SERVICE MANUAL
DIGITAL VIDEO CAMERA
YF08820054
GR-DF430AA, GR-DF430AC,
GR-DF430AG, GR-DF430AH,
GR-DF430AS, GR-DF470AA,
GR-DF470AC, GR-DF470AG,
GR-DF470AH, GR-DF470AS
GR-DF430AAM, GR-DF430ACM,GR-DF430AG,
GR-DF430AH, GR-DF430AS[M5D5S3],
GR-DF470AAM,GR-DF470ACM, GR-DF470AG,
GR-DF470AH, GR-DF470AS[M5D5S7]
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).
Regarding service information other than these sections, refer to the service manual No. YF087 (GR-DF470EX).
Also, be sure to note important safety precautions provided in the service manual.
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
COPYRIGHT © 2005 Victor Company of Japan, Limited
No.YF088
2005/4
SPECIFICATION
Camcorder
For General Power supply DC 11.0 V(Using AC Adapter)
DC 7.2 V (Using battery pack)
Power consumption Approx. 3.2 W(3.5W*)(LCD monitor off, viewfinder on)
Approx. 4.2W (4.5W*)(LCD monitor on, viewfinder off)
* Using LED Light (LED Light model only)
Dimensions (W × H × D) 75 mm × 74mm × 111 mm
(with the LCD monitor closed and the viewfinder pushed back in)
Weight Approx. 400g (without battery, cassette, memory card * and lens cap)
Approx. 480 g (incl. battery, cassette memory card *and lens cap)
* GR-DF430,460,470 only
Operating temperature 0°C to 40°C
Operating humidity 35% to 80%
Storage temperature -20°C to 50°C
Pickup 1/6" CCD
Lens F 1.2, f = 2.6 mm to 39 mm, 15:1 power zoom lens
Filter diameter Ø30.5 mm
LCD monitor 2.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder Electronic viewfinder with 0.16" color LCD
Speaker Monaural
LED Light Effective distance: 1.5 m
For Digital Video
Camera
For Digital Still
Camera
(GR-DF460,470
only)
For Connectors S S-Video input
Format DV format (SD mode)
Signal format PAL standard
Recording/Playback
format
Cassette Mini DV cassette
Tape speed SP: 18.8 mm/s, LP: 12.5 mm/s
Maximum recording time
(using 80 min. cassette)
Storage media SD Memory Card/MultiMediaCard
Compression system JPEG (compatible)
File size Still image : 2 modes ( 1024 × 768 pixels/640 × 480 pixels)
Picture quality 2 modes (FINE/STANDARD)
AV Video input
Microphone input Ø3.5 mm, stereo
DV Input*/output
USB(GR-DF460,470 only) Mini USB-B type, USB 1.1/2.0 compliant
Video Digital component recording
Audio PCM digital recording, 32 kHz 4-channel (12-bit), 48 kHz 2-channel (16-bit)
SP: 80 min., LP: 120 min.
Moving image:1 mode (160 × 120 pixels)
Y: 0.8 V to 1.2 V (p-p), 75Ω , analogue
(GR-DF430,470 only)
S-Video output Y: 1.0 V (p-p), 75Ω, analogue
(GR-DF430,470 only)
Video output 1.0 V (p-p), 75Ω, analogue
Audio input
(GR-DF430,470 only)
Audio output 300 mV (rms), 1 kΩ, analogue, stereo
* GR-DF430,460,
470 only
C: 0.2 V to 0.4 V (p-p), 75Ω , analogue
C: 0.29 V (p-p), 75Ω, analogue
0.8 V to 1.2 V (p-p), 75Ω, analogue
300 mV (rms), 50 kΩ , analogue, stereo
4-pin, IEEE 1394 compliant
AC Adapter
Power requirement AC 110 V to 240 V, 50 Hz/60 Hz
Output DC 11 V, 1 A
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without
notice.
1-2 (No.YF088)
SECTION 1
PRECAUTION
Please refer to "GR-DF470EX No.YF087" about this section.
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
2.1 DIFFERENCE LIST
The following table indicate main different points between models GR-DF420EX, GR-DF430AA, GR-DF430AC, GR-DF430AG,
GR-DF430AH, GR-DF430AS, GR-DF470AA, GR-DF470AC, GR-DF470AG, GR-DF470AH and GR-DF470AS.
MODEL GR-DF420EX GR-DF430AA GR-DF430AC GR-DF430AG GR-DF430AH GR-DF430AS
LED LIGHT NONONONONONO
USB TERMINAL NO NO NO NO NO NO
DV TERMINAL YES(OUT) YES(IN/OUT) YES(IN/OUT) YES(IN/OUT) YES(IN/OUT) YES(IN/OUT)
ANALOG INPUT NO YES YES YES YES YES
AC ADAPTER AP-V14E AP-V14E AP-V14AC AP-V17E AP-V14E AP-V14A
AC CORD YES(BS Plug) YES(AS/NZS Plug) YES(CEE Plug) NO YES(CEE Plug) YES(CEE Plug)
CONVERSION PLUG NO NO NO NO YES NO
USB CABLE NONONONONONO
MEMORY CARD NO NO NO NO NO NO
CD-ROM NONONONONONO
MODEL GR-DF470AA GR-DF470AC GR-DF470AG GR-DF470AH GR-DF470AS
LED LIGHT YES YES YES YES YES
USB TERMINAL YES YES YES YES YES
DV TERMINAL YES(IN/OUT) YES(IN/OUT) YES(IN/OUT) YES(IN/OUT) YES(IN/OUT)
ANALOG INPUT YES YES YES YES YES
AC ADAPTER AP-V14E AP-V14AC AP-V17E AP-V14E AP-V14A
AC CORD YES(AS/NZS Plug) YES(CEE Plug) NO YES(CEE Plug) YES(CEE Plug)
CONVERSION PLUG NO NO NO YES NO
USB CABLE YES YES YES YES YES
MEMORY CARD YES(MMC(8MB)) YES(MMC(8MB)) YES(MMC(8MB)) YES(MMC(8MB)) YES(MMC(8MB))
CD-ROM YES YES YES YES YES
SECTION 3
DISASSEMBLY
Please refer to "GR-DF470EX No.YF087" about this section.
SECTION 4
ADJUSTMENT
Please refer to "GR-DF470EX No.YF087" about this section.
SECTION 5
TROUBLESHOOTING
Please refer to "GR-DF470EX No.YF087" about this section.
(No.YF088)1-3
