How to read this manual

The following icons/symbols are used to indicate:

Press and hold the button(s)

[Hold]

until the desired operation begins.

Turn the control dial.

Turn the control dial to make a selection, then press to confirm.

( <XXXX> Menu setting item

Reference page number

XX)

Continued on the next page

How to attach/detach the control panel

How to reset your unit

Your preset adjustments will also be erased (except the registered Bluetooth device). ( 10)

How to forcibly eject a disc

[Hold]

• You can forcibly eject the loaded disc even if the disc is locked. To lock/unlock the disc,

• Be careful not to drop the disc when it ejects.

• If this does not work, reset your unit.

Thank you for purchasing a JVC product.

Please read all instructions carefully before

operation, to ensure your complete

understanding and to obtain the best possible

performance from the unit.

CONTENTS

3 How to read this manual 3 How to attach/detach the control

panel

3 How to reset your unit 3 How to forcibly eject a disc

4 Canceling the display

demonstration

4 Setting the clock 5 Preparing the remote controller 6 Basic operations 7 Listening to the radio 8 Listening to a disc 10 Using Bluetooth ® devices

11 Using a Bluetooth mobile phone 13 Using a Bluetooth audio player

15 Listening to the HD Radio ™

Broadcast

16 Listening to the satellite radio 18 Listening to the other external

components

19 Selecting a preset sound mode 20 Menu operations 25 Title assignment 26 More about this unit 29 Maintenance 30 Troubleshooting 34 Specifications

3ENGLISH

Canceling the display demonstration

1 Turn on the power.

[Hold]

(Initial setting)

Setting the clock

1 Turn on the power.

3 Select <CLOCK>.

4 Select <CLOCK SET>.

5 Adjust the hour.

[Hold]

(Initial setting)

4 Select <DEMO OFF>.

6 Finish the procedure.

6 Adjust the minute.

7 Finish the procedure.

4 ENGLISH

Preparing the remote controller

When you use the remote controller for the first time, pull out the insulation sheet.

Insulation sheet

For USA-California Only: This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material— special handling may apply. See www.dtsc.ca.gov/hazardouswaste/ perchlorate

If the effectiveness of the remote controller decreases, replace the battery.

Replacing the lithium coin battery

CR2025

Caution:

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• Battery shall not be exposed to excessive heat such as sunshine, fire, or the like.

Warning (to prevent accidents and damage):

• Do not install any battery other than CR2025 or its equivalent.

• Do not leave the remote controller in a place (such as dashboards) exposed to direct sunlight for a long time.

• Store the battery in a place where children cannot reach.

• Do not recharge, short, disassemble, heat the battery, or dispose of it in a fire.

• Do not leave the battery with other metallic materials.

• Do not poke the battery with tweezers or similar tools.

• Wrap the battery with tape and insulate when throwing away or saving it.

KD-A315 is equipped with the steering wheel remote control function. Before operating, connect an exclusive remote adapter (not supplied) which matches your car to the steering wheel remote input terminal on the rear of the unit.

• For details, refer also to the instructions supplied with the remote adapter.

5ENGLISH

Basic operations

Control dialEjects the disc Loading slot

Remote sensor

• DO NOT expose to bright sunlight.

Detaches the panel

When you press or hold the following button(s)...

Main unit

Remote

controller

Turns on.

• When the power is on, pressing /I/ATT on the remote controller also mutes the sound or pauses. Press /I/ATT again to cancel muting or resume playback.

Turns off if pressed and held. Selects the available sources (if the power is turned on).

• If the source is ready, playback also starts.

Adjusts the volume level.

Display window

Auxiliary input jack

General operation

6 ENGLISH

— Selects items.

• Mutes the sound during playback. If the source is “CD,” playback

—

— Returns to the previous menu.

—

pauses. Press the control dial again to cancel muting or resume playback.

• Confirms selection.

Selects the sound mode.

• Enters tone level adjustment directly ( 19) if pressed and held

EQ BASS-TRE

• Enters <COLOR> setting directly (

• Enters <COLOR SETUP> setting directly ( 22) if pressed and held.

Power off : Checks the current clock time. Power on : Changes the display information.

on the main unit.

22).

Listening to the radio

]

“FM” or “AM”

“ST” lights up when receiving an FM stereo broadcast with sufficient signal strength.

Manual search

“M” flashes, then press

[Hold]

the button repeatedly.

When an FM stereo broadcast is hard to receive

[Hold]

]

<TUNER> ] <MONO> ] <MONO ON> Reception improves, but stereo effect will be lost.

To restore the stereo effect, repeat the same procedure to select <MONO OFF>.

Changing the display information

Station name * = Frequency = Clock = (back to the beginning)

* If no title is assigned to a station, “NO NAME”

appears for a few seconds. To assign a title to a station, 25.

Automatic presetting (FM)—

SSM (Strong-station Sequential Memory)

You can preset up to 18 stations for FM.

While listening to a station...

[Hold]

]

<TUNER> ] <SSM> ] <SSM 01 – 06> / <SSM 07 – 12> / <SSM 13 – 18> “SSM” flashes and local stations with the strongest signal are searched and stored automatically.

To preset another 6 stations, repeat the above procedure by selecting one of the other 6 SSM setting ranges.

If an HD Radio tuner box is connected ( you can also search and store 6 stations for AM by following the above operations.

15),

7ENGLISH

Manual presetting (FM/AM)

You can preset up to 18 stations for FM and 6 stations for AM.

Ex.: Storing FM station of 92.50 MHz into preset number “04.”

]

“92.50MHz”

“PRESET MODE” flashes.

[Hold]

]

Selects preset number “04.”

“P04” flashes and “MEMORY” appears.

Listening to a disc

Selecting a preset station

Using the remote controller

5 U

/ D ∞: Changes the preset

stations

2 R

/ F 3: Searches for stations

Stopping playback and ejecting the disc

“NO DISC” appears. Press /

SOURCE

to listen to

another playback source.

Prohibiting disc ejection

To cancel the prohibition, repeat the same procedure.

8 ENGLISH

[Hold]

All tracks will be played repeatedly until you change the source or eject the disc.

Selects folder of the MP3/WMA

Selects track

Fast-forwards or

[Hold]

reverses the track

Selecting a track/folder

Selecting the playback modes

You can use only one of the following playback modes at a time.

[Hold]

For MP3/WMA discs, select the desired folder, then the desired track by repeating step 2.

• To return to the previous menu, press

BACK

Changing the display information

Disc title/Album name/performer (folder name)* = Track title (file name)* = Current track number with the elapsed playing time

Current track number with the clock

time = (back to the beginning)

* If the current disc is an audio CD, “NO NAME”

appears.

If an MP3/WMA file does not have Tag

information or <TAG DISPLAY> is set to <TAG OFF> ( 21), folder name and file name appear.

Caution on volume setting:

Discs produce very little noise compared with other sources. Lower the volume before playing a disc to avoid damaging the speakers by the sudden increase of the output level.

]

“REPEAT” j “RANDOM”

REPEAT TRACK RPT : Repeats current track FOLDER RPT : Repeats current folder

RANDOM FOLDER RND : Randomly plays all tracks

of current folder, then tracks of next folders

ALL RND : Randomly plays all tracks

To cancel repeat play or random play, select “RPT OFF” or “RND OFF.”

Using the remote controller

5 U

/ D ∞: Selects folder of the

MP3/WMA

2 R

/ F 3: Selects track

2 R

/ F

: Fast-forwards or

[Hold]

reverses the track

9ENGLISH

Using Bluetooth ® devices

For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA200 (not supplied) to the expansion port on the rear of this unit.

• Refer to pages i and ii at the end of the manual to check the countries where you may use the Bluetooth ® function.

• For details, refer also to the instructions supplied with the Bluetooth adapter and the Bluetooth device.

To use a Bluetooth device through the unit (“BT-PHONE” and “BT-AUDIO”) for the first time, you need to establish a Bluetooth wireless connection between the unit and the device.

• Once the connection is established, it is registered on the unit even if you reset your unit. Up to five devices can be registered in total.

• Only one device can be connected at a time for each source (“BT-PHONE” and “BT-AUDIO”).

Registration (Pairing) methods

Use either of the following items (“OPEN” or “SEARCH” ) in the Bluetooth menu to register and make the unit ready to establish a new Bluetooth connection with a device. “OPEN” : Connection is established by

operating the Bluetooth device.

“SEARCH” : Connection is established by

operating the unit.

Registering using “OPEN”

Preparation: Operate the device to turn on its Bluetooth function.

]

“BT-PHONE” or “BT-AUDIO”

]

“NEW DEVICE” ] “OPEN”

]

Enter a PIN (Personal Identification Number) code in to the unit. You can enter any number you like (1-digit to 16-digit number). [Initial: 0000]

• Some devices have their own PIN

code. Enter the specified PIN code in to the unit.

Repeat step 3 until you have finished

entering the PIN code.

“OPEN..” flashes. Use the Bluetooth device to search and

connect. On the device to be connected, enter the same PIN code you have just entered for this unit. “CONNECTED” appears. Now connection is established and you can use the device through the unit.

The device remains registered even after you disconnect the device. Use “CONNECT“ (or activate “AUTO CNNCT”) to connect the same device from next time on. (

11, 14)

10 ENGLISH

Registering a device (“SEARCH”/“SPECIAL”)

]

“BT-PHONE” or “BT-AUDIO”

]

“NEW DEVICE”

]

“SEARCH” : To search for available devices The unit searches and displays the list of the available devices. “UNFOUND” appears if no available device is detected.

– – – – – or – – – – –

]

“SPECIAL” : To connect a special device The unit displays the list of the preset devices.

]

Select a device you want to connect.

For available devices...

]

Enter the specific PIN code of the device to the unit.

• Refer to the instructions supplied with

the device to check the PIN code. Use the Bluetooth device to connect. Now connection is established and you can use the device through the unit.

For special device...

Use “OPEN” or “SEARCH” to connect.

Connecting/disconnecting/ deleting a registered device

]

“BT-PHONE” or “BT-AUDIO”

]

Select a device you want to

connect/disconnect/delete.

]

“CONNECT” or “DISCONNECT” : To

connect/disconnect the selected device

– – – – – or – – – – –

]

“DELETE” ] “YES” : To delete the

selected device

You can set the unit to connect the Bluetooth device automatically when the unit is turned on. ( “AUTO CNNCT,”

14)

Using a Bluetooth mobile phone

]

“BT-PHONE”

]

Bluetooth menu

! Make a call or setting using

the Bluetooth setting menu. ( 13)

11ENGLISH

When a call comes in....

The source is automatically changed to “BT-PHONE.”

• The display will flash in blue. (<RING COLOR>,

22)

When “AUTO ANSWER” is activated....

The unit answers the incoming calls automatically. (

• When “AUTO ANSWER” is deactivated, press any button (except answer the incoming call.

• You can adjust the microphone volume level. ( 14)

To end the call

Hold any button (except

14)

/ SOURCE

/ / 0) to

/ / 0).

When a text message comes in....

If the mobile phone is compatible with text message (notified through JVC Bluetooth adapter) and “MSG INFO” (message info) is set to “AUTOMATIC” ( 14), the unit rings to inform you of the message arrival.

• “RCV MESSAGE” (receiving message) appears and the display illuminate in blue. (<RING COLOR>,

22)

Using the remote controller

5 U

2 R

/ F 3 /

5 U

/ F 3 /

/ D ∞ /

[Hold]

: Answers calls

SOURCE

: Rejects calls

SOURCE

Making a call

]

“BT-PHONE”

]

Select “DIAL” menu.

]

Select a calling method.

PHONE BOOK* NUMBER VOICE DIAL REDIAL* RECEIVED* (back to

the beginning)

For REDIAL, RECEIVED, MISSED

]

Repeat step 4 to select a name (if it is

acquired) or a phone number.

For PHONE BOOK

]

Repeat step 4 to select a name or a

phone number.

For NUMBER

]

Enter a phone number.

]

Confirm.

For VOICE DIAL

]

Speak the name you want to call

when “SAY NAME” appears.

• If your mobile phone does not support the voice recognition system, “ERROR” appears.

• Using voice tags may be difficult in a noisy environment or during an emergency.

• To return to the previous menu, press

* Displays only when your mobile phone is

equipped with these functions and is compatible with this unit.

MISSED*

12 ENGLISH

Using a Bluetooth audio player

]

“BT-AUDIO” If playback does not start, operate the Bluetooth audio player to start playback. Operate the Bluetooth audio player to pause (if playback does not pause when you change the source).

Reverse skips/forward skips

Pauses/starts playback* * Operation may be different

according to the connected Bluetooth audio player.

Enter setting menu (Device list)

For connecting/disconnecting/deleting a registered device,

Using the remote controller

11.

2 R

/ F 3: Reverse skips/forward

skips

Changing the Bluetooth settings

]

“BT-PHONE” or “BT-AUDIO”

]

Bluetooth menu

]

“SETTINGS”

]

Select a setting item.

AUTO CNNCT Ô AUTO ANSWER *1

MSG INFO *2 Ô MIC SETTING *1

VERSION *3 Ô (back to the

beginning)

]

Change the setting accordingly. For

setting menu, 14.

Appears only when a Bluetooth phone is

connected.

*2 Appears only when a Bluetooth phone is

connected and it is compatible with text message (notified through JVC Bluetooth adapter).

*3 Bluetooth Audio: Shows only “Version.”

13ENGLISH

Setting menu ( : Initial)

AUTO CNNCT (connect)

When the unit is turned on, the connection is established automatically with...

OFF: No Bluetooth device. LAST: The last connected Bluetooth device. ORDER: The available registered Bluetooth

device found at first.

AUTO ANSWER

Only for the device being connected for “BT PHONE.” ON: The unit answers the incoming calls

automatically.

OFF: The unit does not answer the calls

automatically. Answer the calls manually.

REJECT: The unit rejects all incoming calls.

MSG INFO (message info)

Only for the device being connected for “BT-PHONE.” AUTOMATIC: The unit informs you of the

arrival of a message by ringing and displaying “RCV MESSAGE” (receiving message).

• The display illuminate in blue. (<RING COLOR>,

MANUAL: The unit does not inform you of

the arrival of a message.

MIC SETTING (microphone setting)

Only for the device being connected for “BT-PHONE.” Adjust microphone volume connected to the Bluetooth adapter, [LEVEL 01/02/03].

22)

Warning messages

ERROR CNNCT (Error Connection) The device is registered but the connection

has failed. Use “CONNECT” to connect the device again. ( 11)

ERROR

Try the operation again. If “ERROR” appears

again, check if the device supports the function you have tried.

UNFOUND

No available Bluetooth device is detected

by “SEARCH.” LOADING * The unit is updating the phone book.

PLEASE WAIT

The unit is preparing to use the Bluetooth

function. If the message does not disappear,

turn off and turn on the unit, then connect

the device again (or reset the unit).

RESET 8

Check the connection between the adapter

and this unit.

* Displays only when your mobile phone

is equipped with these functions and is

compatible with this unit.

Bluetooth Information: If you wish to receive more information about Bluetooth, visit the following JVC web site: <http://www.jvc.co.jp/english/car/> (English website only)

VERSION

The Bluetooth software and hardware versions are shown.

14 ENGLISH

Listening to the HD Radio ™ Broadcast

Before operating, connect HD Radio tuner box, KT-HD300 (not supplied) to the expansion port on the rear of the unit.

• For details, refer also to the instructions supplied with the HD Radio tuner box.

What is HD Radio Technology?

HD Radio Technology can deliver high-quality digital sound—AM digital will have FM-like quality (in stereo) and FM digital will have CD-like quality—with static-free and clear reception. Furthermore, stations can offer text and data, such as artist names and song titles.

• When the HD Radio tuner box is connected, it can also receive conventional analog broadcasts.

• Many HD Radio stations also offer more than one channel of programming. This service is called multicasting.

• To find HD Radio stations in your area, visit <http://www.hdradio.com/>.

For basic radio operations, 7, 8.

When receiving...

An HD Radio station

Lights up when digital audio is broadcast Flashes when analog audio is broadcast

Select your desired channel.

HD1 HD2 .... HD8

(back to the beginning)

“LINKING” appears while linking to a multicast channel.

Searching for HD Radio stations only

“HD” flashes.

[Hold]

Changing HD Radio reception mode

While receiving an HD Radio broadcast, the unit receives digital or analog audio automatically due to the receiving condition.

While listening to an HD Radio station...

[Hold]

Station Call Sign appears.

HD Radio multicast channels

Channel number

First four letters of Call Sign

]

<TUNER> ] <BLEND HOLD> ] <AUTO> / <DIGITAL> / <ANALOG> “HD” lights up when holding the digital reception or flashes when holding the analog reception.

• If no sound can be heard with <AUTO>, change the setting to <ANALOG> or <DIGITAL>.

• The setting automatically changes to <AUTO> if you tune in to or change to another station, or if you turn off the power.

15ENGLISH

• This setting cannot take effect for the conventional FM/AM stations.

• If the radio station forces the reception mode to digital, the HOLD indicator flashes.

Using the remote controller

5 U

/ D ∞: Changes the preset

stations

2 R

/ F 3: Searches for stations

Changing the display information

Call Sign *1 = Frequency = Title/artist/album name of the current segment *

(back to the beginning)

“ **** -FM” or “ **** ” appears when no Call Sign is received. “NO TEXT” appears when no text is received.

Listening to the satellite radio

Before operating, connect either one of the following systems (not supplied) to the expansion port on the rear of this unit.

For listening to a SIRIUS Satellite radio:

• SC-C1 and KS-SRA100

• PnP, SC-VDOC1 and KS-SRA100

For listening to an XM Satellite radio:

• JVC Smart Digital Adapter (XMDJVC100)

• CNP2000UC and CNPJVC1

• For details, refer also to the instructions supplied with the other components.

GCI (Global Control Information) update

• If channels are updated after subscription, updating starts automatically. “UPDATING” flashes and no sound can be heard.

• Update takes a few minutes to complete.

• During update, you cannot operate your satellite radio.

]

“SIRIUS” or “XM”

]

Select a category.

SIRIUS: If you select “ALL,” you can

tune in to all the channels of all categories.

]

Select a channel to listen.

Holding the button changes the

channels rapidly.

While searching, invalid and

unsubscribed channels are skipped.

XM: If you do not select a channel

within 15 seconds, category selected in step Ÿ is canceled. You can select all channels of all categories now (including non-categorised channels).

= Clock =

16 ENGLISH

Activate your SIRIUS subscription after connection

]

“SIRIUS” SIRIUS Satellite radio starts updating all the SIRIUS channels. Once completed, SIRIUS Satellite radio tunes in to the preset channel, CH184.

Check your SIRIUS ID. ( 21)

Contact SIRIUS on the internet at

<http://activate.siriusradio.com/> to activate your subscription, or you can call SIRIUS toll-free at 1-888-539-SIRIUS (7474).

• “SUB UPDT PRESS ANY KEY” scrolls on

the display once subscription has been completed.

Activate your XM subscription after connection

• Only Channel 0, 1, and 247 are available before activation.

]

“XM” XMDirect ™ Tuner Box or XMDirect2 Tuner System starts updating all the XM channels. “Channel 1” is tuned in automatically.

Check your XM Satellite radio ID labelled

on the casing of the XMDirect™ Tuner Box or XMDirect2 Tuner System, or tune in to “Channel 0”. ( right column)

Contact XM Satellite radio on

the internet at <http://xmradio. com/activation/> to activate your subscription, or you can call 1-800-XMRADIO (1-800-967-2346).

• Once completed, the unit tunes in to

one of the available channels (Channel 4 or higher).

Storing channels in memory

You can preset up to 18 channels for both SIRIUS and XM.

Ex.: Storing channel into preset number “04.”

Tune in to a channel you want to store.

(Steps ~ – !, 16.)

“PRESET MODE” flashes.

[Hold]

]

Select preset number “04.”

“P04” flashes and “MEMORY” appears.

Selecting SIRIUS/XM preset station

Checking the satellite radio ID

While selecting “SIRIUS” or “XM”...

]

Select “Channel 0.” SIRIUS: SIRIUS identification number is displayed after “Channel 0” is selected. XM: The display alternately shows “RADIO ID” and the 8-digit (alphanumeric) ID number.

To cancel the ID number display, select any channel other than “Channel 0.”

17ENGLISH

Using the remote controller

5 U

/ D ∞: Changes the

Category

DEMO

CLOCK

PRO EQ

Displayed only when SIRIUS Satellite radio or XM Satellite radio is connected.

* *2 Displayed only when <CLOCK ADJ> is set to <AUTO>.

[Hold]

Menu item Selectable setting, [Initial: Underlined]

DEMO

Display demonstration

CLOCK SET Clock setting—[1:00]

CLOCK ADJ *

Clock adjustment

TIME ZONE *

1, *2

DST * Daylight savings time

BASS —

MIDDLE

TREBLE

• DEMO ON

• DEMO OFF

• AUTO

• OFF

1, *2

EASTERN, ATLANTIC, NEWFOUND, ALASKA, PACIFIC, MOUNTAIN, CENTRAL

• DST ON

• DST OFF

: Display demonstration will be activated

automatically if no operation is done for about 20 seconds. ( 4)

: Cancels.

: Adjust the hour, then the minute. (

: The built-in clock is automatically adjusted using

the clock data provided via the satellite radio channel.

: Cancels.

: Select your residential area from one of the time

zones for clock adjustment.

: Activates daylight savings time if your residential

area is subject to DST.

: Cancels.

: For settings,

Repeat step 2 if necessary.

• To return to the previous menu, press

BACK

• To exit from the menu, press or

19.

DISP

20 ENGLISH

Category

Menu item Selectable setting, [Initial: Underlined]

DIMMER • DIMMER ON

• DIMMER OFF

SCROLL *

• SCROLL ONCE

• SCROLL AUTO

• SCROLL OFF

DISPLAY

Pressing regardless of the setting.

TAG DISPLAY • TAG ON

: Dims the display and button illumination. : Cancels.

: Scrolls the displayed information once. : Repeats scrolling (at 5-second intervals). : Cancels.

DISP

for more than one second can scroll the display

: Shows the Tag information while playing MP3/

WMA tracks.

SSM

Strong-station Sequential

• TAG OFF

• SSM 01 – 06 *

• SSM 07 – 12

• SSM 13 – 18

: Cancels.

: For settings,

Memory

AREA

Tuner channel interval

• AREA US

• AREA EU

: When using in North/Central/South America.

AM/FM intervals are set to 10 kHz/200 kHz.

: When using in any other areas. AM/FM intervals

are set to 9 kHz/50 kHz (100 kHz during auto search).

• AREA SA

: When using in South American countries where

FM interval is 100 kHz. AM interval is set to 10 kHz.

MONO *

TUNER

Monaural mode

SID * SIRIUS ID

• MONO ON

: Activate monaural mode to improve FM

reception, but stereo effect will be lost. ( 7)

• MONO OFF

: Restore the stereo effect.

— : Your SIRIUS identification number scrolls on the

display 5 seconds after “SID” is selected. ( 17)

If no operation is done for about 60 seconds,

the unit returns to playback mode.

BLEND HOLD *

• AUTO HD Radio reception mode

• DIGITAL

• ANALOG

Some characters or symbols will not be shown correctly (or will be blanked) on the display.

If an HD Radio tuner box is connected, you can also search and store the AM stations to

: Switch between digital and analog audio

automatically. ( 15) : Tune in to digital audio only. : Tune in to analog audio only.

<SSM 01 – 06>.

Displayed only when the source is “FM” or “HD Radio.”

Displayed only when SIRIUS Satellite radio is connected.

Displayed only when HD Radio tuner box is connected.

21ENGLISH

Category

Menu item Selectable setting, [Initial: Underlined]

IF BAND

Intermediate frequency band

TUNER

• AUTO

• WIDE

: Increases the tuner selectivity to reduce

interference noises between adjacent stations. (Stereo effect may be lost.)

: Subject to interference noises from adjacent

stations, but sound quality will not be degraded and the stereo effect will remain.

BUTTON ZONE COLOR 01 —

COLOR 29, USER

COLOR

DISP ZONE

Display zone

ALL ZONE

DAY COLOR • BUTTON ZONE

: For settings, 24. [ COLOR 06 ]

: For settings, 24. [ COLOR 01 ]

: For settings, 24. [ COLOR 06 ]

: For settings,

• DISP ZONE

NIGHT COLOR • BUTTON ZONE

: For settings, 24, 25.

• DISP ZONE

MENU COLOR

• ON

: Changes the display and buttons (except for 0

EQ BASS-TRE

list search and playback mode operations.

• OFF

RING COLOR *8• ON

COLOR SETUP

: Cancels.

: When a call comes in, the display will flash in

blue.

• The display will change to the original color when the call is answered or the incoming call stops.

When the unit receives a text message, the

display only illuminate in blue.

• OFF

FADER *

R06 – F06

[00]

BALANCE *

L06 – R06 [00]

AUDIO

LOUD

• LOUD ON

Loudness

• LOUD OFF

Displayed only when Bluetooth adapter, KS-BTA200 is connected.

: Cancels.

: Adjust the front and rear speaker output

balance.

: Adjust the left and right speaker output

balance.

: Boost low and high frequencies to produce a

well-balanced sound at a low volume level.

: Cancels.

*9 If you are using a two-speaker system, set the fader level to “00.”

This adjustment will not affect the subwoofer output.

24, 25.

DISP

) illumination during menu,

22 ENGLISH

Category

Menu item Selectable setting, [Initial: Underlined]

VOL ADJUST

Volume adjust

VOL ADJ –05 — VOL ADJ +05

[VOL ADJ 00]

: Preset the volume adjustment level of

each source (except FM), compared to the FM volume level. The volume level will automatically increase or decrease when you change the source.

• Before making an adjustment, select the source you want to adjust.

• “VOL ADJ FIX” appears on the display if “FM” is selected as the source.

L/O MODE

Line output mode

• SUB.W

• REAR

: Select if the REAR LINE OUT terminals are

used for connecting a subwoofer (through an external amplifier).

: Select if the REAR LINE OUT terminals are

used for connecting the speakers (through an external amplifier).

SUB.W FREQ *

AUDIO

Subwoofer cutoff frequency

• LOW

: Frequencies lower than 72 Hz are sent to the

subwoofer.

• MID

: Frequencies lower than 111 Hz are sent to

the subwoofer.

• HIGH

: Frequencies lower than 157 Hz are sent to

the subwoofer.

SUB.W LEVEL * Subwoofer level

SUB.W 00 — SUB.W 08

: Adjust the subwoofer output level.

[SUB.W 04]

BEEP

Keytouch tone

AMP GAIN * Amplifier gain control

Displayed only when <L/O MODE> is set to <SUB.W>.

The volume level automatically changes to “VOLUME 30” if you change to <LOW POWER> with the

• BEEP ON

• BEEP OFF

• LOW POWER

• HIGH POWER

: Activates the keypress tone. : Deactivates the keypress tone.

: VOLUME 00 – VOLUME 30 (Select if the

maximum power of each speaker is less than 50 W to prevent damaging the speakers.)

: VOLUME 00 – VOLUME 50

volume level set higher than “VOLUME 30.”

23ENGLISH

Category

Displayed only when any source other than “AM” is selected.

Displayed only when any source other than “EXT INPUT“ is selected.

Displayed only when any source other than “AUX IN“ is selected.

Menu item Selectable setting, [Initial: Underlined]

AM * AM station

EXT IN * External input

SRC SELECT

AUX IN *

Auxiliary input

• AM ON

• AM OFF

• EXT ON

• EXT OFF

• AUX ON

• AUX OFF

: Enable “AM” in source selection. : Disable “AM” in source selection.

: Enable “EXT IN” in source selection. : Disable “EXT IN” in source selection.

: Enable “AUX IN” in source selection. : Disable “AUX IN” in source selection.

Selecting the variable buttons and display color illumination

You can select your preferred color for buttons illumination (except for 0 / and display color seperately.

Button zone

All zone

[Hold]

EQ BASS-TRE / DISP

Display zone

)

]

<COLOR> ] <BUTTON ZONE> /

• Pressing

COLOR

in step 1 will enter zone selection menu (BUTTON ZONE / DISP ZONE / ALL ZONE) directly.

]

Select your preferred color from one

of the 29 preset colors or <USER> color.

Repeat steps 2 and 3 to select a

different zone and your preferred color.

• If <ALL ZONE> is selected in step 2, the buttons and display illumination changed to the current/selected <BUTTON ZONE> color.

You can also change the <ALL ZONE>

color to one of your preferred color by performing step 3.

]

Exit from the setting.

Creating your own day and night colors—USER

You can create your own colors for <DAY COLOR> and <NIGHT COLOR> to apply to button zone and display zone.

• <DAY COLOR> Displayed when <DIMMER> is set to <DIMMER OFF>.

• <NIGHT COLOR> Displayed when <DIMMER> is set to <DIMMER ON>.

24 ENGLISH

Menu hierarchy Operation

DAY COLOR

COLOR SETUP

NIGHT COLOR

Ex.: Creating <USER> color for <BUTTON ZONE> in <DAY COLOR>.

]

]

• Holding selection menu (BUTTON ZONE / DISP ZONE) directly.

]

Select a primary color. RED GREEN BLUE (back to the beginning)

• BUTTON ZONE Follow example below.

• DISP ZONE Press

• BUTTON ZONE Press

• DISP ZONE

[Hold]

COLOR

in step 1 will enter zone

step 2.

[Hold]

BACK

after step 5, then select DISP ZONE in step 2.

BACK

after step 5, then select NIGHT COLOR in

]

Adjust the level of the selected primary color. 00 to 31

Repeat steps 3 and 4 to adjust other

primary colors.

]

Exit from the setting.

Title assignment

You can assign titles to 30 station frequencies (FM and AM) using 8 characters (maximum) for each title.

• If you try to assign titles to more than 30 station frequencies, “NAME FULL” appears. Delete unwanted titles before assignment.

• When HD Radio tuner box is connected, this feature will be disabled.

]

“FM” or “AM”

]

Show the title entry screen.

]

Select a character. ( 28)

[Hold]

]

Move to the next (or previous)

character position. Repeat steps 3 and 4 until you have

finished entering the title.

To erase the entire title, press and hold DISP is step 2, then press the control dial to confirm.

25ENGLISH

More about this unit

Basic operations

Turning off the power

• If you turn off the power while listening to a track, playback will start from where it had been stopped previously next time you turn on the power.

General

• If you change the source while listening to a disc, playback stops. Next time you select “CD” as the playback source, playback will start from where it had been stopped previously.

• After ejecting a disc, “NO DISC” appears and you cannot operate some of the buttons. Insert another disc or press select another playback source.

• If no operation is done for about 60 seconds after pressing be canceled.

/ SOURCE

button, the operation will

Tuner operations

Storing stations in memory

• During SSM search...

– All previously stored stations are erased and

the stations are stored anew.

– When SSM is over, the station stored in the

lowest preset number will be automatically tuned in.

• When storing a station manually, the previously preset station is erased when a new station is stored in the same preset number.

Disc operations

Caution for DualDisc playback

• The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

General

• This unit has been designed to reproduce CDs/CD Texts, and CD-Rs (Recordable)/CDRWs (Rewritable) in audio CD (CD-DA), MP3 and WMA formats.

• When a disc is inserted upside down, “PLEASE” and “EJECT” appear alternately on the display. Press 0 to eject the disc.

• MP3 and WMA “tracks” (words “file” and “track” are used interchangeably) are recorded in “folders.”

• While fast-forwarding or reversing on an MP3 or WMA disc, you can only hear intermittent sounds.

Playing a CD-R or CD-RW

• Use only “finalized” CD-Rs or CD-RWs.

• This unit can only play back files of the same type as those detected first if a disc includes both audio CD (CD-DA) files and MP3/WMA files.

• This unit can play back multi-session discs; however, unclosed sessions will be skipped while playing.

26 ENGLISH

• Some CD-Rs or CD-RWs may not play back on this unit because of their disc characteristics, or for the following reasons:

– Discs are dirty or scratched. – Moisture condensation has occurred on the

lens inside the unit. – The pickup lens inside the unit is dirty. – The files on the CD-R/CD-RW are written

using the “Packet Write” method. – There are improper recording conditions

(missing data, etc.) or media conditions

(stained, scratched, warped, etc.).

• CD-RWs may require a longer readout time

since the reflectance of CD-RWs is lower than that of regular CDs.

• Do not use the following CD-Rs or CD-RWs: – Discs with stickers, labels, or a protective seal

stuck to the surface. – Discs on which labels can be directly printed

by an ink jet printer. Using these discs under high temperature

or high humidity may cause malfunctions or damage to the unit.

Playing an MP3/WMA disc

• This unit can play back MP3/WMA files with

the extension code <.mp3> or <.wma> (regardless of the letter case—upper/lower).

• This unit can show the names of albums,

artists (performer), and Tag (Version 1.0, 1.1,

2.2, 2.3, or 2.4) for MP3 files and for WMA files.

• This unit can display only one-byte characters.

No other characters can be correctly displayed.

• This unit can play back MP3/WMA files

meeting the conditions below: – Bit rate: 8 kbps — 320 kbps – Sampling frequency: 48 kHz, 44.1 kHz, 32 kHz (for MPEG-1) 24 kHz, 22.05 kHz, 16 kHz (for MPEG-2) – Disc format: ISO 9660 Level 1/Level 2,

Romeo, Joliet, Windows long file name

• The maximum number of characters for file/folder names vary depending on the disc format used (includes 4 extension characters—<.mp3> or <.wma>).

– ISO 9660 Level 1: up to 12 characters – ISO 9660 Level 2: up to 31 characters – Romeo: up to 128 characters – Joliet: up to 64 characters – Windows long file name: up to 128

characters

• This unit can recognize a total of 512 files, 255 folders, and 8 hierarchical levels.

• This unit can play back files recorded in VBR (variable bit rate).

Files recorded in VBR have a discrepancy

in the elapsed time display, and do not show the actual elapsed time. In particular, this difference becomes noticeable after performing the search function.

• This unit cannot play back the following files:

– MP3 files encoded in MP3i and MP3 PRO

format.

– MP3 files encoded in an inappropriate

format. – MP3 files encoded with Layer 1/2. – WMA files encoded in lossless, professional,

and voice format. – WMA files which are not based upon

Windows Media ® Audio. – WMA files copy-protected with DRM. – Files which have data such as AIFF, ATRAC3,

etc.

• The search function works but search speed is

not constant.

27ENGLISH

Ejecting a disc

• If the ejected disc is not removed within 15 seconds, it is automatically inserted into the loading slot again to protect it from dust. Playback starts automatically.

Bluetooth operations

• While driving, do not perform complicated operation such as dialing the numbers, using phone book, etc. When you perform these operations, stop your car in a safe place.

• Some Bluetooth devices may not be connected to this unit depending on the Bluetooth version of the device.

• This unit may not work for some Bluetooth devices.

• Connecting condition may vary depending on the circumstances around you.

• When the unit is turned off, the device is disconnected.

HD Radio reception

• HD Radio broadcasting can normally be received in the USA, and it may also be received in countries where limited broadcasting has already begun.

• During SSM search...

– All stations including conventional FM/AM

stations are searched and stored for the selected band.

Satellite radio

• To know more about SIRIUS Satellite radio or to sign up, visit <http://www.sirius.com>.

• For the latest channel listings and programming information, or to sign up for XM Satellite radio, visit <http://www.xmradio. com>.

Available characters

ABCDEFGHI

JKLMNOPQR STUVWXYZ0 123456789

—/ <> Space

• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Victor Company of Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective owners.

• HD Radio ™ and the HD Radio Ready logo are proprietary trademarks of iBiquity Digital Corp.

• “SIRIUS” and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.

• XM and its corresponding logos are registered trademarks of XM Satellite Radio Inc.

• “SAT Radio,” the SAT Radio logo and all related marks are trademarks of SIRIUS Satellite Radio Inc., and XM Satellite Radio, Inc.

28 ENGLISH

Maintenance

How to clean the connectors

Frequent detachment will deteriorate the connectors. To minimize this possibility, periodically wipe the connectors with a cotton swab or cloth moistened with alcohol, being careful not to damage the connectors.

Connectors

Moisture condensation

Moisture may condense on the lens inside the unit in the following cases:

• After starting the heater in the car.

• If it becomes very humid inside the car. Should this occur, the unit may malfunction. In this case, eject the disc and leave the unit turned on for a few hours until the moisture has evaporated.

How to handle discs

When removing a disc from its case, press down

the center holder of the case and lift the disc out, holding it by the edges.

• Always hold the disc by the edges. Do not touch its recording surface.

When storing a disc in its case, gently insert the disc around the center holder (with the printed surface facing up).

• Make sure to store discs in cases after use.

Center holder

To keep discs clean

A dirty disc may not play correctly. If a disc does become dirty, wipe it with a soft cloth in a straight line from center to edge.

• Do not use any solvents (for example, conventional record cleaner, spray, thinner, benzine, etc.) to clean discs.

To play new discs

New discs may have some rough spots around the inner and outer edges. If such a disc is used, this unit may reject the disc. To remove these rough spots, rub the edges with a pencil or ball-point pen, etc.

Do not use the following discs:

Single CD—8 cm

(3-3/16”) disc

Sticker and sticker

residue

Unusual shape

Warped disc

Stick-on label

C-thru Disc

(semitransparent

disc)

Transparent or

semitransparent

parts on its recording

area

29ENGLISH

Troubleshooting

Symptom Remedy/Cause

Sound cannot be heard from the speakers.

“PROTECT” appears on the display and no operations can be done.

General

The unit does not work at all.

“AUX” cannot be selected. Check the <SRC SELECT>

SSM automatic presetting does not work.

Static noise while listening to the

FM/AM

radio.

“AM” cannot be selected.

Disc cannot be played back. Insert the disc correctly.

• CD-R/CD-RW cannot be played back.

• Tracks on the CD-R/CD-RW cannot be skipped.

Disc can neither be played back nor ejected.

• Adjust the volume to the optimum level.

• Make sure the unit is not muted/paused ( 6).

• Check the cords and connections.

Check to be sure the terminals of the speaker leads are covered with insulating tape properly, then reset the unit ( If “PROTECT” does not disappear, consult your JVC car audio dealer or a company supplying kits.

Reset the unit. (

( 24)

Store stations manually.

Connect the antenna firmly.

Check the <SRC SELECT>

• Insert a finalized CD-R/CD-RW.

• Finalize the CD-R/CD-RW with the component which you used for recording.

• Unlock the disc. (

• Eject the disc forcibly. ( 3)

3).

<AUX IN> setting.

<AM> setting. ( 24)

Disc sound is sometimes

Disc playback

interrupted.

“NO DISC” appears on the display. Insert a playable disc into the loading slot.

“PLEASE” and “EJECT“ appear alternately on the display.

30 ENGLISH

• Stop playback while driving on rough roads.

• Change the disc.

• Check the cords and connections.

Press

, then insert a disc correctly.

+ 77 hidden pages

JVC GET0626-001B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
