SERVICE MANUAL
DIGITAL VIDEO CAMERA
GR-DVP7A-BK/A-SL/ED/SH
Regarding service information other than these sections, refer to the GR-DVP7EG service manual (No. 86682).
Also, be sure to note important safety precautions provided in the service manual.
SPECIFICATIONS
(The specifications shown pertain specifically to the model GR-DVP7A-BK/A-SL/ED/SH)
Camcorder
For General
Power supply :DC 6.3 V (Using AC Power Adapter/Charger)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.2 W
LCD monitor on, viewfinder off : Approx. 5.0 W
Dimensions (W x H x D) : 43 mm x 115 mm x 80 mm
Weight : Approx. 350 g
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/3.8” CCD
Lens :F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens
LCD monitor :
Viewfinder : Electronic viewfinder with 0.44” colour LCD
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video : Digital component recording
Cassette : Mini DV cassette
Tape speed :SP : 18.8 mm/s
Maximum recording time : SP : 80 min.
(using 80 min. cassette) LP : 120 min.
For Digital Still Camera
Storage media : SD Memory Card/MultiMediaCard
Compression system : Still image : JPEG (compatible)
File size
Still Image : 3 modes
Moving Image : 2 modes (240 x 176 pixels/160 x 120 pixels)
Picture quality : 2 modes (FINE/STANDARD)
Approximate number of storable images : see pg. 49
DC 7.2 V (Using battery pack)
(with the LCD monitor closed and the viewfinder pushed back in)
(without grip belt, battery and cassette)
Approx. 420 g
(incl. grip belt, battery and cassette)
(It is not possible to attach any lens filter or conversion lens.)
2” diagonally measured, LCD panel/TFT active matrix system
Audio : PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
LP : 12.5 mm/s
Moving image : MPEG4 (compatible)
(1280 x 960 pixels/1024 x 768 pixels/640 x 480 pixels)
For Connectors
S/AV
S-Video input : Y :0.8 V to 1.2 V (p-p), 75 Ø, analogue
S-Video output : Y :1.0 V (p-p), 75 Ø, analogue
Video input : Y :0.8 V to 1.2 V (p-p), 75 Ø, analogue
Video output : Y :1.0 V (p-p), 75 Ø, analogue
Audio input : 300 mV (rms), 50 kØ, analogue, stereo
Audio output : 300 mV (rms), 1 kØ, analogue, stereo
Edit : ø3.5 mm, 2-pole
Headphone output : Stereo
DV
Input/output : 4-pin, IEEE 1394 compliant
USB : 5-pin
C :0.2 V to 0.4 V (p-p), 75 Ø, analogue
C :0.3 V (p-p), 75 Ø, analogue
AC Power Adapter/Charger
For General
Power requirement : AC 110 V to 240 V ` , 50 Hz/60 Hz
Power consumption : 23W
Output
Charge : DC 7.2 V
VTR : DC 6.3 V
Weight : Approx. 260 g (AA-V100EA)
Specifications shown are for SP mode unless otherwise indicated. E & O.E.
Design and specifications subject to change without notice.
}
, 1.2 A
}
, 1.8 A
Approx. 250 g (AA-V100A)
Approx. 250 g (AA-V100A-S)
Approx. 325 g (AA-V100SH)
Approx. 250 g (AA-V100ED)
This service manual is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
No. 86694
April 2002
TABLE OF CONTENTS
DIFFERENT TABLE ........................................................................................................................................................... 1 to 2
5. PARTS LIST (5-1 to 5-12)
5.1 PACKING AND ACCESSORY ASSEMBLY <M1> ........................................................................................................ 5-1
5.2 ELECTRICAL PARTS LIST ........................................................................................................................................... 5-3
The following table indicate main different points between models GR-DVP7EG-X, GR-DVP7A-BK, GR-DVP7A-SL,
GR-DVP7ED, and GR-DVP7SH.
ITEM
AC ADAPTER CHARGER AA-V100EG AA-V100A-S AA-V100A AA-V100ED AA-V100SH
BATTERY PACK BN-V107U-B BN-V107U-S
BODY COLOR BLACK BLACK/SILVER SILVER
MODEL
The following table indicate different parts number between models GR-DVP7EG-X, GR-DVP7A-BK, GR-DVP7A-SL,
GR-DVP7ED and GR-DVP7SH.
GR-DVP7EG-X GR-DVP7A-BK GR-DVP7A-SL GR-DVP7ED GR-DVP7SH
PACKING AND ACCESSORY ASSEMBLY <M1> Note: As for IB (INSTRUCTIONS), refer to sec.5.
REF. MODEL
!
NO. ITEM
1 PACKING CASE LY32303-011A LY32303-012A LY32303-010A LY32303-013A
7 WARRANTY CARD BT-54013-2 — — BT-59011-2 —
10 GUARANTY CARD — — — BT-59012-1 —
14 SHEET(CON.PLUG) — LYT0609-001A ——
! 20
21 DC CORD ASSY LY32226-003A LY32226-002A
! 35 BATTERY PACK LY32203-006A LY32203-003A
42 ADAPTER PLUG QAM0302-001 — — — —
! 45 CONVERSION PLUG — PEMC1012 PEMC1012-02 — —
AC POWER ADAPTER/CHARGER
GR-DVP7EG-X GR-DVP7A-BK GR-DVP7A-SL GR-DVP7ED GR-DVP7SH
LY20754-002B LY20754-009A LY20754-008A LY20754-006B LY20754-007A
Notes : Mark is same as left.
Mark — is not used.
1
FINAL ASSEMBLY <M2>
REF. MODEL
!
NO. ITEM
101 MIC COVER LY20845-002C LY20845-001C
102 SPECIAL SCREW,X3 LY30018-055A LY30018-043B
106 COVER(SHUT)ASSY LY43431-002C LY43431-004C LY43431-003C
107 COVER(UNDER) LY32228-003A LY32228-002A
108 SPECIAL SCREW LY30018-065A LY30018-043B
120 BOTTOM COVER LY20844-002B LY20844-002C LY20844-003C
124 SPECIAL SCREW,X3 LY30018-092A LY30018-093A
125 COVER(SD)ASSY LY32279-004A LY32279-002D
126 SPECIAL SCREW,X2 LY30018-081A LY30018-043B
128 SPECIAL SCREW,X2 LY30018-031A LY30018-032A
129 DV COVER ASSY LY43487-002B LY43487-001B
130 MULTI/USB COVER LY32637-002B LY32637-001B
133 SPECIAL SCREW,X2 LY30018-031A LY30018-032A
136 SPECIAL SCREW,X2 LY30018-0F9A LY30018-0G1A
137 SPECIAL SCREW,X2 LY30018-0D5A LY30018-0D8A
139 SPECIAL SCREW LY30018-065A LY30018-0A2A
140 SPECIAL SCREW LY30018-065A LY30018-0A2A
150 UPPER CASE ASSY LY32635-002C LY32635-003C
151 SUB OPE UNIT LY32625-002A LY32625-003A
155 SHOE COVER LY32628-002A LY32628-001A
156 SPECIAL SCREW,X2 LY30018-065A LY30018-0A2A
157 COVER(JIG CONN) LY41393-008A LY41393-005A
158 SPECIAL SCREW LY30018-031A LY30018-032A
167 SPECIAL SCREW LY30018-055A LY30018-070A
168 SPECIAL SCREW,X2 LY30018-055A LY30018-070A
169 SPECIAL SCREW LY30018-055A LY30018-032A
170 SPECIAL SCREW LY30018-055A LY30018-070A
171 SPECIAL SCREW,X2 LY30018-0D5A LY30018-0D8A
172 SPECIAL SCREW LY30018-065A LY30018-0A2A
173 GUIDE(MONITOR) LY32623-002B LY32623-001B
174 SPECIAL SCREW,X2 LY30018-031A LY30018-032A
176 DUMMY BATTERY LY32884-001A LY32884-002A
177 STICKER(MONI.) LY43865-002A LY43865-001A
178 SPACER(A) LY30030-009A LY30030-006A
205 LOWER CASE LY20842-002C LY20842-002D LY20842-003D
227 OPERATION UNIT LY20843-002A LY20843-003A
230 CASSETTE COVER LY20757-003A LY20757-002B
231 SPECIAL SCREW LY30018-081A LY30018-043B
232 SPECIAL SCREW LY30018-081A LY30018-043B
234 COVER(M.ADJ) LY32247-003A LY32247-001A
! 235 LABEL(CAUTION) YQ32492-2 ————
243 SPECIAL SCREW,X2 LY30018-065A LY30018-0C3A
251 SPECIAL SCREW LY30018-055A LY30018-070A
GR-DVP7EG-X GR-DVP7A-BK GR-DVP7A-SL GR-DVP7ED GR-DVP7SH
MONITOR ASSEMBLY <M5>
REF. MODEL
!
NO. ITEM
500 MONITOR ASSY LYH20424-003B LYH20424-002B
501 MONITOR CASE ASSY LY32633-002A * LY32633-002B LY32633-001A
502 MONITOR COVER LY10346-002A LY10346-003A
506 HINGE COVER(U) LY32267-003A LY32267-002A
507 HINGE COVER(L) LY32268-003A LY32268-002A
509 SPECIAL SCREW,X2 LY30018-0D3A LY30018-0D9A
510 SPECIAL SCREW LY30018-081A LY30018-043B
511 SPECIAL SCREW,X2 LY30018-063A LY30018-0B7A
512 MARK LY43523-002A LY43523-001A
519 SPACER(A) LY30030-004A * LY30030-004B
GR-DVP7EG-X GR-DVP7A-BK GR-DVP7A-SL GR-DVP7ED GR-DVP7SH
MAIN BOARD ASSEMBLY <01>
REF. MODEL
!
NO. ITEM
PW MAIN BOARD ASSY YB10370C-02 YB10370E-02
GR-DVP7EG-X GR-DVP7A-BK GR-DVP7A-SL GR-DVP7ED GR-DVP7SH
Notes : Mark is same as left.
Mark — is not used.
Mark * reference model was also changed.
2
VICTOR COMPANY OF JAPAN, LIMITED
VIDEO DIVISION
S40894
Printed in Japan
