JVC GET0602-001A User Manual

KW-ADV792/KW-AVX720DVD RECEIVER WITH MONITOR

ENGLISH

RECEPTOR DVD CON MONITOR

RÉCEPTEUR DVD ET MONITEUR

For canceling the display demonstration, see page 12. Para cancelar la demonstración en pantalla, consulte la página 12. Pour annuler la démonstration des affichages, référez-vous à la page 12.

For installation and connections, refer to the separate manual. Para la instalación y las conexiones, refiérase al manual separado. Pour l’installation et les raccordements, se référer au manuel séparé.

KW-ADV792/KW-AVX720

INSTRUCTIONS

MANUAL DE INSTRUCCIONES

MANUEL D’INSTRUCTIONS

FRANÇAIS ESPAÑOL

For customer Use:

Enter below the Model No. and Serial No. which are located on the top or bottom of the cabinet. Retain this information for future reference.

Model No. Serial No.

GET0602-001A

[J]

Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best

possible performance from the unit.

INFORMATION (For U.S.A.)

ENGLISH

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help.

Caution:

Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to

qualified service personnel.

3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam. (For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with

optical instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

For safety...

• Do not raise the volume level too much, as this will

[European Union only]

block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

Caution:

This product has a fluorescent lamp that contains mercury. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities or for USA, the Electronic Industries Alliance: <http://www.eiae.org.>

Cautions on the monitor:

• The monitor built in this unit has been produced with high precision, but it may have some ineffective dots. This is inevitable and is not malfunction.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point pen or similar tool with the sharp tip.

Touch the buttons on the touch panel with your

finger directly (if you are wearing a glove, take it off).

• When the temperature is very cold or very hot...

– Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with the sound or picture quality may decline in such environments.

How to read this manual

• < > is used to indicate the variable screens/ menus/operations/settings that appear on the touch panel.

• [ ] is used to indicate the buttons on the touch panel.

page number) is used to indicate the

• ( reference page number of the related topics/ operations/settings.

• Operation index: To locate easily the desired operations/functions. (

• Indication language: English indications are used for the purpose of explanation. You can select the indication language from the <AV Menu>. (

63)

15)

How to reset your unit

• Your preset adjustments will also be erased (except the

registered Bluetooth device). ( 27, 38)

How to forcibly eject a disc

ENGLISH

WARNINGS: (To prevent accidents and damage)

• DO NOT install any unit or wire any cable in a location where;

– it may obstruct the steering wheel and gearshift

lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving.

If you need to operate the unit while driving, be

sure to look around carefully.

• The driver must not watch the monitor while driving.

Back

• You can forcibly eject the loaded disc even if the disc is

locked. To lock/unlock the disc, 30.

• Be careful not to drop the disc when it ejects.

• If this does not work, reset your unit.

Playable disc type

Disc type Recording format, file type, etc Playable

DVD

ENGLISH

• DTS sound cannot be reproduced.

DVD Recordable/Rewritable (DVD-R/-RW *2, +R/+RW *3)

• DVD Video: UDF bridge

• DVD-VR

• MPEG1/MPEG2/JPEG/MP3/ WMA/WAV: ISO 9660 level 1, level 2, Romeo, Joliet

Dual Disc DVD side

CD/VCD Audio CD/CD Text (CD-DA)

CD Recordable/Rewritable (CD-R/-RW)

• ISO 9660 level 1, level 2, Romeo, Joliet

*1 If you insert a DVD Video disc of an incorrect Region Code, “Region code error” appears on the screen. *2 DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not

playable.

*3 It is possible to play back finalized +R/+RW (Video format only) discs. “DVD” is selected as its disc type when a

+R/+RW disc is loaded. +RW double layer discs are not playable.

DVD-Video (Region Code: 1) *

DVD-Audio/DVD-ROM DVD-Video DVD-VR MPEG1/MPEG2 JPEG MP3/WMA/WAV AAC/DivX/MPEG4/DVD+VR/DVD-RAM

Non-DVD side

VCD (Video CD) DTS-CD/SVCD (Super Video CD)/CD-ROM/

CD-I (CD-I Ready) CD-DA VCD (Video CD) MPEG1/MPEG2 JPEG MP3/WMA/WAV AAC/DivX/MPEG4

Caution for DualDisc playback

The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

How to read this manual .............................. 3

How to reset your unit ................................. 3

How to forcibly eject a disc ........................... 3

Playable disc type ........................................ 4

INTRODUCTIONS

Basic operations ................................................. 6

• Using the monitor panel/touch panel ......... 6

• Using the remote controller (RM-RK252) .... 9

Preparation .................................................. 12

AV MENU

AV Menu operations .................................... 13

OPERATIONS

Listening to the radio ................................... 29

Disc operations ............................................. 30

• Operation buttons on the screen ................ 32

• Operations using the remote controller

(RM-RK252) ................................................ 33

USB operations ............................................ 37

EXTERNAL DEVICES

Using the Bluetooth® devices ....................... 38

• Connecting a new Bluetooth device ........... 38

• Using the Bluetooth cellular phone ............ 39

• Using the Bluetooth audio player ............... 41

Listening to the CD changer ......................... 41

Listening to the satellite radio ..................... 42

• Tuning in to a channel you want ................. 43

Listening to the HD Radio™ Broadcast ......... 44

Listening to the iPod/iPhone ....................... 45

• When connected with the USB cable .......... 45

• When connected with the interface

adapter ....................................................... 46

Using other external components ................ 47

• AV-INPUT .................................................... 47

• EXT-INPUT .................................................. 48

REFERENCES

More about this unit .................................... 48

Maintenance ................................................ 55

Troubleshooting ........................................... 56

Specifications ............................................... 61

Operation index ........................................... 63

ENGLISH

Basic operations

Using the monitor panel/touch panel

Display <AV Menu> screen, ( 13)

ENGLISH

Display the <Source Menu> screen, (

Display/exit the Short Cut icons, (

SOURCE

MP3

FLAT

3:00

Folder Name File Name

Track Title Artist Name Disc Title

01 01

USB cable from the rear of the unit, (

0:02:26

37)

1 Resets the unit ( 3). 2 • Turns on the power.

• Attenuates the sound (if the power is on).

• Turns off the power. (Hold)

3 Changes the display information. * 4 • Adjusts the volume.

•

Bluetooth PHONE

the incoming calls. *

5 Remote sensor 6 Touch panel (see the following pages).

• Most of the operations are explained using the

touch panel unless mentioned otherwise.

• The screen will turn off if no operation is

done for about 10 seconds (depends on the <Illumination> setting). ( 18)

: Adjusts the volume of

7 Motion sensor 8 Displays <AV Menu> screen. 9 • Selects the source. *

TUNER/HD Radio (DVD/VCD/CD) CD-CH/iPod/EXT-IN PHONE

= (back to the beginning)

•

Bluetooth PHONE

<Dial Menu> screen. (Hold) *

p • Selects “

• Switches the setting between “HEAD MODE” and

*1 – *4 : 7

USB/ iPod

“iPod MODE” (Hold)

SAT

USB/ iPod

Bluetooth AUDIO

: Displays the

” as the source.

DISC

Bluetooth

AV-IN

q • Displays <Open/Tilt> screen. *

[Open] : Opens the monitor panel. [Eject] : Ejects the disc. [Close] : Closes the monitor panel. [Tilt +] : Tilts open the monitor panel. [Tilt –] : Tilts close the monitor panel.

• Ejects the disc and display <Open/Tilt>

screen. (Hold)

• Closes the monitor panel when the panel is

opened.

w Monitor panel

<Source Menu> screen

You can also select the source using the touch panel.

SOURCE

TUNER

3:00

FLAT

1FM1 87. 5 MHz

ABC Radio

ENGLISH

BAND

*1 Available display information varies among the

playback sources. (

This adjustment does not affect the volume level of

53)

other sources.

*3 Available sources depend on the external components

you have connected, media you have attached, and the <Input> settings you have made. ( 17, 18)

*4 Only when Bluetooth phone is connected. *5 Shaded items cannot be used.

You can also adjust the volume by moving your finger on the touch panel as illustrated.

When you drag your finger on the touch panel, it functions in the same way as touching [

4 / ¢].

5 / ∞ /

Caution on volume setting:

Digital devices (CD/USB) produce very little noise compared with other sources. Lower the volume before playing these digital sources to avoid damaging the speakers by sudden increase of the output level.

Source Menu

Current source Exit

Touch panel and button illumination

Dependable on the <Illumination> setting.

( 18)

• Turned off: When no operation is done for about 10 seconds.

• Turned on again: – When you touch the touch panel or move your

hand nearby. – When you use the remote controller. – When a call/SMS comes in (for Bluetooth

cellular phone). – When the signal from the rear view camera

comes in

• Always turned on: – When <AV Menu> screen is displayed. – When <Source Menu> screen is displayed. – When <Open/Tilt> screen is displayed. – When <Illumination> is set to <Normal>.

Continued on the next page

7INTRODUCTIONS

Short Cut icons

You can easily access some frequently used functions by using the Short Cut icons.

SOURCE

TUNER

ENGLISH

3:00

FLAT

1FM1 87. 5 MHz

ABC Radio

Short Cut window appears.

• To exit from the window, press the button again.

SOURCE

TUNER

3:00

FLAT

1FM1 87. 5 MHz

Press a Short Cut icon.

Setup

Beep Telephone Muting

Illumination Motion Sensitiv. Initialize

Back

Touch Panel - LCD

The corresponding screen is displayed.

Normal Proximity/Motion Proxi/Motion-LCD

Touch Panel

BAND

Available icons vary among the sources.

Displays <Illumination> menu.

( 18)

Changes the sound mode. ( 19)

Turns on or off Track/Chapter Repeat.

( 22)

Displays <Aspect> menu.

( 15)

Activates <Voice Dialing> function.

( 26)

Displays <Redial> menu. ( 26)

Displays <Sirius ID> menu. ( 17)

Displays <Blend Hold> menu.

( 21)

Using the remote controller (RM-RK252)

Installing the batteries

R03/LR03/AAA

Insert the batteries into the remote controller by matching the polarity (+ and –) correctly.

Caution:

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• Battery shall not be exposed to excessive heat such as sunshine, fire, or the like.

If the effectiveness of the remote controller decreases, replace the batteries.

Before using the remote controller:

• Aim the remote controller directly at the remote sensor on the unit.

• DO NOT expose the remote sensor to bright light (direct sunlight or artificial lighting).

The following describes all the available operations for all the sources.

• To easily locate the available operations between

different type of files, 33, 34.

1 button

• Turns the power on if pressed briefly or

• Turns the power off if pressed and held.

2 5/∞ buttons

•

attenuates the sound when the power is on.

TUNER

: Selects the preset stations.

HD Radio SAT

: Selects a multicast channel.

: Selects the categories.

ENGLISH

Continued on the next page

9INTRODUCTIONS

•

DISC/USB

: – DVD-Video: Selects the title. – DVD-VR: Selects the program/Playlist. –

USB/CD-CH

/MP3/WMA/WAV: Selects the

folders if included.

•

iPod

ENGLISH

–

5 : Enters the main menu (then 5 / ∞ /

4 / ¢ work as menu

selecting buttons.)

5 : Returns to the previous menu.

∞ : Confirms the selection.

– ∞ : Pauses or resumes playback.

4 / ¢ buttons

•

TUNER/HD Radio

– Searches for stations automatically if pressed

briefly.

– Searches for stations manually if pressed and

held.

•

SAT

: – Selects a channel if pressed briefly. – Selects a channel rapidly if pressed and held.

•

DISC/USB/CD-CH

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held.

•

iPod

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held.

•

iPod

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held. In menu selecting mode: – Selects an item if pressed briefly. (Then, press

∞ to confirm the selection.)

– Skips 10 items at a time if pressed and held.

•

Bluetooth AUDIO

– Reverse skip/forward skip if pressed briefly.

3 VOL (volume) + / – buttons

• Adjusts the volume level.

•

Bluetooth PHONE

– Adjusts the volume of the incoming calls.

2nd VOL (volume) buttons

• Not applicable for this unit.

4 * ASPECT button

• Changes the aspect ratio of the playback pictures.

5 PHONE button

Applicable only when a Bluetooth phone is

connected.

• Displays <Dial Menu> screen.

• Displays <Redial> menu if pressed and held.

• Answers incoming calls.

6 * SETUP button

• Not applicable for this unit.

7 * TOP M (menu) button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Original Program screen.

• VCD: Resumes PBC playback.

8 OSD (on-screen display) button

• Shows the on-screen bar.

• Does not function as “*.”

9 SHIFT button

• Functions with other buttons.

p DISP (display) button

• Changes the display information.

q 1 / ¡ buttons

• MP3/WMA/WAV/

USB/ iPod

: Reverse search/

forward search.

w SOURCE button

• Selects the source.

e 3 (play) / 8 (pause) button

•

DISC/USB/ iPod

•

Bluetooth PHONE

•

Bluetooth AUDIO

r (end call) button

•

Bluetooth PHONE

: Starts playback/pauses.

: Answers incoming calls.

: Starts playback.

: Ends the call.

BAND button

•

TUNER/HD Radio/SAT

: Selects the bands.

7 (stop) button

•

DISC/USB/ iPod Bluetooth AUDIO

•

t * RETURN button

: Stops playback. : Pauses.

• VCD: Returns to the PBC menu.

y * MENU button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Playlist screen.

• VCD: Resumes PBC playback.

u * % / ﬁ buttons

• DVD-Video: Makes selection/settings.

•

CD-CH

: Changes discs in the magazine.

@ / # buttons

• DVD-Video: Makes selection/settings.

• MPEG Video: Skips back or forward by about 5 minutes.

ENT (enter) button

• Confirms selection.

i DUAL button

• Not applicable for this unit.

• Does not function as “#.”

o DIRECT button

•

DISC/USB

: Enters direct search mode for chapter/title/program/playlist/folder/track when pressed with SHIFT button ( 34).

CLR (clear) button

•

DISC/USB

: Erases the misentry when pressed with SHIFT button.

SURROUND button

• Not applicable for this unit.

* Functions as number buttons when pressed with SHIFT

button.

–

DISC/USB

: Enters chapter/title/program/playlist/ folder/track number after entering search mode by pressing SHIFT and DIRECT. (

–

TUNER/HD Radio/SAT

34)

: (Number 1 to 6) :

Enters preset station/channel number.

This unit is equipped with the steering wheel remote control function.

• See the Installation/Connection Manual (separate volume) for connection.

• Some of the operations might be different with the steering wheel remote control function.

ENGLISH

11INTRODUCTIONS

Preparation

Canceling the display demonstration and setting the clock

~ Turn on the power.

ENGLISH

Ÿ Display <AV Menu> screen.

! Display <Setup> screen.

AV Menu

⁄ Cancel the demonstration.

Select [

Off

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Metal

Blue

Auto

@ Set the clock.

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Setup

Time Set Time Format

BAND

OSD Clock Clock Adjust Time Zone DST

Back

Setup

Time Set Time Format OSD Clock Clock Adjust Time Zone DST

Back

Bright

Blue

AutoOnce

Auto

7 AM6 PM

1 : 00

12Hours 24Hours

Off

3 : 45

¤ Finish the procedure.

Back

AutoOnce

7 AM6 PM

12 INTRODUCTIONS

AV Menu operations

You can use the <AV Menu> for most of the operations and settings. The available menu items shown on the touch panel, depends on the selected source.

• Non-available items will be shaded.

The following steps are one of the fundamental procedures.

• You can perform the operations/change the settings by following these steps unless mentioned otherwise.

~ Turn on the power.

Ÿ Display <AV Menu> screen.

BAND

AV Menu

! Press the desired icon/item to perform

the desired operations/settings.

Moves to the preceding menu page

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Returns to the previous screen.

Moves to the succeeding menu page

• Some of the settings do not open the sub-setting screen, but just selecting an option will change the setting.

• To exit from the setting, press [

Indicates the next hierarchy level/setting item exists

Bright Blue

AutoOnce

Auto

7 AM6 PM

Indicates the remaining time before the current screen exit automatically.

Exit

ENGLISH

Setup : 14 – 18 Equalizer : 19 Sound : 20 Mode : 21 – 23 List : 24 – 25 Bluetooth : 26 – 28

Continued on the next page

13AV MENU

Menu item Selectable setting/item

Demonstration

ENGLISH

Wall Paper You can select the background picture of the screen.

Color You can select the color of the background picture.

Scroll

Dimmer

Display

Dimmer Time Set Dimmer Level You can select the brightness for dimmer.

Bright You can adjust the brightness of the screen.

Picture Adjust *

The ILLUMINATION CONTROL lead connection is required. (See the Installation/Connection Manual.)

*2 Adjustable only when the source is “

♦

Off

♦

: Cancels. : Activates the demonstration on the screen. To stop it

temporarily, touch the screen. (

♦

Bright, Future, Horizon, Plain

♦

Blue, Light-Blue, Red, Orange, Yellow, Green, Purple, Dark-Blue,

Dark-Green, Brown, Light-Brown, Black

♦

Off Once Auto

: Cancels. : Scrolls the displayed information once. : Repeats scrolling (at 5-second intervals).

• Touching the information bar scrolls the text regardless of the setting.

♦

Off

♦

Auto

♦

Dimmer Time Set

Sets the Dimmer On (

♦

01 (bright), 02 (middle), 03 (dark)

♦

–15 to +15; Initial 00

You can adjust the following to make the screen clear and legible for watching

: Cancels. : Activates dimmer. : Dims the monitor when you turn on the headlights. * : Activates the Dimmer Time setting (see below).

)/Off ( ) times.

the playback picture. The setting will be stored—one for “

iPod

” (common) and the other for “

AV-IN

Press [5] or [∞] to adjust. (–15 to +15; Initial 00)

♦

Bright

♦

Contrast

♦

Color

♦

Tint

DISC/USB/ iPod

: Adjust if the picture is too bright or too dark. : Adjust the contrast. : Adjust the color of the picture—lighter or darker. : Adjust the tint if the human skin color is unnatural.

” (the media must contain pictures or videos) or “

Initial: Underlined

12)

DISC/USB/

.”

AV-IN

.”

Menu item Selectable setting/item

Aspect *

Display

Language *

Time Set Time Format

OSD Clock

Clock Adjust *

Clock

Time Zone *

DST (Daylight Saving

5, *6

Time) *

Not adjustable when no picture is shown.

* *4 Turn off then on the power so that your setting takes effect. *5 Appears only when SIRIUS Satellite Radio or XM Satellite Radio is connected. *6 Appears only when <Clock Adjust> is set to <Auto>.

You can change the aspect ratio of the picture.

Aspect ratio of the incoming signal

Regular:

For 4:3 original pictures

Full:

For 16:9 original pictures

Panorama:

For viewing 4:3 pictures naturally on the wide screen

Auto: • For “

selected to match the incoming signals.

• For the other video sources: Aspect ratio is

fixed to <Regular>.

Select the indication language shown on the screen.

♦

English, Español, Français, Deutsch, Italiano, Nederlands, Svenska,

Dansk, Руccĸий, Português

• The characters you can enter for assigning the titles also change according to the language selected. ( 52)

Initial 1:00AM (

12)

Select either 12-hour system or 24-hour system. (

♦

12 Hours, 24 Hours

♦

Off

♦

Off

♦

Auto

: Cancels. : The clock time is displayed on the playback picture.

: Cancels. : The built-in clock is automatically adjusted using the clock

time data provided via the satellite radio channel.

5, *6

Select your residential area from one of the following time zones for clock adjustment.

Alaska, Pacific, Mountain, Central, Eastern, Atlantic, Newfoundland

Activates this if your residential area is subject to DST.

♦

Off

♦

: Cancels. : Activates daylight saving time.

4:3 16:9

DISC

”: Aspect ratio is automatically

12)

Continued on the next page

ENGLISH

15AV MENU

ENGLISH

Menu item Selectable setting/item

Menu Language * Audio Language * Subtitle *

Monitor Type *

16:9 4:3LB

4:3PS

OSD Position *

Select the menu language; Initial English ( 54) Select the audio language; Initial English ( 54) Select the subtitle language or erase the subtitle <Off>.; Initial Off

( 54)

Select the monitor type to watch a wide screen picture on the external monitor.

♦

16:9

: Select when the aspect ratio of the external

monitor is 16:9.

♦

4:3LB

(Letterbox)/

: Select when the aspect ratio of the external

monitor is 4:3.

4:3PS

(Pan Scan)

Select the position of the on-screen bar. ( 36)

♦

: Higher position. : Lower position.

File Type *

Select the playback file type when a disc/USB contains different types of files. You can store this setting separately for each source— “

DISC/USB

Disc

iPod Artwork *

♦

While playing back a track (in “HEAD MODE”), Artwork recorded for the track is displayed on the monitor.

♦

D. (Digital) Audio Output *

Select the signal format emitted through the DIGITAL OUT (optical) terminal. ( 53)

♦

*7 Selectable only for “

DISC/USB

.” (Playback stops when you change the setting.)

*8 Skip the track so that your setting takes effect.

.”

Audio Still Picture Video Audio&Video

Off On

PCM

Dolby D

Stream

: Plays back audio files. : Plays back JPEG files. : Plays back MPEG1/MPEG2 files. : Plays back audio files and MPEG1/MPEG2 files.

: Cancels. : Activates Artwork display. To display the artwork,

press DISP repeatedly.

• It takes 5 seconds or more to display an Artwork and no operations are available while loading it.

: Select this when connecting an amplifier or a

decoder incompatible with Dolby Digital or MPEG Audio, or when connecting to a recording device.

: Select this when connecting an amplifier or a

decoder compatible with Dolby Digital.

: Select this when connecting an amplifier or a

decoder compatible with Dolby Digital or MPEG Audio.

Menu item Selectable setting/item

Down Mix *

Disc

D. (Dynamic) Range Compres. (Compression) *

IF Band Width

Area Setting

Tuner

Sirius ID * AV Input *

Input

Selectable only for “

*10 Appears only when a SIRIUS Satellite Radio is connected. *11 Not selectable when “

The REVERSE GEAR SIGNAL lead connection is required. See Installation/Connection Manual. The rear view through

the camera appears on the screen in <Full> aspect ratio (regardless of the aspect ratio setting) when you shift the gear to the reverse (R) position. When you press DISP on the monitor panel, or when you shift the gear to another position other than the reverse (R) position, the rear view screen is cleared.

When playing back a multi-channel disc, this setting affects the signals reproduced through the LINE OUT jacks.

♦

You can enjoy a powerful sound at a low volume level while playing Dolby Digital software.

♦

Your SIRIUS identification number appears on the monitor.

You can determine the use of LINE IN and VIDEO IN jacks. ( 47)

♦

DISC/USB

AV-IN

” is selected as the source.

Dolby Surr.

: Select this to enjoy multi-channel surround audio by

connecting an amplifier compatible with Dolby Surround.

Stereo

Auto

: Normally select this.

: Select to apply the effect to multi-channel encoded

software.

On Auto

: Select to always use this function. : Increases the tuner selectivity to reduce interference noises

between adjacent stations. (Stereo effect may be lost.)

Wide

: Subject to the interference from adjacent stations, but

sound quality will not be degraded and the stereo effect will remain.

: When using in North/Central/South America. FM/AM

intervals are set to 200 kHz/10 kHz.

Europe

: When using in any other areas. FM/AM intervals are set to

50 kHz (100 kHz during auto search)/9 kHz.

: When using in South American countries where FM interval

is 100 kHz. AM interval is set to 10 kHz.

Off

: Select when no component is connected (“

skipped while selecting the source).

iPod (Off)

: Select when connecting the iPod/iPhone using the USB

Audio and Video cable for iPod/iPhone. ( 45)

Audio&Video Audio

Camera *

: Select when connecting an AV component such as a VCR. : Select when connecting an audio component such as a

portable audio player.

: Select when connecting a rear view camera to display the

picture (as it is taken).

Navigation

: Select when connecting a Navigation System. ( 47)

.” (Playback stops when you change the setting.)

AV-IN

Continued on the next page

ENGLISH

” is

17AV MENU

Input

ENGLISH

Menu item Selectable setting/item

External Input *

13, *14

For connecting an external component to the CD changer jack on the rear.

♦

Changer/iPod *

♦

External

: CD changer, (

41), iPod, ( 45).

: Any other than the above, ( 48).

♦

Off

♦

Off

♦

Muting1,

Muting2

: Cancels. : Activates the key-touch tone.

: Cancels. : Select either one which mutes the sounds while

using the cellular phone.

Beep

Telephone Muting *

Illumination You can turn off the screen and the light of the buttons on the monitor panel

while turning on the unit.

( 7)

Buttons on the

monitor panel

Screen

Normal: Always lights. Always lights. Proximity/Motion: Lights up when your

Always lights. hand moves close to the buttons.

Others

Proxi/Motion-LCD: Lights up when your

hand moves close to the buttons.

Touch Panel: Lights up when your

Lights up when your

hand moves close to

the buttons.

Always lights. finger touches the buttons or touch panel.

Touch Panel-LCD: Lights up when your

finger touches the buttons or touch panel.

Motion Sensitiv. Change the sensitivity of the sensor for <

♦

Low, Mid, High

Lights up when your

finger touches the

buttons or touch panel.

Illumination> above.

Initialize Initialize all settings you have made in <AV Menu>. Press and hold [Enter]

to initialize the settings, then reset the unit. (

*13 Not required for Bluetooth, Satellite radio interface, and XMDirect™ Tuner Box. They are automatically detected. *14 Not selectable when the component connected to the CD changer jack is selected as the source. *15 The name of the component detected through the CD changer jack is shown. *16 The TEL MUTING lead connection is required. See Installation/Connection Manual.

Selects a preset sound mode suitable to the music genre.

♦

Flat (Initial), Hard Rock, R&B, Pop, Jazz, Dance, Country, Reggae, Classic, User1, User2, User3

1 Display <AV Menu> screen.

2 Adjust the settings, then store.

Equalizer

ENGLISH

Back Edit

BAND

2 Display <Equalizer> screen.

AV Menu

3 Select a sound mode.

Equalizer

Back Edit

Moves to the other 6 sound modes.

Ex.: When <Hard Rock> is selected

Storing your own adjustments

You can store your adjustments into <User1>, <User2>, and <User3>.

1 Perform steps 1 and 2 above to enter the

<Equalizer> screen.

Make adjustments by moving each bar directly.

User Store

User1 User2 User3

Back

Ex.: When storing into <

User2>

Preset equalizing values

Sound

150 Hz

400 Hz

1 kHz

2.5 kHz

6.3 kHz

mode

60 Hz

Flat 00 00 00 00 00 00 00 Hard Rock +03 +03 +01 00 00 +02 +01 R&B +03 +02 +02 00 +01 +01 +03 Pop 00 +02 00 00 +01 +01 +02 Jazz +03 +02 +01 +01 +01 +03 +02 Dance +04 +02 00 –02 –01 +01 +01 Country +02 +01 00 00 00 +01 +02 Reggae +03 00 00 +01 +02 +02 +03 Classic +02 +03 +01 00 00 +02 00 User1/2/3 00 00 00 00 00 00 00

15 kHz

19AV MENU

Menu item Selectable setting/item

Fader/Balance Fader : Adjust the front and rear speaker output balance.

ENGLISH

• When using a two-speaker system, set the fader level to “0.”

♦

F6 to R6; Initial 0

Balance : Adjust the left and right speaker output balance.

♦

L6 to R6; Initial 0

Press [

5/∞/2/3 ] to adjust.

Fader/Balance

Back

Reset

Fader 0 Balance 0

Initial: Underlined

Volume Adjust *

Adjust and store the auto-adjustment volume level for each source, comparing to the FM volume level. The volume level will automatically increase or decrease when you change the source.

• <Fix> appears if “

♦

–12 to +12; Initial 00

TUNER/Bluetooth PHONE

” is selected as the source.

Subwoofer Level Adjust the subwoofer output level.

♦

–06 to +08; Initial 00

High Pass Filter

♦

Through

♦

: Select when the subwoofer is not connected. : Select when the subwoofer is connected.

Crossover Select the crossover frequency between the front/rear speakers and the

subwoofer.

♦

80Hz, 120Hz, 150Hz

Amplifier Gain *

You can change the maximum volume level of this unit.

♦

Off

♦

Low

: Deactivates the built-in amplifier. : VOL 00 to 30 (Select this if the maximum power of the

speakers is less than 50 W.)

♦

For “

DISC/USB

High

”: You can make the adjustments separately depending on the audio format—Dolby digital, MPEG

: VOL 00 to 50

Audio, and the others.

*2 The volume level automatically changes to “VOL 30” if you change to <Low> with the volume level set higher than

“VOL 30.”

Selectable items when the source is:

•

TUNER

•

: Mono, SSM, Title Entry

HD Radio DISC, USB, CD-CH, iPod

AV-IN, EXT-IN

: Mono, SSM, DX/Local, Blend Hold

: Repeat, Random

iPod

*1 : Repeat, Random, Audiobooks

: Title Entry

Menu item Selectable setting/item

Mono *

DX/Local Only for FM station of the HD Radio.

SSM (Strong-

station Sequential

Memory) *

When an FM stereo broadcast is hard to receive, activate monaural mode for better reception. The MONO indicator lights up.

♦

: Activate monaural mode to improve FM reception, but stereo effect

will be lost. The MONO indicator lights up.

♦

OFF

Local

: Restore the stereo effect.

: Activate to improve FM reception, but stereo effect will be lost. The LO

indicator lights up.

♦

: Restore the stereo effect.

You can automatically preset 6 stations for each FM band.

Mode

Mono SSM Title Entry

Back

Start

Enter

Initial: Underlined

ENGLISH

• Local FM stations with the strongest signals are searched and stored automatically in the FM band.

Blend Hold *

While receiving an HD Radio broadcast, the unit tunes to digital or analog audio automatically due to the receiving condition. You can change the HD Radio reception mode manually.

♦

Analog

♦

Digital

♦

Auto

Not applicable in “iPod MODE.” ( 45)

: Tuning to analog audio only. : Tuning to digital audio only. : Switch between digital and analog audio automatically.

*2 Only works for FM station and FM station of the HD Radio. *3 Also available for AM when an HD Radio tuner box is connected. *4 – Appears only when an HD Radio tuner box is connected. – If no sound can be heard from the selected setting, change the setting to <Analog> or <Digital>. – The setting automatically changes to <Auto> if you tuned in to or change to another station, or if you turned off

the power.

– This setting cannot take effect for the conventional FM/AM stations. – If the radio station forces the reception mode to digital, the DIGITAL indicator flashes.

Continued on the next page

21AV MENU

Menu item Selectable setting/item

Title Entry *5You can assign titles (up to 16 characters) to 30 station frequencies (FM and AM),

EXT-IN

. (For available characters, 52.)

Press [Enter] to show the <Title Entry> screen.

ENGLISH

;

Back

[Store] : Confirm the entry. [

2/3] : Move the cursor.

[BS] : Erase the character before the cursor. [Del] : Erase the character on the cursor. [Cap] : Change the letter case (upper/lower). [A

= 0 = Ä] : Change the character set.

[Space] : Enter a space.

Repeat *

Available items depend on the loaded disc type and playback file.

Source

Repeat

Chapter Title Program Disc Folder Track One All Off

♦

Chapter

♦

Title

♦

Program

♦

Disc

♦

Folder

♦

Track

♦

One

♦

All

♦

Off

Disc/file type

DVD-

Video

: Repeats current chapter. : Repeats current title. : Repeats current program (for DVD-VR, not available during Playlist playback). : Repeats all tracks of the current disc. : Repeats all tracks of the current folder. : Repeats current track. (For VCD: When PBC is not in used.) : Functions the same as “Repeat One” of the iPod. : Functions the same as “Repeat All” of the iPod. : Cancels.

DISC USB CD-CH iPod iPod

MPEG/

MP3/

DVD-VR

WMA/

WAV

JPEG VCD/CD

*5 Unavailable for AM/FM stations when an HD Radio tuner box is connected. *6 Not applicable in “iPod MODE.” ( 45)

MPEG/

MP3/

JPEG CD MP3 ——

WMA/

WAV

AV-IN

, and

Menu item Selectable setting/item

Random *7Available items depend on the loaded disc type and playback file.

Source

Disc/file type

Random

Folder Disc/USB (All) All Song Album Off

♦

Folder

♦

Disc/USB (All)

♦

All

♦

Song

♦

Album

♦

Off

Audiobooks You can select the playback speed of the “Audiobook” sound file in your iPod.

♦

Normal

♦

Faster

♦

Slower

Not applicable in “iPod MODE.” ( 45)

* *8 Not applicable for video file. *9 You can activate <Shuffle Songs> in <Search Mode> menu. ( 25)

DISC USB CD-CH iPod

MPEG/MP3/

WMA/WAV

VCD/CD

MPEG/MP3/

WMA/WAV

CD MP3 ——

: Randomly plays all tracks of the current folder, then tracks of the next

folders. : Randomly plays all tracks. (For VCD: When PBC is not in used.) : Randomly plays all tracks of all loaded discs. : Functions the same as “Shuffle Songs” *9 of the iPod. : Functions the same as “Shuffle Albums” of the iPod. : Cancels.

: Plays at normal speed. : Plays faster. : Plays slower.

iPod

ENGLISH

23AV MENU

Source Operation/setting

TUNER/

ENGLISH

HD Radio

SAT • Storing a preset channel manually

• Storing a preset station manually 1 Press [BAND], then [ / ] to tune in to the station you want to preset. 2 Select <List> from the <AV Menu>. 3 Press and hold a preset number.

List

FM1 FM2 FM3

Back

• Selecting a preset station on the list

List

FM1 FM2 FM3

Back

1 Press [BAND], then [5 CATEGORY / ∞ CATEGORY], then [ / ] to tune in to the

channel you want to preset.

2 Select <List> from the <AV Menu>. 3 Press and hold a preset number.

Back

List

SR1 SR2 SR3 Category

Category Name 1 Category Name 2 Category Name 3 Category Name 4 Category Name 5 Category Name 6

• Selecting a preset category/channel on the list

List

C A

Pop

C A

Rock

C A

Country

C A

Hip-Hop

C A

R&B/Urban

C A

Dance/Electronic

Back

SIRIUS HITS 1 STARLITE SIRIUS LOVE MOVIN’ EASY SIRIUS GOLD ’60s VIBRATIONS

The station selected in step 1 is now stored in preset number 4.

The channel selected in step 1 is now stored in preset number 4.

* Press: Skips the list up or down.

Drag: Scrolls the list up or down.

Source Operation/setting

DISC/USB Selecting a track on the list

If the device contains folders, you can display the Folder/Track (File) Lists, then start playback.

List

Folder 01 Folder 02 Folder 03 Folder 04 Folder 05 Folder 06

Back

Bluetooth PHONE

Selecting a preset phone number on the list to make a call

List

Phone Number

Back

CD-CH Selecting a disc on the list

Disc List

Disc 01

Disc 02

Disc 03

Back

To go to the other list

iPod

Selecting a track/video from <Search Mode>

• Not applicable in “iPod MODE.” ( 45)

Search Mode

Music Videos Shuffle Songs

Back

List

Playlists Artists Albums Songs Podcasts Genres

Back

0003/00990005/0035

Track001.mp3 Track002.mp3 Track003.mp3 Track004.mp3 Track005.mp3 Track006.mp3

Disc 04

MP3 Disc

Disc 06

Playlists Artists Albums Songs Podcasts Genres

0003/0099

Track 01 Track 02 Track 03 Track 04 Track 05 Track 06

1 Current folder list number/total

folder list number

2 Current track list number/total track

list number of the current folder

* Press: Skips the list up or down.

Drag: Scrolls the list up or down.

If an MP3 disc is selected, Folder/Track List appear. Select a track to start playback.

♦

Music : Playlists, Artists, Albums,

Songs, Podcasts, Genres, Composers, Audiobooks

♦

Videos : Video Playlists, Movies, Music

Videos, TV shows, Video Podcasts

♦

Shuffle Songs : Playback starts if this

is selected.

Current track (video) number/total track (video) number

ENGLISH

25AV MENU

Select “

Bluetooth PHONE

” or “

Bluetooth AUDIO

” as the source for operations.

• Firstly, use <Open> or <Search> to register and establish the connection with a device.

Menu item Selectable setting/item

ENGLISH

Dial Menu *

Select the method to make a call.

♦

Redial

♦

Received Calls

♦

Phonebook

♦

Missed Calls

♦

Phone Number

: Shows the list of the phone numbers you have dialed. : Shows the list of the received calls. : Shows the phone book of the connected cellular phone. : Shows the list of the missed calls. : Shows the phone number entry screen.

Phone Number

Back

[BS] : Erase the character before the cursor. [Del] : Erase the character on the cursor. [Preset] : Goes to Preset List. You can preset the entered

number by selecting a preset number.

[Dial] : Calls the entered number.

♦

Voice Dialing

: Only when the connected cellular phone has the voice

recognition system: = Speak the name you want to call.

Message *

If <Message Info> is set to <Manual>... ( 28)

Access the message list to read messages.

♦

Unread

♦

Read

♦

Unsent

♦

Sent

: Messages you have not read. : Messages you have read. : Messages you have not sent. : Messages you have sent.

• The number of messages in each history is also shown.

Only for the device connected for “

* *2 Selectable only when the source is “

Bluetooth PHONE

.”

Bluetooth PHONE

” and the connected cellular phone is compatible with SMS

(Short Message Service).

Menu item Selectable setting/item

Open Preparation:

• Operate the Bluetooth device to turn on its Bluetooth function.

• Make sure “NEW DEVICE” is selected. If not, press [ 5 ] or [ ∞ ] to select it.

1 Press <Open> on the <Bluetooth> menu. 2 Enter a PIN (Personal Identification Number) *

• You can enter any number you like (1-digit to 16-digit number).

PIN Code

Back

3 Operate the Bluetooth device to connect while “Open...” is displayed on the screen.

Enter the same PIN code (as entered in the above step) on the device to be connected.

Now connection is established and you can use the device through the unit.

• The device remains registered even after you disconnect the device. Use <Connect> or activate <Auto Connect> to connect the same device the next time.

Search Preparation:

• Make sure “NEW DEVICE” is selected. If not, press [

1 Press <Search> on the <Bluetooth> menu.

The unit searches for available devices and displays the list of them. (If no available

device is detected, “Device Unfound” appears.)

2 Select a device you want to connect. 3 Enter the specific PIN code of the device to the unit.

• Refer to the instructions supplied with the device to check the PIN code.

4 Operate the Bluetooth device to connect while “Connecting...” is displayed on the

screen.

Now connection is established and you can use the device through the unit.

Some devices have their own PIN code. Enter the specified PIN code to the unit.

You can enter [0] – [9] only. [BS] : Erases the character

before the cursor.

[Del] : Erases the character on

the cursor.

[Enter] : Confirms the entry.

5 ] or [ ∞ ] to select it.

ENGLISH

Continued on the next page

27AV MENU

Menu item Selectable setting/item

Special Device Only for “NEW DEVICE.”

Select a device you want to connect from the list of Bluetooth devices which require some special procedure to establish the Bluetooth connection. Then, use <Open> or

ENGLISH

Connect Only for the registered devices.

Disconnect Only for the connected devices.

Delete Pairing Only for the registered devices.

Settings Initial: Underlined

Selectable only for “

*5 Only for the cellular phone connected for “

<Search> to connect.

• Once the connection is established, it is registered in the unit. You can connect the unit

and the device by using <Connect> the next time.

Select a device from the list of registered devices, establish the connection with it.

Disconnect the current device before connecting another device.

Press <Yes> to confirm delete the registered devices.

Auto Connect *

When the unit is turned on, the connection is established automatically with...

♦

Auto Answer *

Message Info *

MIC Setting *

Off

♦

Last

♦

Order

♦

Off

♦

Reject

♦

Auto

♦

Manual

Adjust the volume of the microphone connected to the Bluetooth

: No Bluetooth device. : The last connected Bluetooth device. : The available registered Bluetooth device found

: The unit does not answer the calls automatically.

: The unit answers the incoming calls

: The unit rejects all incoming calls. : The unit informs you of the arrival of a message

: The unit does not inform you of the arrival of a

adapter.

♦

01/02/03

Version The Bluetooth software and hardware versions are shown.

Bluetooth PHONE

.”

Bluetooth PHONE

first.

Answer the calls manually.

automatically.

by ringing and displaying “Receiving Message.” To read the message, 40.

message.

.” Not selectable when “NEW DEVICE” is selected.

28 AV MENU

Listening to the radio

Preset number

SOURCE

TUNER

Band

Sound mode

Tuner indicator

FLAT

3:00

~ Press [SOURCE], then press [TUNER]. Ÿ Press [BAND]. ! Press [ ] or [ ] to search for a station—Auto Search.

• Manual Search: Hold either [ ]or [ ] until “Manual Search” appears on the screen, then press it repeatedly.

• The ST indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

1FM1 87. 5 MHz

ABC Radio

Assigned station name

( 22)

• If no name is assigned, “No Name” appears.

BAND

ENGLISH

Selecting a preset station

• Directly from the touch panel

SOURCE

TUNER

FLAT

3:00

You can also select a preset station using the remote controller ( 9) and from the Preset List ( 24).

You can display the Preset List by pressing [ ] or holding [5/∞].

1FM1 87. 5 MHz

ABC Radio

BAND

Changing the display information

( 53)

• To improve the FM reception, 21.

• To automatically preset stations into memory,

21.

• To manually preset stations into memory, 24.

• To assignning titles to stations, 22.

OPERATIONS

Disc operations

The disc type is automatically detected, then playback starts (for some discs, the top menu of the disc appears).

If a disc does not have any disc menu, all tracks on it will be played repeatedly until you change the source or eject

ENGLISH

the disc.

” appears on the screen, the unit cannot accept the operation you have tried to do.

If “

• In some cases, without showing “ ,” operations will not be accepted.

~ Open the monitor panel.

<Open/Tilt> menu is displayed.

• By pressing and holding the button, you can open the monitor panel and eject the disc.

Open/Tilt

Prohibiting disc ejection

You can lock a disc in the loading slot.

! Insert a disc.

Label side

Monitor panel closes automatically. If not, press [Close].

Caution:

Do not place your finger behind the monitor panel.

When playing back a multi-channel encoded disc, the multi-channel signals are downmixed.

• You can fully enjoy multi-channel sound by connecting an amplifier or a decoder compatible with these multi-channel sources. ( 53)

• To select the playback mode, 22, 23.

• To select tracks on the list, 25.

Back

To cancel the prohibition, repeat the same procedure to select <EJECT OK?>.

• Discs can be forcibly ejected. ( 3)

Changing the display information

Each time you press the button, the display changes to show the different information. ( 53)

Ex.: While playing a DVD Video

SOURCE

DVD

FLAT

CHAP. RPT

3:00

1 Audio format—Dolby Digital, MP3, WMA, WAV 2 Disc type—DVD, DVD-VR, VCD, CD 3 Video format—MPEG, VR-PRG (program), VR-

PLAY (playlist), PBC

4 [5 / ∞]

• DVD Video/DVD-VR: Selects title/program/ playlist.

• MPEG/JPEG/MP3/WMA/WAV:

– Selects folder – Displays Folder/Track List (Hold)

5 • DVD Video: Title no./Chapter no./Playing time

• DVD-VR: Program no. (or Playlist no.)/Chapter no./Playing time

• MPEG/MP3/WMA/WAV: Folder no./Track no./ Playing time

• JPEG: Folder no./Track no.

• VCD/CD: Track no./Playing time

6 [6 ]

Starts playback/pauses

7 Indicates the button pressed ( / 8 / 7 ) 8 Sound mode ( 19) 9

Playback mode ( 22, 23)

Disc/track information

• DVD Video/DVD-VR: Sampling frequency/Bit rate/Recorded signal channel no.

• MPEG/JPEG: Folder name/file name

• CD Text: Title/artist name/album name

– “No Name” appears for conventional CDs or if

not recorded

• MP3/WMA/WAV: Current folder name/current file name/tag data (current track title/artist name/album title) if it is recorded

q Stops playback w [4 / ¢]

• DVD Video/DVD-VR: Selects chapter.

• MPEG/JPEG/VCD/CD/MP3/WMA/WAV: Selects track.

• DVD Video/DVD-VR/MPEG/VCD/CD/MP3/WMA/ WAV: Reverse/forward search (Hold)

ENGLISH

31OPERATIONS

Operation buttons on the screen

You can display the following operation buttons while watching the playback pictures on the screen.

• If no operation is done after awhile, the operation buttons disappear (except when a disc menu is displayed).

ENGLISH

Touch the screen (center portion).

Touch [KEY].

KEY].

Touch [

[SOURCE] Displays <Source Menu> screen [5 ∞] 31 [3 / 8] Starts playback/pause [4 ¢] • Selects tracks

• Reverse/forward search (Hold) [ ] Displays <AV Menu> screen [7] Stops playback

• The above buttons also work when they are not shown on the screen (while watching the playback picture).

For DVD/VCD menu operation playback [5 ∞ 2 3] Selects the menu items [ENTER] Confirms the selection [TOP MENU] Displays the disc menu [MENU] Displays the disc menu [RETURN] Returns to the previous menu or

displays the menu (only for VCD with PBC)

For entering the numbers [0]–[9]=[ENTER] Enters numbers [Direct/CLR] • Switches between chapter/track

entry and title/folder entry

• Erases the last entry when you

enter a wrong number

Ex.: To enter “105,” press [1], [0], [5], then [ENTER]

Touch [

KEY].

To end the operations, touch the screen again.

*1 While a disc menu is played back for DVD, [KEY] is

automatically displayed. On the disc menu, you can select a menu item directly by touching it on the screen

*2 Displays Short Cut icons. ( 8) *3 Playback time. ( 31)

Operations using the remote controller (RM-RK252)

Button

Stop play Stop play

Start play/Pause (if pressed during play)

• Reverse/forward chapter search *1 (No sound

can be heard.)

• Slow motion *2 during pause (No sound can

be heard.)

– DVD-VR: Reverse slow motion does not work.

• Select chapter (during play or pause)

• Reverse/fast-forward chapter search *3 (No

sound can be heard.) (Hold)

• DVD-Video: Select title (during play or pause)

• DVD-VR: • Select program

•

Select playlist (during play or pause)

—

Select aspect ratio Select aspect ratio

Search speed:

*2 Slow motion speed: *3 Search speed: *4 Search speed: *5 Search speed:

Using menu driven features... (DVD-Video)

1 Enter the menu screen.

• MPEG: Start play/Pause (if pressed during play)

• JPEG: • Start play (Slide show: Each file is

shown for a few seconds.)

• Pause (if pressed during play).

• MPEG: Reverse/forward track search * sound can be heard.)

• MPEG: • Select track

• Reverse/fast-forward track search *

(No sound can be heard.) (Hold)

• JPEG: Select file

Select folder

• MPEG: Skip back or forward the scenes by about 5 minutes

Canceling the PBC playback... (VCD)

During stop...

ENGLISH

(No

2 Select an item you want to start play.

Number buttons

(0 – 9)

• To resume PBC, press TOP M/MENU.

Continued on the next page

33OPERATIONS

Button

Stop play Stop play Stop play

ENGLISH

Start play/Pause (if pressed during play)

Reverse/forward track search *

• Forward slow motion *7

during pause. (No sound can be heard.)

– Reverse slow motion does not

work.

• Select track

• Reverse/fast-forward track

search *8 (No sound can be heard.) (Hold)

—

Select aspect ratio

Search speed:

*7 Slow motion speed: *8 Search speed:

Searching for an item directly

1 While holding SHIFT, press DIRECT repeatedly to

select the desired search mode.

DVD-Video:

DVD-VR:

MPEG:

JPEG:

MP3/WMA/ WAV:

VCD/CD:

Start play/Pause (if pressed during play)

Reverse/forward track search *6Reverse/forward track search *

• Select track

• Reverse/fast-forward track

search *8 (Hold)

Start play/Pause (if pressed during play)

• Select track

• Reverse/fast-forward track

search *8 (Hold)

Select folder

—

——

2 While holding SHIFT, press the number buttons

(0 – 9) to enter the desired number.

3 Press ENT (enter) to confirm.

• For MPEG/JPEG/MP3/WMA/WAV, track is searched within the same folder.

• For DVD-VR, program/playlist search is possible during Original program playback (PG)/Playlist playback (PL).

• To erase a misentry, press CLR (clear) while holding SHIFT.

• To return to the previous screen, press RETURN.

Using the list screens... (DVD-VR)

1 Display the Original Program screen.

Display the Playlist screen.

2 Select an item you want to start play.

Original Program/Playlist screen

• Original Program

Operations using the

on-screen bar

(DVD/DVD-VR/MPEG/JPEG/VCD)

These operations are possible on the monitor using the remote controller.

1 Show the on-screen bar ( 36).

(twice)

2 Select an item.

3 Make a selection.

If pop-up menu appears...

• To cancel pop-up menu, press RETURN.

• For entering time/numbers, see the following.

ENGLISH

• Playlist

1 Original Program/Playlist number 2 Recording date 3 Recording source (TV station, the input terminal of

the recording equipment, etc.)

4 Start time of recording 5 Title of the program/playlist * 6 Highlight bar (current selection) 7 Creating date of playlist 8 Total number of chapters included in the playlist 9 Playback time

* The title of the original program or playlist may not be

displayed depending on the recording equipment.

Entering time/numbers

Press % / ﬁ to change the number, then press @ / # to move to the next entry.

• Each time you press % / ﬁ, the number increases/ decreases by one value.

• After entering the numbers, press ENT (enter).

• It is not required to enter the zero and tailing zeros (the last two digits in the example below).

Ex.: Time search DVD: _:_ _:_ _ (Ex.: 1:02:00) Press

% once, then # twice to go to the third entry, %

twice, then press ENT (enter).

Removing the on-screen bar

Continued on the next page

35OPERATIONS

On-screen bar

Ex.: DVD-Video

ENGLISH

Information

Operation

1 Disc type 2 • DVD-Video: Audio signal format type and

channel

• VCD: PBC

3 Playback mode *

DVD-Video: T. RPT: Title repeat C. RPT: Chapter repeat DVD-VR: C. RPT: Chapter repeat PG. RPT: Program repeat MPEG Video: T. RPT: Track repeat F. RPT: Folder repeat A. RND: All (Disc) random F. RND: Folder random JPEG: F. RPT: Folder repeat VCD *2: T. RPT: Track repeat A. RND: All (Disc) random

4 Playback information

Current title/chapter

5 Time indication

Current program/chapter Current playlist/chapter

Current track

Current folder/track Current folder/file

Elapsed playing time of the disc

(For DVD-Video, elapsed playing time of the current title/program/ playlist.)

DVD-Video/DVD-VR: Remaining

title/program/playlist time

VCD: Remaining disc time

Elapsed playing time of the current

chapter/track *

Remaining time of the current

chapter/track *

6 Playback status

Play Forward/reverse search Forward/reverse slow-motion Pause Stop

7 Operation icons

Change time indication (see 5) Time Search (Enter the elapsed

playing time of the current title/ program/playlist or of the disc.)

Title Search (by its number)

Repeat play * Random play *

Chapter Search (by its number)

Track Search (by its number)

Change the audio language, audio

stream, or audio channel

Change or turn off the subtitle

language

Change the view angle

*1 For repeat play/random play, 22, 23. *2 While PBC is not in use. *3 Not applicable for DVD-VR.

USB operations

You can connect a USB mass storage class device such as a USB memory, Digital Audio Player, portable HDD, etc. to the unit.

• You can also connect the iPod to the USB terminal of the unit. For details of the operations, 45 – 46.

USB cable from the rear of the unit

ENGLISH

This unit can play JPEG/MPEG1/MPEG2/MP3/WMA/ WAV files stored in USB mass storage class device.

• You can operate the USB device in the same way you operate the files on discs.

• All tracks in the USB device will be played repeatedly until you change the source.

• Playback starts from where it has been stopped previously when you reconnect the same USB device again.

• To select the playback mode, 22, 23.

• To select tracks on the list, 25.

Changing the display information

( 53)

Cautions:

• Avoid using the USB device if it might hinder your safety driving.

• Do not pull out and attach the USB device repeatedly while “Now Reading” is shown on the screen.

• Do not start the car engine if a USB device is connected.

• This unit may not be able to play the files depending on the type of USB device.

• Operation and power supply may not work as intended for some USB devices.

• You cannot connect a computer to the USB input terminal of the unit.

• Make sure all important data has been backed up to avoid losing the data.

• Do not leave a USB device in the car, expose to direct sunlight, or high temperature to avoid deformation or cause damages to the device.

• Some USB devices may not work immediately after you turn on the power.

• For more details about USB operations, 50.

37OPERATIONS

Using the Bluetooth® devices

For Bluetooth operations, it is required to connect the Bluetooth adapter, KS-BTA200 (not supplied) to the CD changer jack on the rear of this unit.

• Refer also to the instructions supplied with the Bluetooth adapter and the Bluetooth device.

ENGLISH

• Refer to the list (included in the box) to check the countries where you may use the Bluetooth ® function.

To use a Bluetooth device through the unit (“ you need to establish Bluetooth wireless connection between the unit and the device.

• Once the connection is established, it is registered in the unit even if you reset your unit. Up to five devices can be registered in total.

• Only one device can be connected at a time for each source (“

Bluetooth PHONE

” and “

Bluetooth PHONE

Bluetooth AUDIO

”) for the first time,

” and “

Bluetooth AUDIO

Connecting a new Bluetooth device

Registration (Pairing) methods

Use either of the following items in <Bluetooth> menu to register and establish the connection with a device.

• Select “

Bluetooth PHONE

Open Make the unit ready to establish a new Bluetooth connection. The connection is established by

operating the Bluetooth device.

Search Make the unit ready to establish a new Bluetooth connection. The connection is established by

operating this unit.

• To register a device using <Open> or <Search>,

• To connect a special device, 28.

• To connect/disconnect/delete a device, 28.

Changing the display information

” or “

Bluetooth AUDIO

( 53)

” as the source to operate <Bluetooth> menu.

27.

”).

Bluetooth Information:

If you wish to receive more information about Bluetooth, visit the following JVC web site: <http://www.jvc.co.jp/english/car/> (English website only).

Using the Bluetooth cellular phone

Status of the device

• Signal strength/Battery remainder (only when the information comes from the device).

SOURCE

[5 / ∞]: Selects the other registered device.

Connected device name

• When a cellular phone with audio function is registered/connected,

appears.

ENGLISH

Activates <

Voice Dialing>

function. (Hold)

FLAT

3:00

Display <

• Appears on any source information screen

Connected Device Name

Dial Menu> screen.

when the Bluetooth adapter is connected.

Bluetooth icon

• Lights up when the Bluetooth adapter

is connected.

~ Press [SOURCE], then press [Bluetooth PHONE]. Ÿ Press [ ]. ! Press [Bluetooth]. ⁄ Establish the connection with a device, then make a call (or settings using <Bluetooth>

menu). (

When a call comes in...

The source is changed to “ automatically.

Name and phone number (if acquired)

When <Auto Answer> is activated...

The unit answers the incoming call automatically. ( 28)

26 – 28)

Bluetooth PHONE

To end the call

”

• Hold the message displayed on the touch panel.

• Hold any button on the monitor panel (except or VOL +/–).

• You can adjust the microphone volume, 28.

To make a call, use <Dial Menu>. ( 26)

When <Auto Answer> is deactivated... To answer the incoming call

• Press the message displayed on the touch panel.

• Press any button on the monitor panel (except or VOL +/–).

Continued on the next page

39EXTERNAL DEVICES

When an SMS comes in...

If the cellular phone is compatible with SMS (Short Message Service), you can read the messages on the screen.

• You cannot edit or send a message through the unit.

ENGLISH

When <Message Info> is set to <Auto>...

The unit rings and the following screen is displayed to inform you of a message arrival. (

Device Name

Receiving Message

Read ?

Yes No

To read the message, press [Yes]. The source is changed to “Bluetooth PHONE.”

To read the message later, press [No].

• The message is stored into <Message> = <Unread>. ( 26)

28)

Jack

Presetting the phone

numbers

You can preset up to 6 phone numbers.

1 Select the phone number you want to

preset from <Phonebook>, <Redial>, <Received Calls>, or <Missed Calls>.

( 26)

2 Select a telephone number to store.

Dial Menu

Back

3 Select a preset number.

Dial Menu

When <Message Info> is set to <Manual>...

Access the message list to read messages, 28.

To stop ringing (canceling the outgoing call)

Hold any button on the monitor panel (except or VOL +/–).

Back

Now “Tom” is stored into preset no. 1.

To call a preset number, 25.

Using the Bluetooth audio player

Starts playback/pause

SOURCE

FLAT

3:00

Connected Device Name

Indicates the button pressed.

• It may be different from the operation status.

ENGLISH

[4 / ¢]: Reverse/forward search

[5 / ∞]: Selects the other registered device.

Stops playback

~ Press [SOURCE], then press [Bluetooth AUDIO]. Ÿ Start playback.

If playback does not start automatically, operate the Bluetooth audio player to start playback.

Listening to the CD changer

It is recommended to use a JVC MP3-compatible CD changer with your unit.

• You can play only CDs (CD-DA) and MP3 discs.

Preparation:

Make sure <Changer> is selected for <External Input>. ( 18)

Ex.: While playing an MP3 disc

• [4 / ¢]: Selects track

• [4 / ¢]: Reverse/forward search (Hold)

SOURCE

CD-CH

FLAT

REPEAT

3:00

[5 / ∞]: Displays Disc List.

DISC 1

Current Folder Name Current File Name.mp3 Current Track Title Artist Name

Album Title

Tag data (if it is recorded) Folder no./Track no./Playing time

~ Press [SOURCE], then press [CD-CH]. Ÿ Press [ ]. ! Press [List].

⁄ Select a disc to start playing.

To select the playback mode, 22, 23.

41EXTERNAL DEVICES

Listening to the satellite radio

Before operating, connect either one of the following (not supplied) to the CD changer jack on the rear of this unit.

• JVC SIRIUS satellite radio System, SC-C1 and KS-SRA100, PnP, SC-VDOC1 and KS-SRA100, for listening to the SIRIUS Satellite radio.

ENGLISH

• XM satellite radio System, JVC Smart Digital Adapter–XMDJVC100, CNP2000UC and CNPJVC1 for listening to the XM Satellite radio.

GCI (Global Control Information) update

• If channels are updated after subscription, updating starts automatically, and no sound can be heard:

– For SIRIUS Satellite radio: “Channel is updating XX% completed” appears. – For XM Satellite radio: “UPDATING” appears.

• Update takes a few minutes to complete.

• Do not press any buttons or perform any operations until updating is completed.

For SIRIUS Radio

Activate your subscription after connection:

1 Turn on the power.

2 Select “SAT” for the source.

The SIRIUS Satellite radio starts updating all the

SIRIUS channels. ( “GCI update” above.)

• Once completed, SIRIUS Satellite radio tunes in

to the preset channel, CH184.

3 Check your SIRIUS ID. ( 17)

4 Contact SIRIUS on the internet at <http://

activate.siriusradio.com/> to activate your subscription, or you can call SIRIUS toll-free at 1-888-539-SIRIUS (7474).

“Subscription updated Press Any Key to Continue”

appears on the monitor once subscription has been completed.

For XM Radio

Activate your subscription after connection:

• Only Channel 0, 1, and 247 are available before activation.

1 Turn on the power.

2 Select “SAT” for the source.

The XMDirect ™ Universal Tuner Box starts updating

all the XM channels. “Channel 1” is tuned in automatically. ( “GCI update” above.)

3 Check your XM Satellite radio ID labelled on

the casing of the XMDirectTM Universal Tuner Box, or tune in to “Channel 0.” ( 43)

4 Contact XM Satellite radio on the internet

at <http://xmradio.com/activation/> to activate your subscription, or you can call 1800-XM-RADIO (1-800-967-2346).

Once completed, the unit tunes in to one of the

available channels (Channel 4 or higher).

Tuning in to a channel you want

SOURCE

SAT

Band

C A

Sound mode

Signal Reception

indicator

FLAT

LEVEL

3:00

Category Name

Channel Name

Song Title Artist Name Composer Name

1SR1 01

Listening to the iPod/iPhone

You can connect the iPod/iPhone using the following cable or adapter:

To Cable/adapter To operate

Listen to the music

Watch the video USB Audio and Video cable for iPod/iPhone, KS-U30

When connected with the USB cable

There are 2 control modes in ”

• “HEAD MODE” : Control by this unit.

• “iPod MODE” : Control by the connected iPod/iPhone. Make sure <iPod (Off)> is selected for <AV Input> when using KS-U30 to connect. ( 17)

• Press and hold to switch between “HEAD MODE” and “iPod MODE.” The operation explained below are under “HEAD MODE.”

USB 2.0 cable (accessory of the iPod/iPhone) to the USB cable from the rear of the unit.

Interface Adapter for iPod, KS-PD100 (not supplied) to the CD changer jack on the rear of the unit.

(not supplied) to the USB cable from the rear of the unit.

iPod

“ source.

• [5 / ∞]: Moves to the previous/next item of a category

• Enters <Search Mode> menu (Hold) *2 ( 25 )

Starts playback/pause

See “When connected with the USB cable” below.

See “When connected with the interface adapter” on page 46.

See “When connected with the USB cable” below.

• Make sure <iPod (Off)> is selected for <AV Input>,

17.

ENGLISH

Indicates the controlling unit for playback

• [4 / ¢]: Selects a track/video

• [4 / ¢]: Reverse/forward search (Hold)

SOURCE

HEAD MODE

FLAT

REPEAT

3:00

iPod

Current Track Title Artist Name

Album Title

~ Press [SOURCE], then press [ iPod].

Playback starts automatically.

• When you connect the iPod to the USB terminal, “ and playback starts automatically.

iPod

” is selected as the source

*1 [5 / ∞] may not

function depending on how you select the current track/video.

*2 Not applicable in “iPod

MODE.”

Track no./Playing time

Stops playback

Ÿ Press [4] or [¢] to select a track/

video.

You cannot resume playback for video sources.

Continued on the next page

45EXTERNAL DEVICES

The following operations/settings are only available in “HEAD MODE.”

• To display the <iPod Artwork>, 16.

• To select track/video from <Search Mode>, 25.

• To select the playback mode, 22, 23.

• To change the play speed of the audio books, 23.

ENGLISH

When connected with the interface adapter

Enters main menu

SOURCE

iPod

FLAT

REPEAT

3:00

Song Name Artist Name Album Title

Track no./Playing time

• [4 / ¢]: Reverse/forward search (Hold)

Preparation: Make sure <iPod> is selected for <External Input>. ( 18)

~ Press [SOURCE], then press [iPod].

Playback starts automatically.

Selecting a track from the main

Starts playback/pause• [4 / ¢]: Selects tracks

Ÿ Press [4] or [¢] to select a track.

3 Press [3 / 8] to confirm the selection. 4 Repeat steps 2 and 3 to select a track.

1 Press [SEARCH] to enter the main menu.

“SEARCH” flashes on the screen during menu

operations.

• This mode will be canceled if no operations are done for about 5 seconds.

2 Press [4] or [¢] to select the desired

item.

• Skips 10 items at a time if there are more than 10 items. (Hold)

Playlists

Ô Artists Ô Albums Ô Songs

Ô Genres Ô Composers Ô (back to the

beginning)

Changing the display information

• When a track is selected finally, playback starts.

• To return to the previous menu, press [SEARCH].

To select the playback mode, 22, 23.

( 53)

Using other external components

AV-INPUT

You can connect an external component to the LINE IN/VIDEO IN jacks.

Assigned title ( 22)

SOURCE

AV-IN

FLAT

3:00

~ Press [SOURCE], then press [AV-IN]. Ÿ Turn on the connected component and start playing the source.

To display the operation buttons while watching the playback picture, 32.

Navigation screen

You can also connect a Navigation System to the LINEIN/VIDEO IN jack so that you can watch the navigation screen.

Preparation: Make sure <Navigation> is selected for <AV Input>. ( 17)

ENGLISH

To view the navigation screen

Press DISP on the monitor panel repeatedly. ( 53)

• The aspect ratio of the navigation screen is fixed to <Full> regardless of the <Aspect> setting. ( 15)

When <Navigation> is selected for <AV Input> ( 17)

• You can use the source “

AV-IN

” for listening to an audio source connected to the LINE IN jacks.

Continued on the next page

47EXTERNAL DEVICES

EXT-INPUT

You can connect an external component to the CD changer jack on the rear using the Line Input Adapter, KS-U57 (not supplied) or AUX Input Adapter, KS-U58 (not supplied).

Assigned title ( 22)

ENGLISH

Preparation: Make sure <External> is selected for <External Input>. (

~ Press [SOURCE], then press [EXT-IN]. Ÿ Turn on the connected component and

SOURCE

EXT-IN

FLAT

3:00

18)

Changing the display information

( 53)

start playing the source.

More about this unit

General

Turning on the power

• By pressing SOURCE on the monitor panel, you can also turn on the power. If the source is ready, playback starts.

Tuner (FM only)

Storing stations in memory

• When SSM is over, received stations are preset in no. 1 (lowest frequency) to no. 6 (highest frequency).

Disc

General

• In this manual, words “track” and “file” are interchangeably used.

• This unit can only play back audio CD (CD-DA) files if different type of audio files (MP3/WMA/WAV) are recorded on the same disc.

Inserting a disc

• When a disc is inserted upside down or has no playable files, “Cannot play this disc Check the disc” appears on the screen. Eject the disc.

Ejecting a disc

• If “No Disc“ appears after removing a disc, insert a disc or select another playback source.

• If the ejected disc is not removed within 15 seconds, the disc is automatically inserted again into the loading slot to protect it from dust.

Playing Recordable/Rewritable discs

• This unit can recognize a total of 5 000 files and 250 folders (a maximum of 999 files per folder).

• Use only “finalized” discs.

• This unit can play back multi-session discs; however, unclosed sessions will be skipped while playing.

• This unit can recognize a total of 25 characters for file/folder names.

• Some discs or files may not be played back due to their characteristics or recording conditions.

Playing DVD-VR

• For details about DVD-VR format and playlist, refer to the instructions supplied with the recording equipment.

File playback

Playing MPEG1/MPEG2 files

• This unit can play back MPEG1/MPEG2 files with the extension code <.mpg>, <.mpeg>, or <.mod>*.

* <.mod> is an extension code used for the MPEG2 files

recorded by JVC Everio camcorders. The MPEG2 files with the <.mod> extension code cannot be played back when stored on a USB mass storage class device.

• The stream format should conform to MPEG system/ program stream.

The file format should be MP@ML (Main Profile at

Main Level)/SP@ML (Simple Profile at Main Level)/ MP@LL (Main Profile at Low Level).

• Audio streams should conform to MPEG1 Audio Layer-2 or Dolby Digital.

• The maximum bit rate for video signals (average) is 4 Mbps.

Playing JPEG files

• This unit can play back JPEG files with the extension code <.jpg>, or <.jpeg>.

• This unit can play back JPEG files that are at 32 × 32 to 8 192 × 7 680 resolution.

It may take time to display the file depending on its

resolution.

• This unit can play back baseline JPEG files. Progressive JPEG files or lossless JPEG files cannot be played.

Playing MP3/WMA/WAV files

• This unit can play back files with the extension code <.mp3>, <.wma>, or <.wav> (regardless of the letter case—upper/lower).

• This unit can play back the files meeting the conditions below:

– Bit rate: MP3/WMA: 32 kbps — 320 kbps – Sampling frequency: 48 kHz, 44.1 kHz, 32 kHz (for MPEG1) 24 kHz, 22.05 kHz, 16 kHz (for MPEG2) 48 kHz, 44.1 kHz, 32 kHz, 22.05 kHz (for WMA)

44.1 kHz (for WAV)

• This unit can show ID3 Tag Version

1.0/1.1/2.2/2.3/2.4 (for MP3).

• This unit can also show WAV/WMA Tag.

• This unit can play back files recorded in VBR (variable bit rate).

• Files recorded in VBR have a discrepancy in elapsed time indication.

• This unit cannot play back the following files:

– MP3 files encoded with MP3i and MP3 PRO format. – MP3 files encoded with Layer 1/2. – WMA files encoded with lossless, professional, and

voice format.

– WMA files which are not based upon Windows

Media® Audio. – WMA files copy-protected with DRM. – Files which have the data such as AIFF, ATRAC3,

etc.

Disc/file information shown on the

external monitor

The following screens appear only on the external monitor.

• CD

TIME 00:14

Track : 6 / 14

Cloudy Fair Fog Hail Indian summer

Rain

Shower Snow Thunder Typhoon Wind Winter sky

Continued on the next page

49REFERENCES

Track Information

Album Four seasons Artist Robert M. Smith Title Rain

T. RPT

ENGLISH

1 Selected playback mode 2 Elapsed playing time of the current track 3 Operation status 4 Current track number/total number of tracks on the

disc

5 Track information

ENGLISH

6 Track list 7 Current track (highlighted bar)

• MPEG1/MPEG2/JPEG/MP3/WMA/WAV

* If tag data includes “Jacket Picture” (baseline JPEG), it

will be displayed.

1 Current folder (highlighted bar) 2 Current folder number/total folder number 3 Folder list 4 Selected playback mode 5 Elapsed playing time of the current track (not

displayed for JPEG)

6 Operation status 7 Current track number/total number of tracks in the

current folder (total number of tracks on the disc)

8 Track information (only for MP3/WMA/WAV) 9 Track list p Current track (highlighted)

USB

• If “No USB Device“ appears after removing a device, reattach a device or select another playback source.

• When the USB device has no playable files, or has not been formatted correctly, “Cannot play this device Check the device” appears on the screen.

• This unit cannot recognize a USB device whose rating is other than 5 V and exceeds 500 mA.

• While playing from a USB device, the playback order may differ from other players.

• This unit may be unable to play back some USB devices or some files due to their characteristics or recording conditions.

• USB devices equipped with special functions such as data security functions cannot be used with the unit.

• Do not use a USB device with two or more partitions.

• Depending on the shape of the USB devices and connection ports, some USB devices may not be attached properly or the connection might be loose.

• When connecting a USB device, refer also to its instructions.

• Connect only one USB device to the unit at a time. Do not use a USB hub.

• This unit may not recognize a USB device connected through a USB card reader.

• When connecting with a USB cable, use the USB 2.0 cable.

• This unit may not play back files in a USB device properly when using a USB extension cord.

• This unit cannot assure proper functions or supply power to all types of the devices.

• This unit can recognize a total of 5 000 files and 250 folders (a maximum of 999 files per folder).

• This unit can recognize a total of 25 characters for file/folder names.

• For MPEG1/2 files: The maximum bit rate for video signals (average) is 2 Mbps.

Bluetooth operations

General

• While driving, do not perform complicated operation such as dialing the numbers, using phone book, etc. When you perform these operations, stop your car in a safe place.

• Some Bluetooth devices may not be connected to this unit depending on the Bluetooth version of the device.

• This unit may not work for some Bluetooth devices.

• Connecting condition may vary depending on circumstances around you.

• When the unit is turned off, the device is disconnected.

Warning messages for Bluetooth operations

• Connection Error:

The device is registered but the connection has failed.

Use <Connect> to connect the device again. ( 28)

• Error:

Try the operation again. If “Error” appears again,

check if the device supports the function you have tried.

• Device Unfound:

No available Bluetooth device is detected by

<Search>.

• Loading:

The unit is updating the phone book or SMS.

• Please Wait...:

The unit is preparing to use the Bluetooth function. If

the message does not disappear, turn off and turn on the unit, then connect the device again (or reset the unit).

• Reset08:

Check the connection between the adapter and this

unit.

Icons for phone types

• These icons indicate the phone type set on the device.

: Cellular phone

: Household phone

: Office

: General

: Other than above

CD changer

• If you select a folder, which does not include any music files, on the list ( 25), you will hear a beep. Select another folder including music files.

Satellite radio operations

• To know more about SIRIUS Satellite radio or to sign up, visit <http://www.sirius.com>.

• For the latest channel listings and programming information, or to sign up for XM Satellite radio, visit <http://www.xmradio.com>.

iPod/iPhone operations

• You can control the following types of iPod/iPhone:

(A) Connected with the USB cable: – iPod with video (5th Generation) * – iPod classic * – iPod nano *

1, *2

2, *3

– iPod nano (2nd Generation) * – iPod nano (3rd Generation) * – iPod nano (4th Generation) * – iPod Touch * – iPod Touch (2nd Generation) * – iPhone/iPhone 3G *

1, *2

(B) Connected with the interface adapter: – iPod with Click Wheel (4th Generation) – iPod mini – iPod photo – iPod with video (5th Generation) – iPod classic – iPod nano – iPod nano (2nd Generation) – iPod nano (3rd Generation) – iPod nano (4th Generation) *

*1 To watch the video with its audio, connect the iPod/

iPhone using USB Audio and Video cable (KS-U30, not supplied).

*2 “iPod MODE” is available, 45. *3 To listen to the sound in “iPod MODE,” connect

the iPod/iPhone using USB Audio and Video cable (KS-U30, not supplied).

*4 It is not possible to charge the battery through this

unit.

1, *2, *3

1, *2

Continued on the next page

51REFERENCES

ENGLISH

• If the iPod does not play correctly, update your iPod software to the latest version. For details about updating your iPod, visit <http://www.apple.com>.

• When you turn on this unit, the iPod is charged through the unit.

• The text information may not be displayed correctly.

ENGLISH

• The text information scrolls on the monitor. This unit can display up to 40 characters when using the interface adapter and up to 128 characters when using the USB 2.0 cable or USB Audio and Video cable (KS-U30).

Notice:

When operating an iPod/iPhone, some operations may not be performed correctly or as intended. In this case, visit the following JVC web site: <http://www.jvc.co.jp/english/car/> (English website only)

For the USB connection:

When <iPod Artwork> is set to <On>: Do not press any keys during the first 5 seconds or more of playing back any track containing an Artwork*. It takes 5 seconds or more to display an Artwork and no operations are available while loading it.

* The picture displayed on the iPod’s/iPhone’s screen

while playing back a track.

Characters you can enter for titles

In addition to the roman alphabet (A – Z, a – z), you can use the following characters to assign titles. (

22)

• When <Руccĸий> is selected for <Language>.

15)

(

Upper and lower cases

Numbers and symbols

• When any language other than <Руccĸий> is selected for <Language>. ( 15)

Upper and lower cases

Menu settings

• If you change the <Amplifier Gain> setting from <High> to <Low> while the volume level is set higher than “30,” the unit automatically changes the volume level to “VOL 30.”

• After you change any of <Menu Language/Audio Language/Subtitle> settings, turn off then on the power, and re-insert the disc (or insert another disc) so that your setting takes effect.

• When you select <16:9> for a picture whose aspect ratio is 4:3, the picture slightly changes due to the process for converting the picture width.

• Even if <4:3PS> is selected, the screen size may become <4:3LB> for some discs.

Numbers and symbols

Sound signals emitted through the rear terminals

Through the analog terminals (Speaker out/LINE OUT)

2-channel signal is emitted. When playing multi-channel encoded disc, multi-channel signals are downmixed.

• DTS sound cannot be reproduced.

Through the DIGITAL OUT terminal

Digital signals (Linear PCM, Dolby Digital, MPEG Audio) are emitted.

• DTS sound cannot be emitted.

• To reproduce the multi-channel sounds such as Dolby Digital and MPEG Audio, connect an amplifier or a decoder

compatible with these multi-channel sources to this terminal, and set <D. Audio Output> correctly. ( 16)

<D. Audio Output>

Playback disc

48 kHz, 16/20/24 bits Linear PCM 48 kHz, 16 bits stereo Linear PCM* 96 kHz, Linear PCM 48 kHz, 16 bits stereo Linear PCM

DVD

with Dolby Digital Dolby Digital bitstream

with MPEG Audio MPEG bitstream 48 kHz, 16 bits stereo Linear PCM

Audio CD, Video CD

with Dolby Digital Dolby Digital bitstream

MPEG

with MPEG Audio 32/44.1/48 kHz, 16 bits Linear PCM MP3/WMA 32/44.1/48 kHz, 16 bits Linear PCM WAV 44.1 kHz, 16 bits Linear PCM

* Digital signals may be emitted at 20 or 24 bits (at their original bit rate) through the DIGITAL OUT terminal if the discs

are not copy-protected.

Output signals

48 kHz, 16 bits stereo

Linear PCM

44.1 kHz, 16 bits stereo Linear PCM / 48 kHz, 16 bits stereo Linear PCM

48 kHz, 16 bits stereo

Linear PCM

ENGLISH

Display information

• Available display information varies among the playback sources.

Each time you press DISP, the display changes to show the various information.

*1 When the source is “

song is shown if the song has an Artwork data. (

16) While MP3/WMA file is played, “Jacket picture” is shown if the file has the tag data including “Jacket picture.”

*2 When <Navigation> is selected for <AV Input>.

( 17)

iPod

,” the Artwork of the

Ex.: When the playback source is a DVD video disc

Playback picture screen (only for video sources)

SOURCE

DVD

FLAT

CHAP. RPT

3:00

Source information screen

Navigation screen *

SOURCE

DVD

FLAT

3:00

Playback picture and source

information screen

53REFERENCES

Language codes (for DVD language selection)

Code

Language Code Language Code Language Code Language Code Language

AA Afar FA Persian KK Kazakh NO Norwegian ST Sesotho AB Abkhazian FI Finnish KL Greenlandic OC Occitan SU Sundanese AF Afrikaans FJ Fiji KM Cambodian OM (Afan) Oromo SW Swahili

ENGLISH

AM Ameharic FO Faroese KN Kannada OR Oriya TA Tamil AR Arabic FY Frisian KO Korean (KOR) PA Panjabi TE Telugu AS Assamese GA Irish KS Kashmiri PL Polish TG Tajik AY Aymara GD Scots Gaelic KU Kurdish PS Pashto, Pushto TH Thai AZ Azerbaijani GL Galician KY Kirghiz QU Quechua TI Tigrinya BA Bashkir GN Guarani LA Latin RM BE Byelorussian GU Gujarati LN Lingala RN Kirundi TL Tagalog BG Bulgarian HA Hausa LO Laothian RO Rumanian TN Setswana BH Bihari HI Hindi LT Lithuanian RW Kinyarwanda TO Tonga BI Bislama HR Croatian LV Latvian, Lettish SA Sanskrit TR Turkish BN Bengali, Bangla HU Hungarian MG Malagasy SD Sindhi TS Tsonga BO Tibetan HY Armenian MI Maori SG Sangho TT Tatar BR Breton IA Interlingua MK Macedonian SH Serbo-Croatian TW Twi CA Catalan IE Interlingue ML Malayalam SI Singhalese UK Ukrainian CO Corsican IK Inupiak MN Mongolian SK Slovak UR Urdu CS Czech IN Indonesian MO Moldavian SL Slovenian UZ Uzbek CY Welsh IS Icelandic MR Marathi SM Samoan VI Vietnamese DZ Bhutani IW Hebrew MS Malay (MAY) SN Shona VO Volapuk EL Greek JA Japanese MT Maltese SO Somali WO Wolof EO Esperanto JI Yiddish MY Burmese SQ Albanian XH Xhosa ET Estonian JW Javanese NA Nauru SR Serbian YO Yoruba EU Basque KA Georgian NE Nepali SS Siswati ZU Zulu

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation registered in the US, Japan and other countries.

• HD Radio ™ and the HD Radio Ready logo are proprietary trademarks of iBiquity Digital Corp.

• “SIRIUS” and the SIRIUS dog logo are registered trademarks of SIRIUS Satellite Radio Inc.

• XM and its corresponding logos are registered trademarks of XM Satellite Radio Inc.

• “SAT Radio,” the SAT Radio logo and all related marks are trademarks of SIRIUS Satellite Radio Inc., and XM Satellite Radio, Inc.

• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States

and/or other countries.

• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Victor Company of

Japan, Limited (JVC) is under license. Other trademarks and trade names are those of their respective owners.

• “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by

the developer to meet Apple performance standards.

• “Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and has been

certified by the developer to meet Apple performance standards.

• Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

• iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

• iPhone is a trademark of Apple Inc.

• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property

rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Rhaeto-Romance

TK Turkmen

Maintenance

Caution on cleaning the unit

Do not use any solvent (for example, thinner, benzine, etc.), detergent, or insecticide. This may damage the monitor or the unit.

Recommended cleaning method:

Gently wipe the panel with a soft, dry cloth.

Moisture condensation

Moisture may condense on the lens inside the unit in the following cases:

• After starting the heater in the car.

• If it becomes very humid inside the car.

Should this occur, the unit may malfunction. In this case, eject the disc and leave the unit turned on for a few hours until the moisture evaporates.

Center holder

How to handle discs

When removing a disc from its case, press down the

center holder of the case and lift the disc out, holding it by the edges.

• Always hold the disc by the edges. Do not touch its recording surface.

When storing a disc in its case, gently insert the disc around the center holder (with the printed surface facing up).

• Make sure to store discs in cases after use.

To keep discs clean

A dirty disc may not play correctly. If a disc does become dirty, wipe it with a soft cloth in a straight line from center to edge.

• Do not use any solvents (for example, conventional record cleaner, spray, thinner, benzine, etc.) to clean discs.

To play new discs

New discs may have some rough spots around the inner and outer edges. If such a disc is used, this unit may reject the disc. To remove these rough spots, rub the edges with a pencil or ball-point pen, etc.

Do not use the following discs:

Single CD

—8 cm (3-3/16”) disc Warped disc

Sticker and sticker residue Stick-on label

Unusual shape

Transparent or semi-

transparent parts on its

recording area

C-thru Disc (semi-

transparent disc)

ENGLISH

55REFERENCES

Troubleshooting

What appears to be trouble is not always serious. Check the following points before calling a service center.

• For operations with the external components, refer also to the instructions supplied with the adapters used for the connections (as well as the instructions supplied with the external components).

ENGLISH

• Messages (enclosed in “ ”) in the tables below are shown in the language selected on <Language>. ( 15) Messages described here are in the language of this manual.

Symptom Remedy/Cause

• No sound comes out of the speakers. • Adjust the volume to the optimum level.

• Check the cords and connections.

• The screen is not clear and legible. Sunshine from the windshield may cause this symptom.

Adjust <Bright>. ( 14)

• “Position Error Push Open Key” appears on the screen.

• “Mecha Error Push Reset” appears on the screen, and the panel does not move.

• “No Signal” appears. • Change the source.

General

• The buttons on the monitor panel do not work.

• The unit does not work at all.

• The touch panel does not respond properly.

• <Illumination> function does not work properly.

• SSM automatic presetting does not work.

• Static noise while listening to the

TUNER

radio.

The monitor panel angle has been forcibly adjusted, or its adjustment has been interrupted while opening or closing. Press [OPEN/TILT].

Reset the unit. (

• Start the playback on the external component connected to VIDEO IN jack.

• Check the cords and connections.

• Signal input is too weak.

When the monitor panel is open, only VOL +/– and work. The other buttons do not function.

Reset the unit. (

• Keep your hands and the touch panel clean and dry.

• Eliminate static electricity and do not place magnetic items near the unit.

• Leave the unit until the temperature becomes stable in the car.

• A rubber mat on the floor may cause this symptom. In this case, do not use the rubber mat.

Store stations manually. (

Connect the antenna firmly.

24)

Symptom Remedy/Cause

• Disc can be neither recognized nor played back.

• Disc cannot be ejected.

• Recordable/Rewritable discs cannot be played back.

• Tracks on the Recordable/Rewritable discs cannot be skipped.

• Playback does not start. • Insert the disc correctly again.

• The playback picture is not clear and legible.

• Sound and pictures are sometimes interrupted or distorted.

Disc in general

• No playback picture is shown and “Parking Brake” appears on the screen, even when the parking brake is engaged.

• No picture appears on the external monitor.

• “Eject Error” or “Loading Error” appears on the screen.

• “Region code error” appears on the screen when you insert a DVD Video.

• Disc cannot be played back. • Change the disc.

• Noise is generated. The track played back is not a playable file format. Skip to

• Tracks are not played back as you have intended them to play.

• Elapsed playing time is not correct. This sometimes occurs during playback. This is caused by how

MPEG1/MPEG2/MP3/WMA/WAV

• “Not Support” appears on the screen and track skips.

Eject the disc forcibly. (

Unlock the disc. (

• Insert a finalized disc.

• Finalize the discs with the component which you used for recording.

• The format of files is not supported by the unit.

Adjust items in <Picture Adjust> menu. (

• Stop playback while driving on rough roads.

• Change the disc.

Parking brake lead is not connected properly. See Installation/Connection Manual.

• Connect the video cord correctly.

• Select the correct input on the external monitor.

Change the source by pressing SOURCE.

Region code is not correct. (

• Record the tracks using a compliant application on the appropriate discs. ( 4)

• Add appropriate extension codes to the file names.

another file. Playback order may differ from the one played back using other

players.

the tracks are recorded. The track is unplayable.

30)

14)

ENGLISH

Continued on the next page

57REFERENCES

ENGLISH

USB

Bluetooth

Symptom Remedy/Cause

• Noise is generated. The track played back is not a playable file format. Skip to another file.

• Tracks cannot play back as you have

intended them to play.

• “Now Reading...” keeps flashing on

the screen.

• “Cannot play this device Check the

device” appears on the screen.

• Correct characters are not displayed

(e.g. album name).

• While playing a track, sound is

sometimes interrupted.

• Bluetooth device does not detect the

unit.

• The unit does not detect the

Bluetooth device.

• The unit does not make pairing with

the Bluetooth device.

• Echo or noise occurs. Adjust the microphone unit (supplied with Bluetooth Adapter)

• Phone sound quality is poor. • Reduce the distance between the unit and the Bluetooth

• The sound is interrupted or skipped

while using a Bluetooth audio player.

• “NEW DEVICE” cannot be selected for

“

Bluetooth AUDIO

• The connected audio player cannot

be controlled.

.”

Playback order may differ from the one played back using other players.

• Readout time varies depending on the USB device.

• Do not use too many hierarchy and folders.

• Turn off the power then on again. No tracks are stored. Copy tracks to the USB device.

For available characters,

The tracks are not properly copied into the USB device. Copy tracks again, and try again.

This unit can be connected with one Bluetooth cellular phone and one Bluetooth audio player at a time. While connected to a device, this unit cannot be detected from another device. Disconnect currently connected device and search again.

• Check the Bluetooth setting of the device.

• Search from the Bluetooth device.

• Enter the same PIN code for both the unit and target

device. If the PIN code of the device is not indicated on its instructions, try “0000” or “1234.”

• Select the device name from <Special Device>, then try to

connect again. (

position.

cellular phone.

• Move the car to place where you can get a better signal

reception.

• Reduce the distance between the unit and the Bluetooth

audio player.

• Disconnect the device connected for “

• Turn off, then turn on the unit.

• (When the sound is not yet restored,) connect the player

again.

Bluetooth audio player is already connected. To select “NEW DEVICE,” disconnect it. ( 27)

Check whether the connected audio player supports AVRCP (Audio Video Remote Control Profile).

52.

28)

Bluetooth PHONE

.”

Symptom Remedy/Cause

• “No Disc” appears on the screen. Insert a disc into the magazine.

• “No Magazine” appears on the screen. Insert the magazine.

• “Cannot play this disc Check the disc” appears on the screen.

• “Reset08” appears on the screen. Connect this unit and the CD changer correctly and

CD changer

• “Reset01” – “Reset07” appears on the screen. Press the reset button of the CD changer.

• The CD changer does not work at all.

• “CALL 1-888-539-SIRIUS TO SUBSCRIBE” appears on the screen.

• “Acquiring Signal” or “NO SIGNAL” appears on the screen.

• “No Antenna” or “ANTENNA” appears on the screen.

• “No CH” appears on the screen for about 5 seconds, then returns to the previous display when listening to the SIRIUS Satellite radio.

• “CH–––” appears on the screen for about 2 seconds, then returns to the previous channel while listening to the XM Satellite radio.

• “NO NAME” appears on the screen. No text information for the selected channel.

Satellite radio

• “UPDATING” appears on the screen and no sound can be heard.

• “OFF AIR” appears on the screen while listening to the XM Satellite radio.

• “LOADING” appears on the screen while listening to the XM Satellite radio.

• “Reset08” appears on the screen. Reconnect this unit and the Satellite radio correctly

• Satellite radio does not work at all. Reconnect the Satellite radio after a few seconds.

Current disc does not include playable files. Replace the disc with one including playable files.

press the reset button of the CD changer.

Reset the unit. ( Starts subscribing SIRIUS Satellite radio. (

Move to an area with stronger signals.

Connect the antenna firmly.

No broadcast on the selected channel. Select another channel or continue listening to the previous channel.

Selected channel is no longer available or is unauthorized. Select another channel or continue listening to the previous channel.

The receiver is updating the channel information and it takes a few minutes to complete.

Selected channel is not broadcasting at this time. Select another channel or continue listening to the previous channel.

The unit is loading the channel information and audio. Text information is temporarily unavailable.

and reset the unit.

ENGLISH

42)

Continued on the next page

59REFERENCES

ENGLISH

HD Radio reception

iPod /iPhone

AV-IN

Symptom Remedy/Cause

• Sound quality changes when receiving HD Radio stations.

• No sound can be heard. • “Analog” is selected when receiving all digital

• “Reset08” appears on the screen. Reconnect this unit and the HD Radio tuner box

• The iPod/iPhone does not turn on or does not work.

• Sound is distorted. Deactivate the equalizer either on this unit or the iPod.

• “Disconnect” appears on the screen. Check the connection.

• Playback stops. The headphones are disconnected during playback.

• “Cannot play this device Check the device” appears on the screen.

• No operations are available when playing back a track containing Artwork.

• “Reset01” – “Reset07” appears on the screen. Disconnect the adapter from both this unit and iPod.

• “Reset08” appears on the screen. Check the connection between the adapter and this

• The iPod’s controls do not work after disconnecting from this unit.

• “Restricted Device” appears on the screen. Check whether the connected iPod is compatible with

• No picture appears on the screen. • Turn on the video component if it is not on.

• Playback picture is not clear and legible.

Fix the reception mode either to <Digital> or <Analog>. ( 21)

broadcast of HD Radio station. Select <Digital> or <Auto>. (

• <Digital> is selected when receiving weak digital signals or receiving conventional radio broadcast. Select <Analog> or <Auto>. ( 21)

correctly, then reset the unit.

• Check the connecting cable and its connection.

• Update the firmware version of the iPod/iPhone.

• Charge the battery of the iPod/iPhone.

• Check whether “HEAD MODE” or “iPod MODE” is correctly selected. ( 45)

• Reset the iPod/iPhone.

Restart playback. No tracks are stored. Import tracks to the iPod/iPhone.

Operate the unit after the Artwork is loaded. (

Then, connect them again.

unit. Reset the iPod.

this unit. ( 51)

• Connect the video component correctly.

Adjust items in <Picture Adjust> menu. (

21)

16)

14)

JVC bears no responsibility for any loss of data in an iPod/iPhone and/or USB mass storage class device while using this unit.

Specifications

Power Output: 20 W RMS × 4 Channels at 4 Ω and ≤ 1%

THD+N

Signal-to-Noise Ratio: 80 dBA (reference: 1 W into 4 Ω) Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)

Equalizer Control Range: Frequencies: 60 Hz, 150 Hz, 400 Hz, 1 kHz, 2.5

kHz, 6.3 kHz, 15 kHz

Level: ±10 dB

Audio Output Level:

• LINE OUT (REAR)

AMPLIFIER

• SUBWOOFER Color System: NTSC Video Output (composite): 1 Vp-p/75 Ω Other Terminals: Input: LINE IN, VIDEO IN, Antenna input, USB input, Steering wheel remote

Frequency Range: FM: with channel interval set to

FM Tuner: Usable Sensitivity: 9.3 dBf (0.8 μV/75 Ω)

TUNER SECTION

AM Tuner: Sensitivity: 20 μV

Signal Detection System: Non-contact optical pickup (semiconductor laser) Frequency Response: DVD, fs=48 kHz/96 kHz: 16 Hz to 22 000 Hz

Dynamic Range: 96 dB

DVD/CD

Signal-to-Noise Ratio: 98 dB Wow and Flutter: Less than measurable limit

Line-Out Level/Impedance: 2.5 V/20 kΩ load (full scale) Output Impedance: 1 kΩ

input Output: VIDEO OUT Others: CD changer, DIGITAL OUT (optical)

87.5 MHz to 107.9 MHz

100 kHz or 200 kHz

with channel interval set to 50 kHz 87.5 MHz to 108.0 MHz AM: with channel interval set to 10 kHz 530 kHz to 1 710 kHz

with channel interval set to 9 kHz: 531 kHz to 1 602 kHz

50 dB Quieting Sensitivity: 16.3 dBf (1.8 μV/75 Ω) Alternate Channel Selectivity (400 kHz): 65 dB Frequency Response: 40 Hz to 15 000 Hz Stereo Separation: 40 dB

Selectivity: 40 dB

VCD/CD: 16 Hz to 20 000 Hz

ENGLISH

Continued on the next page

61REFERENCES

USB Standards: USB 2.0 Full Speed Data Transfer Rate Full Speed: Maximum 12 Mbps

USB

Compatible Device: Mass storage class

ENGLISH

Compatible File System: FAT 32/16/12 Max. Current: DC 5 V Screen Size: 7 inch wide liquid crystal display Number of Pixel: 336 960 pixels: 480 × 3 (horizontal) × 234 (vertical) Drive Method: TFT (Thin Film Transistor) active matrix format

MONITOR

Color System: NTSC/PAL Aspect Ratio: 16:9 (wide) Power Requirement: Operating Voltage: DC 14.4 V (11 V to 16 V allowance) Grounding System: Negative ground Allowable Storage Temperature: –10°C to +60°C (14°F to 140°F) Allowable Operating Temperature: 0°C to +40°C (32°F to 104°F) Dimensions (W × H × D):

• With trim plate and sleeve

GENERAL

attached

Mass (approx.):

Design and specifications are subject to change without notice.

If a kit is necessary for your car, consult your telephone directory for the nearest car audio speciality shop.

Low Speed: Maximum 1.5 Mbps

500 mA

Installation Size (approx.): 182 mm × 111 mm × 161 mm

(7-3/16” × 4-3/8” × 6-3/8”)

Panel Size (approx.): 188 mm × 117 mm × 22 mm

(7-7/16” × 4-5/8” × 7/8”)

3.3 kg (7.3 lbs) (including trim plate and sleeve)

Required space for installation and the monitor ejection

20 (13/16)

4 (3/16)

161 (6-3/8) 91.3 (3-5/8)

Dashboard

CAUTION: When ejecting the monitor, leave an open space for the monitor to come out. If you do not, the monitor may obstruct the steering wheel and gearshift lever operations, and this may result in a traffic accident.

111 (4-3/8)

Unit: mm (inch)

Operation index

General

Reset ..................................................................3, 6

Volume ................................................ 6, 7, 10, 20

AV Menu ........................................................ 6, 13

Source ..................................................6, 7, 11, 32

Short Cut ...................................................6, 8, 32

RM-RK252 ................................... 9 – 11, 33 – 36

Clock .............................................................12, 15

Display demonstration ...........................12, 14

Tuner

Listen to the radio (FM/AM) ...............6, 9, 29

Auto/manual search ................................10, 29

Select preset station ........................... 9, 24, 29

Store station

(automatically/manually) ...................21, 24

Improve FM reception ................................... 21

Assign title .........................................................22

Disc

Open/close ................................................... 7, 30

Eject ....................................................................3, 7

Lock/unlock disc .............................................. 30

Playable disc type ............................................. 4

Display information ........................................31

Repeat/random play ........................22, 23, 36

Select track/folder ................... 11, 25, 31 – 34

Select title/program/

playlist ...................................... 10, 11, 31 – 33

Start/stop/pause/resume

playback ......................................... 11, 32 – 34

Search/skip .......................................10, 32 – 34

OSD .................................................10, 16, 35, 36

PBC playback ......................................10, 11, 33

USB

Attach/detach ...................................................37

Start/pause playback ..............................11, 37

Repeat/random play ...............................22, 23

CD changer

Start playback ............................................ 25, 41

Repeat/random play ...............................22, 23

Satellite radio

Activate subscription ..................................... 42

Listen to a channel ..........................................43

Store channel ....................................................24

Preset channel ..................................................24

HD Radio operation

Listen to a channel ..........................................44

Change the HD Radio reception mode ...21

Improve reception ..........................................21

Bluetooth

Connect/disconnect/delete ..........27, 28, 38

Make a call ..................................................26, 39

Answer/end call ........................................28, 39

Read SMS .....................................................26, 40

Microphone volume .......................................28

Preset phone number ....................................25

iPod

Connect .......................................................45, 46

Start/pause playback ..............................45, 46

Head Mode/iPod Mode .................................45

Repeat/random play ...............................22, 23

Audiobooks .......................................................23

Select track ..........................................25, 45, 46

External component

AV-INPUT ............................................................47

EXT-INPUT ..........................................................48

ENGLISH

63REFERENCES

Having TROUBLE with operation?

Please reset your unit

Refer to page of How to reset your unit

Still having trouble??

USA ONLY

Call 1-800-252-5722

http://www.jvc.com

We can help you!

EN, SP, FR

0109DTSMDTJEIN

KW-ADV792/KW-AVX720

Installation/Connection Manual Manual de instalación/conexión Manuel d’installation/raccordement

GET0602-002A

[J]

ENGLISH

This unit is designed to operate on 12 V DC , NEGATIVE ground electrical systems. If your vehicle does not have this system, a

voltage inverter is required, which can be purchased at JVC car audio dealers.

WARNINGS

• DO NOT install any unit or wire any cable in a location where; – it may obstruct the steering wheel and gearshift lever operations,

as this may result in a traffic accident.

– it may obstruct the operation of safety devices such as air bags, as

this may result in a fatal accident.

– it may obstruct visibility.

• DO NOT operate any unit while manipulating the steering wheel, as this may result in a traffic accident.

• The driver must not watch the monitor while driving. It may lead to carelessness and cause an accident.

• If you need to operate the unit while driving, be sure to look around carefully or you may be involved in a traffic accident.

• If the parking brake is not engaged, “Parking Brake” appears on the monitor, and no playback picture will be shown. – This warning appears only when the parking brake wire is

connected to the parking brake system built in the car.

To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all electrical connections before installing the unit.

• Be sure to ground this unit to the car ’s chassis again after installation.

Notes on electrical connections:

• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio dealer.

• It is recommended to connect speakers with maximum power of more than 50 W (both at the rear and at the front, with an impedance of 4 Ω to 8 Ω).

If the maximum power is less than 50 W, change <Amplifier Gain>

setting to prevent the speakers from being damaged (see page 20 of the INSTRUCTIONS).

• To prevent short circuits, cover the terminals of the UNUSED leads with insulating tape.

• The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.

Heat sink

Sumidero térmico

Dissipateur de chaleur

ESPAÑOL

Esta unidad está diseñada para funcionar con 12 V de CC, con sistemas eléctricos de masa NEGATIVA. Si su vehículo no posee

este sistema, será necesario un inversor de tensión, que puede ser adquirido en los concesionarios de JVC de equipos de audio para automóviles.

ADVERTENCIAS

• NO instale ningún receptor o tienda ningún cable en una ubicación donde;

– Donde pueda obstruir la maniobra del volante de dirección y del

cambio de engranajes, con el consiguiente riesgo de accidentes de tráfico.

– Donde pueda obstruir el funcionamiento de dispositivos de

seguridad tales como bolsas de aire, pues podría resultar en un accidente fatal.

– Donde pueda obstruir la visibilidad.

• NO OPERE la unidad mientras está maniobrando el volante de dirección, pues podría producirse un accidente de tráfico.

• El conductor no debe mirar el monitor mientras conduce. Podría producirse un descuido, y causar un accidente.

• Si necesita operar la unidad mientras conduce, asegúrese de mirar atentamente a su alrededor pues de lo contrario, se podría producir un accidente de tráfico.

• Si el freno de mano no está en uso, aparecerá “Parking Brake (Freno de Mano)” en la pantalla y no se mostrará ninguna secuencia de imagen.

– Esta advertencia aparece únicamente cuando el cable del freno de

estacionamiento se encuentra conectado al sistema del freno de estacionamiento incorporado al automóvil.

Para evitar cortocircuitos, recomendamos que desconecte el terminal negativo de la batería y que efectúe todas las conexiones eléctricas antes de instalar la unidad.

• Asegúrese de volver a conectar a masa esta unidad al chasis del automóvil después de la instalación.

Notas sobre las conexiones eléctricas:

• Reemplace el fusible por otro del régimen especificado. Si el fusible se funde frecuentemente, consulte con su concesionario de JVC de equipos de audio para automóviles.

• Se recomienda conectar los altavoces con una potencia máxima de más de 50 W (tanto atrás como adelante, con una impedancia de 4 Ω a 8 Ω).

Si la potencia máxima es de menos de 50 W, cambie <Amplifier

Gain> para evitar daños en los altavoces (consulte la página 20 de MANUAL DE INSTRUCCIONES).

• Para evitar cortocircuitos, cubra los terminales de los cables NO UTILIZADOS con cinta aislante.

• La unidad estará muy caliente después del uso. Tenga la precaución de no quemarse al efectuar su desmontaje.

0109DTSMDTJEIN

EN, SP, FR

FRANÇAIS

Cet appareil est conçu pour fonctionner sur des sources de courant continu de 12 V à masse NEGATIVE. Si votre véhicule n’offre pas ce

type d’alimentation, il vous faut un convertisseur de tension, que vous pouvez acheter chez un revendeur d’autoradios JVC.

AVERTISSEMENTS

• N’INSTALLEZ aucun appareil ni aucun câble dans un endroit où: – où il peut gêner l’accès au volant ou au levier de vitesse car cela

peut entraîner un accident de la circulation.

– où il peut gêner la manipulation de dispositifs de sécurité tels que

les airbags car cela peut entraîner un accident fatal.

– où il peut gêner la visibilité.

• NE COMMANDEZ pas l’appareil lors de la manipulation du volant car cela peut entraîner un accident de la circulation.

• Le conducteur ne doit pas regarder le moniteur lorsqu’il conduit. Cela peut lui faire perdre sa concentration et causer un accident.

• Si vous souhaitez opérer l’appareil pendant que vous conduisez, assurez-vous de bien regarder autour de vous afin de ne pas causer un accident de la circulation.

• Si le frein à main n’est pas engagé, “Parking Brake (Frein à Main)” s’affiche sur le moniteur et aucune image de lecture n’apparaît. – Cet avertissement apparaît uniquement quand le fil du frein de

stationnement est connecté au système de frein de stationnement intégré à la voiture.

Pour éviter tout court-circuit, nous vous recommandons de débrancher la borne négative de la batterie et d’effectuer tous les raccordements électriques avant d’installer l’appareil.

• Assurez-vous de raccorder de nouveau la mise à la masse de

cet appareil au châssis de la voiture après l’installation.

Remarques sur les connexions électriques:

• Remplacer le fusible par un de la valeur précisée. Si le fusible saute souvent, consulter votre revendeur d’autoradios JVC.

• Il est recommandé de connecter des enceintes avec une puissance de plus de 50 W (les enceintes arrière et les enceintes avant, avec une impédance comprise entre 4 Ω et 8 Ω).

Si la puissance maximum est inférieure à 50 W, changez <Amplifier

Gain> pour éviter d’endommager vos enceintes (voir page 20 du MANUEL D’INSTRUCTIONS).

• Pour éviter les court-circuits, couvrir les bornes des fils qui ne sont PAS UTILISÉS avec de la bande isolante.

• Le dissipateur de chaleur devient très chaud après usage. Faire attention de ne pas le toucher en retirant cet appareil.

Parts list for installation and connection

If any item is missing, consult your JVC car audio dealer immediately.

Main unit

Unidad principal

Appareil principal

Flat head screws

Tornillos de cabeza plana *1 (M5 × 8 mm/M5 × 3/8 pulgada)

Vis à tête plate *1 (M5 × 8 mm/M5 × 3/8 pouces)

Round head screws *1 (M2.6 × 3 mm/M2.6 × 1/8")

Tornillos de cabeza esférica

Vis à tête ronde *1 (M2,6 × 3 mm/M2,6 × 1/8 pouces)

Power cord

Cable de alimentación

Cordon d’alimentation

(M5 × 8 mm/M5 × 3/8")

(M2,6 × 3 mm/M2,6 × 1/8 pulgada)

Lista de piezas para instalación y conexión

Si hay algún elemento faltante, consulte inmediatamente con su concesionario de JVC de equipos de audio para automóviles.

Sleeve *

Cubierta*

Manchon *

Crimp connector

Conector de engarce

Raccord à sertir

Remote controller

Control remoto

Télécommande

Trim plate

Placa de guarnición

Plaque d’assemblage

Batteries

Pilas

Piles

Liste des pièces pour l’installation et raccordement

Si quelque chose manquait, consultez votre revendeur autoradio JVC immédiatement.

Brackets *

Ménsulas *

Supports *

Use these screws when installing the unit without the supplied sleeve.

Utilice estos tornillos cuando instale la unidad sin la funda suministrada.

Utilisez ces vis lors de l’installation de l’appareil sans le manchon fourni.

Flat head screws (M5 × 8 mm/M5 × 3/8")

Tornillos de cabeza plana (M5 × 8 mm/ M5 × 3/8 pulgada)

Vis à tête plate (M5 × 8 mm/M5 × 3/8 pouces)

Round head screws (M5 × 8 mm/M5 × 3/8")

Tornillos de cabeza esférica (M5 × 8 mm/ M5 × 3/8 pulgada)

Vis à tête ronde (M5 × 8 mm/M5 × 3/8 pouces)

*1 Fitted to the main unit when shipped. *1 Fijado a la unidad principal cuando se expide de fábrica.

Fixé à l’appareil lors de l’expédition.

INSTALLATION

INSTALACION (MONTAJE EN EL

INSTALLATION (MONTAGE DANS LE

(IN-DASH MOUNTING)

The following illustration shows a typical installation. However, you should make adjustments corresponding to your specific car. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits.

• If you are not sure how to install this unit correctly, have it installed by a qualified technician.

Before installing the unit

• When mounting the unit, be sure to use the screws provided, as instructed. If other screws are used, parts could become loose or damaged.

• When tightening screws or bolts, be careful not to pinch any connection cord.

• Make sure not to block the fan on the rear to maintain proper ventilation when installing the unit.

1 Remove the audio system originally installed in the car, together

with its mounting brackets.

Note: Be sure to keep all the screws and parts removed from

your car for future use.

2 Install the sleeve in the dashboard of the car. 3 Attach the brackets to the main unit.

• Make sure to use the supplied flat head screws (M5 × 8 mm/ M5 × 3/8"). If longer screws are used, they could damage the unit.

4 Do the required electrical connections.

• See pages 3 – 6.

5 Install the main unit in the sleeve. 6 Attach the trim plate.

TABLERO DE INSTRUMENTOS)

La siguiente ilustración muestra una instalación típica. Sin embargo usted deberá efectuar los ajustes correspondientes a su automóvil. Si tiene alguna pregunta o necesita información acerca de las herramientas para instalación, consulte con su concesionario de JVC de equipos de audio para automóviles o a una compañía que suministra tales herramientas.

• Si no está seguro de poder instalar la unidad correctamente, déjela en manos de un técnico cualificado.

Antes de instalar la unidad

• Al instalar la unidad, asegúrese de usar los tornillos suministrados, de acuerdo con las instrucciones. Si emplea otros tipos de tornillos, corre el riesgo de que las piezas se aflojen o se dañen.

• Al apretar los tornillos o los pernos, asegúrese de que ningún cable de conexión quede pillado.

• Al efectuar la instalación, asegúrese de no bloquear el ventilador del panel trasero a fin de mantener una ventilación correcta.

1 Desmonte el sistema de audio instalado originalmente en el coche,

junto con los ménsulas de montaje.

Nota:

Asegúrese de guardar todos los tornillos y piezas quitados

de su vehículo para poderlos usar en el futuro.

2 Instale la cubierta en el cubretablero del automóvil. 3 Fije los ménsulas a la unidad principal.

• Asegúrese de usar los tornillos de cabeza plana suministrados (M5 × 8 mm/M5 × 3/8 pulgada). El uso de tornillos más largos producir daños a la unidad.

4 Realice todas las conexiones eléctricas necesarias.

• Consulte las páginas 3 – 6.

5 Coloque la unidad principal en la cubierta. 6 Fije la placa de guarnición.

TABLEAU DE BORD)

L’illustration suivante est un exemple d’installation typique. Cependant, vous devez faire les ajustements correspondant à votre voiture. Si vous avez des questions ou avez besoin d’information sur des kits d’installation, consulter votre revendeur d’autoradios JVC ou une compagnie d’approvisionnement.

• Si vous n’êtes pas sûr de pouvoir installer l’appareil correctement, faite-le installer par un technicien qualifié.

Avant d’installer l’appareil

• Lors du montage de l’appareil, assurez-vous d’utiliser les vis fournies, de la façon indiquée. Si vous utilisez d’autres vis, certaines pièces peuvent être perdues ou endommagées.

• Lorsque vous serrez des vis ou des boulons, faites attention de ne pas pincer un cordon de connexion.

• Assurez-vous de ne pas bloquer le ventilateur sur le panneau arrière lors de l’installation afin de permettre une ventilation correcte.

1 Retirez le système audio d’origine installé dans la voiture en même

temps que les supports de montage.

Remarque: Assurez-vous de conserver toutes les vis et pièces

détachées de votre voiture pour une utilisation dans le future.

2 Installez le manchon dans le tableau de bord de la voiture. 3 Attachez les supports à l’appareil principal.

• Assurez-vous d’utiliser les vis à tête plate fournis— (M5 × 8 mm/M5 × 3/8 pouces). Vous risquez d’endommager l’appareil si vous utilisez des vis plus longues.

4 Réalisez les connexions électriques requises.

• Référez-vous aux pages 3 – 6.

5 Installez l’appareil principal dans le manchon. 6 Fixez la plaque d’assemblage.

Flat head screws (M5 × 8 mm/M5 × 3/8")

Tornillos de cabeza plana (M5 × 8 mm/M5 × 3/8 pulgada)

Vis à tête plate (M5 × 8 mm/M5 × 3/8 pouces)

/ Ménsulas / Supports

Brackets

Sleeve

Cubierta

Manchon

Tornillos de cabeza esférica (M2,6 × 3 mm/M2,6 × 1/8 pulgada)

Required space for installation and the monitor ejection Espacio requerido para la instalación y la expulsión del monitor Espace nécessaire pour l’installation et l’éjection du moniteur

Round head screws (M2.6 × 3 mm/M2.6 × 1/8")

Vis à tête ronde (M2,6 × 3 mm/M2,6 × 1/8 pouces)

20 (13/16)

4 (3/16)

161 (6-3/8)

Dashboard

Tablero

Tableau de bord

91.3 (3-5/8)

111 (4-3/8)

Unit: mm (inch)

Unidad: mm (pulgada)

Unité: mm (pouces)

Trim plate

Placa de guarnición

Plaque d’assemblage

Install the unit at an angle of less than 30˚, taking it into account that the monitor would eject when in use.

Instale la unidad a un ángulo de menos de 30°, teniendo en cuenta que el monitor debe extraerse para su uso.

Installez l’appareil avec un angle de moins de 30°, en tenant compte du fait que le moniteur doit être déployé lors de son utilisation.

30˚

ELECTRICAL CONNECTIONS

Typical connections / Conexiones tipicas / Raccordements typiques

RACCORDEMENTS ELECTRIQUESCONEXIONES ELECTRICAS

Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit. The leads of the power cord and those of the connector from the car body may be different in color.

1 Connect the colored leads of the power cord in the order

specified in the illustration below.

2 Connect the antenna cord. 3 Finally connect the wiring harness to the unit.

Antenna terminal / Terminal de la antena / Borne de l’antenne

DIGITAL OUT

(see diagram

/ véase diagrama / voir le diagramme )

Rear ground terminal / Terminal de tierra posterior /

Borne arrière de masse

(see diagram / véase diagrama / voir le diagramme

(see diagram

voir le diagramme )

Antes de la conexión: Verifique atentamente el conexionado del vehículo. Una conexión incorrecta podría producir daños graves en la unidad. Los cordones del cable de alimentación y los del conector procedentes de la carrocería del automóvil podrían ser de diferentes en color.

1 Conecte los conductores de color del cable de alimentación en el

orden especificado en la ilustración de abajo.

2 Conecte el cable de antena. 3 Por último, conecte el cable de alimentación a la unidad.

If your car is equipped with the steering wheel remote controller, you can operate this unit using the controller. For connection, an exclusive remote adapter (not supplied) which matches your car is required. For details, consult the same car audio dealer as where the unit is purchased.

Si su automóvil está equipado con control remoto en el volante de dirección, podrá controlar este receptor utilizando el control remoto. Para la conexión, se requiere un adaptador remoto exclusivo (no suministrado) que sea adecuado para su automóvil.

)

/ véase diagrama /

SUBWOOFER

(see diagram

voir le diagramme )

Fan / Ventilador / Ventilateur

/ véase diagrama /

Para los detalles, consulte con el concesionario car audio donde compró el receptor.

Si votre voiture est équipée d’une télécommande de volant, vous pouvez commander cet autoradio en utilisant cette télécommande. Pour la connexion, vous avez besoin d’un adaptateur de télécommande spécialisé (non fourni) correspondant à votre voiture. Pour en savoir plus, consultez le revendeur autoradio où vous avez acheté votre autoradio.

Avant de commencer la connexion: Vérifiez attentivement le câblage du véhicule. Une connexion incorrecte peut endommager sérieusement l’appareil. Le fil du cordon d’alimentation et ceux des connecteurs du châssis de la voiture peuvent être différents en couleur.

1 Connectez les fils colorés du cordon d’alimentation dans l’ordre

spécifié sur l’illustration ci-dessous.

2 Connectez le cordon d’antenne. 3 Finalement, connectez le faisceau de fils à l’appareil.

Steering wheel remote controller (equipped in the car)

Control remoto del volante de dirección (equipado en el vehículo)

Télécommande de volant (installée dans la voiture)

Steering wheel remote input

Entrada del control remoto del volante de dirección

Entrée de la télécommande de volant

Remote adapter Adaptador para remoto exclusivo * Adaptateur pour télécommande spécialisé *

VIDEO OUT

(see diagram

véase diagrama voir le diagramme

VIDEO IN

(see diagram

véase diagrama / voir le diagramme )

LINE IN

(see diagram

véase diagrama / voir le diagramme )

REAR OUT

(see diagram

véase diagrama / voir le diagramme )

15 A fuse

Fusible de 15 A

Fusible 15 A

To external components (see diagram

A un componente externo (véase diagrama )

Pour connecter un appareil extérieur (véase diagrama )

)

Black

Negro

Noir

Yellow

Amarillo *

Jaune *

Red

Rojo

Rouge

Blue

Azul

Bleu

Blue with white stripe

Azul con rayas blancas

Bleu avec bande blanche

Orange with white stripe

Naranja con rayas blancas

Orange avec bande blanche

Brown

Marrón

Marron

To the metallic body or chassis of the car

A un cuerpo metálico o chasis del automóvil

Vers corps métallique ou châssis de la voiture

To a live terminal in the fuse block connecting to the car battery (bypassing the ignition switch) (constant 12 V)

A un terminal activo del bloque de fusibles conectado a la batería del automóvil (desviando el interruptor de encendido) (12 V constantes)

A une borne sous tension du porte-fusible connectée à la batterie de la voiture (en dérivant l’interrupteur d’allumage) (12 V constant)

To an accessory terminal in the fuse block

A un terminal accesorio del bloque de fusibles

Vers borne accessoire du porte-fusible

To automatic antenna if any (250 mA max.)

A la antena automática, si hubiere (250 mA máx.)

À l’antenne automatique s’il y en a une (250 mA max.)

To the remote lead of other equipment (200 mA max.)

Al conductor remoto del otro equipo (200 mA máx.)

Au fil de télécommande d’un autre appareil (200 mA max.)

To car light control switch

Al interruptor de control de las luces del automóvil

À l’interrupteur d’éclairage de la voiture

To cellular phone system

Al sistema de teléfono celular

À un système de téléphone cellulaire

Ignition switch

Interruptor de encendido

Interrupteur d’allumage

Fuse block

Bloque de fusibles

Porte-fusible

White with black stripe

Blanco con rayas negras

Blanc avec bande noire

Not supplied for this unit.

Before checking the operation of this unit prior to installation, this lead

must be connected, otherwise power cannot be turned on.

White

Blanco

Blanc

Left speaker (front)

Altavoz izquierdo (frontal)

Enceinte gauche (avant)

Gray with black stripe

Gris con rayas negras

Gris avec bande noire

Light green

Verde claro

Vert clair

Gray

Gris

Right speaker (front)

Altavoz derecho (frontal)

Enceinte droit (avant)

No suministrado con esta unidad.

Antes de comprobar el funcionamiento de esta unidad previa a de la

instalación, es necesario conectar este cable, de lo contrario no se podrá conectar la alimentación.

Green with black stripe

Verde con rayas negras

Vert avec bande noire

Crimp connector

Conector de sujeción

Raccord à sertir

Green

Verde

Vert

Left speaker (rear)

Altavoz izquierdo (trasero)

Enceinte gauche (arrière)

Non fourni avec cet appareil.

Pour vérifier le fonctionnement de cet appareil avant installation, ce fil

doit être raccordé, sinon l’appareil ne peut pas être mis sous tension.

To parking brake (see diagram

Al freno de estacionamiento (véase diagrama ) Au frein de stationnement (voir le diagramme )

Purple with black stripe

Púrpura con rayas negras

Violet avec bande noire

)

Purple

Púrpura

Violet

Right speaker (rear)

Altavoz derecho (trasero)

Enceinte droit (arrière)

REVERSE

GEAR

SIGNAL

ENGLISH ESPAÑOL FRANÇAIS

PRECAUTIONS on power supply and speaker connections:

• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit will be seriously damaged.

• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in your car.

PRECAUCIONES sobre las conexiones de la fuente de alimentación y de los altavoces:

• NO conecte los conductores de altavoz del cable de alimentación a la batería de automóvil, pues podrían producirse graves daños en las unidades.

• ANTES de conectar a los altavoces los conductores de altavoz del cable de alimentación, verifique el conexionado de altavoz de su

PRECAUTIONS sur l’alimentation et la connexion des enceintes:

• NE CONNECTEZ PAS les fils d’enceintes du cordon d’alimentation à la batterie; sinon, l’appareil serait sérieusement endommagé.

• AVANT de connecter les fils d’enceintes du cordon d’alimentation aux enceintes, vérifiez le câblage des enceintes de votre voiture.

automóvil.

Connecting the parking brake lead / Conexión del cable del freno de estacionamiento / Connexion du fil de frein de stationnement

Parking brake lead (light green)

Cable del freno de estacionamiento (verde claro)

Fil du frein de stationnement (vert clair)

Parking brake

Freno de estacionamiento

Frein de stationnement

Parking brake switch (inside the car)

Interruptor del freno de estacionamiento (dentro del automóvil)

Commutateur de frein de stationnement (intérieur de la voiture)

Connecting the reverse gear signal lead (for rear view camera) / Conexión del cable de señal del engranaje de marcha atrás (para cámara de

Crimp connector

Conector de engarce

Raccord à sertir

To metallic body or chassis of the car

A un cuerpo metálico o chasis del automóvil

Vers corps métallique ou châssis de la voiture

retrovisión) / Connexion du fil de signal de marche arrière (pour la caméra du rétroviseur)

Locate the reverse lamp lead in the trunk.

Purple with white stripe

Púrpura con rayas blancas

Violet avec bande blanche

Localice el conductor de la luz de marcha atrás en el portaequipajes.

Extension lead

Cable prolongador *

Fil prolongateur *

A la batería del automóvil

À la batterie de la voiture

To car battery

Crimp connector *

Conector de sujeción *

Raccord à sertir *

Localisez le fil des feux de recul dans le coffre.

To reverse lamp

A la luz de marcha atrás

Aux feux de recul

Not supplied for this unit.

TROUBLESHOOTING

• The fuse blows.

* Are the red and black leads connected correctly?

• Power cannot be turned on.

* Is the yellow lead connected?

• No sound from the speakers.

* Is the speaker output lead short-circuited?

• Sound is distorted.

* Is the speaker output lead grounded? * Are the “–” terminals of L and R speakers grounded in common?

• Noise interfere with sounds.

* Is the rear ground terminal connected to the car’s chassis using

shorter and thicker cords?

• This unit becomes hot.

* Is the speaker output lead grounded? * Are the “–” terminals of L and R speakers grounded in common?

• This unit does not work at all.

* Have you reset your unit?

Conductor de la luz de marcha atrás

No suministrado con esta unidad

Reverse lamp lead

Fil des feux de recul

LOCALIZACION DE AVERIAS

• El fusible se quema.

* ¿Están los conductores rojo y negro correctamente conectados?

• No es posible conectar la alimentación.

* ¿Está el cable amarillo conectado?

• No sale sonido de los altavoces.

* ¿Está el cable de salida del altavoz cortocircuitado?

• El sonido presenta distorsión.

* ¿Está el cable de salida del altavoz conectado a masa? * ¿Están los terminales “–” de los altavoces L y R conectados a una

masa común?

• Perturbación de ruido.

* ¿El terminal de tierra trasero está conectado al chasis del automóvil

utilizando los cordones más corto y más grueso?

• Esta unidad se calienta.

* ¿Está el cable de salida del altavoz conectado a masa? * ¿Están los terminales “–” de los altavoces L y R conectados a una

masa común?

• Esta unidad no funciona en absoluto.

* ¿Reinicializó la unidad?

Reverse lamps

Luz de marcha atrás

Feux de recul

Non fourni avec cet autoradio.

EN CAS DE DIFFICULTES

• Le fusible saute.

* Les fils rouge et noir sont-ils racordés correctement?

• L’appareil ne peut pas être mise sous tension.

* Le fil jaune est-elle raccordée?

• Pas de son des enceintes.

* Le fil de sortie d’enceinte est-il court-circuité?

• Le son est déformé.

* Le fil de sortie d’enceinte est-il à la masse? * Les bornes “–” des enceintes gauche et droit sont-elles mises ensemble

à la masse?

• Interférence avec les sons.

* La prise arrière de mise à la terre est-elle connectée au châssis de la

voiture avec un cordon court et épais?

• Cet appareil devient chaud.

* Le fil de sortie d’enceinte est-il à la masse? * Les bornes “–” des enceintes gauche et droit sont-elles mises ensemble

à la masse?

• Cet appareil ne fonctionne pas du tout.

* Avez-vous réinitialisé votre appareil?

Connecting the external amplifier and/or subwoofer / Conexión del amplificador y/o subwoofer exterior / Connexion d’amplificateurs

extérieurs et/ou d’un caisson de grave

You can connect an amplifier to upgrade your car stereo system.

• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.

• For amplifier only:

– Disconnect the speakers from this unit, connect them to

the amplifier. Leave the speaker leads of this unit unused.

– You can switch off the built-in amplifier and send the audio

signals only to the external amplifier(s) to get clear sounds and to prevent internal heat built-up inside the unit. See page 20 of the INSTRUCTIONS (separate volume).

Remote lead *2 / Cable remoto *

Rear speakers

Altavoces traseros

Enceintes arrière

JVC Amplifier

Amplificador de JVC

JVC Amplificateur

Usted podrá conectar un amplificador para mejorar el sistema estéreo de su automóvil.

•

Conecte el conductor remoto (azul con rayas blancas) al conductor remoto del otro equipo para poderlo controlar a través de esta unidad.

• Sólo para el amplificador: – Desconecte los altavoces de esta unidad y conéctelos al

amplificador. Los cables de los altavoces de esta unidad quedan sin usar.

– Podrá desconectar el amplificador incorporado y enviar las

señales de audio solamente al(los) amplificador(es) externo(s) para obtener sonidos nítidos y evitar que se caliente el interior de la unidad. Consulte la página 20 del MANUAL DE INSTRUCCIONES (volumen separado).

2 /

Fil d’alimentation à distance *

Remote lead (blue with white stripe)

Cable remoto (Azul con rayas blancas)

Fil d’alimentation à distance (bleu avec bande blanche)

Y-connector *2 / Conector en Y*2 / Connecteur Y *

Vous pouvez connecter un amplificateur pour améliorer votre système autoradio.

• Connectez le fil de commande à distance (bleu avec bande blanche)

au fil de commande à distance de l’autre appareil de façon qu’il puisse être commandé via cet appareil.

• Pour l’amplificateur seulement: – Déconnectez les enceintes de cet appareil et connectez-

les à l’amplificateur. Laissez les fils d’enceintes de cet appareil inutilisés.

– Vous pouvez mettre hors service l’amplificateur intégré et

envoyer les signaux audio uniquement sur un ou plusieurs amplificateurs extérieurs afin d’obtenir un son clair et d’éviter tout échauffement interne de l’autoradio. Voir page 20 du MANUEL D’INSTRUCTIONS (volume séparé).

To the remote lead of other equipment or automatic antenna if any

Al conductor remoto de otro equipo o de la antena automática, si hubiere

Au fil de télécommande de l’autre appareil ou à l’antenne automatique s’il y en a une

JVC Amplifier

Amplificador de JVC

JVC Amplificateur

Subwoofer

Caisson de grave

Front speakers

Altavoces delanteros

Enceintes avant

Connecting the external components / Conexión de otros componentes externos / Connexion des appareils extérieurs

AV amplifier or decoder

Amplificador o decodificador AV

Amplificateur AV ou décodeur

Digital optical cable *

Cable óptico digital*

Câble optique numérique *

Video cord *

Cable de video *

Cordon vidéo *

External component

Componente exterior

Appareil extérieur

USB devices / Dispositivos USB / Périphériques USB

Video cord

Cable de video *

Cordon vidéo *

Connecting the iPod/iPhone to the USB terminal / Conectar el iPod/iPhone al termina USB / Connexion du iPod/iPhone à la prise USB

USB cable, approx. 1.2 m (4 feet)

Cable USB, aprox. 1,2 m (4 pie)

Câble USB, environ 1,2 m (4 pieds)

USB device

Dispositivo USB

Périphérique USB

You can connect the iPod/iPhone to the USB terminal using the following cables:

• To listen to the music: USB 2.0 cable (supplied for the iPod/iPhone)

• To watch the video: USB Audio and Video cable for iPod/iPhone—KS-U30 (not supplied) *

Puede conectar el iPod/iPhone al terminal USB utilizado los siguientes cables:

• Para escuchar la música: Cable USB 2.0 (suministrado con el iPod/iPhone)

• Para ver vídeo: Cable USB audio y video para iPod/iPhone—KS-U30 (no suministrado) *

Vous pouvez connecter le iPod/iPhone à la prise USB en utilisant les câbles suivants:

• Pour écouter la musique: Câble USB 2.0 (fourni pour le iPod/iPhone)

• Pour regarder une séquence vidéo: Câble USB Audio et Vidéo pour iPod/iPhone—KS-U30 (non fourni) *

USB 2.0 cable

Cable USB 2.0

Câble USB 2.0

External monitor

Moniteur extérieur

KV-CM1

Rear view camera

Cámara de reprovisión

Caméra de recul

Apple iPod/iPhone

iPod Apple/iPhone

Monitor externo

You cannot connect a computer to the USB (

No se puede conectar un ordenador al terminal USB (

Vous ne pouvez pas connecter un ordinateur à la prise USB (

) terminal of the unit.

) de la unidad.

) de l’appareil.

iPod is a trademark of Apple Inc., registered in the U.S. and other countries.

iPod es una marca comercial de Apple Inc., registrada en los EE.UU. y otros países.

iPod est une marque de commerce d’Apple Inc., enregistrée aux États-Unis et dans les autres pays.

iPhone is a trademark of Apple Inc.

iPhone es una marca comercial de Apple Inc.

iPhone est une marque de commerce de Apple Inc.

Not supplied for this unit.

Signal cord (not supplied for this unit).

Audio cord (not supplied for this unit).

Firmly attach the ground wire to the metallic body or to the chassis of

the car—to the place uncoated with paint (if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to the unit.

When using the cable, make sure <iPod (Off)> is selected for

<AV Input> (see page 17 of the INSTRUCTIONS).

No suministrado con esta unidad.

Cable de señal (no suministrado con esta unidad).

Cable de audio (no suministrado con esta unidad).

Fije firmemente el cable de tierra a la carrocería metálica o al chasis—a

un lugar no cubierto con pintura (si está cubierto con pintura, quítela antes de fijar el cable). De lo contrario, se podrían producir daños en la unidad.

Cuando utilice el cable, asegúrese de haber seleccionado

<iPod (Off)> para <AV Input> (consulte la página 17 del MANUAL DE INSTRUCCIONES).

Apple iPod/iPhone

iPod Apple/iPhone

KS-U30

Non fourni avec cet appareil.

Cordon de signal (non fourni avec cet appareil).

Cordon audio (non fourni avec cet appareil).

Attachez solidement le fil de mise à la masse au châssis métallique de

la voiture—à un endroit qui n’est pas recouvert de peinture (s’il est recouvert de peinture, enlevez d’abord la peinture avant d’attacher le fil). L’appareil peut être endommagé si cela n’est pas fait correctement.

Lors de l’utilisation de ce câble, assurez-vous que <iPod (Off)> est choisi

pour <AV Input> (voir page 17 du MANUEL D’INSTRUCTIONS).

Connecting the external components to the CD changer jack / Conexión de los componentes externos al jack del cambiador de CD /

Connexion des appareils extérieurs au changeur de CD

When connecting the external components, refer also to the manuals supplied for the components and adapter.

CAUTION:

Before connecting the external components, make sure that the

unit is turned off.

You can connect the following JVC components to the CD changer jack.

JVC component Model name

CD changer (CD-CH) CH-X1500, etc.

HD Radio

You can also connect the following components through the various JVC adapters or system.

• Connection cords may need to be purchased separately.

Component Adapter/System Model name

Bluetooth device Bluetooth adapter KS-BTA200

iPod Interface adapter for

XMDirect

XMDirect2 Tuner System

SIRIUS satellite radio SIRIUS satellite radio

Portable audio player with line output jacks

Portable audio player with 3.5 mm (3/16") stereo mini jack

tuner box KT-HD300

KS-PD100

iPod

Tuner Box Smart Digital Adapter XMDJVC100

XM satellite radio System

CNP2000UC and CNPJVC1

SC-C1 and

System

KS-SRA100

PnP, SC-VDOC1

System

and KS-SRA100

Line input adapter KS-U57

AUX input adapter KS-U58

Cuando conecte componentes externos, consulte, también, los manuales suministrados con los componentes y el adaptador.

PRECAUCION:

Antes de conectar los componentes externos, asegúrese de que la

unidad esté apagada.

Puede conectar los siguientes componentes JVC al jack del cambiador de CD.

Componente JVC

Cambiador de CD (CD-CH) CH-X1500, etc.

Sintonizador HD Radio

También puede conectar los siguientes componentes a través de los diversos adaptadores o sistema JVC.

• Puede ser necesario comprar los cables de conexión por separado.

Componente Adaptador/Sistema

Dispositivo Bluetooth Adaptador Bluetooth KS-BTA200

iPod Adaptador de interfaz

para iPod

XMDirect

Tuner Box Adaptador digital

inteligente

Sistema de sintonizador XMDirect2

Sistema de radio XM Satellite

Radio por satélite SIRIUS Sistema de radio

satelital SIRIUS

Radio por satélite SIRIUS Sistema de radio

satelital SIRIUS

Reproductor de audio portátil con jacks de

Adaptador de entrada por línea

salida de línea

Reproductor de audio portátil con jack mini

Adaptador de entrada

AUX estéreo de 3,5 mm (3/16 pulgada)

Nombre del modelo

KT-HD300

Nombre del modelo

KS-PD100

XMDJVC100

CNP2000UC y CNPJVC1

SC-C1 y KS-SRA100

PnP, SC-VDOC1 y KS-SRA100

KS-U57

KS-U58

Lors de la connexion des appareils extérieurs, référez-vous aussi aux manuels fournis avec les appareils et les adaptateurs.

PRECAUTION:

Avant de connecter les appareils extérieurs, assurez-vous que

l’appareil est hors tension.

Vous pouvez connecter les appareils JVC suivants à la prise de changeur de CD.

Appareil JVC

Changeur de CD (CD-CH) CH-X1500, etc. Tuner HD Radio

Vous pouvez aussi connecter les appareils suivants en utilisant divers adaptateurs JVC ou systèmes.

• Vous pouvez avoir besoin d’acheter certains cordons de connexion

séparément.

Appareil

Adaptateur/ Système

Périphérique Bluetooth Adaptateur Bluetooth KS-BTA200 iPod Adaptateur d’interface

pour iPod

XMDirect

Tuner Box Adaptateur numérique

intelligent

XMDirect2 Tuner

Système radio satellite XMCNP2000UC et

System Radio satellite SIRIUS Système radio satellite

SIRIUS

Radio satellite SIRIUS Système radio satellite

SIRIUS

Lecteur audio portable avec prises de sortie de

Adaptateur d’entrée de ligne

ligne

Lecteur audio portable avec mini fiche stéréo

Adaptateur d’entrée

auxiliaire de 3,5 mm (3/16 pouces)

Nom du modèle

KT-HD300

Nom du modèle

KS-PD100

XMDJVC100

CNPJVC1 SC-C1 et

KS-SRA100 PnP, SC-VDOC1

et KS-SRA100 KS-U57

KS-U58

When connecting more than one component (maximum: three), it is recommended that you connect the components in series as explained below.

• XM Radio and SIRIUS satellite radio cannot be used together.

Cuando conecte más de un componente (máximo: tres), se recomienda que conecte los componentes en serie, como se explica a continuación.

• No puede utilizar juntas la radio XM y la radio satelital SIRIUS.

When connecting two components in series / Cuando conecta dos componentes en serie / Lors de la connexion de deux appareils en série

CD changer jack / Jack para el cambiador de CD / Prise du changeur CD

A KT-HD300 *

B *

CD-CH / KS-PD100 / KS-U57 / KS-U58

/ KS-SRA100 *

To disconnect the connector / Para desconectar el cable / Pour déconnecter le

connecteur

8, *9

/ KS-BTA200 / XMDJVC100 / CNP2000UC *

Hold the connector top tightly (

1 ), then pull it out ( 2 ).

Sujete firmemente la parte superior del conector ( seguidamente, extráigalo (

2 ).

Tenez fermement le connecteur par-dessus ( vers l’extérieur (

2 ).

1 ) y

1 ) et tirez

Lors de la connexion de plus d’un appareil (maximum: trois), il est recommandé que vous connectiez les appareils en série comme nous l’expliquons ci-dessous.

• La radio XM et SIRIUS ne peuvent pas être utilisées en même

temps.

When connecting three components in series / Cuando conecta tres componentes en serie / Lors de la connexion de trois appareils en série

CD changer jack / Jack para el cambiador de CD / Prise du changeur CD

A KT-HD300 * B KS-BTA200

C *

KS-PD100 / KS-U57 / KS-U58

It is not recommended to connect KS-U57/KS-U58 at

No se recomienda conectar el KS-U57/KSU58 en

Il n’est pas recommandé de connecter le KS-U57/KS-U58 en série à KS-BTA200.

/ KS-SRA100 *8, *9 / XMDJVC100 / CNP2000UC *

C in series with XMDJVC100, CNP2000UC and KS-BTA200.

C, en serie con XMDJVC100, CNP2000UC y KS-BTA200.

C in avec le XMDJVC100, CNP2000UC et le

HD Radio TM is a proprietary trademark of iBiquity Digital Corp.

To use these components, set the external input setting correctly (see

page 18 of the INSTRUCTIONS).

Power cannot be supplied to the component through the CD changer

jack. You need to connect the power cord supplied for the component separately.

This model is a component of SIRIUS satellite radio System.

This model is a component of XM satellite radio System.

HD Radio

es una marca comercial de iBiquity Digital Corp.

Para utilizar estos componentes, configure el ajuste de entrada externa

correctamente (consulte la página 18 del MANUAL DE INSTRUCCIONES).

No puede suministrar energía eléctrica al componente a través del

jack del cambiador de CD. Es necesario conectar, aparte, el cable de alimentación suministrado con el componente.

Este modelo es un componente del sistema de radio satelital SIRIUS.

Este modelo es un componente del sistema de radio XM Satellite.

HD Radio

* *

est une marque de commerce d’iBiquity Digital Corp.

Pour utiliser ces appareils, réglez l’entrée extérieure correctement (voir

page 18 du MANUEL D’INSTRUCTIONS).

L’alimentation ne peut pas être fournie à l’appareil par la prise

de changeur de CD. Vous devez connecter séparément le cordon d’alimentation fourni pour l’appareil.

Ce modèle est un composant du système radio satellite SIRIUS.

Ce modèle est un composant du système radio satellite XM.

DVD RECEIVER WITH MONITOR

KW-AVX726/KW-AVX725/KW-AVX724/ KW-AVX626/KW-AVX625/KW-AVX624

For canceling the display demonstration, see page 10.

For installation and connections, refer to the separate manual.

INSTRUCTIONS

GET0605-001A

[U/UN/UT/A/UI]

Thank you for purchasing a JVC product.

Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best

possible performance from the unit.

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to

qualified service personnel.

3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical

instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.

How to read this manual

[European Union only]

Cautions on the monitor:

• The monitor built in this unit has been produced with high precision, but it may have some ineffective dots. This is inevitable and is not malfunction.

• Do not expose the monitor to direct sunlight.

• Do not operate the touch panel using a ball-point pen or similar tool with the sharp tip.

Touch the buttons on the touch panel with your

finger directly (if you are wearing a glove, take it off).

• When the temperature is very cold or very hot...

– Chemical changes occur inside, causing

malfunction.

– Pictures may not appear clearly or may move

slowly. Pictures may not be synchronized with the sound or picture quality may decline in such environments.

• < > is used to indicate the variable screens/ menus/operations/settings that appear on the touch panel.

• [ ] is used to indicate the buttons on the touch panel.

• ( page number) is used to indicate the reference page number of the related topics/ operations/settings.

• Operation index: To locate easily the desired operations/functions. ( 59)

• Indication language: English indications are used for the purpose of explanation. You can select the indication language from the <AV Menu>. ( 13)

For safety...

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any complicated operations.

Temperature inside the car...

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

How to reset your unit

• Your preset adjustments will also be erased (except the

registered Bluetooth device). ( 24, 35)

How to forcibly eject a disc

Back

• You can forcibly eject the loaded disc even if the disc is

locked. To lock/unlock the disc, 27.

• Be careful not to drop the disc when it ejects.

• If this does not work, reset your unit.

WARNINGS: (To prevent accidents and damage)

• DO NOT install any unit or wire any cable in a location where;

– it may obstruct the steering wheel and gearshift

lever operations.

– it may obstruct the operation of safety devices

such as air bags.

– it may obstruct visibility.

• DO NOT operate the unit while driving.

If you need to operate the unit while driving, be

sure to look around carefully.

• The driver must not watch the monitor while driving.

How to read this manual .............................. 2

How to reset your unit ................................. 3

How to forcibly eject a disc ........................... 3

INTRODUCTIONS

Playable disc type ........................................ 4

Basic operations ........................................... 5

• Using the monitor panel/touch panel ......... 5

• Using the remote controller (RM-RK252) .... 7

Preparation .................................................. 10

AV MENU

AV Menu operations .................................... 11

OPERATIONS

Listening to the radio ................................... 26

Disc operations ............................................. 27

• Operation buttons on the screen ................ 29

• Operations using the remote controller

(RM-RK252) ................................................ 30

USB operations (for

KW-AVX725/KW-AVX724

EXTERNAL DEVICES

Using the Bluetooth® devices ....................... 35

• Connecting a new Bluetooth device ........... 35

• Using the Bluetooth cellular phone ............ 36

• Using the Bluetooth audio player ............... 38

Listening to the CD changer ......................... 38

Listening to the iPod/iPhone ....................... 39

• When connected with the USB cable .......... 39

• When connected with the interface

adapter ....................................................... 40

Using other external components ................ 41

• AV-INPUT .................................................... 41

• EXT-INPUT .................................................. 42

REFERENCES

Maintenance ................................................ 43

More about this unit .................................... 44

Troubleshooting ........................................... 52

Specifications ............................................... 56

Operation index ........................................... 59

KW-AVX726/

) ....................... 34

Playable disc type

Disc type Recording format, file type, etc Playable

DVD

• DTS sound cannot be reproduced.

DVD Recordable/Rewritable (DVD-R/-RW *2, +R/+RW *3)

• DVD Video: UDF bridge

• DVD-VR

• DivX/MPEG1/MPEG2/JPEG/ MP3/WMA/WAV: ISO 9660 level 1, level 2, Romeo, Joliet

Dual Disc DVD side

CD/VCD Audio CD/CD Text (CD-DA)

CD Recordable/Rewritable (CD-R/-RW)

• ISO 9660 level 1, level 2, Romeo, Joliet

playable.

*3 It is possible to play back finalized +R/+RW (Video format only) discs. “DVD” is selected as its disc type when a

+R/+RW disc is loaded. +RW double layer discs are not playable.

DVD-Video * Region Code: South East Asia, Hong Kong region: 3 Australia: 4 India: 5 Ex.:

DVD-Audio/DVD-ROM

DVD-Video

DVD-VR

DivX/MPEG1/MPEG2

JPEG

MP3/WMA/WAV

AAC/MPEG4/DVD+VR/DVD-RAM

Non-DVD side

VCD (Video CD)

DTS-CD/SVCD (Super Video CD)/CD-ROM/ CD-I (CD-I Ready)

CD-DA

VCD (Video CD)

DivX/MPEG1/MPEG2

JPEG

MP3/WMA/WAV

AAC/MPEG4

Caution for DualDisc playback

The Non-DVD side of a “DualDisc” does not comply with the “Compact Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product may not be recommended.

Basic operations

Using the monitor panel/touch panel

Display <AV Menu> screen, ( 11)

Display the <Source Menu> screen, (

Display/exit the Short Cut icons, (

SOURCE

MP3

FLAT

3:00

01 01

Folder Name File Name

Track Title Artist Name Disc Title

USB cable from the rear of the unit, (

0:02:26

34) *

1 Resets the unit ( 3). 2 • Turns on the power.

• Attenuates the sound (if the power is on).

• Turns off the power. (Hold)

3 Changes the display information. * 4 • Adjusts the volume.

•

Bluetooth PHONE

the incoming calls. *

5 Remote sensor 6 Touch panel (see the following pages).

• Most of the touch panel operations are explained

unless mentioned otherwise.

• The screen will turn off if no operation is

done for about 10 seconds (depends on the <Illumination> setting). ( 16)

7 Motion sensor 8 Displays <AV Menu> screen.

: Adjusts the volume of

9 • Selects the source. *

TUNER USB

*1/

Bluetooth PHONE

AUDIO

•

Bluetooth PHONE

<Dial Menu> screen. *5 (Hold)

p •

KW-AVX726/KW-AVX725/KW-AVX724

: – Selects “ – Switches the setting between “HEAD MODE”

and “iPod MODE” (Hold)

•

KW-AVX626/KW-AVX625/KW-AVX624

AV-IN : Selects “

*1 – *5 : 6

DISC (DVD/VCD/CD)

iPod

*1 =

CD-CH/iPod/EXT-IN

Bluetooth

AV-IN

= (back to the beginning)

: Displays the

USB/

iPod

” as the source.

AV-IN

” as the source.

Continued on the next page

5INTRODUCTIONS

q • Displays <Open/Tilt> screen. *

[Open] : Opens the monitor panel. [Eject] : Ejects the disc. [Close] : Closes the monitor panel. [Tilt +] : Tilts open the monitor panel. [Tilt –] : Tilts close the monitor panel.

• Ejects the disc and display <Open/Tilt>

screen. (Hold)

• Closes the monitor panel when the panel is

opened.

w Monitor panel

<Source Menu> screen

You can also select the source using the touch panel.

SOURCE

TUNER

3:00

FLAT

1FM1 87. 5 MHz

ABC Radio

BAND

*1 For

KW-AVX726/KW-AVX725/KW-AVX724

Available display information varies among the

playback sources. (

50)

*3 This adjustment does not affect the volume level of

other sources.

*4 Available sources depend on the external components

you have connected, media you have attached, and the <Input> settings you have made. ( 15, 16)

*5 Only when Bluetooth phone is connected. *6 Shaded items cannot be used.

You can also adjust the volume by moving your finger on the touch panel as illustrated.

Caution on volume setting:

Source Menu

Current source Exit

Touch panel and button illumination

Dependable on the <Illumination> setting. ( 16)

• Turned off: When no operation is done for about 10 seconds.

• Turned on again: – When you touch the touch panel or move your

hand nearby. – When you use the remote controller. – When a call/SMS comes in (for Bluetooth

cellular phone). – When the signal from the rear view camera

comes in.

• Always turned on: – When <AV Menu> screen is displayed. – When <Source Menu> screen is displayed. – When <Open/Tilt> screen is displayed. – When <Illumination> is set to <Normal>.

When you drag your finger on the touch panel, it functions in the same way as touching [5 / ∞ /

4 / ¢].

Short Cut icons

You can easily access some frequently used functions by using the Short Cut icons.

SOURCE

TUNER

FLAT

3:00

Short Cut window appears.

• To exit from the window, press the button again.

SOURCE

TUNER

FLAT

3:00

Press a Short Cut icon.

Setup

Beep Telephone Muting

Illumination Motion Sensitiv. Initialize

Back

The corresponding screen is displayed.

Available icons vary among the sources.

1FM1 87. 5 MHz

ABC Radio

1FM1 87. 5 MHz

Normal

Proximity/Motion

Proxi/Motion-LCD

Touch Panel

Touch Panel - LCD

Displays <Illumination> menu.

( 16)

Changes the sound mode. ( 17)

Using the remote controller (RM-RK252)

Installing the batteries

BAND

R03/LR03/AAA

Insert the batteries into the remote controller by matching the polarity (+ and –) correctly.

BAND

Caution:

• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

• Battery shall not be exposed to excessive heat such as sunshine, fire, or the like.

If the effectiveness of the remote controller decreases, replace the batteries.

Before using the remote controller:

• Aim the remote controller directly at the remote sensor on the unit.

• DO NOT expose the remote sensor to bright light (direct sunlight or artificial lighting).

Turns on or off Track/Chapter Repeat. ( 20)

Displays <Aspect> menu.

( 13)

Activates <Voice Dialing> function. ( 23)

Displays <Redial> menu. (

23)

The following describes all the available operations for all the sources.

iPod operations are only applicable for

• USB/

KW-AVX726/KW-AVX725/KW-AVX724

• To easily locate the available operations between different type of files,

30, 31.

Continued on the next page

7INTRODUCTIONS

1 button

• Turns the power on if pressed briefly or attenuates the sound when the power is on.

• Turns the power off if pressed and held.

2 5/∞ buttons

•

TUNER

: Selects the preset stations.

•

DISC/USB

: – DVD-Video: Selects the title. – DVD-VR: Selects the program/Playlist. –

USB

/other discs (except VCD/CD): Selects the

folders if included.

•

CD-CH

– Selects the folders if included.

•

iPod

– 5 : Enters the main menu (then 5 / ∞ /

4 / ¢ work as menu

selecting buttons.) 5 : Returns to the previous menu. ∞ : Confirms the selection.

∞ : Pauses or resumes playback.

–

4 / ¢ buttons

•

TUNER

– Searches for stations automatically if pressed

briefly.

– Searches for stations manually if pressed and

held.

•

DISC/USB/CD-CH

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held.

•

iPod

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held.

•

iPod

: – Reverse skip/forward skip if pressed briefly. – Reverse search/forward search if pressed and

held. In menu selecting mode: – Selects an item if pressed briefly. (Then, press

∞ to confirm the selection.)

– Skips 10 items at a time if pressed and held.

•

Bluetooth AUDIO

– Reverse skip/forward skip if pressed briefly.

3 VOL (volume) + / – buttons

• Adjusts the volume level.

Bluetooth PHONE

•

– Adjusts the volume of the incoming calls.

2nd VOL (volume) buttons

• Not applicable for this unit.

4 * ASPECT button

• Changes the aspect ratio of the playback

pictures.

5 PHONE button

Applicable only when a Bluetooth phone is

connected.

• Displays <Dial Menu> screen.

• Displays <Redial> menu if pressed and held.

• Answers incoming calls.

6 * SETUP button

• Not applicable for this unit.

7 * TOP M (menu) button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Original Program screen.

• VCD: Resumes PBC playback.

8 OSD (on-screen display) button

• Shows the on-screen bar.

• Does not function as “*.”

9 SHIFT button

• Functions with other buttons.

p DISP (display) button

• Changes the display information.

q 1 / ¡ buttons

•

DISC/USB/ iPod

: Reverse search/forward

search.

w SOURCE button

• Selects the source.

e 3 (play) / 8 (pause) button

•

DISC/USB/ iPod

•

Bluetooth PHONE

•

Bluetooth AUDIO

r (end call) button

•

Bluetooth PHONE

: Starts playback/pauses.

: Answers incoming calls.

: Starts playback.

: Ends the call.

BAND button

•

TUNER

: Selects the bands.

7 (stop) button

•

DISC/USB/ iPod

•

Bluetooth AUDIO

: Stops playback.

: Pauses.

t * RETURN button

• VCD: Returns to the PBC menu.

y * MENU button

• DVD-Video: Shows the disc menu.

• DVD-VR: Shows the Playlist screen.

• VCD: Resumes PBC playback.

u * % / ﬁ buttons

• DVD-Video: Makes selection/settings.

•

CD-CH

: Changes discs in the magazine.

@ / # buttons

• DVD-Video: Makes selection/settings.

• DivX/MPEG Video: Skips back or forward by about 5 minutes.

ENT (enter) button

• Confirms selection.

i DUAL button

• Not applicable for this unit.

• Does not function as “#.”

o DIRECT button

•

DISC/USB

: Enters direct search mode for chapter/title/program/playlist/folder/track when pressed with SHIFT button ( 31).

CLR (clear) button

•

DISC/USB

: Erases the misentry when pressed with SHIFT button.

SURROUND button

• Not applicable for this unit.

* Functions as number buttons when pressed with SHIFT

button.

–

DISC/USB

: Enters chapter/title/program/playlist/ folder/track number after entering search mode by pressing SHIFT and DIRECT. ( 31)

–

TUNER

: (Number 1 to 6) : Enters preset station

number.

9INTRODUCTIONS

Preparation

Canceling the display demonstration and setting the clock

~ Turn on the power.

Ÿ Display <AV Menu> screen.

! Display <Setup> screen.

AV Menu

⁄ Cancel the demonstration.

Select [

Off

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Metal

Blue

Auto

@ Set the clock.

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Setup

Time Set Time Format

BAND

OSD Clock

Back

Setup

Time Set Time Format OSD Clock

Back

Bright

Blue

AutoOnce

Auto

7 AM6 PM

1 : 00

12Hours 24Hours

Off

3 : 45

¤ Finish the procedure.

Back

AutoOnce

7 AM6 PM

10 INTRODUCTIONS

AV Menu operations

You can use the <AV Menu> for most of the operations and settings. The available menu items shown on the touch panel, depends on the selected source.

• Non-available items will be shaded.

The following steps are one of the fundamental procedures.

• You can perform the operations/change the settings by following these steps unless mentioned otherwise.

~ Turn on the power.

Ÿ Display <AV Menu> screen.

BAND

AV Menu

! Press the desired icon/item to perform

the desired operations/settings.

Moves to the preceding menu page

Setup

Demonstration Wall Paper Color Scroll Dimmer

Dimmer Time Set

Back

Returns to the previous screen.

Moves to the succeeding menu page

• Some of the settings do not open the sub-setting screen, but just selecting an option will change the setting.

• To exit from the setting, press [

Indicates the next hierarchy level/setting item exists

Bright

Blue

AutoOnce

Auto

7 AM6 PM

Indicates the remaining time before the current screen exit automatically.

Exit

Setup : 12 – 16 Equalizer : 17 Sound : 18 Mode : 19 – 21 List : 21 – 22 Bluetooth : 23 – 25

Continued on the next page

11AV MENU

Menu item Selectable setting/item

Demonstration

Wall Paper You can select the background picture of the screen.

Color You can select the color of the background picture.

Scroll

Dimmer

Display

Dimmer Time Set Dimmer Level You can select the brightness for dimmer.

Bright You can adjust the brightness of the screen.

Picture Adjust *

The ILLUMINATION CONTROL lead connection is required. (See the Installation/Connection Manual.)

*2 Adjustable only when the source is “

♦

Off

♦

: Cancels. : Activates the demonstration on the screen. To stop it

temporarily, touch the screen. (

♦

Bright, Future, Horizon, Plain

♦

Blue, Light-Blue, Red, Orange, Yellow, Green, Purple, Dark-Blue,

Dark-Green, Brown, Light-Brown, Black

♦

Off Once Auto

: Cancels. : Scrolls the displayed information once. : Repeats scrolling (at 5-second intervals).

• Touching the information bar scrolls the text regardless of the setting.

♦

Off

♦

Auto

♦

Dimmer Time Set

Sets the Dimmer On (

♦

01 (bright), 02 (middle), 03 (dark)

♦

–15 to +15; Initial 00

You can adjust the following to make the screen clear and legible for watching

: Cancels. : Activates dimmer. : Dims the monitor when you turn on the headlights. * : Activates the Dimmer Time setting (see below).

)/Off ( ) times.

the playback picture. The setting will be stored—one for “

iPod

” (common) and the other for “

AV-IN

.”

Press [5] or [∞] to adjust. (–15 to +15; Initial 00)

♦

Bright

♦

Contrast

♦

Color

♦

Tint

: Adjust if the picture is too bright or too dark. : Adjust the contrast. : Adjust the color of the picture—lighter or darker. : Adjust the tint if the human skin color is unnatural,

only when color system setting is <NTSC>. ( 13)

DISC/USB/ iPod

” (the media must contain pictures or videos) or “

Initial: Underlined

10)

DISC/USB/

AV-IN

.”

Menu item Selectable setting/item

Aspect *

Display

Language *

NTSC/PAL *

Time Set Time Format

Clock

OSD Clock

Menu Language * Audio Language *

Disc

Not adjustable when no picture is shown.

*4 Turn off then on the power so that your setting takes effect. *5 Selectable only for “

Subtitle *

DISC/USB

You can change the aspect ratio of the picture.

Regular:

For 4:3 original pictures

Full:

For 16:9 original pictures

Panorama:

For viewing 4:3 pictures naturally on the wide screen

Auto: • For “

Select the indication language shown on the screen.

♦

English, Español, Français, Deutsch, Italiano, Nederlands, Svenska,

Dansk, Руccĸий, Português, , , ,

, Türkçe, ,

• The characters you can enter for assigning the titles also change according to the language selected. ( 48)

Select the color system of the external monitor connected.

♦

NTSC, PAL

Initial 1:00AM (

10)

Select either 12-hour system or 24-hour system. (

♦

12 Hours, 24 Hours

♦

Off

♦

Select the menu language; Initial English ( 50)

Select the audio language; Initial English ( 50)

: Cancels. : The clock time is displayed on the playback picture.

Select the subtitle language or erase the subtitle <Off>.; Initial English ( 50)

” (Playback stops when you change the setting.)

Aspect ratio of the incoming signal

4:3 16:9

DISC

”: Aspect ratio is automatically

selected to match the incoming signals.

• For the other video sources: Aspect ratio is

fixed to <Regular>.

10)

Continued on the next page

13AV MENU

Menu item Selectable setting/item

Monitor Type *

4:3PS

OSD Position *

16:9 4:3LB

Select the monitor type to watch a wide screen picture on the external monitor.

♦

16:9

: Select when the aspect ratio of the external

monitor is 16:9.

♦

4:3LB

(Letterbox)/

: Select when the aspect ratio of the external

monitor is 4:3.

4:3PS (Pan Scan)

Select the position of the on-screen bar. ( 33)

♦

: Higher position. : Lower position.

File Type *

Select the playback file type when a disc/USB contains different types of files. You can store this setting separately for each source— “

DISC/USB

♦

DivX Regist.

Disc

(Registration) *

This unit has its own Registration Code. Once you have played back a file with which the Registration Code recorded, this unit’s Registration Code is overwritten for copyright protection.

iPod Artwork *

7, *8

While playing back a track (in “HEAD MODE”), Artwork recorded for the track is displayed on the monitor.

♦

D. (Digital) Audio Output *

Select the signal format emitted through the DIGITAL OUT (optical) terminal. ( 49)

♦

*6 Selectable only for “ *7 For

KW-AVX726/KW-AVX725/KW-AVX724

DISC/USB

.” (Playback stops when you change the setting.)

*8 Skip the track so that your setting takes effect.

.” * Audio Still Picture Video Audio&Video

Off On

PCM

Dolby D

Stream

: Plays back audio files. : Plays back JPEG files. : Plays back DivX/MPEG1/MPEG2 files. :

Plays back audio files and DivX/MPEG1/MPEG2 files.

: Cancels. : Activates Artwork display. To display the artwork,

press DISP repeatedly.

• It takes 5 seconds or more to display an Artwork and no operations are available while loading it.

: Select this when connecting an amplifier or a

decoder incompatible with Dolby Digital or MPEG Audio, or when connecting to a recording device.

: Select this when connecting an amplifier or a

decoder compatible with Dolby Digital.

Select this when connecting an amplifier or a decoder compatible with Dolby Digital or MPEG Audio.

Menu item Selectable setting/item

Down Mix *

Disc

D. (Dynamic) Range Compres. (Compression) *

IF Band Width

Tuner

AV Input *

Input

Selectable only for “

* *10 Not selectable when “ *11 For

KW-AVX726/KW-AVX725/KW-AVX724

*12 The REVERSE GEAR SIGNAL lead connection is required. See Installation/Connection Manual. The rear view through

DISC/USB

.” (Playback stops when you change the setting.)

AV-IN

” is selected as the source.

When playing back a multi-channel disc, this setting affects the signals reproduced through the LINE OUT jacks.

♦

Dolby Surr.

: Select this to enjoy multi-channel surround audio

by connecting an amplifier compatible with Dolby Surround.

♦

Stereo

: Normally select this.

You can enjoy a powerful sound at a low volume level while playing Dolby Digital software.

♦

Auto

: Select to apply the effect to multi-channel encoded

software.

♦

On Auto

: Select to always use this function. : Increases the tuner selectivity to reduce interference

noises between adjacent stations. (Stereo effect may be lost.)

♦

Wide

: Subject to the interference from adjacent stations, but

sound quality will not be degraded and the stereo effect will remain.

You can determine the use of LINE IN and VIDEO IN jacks. ( 41)

♦

Off

♦

iPod (Off) *

: Select when no component is connected (“

skipped while selecting the source).

: Select when connecting the iPod/iPhone using the USB

AV-IN

Audio and Video cable for iPod/iPhone. ( 39)

♦

Audio&Video

♦

Audio

♦

Camera *

: Select when connecting an AV component such as a VCR. : Select when connecting an audio component such as a

portable audio player.

: Select when connecting a rear view camera to display

the picture (as it is taken).

♦

Navigation

: Select when connecting a Navigation System. ( 42)

” is

Continued on the next page

15AV MENU

Menu item Selectable setting/item

External Input *

Input

13, *14

For connecting an external component to the CD changer jack on the rear.

♦

Changer/iPod *

♦

External

: CD changer, ( : Any other than the above, ( 42).

38), iPod, ( 40).

♦

Off

♦

Off

♦

Muting1,

Muting2

: Cancels. : Activates the key-touch tone.

: Cancels. : Select either one which mutes the sounds while

using the cellular phone.

Beep

Telephone Muting *

Illumination You can turn off the screen and the light of the buttons on the monitor panel

while turning on the unit.

( 6)

Buttons on the

monitor panel Normal: Always lights. Always lights. Proximity/Motion: Lights up when your

Always lights. hand moves close to the buttons.

Others

Proxi/Motion-LCD: Lights up when your

hand moves close to the buttons.

Touch Panel: Lights up when your

Lights up when your

hand moves close to

the buttons.

Always lights. finger touches the buttons or touch panel.

Touch Panel-LCD: Lights up when your

finger touches the buttons or touch panel.

Motion Sensitiv. Change the sensitivity of the sensor for <

♦

Low, Mid, High

Lights up when your

finger touches the

buttons or touch panel.

Illumination> above.

Initialize Initialize all settings you have made in <AV Menu>. Press and hold [Enter]

to initialize the settings, then reset the unit. (

Not required for Bluetooth. They are automatically detected.

*14 Not selectable when the component connected to the CD changer jack is selected as the source. *15 The name of the component detected through the CD changer jack is shown. *16 The TEL MUTING lead connection is required. See Installation/Connection Manual.

Screen

Selects a preset sound mode suitable to the music genre.

♦

Flat (Initial), Hard Rock, R&B, Pop, Jazz, Dance,

Country, Reggae, Classic, User1, User2, User3

1 Display <AV Menu> screen.

2 Adjust the settings, then store.

Equalizer

Back Edit

BAND

2 Display <Equalizer> screen.

AV Menu

3 Select a sound mode.

Equalizer

Back Edit

Moves to the other 6 sound modes.

Ex.: When <Hard Rock> is selected

Storing your own adjustments

You can store your adjustments into <User1>, <User2>, and <User3>.

1 Perform steps 1 and 2 above to enter the

<Equalizer> screen.

Makes adjustments by moving each bar directly.

User Store

User1 User2 User3

Back

Ex.: When storing into <

User2>.

Preset equalizing values

Sound

400 Hz

1 kHz

2.5 kHz

6.3 kHz

mode

60 Hz

150 Hz

15 kHz

17AV MENU

Menu item Selectable setting/item

Fader/Balance Fader : Adjust the front and rear speaker output balance.

• When using a two-speaker system, set the fader level to “0.”

♦

F6 to R6; Initial 0

Balance : Adjust the left and right speaker output balance.

♦

L6 to R6; Initial 0

Press [

5/∞/2/3 ] to adjust.

Fader/Balance

Fader 0 Balance 0

Back

Initial: Underlined

Reset

Volume Adjust *

Adjust and store the auto-adjustment volume level for each source, comparing to the FM volume level. The volume level will automatically increase or decrease when you change the source.

Subwoofer Level *

High Pass Filter *

Crossover *

• <Fix> appears if “

♦

–12 to +12; Initial 00

Adjust the subwoofer output level.

♦

–06 to +08; Initial 00

♦

Through

♦

Select the crossover frequency between the front/rear speakers and the

TUNER/Bluetooth PHONE

” is selected as the source.

: Select when the subwoofer is not connected. : Select when the subwoofer is connected.

subwoofer.

♦

80Hz, 120Hz, 150Hz

Amplifier Gain *

You can change the maximum volume level of this unit.

♦

Off

♦

Low

: Deactivates the built-in amplifier. : VOL 00 to 30 (Select this if the maximum power of the

speakers is less than 50 W.)

♦

For “

DISC/USB

High

”: You can make the adjustments separately depending on the audio format—Dolby digital/MPEG

: VOL 00 to 50

Audio and the others.

*2 For

KW-AVX726/KW-AVX725/KW-AVX724

*3 The volume level automatically changes to “VOL 30” if you change to <Low> with the volume level set higher than

“VOL 30.”

Initial: Underlined

Selectable items when the source is:

•

TUNER

•

: Mono, SSM, Title Entry

DISC, USB, CD-CH, iPod

1, *2

iPod

: Repeat, Random, Audiobooks

AV-IN, EXT-IN

: Title Entry

: Repeat, Random

Menu item Selectable setting/item

Mono When an FM stereo broadcast is hard to receive, activate monaural mode for better

reception. The MONO indicator lights up.

♦

OFF

SSM (Strong-station

Sequential Memory)

You can automatically preset 6 stations for each FM band.

• Local FM stations with the strongest signals are searched and stored automatically in the FM band.

Title Entry You can assign titles (up to 16 characters) to 30 station frequencies (FM and AM),

and

EXT-IN

Press [Enter] to show the <Title Entry> screen.

: Activate monaural mode to improve FM reception, but stereo effect

will be lost. The MONO indicator lights up.

: Restore the stereo effect.

Mode

Mono SSM Title Entry

Back

Start Enter

. (For available characters, 48.)

AV-IN

[Store] : Confirm the entry. [2/3] : Move the cursor. [BS] : Erase the character before the cursor. [Del] : Erase the character on the cursor. [Cap] : Change the letter case (upper/lower). [A = 0 = Ä] : Change the character set. [Space] : Enter a space.

For

KW-AVX726/KW-AVX725/KW-AVX724

* *2 Not applicable in “iPod MODE.” ( 39)

;

Back

Continued on the next page

19AV MENU

Menu item Selectable setting/item

Repeat *

Available items depend on the loaded disc type and playback file.

Source

Disc/file type

DISC USB

CD-CH iPod iPod

Random

Repeat Chapter

Title Program Disc Folder Track One All Off

♦

Chapter

♦

Title

♦

Program

♦

Disc

♦

Folder

♦

Track

♦

One

♦

All

♦

Off

Available items depend on the loaded disc type and playback file.

Source

Disc/file type

Random Folder

Disc/USB (All) All Song Album Off

♦

Folder

♦

Disc/USB

DVD-Video

DVD-VR

DivX/MPEG/

MP3/WMA/

WAV

JPEG

VCD/CD

DISC USB

DivX/MPEG/

MP3/WMA/

WAV

VCD/CD

MPEG/MP3/

WMA/WAV

: Randomly plays all tracks of the current folder, then tracks of the next folders. : Randomly plays all tracks. (For VCD: When PBC is not in used.)

(All)

♦

All

♦

Song

♦

Albums

♦

Off

Not applicable in “iPod MODE.” ( 39)

* *4 For

KW-AVX726/KW-AVX725/KW-AVX724

: Randomly plays all tracks of all loaded discs. : Functions the same as “Shuffle Songs” *6 of the iPod. : Functions the same as “Shuffle Albums” of the iPod. : Cancels.

*5 Not applicable for video file. *6 You can activate <Shuffle Songs> in <Search Mode> menu. ( 22)

MPEG/MP3/

WMA/WAV

JPEG

MP3

CD-CH iPod iPod

MP3

—

Menu item Selectable setting/item

Audiobooks *

* *8 Not applicable in “iPod MODE.” ( 39)

*8You can select the playback speed of the “Audiobook” audio file in your iPod.

♦

Normal

♦

Faster

♦

Slower

For

KW-AVX726/KW-AVX725/KW-AVX724

: Plays at normal speed. : Plays faster. : Plays slower.

Source Operation/setting

TUNER • Storing a preset station manually

1 Press [BAND], then [ / ] to tune in to the station you want to preset. 2 Select <List> from the <AV Menu>. 3 Press and hold a preset number.

List

FM1 FM2 FM3

Back

• Selecting a preset station on the list

List

FM1 FM2 FM3

The station selected in step

1 is now stored in preset

number 4.

DISC/USB *

Selecting a track on the list

If the device contains folders, you can display the Folder/Track (File) Lists, then start playback.

*1 For

KW-AVX726/KW-AVX725/KW-AVX724

Back

List

Back

Folder 01 Folder 02 Folder 03 Folder 04 Folder 05 Folder 06

0003/00990005/0035

Track001.mp3 Track002.mp3 Track003.mp3 Track004.mp3 Track005.mp3 Track006.mp3

1 Current folder list number/

total folder list number

2 Current track list number/total

track list number of the current folder

* Press: Skips the list up or down.

Drag: Scrolls the list up or down.

Continued on the next page

21AV MENU

Source Operation/setting

Bluetooth PHONE Selecting a preset phone number on the list to make a call

List

Phone Number

Back

CD-CH Selecting a disc on the list

iPod *

2, *3

Disc List

Back

Disc 01

Disc 02

Disc 03

Disc 04

MP3 Disc

Disc 06

To go to the other list

Selecting a track/video from <Search Mode>

Search Mode

Music Videos Shuffle Songs

Back

List

Playlists Artists Albums Songs Podcasts Genres

Back

Playlists Artists Albums Songs Podcasts Genres

0003/0099

Track 01 Track 02 Track 03 Track 04 Track 05 Track 06

If an MP3 disc is selected, Folder/ Track List appear. Select a track to start playback.

♦

Music : Playlists, Artists, Albums,

Songs, Podcasts, Genres, Composers, Audiobooks

♦

Videos : Video Playlists, Movies,

Music Videos, TV shows, Video Podcasts

♦

Shuffle Songs : Playback starts if

this is selected.

Current track (video) number/total track (video) number

For

KW-AVX726/KW-AVX725/KW-AVX724

* *3 Not applicable in “iPod MODE.” ( 39)

Select “

Bluetooth PHONE

” or “

Bluetooth AUDIO

” as the source for operations.

• Firstly, use <Open> or <Search> to register and establish the connection with a device.

Menu item Selectable setting/item

Dial Menu *

Message *

* *2 Selectable only when the source is “

Select the method to make a call.

♦

Redial

♦

Received Calls

♦

Phonebook

♦

Missed Calls

♦

Phone Number

♦

Voice Dialing

If <Message Info> is set to <Manual>... ( 25)

Access the message list to read messages.

♦

Unread

♦

Read

♦

Unsent

♦

Sent

• The number of messages in each history is also shown.

Only for the device connected for “

(Short Message Service).

[BS] : Erase the character before the cursor. [Del] : Erase the character on the cursor. [Preset] : Goes to Preset List. You can preset the entered

[Dial] : Calls the entered number. : Only when the connected cellular phone has the voice

recognition system: = Speak the name you want to call.

: Messages you have not read. : Messages you have read. : Messages you have not sent. : Messages you have sent.

Bluetooth PHONE

.”

Bluetooth PHONE

Phone Number

Back

number by selecting a preset number.

” and the connected cellular phone is compatible with SMS

Continued on the next page

23AV MENU

Menu item Selectable setting/item

Open Preparation:

• Operate the Bluetooth device to turn on its Bluetooth function.

• Make sure “NEW DEVICE” is selected. If not, press [ 5 ] or [ ∞ ] to select it.

1 Press <Open> on the <Bluetooth> menu. 2 Enter a PIN (Personal Identification Number) *

• You can enter any number you like (1-digit to 16-digit number).

PIN Code

Back

3 Operate the Bluetooth device to connect while “Open...” is displayed on the screen.

Enter the same PIN code (as entered in the above step) on the device to be connected.

Now connection is established and you can use the device through the unit.

• The device remains registered even after you disconnect the device. Use <Connect> or activate <Auto Connect> to connect the same device the next time.

Search Preparation:

• Make sure “NEW DEVICE” is selected. If not, press [

1 Press <Search> on the <Bluetooth> menu.

The unit searches for available devices and displays the list of them. (If no available

device is detected, “Device Unfound” appears.)

2 Select a device you want to connect. 3 Enter the specific PIN code of the device to the unit.

• Refer to the instructions supplied with the device to check the PIN code.

4 Operate the Bluetooth device to connect while “Connecting...” is displayed on the

screen.

Now connection is established and you can use the device through the unit.

Some devices have their own PIN code. Enter the specified PIN code to the unit.

You can enter [0] – [9] only. [BS] : Erases the character

before the cursor.

[Del] : Erases the character on

the cursor.

[Enter] : Confirms the entry.

5 ] or [ ∞ ] to select it.

Menu item Selectable setting/item

Special Device Only for “NEW DEVICE.”

Select a device you want to connect from the list of Bluetooth devices which require some special procedure to establish the Bluetooth connection. Then, use <Open> or <Search> to connect.

• Once the connection is established, it is registered in the unit. You can connect the unit

and the device by using <Connect> the next time.

Connect Only for the registered devices.

Select a device from the list of registered devices, establish the connection with it.

Disconnect Only for the connected devices.

Disconnect the current device before connecting another device.

Delete Pairing Only for the registered devices.

Press <Yes> to confirm delete the registered devices.

Settings

Auto Connect *

Initial: Underlined

Auto Answer *

Message Info *

MIC Setting *

Version The Bluetooth software and hardware versions are shown.

Selectable only for “

Bluetooth PHONE

*5 Only for the cellular phone connected for “

When the unit is turned on, the connection is established automatically with...

♦

Off Last Order

: No Bluetooth device. : The last connected Bluetooth device. : The available registered Bluetooth device found

first.

♦

Off

: The unit does not answer the calls automatically.

Answer the calls manually.

♦

: The unit answers the incoming calls

automatically.

♦

Reject

♦

Auto

: The unit rejects all incoming calls. : The unit informs you of the arrival of a message

by ringing and displaying “Receiving Message.” To read the message, 37.

♦

Manual

: The unit does not inform you of the arrival of a

message.

Adjust the volume of the microphone connected to the Bluetooth adapter.

♦

01/02/03

.”

Bluetooth PHONE

.” Not selectable when “NEW DEVICE” is selected.

25AV MENU

Listening to the radio

Preset number

SOURCE

TUNER

Band

Sound mode

Tuner indicator

FLAT

3:00

~ Press [SOURCE], then press [TUNER]. Ÿ Press [BAND]. ! Press [ ] or [ ] to search for a station—Auto Search.

• Manual Search: Hold either [ ]or [ ] until “Manual Search” appears on the screen, then press it repeatedly.

• The ST indicator lights up when receiving an FM stereo broadcast with sufficient signal strength.

1FM1 87. 5 MHz

ABC Radio

Assigned station name

( 19)

• If no name is assigned, “No Name” appears.

BAND

Selecting a preset station

• Directly from the touch panel

SOURCE

TUNER

3:00

FLAT

1FM1 87. 5 MHz

ABC Radio

BAND

You can also select a preset station using the remote controller ( 8, 9) and from the Preset List ( 21).

You can display the Preset List by pressing [ ] or holding [5/∞].

Changing the display information

( 50)

• To improve the FM reception, 19.

• To automatically preset stations into memory,

19.

• To manually preset stations into memory, 21.

• To assignning titles to stations, 19.

Disc operations

The disc type is automatically detected, then playback starts (for some discs, the top menu of the disc appears).

If a disc does not have any disc menu, all tracks on it will be played repeatedly until you change the source or eject the disc.

” appears on the screen, the unit cannot accept the operation you have tried to do.

If “

• In some cases, without showing “ ,” operations will not be accepted.

~ Open the monitor panel.

<Open/Tilt> menu is displayed.

• By pressing and holding the button, you can open the monitor panel and eject the disc.

Open/Tilt

Prohibiting disc ejection

You can lock a disc in the loading slot.

! Insert a disc.

Label side

Monitor panel closes automatically. If not, press [Close].

Caution:

Do not place your finger behind the monitor panel.

When playing back a multi-channel encoded disc, the multi-channel signals are downmixed.

• You can fully enjoy multi-channel sound by connecting an amplifier or a decoder compatible with these multi-channel sources. ( 49)

• To select the playback mode, 20.

• To select tracks on the list, 21.

Back

To cancel the prohibition, repeat the same procedure to select <EJECT OK?>.

• Discs can be forcibly ejected. ( 3)

Continued on the next page

27OPERATIONS

Changing the display information

Each time you press the button, the display changes to show the different information. ( 50)

Ex.: While playing a DVD Video

SOURCE

DVD

FLAT

CHAP. RPT

3:00

1 Audio format—Dolby Digital, MP3, WMA, WAV 2 Disc type—DVD, DVD-VR, VCD, CD 3 Video format—DivX, MPEG, VR-PRG (program),

VR-PLAY (playlist), PBC

4 [5 / ∞]

• DVD Video/DVD-VR: Selects title/program/ playlist.

• DivX/MPEG/JPEG/MP3/WMA/WAV:

– Selects folder – Displays Folder/Track List (Hold)

5 • DVD Video: Title no./Chapter no./Playing time

• DVD-VR: Program no. (or Playlist no.)/ Chapter no./Playing time

• DivX/MPEG/MP3/WMA/WAV: Folder no./Track no./Playing time

• JPEG: Folder no./Track no.

• VCD/CD: Track no./Playing time

6 [6 ]

Starts playback/pauses

7 Indicates the button pressed ( / 8 / 7) 8 Sound mode ( 17) 9

Playback mode ( 20)

Disc/track information

• DVD Video/DVD-VR: Sampling frequency/Bit rate/Recorded signal channel no.

• DivX/MPEG/JPEG: Folder name/file name

• CD Text: Title/artist name/album name

– “No Name” appears for conventional CDs or if

not recorded

• MP3/WMA/WAV: Current folder name/current file name/tag data (current track title/artist name/album title) if it is recorded

q Stops playback w [4 / ¢]

• DVD Video/DVD-VR: Selects chapter.

• DivX/MPEG/JPEG/VCD/CD/MP3/WMA/WAV: Selects track.

• DVD Video/DVD-VR/DivX/MPEG/VCD/CD/MP3/ WMA/WAV: Reverse/forward search (Hold)

Operation buttons on the screen

You can display the following operation buttons while watching the playback pictures on the screen.

• If no operation is done for about 5 seconds, the operation buttons disappear (except when a disc menu is displayed).

[SOURCE] Displays <Source Menu> screen [5 ∞] 28 [3 / 8] Starts playback/pause [4 ¢] • Selects tracks

• Reverse/forward search (Hold)

Touch the screen (center portion).

Touch [KEY].

KEY].

Touch [

[ ] Displays <AV Menu> screen [7] Stops playback

• The above buttons also work when they are not shown on the screen (while watching the playback picture).

displays the menu (only for VCD with PBC)

For entering the numbers [0]–[9]=[ENTER] Enters numbers [Direct/CLR] • Switches between chapter/track

entry and title/folder entry

• Erases the last entry when you

enter a wrong number

Ex.: To enter “105,” press [1], [0], [5], then [ENTER]

Touch [

KEY].

To end the operations, touch the screen again.

*1 While a disc menu is played back for DVD, [KEY] is

automatically displayed. On the disc menu, you can select a menu item directly by touching it on the screen

*2 Displays Short Cut icons. ( 7) *3 Playback time. ( 28)

29OPERATIONS

Operations using the remote controller (RM-RK252)

Button

Stop play Stop play

Start play/Pause (if pressed during play) • DivX/MPEG: Start play/Pause (if pressed

• Reverse/forward chapter search *1 (No sound

can be heard.)

• Slow motion *2 during pause (No sound can

be heard.)

– DVD-VR: Reverse slow motion does not work.

• Select chapter (during play or pause)

• Reverse/fast-forward chapter search *3 (No

sound can be heard.) (Hold)

• DVD-Video: Select title (during play or pause)

• DVD-VR: • Select program

• Select playlist (during play or pause)

—

Select aspect ratio Select aspect ratio

Search speed:

*2 Slow motion speed: *3 Search speed: *4 Search speed: *5 Search speed:

Using menu driven features... (DVD-Video)

1 Enter the menu screen.

2 Select an item you want to start play.

during play)

• JPEG: • Start play (Slide show: Each file is shown for a few seconds.)

• Pause (if pressed during play).

• DivX/MPEG: Reverse/forward track search *

(No sound can be heard.)

• DivX/MPEG: • Select track

• Reverse/fast-forward track

search *5 (No sound can be heard.) (Hold)

• JPEG: Select file

Select folder

• DivX/MPEG: Skip back or forward the scenes

by about 5 minutes

Canceling the PBC playback... (VCD)

During stop...

• To resume PBC, press TOP M/MENU.

Number buttons

(0 – 9)

JVC GET0602-001A User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

INSTRUCTIONS

INFORMATION (For U.S.A.)

IMPORTANT FOR LASER PRODUCTS

Playable disc type

CONTENTS

Basic operations

Preparation

AV Menu operations

Listening to the radio

Disc operations

USB operations

Listening to the CD changer

Listening to the satellite radio

Listening to the iPod/iPhone

Using other external components

More about this unit

Maintenance

Troubleshooting

Specifications

Operation index

WARNINGS

Parts list for installation and connection

INSTALLATION

Before installing the unit

ELECTRICAL CONNECTIONS

TROUBLESHOOTING

INSTRUCTIONS

IMPORTANT FOR LASER PRODUCTS

CONTENTS

Playable disc type

Basic operations

Preparation

AV Menu operations

Listening to the radio

Disc operations
