VIDEO CASSETTE RECORDER

HR-A54U HR-A34U

TV operation – Press and hold TV button, then press POWER, TV CH +/–, VOL +/–, TV/VCR

PROG.

POWER

PROG.

CHECK

DISPLAY

12 3

TV/VCR

SP/EP

DAILY9WEEKLY

AUX

TIMER

CANCEL

ENTER

C.RESET OSD

START

STOP DATE CH

PLAY

REW FF

STOP

PAUSE

REC

TV CH +

+ VOL

VOL –

TV CH –

POWER

L–AUDIO–R

VIDEO

(MONO)

POWER TV/VCR TIMER REC MTB

(Hi-Fi)

(Monaural)

The VCR illustrations appearing in this instruction manual are of the HR-A54U.

PLAY

REW FF

STOP/EJECT

REC

PAUSE

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located on the rear of cabinet. Retain this information for future reference.

Model No. Serial No.

LPT0013-001A

2 EN

Dear Customer,

Thank you for purchasing the JVC VHS video cassette recorder. Before use, please read the safety information and precautions contained in the following pages to ensure safe use of your new VCR.

Failure to heed the following precautions may result in

CAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

CAUTION:

This video cassette recorder should be used with AC 120V`, 60Hz only. To prevent electric shocks and fire hazards, DO NOT use any other power source.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

damage to the VCR, remote control or video cassette.

1. DO NOT place the VCR . . .

... in an environment prone to extreme temperatures or

humidity. ... in direct sunlight. ... in a dusty environment. ... in an environment where strong magnetic fields are

generated. ... on a surface that is unstable or subject to vibration.

2. DO NOT block the VCR’s ventilation openings.

3. DO NOT place heavy objects on the VCR or remote control.

4. DO NOT place anything which might spill on top of the VCR or remote control.

5. AVOID violent shocks to the VCR during transport.

**MOISTURE CONDENSATION

Moisture in the air will condense on the VCR when you move it from a cold place to a warm place, or under extremely humid conditions—just as water droplets form on the surface of a glass filled with cold liquid. Moisture condensation on the head drum will cause damage to the tape. In conditions where condensation may occur, keep the VCR’s power turned on for a few hours to let the moisture dry before inserting a tape.

**ABOUT HEAD CLEANING

Accumulation of dirt and other particles on the video heads may cause the playback picture to become blurred or interrupted. Be sure to contact your nearest JVC dealer if such troubles occur.

CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU'AU FOND.

Note to CATV system installer:

This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

CAUTION:

Changes or modifications not approved by JVC could void user's authority to operate the equipment.

VCR Plus+ and PlusCode are trademarks of Gemstar Development Corporation. The VCR Plus+ system is manufactured under license from Gemstar Development Corporation.

n Cassettes marked "VHS" (or "S-VHS") can be used with this

video cassette recorder. However, S-VHS recording is not possible with this model.

n This model is equipped with SQPB (S-VHS QUASI PLAY-

BACK) that makes it possible to play back S-VHS recordings with regular VHS resolution.

n HQ VHS is compatible with existing VHS equipment. n As an E

NERGY STA R

product or product model meets the ENERGY STAR® guidelines for energy efficiency.

Partner, JVC has determined that this

EN 3

IMPORTANT PRODUCT SAFETY INSTRUCTIONS

Electrical energy can perform many useful functions. But improper use can result in potential electrical shock or fire hazards. This product has been engineered and manufactured to assure your personal safety. In order not to defeat the built-in safeguards, observe the following basic rules for its installation, use and servicing.

ATTENTION:

Follow and obey all warnings and instructions marked on your product and its operating instructions. For your safety, please read all the safety and operating instructions before you operate this product and keep this booklet for future reference.

INSTALLATION

1. Grounding or Polarization

(A) Your product may be equipped with a polarized alternating-

current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.

(B) Your product may be equipped with a 3-wire grounding-type

plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

2. Power Sources

Operate your product only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. If your product is intended to operate from battery power, or other sources, refer to the operating instructions.

3. Overloading

Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.

4. Power Cord Protection

Power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they exit from the product.

5. Ventilation

Slots and openings in the cabinet are provided for ventilation. To ensure reliable operation of the product and to protect it from overheating, these openings must not be blocked or covered.

• Do not block the openings by placing the product on a bed,

sofa, rug or other similar surface.

• Do not place the product in a built-in installation such as a

bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

6. Wall or Ceiling Mounting

The product should be mounted to a wall or ceiling only as recommended by the manufacturer.

ANTENNA INSTALLATION INSTRUCTIONS

1. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

2. Lightning

For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.

3. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70

ANTENNA LEAD IN WIRE

GROUND CLAMP

ANTENNA DISCHARGE UNIT (NEC SECTION

ELECTRIC SERVICE EQUIPMENT

POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250. PART H)

NEC – NATIONAL ELECTRICAL CODE

810-20)

GROUNDING CONDUCTORS (NEC SECTION 810-21)

GROUND CLAMPS

4 EN

USE

1. Accessories

To avoid personal injury:

• Do not place this product on an unstable cart, stand, tripod, bracket, or table. It may fall, causing serious injury to a child or adult, and serious damage to the product.

• Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.

• Use a mounting accessory recommended by the manufacturer and follow the manufacturer’s instructions for any mounting of the product.

• Do not try to roll a cart with small casters across thresholds or deep-pile carpets.

2. Product and Cart Combination

A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn.

3. Water and Moisture

Do not use this product near water—for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool and the like.

4. Object and Liquid Entry

Never push objects of any kind into this product through openings as they may touch dangerous voltage points or shortout parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.

5. Attachments

Do not use attachments not recommended by the manufacturer of this product as they may cause hazards.

6. Cleaning

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

7. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

PORTABLE CART WARNING (Symbol provided by RETAC)

SERVICING

1. Servicing

If your product is not operating correctly or exhibits a marked change in performance and you are unable to restore normal operation by following the detailed procedure in its operating instructions, do not attempt to service it yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

2. Damage Requiring Service

Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a.When the power supply cord or plug is damaged. b.If liquid has been spilled, or objects have fallen into the

product. c.If the product has been exposed to rain or water. d.If the product does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions as an improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the product to its normal operation. e.If the product has been dropped or damaged in any way. f. When the product exhibits a distinct change in

performance—this indicates a need for service.

3. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

4. Safety Check

Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in safe operating condition.

HOW TO USE THIS INSTRUCTION MANUAL

● All major sections and subsections are listed in the Table Of

Contents on page 5. Use this when searching for information

on a specific procedure or feature.

● The Index on pages 38–40 lists frequently-used terms, and

the number of the page on which they are used or explained

in the manual. This section also illustrates the controls and

connections on the front and rear panel, the front display

panel and the remote control.

● The Z mark signals a reference to another page for

instructions or related information.

● Operation buttons necessary for the various procedures are

clearly indicated through the use of illustrations at the

beginning of each major section.

BEFORE YOU INSTALL YOUR NEW VCR . . .

. . . please read the sections/literature listed below.

● ”Cautions” on page 2

● ”Important Products Safety Instructions” on the previous pages

CONTENTS

EN 5

NSTALLING YOUR NEW VCR 6

Basic Connections .................................. 6

NITIAL SETTINGS 8

Language ..................................................... 8

Clock ............................................................ 9

Tuner .......................................................... 10

Set Receivable Channels ..........................................10

Add Or Delete A Channel........................................11

IMPLE PLAYBACK AND

RECORDING 12

Simple Playback ......................................... 12

Simple Recording ........................................ 13

LAYBACK AND RECORDING FEATURES 14

Playback Features ...................................... 14

Still Picture/Frame-By-Frame Playback.....................14

Slow Motion ............................................................14

High-Speed Search ..................................................14

Index Search ............................................................14

Manual Tracking ......................................................15

Video Stabilizer .......................................................16

Repeat Playback ......................................................17

Counter Reset ..........................................................17

Tape Position Indicator ............................................17

Next-Function Memory............................................17

Superimpose ............................................................18

Select The Soundtrack (HR-A54U only) ...................19

Auto Picture ................................................ 20

Preparation ..............................................................20

Playback ..................................................................21

Recording Features ..................................... 22

Record One Program While

Watching Another....................................................22

Display Elapsed Recording Time..............................22

Stereo And SAP (Second Audio Program)

(HR-A54U only).......................................................23

To Record SAP Programs (HR-A54U only) ...............23

DITING 33

Edit To Another VCR .................................... 33

Edit From A Camcorder Or Another VCR ...... 34

ROUBLESHOOTING 35

Power ........................................................ 35

Tape Transport ............................................ 35

Playback .................................................... 35

Recording ...................................................35

Timer Recording.......................................... 36

Other Problems .......................................... 36

UESTIONS AND ANSWERS 37

Playback .................................................... 37

Recording ...................................................37

Timer Recording.......................................... 37

NDEX 38

List Of Terms............................................... 38

Front View .................................................. 39

Front Panel Indicators ................................. 39

Rear View .................................................. 39

Remote Control ........................................... 40

PECIFICATIONS 41

OR SERVICING (Only in U.S.A.) 42

F W

ARRANTY (Only in U.S.A.) 43

IMER RECORDING 24

VCR Plus+ Timer Programming

(HR-A54U only) .......................................... 24

VCR Plus+ Setup (HR-A54U only)................. 26

Express Timer Programming ....................... 28

Check, Cancel And Revise Programs ....................... 30

Auto SP→EP Timer ..................................................31

Auto Timer............................................................... 31

Instant Timer Recording (ITR)....................... 32

6 EN

Basic Connections

Antenna or Cable

AC Power Cord

INSTALLING YOUR NEW VCR

ANT. IN (Antenna or Cable input)

Coaxial Cable

Flat Feeder

Matching Transformer (not supplied)

AC Outlet

Back of VCR

Audio/Video Cable (not supplied)

75 ohm terminal

Back of VCR

CH3 CH4

AUDIO

VIDEO

ANT. IN

OUT

RF OUT

RF Cable (supplied)

EN 7

CHECK CONTENTS

Make sure the package contains all of the accessories listed in “SPECIFICATIONS” (Z pg. 41).

SITUATE VCR

Place the VCR on a stable, horizontal surface.

CONNECT VCR TO TV

The connection method you use depends on the type of TV you have.

RF Connection

●

To Connect To A TV With NO AV Input Terminals . . .

a– Disconnect the TV antenna from the TV. b– Connect the TV antenna cable to the ANT. IN jack

on the rear of the VCR.

c– Connect the supplied RF cable between the RF

OUT jack on the rear of the VCR and the TV’s antenna terminal. Set TV on CH3 or CH4 corresponding to the CH3 – CH4 switch setting on the back of the VCR.

AV Connection

●

To Connect To A TV With AV Input Terminals . . .

a– Connect the antenna, VCR and TV as shown in

the illustration.

b– Connect an Audio/Video Cable between the AUDIO

OUT and VIDEO OUT jacks on the rear of the VCR and the AV IN jacks on the TV. Set your TV in video input mode or A/V input mode. Refer to the TV Instruction Manual.

For HR-A34U Owners:

If your TV has AUDIO IN L and R connectors,

connect the VCR to the L connector.

NOTES:

●

The VCR channel is the channel on the TV which will display

the audio and video signals from the VCR. The VCR's CH3-

CH4 switch, on the back of the VCR, sets the VCR channel to

CH3 or CH4.

●

The CH3–CH4 switch is preset to the CH3 position.

Set to CH4 if CH3 is used for broadcasting in your area and

set the channel on the TV to correspond to the VCR's CH3–

CH4 switch setting.

●

If RF connection to TV is used, when switching from VCR to TV

mode and from TV to VCR it may be necessary to issue a CH UP

and then CH DOWN on TV to obtain a good quality picture.

●

Even if you are using AV cables to connect your VCR to your

TV, you must also connect it using the RF cable. This will

ensure that you can record one show while watching another

(Z pg. 22).

●

For full identification of the VCR's rear panel, refer to the

Index (REAR VIEW Z pg. 39).

CONNECT VCR TO POWER SOURCE

Connect the power plug to an AC outlet.

FINAL PREPARATION FOR USE

Power on the VCR and select the VCR channel (3 or 4) by setting the switch on the rear of the VCR as shown in

the illustration. You can now perform simple playback (Z pg. 12) or simple recording (Z pg. 13).

8 EN

POWER

Language

INITIAL SETTINGS

This VCR offers you the choice to view on-screen messages in English, Spanish or French (not including messages superimposed on the TV picture). Select the desired language using this procedure. The default setting is "ENGLISH".

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

POWER

TURN ON THE VCR

Press POWER.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS INITIAL SET SCREEN

At the Main Menu screen, move the highlight bar

(arrow) to “INITIAL SET” by pressing CH5∞ or %ﬁ, then press OK or .

SELECT LANGUAGE

Move the highlight bar (arrow) to "LANGUAGE"

by pressing CH 5∞ or %ﬁ, then press OK or to

select the desired language.

● "GUIDE CHANNEL SET" will appear with HRA54U only.

MAIN MENU

FUNCTION SET TUNER SET

= INITIAL SET

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

INITIAL SET

CLOCK SET

=LANGUAGE ENGLISH

GUIDE CHANNEL SET

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

RETURN TO NORMAL SCREEN

Press MENU.

Clock

POWER

EN 9

TURN ON THE VCR

Press POWER.

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

POWER

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS INITIAL SET SCREEN

At the Main Menu screen, move the highlight bar (arrow) to “INITIAL SET” by pressing CH5∞ or %ﬁ,

then press OK or .

ACCESS CLOCK SET SCREEN

Move the highlight bar (arrow) at the Initial Set screen to “CLOCK SET” by pressing CH5∞ or %ﬁ, then press

OK or .

● "GUIDE CHANNEL SET" will appear with HR-A54U only.

SET TIME

Press CH 5∞ or %ﬁ until the desired time appears,

then press OK or .

● Press and hold CH 5∞ or %ﬁ to change the time by 30 minutes.

SET DATE

Press CH 5∞ or %ﬁ until the desired date appears, then press OK or .

● Press and hold CH 5∞ or %ﬁ to change the date by 15 days.

TIME DATE YEAR

– –:– –AM 1/ 1 98

D.S.T. : ON

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

CLOCK SET

**AUTO DAYLIGHT SAVING TIME

This function enables automatic adjustment of the VCR’s clock at the start and end of Daylight Saving Time. With Auto DST activated, . . . . . . on the first Sunday of April at 2:00 AM, the clock is

adjusted to 3:00 AM.

. . . on the last Sunday of October at 2:00 AM, the clock is

adjusted to 1:00 AM.

SET YEAR

Press CH 5∞ or %ﬁ until the desired year appears, then press OK or twice.

SELECT D.S.T. MODE

Press CH 5∞ or %ﬁ to select the desired mode. a– Set to "ON" so that the adjustment to your VCR's

clock will be made on the clock itself.

b– Set to "OFF" if Daylight Saving Time does not apply

to you.

START CLOCK

Press MENU and normal screen appears.

To Make Corrections

Press OK or until the item you want to change blinks, then press CH 5∞ or %ﬁ.

10 EN

POWER

INITIAL SETTINGS (cont.)

Set Receivable Channels

Tuner

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

POWER

TURN ON THE VCR

Press POWER.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS TUNER SET SCREEN

Move the highlight bar (arrow) to "TUNER SET" by

pressing CH5∞ or %ﬁ, then press OK or .

PERFORM AUTO CHANNEL SET

Move the highlight bar (arrow) to "AUTO

CHANNEL SET" by pressing CH5∞ or %ﬁ, then press OK or .

● Receivable channels in your area are automatically assigned to the CH5∞ buttons, and non-receivable channels are skipped.

NOTES:

●

At the end of Auto Channel Set, “SCAN COMPLETED” appears on screen.

●

If the scan was unsuccessful, “SCAN COMPLETED– NO SIGNAL” appears on screen. Check the connections and start again.

FUNCTION SET

= TUNER SET

INITIAL SET

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

BAND CATV

=AUTO CHANNEL SET

MANUAL CHANNEL SET

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

AUTO CHANNEL SET

PRESS (MENU) TO END

MAIN MENU

TUNER SET

SCANNING...

INFORMATION

The VCR detects the band (TV or CATV) and selects the correct band automatically during Auto Channel Set. The selected band will be displayed on the right side of "BAND" on the Tuner Set screen.

RETURN TO NORMAL SCREEN

Press MENU.

12 3 4506

789

NUMBER

EN 11

Add Or Delete A Channel

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS TUNER SET SCREEN

Move the highlight bar (arrow) to "TUNER SET" by pressing CH5∞ or %ﬁ, then press OK or .

ACCESS MANUAL CHANNEL SET SCREEN

Move the highlight bar (arrow) to "MANUAL

CHANNEL SET" by pressing CH5∞ or %ﬁ, then press OK or .

ADD OR SKIP DESIRED CHANNEL

Input the channel number using the NUMBER keys or

by pressing CH5∞ or %ﬁ, then press OK or to set to "ADD" or "SKIP" as required. Repeat for each channel you want to add or skip.

TUNER SET

BAND CATV AUTO CHANNEL SET

=MANUAL CHANNEL SET

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

MANUAL CHANNEL SET

(CATV)

CH 45 ADD

PRESS NUMBER KEY (0–9)

OR (5,∞), THEN (OK)

PRESS (MENU) TO END

RETURN TO NORMAL SCREEN

Press MENU.

12 EN

PLAY

STOP

STOP/EJECT

PLAY

REW

Simple Playback

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

SIMPLE PLAYBACK AND RECORDING

LOAD A CASSETTE

Make sure the window side is up, the rear label side is facing you and the arrow on the front of the cassette is

pointing towards the VCR. Don’t apply too much pressure when inserting.

● The VCR’s power comes on automatically.

● The counter is automatically reset to "0:00:00".

● If the cassette's record safety tab has been removed,

playback begins automatically.

FIND PROGRAM START POINT

If the tape is advanced past the start point, press REW. To go forward, press FF.

START PLAYBACK

Press PLAY. "AUTO PICTURE" appears on the screen (when AUTO PICTURE is set to "ON" Z pg. 20).

STOP PLAYBACK

Press STOP or STOP/EJECT. Then press STOP/EJECT to remove the cassette.

REW (Rewind)

12 3 4506

789

FF (Fast-Forward)

INFORMATION

This video recorder is equipped with SQPB (S-VHS QUASI PLAYBACK) that lets you watch tapes recorded in the S-VHS format with regular VHS resolution.

● SQPB does not deliver Super VHS resolution.

● S-VHS recording is not possible with this video recorder.

Usable cassettes

Full-Size VHS T-30 (ST-30**) T-60 (ST-60**) T-90 T-120 (ST-120**) T-160 (ST-160**) ST-210**

Compact VHS* TC-20 (ST-C20**) TC-30 (ST-C30**) TC-40 (ST-C40**)

* Compact VHS camcorder recordings can be played on

this video recorder. Simply place the recorded cassette into a VHS Cassette Adapter and it can be used just like any full-sized VHS cassette.

** This video recorder can record on regular VHS and

Super VHS cassettes. However, it will record regular VHS signals only.

Simple

STOP

PAUSE

STOP/EJECT

REC

PLAY

EN 13

LOAD A CASSETTE

Make sure the record safety tab is intact. If not, cover the hole with adhesive tape before inserting the cassette.

Recording

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

REC Indicator

12 3

PAUSE

TV/VCR

SP/EP

REC

4506

789

ENTER

PLAY

NUMBER

SELECT RECORDING CHANNEL

Press CH5∞. Or press the appropriate NUMBER keys, then press ENTER. (The channel changes after a few

seconds whether you press ENTER or not.)

● If you use the RF connection, by pressing the TV/VCR button, select VCR mode to view the program to be recorded.

SET TAPE SPEED

Press SP/EP to set the recording speed.

START RECORDING

Press and hold REC and press PLAY on the remote control, or press REC on the VCR's front panel.

● The REC indicator lights on the front display panel.

PAUSE/RESUME RECORDING

Press PAUSE. Press PLAY to resume recording.

● During record pause, you can change the recording

channel by using the CH5∞ buttons or NUMBER keys.

STOP RECORDING

Press STOP or STOP/EJECT. Then press STOP/EJECT to remove the cassette.

Accidental erasure prevention

● To prevent accidental recording on a recorded cassette, remove its record safety tab. To record on it later, cover the hole with adhesive tape.

Record safety tab

14 EN

PLAY

PAUSE

PLAY

PLAYBACK AND RECORDING FEATURES

Slow Motion

Playback Features

REW

12 3 4506

789

ACTIVATE SLOW-MOTION PLAYBACK

For forward slow motion during still picture, press and hold PAUSE for more than 2 seconds. Press PAUSE

again to return to still picture.

● Reverse slow motion is not possible with this recorder.

To resume normal playback, press PLAY.

High-Speed Search

ACTIVATE HIGH-SPEED SEARCH

During playback or still, press FF for forward highspeed search, or REW for reverse high-speed search.

To resume normal playback, press PLAY.

NOTE:

For short searches, during playback or still, press and hold FF or REW for over 2 seconds. When released, normal playback

resumes.

REW

Still Picture/Frame-ByFrame Playback

PAUSE DURING PLAYBACK

Press PAUSE. If there is vertical jitter, use the CH 5 or button to correct the picture.

ACTIVATE FRAME-BYFRAME PLAYBACK

Press PAUSE repeatedly to advance one frame at a time.

● Reverse frame-by-frame playback is not possible with

To resume normal playback, press PLAY.

this recorder.

PAUSE

Index Search

Index codes are placed on the tape at the start of each recording. You can find and automatically play back from the start of any recording using the Index Search function.

START SEARCH

While the tape is stopped, press ™ or £ ( or ).

ACCESS DISTANT CODE

To access a recording 2–9 index codes away, press ™ or £ ( or ) repeatedly until the correct number is

displayed on screen (only if SUPERIMPOSE is set to ON (Z pg. 18). Playback begins automatically when the desired recording is located.

● If necessary press REW or FF when play starts to

∞

NOTE:

An index code is not placed on the tape when recording is paused and then resumed.

ﬁ

search visually to find the very beginning of the desired program.

ﬁ

12 3 4506

789

EN 15

Manual Tracking

Once playback begins, the VCR’s automatic tracking function is engaged. If tracking noise appears in the picture, you can override this and make the adjustment manually.

ENGAGE MANUAL TRACKING MODE

During playback, press the CH5 and ∞ buttons on the VCR's front panel simultaneously to cancel the

automatic tracking mode and enable manual tracking adjust.

ADJUST MANUAL TRACKING

Press CH 5 or ∞ on the VCR's front panel or remote. Press briefly for fine adjust, or press and hold for coarse

adjust. Watch the screen and continue adjusting until optimum picture and sound quality are achieved.

RE-ENGAGE AUTOMATIC TRACKING

Press the CH5 and ∞ buttons on the VCR's front panel simultaneously.

● When automatic tracking is re-engaged, Auto Picture is automatically activated.

NOTES:

●

To obtain a noiseless still picture it may be necessary to adjust tracking in slow playback and then engage Pause.

●

Manual tracking is possible during slow motion. During slowmotion playback, simply press CH 5 panel or remote to adjust tracking.

∞

on the VCR's front

16 EN

PLAYBACK AND RECORDING FEATURES (cont.)

Video Stabilizer

By activating the Video Stabilizer you can correct vertical vibrations in the picture when playing back unstable EP recordings that were made on another VCR. When this function is set to "ON", vertical vibration will be automatically corrected. *The default setting is "OFF".

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION

SET" by pressing CH5∞ or

ﬁ, then press OK or .

MAIN MENU

= FUNCTION SET

TUNER SET INITIAL SET

12 3 4506

789

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

ACTIVATE VIDEO STABILIZER

HR-A34U HR-A54U

= VIDEO STABILIZER ON

Move the highlight bar (arrow) to "VIDEO STABILIZER" by pressing CH 5∞ or %ﬁ, then press OK or to set to "ON".

FUNCTION

AUTO TIMER OFF SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

=VIDEO STABILIZER ON

FUNCTION

AUTO TIMER OFF SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

RETURN TO NORMAL SCREEN

Press MENU.

NOTES:

●

The Superimpose mode indications may jitter vertically when "VIDEO STABILIZER" is set to "ON".

●

Regardless of the setting, this function has no effect with SP recordings, during recording and during special-effects playback.

●

When you finish viewing the tape, be sure to set it back to "OFF".

PLAY

STOP

POWER

PAUSE

STOP

PLAY

REW

Repeat Playback

START REPEAT

Press and hold PLAY (until "PLAY" blinks on the screen) during playback, then release.

● The entire tape is played back 50 times.

STOP REPEAT

To stop, press STOP at any time.

NOTE:

Pressing PLAY, REW, FF or PAUSE also stops Repeat Playback.

Counter Reset

EN 17

C.RESET

REW

12 3 4506

789

POWER

TIMER

PAUSE

RESET COUNTER TO ZERO

Press C.RESET.

Tape Position Indicator

The Tape position indicator appears on screen when, from the stop mode, you press FF or REW, or perform an Index Search. The position of " " in relation to "B" (Beginning) or "E" (End) shows you where you are on the tape.

NOTES:

●

"SUPERIMPOSE" must be set to "ON", or the indicator will not appear (Z pg. 18).

●

It may take a few seconds for the Tape Position Indicator to be displayed.

Next-Function Memory

The Next Function Memory “tells” the VCR what to do after rewinding. Before continuing, ensure that the VCR is in stop mode.

a– For Automatic Start Of Playback After Tape Rewind . . . . . . press REW, then press PLAY within 2 seconds. b– For Automatic Power Off After Tape Rewind . . . . . . press REW, then press POWER within 2 seconds. c– For Automatic Timer Standby After Tape Rewind . . . . . . press REW, then press TIMER within 2 seconds.

+++

COUNT 0:33:27

NOTE:

It is not possible to select the Automatic Timer functions if the cassette's record safety tab is removed.

18 EN

OSD

PLAYBACK AND RECORDING FEATURES (cont.)

12 3 4506

789

Superimpose

This function, switchable between ON and OFF, determines whether or not operational indicators will appear on screen.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION SET" by pressing CH5∞ or %ﬁ, then press OK or .

SELECT SUPERIMPOSE SET MODE

HR-A34U HR-A54U

FUNCTION

AUTO TIMER OFF

= SUPERIMPOSE ON

AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

FUNCTION

AUTO TIMER OFF

=SUPERIMPOSE ON

AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

To recall an indication

1 Press OSD.

n All indications corresponding to the current status are

displayed for 5 seconds. After that, the counter information and RECORD/PAUSE if in the Record Pause mode, are left displayed on the screen.

2 Press OSD again to clear the display.

The superimposed indication on the TV screen tells you what the VCR is doing.

Tuned-in channel or AUX(iliary) mode

When the channel is changed, the new

channel is displayed on the screen for 5

seconds.

Clock time

Stereo program indication

(HR-A54U only)

Second Audio Program indication

(HR-A54U only)

Tape position indicator

Audio mode indications (HR-A54U only)

CH 125 RECORD THU 12:00 AM PAUSE STEREO ] SP SAP

NORM HI–FI COUNT –1:23:45

NOTES:

●

If you engage the Record Pause mode, RECORD/PAUSE is displayed regardless of the Superimpose mode setting.

●

If you select a channel on which no signal is received, the channel number is displayed regardless of the Superimpose mode setting.

+++

INDEX-1

Counter reading

Move the highlight bar (arrow) to "SUPERIMPOSE" by pressing CH5∞ or %ﬁ, then press OK or to select the desired mode: a– Select "ON" if you want the superimposed opera-

tional indications on the TV screen.

b– Select "OFF" if you do not want the superimposed

operational indications on the screen.

RETURN TO NORMAL SCREEN

Press MENU.

Operation mode

When the operation mode is changed, the new mode is displayed — RECORD (5 sec.), PLAY (5 sec.), FF/REW (5 sec. when engaged from Stop mode), RECORD PAUSE (for as long as Pause is engaged), and ITR *:** (5 sec.).

Tape speed indication

"Cassette Loaded" mark

When a cassette is loaded, the mark is displayed for 5 seconds. It blinks when the VCR's EJECT button is pushed.

INDEX indication

12 3 4506

789

EN 19

Select The Soundtrack (HR-A54U Only)

Your VCR can record two soundtracks simultaneously (Normal and Hi-Fi) and play back the selected one, or both together. Or, when viewing a pre-recorded tape that contains two separate Hi-Fi audio programs, you can choose to listen to either one by selecting either "Hi-Fi L" or "Hi-Fi R" in step 3.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION SET" by pressing CH5∞ or %ﬁ, then press OK or .

SELECT AUDIO MONITOR SET MODE

Move the highlight bar (arrow) to "AUDIO

MONITOR" by pressing CH 5∞ or %ﬁ, then press

OK or to select the desired mode:

a– Hi-Fi b– Hi-Fi L c– Hi-Fi R d– Normal e– Mix

=AUTO TIMER OFF

=AUDIO MONITOR HI–FI

FUNCTION

SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

PREVIOUS PAGE 2ND AUDIO RECORD OFF

AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

RETURN TO NORMAL SCREEN

Press MENU.

NOTES:

●

If the tape being played back has no Hi-Fi soundtrack, the Normal soundtrack will be heard no matter what choice you make in step 3.

●

If RF connection is used for TV, even if Hi-Fi audio monitor is selected the sound will be mono and will be reproduced in both loudspeakers.

20 EN

POWER

PLAYBACK AND RECORDING FEATURES (cont.)

Auto Picture

Auto Picture compensates for variations in tape characteristics to ensure the best possible playback picture. It checks and compensates for the condition of the tape at the beginning of automatic tracking when playback is selected. The default setting is "ON".

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

POWER

Preparation

TURN ON THE VCR

Press POWER.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Press CH5∞ or %ﬁ to move the highlight bar

(arrow) to “FUNCTION SET”, then press OK or .

SELECT AUTO PICTURE

HR-A34U HR-A54U

= AUTO PICTURE ON

Press CH 5∞ or %ﬁ to move the highlight bar (arrow) to "AUTO PICTURE", then press OK or to set to "ON" or "OFF".

FUNCTION

AUTO TIMER OFF SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

= FUNCTION SET

=AUTO TIMER OFF

=AUTO PICTURE ON

MAIN MENU

TUNER SET INITIAL SET

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

FUNCTION

SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

PREVIOUS PAGE 2ND AUDIO RECORD OFF AUDIO MONITOR HI–FI

NOTE:

When using rental tapes, or tapes recorded on other VCRs, select "ON" or "OFF" as desired to give the best picture.

RETURN TO NORMAL SCREEN

Press MENU.

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

PLAY

12 3 4506

789

EN 21

Playback

The VCR assesses the quality of the tape once you start playback.

Perform steps 1 and 2 on page 12 ("Simple Playback") before continuing.

START PLAYBACK

Press PLAY.

● The VCR adjusts the

playback picture quality based on the quality of the tape in use.

AUTO PICTURE

NOTES:

●

When using rental tapes, or tapes recorded on other VCRs, set “AUTO PICTURE” in step 4 of the Preparation procedure to either “ON” or “OFF” as desired to give the best picture (Z pg. 20).

●

The Auto Picture screen only appears at the beginning of automatic tracking. Even though the screen doesn't appear after that, the Auto Picture function is operative.

●

To display the Auto Picture screen, “SUPERIMPOSE” must be set to "ON" or the Auto Picture screen will not appear (Z pg. 18).

22 EN

Recording Features

TV/VCR Indicator

PLAYBACK AND RECORDING FEATURES (cont.)

Record One Program While Watching Another

ENGAGE TV MODE

During recording...

● Press TV/VCR. The VCR's TV/VCR indicator goes out.

(If you are using the RF connection (Z pg. 6) to view the output from your VCR, the TV broadcast being recorded disappears.)

● If you are using the AV connection (Z pg. 6) to view the output from your VCR, change the TV's input mode from AV to TV.

SELECT CHANNEL FOR VIEWING

Use the TV’s channel selector to set the channel you want to watch.

Display Elapsed Recording Time

TV/VCR

C.RESET

12 3 4506

789

OSD

RESET COUNTER TO ZERO

Before recording starts, press C.RESET. The counter resets to zero and displays the exact elapsed time as the

tape runs.

DISPLAY ELAPSED TIME ON SCREEN

During recording, press OSD at any time to see the elapsed time.

All indications corresponding to the current status of the VCR are displayed for 5 seconds. The counter display remains on the screen indicating the elapsed time. Press OSD again to remove the display.

● Make sure "SUPERIMPOSE" is set to "ON" (Z pg. 18).

● The indications are not recorded.

MTS Indicator

12 3 4506

EN 23

Stereo And SAP (Second Audio Program) (HR-A54U Only)

Your VCR’s built-in MTS decoder enables reception of Multichannel TV Sound broadcasts. The MTS indicator lights during reception of stereo or SAP

broadcasts, and when a stereo program is accompanied by SAP audio. When the channel is changed...

● The "STEREO" indication appears on the screen for about 5 seconds if the program is a stereo broadcast.

● The "SAP" indication appears on the screen for about 5 seconds if the program is an SAP broadcast.

● Both indications appear when a stereo program is accompanied by SAP audio.

To Record Stereo Programs . . .

. . . simply follow the basic recording procedure.

To Listen To Stereo Soundtrack During Recording . . .

. . . set "AUDIO MONITOR" to "HI-FI" at the Function screen (

Z pg. 19).

To Record SAP Programs . . .

789

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION SET" by pressing CH5∞ or%ﬁ, then press OK or .

SELECT 2ND AUDIO RECORD SET MODE

Move the highlight bar (arrow) to "2ND AUDIO

RECORD" by pressing CH

∞ or %ﬁ, then press OK

or to set to "ON".

=AUTO TIMER OFF

SUPERIMPOSE ON AUTO SP VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

=2ND AUDIO RECORD ON

AUDIO MONITOR HI–FI AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

FUNCTION

=EP TIMER OFF

NOTES:

●

If a SAP program is received and "2ND AUDIO RECORD" is set to "ON", the SAP audio is recorded on both the Normal and Hi-Fi tracks. The main audio program is not recorded.

●

If a non-SAP program is received, the main audio is recorded on both the Hi-Fi and Normal audio tracks.

RETURN TO NORMAL SCREEN

Press MENU.

24 EN

PROG.

VCR Plus+ Timer Programming (HR-A54U Only)

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

TIMER RECORDING

Timer recording allows you to program the VCR to automatically record a program that will be broadcast at some future time. The timer record function can be programmed using VCR Plus+ or Express Timer Programming up to 8 shows as far as a year in advance. (Z pg. 24 or 28) The VCR Plus+ timer programming system eliminates the need to input channel, date, start and stop time data when setting the timer record function. Simply key in the PlusCode number for the TV program you wish to record and the VCR's timer will be automatically programmed. (The PlusCodes are the numbers next to the programs in most TV listings.)

LOAD A CASSETTE

Make sure the record safety tab is present.

● The VCR’s power comes on automatically.

ACCESS VCR PLUS+ SCREEN

Press PROG. on the remote control.

● The clock must be set in order to access the VCR Plus+ screen. If you haven’t set the clock, the Main Menu screen appears after an error message is displayed. Refer to page 9 for the clock setting procedure.

VCR PLUS+

PRESS NUMBER KEY (0–9) PRESS (+/–) TO SET

EXPRESS PROGRAMMING

PRESS (PROG.) TO END

CANCEL

12 3 4506

789

NUMBER

ENTER PLUSCODE NUMBER

Press the appropriate

NUMBER keys to enter the

PlusCode number printed in the TV listings for the TV program you wish to record and press OK.

If the Guide Channel Set screen appears, go to step

If the VCR Plus+ Program screen appears, go to step 5.

● To make corrections, press CANCEL and input the correct PlusCode number.

VCR PLUS+

123

PRESS NUMBER KEY (0–9)

PRESS (PROG.) TO END

INPUT RECEIVING CHANNEL NUMBER

The Guide Channel Number, which is assigned to the TV or cable station for the

PlusCode number that you entered in step 3, will appear automatically on the Guide Channel Set screen. Input the number of the channel on which the broadcast for the PlusCode number is received on the VCR or cable box using the NUMBER keys, CH 5∞ or %ﬁ, then press OK.

● The Guide Channel Set screen appears only when you input the PlusCode number of a station for which the Guide Channel number has not been set already.

GUIDE CHANNEL SET

GUIDE CH: 12

VCR CH : –– –

PRESS NUMBER KEY (0–9)

OR (5,∞), THEN (OK)

PRESS (PROG.) TO END

THEN (OK)

PROG.

NUMBER "9"

NUMBER "8"

TIMER Indicator

12 3 4506

CHECK PROGRAM DATA

The PlusCode number you entered and the matching

Timer-Recording information is displayed on the Program screen. Check to make sure it’s accurate.

● To change the stop time, press STOP +/–.

● To timer-record daily or weekly serials, press DAILY (NUMBER “8”) or WEEKLY (NUMBER “9”). “DAILY” or “WEEKLY” appears on the Program screen. Pressing the button again makes each corresponding display disappear.

● If you made a mistake, press CANCEL to access the VCR Plus+ screen again and input the correct PlusCode number.

● If the PlusCode number you inputted is incorrect, "ERROR" may appear on the screen to advise you of the error. This happens when the PlusCode number is for a program which has already passed. "ERROR" is displayed for about 5 seconds and the VCR Plus+ screen reappears.

(VCR PLUS+ 12345678)

START STOP 8:00PM = 10:00PM DATE CH

12/24/98 12 SP

THU

PRESS (8=DAILY, 9=WEEKLY STOP+/– = STOP TIME, SP/EP) PRESS (OK) TO END

EN 25

PROGRAM 1

ATTENTION

If there is a conflict in the timer schedule and one program overlaps with another, only the parts shown below in gray will be recorded.

Pattern 1: The program with the lower program number

Program 1

Program 2

Pattern 2: The program that is broadcast earlier will be

Program 1

Pattern 3: The program that is broadcast earlier will be

Program 1

789

SP/EP

CANCEL

STOP+/–

will be recorded.

10:00

recorded.

10:00

Program 2

recorded, followed by the remaining portion of the other program.

10:00

11:00

CH10 CH40 Not recorded

11:00

CH10

CH40

11:00

CH10

Program 2

Not recorded

12:00

Not recorded

12:00

TIMER

CH40

SET TAPE SPEED

Press SP/EP.

RETURN TO NORMAL SCREEN

Press PROG. or OK. "PROGRAM COMPLETED" appears on the screen for about 5 seconds, then normal

screen appears.

ENGAGE TIMER MODE

Press TIMER. The VCR turns off automatically and the VCR's TIMER indicator lights.

IMPORTANT

If you have moved to a different area or if a broadcasting station's channel number has been changed, the wrong VCR or CABLE CH number will be displayed on the VCR Plus+ Program screen in step 5. When this happens, set the correct the Guide Channel number for that station. (Z pg. 26, "VCR Plus+ Setup")

NOTES:

●

To disengage the timer before recording starts, press TIMER again. Pressing once more re-engages it.

●

In case of a power failure after programming, the VCR’s memory backup keeps your selections for approximately 3 minutes.

●

When timer-recording cable channels received through a Cable Box, be sure to keep the Cable Box set to ON.

26 EN

POWER

VCR Plus+ Setup

TIMER RECORDING (cont.)

IMPORTANT

If you have moved to a different area or if a broadcasting station's channel number has been changed, the wrong VCR or CABLE CH number will be displayed on the VCR Plus+ Program screen (Z step 5 on page 25). When this happens, perform the following steps to set the correct the Guide Channel number for that station.

(HR-A54U Only)

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

POWER

To ensure that VCR Plus+Timer Recording operates correctly it is necessary to set the VCR Plus+ "Guide Channel Set " for each station. Please read the following information carefully.

VCR Plus+ Guide Channel Matching

VCR Plus+ assigns a VCR Plus+ "Guide Channel" to broadcast and cable TV channels. These Guide Channel numbers are also called the VCR Plus+ Channel Codes. Most TV listings have a section, usually a chart, indicating the "Guide Channel" numbers assigned to each station. For accurate VCR Plus+ Programming the VCR Plus+ Guide Channel number for each station should match the channel number on which it is received in your area.

NOTES:

●

In many instances the VCR Plus+ Guide Channel numbers for cable and broadcast TV stations DO NOT match the channel number on which it is received by your VCR or cable box. Check your TV listing, or contact your cable supplier for details.

●

Many broadcast TV stations can be viewed on cable. Check your TV listing, or contact your cable supplier for details.

TURN ON THE VCR

Press POWER.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS INITIAL SET SCREEN

Press CH move the highlight bar (arrow) to “INITIAL SET”,

then press OK or .

∞

ﬁ

MAIN MENU

FUNCTION SET TUNER SET

= INITIAL SET

PRESS (5,∞), THEN (OK) PRESS (MENU) TO END

12 3 4506

789

NUMBER

ACCESS GUIDE CHANNEL SET SCREEN

Press CH5∞ or %ﬁ to move the highlight bar

(arrow) to “GUIDE CHANNEL SET”, then press OK or .

CLOCK SET LANGUAGE ENGLISH

=GUIDE CHANNEL SET

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

INPUT GUIDE CHANNEL NUMBER

Press CH5∞, %ﬁ or the appropriate NUMBER

keys to input the VCR Plus+ Guide Channel number as shown in the TV listing. Then press OK

or .

(Ex.) When inputting the Guide Channel number 6 for WNJU(Ind.)

GUIDE CHANNEL SET

GUIDE CH : 6

VCR CH : – – –

PRESS NUMBER KEY (0-9)

OR (5,∞), THEN (OK)

PRESS (MENU) TO END

INPUT RECEIVING CHANNEL NUMBER

Press CH5∞, %ﬁ or the appropriate NUMBER keys

to input the number of the channel on which the Guide Channel’s broadcasts are received. Then press OK or .

● Repeat steps 5 and 6 for

each instance.

(Ex.) If WNJU(Ind.) is received on channel 47

GUIDE CHANNEL SET

GUIDE CH : 6

VCR CH : 47

PRESS NUMBER KEY (0-9)

OR (5,∞), THEN (OK)

PRESS (MENU) TO END

EN 27

INITIAL SET

RETURN TO NORMAL SCREEN

Press MENU.

ATTENTION CABLE BOX SUBSCRIBERS

● In order to set the Guide Channel for a cable program, you must select your cable box's output channel as the VCR channel in step 6. If the cable box is connected to your VCR's ANT. IN connector, select the cable box's RF output channel. If the cable box is connected to your VCR's VIDEO IN and AUDIO IN connectors, press NUMBER key "0" to select "F-1" as the VCR channel.

● It is important that you keep the cable box ON and tuned to the cable station of the program you want to record until timer recording is completed.

28 EN

PROG.

STOP+/–

DATE+/–

Express Timer Programming

Turn on the TV and select the VCR channel 3 or 4 (or AV mode).

12 3 4506

789

START+/–

TIMER RECORDING (cont.)

You can directly program the VCR’s timer to record up to 8 shows, as far as a year in advance. Remember, the clock must be set before you can program the timer (Z pg. 9).

LOAD A CASSETTE

Make sure the record safety tab is intact. If not, cover the hole with adhesive tape, then load it into the VCR.

● The VCR comes on, and the counter is reset, automatically.

ACCESS PROGRAM SCREEN

Press PROG. If you own the HR-A54U,

press PROG., then START +/–. (If you're just starting

out, "PROGRAM 1" appears.)

● The screen to the right appears.

PROGRAM 1

START STOP

– –:– –AM = – –:– –AM

DATE CH

– –/– –/– – – – – SP

PRESS (+/–, SP/EP, 8=DAILY, 9=WEEKLY), THEN (0K) PRESS (PROG.) TO END

SET PROGRAM START TIME

Press START +/– to enter the time you want

recording to start.

● Press and hold START +/– to move in 30-

minute increments, or press and release repeatedly to move 1 minute at a time.

PROGRAM 1

START STOP

8:00 AM = – –:– –AM

DATE CH

– –/– –/– – – – – SP

PRESS (+/–, SP/EP, 8=DAILY, 9=WEEKLY), THEN (0K) PRESS (PROG.) TO END

SET PROGRAM STOP TIME

Press STOP +/– to enter the time you want recording to stop.

● Press and hold STOP +/– to move in 30-minute increments, or press and release repeatedly to move 1 minute at a time.

SET PROGRAM DATE

Press DATE +/–. (The current date is displayed on screen. The date you enter appears in its place.)

SET CHANNEL NUMBER

Press CH 5∞.

● Holding down CH 5∞ rapidly scans through the

channels.

● If you are using a cable box (or DBS receiver), enter the cable box (or DBS receiver) channel, not the channel to be recorded. The channel to be recorded must be selected on the cable box (or DBS receiver). (The cable box (or DBS receiver) channel is the VCR's channel that displays the channels received by the cable box (or DBS receiver).)

NUMBER "8"

PROG.

TIMER Indicator

SET TAPE SPEED

Press SP/EP to set the tape speed.

RETURN TO NORMAL SCREEN

Press PROG. or OK. "PROGRAM COMPLETED" appears on the screen for about 5 seconds, then normal

screen appears.

ENGAGE TIMER MODE

Press TIMER. The VCR turns off automatically and the VCR's TIMER indicator lights.

EN 29

ATTENTION

If there is a conflict in the timer schedule and one program overlaps with another, only the parts shown below in gray will be recorded.

Pattern 1: The program with the lower program number

Program 1

Program 2

Pattern 2: The program that is broadcast earlier will be

Program 1

Pattern 3: The program that is broadcast earlier will be

Program 1

12 3

12:00

NUMBER "9"

TIMER

CH40

4506

789

SP/EP

will be recorded.

10:00

recorded.

10:00

Program 2

recorded, followed by the remaining portion of the other program.

10:00

11:00

CH10 CH40 Not recorded

11:00

CH10

CH40

11:00

CH10

Program 2

Not recorded

To Timer-Record Weekly Or Daily Serials . . .

. . . anytime during steps 2 through 8, press WEEKLY (NUMBER key “9”) for weekly serials or DAILY (NUMBER key “8”) for daily serials (Monday–Friday). Either "WEEKLY" or "DAILY" appears on the screen. Pressing the button again makes the corresponding indication disappear.

NOTES:

●

To disengage the timer before recording starts, press TIMER again. Pressing once more re-engages it.

●

In case of a power failure after programming, the VCR’s memory backup keeps your selections for approximately 3 minutes.

●

Programs that start after midnight must have the next day’s date.

●

After timer recording is completed, the VCR’s power goes off automatically.

●

You can program the timer while a regular recording is in progress; the on-screen menu will not be recorded.

●

If the end of tape is reached during timer recording, the cassette is automatically ejected.

●

When timer-recording cable or satellite channels through an external tuner, be sure to keep the cable box or satellite receiver's power ON.

30 EN

STOP+/–

DATE+/–

POWER

PROG. CHECK

SP/EP

CANCEL

START+/–

12 3 4506

789

POWER

TIMER

TIMER RECORDING (cont.)

Check, Cancel And Revise Programs

DISENGAGE TIMER

Press TIMER, then press POWER.

ACCESS PROGRAM CHECK SCREEN

Press PROG. CHECK.

PR START STOP CH DATE 1 8:00P 10:00 12 12/24 2 10:00A 10:45 40 12/25 3 11:30P 01:00 125 12/25 4 5 6 7 8

PRESS (CHECK) TO NEXT

ACCESS PROGRAM SCREEN

Press PROG. CHECK again to check more information. Each time you press PROG. CHECK, the next program's

information appears.

To Cancel Or Revise A Program...

CANCEL OR REVISE A PROGRAM

To cancel a program, press CANCEL. To revise a program, press the appropriate button:

START+/–, STOP+/–, DATE+/–, CH5∞, SP/EP.

RETURN TO NORMAL SCREEN

Press PROG. CHECK as many times as necessary. If there are still programs remaining, go to step 6.

RE-ENGAGE TIMER

Press TIMER.

EN 31

Auto SP→EP Timer

If, when recording in SP mode, there is not enough tape to record the entire program, the VCR automatically switches to EP mode to allow complete recording. This feature is especially handy when recording a program of more than 2 hours in length.

For Example . . .

Recording a program of 140 minutes in length onto a 120minute tape

Approximately 110 minutes

SP mode

Total 140 minutes

Make sure you set "AUTO SP→EP TIMER" to “ON” at the Function screen before the timer recording starts.

Approximately 30 minutes

EP mode

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION SET" by pressing CH 5∞ or %ﬁ, then press OK or .

SELECT AUTO SP→EP TIMER SET MODE

HR-A34U HR-A54U

=AUTO SP

Move the highlight bar (arrow) to "AUTO SP→EP TIMER" by pressing CH 5∞ or %ﬁ, then press OK or to set to "ON".

FUNCTION

AUTO TIMER OFF SUPERIMPOSE ON

=EP TIMER ON

VIDEO STABILIZER OFF AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

= AUTO SP

RETURN TO NORMAL SCREEN

Press MENU.

FUNCTION

AUTO TIMER OFF SUPERIMPOSE ON

=EP TIMER ON

VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

Auto Timer

When the Auto Timer is set to ON the timer is automatically engaged when the VCR's power is turned off. It is automatically disengaged when the VCR is powered back on.

ACCESS MAIN MENU SCREEN

Press MENU.

ACCESS FUNCTION SET SCREEN

Move the highlight bar (arrow) to "FUNCTION SET" by pressing CH5∞ or %ﬁ, then press OK or .

SELECT AUTO TIMER SET MODE

HR-A34U HR-A54U

=AUTO TIMER OFF

Move the highlight bar (arrow) to "AUTO TIMER" by pressing CH "ON" or "OFF".

FUNCTION

SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF AUTO PICTURE ON

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

ﬁ

∞

=AUTO TIMER OFF

, then press OK or to set to

RETURN TO NORMAL SCREEN

Press MENU.

NOTE:

For safety, when AUTO TIMER is set to “OFF”, all other VCR functions are disabled while the Timer mode is engaged. To disengage the timer, press TIMER.

FUNCTION

SUPERIMPOSE ON AUTO SP

=EP TIMER OFF

VIDEO STABILIZER OFF NEXT PAGE

SELECT WITH (5,∞) AND (OK) PRESS (MENU) TO END

NOTES:

●

If you have programmed the VCR to timer-record 2 or more programs, the second program and those thereafter may not fit on the tape if you set the Auto SP→EP Timer mode to "ON". In this case, make sure the mode is not engaged, then set the tape speed manually during timer programming.

●

In order to ensure that the recording fits on the tape, this feature may leave a slight non-recorded section at the end of the tape.

●

There may be some noise at the point on the tape where the VCR switches from SP to EP mode.

●

The Auto SP→EP Timer feature is not available during ITR (Instant Timer Recording), and the feature will work with the following tapes: T(ST)-30, T(ST)-60, T(ST)-90, and T(ST)-120.

32 EN

REC

Instant Timer Recording (ITR)

REC Indicator

TIMER RECORDING (cont.)

This easy method lets you record from 30 minutes to 6 hours (selectable in 30-min. increments) and shuts the VCR off after recording is finished.

START RECORDING

Press REC on the front panel.

ENGAGE ITR MODE

Press REC again. "ITR 0:30" appears on screen and "ITR" blinks for about 5 seconds.

● The REC indicator blinks on the front display panel.

SET RECORDING DURATION

If you want to record for more than 30 minutes, press

REC to extend the time. Each press extends recording

time by 30 minutes.

NOTES:

●

You can only perform ITR using the REC button on the VCR's front panel.

●

After you set the ITR time, the previous display reappears.

●

To check the remaining time, press REC once during record- ing and the remaining time will be displayed for about 5 seconds. Be careful not to press REC again within these 5 seconds, or you will round the recording time up to the next 30 minute increment.

EDITING

PLAY

EN 33

You can use your VCR as the player and another VCR as the recorder.

Edit To Another VCR

Player Your VCR

AUDIO OUT

VIDEO IN AUDIO IN

Recorder

VIDEO OUT

Audio/Video Cable (not supplied)

Another VCR

MAKE CONNECTIONS

Connect an AV cable between your VCR's VIDEO OUT and AUDIO OUT connectors and another VCR’s

VIDEO IN and AUDIO IN connectors.

For HR-A54U owners...

● When connecting to a monaural VCR, connect your VCR's AUDIO OUT L connector to the AUDIO IN connector on the monaural VCR.

For HR-A34U owners...

● When connecting to a Hi-Fi VCR, connect your VCR's AUDIO OUT connector to the AUDIO IN L connector on the Hi-Fi VCR.

LOAD CASSETTES

Insert the playback cassette into your VCR and the cassette to be recorded on into the other VCR.

SET RECORDER’S INPUT MODE

Set the other VCR's auxiliary (AV) input mode.

START PLAYER

Press PLAY on your VCR.

NOTE:

If you don't want to record the superimposed indication on the edited tape, be sure to set "SUPERIMPOSE" to OFF before pressing PLAY (Z pg. 18).

START RECORDER

Set the other VCR to its record mode.

34 EN

NUMBER "0"

EDITING (cont.)

You can use a camcorder or another VCR as the player and your VCR as the recorder.

Edit From A Camcorder Or Another VCR

Recorder Your VCR

AUDIO IN

VIDEO IN

Camcorder

Another VCR

AV cable (not supplied)

Player

VIDEO OUT

AUDIO OUT

MAKE CONNECTIONS

Connect an AV cable between the camcorder’s or the playback VCR's VIDEO OUT and AUDIO OUT

connectors and your VCR’s VIDEO IN and AUDIO IN connectors.

For HR-A54U owners...

● When using a monaural camcorder or a monaural VCR, connect its AUDIO OUT connector to the AUDIO IN L connector on your VCR.

For HR-A34U owners...

● When using a Hi-Fi camcorder or a Hi-Fi VCR, connect its AUDIO OUT L connector to the AUDIO IN connector on your VCR.

LOAD A CASSETTE

Insert the cassette to be recorded on into your VCR and the playback cassette into the camcorder or the

playback VCR.

SET RECORDER’S INPUT MODE

Press NUMBER key “0” to set your VCR to F-1.

START PLAYER

Set the camcorder or the playback VCR to its play mode.

NOTE:

If the camcorder or another VCR is equipped with a superimpose/OSD disable feature then set its superimpose or display feature to OFF before pressing play.

START RECORDER

Set your VCR to its record mode.

12 3 4506

789

TROUBLESHOOTING

Before requesting service for a problem, use this chart and see if you can repair the trouble yourself. Small problems are often easily corrected, and this can save you the trouble of sending your VCR off for repair.

EN 35

POWER

SYMPTOM

1. The power won’t come on.

2. The clock works, but the VCR’s power won’t come on.

3. The remote control won’t function.

TAPE TRANSPORT

SYMPTOM

1. The cassette gets stuck partway during loading, and is ejected.

PLAYBACK

SYMPTOM

1. The tape is running but the picture won’t appear.

2. Noise appears during visual search.

3. (HR-A54U only) Breaks are noticeable in Hi-Fi soundtrack.

4. The playback picture is blurred or interrupted, even though TV broadcasts are clear.

5. (HR-A54U only) The Hi-Fi soundtrack cannot be heard.

POSSIBLE CAUSE

● The power cord is disconnected.

● The TIMER mode is engaged with

Auto Timer set to "OFF" (Z pg. 31).

● The batteries are discharged.

POSSIBLE CAUSE

● The cassette was inserted incorrectly.

POSSIBLE CAUSE

● If you’re using the RF OUT connection (Z pg. 6), the channel selector on the TV is set incorrectly.

● If you’re using the AV connection (Z pg. 6), the TV receiver is set to the wrong mode.

● This is normal.

● Automatic tracking is engaged.

● The video heads may be dirty.

● The AUDIO MONITOR option was

set incorrectly.

CORRECTIVE ACTION

Connect the power cord. Press TIMER to disengage.

Replace the dead batteries with new ones.

CORRECTIVE ACTION

Make sure the cassette's window is facing up, the rear label side is facing you and the arrow on the front of the cassette is pointing towards the VCR. Then insert the cassette.

CORRECTIVE ACTION

Set the channel selector to channel 3 or 4.

Set the TV receiver to its AV mode.

Disengage Auto Tracking and adjust the tracking manually (Z pg. 15).

The heads must be cleaned. Consult your JVC dealer.

Set AUDIO MONITOR to "HI-FI" (Z pg. 19).

RECORDING

SYMPTOM

1. Recording won’t start.

2. TV broadcasts won’t record properly.

3. Tape-to-tape editing won’t work.

POSSIBLE CAUSE

● There’s no cassette loaded.

● The loaded cassette has had its

record safety tab removed.

● The VCR has been set to its AUX mode by mistake.

●The VCRs or the camcorder and the VCR have been incorrectly connected.

● The power to one or more of the units has not been turned on.

● The recorder’s input mode has been set incorrectly.

CORRECTIVE ACTION

Insert a cassette. Remove the cassette and cover the hole with adhesive tape, or load a cassette on which the record safety tab is intact.

Set the VCR to the appropriate channel.

Refer to the directions and the illustration under “Edit To Another VCR” (

Z pg. 33) or “Edit From A

Camcorder Or Another VCR” (Z pg.

34) and properly connect the units. Make sure the power to all units is on.

Select the recorder’s appropriate input mode.

CONTINUED ON NEXT PAGE

36 EN

TIMER RECORDING

TROUBLESHOOTING (cont.)

SYMPTOM

1. Timer recording won’t work.

2. Timer programming won’t work.

3. The Timer indicator on the front of the VCR won’t stop blinking.

4. The Timer indicator on the front of the VCR blinks for 10 seconds and the timer mode is disengaged.

5. The cassette is automatically ejected, the power shuts off and the Timer indicator on the front of the VCR won’t stop blinking.

6. (HR-A54U only) We moved, and now VCR Plus+ doesn’t work properly.

7. “PROGRAM FULL” is displayed on the screen.

POSSIBLE CAUSE

● The clock and/or the timer have been set incorrectly.

● The timer is not engaged.

● The VCR has not been set up properly.

● Timer recording is in progress.

● The timer is engaged but there’s no

cassette loaded.

● The loaded cassette has had its record safety tab removed.

● TIMER has been pressed when there are no programs in memory, or the timer record program information has not been programmed correctly.

● The end of tape was reached during timer recording.

● The receivable stations in the new area are received on different channels than those in the previous area.

● All 8 programs of the VCR’s timer memory are used.

CORRECTIVE ACTION

Set the clock and/or timer correctly.

Press TIMER and check to make sure that the TIMER indicator on the front panel lights. Re-perform the set-up procedures.

Timer programming can’t be performed when timer recording is in progress. Wait until it finishes.

Load a cassette with the record safety tab intact, or with the hole covered with adhesive tape. Press TIMER so that the Timer indicator on the front panel goes out, then eject the cassette and cover its hole with adhesive tape, or replace it with a cassette on which the safety tab is intact.

Check the programmed data and reprogram as necessary, then press TIMER again.

The program may not have been recorded in its entirety. Next time make sure you have enough time on the tape to record the entire program.

Re-perform the VCR Plus+ setup procedure (

Wait until a space in memory clears, or cancel unnecessary program information (Z pg. 30).

Z pg. 26).

OTHER PROBLEMS

SYMPTOM

1. When scanning channels, some of them are skipped over.

2. The channel can’t be changed.

● Those channels have been preset to

● Recording is in progress.

POSSIBLE CAUSE

be skipped.

ATTENTION:

This VCR contains microcomputers. External electronic noise or interference can cause microcomputer to malfunction. If the VCR does not operate correctly switch its power off and unplug the power cord from the AC supply. Wait for a while and then plug the power back in. Eject and check the condition of the cassette. If everything appears normal resume operating the VCR as usual.

CORRECTIVE ACTION

If you need the skipped channels, restore them (Z pg. 11).

Press PAUSE to pause the recording, change channels, then press PLAY to resume recording.

QUESTIONS AND ANSWERS

EN 37

PLAYBACK

Q. What happens if the end of the tape is reached

during playback or search?

A. The tape is automatically rewound to the beginning.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Can the VCR indefinitely remain in the still mode? A. No. It stops automatically after 5 minutes to protect

the heads.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. During search, slow, still and frame-by-frame

playback, I can’t hear any audio. What’s the problem?

A. This is normal.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. During search, still and frame-by-frame playback,

the picture is intermittent. What’s the cause?

A. Picture loss occurs when these types of playback are

attempted with a tape recorded in LP mode. Pressing PLAY to return to normal playback will restore the picture.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. When returning from search to normal playback, the

picture is disturbed. Should I be concerned about this?

A. No, it is normal.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Noise bars appear during search. What’s the

problem?

A. This is normal.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. When playing back programs that have been timer-

recorded with consecutive times (such one program from 8:00 to 9:00 and another one from 9:00 to 10:00), the picture and sound become momentarily distorted at the point where the first program ends and the second program begins. Is this a malfunction?

A. No. This is normal.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Other than preventing further recording, what effect

does removing the safety tab have?

A. It disables marking of index codes.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Sometimes, during Index Search, the VCR can’t find

the program I want to see. Why not?

A. There may be index codes too close together.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. During playback, on-screen operational indicators

sometimes jitter. Why does this happen?

A. If the condition of the tape being played back is not

good, jittering of the video (including on-screen indicators) may occur.

RECORDING

Q. When I pause and then resume a recording, the end

of the recording before the pause is overlapped by the new recording. Why does this happen?

A. This is normal. It reduces distortion at the pause and

resume points.

○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Can the VCR indefinitely remain in the Record-Pause

mode?

A. No. The VCR automatically goes to its Stop mode

after 5 minutes to protect the heads. When paused during Instant Timer Recording (ITR), the VCR shuts off automatically after 5 minutes.

○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. What happens if the tape runs out during recording? A. The VCR automatically rewinds it to the beginning.

TIMER RECORDING

Q. The REC and TIMER indicators on the front panel

remain lit. Is there a problem?

A. No. This is a normal condition for a timer recording

in progress.

○○ ○○○○○○○○○○○○○○○○○○○○○○○○○○

Q. Can I program the timer while I’m watching a tape

or a TV broadcast?

A. Yes, but while you are setting the timer you won't see

the tape's or broadcast program's picture as it is replaced by the on-screen menu. The audio from the tape or broadcast program will be present during the setting of the timer.

38 EN

List Of Terms

This guide serves as a quick way to locate frequently used terms and on-screen display names.

INDEX

Add Channel ............................................................... 11

Audio Monitor ............................................................ 19

Auto Channel Setting ..................................................10

Auto Daylight Saving Time............................................9

Auto Picture ................................................................20

Auto SP→EP Timer ......................................................31

Auto Timer ..................................................................31

Automatic Tracking .....................................................15

Aux Input ....................................................................33

AV Connection .............................................................6

Band ...........................................................................10

Cancel Program .......................................................... 30

Cassette Adapter.................................... ......................12

Check Program ........................................................... 30

Clock Setting .................................................................9

Connection to TV ..........................................................6

Contents........................................................................5

Counter Reset..............................................................17

Delete Channel ...........................................................11

Editing.........................................................................33

Express Timer Programming ........................................28

Express Timer Recording .............................................28

Frame-by-Frame Playback ...........................................14

Guide Channel Setting ................................................27

Index Search ...............................................................14

Insert Cassette .............................................................12

ITR (Instant Timer Recording) ......................................32

Language Selection .......................................................8

Main Menu ...................................................................8

Manual Channel Setting ..............................................11

Manual Tracking .........................................................15

Next-Function Memory ...............................................17

On-Screen Display ......................................................18

Playback .....................................................................12

Record Safety Tab .......................................................13

Recording ................................................................... 13

Repeat Playback..........................................................17

RF Connection ..............................................................6

SAP (Second Audio Program) ......................................23

Second Audio ............................................................. 23

Slow Motion Playback ................................................ 14

Specifications ..............................................................41

SQPB (S-VHS Quasi Play Back) ...................................12

Still Picture Playback...................................................14

Superimpose ...............................................................18

Tape Position Indicator ................................................17

Tape Speed Setting ......................................................13

Tuner Setting ...............................................................10

VCR Plus+ Timer Programming ................................... 24

VCR Plus+ Timer Recording ........................................24

Video Stabilizer...........................................................16

FRONT VIEW

EN 39

POWER

VIDEO

(MONO)

L–AUDIO–R

POWER

1 Power On/Off Button (Z pg. 8) 2 Cassette Loading Slot 3 Rewind [REW] Button (Z pg. 12) 4 PLAY Button (Z pg. 12) 5 Fast-Forward [FF] Button (Z pg. 12) 6 VIDEO/AUDIO Input Connectors (Z pg. 34)

* The HR-A34U has only one AUDIO input connector.

7 MENU Button (Z pg. 8)

FRONT PANEL INDICATORS

TV/VCR TIMER REC MTB

8 Front Panel Indicators (See below) 9 Remote Control Sensor 0 Channel [CH] 5∞ Button (Z pg. 13) ! OK Button (Z pg. 8) @ Record [REC] Button (Z pg. 13) # STOP/EJECT Button (Z pg. 12) $ PAUSE Button (Z pg. 14)

3 4

REW FF

REC

PLAY

STOP/EJECT

#! @87

PAUSE

POWER TIMER REC MTS

TV/VCR

4 5 1

REAR VIEW

1 Power Cord (Z pg. 6) 2 ANT. IN Connector (Z pg. 6) 3 Channel 3/4 Switch (Z pg. 6)

1 Power Indicator 2 VCR Mode Indicator (Z pg. 22) 3 Timer Mode Indicator (Z pg. 25) 4 Recording Mode Indicator (Z pg. 13) 5 Multichannel TV Sound Indicators

(HR-A54U only)(Z pg. 23)

ANT. IN

OUT

AUDIO

RF OUT

VIDEO

CH3 CH4

4 VIDEO/AUDIO Output Connectors (Z pg. 33)

* The HR-A34U has only one AUDIO output connector.

5 RF OUT Connector (Z pg. 6)

40 EN

3 4

0 !

@ # $

1 2

^ &

w e

( ) q

REMOTE CONTROL

DISPLAY

TV/VCR

SP/EP

CANCEL

C.RESET OSD

START

REW FF

REC

Buttons with a small dot on the left side of the name can also be used to operate your JVC TV while holding down the TV button.

Installing Batteries

1 Open the battery compartment cover. 2 Insert 2 "AA"-size batteries (provided) in the direction

indicated under the battery cover.

3 Replace the cover.

TV operation – Press and hold TV button, then press POWER, TV CH +/–, VOL +/–, TV/VCR

PROG.

CHECK

12 3 45

DAILY9WEEKLY

AUX

ENTER

STOP DATE CH

PLAY

STOP

TV CH +

TV VOL –

TV CH –

POWER

TIMER

PAUSE

+ VOL

INDEX (cont.)

1 PROG. Button (Z pg. 24, 28) 2 TV Button (See below) 3 DISPLAY Button (No Function) 4 TV/VCR Button (Z pg. 22) 5 Recording Speed [SP/EP] Button (Z pg. 13) 6 ENTER Button (Z pg. 13)

On-Screen Display [OSD] Button (Z pg. 18)

7 CANCEL Button (Z pg. 30)

Counter [C.] RESET Button (Z pg. 17)

8 START +/– Button (Z pg. 28) 9 STOP +/– Button (Z pg. 28) 0 Rewind [REW] Button (Z pg. 12) ! PLAY Button (Z pg. 12) @ Record [REC] Button (Z pg. 13) # MENU Button (Z pg. 8) $ OK Button (Z pg. 8) % PROG. CHECK Button (Z pg. 30) ^ POWER On/Off Button (Z pg. 8) & NUMBER Buttons (Z pg. 13, 24) * DAILY Timer Recording Button (Z pg. 25, 29) ( WEEKLY Timer Recording Button (Z pg. 25, 29) ) "AUX" Mode Select Button (Z pg. 34) q TIMER Button (Z pg. 25, 29) w Channel [CH] 5∞ Button (Z pg. 13, 29) e DATE +/– Button (Z pg. 28) r Fast-Foward [FF] Button (Z pg. 12) t STOP Button (Z pg. 12) y PAUSE Button (Z pg. 14) u %ﬁ Button (Z pg. 8)

TV Channel [CH] +/– Button (See below)

i ™£ ( ) Button (Z pg. 14)

ﬁ

TV Volume [VOL] +/– Button (See below)

How To Use

The remote control can operate most of your VCR's functions.

1 Point the remote control toward the sensor window. 2 Press the appropriate operation button. 3 The maximum operating distance of the remote control

is about 8 m.

Operating JVC TVs

To operate your TV, while holding down TV, press the corresponding button: POWER, TV/VCR, TV CH +/–. TV VOL +/– can be used without holding down TV.

NOTES:

●

Depending on the type of JVC TV, there may be cases where some or all functions cannot be operated using the remote control.

●

If the remote control doesn't work properly, remove its batteries, wait a short time, replace the batteries and then try again.

SPECIFICATIONS

EN 41

GENERAL

Power requirement : AC 120 V` , 60 Hz Power consumption

Power on : 22 W (HR-A54U)

: 20 W (HR-A34U)

Power off : 2 W

Temperature

Operating : 5°C to 40°C (41°F to 104°F)

Storage : –20°C to 60°C (–4°F to140°F) Operating position : Horizontal only Dimensions (W x H x D) : 360 x 94 x 273 mm

(14-3/16" x 3-3/4" x 10-3/4") Weight : 3.0 kg (6.6 lbs) Format : VHS NTSC standard Maximum recording time

SP : 210 min. with ST-210 video

cassette

EP : 630 min. with ST-210 video

cassette

VIDEO/AUDIO

Signal system : NTSC-type color signal and

EIA monochrome signal, 525

lines/60 fields Recording/ Playback system : DA-4 (Double Azimuth) head

helical scan system Signal-to-noise ratio : 45 dB Horizontal resolution : 240 lines Frequency range

Normal audio : 70 Hz to 10,000 Hz Hi-Fi audio (HR-A54U only) : 20 Hz to 20,000 Hz

Input/Output : RCA connectors

(IN x 1, OUT x 1)

TIMER

Clock reference : Quartz Program capacity : 1-year programmable timer/

8 programs

Memory backup time : Approx. 3 min.

ACCESSORIES

Provided accessories : RF cable (F-type),

Infrared remote control unit, “AA” battery x 2

Specifications shown are for SP mode unless otherwise specified. E. & O.E. Design and specifications subject to change without notice.

TUNER

Tuning system : Frequency-synthesized tuner Channel coverage

VHF : Channels 2–13 UHF : Channels 14–69 CATV : 113 Channels

RF output : Channel 3 or 4 (switchable;

preset to Channel 3 when

shipped) 75 ohms,

unbalanced

42 EN

FOR SERVICING (Only in U.S.A.)

HOW TO LOCATE YOUR JVC SERVICE CENTER

TOLL FREE: 1-800-252-5722

Dear customer:

In order to receive the most satisfaction from your purchase, read the instruction booklet before operating the unit. In the event that repair is necessary, or for the address nearest your location, please refer to the factory service center list below or within the Continental United States, call 1-800-252-5722 for your authorized servicer. Remember to retain your Bill of Sale for Warranty Service.

JVC SERVICE & ENGINEERING

COMPANY OF AMERICA

DIVISION OF US JVC CORP.

FACTORY SERVICE CENTER LOCATIONS

107 Little Falls Road 1500 Lakes Parkway 705 Enterprise Street Fairfield, NJ 07004-2105 Lawrenceville, GA 30243-5857 Aurora, IL 60504-8135 (973) 808-9279 (770) 339-2522 (630) 851-7855

5665 Corporate Avenue 10700 Hammerly Boulevard, Suite 110 2969 Mapunapuna Place, Suite 101 Cypress, CA 90630-4727 Houston, TX 77043-2310 Honolulu, HI 96819-2000 (714) 229-8011 (713) 935-9331 (808) 833-5828

— JVC

230 Eliot Street 8192 W State Road 84 890 Dubuque Avenue Ashland, MA 01721-2377 Davie, FL 33324-4611 South San Francisco, CA 94080-1804 (508) 881-5923 (954) 472-1960 (415) 871-2666

Sophisticated electronic products may require occasional service. Just as quality is a keyword in the engineering and production of the wide array of JVC products, service is the key to maintaining the high level performance for which JVC is world famous. The JVC service and engineering organization stands behind our products.

NATIONAL HEADQUARTERS

JVC SERVICE & ENGINEERING COMPANY OF AMERICA

DIVISION OF US JVC CORP.

107 Little Falls Road

Fairfield, NJ 07004-2105

If you ship the product...

Pack your JVC unit in the original carton or one of equivalent size and strength. Enclose, with the unit, a letter stating the problem or symptom that exists and also a copy of the receipt or bill of sale you received when you purchased your JVC unit. Print your home return address on the outside and the inside of the carton. Send to the appropriate JVC Factory Service Center as listed above.

Don't service it yourself.

CAUTION

To prevent electrical shock, do not open the cabinet. No user serviceable parts inside. Refer servicing to qualified service personnel.

ACCESSORIES

To purchase accessories for your JVC product, you may contact your local JVC Dealer. Or from the 48 Continental United States call toll free: 1-800-882-2345.

WARRANTY (Only in U.S.A.)

EN 43

LIMITED WARRANTY CONSUMER VIDEO 1-90

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONL Y TO THE ORIGINAL PURCHASER A T RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period as shown below. ("The Warranty Period")

PARTS LABOR

1 YR 90 DAYS

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts thereof may be brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen size 25 inches and above which are covered on an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized service center, please call toll free: (800) 252-5722.

If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with a copy of your bill of sale plus a letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location of which will be given to you by the toll-free number.

If you have any questions concerning your JVC Product, please contact our Customer Relations Department.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by JVC to render such service, or if affixed to any attachment not provided with the products, or if the model or serial number has been altered, tampered with, defaced or removed;

2. Initial installation and installation and removal for repair;

3. Operational adjustments covered in the Owner's Manual, normal maintenance, video and audio head cleaning;

4. Damage that occurs in shipment, due to act of God, and cosmetic damage;

5. Signal reception problems and failures due to line power surge;

6. Video Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus (Needle) are covered for 90 days from the date of purchase;

7. Accessories;

8. Batteries (except that Rechargeable Batteries are covered for 90 days from the date of purchase); from the date of purchase);

There are no other express warranties except as listed above. THE DURATION OF ANY IMPLIED WARRANTIES INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS

LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER

DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE T O TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential dameges or limitations on how long an implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

JVC COMPANY OF AMERICA 41 Slater Drive DIVISION OF US JVC CORP. Elmwood Park, New Jersey 07407

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF REFURBISHED PRODUCT WARRANTY, PLEASE REFER T O THE REFURBISHED PRODUCT WARRANTY INFORMATION PACKAGED WITH EACH REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. and Serial No. which is located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No.: Serial No.: Purchase date: Name of dealer:

HR-A54U/34U

JVC COMPANY OF AMERICA

DIVISION OF US JVC CORP.

41 Slater Drive, Elmwood Park, N.J. 07407

21 Finchdene Square, Scarborough Ontario M1X 1A7

JVC CANADA INC.

U/U(C)

Printed in Malaysia 0298 IYV*UN*PJ

JVC HR-A34U, HR-A54U User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
