JVC GR-DF450US User Manual

DIGITAL VIDEO CAMERA
Dear Customer,
Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions contained in the pages 3 – 4 and 10 to ensure safe use of this product.
ENGLISH
GR-DF470 GR-DF450 GR-DF430
Please visit our Homepage on the World Wide Web for Digital Video Camera:
http://www.jvc.co.jp/english/cyber/
For Accessories:
http://www.jvc.co.jp/english/accessory/
The camcorder illustrations appearing in this instruction manual are of the GR-DF470.
The D.S.C (Digital Still Camera) features are available on GR-DF470 and GR-DF450.
GETTING STARTED
VIDEO RECORDING & PLAYBACK
DIGITAL STILL CAMERA (D.S.C.) RECORDING & PLAYBACK (GR-DF470/450 only)
ADVANCED FEATURES
REFERENCES
TERMS
For Customer Use:
Enter below the Model No. and Serial No. which is located on the bottom of the camcorder. Retain this information for future reference.
Model No. Serial No.
To deactivate the demonstration, set “DEMO MODE” to “OFF”. (pg. 36, 39)
6
19
27
36
56
67
INSTRUCTIONS
LYT1426-001C
EN
2 EN
Major Features of this Camcorder
Wipe/Fader Effects
You can use the Wipe/Fader Effects to make pro-style scene transitions. (墌 pg. 47)
Fade in
Fade out
Program AE with Special Effects
For example, “SPORTS” mode allows fast­moving images to be captured one frame at a time, for vivid, stable slow-motion. (墌 pg. 47)
Backlight Compensation
Simply pressing the BACK LIGHT button brightens the image darkened by backlight. (pg. 45)
You can also select a spot metering area so that more precise exposure compensation is available. (pg. 45, Spot Exposure Control)
Navigation Function*
The Navigation Function helps you check tape contents by making thumbnail images on a memory card. (墌 pg. 48)
DAT : 3:29 MMAY 2 4 0 4’A TC : : 3 : 1 5
1 2 3
4 5
ONITNAV I GA
2E31
E-Mail Clip Recording*
You can record video clips on the memory card as files which can be sent via e-mail. (pg. 31)
* GR-DF470/450 only

SAFETY PRECAUTIONS

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTIONS:
This camcorder is designed to be used with NTSC-type colour television signals. It cannot be used for playback with a television of a different standard. However, live recording and LCD monitor/viewfinder playback are possible anywhere.
This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BN-VF707U/VF714U/VF733U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)
Caution on Replaceable lithium battery
The battery used in this device may present a fire or chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C (212F°) or incinerate.
Replace battery with Panasonic (Matsushita Electric), Sanyo, Sony or Maxell CR2025.
Danger of explosion or Risk of fire if the battery is incorrectly replaced.
Dispose of used battery promptly.
Keep away from children.
Do not disassemble and do not dispose of in
fire.
EN 3
NOTES:
The rating plate (serial number plate) and safety caution are on the bottom and/or the back of the main unit.
The rating information and safety caution of the AC Adapter are on its upper and lower sides.
This product has a fluorescent lamp that contains a small amount of mercury. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information please contact your local authorities, or the Electronics Industries Alliance:
<http://www.eiae.org>
4 EN
When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm (3-15/16") or more on both sides, on top and at the rear).
Do not block the ventilation holes. (If the ventilation holes are blocked by a newspaper, or cloth etc. the heat may not be able to get out.)
No naked flame sources, such as lighted candles, should be placed on the apparatus.
When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.
The apparatus shall not be exposed to dripping or splashing.
Do not use this equipment in a bathroom or places with water. Also do not place any containers filled with water or liquids (such as cosmetics or medicines, flower vases, potted plants, cups etc.) on top of this unit. (If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)
Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock.
CAUTION!
The following notes concern possible physical damage to the camcorder and to the user.
When carrying, be sure to always securely attach and use the provided strap. Carrying or holding the camcorder by the viewfinder and/or the LCD monitor can result in dropping the unit, or in a malfunction.
Take care not to get your finger caught in the cassette holder cover. Do not let children operate the camcorder, as they are particularly susceptible to this type of injury.
Do not use a tripod on unsteady or unlevel surfaces. It could tip over, causing serious damage to the camcorder.
CAUTION!
Connecting cables (Audio/Video, S-Video, etc.) to the camcorder and leaving it on top of the TV is not recommended, as tripping on the cables will cause the camcorder to fall, resulting in damage.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Only use attachments/accessories specified by the manufacturer.
10. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip­over.
11. Unplug this apparatus during lightning storms or when unused for long periods of time.
12. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
GETTING STARTED 6
Index................................................................. 6
Provided Accessories ..................................... 11
Power.............................................................. 13
Operation Mode.............................................. 15
Language Settings..........................................16
Date/Time Settings ......................................... 16
Grip Adjustment.............................................. 16
Viewfinder Adjustment.................................... 16
Brightness Adjustment Of The Display........... 17
Tripod Mounting.............................................. 17
Loading/Unloading A Cassette....................... 17
Loading/Unloading A Memory Card
(GR-DF470/450 only) ................................. 18
VIDEO RECORDING & PLAYBACK 19
VIDEO RECORDING ........................................... 19
Basic Recording.............................................. 19
Tape Remaining Time ................................ 19
LCD Monitor And Viewfinder ...................... 19
Zooming...................................................... 20
Journalistic Shooting .................................. 20
Self Recording............................................ 20
Time Code .................................................. 21
Quick Review.............................................. 21
Recording From The Middle Of A Tape...... 21
VIDEO PLAYBACK ............................................. 22
Normal Playback............................................. 22
Still Playback .............................................. 22
Shuttle Search............................................22
Blank Search .............................................. 22
Connections To A TV Or VCR........................ 23
Playback Using The Remote Control.............. 24
DIGITAL STILL CAMERA (D.S.C.) RECORDING & PLAYBACK (GR-DF470/450 only) 27
D.S.C. RECORDING (GR-DF470/450 only) ......... 27
Basic Shooting (D.S.C. Snapshot).................. 27
Interval Shooting......................................... 28
D.S.C. PLAYBACK (GR-DF470/450 only)............ 29
Normal Playback Of Images........................... 29
Auto Playback Of Images ............................... 29
Playback Of Video Clips ................................. 29
Index Playback Of Files.................................. 30
Viewing File Information ................................. 30
Removing On-Screen Display ........................ 30

CONTENTS

EN
ADDITIONAL FEATURES FOR D.S.C.
(GR-DF470/450 only) ...................................... 31
E-Mail Clip Recording..................................... 31
Dubbing Still Images Recorded On A Tape
To A Memory Card ..................................... 32
Resetting The File Name................................ 32
Protecting Files............................................... 32
Deleting Files.................................................. 33
Setting Print Information (DPOF Setting)........34
Initializing A Memory Card.............................. 35
ADVANCED FEATURES 36
MENUS FOR DETAILED ADJUSTMENT.................. 36
Changing The Menu Settings......................... 36
Recording Menus............................................ 37
Playback Menus ............................................. 40
FEATURES FOR RECORDING............................... 42
LED Light........................................................ 42
Live Slow (GR-DF470/450 only)..................... 42
5-Second Recording....................................... 42
Night-Alive ...................................................... 43
Snapshot (For Video Recording).................... 43
Manual Focus ................................................. 44
Exposure Control............................................ 44
Iris Lock .......................................................... 45
Backlight Compensation................................. 45
Spot Exposure Control.................................... 45
White Balance Adjustment.............................. 46
Manual White Balance Adjustment................. 46
Wipe Or Fader Effects .................................... 47
Program AE With Special Effects ................... 47
Navigation Function (GR-DF470/450 only)..... 48
EDITING............................................................ 51
Dubbing To Or From A VCR........................... 51
Dubbing To Or From A Video Unit Equipped With
A DV Connector (Digital Dubbing).............. 52
Connection To A Personal Computer............. 53
Audio Dubbing ................................................ 54
Insert Editing...................................................55
REFERENCES 56
TROUBLESHOOTING.......................................... 56
USER MAINTENANCE......................................... 61
CAUTIONS ........................................................62
SPECIFICATIONS................................................ 66
TERMS 67
5
6 EN

Index

GETTING STARTED

e
MN
aZ
1C
B
J
9
8
G
fO T
U V
W X
KS
b
c
d
L
D E
F
hig
j
PQR
lkY
onm

Controls

A Menu Button [MENU] (墌 pg. 36)
Data Battery Button [BATT. DATA] (墌 pg. 14)
B E-Mail Clip Recording Button [E-MAIL]*
(pg. 31) Index Button [INDEX]* (pg. 30)
C D.S.C. Playback Select Button [SEL]*
(pg. 29) Thumbnail Storing Button [STORE]* (pg. 48)
D Information Button [INFO]*
(pg. 30)
E Set Button [SET] (pg. 36) F Fast-Forward Button [
LED Light Button [LIGHT] (pg. 42) Right Button [>] (墌 pg. 36)
G Stop Button [8] (墌 pg. 22)
Backlight Compensation Button [BACK LIGHT] (墌 pg. 45) Down Button [ ] (墌 pg. 36)
H Rewind Button [
Quick Review Button [Q.REVIEW] (墌 pg. 21) Left Button [<] (墌 pg. 36)
I VIDEO/MEMORY Switch*
(pg. 15)
J Play/Pause Button [4/9] (墌 pg. 22)
Manual Focus Button [FOCUS] (墌 pg. 44) Up Button [ ] (墌 pg. 36)
K Diopter Adjustment Control (pg. 16) L Battery Release Button [BATT. RELEASE]
(pg. 14)
M Snapshot Button [SNAPSHOT]
(pg. 27, 43) Live Slow Button [SLOW]* (pg. 36, 42)
N Power Zoom Lever [T/W] (墌 pg. 20)
Speaker Volume Control [VOL. +, –] (pg. 22)
O Cassette Open/Eject Switch [OPEN/EJECT]
(pg. 17)
P Recording Start/Stop Button (pg. 19) Q Power Switch [A, M, PLAY, OFF] (pg. 15) R Lock Button (pg. 15)
3
] (pg. 22)
5
] (pg. 22)
GETTING STARTED
EN 7

Connectors

The connectors are located beneath the covers.
S S-Video Input/Output Connector [S]
(pg. 23, 51)
T Microphone connector [MIC] (pg. 54) U USB (Universal Serial Bus) Connector*
(pg. 53)
V Digital Video (i.Link) Connector [DV IN/OUT]
(pg. 52, 53)
i.Link: i.Link refers to the IEEE1394-1995
industry specification and extensions thereof. The logo is used for products compliant with the i.Link standard.
W Audio/Video Input/Output Connector [AV]
(pg. 23, 51)
X DC Input Connector [DC] (墌 pg. 13)

Indicators

Y POWER/CHARGE Lamp (pg. 13, 19)

Other Parts

Z LCD Monitor (pg. 19, 20) a Shoe
(Before you purchase optional shoe
accessories, make sure the items are
compatible and can attach to the shoe on
your camcorder. There may be cases where a
part of an accessor y item obtrudes onto the
camcorder’s body, preventing attachment to
your unit.)
b Viewfinder (pg. 16) c Speaker (pg. 22) d Battery Pack Mount (pg. 14) e Cassette Holder Cover (pg. 17) f Lens g LED Light (pg. 42)
(When using an optional conversion lens, it
may cover this area and block the light.)
h Remote Sensor (pg. 24) i Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
j Stereo Microphone (pg. 54) k Shoulder Strap Eyelet (pg. 12) l Grip Strap (pg. 16) m Card Cover [MEMORY CARD]*
(pg. 18)
n Tripod Mounting Socket (pg. 17) o Stud Hole (pg. 17)
* GR-DF470/450 only
GETTING STARTED
8 EN
GETTING STARTED

LCD Monitor/Viewfinder Indications

During Video Recording Only

13467
r
SOUND12BIT
e
15:55
w
a Navigation Indicator*
(pg. 48)
B Selected Wipe/Fader Effect Indicator
(pg. 47)
C Tape Running Indicator (墌 pg. 19)
(Rotates while tape is running.)
D Selected Wide Mode Indicator (pg. 38) E : Live Slow Indicator*
(pg. 42)
: Snapshot Indicator*
(pg. 43)
F Recording Speed Mode (SP/LP) (pg. 37) G Tape Remaining Time (pg. 19) H REC: (Appears during recording.) (pg. 19)
PAUSE: (Appears during Record-Standby mode.) (墌 pg. 19)
I Insert Editing/Insert Editing Pause Mode
(pg. 55)
J 5S/Anim.: Displays the 5-Second Recording
mode or Animation recording mode. (pg. 38)
K Wind Cut Indicator (pg. 38) L Time Code (pg. 39, 41) M Digital Image Stabilizer (“DIS”) (pg. 38) N SOUND 12BIT/16BIT: Sound Mode Indicator
(pg. 37) (Appears for approx. 5 seconds after turning on the camcorder.)
L R
(Appears when an optional microphone is connected. pg. 39, “AUDIO LEV.”)
* GR-DF470/450 only
: Auxiliary Microphone Level
Indicator
5
2
1h40m
REC
8 9 0
q

During D.S.C. Recording Only (GR-DF470/ 450 only)

634 5
1024
INTERVAL
51
7
a Image Size: 1024 (1024 x 768) or 640
(640x480) (墌 pg. 40)
B : Interval Shooting Icon (墌 pg. 28)
: Focus Icon (墌 pg. 27)
C Shooting Icon
(Appears and blinks during shooting.)
D Card Icon
: Appears during shooting. : Blinks in white when a memory card is
not loaded.
: Blinks in yellow while the camcorder is reading the data in the memory card such as Navigation thumbnail images, video clips, still images, etc.
E Picture Quality: (FINE) and
(STANDARD) (in order of quality) (墌 pg. 40)
F Remaining Number Of Shots (墌 pg. 27)
(Displays the approximate remaining number of shots that can be stored during D.S.C. recording.)
G Clock Icon (墌 pg. 28)

During E-Mail Clip Recording (GR-DF470/ 450 only)

160
a Image Size: 160 (160 x 120) b Shooting Icon (pg. 27, 31) c E-Mail Clip Recording Indicator (pg. 31) d Memory Card Remaining Time For E-Mail
Clip Recording (墌 pg. 31)
e E-Mail Clip Recording Time (墌 pg. 31)
0
hm
PILC-E
:10
00:15

During Both Video And D.S.C.* Recording

8
9
1 2
1
5
3 4 5
6 7
x
BRIGHT
W
T
N
OV
10
a Operation Mode (pg. 15)
B : Gain Up Mode (pg. 37) C LED Light Indicator (pg. 42) D White Balance Indicator (pg. 46) E : Spot Exposure Control Indicator
(pg. 45)
: Backlight Compensation Indicator (pg. 45) ±: Exposure Adjustment Indicator (墌 pg. 44)
F Selected Program AE With Special Effects
Indicator (墌 pg. 47)
: Night-Alive Indicator (墌 pg. 43)
G Iris Lock Indicator (pg. 45) H Approximate Zoom Ratio (pg. 20) I Zoom Indicator (pg. 20) J O: (Appears when taking Snapshot.)
(pg. 28, 43)
SLOW
: (Appears when using Live Slow.)*
(pg. 42)
K Brightness Control Indicator (LCD monitor/
Viewfinder) (墌 pg. 17)
L Battery Remaining Power Indicator
(pg. 58)
M Date/Time (pg. 16) N Manual Focus Adjustment Indicator
(pg. 44)
:10000A
O
50m
er
'
5
M
GETTING STARTED

During Video Playback

1
BIT
1L2
2 0 :/2M
0
q
w
q
PUSH "STOP" BUTTON
L
V
R
1
0
a Sound Mode Indicator (pg. 40)
B Blank Search Indicator (pg. 22) C : Live Slow Indicator*
(pg. 42)
: Snapshot Indicator*
(pg. 43)
D Tape Speed (pg. 37) E 4: Playback
5
: Fast-Forward/Shuttle Search
3
: Rewind/Shuttle Search
9: Pause 9 U: Forward Frame-By-Frame Playback/
Slow-Motion Y 9: Reverse Frame-By-Frame Playback/ Slow-Motion D: Audio Dubbing 9D: Audio Dubbing Pause (Appear while a tape is running.)
F Sound Input For Audio Dubbing (pg. 54) G Battery Remaining Power Indicator
(pg. 58)
H Date/Time (pg. 39, 41) I VOLUME: Volume Level Indicator (pg. 22)
BRIGHT: Brightness Control Indicator (LCD monitor/Viewfinder) (墌 pg. 17)
J Time Code (pg. 39, 41) K : Auxiliary Microphone Level
L R
(Appears when an optional microphone is connected during Audio Dubbing. 墌 pg. 54)
* GR-DF470/450 only
Indicator
2
I
X
BLANK SEARCH
TO CANCEL
O
L
U
M
E
OV
N
:
2
5
10
9
43
5
50m
:10000A
8
MIC
'
5 M
EN 9
6
7
GETTING STARTED
10 EN
GETTING STARTED

During D.S.C. Playback (GR-DF470/450 only)

1
BR IGHT
4
a Operation Mode Indicator (pg. 30)
B Folder/File Number (pg. 30) C Battery Remaining Power Indicator
(pg. 58)
D Brightness Control Indicator (LCD monitor/
Viewfinder) (墌 pg. 17)
2
100-0013
50m
3

Before Using This Camcorder

Make sure you only use cassettes with the Mini DV mark .
Make sure you only use memory cards* with the mark or .
This camcorder is designed exclusively for the digital video cassette, SD Memory Card and MultiMediaCard. Only cassettes marked “ ” and memory cards marked “ ” or “ ” can be used with this unit.
* Memory cards can be used with GR-DF470 and
GR-DF450 only.
Remember that this camcorder is not compatible with other digital video formats.
Remember that this camcorder is intended for private consumer use only.
Any commercial use without proper permission is prohibited. (Even if you record an event such as a show, performance or exhibition for personal enjoyment, it is strongly recommended that you obtain permission beforehand.)
Before recording important video, be sure to make a trial recording.
Play back your trial recording to make sure the video and audio have been recorded properly.
We recommend cleaning your video heads before use.
If you haven’t used your camcorder for a while, the heads may be dirty. We recommend periodically cleaning the video heads with a cleaning cassette (optional).
Be sure to store your cassette tapes and camcorder in the proper environment.
Video heads can become dirty more easily if your cassette tapes and camcorder are stored in a dusty area. Cassette tapes should be removed from the camcorder and stored in cassette cases. Store the camcorder in a bag or other container.
Use SP (Standard) mode for important video recordings.
LP (Long Play) mode lets you record 50% more video than SP (Standard) mode, but you may experience mosaic-like noise during playback depending on the tape characteristics and the usage environment. So, for important recordings, we recommend using SP mode.
It is recommended that you use JVC brand cassette tapes.
Your camcorder is compatible with all brands of commercially available cassette tapes complying with the MiniDV standard, but JVC brand cassette tapes are designed and optimized to maximize the performance of your camcorder.
Also read “CAUTIONS” on pages 62 – 65.
®
Microsoft trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Macintosh is a registered trademark of Apple Computer, Inc.
QuickTime is a registered trademark of Apple Computer, Inc.
and Windows® are either registered

Provided Accessories

OR
a AC Adapter AP-V16U or AP-V14U b Battery Pack BN-VF707U c AV Ca bl e d Audio Extension Cable
(for optional microphone, pg. 12 for connection)
e USB Cable* f Core Filter [large]*
(for USB cable pg. 13 for attachment)
g Core Filter [small] x 2
(for Audio extention cable pg. 13 for attachment)
h Core Filter
(for AV cable pg. 13 for attachment)
i CD-ROM* j Remote Control Unit RM-V720U k Lithium Battery CR2025**
(for remote control unit)
l Memory Card 8 MB***
(Already inserted in the camcorder)
m Shoulder Strap (pg. 12 for attachment) n Lens Cap (see the right column for
attachment)
* GR-DF470/450 only ** A lithium battery is pre-installed in the Remote
Control Unit at time of shipment (with insulation sheet). To use the Remote Control Unit, remove the insulation sheet.
***GR-DF470 only
GETTING STARTED
NOTES:
In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter. If a cable has only one core filter, the end that is closest to the filter should be connected to the camcorder.
Make sure to use the provided cables for connections. Do not use any other cables.
EN 11

How To Attach The Lens Cap

To protect the lens, attach the provided lens cap to the camcorder as shown in the illustration.
NOTE:
To confirm the lens cap is on correctly make sure the cap is flush to the camcorder.
Place here during
shooting.
GETTING STARTED
CONTINUED ON NEXT PAGE
12 EN
GETTING STARTED

How To Attach The Shoulder Strap

Follow the illustration.
1 Thread the strap through the eyelet. 2 Fold it back and thread it through the strap
guide and the buckle.
To adjust the length of the strap, loosen and then tighten the strap in the buckle.
3 Slide the strap guide fully towards the eyelet.
Strap guide
Buckle

How To Use The Audio Extension Cable

When using an optional external microphone, connect to the provided Audio extension cable (with a core filter attached), then connect the Audio extension cable to the camcorder. The core filter reduces interference. (墌 pg. 13)
Open the
cover.
Eyelet
2
1
3
Stereo microphone
Core filter
To M IC
Audio extension cable (provided)

How To Attach The Core Filter

Attach the core filters to the cables. The core filter reduces interference.
1 Release the stoppers on both ends of the
core filter.
Stopper
2 Run the cable through the core filter, leaving
approx. 3 cm (1-3/16") of cable between the cable plug and the core filter. Wind the cable once around the outside of the core filter as shown in the illustration.
3 cm (1-3/16")
Core filter
GETTING STARTED
EN 13

Power

This camcorder’s 2-way power supply system lets you choose the most appropriate source of power. Do not use provided power supply units with other equipment.

Charging The Battery Pack

BATT. RELEASE
Battery pack
Arrow
Battery pack mount
Open the cover.
To DC connector
mark
GETTING STARTED
Wind once.
3 Close the core filter until it clicks shut.
NOTES:
Take care not to damage the cable.
When connecting a cable, attach the end with the
core filter to the camcorder.
Power switch
POWER/CHARGE lamp
To AC outlet
AC Adapter
1 Set the Power Switch to “OFF”. 2 With the arrow on the battery pack pointing
right, push the battery pack slightly against the battery pack mount a.
3 Slide the battery pack to the right until it locks
in place b.
4 Connect the AC Adapter to the camcorder. 5 Plug the AC Adapter into an AC outlet. The
POWER/CHARGE lamp on the camcorder blinks to indicate charging has started.
6 When the POWER/CHARGE lamp goes out,
charging is finished. Unplug the AC Adapter from the AC outlet. Disconnect the AC Adapter from the camcorder.
CONTINUED ON NEXT PAGE
14 EN
A
GETTING STARTED
To detach the battery pack
Slide the battery pack to the left while pressing BATT. RELEASE to detach it.
Battery pack Charging time
BN-VF707U* Approx. 1 hr. 30 min.
BN-VF714U Approx. 2 hr. 40 min.
BN-VF733U Approx. 5 hr. 40 min.
* Provided
NOTES:
This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BN­VF707U/VF714U/VF733U battery packs. Using generic non-JVC batteries can cause damage to the internal charging circuitry.
If the protective cap is attached to the battery pack, remove it first.
During charging, the camcorder cannot be operated.
Charging is not possible if the wrong type of battery is used.
When charging the battery pack for the first time or after a long storage period, the POWER/ CHARGE lamp may not light. In this case, remove the battery pack from the camcorder, then try charging again.
If the battery operation time remains extremely short even after having been fully charged, the battery is worn out and needs to be replaced. Please purchase a new one.
Since the AC Adapter processes electricity internally, it becomes warm during use. Be sure to use it only in well-ventilated areas.
Using the optional AA-VF7 Battery Charger, you can charge the BN-VF707U/VF714U/VF733U battery pack without the camcorder.
After 5 minutes has elapsed in Record-Standby mode with the cassette inserted, the camcorder will automatically turn off its power supplied from the AC adapter. In this case, the battery charge starts if the battery is attached to the camcorder.

Using The Battery Pack

Perform steps 23 in “Charging The Battery Pack”.
Maximum continuous recording time
Battery pack LCD monitor on Viewfinder on
BN-VF707U* 1hr.5min. 1hr.25min.
BN-VF714U 2 hr. 20 min. 3 hr.
BN-VF733U 5 hr. 25 min. 7 hr. 5 min.
* Provided
NOTES:
Recording time is reduced significantly under the following conditions:
Zoom or Record-Standby mode is engaged
repeatedly.
The LCD monitor is used repeatedly.
The playback mode is engaged repeatedly.
The LED Light is used.
Before extended use, it is recommended that you prepare enough battery packs to cover 3 times the planned shooting time.
TTENTION:
Before detaching the power source, make sure that the camcorder’s power is turned off. Failure to do so can result in a camcorder malfunction.

Data Battery System

You can check the remaining battery power and the recordable time.
1) Make sure the battery is attached and the
Power Switch is set to “OFF”.
2) Open the LCD monitor fully.
3) Press BATT. DATA, and the battery status
screen appears.
It can be displayed on the viewfinder when the LCD monitor is closed.
It is displayed for approx. 3 seconds if the button is pressed and released quickly, and for 15 seconds if the button is pressed and hold for several seconds.
If “COMMUNICATION ERROR” appears instead of the battery status even though you tried to press BATT. DATA several times, there may be a problem on the battery. In such a case, consult your nearest JVC dealer.

Using AC Power

Perform step 4 in “Charging The Battery Pack”.
NOTE:
The provided AC Adapter features automatic voltage selection in the AC range from 110 V to 240 V.

About Batteries

DANGER! Do not attempt to take the batteries apart, or expose them to flame or excessive heat, as it may cause a fire or explosion. WARNING! Do not allow the battery or its terminals to come in contact with metals, as this can result in a short circuit and possibly start a fire.
To resume the original function of the accurate battery power indication
If the battery power indication differs from the actual operating time, fully charge the battery, and then run it down. However this function may not turn back if the battery was used for a long period of time under extremely high/low temperature condition or charged too many times.

Operation Mode

To turn on the camcorder, set the Power Switch to any operation mode except “OFF” while pressing down the Lock Button located on the switch.
Power Switch
Lock Button
POWER/
VIDEO/MEMORY*
Choose the appropriate operation mode according to your preference using the Power Switch and VIDEO/MEMORY Switch.*
* GR-DF470/450 only
Power Switch Position
A (Full Auto Recording):
Allows you to record using NO special effects or manual adjustments. Suitable for standard recording. The “A” indicator appears on the display.
CHARGE lamp
GETTING STARTED
M (Manual Recording):
Allows you to set various recording functions using the Menus. (墌 pg. 36) If you want more creative capabilities than Full Auto Recording, try this mode.
OFF: Allows you to switch off the camcorder.
PLAY:
Allows you to play back a recording on the tape.
Allows you to display a still image stored in the memory card or to transfer a still image stored in the memory card to a PC. (GR-DF470/450 only)
Allows you to set various playback functions using the Menus. (墌 pg. 36)
VIDEO/MEMORY Switch Position
(GR-DF470/450 only)
VIDEO:
Allows you to record on a tape or play back a tape. If “REC SELECT” is set to “ / ” (pg. 40), still images are recorded both on the tape and the memory card.
MEMORY:
Allows you to record in a memory card or access data stored in a memory card.
When the Power Switch is set to “A” or “M”, the currently selected image size appears.
EN 15

Power-Linked Operation

When the Power Switch is set to “A” or “M”, you can also turn on/off the camcorder by opening/ closing the LCD monitor or pulling out/pushing in the viewfinder.
INFORMATION:
The following explanations in this manual supposes the use of LCD monitor in your operation. If you want to use the viewfinder, close the LCD monitor and pull out the viewfinder fully.
GETTING STARTED
16 EN
PAUSE
GETTING STARTED

Language Settings

The language on the display can be changed. (pg. 36, 39, 41)
1 Set the Power Switch to “M” while pressing
down the Lock Button located on the switch.
2 Open the LCD monitor fully. (pg. 19) 3 Press MENU. The Menu Screen appears. 4 Press or to select
n”, and press SET. The CAMERA DISPLAY Menu appears.
5 Press or to select
“LANGUAGE”, and press SET.
6 Press or to select
the desired language, and press SET.
7 Press or to select
BRETURN”, and press SET twice. The Menu Screen closes.
ex. for GR-DF470/ 450
LANGUAGE
J
NRETUR
LA DASERA CM I YP
BRIGHT
LC – T/D
NCREON S E
AU
/TI DA E
MET
OT
OF
CO TI E
DEM
F
LANGUAGE ENGLISH
OND–OLEV.AU DEC 02
OK CL CI
: 0 0
5
AD .
LA DASERA CM I YP
ENGLISH FRANÇAIS ESPAÑOL PORTUGUÊS

Date/Time Settings

The date/time is recorded onto the tape at all times, but its display can be turned on or off during playback. (墌 pg. 36, 41)
1 Perform steps 1 – 4 in “Language Settings”
above.
2 Press or to select “CLOCK ADJ.”, and
press SET. The parameter for “Month” is highlighted.
I Y
D
P
ASERA CM
3 Press or to input
the day, and press SET. Repeat to input the day, year, hour and minute.
4 Press or to select
BRETURN”, and press SET twice. The Menu Screen closes.
O
KCL C
AD
J.
LA
02
ECD
:
5
0
0

Grip Adjustment

1 Adjust the velcro strip. 2 Pass your right hand
through the loop and grasp the grip.
3 Adjust your thumb and
fingers through the grip to easily operate the Recording Start/Stop
V
Button, Power Switch and Power Zoom Lever. Be sure to fasten the velcro strip to your preference.
' 0 5 PM

Viewfinder Adjustment

1 Set the Power Switch to “A” or “M” while
pressing down the Lock Button located on the switch.
2 Make sure the LCD monitor is closed and
locked. Pull out the viewfinder fully and adjust it manually for best viewability.
3 Turn the Diopter Adjustment Control until the
indications in the viewfinder are clearly focused.
Example:
CAUTION:
When retracting the viewfinder, take care not to
05
'
PM
pinch your fingers.
Diopter Adjustment Control
GETTING STARTED
EN 17

Brightness Adjustment Of The Display

1 Set the Power Switch
to “M” or “PLAY” while pressing down the Lock Button located on the switch.
2 Open the LCD monitor
fully. (pg. 19)
To adjust the brightness of
the viewfinder, pull out the viewfinder fully and set “PRIORITY” to “FINDER” (pg. 36, 39).
3 Press MENU. The
Menu Screen appears.
4 Press or to select “n”, and press SET.
The CAMERA DISPLAY or VIDEO DISPLAY Menu appears.
5 Press or to select “BRIGHT”, and press
SET. The Menu Screen closes and the brightness control indicator appears.
6 Press < or > until the appropriate brightness
is reached.
7 Press MENU to clear the brightness control
indicator from the display.
MENU
<
SET
>
BRIGHT

Tripod Mounting

To attach the camcorder to a tripod, align the direction stud and screw to the mounting socket and stud hole on the camcorder. Then tighten the screw clockwise.
Some tripods are not equipped with studs.

Loading/Unloading A Cassette

The camcorder needs to be powered up to load or eject a cassette.
Cassette holder cover
PUSH HERE
OPEN/EJECT Erase protection tab
Make sure the window side is facing out.
1 Slide and hold OPEN/EJECT in the direction
of the arrow, then pull the cassette holder cover open until it locks. The cassette holder opens automatically.
Do not touch internal components.
2 Inser t or remove a tape and press “PUSH
HERE” to close the cassette holder.
Be sure to press only the section labeled “PUSH HERE” to close the cassette holder; touching other parts may cause your finger to get caught in the cassette holder, resulting in injury or product damage.
Once the cassette holder is closed, it recedes automatically. Wait until it recedes completely before closing the cassette holder cover.
When the battery pack’s charge is low, you may not be able to close the cassette holder cover. Do not apply force. Replace the battery pack with a fully charged one or use AC power before continuing.
3 Close the cassette holder cover firmly until it
locks into place.
To protect valuable recordings
Slide the erase protection tab on the back of the tape in the direction of “SAVE”. This prevents the tape from being recorded over. To record on this tape, slide the tab back to “REC” before loading it.
Cassette holder
GETTING STARTED
CONTINUED ON NEXT PAGE
18 EN
A
GETTING STARTED
NOTES:
If you wait a few seconds and the cassette holder does not open, close the cassette holder cover and try again. If the cassette holder still does not open, turn the camcorder off then on again.
If the tape does not load properly, open the cassette holder cover fully and remove the cassette. A few minutes later, insert it again.
When the camcorder is suddenly moved from a cold place to a warm environment, wait a short time before opening the cassette holder cover.

Loading/Unloading A Memory Card (GR-DF470/450 only)

The provided memory card is already inserted* in the camcorder at the time of purchase.
Card Cover (MEMORY CARD)
Memory card
Clipped edge
NOTES:
Some brands of memory cards are not compatible with this camcorder. Before purchasing a memory card, consult its manufacturer or dealer.
Before using a new memory card, it is necessary to format the card. (墌 pg. 35)
TTENTION:
Do not insert or remove the memory card while the camcorder is turned on, as this may cause the memory card to be corrupted or cause the camcorder to become unable to recognize whether or not the card is installed.
Write/erase protection tab
* GR-DF470 only
1 Make sure the camcorder’s power is off. 2 Open the card cover (MEMORY CARD). 3 To load a memory card, firmly insert it with
its clipped edge first. To unload a memory card, push it once. After the memory card comes out of the camcorder, pull it out.
Do not touch the terminal on the reverse side of the label.
4 Close the card cover.
To protect valuable files (available only for SD Memory Card)
Slide the write/erase protection tab on the side of the memory card in the direction of “LOCK”. This prevents the memory card from being recorded over. To record on this memory card, slide the tab back to the position opposite to “LOCK” before loading it.
Label

Basic Recording

NOTE:
Before continuing, perform the procedures listed below:
Power (pg. 13)
Loading A Cassette (pg. 17)
VIDEO/MEMORY*
Power Zoom Lever
Power Switch
Recording Start/Stop Button
Lock Button
POWER/CHARGE Lamp
1 Remove the lens cap. (pg. 11) 2 Open the LCD monitor fully. 3 Set the VIDEO/MEMORY Switch to
“VIDEO”.*
4 Set the Power Switch to “A” or “M” while
pressing down the Lock Button located on the switch.
The POWER/CHARGE lamp lights and the camcorder enters the Record-Standby mode. “PAUSE” is displayed.
To record in LP (Long Play) mode, 墌 pg. 37.
5 To start recording, press the Recording Start/
Stop Button. “T REC” appears on the display while recording is in progress.
6 To stop recording, press the Recording Star t/
Stop Button again. The camcorder re-enters the Record-Standby mode.
* GR-DF470/450 only
Approximate recording time
Tape
30 min. 30 min. 45 min.
60 min. 60 min. 90 min.
80 min. 80 min. 120 min.
Recording mode
SP LP

VIDEO RECORDING

EN
19
NOTES:
If the Record-Standby mode continues for 5 minutes, the camcorder’s power shuts off automatically. To turn the camcorder on again, push back and pull out the viewfinder again or close and re-open the LCD monitor.
When a blank portion is left between recorded scenes on the tape, the time code is interrupted and errors may occur when editing the tape. To avoid this, refer to “Recording From The Middle Of A Tape” (墌 pg. 21).
To turn the beep sounds off, 墌 pg. 36, 38.

Tape Remaining Time

Approximate tape remaining time appears on the display. “–h––m” means the camcorder is calculating the remaining time. When the remaining time reaches 2 minutes, the indication starts blinking.
The time required to calculate and display the remaining tape length, and the accuracy of the calculation, may vary according to the type of tape used.

LCD Monitor And Viewfinder

While using the LCD monitor:
Make sure the viewfinder is pushed back in. Pull on the end of the LCD monitor and open the LCD monitor fully. It can rotate 270° (90° downward, 180° upward).
While using the viewfinder:
Make sure the LCD monitor is closed and locked. Pull out the viewfinder fully.
180˚
90˚
VIDEO RECORDING & PLAYBACK
CONTINUED ON NEXT PAGE
20 EN
VIDEO RECORDING
NOTES:
The image will not appear simultaneously on the LCD monitor and the viewfinder. When the viewfinder is pulled out while the LCD monitor is opened, you can select which one to use. Set “PRIORITY” to the desired mode in SYSTEM Menu. (墌 pg. 36, 39)
Colored bright spots may appear all over the LCD monitor or the viewfinder. However, this is not a malfunction. (墌 pg. 57)

Zooming

Produces the zoom in/out effect, or an instantaneous change in image magnification.
Zoom In
Slide the Power Zoom Lever towards “T”.
Zoom Out
Slide the Power Zoom Lever towards “W”.
The further you slide the Power Zoom Lever, the quicker the zoom action.
Zoom in (T: Telephoto)
1xW
T
10xW
T
20xW
T
40xW
T
Zoom out (W: Wide angle)
10xW
T
Digital zoom zone
15X (optical) zoom zone
Approximate zoom ratio
Macro shooting (as close as approx. 5 cm (2") to
the subject) is possible when the Power Zoom Lever is set all the way to “W”. Also see “TELE MACRO” in MANUAL Menu on page 38.
When shooting a subject close to the lens, zoom out first. If zoomed-in in the auto focus mode, the camcorder may automatically zoom out depending on the distance between the camcorder and the subject. This will not occur when “TELE MACRO” is set to “ON”. (墌 pg. 38)

Journalistic Shooting

In some situations, different shooting angles may provide more dramatic results. Hold the camcorder in the desired position and tilt the LCD monitor in the most convenient direction. It can rotate 270° (90° downward, 180° upward).

Self Recording

Open the LCD monitor and tilt it upward to 180° so that it faces forward, point the lens toward yourself and start recording.
Self Recording
NOTES:
Focusing may become unstable during Zooming. In this case, set the zoom while in Record­Standby, lock the focus by using the manual focus (pg. 44), then zoom in or out in Record mode.
Zooming is possible to a maximum of 700X, or it can be switched to 15X magnification using the optical zoom. (墌 pg. 37)
Zoom magnification of over 15X is done through Digital image processing, and is therefore called Digital Zoom.
During Digital zoom, the quality of image may suffer.
Digital zoom cannot be used when the VIDEO/ MEMORY Switch is set to “MEMORY”.
(GR-DF470/450 only)

Time Code

During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback.
Display
Minutes Seconds Frames*
12:34:24
* Frames are not displayed during recording.
If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame). If recording starts from the end of a previously recorded scene, the time code continues from the last time code number. If during recording a blank por tion is left partway through the tape, the time code is interrupted. When recording is resumed, the time code starts counting up again from “00:00:00”. This means the camcorder may record the same time codes as those existing in a previously recorded scene. To prevent this, perform Recording From The Middle Of A Tape (See the right column.) in the following cases;
When shooting again after playing back a recorded tape.
When power shuts off during shooting.
When a tape is removed and re-inserted during
shooting.
When shooting using a partially recorded tape.
When shooting on a blank portion located partway
through the tape.
When shooting again after shooting a scene then opening/closing the cassette holder cover.
NOTES:
The time code cannot be reset.
During fast-forwarding and rewinding, the time
code indication does not move smoothly.
The time code is displayed only when “TIME CODE” is set to “ON”. (墌 pg. 39)
(30 frames = 1 second)
VIDEO RECORDING
EN 21

Quick Review

Enables to check the end of the last recording.
1) Press Q.REVIEW during the Recording­Standby mode.
2) Tape is rewound for about several seconds and played back automatically, then pauses in the Recording-Standby mode for the next shot.
Distortion may occur at start of playback. This is normal.

Recording From The Middle Of A Tape

1) Play back a tape or use Blank Search
(pg. 22) to find the spot at which you want to start recording, then engage the Still Playback mode. (墌 pg. 22)
2) Set the Power Switch to “A” or “M” while
pressing down the Lock Button located on the switch, then start recording.
VIDEO RECORDING & PLAYBACK
Loading...
+ 47 hidden pages
