JVC HM-HDS1MS Parts List

Download

SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSORY ASSEMBLY <M1>

The instruction manual to be provided with this product will differ according to the destination.

302

306

306A

FINAL ASSY <M2>

ADHESIVE TAPE

318

319

302

SPEC OF BARCODE

311

303

317

ADHESIVE TAPE

310

315

307

312

314

308

301

SPEC OF BARCODE

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

PACKING AND ACCESSORY ASSEMBLY <M1>

301 LP30823-016A PACKING CASE 302 LP30868-001B CUSHION ASSY 303 PQM30021-95 POLY BAG 306 LP20873-009B REMOTE CONTROLLER 306A LP40254-007A COVER(BATTERY) 307 – BATTERY,X2(“R6”TYPE)

308 QPC02202230P POLY BAG

310 LPT0608-001A INST BOOK(FR) 311 QPA02503503P POLY BAG 312 PEAC0300-02 RF CABLE 314 QAL0095-005 LED CABLE ASSY 315 QAM0020-001 PERI CABLE 317 BT-54008-2 GUARANTY CARD 318 LPT0002-0F6B SHEET(ATTENTION) 319 QPC02503530P POLY BAG

5-1

5.2 FINAL ASSEMBLY <M2>

BEWARE OF BOGUS PARTS

Parts that do not meet specifications may cause trouble in regard to safety and performance. We recommend that genuine JVC parts be used.

509

566

564

DIGITAL SUB BOARD ASSY <49>

542

DIGITAL BOARD ASSY <50>

557

557A

558

542

WR19

566

WR18

510

535

563

565

WR20

WR2

542

SW/DISPLAY BOARD ASSY <28>

508

507

505F 505E

571

570

542

553

LED BOARD ASSY <90>

531

MECHANISM ASSY <M4>

WR17

M G L

567

553

LED/SW BOARD ASSY <47>

WR6

WR8

507

506

505

569

510

S-SUB BOARD

ASSY <15>

WR1

532

535

572

573

WR10

REG BOARD ASSY <02>

511E

553

JACK BOARD ASSY <36>

WR16

568

511B

553

EJECT SW BOARD ASSY <27>

503

550

WR100 < Incl <03> >

ON SCREEN BOARD ASSY <17>

WR21

S/P CONVERTER BOARD ASSY <87>

511B

MAIN BOARD ASSY <03>

511E

511F

553

548

551

550

3D DIGITAL/2M BOARD ASSY <05>

WR7

538

556

533

561

533

538

526

511A

511C

511D

520

TERMINAL BOARD ASSY <06>

539

526

511C

504

RATING LABEL (SERIAL)

DEMOD

BOARD ASSY <14>

543

WR9

SW.REG BOARD ASSY <01>

519

555

549

521

503

521

530

504

502

LEBEL (PATENT)

523

528

504

503

521

525

522

521

534

554

526

517

511

5-2

501

501E

501J

501B

501A

527

529

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

564 LP40738-001A SCREW,X4

******************************

FINAL ASSEMBLY <M2>

501 LP10331-014A FRONT PANEL ASSY 501A LP20968-007A CASSETTE DOOR 501B PQ46448 TORSION SPRING 501E LP30763-005A DOOR(JACK) 501J PU60109 CATCHER

502 LP10128-006A TOP COVER 503 QYTDST3006R SCREW,X4 TOP COVER(SIDE) 504 QYTDST3006M SCREW,X3 TOP COVER(REAR) 505 LP20617-016A DRUM SUB ASSY 505E LP40323-001A CONTACT 505F LP30004-014A COMPRESION SPRING 506 PDZ0179-1-4 ROTOR ASSY 507 QYSPSP3006Z SCREW,X2

508 QAR0119-001 STATOR ASSY 509 QYSPSPH2606Z SCREW,X2 510 QYTDST2610Z SCREW,X3 DRUM

511 LP10156-004B BOTTOM CHASSIS ASSY 511A LP10130-002B BRACKET(1) 511B PEME0834 SPACER (BOARD),X3 511C LP40696-001A HOLDER(BOARD),X2 511D LP40696-002A HOLDER(BOARD) 511E QYTDST3006Z SCREW,X4 511F LP20355-001B BRACKET(2) 517 LP20939-001C BASE(1) 519 QYTDSF3010Z SCREW,BOTTOM CHASSIS

520 LP10339-004A REAR COVER 521 QYTDST3006M SCREW,X5 REAR 522 QYTDSF3008M SCREW,X4 PERI 523 QYTDSF3008M SCREW,JACK 525 QYTDSF3008M SCREW,S JACK 526 QYTDST3006Z SCREW,X3 BASE(1) 527 PQ46617C FOOT ASSY,X2 528 PQ35504 FOOT(2),X2 529 QYTDST3006Z SCREW,X4

530 QMP4A10-170 POWER CORD 531 PQ40413 SPECIAL SCREW,MECHA 532 LP40700-001A SPECIAL SCREW,MECHA 533 LP40226-001A PC SUPPORT,X2 534 PQ21623-2-5 EARTH PLATE(RF) 535 QYTDSF3010Z SCREW,X2 MECHA 538 QYTDSF3010Z SCREW,X2 MAIN 539 QYTDST3006Z SCREW,MAIN 542 QYTDST3006Z SCREW,X4 DIGITAL 543 QYTDST3006Z SCREW,X2 SW.REG 548 QAR0121-001 FAN MOTOR 549 QYTDSP4030M SCREW,X2 550 QYNNS4000Z NUT,X2 551 QYWLS4277A0Z SPRING WASHER,X2 553 QYTDSF2608Z SCREW,X15 FRONT 554 LP30312-001B BRACKET(CHASSIS) 555 QYTDSF3010Z SCREW,X2 556 LP40407-001A KNOB ASSY 557 LP40370-001E ROLLER ARM ASSY 557A PDM4311A-1 ROLLER ASSY 558 PQ45160 INERTIA PLATE 561 LP40253-001B STOPPER 563 LPH30379-006A HDD

565 LP20962-001B FRAME(HDD) 566 QYTDST3006Z SCREW,X4 567 PU49485-4 WIRE CLAMP 568 LP30356-003A DRUM SHIELD 569 QYTDST2606Z SCREW,X2 570 LP40931-001A STABILIZER 571 QYTDST3006Z SCREW 572 QYTDST3006Z SCREW,X2 S/P CONVERTER 573 PQ41556 EARTH PLATE,S/P CONVERTER WR1 WJT0005-002A E-CARD WIRE,A/C HEAD CN2001 WR2 QUQ210-0830CC FFC WIRE,DIGITAL CN2601 WR4 QUQ210-0620CC FFC WIRE,DIGITAL CN3014 WR6 QUQ112-1010CG FFC WIRE,FRONT CN3011 WR7 QJN019-063011 SHI CR C-C WIRE,MAIN CN8601 WR8 QUQ212-0516CG FFC WIRE,DRUM CN3001 WR9 QUQ212-1910CG FFC WIRE,SW.REG CN5301 WR10 QUQ212-1330CG FFC WIRE,REG CN7508 WR16 QUQ112-1810CG FFC WIRE,FRONT CN7507 WR17 QUQ212-1540CG FFC WIRE,REG CN7509 WR18 QJJ001-091704 SIN CR C-C WIRE,DIGITAL CN5323 WR19 QJJ032-041504 SIN CR C-C WIRE,HDD CN5326 WR20 WJS0018-001A E-FL/RB WIRE,DIGITAL CN8001 WR21 QUQ112-0812CG FFC WIRE,S/P CONVERTER CN701

5-3

5.3 MECHANISM ASSEMBLY <M4>

124

128

131

122

143

130

120

104

142

134

135

141

139

121

132

137

143

107

138

139

129

127

140

123

105

106

12107

A/C HEAD BOARD ASSY <12>

LOADING MOTOR BOARD ASSY <55>

Classification drawing

Part No.

Grease KYODO-SH-P AA

Oil COSMO-HV56 BB

5-4

103

102

Symbol in

111

113

114

112

151

116

115

117

118

108

109

100

110

119

NOTE:This section indicates that the grease and oil are to be

applied on locations marked with AA and BB. During checking and servicing, check if grease has been applied on the locations marked with AA and oil on the locations marked with BB.

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

1 LP20821-002F MAIN DECK ASSY 1A LP40275-004B PLATE(SUPPLY) 1B QYTDST2605Z SCREW,X4 3 LP30492-002B GIDE POLE GUARD 4 NAH0001-001 FULL ERASE HEAD 5 LP40098-001B GUIDE POLE(SUPPLY) 6 QYTDST2608Z SCREW 7 LP40637-002A TENSION STUD BASE ASSY 10 QYTDST2606Z SCREW 11 LP30409-002C UV CATCHER 2(SUPPLY) 12 LP30409-002C UV CATCHER 2(TAKE UP) 13 QYTPST2606Z SCREW,X2 14 PQ40919-10 SPACER (TAKE UP) 15 LP30223-003C LOADING ARM GEAR SHAFT 16 QYTDST2606Z SCREW 18 LP30224-001B LOADING ARM GEAR(SUPPLY) 19 LP40099-001A TORSION ARM 20 LP40100-001A PIN 21 LP40101-006A POLE BASE ASSY(SUPPLY) 22 QYSPSTG2606Z SCREW 23 LP40103-002B LOADING ARM GEAR(TAKE UP) 24 LP40099-001A TORSION ARM 25 LP40100-001A PIN 26 LP40104-006A POLE BASE ASSY(TAKE UP) 27 QYSPSTG2606Z SCREW 31 LP20233-004B ROTARY ENCODER GUIDE 32 QYTPST2606Z SCREW 34 LP30226-004E CONTROL PLATE GUIDE 35 QYTPST2605Z SCREW 36 LP30249-003B TAKE UP LEVER 37 LP30003-006A TENSION SPRING 38 LP40119-002A T.UP HEAD 39 LP20234-004B LID GUIDE 40 QYTDST2606Z SCREW,X2 42 LP40105-003A PINCH ROLLER ARM ASSY 43 LP40753-001A PINCH ROLLER SHEET 3 44 LP40148-002A TORSION SPRING 46 LP40149-001C PRESS LEVER ASSY 49 LP40106-007A GUIDE ARM ASSY 51 LP40134-001C TENSION SPRING 52 QAH0010-005 AC HEAD 53 LP30228-001C HEAD BASE 54 LP30004-013A COMPRESSION SPRING,X3 55 LP40236-001A COMPRESSION SPRING 57 LP40213-002B SPECIAL SCREW,X3 58 QYTDST2608Z SCREW,X2 59 QAR0023-001 LOADING MOTOR 60 PQ43546-1-2 MOTOR PULLEY 61 LP30230-003D MOTOR GUIDE 62 QYTPSP3003Z SCREW,X2 63 LP30005-003A BELT,LOADING MOTOR 64 LP20791-002D CONTROL CAM 65 PQM30017-24 SLIT WASHER 66 LP40120-001A WORM GEAR 67 LP40107-002A LINK LEVER ASSY 68 PQM30017-24 SLIT WASHER 69 LP10284-002E CONTROL PLATE 70 LP40379-001B CONTROL BRACKET(1) 71 QYTDSF2608M SCREW 72 LP40108-002A TENSION ARM ASSY 73 LP30003-010A TENSION SPRING

MECHANISM ASSEMBLY <M4>

74 LP40109-003D TENSION BRAKE ASSY 75 PQ46302-1-3 ADJUST PIN 76 LP30232-002A TENSION ARM BEARING 78 LP40532-009B MAIN BRAKE ASSY (SUPPLY) 80 LP40111-014C MAIN BRAKE ASSY (TAKE UP) 81 LP30003-029A TENSION SPRING 82 LP40112-001F SUB BRAKE ASSY(TAKE UP) 83 LP40357-001B TENSION SPRING 84 LP40461-001A CAPSTAN BRAKE ASSY 85 QAR0132-001 CAPSTAN MOTOR 86 QYTDSF2606M SCREW,X3 87 LP30005-008A BELT,CAPSTAN MOTOR 88 LP40114-011B IDLER ARM ASSY 89 LP30016-001A SLIT WASHER 90 LP40593-003B CLUTCH UNIT 3 91 LP30002-097A SPACER,CAPSTAN MOTOR 92 PQM30017-47 SLIT WASHER 93 LP30696-002A CLUTCH GEAR 4 94 LP30697-003A COUPLING GEAR 95 LP40554-002A COMPRESSION SPRING 96 LP40442-001A DIRECT GEAR 97 LP30017-019A SPACER,C.GEAR4 99 LP40483-002A COMPRESSION SPRING 100 LP30016-001A SLIT WASHER 102 LP40484-003B CHANGE LEVER ASSY 103 LP40512-002B COMPRESSION SPRING 104 LP30236-002C IDLER LEVER 105 LP20237-003B REEL DISK ASSY(SUPPLY) 106 LP20238-003B REEL DISK ASSY(TAKE UP) 107 LP30017-015A SPACER,X2 108 QSW0554-003 ROTARY ENCODER 109 LP40746-001A SPECIAL SCREW 110 LP30237-002B CASSETTE GEAR 111 LP30239-002G LIMIT GEAR(1) 112 LP30240-002G LIMIT GEAR(2) 113 LP40136-001E TORSION SPRING 114 LP30242-002B RELAY GEAR 115 LP30339-002F OPENER GUIDE 116 LP40545-001A TORSION SPRING 117 LP40214-001B C.H.BRACKET 118 PQM30017-47 SLIT WASHER,X2 119 LP30243-002A DRIVE GEAR 120 LP20240-001G DRIVE ARM 121 LP40137-001A TORSION SPRING 122 LP10081-002L SIDE HOLDER(L) 123 LP10082-002U SIDE HOLDER(R) 124 LP30255-006B LOCK LEVER(L) 127 LP30256-001H LOCK LEVER(R) 128 LP40168-003A TORSION SPRING(L) 129 LP40218-001B TORSION SPRING(R) 130 LP30257-001G CASSETTE HOLDER 131 PQ40919-30 SPACER,EARTH PLATE 132 LP30244-002G GUIDE RAIL 134 LP30245-002F REC SAFETY LEVER 135 LP30003-004A TENSION SPRING 137 LP20578-001C TOP GUIDE 138 LP30500-001C HOLD PLATE 139 LP40450-003A PAD,X2 140 LP30003-025B TENSION SPRING 141 LP30003-024A TENSION SPRING 142 LP40481-003A ROLLER CAM ASSY 143 LP30019-014A PAD,X2 151 LP20324-003B DOOR OPENER

5-5

5.4 ELECTRICAL PARTS LIST

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or 1SS270A DIODE

******************************

SW.REG BOARD ASSEMBLY <01>

PW1 LPA10119-06A1 SW.REG BOARD ASSY IC5101 STR-F6552 IC IC5301 L5431 IC

or MM1431AT IC

Q5301 2SD1819A/RS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/RS/-X TRANSISTOR

Q5302 DTA114EU TRANSISTOR

or RN2302 TRANSISTOR or UN5111 TRANSISTOR

or PDTA114EU TRANSISTOR D5001 D3SBA60 BRIDGE DIODE D5101 SARS01 DIODE D5102 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE

or PG104RS FR DIODE

or 1SR153-400-T2 FR DIODE

or 10ELS2 FR DIODE D5103 1SS133 DIODE

or 1SS270A DIODE D5201 AK04 DIODE

or 1S4 SB DIODE

or 11EQS04 SB DIODE D5202 FML-12S FR DIODE

or FCF06A20 FR DIODE

or ER602FCT FR DIODE

or SF5LC20U FR DIODE

or YG901C2 FR DIODE D5203 FMB-24 BARRIER DIODE

or FSQ05A04B SB DIODE

or SB640FCT SB DIODE

or SF5SC4 SB DIODE

or YG801C04 SB DIODE D5204 1SR153-400-T2 FR DIODE

or PG104RS FR DIODE

or 10ELS2 FR DIODE

or ERA18-02-T2 FR DIODE D5206 FMB-24 BARRIER DIODE

or FSQ05A04B SB DIODE

or SB640FCT SB DIODE

or SF5SC4 SB DIODE

or YG801C04 SB DIODE D5210 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE

or PG104RS FR DIODE

or 1SR153-400-T2 FR DIODE

or 10ELS2 FR DIODE D5211 AU01Z FR DIODE

or ERA18-02-T2 FR DIODE

or 1SR153-400-T2 FR DIODE

or 10ELS2 FR DIODE

or PG104RS FR DIODE D5301 MTZJ15A ZENER DIODE

or RD15ES/B1/-T2 ZENER DIODE D5303 MTZJ7.5A ZENER DIODE

or RD7.5ES/B1/-T2 ZENER DIODE D5304 1SS133 DIODE

D5305 MTZJ27C ZENER DIODE

or RD27ES/B3/-T2 ZENER DIODE

D5306 MTZJ2.7B ZENER DIODE

or RD2.7ES/B2/-T2 ZENER DIODE

D5307 1SS133 DIODE

or 1SS270A DIODE

D5308 1SS133 DIODE

or 1SS270A DIODE

D5309 1SS133 DIODE

or 1SS270A DIODE

D5310 1SS133 DIODE

or 1SS270A DIODE

D5311 1SS133 DIODE

or 1SS270A DIODE

D5312 1SS133 DIODE

or 1SS270A DIODE

D5313 1SS133 DIODE

or 1SS270A DIODE R5101 QRG02GJ-683 OMF RESISTOR 68kØ,2W R5102 QRE141J-100Y RESISTOR 10Ø,1/4W R5103 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R5104 QRE141J-681Y RESISTOR 680Ø,1/4W R5105 QRT01DJ-R47X MF RESISTOR 0.47Ø,1W R5107 QRE141J-684Y RESISTOR 680kØ,1/4W R5108 QRE121J-470Y RESISTOR 47Ø,1/2W R5302 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R5303 NRVA02D-123X CMF RESISTOR 12kØ,1/10W R5304 NRVA02D-302X CMF RESISTOR 3kØ,1/10W R5305 NRSA02J-223X MG RESISTOR 22kØ,1/10W

R5306 QRZ9005-470X FUSI RESISTOR 47Ø,1/4W R5307 NRSA02J-221X MG RESISTOR 220Ø,1/10W R5308 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5309 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R5310 QRL02DJ-821X OMF RESISTOR 820Ø,2W R5311 NRSA02J-473X MG RESISTOR 47kØ,1/10W R5313 NRSA02J-561X MG RESISTOR 560Ø,1/10W R5314 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5316 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5317 NRSA02J-333X MG RESISTOR 33kØ,1/10W B5003 QUY160-100Y IM BUS WIRE

C5001 QFZ9073-683 F CAPACITOR 0.068µF,250V

C5002 QFZ9051-333 F CAPACITOR 0.033µF,250V

C5004 QCZ9071-222 CAPACITOR 0.0022µF,250V C5007 QEZ0374-826 E CAPACITOR 82µF,400V C5102 QEMU1VM-276 E CAPACITOR 27µF,35V C5103 QCZ0302-330Z CAPACITOR 33pF,1kV C5104 QFLC1HJ-471Z F CAPACITOR 470pF,50V C5105 NCB21HK-223X CAPACITOR 0.022µF,50V C5106 QCZ0212-472 CAPACITOR 0.0047µF,1kV C5201 QEMU0JM-227 E CAPACITOR 220µF,6.3V C5202 QEMT1CM-827 E CAPACITOR 820µF,16V C5203 QETN1CM-227 E CAPACITOR 220µF,16V C5204 QEMT1AM-228 E CAPACITOR 2200µF,10V C5205 QETN1AM-227 E CAPACITOR 220µF,10V C5206 QEMU1EM-187 E CAPACITOR 180µF,25V C5207 QETN2AM-475 E CAPACITOR 4.7µF,100V C5208 QEMU1HM-186 E CAPACITOR 18µF,50V C5212 QEMT1AM-278 E CAPACITOR 2700µF,10V C5213 QETN1AM-227 E CAPACITOR 220µF,10V C5301 QFLC1HJ-103Z F CAPACITOR 0.01µF,50V

5-6

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C5302 QFLC1HJ-473Z F CAPACITOR 0.047µF,50V C5303 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V C5304 QETN1EM-476 E CAPACITOR 47µF,25V C5305 QFLC1HJ-103Z F CAPACITOR 0.01µF,50V L5201 PELN1184 COIL 33µH L5202 PU60944-330K COIL 33µH L5205 PELN1184 COIL 33µH K5101 QQR0678-001Z FERRITE BEAD

PC5101 PC123F2 PH COUPLER

T5001 QQS0092-001 SW TRANSFORMER HS2 LP40515-001B HEAT SINK,D5203 OT1 QYTDST3008Z SCREW,X2,D5203 FC5001 QNG0006-001Z FUSE CLIP,F5001 FC5002 QNG0006-001Z FUSE CLIP,F5001

LF5001 PELN1204-01-01 LINE FILTER

LF5002 QQR1031-001 LINE FILTER

CN5001 QGA7901C3-02 CONNECTOR,(1-2)AC IN CN5201 QGF1208C1-19 FPC CONNECTOR,(1-19)REG

CP5301 ICP-N25 CIRCUIT PROTECTOR

F5001 QMF51E2-2R0J1 FUSE T2.0A,AC250V

******************************

REG BOARD ASSEMBLY <02>

PW2 LPA10119-06A2 REG BOARD ASSY IC5321 PQ15RW11 IC IC5322 PQ5EV3 IC Q5321 2SD2528/QP/ TRANSISTOR Q5322 2SD1819A/RS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/RS/-X TRANSISTOR Q5326 2SD2375/QP/ TRANSISTOR Q5327 2SD1819A/RS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/RS/-X TRANSISTOR Q5328 2SD1302/ST/-T TRANSISTOR

or 2SD1450/ST/-T TRANSISTOR Q5329 DTA114EU TRANSISTOR

or RN2302 TRANSISTOR

or UN5111 TRANSISTOR

or PDTA114EU TRANSISTOR Q5330 2SD2144S/UV/-T TRANSISTOR Q5331 2SB1068/KU/-T TRANSISTOR Q5332 DTC114EU TRANSISTOR

or PDTC114EU TRANSISTOR

or RN1302 TRANSISTOR

or UN5211 TRANSISTOR Q5333 2SD1450/ST/-T TRANSISTOR

or 2SD1302/ST/-T TRANSISTOR Q5335 2SB1256 TRANSISTOR Q5336 DTC114TU TRANSISTOR

or PDTC114TU TRANSISTOR

or RN1311 TRANSISTOR

or UN5215 TRANSISTOR D5321 FML-12S FR DIODE

or FCF06A20 FR DIODE

or YG901C2 FR DIODE

or ER602FCT FR DIODE

or SF5LC20U FR DIODE

D5325 RD5.1JS/B2/-T2 ZENER DIODE

or MA4051N/M/-T2 ZENER DIODE

D5326 1SS133 DIODE

or 1SS270A DIODE

D5327 RD5.1JS/B2/-T2 ZENER DIODE

or MA4051N/M/-T2 ZENER DIODE

D5328 1SS133 DIODE

or 1SS270A DIODE

D5329 1SS133 DIODE

or 1SS270A DIODE

D5331 1SS133 DIODE

or 1SS270A DIODE

D5333 1SS133 DIODE

or 1SS270A DIODE

D5334 11ES2 DIODE

or ERA15-02-T2 DIODE or 1A3G DIODE

D5335 1SS133 DIODE

or 1SS270A DIODE

D5336 MTZJ12A ZENER DIODE

or RD12ES/B1/-T2 ZENER DIODE R5322 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5323 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5324 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5325 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5326 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5327 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5328 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5329 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5330 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5331 NRSA02J-473X MG RESISTOR 47kØ,1/10W R5334 NRVA02D-472X CMF RESISTOR 4.7kØ,1/10W R5335 NRVA02D-472X CMF RESISTOR 4.7kØ,1/10W R5336 NRVA02D-472X CMF RESISTOR 4.7kØ,1/10W R5337 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W R5338 NRSA02J-103X MG RESISTOR 10kØ,1/10W R5339 NRSA02J-102X MG RESISTOR 1kØ,1/10W R5340 QRL01DJ-101X OMF RESISTOR 100Ø,1W R5341 NRSA02J-511X MG RESISTOR 510Ø,1/10W R5342 NRSA02J-471X MG RESISTOR 470Ø,1/10W R5343 NRSA02J-473X MG RESISTOR 47kØ,1/10W R5344 NRSA02J-221X MG RESISTOR 220Ø,1/10W R5345 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R5346 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R5353 NRSA02J-103X MG RESISTOR 10kØ,1/10W B5301 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5302 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5303 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5305 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B5306 QUY153-050Y IM BUS WIRE B5307 QUY153-050Y IM BUS WIRE C5321 QETN1AM-107 E CAPACITOR 100µF,10V C5322 QETN1HM-106 E CAPACITOR 10µF,50V C5323 QETN1CM-107 E CAPACITOR 100µF,16V C5324 QFLC1HJ-102Z F CAPACITOR 0.001µF,50V C5325 QFLC1HJ-102Z F CAPACITOR 0.001µF,50V C5326 QETN1AM-107 E CAPACITOR 100µF,10V C5327 NCB21HK-103X CAPACITOR 0.01µF,50V C5328 QETN1AM-107 E CAPACITOR 100µF,10V C5329 NCB21HK-103X CAPACITOR 0.01µF,50V

5-7

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C5330 QETN1AM-107 E CAPACITOR 100µF,10V C5332 QETN1CM-226 E CAPACITOR 22µF,16V C5333 QETN1AM-107 E CAPACITOR 100µF,10V C5334 QETN1CM-227 E CAPACITOR 220µF,16V C5335 QETN1CM-107 E CAPACITOR 100µF,16V L5321 QQL01BK-101Z COIL 100µH HS1 LP40090-001A HEAT SINK,IC5322 HS2 LP40090-001A HEAT SINK,Q5321 OT1 QYTDST3006Z SCREW,IC5322 OT2 QYTDST3006Z SCREW,Q5321 CN5301 QGF1208C1-19 FPC CONNECTOR,(1-19)SW/REG CN5321 QGF1208F1-15 FPC CONNECTOR,(1-15)MAIN CN5322 QGF1208F1-13 FPC CONNECTOR,(1-13)MAIN CN5323 QGA2001C1-09 CONNECTOR,(1-9)DIGITAL CN5325 QGA2001F1-02 CONNECTOR,(1-2)FAN MOTOR CN5326 QGA2501C1-04 CONNECTOR,(1-4)HDD

CP5322 ICP-N25 CIRCUIT PROTECTOR

******************************

MAIN BOARD ASSEMBLY <03>

PW1 LPA10113-09B MAIN BOARD ASSY IC1 JCP8050-MSA IC IC2 MM1113XF IC IC301 LA7358 IC IC702 MM1113XF IC IC703 MM1117XF IC IC705 MM1117XF IC IC706 PQ05TZ1U IC

or PQ05TZ5U IC IC707 AN3916 IC IC708 MM1115XF IC IC709 MM1031XM IC IC710 MM1117XF IC IC711 MM1117XF IC IC712 MM1113XF IC IC713 MM1111XF IC IC2601 BU4052BCF IC IC2602 BA15218F-XE IC IC2603 BU4052BCF IC IC2605 BA15218F-XE IC IC2606 BU4052BCF IC IC2607 BU4052BCF IC IC2608 BA15218F-XE IC IC2610 BU4053BCF IC IC3001 HD6432194AA27F IC(MCU) IC3002 S-80727AN-DQ-X IC

or S-80827ANUP-W IC IC3003 AT24C16-10PC IC

or 24LC16B/P IC IC3004 BA6956AN IC IC3006 TC7S04F IC(DIGITAL) IC3601 BU2090FS IC IC3651 BU2090FS IC Q1 2SC4081/S/-X TRANSISTOR Q2 2SC4081/S/-X TRANSISTOR Q3 2SC4081/S/-X TRANSISTOR Q4 2SC4081/S/-X TRANSISTOR

Q5 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SA1576A/QR/-X TRANSISTOR

Q7 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q8 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q9 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q10 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SA1576A/QR/-X TRANSISTOR

Q14 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR or RN2309 TRANSISTOR or UN511E TRANSISTOR

Q17 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR or RN1309 TRANSISTOR or UN521E TRANSISTOR

Q21 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SA1576A/QR/-X TRANSISTOR

Q24 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q25 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR or RN1309 TRANSISTOR or UN521E TRANSISTOR

Q38 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q41 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR or RN1309 TRANSISTOR or UN521E TRANSISTOR

Q301 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SA1576A/QR/-X TRANSISTOR

Q302 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR or RN2309 TRANSISTOR

or UN511E TRANSISTOR Q401 2SA1576A/QR/-X TRANSISTOR Q402 2SA1576A/QR/-X TRANSISTOR Q403 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q404 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q405 2SA1576A/QR/-X TRANSISTOR Q703 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

5-8

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

Q705 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q706 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q708 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q709 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q710 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q711 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q712 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q725 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q726 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q727 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q728 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q732 DTC114ESA-T TRANSISTOR Q2001 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR Q2002 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q2003 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR

or RN2309 TRANSISTOR

or UN511E TRANSISTOR Q2004 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q2051 2SC4081/QRS/-X TRANSISTOR Q2052 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q2053 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q2054 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q2061 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

Q2062 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR or 2SB1218A/QR/-X TRANSISTOR

Q2251 DTA144WU TRANSISTOR

or PDTA144WU TRANSISTOR or UN511E TRANSISTOR or RN2309 TRANSISTOR

Q2252 DTC114EU TRANSISTOR

or PDTC114EU TRANSISTOR or RN1302 TRANSISTOR

or UN5211 TRANSISTOR Q2601 2SC4081/QRS/-X TRANSISTOR Q2602 2SC4081/QRS/-X TRANSISTOR Q3001 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q3002 PTZ-NV16 PHOTO TRANSISTOR

or PTZ-NV16A PHOTO TRANSISTOR Q3003 PTZ-NV16 PHOTO TRANSISTOR

or PTZ-NV16A PHOTO TRANSISTOR Q3004 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR Q3005 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q3007 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or UN521E TRANSISTOR

or RN1309 TRANSISTOR Q3302 DTC144WU TRANSISTOR

or PDTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q4001 UN5211 TRANSISTOR

or RN1302 TRANSISTOR

or DTC114EU TRANSISTOR Q4002 UN5211 TRANSISTOR

or DTC114EU TRANSISTOR

or RN1302 TRANSISTOR Q4003 UN5211 TRANSISTOR

or DTC114EU TRANSISTOR

or RN1302 TRANSISTOR Q6030 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q6031 DTC144EU TRANSISTOR Q6032 DTC144EU TRANSISTOR Q7501 2SC1317/RS/-T TRANSISTOR Q7503 DTC144WU TRANSISTOR D6 MTZJ5.1C ZENER DIODE D8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W D706 1SS355 DIODE D2001 1SS355 DIODE D2121 MTZJ8.2C ZENER DIODE D2201 11ES2 DIODE

or 1A3G DIODE D3001 LNB2301L01VI LE DIODE D3002 1SS133 DIODE D3003 RD33ES/B2/-T2 ZENER DIODE

or MTZJ33C ZENER DIODE

or 2PC4081/R/-X TRANSISTOR

5-9

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

D3004 11ES2 DIODE

or 1A3G DIODE

D3005 11ES2 DIODE

or 1A3G DIODE D3007 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W D3008 1SS355 DIODE D4001 1SS355 DIODE D4002 1SS355 DIODE D6002 HZ30-2L-T2 ZENER DIODE

or HZ30-2LTD Z DIODE (M) R1 NRVA02D-682X CMF RESISTOR 6.8kØ,1/10W R2 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W R4 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R5 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6 NRSA02J-273X MG RESISTOR 27kØ,1/10W R7 NRSA02J-681X MG RESISTOR 680Ø,1/10W R8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R9 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R21 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R22 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R23 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R24 NRSA02J-331X MG RESISTOR 330Ø,1/10W R25 NRSA02J-103X MG RESISTOR 10kØ,1/10W R26 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R27 NRSA02J-221X MG RESISTOR 220Ø,1/10W R28 NRSA02J-221X MG RESISTOR 220Ø,1/10W R29 NRSA02J-681X MG RESISTOR 680Ø,1/10W R30 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R31 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R32 NRSA02J-471X MG RESISTOR 470Ø,1/10W R33 NDC21HJ-8R0X CAPACITOR 8pF,50V R34 NDC21HJ-390X CAPACITOR 39pF,50V R36 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R38 NRSA02J-102X MG RESISTOR 1kØ,1/10W R40 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R41 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R42 NRSA02J-681X MG RESISTOR 680Ø,1/10W R46 NRSA02J-271X MG RESISTOR 270Ø,1/10W R47 NRSA02J-821X MG RESISTOR 820Ø,1/10W R48 NRSA02J-102X MG RESISTOR 1kØ,1/10W R51 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R68 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R70 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R77 NRSA02J-103X MG RESISTOR 10kØ,1/10W R84 NRSA02J-103X MG RESISTOR 10kØ,1/10W R88 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R90 NRSA02J-391X MG RESISTOR 390Ø,1/10W R92 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R93 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R104 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R113 NRSA02J-101X MG RESISTOR 100Ø,1/10W R114 NRSA02J-104X MG RESISTOR 100kØ,1/10W R301 NRSA02J-273X MG RESISTOR 27kØ,1/10W R302 NRSA02J-124X MG RESISTOR 120kØ,1/10W R303 NRSA02J-273X MG RESISTOR 27kØ,1/10W R304 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R305 NRSA02J-473X MG RESISTOR 47kØ,1/10W R306 NRSA02J-273X MG RESISTOR 27kØ,1/10W R307 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R309 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R310 NRSA02J-223X MG RESISTOR 22kØ,1/10W

R311 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R312 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R313 NRSA02J-223X MG RESISTOR 22kØ,1/10W R314 NRSA02J-243X MG RESISTOR 24kØ,1/10W R315 NRSA02J-564X MG RESISTOR 560kØ,1/10W R316 NRSA02J-124X MG RESISTOR 120kØ,1/10W R328 NRSA02J-153X MG RESISTOR 15kØ,1/10W R329 NRSA02J-103X MG RESISTOR 10kØ,1/10W R401 NRSA02J-221X MG RESISTOR 220Ø,1/10W R402 NRSA02J-681X MG RESISTOR 680Ø,1/10W R403 NRSA02J-561X MG RESISTOR 560Ø,1/10W R404 NRSA02J-473X MG RESISTOR 47kØ,1/10W R405 NRSA02J-683X MG RESISTOR 68kØ,1/10W R406 NRSA02J-393X MG RESISTOR 39kØ,1/10W R407 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R408 NRSA02J-473X MG RESISTOR 47kØ,1/10W R409 NRSA02J-103X MG RESISTOR 10kØ,1/10W R704 NRSA02J-333X MG RESISTOR 33kØ,1/10W R705 NRSA02J-223X MG RESISTOR 22kØ,1/10W R706 NRVA02D-271X CMF RESISTOR 270Ø,1/10W R707 NRVA02D-561X CMF RESISTOR 560Ø,1/10W R710 NRSA02J-561X MG RESISTOR 560Ø,1/10W R711 NRSA02J-820X MG RESISTOR 82Ø,1/10W R712 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R713 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R714 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R716 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R717 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R718 NRVA02D-271X CMF RESISTOR 270Ø,1/10W R719 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R720 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R721 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R722 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R723 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R724 NRSA02J-102X MG RESISTOR 1kØ,1/10W R725 NRSA02J-105X MG RESISTOR 1MØ,1/10W R726 NCB21HK-103X CAPACITOR 0.01µF,50V R727 NRSA02J-105X MG RESISTOR 1MØ,1/10W R767 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R768 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R769 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R770 NRSA02J-471X MG RESISTOR 470Ø,1/10W R771 NRSA02J-471X MG RESISTOR 470Ø,1/10W R772 NRSA02J-102X MG RESISTOR 1kØ,1/10W R773 NRSA02J-223X MG RESISTOR 22kØ,1/10W R774 NRSA02J-274X MG RESISTOR 270kØ,1/10W R775 NRSA02J-183X MG RESISTOR 18kØ,1/10W R776 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R777 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R778 NRSA02J-102X MG RESISTOR 1kØ,1/10W R779 NRSA02J-102X MG RESISTOR 1kØ,1/10W R780 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R781 NRSA02J-102X MG RESISTOR 1kØ,1/10W R782 NRSA02J-220X MG RESISTOR 22Ø,1/10W R783 NRSA02J-102X MG RESISTOR 1kØ,1/10W R784 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W VR701 QVP0039-333Z TRIM RESISTOR,DV AGC R2003 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2004 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R2005 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R2006 NRSA02J-393X MG RESISTOR 39kØ,1/10W

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R2007 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2008 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2009 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2010 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2011 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2012 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2013 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R2014 NRSA02J-224X MG RESISTOR 220kØ,1/10W R2015 NRSA02J-181X MG RESISTOR 180Ø,1/10W R2016 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2017 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2019 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2020 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2053 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R2054 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2055 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W R2056 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2057 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2058 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2059 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2060 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2061 NRSA02J-273X MG RESISTOR 27kØ,1/10W R2062 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W R2063 NRSA02J-151X MG RESISTOR 150Ø,1/10W R2064 NRSA02J-473X MG RESISTOR 47kØ,1/10W R2065 NRSA02J-183X MG RESISTOR 18kØ,1/10W R2121 QRE141J-151Y RESISTOR 150Ø,1/4W R2206 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2207 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R2208 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2209 NRSA02J-101X MG RESISTOR 100Ø,1/10W R2210 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2211 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2213 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2215 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2217 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R2218 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2219 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2220 NRSA02J-393X MG RESISTOR 39kØ,1/10W R2222 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2223 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2224 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2225 NRSA02J-153X MG RESISTOR 15kØ,1/10W R2226 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2227 NRSA02J-123X MG RESISTOR 12kØ,1/10W R2228 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2229 NRSA02J-563X MG RESISTOR 56kØ,1/10W R2251 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2252 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R2601 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2602 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2603 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2604 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2605 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2606 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2607 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2608 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2609 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2610 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2611 NRSA02J-102X MG RESISTOR 1kØ,1/10W

R2613 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2614 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2616 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2617 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2618 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2623 NRSA02J-223X MG RESISTOR 22kØ,1/10W R2624 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R2625 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R2626 NRSA02J-223X MG RESISTOR 22kØ,1/10W R2627 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2629 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2630 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2631 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2632 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2633 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2634 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2636 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2637 NRSA02J-105X MG RESISTOR 1MØ,1/10W R2638 NRSA02J-105X MG RESISTOR 1MØ,1/10W R2651 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2652 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2653 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2654 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2655 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2656 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2657 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2658 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2659 NRSA02J-102X MG RESISTOR 1kØ,1/10W R2660 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2661 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2662 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2663 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2664 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2665 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2666 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2667 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2681 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2682 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2683 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R2684 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2685 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R2686 NRSA02J-103X MG RESISTOR 10kØ,1/10W R2687 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2688 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2689 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R2691 NRSA02J-221X MG RESISTOR 220Ø,1/10W R2692 NRSA02J-121X MG RESISTOR 120Ø,1/10W R3011 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3012 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3013 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3016 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3018 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3019 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R3021 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3022 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3025 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3026 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3027 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3029 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3030 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3031 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

5-11

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R3033 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3034 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3038 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R3040 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3041 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3042 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3044 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3046 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3047 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3048 NRSA02J-221X MG RESISTOR 220Ø,1/10W R3049 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3050 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3051 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3052 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3053 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3054 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3055 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3056 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3057 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3058 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3059 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3060 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3061 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3062 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3063 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3066 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3069 NRSA02J-101X MG RESISTOR 100Ø,1/10W R3071 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3072 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3073 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3075 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3076 NRSA02J-471X MG RESISTOR 470Ø,1/10W R3078 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3079 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3083 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3085 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3086 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3087 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3088 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3089 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3091 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3094 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3095 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3096 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3097 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3103 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3104 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3105 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3106 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3201 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3202 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3203 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3204 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3205 QRE141J-181Y RESISTOR 180Ø,1/4W R3206 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3207 NRSA02J-183X MG RESISTOR 18kØ,1/10W R3208 NRSA02J-181X MG RESISTOR 180Ø,1/10W R3209 NRSA02J-273X MG RESISTOR 27kØ,1/10W R3210 NRSA02J-181X MG RESISTOR 180Ø,1/10W R3211 NRSA02J-273X MG RESISTOR 27kØ,1/10W R3212 NRSA02J-474X MG RESISTOR 470kØ,1/10W

R3213 NRSA02J-334X MG RESISTOR 330kØ,1/10W R3214 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3215 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3216 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3217 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R3218 QRE141J-472Y RESISTOR 4.7kØ,1/4W R3219 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3220 NRSA02J-104X MG RESISTOR 100kØ,1/10W R3222 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3223 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3224 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3225 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3229 NRSA02J-105X MG RESISTOR 1MØ,1/10W R3230 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3231 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3233 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3234 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3235 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3236 NRSA02J-102X MG RESISTOR 1kØ,1/10W R3238 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3241 NRSA02J-104X MG RESISTOR 100kØ,1/10W R3245 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3251 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3258 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R3381 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3601 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3602 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3603 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3604 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3605 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3606 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3607 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3608 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3609 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3610 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3611 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R3612 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3613 NRSA02J-103X MG RESISTOR 10kØ,1/10W R3616 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R3618 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4001 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R4003 NRSA02J-561X MG RESISTOR 560Ø,1/10W R4004 NRSA02J-561X MG RESISTOR 560Ø,1/10W R4005 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R4007 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4008 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4009 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4010 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4011 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R4012 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R4013 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4014 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R4015 NRSA02J-223X MG RESISTOR 22kØ,1/10W R4016 NRSA02J-103X MG RESISTOR 10kØ,1/10W R4017 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4018 NRSA02J-102X MG RESISTOR 1kØ,1/10W R4019 NRSA02J-103X MG RESISTOR 10kØ,1/10W R4020 NRSA02J-103X MG RESISTOR 10kØ,1/10W R4021 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6020 NRSA02J-471X MG RESISTOR 470Ø,1/10W R6021 NRSA02J-471X MG RESISTOR 470Ø,1/10W

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R6022 NRSA02J-471X MG RESISTOR 470Ø,1/10W R6030 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6031 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6032 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R6033 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R6060 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6061 NRSA02J-103X MG RESISTOR 10kØ,1/10W R6508 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6510 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6553 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6554 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R7505 NRSA02J-221X MG RESISTOR 220Ø,1/10W R7506 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7507 QRE121J-100Y RESISTOR 10Ø,1/2W R7512 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W B8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B18 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B22 NRSA02J-103X MG RESISTOR 10kØ,1/10W B26 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B37 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B38 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B42 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B46 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B49 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B50 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B55 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B56 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B57 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B701 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B710 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B714 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B715 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B717 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B730 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B734 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B737 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B740 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2011 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2601 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2602 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2607 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2608 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B2610 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3011 NQR0227-003X FERRITE CORE B3013 NRSA02J-101X MG RESISTOR 100Ø,1/10W B3014 NQR0227-003X FERRITE CORE B3017 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3018 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3019 NRSA02J-102X MG RESISTOR 1kØ,1/10W B3021 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3022 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3023 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3025 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B3027 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B6001 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B6032 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B6565 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B6566 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7503 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7509 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7510 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

B7512 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7514 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7516 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7518 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B7519 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C1 NCB21EK-103X CAPACITOR 0.01µF,25V C2 NCB21EK-103X CAPACITOR 0.01µF,25V C3 NCB21EK-103X CAPACITOR 0.01µF,25V C4 NCB21EK-103X CAPACITOR 0.01µF,25V C5 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C6 NCB11EK-104X CAPACITOR 0.1µF,25V C7 NCB21HK-102X CAPACITOR 0.001µF,50V C8 NCB21EK-104X CAPACITOR 0.1µF,25V C9 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C10 NDC21HG-151X CAPACITOR 150pF,50V C11 NCB21EK-104X CAPACITOR 0.1µF,25V C14 NCB21EK-104X CAPACITOR 0.1µF,25V C15 NCB21EK-103X CAPACITOR 0.01µF,25V C16 NCB11EK-104X CAPACITOR 0.1µF,25V C17 QEKJ1HM-335 E CAPACITOR 3.3µF,50V C19 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C20 QEKJ1HM-105 E CAPACITOR 1µF,50V C21 NCB21EK-104X CAPACITOR 0.1µF,25V C22 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C23 NCB21EK-104X CAPACITOR 0.1µF,25V C24 NCB21EK-104X CAPACITOR 0.1µF,25V C25 NDC21HJ-6R0X CAPACITOR 6pF,50V C26 NCB21EK-104X CAPACITOR 0.1µF,25V C27 NCB21HK-223X CAPACITOR 0.022µF,50V C28 QEKJ1HM-335 E CAPACITOR 3.3µF,50V C29 NCB21EK-333X CAPACITOR 0.033µF,25V C30 NCB21CK-474X CAPACITOR 0.47µF,16V C31 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C33 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C34 NCB21EK-104X CAPACITOR 0.1µF,25V C35 NCB21HK-103X CAPACITOR 0.01µF,50V C36 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C37 NCB21AK-105X CAPACITOR 1µF,10V C38 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C39 NCB21EK-104X CAPACITOR 0.1µF,25V C40 QEKJ1CM-106 E CAPACITOR 10µF,16V C53 NDC21HJ-101X CAPACITOR 100pF,50V C59 NCB21EK-104X CAPACITOR 0.1µF,25V C60 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C61 NCB21HK-103X CAPACITOR 0.01µF,50V C63 NCB21EK-104X CAPACITOR 0.1µF,25V C64 NDC21HJ-220X CAPACITOR 22pF,50V C65 QEKJ1HM-105 E CAPACITOR 1µF,50V C69 NCB21EK-104X CAPACITOR 0.1µF,25V C70 NCB21EK-104X CAPACITOR 0.1µF,25V C72 NDC21HJ-470X CAPACITOR 47pF,50V C73 NDC21HJ-120X CAPACITOR 12pF,50V C76 NCB21HK-103X CAPACITOR 0.01µF,50V C77 NCB21HK-103X CAPACITOR 0.01µF,50V C78 NCB21HK-103X CAPACITOR 0.01µF,50V C79 NDC21HJ-390X CAPACITOR 39pF,50V C80 NCB21HK-103X CAPACITOR 0.01µF,50V C84 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W C93 NDC21HJ-220X CAPACITOR 22pF,50V C94 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C103 NCB21HK-103X CAPACITOR 0.01µF,50V

5-13

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C106 NCB21HK-821X CAPACITOR 820pF,50V C108 NDC21HJ-680X CAPACITOR 68pF,50V C109 NCB21CK-224X CAPACITOR 0.22µF,16V C110 NDC21HJ-820X CAPACITOR 82pF,50V C114 NDC21HJ-181X CAPACITOR 180pF,50V C131 NCB21HK-103X CAPACITOR 0.01µF,50V C301 NDC21HJ-151X CAPACITOR 150pF,50V C302 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C303 NCB21HK-682X CAPACITOR 0.0068µF,50V C304 NCB21HK-682X CAPACITOR 0.0068µF,50V C305 NCB21HK-103X CAPACITOR 0.01µF,50V C307 NDC21HJ-151X CAPACITOR 150pF,50V C308 NCB21HK-103X CAPACITOR 0.01µF,50V C309 NCB21EK-104X CAPACITOR 0.1µF,25V C310 NCB21HK-103X CAPACITOR 0.01µF,50V C312 NCB21HK-102X CAPACITOR 0.001µF,50V C313 NCB21CK-474X CAPACITOR 0.47µF,16V C315 NCB21AK-105X CAPACITOR 1µF,10V C316 NCB21HK-103X CAPACITOR 0.01µF,50V C317 NDC21HJ-681X CAPACITOR 680pF,50V C318 NCB21EK-223X CAPACITOR 0.022µF,25V C319 NCB21AK-105X CAPACITOR 1µF,10V C320 NCB21HK-103X CAPACITOR 0.01µF,50V C321 NDC21HG-301X CAPACITOR 300pF,50V C322 NCB21CK-474X CAPACITOR 0.47µF,16V C323 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C401 NCB21HK-103X CAPACITOR 0.01µF,50V C402 NCB21HK-223X CAPACITOR 0.022µF,50V C403 NDC21HJ-131X CAPACITOR 130pF,50V C404 NDC21HJ-470X CAPACITOR 47pF,50V C406 NCB21HK-102X CAPACITOR 0.001µF,50V C407 NDC21HJ-150X CAPACITOR 15pF,50V C704 NCB21HK-103X CAPACITOR 0.01µF,50V C706 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C708 NCB21HK-103X CAPACITOR 0.01µF,50V C709 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C710 NCB21HK-103X CAPACITOR 0.01µF,50V C712 NCB21HK-103X CAPACITOR 0.01µF,50V C713 NCB21HK-103X CAPACITOR 0.01µF,50V C714 NCB21HK-103X CAPACITOR 0.01µF,50V C715 QEKJ1CM-226 E CAPACITOR 22µF,16V C718 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C719 NCB21HK-103X CAPACITOR 0.01µF,50V C720 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C721 NDC21HJ-101X CAPACITOR 100pF,50V C722 NCB21HK-103X CAPACITOR 0.01µF,50V C757 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C758 NDC21HJ-101X CAPACITOR 100pF,50V C759 QEPF1HM-225 NP E CAPACITOR 2.2µF,50V C760 NCB21HK-103X CAPACITOR 0.01µF,50V C761 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C762 NDC21HJ-101X CAPACITOR 100pF,50V C763 QEKJ1HM-105 E CAPACITOR 1µF,50V C764 QEKJ0JM-107 E CAPACITOR 100µF,6.3V C765 NCB21HK-332X CAPACITOR 0.0033µF,50V C766 NCB21HK-103X CAPACITOR 0.01µF,50V C767 NCB21HK-473X CAPACITOR 0.047µF,50V C768 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C769 QEKJ1CM-106 E CAPACITOR 10µF,16V C770 QEKJ1CM-106 E CAPACITOR 10µF,16V C771 QEKJ1EM-475 E CAPACITOR 4.7µF,25V

C772 NCB21HK-103X CAPACITOR 0.01µF,50V C773 NDC21HJ-470X CAPACITOR 47pF,50V C774 QEKJ1CM-106 E CAPACITOR 10µF,16V C776 NCB21HK-103X CAPACITOR 0.01µF,50V C777 QEKJ1CM-106 E CAPACITOR 10µF,16V C779 NDC21HJ-150X CAPACITOR 15pF,50V C780 NCB21HK-103X CAPACITOR 0.01µF,50V C781 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C782 NCB21HK-103X CAPACITOR 0.01µF,50V C783 QEKJ1CM-106 E CAPACITOR 10µF,16V C784 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C785 NDC21HJ-680X CAPACITOR 68pF,50V C786 QEKJ1CM-106 E CAPACITOR 10µF,16V C788 NCB21HK-103X CAPACITOR 0.01µF,50V C790 NCB21HK-103X CAPACITOR 0.01µF,50V C791 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C794 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C795 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C796 NCB21HK-103X CAPACITOR 0.01µF,50V C797 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C799 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C800 NCB21HK-103X CAPACITOR 0.01µF,50V C801 NCB21HK-103X CAPACITOR 0.01µF,50V C802 NCB21HK-103X CAPACITOR 0.01µF,50V C803 NCB21HK-103X CAPACITOR 0.01µF,50V C804 NCB21HK-103X CAPACITOR 0.01µF,50V C805 NCB21HK-103X CAPACITOR 0.01µF,50V C806 NCB21HK-103X CAPACITOR 0.01µF,50V C2001 QETJ1HM-475 E CAPACITOR 4.7µF,50V C2002 QEKJ1CM-106 E CAPACITOR 10µF,16V C2003 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C2004 NCB21HK-103X CAPACITOR 0.01µF,50V C2005 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2006 NCB21HK-123X CAPACITOR 0.012µF,50V C2007 QEKJ1CM-226 E CAPACITOR 22µF,16V C2008 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2009 NCB21HK-122X CAPACITOR 0.0012µF,50V C2010 NCB21HK-152X CAPACITOR 0.0015µF,50V C2011 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2012 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2013 NCB21HK-331X CAPACITOR 330pF,50V C2051 NCB21HK-331X CAPACITOR 330pF,50V C2052 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V C2053 NCB21HK-472X CAPACITOR 0.0047µF,50V C2054 NCB21HK-103X CAPACITOR 0.01µF,50V C2055 QEKJ1CM-106 E CAPACITOR 10µF,16V C2061 QFLC1HJ-333Z F CAPACITOR 0.033µF,50V C2062 NCB21HK-332X CAPACITOR 0.0033µF,50V C2063 NCB21HK-103X CAPACITOR 0.01µF,50V C2064 QEKJ1CM-106 E CAPACITOR 10µF,16V C2121 QEKJ1CM-476 E CAPACITOR 47µF,16V C2201 NCB21EK-104X CAPACITOR 0.1µF,25V C2202 NCB21EK-333X CAPACITOR 0.033µF,25V C2203 QEKJ1CM-106 E CAPACITOR 10µF,16V C2204 NCB21HK-102X CAPACITOR 0.001µF,50V C2205 QEKJ1HM-105 E CAPACITOR 1µF,50V C2207 QEKJ1CM-476 E CAPACITOR 47µF,16V C2208 QETJ1HM-475 E CAPACITOR 4.7µF,50V C2213 QEKJ1CM-106 E CAPACITOR 10µF,16V C2214 QEKJ1CM-106 E CAPACITOR 10µF,16V C2215 QERF1EM-475 E CAPACITOR 4.7µF,25V

5-14

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C2216 QEKJ1HM-474 E CAPACITOR 0.47µF,50V C2217 QEKJ1CM-106 E CAPACITOR 10µF,16V C2218 QEKJ1HM-474 E CAPACITOR 0.47µF,50V C2219 QEKJ1CM-106 E CAPACITOR 10µF,16V C2220 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2221 NCB21HK-103X CAPACITOR 0.01µF,50V C2222 QEKJ1HM-474 E CAPACITOR 0.47µF,50V C2223 QEKJ1HM-474 E CAPACITOR 0.47µF,50V C2224 NCB21HK-103X CAPACITOR 0.01µF,50V C2225 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C2226 QEKJ1CM-106 E CAPACITOR 10µF,16V C2227 NCB21CK-104X CAPACITOR 0.1µF,16V C2228 NCB21CK-104X CAPACITOR 0.1µF,16V C2229 NDC21HJ-101X CAPACITOR 100pF,50V C2230 NDC21HJ-101X CAPACITOR 100pF,50V C2231 NCB21HK-222X CAPACITOR 0.0022µF,50V C2251 QEKJ1CM-476 E CAPACITOR 47µF,16V C2252 NCB21HK-103X CAPACITOR 0.01µF,50V C2253 NCB21CK-104X CAPACITOR 0.1µF,16V C2254 NCB21CK-104X CAPACITOR 0.1µF,16V C2255 NDC21HJ-181X CAPACITOR 180pF,50V C2601 QEKJ1CM-106 E CAPACITOR 10µF,16V C2602 NDC21HJ-101X CAPACITOR 100pF,50V C2603 NDC21HJ-101X CAPACITOR 100pF,50V C2604 QEKJ1CM-476 E CAPACITOR 47µF,16V C2605 QEKJ1CM-106 E CAPACITOR 10µF,16V C2606 QEKJ1HM-105 E CAPACITOR 1µF,50V C2607 QEKJ1HM-105 E CAPACITOR 1µF,50V C2610 NDC21HJ-101X CAPACITOR 100pF,50V C2611 NDC21HJ-101X CAPACITOR 100pF,50V C2612 QEKJ1CM-106 E CAPACITOR 10µF,16V C2651 QEKJ1CM-106 E CAPACITOR 10µF,16V C2652 QEKJ1CM-106 E CAPACITOR 10µF,16V C2653 NDC21HJ-101X CAPACITOR 100pF,50V C2654 NDC21HJ-101X CAPACITOR 100pF,50V C2655 QEKJ1CM-106 E CAPACITOR 10µF,16V C2681 QEKJ1CM-106 E CAPACITOR 10µF,16V C2682 QEKJ1CM-476 E CAPACITOR 47µF,16V C2683 QEKJ1CM-476 E CAPACITOR 47µF,16V C3001 NCB21EK-104X CAPACITOR 0.1µF,25V C3002 NCB21HK-103X CAPACITOR 0.01µF,50V C3003 QEKJ1CM-106 E CAPACITOR 10µF,16V C3004 NCB21EK-104X CAPACITOR 0.1µF,25V C3008 NCB21HK-102X CAPACITOR 0.001µF,50V C3010 QEZ0244-229 EDL CAPACITOR 0.0022F,5.5V C3012 QEKJ0JM-107 E CAPACITOR 100µF,6.3V C3015 NCB21EK-104X CAPACITOR 0.1µF,25V C3016 NCB21EK-104X CAPACITOR 0.1µF,25V C3022 NCB21EK-104X CAPACITOR 0.1µF,25V C3024 NDC21HJ-120X CAPACITOR 12pF,50V C3027 QERF1CM-106 E CAPACITOR 10µF,16V C3030 QERF1CM-226 E CAPACITOR 22µF,16V C3031 NCB21EK-104X CAPACITOR 0.1µF,25V C3032 NCB21EK-104X CAPACITOR 0.1µF,25V C3033 NCB21EK-104X CAPACITOR 0.1µF,25V C3036 NDC21HJ-180X CAPACITOR 18pF,50V C3037 NDC21HJ-120X CAPACITOR 12pF,50V C3040 NCB21HK-103X CAPACITOR 0.01µF,50V C3041 NDC21HJ-100X CAPACITOR 10pF,50V C3042 QETJ0JM-477 E CAPACITOR 470µF,6.3V C3054 NCB21EK-104X CAPACITOR 0.1µF,25V

C3602 NCB21EK-104X CAPACITOR 0.1µF,25V C3652 NCB21EK-104X CAPACITOR 0.1µF,25V C4002 NCB21EK-104X CAPACITOR 0.1µF,25V C4003 NCB21HK-102X CAPACITOR 0.001µF,50V C4004 QERF1CM-226 E CAPACITOR 22µF,16V C4006 QERF0JM-476 E CAPACITOR 47µF,6.3V C4007 NCB21HJ-102X CAPACITOR 0.001µF,50V C4008 NCB21AK-105X CAPACITOR 1µF,10V C4009 NCB21HK-563X CAPACITOR 0.056µF,50V C4010 NCB21EK-223X CAPACITOR 0.022µF,25V C4011 NCB21EK-104X CAPACITOR 0.1µF,25V C4012 NCB21EK-224X CAPACITOR 0.22µF,25V C4013 NCB21HK-563X CAPACITOR 0.056µF,50V C4014 NDC21HJ-101X CAPACITOR 100pF,50V C4015 NDC21HJ-331X CAPACITOR 330pF,50V C4016 NCB21HK-681X CAPACITOR 680pF,50V C4017 NCB21HK-222X CAPACITOR 0.0022µF,50V C6007 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C6008 NCB21HK-102X CAPACITOR 0.001µF,50V C6014 NCB21HK-103X CAPACITOR 0.01µF,50V C6023 NCB21HK-103X CAPACITOR 0.01µF,50V C6033 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C6037 QEKJ1CM-106 E CAPACITOR 10µF,16V C6553 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C6555 NCB21HK-102X CAPACITOR 0.001µF,50V C7503 QETJ0JM-477 E CAPACITOR 470µF,6.3V C7515 NCB21EK-104X CAPACITOR 0.1µF,25V C7516 NDC21HJ-101X CAPACITOR 100pF,50V L1 QQL29BJ-100Z COIL 10µH L3 QQL29BJ-100Z COIL 10µH L4 QQL29BJ-100Z COIL 10µH L5 QQR0521-012Z NOISE FILTER L12 QQR0967-001 COIL 12µH L13 QQL231J-330Y COIL 33µH L14 QQL231J-101Y COIL 100µH L15 QQL29BJ-100Z COIL 10µH L17 QQL231J-5R6Y COIL 5.6µH L18 QQL231J-220Y COIL 22µH L19 QQL231J-120Y COIL 12µH L20 QQL231J-680Y COIL 68µH L24 QQL231J-270Y COIL 27µH L25 QUY153-050Y IM BUS WIRE L26 QUY153-050Y IM BUS WIRE L27 QQL231J-330Y COIL 33µH L28 QQL231J-680Y COIL 68µH L301 QQL29BJ-100Z COIL 10µH L302 QQL231J-6R8Y COIL 6.8µH L303 QQL231J-270Y COIL 27µH L401 QQL071J-150Y COIL 15µH L402 QUY153-050Y IM BUS WIRE L701 QQL29BJ-4R7Z COIL 4.7µH L702 QQL29BJ-4R7Z COIL 4.7µH L712 QQL29BJ-4R7Z COIL 4.7µH L713 QQL231J-4R7Y COIL 4.7µH L714 QQL29BJ-4R7Z COIL 4.7µH L715 QQL29BJ-4R7Z COIL 4.7µH L2001 QQL29BJ-100Z COIL 10µH L2251 QQL29BJ-100Z COIL 10µH L2252 QQL29BJ-151Z COIL 150µH L3001 QRE141J-0R0Y RESISTOR 0Ø,1/4W L3011 QRE141J-0R0Y RESISTOR 0Ø,1/4W

5-15

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

L3012 QRE141J-0R0Y RESISTOR 0Ø,1/4W L6001 QQL29BJ-100Z COIL 10µH L6002 QQL29BJ-100Z COIL 10µH L6005 QQL29BJ-100Z COIL 10µH L6032 QUY153-050Y IM BUS WIRE L7501 QQL29BJ-101Z COIL 100µH X1 QAX0576-001 CRYSTAL RESONATOR X3001 QAX0444-001 CRYSTAL RESONATOR X3002 QAX0527-001 CRYSTAL RESONATOR S3001 QSW0602-004 PUSH SWITCH,REC SAFETY S3002 QSW0695-001 PUSH SWITCH,S.CASS.SW K2001 NQL092M-47NX COIL K2002 NQL092M-47NX COIL K2251 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W K2252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W K2253 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W K6080 NRSA02J-103X MG RESISTOR 10kØ,1/10W PC3001 GP3S123 IC(PHOTO SENSOR) PC3002 GP3S123 IC(PHOTO SENSOR) T2051 PELN0860 OSC TRANSFORMER T2052 PELN0861 OSC TRANSFORMER TU6001 QAU0175-001 TUNER SD1 LP30644-001A SHIELD CASE(PRE) FL701 PELN1199 EQUALIZER FL702 PELN1198 EQUALIZER WR100 QUQ112-1414CG FFC WIRE,S-SUB WR101 QUQ112-0922CG FFC WIRE,S-SUB WR3002 QUB351-15A4A4 SIN TWIST WIRE WR3003 QUB351-25A1A1 SIN TWIST WIRE OT1 LP40229-002A PLATE,S.CASE CN1 QGF1028C1-13 FPC CONNECTOR,(1-13)U.DRUM CN701 QGF1207C1-08 CN702 QGF1207C1-09 FPC CONNECTOR,(1-9)S-SUB CN703 QGA2001C1-06 CONNECTOR,(1-6)DIGITAL CN2001 QGF1207C1-07 FPC CONNECTOR,(1-7)A/C HEAD CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD CN2601 QGF1016C3-08 FFC/FPC CONNECTOR,(1-9)DIGITAL CN3001 QGF1207C1-05 FPC CONNECTOR,(1-5)DRUM CN3002 QGB2532J1-02 CONNECTOR,(1-2)LOADING MOTOR CN3003 QGB2015M2-08 CONNECTOR,(1-8)CAPSTAN MOTOR CN3004 QGB2534J2-04 CONNCTOR,(1-4)ROTARY ENCODER CN3011 QGF1209F2-18 CN3014 QGF1016C3-06 FFC/FPC CONNECTOR,(1-6)DIGITAL CN7501 QGB2024K1-15S CONNECTOR,(1-15)TERMINAL CN7502 QGB2024K1-05S CONNECTOR,(1-5)TERMINAL CN7503 QGB2024K1-14S CONNECTOR,(1-14)TERMINAL CN7504 QGB2024K1-11S CONNECTOR,(1-11)TERMINAL CN7506 QGF1207C1-14 FPC CONNECTOR,(1-14)S-SUB CN7507 QGF1209F2-10 FFC/FPC CONNECTOR,(1-10)JACK CN7508 QGF1207C1-13 FPC CONNECTOR,(1-13)REG CN7509 QGF1207C1-15 FPC CONNECTOR,(1-15)REG

CP3002 ICP-N15 CIRCUIT PROTECTOR

CP3003 ICP-N25 CIRCUIT PROTECTOR

CP3004 ICP-N15 CIRCUIT PROTECTOR

CP4001 ICP-N25 CIRCUIT PROTECTOR

FPC CONNECTOR,(1-8)S/P CONVERTER

FFC/FPC CONNECTOR,(1-18)SW/DISPLAY

******************************

3D DIGITAL/2M BOARD ASSEMBLY <05>

PW1 LPA10105-03A 3D DIGITAL/2M BOARD ASSY IC1401 JCP8026 IC Q1401 2SC1317/RS/-T TRANSISTOR Q1402 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q1403 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q1404 DTC144WU TRANSISTOR

or RN1309 TRANSISTOR or UN521E TRANSISTOR

Q1406 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q1407 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1408 2SC4081/S/-X TRANSISTOR Q1410 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1412 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1413 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1414 DTC144WU TRANSISTOR

or RN1309 TRANSISTOR

or UN521E TRANSISTOR Q1417 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q1418 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR Q1419 DTC124TU TRANSISTOR Q1420 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR D1401 RD4.3ES/B2/-T2 ZENER DIODE

or MTZJ4.3B ZENER DIODE D1402 1SS133 DIODE

or 1N4148M DIODE R1401 NRSA02J-181X MG RESISTOR 180Ø,1/10W R1402 NRSA02J-101X MG RESISTOR 100Ø,1/10W R1404 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R1406 NRSA02J-471X MG RESISTOR 470Ø,1/10W R1407 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R1408 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R1410 NRSA02J-391X MG RESISTOR 390Ø,1/10W R1411 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R1413 NRSA02J-331X MG RESISTOR 330Ø,1/10W R1414 NRSA02J-821X MG RESISTOR 820Ø,1/10W R1415 NRSA02J-221X MG RESISTOR 220Ø,1/10W R1416 NRSA02J-104X MG RESISTOR 100kØ,1/10W R1417 NRSA02J-101X MG RESISTOR 100Ø,1/10W R1418 NRSA02J-471X MG RESISTOR 470Ø,1/10W R1421 NRSA02J-391X MG RESISTOR 390Ø,1/10W R1426 NRSA02J-561X MG RESISTOR 560Ø,1/10W R1427 NRSA02J-333X MG RESISTOR 33kØ,1/10W R1428 NRSA02J-393X MG RESISTOR 39kØ,1/10W R1429 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R1430 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R1431 NRSA02J-821X MG RESISTOR 820Ø,1/10W R1432 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W

5-16

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R1433 NRSA02J-510X MG RESISTOR 51Ø,1/10W R1434 NRSA02J-153X MG RESISTOR 15kØ,1/10W R1435 NRSA02J-223X MG RESISTOR 22kØ,1/10W R1436 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R1437 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R1438 NRSA02J-473X MG RESISTOR 47kØ,1/10W R1439 NRSA02J-273X MG RESISTOR 27kØ,1/10W R1440 NRSA02J-473X MG RESISTOR 47kØ,1/10W R1441 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R1442 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R1446 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1447 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1448 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1449 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1450 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1452 NRSA02J-471X MG RESISTOR 470Ø,1/10W R1453 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1454 NRSA02J-102X MG RESISTOR 1kØ,1/10W R1455 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1458 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1459 NRSA02J-681X MG RESISTOR 680Ø,1/10W R1460 NRSA02J-273X MG RESISTOR 27kØ,1/10W R1461 NRSA02J-121X MG RESISTOR 120Ø,1/10W R1463 NRSA02J-101X MG RESISTOR 100Ø,1/10W VR1401 QVZ3521-103Z V RESISTOR,D/A LEVEL ADJ B1412 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C1401 QEKJ1CM-336 E CAPACITOR 33µF,16V C1402 NCB21HK-103X CAPACITOR 0.01µF,50V C1403 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C1404 NCF21EZ-104X CAPACITOR 0.1µF,25V C1405 NCF21EZ-104X CAPACITOR 0.1µF,25V C1406 NCB21HK-103X CAPACITOR 0.01µF,50V C1407 NDC21HJ-680X CAPACITOR 68pF,50V C1408 NDC21HJ-330X CAPACITOR 33pF,50V C1410 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C1411 NCF21EZ-104X CAPACITOR 0.1µF,25V C1412 NDC21HJ-680X CAPACITOR 68pF,50V C1413 NDC21HJ-330X CAPACITOR 33pF,50V C1415 NCF21EZ-104X CAPACITOR 0.1µF,25V C1416 QEKJ1CM-106 E CAPACITOR 10µF,16V C1417 NCF21EZ-104X CAPACITOR 0.1µF,25V C1421 NDC21HJ-330X CAPACITOR 33pF,50V C1422 NDC21HJ-680X CAPACITOR 68pF,50V C1423 NCF21EZ-104X CAPACITOR 0.1µF,25V C1424 NCB21HK-103X CAPACITOR 0.01µF,50V C1425 NCB21HK-103X CAPACITOR 0.01µF,50V C1426 NDC21HJ-390X CAPACITOR 39pF,50V C1428 NDC21HJ-220X CAPACITOR 22pF,50V C1429 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C1430 NCF21EZ-104X CAPACITOR 0.1µF,25V C1432 NCF21CZ-105X CAPACITOR 1µF,16V C1433 NCF21EZ-104X CAPACITOR 0.1µF,25V C1435 NCF21EZ-104X CAPACITOR 0.1µF,25V C1436 NCF21EZ-104X CAPACITOR 0.1µF,25V C1437 NCF21EZ-104X CAPACITOR 0.1µF,25V C1438 NCF21EZ-104X CAPACITOR 0.1µF,25V C1439 NCF21CZ-105X CAPACITOR 1µF,16V C1440 NCF21EZ-104X CAPACITOR 0.1µF,25V C1441 NCF21EZ-104X CAPACITOR 0.1µF,25V C1442 NCF21CZ-105X CAPACITOR 1µF,16V C1444 NCF21EZ-104X CAPACITOR 0.1µF,25V

C1445 NCF21EZ-104X CAPACITOR 0.1µF,25V C1446 QEKJ0JM-107 E CAPACITOR 100µF,6.3V C1447 NCF21EZ-104X CAPACITOR 0.1µF,25V C1448 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C1449 NCF21EZ-104X CAPACITOR 0.1µF,25V C1450 NCF21EZ-104X CAPACITOR 0.1µF,25V C1451 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C1452 NCF21EZ-104X CAPACITOR 0.1µF,25V C1453 NCF21EZ-104X CAPACITOR 0.1µF,25V C1454 NCF21EZ-104X CAPACITOR 0.1µF,25V C1455 NCF21EZ-104X CAPACITOR 0.1µF,25V C1459 NDC21HJ-470X CAPACITOR 47pF,50V C1460 NDC21HJ-470X CAPACITOR 47pF,50V C1461 NDC21HJ-470X CAPACITOR 47pF,50V C1462 NDC21HJ-470X CAPACITOR 47pF,50V C1463 QEKJ0JM-336 E CAPACITOR 33µF,6.3V C1465 NDC21HJ-470X CAPACITOR 47pF,50V C1466 NDC21HJ-470X CAPACITOR 47pF,50V C1467 NDC21HJ-470X CAPACITOR 47pF,50V C1468 NDC21HJ-101X CAPACITOR 100pF,50V C1470 NDC21HJ-330X CAPACITOR 33pF,50V C1471 NCF21EZ-104X CAPACITOR 0.1µF,25V C1472 NCF21EZ-104X CAPACITOR 0.1µF,25V C1473 NCF21EZ-104X CAPACITOR 0.1µF,25V L1401 QQL29BJ-100Z COIL 10µH L1402 QQL071J-6R8Y COIL 6.8µH L1403 QQL071J-6R8Y COIL 6.8µH L1404 QQL071J-6R8Y COIL 6.8µH L1405 QQL29BJ-101Z COIL 100µH L1406 QQL071J-330Y COIL 33µH L1407 QQL29BJ-101Z COIL 100µH L1409 QQL071J-1R0Y COIL 1.0µH LC1401 QQR0521-007Z NOISE FILTER LC1402 QQR0521-006Z NOISE FILTER SD1 LP30706-001C SHIELD FRAME(S-VHS) SD2 LP30684-001A SHIELD CASE(S-VHS) CN1401 QGG2502K1-17 HEADER PIN,(1-7)MAIN

******************************

TERMINAL BOARD ASSEMBLY <06>

PW1 LPA10114-04A TERMINAL BOARD ASSY IC7101 MM1224XF IC IC7102 MM1228XF IC IC7103 MM1024AF IC IC7104 BH7636S IC Q7102 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q7103 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q7104 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q7106 DTC144WUA-X TRANSISTOR

or UN521E-X TRANSISTOR or RN1309-X TRANSISTOR

5-17

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

or PDTC144WU-X TRANSISTOR Q7107 2SC3938/QR/-X TRANSISTOR Q7108 2SC3938/QR/-X TRANSISTOR Q7109 2SC3938/QR/-X TRANSISTOR Q7110 2SC3938/QR/-X TRANSISTOR Q7111 DTC144WUA-X TRANSISTOR

or UN521E-X TRANSISTOR

or RN1309-X TRANSISTOR

or PDTC144WU-X TRANSISTOR Q7112 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q7113 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7114 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q7115 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7116 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q7117 DTC114EU TRANSISTOR

or PDTC114EU TRANSISTOR

or RN1302 TRANSISTOR

or UN5211 TRANSISTOR Q7118 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7119 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR Q7120 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7121 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q7122 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR Q7123 2SA1576A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR Q7124 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR D7101 DA204U-W DIODE R7102 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7104 NRVA02D-561X CMF RESISTOR 560Ø,1/10W R7105 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R7107 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7108 NRSA02J-821X MG RESISTOR 820Ø,1/10W R7109 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7110 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R7111 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7112 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R7113 NRSA02J-271X MG RESISTOR 270Ø,1/10W R7114 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W

R7115 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R7116 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R7117 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R7118 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W R7119 NRSA02J-471X MG RESISTOR 470kØ,1/10W R7120 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R7121 NRVA02D-561X CMF RESISTOR 560Ø,1/10W R7122 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R7123 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7124 NRVA02D-750X CMF RESISTOR 75Ø,1/10W R7125 NRVA02D-750X CMF RESISTOR 75Ø,1/10W R7126 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7127 NRVA02D-561X CMF RESISTOR 560Ø,1/10W R7128 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R7129 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7130 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R7131 NRSA02J-153X MG RESISTOR 15kØ,1/10W R7132 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7133 QRE121J-331Y RESISTOR 330Ø,1/2W R7134 QRE141J-680Y RESISTOR 68Ø,1/4W R7135 NRVA02D-680X CMF RESISTOR 68Ø,1/10W R7136 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7137 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R7138 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7139 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7140 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7141 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7142 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7143 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7144 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7145 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7146 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7147 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7148 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7149 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R7150 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7151 NRSA02J-471X MG RESISTOR 470Ø,1/10W R7152 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R7153 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7154 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R7155 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R7156 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7157 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7158 NRSA02J-102X MG RESISTOR 1kØ,1/10W R7159 NRSA02J-750X MG RESISTOR 75Ø,1/10W R7160 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7161 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7162 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7163 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7164 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7165 NRSA02J-101X MG RESISTOR 100Ø,1/10W R7167 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7168 NRSA02J-271X MG RESISTOR 270Ø,1/10W R7169 QRE141J-682Y RESISTOR 6.8kØ,1/4W R7170 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7171 NRSA02J-333X MG RESISTOR 33kØ,1/10W R7172 NRSA02J-103X MG RESISTOR 10kØ,1/10W R7173 NRSA02J-3R3X MG RESISTOR 3.3Ø,1/10W R7174 QRE141J-152Y RESISTOR (W7159) 1.5kØ,1/2W C7101 NCB21HK-103X CAPACITOR 0.01µF,50V C7102 QEKJ0JM-476 E CAPACITOR 47µF,6.3V

5-18

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C7103 QEKJ1CM-476 E CAPACITOR 47µF,16V C7104 NCB21HK-103X CAPACITOR 0.01µF,50V C7105 NCB21HK-103X CAPACITOR 0.01µF,50V C7106 NCB21EK-104X CAPACITOR 0.1µF,25V C7107 NCB21HK-103X CAPACITOR 0.01µF,50V C7108 NCB21HK-103X CAPACITOR 0.01µF,50V C7110 NCB21HK-103X CAPACITOR 0.01µF,50V C7112 QEKJ1CM-106 E CAPACITOR 10µF,16V C7113 NCB21HK-103X CAPACITOR 0.01µF,50V C7114 NCB21HK-103X CAPACITOR 0.01µF,50V C7116 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C7117 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C7118 QEKJ0JM-107 E CAPACITOR 100µF,6.3V C7119 NCB21HK-103X CAPACITOR 0.01µF,50V C7120 QEPF1HM-474 NP E CAPACITOR 0.47µF,50V C7121 NDC21HJ-270X CAPACITOR 27pF,50V C7122 NCB21HK-103X CAPACITOR 0.01µF,50V C7123 NCB21HK-103X CAPACITOR 0.01µF,50V C7124 NCB21HK-103X CAPACITOR 0.01µF,50V C7125 QEKJ1CM-476 E CAPACITOR 47µF,16V C7126 NCB21HK-103X CAPACITOR 0.01µF,50V C7127 NDC21HJ-330X CAPACITOR 33pF,50V C7129 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C7130 NCB21HK-681X CAPACITOR 680pF,50V C7131 NCB21HK-102X CAPACITOR 0.001µF,50V C7132 NCB21HK-681X CAPACITOR 680pF,50V C7133 NCB21HK-102X CAPACITOR 0.001µF,50V C7138 QEKJ1CM-107 E CAPACITOR 100µF,16V C7139 QEKJ1CM-107 E CAPACITOR 100µF,16V C7140 NCB21EK-104X CAPACITOR 0.1µF,25V C7142 NCB21EK-104X CAPACITOR 0.1µF,25V C7143 NCB21EK-104X CAPACITOR 0.1µF,25V C7145 NCB21EK-104X CAPACITOR 0.1µF,25V C7146 NDC21HJ-330X CAPACITOR 33pF,50V C7147 NCB21EK-104X CAPACITOR 0.1µF,25V C7148 NCB21EK-104X CAPACITOR 0.1µF,25V C7150 NCB21HK-103X CAPACITOR 0.01µF,50V C7151 QEKJ1CM-106 E CAPACITOR 10µF,16V C7152 QEKJ1CM-106 E CAPACITOR 10µF,16V C7153 QEKJ1CM-106 E CAPACITOR 10µF,16V C7154 NCB21CK-105X CAPACITOR 1µF,16V C7155 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C7156 NCB21HK-681X CAPACITOR 680pF,50V C7158 NCB21HK-681X CAPACITOR 680pF,50V C7159 NCB21HK-102X CAPACITOR 0.001µF,50V C7166 NCB21HK-102X CAPACITOR 0.001µF,50V C7167 NCB21HK-102X CAPACITOR 0.001µF,50V C7168 QEKJ0JM-476 E CAPACITOR 47µF,6.3V C7169 NCB21HK-103X CAPACITOR 0.01µF,50V C7170 NCB21HK-102X CAPACITOR 0.001µF,50V L7101 QQL29BJ-4R7Z COIL 4.7µH L7102 QQL29BJ-4R7Z COIL 4.7µH L7103 QQL29BJ-4R7Z COIL 4.7µH L7104 QUY153-050Y IM BUS WIRE L7105 QUY153-050Y IM BUS WIRE L7106 QQL071J-4R7Y COIL 4.7µH L7107 QQL071J-4R7Y COIL 4.7µH L7108 QQL071J-4R7Y COIL 4.7µH L7109 QQL071J-4R7Y COIL 4.7µH L7110 QUY153-050Y IM BUS WIRE L7113 QQL071J-1R0Y COIL 1.0µH

L7115 QQL29BK-1R0Z COIL 1.0µH L7116 QUY153-050Y IM BUS WIRE L7117 QQL071J-4R7Y COIL 4.7µH L7118 QQL071J-4R7Y COIL 4.7µH L7119 QQL071J-4R7Y COIL 4.7µH L7120 QQL071J-4R7Y COIL 4.7µH L7121 QQL071J-4R7Y COIL 4.7µH L7122 QQL071J-4R7Y COIL 4.7µH L7123 QUY153-050Y IM BUS WIRE ET1 QNZ0431-001Z EARTH TERMINAL J7101 QND0009-001 S JACK,S_OUT J7102 QNZ0418-001 21P CONNECTOR,AV1 J7103 PU60659 MINI JACK,SAT_CTL J7104 QNZ0418-001 21P CONNECTOR,AV2 J7105 QNN0295-002 PIN JACK,A.OUT(L/R) CN7101 QGB2024J1-15S CONNECTOR,(1-15)MAIN CN7102 QGB2024J1-05S CONNECTOR,(1-5)MAIN CN7103 QGB2024J1-14S CONNECTOR,(1-14)MAIN CN7104 QGB2024J1-11S CONNECTOR,(1-11)MAIN

******************************

A/C HEAD BOARD ASSEMBLY <12>

PW1 LPA10010-01A1 A/C HEAD BOARD ASSY CN1 QGF1208F1-07 FPC CONNECTOR

******************************

DEMOD BOARD ASSEMBLY <14>

PW1 LPA10094-05A DEMOD BOARD ASSY IC6701 MSP3417D IC

or MSP3417DG3 IC

or MSP3417G IC Q6701 2SC3936/BC/-X TRANSISTOR D6701 1SS133 DIODE

or 1N4148M DIODE R6701 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R6702 NRSA02J-682X MG RESISTOR 6.8kØ,1/10W R6703 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6705 NRSA02J-271X MG RESISTOR 270Ø,1/10W R6707 NQR0200-003X FERRITE BEAD R6708 NQR0200-003X FERRITE BEAD R6709 NQR0200-003X FERRITE BEAD R6710 NQR0200-003X FERRITE BEAD R6711 NRSA02J-684X MG RESISTOR 680kØ,1/10W R6712 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6714 NRSA02J-102X MG RESISTOR 1kØ,1/10W R6716 NQR0200-003X FERRITE BEAD R6719 QRE141J-103Y RESISTOR 10kØ,1/4W R6720 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R6721 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W C6701 NCB21HK-103X CAPACITOR 0.01µF,50V C6704 NCB21HK-103X CAPACITOR 0.01µF,50V C6707 NDC21HJ-470X CAPACITOR 47pF,50V

5-19

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C6708 NDC21HJ-7R0X CAPACITOR 7pF,50V C6709 NDC21HJ-3R0X CAPACITOR 3pF,50V C6713 NCF21CZ-224X CAPACITOR 0.22µF,16V C6714 NCB21HK-682X CAPACITOR 0.0068µF,50V C6715 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6716 NCB21HK-682X CAPACITOR 0.0068µF,50V C6717 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C6719 QEKJ1EM-106 E CAPACITOR 10µF,25V C6720 QEKJ1EM-106 E CAPACITOR 10µF,25V C6721 NCB21HK-103X CAPACITOR 0.01µF,50V C6723 NCB21HK-103X CAPACITOR 0.01µF,50V C6724 QEKJ1HM-225 E CAPACITOR 2.2µF,50V L6701 QUY153-050Y IM BUS WIRE X6701 QAX0443-001 CRYSTAL RESONATOR K6701 NRSA02J-330X MG RESISTOR 33Ø,1/10W K6702 NQR0200-003X FERRITE BEAD K6703 NRSA02J-102X MG RESISTOR 1kØ,1/10W K6704 NRSA02J-102X MG RESISTOR 1kØ,1/10W K6705 NRSA02J-100X MG RESISTOR 10Ø,1/10W K6706 NRSA02J-470X MG RESISTOR 47Ø,1/10W K6707 NQR0200-003X FERRITE BEAD BK1 LP40425-001A BRACKET(BOARD) CN6701 QGG2502K1-10 HEADER PIN

******************************

S-SUB BOARD ASSEMBLY <15>

PW1 LPA10103-02A S-SUB BOARD ASSY IC501 JCP8018 IC

or JCP8028 IC or JCP8028-01 IC

or JCP8038 IC IC502 VC2076DP IC R503 NRSA02J-221X MG RESISTOR 220Ø,1/10W R504 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R505 NRSA02J-392X MG RESISTOR 3.9kØ,1/10W R506 NRSA02J-391X MG RESISTOR 390Ø,1/10W R507 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R508 NRSA02J-151X MG RESISTOR 150Ø,1/10W R509 NRSA02J-162X MG RESISTOR 1.6kØ,1/10W R510 NRVA02D-102X CMF RESISTOR 1kØ,1/10W R511 NRVA02D-471X CMF RESISTOR 470Ø,1/10W R512 NRVA02D-102X CMF RESISTOR 1kØ,1/10W R513 NRVA02D-152X CMF RESISTOR 1.5kØ,1/10W R514 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W R515 NRVA02D-332X CMF RESISTOR 3.3kØ,1/10W R516 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R517 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R525 NRSA02J-125X MG RESISTOR 1.2MØ,1/10W R531 NRSA02J-101X MG RESISTOR 100Ø,1/10W R532 NRSA02J-101X MG RESISTOR 100Ø,1/10W R533 NRSA02J-101X MG RESISTOR 100Ø,1/10W R534 NRSA02J-101X MG RESISTOR 100Ø,1/10W R535 NRSA02J-101X MG RESISTOR 100Ø,1/10W R536 NRSA02J-101X MG RESISTOR 100Ø,1/10W B501 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B503 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W

C501 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C502 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C503 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C504 NCB21EK-104X CAPACITOR 0.1µF,25V C505 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C506 NCB21EK-104X CAPACITOR 0.1µF,25V C507 QEKJ0JM-227 E CAPACITOR 220µF,6.3V C508 QEPF1HM-474 NP E CAPACITOR 0.47µF,50V C509 QEKJ1CM-106 E CAPACITOR 10µF,16V C510 QEKJ0JM-227 E CAPACITOR 220µF,6.3V C511 NCB21HK-103X CAPACITOR 0.01µF,50V C512 NCB21HK-103X CAPACITOR 0.01µF,50V C513 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C514 NCB21HK-103X CAPACITOR 0.01µF,50V C515 NCB21HK-103X CAPACITOR 0.01µF,50V C516 NCB21HK-103X CAPACITOR 0.01µF,50V C517 NCF21EZ-104X CAPACITOR 0.1µF,25V C518 NCB21EK-104X CAPACITOR 0.1µF,25V C519 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C520 QERF1EM-475 E CAPACITOR 4.7µF,25V C521 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C522 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C523 QEKJ1HM-225 E CAPACITOR 2.2µF,50V C524 NDC21HG-301X CAPACITOR 300pF,50V C525 NDC21HG-301X CAPACITOR 300pF,50V C526 NDC21HJ-101X CAPACITOR 100pF,50V C527 NDC21HJ-181X CAPACITOR 180pF,50V C528 NDC21HG-271X CAPACITOR 270pF,50V C529 NDC21HG-820X CAPACITOR 82pF,50V C530 NDC21HG-221X CAPACITOR 220pF,50V C531 NDC21HG-301X CAPACITOR 300pF,50V C532 NDC21HG-301X CAPACITOR 300pF,50V C533 NCB21HK-103X CAPACITOR 0.01µF,50V C534 QETJ0JM-477 E CAPACITOR 470µF,6.3V C535 NCB21HK-103X CAPACITOR 0.01µF,50V C551 QEKJ1HM-105 E CAPACITOR 1µF,50V C553 NCB21HK-103X CAPACITOR 0.01µF,50V C554 QEKJ1HM-105 E CAPACITOR 1µF,50V C556 NCB21HK-103X CAPACITOR 0.01µF,50V C557 QEKJ1HM-105 E CAPACITOR 1µF,50V C559 NCB21HK-103X CAPACITOR 0.01µF,50V C560 QEKJ1HM-105 E CAPACITOR 1µF,50V C561 QEKJ1HM-105 E CAPACITOR 1µF,50V C562 QEKJ1HM-105 E CAPACITOR 1µF,50V C564 NCB21HK-103X CAPACITOR 0.01µF,50V C566 NCB21HK-103X CAPACITOR 0.01µF,50V C568 NDC21HJ-680X CAPACITOR 68pF,50V C569 NDC21HJ-680X CAPACITOR 68pF,50V C570 NDC21HJ-680X CAPACITOR 68pF,50V C571 NDC21HJ-680X CAPACITOR 68pF,50V C572 NDC21HJ-680X CAPACITOR 68pF,50V C573 NDC21HJ-680X CAPACITOR 68pF,50V L501 QQL29BJ-100Z COIL 10µH L503 QQL29BJ-100Z COIL 10µH L504 QQL29BJ-100Z COIL 10µH BK1 LP40077-001A BRACKET(BOARD) CN511 QGG2503K2-30 HEADER PIN,(1-30)MAIN CN512 QGF1209F2-14 FFC/FPC CONNE,(1-14)MAIN CN513 QGF1208F1-09 FPC CONNECTOR,(1-9)P/S CONVERTER

5-20

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C857 NDC21HJ-560X CAPACITOR 56pF,50V

******************************

ON SCREEN BOARD ASSEMBLY <17>

PW1 LPA10127-06A ON SCREEN BOARD ASSY IC851 LC74775-9750 IC Q853 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q857 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q858 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SD1819A/QRS/-X TRANSISTOR

Q859 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q860 DTC114EU TRANSISTOR

or PDTC114EU TRANSISTOR or RN1302 TRANSISTOR

or UN5211 TRANSISTOR D851 QUY153-050Y IM BUS WIRE D852 QRE141J-152Y RESISTOR 1.5kØ,1/4W D853 QRE141J-101Y RESISTOR 100Ø,1/4W D854 QRE141J-101Y RESISTOR 100Ø,1/4W D855 DA204U DIODE R853 NRSA02J-103X MG RESISTOR 10kØ,1/10W R857 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R860 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R862 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R863 NRSA02J-331X MG RESISTOR 330Ø,1/10W R870 NRSA02J-103X MG RESISTOR 10kØ,1/10W R872 NRSA02J-103X MG RESISTOR 10kØ,1/10W R873 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R874 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R875 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R876 NRSA02J-512X MG RESISTOR 5.1kØ,1/10W R877 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R878 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W R879 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R880 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R881 NRSA02J-471X MG RESISTOR 470Ø,1/10W R882 NRSA02J-184X MG RESISTOR 180kØ,1/10W R883 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W R884 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W R885 NRSA02J-153X MG RESISTOR 15kØ,1/10W R886 NRSA02J-681X MG RESISTOR 680Ø,1/10W R887 NRSA02J-103X MG RESISTOR 10kØ,1/10W R888 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R891 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B851 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B853 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B855 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B857 QUY153-050Y IM BUS WIRE B860 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B863 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C851 QEKJ0JM-337 E CAPACITOR 330µF,6.3V C852 NCB21EK-224X CAPACITOR 0.22µF,25V C853 NCB21CK-105X CAPACITOR 1µF,16V C856 NCB21CK-105X CAPACITOR 1µF,16V

C858 NCB21CK-474X CAPACITOR 0.47µF,16V C860 NCB21HK-103X CAPACITOR 0.01µF,50V C865 NDC21HJ-100X CAPACITOR 10pF,50V C867 NDC21HJ-330X CAPACITOR 33pF,50V C868 NDC21HJ-330X CAPACITOR 33pF,50V C870 NDC21HJ-101X CAPACITOR 100pF,50V C871 NDC21HJ-101X CAPACITOR 100pF,50V C872 NCB21EK-104X CAPACITOR 0.1µF,25V C873 QEKJ1EM-475 E CAPACITOR 4.7µF,25V C874 NCB21EK-224X CAPACITOR 0.22µF,25V C875 NCB21EK-224X CAPACITOR 0.22µF,25V C876 QEKJ0JM-227 E CAPACITOR 220µF,6.3V C877 QEKJ1CM-476 E CAPACITOR 47µF,16V C878 NCB21HK-103X CAPACITOR 0.01µF,50V C879 NCB21EK-104X CAPACITOR 0.1µF,25V C881 NCB21HK-471X CAPACITOR 470pF,50V C882 NCB21HK-223X CAPACITOR 0.022µF,50V C883 QEKJ1HM-225 E CAPACITOR 2.2µF,50V L851 QQL01BK-1R0Z COIL 1.0µH L852 QQL071J-220Y COIL 22µH L853 QQL29BJ-100Z COIL 10µH L854 QUY153-050Y IM BUS WIRE L855 QUY153-050Y IM BUS WIRE L857 QQL071J-330Y COIL 33µH L858 QQL37CJ-220Z COIL 22µH L859 QQL29BJ-4R7Z COIL 4.7µH T851 PELN0806 LC TRAP BK1 LP40077-001A BRACKET(BOARD) CN851 QGG2502K1-20 HEADER PIN

******************************

EJECT SW BOARD ASSEMBLY <27>

PW5 LPA10126-01C5 EJECT SW BOARD ASSY S7011 QSW0456-002Z TACT SWITCH,VHS EJECT FW7005 QUM022-15A4A4 PARA RIBON WIRE

******************************

SW/DISPLAY BOARD ASSEMBLY <28>

PW1 LPA10126-04A1 SW/DISPLAY BOARD ASSY IC7001 M35500BGP IC

or M35500AGP IC or M35500BFP IC

IC7002 PNA4652M00XB IR DETECT UNIT

or GP1U281X IR DETECT UNIT Q7001 DTC114ES TRANSISTOR D7002 RD9.1ES/B2/-T2 ZENER DIODE

or UZ9.1BSB ZENER DIODE

or MTZJ9.1B ZENER DIODE D7004 1SS133 DIODE

or 1N4148M DIODE D7005 1SS133 DIODE

or 1N4148M DIODE D7006 1SS133 DIODE

or 1N4148M DIODE

5-21

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

D7009 SLR-342DU3F LE DIODE,VHS D7010 SLR-342MG3F LE DIODE,VHS PLAY D7011 SLR-342VR3F LE DIODE,VHS REC D7013 SLR-342MG3F LE DIODE,D/H PLAY D7014 SLR-342VR3F LE DIODE,D/H REC R7001 QRE141J-471Y RESISTOR 470Ø,1/4W R7002 QRE141J-471Y RESISTOR 470Ø,1/4W R7003 QRE141J-471Y RESISTOR 470Ø,1/4W R7004 QRE141J-471Y RESISTOR 470Ø,1/4W R7006 QRE141J-103Y RESISTOR 10kØ,1/4W R7007 QRE141J-103Y RESISTOR 10kØ,1/4W R7008 QRE141J-103Y RESISTOR 10kØ,1/4W R7013 QRE141J-103Y RESISTOR 10kØ,1/4W R7014 QUY153-050Y IM BUS WIRE R7015 QUY153-050Y IM BUS WIRE R7020 QRE141J-103Y RESISTOR 10kØ,1/4W R7021 QRE141J-122Y RESISTOR 1.2kØ,1/4W R7022 QRE141J-182Y RESISTOR 1.8kØ,1/4W R7023 QRE141J-222Y RESISTOR 2.2kØ,1/4W R7024 QRE141J-272Y RESISTOR 2.7kØ,1/4W R7025 QRE141J-472Y RESISTOR 4.7kØ,1/4W R7026 QRE141J-682Y RESISTOR 6.8kØ,1/4W R7027 QRE141J-153Y RESISTOR 15kØ,1/4W R7028 QRE141J-393Y RESISTOR 39kØ,1/4W R7030 QRE141J-103Y RESISTOR 10kØ,1/4W R7031 QRE141J-122Y RESISTOR 1.2kØ,1/4W R7032 QRE141J-182Y RESISTOR 1.8kØ,1/4W R7033 QRE141J-222Y RESISTOR 2.2kØ,1/4W R7034 QRE141J-272Y RESISTOR 2.7kØ,1/4W R7035 QRE141J-472Y RESISTOR 4.7kØ,1/4W R7036 QRE141J-682Y RESISTOR 6.8kØ,1/4W R7037 QRE141J-153Y RESISTOR 15kØ,1/4W R7038 QRE141J-393Y RESISTOR 39kØ,1/4W R7040 QRE141J-103Y RESISTOR 10kØ,1/4W R7041 QRE141J-122Y RESISTOR 1.2kØ,1/4W R7042 QRE141J-182Y RESISTOR 1.8kØ,1/4W R7043 QRE141J-222Y RESISTOR 2.2kØ,1/4W R7044 QRE141J-272Y RESISTOR 2.7kØ,1/4W R7045 QRE141J-472Y RESISTOR 4.7kØ,1/4W R7046 QRE141J-682Y RESISTOR 6.8kØ,1/4W R7047 QRE141J-153Y RESISTOR 15kØ,1/4W R7051 QRE141J-331Y RESISTOR 330Ø,1/4W R7052 QRE141J-331Y RESISTOR 330Ø,1/4W R7053 QRE141J-331Y RESISTOR 330Ø,1/4W R7054 QRE141J-331Y RESISTOR 330Ø,1/4W R7057 QRE141J-331Y RESISTOR 330Ø,1/4W R7058 QRE141J-331Y RESISTOR 330Ø,1/4W R7059 QRE141J-331Y RESISTOR 330Ø,1/4W R7060 QRE141J-103Y RESISTOR 10kØ,1/4W C7001 QCFB1HZ-104 CAPACITOR 0.1µF,50V C7002 QETN1HM-106 E CAPACITOR 10µF,50V C7007 QEKC0JM-476 E CAPACITOR 47µF,6.3V C7009 QCSB1HJ-150 CAPACITOR 15pF,50V C7010 QCFB1HZ-104 CAPACITOR 0.1µF,50V C7011 QEKC1AM-227 E CAPACITOR 220µF,10V C7019 QDVB1EZ-223Y CAPACITOR 0.022µF,25V L7001 QUY153-050Y IM BUS WIRE S7001 QSW0456-002Z TACT SWITCH,POWER S7002 QSW0456-002Z TACT SWITCH,CH+ S7003 QSW0456-002Z TACT SWITCH,CHS7004 QSW0456-002Z TACT SWITCH,REC

S7005 QSW0456-002Z TACT SWITCH,PAUSE S7006 QSW0456-002Z TACT SWITCH,PLAY S7007 QSW0456-002Z TACT SWITCH,STOP S7012 QSW0456-002Z TACT SWITCH,SVHS ET S7013 QSW0456-002Z TACT SWITCH,VHS S7015 QSW0456-002Z TACT SWITCH,REW S7016 QSW0456-002Z TACT SWITCH,MENU S7017 QSW0456-002Z TACT SWITCH,NAVI S7018 QSW0456-002Z TACT SWITCH,A.DUB S7019 QSW0456-002Z TACT SWITCH,FF S7021 QSW0456-002Z TACT SWITCH,LEFT S7022 QSW0456-002Z TACT SWITCH,RIGHT S7023 QSW0456-002Z TACT SWITCH,OK S7026 QSW0456-002Z TACT SWITCH,UP S7027 QSW0456-002Z TACT SWITCH,DOWN DI7001 QLF0031-002 FL TUBE HD1 PQ34949 FDP HOLDER(L),DI7001 HD2 PQ34950 FDP HOLDER(R),DI7001 HD3 PQ40795-2-2 LED HOLDER,D7009 HD4 PQM30038-1-2 LED HOLDER,D7010 HD5 PQM30038-1-2 LED HOLDER,D7011 HD6 PQM30038-1-2 LED HOLDER,D7013 HD7 PQM30038-1-2 LED HOLDER,D7014 CN7001 QGF1207F1-18 FPC CONNECTOR,(1-18)MAIN

******************************

JACK BOARD ASSEMBLY <36>

PW2 LPA10126-04A2 JACK BOARD ASSY D7063 1SS133 DIODE

or 1N4148M DIODE

D7064 1SS133 DIODE

or 1N4148M DIODE

D7065 1SS133 DIODE

or 1N4148M DIODE

D7066 1SS133 DIODE

or 1N4148M DIODE R7061 QRE141J-750Y RESISTOR 75Ø,1/4W R7062 QUY153-050Y IM BUS WIRE R7063 QRE141J-750Y RESISTOR 75Ø,1/4W R7064 QRE141J-750Y RESISTOR 75Ø,1/4W C7061 QDYB1CM-103Y CAPACITOR 0.01µF,16V C7062 QCBB1HJ-681 CAPACITOR 680pF,50V C7064 QCBB1HJ-681 CAPACITOR 680pF,50V L7061 QQL071J-100Y COIL 10µH L7062 QQL071J-100Y COIL 10µH L7063 QUY153-050Y IM BUS WIRE L7064 QUY153-050Y IM BUS WIRE J7001 QND0084-001 S JACK,S VIDEO J7002 PEMC1009-04 PIN JACK,V IN J7003 PEMC1010-02 PIN JACK(SW),R IN J7004 PEMC1010-03 PIN JACK(SW),L IN J7005 PU60659 MINI JACK,R.PAUSE CN7002 QGF1207F1-10 FPC CONNECTOR,(1-10)MAIN

5-22

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

IC8203 K4S641632E-TC1H IC

******************************

LED/SW BOARD ASSEMBLY <47>

PW3 LPA10126-04A3 LED/SW BOARD ASSY D7012 SLR-342DU3F LE DIODE,HDR D7018 SLR-342VR3F LE DIODE,REC LINK S7010 QSW0456-001Z TACT SWITCH,HDR S7028 QSW0456-001Z TACT SWITCH,REC LINK FW7003 QUM036-04A4A4 PARA RIBON WIRE

******************************

DIGITAL SUB BOARD ASSEMBLY <49>

PW1 LPA20023-01A DIGITAL SUB BOARD ASSY IC1 EPM3064AT10-003 IC IC2 UPD485505G-25 IC R1 NRSA63J-102X MG RESISTOR 1kØ,1/16W R2 NRSA63J-102X MG RESISTOR 1kØ,1/16W R3 NRSA63J-103X MG RESISTOR 10kØ,1/16W R4 NRSA63J-103X MG RESISTOR 10kØ,1/16W R5 NRSA63J-102X MG RESISTOR 1kØ,1/16W RA1 NRZ0040-330X NETWORK RESISTOR 33Ø RA2 NRZ0040-330X NETWORK RESISTOR 33Ø C1 NCB31CK-104X CAPACITOR 0.1µF,16V C2 NBE20JM-106X T CAPACITOR 10µF,6.3V C3 NCB31CK-104X CAPACITOR 0.1µF,16V C4 NCB31CK-104X CAPACITOR 0.1µF,16V C5 NCB31CK-104X CAPACITOR 0.1µF,16V C6 NCB31CK-104X CAPACITOR 0.1µF,16V C7 NCB31CK-104X CAPACITOR 0.1µF,16V C8 NCB31CK-104X CAPACITOR 0.1µF,16V C9 NBE20JM-106X T CAPACITOR 10µF,6.3V C10 NCB31CK-104X CAPACITOR 0.1µF,16V K1 NQR0339-001X FERRITE BEAD K2 NQR0339-001X FERRITE BEAD CN1 QGF0503C1-15V FFC/FPC CONNECTOR,(1-15)DIGITAL CN2 QGF0512C1-12X FPC CONNECTOR,(1-12)DIGITAL

******************************

DIGITAL BOARD ASSEMBLY <50>

PW1 LPA10121-04C DIGITAL BOARD ASSY IC8001 JCP8043-2 IC IC8002 KM416S1120DT-G8 IC

or K4S161622D-TC80 IC or A43L0616AV-7-12 IC

or HY57V161610DTC8 IC IC8003 MN1382/K/-X IC IC8201 NDV8501VWB IC(DIGITAL)

or NDV8501-2VWA IC(DIGITAL) IC8202 K4S641632E-TC1H IC

or HY57641620HGLTH IC

or HY57641620HGLTP IC

or HY57641620HGLTH IC

or HY57641620HGLTP IC IC8204 39VF800A7CEK04A IC(MICRO C ROM) IC8206 SN74LV573APW IC IC8207 SN74LV573APW IC IC8210 TC7WU04FU IC(DIGITAL) IC8401 MB86390 IC(DIGITAL) IC8402 KM416S1120DT-G8 IC

or K4S161622D-TC80 IC

or A43L0616AV-7-12 IC

or HY57V161610DTC8 IC IC8403 KM416S1120DT-G8 IC

or K4S161622D-TC80 IC

or A43L0616AV-7-12 IC

or HY57V161610DTC8 IC IC8404 KM416S1120DT-G8 IC

or K4S161622D-TC80 IC

or A43L0616AV-7-12 IC

or HY57V161610DTC8 IC IC8405 KM416S1120DT-G8 IC

or K4S161622D-TC80 IC

or A43L0616AV-7-12 IC

or HY57V161610DTC8 IC IC8601 JCP8029 IC IC8801 AK4518-VF-X IC IC8802 BA15218F-XE IC IC8803 BA15218F-XE IC IC8901 SI-3018LS-X IC

or SI-3018LSA-X IC Q8601 2SC4617/RS/-X TRANSISTOR Q8602 2SA1774/RS/-X TRANSISTOR Q8603 2SC4617/RS/-X TRANSISTOR Q8604 2SA1774/RS/-X TRANSISTOR Q8605 2SC4617/RS/-X TRANSISTOR Q8606 2SC4617/RS/-X TRANSISTOR Q8607 2SC4617/RS/-X TRANSISTOR Q8608 2SC4617/RS/-X TRANSISTOR Q8609 2SC4617/RS/-X TRANSISTOR Q8610 2SA1774/RS/-X TRANSISTOR Q8611 2SC4617/RS/-X TRANSISTOR Q8612 2SA1774/RS/-X TRANSISTOR Q8613 2SC4617/RS/-X TRANSISTOR Q8614 2SA1774/RS/-X TRANSISTOR Q8615 2SA1774/RS/-X TRANSISTOR Q8616 2SC4617/RS/-X TRANSISTOR Q8617 2SA1774/RS/-X TRANSISTOR Q8618 2SC4617/RS/-X TRANSISTOR Q8619 2SA1774/RS/-X TRANSISTOR R8001 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8002 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8004 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8005 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8006 NRSA63J-752X MG RESISTOR 7.5kØ,1/16W R8007 NRSA63J-390X MG RESISTOR 39Ø,1/16W R8008 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W R8009 NRSA63J-105X MG RESISTOR 1MØ,1/16W R8011 NRSA63J-512X MG RESISTOR 5.1kØ,1/16W R8012 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8013 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8014 NRSA63J-820X MG RESISTOR 82Ø,1/16W

5-23

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R8015 NRSA63J-820X MG RESISTOR 82Ø,1/16W R8016 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8017 NRSA63J-820X MG RESISTOR 82Ø,1/16W R8018 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W R8019 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8020 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8021 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8022 NRSA63J-330X MG RESISTOR 33Ø,1/16W R8023 NRSA63J-330X MG RESISTOR 33Ø,1/16W R8024 NRSA63J-330X MG RESISTOR 33Ø,1/16W R8026 NRSA63J-330X MG RESISTOR 33Ø,1/16W R8027 NRSA63J-330X MG RESISTOR 33Ø,1/16W R8031 NRSA63J-333X MG RESISTOR 33kØ,1/16W R8033 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8037 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8039 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8040 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8041 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8042 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8044 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8046 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8047 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8048 NRSA63J-561X MG RESISTOR 560Ø,1/16W R8203 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8205 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8206 NRSA63J-390X MG RESISTOR 39Ø,1/16W R8215 NRSA63J-750X MG RESISTOR 75Ø,1/16W R8217 NRSA63J-220X MG RESISTOR 22Ø,1/16W R8218 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8224 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8225 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8226 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8230 NRSA63J-220X MG RESISTOR 22Ø,1/16W R8233 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W R8241 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8242 NRSA63J-105X MG RESISTOR 1MØ,1/16W R8243 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8244 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8245 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8246 NRSA63J-112X MG RESISTOR 1.1kØ,1/16W R8247 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8401 NRSA63J-512X MG RESISTOR 5.1kØ,1/16W R8402 NRSA63J-512X MG RESISTOR 5.1kØ,1/16W R8403 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8406 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8407 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W R8408 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8409 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8410 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8601 NRSA63J-333X MG RESISTOR 33kØ,1/16W R8602 NRSA63J-223X MG RESISTOR 22kØ,1/16W R8603 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8604 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8605 NRVA63D-182X CMF RESISTOR 1.8kØ,1/16W R8606 NRSA63J-391X MG RESISTOR 390Ø,1/16W R8609 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8610 NRSA63J-751X MG RESISTOR 750Ø,1/16W R8612 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8613 NRSA63J-471X MG RESISTOR 470Ø,1/16W R8616 NRSA63J-684X MG RESISTOR 680kØ,1/16W R8617 NRSA63J-221X MG RESISTOR 220Ø,1/16W

R8618 NRSA63J-223X MG RESISTOR 22kØ,1/16W R8619 NRSA63J-273X MG RESISTOR 27kØ,1/16W R8620 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8622 NRSA63J-751X MG RESISTOR 750Ø,1/16W R8623 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8624 NRVA63D-152X CMF RESISTOR 1.5kØ,1/16W R8625 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R8626 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8627 NRSA63J-331X MG RESISTOR 330Ø,1/16W R8628 NRSA63J-331X MG RESISTOR 330Ø,1/16W R8629 NRSA63J-273X MG RESISTOR 27kØ,1/16W R8631 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8632 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8633 NRSA63J-751X MG RESISTOR 750Ø,1/16W R8635 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8636 NRSA63J-391X MG RESISTOR 390Ø,1/16W R8637 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8638 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8639 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8640 NRSA63J-223X MG RESISTOR 22kØ,1/16W R8641 NRSA63J-273X MG RESISTOR 27kØ,1/16W R8643 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8644 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8646 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8647 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8648 NRSA63J-751X MG RESISTOR 750Ø,1/16W R8650 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8651 NRSA63J-391X MG RESISTOR 390Ø,1/16W R8652 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8653 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8654 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8655 NRSA63J-273X MG RESISTOR 27kØ,1/16W R8656 NRSA63J-273X MG RESISTOR 27kØ,1/16W R8658 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8659 NRSA63J-201X MG RESISTOR 200Ø,1/16W R8660 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W R8661 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W R8662 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8663 NRSA63J-101X MG RESISTOR 100Ø,1/16W R8664 NRSA63J-473X MG RESISTOR 47kØ,1/16W R8665 NRSA63J-473X MG RESISTOR 47kØ,1/16W R8666 NRSA63J-221X MG RESISTOR 220Ø,1/16W R8667 NRSA63J-221X MG RESISTOR 220Ø,1/16W R8668 NRSA63J-221X MG RESISTOR 220Ø,1/16W R8672 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8673 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8674 NRSA63J-821X MG RESISTOR 820Ø,1/16W R8675 NRSA63J-101X MG RESISTOR 100Ø,1/16W R8676 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W R8677 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W R8678 NRSA63J-561X MG RESISTOR 560Ø,1/16W R8801 NRSA63J-153X MG RESISTOR 15kØ,1/16W R8802 NRSA63J-153X MG RESISTOR 15kØ,1/16W R8803 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W R8804 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W R8810 NRSA63J-100X MG RESISTOR 10Ø,1/16W R8812 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8813 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8814 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8818 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8819 NRSA63J-221X MG RESISTOR 220Ø,1/16W

5-24

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

R8820 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8821 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8823 NRSA63J-302X MG RESISTOR 3kØ,1/16W R8824 NRSA63J-221X MG RESISTOR 220Ø,1/16W R8825 NRSA63J-222X MG RESISTOR 2.2kØ,1/16W R8826 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8828 NRSA63J-302X MG RESISTOR 3kØ,1/16W R8829 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8830 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8831 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8832 NRSA63J-103X MG RESISTOR 10kØ,1/16W R8833 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8834 NRSA63J-102X MG RESISTOR 1kØ,1/16W R8835 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R8836 NRSA63J-103X MG RESISTOR 10kØ,1/16W VR8603 NVP1311-102N

V RESISTOR,HDD PB C burst LEVEL ADJ VR8604 NVP1311-103N V RESISTOR,HDD PB Y LEVEL ADJ RA8001 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8002 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8003 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8004 NRZ0040-330X NETWORK RESISTOR 33Ø RA8005 NRZ0040-330X NETWORK RESISTOR 33Ø RA8006 NRZ0040-330X NETWORK RESISTOR 33Ø RA8007 NRZ0040-330X NETWORK RESISTOR 33Ø RA8008 NRZ0040-330X NETWORK RESISTOR 33Ø RA8009 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8010 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8212 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8213 NRZ0040-0R0X NETWORK RESISTOR 0Ø RA8214 NRZ0040-0R0X NETWORK RESISTOR 0Ø B8001 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W B8002 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W B8201 QRE141J-0R0Y RESISTOR 0Ø,1/4W C8001 NCB31CK-104X CAPACITOR 0.1µF,16V C8002 NCB31CK-104X CAPACITOR 0.1µF,16V C8003 NCB31CK-104X CAPACITOR 0.1µF,16V C8004 NCB31CK-104X CAPACITOR 0.1µF,16V C8005 NEA70JM-107X E CAPACITOR 100µF,6.3V C8006 NCB31CK-104X CAPACITOR 0.1µF,16V C8007 NCB31CK-104X CAPACITOR 0.1µF,16V C8008 NCB31CK-104X CAPACITOR 0.1µF,16V C8009 NCB31CK-104X CAPACITOR 0.1µF,16V C8010 NCB31CK-104X CAPACITOR 0.1µF,16V C8011 NCB31CK-104X CAPACITOR 0.1µF,16V C8012 NEA70JM-107X E CAPACITOR 100µF,6.3V C8013 NCB31CK-104X CAPACITOR 0.1µF,16V C8014 NCB31CK-104X CAPACITOR 0.1µF,16V C8015 NCB31CK-104X CAPACITOR 0.1µF,16V C8016 NDC31HJ-120X CAPACITOR 12pF,50V C8017 NCB31HK-103X CAPACITOR 0.01µF,50V C8018 NCB31CK-104X CAPACITOR 0.1µF,16V C8019 NCB31CK-104X CAPACITOR 0.1µF,16V C8020 NCB31CK-104X CAPACITOR 0.1µF,16V C8021 NCB31CK-104X CAPACITOR 0.1µF,16V C8022 NCB31CK-104X CAPACITOR 0.1µF,16V C8023 NCB31CK-104X CAPACITOR 0.1µF,16V C8024 NCB31CK-104X CAPACITOR 0.1µF,16V C8025 NEA70JM-107X E CAPACITOR 100µF,6.3V C8026 NCB31CK-104X CAPACITOR 0.1µF,16V C8027 NCB31AK-224X CAPACITOR 0.22µF,10V C8028 NCB31CK-104X CAPACITOR 0.1µF,16V

C8029 NBE20JM-106X T CAPACITOR 10µF,6.3V C8030 NCB31CK-104X CAPACITOR 0.1µF,16V C8031 NCB31CK-104X CAPACITOR 0.1µF,16V C8032 NDC31HJ-470X CAPACITOR 47pF,50V C8033 NCB31CK-104X CAPACITOR 0.1µF,16V C8036 NCB31CK-104X CAPACITOR 0.1µF,16V C8038 NCB30JK-105X CAPACITOR 1µF,6.3V C8201 NCB31CK-104X CAPACITOR 0.1µF,16V C8202 NCB31CK-104X CAPACITOR 0.1µF,16V C8203 NCB31CK-104X CAPACITOR 0.1µF,16V C8204 NCB31CK-104X CAPACITOR 0.1µF,16V C8205 NCB31CK-104X CAPACITOR 0.1µF,16V C8206 NCB31CK-104X CAPACITOR 0.1µF,16V C8207 NCB31CK-104X CAPACITOR 0.1µF,16V C8208 NCB31CK-104X CAPACITOR 0.1µF,16V C8209 NCB31CK-104X CAPACITOR 0.1µF,16V C8210 NCB31CK-104X CAPACITOR 0.1µF,16V C8211 NCB31CK-104X CAPACITOR 0.1µF,16V C8212 NCB31CK-104X CAPACITOR 0.1µF,16V C8213 NCB31CK-104X CAPACITOR 0.1µF,16V C8214 NCB31CK-104X CAPACITOR 0.1µF,16V C8215 NCB31CK-104X CAPACITOR 0.1µF,16V C8216 NBE20JM-226X T CAPACITOR 22µF,6.3V C8217 NCB31CK-104X CAPACITOR 0.1µF,16V C8218 NBE20JM-226X T CAPACITOR 22µF,6.3V C8219 NCB31CK-104X CAPACITOR 0.1µF,16V C8220 NBE20JM-226X T CAPACITOR 22µF,6.3V C8221 NCB31CK-104X CAPACITOR 0.1µF,16V C8222 NBE20JM-226X T CAPACITOR 22µF,6.3V C8223 NCB31CK-104X CAPACITOR 0.1µF,16V C8227 NCB31CK-104X CAPACITOR 0.1µF,16V C8229 NCB31CK-104X CAPACITOR 0.1µF,16V C8230 NCB31CK-104X CAPACITOR 0.1µF,16V C8231 NCB31CK-104X CAPACITOR 0.1µF,16V C8232 NCB31CK-104X CAPACITOR 0.1µF,16V C8233 NCB31CK-104X CAPACITOR 0.1µF,16V C8234 NCB31CK-104X CAPACITOR 0.1µF,16V C8235 NCB31CK-104X CAPACITOR 0.1µF,16V C8236 NCB31CK-104X CAPACITOR 0.1µF,16V C8237 NCB31CK-104X CAPACITOR 0.1µF,16V C8238 NCB31CK-104X CAPACITOR 0.1µF,16V C8239 NCB31CK-104X CAPACITOR 0.1µF,16V C8240 NCB31CK-104X CAPACITOR 0.1µF,16V C8241 NCB31CK-104X CAPACITOR 0.1µF,16V C8242 NCB31CK-104X CAPACITOR 0.1µF,16V C8243 NCB31CK-104X CAPACITOR 0.1µF,16V C8244 NCB31CK-104X CAPACITOR 0.1µF,16V C8245 NCB31CK-104X CAPACITOR 0.1µF,16V C8246 NCB31CK-104X CAPACITOR 0.1µF,16V C8247 NCB31CK-104X CAPACITOR 0.1µF,16V C8248 NCB31CK-104X CAPACITOR 0.1µF,16V C8249 NCB31CK-104X CAPACITOR 0.1µF,16V C8250 NCB31CK-104X CAPACITOR 0.1µF,16V C8251 NCB31CK-104X CAPACITOR 0.1µF,16V C8252 NCB31CK-104X CAPACITOR 0.1µF,16V C8253 NCB31CK-104X CAPACITOR 0.1µF,16V C8254 NCB31CK-104X CAPACITOR 0.1µF,16V C8255 NCB31CK-104X CAPACITOR 0.1µF,16V C8256 NCB31CK-104X CAPACITOR 0.1µF,16V C8267 NCB31CK-104X CAPACITOR 0.1µF,16V C8268 NCB31CK-104X CAPACITOR 0.1µF,16V

5-25

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C8269 NCB31CK-104X CAPACITOR 0.1µF,16V C8270 NCB31CK-104X CAPACITOR 0.1µF,16V C8271 NBE20JM-226X T CAPACITOR 22µF,6.3V C8272 NBE20JM-226X T CAPACITOR 22µF,6.3V C8273 NCB31CK-104X CAPACITOR 0.1µF,16V C8274 NCB31CK-104X CAPACITOR 0.1µF,16V C8280 NCB31CK-104X CAPACITOR 0.1µF,16V C8281 NBE20JM-226X T CAPACITOR 22µF,6.3V C8282 NEA70JM-107X E CAPACITOR 100µF,6.3V C8283 NCB31CK-104X CAPACITOR 0.1µF,16V C8287 NEA70JM-107X E CAPACITOR 100µF,6.3V C8288 NCB31CK-104X CAPACITOR 0.1µF,16V C8289 NCB31CK-104X CAPACITOR 0.1µF,16V C8401 NBE20JM-226X T CAPACITOR 22µF,6.3V C8402 NBE20JM-106X T CAPACITOR 10µF,6.3V C8403 NCB31CK-104X CAPACITOR 0.1µF,16V C8404 NBE20JM-226X T CAPACITOR 22µF,6.3V C8405 NCB31CK-104X CAPACITOR 0.1µF,16V C8407 NCB31CK-104X CAPACITOR 0.1µF,16V C8408 NCB31CK-104X CAPACITOR 0.1µF,16V C8409 NCB31CK-104X CAPACITOR 0.1µF,16V C8410 NCB31CK-104X CAPACITOR 0.1µF,16V C8411 NCB31CK-104X CAPACITOR 0.1µF,16V C8412 NCB31CK-104X CAPACITOR 0.1µF,16V C8413 NCB31CK-104X CAPACITOR 0.1µF,16V C8414 NCB31CK-104X CAPACITOR 0.1µF,16V C8415 NCB31CK-104X CAPACITOR 0.1µF,16V C8416 NCB31CK-104X CAPACITOR 0.1µF,16V C8417 NCB31CK-104X CAPACITOR 0.1µF,16V C8418 NCB31CK-104X CAPACITOR 0.1µF,16V C8419 NCB31CK-104X CAPACITOR 0.1µF,16V C8420 NCB31CK-104X CAPACITOR 0.1µF,16V C8421 NCB31CK-104X CAPACITOR 0.1µF,16V C8422 NCB31CK-104X CAPACITOR 0.1µF,16V C8423 NCB31CK-104X CAPACITOR 0.1µF,16V C8424 NCB31CK-104X CAPACITOR 0.1µF,16V C8425 NCB31CK-104X CAPACITOR 0.1µF,16V C8426 NCB31CK-104X CAPACITOR 0.1µF,16V C8427 NCB31CK-104X CAPACITOR 0.1µF,16V C8428 NCB31CK-104X CAPACITOR 0.1µF,16V C8429 NCB31CK-104X CAPACITOR 0.1µF,16V C8430 NCB31CK-104X CAPACITOR 0.1µF,16V C8431 NCB31CK-104X CAPACITOR 0.1µF,16V C8432 NCB31CK-104X CAPACITOR 0.1µF,16V C8433 NCB31CK-104X CAPACITOR 0.1µF,16V C8434 NCB31CK-104X CAPACITOR 0.1µF,16V C8435 NCB31CK-104X CAPACITOR 0.1µF,16V C8436 NCB31CK-104X CAPACITOR 0.1µF,16V C8437 NCB31CK-104X CAPACITOR 0.1µF,16V C8438 NCB31CK-104X CAPACITOR 0.1µF,16V C8439 NCB31CK-104X CAPACITOR 0.1µF,16V C8440 NBE20JM-106X T CAPACITOR 10µF,6.3V C8441 NCB31CK-104X CAPACITOR 0.1µF,16V C8442 NCB31CK-104X CAPACITOR 0.1µF,16V C8443 NCB31CK-104X CAPACITOR 0.1µF,16V C8444 NCB31CK-104X CAPACITOR 0.1µF,16V C8445 NCB31CK-104X CAPACITOR 0.1µF,16V C8446 NCB31CK-104X CAPACITOR 0.1µF,16V C8447 NBE20JM-106X T CAPACITOR 10µF,6.3V C8448 NCB31CK-104X CAPACITOR 0.1µF,16V C8449 NCB31CK-104X CAPACITOR 0.1µF,16V

C8450 NCB31CK-104X CAPACITOR 0.1µF,16V C8451 NCB31CK-104X CAPACITOR 0.1µF,16V C8452 NCB31CK-104X CAPACITOR 0.1µF,16V C8453 NCB31CK-104X CAPACITOR 0.1µF,16V C8454 NBE20JM-106X T CAPACITOR 10µF,6.3V C8455 NCB31CK-104X CAPACITOR 0.1µF,16V C8456 NCB31CK-104X CAPACITOR 0.1µF,16V C8457 NCB31CK-104X CAPACITOR 0.1µF,16V C8458 NCB31CK-104X CAPACITOR 0.1µF,16V C8459 NCB31CK-104X CAPACITOR 0.1µF,16V C8460 NCB31CK-104X CAPACITOR 0.1µF,16V C8601 NBE20JM-106X T CAPACITOR 10µF,6.3V C8602 NCB31CK-104X CAPACITOR 0.1µF,16V C8603 NDC31HJ-8R0X CAPACITOR 8pF,50V C8604 NDC31HJ-150X CAPACITOR 15pF,50V C8605 NDC31HJ-390X CAPACITOR 39pF,50V C8606 NDC31HJ-330X CAPACITOR 33pF,50V C8607 NCB11AK-475X CAPACITOR 4.7µF,10V C8608 NCB31HK-103X CAPACITOR 0.01µF,50V C8609 NEA70JM-107X E CAPACITOR 100µF,6.3V C8610 NCB31HK-103X CAPACITOR 0.01µF,50V C8611 NCB31HK-103X CAPACITOR 0.01µF,50V C8612 NCB31CK-104X CAPACITOR 0.1µF,16V C8613 NDC31HJ-8R0X CAPACITOR 8pF,50V C8614 NDC31HJ-150X CAPACITOR 15pF,50V C8615 NDC31HJ-390X CAPACITOR 39pF,50V C8616 NDC31HJ-330X CAPACITOR 33pF,50V C8617 NCB31HK-103X CAPACITOR 0.01µF,50V C8618 NCB31HK-103X CAPACITOR 0.01µF,50V C8619 NEA70JM-107X E CAPACITOR 100µF,6.3V C8620 NCB31CK-104X CAPACITOR 0.1µF,16V C8621 NDC31HJ-330X CAPACITOR 33pF,50V C8622 NDC31HJ-390X CAPACITOR 39pF,50V C8623 NDC31HJ-150X CAPACITOR 15pF,50V C8624 NDC31HJ-8R0X CAPACITOR 8pF,50V C8625 NCB31CK-104X CAPACITOR 0.1µF,16V C8626 NCB31HK-103X CAPACITOR 0.01µF,50V C8627 NCB31CK-104X CAPACITOR 0.1µF,16V C8628 NDC31HJ-330X CAPACITOR 33pF,50V C8629 NDC31HJ-390X CAPACITOR 39pF,50V C8630 NDC31HJ-120X CAPACITOR 12pF,50V C8631 NDC31HJ-8R0X CAPACITOR 8pF,50V C8632 NCB31CK-104X CAPACITOR 0.1µF,16V C8633 NBE20JM-106X T CAPACITOR 10µF,6.3V C8634 NBE20JM-106X T CAPACITOR 10µF,6.3V C8635 NCB31HK-103X CAPACITOR 0.01µF,50V C8636 NCB31CK-104X CAPACITOR 0.1µF,16V C8637 NCB31CK-104X CAPACITOR 0.1µF,16V C8638 NCB31CK-104X CAPACITOR 0.1µF,16V C8639 NCB31CK-104X CAPACITOR 0.1µF,16V C8640 NCB31CK-104X CAPACITOR 0.1µF,16V C8641 NCB31CK-104X CAPACITOR 0.1µF,16V C8642 NCB31CK-104X CAPACITOR 0.1µF,16V C8643 NCB31CK-104X CAPACITOR 0.1µF,16V C8644 NCB31CK-104X CAPACITOR 0.1µF,16V C8645 NBE20JM-106X T CAPACITOR 10µF,6.3V C8646 NCB31CK-104X CAPACITOR 0.1µF,16V C8647 NBE20JM-106X T CAPACITOR 10µF,6.3V C8648 NCB31CK-104X CAPACITOR 0.1µF,16V C8649 NBE20JM-106X T CAPACITOR 10µF,6.3V C8650 NCB31CK-104X CAPACITOR 0.1µF,16V

5-26

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C8651 NCB31CK-104X CAPACITOR 0.1µF,16V C8652 NCB31CK-104X CAPACITOR 0.1µF,16V C8654 NCB31CK-104X CAPACITOR 0.1µF,16V C8655 NCB31CK-104X CAPACITOR 0.1µF,16V C8656 NCB31CK-104X CAPACITOR 0.1µF,16V C8657 NCB31CK-104X CAPACITOR 0.1µF,16V C8801 NEA71HM-105X E CAPACITOR 1µF,50V C8802 NEA71HM-105X E CAPACITOR 1µF,50V C8803 NBE20JM-475X T CAPACITOR 4.7µF,6.3V C8804 NDC31HJ-151X CAPACITOR 150pF,50V C8805 NCB31CK-104X CAPACITOR 0.1µF,16V C8806 NCB31CK-104X CAPACITOR 0.1µF,16V C8807 NBE20JM-475X T CAPACITOR 4.7µF,6.3V C8808 NDC31HJ-151X CAPACITOR 150pF,50V C8809 NCB31CK-104X CAPACITOR 0.1µF,16V C8810 NBE20JM-226X T CAPACITOR 22µF,6.3V C8811 NCB31CK-104X CAPACITOR 0.1µF,16V C8812 NBE20JM-475X T CAPACITOR 4.7µF,6.3V C8813 NCB31CK-104X CAPACITOR 0.1µF,16V C8814 NBE20JM-226X T CAPACITOR 22µF,6.3V C8815 NCB31CK-104X CAPACITOR 0.1µF,16V C8816 NEA71HM-105X E CAPACITOR 1µF,50V C8820 NEA71HM-105X E CAPACITOR 1µF,50V C8825 NCB31HK-332X CAPACITOR 0.0033µF,50V C8826 NCB31HK-682X CAPACITOR 0.0068µF,50V C8828 NBE20JM-106X T CAPACITOR 10µF,6.3V C8830 NCB31HK-332X CAPACITOR 0.0033µF,50V C8831 NCB31HK-682X CAPACITOR 0.0068µF,50V C8833 NBE20JM-106X T CAPACITOR 10µF,6.3V C8834 NCB31CK-104X CAPACITOR 0.1µF,16V C8835 NEA71CM-476X E CAPACITOR 47µF,16V C8836 NCB31CK-104X CAPACITOR 0.1µF,16V C8837 NEA71CM-476X E CAPACITOR 47µF,16V C8901 NEA71CM-107X E CAPACITOR 100µF,16V C8902 NCB31CK-104X CAPACITOR 0.1µF,16V C8903 NEA71CM-107X E CAPACITOR 100µF,16V C8904 NCB31CK-104X CAPACITOR 0.1µF,16V C8905 NEA70JM-107X E CAPACITOR 100µF,6.3V C8906 NCB31CK-104X CAPACITOR 0.1µF,16V C8907 NEA70JM-107X E CAPACITOR 100µF,6.3V C8908 NCB31CK-104X CAPACITOR 0.1µF,16V C8909 NEA70JM-107X E CAPACITOR 100µF,6.3V C8910 NCB31CK-104X CAPACITOR 0.1µF,16V C8911 NEA70JM-107X E CAPACITOR 100µF,6.3V C8912 NCB31CK-104X CAPACITOR 0.1µF,16V C8913 NEA70JM-107X E CAPACITOR 100µF,6.3V C8914 NCB31CK-104X CAPACITOR 0.1µF,16V C8915 NEA70JM-107X E CAPACITOR 100µF,6.3V C8916 NCB31CK-104X CAPACITOR 0.1µF,16V C8917 NBE20JM-106X T CAPACITOR 10µF,6.3V C8918 NCB31CK-104X CAPACITOR 0.1µF,16V C8919 NBE20JM-106X T CAPACITOR 10µF,6.3V C8920 NCB31CK-104X CAPACITOR 0.1µF,16V C8921 NEA70JM-107X E CAPACITOR 100µF,6.3V C8922 NCB31CK-104X CAPACITOR 0.1µF,16V L8001 NQR0339-001X FERRITE BEAD L8401 NQR0339-001X FERRITE BEAD L8402 NQR0339-001X FERRITE BEAD L8403 NQR0339-001X FERRITE BEAD L8601 NQL025J-150X COIL 15µH L8602 NQL085J-330X COIL 33µH

L8603 NQR0339-001X FERRITE BEAD L8604 NQL025J-150X COIL 15µH L8605 NQL085J-330X COIL 33µH L8606 NQR0339-001X FERRITE BEAD L8607 NQL085J-330X COIL 33µH L8608 NQL025J-150X COIL 15µH L8609 NQL085J-330X COIL 33µH L8610 NQL025J-150X COIL 15µH

L8611 NQL035K-100X COIL 10µH L8612 NQR0129-002X FERRITE BEAD L8613 NQR0339-001X FERRITE BEAD L8614 NQR0339-001X FERRITE BEAD L8801 NQR0339-001X FERRITE BEAD

L8802 NQL035K-100X COIL 10µH L8803 NQL035K-100X COIL 10µH X8001 NAX0304-001X CXO K8001 NRSA02J-150X MG RESISTOR 15Ø,1/10W

K8207 NQR0129-002X FERRITE BEAD K8209 NQR0129-002X FERRITE BEAD K8210 NQR0339-001X FERRITE BEAD K8701 QQR0717-031 FERRITE CORE K8901 NQR0339-001X FERRITE BEAD K8902 NQR0339-001X FERRITE BEAD K8903 NQR0339-001X FERRITE BEAD K8904 NQR0339-001X FERRITE BEAD K8905 NQR0339-001X FERRITE BEAD K8906 NQR0339-001X FERRITE BEAD K8907 NQR0339-001X FERRITE BEAD K8908 NQR0339-001X FERRITE BEAD ET1 QNZ0136-001Z EARTH TERMINAL J1 QUQ105-1210AA FFC WIRE,DIGITAL SUB CN2 J2 QUQ105-1504AA FFC WIRE,DIGITAL SUB CN1 CN8001 QGA2523F1-40 CONNECTOR,(1-40)HDD CN8002 QGF1016F2-06W FFC/FPC CONNECTOR,(1-6)MAIN CN8202 QGF1016F2-06W FFC/FPC CONNECTOR CN8401 QGF0503C1-15V CN8601 QGA2001F2-06V CONNECTOR,(1-6)MAIN CN8602 QGF0512C1-12X FPC CONNECTOR,(1-12)DIGITAL SUB CN8801 QGF1016F4-08W FFC/FPC CONNECTOR,(1-8)MAIN CN8901 QGA2001F2-09V CONNECTOR,(1-9)REG

FFC/FPC CONNECTOR(1-15)DIGITAL SUB

******************************

LOADING MOTOR BOARD ASSEMBLY <55>

PW2 LPA10010-01A2 LOADING MOTOR BOARD ASSY CN1 QGB2533K1-02 CONNECTOR

******************************

S/P CONVERTER BOARD ASSEMBLY <87>

PW1 PB10999C S/P CONVERTER BOARD ASSY IC1 CXA1227Q-V IC IC2 CXA1229AM IC IC3 MM1108XF IC Q1 IMX3 PAIR TRANSISTOR

5-27

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

Q3 IMX3 PAIR TRANSISTOR Q4 IMX3 PAIR TRANSISTOR Q5 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q6 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q7 2SB1218A/QR/-X TRANSISTOR

or 2SA1576A/QRS/-X TRANSISTOR or 2PA1576/R/-X TRANSISTOR

Q8 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q9 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q11 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR or 2SC4081/QRS/-X TRANSISTOR

Q12 2SD1819A/QRS/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR or 2PC4081/R/-X TRANSISTOR

Q14 UN521E TRANSISTOR

or DTC144WU TRANSISTOR or RN1309 TRANSISTOR

Q15 UN521E TRANSISTOR

or RN1309 TRANSISTOR

or DTC144WU TRANSISTOR R1 NRSA02J-391X MG RESISTOR 390Ø,1/10W R2 NRSA02J-105X MG RESISTOR 1MØ,1/10W R3 NRSA02J-223X MG RESISTOR 22kØ,1/10W R4 NRSA02J-225X MG RESISTOR 2.2MØ,1/10W R5 NRSA02J-242X MG RESISTOR 2.4kØ,1/10W R6 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R7 NRSA02J-242X MG RESISTOR 2.4kØ,1/10W R8 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W R9 NRSA02J-223X MG RESISTOR 22kØ,1/10W VR1 QVP0039-103Z TRIM RESISTOR,FH SYNC ADJ VR2 QVP0039-683Z TRIM RESISTOR,FH FREE RUN ADJ VR3 QVP0039-331Z TRIM RESISTOR,R-Y LEVEL ADJ VR4 QVP0039-331Z TRIM RESISTOR,B-Y LEVEL ADJ R10 NRSA02J-104X MG RESISTOR 100kØ,1/10W R11 NRSA02J-473X MG RESISTOR 47kØ,1/10W R12 NRSA02J-391X MG RESISTOR 390Ø,1/10W R13 NRSA02J-391X MG RESISTOR 390Ø,1/10W R14 NRSA02J-391X MG RESISTOR 390Ø,1/10W R15 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R16 NRSA02J-101X MG RESISTOR 100Ø,1/10W R17 QRE141J-221Y RESISTOR 220Ø,1/4W R18 QRE141J-221Y RESISTOR 220Ø,1/4W R19 NRSA02J-271X MG RESISTOR 270Ø,1/10W R20 NRSA02J-271X MG RESISTOR 270Ø,1/10W R21 NRSA02J-183X MG RESISTOR 18kØ,1/10W R22 NRSA02J-223X MG RESISTOR 22kØ,1/10W R23 NRSA02J-102X MG RESISTOR 1kØ,1/10W R24 NRSA02J-102X MG RESISTOR 1kØ,1/10W R25 NRSA02J-102X MG RESISTOR 1kØ,1/10W R26 NRSA02J-102X MG RESISTOR 1kØ,1/10W R27 NRSA02J-102X MG RESISTOR 1kØ,1/10W R28 NRSA02J-102X MG RESISTOR 1kØ,1/10W

R31 NRVA02D-273X CMF RESISTOR 27kØ,1/10W R32 NRSA02J-183X MG RESISTOR 18kØ,1/10W R33 NRSA02J-223X MG RESISTOR 22kØ,1/10W R34 NRSA02J-331X MG RESISTOR 330Ø,1/10W R35 NRSA02J-102X MG RESISTOR 1kØ,1/10W R36 NRSA02J-103X MG RESISTOR 10kØ,1/10W R37 NRSA02J-102X MG RESISTOR 1kØ,1/10W R38 NRSA02J-153X MG RESISTOR 15kØ,1/10W R39 NRSA02J-223X MG RESISTOR 22kØ,1/10W R40 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R41 NRSA02J-121X MG RESISTOR 120Ø,1/10W R42 NRSA02J-121X MG RESISTOR 120Ø,1/10W R43 NRSA02J-102X MG RESISTOR 1kØ,1/10W R44 NRSA02J-102X MG RESISTOR 1kØ,1/10W R45 NRSA02J-560X MG RESISTOR 56Ø,1/10W R46 NRSA02J-560X MG RESISTOR 56Ø,1/10W R47 NRSA02J-331X MG RESISTOR 330Ø,1/10W R48 NRSA02J-331X MG RESISTOR 330Ø,1/10W R49 NRSA02J-151X MG RESISTOR 150Ø,1/10W R50 NRSA02J-151X MG RESISTOR 150Ø,1/10W R51 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R52 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R53 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R54 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W R55 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R56 NRSA02J-182X MG RESISTOR 1.8kØ,1/10W R57 NRSA02J-102X MG RESISTOR 1kØ,1/10W R58 NRSA02J-102X MG RESISTOR 1kØ,1/10W R59 NRSA02J-911X MG RESISTOR 910Ø,1/10W R60 NRSA02J-152X MG RESISTOR 1.5kØ,1/10W R71 NRSA02J-561X MG RESISTOR 560Ø,1/10W R72 NRSA02J-334X MG RESISTOR 330kØ,1/10W R74 NRVA02D-104X CMF RESISTOR 100kØ,1/10W R75 NRSA02J-823X MG RESISTOR 82kØ,1/10W R76 NRSA02J-122X MG RESISTOR 1.2kØ,1/10W R77 NRSA02J-103X MG RESISTOR 10kØ,1/10W R78 NRSA02J-103X MG RESISTOR 10kØ,1/10W R79 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W R80 NRSA02J-103X MG RESISTOR 10kØ,1/10W B102 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W B103 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C1 NDC21HJ-101X CAPACITOR 100pF,50V C2 NDC21HJ-270X CAPACITOR 27pF,50V C3 NCB21HK-103X CAPACITOR 0.01µF,50V C4 NCB21HK-103X CAPACITOR 0.01µF,50V C6 NDC21HJ-221X CAPACITOR 220pF,50V C7 NDC21HJ-221X CAPACITOR 220pF,50V C9 NCB21HK-103X CAPACITOR 0.01µF,50V C10 NDC21HJ-102X CAPACITOR 0.001µF,50V C11 NCB21HJ-472X CAPACITOR 0.0047µF,50V C12 NCB21HK-103X CAPACITOR 0.01µF,50V C13 NDC21HJ-270X CAPACITOR 27pF,50V C14 NDC21HJ-101X CAPACITOR 100pF,50V C15 NCB21HK-103X CAPACITOR 0.01µF,50V C16 NCB21HK-103X CAPACITOR 0.01µF,50V C17 NCB21HK-103X CAPACITOR 0.01µF,50V C18 NCB21HK-103X CAPACITOR 0.01µF,50V C19 NDC21HJ-101X CAPACITOR 100pF,50V C20 NCB21HK-103X CAPACITOR 0.01µF,50V C21 NDC21HJ-100X CAPACITOR 10pF,50V C22 NDC21HJ-100X CAPACITOR 10pF,50V

5-28

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

C24 NDC21HJ-220X CAPACITOR 22pF,50V C25 NDC21HJ-101X CAPACITOR 100pF,50V C26 NDC21HJ-101X CAPACITOR 100pF,50V C31 QEKJ1CM-106 E CAPACITOR 10µF,16V C32 QEKJ1CM-106 E CAPACITOR 10µF,16V C33 QEKJ1CM-106 E CAPACITOR 10µF,16V C34 QEKJ1HM-105 E CAPACITOR 1µF,50V C35 QEKJ1HM-105 E CAPACITOR 1µF,50V C36 QEKJ1HM-105 E CAPACITOR 1µF,50V C37 QEKJ1CM-106 E CAPACITOR 10µF,16V C38 QEKJ1CM-226 E CAPACITOR 22µF,16V C39 QEKJ1CM-226 E CAPACITOR 22µF,16V C40 QEKJ1HM-105 E CAPACITOR 1µF,50V C41 NDC21HJ-330X CAPACITOR 33pF,50V C43 NDC21HJ-330X CAPACITOR 33pF,50V C44 NCB21HK-103X CAPACITOR 0.01µF,50V C45 NCB21HK-103X CAPACITOR 0.01µF,50V C46 NCB21HK-103X CAPACITOR 0.01µF,50V C47 NCB21HK-103X CAPACITOR 0.01µF,50V C48 NCB21HK-103X CAPACITOR 0.01µF,50V C49 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C50 NCB21HK-103X CAPACITOR 0.01µF,50V C51 QEKJ1CM-107 E CAPACITOR 100µF,16V C52 QEKJ1CM-106 E CAPACITOR 10µF,16V C53 QEKJ1CM-106 E CAPACITOR 10µF,16V C54 QEKJ1CM-107 E CAPACITOR 100µF,16V C55 QEKJ1HM-105 E CAPACITOR 1µF,50V C56 QEKJ1HM-105 E CAPACITOR 1µF,50V C57 QEKJ1CM-476 E CAPACITOR 47µF,16V C58 NDC21HJ-471X CAPACITOR 470pF,50V C60 NCB21HK-103X CAPACITOR 0.01µF,50V C61 QEKJ1CM-226 E CAPACITOR 22µF,16V C62 QEKJ1CM-226 E CAPACITOR 22µF,16V C63 QEKJ1CM-476 E CAPACITOR 47µF,16V C64 QEKJ1CM-476 E CAPACITOR 47µF,16V C65 NCB21HK-103X CAPACITOR 0.01µF,50V C66 NCB21HK-103X CAPACITOR 0.01µF,50V C67 QEKJ1CM-476 E CAPACITOR 47µF,16V C68 NCB21HK-103X CAPACITOR 0.01µF,50V C69 NCB21HK-103X CAPACITOR 0.01µF,50V C70 NCB21EK-333X CAPACITOR 0.033µF,25V C71 NDC21HJ-561X CAPACITOR 560pF,50V C72 QEKJ1HM-335 E CAPACITOR 3.3µF,50V C73 NDC21HJ-221X CAPACITOR 220pF,50V C74 NCB21HK-102X CAPACITOR 0.001µF,50V C75 NCB21HK-392X CAPACITOR 0.0039µF,50V C76 NCB21EK-333X CAPACITOR 0.033µF,25V L1 QQL231J-120Y COIL 12µH L2 PELN1206 COIL 47µH L5 PELN1206 COIL 47µH L6 QQL231J-120Y COIL 12µH L7 QQL231J-8R2Y COIL 8.2µH L8 QQL231J-8R2Y COIL 8.2µH L10 PU48530-120J COIL 12µH L11 PU48530-120J COIL 12µH L12 PU48530-120J COIL 12µH X1 PEVB0550 CRYSTAL RESONATOR FL1 PELN1205 LC TRAP FL2 PU60904-2 DELAY LINE FL3 PELN1207 LOW PASS FILTER FL4 PELN1207 LOW PASS FILTER

FL5 PELN1225 BAND PASS FILTER SD1 PQ21952 SHIELD FRAME CN1 QGF1208F1-08 FPC CONNECTOR,(9-16)MAIN

******************************

LED BOARD ASSEMBLY <90>

PW4 LPA10126-04A4 LED BOARD ASSY D7017 SELU5E20C LE DIODE D7019 QRE141J-103Y RESISTOR 10kØ,1/4W R7056 QRE141J-101Y RESISTOR 100Ø,1/4W C7022 QDYB1CM-103Y CAPACITOR 0.01µF,16V FW7001 QUM022-07A4A4 PARA RIBON WIRE

E. & O. E. No. 82898 (Sanwa)-V13HV4

5-29

JVC HM-HDS1MS Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual

PARTS LIST

5.1 PACKING AND ACCESSORY ASSEMBLY <M1>

5.2 FINAL ASSEMBLY <M2>

5.3 MECHANISM ASSEMBLY <M4>

5.4 ELECTRICAL PARTS LIST
