JVC GR-DVL145EG Diagram
SCHEMATIC DIAGRAMS
DIGITAL VIDEO CAMERA
GR-DVL145EG
CD-ROM No.SML200205
SPECIFICATIONS
(The specifications shown pertain specifically to the model GR-DVL145EG/EK)
Camcorder
General
Power supply : DC 11.0 V (Using AC Adapter)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.3 W
LCD monitor on, viewfinder off : Approx. 5.3 W
Dimensions (W x H x D) : 83 mm x 94 mm x 223 mm
Weight : Approx. 630 g
Operating temperature : 0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/4" CCD
Lens :
Filter diameter : ø40.5 mm
LCD monitor : 2.5" diagonally measured, LCD panel/TFT active
Viewfinder : Electronic viewfinder with 0.24" black/white LCD
Speaker : Monaural
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video: Digital component recording
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
DC 7.2 V (Using battery pack)
(with the LCD monitor closed and the viewfinder
pushed down)
F 1.6, f = 3.9 mm to 62.4 mm, 16:1 power zoom lens
matrix system
Digital Video Camera
: Audio: PCM digital recording, 32 kHz 4-channel
(12-bit), 48 kHz 2-channel (16-bit)
LP: 12.5 mm/s
Connectors
S-Video
Output : Y: 1 V (p-p), 75 Ω, analogue
AV
Video output : 1 V (p-p), 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
DV
Output : 4-pin, IEEE 1394 compliant
C: 0.29 V (p-p), 75 Ω, analogue
AC Adapter
Power requirement : AC 110 V to 240 V`, 50 Hz/60 Hz
Output : DC 11 V , 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E.
Design and specifications subject to change without notice.
This schematic diagrams is printed on 100% recycled paper.
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
No. 86693SCH
April 2002
SECTION 4
CHARTS AND DIAGRAMS
NOTES OF SCHEMATIC DIAGRAM
Safety precautions
The Components identified by the symbol are
critical for safety. For continued safety, replace safety
critical components only with manufacturer's recommended parts.
1. Units of components on the schematic diagram
Unless otherwise specified.
1) All resistance values are in ohm. 1/6 W, 1/8 W (refer to
parts list).
Chip resistors are 1/16 W.
K: KØ (1000Ø), M: MØ (1000KØ)
2) All capacitance values are in µF, (P: PF).
3) All inductance values are in µH, (m: mH).
4) All diodes are 1SS133, MA165 or 1N4148M (refer to parts
list).
2. Indications of control voltage
AUX : Active at high.
AUX or AUX(L) : Active at low.
4. Voltage measurement
1) Regulator (DC/DC CONV) circuits
REC : Colour bar signal.
PB : Alignment tape (Colour bar).
— : Unmeasurable or unnecessary to measure.
4) Indication on schematic diagram
Voltage Indications for REC and PB mode on the schematic diagram are as shown below.
REC mode
12 3
2.5
(5.0)
PB mode
1.8
PB and REC modes
(Voltage of PB and REC modes
are the same)
Note: If the voltages are not indicated on the schematic
diagram, refer to the voltage charts.
5. Signal path Symbols
The arrows indicate the signal path as follows.
NOTE : The arrow is DVC unique object.
Playback signal path
3. Interpreting Connector indications
1
2
Removable connector
3
1
2
Wire soldered directly on board
3
1
Non-removable Board connector
2
3
1
2
4
Board to Board
3
Connected pattern on board
The arrows indicate signal path
Playback and recording signal path
Recording signal path
(including E-E signal path)
Capstan servo path
Drum servo path
(Example)
R-Y
Playback R-Y signal path
Y
Recording Y signal path
6. Indication of the parts for adjustments
The parts for the adjustments are surrounded with the circle as
shown below.
7. Indication of the parts not mounted on the circuit board
“OPEN” is indicated by the parts not mounted on the circuit
board.
S40889-01
R216
OPEN
4-1
CIRCUIT BOARD NOTES
1. Foil and Component sides
1) Foil side (B side) :
Parts on the foil side seen from foil face (pattern face)
are indicated.
2) Component side (A side) :
Parts on the component side seen from component face
(parts face) indicated.
2. Parts location guides
Parts location are indicated by guide scale on the circuit board.
LOCATION
IC
Category : IC
Horizontal “A” zone
Vertical “6” zone
(A : Component side)
D : Discrete component)
B : Foil side
C : Chip component
REF No.
IC101 B C 6 A
Note: For general information in service manual, please
refer to the Service Manual of GENERAL INFORMATION Edition 4 No. 82054D (January 1994).
4-2
S40889-01
BOARD INTERCONNECTIONS4.1
GND
IR_RMC
NC/B_SEL
BATT_+
BATT_+
BATT_CHK
ADP_DC
ADP_DC
ADP_H
T_BATT
GND
GND
IR_OUT
REG_4.8V
IR_AMP
DC JACK
J503
34
1
2
56
CN502
YTU94074-20
∗
YTU94077-20
CN103
CN109
ZOOM_SW
GND
GND
FOCUS_SW
PHOTO_SW
MENU_P_A
MENU_P_B
MENU_SET
DIAL_PB
DIAL_OFF
DIAL_AUTO
DIAL_MANU
POW_LED
TRIG_SW
REG_3V
07
REAR
UNIT
BATT_TERM.
+-
T
S
OUT
CN105
∗
GND
TPB-
TPB+
TPA-
TPA+
GND
YTU94074-15
YTU94077-15
JIG
CONN.
VPPC
REG_3V
SRV_TX
CJIG_RST
IF_TX
I_MTR
FS_PLL
ATFI
MAIN_VCO
ENV_OUT
PB_CLK
HID1
GND
JLIP_TX
JLIP_RX
SRV_RX
VPPD
DRST
DISCRI
AL_3VSYS
J101
IN/OUT
ZOOM UNIT
YTU94074-20
∗
YTU94077-20
NOTE )∗ : The number of patch cords
are indicated by interconnected.
04
TEST
Vdd
CCD
(Page 4-35)
V4
V2
GND
V1
V3
5
CN5001
OP BLOCK
VL
H1
H2
Vout
SUB
GND
YTU94074-22
∗
Z_SENS
ZOOM_LED
Z_L_VCC
YTU94077-22
OP.DRV
CAM_VD
CLK4M5
IRIS_PWM
H_OFFSET
H_GAIN
CN108
ZOOM2
ZOOM4V1ZOOM3
ZOOM2
CN108
ZOOM4
ZOOM1
FOCUS1
FOCUS4
FOCUS2
ZOOM3
ZOOM1
FOCUS1
FOCUS4
FOCUS2
FOCUS3
OP.DRV
(Page 4-25)
FOCUS3
OP_VCC
OP_VCC
DUMP+
F_SENS
DRIVE+
F_LED
DUMP-
DUMP+
HE_OUT+
DRIVE+
HE_IN-
DUMP-
HE_OUT-
GND
HE_IN+
REG
M_REG4.8
REG_4.8V
REG_3V
HE_OUT+
HE_IN-
ZOOM_LED
GND
HE_OUT-
HE_IN+
4
HALL_AD
IRIS_O/C
SYSCON
F/Z_CS
DATA_OUT
CLK_OUT
F/Z_RST
DSP
H_GAIN
CAM_VD
CLK4M5
H_OFFSET
IRIS_PWM
3
MONITOR 02
(Page 4-31)
BL_GND
REV_SW
CN753
CN752
SPK-
SPK+
BL_GND
BL_GND
LCD_CTL
BL_4.8V
CN751
BL_4.8V
NC/A_REG_3V
LCD_VDD/VDD
LCD_COM
LCD_VEE
LCD_RVS
LCD BL (Page 4-33)
0
CN765
MON_R
MON_G
MON_B
NC
VGL
VSS
STV1
UD
CPV
OEV
STV2
VGH
STH2
VB
GND
GND
CLK3
CLK2
CLK1
Q2H
OEH
STH1
CN764
GND
08
2019181716151413121110
NC
MONITOR
BL_4.8V
VGL
VSS
STV1
UD
CPV
OEV
STV2
VDD
VGH
LCD_COM
LCD_VEE
STH2
LCD_RVS
VB
MON_R
MON_G
MON_B
CLK3
CLK2
CLK1
Q2H
OEH
STH1
NCRGNC
NC
NC
VDD
GND
VFREG4.8
VFREG4.8
VDD
BW_Y
B/W VF (Page 4-39)
NC
TCL
VIDLO
RENON
RENEN
HCLKN
GND
HPLN
VREF
BW_VDD
LCD(B/W-VF) MODULE
TL7503
HV
BL_GND
BL
TL7504
VGL
VSS
STV1
UD
CPV
OEV
STV2
VDD
2
VGH
VCOM
VEE
STH2
RL
VB
R
G
B
SIG_GND
CLK3
CLK2
CLK1
Q2H
OEH
LCD(MONITOR) MODULE
STH1
SPEAKER
1
V2
V3
V4
NC/GND
CCD +15V
CCD +15V
GND
GND
GND
CCD_OUT
GND
GND
GND
GND
RG
H1
H2
CCD -7.0V
SUB
GND
REG
REG_3V
REG_1.8V
REG_4.8V
DA_G
DA_B
DA_R
MONI IF
DA_B
DA_R
DA_G
DSP
DECK OPE
LITHIUM
BATT.
VFREG4.8
BW_Y
VDD
VF_CTL
REG_12V
NC
NC
NC
VDD
REG_12V
SLEEP/VF_CTL
987654321
VPLN
VCKN
HODL
HLTOR
BW_VEE
BW_COM
CN107
CN107
CCD_OUT
VDCVF
HDCVF
HRP
CN101
MONI IF
(Page 4-23)
CN763
NC
NC
NC
CN721
CN722
NC
PDR
VIDHI
YTU94074-20
∗
YTU94077-20
C_FG[-]
C_COIL_V
C_COIL_V
RG
SUB
CCD -7.0V
AD_CLK
SHP
SHD
DSP CN107
TG
PBLK
CLK27
AD_CLK
DSP
(Page 4-21)
SYSCON
CDS_CS
CLK_OUT
DATA_OUT
GND
REG
REG_2.5V
REG_-15V
KEY_A
LITHIUM
MONI_SW
LCD_RST
REV_SW
REG_15V
REG_-15V
REG_12V
REG_4.8V
VFREG4.8
REG_3V
M_REG4.8
CAPSTAN MOTOR DRUM MOTOR HEAD
C_FG[+]
GND
REG_3V
V4
H2
H1
CCD +15V
TG
(Page 4-27)
PBLK
XAVD
OBCLP
VGAT
ID
XAVD
CLK18
CLK13
CRWSEL
CDSTB
MVD
BUS[0-15]
CALE
REG_3V
REG_4.8V
HRP
VDCVF
HDCVF
LCD_R
LCD_G
LCD_B
BW_Y
VF_LCD
GND
C_COIL_W
C_COIL_W
XAHD
ID
VGAT
XAHD
OMT
MFLD
SYSCON
M
C_COIL_U
V1V2V3
CLK13
CLK18
SHD
OBCLP
DSP_RST
CN101
C_COIL_U
CLK27
SHP
BLK[A-C]
VC[0-3]
VF_LCD
LCD_R
LCD_G
LCD_B
BW_Y
HG_V[-]
HG_V[+]
SYSCON
DOT_CLK
OSD_VD
HG_U[-]
TG_RST
OSD_HD
HG_BS[+]
REG
REG_3V
CLK_OUT
DATA_OUT
PRE/REC
INV
HG_BS[-]
HG_W[+]
REG_15V
REG-CCD
TG_CS
NOSIG_LV
DUMP_CTL
HG_W[-]
GND
DVMAIN
RECCADJ
ATF_GAIN
MECHA
HG_U[+]
CLK27
DVMAIN
S_SHUT
AUDIO
DCI[0-3]
DYI[0-3]
DCO[0-3]
DYO[0-3]
FSPLLCTL
M_VCOCTL
PBVCOCTL
PBPLLCTL
D.CPU
CAM_VD
V OUT
DV_C
DV_Y
∗
CN761
CN572
TDO
TMS
TDB
OUTV
OUTH
INV
INH
TCMK
TRST
YTU94105-40
YTU94077-40
M_RVS
LITHIUM
KEY_A
VFREG4.8
GND
VF_LCD
MONI_SW
REG_15V
GND
REG_-15V
REG_-15V
LCD_RST
REG_12V
REG_4.8V
REG_4.8V
SPK+
SPK-
GND
REG_3V
HRP
GND
VDCVF
HDCVF
GND
LCD_R
GND
LCD_G
GND
LCD_B
GND
REV_SW
M_REG4.8
M_REG4.8
LCD_CTL
BL_GND/GND
BL_GND/GND
BL_GND/GND
BL_GND/GND
BL_GND/GND
BW_Y
TAPE_GND
TAPE_LED
CN101
MIC
SENSOR
REEL_GND
S_REEL
E_SENS
SREELLED
TREELLED
T_REEL
S_REEL
EJT_SW
E_SENS
TAPE_LED
SREELLED
GND/TAPE_GND
REG
REG_3V
M_REG4.8
M_UNREG
CN112
C_FG[+]
C_FG[-]
C_COIL_V
GND
CAS_SW
REC_SAFE
S_SENS
MIC3
MIC2
MIC1
JUNCTION (Page 4-36)
0
5
GND
MIC3
MIC2
MIC1
T_REEL
S_SENS
GND/REEL_GND
GND
MDA
DRUM_PWR
(Page 4-11)
HG_W[-]
HG_BS[-]
HG_W[+]
HG_BS[+]
HG_U[-]
HG_V[+]
REC_SAFE
HG_U[+]
CAS_SW
CN113
D.CPU
LD_REV
TREELLED
CAP_ERR
DRUM_ERR
C_COIL_U
C_COIL_W
CAP_PWR
HG_V[-]
DSP
DSP
OP.DRV
DATA_OUT
CLK_OUT
HALL_AD
IRIS_O/C
F/Z_CS
F/Z_RST
CN108
Z_SENS
F_SENS
MONI IF, CN101
VF_LCD
CN101
REV_SW
LCD_RST
M_RVS
LCD_CTL
MONI_SW
KEY_A
INT_MIC/R
IM_GND
INT_MIC/L
V_BATT
REG
CN106
DATA_OUT
VF_CTL
CLK_OUT
D_PG[-]
D_FG[-]
D_PFG[+]
D_COIL_W
COIL_COM
GND/DR_GND
D_PG[-]
D_PFG[+]
D_COIL_V
D_COIL_U
D_COIL_W
COIL_COM
CAP_RVS
MDA_PS
LD_FWD
DRUM_BRK
CAP_BRK
CAP_REF
DV_Y
DV_C
V OUT
(Page 4-19)
SYSCON
INV
CALE
CDSTB
CDS_CS
CRWSEL
BUS[0-15]
CHRG_EVR
I_MTR
AREG_SO
AREG_CLK
REG_CS
D_COIL_U
D_COIL_U
D_COIL_V
D_COIL_W
D_FG[-]
LOAD_FWD
DRUM_REF
CAP_FG
ASPECT1
ASPECT2
MVD
DSP_RST
AL_3V
LIT_3V
M
D_COIL_V
D_COIL_V
LOAD_REV
DRUM_PG
OMT
REG_3V
D_COIL_V
D_COIL_U
TREELLED
SREELLED
LD_ON
DRUM_FG
CN103
REG_4.8V
MFLD
OSD_HD
GND
D_COIL_W
D_COIL_W
D_PG[-]
D_COIL_U
T_REEL
S_REEL
REEL_VCC
TREEL_IN
V_OUT
C_OUT
REG
GND
VC[0-3]
OSD_VD
CN104
DR_GND
D_PFG[+]
COIL_COM
GND
D_FG[-]
LOAD_FWD
LOAD_FWD
DEW_SENS
SREEL_IN
Y_OUT
TG
BLK[A-C]
DOT_CLK
CLK_OUT
DATA_OUT
SYSCON
(Page 4-7)
POW_LED
T_BATT
ADP_H
CN109
LOADING MOTOR
M
LOAD_REV
LOAD_REV3LOAD_FWD
CHRG_LED
CN571
LOAD_REV
LOAD_REV
CHAG_LED
CN113
TG_CS
TG_RST
CN113
DIAL_AUTO
DIAL_PB
DIAL_OFF
DIAL_MANU
TRIG_SW
FOCUS_SW
PHOTO_SW
LOAD_FWD
EJT_SW
CAS_SW
CHRG_LED
MENU_SET
MENU_P_A
MENU_P_B
SYSCON
CHRG_EVR
I_MTR
V_BATT
AREG_SO
AREG_CLK
REG_CS
VF_CTL
GND
DEW_SENS
DSP
REG
S_SHUT
AUDIO
(Page 4-13)
SPK-
SPK+
CN101
V OUT
ASPECT2
ASPECT1
SRV_RST
ZOOM_SW
D.CPU
REG_3V
SRV_CS
M_REG4.8
SRV_RDY
S_CLK
GND
REG_4.8V
S_DT_OUT
EEPROM_CS
S_DT_IN
REG_3V
M_UNREG
OUTPUT
1S1FGND
1F
1S
CN110
DUMP_CTL
ATF_GAIN
DSP
SYSCON
EEP_DT_CLK
EEP_DT_OUT
REG_2.5V
REG_1.8V
REG_4.8V
2F
GND
GND
2F
2S
NOSIG_LV
RECCADJ
CN113
PD_L
CLK_OUT
AUDIO_CS
DATA_OUT
AUDIO
DATA_OUT
CLK_OUT
AUDIO_CS
CN103
CN105
CJIG_RST
AL_3VSYS
EEP_IN
REG_15V
REG_12V
VFREG4.8
M_REG4.8
(Page 4-29)
ROTARY
ENCODER
SW
2S
GND
CN110
GND
PRE/REC
(Page 4-17)
RECH
PBH
HID3
HID1
D.CPU
MONI_CHG
AU_SIG/L
AU_SIG/R
S_MUTE
A_MUTE
BUZZER
BUZZER
S_MUTE
A_MUTE
PD_L
S_DET
IR_RMC
IR_AMP
IR_OUT
P_DET
VPPC
IF_TX
JLIP_TX
JLIP_RX
AL_3V
LIT_3V
LITHIUM
REG-CCD
REG_-15V
REG
DVMAIN
DVMAIN
AIMCK
AILRCK
AIBCK
AODAT
AIDAT
INT_MIC/R
CN106
GND
MDA
NC
REC_CLK
IM_GND
DRUM_PWR
R.E.SW
CAM_SW_A0CAM_SW_B
NC
VRB_AGC
AGC_OUT
VREF_1.1
INT_MIC/L
CAP_ERR
CAP_PWR
DRUM_ERR
CAM_SW_C
ATFI
VRB_ATF
GND
CN111CN574CN573CN112
CN105
REF_CLK
REC_DATA
D.CPU
ATFI
ENV_OUT
REC_CTL
DSP
CAM_VD
SYSCON
SRV_RDY
S_DT_OUT
S_DT_IN
S_CLK
SRV_CS
SRV_RST
EEP_IN
EEP_DT_OUT
EEP_DT_CLK
EEPROM_CS
D_GAIN
BATT_CHK
REG_4.8V
REG_3V
REG_2.5V
CN113
CN105
I_MTR
CJIG_RST
CN104
BATT_+
ADP_DC
REG
GND
TAPE_LED
GND
S_SENS
REG
E_SENS
DEW_SENS
REG_3V
MIC3
D_GAIN
AUDIO
AODAT
AIDAT
AIMCK
AIBCK
AILRCK
TG
CLK27
DSP
TDB
INV
INH
OUTV
OUTH
DCO[0-3]
DYO[0-3]
DCI[0-3]
DYI[0-3]
FSPLLCTL
M_VCOCTL
PBVCOCTL
PBPLLCTL
TDO
TMS
TCMK
TRST
MIC1
MIC2
GND
01
REC_SAFE
D.CPU
(Page 4-9)
GND/AV_GND
GND/AV_GND
V_OUT
P_DET
AU_SIG/L
AGC_OUT
PRE/REC
DVMAIN
(Page 4-15)
ADDT[00-15]
OUTV
DV_WAIT
D.CPU
MDA
CAP_FG
CAP_REF
DRUM_FG
DRUM_PG
DRUM_REF
SRV_TX
CN105
HID1
MAIN
VRB_AGC
DRWSEL
CAP_BRK
SRV_RX
GND/AV_GND
VREF_1.1
DRE
LD_ON
VPPD
J501
AU_SIG/R
REC_DATA
DWE
CAP_RVS
DRST
GND/AV_GND
C_OUT
REC_CTL
REC_CLK
DALE
DV_RST
MDA_PS
DRUM_BRK
PRE/REC
∗
AV
OUT
JACK (Page 4-37)
6
S_DET
GND
GND/AV_GND
GND/AV_GND
Y_OUT
GND
ATFI
VRB_ATF
REF_CLK
CN105
FS_PLL
MAIN_VCO
PB_CLK
DISCRI
J101
TPA+
TPA-
TPB+
TPB-
REG
REG_3V
REG_2.5V
REG_1.8V
GND
HID1
CLK27SEL
SRV_TRK
TSR
FRP
SPA
LD_REV
LD_FWD
TREEL_IN
SREEL_IN
REEL_VCC
HID1
RECH
PBH
HID3
MONI_CHG
DVMAIN
TSR
FRP
SPA
SRV_TRK
HID1
OUTV
DV_RST
CLK27SEL
DV_WAIT
DWE
DALE
DRWSEL
DRE
ADDT[00-15]
CN111
CAM_SW_A
CAM_SW_B
CAM_SW_C
YTU94074-10
YTU94077-10
CN104 CN1
y10267001a_rev0
4-44-3
EDCBA
HGF
MAIN IF SCHEMATIC DIAGRAM4.2
TO CAPSTAN MOTOR TO JUNCTION CN571 TO ZOOM UNIT
5
TO
OP BLOCK
4
Z_L_VCC
ZOOM_LED
Z_SENS
HE_IN+
HE_OUT-
HE_IN-
HE_OUT+
GND
DUMP-
DRIVE+
DUMP+
F_LED
F_SENS
OP_VCC
FOCUS3
FOCUS2
FOCUS4
FOCUS1
ZOOM1
ZOOM3
ZOOM4
ZOOM2
CN108
CN108
ZOOM_LED
Z_SENS
HE_IN+
HE_OUT-
HE_IN-
HE_OUT+
GND
DUMP-
DRIVE+
DUMP+
F_SENS
OP_VCC
FOCUS3
FOCUS2
FOCUS4
FOCUS1
ZOOM1
ZOOM3
ZOOM4
ZOOM2
C_COIL_V
C_COIL_V
CN112
C_COIL_V
TO MDA
TO OP.DRV
TO SYSCON
TO OP.DRV
TO REG
TO OP.DRV
TO SYSCON
TO OP.DRV
C_FG[-]
GND
GND
C_FG[-]
TO REG
C_FG[+]
REG_3V
C_FG[+]
REG_3V
TO MDA
TO REG
C_COIL_U
C_COIL_W
C_COIL_W
C_COIL_U
C_COIL_W
HG_V[-]
HG_V[+]
C_COIL_U
HG_V[-]
HG_V[+]
TO MDA
HG_U[-]
HG_BS[+]
HG_U[-]
HG_BS[+]
HG_BS[-]
HG_W[+]
HG_W[+]
HG_BS[-]
HG_W[-]
HG_U[+]
HG_W[-]
HG_U[+]
GND/TAPE_GND
EJT_SW
CN113
GND
EJT_SW
TO REG
TO SYSCON
TAPE_LED
E_SENS
E_SENS
TAPE_LED
S_REEL
SREELLED
S_REEL
SREELLED
TO MDA
TREELLED
GND/REEL_GND
T_REEL
T_REEL
TREELLED
S_SENS
MIC1
MIC1
S_SENS
TO D.CPU
MIC2
MIC2
REC_SAFE
MIC3
MIC3
REC_SAFE
GND
CAS_SW
CAS_SW
GND
COIL_COM
COIL_COM
D_PFG[+]
D_COIL_W
D_PFG[+]
D_COIL_W
D_COIL_W
D_COIL_V
D_COIL_V
TO MDA
D_COIL_V
D_COIL_U
D_COIL_U
D_COIL_U
D_PG[-]
D_FG[-]
D_FG[-]
D_PG[-]
GND
DEW_SENS
LOAD_FWD
GND
LOAD_FWD
DEW_SENS
TO MDA
TO RE G
LOAD_REV
LOAD_FWD
LOAD_REV
CHRG_LED
LOAD_REV
CHRG_LED
TO D.CP U
TO D.CPU
TO SYSCON
01 MAIN (MAIN IF)
GND
ZOOM_SW
CN109
GND
ZOOM_SW
TO SYSCON
TO REG
GND
FOCUS_SW
FOCUS_SW
MENU_P_A
PHOTO_SW
MENU_P_A
PHOTO_SW
DIAL_PB
MENU_P_B
DIAL_OFF
MENU_SET
DIAL_PB
DIAL_OFF
MENU_P_B
MENU_SET
TO SYSCON
DIAL_AUTO
DIAL_MANU
DIAL_AUTO
DIAL_MANU
TRIG_SW
POW_LED
REG_3V
REG_3V
TRIG_SW
POW_LED
TO REG
TO SYSCON, REG
TO SYSCON
TO RE G
TO D.CP U
TO SYSCON
TO REG
TO DVMAIN
TO PRE/REC
TO DVMAIN
TO PRE/REC
TO DVMAIN
TO D.CPU
TO REG
TO SYSCON
TO D.CPU
TO SYSCON
(N.C)
VPPC
REG_3V
SRV_TX
CJIG_RST
IF_TX
I_MTR
FS_PLL
ATFI
MAIN_VCO
ENV_OUT
PB_CLK
HID1
GND
JLIP_TX
JLIP_RX
SRV_RX
VPPD
DRST
DISCRI
AL_3VSYS
CN105
VPPC
REG_3V
SRV_TX
CJIG_RST
IF_TX
I_MTR
FS_PLL
ATFI
MAIN_VCO
ENV_OUT
PB_CLK
HID1
GND
JLIP_TX
JLIP_RX
SRV_RX
VPPD
DRST
DISCRI
AL_3VSYS
JIG
CONN.
3
TO
ROTARY
ENCODER SW
2
CN111
CAM_SW_A
CAM_SW_B
CAM_SW_C
GND
TO RE G
TO DVMAIN
TPA+
TPA-
TPB-
TPB+
GND
J101J101
J101J101J101J101
CN104
NC
NC
TO D.CPU
CAM_SW_A
CAM_SW_B
CAM_SW_C
GND
TO REG
DV
IN/OUT
TO REG
TO SYSCON
TO REG
TO REG
TO SYSCON
TO SYSCON
LITHIUM
KEY_A
M_RVS
TO REG
VFREG4.8
TO SYSCON
VF_LCD
TO REG
MONI_SW
REG_15V
TO REG
TO SYSCON
TO REG
REG_-15V
LCD_RST
REG_12V
REG_4.8V
TO AUDIO
SPK+
REG_4.8V
SPK-
TO REG
TO DSP
REG_3V
HRP
VDCVF
HDCVF
TO MONI IF
LCD_R
LCD_G
LCD_B
TO REG
TO SYSCON
M_REG4.8
REV_SW
TO SYSCON
LCD_CTL
TO REG
GND
TO MONI IF
BW_Y
TO REG
TO SYSCON
IR_AMP
REG_4.8V
IR_OUT
TO SYSCON
IR_RMC
TO V OUT
Y_OUT
S_DET
TO AUDIO
C_OUT
AU_SIG/R
AU_SIG/L
TO V OUT
TO REG
GND
V_OUT
TO SYSCON
P_DET
BATT_+
BATT_CHK
ADP_DC
ADP_H
T_BATT
GND
B_SEL
BATT_+
BATT_+
BATT_CHK
ADP_DC
ADP_DC
ADP_H
T_BATT
GND
GND
TO
REAR UNIT
1
CN101
M_RVS
KEY_A
LITHIUM
GND
VFREG4.8
VF_LCD
MONI_SW
GND
REG_15V
REG_-15V
REG_-15V
REG_12V
LCD_RST
REG_4.8V
REG_4.8V
SPK+
SPK-
GND
HRP
REG_3V
GND
VDCVF
HDCVF
GND
LCD_R
GND
GND
LCD_G
LCD_B
GND
REV_SW
M_REG4.8
LCD_CTL
M_REG4.8
BL_GND/GND
BL_GND/GND
BL_GND/GND
BL_GND/GND
BL_GND/GND
BL_GND/GND
BW_Y
CN103
REG_4.8V
IR_AMP
IR_OUT
IR_RMC
GND
GND
GND
S_DET
Y_OUT
C_OUT
AV_GND/GND
AV_GND/GND
AU_SIG/L
AU_SIG/R
AV_GND/GND
AV_GND/GND
V_OUT
AV_GND/GND
P_DET
AV_GND/GND
y20182001a_rev0
TO JACK CN502TO MONITOR CN761
ABCD EFGH
4-64-5
5
4
3
2
1
TO MAIN IF
CN105
TO MAIN IF CN101
TO MAIN IF CN101,
MONI IF
TO MAIN IF CN101
TO MAIN IF
CN103
TO MAIN IF
CN105
TO MAIN IF
CN101
TO DSP
TO AUDIO
TO REG
TO MAIN IF
CN108
TO OP.DRV
TO D.CPU
TO MAIN IF
CN101
TO MAIN IF
CN109
TO MAIN IF
CN101
SYSCON SCHEMATIC DIAGRAM4.3
TO REG
CJIG_RST
TO REG
TO MAIN IF
CN113
CHRG_LED
IR_RMC
TO REG
REG_3V
TO MAIN IF
CN109
POW_LED
TO REG
AL_3VSYS
JLIP_RX
JLIP_TX
TO AUDIO, DSP,
OP.DRV, TG
DATA_OUT
CLK_OUT
TO DSP
TBC_CS
A_CSYNC
TBC_RST
EXT_IN_L
S_IN_L
TBC_DTI
TO TG
LCD_CTL
TO OP.DRV
HALL_AD
IRIS_O/C
F/Z_RST
TO MAIN IF
CN113
CAS_SW
MONI_SW
TRIG_SW
FOCUS_SW
PHOTO_SW
MENU_SET
MENU_P_A
MENU_P_B
ZOOM_SW
FADE_CTL
LIT_3V
AL_3V
V_BATT
IR_AMP
IR_OUT
VPPC
IF_TX
TL1021
TL1022
TL1023
TL1024
TL1025
TL1026
REV_SW
LCD_RST
TG_RST
TG_CS
CDS_CS
BUZZER
M_RVS
VF_LCD
VF_CTL
Z_SENS
F_SENS
F/Z_CS
EJT_SW
KEY_A
TL1027
0 1 MAIN (SYSCON)
L1002
10µ
C1003
C1004
0.1
10
R1013
/6.3
R1002
220K
R1003
4.7K
10K
R1004
15K
10K
R1005
R1006
R1017
560
D1002
RSD376-X
R1016
∗
Q1004
DTC143XE-X
IC1009
TC7W08FU-X
R1053 R1051
150K 2.7K
Q1002
2SC4617/QR/-X
10K
Q1001
DTC124EE-X
R1055R1056
4.7K
0R0
22k
39k
0.01
0.01
R1050
R1049
R1048
C1028
C1029
RA1009
C1030
100k
R1046
R1045
R1044
10k
R1081
10k
R1082
100k
10k
8.2k
12k
10k
R1083
GND
GND
INV
Vcc OUT
N.C
GND
330K
R1007
R1026
4.7k
IC1007
SN74AHC1G08K-X
R1052
18K
DA221-X
C1031
1
47K
R1054
0.01
RA1008
100k
IC1008
IC-PST3423U-X
RESET_DET
D1001
R1001
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
EEPROM_CS
R1020
330
EEP_DT_CLK
330
R1021
EEP_DT_OUT
330
R1022
EEP_IN
TO D.CPU
S_CLK
10K
0.01
C1015
HOLD
R1018
VCC
SCK
SI
0.01
C1016
0.01
C1017
C1007
0.01
0.01
C1019
D1003
MA8068-X
R1008
R1066
47K
C1013
∗
1k
R1030
100k
IC1002
RS5C314-X
VDD
CLKCSXin
SIO
ASTB
DSTB
MENU_KEY
SHOE_VON
PWAD2
MD_DEM1
VSS
C1038
0.01
NC
R/W
WRL
NC
I_MTR
T_BATT
SHOE_AD/STRB_AD
FOCUS_PB/
FOCUS_PA/
JLIP_INT
PD_L
MXDT_OUT
VDD
VSS
DV_DEM0
Xout
INTR
VSS
STRB_CHG
SENSPULS
STO_OFF
DV_DEM1
Q1008
100K
2.2k
R1058
C1034
0.01
TL1001
R1072
100K
IC1001
R1009
DTA114EE-X
560
Q1009
DTC144EE-X
R1015
470K
DSC_DT_IN
DSC_DT_OUT
S_DT_IN
S_DT_OUT
S_CLK
DATA_IN
DATA_OUT
CLK_OUT
SRV_CS
SRV_RDY
VDD
VSS
SRV_RST
RTC_CS
JLIP_L
PWR_CTL
TIMER_OUT
IRIS_C
IR_WB
OSD_CS
OSD_TBC_IN
OSD_TBC_OUT
OSD_TBC_CLK
TBC_CS
BZ_FREQ
BZ_ENV
A_CSYNC
TBC_RST
EXT_IN_L
S_IN_L
TGFZ_RST
TG_CS
CDS_CS
CCD_CTL
REV_SW
LCD_RST
VDD
VSS
M_RVS
FLSH_RST
REG_CS
DSC_STS
DSC_RST
USBDOWN
DSC_PCTL
DSC_CLK
RXD
TXD
EEPROM_CS
VF_CS
ROM_CS
M_CS
VF_LCD
LCD_CTL
VF_CTL
DAC_CS
LAMP_ONNCCHRG_WKUP
AVREF_OFF
TL1010
R1071
10K
R1034
S_DET
BUS15
CHRG_LED
470K
BUS12
BUS13
BUS14
TL1003
TL1002
10K
1k
R1033
R1080
WAIT
P_DET
KENTO
SYSCLK
TRIG_SW
MENU_SET
IC1001
UPD70F3040F1A32
UPD703039F1-A32
SHOE_PWM
DIAL_MANU
A_FADE
CHRG_EVR
PHOTO_SW
FOCUS_SW
P_MEDIANCF/Z_CS
GATEPULS
TL1009
DIAL_PB
DIAL_OFF
DIAL_AUTO
C1039
0.01
BUS6
BUS7
BUS8
BUS9
BVSS
BVDD
BUS10
BUS11
IRIS_O/C
VPP
XT1
RESET
XT2
VDD
OSCO
C1036
0.01
C1026
0.1
R1037
10K
10k
R1039
R1036
1k
BUS0
BUS1
BUS2
BUS3
BUS4
BUS5
ADP_H
BATT_H
S_MUTE
OSCI
VSS
AUDIO_CS
A_MUTE
PWDA1
PWDA2
PWAD1
X1001
NAX0474-001X
16MHZ
VDD
SHOE_DET
L_MUTE
AVSS
AVDD
S_DC_IN
ZOOM_SW
OP_THRMO
F_PTR_AD
Z_PTR_AD
HALL_AD
TRG_OUT
RTC_INT
MENU_P_B
MENU_P_A
CAPT_REQ
ASPECT2
ASPECT1
DSP_RST
TBC_INV
REMOTE
DSC_CS
EJCT_SW
CAS_SW
MONI_SW
VF_SW
A_P_CTL
INT_L
KEY_C
KEY_B
KEY_A
IR_DET
V_BATT
MMC_L
AVREF
TALLY
FLD
VSS
VDD
OMT
MP_MUTE
32kHz
X1002
NAX0325-001X
C1006
13p
R1014
∗
S
G
D
Q1005
2SJ347-X
NC
NC
NC
NC
NC
R1079
R1078
NC
VD
NC
0.01
TL1004
TL1005
TL1006
TL1007
C1009
1k
1k
0.01
C1010
IC1003
X25170S8I2.5-X
CS
SO
WP
VSS
C1037
0.01
RA1010
Q1010
UMX1N-W
RA1011
Q1012
UMX1N-W
R1032
100k
470k
470k
R1031
C1021
C1023
0.1
Q1013
82k
R1024
62k
R1019
Q1011
10k
R1023
100k
R1038
100k
R1027
1k
∗
UMX1N-W
UMX1N-W
VDD
∗
IC1004
[-]
C1020
IC1005
TC7S00FU-X
R1090
470K
R1092
150K
R1094
470K
R1096
150K
TC75S56FU-X
OUT
VSS
[+]
R1028
∗
SCLK
CS
DATA
RST
VDD
SDR
XD
EXD
TEST
VSS BLKC
IC1006
R1091
470K
R1093
150K
R1095
470K
R1097
150K
HD
VD
VC0
VC1
VC2
BLKA
VC3
BLKB
TST0
MB90097PFV145-X
S_DT_OUT
S_DT_IN
TO MAIN IF CN109
DIAL_MANU
DIAL_AUTO
DIAL_OFF
DIAL_PB
TO D.CPU
SRV_RST
SRV_CS
SRV_RDY
CALE
CDSTB
CRWSEL
BUS15
BUS14
BUS13
BUS12
BUS11
BUS10
TO DSP
BUS9
BUS8
BUS7
BUS6
BUS5
BUS4
BUS3
BUS2
BUS1
BUS0
ADP_H
TO MAIN IF
CN104
T_BATT
I_MTR
CHRG_EVR
REG_CS
TO REG
AREG_CLK
AREG_SO
TO MAIN IF
P_DET
CN103
S_DET
TO V OUT
ASPECT1
ASPECT2
TO DSP
DSP_RST
MVD
OMT
MFLD
TO AUDIO
A_MUTE
S_MUTE
PD_L
AUDIO_CS
TO DSP
OSD_HD
OSD_VD
VC0
VC1
VC2
BLKA
VC3
BLKB
BLKC
DOT_CLK
NOTE : The parts with marked ( ) is not used.
∗
y10268001a_rev0
4-84-7
EDCBA
HGF
5
4
3
2
TO DSP
TO
DVMAIN
TO MAIN IF CN105,
DVMAIN, PRE/REC
TO DVMAIN
TO
SYSCON
TO
SYSCON
EEP_DT_OUT
EEP_DT_CLK
EEPROM_CS
TO MAIN IF
CN105
D.CPU SCHEMATIC DIAGRAM4.4
TO REG
REG_3V
CAM_VD
SRV_TRK
SRV_RDY
S_DT_OUT
S_DT_IN
S_CLK
SRV_CS
SRV_RST
EEP_IN
SRV_TX
SRV_RX
VPPD
DRST
OUTV
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
01
MAIN (D.CPU)
L1401
NQR006-001X
GND
TSR
FRP
SPA
HID1
TL1411
TL1410
TL1409
TL1408
TL1407
TL1406
R1417
100
C1403C1408
T
∗
0.1
TREEL_IN
SREEL_IN
TL1413
TL1412
R1414 R1413 R1412 R1411
3.3k 3.3k 3.3k 3.3k
C1414C1415 C1413 C1412
0.0220.022 0.022 0.022
C1404
TSR
FRP
SPA
SRV_TRK
HID
SRV_CS
DRUM_REF
CAP_REF
TL1405
NC
NC
NCNCNC
READY
SYS_IN
SYS_CLK
RXD
TXD
NC
MIC_SDA
MIC_CTL
MIC_SCL
EEP_READ
EEP_WRITE
EEP_CLK
EEP_CS
0.1
TL1419
XI164SEL
4.7K
4.7K
TL1401
R1416
R1415
TL1402
R1424
EEP_SEL
100K
Vdd
Vss
CAM_VD
NC
NC
NC
TAPE_LED
NC
NC
NC
MDA_PS
DRUM_BRK
CAP_RVS
CAP_BRK
LD_ON
D_GAIN
LD_FWD
LD_REV
CAM0
CAM1
CAM2
REC_SAFE
HID
DIN_L
NC
XI164SEL
VDD
VSS
REEL_ON
KENTO1
KENTO2
HID3
MONI_CHG
DV_WAIT
CLK_OUT
SYS_OUT
CLK27SEL
FFREWH
DV_RSTNCNCNCNCNCNCNCNC
NCNCNC
NC
ADDT15
ADDT14
ADDT13
ADDT12
ADDT11
ADDT10
ADDT09
ADDT08
BVSS
BVDD
ADDT05
ADDT06
ADDT07
IC1401
UPD703040YF-M12
UPD70F3040YFM12
CAP_REF
DRUM_REF
KENTO1_REF
KENTO2_REFNCNCNCNC
VPP
XT1
RESET
XT2
VDD
OSCO
OSCI
ADDT03
ADDT04
VSSNCHID
ADDT02
ADDT01
PBH
NC
ADDT00
RECHNCNCNCNC
NC
DRE
DALE
DRWSEL
VDD
C1407
0.1
NC
VSS
VDD
DWE
AVSS
AVDD
DEW_SENS
VSSNCNCNCNCNCNC
AVREF
BCID3
BCID2
BCID1
E_SENS
S_SENS
CAP_FG
DRUM_FG
SRVTRK
S_REEL
T_REEL
OUTV
DRUM_PG
DRUM_FG
MSELECT
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
SPA
NC
NC
NC
NC
FRP
TSR
VSS
VDD
NC
C1406
NC
0.1
NC
NC
NC
NC
0.01
C1411
0.01
C1410
0.01
C1409
TL1417
TL1416
TL1415
TL1414
330k
R1409
75k
R1408
TSR
FRP
SPA
SRV_TRK
3.3k
R1407
Q1401
DTA114EE-X
3.3k
R1406
3.3k
R1405
15k
R1422
10k
R1421
MIC_CTL
R1404
4.7k
TAPE_LED
Q1403
UMC3N-W
REEL_VCC
Q1402
UMC3N-W
RA1401
47k
*
R1410
R1423
82
TO REG
GND
REG_3V
M_REG4.8
M_UNREG
TO SYSCON
CAS_SW
CAS_SW
M_UNREG
M_REG4.8
REG_3V
GND
TREEL_IN
SREEL_IN
TAPE_LED
REEL_VCC
S_SENS
E_SENS
DEW_SENS
MIC3
MIC2
MIC1
REC_SAFE
TO MAIN IF
CN111
CAM_SW_A
CAM_SW_B
CAM_SW_C
TO PRE/REC
RECH
PBH
HID3
MONI_CHG
TO
DVMAIN
DV_RST
CLK27SEL
DV_WAIT
DWE
DALE
DRWSEL
DRE
ADDT00
ADDT01
ADDT02
ADDT03
ADDT04
ADDT05
ADDT06
ADDT07
ADDT08
ADDT09
ADDT10
ADDT11
ADDT12
ADDT13
ADDT14
ADDT15
TO MAIN IF
CN113
TO MDA
TO MDA
TO MAIN IF
CN113
TO MAIN IF
CN113
TO REG
D_GAIN
DRUM_PWR
CAP_PWR
DRUM_ERR
CAP_ERR
TO MDA
CAP_ERR
DRUM_ERR
CAP_PWR
DRUM_PWR
DRUM_REF
CAP_REF
CAP_FG
1
DRUM_PG
DRUM_FG
CAP_BRK
LD_ON
CAP_RVS
DRUM_BRK
MDA_PS
LD_FWD
LD_REV
NOTE : The parts with marked ( ) is not used.
VPPD
DRST
∗
TL1418
FFREWH
TESTDA0 TESTDA1
TL1403 TL1404
C1416
R1403
R1402
0.1
10K
1k
ABCD EFGH
C1405
R1401
0.1
C1401
C1402
15p1M15p
X1401
NAX0204-001X
y10269001a_rev0
4-104-9
MDA SCHEMATIC DIAGRAM4.5
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
TO D.CPU
LD_REV
LD_FWD
DRUM_BRK
MDA_PS
5
CAP_RVS
CAP_BRK
CAP_REF
CAP_FG
DRUM_REF
DRUM_PG
DRUM_FG
LD_ON
DRUM_ERR
M_UNREG
4
TO MAIN IF
CN113
3
LOAD_FWD
LOAD_REV
0 1 MAIN (MDA)
TL1612
TL1601
C1601
0.01
D1602
DAP222-X
TL1613
R1630
R1631
C1607
0.047
C1603
C1605
0.1
270
R1628
10
T
R1603
4.7K
TL1622
TL1621
TL1620
TL1617
TL1618
0
0
TL1607
R1620
TL1606
10K
TL1619
TL1605
R1622
10K
D1604
DAP222-X
TL1602
TL1603
TO D.CPU
GND
REG_3V
CAP_ERR
CAP_PWR
10K
R1621
/6.3
T
10
C1602
/6.3
R1601
680
C1606
0.0015
R1604
100k
TL1609
∗
R1643
560K
R1629
R1602
TL1610
120k
D.PG-
D.FGPG+
D.FG-
D.FGOUT
D.FGSOUT
D.V S
GND1
D.U IN
D.V IN
0.22
C1628
D.PGOUT
330P
C1626
L.RIN
D.PGSOUT
39K
R1619
0.047
C1625
L.FIN
D.PCV
D.OSC
D.DETECT
IC1601
BD6631KV
0.01
C1624
D.PCI
D.E C
GND2
D.W IN
C1627
R1624
0.0082
12K
D.COM
D.S L
D.ISET
L.REF
D.UNREG
D.V M
FGND1
D.U
D.V
D.W
D.GND
N.C
L.FWD
FGND2
L.GND
L.REV
C1641
0.47
D.BRK
C.GND
P. S
C.FR
L.UNREG
C.U
390
R1616
C.EC
C.BRK
C.RCC
C.PCI
C.PCV
C.VS
C.FG+
C.FG-
C.FGOUT
C.FGSOUT
C.HU+
C.HU-
C.HV+
C.HV-
C.HW+
C.HW-
C.UNREG
C.VM
C.V
C.W
N.C
VCC
TL1611
C1623
C1622
C1618
C1619
C1620
0.047
0.022
0.0022
0.0022
0.0022
C1642
∗
TL1604
C1632
10
/6.3
T
M_REG4.8
DRUM_PWR
TO
MAIN IF
CN112
C_FG[+]
C_FG[-]
C_COIL_U
C_COIL_V
C_COIL_W
TL1608
R1612
R1613
100K
1K
C1621
1
HG_U[+]
HG_U[-]
HG_V[+]
HG_V[-]
HG_W[+]
R1611
R1610
470
470
HG_W[-]
HG_BS[-]
HG_BS[+]
180
180
TO D.CPU
REEL_VCC
TO MAIN IF CN113
TREELLED
TO MAIN IF
CN113
D_FG[-]
2
D_PG[-]
D_PFG[+] SREELLED
TL1614
COIL_COM
R1625
R1626
D_COIL_U
D_COIL_V
D_COIL_W
TO D.CPU
GND
0.22
R1605
0.33
R1609
/6.3
10
C1614
T
1K
R1614
TO D.CPU
TREEL_IN
SREEL_IN
TO
MAIN IF
CN113
T_REEL
S_REEL
D1603
DAP222-X
Q1601
R1635
1
NOTE : The parts with marked ( ) is not used.
∗
UMC3N-W
4.7K
R1636
10K
R1637
150K
4-124-11
C1633
0.47
EDCBA
IC1602
TC7W14FU-X
R1615
1K
68K
R1618
68K
R1617
y20171001a_rev0
HGF
AUDIO SCHEMATIC DIAGRAM4.6
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
TO MAIN IF
0 1 MAIN (AUDIO)
L2002
22µ
5
-
3.3k
R2129
LINE
++-
LINE
3.3k
R2130
SVDD
VCOM
C2015
4.0V
1.5V
1
C2004
/6.3
10
T
GND
MIX
MIX
VREF
MIC SEL
(SVDD)
1.5V
1
C2005
GND
(VA)
C2013
2.7
R2019
0.1
VA
SPK+
D/A Converter
3V
LINE OUT2
C2002
10
T
ND
C2018
0.1
/6.3
Rch
C2014
2.7
R2020
SIG
+
0.1
C2003
*
PD
SPK-
++--
BEEP
LINE OUT2
C2019
0.1
BEEP
Lch
Clock
Divider
HPFA/D Converter
++--
VOLVOL
MCLK
R2028
220k
C2021
0.1
LRCK
+
-
+
-
+
-
+
-
SIG
-
R2024
Controller
18k
BCLK
Audio I/F
R2025
Control
Register
MIX
C2020
0.1
100k
CCLK
I/F
-
+
AVR OUT
CS
DATA
SDTI
SDTO
GND
(VD)
VD
3V
A_MUTE
HP OUT
Lch
HP OUT
Rch
HVDD
4.8V
HVCM
2.4V
LINE OUT
Rch
LINE IN
Rch
LINE OUT
Lch
LINE IN
Lch
SP IN
R2023
1k
Q2004
2SC4617/QR/-X
T
R2018
10k
R2027
3.3k
C2001
10
C2016
0.022
/6.3
R2014
R2015
R2016
R2006
C2017
0.033
10
T
C2011
10
C2008
1
C2007
0.1
C2006
0.1
L2001
10µ
82
82
82
/6.3
R2017
1k
C2012
10
/6.3
Q2002
2SC4617/QR/-X
T
D2001
C2009
1
C2010
1
D2002
∗
∗
R2007
1k
R2008
1k
Q2001
UMX1N-W
R2009
3.3k
C2133
0.01
C2113
+-
C2111
0.0047
C2112
0.0047
0.0047
+
-
HPFONON
OFF
Rch
IC2001
AK4560AVQ
Lch
HPF
OFF
-
+
C2114
0.0047
47k
R2107
++-
INT
EXT
Rch
ALC AMP
Lch
ALC AMP
EXT
INT
+-
47k
R2108
C2134
0.01
C2115
MIC
MIC
C2116
0.1
0.1
R2105
100k
C2105
C2106
R2113
15k
R2103
15k
-
∗
C2101
0.1
C2102
0.1
MPWR
3.3V
EXT MIC
Rch
INT MIC
Rch
MRF
MVCM
2V
GND
(MVDD)
MVDD
4V
INT MIC
Lch
EXT MIC
Lch
MA
BIAS
2V
∗
R2104
15k
R2114
15k
R2106
100k
C2107
T
C2108
C2132
0.001
R2110
4.7k
C2121
0.022
R2111
2.2k
R2117R2119
4.7k15k
R2101
1.8k
∗
∗
R2102
1.8k
R2118R2120
4.7k15k
R2112
2.2k
C2122
0.022
C2125
0.022
4
R2201 R2202 C2131
1.8k 1.8k 0.001
L2201
0Ω
TO MIC
CN106
INT_MIC/R
IM_GND
3
INT_MIC/L
L2202
0Ω
L2203
0Ω
C2201
0.01
C2202
0.01
C2124
0.022
2
R2127 R2109
4.7k 4.7k
C2123
0.022
C2103
1
C2129
∗
C2110
1
C2109
/6.3
10
C2130
∗
C2104
1
R2128
4.7k
C2126
0.022
CN101
SPK+
SPK-
TO
DVMAIN
AIMCK
AILRCK
AIBCK
AODAT
AIDAT
TO SYSCON
PD_L
CLK_OUT
AUDIO_CS
DATA_OUT
TO REG
REG_3V
M_REG4.8
REG_4.8V
GND
TO MAIN IF
CN103
AU_SIG/R
AU_SIG/L
TO SYSCON
BUZZER
S_SHUT
A_MUTE
S_MUTE
TO DSP
TO SYSCON
1
NOTE : The parts with marked ( ) is not used.
ABCD EFGH
∗
4-144-13
y20217001a_rev0
DVMAIN SCHEMATIC DIAGRAM4.7
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
TBST
EXDATAI2
C3061
TTST
EXDATAI1
∗
PBI
N.C
EXDATAI0
PBCLKO
R3049
2SC4617/RS/-X
R3072
C3040C3041
∗∗
N.C
N.C
N.C
N.C
N.C
N.C
VCO D/AA/D A/DD/A
PBCLKI
VSSP
VCI4185
VDDP
DAAOUT0
DAVRO0
10k
0.01
R3002
C3013
R3073
Q3002
∗
Q3002
∗
R3066
R3074
10K
EXTDATA7
DAVREF0
560
0.1
C3039
VSS
VSS
VSS
VDDE
EXTDATA2
EXTDATA5
EXTDATA6
EXTDATA3
EXTDATA4
DAAVS0
DAAVD0
DAAOUT1
DAVRO1
DAVREF1
DAAVS1
DAAVD1
SBE
0.01
10k
0.1
R3004
C3015
C3016
R3050
∗
VSS
VDDI
ADRS7
ADRS8
ADRS9
EXTACCESS
EXTREQ
ADRS10
EXTFRP
EXTDATA0
EXTDATA1
IC3001
JCY0152
[DVMAIN]
HID
HSP
RECDATA
RECCLK
RECCTL
SPA
VSS
VDDE
VSS
OSC4185I
OSC4185O
DISCRI
10
0.1
5.6k
C3017
R3057
R3007
ADRS6
REFCLK
ADRS5
ADVIN1
0.1
C3020
2.2k
R3008
AD14
VDDI
0.1
C3025
AD13
FRRES
AD12
FRREF
AD11
TRKREF
AD9
AD10
SERVOFRREF
SERVOTRKREF
PHYTPA
PHYTPB
PHYTPBIAS
1
C3026
PHYXTPA
CPUWAITLOGIC
VCO
PHYXTPB
PHYRO
2.4k
3.9k
R3013
R3014
CPUBUSTYPE
CPUDSLOGIC
CPUWAIT
XCPUCS
XCPURW
XCPUDSTB1
XCPUDSTB0
CPUALE
OUTV
OUTH
BRSI3
BRSI2
BRSI1
BRSI0
BRSO3
BRSO2
BRSO1
BRSO0
YSO3
YSO2
YSO1
YSO0
AODAT0
AODAT1
AOBCK
AOLRCK
DODAT
DOBCK
DOLRCK
AIDAT0
AIDAT1
AIMCK
AIBCK
AILRCK
DIDAT
DIMCK
DIBCK
DILRCK
OSC11O
OSC11I
OSC24O
OSC24I
VCXO12O
VCXO12I
VCXO11O
VCXO11I
VDDP
VCIAUD
VSSP
VDDE
PWMAUDIO
VDDE
LPFIN
LPFOUT
VDDE
PHYAVS3
PHYVSR
PHYVSA
PHYVDR
PHYVDA
PHYFIL
PHYRF
PHYFIL
XRESET
R3015
0.01
C3055
VDDI
C3027
XINT
INV
INH
YSI3
YSI2
YSI1
YSI0
VSS
C3038
0.1
1000P
C3064
R3031
R3034
2.2k
L3009
∗
CH
C3035
C3034
∗
∗
220k
D3003
EC2C01C-X
CH
8P
C3037
X3002
1M
[NAX0480-001X]
CH
R3032
C3036
8P
R3033
∗
L3008
C3031
0.1
0.1
C3030
0.5
R3016
0.5
56
R3017
0.5
565656
R3018
0.5
R3019
R3036
R3027
10k
C3049
2200P
R3037
C3048
10K
680
0.047
C3029
0.01
C3050
0.01
0.5
270p
CH
5.1k
R3020
C3028
VSS
N.C
3.9k
0.0047
C3032
0.001
R3030
R3029
6.8K
12µ
CH
C3033
8P
220k
D3002
EC2C01C-X
RA3001
10
RA3002
10
TL3006
SBE
RA3005
NRZ0040-0R0X
R3005
R3006
0Ω
RA3003
INV
TO DSP
INH
10
10
10
OUTV
OUTH
DCO3
DCO2
DCO1
DCO0
DYO3
DYO2
DYO1
DYO0
DCI3
DCI2
DCI1
DCI0
DYI3
DYI2
DYI1
DYI0
CLK27
TO AUDIO
AODAT
AIDAT
AIMCK
AIBCK
AILRCK
TO D.CPU
ADDT15
ADDT14
ADDT13
ADDT12
ADDT11
ADDT10
ADDT09
ADDT08
ADDT07
ADDT06
ADDT05
ADDT04
ADDT03
ADDT02
ADDT01
ADDT00
DV_WAIT
DRWSEL
DRE
DWE
DALE
DV_RST
CLK27SEL
SRV_TRK
TSR
FRP
SPA
HID1
TO MAIN IF
CN105
FS_PLL
MAIN_VCO
PB_CLK
(NC)
DISCRI
TO MAIN IF
J101
TPA+
TPB+
TPB-
TO
DSP
TO D.CPU,
DSP
TO TG
VSS
0.1
C3021
ADRS4
VSS
ADRS2
ADRS3
PWM27O
VDDE
33p
CH
C3023
VSS
VDDI
AD15
VDDE
ADRS0
ADRS1
OSC27I
OSC27O
CLK27I
CLK27O
CLK27SEL
VSS
CLK135O
L3007
C3024
0.001
2.2µ
D3001
220k
R3011
EC2C01C-X
0.1
C3022
TL3001
VSS
VDDI
VDDE
BUSCLK
ADAVD1
ADAVS1
ADVRH1
ADVRL1
R3009
10k
R3010
10k
AD0
AD1
AD2
AD3
AD4
AD5
AD6
AD7
AD8
∗
∗
R3075
VCC
1560
NORI1
NORI2
TRICSW
IC3005
JCY0136-X
AMP-
AMPO
GND
R3068
0Ω
270
C3068
4.7K
∗
C3069
0.1
R3069
X3001
∗
[41.85M]
NAX0169-001X
CH CH
C3057
R3051
∗
R3047
R3048
∗
∗
TO DSP
C3058
∗
FSPLLCTL
M_VCOCTL
PBVCOCTL
PBPLLCTL
R3067
C3066
C3067
1000P
AMP+
0
1
MAIN (DVMAIN)
TO DSP
TDO
TMS
TCMK
TRST
TDB
5
TO REG
REG_3V
REG_2.5V
REG_1.8V
GND
4
L3002
NQR0129-002X
L3003
C3004
L3005
NQR0006-001X
L3004
NQR0006-001X
10
L3006
10
D3004
C3003
∗
C3007
C3005
∗
C3008
1
∗
10
/6.3
T
/6.3
T
MA2Z720-X
3
R3025
1K
C3006
R3026
1
∗
2
TO PRE/REC
AGC_OUT
VRB_AGC
VREF_1.1 TPA-
REC_DATA
REC_CLK
REC_CTL
REF_CLK
ATFI
VRB_ATF
1
DIGITAL_3V
NCB30JK-105X
DIGITAL_2.5V
DIGITAL_1.8V
NCB10JK-106X
ANALOG_2.5V
ANALOG_1.8V
Q3001
2SC4617/R5/-X
C3009
1
L3001
NQR0129-002X
C3001
10
L3012
NQR0129-002X
R3059
/6.3
NQR0006-001X
100
C3047
∗
C3042
0.01
C3043
0.01
C3044
0.1
PHY_2.85V
T
C3045
0.1
10k
RA3004
0.01
C3046
TL3005
L3015
R3046
R3070
∗
R3045
T
C3056
∗
C3053
C3054
∗
∗
∗
∗
R3043
∗
C3052
R3044
∗
VCO
IC3007
∗
N.C
N.C
MON0
MON1
VDDE
VDDI
MON2
MON3
MON4
MON5
VSS
MON6
MON7
MON8
MON9
MON10
MON11
MON12
VDDE
VDDI
MON13
MON14
MON15
MON16
MON17
MON18
MON19
VSS
MON20
MON21
MON22
MON23
VDDE
MON24
MON25
MON26
MON27
VDDE
N.C
VDDP
VSSP
VDDA
VSS
N.C
N.C
VDDE
VSS
VSS
VDDE
VDDI
VSS
VDDE
VDDE
VDDI
VSS
VSS
MTEST
PHYAVD2
BUSRST
PHYAVS2
PMODE
PWR3
PWR1
PWR2
VDDI
PHYAVS1
PHYAVD3
PHYAVD1
VSS
VDDE
VDDI
VSS
R3071
C3011
0.1
∗
R3040
∗
∗
R3042
C3051
TDI
ADVRH0
0.1
C3012
VSS
ADVRL0
R3003
TRST
EXDATAI7
DCTEST0
DCTEST1
EXDATAI6
EXDATAI5
N.C
VPD
EXDATAI4
EXDATAI3
∗
TCK
TMS
TDO
ADVIN0
ADAVD0
ADAVS0
0Ω
C3014
∗
IC3004
∗
R3041
∗
∗
NOTE : The parts with marked ( ) is not used.
∗
y10253001a_rev0
4-164-15
EDCBA
HGF
PRE/REC SCHEMATIC DIAGRAM4.8
NOTES :
For the destination of each signal and further line connections that are cut off from
this diagram,refer to "4.1 BOARD INTERCONNECTIONS".
When ordering parts,be sure to order according to the Part Number indicated in the Parts List.
MAIN0 1 (PRE/REC)
5
4
3
2
TO D.CPU
MONI_CHG
TO
MAIN IF
CN105
ENV_OUT
TO DSP
DUMP_CTL
ATF_GAIN
NOSIG_LV
RECCADJ
TO
DVMAIN
REC_CTL
VREF_1.1
AGC_OUT
VRB_AGC
VRB_ATF
REF_CLK
REC_DATA
REC_CLK
HID3
HID1
PBH
RECH
ATFI
ATFI
TL3501
L3501
L3502
SN74AHC1G04K-X
NQR0129-002X
10µ
L3503
L3504
L3505
IC3502
C3528
0.01
NQR0006-001X
NQR0006-001X
NQR0006-001X
R3512 R3511
100
∗
IC3502
R3509
R3510
C3516
0.047
6dB
C3517
C3527
220p
0.01
CH
C3518
C3519
0.001
C3521
0.1
C3522
4.7
C3523
0.01
C3525
4.7
0.01
C3520
0.01
C3524
0.01
∗
∗
PB_OUT
AGC_IN
AGC_CTL
AGC_DET
PB_GND
AGC_OUT
AGC_BUFF_IN
REG_1.1V
AGC_BUFF_OUT
VRB_AGC
MAIN_GND
ATF_GAIN
VCA_OUT
ATF_IN
BIAS
VRB_ATF
REG
ATF_OUT
0.047
C3515
PB_MONI
DCS_C3
DCS_C2
DC Servo
Typ:-1.3dB
BIASREG
10.3dB
REG
F0_EVR
0.01
C3526
12dB
R3501 C3504
10dB
470 0.047
BPF
ATF_GNDTCPB_GND
C3514
0.047
DCS_C1
R_CTL
AGCLPF
Typ:7.8dB
VCA
Typ:24dB
F0 Auto
ADREF
0.022
1
C3505
C3506
C3513
VCC5
REF_CLK
0.01
C3507
0.1
REC_DATA
R3502
REC_H
100k
PB_H
LOGIC
10dB
F. F.
REC_GND
REC_CLK
HID1
REC
REC_MONI
0.01
C3508
HID2
10dB
REC_GAIN
C3512
HID3
VCC3
0.01
C3509
0.1
VDD2.8
MONI_CHG
DUMP
Dumping
HEAD_VCC
0.1
C3510
0.01
C3511
REC_R
R3503
22k
R3508
PBIN_R
1k
HEAD_GND
HEAD_GND
30dB
30dB
30dB
HEAD_GND
IC3501
JCY0132
HEAD_GND
HEAD_GND
HEAD_GND
HEAD_GND
HEAD_GND
DX3
X3
Y3
DY3
DX2
X2
Y2
DY2
DX1
X1
Y1
DY1
R3507
240
R3506
240
R3505
240
R3504
240
R3522 R3521
0Ω 0Ω
TO HEAD
CN110
GND[P/R_GND]
2S
2F
GND[P/R_GND]
GND[P/R_GND]
1S
1F
GND[P/R_GND]
1
REG_4.8V
REG_3V
REG_2.5V
GND
NOTE : The parts with marked ( ) is not used.
TO REG
C3501
10
∗
ABCD EFGH
C3502
10
/6.3
C3503
10
/6.3/6.3
TTT
y20172001a_rev0
4-184-17
Loading...
