUS WIRE B3002 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3003 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5001 QUY160-100Y IM BUS WIRE B5002 QUY160-100Y IM BUS WIRE B6701 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7116 NRSA02J-0R0X MG RESISTOR,B 0Ø,1/10W B7118 QUY153-050Y IM BUS WIRE,B C1 NCB21HK-103X CAPACITOR 0.01µF ,50V C2 NCB21HK-103X CAPACITOR 0.01µF ,50V C3 NCB21HK-103X CAPACITOR 0.01µF ,50V C4 NCB21HK-103X CAPACITOR 0.01µF ,50V C5 QEKC0JM-476 E CAPACITOR 47µF ,6.3V C6 QDYB1CM-103Y CAPACIT OR 0.01µF,16V C7 NCB21HK-102X CAPACITOR 0.001µF,50V C8 NCB21EK-104X CAP ACITOR 0.1µF ,25V C9 QEKJ1HM-105 E CAPACITOR 1µF ,50V C10 NDC21HJ-151X CAP ACITOR 150pF ,50V C11 NCB21EK-104X CAP ACITOR 0.1µF ,25V C12 NDC21HJ-8R0X CAP ACITOR 8pF ,50V C14 NCB21EK-104X CAP ACITOR 0.1µF ,25V C15 NCB21HK-103X CAPACITOR 0.01µF ,50V C16 NCB21EK-104X CAP ACITOR 0.1µF ,25V C17 QEKJ1HM-335 E CAPACITOR 3.3µF ,50V C18 QEKJ1HM-105 E CAPACITOR 1µF ,50V C19 QEKJ1HM-225 E CAPACITOR 2.2µF ,50V C20 NCB21AK-105X CAP ACITOR 1µF,10V C21 NCB21EK-104X CAP ACITOR 0.1µF ,25V C22 QEKJ0JM-476 E CAPACIT OR 47µF,6.3V C23 NCB21EK-104X CAP ACITOR 0.1µF ,25V C24 NCB21EK-104X CAP ACITOR 0.1µF ,25V C25 NDC21HJ-6R0X CAP ACITOR 6pF ,50V

C27 NCB21EK-223X CAP ACITOR 0.022µF,25V C28 QEKJ1HM-335 E CAPACITOR 3.3µF ,50V C29 NCB21EK-333X CAP ACITOR 0.033µF,25V C30 QEKJ1HM-474 E CAPACITOR 0.47µF ,50V C31 QEKJ0JM-476 E CAPACIT OR 47µF,6.3V C32 NCB21EK-104X CAP ACITOR 0.1µF ,25V C33 QEKJ1HM-225 E CAPACITOR 2.2µF ,50V C34 NCB21CK-224X CAPACITOR 0.22µF ,16V C35 NCB21HK-103X CAPACITOR 0.01µF ,50V C36 QERF1EM-475 E CAPACITOR 4.7µF ,25V C37 QEKJ1HM-105 E CAPACITOR 1µF ,50V C38 QEKJ0JM-476 E CAPACIT OR 47µF,6.3V C39 NCB21HK-103X CAPACITOR 0.01µF ,50V C40 QEKJ1EM-106 E CAPACITOR 10µF,25V C53 NDC21HJ-101X CAP ACITOR 100pF ,50V C59 NCB21HK-103X CAPACITOR 0.01µF ,50V C60 QEKJ0JM-476 E CAPACIT OR 47µF,6.3V C61 NCB21HK-103X CAPACITOR 0.01µF ,50V C63 NCB21EK-104X CAP ACITOR 0.1µF ,25V C64 NDC21HJ-220X CAP ACITOR 22pF ,50V C65 QEKJ1HM-105 E CAPACITOR 1µF ,50V C69 NCB21HK-103X CAPACITOR 0.01µF ,50V C70 NCB21HK-103X CAPACITOR 0.01µF ,50V C72 NDC21HJ-470X CAP ACITOR 47pF ,50V C73 NDC21HJ-120X CAP ACITOR 12pF ,50V C78 NCB21HK-103X CAPACITOR,C 0.01µF ,50V C79 NDC21HJ-390X CAPACIT OR,C 39pF ,50V C80 NCB21HK-103X CAPACITOR 0.01µF ,50V C84 NDC21HJ-470X CAP ACITOR 47pF ,50V C94 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C103 NCB21HK-103X CAPACITOR 0.01µF,50V C106 NCB21HK-821X CAPACITOR 820pF,50V C108 NDC21HJ-680X CAPACIT OR 68pF,50V C109 NCB21CK-224X CAPACITOR 0.22µF,16V C110 NDC21HJ-820X CAPACIT OR 82pF,50V C114 NDC21HJ-181X CAPACITOR,A,C 180pF,50V C201 NDC21HJ-220X CAPACIT OR 22pF,50V C202 QERF1EM-475 E CAPACITOR 4.7µF,25V C203 NCB21HK-102X CAP ACITOR 0.001µF,50V C204 NCB21HK-681X CAP ACITOR 680pF ,50V C205 QEQF1EM-475 NP E CAPACITOR 4.7µF,25V C207 QEPF1EM-475 NP E CAPACITOR 4.7µF,25V C209 QEKJ0JM-476 E CAPACITOR 47µF ,6.3V C210 NCB21HK-103X CAP ACITOR 0.01µF,50V C212 NCB21HK-103X CAP ACITOR 0.01µF,50V C213 NDC21HJ-100X CAPACIT OR 10pF,50V C251 NCB21HK-103X CAP ACITOR 0.01µF,50V C252 QEKJ1EM-475 E CAPACITOR 4.7µF ,25V C253 NCB21EK-563X CAPACITOR 0.056µF,25V C254 QEPF1HM-105 NP E CAP ACIT OR 1µF,50V C255 QEKJ0JM-227 E CAPACITOR 220µF ,6.3V C256 NCB21CK-224X CAP ACITOR 0.22µF,16V C257 QEKJ1HM-105 E CAP ACITOR 1µF ,50V C258 NCB21CK-224X CAP ACITOR 0.22µF,16V C259 QEKJ0JM-227 E CAPACITOR 220µF ,6.3V C301 NDC21HJ-151X CAPACITOR,C 150pF,50V C302 QEKJ1HM-225 E CAP ACITOR,C 2.2µF ,50V C303 NCB21HK-682X CAPACITOR,C 0.0068µF ,50V C304 NCB21HK-682X CAPACITOR,C 0.0068µF ,50V C305 NCB21HK-103X CAPACITOR,C 0.01µF,50V C307 NDC21HJ-151X CAPACITOR,C 150pF,50V

5-11

# REF No. PART No. P ART NAME, DESCRIPTION # REF No. P AR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C308 NCB21HK-103X CAPACITOR,C 0.01µF,50V C309 NCB21EK-104X CAPACIT OR,C 0.1µF ,25V C310 NCB21HK-103X CAPACITOR,C 0.01µF,50V C311 NCB21HK-103X CAPACITOR,C 0.01µF,50V C312 NCB21HK-102X CAPACITOR,C 0.001µF,50V C313 QERF1HM-474 E CAPACITOR,C 0.47µF ,50V C315 QERF1HM-105 E CAPACITOR,C 1µF,50V C316 NCB21HK-103X CAPACITOR,C 0.01µF,50V C317 NCB21HK-681X CAPACITOR,C 680pF,50V C318 NCB21EK-223X CAPACIT OR,C 0.022µF ,25V C319 QERF1HM-105 E CAPACITOR,C 1µF,50V C320 NCB21HK-103X CAPACITOR,C 0.01µF,50V C321 NDC21HG-301X CAPACITOR,C 300pF ,50V C322 NCB21CK-474X CAPACITOR,C 0.47µF,16V C323 QEKJ0JM-476 E CAPACITOR,C 47µF ,6.3V C2001 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2002 QEKJ1HM-105 E CAPACITOR 1µF ,50V C2003 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C2005 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2006 NCB21HK-123X CAPACITOR 0.012µF,50V C2007 QEKJ1CM-226 E CAPACITOR 22µF,16V C2008 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2009 NCB21HK-102X CAPACITOR 0.001µF,50V C2010 NCB21HK-152X CAPACITOR 0.0015µF,50V C2011 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2012 QEKC1HM-475 E CAPACIT OR 4.7µF,50V C2013 NDC21HJ-180X CAPACITOR 18pF ,50V C2016 NDC21HJ-101X CAPACITOR 100pF ,50V C2051 NCB21HK-331X CAPACITOR 330pF ,50V C2053 NCB21HK-472X CAPACITOR 0.0047µF,50V C2054 NCB21EK-223X CAP ACITOR 0.022µF,25V C2055 QEKJ1EM-106 E CAPACITOR 10µF,25V C2061 QFLC1HJ-823Z F CAPACIT OR 0.082µF ,50V C2201 QEKJ1EM-106 E CAPACITOR 10µF,25V C2202 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2203 QEKJ1HM-475 E CAPACITOR 4.7µF,50V C2204 QEKJ0JM-336 E CAP ACITOR 33µF ,6.3V C2205 QEKJ1EM-106 E CAPACITOR 10µF,25V C2206 QEKJ1EM-106 E CAPACITOR 10µF,25V C2207 NCB21HK-153X CAPACITOR 0.015µF,50V C2208 NCB21HK-153X CAPACITOR 0.015µF,50V C2209 QERF1CM-106 E CAPACITOR 10µF,16V C2210 QERF1CM-106 E CAPACITOR 10µF,16V C2211 QEKJ0JM-336 E CAP ACITOR 33µF ,6.3V C2212 QERF0JM-476 E CAPACITOR 47µF,6.3V C2213 NCB21EK-104X CAP ACITOR 0.1µF ,25V C2214 QEKJ1EM-106 E CAPACITOR 10µF,25V C2215 QEKJ1EM-106 E CAPACITOR 10µF,25V C2216 QEKJ1CM-476 E CAPACITOR 47µF,16V C2217 NCB21EK-104X CAP ACITOR 0.1µF ,25V C2218 QEKJ1EM-106 E CAPACITOR,A,B 10µF ,25V C2219 QEKJ1CM-226 E CAPACITOR,A,B 22µF,16V C2220 QEKJ1EM-106 E CAPACITOR 10µF,25V C2221 NCB21EK-223X CAP ACITOR 0.022µF,25V C2222 NCB21HK-103X CAPACITOR 0.01µF ,50V C2223 NCB21EK-473X CAP ACITOR 0.047µF,25V C2224 NCB21EK-473X CAP ACITOR 0.047µF,25V C2225 NCB21AK-105X CAP ACITOR 1µF ,10V C2226 NCB21AK-105X CAP ACITOR 1µF ,10V C2227 QERF1CM-106 E CAPACITOR 10µF,16V C2230 QEKJ1EM-106 E CAPACITOR,A,C 10µF,25V

C2231 QEKJ1EM-106 E CAPACITOR,A,C 10µF,25V C2251 NCB21HK-103X CAPACITOR 0.01µF ,50V C2252 NCB21HK-103X CAPACITOR 0.01µF ,50V C2253 NCB21HK-103X CAPACITOR 0.01µF ,50V C2254 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C2255 NCB21HK-103X CAPACITOR 0.01µF ,50V C2256 NCB21HK-103X CAPACITOR 0.01µF ,50V C2257 NCB21HK-103X CAPACITOR 0.01µF ,50V C2258 NDC21HJ-181X CAP ACITOR,A,C 180pF ,50V C2259 QEKJ1HM-334 E CAPACITOR 0.33µF ,50V C3004 NCB21EK-473X CAP ACITOR 0.047µF,25V C3011 QETL0JM-338 E CAP ACITOR 3300µF,6.3V C3012 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C3013 NCB21HK-103X CAPACITOR 0.01µF ,50V C3014 QERF0JM-476 E CAPACITOR 47µF,6.3V C3016 NCB21EK-473X CAP ACITOR 0.047µF,25V C3022 NCB21EK-473X CAP ACITOR 0.047µF,25V C3024 NDC21HJ-120X CAPACITOR 12pF ,50V C3025 QA T3725-300Z TRIM CAPACITOR,TIMER CLOCK,A C3030 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C3031 NCB21EK-473X CAP ACITOR 0.047µF,25V C3033 NCB21EK-473X CAP ACITOR 0.047µF,25V C3036 NDC21HJ-180X CAPACITOR 18pF ,50V C3037 NDC21HJ-120X CAPACITOR 12pF ,50V C3041 NDC21HJ-180X CAP ACITOR,B,C 18pF,50V C3045 NDC21HJ-101X CAPACITOR 100pF ,50V C3048 NCB21HK-103X CAPACITOR 0.01µF ,50V C3050 NCF21EZ-104X CAP ACITOR 0.1µF ,25V C3051 NCB21EK-104X CAP ACITOR 0.1µF ,25V C3052 QEKJ1EM-106 E CAPACITOR 10µF,25V C3054 NCB21HK-222X CAPACITOR 0.0022µF,50V C3056 NCB21EK-104X CAP ACITOR 0.1µF ,25V C3057 NCB21HK-103X CAPACITOR 0.01µF ,50V C3071 QEKJ1CM-336 E CAPACITOR 33µF,16V C3073 QDYB1CM-103Y CAP ACITOR 0.01µF,16V C3074 NCB21HK-103X CAPACITOR 0.01µF ,50V C3075 NCB21HK-103X CAPACITOR 0.01µF ,50V C3076 NCB21HK-103X CAPACITOR 0.01µF ,50V C4002 NCB21HK-103X CAPACITOR 0.01µF ,50V C4004 QERF1CM-226 E CAPACITOR 22µF,16V C4005 NCB21HK-222X CAPACITOR 0.0022µF,50V C4006 QERF0JM-476 E CAPACITOR 47µF,6.3V C4008 QEQF1HM-105 NP E CAPACIT OR 1µF ,50V C4009 NCB21HK-563X CAPACITOR 0.056µF,50V C4010 NCB21EK-223X CAP ACIT OR 0.022µF,25V C4011 NCB21EK-104X CAP ACIT OR 0.1µF ,25V C4012 QERF1HM-105 E CAPACITOR 1µF ,50V C4014 NDC21HJ-101X CAPACITOR 100pF ,50V C4015 NCB21HK-102X CAPACITOR 0.001µF,50V C4016 NDC21HJ-101X CAPACITOR 100pF ,50V C4031 QEKJ1CM-336 E CAPACITOR 33µF,16V

C5001 QFZ9072-473 F CAPACITOR 0.047µF ,250V

C5004 QCZ9071-222 CAPACITOR 0.0022µF,250V C5006 QEZ0375-686 E CAPACITOR 68µF,400V C5101 QCZ0212-472 CAPACIT OR 0.0047µF,1kV C5102 QCZ0302-330Z CAP ACITOR 33pF,1kV C5104 QEKJ1HM-105 E CAPACITOR 1µF ,50V C5105 QFN31HJ-153 F CAPACITOR 0.015µF,50V C5106 QCBB1HJ-271 CAP ACITOR 270pF ,50V C5107 QFV91HJ-104 F CAPACIT OR,B,C 0.1µF ,50V C5202 QETN1CM-108 E CAPACITOR 1000µF,16V

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C5203 QEMT1AM-128 E CAPACIT OR 1200µF,10V C5204 QETJ2AM-475 E CAPACITOR 4.7µF ,100V C5206 QEKJ1CM-476 E CAPACITOR 47µF,16V C5207 QEKJ1CM-107 E CAPACITOR 100µF,16V C5301 QEKJ1CM-107 E CAPACITOR 100µF,16V C5303 QEKJ1CM-107 E CAPACITOR 100µF,16V C5305 QFVF1HJ-274Z F CAPACIT OR 0.27µF,50V C5307 QEKJ1CM-476 E CAPACITOR 47µF,16V C5308 QEKJ1CM-107 E CAPACITOR 100µF,16V C6008 NCB21HK-123X CAP ACITOR,C 0.012µF ,50V C6013 NCB21HK-103X CAPACITOR 0.01µF ,50V C6016 NDC21HJ-101X CAP ACITOR,A,B 100pF,50V C6027 NDC21HJ-151X CAP ACITOR,A,B 150pF,50V C6032 NCB21EK-473X CAPACITOR,A,B 0.047µF ,25V C6037 QEKJ1HM-106 E CAPACITOR 10µF,50V C6056 NDC21HJ-470X CAP ACITOR,A,B 47pF ,50V C6501 QEKJ1EM-106 E CAPACITOR 10µF,25V C6502 NCB21HK-103X CAPACITOR 0.01µF ,50V C6704 NCB21HK-103X CAPACITOR 0.01µF ,50V C6707 NDC21HJ-470X CAPACITOR 47pF ,50V C6708 NDC21HJ-8R0X CAPACIT OR 8pF,50V C6709 NDC21HJ-2R0X CAPACIT OR 2pF,50V C6713 NCF21CZ-224X CAPACITOR 0.22µF,16V C6714 NCB21HK-222X CAPACITOR 0.0022µF,50V C6715 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6716 NCB21HK-222X CAPACITOR 0.0022µF,50V C6717 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6719 QEKJ1EM-106 E CAPACITOR 10µF,25V C6720 QEKJ1EM-106 E CAPACITOR 10µF,25V C6721 NCB21HK-103X CAPACITOR 0.01µF ,50V C6723 NCB21HK-103X CAPACITOR 0.01µF ,50V C6724 QEKJ1HM-225 E CAPACITOR,C 2.2µF ,50V C7011 QEKJ0JM-227 E CAP ACITOR 220µF ,6.3V C7103 NCB21HK-681X CAP ACITOR,A,C 680pF ,50V C7104 NCB21HK-681X CAP ACITOR,A,C 680pF ,50V C7117 QETN0JM-477 E CAPACITOR 470µF ,6.3V C7119 NCB21HK-681X CAPACITOR 680pF ,50V C7120 NCB21HK-681X CAPACITOR 680pF ,50V C7128 QEKJ1CM-107 E CAPACITOR 100µF,16V C7129 NCB21HK-103X CAPACITOR 0.01µF ,50V C7131 QETJ0JM-477 E CAPACITOR,A,C 470µF,6.3V C7134 QEKJ1HM-225 E CAPACITOR,B 2.2µF,50V

QEKJ1HM-474 E CAPACITOR,A,C 0.47µF,50V

C7135 QEKJ1HM-225 E CAPACITOR,B 2.2µF,50V

QEKJ1HM-474 E CAPACITOR,A,C 0.47µF,50V C7136 QEKJ1HM-474 E CAPACITOR 0.47µF ,50V C7137 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C7138 NCB21HK-103X CAPACITOR 0.01µF ,50V C7139 QEKJ1HM-106 E CAPACITOR 10µF,50V C7140 NCB21EK-104X CAP ACITOR 0.1µF ,25V C7141 NCB21HK-103X CAPACITOR 0.01µF ,50V C7143 NDC21HJ-330X CAP ACITOR,A,C 33pF,50V C7144 NDC21HJ-680X CAP ACITOR,A,C 68pF,50V C7153 NDC21HJ-330X CAPACITOR 33pF ,50V C7155 NDC21HJ-680X CAP ACITOR,A,C 68pF,50V C7156 QEKJ1HM-474 E CAPACITOR,A,C 0.47µF,50V C7157 QEPF1HM-474 NP E CAPACIT OR,A,C 0.47µF,50V C7158 QEKJ1HM-474 E CAPACITOR,A,C 0.47µF,50V C7159 QEKJ1HM-225 E CAPACITOR,A,C 2.2µF,50V C7160 NDC21HJ-330X CAP ACITOR,A,C 33pF,50V C7164 NCB21HK-681X CAPACITOR 680pF ,50V

C7166 NCB21HK-681X CAPACITOR 680pF ,50V C7168 NCB21HK-681X CAPACITOR 680pF ,50V C7169 NCB21HK-681X CAPACITOR 680pF ,50V C7170 NCB21HK-821X CAPACITOR 820pF ,50V C7171 NCB21HK-821X CAPACITOR 820pF ,50V C7182 NCB21HK-681X CAPACITOR 680pF ,50V C7183 NCB21HK-681X CAPACITOR 680pF ,50V C7197 NCB21EK-104X CAP ACITOR 0.1µF ,25V L1 QQL29BJ-100Z COIL 10µH L2 QQL071J-121Y COIL 120µH L3 QQL29BJ-100Z COIL 10µH L4 QQL29BJ-100Z COIL 10µH L5 QQR0521-012Z NOISE FILTER L12 QQR0967-001 COIL 12µH L13 QQL071J-330Y COIL 33µH L14 QQL071J-101Y COIL,C 100µH L15 QQL29BJ-100Z COIL 10µH L18 QQL071J-220Y COIL 22µH L19 QQL071J-120Y COIL 12µH L20 QUY153-050Y IM BUS WIRE L24 QQL071J-270Y COIL 27µH L27 QQL071J-330Y COIL 33µH L28 QQL071J-680Y COIL 68µH L201 QQL071J-150Y COIL 15µH L202 QUY153-050Y IM BUS WIRE L203 QQL071J-330Y COIL 33µH L204 QQL071J-151Y COIL 150µH L251 QUY153-050Y IM BUS WIRE L252 QUY153-050Y IM BUS WIRE L301 QQL29BJ-100Z COIL,C 10µH L302 QQL29BJ-6R8Z COIL,C 6.8µH L303 QQL231J-270Y COIL,C 27µH L2001 QUY153-050Y IM BUS WIRE L2201 QUY153-050Y IM BUS WIRE L2251 QQL29BJ-100Z COIL 10µH L2252 QQL29BJ-151Z COIL,A,C 150µH L3001 QQL231J-100Y COIL 10µH L4001 QUY153-050Y IM BUS WIRE L5201 PELN1184 COIL 33µH L5202 PELN1184 COIL 33µH L6001 QQL29BK-1R0Z COIL,A,B 1.0µH

QQL29BJ-100Z COIL,C 10µH L6002 QQL29BJ-100Z COIL 10µH L6501 QQL29BJ-3R3Z COIL 3.3µH L6502 QUY153-050Y IM BUS WIRE L7101 QQL231J-R22Y COIL 0.22µH L7102 QQL231J-R22Y COIL 0.22µH L7105 QQL231J-1R0Y COIL 1.0µH L7107 QUY153-050Y IM BUS WIRE L7109 QQL231J-1R0Y COIL,A,C 1.0µH L7113 QQL231J-1R0Y COIL,A,C 1.0µH X1 QAX0576-001Z CRYSTAL RESONATOR X3001 QAX0444-001 CRYST AL RESONA TOR,B,C

QAX0445-001 CRYST AL RESONA T OR,A X3002 QAX0527-001 CRYSTAL RESONA TOR X6701 QAX0443-001 CRYSTAL RESONA TOR S3001 QSW0602-004 PUSH SWITCH,REC.SAFETY S3002 QSW0602-004 PUSH SWITCH,S.CASS S7001 QSW0456-002Z TACT SWITCH S7002 QSW0456-002Z TACT SWITCH S7004 QSW0456-002Z TACT SWITCH

5-13

REF No. P ART No. PART NAME, DESCRIPTION #

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

S7006 QSW0456-002Z TACT SWITCH S7008 QSW0456-002Z TACT SWITCH S7010 QSW0456-002Z TACT SWITCH S7012 QSW0456-002Z TACT SWITCH S7014 QSW0456-002Z TACT SWITCH S7015 QSW0456-002Z TACT SWITCH S7016 QSW0456-002Z TACT SWITCH K2001 NQL103K-R10X COIL K2002 NQL103K-R10X COIL K2003 NQR0403-003X FERRATE BEADS K2004 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W K2251 NQR0007-002X FERRATE BEADS K2252 NQR0007-002X FERRATE BEADS K2253 NQR0007-002X FERRATE BEADS K5101 QQR0678-001Z FERRATE BEADS K5102 QUY153-050Y IM BUS WIRE K6701 NQR0200-003X FERRATE BEADS K6702 NQR0200-003X FERRATE BEADS K6703 NQR0200-003X FERRATE BEADS K6704 NQR0200-003X FERRATE BEADS K6705 NQR0200-003X FERRATE BEADS K6706 NQR0200-003X FERRATE BEADS K6707 NQR0200-003X FERRATE BEADS,C PC3001 RPI-304J IC(PHOTO SENSOR) PC3002 RPI-304J IC(PHOTO SENSOR)

PC5101 PS2561L1-1/L/ IC(PHOTO COUPLE) T2051 PELN0832 OSC TRANSFORMER

T5001 QQS0083-001 SW TRANSF TU6001 QAU0261-002 TUNER,A,B

QAU0266-001 TUNER,C SD1 LP21105-001A SHIELD CASE DI7001 LTG-Y2K16M-02J LE DIODE ET1 PQ21623-2-5 EARTH PLATE(RF) HS1 LP40090-001A HEAT SINK,Q5101 JS3001 QSW0954-002 ROT ARY ENCODER

TB1 LP20317-011B TERMINAL BOARD(PAL) J7101 PEMC1104 RGB21PIN SOCKET J7102 PEMC1104 RGB21PIN SOCKET J7103 QNN0292-003 PIN JACK J7105 QNN0381-002 PIN JACK OT1 QYTDST3006Z SCREW,Q5101 FC5001 QNG0006-001Z FUSE CLIP ,F5001 FC5002 QNG0006-001Z FUSE CLIP ,F5001

LF5002 QQR0978-001 LINE FILTER CN1 QGF1201C2-09 FPC CONNECTOR,(1-9)DRUM CN2001QGF1207C1-06FPC CONNECTOR,(1-6)A/C HEAD CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD CN3001 QGB2032M4-12 CONNECTOR,(1-12)CAPSTAN MOTOR

CN5001 QGA7901C3-02 CONNECTOR,(1-2)AC IN

CP3001 QMFZ050-1R5X-E FUSE T1.5A

CP4001 QMFZ050-1R5X-E FUSE T1.5A

F5001 QMF51E2-2R0J1 FUSE T2.0A,AC250V

******************************

A/C HEAD BOARD ASSEMBLY <12>

PW1 LPA10158-01A1 A/C HEAD BOARD ASSY

REF No. PART No. PART NAME, DESCRIPTION

******************************

S-SUB BOARD ASSEMBLY <15>

PW1 LPA10164-01D S-SUB BOARD ASSY,A,B

LPA10164-02C S-SUB BOARD ASSY,C IC501 JCP8038 IC IC502 VC2076DP IC IC581 MM1503XN IC Q581 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q582 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q583 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q584 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR or UN521E DIGI TRANSISTOR or RN1309 DIGI TRANSISTOR

Q585 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q586 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR R502 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W R504 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R505 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R506 NRSA02J-391X MG RESISTOR 390Ø,1/10W R507 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R508 NRSA02J-151X MG RESISTOR 150Ø,1/10W R509 NRSA02J-162X MG RESISTOR 1.6kØ,1/10W R510 NRVA02D-102X CMF RESISTOR 1kØ,1/10W R511 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R512 NRVA02D-102X CMF RESISTOR 1kØ,1/10W R513 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W R514 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W R515 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W R516 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R517 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R525 NRSA02J-125X MG RESISTOR 1.2MØ,1/10W R526 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R527 NRSA02J-332X MG RESISTOR,A,B 3.3kØ,1/10W R535 NRSA02J-101X MG RESISTOR 100Ø,1/10W R536 NRSA02J-101X MG RESISTOR 100Ø,1/10W R537 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R538 NRSA02J-101X MG RESISTOR 100Ø,1/10W R580 NRSA02J-102X MG RESISTOR 1kØ,1/10W R581 NRSA02J-331X MG RESISTOR 330Ø,1/10W R582 NRSA02J-821X MG RESISTOR 820Ø,1/10W R583 NRSA02J-221X MG RESISTOR 220Ø,1/10W R584 NRSA02J-272X MG RESISTOR,A,B 2.7kØ,1/10W

NRSA02J-332X MG RESISTOR,C 3.3kØ,1/10W R585 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W R586 NRSA02J-102X MG RESISTOR 1kØ,1/10W R587 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R588 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W

5-14

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R589 NRSA02J-821X MG RESISTOR 820Ø,1/10W R590 NRSA02J-331X MG RESISTOR 330Ø,1/10W R591 NRSA02J-681X MG RESISTOR 680Ø,1/10W R592 NRSA02J-102X MG RESISTOR 1kØ,1/10W R593 NRSA02J-102X MG RESISTOR 1kØ,1/10W R594 NRSA02J-103X MG RESISTOR 10kØ,1/10W R595 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R596 NRSA02J-102X MG RESISTOR 1kØ,1/10W R597 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R598 NRSA02J-105X MG RESISTOR 1MØ,1/10W R599 NRSA02J-102X MG RESISTOR 1kØ,1/10W C501 QEKJ1HM-225 E CAP ACITOR 2.2µF ,50V C502 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C503 QEKJ1HM-225 E CAP ACITOR 2.2µF ,50V C504 NCB21EK-104X CAPACITOR 0.1µF ,25V C505 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C506 NCB21HK-103X CAP ACITOR 0.01µF,50V C507 QEKJ0JM-476 E CAPACITOR 47µF ,6.3V C508 QEKJ1HM-474 E CAP ACITOR 0.47µF ,50V C509 QEKJ1EM-106 E CAPACITOR 10µF,25V C510 QEKJ0JM-476 E CAPACITOR 47µF ,6.3V C511 NCB21HK-103X CAP ACITOR 0.01µF,50V C512 NCB21HK-103X CAP ACITOR 0.01µF,50V C513 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C514 NCB21HK-103X CAP ACITOR 0.01µF,50V C515 NCB21HK-103X CAP ACITOR 0.01µF,50V C516 NCB21HK-103X CAP ACITOR 0.01µF,50V C518 NCB21EK-104X CAPACITOR 0.1µF ,25V C519 QEKJ1HM-225 E CAP ACITOR 2.2µF ,50V C520 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C521 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C522 QEKJ1HM-225 E CAP ACITOR 2.2µF ,50V C523 QEKJ1HM-225 E CAP ACITOR 2.2µF ,50V C524 NDC21HG-301X CAP ACITOR 300pF ,50V C525 NDC21HG-301X CAP ACITOR 300pF ,50V C526 NDC21HJ-101X CAPACIT OR 100pF,50V C527 NDC21HJ-181X CAPACIT OR 180pF,50V C528 NDC21HG-271X CAP ACITOR 270pF ,50V C529 NDC21HG-820X CAP ACITOR 82pF ,50V C530 NDC21HG-221X CAP ACITOR 220pF ,50V C531 NDC21HG-301X CAP ACITOR 300pF ,50V C532 NDC21HG-301X CAP ACITOR 300pF ,50V C533 NCB21HK-103X CAP ACITOR 0.01µF,50V C534 QEKJ0JM-476 E CAPACITOR 47µF ,6.3V C535 NCB21HK-103X CAP ACITOR 0.01µF,50V C536 NCB21HK-103X CAP ACITOR 0.01µF,50V C537 NCB21HK-103X CAP ACITOR 0.01µF,50V C538 NDC21HJ-680X CAPACIT OR 68pF,50V C557 QEKJ1HM-105 E CAP ACITOR 1µF ,50V C559 NCB21HK-103X CAP ACITOR 0.01µF,50V C560 QEKJ1HM-105 E CAP ACITOR 1µF ,50V C562 QEKJ1HM-105 E CAP ACITOR,C 1µF,50V C563 NCB21HK-103X CAPACITOR,A,B 0.01µF,50V C564 NCB21HK-103X CAPACITOR,C 0.01µF,50V C566 NCB21HK-103X CAPACITOR,C 0.01µF,50V C568 NCB21HK-103X CAP ACITOR 0.01µF,50V C569 NCB21HK-103X CAP ACITOR 0.01µF,50V C570 NCB21HK-103X CAP ACITOR 0.01µF,50V C571 NCB21HK-103X CAP ACITOR 0.01µF,50V C572 NDC21HJ-680X CAPACIT OR 68pF,50V C573 NDC21HJ-680X CAPACIT OR 68pF,50V

C575 NDC21HJ-330X CAPACIT OR 33pF,50V C576 NCB21HK-103X CAP ACITOR 0.01µF,50V C577 NDC21HJ-680X CAPACIT OR 68pF,50V C579 NDC21HJ-820X CAPACIT OR 82pF,50V C580 QEKJ1CM-226 E CAP ACITOR 22µF,16V C581 QEKJ1CM-107 E CAP ACITOR 100µF ,16V C582 NCB21HK-103X CAP ACITOR 0.01µF,50V C584 NDC21HJ-390X CAPACIT OR 39pF,50V C585 NDC21HJ-101X CAPACIT OR 100pF,50V C586 NDC21HJ-181X CAPACIT OR 180pF,50V C587 NDC21HJ-390X CAPACIT OR 39pF,50V C588 NCB21HK-103X CAP ACITOR 0.01µF,50V C589 NCB21HK-103X CAP ACITOR 0.01µF,50V C590 NCB21HK-103X CAP ACITOR 0.01µF,50V C591 NDC21HJ-121X CAPACIT OR 120pF,50V C592 NDC21HJ-220X CAPACIT OR 22pF,50V C593 NDC21HJ-820X CAPACIT OR 82pF,50V C594 NDC21HJ-101X CAPACIT OR 100pF,50V C595 NDC21HJ-220X CAPACIT OR 22pF,50V C596 QEKJ1HM-475 E CAP ACITOR 4.7µF ,50V C597 QEKJ1HM-474 E CAP ACITOR 0.47µF ,50V C598 NCB21HK-103X CAP ACITOR 0.01µF,50V C599 QEKJ1HM-474 E CAP ACITOR 0.47µF ,50V L501 QQL29BJ-100Z COIL 10µH L503 QQL29BJ-100Z COIL 10µH L504 QQL29BJ-100Z COIL 10µH L505 QQL071J-1R0Y COIL 1.0µH L581 QQL29BJ-100Z COIL 10µH L582 QQL071J-390Y COIL 39µH L583 QQL071J-120Y COIL 12µH L584 QQL071J-101Y COIL 100µH L585 QQL071J-330Y COIL 33µH L586 QQL071J-470Y COIL 47µH L587 QQL071J-560Y COIL 56µH L588 QQL071J-101Y COIL 100µH L589 QQL071J-560Y COIL 56µH L590 QQL071J-120Y COIL 12µH BK1 LP40077-001A BRACKET(PWB) SD1 LP40954-001A SHIELD PLATE CN511 QGG2503K2-30 HEADER PIN CN513 QGF1208F1-11 FPC CONNECTOR,(1-11)S/P CONV.,C

******************************

LOADING MOTOR BOARD ASSEMBLY <55>

PW2 LPA10158-01A2 LODING MOTOR BOARD ASSY

******************************

S/P CONVERTER BOARD ASSEMBLY [HR-S5955MS] <87>

PW1 LPA10144-03A S/P CONVERTER BOARD ASSY IC1601 BA7046F-XE IC IC1602 74HC132D IC(DIGITAL) IC1603 74HC4538D IC IC1604 74HC74D IC IC1605 TDA8395 IC

5-15

# REF No. PART No. P ART NAME, DESCRIPTION # REF No. P AR T No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

IC1606 TDA4665T IC IC1607 TDA8501T/N1-X IC Q1601 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q1604 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q1605 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1606 2SC1740S/QRS/-T TRANSISTOR Q1607 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1608 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR Q1609 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1610 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR Q1611 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1612 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1613 2SC4083/NP/-X TRANSISTOR Q1614 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1615 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1616 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1617 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR D1601 1SS133 DIODE R1601 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R1605 NDC21HJ-331X CAPACITOR 330pF,50V R1606 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R1608 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R1609 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1610 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1611 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R1612 NRSA02J-103X MG RESISTOR 10kØ,1/10W R1615 NRSA02J-331X MG RESISTOR 330Ø,1/10W R1616 NRSA02J-474X MG RESISTOR 470kØ,1/10W R1617 NRSA02J-474X MG RESISTOR 470kØ,1/10W R1618 NRSA02J-103X MG RESISTOR 10kØ,1/10W R1619 NRSA02J-134X MG RESISTOR 130kØ,1/10W R1620 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R1621 QRE141J-103Y RESISTOR 10kØ,1/4W R1622 QRE141J-103Y RESISTOR 10kØ,1/4W R1623 NRSA02J-123X MG RESISTOR 12kØ,1/10W

R1624 NRSA02J-124X MG RESISTOR 120kØ,1/10W R1631 NRSA02J-561X MG RESISTOR 560Ø,1/10W R1632 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R1633 NRSA02J-223X MG RESISTOR 22kØ,1/10W R1635 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R1636 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1637 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1638 NRSA02J-101X MG RESISTOR 100Ø,1/10W R1639 NRSA02J-331X MG RESISTOR 330Ø,1/10W R1640 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R1641 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1642 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1643 NRSA02J-101X MG RESISTOR 100Ø,1/10W R1644 NRSA02J-331X MG RESISTOR 330Ø,1/10W R1645 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R1646 NRSA02J-104X MG RESISTOR 100kØ,1/10W R1647 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R1648 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1651 NRSA02J-123X MG RESISTOR 12kØ,1/10W R1652 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1653 NRSA02J-184X MG RESISTOR 180kØ,1/10W R1654 NRSA02J-821X MG RESISTOR 820Ø,1/10W R1655 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1656 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R1657 NRSA02J-561X MG RESISTOR 560Ø,1/10W R1658 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1659 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1660 NRSA02J-273X MG RESISTOR 27kØ,1/10W R1661 NRSA02J-333X MG RESISTOR 33kØ,1/10W VR1601 QVP0039-471Z TRIM RESISTOR VR1602 QVP0039-471Z TRIM RESISTOR VR1603 QVP0039-104Z TRIM RESISTOR B1601 NRSA02J-101X MG RESISTOR 100Ø,1/10W B1602 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B1603 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C1601 QEKJ1CM-476 E CAPACITOR 47µF,16V C1602 NCB21HK-103X CAPACITOR 0.01µF ,50V C1605 QEKJ1HM-105 E CAPACITOR 1µF ,50V C1606 NCB21HK-102X CAPACITOR 0.001µF,50V C1607 NCB21HK-103X CAPACITOR 0.01µF ,50V C1608 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C1609 NCB21HK-222X CAPACITOR 0.0022µF,50V C1610 QEKJ1HM-105 E CAPACITOR 1µF ,50V C1611 NDC21HJ-101X CAPACITOR 100pF ,50V C1612 NCB21EK-104X CAP ACITOR 0.1µF ,25V C1613 NCB21EK-104X CAP ACITOR 0.1µF ,25V C1614 NDC21HJ-471X CAPACITOR 470pF ,50V C1615 NDC21HJ-561X CAPACITOR 560pF ,50V C1616 NCB21EK-104X CAP ACITOR 0.1µF ,25V C1631 QEKJ1CM-476 E CAPACITOR 47µF,16V C1632 QEKJ1CM-476 E CAPACITOR 47µF,16V C1633 NCB21HK-103X CAPACITOR 0.01µF ,50V C1634 NDC21HJ-101X CAPACITOR 100pF ,50V C1635 NCB21EK-104X CAP ACITOR 0.1µF ,25V C1636 NCB21CK-224X CAPACITOR 0.22µF ,16V C1637 NCB21HK-103X CAPACITOR 0.01µF ,50V C1638 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C1639 NCB21HK-103X CAPACITOR 0.01µF ,50V C1640 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C1641 NCB21HK-103X CAPACITOR 0.01µF ,50V C1642 NCB21HK-103X CAPACITOR 0.01µF ,50V

5-16

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C1643 NCB21HK-103X CAPACITOR 0.01µF ,50V C1644 NCB21HK-103X CAPACITOR 0.01µF ,50V C1645 QEKJ1HM-105 E CAPACITOR 1µF ,50V C1646 QEKJ1HM-105 E CAPACITOR 1µF ,50V C1647 NCB21CK-224X CAPACITOR 0.22µF ,16V C1648 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C1649 NCB21HK-103X CAPACITOR 0.01µF ,50V C1650 NCB21CK-224X CAPACITOR 0.22µF ,16V C1651 NCB21EK-223X CAP ACITOR 0.022µF,25V C1652 NDC21HJ-120X CAPACITOR 12pF ,50V C1653 NCB21CK-224X CAPACITOR 0.22µF ,16V C1654 NCB21HK-103X CAPACITOR 0.01µF ,50V C1655 QEKJ0JM-476 E CAP ACITOR 47µF ,6.3V C1656 NCB21HK-103X CAPACITOR 0.01µF ,50V L1601 QQL29BJ-100Z COIL 10µH L1602 QQL29BJ-100Z COIL 10µH L1603 QQL29BJ-100Z COIL 10µH L1604 QQL29BJ-100Z COIL 10µH X1601 QAX0613-001Z CRYSTAL RESONA TOR OT1 QYSDST3006Z SCREW FL1601 QQR1187-001 EQUALIZER FL1602 QQR1187-001 EQUALIZER BK1 LP30950-001A BRACKET 1 BK2 LP30951-001A BRACKET(2) CN1601 QGF1208F1-11 FPC CONNECTOR,(1-11)S-SUB

(VP)-V15S0 E. & O. E. No.82922

5-17

JVC HR-S5950EU, HR-S5955EK, HR-S5955MS Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual

PARTS LIST

P ACKING AND ACCESSOR Y ASSEMBLY <M1>

5.2 FINAL ASSEMBLY <M2>

5.3 MECHANISM ASSEMBL Y <M4>

5.4 ELECTRICAL PARTS LIST

MAIN BOARD ASSEMBLY <03>

A/C HEAD BOARD ASSEMBLY <12>

S-SUB BOARD ASSEMBLY <15>

LOADING MOTOR BOARD ASSEMBLY <55>

S/P CONVERTER BOARD ASSEMBLY [HR-S5955MS] <87>
