JVC GRDV-2000 Service manual

Download

SECTION 5

PARTS LIST

SAFETY PRECAUTION

Parts identified by the symbol are critical for safety. Replace only with specified part numbers.

5.1 PACKING AND ACCESSORY ASSEMBLY <M1>

The instruction manual to be provided with this product will differ according to the destination.

# REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- -----------------------------------------------------

******************************

PACKING AND ACCESSORY ASSEMBLY <M1>

9 8

FINAL ASSY

<M2>

1 LY32164-001B PACKING CASE 2 LY20666-001B CUSION 3 LY30023-020A POLY BAG

4 LYT0708-001A INST.BOOK(EN)

! !

5 LYT0708-004A INST.BOOK(PRINTER.EN)

6 LYT0709-001A INST.BOOK(SOFT.3LANG) 8 LYT0378-003A SHEET(AGREMENT) 9 BT-51005-4 WARRANTY INF. 10 BT-51020-2 REGIST.CARD 11 LY20677-002A JACK BOX 12 LY31133-021A CD ROM 13 PEAC0428-150 CABLE ASSY,EDITING CABLE

15 LY20591-001B 16 QAM0170-001 DC CORD 18 QAM0322-001 USB CABLE

19 LY31587-001A BATTERY PACK,BN-V408U 20 QAM0211-001 CABLE ASSY,AUDIO/VIDEO CABEL 22 LY20186-001A SHOULDER STRAP 23 LY20543-002A 24 – BATTERY,AAA(R03),X2 25 QAM0004-004 S VIDEO CABLE 26 QAM0321-002 MULTIMEDIA CARD 27 LY32003-001A LENS HOOD 30 QPA02003006 POLY BAG

LYT0708-002A INST.BOOK(FR) LYT0708-003A INST.BOOK(SP)

LYT0708-005A INST.BOOK(PRINTER.FR) LYT0708-006A INST.BOOK(PRINTER.SP)

AC POWER ADAPTER/CHARGER,AA-V40U

REMOTE CONTROL UNIT,RM-V716U

• INSTRUCTIONS

EN ...... ENGLISH

FR ...... FRENCH

SP ...... SPANISH

15 (Refer to MANUAL

No. 86551 sec.6)

LABEL

(SERIAL)

5-1 5-2

5.2 FINAL ASSEMBLY <M2>

237

233A

251C

233

233B

251H

251C

251B

233A

199

248

251C

251D

237

251D

251F

134

111

132

OPTICAL BLOCK

SECTION

CCD <10>

251J

251C

251A

116

251

110

120

106

114

120

161

239

120

242

192

130

251G

162

245

191

112

251G

243

AUDIO

<04>

184

115

182

163

106F

106C

130

119

106G

106E

119

186

182

106A

106H

106J

106C

117

169

179

244

182

170

165

230

113

106J

RATING LABEL

168

179

171

179

165A

127

183

179

180

127

JACK

<07>

128

121

174

ELECTRONIC VIEWFINDER

216

140C

<M4>

201

216

194

141

DECK OPE.

<09>

155

238

140B

REG <05>

155

140

140C

(FROM

DSC)

247

154

235

PRE/MDA

<03>

140B

151

154

195

140D

238

215

154

238

236

190

150

150C

150D

150B

234

238

232A

236

195

215

144

217

218

203

150E

150A

204

232

236

u v x

208

(FROM

CCD)

152

150E

153

241

MAIN

<01>

198

197

203

153

DSC <02>

209

109

123

121

122

129

EJECT

<08>

211

176

174

123

122

102A

160

160D

166

160B

102

102A

212

123

118

131

210

214

133

102B

105

160C

240

160E

160A

124

200

131

181

129

125

175

181

177

219

195

129

205

180

196

213

126

125

124

231

202

126

167

220

172

202

185

216

246

101

126

193

MECHANISM

<M3>

207

178

141

207

140A

140B

173

5-3 5-4

206

142

MONITOR

<M5>

142

143

206

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

172 LY42920-001A SHEET(FRONT)

******************************

FINAL ASSEMBLY <M2>

101 LY10266-001A LOWER CASE 102 LY31964-001E ARM ASSY 102A LY30002-046B COMPRESSION SPRING,X2 102B LY42814-001A TENSION SPRING 105 LY31984-001B BASE

106 LY20657-002B CASSETTE COVER ASSY 106A LY31973-001A JACK COVER 106C LY30018-021A SPECIAL SCREW,X2 106E LY32045-001A HINGE ASSY(C) 106F LY32045-002A HINGE ASSY(C) 106G LY42786-001A KNOB(LOCK) 106H LY42787-001A HOLDER(LOCK) 106J LY30018-037A SPECIAL SCREW,X2 109 LY20653-002A POWER OPE.UNIT 110 LY31977-001A HOLDER(SPK) 111 LY42918-001B SPACER(SPK) 112 LY42788-001A HOOK 113 LY42789-001B BRACKET(GRIP BELT) 114 LY20658-002A GRIP BELT 115 LY43019-001A SHEET(GRIP BELT) 116 QAS0063-001 SPEAKER 117 LY42878-001C SHEET(MMC) 118 LY42881-001C SPACER(JACK) 119 QYSLSF2050D SCREW,X2 120 LY30018-021A SPECIAL SCREW,X3 121 QYSLSF2040D SCREW,X2 122 LY30018-0C7A SPECIAL SCREW,X2 123 LY30018-0B7A SPECIAL SCREW,X3 124 LY30018-005A SPECIAL SCREW,X2 125 LY30018-080A SPECIAL SCREW,X2 126 LY30018-006B SPECIAL SCREW,X3 127 QYSPSPT1720R SCREW,X3 128 QYSPSPT1720R SCREW 129 LY30018-0B7A SPECIAL SCREW,X3 130 LY30018-038A SPECIAL SCREW,X2 131 LY30018-006B SPECIAL SCREW,X2 132 LY30018-032A SPECIAL SCREW 133 LY30018-0B7A SPECIAL SCREW 134 LY40301-001A SPACER(SPK)

140 LY20659-002B UPPER CASE ASSY 140A LY31981-001A BRACKET(HINGE) 140B LY30018-0A8A SPECIAL SCREW,X3 140C LY40162-001A BRACKET,X2 140D LY40664-001A SPACER,X2 141 LY30018-020A SPECIAL SCREW,X3 142 LY30018-042A SPECIAL SCREW,X3 143 LY30018-055A SPECIAL SCREW,X2 144 LY32051-002A SUB OPE.UNIT 150 LY31986-002B REAR COVER ASSY 150A LY31988-001D KNOB(B.RELEASE) 150B LY31989-001A BRACKET(B.RELEASE) 150C LY42792-001A SHEET(REAR) 150D LY30002-048A COMPRESSION SPRING 150E LY30018-066A SPECIAL SCREW,X2 151 LY31987-001A BRACKET(TERM) 152 LY20660-001B BATTERY TERMINAL UNIT 153 LY30018-038A SPECIAL SCREW,X2 154 LY30018-019A SPECIAL SCREW,X3 155 LY30018-060A SPECIAL SCREW,X2 160 LY20661-002A FRONT COVER ASSY 160A LY30029-0B1A SPACER(A) 160B LY31992-001A LEVER(P/S) 160C LY31993-001A HOLDER(P/S) 160D LY31995-001A COVER(JACK) 160E LY30018-0A7A SPECIAL SCREW 161 LY32009-001B HOOD 162 LY20654-001A FOCUS UNIT 163 LY31996-002A COVER(OP) 165 LY42840-001B FRAME ASSY 165A LY42841-001B SHEET(EARTH) 166 LY20664-001A MICROPHONE 167 LY31997-002A COVER(MENU) 168 LY42949-001A SHOE ASSY 169 LY31999-001A BRACKET(H.S) 170 LY20665-001A BRACKET(AUDIO) 171 LY42913-001A SHEET(AUDIO)

173 LY30018-021A SPECIAL SCREW,X2 174 LY30018-0A1A SPECIAL SCREW,X3 175 LY30018-021A SPECIAL SCREW 176 LY30018-037A SPECIAL SCREW 177 LY30018-037A SPECIAL SCREW,X2 178 LY30018-021A SPECIAL SCREW 179 LY30018-031A SPECIAL SCREW,X4 180 LY30018-052A SPECIAL SCREW,X2 181 LY30018-0C1A SPECIAL SCREW 182 LY30018-032A SPECIAL SCREW,X5 183 LY30018-032A SPECIAL SCREW 184 LY30018-021A SPECIAL SCREW 185 LY10262-002A ZOOM OPE.UNIT 186 LY30029-0D1A SPACER(A) 190 LY41393-004A COVER(JIG CONN) 191 LY42790-001A COVER(CASS) 192 LY32039-001B COVER(CASS.R) 193 LY40699-002A LABEL(PUSH) 194 LY32001-002A LABEL(HOUSING) 195 QYSPSPT1715Z SCREW,X3 196 LY30018-017A SPECIAL SCREW 197 LY42424-001A SPECAL SCREW 198 LY30019-002A SPECIAL SCREW 199 LY30018-006B SPECIAL SCREW 200 LY30018-006B SPECIAL SCREW 201 LY30018-059A SPECIAL SCREW 202 LY30018-006B SPECIAL SCREW,X2 203 LY30018-0C2A SPECIAL SCREW,X2 204 LY30018-011A SPECIAL SCREW 205 LY30018-044A SPECIAL SCREW 206 LY30018-044A SPECIAL SCREW,X4 207 LY30018-006B SPECIAL SCREW,X2 208 LY30018-044A SPECIAL SCREW 209 LY30018-011A SPECIAL SCREW 210 LY30018-044A SPECIAL SCREW 211 LY30018-059A SPECIAL SCREW 212 LY30018-063A SPECIAL SCREW 213 LY30018-006B SPECIAL SCREW 214 LY30018-006B SPECIAL SCREW 215 LY30018-059A SPECIAL SCREW,X2 216 LY30018-006B SPECIAL SCREW,X3 217 LY30018-006B SPECIAL SCREW 218 LY30018-026A SPECIAL SCREW 219 LY32072-001A MENU SW UNIT 220 LY32071-001A FRONT FPC UNIT 230 LY20676-001C LENS SHUTTER ASSY 231 QAL0260-001 FPC,JACK CN301 232 LY32066-001A BRACKET(MECHA)ASSY 232A LY42796-001A BUSH,X3 233 LY32067-001B BRACKET(OP)ASSY 233A LY42796-001A BUSH,X2 233B LY30029-0C6A SPACER(A) 234 LY32012-001A SHIELD COVER(PR) 235 LY42889-001A SHIELD(REG) 236 LY30019-028A SPECIAL SCREW,X3 237 LY30019-029B SPECIAL SCREW,X2 238 QYSPSPT1414M SCREW,X5 239 LY30029-0E6A SPACER(A) 240 LY43002-001A HEAT SINK(BASE) 241 LY42972-001A HEAT SINK(MAIN) 242 LY32194-001B LUG WIRE ASSY 243 LY30029-0C8A SPACER(A) 244 LY42952-001A SHEET(AUDIO) 245 LY42951-001B SHEET(OP) 246 LY43025-001A SHEET(D.FPC) 247 QYSPSPT1712M SCREW 248 LY30029-0F3A SPACER(A)

– OPTICAL BLOCK SECTION –

251 J9C-101A OPTICAL BLOCK ASSY 251A LY31901-001A ZOOM MOTOR 251B LY31902-001A FOCUS MOTOR 251C LY30727-002A SCREW,X5 251D LY30727-001A SCREW,X2 251F LY31900-001A SPACER RUBBER 251G QYSPSGU1750Z SCREW,X2 251H LY31903-001A IRIS MOTOR UNIT 251J LYH40136-001A CCD BASE ASSY

5-5

5.3 MECHANISM ASSEMBLY <M3>

400

401

402

430

463

446

406

463

462

406

404

405

432

403

465

463

407

464

433

445

444

459

458

410

408

413

414

422

425

427

426

436

436B

437

431

453

455

453

436A

434

454

452

424

429

428

437

435

449

440

438

409

412

413

411

419

423

418

421

420

402

443

439

442

450

441

456

466

402

415

416

417

421

451

461

448

447

5-6

457

Classification Part No. Symbol in drawing

Grease KYODO-SH-P AA

Oil YTU94027 BB

Grease (HANARL)

RX-410R CC

460

NOTE:The section marked in AA and BB, CC indicate

lubrication and greasing areas.

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

******************************

MECHANISM ASSEMBLY <M3>

400 YMA0029A MECHA(A) ASSY 401 LY31543-002B CASSETTE HOUSING ASSY 402 YQ43893-8 MINI SCREW,X3 403 LY31542-001D U.BASE ASSY 404 YQ43893 MINI SCREW 405 YDV2096A DRUM ASSY 406 LY42820-001A DAMP.SCREW ASSY,X2 407 LY42820-002A DAMP.SCREW ASSY 408 LY31538-001B REEL DISK ASSY 409 LY31538-002B REEL DISK ASSY 410 YQ44246 SLIT WASHER,X2 411 LY10217-001A REEL COVER ASSY 412 LY42120-001A MINI SCREW 413 LY41945-003A MINI SCREW,X2 414 YQ44246 SLIT WASHER,X2 415 LY42025-001A TEN.ARM ASSY 416 LY31535-001A S.POLE ARM ASSY 417 LY42031-001C TU ARM ASSY 418 LY31531-001A SWING ARM ASSY 419 YQ43893 MINI SCREW 420 LY20530-001A SLIDE DECK F.ASSY 421 YQ43893 MINI SCREW,X2 422 LY43023-001A MINI SCREW 423 YQ44246 SLIT WASHER 424 LY31533-001C PAD ARM ASSY 425 YQ44246 SLIT WASHER 426 LY42014-001A SUP BRAKE ASSY 427 YQ43893 MINI SCREW 428 LY42016-001A TU BRAKE ASSY 429 YQ44246 SLIT WASHER 430 LY41959-001A T.C.LEVER ASSY 431 LY31525-001A CENTER GEAR 432 LY31516-001B P.R.ARM F.ASSY 433 YQ44246 SLIT WASHER 434 LY41956-001A T.C.PLATE ASSY 435 LY41962-001A B.C.LEVER ASSY 436 LY20525-001C MOTOR BRACKET ASSY 436A QAR0138-001 LOADING MOTOR 436B LY41940-001A TAPPING SCREW,X2 437 YQ43893 MINI SCREW,X3 438 LY20528-001B GUIDE RAIL ASSY 439 YQ43893 MINI SCREW 440 YQ44246 SLIT WASHER,X2 441 LY31498-002A SLIDE LEVER2 ASSY 442 LY41965-001A LOAD.PLATE ASSY 443 YQ44246 SLIT WASHER 444 LY31522-001A EJECT LEVER 445 YQ44246 SLIT WASHER 446 LY41929-001A BASE R ASSY 447 YQ43893 MINI SCREW 448 LY41945-001A MINI SCREW 449 LY41930-001A MODE GEAR 450 QSW0876-001 ROTARY ENCODER 451 YQ43893 MINI SCREW,X2 452 LY31524-001A GEAR COVER ASSY 453 YQ43893 MINI SCREW,X2 454 YQ43893-4 MINI SCREW 455 LY41948-001A MAIN CAM ASSY 456 LY41941-001A SLIDE ARM ASSY

457 LY41951-001A CONNECT GEAR 2 458 LY41954-001A SUB CAM ASSY 459 LY42120-001A MINI SCREW 460 LY41952-001A CONTROL ARM ASSY 461 LY31523-001A REEL GEAR 1 462 LY31508-001B DRUM BASE ASSY 463 QYSPSPU1425M SCREW,X3 464 QAR0142-001 CAPSTAN MOTOR 465 YQ43893 MINI SCREW 466 LY10210-001A MAIN DECK ASSY

5-7

5.4 ELECTRONIC VIEWFINDER ASSEMBLY <M4>

300

311

310

305

302

312

308

312

306

304C

303

304

308

307

304A

304B

304D

301

314

309

304E

313

304E

313

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

ELECTRONIC VIEWFINDER ASSEMBLY <M4>

300 LY20671-002C VF UNIT 301 PTY20671-001 EYE CAP 302 PTY20671-011 BRACKET(VF)ASSY 303 PTY20671-021 UPPER CASE ASSY 304 PTY20671-031 BOTTOM CASE ASSY 304A PTY20671-032 LINK(VF) 304B PTY20671-033 WAVE WASHER 304C PTY20671-034 CAP 304D PTY20671-035 COVER(CAP)

304E PTY30018-0C8A SCREW,X2 304F PTY20671-037 LEVER(VF) 304G LY30018-063A SCREW 305 LY32070-001B VF FPC ASSY 306 PTY20671-041 LCD UNIT 307 PTY20671-051 LENS ASSY 308 PTY20671-061 RIB,X2 309 LY30018-084A SCREW,X2 310 LY30018-031A SCREW,X2 311 LY30018-006B SCREW,X2 312 LY30018-067B SCREW,X2 313 LY30018-084A SCREW,X2 314 LY30019-034A SCREW,X2

304F

304G

5-8

5.5 MONITOR ASSEMBLY <M5>

500

512

509

501

516

512

514

501H

MONITOR

<06>

501J

513

501F

501E

501A

501B

513

501G

501C

501D

501E

506

515

504

503

517

510

508

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------

******************************

MONITOR ASSEMBLY <M5>

507

502B

502D

502

505

502C

502A

511

502C LY30029-0F1A SPACER(A) 502D LY30029-0F2A SPACER(A) 503 QLD0115-003 LCD MODULE 504 QLL0091-001 BACK LIGHT

500 LYH20192-002A MONITOR ASSY

501 LY32013-002B MONITOR COVER ASSY 501A LY42883-002A MARK 501B LY42798-001A MARK 501C LY32014-001A KNOB(LOCK) 501D LY42799-001A BRACKET(LOCK) 501E LY30018-019A SPECIAL SCREW,X2 501F LY30002-047A COMPRESSION SPRING 501G LY42800-001A SHEET(LOCK) 501H LY42980-001A STICKER(2) 501J LY42979-001A STICKER(1) 502 LY32015-001C MONITOR CASE ASSY 502A LY42801-001B SHEET(EARTH.1)

505 LY32016-001A BRACKET(MONITOR CASE) 506 LY30029-0C4A SPACER(A) 507 LY32017-001C HINGE ASSY 508 LY32018-001A HINGE COVER(U) 509 LY32019-001A HINGE COVER(L) 510 LY42355-001A MAGNET 511 LY30018-053A SPECIAL SCREW 512 LY30018-0A2A SPECIAL SCREW,X2 513 LY30018-053A SPECIAL SCREW,X2 514 LY30018-028A SPECIAL SCREW,X2 515 LY42843-001C MONITOR SHIELD PLATE 516 LY41726-001A PLATE(EARTH) 517 LY20681-001A FPC ASSY(LCD)

502B LY42971-001A SHEET(EARTH3)

5-9

5.6 ELECTRICAL PARTS LIST

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

******************************

MAIN BOARD ASSEMBLY <01>

PW YB10301B-03 MAIN BOARD ASSY IC1001 YQ44899A CSP IC ASSY IC1002 RS5C314 IC IC1003 X25330S8I-2.5-X IC

or 25LC320-I/SN-X IC

or AT25320N-10SI-X IC IC1004 TC7W08FU IC(DIGITAL) IC1005 TC7W66FU IC(DIGITAL) IC1006 TC7W53FU IC(DIGITAL)

or SN74AHC2G53T IC IC1007 MB90097PFV139 IC(MICRO C ROM) IC1008 TC74VHC08FT IC(DIGITAL) IC1201 BA6417F IC IC1301 TC7SH32FU IC(DIGITAL) IC1302 TC7S02FU IC(DIGITAL) IC1401 YQ44896A CSP IC ASSY IC1403 TC7W53FU IC(DIGITAL)

or SN74AHC2G53T IC IC3001 JCY0133 IC IC3002 JCY0136 IC IC3302 TLC2940IPW IC IC3701 NJM2538V IC IC3702 MM1385HN IC IC3901 JCP8029 IC IC3903 SN74AHC1G04K IC

or TC7S04FU IC(DIGITAL) IC3951 MM1504XN IC IC4201 HD49325BHF IC IC4202 RH5RZ31CA IC IC4301 YQ44871A CSP ASSY IC4302 MM1385NN IC IC4401 BU2501FV IC IC4802 TA75W01FU IC IC4803 TA75W01FU IC IC4804 NJM3414AV IC IC4805 MM6564XFBE IC IC4806 TC7W00FK IC IC4807 TC7W66FK IC IC4808 TC7S66FU IC(DIGITAL) IC4851 UPD16879GS IC IC4901 TA75W01FU IC IC4902 TA75W01FU IC IC4903 MM6564XFBE IC IC4904 NJM3414AV IC IC5001 JCY0138 IC IC5002 MM1385DN IC IC5004 W194-70G-X IC IC6001 S-80842ANNP-W IC IC6002 S-817A33ANB-W IC IC6003 S-814A30AMC-W IC IC6004 S-80826ANNP-W IC Q1001 DTC143EE TRANSISTOR

or RN1101 TRANSISTOR

or UN921LJ TRANSISTOR Q1002 2SC4617/QR/-X TRANSISTOR Q1003 DTC124EE TRANSISTOR

or RN1103 TRANSISTOR

or UN9212J TRANSISTOR Q1301 2SC4617/RS/-X TRANSISTOR

Q1401 DTA114EE TRANSISTOR

or RN2102 TRANSISTOR

or UN9111J TRANSISTOR Q1402 UMC3N TRANSISTOR Q1403 UMC3N TRANSISTOR Q1404 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q2001 NDS352AP MOS FET Q2002 2SK1830 MOS FET Q3701 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q3702 2SC4617/RS/-X TRANSISTOR Q3951 UMZ1N PAIR TRANSISTOR Q3952 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q3953 UMZ1N PAIR TRANSISTOR Q3954 2SC4617/RS/-X TRANSISTOR Q4351 2SA1832FT/G/-X TRANSISTOR Q4352 UMT2N PAIR TRANSISTOR Q4353 UMT2N PAIR TRANSISTOR Q4354 2SA1832FT/G/-X TRANSISTOR Q4801 2SC4655/BC/-X TRANSISTOR Q4802 2SC4617/RS/-X TRANSISTOR Q4803 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q4804 DTA144EE TRANSISTOR

or RN2104 TRANSISTOR

or UN9113J TRANSISTOR Q4851 2SC4617/RS/-X TRANSISTOR Q4901 2SC4655/BC/-X TRANSISTOR Q6001 CPH3304 MOS FET Q6002 2SK3019 MOS FET

or 2SK1830 MOS FET Q6003 2SJ347 MOS FET Q6004 2SK3019 MOS FET

or 2SK1830 MOS FET Q6005 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q6006 CPH3304 MOS FET Q6007 RN47A3 TRANSISTOR D1002 DA221 DIODE D1201 DAP222 DIODE D1301 RB715F SB DIODE D2001 EMZ6.8N ZENER DIODE D2002 EMZ6.8N ZENER DIODE D2003 EMZ6.8N ZENER DIODE D2004 EMZ6.8N ZENER DIODE D2005 SBS006 SB DIODE D3002 EC2C01C VARI CAP DIODE D3301 EC2C01C VARI CAP DIODE D3302 EC2C01C VARI CAP DIODE D4101 1SS355 DIODE D4801 DAN222 DIODE D4802 DAN222 DIODE D4803 DAN222 DIODE

! D6001 RB706D-40-X SB DIODE

D6002 RB715F SB DIODE

5-10

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R1001 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1002 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1003 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1004 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1005 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1006 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1007 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1008 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1009 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R1010 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R1011 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1012 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1013 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1014 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1015 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1016 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1017 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1018 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1019 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1020 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1021 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1023 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1024 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1025 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1026 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1027 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1028 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1029 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1030 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1031 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1032 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1033 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1034 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R1035 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R1036 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R1037 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R1038 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1040 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1041 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1042 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1043 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1044 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1045 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1046 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1047 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1048 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1049 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1050 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1051 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1053 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1054 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1055 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1056 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1066 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1067 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1068 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1069 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1070 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1071 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1072 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R1073 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R1074 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1075 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W

R1076 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1077 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1078 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1079 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1080 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1081 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R1082 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R1083 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1084 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1085 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R1086 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R1087 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1088 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1089 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1090 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1091 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1092 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1093 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1094 NRSA6AJ-154W MG RESISTOR 150kØ,1/16W R1095 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R1096 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R1097 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1098 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1099 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1100 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1102 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1103 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1105 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1110 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1111 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1112 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1113 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1114 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1115 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1116 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1117 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1201 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1202 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R1301 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1303 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1401 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1402 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1403 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1404 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1408 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1409 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1410 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1411 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1412 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R1414 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1415 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1416 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1417 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1418 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R1419 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R1420 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R1422 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1423 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1424 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1425 NRVA6AD-753W CMF RESISTOR 75kØ,1/16W R1426 NRSA6AJ-334W MG RESISTOR 330kØ,1/16W R1429 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1430 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W

5-11

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R1437 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1438 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1439 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1440 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1441 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1442 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R1443 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1444 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1445 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R2001 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2002 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2003 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2005 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2007 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2008 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2009 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2010 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2011 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2012 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2013 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2014 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2015 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2017 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2018 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2019 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2020 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3001 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R3002 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R3003 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R3004 NRSA6AJ-562W MG RESISTOR 5.6kØ,1/16W R3005 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3006 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3007 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R3008 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3009 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3015 NRSA6AJ-242W MG RESISTOR 2.4kØ,1/16W R3016 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R3017 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R3018 NRVA6AD-560W CMF RESISTOR 56Ø,1/16W R3019 NRVA6AD-560W CMF RESISTOR 56Ø,1/16W R3020 NRVA6AD-560W CMF RESISTOR 56Ø,1/16W R3021 NRVA6AD-560W CMF RESISTOR 56Ø,1/16W R3022 NRVA6AD-512W CMF RESISTOR 5.1kØ,1/16W R3023 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3024 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3025 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3026 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3027 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3029 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W R3030 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R3034 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3044 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3051 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3052 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3053 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3054 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3055 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3059 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3060 NRSA6AJ-272W MG RESISTOR 2.7kØ,1/16W R3061 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3062 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3063 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3064 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W

R3311 NRVA6AD-222W CMF RESISTOR 2.2kØ,1/16W R3313 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R3314 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3315 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3318 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R3319 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R3331 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3332 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3333 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3334 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3335 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3336 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3337 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3338 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R3339 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3340 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3341 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3701 NRSA6AJ-225W MG RESISTOR 2.2MØ,1/16W R3702 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3703 NRSA6AJ-203W MG RESISTOR 20kØ,1/16W R3704 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3706 NRSA6AJ-121W MG RESISTOR 120Ø,1/16W R3707 NRSA6AJ-121W MG RESISTOR 120Ø,1/16W R3708 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3709 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R3710 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R3712 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3713 NRSA6AJ-680W MG RESISTOR 68Ø,1/16W R3714 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R3715 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R3716 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R3901 NRVA6AD-821W CMF RESISTOR 820Ø,1/16W R3902 NRVA6AD-273W CMF RESISTOR 27kØ,1/16W R3903 NRVA6AD-153W CMF RESISTOR 15kØ,1/16W R3904 NRVA6AD-821W CMF RESISTOR 820Ø,1/16W R3951 NRVA6AD-561W CMF RESISTOR 560Ø,1/16W R3953 NRVA6AD-152W CMF RESISTOR 1.5kØ,1/16W R3954 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R3955 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3956 NRSA6AJ-474W MG RESISTOR 470kØ,1/16W R3961 NRVA6AD-561W CMF RESISTOR 560Ø,1/16W R3962 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R3963 NRVA6AD-182W CMF RESISTOR 1.8kØ,1/16W R3964 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R3965 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R3966 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R3967 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R3968 NRSA6AJ-821W MG RESISTOR 820Ø,1/16W R3969 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4101 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4203 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4204 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R4211 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4212 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4213 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4214 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4215 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4216 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4217 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4218 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4219 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4220 NRSA6AJ-221W MG RESISTOR 220Ø,1/16W R4302 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W

5-12

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R4303 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4304 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4305 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4306 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4307 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4308 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4313 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4314 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4315 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4316 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4317 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4318 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R4320 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4321 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4322 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4323 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4328 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4329 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4330 NRSA6AJ-470W MG RESISTOR 47Ø,1/16W R4331 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4332 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4333 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4334 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4335 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4337 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R4342 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4343 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4344 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4345 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4346 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4347 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4348 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4349 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R4356 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R4358 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R4360 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R4362 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R4363 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4364 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4365 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4367 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4369 NRVA6AD-201W CMF RESISTOR 200Ø,1/16W R4370 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4371 NRVA6AD-201W CMF RESISTOR 200Ø,1/16W R4372 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4373 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4374 NRVA6AD-201W CMF RESISTOR 200Ø,1/16W R4375 NRVA6AD-271W CMF RESISTOR 270Ø,1/16W R4376 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4378 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R4379 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R4383 NRVA6AD-271W CMF RESISTOR 270Ø,1/16W R4386 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4387 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4388 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4389 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4390 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4805 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4806 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R4807 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R4808 NRSA6AJ-243W MG RESISTOR 24kØ,1/16W R4809 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W R4810 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W

R4811 NRSA6AJ-684W MG RESISTOR 680kØ,1/16W R4812 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4814 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R4815 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4816 NRSA6AJ-185W MG RESISTOR 1.8MØ,1/16W R4819 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4820 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4821 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4822 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4823 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4824 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4825 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R4826 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4828 NRSA6AJ-122W MG RESISTOR 1.2kØ,1/16W R4829 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4831 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4832 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4833 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4834 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4835 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4836 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R4837 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4838 NRSA6AJ-470W MG RESISTOR 47Ø,1/16W R4839 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4840 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4841 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R4844 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4846 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4854 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4856 NRSA6AJ-6R8W MG RESISTOR 6.8Ø,1/16W R4857 NRSA6AJ-6R8W MG RESISTOR 6.8Ø,1/16W R4858 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4859 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4860 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4862 NRSA6AJ-6R8W MG RESISTOR 6.8Ø,1/16W R4863 NRSA6AJ-6R8W MG RESISTOR 6.8Ø,1/16W R4864 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4865 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4866 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4867 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4868 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4870 NRSA6AJ-271W MG RESISTOR 270Ø,1/16W R4871 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4874 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R4901 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4902 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W R4903 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R4904 NRSA6AJ-243W MG RESISTOR 24kØ,1/16W R4905 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4906 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W R4907 NRSA6AJ-684W MG RESISTOR 680kØ,1/16W R4908 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R4909 NRSA6AJ-185W MG RESISTOR 1.8MØ,1/16W R4910 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R4911 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4912 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4913 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4914 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4915 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R4916 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R4917 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R4918 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R4919 NRSA6AJ-122W MG RESISTOR 1.2kØ,1/16W

5-13

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R4920 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R4921 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R4922 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4923 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R4924 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R4926 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R5002 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5003 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5004 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5005 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5006 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5007 NRVA6AD-100W CMF RESISTOR 10Ø,1/16W R5011 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5013 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5016 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5017 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5018 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5021 NRVA6AD-101W CMF RESISTOR 100Ø,1/16W R5022 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R5023 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5024 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R5025 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5026 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5027 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5028 NRSA6AJ-330W MG RESISTOR 33Ø,1/16W R5029 NRSA6AJ-220W MG RESISTOR 22Ø,1/16W R6001 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6002 NRVA6AD-183W CMF RESISTOR 18kØ,1/16W R6003 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6004 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R6005 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R6006 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6007 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6009 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6010 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6011 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6012 NRVA6AD-823W CMF RESISTOR 82kØ,1/16W R6013 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W

R6017 NRSA63J-102X MG RESISTOR 1kØ,1/16W R6018 NRSA63J-471X MG RESISTOR 470Ø,1/16W RA1001 NRZ0034-102W NETWORK RESISTOR 1kØ RA1002 NRZ0034-102W NETWORK RESISTOR 1kØ RA1003 NRZ0034-102W NETWORK RESISTOR 1kØ RA1004 NRZ0034-102W NETWORK RESISTOR 1kØ RA1005 NRZ0034-102W NETWORK RESISTOR 1kØ RA1006 NRZ0034-104W NETWORK RESISTOR 100kØ RA1007 NRZ0034-104W NETWORK RESISTOR 100kØ RA1401 NRZ0034-473W NETWORK RESISTOR 47kØ RA1402 NRZ0034-102W NETWORK RESISTOR 1kØ RA1403 NRZ0034-102W NETWORK RESISTOR 1kØ RA4301 NRZ0034-221W NETWORK RESISTOR 220Ø RA4302 NRZ0034-221W NETWORK RESISTOR 220Ø RA4303 NRZ0034-221W NETWORK RESISTOR 220Ø RA4304 NRZ0034-221W NETWORK RESISTOR 220Ø RA4305 NRZ0034-221W NETWORK RESISTOR 220Ø RA4306 NRZ0034-221W NETWORK RESISTOR 220Ø RA4307 NRZ0034-221W NETWORK RESISTOR 220Ø RA4308 NRZ0034-221W NETWORK RESISTOR 220Ø C1001 NBE90JM-106X T CAPACITOR 10µF,6.3V C1002 NCBA1AK-104W CAPACITOR 0.1µF,10V C1003 NBE90JM-106X T CAPACITOR 10µF,6.3V C1004 NCBA1AK-104W CAPACITOR 0.1µF,10V C1005 NBE90JM-106X T CAPACITOR 10µF,6.3V

C1006 NCBA1AK-104W CAPACITOR 0.1µF,10V C1007 NCBA1CK-103W CAPACITOR 0.01µF,16V C1008 NCBA1CK-103W CAPACITOR 0.01µF,16V C1009 NDCA1HJ-130W CAPACITOR 13pF,50V C1010 NCBA1CK-103W CAPACITOR 0.01µF,16V C1011 NCBA1AK-104W CAPACITOR 0.1µF,10V C1012 NCBA1CK-103W CAPACITOR 0.01µF,16V C1013 NCBA1CK-103W CAPACITOR 0.01µF,16V C1014 NCBA1CK-103W CAPACITOR 0.01µF,16V C1015 NCBA1CK-103W CAPACITOR 0.01µF,16V C1016 NCBA1CK-103W CAPACITOR 0.01µF,16V C1017 NCBA1CK-103W CAPACITOR 0.01µF,16V C1018 NCBA1CK-103W CAPACITOR 0.01µF,16V C1019 NCBA1CK-103W CAPACITOR 0.01µF,16V C1020 NCBA1CK-103W CAPACITOR 0.01µF,16V C1021 NCBA1AK-104W CAPACITOR 0.1µF,10V C1025 NCBA1AK-104W CAPACITOR 0.1µF,10V C1026 NCBA1CK-103W CAPACITOR 0.01µF,16V C1027 NCBA1CK-103W CAPACITOR 0.01µF,16V C1028 NCBA1CK-103W CAPACITOR 0.01µF,16V C1029 NCBA1CK-103W CAPACITOR 0.01µF,16V C1030 NCBA1AK-104W CAPACITOR 0.1µF,10V C1031 NCBA1CK-103W CAPACITOR 0.01µF,16V C1032 NCB30JK-105X CAPACITOR 1µF,6.3V C1201 NCBA1AK-104W CAPACITOR 0.1µF,10V C1202 NCBA1AK-104W CAPACITOR 0.1µF,10V C1204 NCB21AK-105X CAPACITOR 1µF,10V C1302 NCBA1CK-103W CAPACITOR 0.01µF,16V C1401 NBE90JM-106X T CAPACITOR 10µF,6.3V C1402 NBE90JM-106X T CAPACITOR 10µF,6.3V C1405 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1406 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1408 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1409 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1410 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1411 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1412 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1413 NCFA1AZ-104W CAPACITOR 0.1µF,10V C1414 NCBA1CK-103W CAPACITOR 0.01µF,16V C1415 NCBA1CK-103W CAPACITOR 0.01µF,16V C1416 NCBA1CK-103W CAPACITOR 0.01µF,16V C1417 NCBA1CK-223W CAPACITOR 0.022µF,16V C1418 NCBA1CK-223W CAPACITOR 0.022µF,16V C1419 NCBA1CK-223W CAPACITOR 0.022µF,16V C1420 NCBA1CK-223W CAPACITOR 0.022µF,16V C2003 NCBA1CK-103W CAPACITOR 0.01µF,16V C2004 NCBA1CK-103W CAPACITOR 0.01µF,16V C2005 NCBA1HK-102W CAPACITOR 0.001µF,50V C2006 NCBA1CK-103W CAPACITOR 0.01µF,16V C2007 NCBA1CK-103W CAPACITOR 0.01µF,16V C2008 NCBA1CK-103W CAPACITOR 0.01µF,16V C2009 NCBA1CK-103W CAPACITOR 0.01µF,16V C2010 NCBA1CK-103W CAPACITOR 0.01µF,16V C2011 NCBA1CK-103W CAPACITOR 0.01µF,16V C2012 NCBA1HK-102W CAPACITOR 0.001µF,50V C2013 NCBA1HK-102W CAPACITOR 0.001µF,50V C2014 NCBA1HK-102W CAPACITOR 0.001µF,50V C2015 NCBA1HK-102W CAPACITOR 0.001µF,50V C2016 NCBA1HK-102W CAPACITOR 0.001µF,50V C2017 NCBA1CK-103W CAPACITOR 0.01µF,16V C2018 NCBA1CK-103W CAPACITOR 0.01µF,16V C2019 NCBA1CK-103W CAPACITOR 0.01µF,16V C2020 NCBA1CK-103W CAPACITOR 0.01µF,16V

5-14

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C2021 NCBA1CK-103W CAPACITOR 0.01µF,16V C2022 NCBA1CK-103W CAPACITOR 0.01µF,16V C2023 NCBA1CK-103W CAPACITOR 0.01µF,16V C2024 NCBA1CK-103W CAPACITOR 0.01µF,16V C2025 NCBA1CK-103W CAPACITOR 0.01µF,16V C2026 NCBA1CK-103W CAPACITOR 0.01µF,16V C2027 NCBA1CK-103W CAPACITOR 0.01µF,16V C2028 NCBA1CK-103W CAPACITOR 0.01µF,16V C2029 NCBA1CK-103W CAPACITOR 0.01µF,16V C2030 NCBA1CK-103W CAPACITOR 0.01µF,16V C2031 NCBA1CK-103W CAPACITOR 0.01µF,16V C2032 NCBA1CK-103W CAPACITOR 0.01µF,16V C2033 NCBA1CK-103W CAPACITOR 0.01µF,16V C2034 NCBA1CK-103W CAPACITOR 0.01µF,16V C2035 NCB11CK-105X CAPACITOR 1µF,16V C2036 NCBA1CK-103W CAPACITOR 0.01µF,16V C2037 NCBA1CK-103W CAPACITOR 0.01µF,16V C2038 NCBA1CK-103W CAPACITOR 0.01µF,16V C2039 NCBA1CK-103W CAPACITOR 0.01µF,16V C2040 NCBA1CK-103W CAPACITOR 0.01µF,16V C2041 NCBA1CK-103W CAPACITOR 0.01µF,16V C2042 NCBA1CK-103W CAPACITOR 0.01µF,16V C2043 NCBA1CK-103W CAPACITOR 0.01µF,16V C3002 NCBA1AK-104W CAPACITOR 0.1µF,10V C3005 NCBA1AK-104W CAPACITOR 0.1µF,10V C3006 NCBA1AK-104W CAPACITOR 0.1µF,10V C3008 NCBA1AK-104W CAPACITOR 0.1µF,10V C3009 NCBA1AK-104W CAPACITOR 0.1µF,10V C3010 NCBA1AK-104W CAPACITOR 0.1µF,10V C3012 NCBA1AK-104W CAPACITOR 0.1µF,10V C3014 NDCA1HJ-330W CAPACITOR 33pF,50V C3015 NCBA1HK-102W CAPACITOR 0.001µF,50V C3016 NCBA1AK-104W CAPACITOR 0.1µF,10V C3017 NCB30JK-105X CAPACITOR 1µF,6.3V C3018 NCBA1EK-472W CAPACITOR 0.0047µF,25V C3019 NDCA1EJ-271W CAPACITOR 270pF,25V C3021 NCBA1AK-104W CAPACITOR 0.1µF,10V C3022 NCBA1AK-104W CAPACITOR 0.1µF,10V C3023 NCBA1AK-104W CAPACITOR 0.1µF,10V C3024 NDCA1HJ-100W CAPACITOR 10pF,50V C3025 NDCA1HJ-100W CAPACITOR 10pF,50V C3026 NCBA1AK-104W CAPACITOR 0.1µF,10V C3027 NCBA1AK-104W CAPACITOR 0.1µF,10V C3028 NCBA1AK-104W CAPACITOR 0.1µF,10V C3029 NCBA1AK-104W CAPACITOR 0.1µF,10V C3030 NCBA1AK-104W CAPACITOR 0.1µF,10V C3031 NCBA1AK-104W CAPACITOR 0.1µF,10V C3032 NDCA1HJ-151W CAPACITOR 150pF,50V C3034 NCBA1AK-473W CAPACITOR 0.047µF,10V C3035 NCBA1AK-104W CAPACITOR 0.1µF,10V C3037 NCB30JK-105X CAPACITOR 1µF,6.3V C3038 NCBA1AK-104W CAPACITOR 0.1µF,10V C3039 NBE20JM-106X T CAPACITOR 10µF,6.3V C3040 NBE20JM-106X T CAPACITOR 10µF,6.3V C3041 NCBA1AK-104W CAPACITOR 0.1µF,10V C3042 NCB30JK-105X CAPACITOR 1µF,6.3V C3044 NBE20JM-106X T CAPACITOR 10µF,6.3V C3045 NCBA1AK-104W CAPACITOR 0.1µF,10V C3046 NCB30JK-105X CAPACITOR 1µF,6.3V C3048 NCBA1AK-104W CAPACITOR 0.1µF,10V C3052 NCBA1AK-104W CAPACITOR 0.1µF,10V C3053 NCBA1AK-104W CAPACITOR 0.1µF,10V C3318 NCBA1CK-103W CAPACITOR 0.01µF,16V

C3319 NCBA1CK-103W CAPACITOR 0.01µF,16V C3320 NCB21AK-105X CAPACITOR 1µF,10V C3325 NDCA1HJ-9R0W CAPACITOR 9pF,50V C3326 NDCA1HJ-9R0W CAPACITOR 9pF,50V C3328 NDCA1HJ-470W CAPACITOR 47pF,50V C3329 NCBA1HK-102W CAPACITOR 0.001µF,50V C3330 NCBA1AK-104W CAPACITOR 0.1µF,10V C3331 NCBA1HK-102W CAPACITOR 0.001µF,50V C3332 NDCA1HJ-390W CAPACITOR 39pF,50V C3701 NCBA1AK-104W CAPACITOR 0.1µF,10V C3702 NCBA1CK-103W CAPACITOR 0.01µF,16V C3703 NCBA1CK-103W CAPACITOR 0.01µF,16V C3704 NBE20JM-106X T CAPACITOR 10µF,6.3V C3707 NBE20GM-226X T CAPACITOR 22µF,4.0V C3708 NBE40GM-107X T CAPACITOR 100µF,4.0V C3709 NCBA1CK-103W CAPACITOR 0.01µF,16V C3710 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3711 NCFA1AZ-104W CAPACITOR 0.1µF,10V C3712 NCBA1CK-103W CAPACITOR 0.01µF,16V C3713 NCBA1CK-103W CAPACITOR 0.01µF,16V C3714 NBE20JM-106X T CAPACITOR 10µF,6.3V C3715 NCBA1CK-103W CAPACITOR 0.01µF,16V C3716 NCB30JK-105X CAPACITOR 1µF,6.3V C3721 NBE20JM-226X T CAPACITOR 22µF,6.3V C3722 NCF31AZ-105X CAPACITOR 1µF,10V C3723 NBE20JM-106X T CAPACITOR 10µF,6.3V C3724 NCBA1CK-103W CAPACITOR 0.01µF,16V C3901 NCBA1AK-104W CAPACITOR 0.1µF,10V C3902 NCBA1AK-104W CAPACITOR 0.1µF,10V C3903 NCBA1AK-104W CAPACITOR 0.1µF,10V C3904 NCBA1AK-104W CAPACITOR 0.1µF,10V C3905 NCBA1AK-104W CAPACITOR 0.1µF,10V C3906 NCBA1AK-104W CAPACITOR 0.1µF,10V C3907 NCBA1AK-104W CAPACITOR 0.1µF,10V C3908 NCBA1AK-104W CAPACITOR 0.1µF,10V C3909 NCBA1AK-104W CAPACITOR 0.1µF,10V C3910 NCBA1AK-104W CAPACITOR 0.1µF,10V C3911 NCBA1AK-104W CAPACITOR 0.1µF,10V C3912 NCBA1AK-104W CAPACITOR 0.1µF,10V C3913 NCBA1AK-104W CAPACITOR 0.1µF,10V C3914 NCBA1AK-104W CAPACITOR 0.1µF,10V C3916 NBE20JM-106X T CAPACITOR 10µF,6.3V C3917 NCBA1AK-104W CAPACITOR 0.1µF,10V C3919 NCB21CK-105X CAPACITOR 1µF,16V C3920 NCB21CK-105X CAPACITOR 1µF,16V C3951 NBE90JM-106X T CAPACITOR 10µF,6.3V C3952 NCB30JK-105X CAPACITOR 1µF,6.3V C3954 NCBA1AK-104W CAPACITOR 0.1µF,10V C3955 NDCA1HJ-3R0W CAPACITOR 3pF,50V C3956 NDCA1HJ-5R0W CAPACITOR 5pF,50V C3957 NDCA1HJ-330W CAPACITOR 33pF,50V C3958 NCB20JM-475X CAPACITOR 4.7µF,6.3V C3959 NCBA1CK-103W CAPACITOR 0.01µF,16V C3961 NCBA1HK-102W CAPACITOR 0.001µF,50V C3962 NDCA1HJ-3R0W CAPACITOR 3pF,50V C3963 NDCA1HJ-5R0W CAPACITOR 5pF,50V C3964 NDCA1HJ-330W CAPACITOR 33pF,50V C3965 NCBA1HK-102W CAPACITOR 0.001µF,50V C3967 NCBA1CK-103W CAPACITOR 0.01µF,16V C3968 NCBA1CK-103W CAPACITOR 0.01µF,16V C4101 NCF31EZ-104X CAPACITOR 0.1µF,25V C4102 NBP41EM-475X T CAPACITOR 4.7µF,25V C4103 NCF31EZ-104X CAPACITOR 0.1µF,25V

5-15

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C4104 NCBA1AK-104W CAPACITOR 0.1µF,10V C4105 NBE41AM-476X T CAPACITOR 47µF,10V C4106 NCBA1AK-104W CAPACITOR 0.1µF,10V C4107 NCBA1AK-104W CAPACITOR 0.1µF,10V C4108 NBP21VM-105X T CAPACITOR 1µF,35V C4109 NCF31EZ-104X CAPACITOR 0.1µF,25V C4201 NBE40JM-476X T CAPACITOR 47µF,6.3V C4202 NBE20GM-476X T CAPACITOR 47µF,4.0V C4203 NCBA1CK-103W CAPACITOR 0.01µF,16V C4204 NCBA1AK-104W CAPACITOR 0.1µF,10V C4205 NBE20GM-476X T CAPACITOR 47µF,4.0V C4207 NBE90JM-106X T CAPACITOR 10µF,6.3V C4208 NCBA1AK-104W CAPACITOR 0.1µF,10V C4209 NCBA1AK-104W CAPACITOR 0.1µF,10V C4210 NCB30JK-105X CAPACITOR 1µF,6.3V C4211 NCB30JK-105X CAPACITOR 1µF,6.3V C4212 NCBA1CK-123W CAPACITOR 0.012µF,16V C4213 NCB30JK-105X CAPACITOR 1µF,6.3V C4214 NCBA1AK-104W CAPACITOR 0.1µF,10V C4215 NCB30JK-105X CAPACITOR 1µF,6.3V C4216 NCB30JK-105X CAPACITOR 1µF,6.3V C4217 NCB30JK-105X CAPACITOR 1µF,6.3V C4218 NCBA1AK-104W CAPACITOR 0.1µF,10V C4219 NCBA1AK-104W CAPACITOR 0.1µF,10V C4220 NCBA1AK-104W CAPACITOR 0.1µF,10V C4221 NCBA1CK-103W CAPACITOR 0.01µF,16V C4222 NCBA1CK-103W CAPACITOR 0.01µF,16V C4223 NCBA1CK-103W CAPACITOR 0.01µF,16V C4224 NCBA1CK-103W CAPACITOR 0.01µF,16V C4225 NCBA1CK-103W CAPACITOR 0.01µF,16V C4226 NCBA1CK-103W CAPACITOR 0.01µF,16V C4301 NCB30JK-105X CAPACITOR 1µF,6.3V C4302 NBE90JM-106X T CAPACITOR 10µF,6.3V C4303 NCBA1AK-104W CAPACITOR 0.1µF,10V C4304 NBE90JM-106X T CAPACITOR 10µF,6.3V C4306 NCB30JK-105X CAPACITOR 1µF,6.3V C4307 NBE90JM-106X T CAPACITOR 10µF,6.3V C4308 NCBA1AK-104W CAPACITOR 0.1µF,10V C4309 NCBA1AK-104W CAPACITOR 0.1µF,10V C4310 NBG40GM-226X T CAPACITOR 22µF,4.0V C4312 NCBA1AK-104W CAPACITOR 0.1µF,10V C4313 NCBA1AK-104W CAPACITOR 0.1µF,10V C4315 NCBA1AK-104W CAPACITOR 0.1µF,10V C4316 NCBA1AK-104W CAPACITOR 0.1µF,10V C4317 NCBA1AK-104W CAPACITOR 0.1µF,10V C4318 NCBA1AK-104W CAPACITOR 0.1µF,10V C4319 NCBA1AK-104W CAPACITOR 0.1µF,10V C4320 NCBA1AK-104W CAPACITOR 0.1µF,10V C4321 NCBA1AK-104W CAPACITOR 0.1µF,10V C4322 NCBA1AK-104W CAPACITOR 0.1µF,10V C4323 NBE90JM-106X T CAPACITOR 10µF,6.3V C4351 NCBA1AK-104W CAPACITOR 0.1µF,10V C4352 NCBA1AK-104W CAPACITOR 0.1µF,10V C4353 NCB30JK-105X CAPACITOR 1µF,6.3V C4355 NCB30JK-105X CAPACITOR 1µF,6.3V C4357 NCB30JK-105X CAPACITOR 1µF,6.3V C4359 NCB30JK-105X CAPACITOR 1µF,6.3V C4361 NCBA1AK-104W CAPACITOR 0.1µF,10V C4362 NCBA1AK-104W CAPACITOR 0.1µF,10V C4363 NCBA1AK-104W CAPACITOR 0.1µF,10V C4364 NCBA1AK-104W CAPACITOR 0.1µF,10V C4365 NBE90JM-106X T CAPACITOR 10µF,6.3V C4401 NBE90GM-226X T CAPACITOR 22µF,4.0V

C4402 NCBA1CK-103W CAPACITOR 0.01µF,16V C4801 NBE21AM-106X T CAPACITOR 10µF,10V C4802 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4803 NBE90JM-106X T CAPACITOR 10µF,6.3V C4804 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4805 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4806 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4808 NCB30JK-105X CAPACITOR 1µF,6.3V C4809 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4810 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4811 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4812 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4813 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4814 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4818 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4819 NCB30JK-105X CAPACITOR 1µF,6.3V C4820 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4821 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4851 NBE90JM-106X T CAPACITOR 10µF,6.3V C4852 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4853 NBE91AM-335X T CAPACITOR 3.3µF,10V C4854 NBE21AM-106X T CAPACITOR 10µF,10V C4855 NCB31CK-104X CAPACITOR 0.1µF,16V C4858 NDCA1HJ-330W CAPACITOR 33pF,50V C4859 NCBA1HK-102W CAPACITOR 0.001µF,50V C4860 NCBA1HK-102W CAPACITOR 0.001µF,50V C4861 NCBA1HK-102W CAPACITOR 0.001µF,50V C4862 NCBA1HK-102W CAPACITOR 0.001µF,50V C4863 NCBA1AK-104W CAPACITOR 0.1µF,10V C4864 NBE90JM-106X T CAPACITOR 10µF,6.3V C4865 NCBA1AK-104W CAPACITOR 0.1µF,10V C4901 NBE90JM-106X T CAPACITOR 10µF,6.3V C4902 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4903 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4906 NCB30JK-105X CAPACITOR 1µF,6.3V C4907 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4908 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4909 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4910 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4911 NCFA1HZ-103W CAPACITOR 0.01µF,50V C4912 NCBA1HK-102W CAPACITOR 0.001µF,50V C4913 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4914 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4915 NCBA1HK-331W CAPACITOR 330pF,50V C4917 NCBA1HK-331W CAPACITOR 330pF,50V C4919 NCB30JK-105X CAPACITOR 1µF,6.3V C4920 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4921 NCFA1AZ-104W CAPACITOR 0.1µF,10V C4922 NBE21AM-106X T CAPACITOR 10µF,10V C4923 NCFA1AZ-104W CAPACITOR 0.1µF,10V C5001 NCBA1AK-104W CAPACITOR 0.1µF,10V C5002 NCBA1AK-104W CAPACITOR 0.1µF,10V C5003 NBE40JM-476X T CAPACITOR 47µF,6.3V C5004 NCBA1AK-104W CAPACITOR 0.1µF,10V C5005 NCBA1AK-104W CAPACITOR 0.1µF,10V C5006 NCBA1AK-104W CAPACITOR 0.1µF,10V C5007 NCB30JK-105X CAPACITOR 1µF,6.3V C5008 NBE90JM-106X T CAPACITOR 10µF,6.3V C5009 NCBA1AK-104W CAPACITOR 0.1µF,10V C5011 NCBA1AK-104W CAPACITOR 0.1µF,10V C5012 NCBA1AK-104W CAPACITOR 0.1µF,10V C5013 NCBA1AK-104W CAPACITOR 0.1µF,10V C5014 NBM90JM-226X T CAPACITOR 22µF,6.3V

5-16

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C5017 NCBA1AK-104W CAPACITOR 0.1µF,10V C5018 NCB30JK-105X CAPACITOR 1µF,6.3V C5019 NCB30JK-105X CAPACITOR 1µF,6.3V C5221 NCF31EZ-104X CAPACITOR 0.1µF,25V C5222 NCBA1AK-104W CAPACITOR 0.1µF,10V C5223 NBP41EM-475X T CAPACITOR 4.7µF,25V C5224 NBE41AM-476X T CAPACITOR 47µF,10V C5225 NBE41AM-476X T CAPACITOR 47µF,10V C5227 NCF31EZ-104X CAPACITOR 0.1µF,25V C5228 NCBA1AK-104W CAPACITOR 0.1µF,10V C5230 NBE41AM-476X T CAPACITOR 47µF,10V C5231 NBE41AM-476X T CAPACITOR 47µF,10V C5232 NBE41AM-476X T CAPACITOR 47µF,10V C6001 NCBA1AK-104W CAPACITOR 0.1µF,10V C6002 NCBA1CK-103W CAPACITOR 0.01µF,16V C6003 NCBA1AK-104W CAPACITOR 0.1µF,10V C6004 NBE90JM-106X T CAPACITOR 10µF,6.3V C6005 NBP21CM-685X T CAPACITOR 6.8µF,16V C6006 NCF31AZ-105X CAPACITOR 1µF,10V C6007 NBE90JM-106X T CAPACITOR 10µF,6.3V C6008 NCBA1AK-104W CAPACITOR 0.1µF,10V C6009 NCBA1CK-103W CAPACITOR 0.01µF,16V L1001 NQR0265-001X FERRITE BEAD L1002 NQR0265-001X FERRITE BEAD L1003 NQR0265-001X FERRITE BEAD L1201 NQL315K-100X COIL 10µH L1401 NQR0006-001X FERRITE BEAD L1402 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W L2001 NQR0006-001X FERRITE BEAD L3001 NQR0006-001X FERRITE BEAD L3002 NQR0006-001X FERRITE BEAD L3003 NQR0006-001X FERRITE BEAD L3004 NQR0006-001X FERRITE BEAD L3005 NQR0006-001X FERRITE BEAD L3006 NQR0006-001X FERRITE BEAD L3009 NQL085J-2R2X COIL 2.2µH L3305 NQR0006-001X FERRITE BEAD L3312 NQL085J-120X COIL 12µH L3313 NQL085J-100X COIL 10µH L3701 NQL302N-100X COIL 10µH L3901 NQR0006-001X FERRITE BEAD L3902 NQR0305-001X FERRITE BEAD L3903 NQR0305-001X FERRITE BEAD L3951 NQL302N-100X COIL 10µH L3952 NQL085J-6R8X COIL 6.8µH L3953 NQL085J-6R8X COIL 6.8µH L4101 NQR0129-002X FERRITE BEAD L4102 NQL045K-100X COIL 10µH L4103 NQR0129-002X FERRITE BEAD L4104 NQL045K-100X COIL 10µH L4201 NQR0265-001X FERRITE BEAD L4202 NQL402M-100X COIL 10µH L4203 NQR0265-001X FERRITE BEAD L4301 NQR0265-001X FERRITE BEAD L4302 NQR0265-001X FERRITE BEAD L4303 NQR0265-001X FERRITE BEAD L4305 NQR0265-001X FERRITE BEAD L4306 NQR0129-002X FERRITE BEAD L4307 NQR0265-001X FERRITE BEAD L4351 NQL402M-100X COIL 10µH L4401 NQR0006-001X FERRITE BEAD L4801 NQL302N-100X COIL 10µH L4802 NQL302N-100X COIL 10µH

L4851 NQR0129-002X FERRITE BEAD L4852 NQL315K-100X COIL 10µH L4853 NQL315K-100X COIL 10µH L4901 NQL315K-100X COIL 10µH L4902 NQL315K-100X COIL 10µH L5001 NQR0129-002X FERRITE BEAD L5002 NQL045K-100X COIL 10µH L5003 NQR0129-002X FERRITE BEAD L5004 NQR0129-002X FERRITE BEAD L5005 NQR0129-002X FERRITE BEAD L5201 NQR0129-002X FERRITE BEAD L5202 NQR0129-002X FERRITE BEAD L5203 NQL045K-100X COIL 10µH L5204 NQL045K-100X COIL 10µH L5207 NQL402M-100X COIL 10µH L5208 NQL402M-100X COIL 10µH L6001 NQL402M-100X COIL 10µH X1001 NAX0450-001X C OSCILLATOR X1002 NAX0267-001X CRYSTAL RESONATOR X3002 NAX0206-001X CRYSTAL RESONATOR X3301 NAX0169-001X CRYSTAL RESONATOR X4301 NAX0332-001X CXO WR1 WJT0040-001A E-CARD WIRE,CN113-EJECT CN2422 WR2 WJV0042-001A E-PRIMARY WIRE,TL2001-TL4202 J602 NNZ0041-001X D CONNECTOR CN101 QGA1002F1-02X CONNECTOR CN102 QGF0513F1-20X FPC CONNECTOR CN103 QGA1001F1-02X CONNECTOR CN104 QGF0301F1-39X FPC CONNECTOR CN105 QGB0403M1-C0X CONNECTOR CN106 QGB0404M1-80X CONNECTOR CN107 QGB0509M1-30X CONNECTOR CN108 QGB0512L2-50X CONNECTOR CN109 QGB0507L1-80X CONNECTOR CN110 QGF0517F2-22X FPC CONNECTOR CN111 QGF0517F2-24X FPC CONNECTOR CN112 QGB0402J1-80X CONNECTOR CN113 QGF0501F1-13X FPC CONNECTOR OT1 LY30029-0H1A SPACER(A) OT2 LY30016-0P9A SPACER-A

******************************

DSC BOARD ASSEMBLY <02>

PW YB10302B-01 DSC BOARD ASSY IC8001 JCY0121-4 IC IC8003 M32310D5WG IC IC8004 MBV800TA10PTA17 IC(MICRO C ROM)

or MBV800TA12PTA17 IC(MICRO C ROM) or MBV800TA90PTA17 IC(MICRO C ROM) or 39VF800A7CEKA02 IC(MICRO C ROM)

or 39VF800A9CEKA02 IC(MICRO C ROM) IC8006 MM1385NN IC IC8007 MM1385EN IC IC8008 TC7WHU04FU IC IC8009 TC7WH34FK IC IC8201 JCY0145-2 IC IC8202 MM1385GN IC IC8203 K4S643232C-TC70 IC

5-17

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

or K4S643232C-TC80 IC

IC8204 K4S641632D-TC1H IC

or K4S641632D-TC1L IC IC8401 ML60851CLB IC IC8402 S-80842ANNP-W IC Q8401 DTA114EE TRANSISTOR

or RN2101 TRANSISTOR

or UN9111J TRANSISTOR D8001 RB751V-40-X SB DIODE D8401 1SS355 DIODE R8002 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8004 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8006 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8007 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8008 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8011 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8012 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8013 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R8014 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8015 NRSA6AJ-133W MG RESISTOR 13kØ,1/16W R8017 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8020 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8021 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8022 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8023 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8024 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8025 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8026 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8027 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8028 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8029 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8030 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8031 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8032 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8033 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8034 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8035 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8036 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8037 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8038 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R8039 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8040 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R8041 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8042 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8043 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8044 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8045 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8046 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8047 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R8049 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8050 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8051 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R8052 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W R8053 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8054 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8055 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8056 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8057 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8058 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8059 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8060 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8061 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8062 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W

R8063 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8064 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8065 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8066 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8067 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8068 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8069 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8070 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8071 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8072 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8073 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R8074 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8075 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8076 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8077 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8078 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8079 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8080 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8081 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8082 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8083 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8084 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8086 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8087 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8221 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8222 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8223 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8224 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8225 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8226 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8227 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8228 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R8229 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R8230 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8231 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8235 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8238 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8239 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8248 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8249 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R8401 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R8402 NRS181J-220X MG RESISTOR 22Ø,1/8W R8403 NRS181J-220X MG RESISTOR 22Ø,1/8W R8404 NRSA6AJ-152W MG RESISTOR 1.5kØ,1/16W R8405 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R8406 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R8407 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W RA8001 NRZ0034-100W NETWORK RESISTOR 10Ø RA8002 NRZ0034-100W NETWORK RESISTOR 10Ø RA8003 NRZ0034-100W NETWORK RESISTOR 10Ø RA8004 NRZ0034-100W NETWORK RESISTOR 10Ø RA8201 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8202 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8203 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8204 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8222 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8223 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8224 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8225 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8401 NRZ0034-221W NETWORK RESISTOR 220Ø RA8402 NRZ0034-221W NETWORK RESISTOR 220Ø RA8403 NRZ0034-0R0W NETWORK RESISTOR 0Ø RA8404 NRZ0034-0R0W NETWORK RESISTOR 0Ø

5-18

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C8006 NCBA1AK-104W CAPACITOR 0.1µF,10V C8007 NBE90JM-106X T CAPACITOR 10µF,6.3V C8008 NCB30JK-105X CAPACITOR 1µF,6.3V C8009 NCBA1AK-104W CAPACITOR 0.1µF,10V C8010 NBE90JM-106X T CAPACITOR 10µF,6.3V C8011 NCB30JK-105X CAPACITOR 1µF,6.3V C8017 NCBA1AK-104W CAPACITOR 0.1µF,10V C8020 NBE90JM-106X T CAPACITOR 10µF,6.3V C8021 NCBA1CK-103W CAPACITOR 0.01µF,16V C8022 NCBA1CK-103W CAPACITOR 0.01µF,16V C8023 NCBA1CK-103W CAPACITOR 0.01µF,16V C8024 NCBA1CK-103W CAPACITOR 0.01µF,16V C8025 NCBA1CK-103W CAPACITOR 0.01µF,16V C8026 NCBA1CK-103W CAPACITOR 0.01µF,16V C8027 NCBA1CK-103W CAPACITOR 0.01µF,16V C8028 NCBA1CK-103W CAPACITOR 0.01µF,16V C8029 NCBA1CK-103W CAPACITOR 0.01µF,16V C8030 NCBA1CK-103W CAPACITOR 0.01µF,16V C8031 NCBA1CK-103W CAPACITOR 0.01µF,16V C8032 NCBA1CK-103W CAPACITOR 0.01µF,16V C8033 NCBA1CK-103W CAPACITOR 0.01µF,16V C8034 NCBA1CK-103W CAPACITOR 0.01µF,16V C8035 NCBA1CK-103W CAPACITOR 0.01µF,16V C8036 NCBA1CK-103W CAPACITOR 0.01µF,16V C8037 NCBA1CK-103W CAPACITOR 0.01µF,16V C8038 NCBA1CK-103W CAPACITOR 0.01µF,16V C8039 NCBA1CK-103W CAPACITOR 0.01µF,16V C8040 NCBA1CK-103W CAPACITOR 0.01µF,16V C8041 NCBA1CK-103W CAPACITOR 0.01µF,16V C8042 NCBA1CK-103W CAPACITOR 0.01µF,16V C8043 NCBA1CK-103W CAPACITOR 0.01µF,16V C8044 NBE80GM-226X T CAPACITOR 22µF,4.0V C8045 NBE80GM-226X T CAPACITOR 22µF,4.0V C8046 NBE90JM-106X T CAPACITOR 10µF,6.3V C8048 NBE80GM-226X T CAPACITOR 22µF,4.0V C8049 NCBA1CK-103W CAPACITOR 0.01µF,16V C8050 NCBA1CK-103W CAPACITOR 0.01µF,16V C8051 NBE80GM-226X T CAPACITOR 22µF,4.0V C8052 NCBA1CK-103W CAPACITOR 0.01µF,16V C8054 NCB31HK-392X CAPACITOR 0.0039µF,50V C8056 NCBA1CK-103W CAPACITOR 0.01µF,16V C8057 NCBA1CK-103W CAPACITOR 0.01µF,16V C8058 NCBA1AK-104W CAPACITOR 0.1µF,10V C8059 NCBA1CK-103W CAPACITOR 0.01µF,16V C8060 NCBA1CK-103W CAPACITOR 0.01µF,16V C8062 NCB30JK-105X CAPACITOR 1µF,6.3V C8063 NBE80GM-226X T CAPACITOR 22µF,4.0V C8064 NBE80GM-226X T CAPACITOR 22µF,4.0V C8065 NBE80GM-226X T CAPACITOR 22µF,4.0V C8201 NCBA1AK-104W CAPACITOR 0.1µF,10V C8202 NBE90JM-106X T CAPACITOR 10µF,6.3V C8203 NCBA1AK-104W CAPACITOR 0.1µF,10V C8204 NBE90JM-106X T CAPACITOR 10µF,6.3V C8205 NCBA1AK-104W CAPACITOR 0.1µF,10V C8206 NCBA1AK-104W CAPACITOR 0.1µF,10V C8207 NCBA1AK-104W CAPACITOR 0.1µF,10V C8208 NCBA1AK-104W CAPACITOR 0.1µF,10V C8209 NCBA1AK-104W CAPACITOR 0.1µF,10V C8210 NCBA1AK-104W CAPACITOR 0.1µF,10V C8211 NCBA1AK-104W CAPACITOR 0.1µF,10V C8212 NCBA1AK-104W CAPACITOR 0.1µF,10V C8213 NCBA1AK-104W CAPACITOR 0.1µF,10V C8214 NCBA1AK-104W CAPACITOR 0.1µF,10V

C8215 NCBA1AK-104W CAPACITOR 0.1µF,10V C8216 NCBA1AK-473W CAPACITOR 0.047µF,10V C8217 NCBA1AK-104W CAPACITOR 0.1µF,10V C8218 NCBA1AK-104W CAPACITOR 0.1µF,10V C8219 NCB30JK-105X CAPACITOR 1µF,6.3V C8220 NBE90JM-106X T CAPACITOR 10µF,6.3V C8221 NCBA1AK-104W CAPACITOR 0.1µF,10V C8222 NBE90JM-106X T CAPACITOR 10µF,6.3V C8223 NCBA1AK-104W CAPACITOR 0.1µF,10V C8224 NBE90JM-106X T CAPACITOR 10µF,6.3V C8225 NCBA1AK-104W CAPACITOR 0.1µF,10V C8226 NCBA1AK-104W CAPACITOR 0.1µF,10V C8227 NCBA1AK-104W CAPACITOR 0.1µF,10V C8228 NBE90JM-106X T CAPACITOR 10µF,6.3V C8229 NCBA1AK-104W CAPACITOR 0.1µF,10V C8230 NCBA1AK-104W CAPACITOR 0.1µF,10V C8231 NCBA1AK-104W CAPACITOR 0.1µF,10V C8401 NBE90JM-106X T CAPACITOR 10µF,6.3V C8402 NCBA1AK-104W CAPACITOR 0.1µF,10V C8403 NCBA1AK-104W CAPACITOR 0.1µF,10V C8404 NCBA1AK-104W CAPACITOR 0.1µF,10V L8001 NQR0129-002X FERRITE BEAD L8002 NQR0129-002X FERRITE BEAD L8003 NQR0129-002X FERRITE BEAD L8005 NQR0129-002X FERRITE BEAD L8006 NQR0129-002X FERRITE BEAD L8007 NQR0129-002X FERRITE BEAD L8008 NQR0129-002X FERRITE BEAD L8010 NQR0129-002X FERRITE BEAD L8201 NQR0265-001X FERRITE BEAD L8202 NQR0265-001X FERRITE BEAD L8203 NQR0265-001X FERRITE BEAD L8204 NQR0265-001X FERRITE BEAD L8205 NQR0265-001X FERRITE BEAD L8206 NQR0265-001X FERRITE BEAD L8402 NQR0265-001X FERRITE BEAD X8002 NAX0354-001X RESONATOR X8401 NAX0398-001X C OSCILLATOR HS1 LY42973-001A HEAT SINK(DSC) WR1 QUB450-03A2VL SIN TWIST WIRE,LUG WIRE CN8401 QGB0403L1-C0X CONNECTOR CN8402 QGF0517F1-20X FPC CONNECTOR OT1 LY30029-0D5A SPACER(A)

******************************

PRE/MDA BOARD ASSEMBLY <03>

PW YB10303A-01 PRE/MDA BOARD ASSY IC1601 BD6630KV IC IC1701 TA75W01FU IC IC1702 TA75W393FU IC IC3501 JCY0132 IC IC3502 SN74AHC1G04K IC Q1601 UMC3N TRANSISTOR D1602 DAP222 DIODE D1603 DAP222 DIODE D1604 DAP222 DIODE R1601 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R1602 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W

5-19

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R1603 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1604 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1605 NRV142F-R22X CMF RESISTOR 0.22Ø,1/4W R1606 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1609 NRV142F-R33X CMF RESISTOR 0.33Ø,1/4W R1610 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R1611 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R1612 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R1613 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1614 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R1615 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1616 NRSA6AJ-681W MG RESISTOR 680Ø,1/16W R1617 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R1618 NRSA6AJ-154W MG RESISTOR 150kØ,1/16W R1619 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R1620 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1621 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1622 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1624 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W R1625 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1626 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1627 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1628 NRVA6AD-361W CMF RESISTOR 360Ø,1/16W R1629 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W R1630 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1631 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1632 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1633 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1634 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1635 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1636 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R1637 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R1642 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1644 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1701 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R1702 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1703 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1704 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1705 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R1706 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R1707 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1708 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R1709 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1710 NRSA6AJ-124W MG RESISTOR 120kØ,1/16W R1711 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1712 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R1714 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R1715 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3501 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W R3502 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R3503 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R3504 NRVA6AD-241W CMF RESISTOR 240Ø,1/16W R3505 NRVA6AD-241W CMF RESISTOR 240Ø,1/16W R3506 NRVA6AD-241W CMF RESISTOR 240Ø,1/16W R3507 NRVA6AD-241W CMF RESISTOR 240Ø,1/16W R3508 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R3510 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3513 NRSA6AJ-393W MG RESISTOR 39kØ,1/16W R3514 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R3515 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3517 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R3518 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W C1601 NCBA1CK-103W CAPACITOR 0.01µF,16V

C1602 NBE90JM-106X T CAPACITOR 10µF,6.3V C1603 NBE21AM-106X T CAPACITOR 10µF,10V C1605 NCBA1AK-104W CAPACITOR 0.1µF,10V C1606 NCBA1HK-152W CAPACITOR 0.0015µF,50V C1607 NCBA1AK-473W CAPACITOR 0.047µF,10V C1614 NBE21AM-106X T CAPACITOR 10µF,10V C1618 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1619 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1620 NCBA1HK-222W CAPACITOR 0.0022µF,50V C1621 NCB21AK-105X CAPACITOR 1µF,10V C1622 NCBA1CK-223W CAPACITOR 0.022µF,16V C1623 NCBA1AK-473W CAPACITOR 0.047µF,10V C1624 NCB31EK-103X CAPACITOR 0.01µF,25V C1625 NCBA1AK-473W CAPACITOR 0.047µF,10V C1626 NCBA1HK-331W CAPACITOR 330pF,50V C1627 NCBA1CK-822W CAPACITOR 0.0082µF,16V C1628 NCB21CK-224X CAPACITOR 0.22µF,16V C1632 NBE21AM-106X T CAPACITOR 10µF,10V C1633 NCF21CZ-684X CAPACITOR 0.68µF,16V C1635 NCBA1AK-104W CAPACITOR 0.1µF,10V C1641 NCB31AK-474X CAPACITOR 0.47µF,10V C1701 NCBA1AK-104W CAPACITOR 0.1µF,10V C1702 NCBA1AK-104W CAPACITOR 0.1µF,10V C3501 NCBA1CK-223W CAPACITOR 0.022µF,16V C3502 NCBA1AK-473W CAPACITOR 0.047µF,10V C3503 NCBA1AK-104W CAPACITOR 0.1µF,10V C3504 NBE20JM-106X T CAPACITOR 10µF,6.3V C3505 NCBA1AK-104W CAPACITOR 0.1µF,10V C3506 NCBA1AK-104W CAPACITOR 0.1µF,10V C3507 NCBA1AK-104W CAPACITOR 0.1µF,10V C3508 NBE20JM-106X T CAPACITOR 10µF,6.3V C3509 NCBA1AK-104W CAPACITOR 0.1µF,10V C3510 NBE20JM-106X T CAPACITOR 10µF,6.3V C3511 NCBA1AK-104W CAPACITOR 0.1µF,10V C3512 NCBA1AK-104W CAPACITOR 0.1µF,10V C3513 NBE20JM-106X T CAPACITOR 10µF,6.3V C3514 NCBA1CK-103W CAPACITOR 0.01µF,16V C3516 NCBA1AK-104W CAPACITOR 0.1µF,10V C3517 NDC31HJ-221X CAPACITOR 220pF,50V C3519 NCBA1AK-104W CAPACITOR 0.1µF,10V C3520 NBE20JM-106X T CAPACITOR 10µF,6.3V C3522 NCBA1AK-473W CAPACITOR 0.047µF,10V C3523 NCBA1AK-473W CAPACITOR 0.047µF,10V C3524 NCBA1AK-473W CAPACITOR 0.047µF,10V C3525 NCBA1AK-104W CAPACITOR 0.1µF,10V C3526 NCBA1AK-104W CAPACITOR 0.1µF,10V C3527 NCBA1HK-102W CAPACITOR 0.001µF,50V C3528 NCBA1AK-104W CAPACITOR 0.1µF,10V C3529 NCBA1AK-104W CAPACITOR 0.1µF,10V C3530 NBE90JM-475X T CAPACITOR 4.7µF,6.3V C3531 NCBA1AK-104W CAPACITOR 0.1µF,10V C3532 NCBA1AK-104W CAPACITOR 0.1µF,10V C3533 NBE90JM-475X T CAPACITOR 4.7µF,6.3V L1601 NQL315M-1R0X COIL 1µH L3501 NQL302N-100X COIL 10µH L3502 NQL302N-100X COIL 10µH L3503 NQL302N-100X COIL 10µH L3504 NQR0305-001X FERRITE BEAD L3505 NQL302N-100X COIL 10µH CN401 QGB0404L1-80X CONNECTOR CN402 QGF0517F1-08X FPC CONNECTOR CN403 QGF0517F2-06X FPC CONNECTOR CN404 QGF0517F1-11X FPC CONNECTOR

5-20

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

CN405 QGF0517F1-18X FPC CONNECTOR CN406 QGF0517F2-16X FPC CONNECTOR CN407 QGF0517F1-06X FPC CONNECTOR SD1 LY32011-001A SHIELD CASE(PR)

******************************

AUDIO BOARD ASSEMBLY <04>

PW1 YB10304A1-02 AUDIO BOARD ASSY IC1101 TA75W01FU IC IC2201 AK4560AVQ IC Q1151 RPM-22PB PHOTO TRANSISTOR Q2201 2SC4617/QR/-X TRANSISTOR Q2202 2SC4617/QR/-X TRANSISTOR Q2203 2SD1626 TRANSISTOR Q2601 2SC4617/QR/-X TRANSISTOR Q2602 2SC4617/QR/-X TRANSISTOR Q2603 2SA1774/QR/-X TRANSISTOR Q2604 2SA1774/QR/-X TRANSISTOR Q2605 DTA124EE TRANSISTOR

or UN9112J TRANSISTOR

or RN2103 TRANSISTOR Q2701 2SC4617/QR/-X TRANSISTOR Q2702 2SC4617/QR/-X TRANSISTOR Q2703 2SC5585 TRANSISTOR Q2704 2SC5585 TRANSISTOR Q2901 2SB1121/TU/-X TRANSISTOR

or 2SB1121/ST/-X TRANSISTOR Q2902 2SC4617/QR/-X TRANSISTOR Q2903 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q2904 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or UN9213J TRANSISTOR

or RN1104 TRANSISTOR Q2905 UMH6N TRANSISTOR D2706 DAP222 DIODE D2901 EMZ6.8N ZENER DIODE D2902 EMZ6.8N ZENER DIODE D2903 EMZ6.8N ZENER DIODE R1101 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R1102 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1104 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R1106 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R1107 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1108 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R1109 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R1110 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1111 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1112 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1113 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R1151 NRSA63J-302X MG RESISTOR 3kØ,1/16W R2201 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R2202 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R2203 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2204 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2205 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2206 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W

R2207 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2208 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R2209 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R2210 NRSA6AJ-820W MG RESISTOR 82Ø,1/16W R2211 NRSA6AJ-100W MG RESISTOR 10Ø,1/16W R2212 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2213 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2214 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2215 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2216 NRSA6AJ-2R7W MG RESISTOR 2.7Ø,1/16W R2217 NRSA6AJ-2R7W MG RESISTOR 2.7Ø,1/16W R2218 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2219 NRSA6AJ-123W MG RESISTOR 12kØ,1/16W R2220 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R2601 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2602 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2603 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2604 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2605 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2606 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2607 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2608 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2609 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2610 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2611 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2612 NRSA6AJ-182W MG RESISTOR 1.8kØ,1/16W R2613 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R2614 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W R2615 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2616 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2617 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2618 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2619 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2620 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2623 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R2624 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R2625 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2626 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2627 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2628 NRSA6AJ-332W MG RESISTOR 3.3kØ,1/16W R2629 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R2630 NRSA6AJ-392W MG RESISTOR 3.9kØ,1/16W R2631 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2632 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2633 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2634 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R2635 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2636 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2637 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2638 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2639 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2640 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2641 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2643 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2645 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2646 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2649 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2650 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2651 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2652 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2701 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2702 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2705 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W

5-21

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R2706 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R2707 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R2708 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R2709 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R2710 NRSA6AJ-151W MG RESISTOR 150Ø,1/16W R2713 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2714 NRSA6AJ-682W MG RESISTOR 6.8kØ,1/16W R2901 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R2903 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2905 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R2906 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W R2907 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2908 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R2909 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W R2910 NRSA6AJ-391W MG RESISTOR 390Ø,1/16W R2911 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R2912 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2913 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W R2917 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2918 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W R2919 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R2920 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W C1101 NCBA1AK-104W CAPACITOR 0.1µF,10V C1102 NCBA1CK-223W CAPACITOR 0.022µF,16V C1103 NCBA1CK-223W CAPACITOR 0.022µF,16V C1111 NCB30JK-105X CAPACITOR 1µF,6.3V C1112 NBE20JM-106X T CAPACITOR 10µF,6.3V C1113 NBE20JM-106X T CAPACITOR 10µF,6.3V C1114 NCBA1CK-103W CAPACITOR 0.01µF,16V C1151 NBE20JM-106X T CAPACITOR 10µF,6.3V C2201 NCB21AK-105X CAPACITOR 1µF,10V C2202 NCB21AK-105X CAPACITOR 1µF,10V C2203 NBE80JM-106X T CAPACITOR 10µF,6.3V C2204 NCB30JK-105X CAPACITOR 1µF,6.3V C2205 NCB30JK-105X CAPACITOR 1µF,6.3V C2206 NCBA1AK-104W CAPACITOR 0.1µF,10V C2207 NCBA1AK-104W CAPACITOR 0.1µF,10V C2208 NCBA1AK-333W CAPACITOR 0.033µF,10V C2209 NCBA1CK-153W CAPACITOR 0.015µF,16V C2210 NBE20JM-106X T CAPACITOR 10µF,6.3V C2211 NCB21AK-105X CAPACITOR 1µF,10V C2212 NBE20JM-106X T CAPACITOR 10µF,6.3V C2213 NBE20JM-106X T CAPACITOR 10µF,6.3V C2220 NCBA1AK-104W CAPACITOR 0.1µF,10V C2221 NCBA1AK-104W CAPACITOR 0.1µF,10V C2230 NCBA1CK-103W CAPACITOR 0.01µF,16V C2231 NCBA1CK-103W CAPACITOR 0.01µF,16V C2232 NCBA1CK-103W CAPACITOR 0.01µF,16V C2233 NCBA1CK-103W CAPACITOR 0.01µF,16V C2234 NCBA1CK-103W CAPACITOR 0.01µF,16V C2235 NCBA1CK-103W CAPACITOR 0.01µF,16V C2601 NCBA1HK-102W CAPACITOR 0.001µF,50V C2602 NCBA1HK-102W CAPACITOR 0.001µF,50V C2607 NCBA1HK-102W CAPACITOR 0.001µF,50V C2608 NCBA1HK-102W CAPACITOR 0.001µF,50V C2611 NCBA1AK-104W CAPACITOR 0.1µF,10V C2612 NCBA1AK-104W CAPACITOR 0.1µF,10V C2615 NCBA1CK-103W CAPACITOR 0.01µF,16V C2616 NCBA1CK-103W CAPACITOR 0.01µF,16V C2617 NCBA1AK-473W CAPACITOR 0.047µF,10V C2618 NCBA1AK-473W CAPACITOR 0.047µF,10V C2619 NCBA1HK-102W CAPACITOR 0.001µF,50V C2620 NCBA1HK-102W CAPACITOR 0.001µF,50V

C2621 NCBA1AK-473W CAPACITOR 0.047µF,10V C2622 NCBA1AK-473W CAPACITOR 0.047µF,10V C2625 NBP21DM-475X T CAPACITOR 4.7µF,20V C2626 NBP21DM-475X T CAPACITOR 4.7µF,20V C2627 NCBA1AK-473W CAPACITOR 0.047µF,10V C2628 NCBA1AK-473W CAPACITOR 0.047µF,10V C2629 NCBA1CK-223W CAPACITOR 0.022µF,16V C2630 NCBA1CK-223W CAPACITOR 0.022µF,16V C2631 NCBA1AK-104W CAPACITOR 0.1µF,10V C2632 NCBA1AK-104W CAPACITOR 0.1µF,10V C2633 NCBA1HK-182W CAPACITOR 0.0018µF,50V C2634 NCBA1HK-182W CAPACITOR 0.0018µF,50V C2635 NCB30JK-105X CAPACITOR 1µF,6.3V C2636 NCB30JK-105X CAPACITOR 1µF,6.3V C2637 NCBA1CK-223W CAPACITOR 0.022µF,16V C2638 NCBA1CK-223W CAPACITOR 0.022µF,16V C2639 NCBA1EK-472W CAPACITOR 0.0047µF,25V C2640 NCBA1EK-472W CAPACITOR 0.0047µF,25V C2641 NCBA1EK-472W CAPACITOR 0.0047µF,25V C2642 NCBA1EK-472W CAPACITOR 0.0047µF,25V C2643 NCB30JK-105X CAPACITOR 1µF,6.3V C2644 NCB30JK-105X CAPACITOR 1µF,6.3V C2646 NCB21AK-105X CAPACITOR 1µF,10V C2647 NBE20JM-106X T CAPACITOR 10µF,6.3V C2701 NCB21AK-105X CAPACITOR 1µF,10V C2702 NCB21AK-105X CAPACITOR 1µF,10V C2703 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C2704 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W C2707 NCBA1AK-104W CAPACITOR 0.1µF,10V C2708 NCBA1AK-104W CAPACITOR 0.1µF,10V C2709 NBE20GM-226X T CAPACITOR 22µF,4.0V C2710 NBE20GM-226X T CAPACITOR 22µF,4.0V C2901 NCBA1CK-103W CAPACITOR 0.01µF,16V C2904 NCBA1CK-103W CAPACITOR 0.01µF,16V C2907 NCB30JK-105X CAPACITOR 1µF,6.3V L1101 NQL402M-100X COIL 10µH L1151 NQR0265-001X FERRITE BEAD L2201 NQL315K-100X COIL 10µH L2202 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2203 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2204 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2205 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2206 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2601 NQR0251-004X FERRITE BEAD L2602 NQR0251-004X FERRITE BEAD L2603 NQR0251-004X FERRITE BEAD L2604 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2605 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2606 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2607 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2901 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2902 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2903 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2904 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2905 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2906 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2907 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2908 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2909 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2910 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W L2911 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W J201 QNS0168-001 3.5 JACK,EXT MIC CN201 QGB0402K1-80X CONNECTOR

5-22

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

CN202 QGF0517F1-16X FPC CONNECTOR CN203 QGF0505F2-08X FPC CONNECTOR CN204 QGA1002F1-03X CONNECTOR CN205 QGF0517F1-10X FPC CONNECTOR

******************************

REG BOARD ASSEMBLY <05>

PW2 YB10304A2-02 REG BOARD ASSY IC6101 FA3676F IC Q6101 NDS352AP MOS FET Q6103 NDS352AP MOS FET Q6105 NDS352AP MOS FET Q6106 NDS352AP MOS FET Q6107 NDS352AP MOS FET Q6108 NDS352AP MOS FET Q6109 HN1C01FU/G/-X PAIR TRANSISTOR

or PUMX1 PAIR TRANSISTOR Q6110 2SA1577/QR/-X TRANSISTOR Q6111 2SC4617/QR/-X TRANSISTOR

or 2SC4738/YG/-X TRANSISTOR Q6112 DTC144EE TRANSISTOR

or PDTC144EE TRANSISTOR

or UN9213J TRANSISTOR

or RN1104 TRANSISTOR Q6113 HN1A01FU/G/-X PAIR TRANSISTOR

or PUMT1 PAIR TRANSISTOR Q6114 2SC4617/QR/-X TRANSISTOR

or 2SC4738/YG/-X TRANSISTOR D6101 EP10LA03 SB DIODE D6102 EP10LA03 SB DIODE D6103 EP10LA03 SB DIODE D6104 EP10LA03 SB DIODE D6105 EP10LA03 SB DIODE D6106 1SS383 SB DIODE D6107 MA8091/L/-X ZENER DIODE D6108 1SS383 SB DIODE R6101 NRSA6AJ-224W MG RESISTOR 220kØ,1/16W R6102 NRSA6AJ-184W MG RESISTOR 180kØ,1/16W R6104 NRVA6AD-472W CMF RESISTOR 4.7kØ,1/16W R6105 NRVA6AD-113W CMF RESISTOR 11kØ,1/16W R6106 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R6107 NRSA6AJ-223W MG RESISTOR 22kØ,1/16W R6108 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6109 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R6110 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R6111 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6113 NRVA6AD-223W CMF RESISTOR 22kØ,1/16W R6114 NRVA6AD-113W CMF RESISTOR 11kØ,1/16W R6116 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6118 NRVA6AD-333W CMF RESISTOR 33kØ,1/16W R6119 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6120 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R6121 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6122 NRVA6AD-243W CMF RESISTOR 24kØ,1/16W R6123 NRVA6AD-302W CMF RESISTOR 3kØ,1/16W R6124 NRVA6AD-104W CMF RESISTOR 100kØ,1/16W R6125 NRVA6AD-123W CMF RESISTOR 12kØ,1/16W

R6126 NRVA6AD-103W CMF RESISTOR 10kØ,1/16W R6127 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6128 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6129 NRVA6AD-562W CMF RESISTOR 5.6kØ,1/16W R6130 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R6131 NRVA6AD-223W CMF RESISTOR 22kØ,1/16W R6132 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6133 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6134 NRVA6AD-273W CMF RESISTOR 27kØ,1/16W R6135 NRVA6AD-472W CMF RESISTOR 4.7kØ,1/16W R6136 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6137 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R6138 NRSA6AJ-4R7W MG RESISTOR 4.7Ø,1/16W R6139 NRVA6AD-272W CMF RESISTOR 2.7kØ,1/16W R6140 NRVA6AD-623W CMF RESISTOR 62kØ,1/16W R6141 NRVA6AD-392W CMF RESISTOR 3.9kØ,1/16W R6142 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W R6143 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W R6144 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W R6145 NRSA6AJ-822W MG RESISTOR 8.2kØ,1/16W R6146 NRVA6AD-513W CMF RESISTOR 51kØ,1/16W R6147 NRSA6AD-823W MG RESISTOR 82kØ,1/16W R6148 NRVA6AD-473W CMF RESISTOR 47kØ,1/16W R6149 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W R6151 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W R6152 NRSA6AJ-823W MG RESISTOR 82kØ,1/16W R6153 NRVA6AD-623W CMF RESISTOR 62kØ,1/16W R6155 NRVA6AD-683W CMF RESISTOR 68kØ,1/16W R6156 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R6157 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W R6158 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W R6159 NRSA6AJ-0R0W MG RESISTOR 0Ø,1/16W R6160 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C6101 NCB21CK-105X CAPACITOR 1µF,16V C6102 NCB21CK-105X CAPACITOR 1µF,16V C6103 NBPE1CM-106X T CAPACITOR 10µF,16V C6104 NCBA1AK-104W CAPACITOR 0.1µF,10V C6105 NCF31AZ-105X CAPACITOR 1µF,10V C6106 NCBA1CK-103W CAPACITOR 0.01µF,16V C6107 NCB21CK-105X CAPACITOR 1µF,16V C6108 NCF31AZ-105X CAPACITOR 1µF,10V C6109 NCBA1EK-472W CAPACITOR 0.0047µF,25V C6110 NCBA1CK-223W CAPACITOR 0.022µF,16V C6111 NCBA1AK-104W CAPACITOR 0.1µF,10V C6112 NCBA1HK-272W CAPACITOR 0.0027µF,50V C6113 NCBA1AK-104W CAPACITOR 0.1µF,10V C6114 NCBA1HK-561W CAPACITOR 560pF,50V C6115 NCBA1HK-561W CAPACITOR 560pF,50V C6117 NCBA1CK-103W CAPACITOR 0.01µF,16V C6118 NDCA1HJ-101W CAPACITOR 100pF,50V C6119 NBE20JM-106X T CAPACITOR 10µF,6.3V C6120 NCF31AZ-105X CAPACITOR 1µF,10V C6121 NCB21CK-105X CAPACITOR 1µF,16V C6122 NCB10JK-106X CAPACITOR 10µF,6.3V C6123 NCBA1HK-102W CAPACITOR 0.001µF,50V C6127 NCB21CK-105X CAPACITOR 1µF,16V C6128 NCB10JK-106X CAPACITOR 10µF,6.3V C6129 NCBA1EK-472W CAPACITOR 0.0047µF,25V C6130 NCB21CK-105X CAPACITOR 1µF,16V C6131 NCB21CK-105X CAPACITOR 1µF,16V C6133 NCB31CK-683X CAPACITOR 0.068µF,16V C6134 NCB21CK-105X CAPACITOR 1µF,16V C6135 NCB21CK-105X CAPACITOR 1µF,16V

5-23

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

C6137 NCB31AK-224X CAPACITOR 0.22µF,10V C6138 NCB21CK-105X CAPACITOR 1µF,16V C6139 NCB10JK-106X CAPACITOR 10µF,6.3V C6140 NCBA1HK-102W CAPACITOR 0.001µF,50V C6141 NCB21CK-105X CAPACITOR 1µF,16V C6142 NCB21CK-105X CAPACITOR 1µF,16V C6143 NCB21CK-105X CAPACITOR 1µF,16V C6144 NCB11EK-105X CAPACITOR 1µF,25V C6145 NCBA1HK-102W CAPACITOR 0.001µF,50V C6146 NCBA1CK-103W CAPACITOR 0.01µF,16V C6147 NCB21CK-105X CAPACITOR 1µF,16V C6148 NCB21CK-105X CAPACITOR 1µF,16V C6149 NCB21CK-105X CAPACITOR 1µF,16V C6150 NCB11EK-105X CAPACITOR 1µF,25V C6151 NCB21CK-105X CAPACITOR 1µF,16V C6152 NCB21CK-105X CAPACITOR 1µF,16V L6101 NQLZ011-4R7X COIL 4.7µH L6102 NQLZ011-4R7X COIL 4.7µH L6103 NQLZ007-390X COIL 39µH L6107 NQLZ011-390X COIL 39µH L6108 NQLZ011-470X COIL 47µH L6109 NQLZ011-470X COIL 47µH L6110 NQLZ011-390X COIL 39µH L6111 NQL144K-220X COIL 22µH L6112 NQLZ011-221X COIL 220µH CN601 QGB0507M1-80X CONNECTOR CN602 QGF0505F2-12X FPC CONNECTOR

F6101 NMFZ007-2R0X-K FUSE T2.0A

F6102 NMFZ007-2R0X-K FUSE T2.0A

F6103 NMFZ007-R50X-K FUSE T0.5A OT1 LY42978-001A SPACER(REG PWB)

******************************

MONITOR BOARD ASSEMBLY <06>

PW YB10306B-01 MONITOR BOARD ASSY IC7301 CXA3268AR-B IC IC7302 AT25040N-10SC-X IC

or 25LC040-I/SN-X IC IC7401 CXA3503R-B IC IC7501 TL1451CPW IC IC7502 TC7SH04FU IC(DIGITAL)

or SN74AHC1G04K IC Q7301 2SA1774/QR/-X TRANSISTOR Q7302 2SA1577/QR/-X TRANSISTOR Q7303 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q7304 2SC4617/QR/-X TRANSISTOR

or 2SC4738/YG/-X TRANSISTOR Q7305 2SA1774/QR/-X TRANSISTOR

or 2SA1832/YG/-X TRANSISTOR Q7306 2SC4617/QR/-X TRANSISTOR

or 2SC4738/YG/-X TRANSISTOR Q7307 2SA1774/QR/-X TRANSISTOR

or 2SA1832/YG/-X TRANSISTOR Q7401 2SA1774/QR/-X TRANSISTOR

or 2SA1832/YG/-X TRANSISTOR Q7501 UMD3N TRANSISTOR Q7502 SSM3K01F MOS FET

Q7503 2SC4617/QR/-X TRANSISTOR Q7504 XP6401 TRANSISTOR D7301 MA365 VARI CAP DIODE D7302 UDZ2.7B ZENER DIODE D7303 UDZ4.3B ZENER DIODE D7401 MA365 VARI CAP DIODE D7501 MA142WK DIODE R7301 NRSA63J-271X MG RESISTOR 270Ø,1/16W R7302 NRSA63J-102X MG RESISTOR 1kØ,1/16W R7303 NRVA63D-333X CMF RESISTOR 33kØ,1/16W R7304 NRVA63D-153X CMF RESISTOR 15kØ,1/16W R7305 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7306 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7307 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7314 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R7315 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R7316 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R7320 NRSA63J-473X MG RESISTOR 47kØ,1/16W R7321 NVP0016-473X TRIM RESISTOR,PLL(MONI) R7322 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R7323 NRSA63J-333X MG RESISTOR 33kØ,1/16W R7324 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7325 NRSA63J-102X MG RESISTOR 1kØ,1/16W R7326 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7330 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7331 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R7332 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7333 NRSA63J-223X MG RESISTOR 22kØ,1/16W R7334 NRSA63J-223X MG RESISTOR 22kØ,1/16W R7335 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7336 NRSA63J-473X MG RESISTOR 47kØ,1/16W R7401 NRSA63J-271X MG RESISTOR 270Ø,1/16W R7402 NRSA63J-102X MG RESISTOR 1kØ,1/16W R7403 NRVA63D-333X CMF RESISTOR 33kØ,1/16W R7404 NRVA63D-153X CMF RESISTOR 15kØ,1/16W R7405 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7406 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7407 NRSA63J-100X MG RESISTOR 10Ø,1/16W R7414 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R7415 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R7416 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R7417 NRVA63D-562X CMF RESISTOR 5.6kØ,1/16W R7418 NRVA63D-562X CMF RESISTOR 5.6kØ,1/16W R7420 NRSA63J-393X MG RESISTOR 39kØ,1/16W R7421 NVP0016-473X TRIM RESISTOR,PLL(VF) R7422 NRSA63J-752X MG RESISTOR 7.5kØ,1/16W R7423 NRSA63J-333X MG RESISTOR 33kØ,1/16W R7424 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7425 NRSA63J-102X MG RESISTOR 1kØ,1/16W R7426 NRSA63J-103X MG RESISTOR 10kØ,1/16W R7501 NRVA63D-103X CMF RESISTOR 10kØ,1/16W R7502 NRVA63D-123X CMF RESISTOR 12kØ,1/16W R7503 NRVA63D-334X CMF RESISTOR 330kØ,1/16W R7504 NRSA63J-394X MG RESISTOR 390kØ,1/16W R7505 NRSA63J-562X MG RESISTOR 5.6kØ,1/16W R7506 NRSA63J-183X MG RESISTOR 18kØ,1/16W R7507 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R7508 NRS181J-335X MG RESISTOR 3.3MØ,1/8W R7509 NRS181J-335X MG RESISTOR 3.3MØ,1/8W R7510 NRSA63J-223X MG RESISTOR 22kØ,1/16W R7511 NRSA63J-751X MG RESISTOR 750Ø,1/16W R7512 NRSA63J-822X MG RESISTOR 8.2kØ,1/16W R7513 NRSA63J-273X MG RESISTOR 27kØ,1/16W

5-24

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R7514 NRSA63J-124X MG RESISTOR 120kØ,1/16W R7515 NRSA63J-151X MG RESISTOR 150Ø,1/16W R7516 NRSA63J-151X MG RESISTOR 150Ø,1/16W R7517 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W R7518 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W R7519 NRSA63J-163X MG RESISTOR 16kØ,1/16W R7520 NRSA63J-393X MG RESISTOR 39kØ,1/16W R7521 NRVA63D-153X CMF RESISTOR 15kØ,1/16W R7523 NRVA63D-184X CMF RESISTOR 180kØ,1/16W R7524 NRVA63D-114X CMF RESISTOR 110kØ,1/16W R7525 NRSA63J-333X MG RESISTOR 33kØ,1/16W R7526 NRSA63J-221X MG RESISTOR 220Ø,1/16W C7301 NCB21CK-105X CAPACITOR 1µF,16V C7302 NCB31CK-104X CAPACITOR 0.1µF,16V C7303 NBE20JM-226X T CAPACITOR 22µF,6.3V C7304 NCB31EK-103X CAPACITOR 0.01µF,25V C7305 NCB21CK-105X CAPACITOR 1µF,16V C7306 NCB21CK-105X CAPACITOR 1µF,16V C7307 NCB21CK-105X CAPACITOR 1µF,16V C7308 NBP41CM-106X T CAPACITOR 10µF,16V C7309 NCB21CK-105X CAPACITOR 1µF,16V C7310 NCB31CK-104X CAPACITOR 0.1µF,16V C7311 NBP41CM-106X T CAPACITOR 10µF,16V C7312 NCB31CK-104X CAPACITOR 0.1µF,16V C7313 NCB31CK-104X CAPACITOR 0.1µF,16V C7314 NBE20JM-226X T CAPACITOR 22µF,6.3V C7315 NCB31CK-104X CAPACITOR 0.1µF,16V C7316 NCB21CK-105X CAPACITOR 1µF,16V C7317 NCB31CK-104X CAPACITOR 0.1µF,16V C7318 NCB31CK-104X CAPACITOR 0.1µF,16V C7319 NCB31CK-104X CAPACITOR 0.1µF,16V C7320 NDC31HJ-300X CAPACITOR 30pF,50V C7321 NCB31HK-102X CAPACITOR 0.001µF,50V C7322 NCB31EK-103X CAPACITOR 0.01µF,25V C7323 NCB31HK-682X CAPACITOR 0.0068µF,50V C7324 NCB11AK-335X CAPACITOR 3.3µF,10V C7330 NCB21CK-105X CAPACITOR 1µF,16V C7331 NCB10JK-106X CAPACITOR 10µF,6.3V C7332 NCB21CK-105X CAPACITOR 1µF,16V C7333 NCB21CK-105X CAPACITOR 1µF,16V C7335 NCB31CK-104X CAPACITOR 0.1µF,16V C7336 NCB21CK-105X CAPACITOR 1µF,16V C7337 NCB21CK-105X CAPACITOR 1µF,16V C7338 NCB31EK-103X CAPACITOR 0.01µF,25V C7401 NCB21CK-105X CAPACITOR 1µF,16V C7402 NCB31CK-104X CAPACITOR 0.1µF,16V C7403 NBE20JM-226X T CAPACITOR 22µF,6.3V C7404 NCB31EK-103X CAPACITOR 0.01µF,25V C7405 NCB21CK-105X CAPACITOR 1µF,16V C7406 NCB21CK-105X CAPACITOR 1µF,16V C7407 NCB21CK-105X CAPACITOR 1µF,16V C7408 NBP41CM-106X T CAPACITOR 10µF,16V C7410 NCB31CK-104X CAPACITOR 0.1µF,16V C7411 NBP41CM-106X T CAPACITOR 10µF,16V C7412 NCB31CK-104X CAPACITOR 0.1µF,16V C7413 NCB31CK-104X CAPACITOR 0.1µF,16V C7414 NBE20JM-226X T CAPACITOR 22µF,6.3V C7415 NCB31CK-104X CAPACITOR 0.1µF,16V C7416 NCB21CK-105X CAPACITOR 1µF,16V C7417 NCB31CK-104X CAPACITOR 0.1µF,16V C7418 NCB31CK-104X CAPACITOR 0.1µF,16V C7419 NCB31CK-104X CAPACITOR 0.1µF,16V C7420 NDC31HJ-300X CAPACITOR 30pF,50V

C7421 NDC31HJ-221X CAPACITOR 220pF,50V C7422 NCB31EK-103X CAPACITOR 0.01µF,25V C7423 NCB31HK-682X CAPACITOR 0.0068µF,50V C7424 NCB11AK-335X CAPACITOR 3.3µF,10V C7425 NCB31EK-103X CAPACITOR 0.01µF,25V C7501 NCB31CK-104X CAPACITOR 0.1µF,16V C7502 NCB10JK-106X CAPACITOR 10µF,6.3V C7503 NCB11AK-335X CAPACITOR 3.3µF,10V C7504 NBP41CM-106X T CAPACITOR 10µF,16V C7505 NCB31EK-103X CAPACITOR 0.01µF,25V C7506 NBE90JM-685X T CAPACITOR 6.8µF,6.3V C7507 NDC31HJ-331X CAPACITOR 330pF,50V C7508 NCB31CK-104X CAPACITOR 0.1µF,16V C7509 NBP21CM-685X T CAPACITOR 6.8µF,16V L7301 NQL085J-3R3X COIL 3.3µH L7302 NQL315K-100X COIL 10µH L7303 NQL315K-100X COIL 10µH L7304 NQL315K-100X COIL 10µH L7401 NQL085J-100X COIL 10µH L7402 NQL315K-100X COIL 10µH L7501 NQL144K-220X COIL 22µH T7501 NQS0052-001X SW TRANSF T7502 NAX0334-001 PIEZOELE TRANSF CN7501 QGF0304F1-39X FFC/FPC CONNECTOR CN7502 QGF0517F1-24X FPC CONNECTOR

F7501 NMFZ009-R50X-J1 FUSE T0.5A

******************************

JACK BOARD ASSEMBLY <07>

PW1 YB10305A1-03 JACK BOARD ASSY IC2822 TC7S04FU IC(DIGITAL) Q2801 DTC144EE TRANSISTOR

or RN1104 TRANSISTOR

or UN9213J TRANSISTOR Q2821 2SC4617/QR/-X TRANSISTOR D2821 EMZ6.8N ZENER DIODE D2822 EMZ6.8N ZENER DIODE D2823 EMZ6.8N ZENER DIODE D2825 RB715F SB DIODE R2801 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2802 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2803 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2804 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2805 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2806 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2807 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2808 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2809 NRSA63J-473X MG RESISTOR 47kØ,1/16W R2810 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2812 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2813 NRSA63J-473X MG RESISTOR 47kØ,1/16W R2814 NRSA63J-104X MG RESISTOR 100kØ,1/16W R2816 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2818 NRSA63J-473X MG RESISTOR 47kØ,1/16W R2821 NRSA63J-101X MG RESISTOR 100Ø,1/16W R2822 NRSA63J-470X MG RESISTOR 47Ø,1/16W R2823 NRSA63J-101X MG RESISTOR 100Ø,1/16W R2824 NRSA63J-101X MG RESISTOR 100Ø,1/16W

5-25

# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

R2825 NRSA63J-101X MG RESISTOR 100Ø,1/16W R2826 NRSA63J-101X MG RESISTOR 100Ø,1/16W R2828 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W R2829 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2830 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2831 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2832 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2833 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2841 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2844 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2845 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2848 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2861 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2862 NRSA63J-391X MG RESISTOR 390Ø,1/16W R2883 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2885 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C2802 NBE80JM-106X T CAPACITOR 10µF,6.3V C2821 NCB31EK-103X CAPACITOR 0.01µF,25V C2841 NCB31CK-683X CAPACITOR 0.068µF,16V C2842 NCB31CK-683X CAPACITOR 0.068µF,16V C2843 NCB31HK-102X CAPACITOR 0.001µF,50V C2844 NCB31HK-102X CAPACITOR 0.001µF,50V C2848 NCB31HK-472X CAPACITOR 0.0047µF,50V C2849 NCB31HK-472X CAPACITOR 0.0047µF,50V C2881 NCB31EK-103X CAPACITOR 0.01µF,25V C2882 NCB31EK-103X CAPACITOR 0.01µF,25V C2883 NCB31EK-103X CAPACITOR 0.01µF,25V L2801 NQR0129-002X FERRITE BEAD L2821 NQR0006-001X FERRITE BEAD L2841 NQR0251-004X FERRITE BEAD L2842 NQR0251-004X FERRITE BEAD L2843 NQR0251-004X FERRITE BEAD L2844 NQR0251-004X FERRITE BEAD L2845 NQR0251-004X FERRITE BEAD J301 NNZ0038-001X D CONNECTOR,PRINTER J302 QNS0012-001 3.5 JACK,HP J303 QNS0078-001 3.5 JACK,AV CN301 QGF0301F1-45X FPC CONNECTOR CN302 NNZ0042-001X SD CARD CONNECTOR CN303 QGF0501F1-11X FPC CONNECTOR CN304 QGA1201F2-02X CONNECTOR

BT301 QAB0020-001 LI BATTERY

******************************

DECK OPE. BOARD ASSEMBLY <09>

PW3 YB10305A3-01 DECK OPE.BOARD ASSY R2432 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W R2433 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W R2434 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W R2437 NRSA63J-152X MG RESISTOR 1.5kØ,1/16W R2438 NRSA63J-182X MG RESISTOR 1.8kØ,1/16W R2439 NRSA63J-272X MG RESISTOR 2.7kØ,1/16W R2440 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2441 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2442 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2443 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2444 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W R2445 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W C2431 NCB31EK-103X CAPACITOR 0.01µF,25V S2431 NSW0035-001X TACT SWITCH,STOP S2432 NSW0035-001X TACT SWITCH,REW S2433 NSW0035-001X TACT SWITCH,PB S2434 NSW0035-001X TACT SWITCH,FF S2435 NSW0035-001X TACT SWITCH,P MEDIA S2436 NSW0071-001X DETECT SWITCH,MONI OPEN CN2431 QGF0517F1-08X FPC CONNECTOR CN2432 QGF0517F1-06X FPC CONNECTOR

******************************

CCD BOARD ASSEMBLY <10>

PW YB10307A-01 CCD BOARD ASSY Q5201 2SC3935/Q/-X TRANSISTOR R5201 NRSA63J-122X MG RESISTOR 1.2kØ,1/16W C5202 NCF31EZ-104X CAPACITOR 0.1µF,25V C5203 NBE41AM-476X T CAPACITOR 47µF,10V C5204 NCB31CK-104X CAPACITOR 0.1µF,16V C5205 NCB31CK-104X CAPACITOR 0.1µF,16V C5206 NBZ0003-475X T CAPACITOR 4.7µF C5207 NCF31EZ-104X CAPACITOR 0.1µF,25V C5208 NCB31HK-222X CAPACITOR 0.0022µF,50V C5209 NCB21EK-104X CAPACITOR 0.1µF,25V WR1 WJR0018-001A

E-SH C WIRE C-F,CCD OUT-MAIN CN101

******************************

EJECT BOARD ASSEMBLY <08>

PW2 YB10305A2-01 EJECT BOARD ASSY R2421 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2424 NRSA63J-103X MG RESISTOR 10kØ,1/16W R2425 NRSA63J-103X MG RESISTOR 10kØ,1/16W S2421 NSW0094-001X DETECT SWITCH,EJECT SW CN2421 QGF0512C1-12X FPC CONNECTOR CN2422 QGF0501F2-13X FPC CONNECTOR

5-26

(Sanwa)-M14D6L

JVC GRDV-2000 Service manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PARTS LIST

5.1 PACKING AND ACCESSORY ASSEMBLY <M1>

5.2 FINAL ASSEMBLY <M2>

5.3 MECHANISM ASSEMBLY <M3>

5.4 ELECTRONIC VIEWFINDER ASSEMBLY <M4>

5.5 MONITOR ASSEMBLY <M5>

5.6 ELECTRICAL PARTS LIST
