GZ-MC200 GZ-MC100
DIGITAL MEDIA CAMERAS
...every occasion, every time.
Whenever you need, and wherever you are, you’re always ready to capture that moving experience or shining moment. Everio from JVC lets you shoot DVD-quality MPEG-2 movies and UXGA-size JPEG pictures, giving you life-size quality in a pocket-size camera. Everio. It’s all you need to record your world, and share it with the world. For every occasion, every time.
CUBE STYLE
GZ-MC200
DIGITAL MEDIA CAMERA
Solid impact. Quality intensive. The Everio for everyone who wants a pro-feel, and nothing but the very best. Comes with 4GB Microdrive®.
Everio: every time
VERTICAL STYLE
GZ-MC100
DIGITAL MEDIA CAMERA
Stylishly compact. Casually active. The Everio for everyone who wants quality with the emphasis on mobility. Comes with 4GB Microdrive®.
GZ-MC200
Rotating Grip lets you smoothly
transition from a high-angle to
low-angle shot without removing
your hand from the grip.
Made To Move
Capture memories as moving or still images, then move them to
Moving Images for a Moving Experience
Shoot up to 60 minutes in Video Camera mode of high quality MPEG-2 videos on the supplied 4GB Microdrive®. A selection of recording modes lets you choose more quality or more shooting time. The highest quality ULTRA mode records at a constant bit rate of 8.88 Mbps with AC 3 audio*1— comparable to the DVD (average 4 Mbps video/9.8 Mbps maximum) data rate — for essentially DVD quality with the same video and audio format as a movie DVD. And the 2.12 Megapixel CCD*2offers the high-resolution capabilities needed for high-end digital videography.
MPEG-2
Jack cover
GZ-MC100
Built-in Auto Flash
Built-in Auto Flash
Power dial
1.8" LCD Monitor
Cursor knob
Jack cover
1.8" LCD Monitor
10x Optical Zoom/
200x Digital Zoom
Trigger
Cursor knob
10x Optical Zoom/
200x Digital Zoom
Trigger
Power switch
DVD-Quality
Video bit rate Image size 720 x 576/50i 352 x 288/25p Recording time 60 min. 90 min. 120 min. 300 min.
*3
What is Microdrive®?
The roughly half-an-ounce (16 grams) matchbook-sized 1" Microdrive®is compatible with a wide variety of devices that accept CompactFlash+ Type II and PC Card Type II media. With JVC initially offering 4GB Microdrives, the boom in the most popular portable audio players, digital cameras and need for portable storage are driving Microdrive®manufacturers toward even higher capacity and lower cost.
ULTRA FINE NORM ECO
8.5 Mbps 5.5 Mbps 4.2 Mbps 1.5 Mbps
*1 8.5 Mbps video plus 384kbps AC 3. *2 1.23 million effective pixels for
moving pictures.
*3 Bit rate is fixed for ULTRA and FINE
modes, variable for NORM and ECO modes.
Your Memories
your PC with the convenience of high-capacity removable media.
Still Pictures of those Shining Moments
Shoot JPEG digital stills in DSC mode at up to UXGA (1600 x 1200) size, for excellent quality even when printed. Select the picture quality and image size to match your needs, whether it’s for documents or e-mail attachments. Shoot thousands of pictures
Microdrive
Removable Media
®
without worry thanks to the large-capacity storage. Of course, the 1/3.6" CCD with 2 million effective pixels assures top quality still photography.
Quick, Lossless, High-Speed
Transfer to PC
2 Megapixel
UXGA
UXGA SXGA XGA VGA
1600 x 1200 1280 x 960 1024 x 768 640 x 480 FINE 5595 8752 9999 9999 STD 9999 9999 9999 9999
Above figures are approximate as file size will differ according to type of subject.
Megabrid Engine
Applies separate, optimised processing to moving and still images, providing high sensitivity and a high signal-to-noise ratio for videos even in low-light conditions, as well as clear, high resolution still images that deliver beautiful quality prints.
Intelligent Graphical User Interface (
Effortless access to a host of functions is at the tip of your thumb through JVC’s intuitive, high-resolution GUI. Use the menu to select manual functions including Focus, White Balance, Shutter Speed, Exposure and Program AE. Use thumbnail displays to easily find and view your stored videos and stills, as well as manage, protect, rearrange them and much more.
Voice Recorder Mode lets you record
meetings and make voice memos in 48kHz/16bit PCM stereo, stored as WAV format files.
GUI
)
Share Your Stories, Move
Easily transfer all the memories you’ve captured to your personal
Multiple Advanced Interfaces
Store what you’ve shot on the provided Microdrive®card* or optional CompactFlash** or SD Memory Cards. Microdrive®is a hard disk drive that’s the same size as a CompactFlash card, but with many Gigabytes of capacity. You can eject it, as you would a CompactFlash or SD Memory Card, and load data into your PC via an optional card adapter. Also simply connect the camera via its USB2.0 interface for quick downloading to a PC. All transfer is digital-to-digital, so you won’t lose any quality in the process.
PictBridge and Digital Print Order Format for easy printing
Just connect the USB terminal and print stills directly from the camera to a PictBridge compatible printer. The camera directly creates Digital Print Order Format (DPOF) information for selection and quantity of images to print, rotation, as well as index printing, and user and picture title information, for when you take your media to a printing service.
Microdrive
®
SD Memory Card
Multiple Advanced
Interfaces
CompactFlash
card
USB2.0
Easy DVD creation to save, watch and share your memories
Provided software makes DVD creation incredibly simple, including easy saving (authoring) to a disc that anyone can play on their DVD player, and also feature rich non-linear editing.
*The Microdrive®card slot also accepts CompactFlash card. **Only high-speed CF card supported for videos.
Your Family and Friends
computer and share them with the world with lossless quality.
Quick, Lossless,
High-Speed
Transfer to PC
JVC Everio takes the stress out of digital
creativity, preservation and distribution,
with a wide array of digital interfaces and
provided software that makes media file and
DVD creation drag-and-drop easy.
Three Advanced Applications Provided
Immediate sharing via the Internet
A wide range of media file formats are supported so you can share the fun with e-mail attachments and streaming videos on your website.
Direct output for on-the-spot screening
Video/S-Video outputs let you check your footage immediately, with brilliant results even on high-resolution big-screen displays.
CyberLink is your communication partner, with three bundled software applications to save, manage, create, and distribute your memories. In addition to making it easy to create DVDs, the supplied software supports a variety of file formats for
Power Producer
video clips you choose in any order to DVD, even right from a USB-connected camera, so you can share your original DVDs with anybody who owns a DVD player.
Power Director
offers feature-rich non-linear editing so you can flex your creative muscle with titles, effects, and even mix stills with videos.
TM
offers easy saving (authoring) of
TM
Express
distribution via the web or by e-mail. Supported formats include DV-AVI, Windows-AVI, MPEG-1 and MPEG-2, as well as Windows Media Video and RealVideo movies that can be streamed over the Internet.
Power DVD
and DVD playback with AC 3 audio.
TM
for easy video clip
Other Features
Super Hi-Rez Lens
10x Optical Zoom/200x Digital Zoom
1.8" LCD Monitor
Built-in Auto Flash
Playback Special Effects
(Sepia*, Black & White*, Strobe)
Playback Scene Transitions (White Fader, Black Fader,
Black & White Fader, Corner Wipe, Window Wipe, Slide Wipe, Door Wipe, Scroll Wipe, Shutter Wipe)
Shutter Speeds (1/2 ~ 1/4000 sec.)
White Balance
(Auto, MWB, Fine, Cloudy, Halogen)
Exposure (Video: -6 ~ +6, Stills: -2EV ~ +2EV)
Programme AE (Sports, Snow, Spotlight)
Auto and Manual Focus
Backlight/Spotlight Compensation
Digital Image Stabiliser
Self-timer
Motor-Drive Shooting
* Also applicable while shooting.
Provided Accessories
4GB Microdrive
AC Power Adapter
Rechargeable Battery
AV/S-Video Out Multi-Connector Cable
®
Optional Accessories
USB Cable
Software CD-ROM
(USB Driver*
1
, Digital Photo Navigator,
CyberLink DVD Solution*
*1 USB connection requires Windows XP/2000/Me. *2 CyberLink DVD Solution software requires Windows
XP/2000/Me/98SE and 10 – 15GB free hard disk space (recommended). PowerProducerTMrequires a PC with
2
)
256MB RAM, 700MHz or above Pentium III CPU, USB 2.0/1.1 terminal and a DVD burner. 512MB or more RAM, Pentium 4 2GHz or faster CPU, and 7200rpm HDD are required for editing with PowerDirectorTMExpress.
Specifications
Format SD-VIDEO Entertainment Video Profile:
Storage Media Microdrive®, CompactFlash card, SD Memory Card Image Sensor 1/3.6-inch, 2 Megapixel: 2,120,000-pixel (1726 x 1231)
Lens F1.8-2.2 (f=4.5—45mm) Zoom Ratios Optical: 10x
Filter Diameter 30.5mm Monitor 130,000-pixel 1.8-inch polycrystalline silicon color LCD Interfaces Microdrive
Power Consumption Approx. 4.9W Power Source (Battery) 7.2V
Dimensions (W x H x D) GZ-MC200: 74mm x 56mm x 94mm
Weight (without battery, Microdrive lens cap and hand strap) GZ-MC100: 245g
Weight (including battery, GZ-MC200: 350g Microdrive®, lens cap and hand strap) GZ-MC100: 315g
Video: MPEG-2-PS / Audio: AC 3 Still: JPEG (PictBridge, DPOF compatible) Voice: WAV (Linear PCM)
Effective pixels: Moving images: 1,230,000-pixel (1280 x 960)
Still images: 2,000,000-pixel (1636 x 1220)
Digital: 40x, 200x
®
(CF) slot, SD Memory Card slot, USB2.0/1.1*1,
AV/S-Video Multi-Connector Out, Headphone Out, DC In
(AC adapter) 11V
GZ-MC100: 40.5mm x 103mm x 70.5mm
®
, GZ-MC200: 285g
CU-ASD032/ASD064
32 and 64 MB SD Memory Cards (for still images)
VU-VM10KIT Battery Kit
contains an aluminium carrying case and rechargeable lithium-ion battery pack
BN-VM200 Rechargeable
Lithium-ion Battery Pack
(800mAh)
CB-VM20 Carrying Case
holds camera and extra memory card
Supported Media & Bit Rate
Recording Media
Mode Bit Rate CompactFlash High-Speed SD Memory Card SD Memory Card Microdrive
ULTRA 8.5Mbps NO YES NO YES YES FINE 5.5Mbps NO YES NO YES YES NORM 4.2Mbps NO YES NO YES YES ECO 1.5Mbps YES YES YES YES YES
It should be noted that it may be unlawful to re-record pre-recorded tapes, records, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or
cable programme and in any literary, dramatic, musical, or artistic work embodied therein. Microsoft®and Windows®are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries. Apple, the Apple logo, Macintosh®, Mac OS, Power Macintosh, Powerbook and QuickTime®are either registered trademarks or
trademarks of Apple Computer Inc. in the United States and/or other countries. Microdrive®is a registered trademark of Hitachi Global Storage Technologies in the United States
and/or other countries. CompactFlash™ is a trademark of SanDisk Corporation. The SD logo is a trademark of the SD Card Association. PictBridge is a trademark. All brand names
are trademarks, registered trademarks, or trade names of their respective holders. All screen images and print samples in this catalogue are simulated.
CompactFlash (256MB or less) (over 256MB)
Design and specifications subject to change without notice. The photos of the products
featured in this brochure may not be of actual products that are available in your country.
Copyright © 2004, Victor Company of Japan, Limited (JVC). All Rights Reserved.
®
