JVC HR-S3900U/U, HR-S5900U/U(C) Parts List

SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the ! symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSORY ASSEMBLY <M1>

The instruction manual to be provided with this product will differ according to the destination.

307

312

ADHESIVE TAPE

308

313

306

302

FINAL ASSY <M2>

306A

316

317
310
320

319

311

303

302

SPEC OF BARCODE

301

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

PACKING AND ACCESSORY ASSEMBLY <M1>

301 LP30899-001B PACKING CASE
302 LP30718-001B CUSHION ASSY
303 PQM30021-93 POLY BAG
306 LP20303-015A REMOTE CONTROLLER
306A LP40225-002A COVER(BATTERY)
307 – BATTERY,X2(“AA” TYPE)

SPEC OF BARCODE

308 QPC02202230P POLY BAG

!

310 LPT0503-001A INST.BOOK(EN)

!

311 QPC02503530P POLY BAG
312 PEAC0294-04 RF CABLE
313 QAM0004-002 S CABLE
316 BT-52004-1
317 BT-51020-2 REGIST.CARD,S3900U/S5900U
319 BT-20071B SER.NET CARD,S3900U(C)/S5900U(C)
320 LP30666-002B SHEET(COUPON)

LPT0503-002A INST.BOOK(FR),S3900U(C)/S5900U(C)

WARRANTY CARD,S3900U(C),S5900U(C)

5-1

5.2 FINAL ASSEMBLY

<M2>

BEWARE OF BOGUS PARTS

Parts that do not meet specifications may
cause trouble in regard to safety and per­formance. We recommend that genuine JVC
parts be used.

509

503

504

527

528

510

505F

505E

516

508

507

525

507

506

WR1

A

502

503

505

2D DIGITAL
BOARD ASSY

510

B

WR2

<05>

515

MECHANISM
ASSY <M4>

DEMOD BOARD
ASSY <14>

526

530

519

D

R.PAUSE BOARD
ASSY<91>

ET1

524

C

(Incl <03>)

OT1

C.BOX BOARD

A

B

ASSY<92>

CD1
(Incl <03>)

MAIN BOARD
ASSY <03>

S JACK BOARD
ASSY <36>
(HR-S5900U)

529

5-2

501C

516

D

WR4

531

D

501A

501D

501B

501

ADV.JOG
BOARD ASSY
<38>

514

C

WR3

532

D

513

SPEC OF BARCODE

511

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

FINAL ASSEMBLY <M2>

!

501 LP10289-062C FRONT PANEL ASSY,S5900U/U(C)

!

501A LP20868-005A CASSETTE DOOR,S5900U/U(C)

501B PQ46448 TORSION SPRING
501C LP20869-092A DISPLAY WINDOW,S5900U/U(C)

501D LP21014-001C ORNAMENT

!

502 LP10013-021D TOP COVER
503 QYTDSF3010M SCREW,X2 TOP COVER(SIDE)
504 QYTDSF3010M SCREW,TOP COVER(REAR)
505 LP20981-010A DRUM SUB ASSY,S3900U/U(C)

505E LP40323-001A CONTACT
505F LP30004-014A COMPRESSION SPRING
506 PDZ0179-1-4 ROTOR ASSY
507 QYSPSP3006Z SCREW,X2

!

508 QAR0169-002 STATOR ASSY
509 QYSPSPH2606Z SCREW,X2
510 QYTDST2610Z SCREW,X3 DRUM

!

511 LP10108-012E BOTTOM CHASSIS
513 LP30312-001B BRACKET(CHASSIS)
514 QYTDSF3010Z SCREW,X2
515 QYTDSF4012Z SCREW,MECHA
516 QYTDSF3010Z SCREW,X2 MECHA
519 LP40407-001A KNOB ASSY
524 LP40253-001B STOPPER
525 PQ40413 SPECIAL SCREW,MECHA
526 LP30002-088B SPACER,SHIELD FRAME
527 QYWWS267505Z WASHER
528 LP30017-021A SPACER
529 LP30954-001A KNOB ASSY
530 QYTDSF3010Z SCREW,MAIN
531 QYTDSF2608Z SCREW,X2 S JACK
532 QYTDSF2608Z SCREW,X2 JOG
WR1 QUQ212-0518CG FFC WIRE,DRUM CN3002
WR2 WJT0005-002A E-CARD WIRE,A/C HEAD CN2001
WR3 QUQ112-0914CG FFC WIRE,FRONT CN7001
WR4 WJT0026-001A

LP10289-063C FRONT PANEL ASSY,S3900U/U(C)

LP20868-035A CASSETTE DOOR,S3900U/U(C)

LP20869-093A DISPLAY WINDOW,S3900U/U(C)

LP20981-012A DRUM SUB ASSY,S5900U/U(C)

E-CARD WIRE,S(FSA) CN7103,S5900U/U(C)

5-3

5.3 MECHANISM ASSEMBLY

124

128

143

120

74

104

89

73

88

142

134

78

135

<M4>

122

75

AA

130

AA

76

141

72

AA

139

121

132

AA

10

137

7

143

107

BB

138

139

129

127

140

43

44

42

123

105

51

40

106

13

5

BB

21

6

AA

13

11

4

AA

AA

86

12107

26

AA

3

AA

49

AA

58

39

55

53

AA

46

A/C HEAD
BOARD ASSY <12>

57

52

AA

54

82

LOADING MOTOR
BOARD ASSY <55>

83

AA

59

61

60

62

85

91

AA

81

AA

34

37

35

103

36

38

69

Classifi­cation drawing

Part No.

102

32

AA

AA

80

31

108

109

90

Symbol in

Grease KYODO-SH-P AA

Oil COSMO-HV56 BB

1

AA

111

113

1

AA

112

151

116

115

117

118

63

AA

97

AA

93

95

94

92

20

19

22

99
96

BB

100

15

110

84

24

18

16

87

25

27

70

71

67

AA

23

64

65

AA

AA

114

119

66

68

NOTE:The section marked in AA and BB

indicate lubrication and greasing areas.

5-4

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

74 LP40109-003D TENSION BRAKE ASSY

******************************

MECHANISM ASSEMBLY <M4>

1 LP20821-006A MAIN DECK ASSY
3 LP30492-002B GUIDE POLE GUARD
4 NAH0001-001 FULL ERASE HEAD
5 LP40098-001B GUIDE POLE(SUPPLY)
6 QYTDST2608Z SCREW,FE HEAD
7 LP40637-002A TENSION STUD BASE ASSY
10 QYTDST2606Z SCREW
11 LP30409-002C UV CATCHER 2
12 LP30409-002C UV CATCHER 2
13 QYTPST2606Z SCREW,X2
15 LP30223-003C LOADING ARM GEAR SHAFT
16 QYTDST2606Z SCREW
18 LP30224-001B LOADING ARM GEAR(SUPPLY)
19 LP40099-001A TORSION ARM
20 LP40100-001A PIN
21 LP40101-006A POLE BASE ASSY(SUPPLY)
22 QYSPSTG2606Z SCREW
23 LP40103-002B LOADING ARM GEAR(TAKE UP)
24 LP40099-001A TORSION ARM
25 LP40100-001A PIN
26 LP40104-006A POLE BASE ASSY(TAKE UP)
27 QYSPSTG2606Z SCREW
31 LP20233-004B ROTARY ENCODER GUIDE
32 QYTPST2606Z SCREW
34 LP30226-004E CONTROL PLATE GUIDE
35 QYTPST2605Z SCREW
36 LP30249-003B TAKE UP LEVER
37 LP30003-006A TENSION SPRING
38 LP40119-002A TAKE UP HEAD
39 LP20234-004B LID GUIDE
40 QYTDST2606Z SCREW,X2
42 LP40105-003A PINCH ROLLER ARM ASSY
43 LP40753-001A PINCH ROLLER SHEET3
44 LP40148-002A TORSION SPRING
46 LP40149-001C PRESS LEVER ASSY
49 LP40106-007A GUIDE ARM ASSY
51 LP40134-002A TENSION SPRING
52 QAH0058-001 AC HEAD
53 LP30228-001A HEAD BASE
54 LP30004-013A COMPRESSION SPRING,X3
55 LP40236-001A COMPRESSION SPRING
57 LP40213-002B SPECIAL SCREW,X3
58 QYTDST2608Z SCREW,X2
59 QAR0023-001 LOADING MOTOR
60 PQ43546-1-2 MOTOR PULLEY
61 LP30230-001B MOTOR GUIDE
62 QYTPSP3003Z SCREW,X2
63 LP30005-003A BELT,LOADING MOTOR
64 LP20791-002D CONTROL CAM
65 PQM30017-24 SLIT WASHER
66 LP40120-001A WORM GEAR
67 LP40107-002A LINK LEVER ASSY
68 PQM30017-24 SLIT WASHER
69 LP10201-003E CONTROL PLATE
70 LP40379-001B CONTROL BRACKET(1)
71 QYTDSF2608M SCREW
72 LP40108-002A TENSION ARM ASSY
73 LP30003-010A TENSION SPRING

75 PQ46302-1-3 ADJUST PIN
76 LP30232-002A TENSION ARM BEARING
78 LP40532-008B MAIN BRAKE ASSY (SUPPLY)
80 LP40111-011A MAIN BRAKE ASSY (TAKE UP)
81 LP30003-026A TENSION SPRING
82 LP40112-001F SUB BRAKE ASSY(TAKE UP)
83 LP40357-002A TENSION SPRING
84 LP40461-001A CAPSTAN BRAKE ASSY
85 QAR0087-005 CAPSTAN MOTOR
86 QYTDSF2606M SCREW,X3
87 LP30005-007A BELT,CAPSTAN MOTOR
88 LP40114-012A IDLER ARM ASSY
89 LP40599-001A WASHER
90 LP40593-001A CLUTCH UNIT 3
91 LP30002-097A SPACER,CAPSTAN MOTOR
92 PQM30017-47 SLIT WASHER
93 LP30696-002A CLUTCH GEAR 4
94 LP30697-003A COUPLING GEAR
95 LP40554-002A COMPRESSION SPRING
96 LP40442-001A DIRECT GEAR
97 LP30017-019A SPACER
99 LP40483-002A COMPRESSION SPRING
100 LP30016-001A SLIT WASHER
102 LP40484-001J CHANGE LEVER ASSY
103 LP40512-002B COMPRESSION SPRING
104 LP30236-002C IDLER LEVER
105 LP20237-001B REEL DISK (SUPPLY)
106 LP20238-001B REEL DISK (TAKE UP)
107 LP30017-015A SPACER,X2
108 QSW0554-003 ROTARY ENCODER
109 QYTPST2620Z SCREW
110 LP30237-002B CASSETTE GEAR
111 LP30239-002G LIMIT GEAR(1)
112 LP30240-002G LIMIT GEAR(2)
113 LP40136-001E TORSION SPRING
114 LP30242-002A RELAY GEAR
115 LP30339-002E OPENER GUIDE
116 LP40545-001A TORSION SPRING
117 LP40214-001B C.H.BRACKET
118 PQM30017-47 SLIT WASHER,X2
119 LP30243-001D DRIVE GEAR
120 LP20240-001G DRIVE ARM
121 LP40137-001A TORSION SPRING
122 LP10081-002L SIDE HOLDER(L)
123 LP10082-002M SIDE HOLDER(R)
124 LP30255-006A LOCK LEVER(L)
127 LP30256-001H LOCK LEVER(R)
128 LP40168-003A TORSION SPRING(L)
129 LP40218-001B TORSION SPRING(R)
130 LP30257-001G CASSETTE HOLDER
132 LP30244-002G GUIDE RAIL
134 LP30245-002F REC SAFETY LEVER
135 LP30003-004A TENSION SPRING
137 LP20578-001C TOP GUIDE
138 LP30500-001C HOLD PLATE
139 LP40450-003A PAD,X2
140 LP30003-025B TENSION SPRING
141 LP30003-024A TENSION SPRING
142 LP40481-003A ROLLER CAM ASSY
143 LP30019-014A PAD,X2
151 LP20324-003B DOOR OPENER

5-5

5.4 ELECTRICAL PARTS LIST

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

MAIN BOARD ASSEMBLY <03>

PW1 LPA10134-03D1 MAIN BOARD ASSY,S5900U/U(C)

LPA10134-05D1 MAIN BOARD ASSY,S3900U/U(C)

IC1 JCP8050-NSA IC

or JCP8050-MSA IC
IC501 JCP8038 IC
IC502 VC2076DP IC
IC3001 MN101D02HWD IC
IC3002 BA6956AN IC
IC3003 IC-PST3440U-X IC
IC3004 S-24C04BFJ-X IC

or X24C04S IC

or 24LC04B/SN-X IC

or AT24C04N-10SC-X IC

or BR24C04F-W-X IC
IC5301 L5431 IC

or MM1431AT IC
IC7001 PT6312LQ IC

or UPD16312GB/H/ IC
IC7003 GP1U291Q IR DETECT UNIT

or PIC-28143LJ IR DETECT UNIT

or PIC-37143LJ IR DETECT UNIT

or PNA4652M00YC IR DETECT UNIT
Q1 2SC4081/S/-X TRANSISTOR,S3900U/U(C)
Q2 2SC4081/S/-X TRANSISTOR,S3900U/U(C)
Q3 2SC4081/S/-X TRANSISTOR,S3900U/U(C)
Q4 2SC4081/S/-X TRANSISTOR,S3900U/U(C)
Q7 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
Q8 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
Q9 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR
Q12 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR
Q17 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR
Q21 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR
Q33 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or UN521E TRANSISTOR

or RN1309 TRANSISTOR
Q38 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
Q401 2SA1576A/QR/-X TRANSISTOR,S5900U/U(C)
Q402 2SA1576A/QR/-X TRANSISTOR,S5900U/U(C)
Q403 DTC144WU TRANSISTOR,S5900U/U(C)

or PDTC144WU TRANSISTOR,S5900U/U(C)

or RN1309 TRANSISTOR,S5900U/U(C)

or UN521E TRANSISTOR,S5900U/U(C)
Q404 DTC144WU TRANSISTOR,S5900U/U(C)

or PDTC144WU TRANSISTOR,S5900U/U(C)

or RN1309 TRANSISTOR,S5900U/U(C)

or UN521E TRANSISTOR,S5900U/U(C)
Q405 2SA1576A/QR/-X TRANSISTOR,S5900U/U(C)

Q901 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q903 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q904 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q2001 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR

Q2002 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
or 2SD1819A/QRS/-X TRANSISTOR

Q2003 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR
or RN2309 TRANSISTOR
or UN511E TRANSISTOR

Q2051 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
or 2SD1819A/QRS/-X TRANSISTOR

Q2052 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR
or 2PA1576/R/-X TRANSISTOR

Q2053 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR

Q2054 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR
or 2SB1218A/QR/-X TRANSISTOR

Q2055 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR
or RN1309 TRANSISTOR
or UN521E TRANSISTOR

Q2061 2SC4081/QRS/-X TRANSISTOR,S5900U/U(C)

or 2PC4081/R/-X TRANSISTOR,S5900U/U(C)
or 2SD1819A/QRS/-X TRANSISTOR,S5900U/U(C)

Q2062 2SA1576A/QR/-X TRANSISTOR,S5900U/U(C)

or 2PA1576/R/-X TRANSISTOR,S5900U/U(C)
or 2SB1218A/QR/-X TRANSISTOR,S5900U/U(C)

Q2063 DTC144WU TRANSISTOR,S5900U/U(C)

or PDTC144WU TRANSISTOR,S5900U/U(C)
or RN1309 TRANSISTOR,S5900U/U(C)
or UN521E TRANSISTOR,S5900U/U(C)

Q2251 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR
or RN2309 TRANSISTOR
or UN511E TRANSISTOR

Q3002 PTZ-NV16 PHOTO TRANSISTO

or PTZ-NV16A PHOTO TRANSISTO

Q3005 UN521K TRANSISTOR

or DTC114WU TRANSISTOR

Q4001 UN5211 TRANSISTOR

or DTC114EU TRANSISTOR
or RN1302 TRANSISTOR
or PDTC114EU TRANSISTOR

Q4002 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR
or 2PC4081/R/-X TRANSISTOR

Q5101 2SK2043-CB14 FE TRANSISTOR

or 2SK2043 FE TRANSISTOR
or 2SK2324-LT POWER MOS FET

5-6

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or 2SK2324 POWER MOS FET
Q5102 2SD2144S/UV/-T TRANSISTOR
Q5302 2SD2375/QP/ TRANSISTOR
Q5303 2SD1819A/RS/-X TRANSISTOR

or 2SC4081/RS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
Q5304 2SD2144S/UV/-T TRANSISTOR
Q5305 DTA114EU TRANSISTOR

or PDTA114EU TRANSISTOR

or RN2302 TRANSISTOR

or UN5111 TRANSISTOR
Q5306 DTC114EU TRANSISTOR

or PDTC114EU TRANSISTOR

or UN5211 TRANSISTOR

or RN1302 TRANSISTOR
Q6030 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR
Q6551 2SC1740S/QRS/-T TRANSISTOR

or 2SC3199/YG/-T TRANSISTOR

or KTC3199/YG/-T TRANSISTOR
Q7201 2SA720/RS/-T TRANSISTOR
D1 1SS133 DIODE

or 1SS270A DIODE
D2 1SS133 DIODE

or 1SS270A DIODE
D12 1SS270A DIODE

or 1SS133 DIODE
D2202 MTZJ9.1B ZENER DIODE
D3001 LNB2301L01VI LE DIODE
D3002 1SS133 DIODE

or 1SS270A DIODE
D3005 11ES2 DIODE
D3007 1SS355 DIODE
D3013 DA204U DIODE
D5001 S1WB/A/60-4102 BRIDGE DIODE

or S1WB/A/60-X BRIDGE DIODE

or S1WB(A)60F4072X BRIDGE DIODE
D5101 AU01 FR DIODE

or ERA18-04-T2 FR DIODE

or 10ELS4 FR DIODE

or 1SR153-400-T2 FR DIODE
D5102 AU01 FR DIODE

or ERA18-04-T2 FR DIODE

or 1SR153-400-T2 FR DIODE

or 10ELS4 FR DIODE
D5103 1SS133 DIODE

or 1SS270A DIODE
D5201 AU01Z FR DIODE

or 10ELS2 FR DIODE
D5203 AU01Z FR DIODE

or 10ELS2 FR DIODE
D5204 AU01Z FR DIODE

or 10ELS2 FR DIODE
D5206 FMB-24 BARRIER DIODE

or FSQ05A04B SB DIODE

or SB640FCT SB DIODE

or YG801C04 SB DIODE

or SF5SC4 SB DIODE
D5210 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE

or 10ELS2 FR DIODE
or 1SR153-400-T2 FR DIODE
or PG104RS FR DIODE

D5211 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE
or PG104RS FR DIODE
or 10ELS2 FR DIODE
or 1SR153-400-T2 FR DIODE

D5301 MTZJ15C ZENER DIODE

or RD15ES/B3/-T2 ZENER DIODE
D5302 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
D5303 RD5.1JS/B2/-T2 ZENER DIODE

or MA4051N/M/-T2 ZENER DIODE
D5304 1SS355 DIODE
D5307 QUY153-050Y IM BUS WIRE
D5309 MTZJ27C ZENER DIODE

or RD27ES/B3/-T2 ZENER DIODE
D5310 1SS133 DIODE

or 1SS270A DIODE
D6002 HZ30-2L-T2 ZENER DIODE

or HZ30-2LTD Z DIODE (M)
D6551 MTZJ10B ZENER DIODE
D7001 RD9.1ES/B2/-T2 ZENER DIODE

or UZ9.1BSB ZENER DIODE

or MTZJ9.1B ZENER DIODE
D7003 1SS133 DIODE

or 1SS270A DIODE
D7004 1SS133 DIODE

or 1SS270A DIODE
D7005 1SS133 DIODE

or 1SS270A DIODE
D7006 1SS133 DIODE

or 1SS270A DIODE
D7008 SLR-325MC-T LE DIODE
D7009 SLR-325VC-T LE DIODE
R1 NRVA02D-622X CMF RESISTOR 6.2kØ,1/10W
R2 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W
R3 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R6 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R9 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R12 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R21 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R22 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R25 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R26 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W
R27 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R28 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R29 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R30 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R31 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R32 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R33 NDC21HJ-7R0X CAPACITOR 7pF,50V
R34 NDC21HJ-270X CAPACITOR 27pF,50V
R36 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W
R39 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R42 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R44 NRSA02J-223X MG RESISTOR 22kØ,1/10W
R45 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R46 NRSA02J-471X MG RESISTOR 470Ø,1/10W

5-7

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R48 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R68 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R77 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R90 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R92 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R93 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R104 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R118 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R120 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R201 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R202 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R401 NRSA02J-221X MG RESISTOR,S5900U/U(C) 220Ø,1/10W
R402 NRSA02J-102X MG RESISTOR,S5900U/U(C) 1kØ,1/10W
R403 NRSA02J-391X MG RESISTOR,S5900U/U(C) 390Ø,1/10W
R404 NRSA02J-473X MG RESISTOR,S5900U/U(C) 47kØ,1/10W
R405 NRSA02J-683X MG RESISTOR,S5900U/U(C) 68kØ,1/10W
R407 NRSA02J-472X MG RESISTOR,S5900U/U(C)4.7kØ,1/10W
R408 NRSA02J-473X MG RESISTOR,S5900U/U(C) 47kØ,1/10W
R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R504 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R505 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W
R506 NRSA02J-391X MG RESISTOR 390Ø,1/10W
R507 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R508 NRSA02J-151X MG RESISTOR 150Ø,1/10W
R509 NRSA02J-162X MG RESISTOR 1.6kØ,1/10W
R510 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R511 NRVA02D-471X CMF RESISTOR 470Ø,1/10W
R512 NRVA02D-102X CMF RESISTOR 1kØ,1/10W
R513 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W
R514 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R515 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R901 NRSA02J-820X MG RESISTOR 82Ø,1/10W
R902 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W
R904 QRE123J-331X RESISTOR 330Ø,1/2W
R905 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R911 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R912 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R914 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R915 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R916 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R917 NRSA02J-750X MG RESISTOR 75Ø,1/10W
R919 QRE123J-331X RESISTOR 330Ø,1/2W
R920 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R921 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R922 QRE123J-331X RESISTOR 330Ø,1/2W
R924 NRSA02J-750X MG RESISTOR,S5900U/U(C) 75Ø,1/10W
R925 NRSA02J-750X MG RESISTOR,S5900U/U(C) 75Ø,1/10W
R2001 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R2003 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R2004 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R2005 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R2006 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R2007 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R2009 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R2010 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R2013 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W
R2014 NRSA02J-224X MG RESISTOR 220kØ,1/10W
R2015 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R2016 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R2017 NRSA02J-153X MG RESISTOR 15kØ,1/10W
R2018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W

R2019 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R2053 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R2054 NRSA02J-123X MG RESISTOR,S3900U/U(C) 12kØ,1/10W

NRSA02J-153X MG RESISTOR,S5900U/U(C) 15kØ,1/10W
R2055 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W
R2056 QRE141J-820Y RESISTOR,S3900U/U(C) 82Ø,1/4W

QRE141J-101Y RESISTOR,S5900U/U(C) 100Ø,1/4W
R2057 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R2058 NRSA02J-183X MG RESISTOR 18kØ,1/10W
R2059 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R2060 NRSA02J-183X MG RESISTOR 18kØ,1/10W
R2061 NRSA02J-273X MG RESISTOR,S5900U/U(C) 27kØ,1/10W
R2062 NRSA02J-3R3X MG RESISTOR,S5900U/U(C) 3.3Ø,1/10W
R2063 NRSA02J-151X MG RESISTOR,S5900U/U(C) 150Ø,1/10W
R2064 NRSA02J-473X MG RESISTOR,S5900U/U(C) 47kØ,1/10W
R2065 NRSA02J-183X MG RESISTOR,S5900U/U(C) 18kØ,1/10W
R2201 NRSA02J-680X MG RESISTOR 68Ø,1/10W
R2204 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R2205 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R2206 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R2207 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R2217 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R2218 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R2219 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R2223 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R2224 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R2232 NRSA02J-680X MG RESISTOR 68Ø,1/10W
R2251 QRE141J-102Y RESISTOR 1kØ,1/4W
R3003 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3005 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3008 QUY160-100Y IM BUS WIRE,S5900U/U(C)
R3013 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R3017 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3018 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3021 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3022 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3028 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3035 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3043 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R3058 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3060 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3078 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3088 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3090 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3094 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3095 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R3096 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3097 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3098 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3099 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3201 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R3206 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3207 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3208 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3209 QRE141J-181Y RESISTOR 180Ø,1/4W
R3211 NRSA02J-183X MG RESISTOR 18kØ,1/10W
R3212 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R3213 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R3214 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R3215 NRSA02J-273X MG RESISTOR 27kØ,1/10W
R3216 QRE141J-474Y RESISTOR 470kØ,1/4W

5-8

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R3217 NRSA02J-334X MG RESISTOR 330kØ,1/10W
R3218 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3219 QRE141J-103Y RESISTOR 10kØ,1/4W
R3220 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3221 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R3222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R3223 NRSA02J-105X MG RESISTOR 1MØ,1/10W
R3224 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R3226 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R3227 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R3236 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3237 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3238 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3240 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3241 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3242 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R3243 QRE141J-103Y RESISTOR 10kØ,1/4W
R3244 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R4001 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R4002 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R4003 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R4006 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R4010 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R4011 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R4012 NRSA02J-153X MG RESISTOR 15kØ,1/10W
R4018 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R4019 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4020 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4021 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R4024 QRE141J-103Y RESISTOR 10kØ,1/4W

!

R5001 QRZ9046-475Z RESISTOR 4.7MØ,1/2W
R5101 QRE141J-224Y RESISTOR 220kØ,1/4W
R5102 QRE141J-224Y RESISTOR 220kØ,1/4W
R5103 QRE141J-683Y RESISTOR 68kØ,1/4W
R5104 QRG02GJ-683 OMF RESISTOR 68kØ,2W
R5106 QRT01DJ-R39X MF RESISTOR 0.39Ø,1W
R5107 QRE121J-331Y RESISTOR 330Ø,1/2W
R5108 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R5109 NRSA02J-681X MG RESISTOR 680Ø,1/10W
R5110 NRSA02J-224X MG RESISTOR 220kØ,1/10W
R5301 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5302 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5303 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W
R5304 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5305 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5306 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5308 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5309 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5310 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R5311 NRSA02J-473X MG RESISTOR 47kØ,1/10W
R5312 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W
R5313 NRVA02D-362X CMF RESISTOR 3.6kØ,1/10W
R5314 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R5316 NRVA02D-822X CMF RESISTOR 8.2kØ,1/10W

!

R5318 QRZ9005-221X FUSI RESISTOR 220Ø,1/4W
R5326 QUY153-050Y IM BUS WIRE
R5332 QRE141J-222Y RESISTOR 2.2kØ,1/4W
R6020 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6021 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6030 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R6031 NRSA02J-101X MG RESISTOR 100Ø,1/10W

R6032 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R6050 QRE141J-330Y RESISTOR 33Ø,1/4W
R6051 QRE141J-102Y RESISTOR 1kØ,1/4W
R6508 QUY153-050Y IM BUS WIRE
R6510 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R6551 NRSA02J-271X MG RESISTOR 270Ø,1/10W
R6552 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R7001 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7002 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7003 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7004 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7005 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R7006 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R7007 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7008 NRSA02J-563X MG RESISTOR 56kØ,1/10W
R7009 QRE141J-103Y RESISTOR 10kØ,1/4W
R7010 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R7011 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R7012 QRE141J-333Y RESISTOR 33kØ,1/4W
R7013 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R7014 NRSA02J-333X MG RESISTOR 33kØ,1/10W
R7015 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R7016 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R7017 NRSA02J-331X MG RESISTOR 330Ø,1/10W
R7018 NRSA02J-331X MG RESISTOR 330Ø,1/10W
R7022 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R7026 QUY160-100Y IM BUS WIRE
R7035 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R7202 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R7203 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R7204 QRE123J-100X RESISTOR 10Ø,1/2W
B3 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B6 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B11 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B33 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B43 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B2051 QUY153-050Y IM BUS WIRE,S3900U/U(C)
B3001 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B5301 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B5303 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B5304 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B5308 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B6020 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B6550 QUY160-080Y IM BUS WIRE
B6551 QUY160-080Y IM BUS WIRE
B7002 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7003 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7004 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7005 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7006 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7007 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7013 QUY160-060Y IM BUS WIRE
B7020 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7022 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C1 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V

NCF21CZ-105X CAPACITOR,S5900U/U(C) 1µF,16V

C2 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V

NCF21CZ-105X CAPACITOR,S5900U/U(C) 1µF,16V

C3 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V

NCF21CZ-105X CAPACITOR,S5900U/U(C) 1µF,16V

5-9

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C4 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V

NCF21CZ-105X CAPACITOR,S5900U/U(C) 1µF,16V
C5 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7 NDC21HJ-151X CAPACITOR 150pF,50V
C8 NCB21EK-104X CAPACITOR 0.1µF,25V
C9 NCB21HK-103X CAPACITOR 0.01µF,50V
C10 NDC21HG-151X CAPACITOR 150pF,50V
C11 NCB21EK-104X CAPACITOR 0.1µF,25V
C12 NDC21HJ-7R0X CAPACITOR 7pF,50V
C14 NCB21EK-104X CAPACITOR 0.1µF,25V
C15 NCB21HK-103X CAPACITOR 0.01µF,50V
C16 NCB21EK-104X CAPACITOR 0.1µF,25V
C17 QEKJ1HM-335 E CAPACITOR 3.3µF,50V
C19 QEKJ0JM-336 E CAPACITOR 33µF,6.3V
C20 QEKJ1HM-105 E CAPACITOR 1µF,50V
C21 NCB21EK-104X CAPACITOR 0.1µF,25V
C22 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C23 NCB21HK-103X CAPACITOR 0.01µF,50V
C24 NCB21EK-104X CAPACITOR 0.1µF,25V
C25 NDC21HJ-4R0X CAPACITOR 4pF,50V
C26 NCB21HK-103X CAPACITOR 0.01µF,50V
C27 NCB21HK-223X CAPACITOR 0.022µF,50V
C28 QEKJ1HM-335 E CAPACITOR 3.3µF,50V
C29 NCB21HK-472X CAPACITOR 0.0047µF,50V
C30 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C31 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C32 QCBB1HK-103 CAPACITOR 0.01µF,50V
C33 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C34 NCB21EK-104X CAPACITOR 0.1µF,25V
C35 NCB21EK-104X CAPACITOR 0.1µF,25V
C36 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C37 QEKJ1HM-105 E CAPACITOR 1µF,50V
C38 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C39 NCB21HK-103X CAPACITOR 0.01µF,50V
C40 QEKJ1EM-106 E CAPACITOR 10µF,25V
C54 NCB21HK-103X CAPACITOR 0.01µF,50V
C57 NCB21HK-103X CAPACITOR 0.01µF,50V
C59 NCB21HK-103X CAPACITOR 0.01µF,50V
C60 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C61 NCB21HK-103X CAPACITOR 0.01µF,50V
C63 NCB21EK-104X CAPACITOR 0.1µF,25V
C64 NDC21HJ-120X CAPACITOR 12pF,50V
C69 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V
C70 NCB21HK-103X CAPACITOR,S3900U/U(C) 0.01µF,50V
C71 NCB21HK-103X CAPACITOR 0.01µF,50V
C72 NDC21HJ-470X CAPACITOR 47pF,50V
C73 NDC21HJ-120X CAPACITOR 12pF,50V
C74 NDC21HJ-120X CAPACITOR 12pF,50V
C80 NCB21HK-103X CAPACITOR 0.01µF,50V
C84 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W
C106 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C110 NCB21HK-331X CAPACITOR 330pF,50V
C137 NCB21HK-103X CAPACITOR 0.01µF,50V
C201 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C202 NCB21EK-104X CAPACITOR 0.1µF,25V
C203 QEKJ1HM-105 E CAPACITOR 1µF,50V
C205 NDC21HJ-101X CAPACITOR 100pF,50V
C207 NCF21CZ-105X CAPACITOR 1µF,16V
C220 NDC21HJ-101X CAPACITOR 100pF,50V
C401 NCB21HK-103X CAPACITOR,S5900U/U(C) 0.01µF,50V
C402 NCB21HK-223X CAPACITOR,S5900U/U(C) 0.022µF,50V

C403 NDC21HJ-151X CAPACITOR,S5900U/U(C) 150pF,50V
C404 NDC21HJ-470X CAPACITOR,S5900U/U(C) 47pF,50V
C406 NCB21HK-681X CAPACITOR,S5900U/U(C) 680pF,50V
C407 NDC21HJ-180X CAPACITOR,S5900U/U(C) 18pF,50V
C501 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C502 QEKJ1HM-104 E CAPACITOR 0.1µF,50V
C503 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C504 NCB21EK-104X CAPACITOR 0.1µF,25V
C505 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C506 NCB21HK-103X CAPACITOR 0.01µF,50V
C507 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C508 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C509 QEKJ1CM-106 E CAPACITOR 10µF,16V
C510 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C511 NCB21HK-103X CAPACITOR 0.01µF,50V
C512 NCB21HK-103X CAPACITOR 0.01µF,50V
C513 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C514 NCB21HK-103X CAPACITOR 0.01µF,50V
C515 QCBB1HK-103 CAPACITOR 0.01µF,50V
C516 NCB21HK-103X CAPACITOR 0.01µF,50V
C517 NCB21HK-103X CAPACITOR 0.01µF,50V
C518 NCB21EK-104X CAPACITOR 0.1µF,25V
C519 QERF1HM-225 E CAPACITOR 2.2µF,50V
C520 QERF1EM-475 E CAPACITOR 4.7µF,25V
C521 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C522 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C523 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C524 NDC21HG-301X CAPACITOR 300pF,50V
C525 NDC21HG-301X CAPACITOR 300pF,50V
C526 NDC21HJ-101X CAPACITOR 100pF,50V
C527 NDC21HJ-181X CAPACITOR 180pF,50V
C528 NDC21HG-271X CAPACITOR 270pF,50V
C529 NDC21HG-820X CAPACITOR 82pF,50V
C530 NDC21HG-221X CAPACITOR 220pF,50V
C531 NDC21HG-301X CAPACITOR 300pF,50V
C532 NDC21HG-301X CAPACITOR 300pF,50V
C533 NCB21HK-103X CAPACITOR 0.01µF,50V
C534 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C535 NCB21HK-103X CAPACITOR 0.01µF,50V
C551 QERF1HM-105 E CAPACITOR 1µF,50V
C552 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C553 NCB21HK-103X CAPACITOR 0.01µF,50V
C555 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C557 QERF1HM-105 E CAPACITOR,S5900U/U(C) 1µF,50V
C558 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C559 NCB21HK-103X CAPACITOR,S5900U/U(C) 0.01µF,50V
C560 QERF1HM-105 E CAPACITOR 1µF,50V
C561 QERF1HM-105 E CAPACITOR 1µF,50V
C563 NCB21HK-103X CAPACITOR 0.01µF,50V
C567 NCB21HK-103X CAPACITOR 0.01µF,50V
C901 QETN0JM-477 E CAPACITOR 470µF,6.3V
C904 NCB21HK-103X CAPACITOR 0.01µF,50V
C911 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C912 NCB21HK-103X CAPACITOR 0.01µF,50V
C913 QETN0JM-477 E CAPACITOR 470µF,6.3V
C914 NRSA02J-0R0X MG RESISTOR,S5900U/U(C) 0Ø,1/10W
C2001 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2002 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2003 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C2005 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2006 NCB21HK-123X CAPACITOR 0.012µF,50V

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C2007 QEKJ1CM-226 E CAPACITOR 22µF,16V
C2008 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2009 NCB21HK-102X CAPACITOR 0.001µF,50V
C2010 NCB21HK-222X CAPACITOR 0.0022µF,50V
C2011 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2012 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2051 NCB21HK-331X CAPACITOR 330pF,50V
C2052 QFLC1HJ-823Z F CAPACITOR,S3900U/U(C) 0.082µF,50V

QFLC1HJ-333Z F CAPACITOR,S5900U/U(C) 0.033µF,50V

C2053 NCB21HK-332X CAPACITOR,S5900U/U(C) 0.0033µF,50V

NCB21HK-472X CAPACITOR,S3900U/U(C) 0.0047µF,50V

C2054 NCB21EK-223X CAPACITOR,S3900U/U(C) 0.022µF,25V

NCB21HK-103X CAPACITOR,S5900U/U(C) 0.01µF,50V
C2055 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2061 QFLC1HJ-333Z F CAPACITOR,S5900U/U(C) 0.033µF,50V
C2062 NCB21HK-332X CAPACITOR,S5900U/U(C) 0.0033µF,50V
C2063 NCB21HK-103X CAPACITOR,S5900U/U(C) 0.01µF,50V
C2064 QEKJ1EM-106 E CAPACITOR,S5900U/U(C) 10µF,25V
C2201 NCB21EK-104X CAPACITOR 0.1µF,25V
C2202 NCB21EK-333X CAPACITOR 0.033µF,25V
C2203 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2204 NCB21HK-102X CAPACITOR 0.001µF,50V
C2205 QEKJ1HM-105 E CAPACITOR 1µF,50V
C2206 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2207 QEKJ1CM-476 E CAPACITOR 47µF,16V
C2208 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2209 QEKJ1HM-104 E CAPACITOR 0.1µF,50V
C2210 QEKJ1HM-104 E CAPACITOR 0.1µF,50V
C2215 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2217 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2219 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2220 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2221 NCB21HK-103X CAPACITOR 0.01µF,50V
C2222 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2223 QEKJ1HM-474 E CAPACITOR 0.47µF,50V
C2224 NCB21HK-103X CAPACITOR 0.01µF,50V
C2225 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C2226 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2227 NCB21EK-104X CAPACITOR 0.1µF,25V
C2251 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C2252 NCB21HK-103X CAPACITOR 0.01µF,50V
C2253 NCB21HK-103X CAPACITOR 0.01µF,50V
C2254 NCB21HK-103X CAPACITOR 0.01µF,50V
C3001 NCB21EK-104X CAPACITOR 0.1µF,25V
C3003 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3008 NCB21HK-102X CAPACITOR 0.001µF,50V
C3013 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3016 NDC21HJ-180X CAPACITOR 18pF,50V
C3017 NDC21HJ-270X CAPACITOR 27pF,50V
C3019 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C3022 NCB21EK-104X CAPACITOR 0.1µF,25V
C3023 NCF21CZ-105X CAPACITOR 1µF,16V
C3035 NCB21EK-104X CAPACITOR 0.1µF,25V
C3036 QERF0JM-107 E CAPACITOR 100µF,6.3V
C3048 NCB21HK-103X CAPACITOR 0.01µF,50V
C4001 NCB21EK-104X CAPACITOR 0.1µF,25V
C4002 QERF1HM-105 E CAPACITOR 1µF,50V
C4004 QERF1AM-336 E CAPACITOR 33µF,10V
C4006 NCB21EK-563X CAPACITOR 0.056µF,25V
C4007 NCB21HK-103X CAPACITOR 0.01µF,50V
C4009 NCB21HK-102X CAPACITOR 0.001µF,50V

C4010 QERF0JM-476 E CAPACITOR 47µF,6.3V
C4011 NCB21CK-224X CAPACITOR 0.22µF,16V
C4014 NDC21HJ-101X CAPACITOR 100pF,50V
C4015 NDC21HJ-101X CAPACITOR 100pF,50V
C4019 NCB21HK-103X CAPACITOR 0.01µF,50V
C4022 NDC21HJ-101X CAPACITOR 100pF,50V

!

C5001 QFZ9073-683 F CAPACITOR 0.068µF,250V

!

C5004 QCZ9094-472 CAPACITOR 0.0047µF,125V
C5006 QETM2DM-157 E CAPACITOR 150µF,200V
C5101 QCZ0212-472 CAPACITOR 0.0047µF,1kV
C5102 QCZ0339-101Z CAPACITOR 100pF,1kV
C5104 QEKJ1HM-105 E CAPACITOR 1µF,50V
C5105 QFN31HJ-183 F CAPACITOR 0.018µF,50V
C5107 QFV91HJ-104 F CAPACITOR 0.1µF,50V
C5201 QEMU0JM-227 E CAPACITOR 220µF,6.3V
C5202 QETN1CM-108 E CAPACITOR 1000µF,16V
C5203 QEMT1AM-128 E CAPACITOR 1200µF,10V
C5204 QETJ2AM-475 E CAPACITOR 4.7µF,100V
C5205 QETN1HM-106 E CAPACITOR 10µF,50V
C5206 QETN1AM-476 E CAPACITOR 47µF,10V
C5207 QETN1CM-107 E CAPACITOR 100µF,16V
C5301 QEKJ1CM-107 E CAPACITOR 100µF,16V
C5302 QEKJ1HM-106 E CAPACITOR 10µF,50V
C5303 QEKJ1CM-107 E CAPACITOR 100µF,16V
C5304 NCB21HK-102X CAPACITOR 0.001µF,50V
C5305 QFV91HJ-154 F CAPACITOR 0.15µF,50V
C5311 NCB21HK-103X CAPACITOR 0.01µF,50V
C6029 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C7001 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7002 NCB21EK-104X CAPACITOR 0.1µF,25V
C7003 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C7005 NDC21HJ-470X CAPACITOR 47pF,50V
C7006 NDC21HJ-330X CAPACITOR 33pF,50V
C7007 QEKJ1HM-106 E CAPACITOR 10µF,50V
C7008 NCB21HK-102X CAPACITOR 0.001µF,50V
C7011 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7015 QCFB1HZ-104 CAPACITOR 0.1µF,50V
C7206 QEKJ0JM-227 E CAPACITOR 220µF,6.3V
L1 QQL29BJ-100Z COIL 10µH
L2 QQL29BJ-101Z COIL 100µH
L3 QQL29BJ-100Z COIL 10µH
L4 QQL29BJ-100Z COIL 10µH
L5 QQL29BJ-100Z COIL 10µH
L11 QQL01BJ-120Z COIL 12µH
L13 QQL231J-101Y COIL 100µH
L15 QQL29BJ-100Z COIL 10µH
L18 QUY153-050Y IM BUS WIRE
L19 QQL29BJ-100Z COIL 10µH
L20 QQL231J-101Y COIL 100µH
L28 QQL231J-150Y COIL 15µH
L201 QUY153-050Y IM BUS WIRE
L203 QQL231J-3R3Y COIL 3.3µH
L401 QQL231J-150Y COIL,S5900U/U(C) 15µH
L402 QUY153-050Y IM BUS WIRE,S5900U/U(C)
L501 QQL29BJ-100Z COIL 10µH
L503 QQL29BJ-100Z COIL 10µH
L504 QQL29BJ-100Z COIL 10µH
L901 QQL29BJ-101Z COIL 100µH
L2001 QUY153-050Y IM BUS WIRE
L2251 QQL29BJ-100Z COIL 10µH
L4001 QUY153-050Y IM BUS WIRE

5-11

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

L5201 PELN1184 COIL 33µH
L5202 PU60944-330K COIL 33µH
L5301 QQL01BJ-101Z COIL 100µH
L6001 QQL29BK-1R0Z COIL 1µH
L6003 QQL29BK-1R0Z COIL 1µH
L6004 QQL071J-1R0Y COIL 1µH
L6032 QUY153-050Y IM BUS WIRE
L6050 QUY153-050Y IM BUS WIRE
L7201 QQL29BJ-101Z COIL 100µH
X2 QAX0575-001 CRYSTAL RESONATOR
X3001 QAX0526-001 CRYSTAL RESONATOR
S3001 QSW0602-004 PUSH SWITCH,REC SAFETY
S3002 QSW0695-001 PUSH SWITCH,S CASS
S7001 QSW0456-002Z TACT SWITCH,POWER
S7002 QSW0456-002Z TACT SWITCH,REC LINK
S7004 QSW0456-002Z TACT SWITCH,SP/EP,S3900U/U(C)

QSW0456-002Z TACT SWITCH,INSERT,S5900U/U(C)

S7006 QSW0456-002Z TACT SWITCH,DISPLAY,S3900U/U(C)

QSW0456-002Z TACT SWITCH,A.DUB,S5900U/U(C)
S7008 QSW0456-002Z TACT SWITCH,PLAY
S7010 QSW0456-002Z TACT SWITCH,E.PROG
S7011 QSW0456-002Z TACT SWITCH,REC
S7013 QSW0456-002Z TACT SWITCH,PAUSE
S7015 QSW0456-002Z TACT SWITCH,STOP/EJECT
S7016 QSW0456-002Z TACT SWITCH,SVHS ET
K2251 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2253 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K5101 QQR0678-001Z FERRITE BEAD
K5102 QQR0678-001Z FERRITE BEAD
PC3001 GP3S123 IC(PHOTO SENSOR
PC3002 GP3S123 IC(PHOTO SENSOR

!

PC5101 PS2501-1 PH COUPLER
T2051 PELN0832 OSC TRANSFORMER,S3900U/U(C)

PELN0860 OSC TRANSFORMER,S5900U/U(C)
T2052 PELN0861 OSC TRANSFORMER,S5900U/U(C)

!

T5001 QQS0031-002 SW TRANSFORMER
ET1 LP30859-001A EARTH PLATE
HD1 PQ35479-1-4 HOLDER(FDP),DI7001
HS1 LP40090-001A HEAT SINK,Q5101

!

CD1 QMPD340-165-K POWER CORD
SD1 LP30864-001A SHIELD CASE(PRE)
DI7001 QLF0031-001 FL TUBE
TU6001 QAU0207-001 TUNER
OT1 QYTDSF3010M SCREW,X2
OT2 QYTDST3006Z SCREW,Q5101
J1 QNN0380-002 PIN JACK,REAR1 IN
J2 QNN0286-002 PIN JACK,REAR OUT
J4 QND0076-001 S JACK,REAR S IN
J5 QND0076-001 S JACK,S_OUT

!

TB1 LP20887-009A TERMINAL BOARD
FC5001 QNG0006-001Z FUSE CLIP,F5001
FC5002 QNG0006-001Z FUSE CLIP,F5001
FW3001 QUM022-13A4A4 PARA RIBON WIRE
FW3002 QUM022-30A4A4 PARA RIBON WIRE
J7101 QNN0381-001 PIN JACK,FRONT IN

!

LF5002 QQR0532-001 LINE FILTER

!

VA5001 QAF0023-431Z VARISTOR
CN1 QGF1028C1-11

QGF1028C1-13
CN2001 QGF1207C1-07 FPC CONNECTOR,(1-7)A/C HEAD

FPC CONNECTOR,(1-11)U.DRUM,S3900U/U(C)
FPC CONNECTOR,(1-13)U.DRUM,S5900U/U(C)

CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD
CN3001 QGB2015M2-08 CONNECTOR,(1-8)CAPSTAN MOTOR
CN3002 QGF1207C1-05 FPC CONNECTOR,(1-5)DRUM MDA
CN3003 QGB2532J1-02 CONNECTOR,(1-2)LOADING MOTOR
CN3004 QGB2534J2-04 CONNECTOR,(1-4)ROTARY ENCODER
CN7001 QGF1207C1-09 FPC CONNECTOR,(1-9)ADV.JOG
CN7103 QGF1207C1-04

!

CP4001 ICP-N25 CIRCUIT PROTECTOR

!

CP5302 ICP-N25 CIRCUIT PROTECTOR

!

F5001 QMF51N2-1R25J1 FUSE T1.25A,AC250V

FPC CONNECTOR,(1-4)S JACK,S5900U/U(C)

******************************

2D DIGITAL BOARD ASSEMBLY <05>

PW1 LPA10090-05A 2D DIGITAL BOARD ASSY,S5900U/U(C)

LPA10090-06A 2D DIGITAL BOARD ASSY,S3900U/U(C)

IC1201 JCP8036 IC

!

Q1201 2SC1317/RS/-T TRANSISTOR
Q1202 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q1203 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q1204 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR
Q1205 2SC4081/S/-X TRANSISTOR
D1201 RD4.3ES/B3/-T2 ZENER DIODE
D1202 QUY153-050Y IM BUS WIRE
R1201 NRSA02J-121X MG RESISTOR 120Ø,1/10W
R1202 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R1203 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R1204 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R1205 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1206 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R1207 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R1208 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R1209 NRSA02J-180X MG RESISTOR 18Ø,1/10W
R1210 NRSA02J-393X MG RESISTOR 39kØ,1/10W
R1211 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R1212 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1213 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R1214 NRSA02J-181X MG RESISTOR 180Ø,1/10W
R1215 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R1216 NRSA02J-151X MG RESISTOR 150Ø,1/10W
R1217 NRSA02J-151X MG RESISTOR 150Ø,1/10W
R1218 NRSA02J-301X MG RESISTOR 300Ø,1/10W
R1220 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R1222 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R1223 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R1224 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R1230 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R1231 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R1232 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R1233 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
VR1201 QVZ3521-103Z V RESISTOR
B1204 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C1201 QEKJ0JM-476 E CAPACITOR 47µF,6.3V

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C1211 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1212 NCB21HK-102X CAPACITOR 0.001µF,50V
C1213 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1214 NCF21CZ-105X CAPACITOR 1µF,16V
C1215 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1216 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1217 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1218 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1219 NCF21CZ-105X CAPACITOR 1µF,16V
C1220 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1222 NDC21HJ-151X CAPACITOR 150pF,50V
C1223 NDC21HJ-680X CAPACITOR 68pF,50V
C1225 NDC21HJ-151X CAPACITOR 150pF,50V
C1226 NDC21HJ-680X CAPACITOR 68pF,50V
C1227 NCB21EK-104X CAPACITOR 0.1µF,25V
C1228 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C1229 NCB21HK-103X CAPACITOR 0.01µF,50V
C1230 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1231 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1232 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1233 QDYB1CM-103Y CAPACITOR 0.01µF,16V
C1234 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1235 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C1236 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1237 NCF21EZ-104X CAPACITOR 0.1µF,25V
C1238 NDC21HJ-180X CAPACITOR 18pF,50V
C1239 NDC21HJ-560X CAPACITOR 56pF,50V
C1243 NCB21HK-103X CAPACITOR 0.01µF,50V
C1244 QEKJ1EM-475 E CAPACITOR 4.7µF,25V
C1245 NDC21HJ-150X CAPACITOR 15pF,50V
C1246 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
L1202 QQL29BJ-101Z COIL 100µH
L1203 QQL29BJ-101Z COIL 100µH
L1204 QQL29BJ-101Z COIL 100µH
L1205 QQL071J-2R7Y COIL 2.7µH
L1206 QQL071J-2R7Y COIL 2.7µH
L1207 QQL29BJ-101Z COIL 100µH
L1208 QQL071J-150Y COIL 15µH
L1209 QUY153-050Y IM BUS WIRE

!

LC1201 QQL29BJ-101Z COIL 100µH
SD1 LP30706-001C SHIELD FRAME(S-VHS)
SD2 LP30684-001A SHIELD CASE(S-VHS),S5900U/U(C)
CN1201 QGG2502K1-17 HEADER PIN

******************************

DEMOD BOARD ASSEMBLY <14>

PW1 PB11076A DEMOD BOARD ASSY
IC1501 UPC1852AGT IC

or UPC1854AGT IC
R1501 QRE141J-102Y RESISTOR 1kØ,1/4W
R1502 QRE141J-334Y RESISTOR 330kØ,1/4W
R1503 QRE141J-124Y RESISTOR 120kØ,1/4W
R1504 QRE141J-302Y RESISTOR 3kØ,1/4W
R1505 QRE141J-512Y RESISTOR 5.1kØ,1/4W
R1506 QRE141J-333Y RESISTOR 33kØ,1/4W
R1507 QRE141J-333Y RESISTOR 33kØ,1/4W
R1508 QRE141J-392Y RESISTOR 3.9kØ,1/4W
R1509 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R1510 QRE141J-392Y RESISTOR 3.9kØ,1/4W
R1511 QRE141J-122Y RESISTOR 1.2kØ,1/4W
R1517 QRE141J-123Y RESISTOR 12kØ,1/4W
C1501 QETN1CM-226 E CAPACITOR 22µF,16V
C1502 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1503 QETN1HM-105 E CAPACITOR 1µF,50V
C1504 QETN1HM-475 E CAPACITOR 4.7µF,50V
C1505 QETN1HM-225 E CAPACITOR 2.2µF,50V
C1506 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1507 QFV11HJ-473 F CAPACITOR 0.047µF,50V
C1508 QETN1HM-474 E CAPACITOR 0.47µF,50V
C1509 QETN1HM-104 E CAPACITOR 0.1µF,50V
C1510 QETN1HM-105 E CAPACITOR 1µF,50V
C1511 QETN1HM-105 E CAPACITOR 1µF,50V
C1512 QETN1HM-105 E CAPACITOR 1µF,50V
C1513 QETN1HM-335 E CAPACITOR 3.3µF,50V
C1514 QETN1HM-106 E CAPACITOR 10µF,50V
C1515 QETN1HM-105 E CAPACITOR 1µF,50V
C1516 QETN1HM-106 E CAPACITOR 10µF,50V
C1517 QETN1HM-106 E CAPACITOR 10µF,50V
C1518 QETN1HM-105 E CAPACITOR 1µF,50V
C1521 QETN1HM-106 E CAPACITOR 10µF,50V
BK1 LP40077-001A BRACKET(BOARD)
CN1501 QGG2502K1-09 HEADER PIN

******************************

S JACK BOARD ASSEMBLY(S5900U/U(C))<36>

******************************

A/C HEAD BOARD ASSEMBLY <12>

PW1 LP10122-01A1 A/C HEAD BOARD ASSY
CN1 QGF1208F1-07 FPC CONNECTOR

PW1 LPA20009-02B S JACK BOARD ASSY
J7102 QND0084-001 S JACK
CN7108 QGF1209F1-04 FPC CONNECTOR,(1-4)MAIN

******************************

ADV.JOG BOARD ASSEMBLY <38>

PW1 LPA20013-04B ADV.JOG BOARD ASSY
UN7002 QSW0905-001 ROTARY ENCODER
CN7004 QGF1209F1-09 FPC CONNECTOR,(1-9)MAIN

5-13

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

LOADING MOTOR BOARD ASSEMBLY <55>

PW2 LP10122-01A2 LOADING MOTOR BOARD ASSY
CN1 QGB2533K1-02 CONNECTOR

******************************

R.PAUSE BOARD ASSEMBLY <91>

PW2 LPA10134-03C2 R.PAUSE BOARD ASSY
R7156 NRSA02J-101X MG RESISTOR 100Ø,1/10W
B7151 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B7152 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
J7104 PU60612 MINI JACK

******************************

C.BOX BOARD ASSEMBLY <92>

PW3 LPA10134-03C3 C.BOX BOARD ASSY
R7155 NRSA02J-101X MG RESISTOR 100Ø,1/10W
J7105 PU60612 MINI JACK

5-14
