JVC GD V502U, GD-V422U User Manual

PLASMA DISPLAY MONITOR

GD-V422U GD-V502U

For customer Use:

Enter below the Model No. and the Serial No. which is located on the rear panel of the cabinet. Retain this information for future reference.

INSTRUCTIONS

Model No.

Serial No.

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrow-head within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons.

WARNING: To prevent damage which may result in fire or shock hazard, do not expose this apparatus to rain

or moisture. Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set. (including on shelves above, etc.)

WARNING: 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to

qualified service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin grounding-type power plug. This plug will only fit a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician. Do not defeat the purpose of the grounding plug.

The exclamation point within a triangle is intended to tell the user that important operating and servicing instructions are in the papers with the appliance.

Important Safety Instructions

1) Read these instructions. All the safety and operating instructions should be read before the appliance is operated.

2) Keep these instructions. The safety and operating instructions should be retained for future reference.

3) Heed all warnings. All warnings on the appliance and in the operating instructions should be adhered to.

4) Follow all instructions. All operating and use instructions should be followed.

5) Do not use this apparatus near water. For example, near a bathtub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.

6) Clean only with dry cloth. Do not use liquid cleaners or aerosol cleaners. Use a dry cloth for cleaning.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and Openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11) Only use attachments / accessories specified by the Manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

13) Unplug this apparatus during lightning storms or when unused for long periods of time. This will prevent damage to the product due to lightning and power-line surges.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

Dear JVC Customer

Welcome to the JVC family of customers. We hope that you will have many years of enjoyment from your new Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference. Retain your purchase receipt also, and note down the model number and serial number of your set in the space provided on the cover of these instructions.

Important Safety Instructions ...................................... 3

FCC STATEMENT .......................................................... 5

Safety Precautions ........................................................ 6

Accessories ................................................................... 8

Accessories Supplied ................................................... 8

Remote Control Batteries ............................................. 8

Connections .................................................................. 9

PC Input Terminals connection .................................. 10

SERIAL Terminals connection .................................... 11

AV & COMPONENT connection ................................ 12

RGB signal (R, G, B, HD, VD) ................................... 12

Power ON / OFF ........................................................... 13

AC cord conncection .................................................. 13

Power ON / OFF ........................................................ 13

Basic Controls ............................................................. 14

MULTI PIP .................................................................. 14

On-Screen Menu Displays .......................................... 16

Input Signal Selection................................................. 18

Select the Input Signal ............................................... 18

Selecting the ON-Screen Menu Language ................ 18

ASPECT Controls ........................................................ 19

Adjusting PICTURE POSITION / SIZE........................ 20

SOUND Adjustment .................................................... 21

MUTE ......................................................................... 21

PICTURE Adjustments ................................................ 22

ADVANCED SETTINGS ............................................ 23

PRESENT TIME SETUP / SET UP TIMER .................. 24

PRESENT TIME SETUP............................................ 24

SET UP TIMER .......................................................... 25

SCREENSAVER (For preventing after-images) ........ 26

Setup of SCREENSAVER Time ................................. 27

Reduces screen after-image ...................................... 27

SIDE BAR ADJUST ................................................... 28

Digital Zoom ................................................................ 29

Reduces power consumption .................................... 30

Customizing the Input labels ...................................... 30

SET UP for MULTI DISPLAY ....................................... 31

How to setup MULTI DISPLAY................................... 31

How to set the Display location number for each Plasma Display

SET UP for Input Signals ............................................ 33

COMPONENT / RGB IN SELECT ............................. 33

3D Y / C FILTER – For NTSC Video images ...................... 33

COLOR SYSTEM / ASPECT AUTO........................... 34

3:2 PULLDOWN......................................................... 34

SYNC ......................................................................... 35

H-FREQ. (kHz) / V-FREQ. (Hz).................................. 35

Troubleshooting .......................................................... 36

VIDEO / COMPONENT / RGB / PC input signals ...... 37

Specifications .............................................................. 38

....... 32

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC CAUTION: Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly approved by JVC could cause harmful interference and would void the user’s authority to operate this device.

Attach the ferrite core:

The ferrite cores provided as a supplied accessory must be used when connecting this Plasma Display to video equipment. (see page 10, 11)

FCC CAUTION: To assure continued compliance and possible undesirable interference, the provided ferrite cores must be used when connecting this plasma display to video equipment; and maintain at least 40 cm of spacing from other peripheral devices. Refer to instructions on pages 10, and 11.

CANADIAN NOTICE:

This Class A digital apparatus complies with Canadian ICES-003.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause permanent after-image to remain on the Plasma Display. Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

Trademark Credits

VGA is a trademark of International Business Machines Corporation.

•

Macintosh is a registered trademark of Apple Computer, USA.

•

S-VGA is a registered trademark of the Video Electronics Standard Association.

•

Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.

Safety Precautions

WARNING

Set up

Do not place the Plasma Display on sloped or unstable surfaces.

The Plasma Display may fall off or tip over.

•

Do not place any objects on top of the Plasma Display.

If water spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result in fire

•

or electric shock. If any foreign objects get inside the Plasma Display, please consult an Authorized Service Center.

Do not cover the ventilation holes.

Doing so may cause the Plasma Display to overheat, which can cause fire or damage to the Plasma Display.

•

If using the Stand Unit (optional accessory), leave a space of 3 15/16” (10 cm) or more at the top, left and right, 2 3/8” (6 cm) or more at the bottom, and 2 3/4” (7 cm) or more at the rear. If using some other setting-up method, leave a space of 3 15/16” (10 cm) or more at the top, bottom, left and right, and 3/4” (1.9 cm) or more at the rear.

Avoid installing this product near electronic equipment that easily receives electromagnetic waves.

It may cause interference in image, sound, etc. In particular, keep video equipment away from this product.

•

AC Power Supply Cord

The Plasma Display is designed to operate on 120 V AC, 50/60 Hz. Securely insert the power cord plug as far as it will go.

If the plug is not fully inserted, heat may be generated which could cause fire. If the plug is damaged or the wall socket

•

plate is loose, they should not be used.

Do not handle the power cord plug with wet hands.

Doing so may cause electric shocks.

•

Do not do anything that might damage the power cable. When disconnecting the power cable, hold the plug, not the cable.

Do not make any modifications, place heavy objects on, place near hot objects, heat, bend, twist or forcefully pull the

•

power cable. Doing so may cause damage to the power cable which can cause fire or electric shock. If damage to the cable is suspected, have it repaired at an Authorized Service Center.

If the Plasma Display will not be used for a long period of time, unplug the power cord from the wall outlet.

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odor is detected from the Plasma Display, unplug the power cord immediately.

Continuous use of the Display under these conditions might cause fire or permanent damage to the unit. Have the

•

Display evaluated at an Authorized Service Center. Services to the Display by any unauthorized personnel are strongly discouraged due to its high voltage dangerous nature.

If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damaged, disconnect the power cord plug immediately.

A short may occur, which could cause fire. Contact an Authorized Service Center for any repairs that need to be made.

•

Safety Precautions

CAUTION

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional accessories may cause instability which could result in the possibility of injury.

(All of the following accessories are manufactured by JVC)

Speakers

•

Stand Unit

•

Wall Mounting Unit

•

Wall Mounting Unit (angled)

•

Ceiling Suspension Unit

•

Always be sure to ask a qualified technician to carry out set-up.

...................................................

.................................................

....................................

......................

............................

TS-C422SPG (GD-V422U) TS-C5001SPG (GD-V502U) TS-C50P5G TS-C50P6G TS-C50P2G TS-C50P3G

When using the Plasma Display

Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display.

Top of the Plasma Display is usually very hot due to the high temperature of exhaust air being released through the

•

ventilation holes. Burns or personal injuries can happen if any body parts are brought too close. Placing any object near the top of the display could also result in heat damages to the object as well as to the Display if its ventilation holes are blocked.

Be sure to disconnect all cables before moving the Plasma Display.

Moving the Display with its cables attached might damage the cables which, in turn, can cause fire or electric shock.

•

Disconnect the power plug from the wall outlet as a safety precaution before carrying out any cleaning.

Electric shocks can result if this is not done.

•

Clean the power cable regularly to prevent it from becoming dusty.

Built-up dust on the power cord plug can increase humidity which might damage the insulation and cause fire. Unplug

•

the cord from the wall outlet and clean it with a dry cloth.

This Plasma Display radiates infrared rays, therefore it may affect other infrared communication equipment. Install your infrared sensor in a place away from direct or reflected light from your Plasma Display.

Cleaning and maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint-free cloth.

If the surface is particularly dirty, soak a soft, lint-free cloth in a weak detergent solution and then wring the cloth to

•

remove excess liquid. Use this cloth to wipe the surface of the display panel, then wipe it evenly with a dry cloth, of the same type, until the surface is dry. Do not scratch or hit the surface of the panel with fingernails or other hard objects. Furthermore, avoid contact with volatile

•

substances such as insect sprays, solvents and thinner, otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

If the cabinet is particularly dirty, soak the cloth in a weak detergent solution and then wring the cloth dry. Use this cloth

•

to wipe the cabinet, and then wipe it dry with a dry cloth. Do not allow any detergent to come into direct contact with the surface of the Plasma Display.

•

If water droplets get inside the unit, operating problems may result. Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the cabinet

•

surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact with articles made from rubber or PVC.

Note:

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent after-image to remain on the Plasma Display. Examples of still pictures include logos, video games, computer images, teletext and images displayed in 4:3 mode.

Accessories

Accessories Supplied

Check that you have the Accessories and items shown

Operating Instruction book

Remote Control Transmitter EUR646532

INPUT

SURROUND

VOL


SET UP

SOUND

ZOOM

MULTI

SWAP SELECT

MOVE

GD-V422U GD-V502U

Ferrite core (small size) × 1

PIP

PICTURE POS. /SIZE

ASPECT

OFF TIMER

PLASMA DISPLAY

Ferrite core (large size) × 2

Remote Control Batteries

Requires two AA batteries.

1. Turn the transmitter face down. Press and slide off the battery cover.

2. Install the batteries as shown in the battery compartment.

(Polarity + or – must match the

markings in the compartment.)

Batteries for the Remote Control Transmitter (AA Battery × 2)

Fixing bands

3. Replace the cover and slide in reverse until the lock snaps.

AC cord

Two AA size

Helpful Hint:

For frequent remote control users, replace old batteries with Alkaline batteries for longer life.

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.

Observe the following precautions:

1. Batteries should always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5. Battery replacement is necessary when remote control acts sporadically or stops operating the Plasma Display.

Connections

When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation.

(Example: GD-V422U)

Speakers (Optional accessories)

SPEAKERS Terminals (R)

SPEAKERS Terminals (L)

AC cord connection (see page 13)

– AC cord fixing

1. Open the clamper.

2. Insert the AC cord and

close the clamper securely.

Clamper

Note: The power plug in the illustration may not be the type fitted to your set.

AC cord

– Cable fixing bands Secure any excess cables with bands as required.

Pass the attached cable fixing band through the clip as shown in the figure.

To secure cables connected to Terminals, wrap the cable fixing band around them then pass the pointed end through the locking block, as shown in the figure.

While ensuring there is sufficient slack in cables to minimize stress (especially in the power cord), firmly bind all cables with the supplied fixing band.

To tighten:

Pull

3. Slide up the clamper and fix the AC cord plug securely.

To loosen:

Push the catch

When loosen the clamper:

SLOT1

Optional Terminal Board Insert Slot (covered)

R AUDIO L

AV Terminals (see page12)

R AUDIO L

S VIDEO IN

SLOT2 SLOT3

VIDEO OUT

VIDEO IN

COMPONENT/RGB IN and Audio IN Terminals (see page12)

VD HD

COMPONENT/RGB IN

PR/CR/R PB/CB/B

Y/G

From EXTERNAL monitor terminal on Computer (see page 10)

Notes: (1) At factory shipment, Video Input Cards are installed in SLOT 2 and SLOT 3.

(2) Insert the optional Video Input Cards before combining the Plasma Display with the Stand Unit.

Pull

AUDIO

SERIALPC IN

From SERIAL Terminal on Computer (see page 11)

Connections

PC Input Terminals connection

COMPUTER

R - STANDBY G POWER ON

Conversion adapter (if necessary)

Connect a cable which matches the audio output terminal on the computer.

Installing the ferrite core (Small size)

Less than

(10 cm)

Ferrite core (small size)

Audio

(supplied)

Open

VOL

INPUTMENU ENTER

— +

Ferrite core (large size) (supplied)

RGB

PC cable

Less than

3" (10 cm)

mini D-sub 15p

Stereo plug

AUDIO

PC IN

Pull back the tabs (in two places)

Installing the ferrite core (Large size)

Pull back the tabs (in two places)

Open

Press the cable through and close

Notes:

(1) Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical

scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

(2) The display resolution is a maximum of 768 × 768 dots (GD-V422U), 1,024 × 768 dots (GD-V502U) when the aspect mode

is set to “4:3”, and 1,024 × 768 dots (GD-V422U), 1,366 × 768 dots (GD-V502U) when the aspect mode is set to “16:9”. If the display resolution exceeds these maximums, it may not be possible to show fine detail with sufficient clarity.

(3) The PC input terminals are DDC1/2B-compatible. If the computer being connected is not DDC1/2B-compatible, you will

need to make setting changes to the computer at the time of connection. (4) Some PC models cannot be connected to the set. (5) There is no need to use an adapter for computers with DOS/V compatible mini D-sub 15P terminal. (6) The computer shown in the illustration is for example purposes only. (7) Additional equipment and cables shown are not supplied with this set. (8) Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified

frequency range. (9) Component Input is possible with the pin 1,2,3 of the mini D-sub 15P Connector.

Signal Names for mini D-sub 15P Connector

67839

Pin Layout for PC Input Terminal

1514131211

Pin No.

1 2 3 4 5

Signal Name

R (PR/CR)

G(Y)

B(PB/CB) GND (Ground) GND (Ground)

Pin No.

6 7 8 9

Signal Name GND (Ground) GND (Ground) GND (Ground)

NC (not connected)

GND (Ground)

Pin No.

11 12 13 14 15

Signal Name

GND (Ground)

SDA

HD/SYNC

SCL

SERIAL Terminals connection

The SERIAL terminal is used when the Plasma Display is controlled by a computer.

Connections

COMPUTER

RS-232C Straight cable

Ferrite core (large size) (supplied)

SERIAL

Pin layout for RS-232C

9876

53214

Installing the ferrite core

(Large size)

D-sub 9p

Less than

/16

Open

(10 cm)

Notes:

(1) Use the RS-232C cable to connect the computer to the Plasma Display. (2) The computer shown is for example purposes only. (3) Additional equipment and cables shown are not supplied with this set.

The SERIAL terminal conforms to the RS-232C interface specification, so that the Plasma Display can be controlled by a computer which is connected to this terminal. The computer will require software which allows the sending and receiving of control data which satisfies the conditions given below. Use a computer application such as programming language software. Refer to the documentation for the computer application for details.

Communication parameters

Signal level

Synchronization method

Baud rate

Parity

Character length

Stop bit

Flow control

RS-232C compliant

Asynchronous

9600 bps

None 8 bits

1 bit

–

D-sub 9-pin female

RS-232C Conversion cable

2 3 5

4 • 6

7 8

1 • 9

Details

R X D T X D

GND

Non use

Shorted

Basic format for control data

The transmission of control data from the computer starts with a STX signal, followed by the command, the parameters, and lastly an ETX signal in that order. If there are no parameters, then the parameter signal does not need to be sent.

STX

Start (02h)

Colon Parameter(s)

3-character command (3 bytes)

(1 - 5 bytes)

ETX:C2C1 C3 P2P1 P3 P4 P5

End (03h)

Notes:

(1) If multiple commands are transmitted, be sure to wait

for the response for the first command to come from this unit before sending the next command.

(2) If an incorrect command is sent by mistake, this unit

will send an “ER401” command back to the computer.

Command

Command PON POF AVL

AMT IMS

DAM

Parameter None None

0 1 None SL1 SL2 SL3 PC1 None NORM ZOOM FULL JUST SELF

Power ON Power OFF Volume 00 - 63 Audio MUTE OFF Audio MUTE ON Input select (toggle) Slot1 input Slot2 input Slot3 input PC input Screen mode select (toggle) NORMAL (4:3) ZOOM FULL JUST AUTO

Control details

With the power off, this display responds to PON command only.

Connections

AV & COMPONENT Connection

COMPONENT VIDEO OUT

Example of input signal source

DVD

Digital TV-SET-TOP-BOX (DTV-STB)

Example of input signal source

S VIDEO VCR

CAMCORDER

SLOT1

Y, PB, PR,

OUT

AUDIO

OUT

R AUDIO L

VIDEO OUT

VIDEO IN

S VIDEO IN

SLOT2 SLOT3

VD HD

COMPONENT/RGB IN

PR/CR/R PB/CB/B

RCA-BNC adapter plug

AUDIO

Y/G

PC IN

MONITOR

VIDEO IN

VCR

AUDIO

OUT

S VIDEO

OUT

VIDEO

OUT

Notes:

(1) Change the “Component / RGB-in” setting in the “Setup” menu to “Component”. (see page 33) (2) Additional equipment, cables and adapter plugs shown are not supplied with this set.

RGB signal (R, G, B, HD, VD)

Computer

Notes:

(1) Change the “Component / RGB-in” setting in the “Setup” menu to “RGB”. (see page 33) (2) Additional equipment, cables and adapter plugs shown are not supplied with this set.

RGB Camcorder

R AUDIO L

VIDEO OUT

VIDEO IN

VD HD

COMPONENT/RGB IN

PR/CR/R PB/CB/B

Y/G

Power ON / OFF

AC cord connection

Connecting the AC cord plug to the Plasma Display.

Power ON / OFF

Fix the AC cord plug securely to the Plasma Display with the clamper. (See page 9)

Connecting the AC plug to the Wall Outlet

Note:

AC plug types vary between countries / regions.

VOL

INPUTMENU ENTER

— +

R - STANDBY G POWER ON

Power Indicator

Remote Control Sensor

When the POWER is turned on for the first time, the LANGUAGE selection screen is displayed.

From the second time on, language selection can be done from the setup menu. (see page 18)

Select the desired language using the

and

keys and press the ACTION

button.

INPUT

SURROUND

VOL

Press the Main power switch on the Plasma Display to turn the Plasma Display on: Power-On.

If the power indicator is lit red, press the power button on the remote control to turn the Plasma Display on.

Example: The screen below is displayed for a while after the Plasma

OSD LANGUAGE

English (UK

Deutsch Fran ais

Italiano

a ol

ENGLISH (US

SELECT

Power Indicator: Green

Display is turned on. (setting condition is an example.)

From the second time on, the screen shown

)

SET

Press the

below is displayed for a while (setting condition is an example).

NORMAL

button on the remote control to turn the

Plasma Display off.

Power Indicator: Red (STAND-BY)

Press the

button on the remote control to turn the

Plasma Display on.

Power Indicator: Green

Turn the power to the Plasma Display off by pressing the

Main power switch on the Plasma Display, when the

Plasma Display is on or in standby mode.

Note: During operation of the power management function, the power

indicator turns orange in the power off state.

Basic Controls

INPUT MENU ENTER

Main Power

R - STANDBY G POWER ON

On / Off Switch

Power Indicator

The Power Indicator will light.

Power-OFF .. Indicator not illuminated (The unit will

•

still consume some power as long as the power cord

Remote control sensor

MENU Screen ON / OFF

Each time the MENU button is pressed, the menu screen will switch. (see page 16)

is still inserted into the wall outlet.)

Stand-by .... Red

•

Power-ON ..... Green

•

DPMS ............Orange

•

during operation of PC’s screensaver.]

[With PC input signal and

INPUT button (INPUT1, INPUT2, INPUT3 and PC IN Selection)

(see page 18)

C.A.T.S sensor Plasma C.A.T.S (Contrast Automatic Tracking System)

Plasma C.A.T.S automatically senses the ambient light conditions and adjusts the brightness and gradation accordingly, to optimise contrast. (Effective when Picture mode is set to Auto.)

Status button

Press the “Status” button to display the current system status.

4:3

Aspect mode (see page 19)

Off timer

Input label

The off timer indicator is displayed only when the off

Off timer 90

timer has been set.

MULTI PIP

MULTI

Each time pressing this button main picture and sub picture will be displayed as follows bellow.

PIP

Normal Viewing

[Picture and Picture]

Main picture Sub picture

MULTI

PIP

SWAP SWAP SWAP

[Picture out Picture]

Main picture Sub picture

MULTI

PIP

VOL

– +

Enter / Aspect button

(see page 16, 19)

Normal Viewing PICTURE SET UP

SOUND PICTURE POS./ SIZE

Volume Adjustment

Volume Up “+” Down “–” When the menu screen is displayed.

“+”: press to move the cursor up “–”: press to move the cursor down

N button

(see page 20-23)

PICTURE button

(see page 22)

[Picture in Picture]

Main picture

MULTI

PIP

Sub picture

SWAP

SELECT

press to swap main picture and sub picture.

Press the SELECT button

Under main picture and sub picture display, select the picture which you would like to change input modes.

INPUT

SURROUND

VOL

ZOOM MOVE

Press the MOVE button Each time the location of the sub picture will be moved.

Notes: (1) This button is effective only in the picture in picture.

INPUT

Press to change input signal.

The sub picture may be hidden by the on screen display, depending on its position.

(2)

Notes: (1) Sound output is from the main picture.

(2) Using this function to display picture in picture for the purpose of public display

or commercial gain may infringe on copyright laws.

[Example] Main picture label is bright Sub picture label is bright

PC1

VIDEO1

Input modes switching is possible

Main picture label is changed Sub picture label is changed

VIDEO2 VIDEO1

Picture is changed

SELECT

PC1

VIDEO1

PC1

VIDEO3

Basic Controls

Stand-by (ON / OFF) button

The Plasma Display must first be plugged into the wall outlet and turned on at the power switch (see page 13). Press this button to turn the Plasma Display On, from Standby mode. Press it again to turn the Plasma Display Off to Standby mode.

SURROUND button

The benefits of surround sound are enormous. You can be completely enveloped in sound; just as if you were at a concert hall or cinema.

The surround setting switches on and off each time the SURROUND button is pressed.

INPUT button (

INPUT1, INPUT2, INPUT3 and PC IN

Press to select INPUT1, INPUT2, INPUT3 and PC IN input SLOTS sequentially. (see page 18)

INPUT

SURROUND

Sound mute On / Off (see page 21)

Volume Adjustment

Press the Volume Up “+” or Down “–” button to increase or decrease the sound volume level.

VOL

R button (see page 20-21)

Press the R button to return to previous menu screen.

ON OFF

SURROUND

Note:

The surround settings are memorized separately for each Sound mode (Normal, Auto).

Selection)

ACTION button

Press to make selections.

POSITION buttons SOUND button (see page 21)

Press to adjust the SOUND.


SOUND

SET UP

SET UP button (see page 16-17)

MULTI

PIP

SWAP SELECT

ZOOM

ZOOM MOVE

PICTURE POS./ SIZE button

PICTURE POS. /SIZE

ASPECT

(see page 20)

ASPECT button

Press to adjust the aspect. (see page 19)

OFF TIMER

OFF TIMER button

The Plasma Display can be preset to switch to stand-by after a fixed period. The setting changes to 30 minutes, 60 minutes, 90 minutes and 0 minutes (off timer cancelled) each time the button is pressed.

PLASMA DISPLAY

PC button

Press the “PC” input mode selection button to select the PC input mode. This button is used to switch directly to PC input mode.

Digital Zoom(see page 29)

ZOOM

Press to access

MOVE

Digital Zoom.

This displays an enlargement of the designated part of the displayed image.

30 60

When three minutes remain, “Off timer 3” will flash. The off timer is cancelled if a power interruption occurs.

Note: In 2 screen display, the same input mode cannot be selected for the main picture and sub picture.

On-Screen Menu Displays

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SET UP 2/2

AUTO POWER OFF

OFF

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

The MENU button on the unit can also To PICTURE adjust menu (see page 22)


NORMALIZE PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP ADVANCED SETTINGS

NORMAL

STANDARD

0 0 0 3

NORMAL

be pressed.

INPUT MENU ENTER

VOL

Each time the MENU button is pressed, the menu screen will switch.

Normal Viewing PICTURE SET UP

SOUND PICTURE POS./ SIZE

Press to select .

[ from the unit ]

INPUT MENU ENTER

VOL

Press to select “ON”.

Press to enter ADVANCED SETTINGS.

To ADVANCED SETTINGS (see page 22, 23)

ADVANCED SETTINGS

NORMALIZE BLACK EXTENSION INPUT LEVEL W/B HIGH R W/B HIGH B W/B LOW R W/B LOW B GAMMA AGC

NORMAL

0 0 0

0 0 0 0

2. 2

OFF

To SOUND adjust menu (see page 21)

SOUND

NORMALIZE AUDIO MENU BASS TREBLE BALANCE SURROUND

NORMAL

STANDARD 0 0 0

OFF

INPUT

SURROUND

VOL


MULTI

PIP

PICTURE POS. /SIZE

PLASMA DISPLAY

SOUND

SWAP SELECT

SET UP

ZOOM MOVE

ASPECT

OFF TIMER

Press to select.

Press to access each adjust

screen.

To PICTURE POS./ SIZE adjust menu (see page 20)

During “VIDEO (S VIDEO)” and “COMPONENT” input signal.

PICTURE POS./SIZE

H-POS H-SIZE V-POS V-SIZE

NORMAL

NORMALIZE

During “RGB” and “PC” input signal .

PICTURE POS./SIZE

NORMALIZE

NORMAL

H-POS H-SIZE V-POS V-SIZE CLOCK PHASE

On-Screen Menu Display from Remote Control

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

INTERVAL

SHOW DURATION

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

SAVER DURATION

START

PRESENT TIME OF DAY

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

TIME OF DAY

START TIME

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

FINISH TIME

START

PRESENT TIME OF DAY

10 : 00

Press to access

each adjust

[ from the unit ]

INPUT MENU ENTER

VOL

screen.

Press the R button to return to previous menu.

Press to return to previous menu screen.

To SIGNAL screen for VIDEO (S VIDEO) (see page 33, 34)

[

SIGNAL

3D Y/C FILTER (NTSC COLOR SYSTEM 3:2 PULLDOWN ASPECT AUTO (4:3

)

NORMAL

VIDEO

AUTO

OFF

]

To SIGNAL screen for COMPONENT (see page 34)

SIGNAL

3:2 PULLDOWN

[

COMPONENT

]

OFF

To SIGNAL screen for RGB and PC (see page 35)

SIGNAL

SYNC

FREQ. kHz

31.5

60.0

FREQ. Hz

Note: “SIGNAL” setup menu displays a different setting condition for each input signal. (see page 18)

To setup SCREENSAVER (See page 26-28)

Press to select START TIME / FINISH TIME (When TIME OF DAY is selected). Press to select SHOW DURATION / SAVER DURATION (When INTERVAL is selected).

Press to set up.

SCREENSAVER

PRESENT TIME OF DAY

START FUNCTION MODE START TIME FINISH TIME SIDE BAR ADJUST WOBBLING PEAK LIMIT

[

]

RGB

H & V

WHITE BAR SCROLL

TIME OF DAY

7 : 00 8 : 00

BRIGHT

OFF OFF

10 : 00

To setup MULTIDISPLAY screen. (See page 31)

MULTI DISPLAY SETUP

MULTI DISPLAY SETUP ARRANGEMENT

LOCATION

To SET UP TIMER selection screen.(see page 24-25)

SET UP TIMER

POWER ON FUNCTION

POWER ON TIME POWER OFF FUNCTION POWER OFF TIME

To PRESENT TIME SET UP. (see page 24)

PRESENT TIME SETUP

SET

PRESENT TIME OF DAY

2 2

2 : 30

OFF

0 : 00

OFF

0 : 00

10 : 00

Press the R button to return to “SCREENSAVER” menu.

Press to select POWER ON TIME / POWER OFF TIME.

Press to set up POWER ON TIME / POWER OFF TIME.

Press the R button to return to “SET UP TIMER” menu.

SCREENSAVER

START FUNCTION MODE SHOW DURATION SAVER DURATION SIDE BAR ADJUST WOBBLING PEAK LIMIT

SET UP TIMER

POWER ON FUNCTION

POWER ON TIME POWER OFF FUNCTION POWER OFF TIME

SET UP TIMER

POWER ON FUNCTION

POWER ON TIME POWER OFF FUNCTION POWER OFF TIME

PRESENT TIME OF DAY

WHITE BAR SCROLL

INTERVAL

PRESENT TIME OF DAY

10 : 00

1 : 00 0 : 15

BRIGHT

OFF OFF

2 : 30

OFF

6 : 00

OFF

23 : 15

2 : 30

6 : 00

23 : 15

Input Signal Selection

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

Select the Input Signal

INPUT

Press the INPUT button to select the input signal to be played back from the equipment which has been connected to the Plasma Display.

Input signals will change as follows:

VOL

INPUTMENU ENTER

–+

R - STANDBY G POWER ON

PC ININPUT1 INPUT2 INPUT3

MENU ENTER

INPUT

VOL

Notes:

(1) Input terminal will not be selected if the Video Input Card is not

installed into the SLOT.

INPUT

(2) Select to match the signals from the source connected to the

component / RGB input terminals. (see page 33)

SURROUND

(3) In 2 screen display, the same input mode cannot be selected for

the main picture and sub picture.

VOL

Selecting the On-Screen Menu Language

SURROUND

VOL


SOUND

INPUT

SET UP

press to display the SET UP menu.

press to select OSD LANGUAGE.

press to select your preferred language.

Selectable languages

ENGLISH(UK) Deutsch Français Italiano Español ENGLISH(US)

.......

(Chinese)

NORMAL ZOOM FULL

AUTO JUST

ASPECT Controls

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture.

ASPECT button

The aspect mode changes each time the ASPECT button is pressed.

[from the unit]

INPUT MENU ENTER

VOL

The aspect mode changes each time the ENTER button is pressed.

Picture and Picture, Picture in Picture

the mode switches between “NORMAL”, “ZOOM” and “FULL” only.

NORMAL 16 : 9

INPUT

SURROUND

VOL


MULTI

PICTURE POS. /SIZE

SWAP SELECT MOVE

PIP

SOUND

SET UP

ZOOM

ASPECT

OFF TIMER

Notes:

(1) For PC signal input,

PLASMA DISPLAY

(2)

(3)

ASPECT

[During MULTI PIP Operations] (1) (2) Others : Aspect switching is not possible.

For a 1125 (1080) / 60i · 50i · 24p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p signal input during “COMPONENT” and “RGB” input signal mode, the mode is set to “FULL” mode, and switching is not possible. Auto can be selected only during Video signal input.

The aspect mode is memorized separately for each input terminal (INPUT1, INPUT2 , INPUT3 and PC IN).

Mode

NORMAL

ZOOM

FULL

JUST


NORMAL

NORMAL will display a 4:3 picture at its standard 4:3

ZOOM

FULL

size.

ZOOM mode magnifies the central section of the picture.

16:9 will display the picture at its maximum size but

3 9

JUST

with slight elongation.

JUST mode will display a 4:3 picture at its maximum size but with aspect correction applied to the center of the screen so that elongation is only apparent at the left and right edges of the screen. The size of the picture will depend on the original signal.

416

AUTO

The display will automatically become enlarged (depending on the picture source), allowing you to view the picture at its maximum size.

Explanation

Note:

AUTO

For an elongated image

Image is expanded

Changes in accordance with the AUTO mode setting (see page 34).

AUTO mode is designed to automatically adjust the aspect ratio to handle a mix of 16:9 and 4:3 program material. Certain 4:3 program material, such as stock market data screens, may occasionally cause the image size to change unexpectedly. When viewing such programs, it is recommended that the ASPECT be set

For a 4:3 image

to NORMAL.

Notes: (1) Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a permanent

after-image to remain on the Plasma Display Panel.

(2) Using this function to display a picture with the aspect ratio changed from the original for the purpose of public

display or commercial gain may infringe on copyright laws.

Adjusting PICTURE POSITION/SIZE

PLASMA DISPLAY

N R

INPUT

SURROUND

VOL


SOUND

SET UP

ASPECT

PICTURE POS. /SIZE

OFF TIMER

MULTI

PIP

SWAP SELECT MOVE

ZOOM

Adjusting screen


POS. /SIZE

Press to display the PICTURE POS./ SIZE menu.

Press to select H-POS / H-SIZE / V-POS / V-SIZE / CLOCK PHASE.

During “VIDEO (S VIDEO)” and “COMPONENT” input signal.

PICTURE POS./SIZE NORMALIZE

H-POS H-SIZE V-POS V-SIZE

NORMAL

Press to adjust POS./ SIZE.

Press to exit from adjust mode.

H-POS

H-SIZE

During “RGB” and “PC” input signal.

PICTURE POS./SIZE

NORMALIZE

NORMAL

H-POS H-SIZE V-POS V-SIZE CLOCK PHASE

“ ”

button is pressed.

“ ”

button is pressed.

Notes:

(1)

Adjustment details are memorized separately for different input signal formats (Adjustments for component

signals are memorized for 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i

· 50i · 24p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p each, and RGB / PC signals are memorized for each frequency.)

(2) If a “Cue” or “Rew” signal from a VCR or DVD

player is received, the picture position will shift up or down. This picture position movement cannot be controlled by the PICTURE POS./ SIZE function.

When the Position Right

“ ”

button is pressed.When the Position Left

“ ”

button is pressed.

When the Position Right

“ ”

button is pressed.When the Position Left

V-POS

“ ”

button is pressed.

When the Position Right

“ ”

button is pressed.When the Position Left

V-SIZE

CLOCK PHASE

(RGB / PC in Mode)

Flickering and distortion can be eliminated by using the Position Left carry out adjustment.

“ ”

or Right

“ ”

button to

Note: Using the size adjustment function to display a picture with the aspect ratio changed from the original for the

purpose of the public display or commercial gain may infringe on copyright laws.

Helpful Hint ( /

While the PICTURE POS./SIZE display is active, if either the N button on the remote control is pressed at any time or the

(ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

NORMALIZE

Normalization)

SOUND Adjustment

Select to adjust each item.

BASS

Adjusts low sounds

TREBLE

Adjusts high sounds

BALANCE

Adjusts left and right volumes

SOUND

Press to display the Sound menu.

Press to select the desired adjustment menu.

Select the desired level by listening to the sound.

SOUND

NORMALIZE AUDIO MENU BASS TREBLE BALANCE SURROUND

NORMAL

STANDARD 0 0 0

OFF

STANDARD

AUTO

INPUT

SURROUND

VOL

N R


MULTI

PIP

Emits the original sound.

Automatically controls proper volume level.

SOUND

SWAP SELECT MOVE

SET UP

ZOOM

SURROUND

Select ON or OFF

To end adjustments

•

Press the R button

Note:

Press the SURROUND button to directly turn the surround effect ON and OFF. (see page 15) BASS, TREBLE and SURROUND settings are memorized separately for each SOUND mode (STANDARD, AUTO).

Helpful Hint ( /

While the “SOUND” menu is displayed, if either the N button on the remote control is pressed at any time or the (ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

NORMALIZE

Normalization)

MUTE

Useful when answering the phone or receiving visitors.

Press this button to mute the sound. Press again to reactivate sound. Sound is also reactivated when power is turned off or volume level is changed.

PICTURE Adjustments


Select to adjust each item.


NORMALIZE PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP ADVANCED SETTINGS

NORMAL

Press to select “ON”.

Press to display the PICTURE menu.

Press to select the menu to adjust.

Select the desired level by looking at the picture behind the menu.

Press the left modes.

STANDARD

0 0 0 3

NORMAL

AUTO

Automatically selects the mode that best suits the brightness of the environment.

STANDARD

For viewing in standard (evening lighting) environments. This menu selects the normal levels of BRIGHTNESS and PICTURE.


NORMAL

or right

NORMALIZE PICTURE MENU PICTURE BRIGHTNESS COLOR TINT SHARPNESS COLOR TEMP ADVANCED SETTINGS

button to switch between

AUTO STANDARD

CINEMA DYNAMIC

STANDARD

0 0 0 3

NORMAL

OFF

Press to enter Advanced Settings.

DYNAMIC

For viewing in brighter environments. This menu selects higher than normal levels of

ADVANCED SETTINGS ON Enables fine picture adjustment at a professional level (see next page).

ADVANCED SETTINGS

NORMALIZE BLACK EXTENSION INPUT LEVEL W/B HIGH R W/B HIGH B W/B LOW R W/B LOW B GAMMA AGC

NORMAL

0 0 0

0 0 0 0

2. 2

OFF

ADVANCED SETTINGS OFF

BRIGHTNESS and PICTURE.

CINEMA

Ideal for movies.

Note:

If you would like to change the picture and color of the selected PICTURE menu to something else, adjust using the items in the PICTURE menu. (see next page)

Press the left

or right

button to switch between

modes.

NORMAL COOL WARM

Displays images with settings of the PICTURE menu.

Helpful Hint ( /

NORMALIZE

Normalization)

While the “PICTURE” menu is displayed, if either the N button on the remote control is pressed at any time or the (ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory settings.

PICTURE Adjustments

Item


BRIGHTNESS

COLOR

TINT

(NTSC only)

SHARPNESS

Note:

In PICTURE, there is nor a noticeable change even when contrast is increased with a bright picture or reduced with a dark picture.

Effect Adjustments

Adjusts the proper picture contrast.

Less More

Adjusts for easier viewing of dark pictures

Darker Brighter

Less More

Reddish Greenish

Less More

such as night scenes and black hair.

Adjusts color saturation.

Adjust for natural flesh tones.

Adjusts picture sharpness.

Notes:

(1)

“COLOR” and “TINT” be adjusted for “RGB” and “PC” input signals.

(2) You can change the level of each

function (PICTURE, BRIGHTNESS, COLOR, TINT, SHARPNESS) for each PICTURE menu.

(3) The setting details for STANDARD,

DYNAMIC and CINEMA respectively are memorized separately for each input mode (INPUT1, INPUT2 , INPUT3 and PC IN).

(4) The “TINT” setting can be adjusted for

NTSC signal only during “VIDEO (S VIDEO)” input signal.

settings cannot

ADVANCED SETTINGS

Item

BLACK

EXTENSION

Effect

Less More

Adjusts the dark shades of the image in gradation.

(This cannot be adjusted when the input signal is RGB or PC.)

Details

INPUT LEVEL

W / B HIGH R

W / B HIGH B

W / B LOW R

W / B LOW B

GAMMA

AGC

Notes:

(1) Carry out “W / B” adjustment as follows.

A Adjust the white balance of the bright sections using the “W / B HIGH R” and “W / B HIGH B” settings. B Adjust the white balance of the dark sections using the “W / B LOW R” and “W / B LOW B” settings. C Repeat steps A and B to adjust.

Steps A and B affect each other’s settings, so repeat each step in turn to make the adjustment. (2) The adjustment values are memorized separately for each input mode (INPUT1, INPUT2 , INPUT3 and PC IN). (3) The adjustment range values should be used as an adjustment reference.

Less More

Down Up

OFF ON

Adjustment of parts which are extremely bright and hard to see.

Adjusts the white balance for light red areas.

Adjusts the white balance for light blue areas.

Adjusts the white balance for dark red areas.

Adjusts the white balance for dark blue areas.

S CURVE

Increases the brightness of dark signal automatically.

2.0

2.2

2.5

Helpful Hint ( /

On the remote control unit, while the “ADVANCED SETTINGS” menu is displayed, if either the N button is pressed at any time or the settings.

(ACTION button) is pressed during “NORMALIZE”, then all adjustment values are returned to the factory

NORMALIZE

Normalization)

PRESENT TIME SETUP / SET UP TIMER

SET UP 2/2

AUTO POWER OFF

OFF

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

The timer can switch the Plasma Display ON or OFF.

Before attempting Timer Set, confirm the PRESENT TIME OF DAY and adjust if necessary. Then set POWER ON TIME / POWER OFF TIME.

SET UP

Press to display the

INPUT

SURROUND

VOL

SETUP menu screen.

Press to select SET UP TIMER or PRESENT TIME SETUP.

Press to display the SET UP TIMER


SOUND

SET UP

screen or PRESENT TIME SETUP screen.

PRESENT TIME SETUP

Display the PRESENT TIME SETUP screen.

To set up PRESENT TIME, follow the procedure described below.

Press to select PRESENT TIME OF DAY.

Press to set up PRESENT TIME OF DAY.

button: Forward

button: Back

PRESENT TIME SETUP

PRESENT TIME OF DAY

SET

PRESENT TIME OF DAY

0 : 00

Notes:

• Pressing

Note:

Set cannot be selected unless PRESENT TIME OF DAY is set.

“ ” or “ ” “ ” or “ ”

SET UP

button once changes PRESENT TIME OF DAY 1minute. button continuously changes PRESENT TIME OF DAY by 15 minutes.

Press to select Set.

PRESENT TIME SETUP

SET

PRESENT TIME OF DAY

Press to store PRESENT TIME SETUP.

Press to exit from PRESENT TIME SETUP.

PRESENT TIME OF DAY

10 : 00

SET UP TIMER

Display the SET UP TIMER SCREEN.

PRESENT TIME SETUP/SET UP TIMER

Notes:

• Pressing

“ ” or “ ” “ ” or “ ”

Press to select POWER ON TIME/POWER OFF TIME.

Press to set up POWER ON TIME / POWER OFF TIME.

button: Forward

button: Back

button once changes POWER ON TIME / POWER OFF TIME 1minute. button continuously changes POWER ON TIME / POWER OFF TIME by 15 minutes.

Press to select POWER ON FUNCTION / POWER OFF FUNCTION.

Press to select ON.

SET UP TIMER

PRESENT TIME OF DAY

POWER ON FUNCTION POWER ON TIME POWER OFF FUNCTION POWER OFF TIME

SET UP TIMER

PRESENT TIME OF DAY

POWER ON FUNCTION POWER ON TIME POWER OFF FUNCTION

POWER OFF TIME

2 : 30

OFF

0 : 00

OFF

0 : 00

2 : 30

6 : 00

23 : 15

Note:

Timer function will not work unless “PRESENT TIME OF DAY” is set.

Press twice to exit from SETUP.

SCREENSAVER (For preventing after-images)

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

OFF

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

WOBBLING

OFF

PEAK LIMIT

OFF

START

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

OFF

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

WOBBLING

OFF

PEAK LIMIT

OFF

START

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

WOBBLING

OFF

PEAK LIMIT

OFF

START

10 : 00

Do not display a still picture, especially in 4:3 mode, for any length of time. If the display must remain on, a SCREENSAVER should be used.

SET UP

Press to display the SETUP menu screen.

Press to select the SCREENSAVER.

Press to select the SCREENSAVER screen.

NEGATIVE / SCROLL selection

MODE selection

Press to select the FUNCTION.

Press to select the desired function. WHITE BAR SCROLL NEGATIVE

WHITE BAR SCROLL : A white bar will scroll from left to right. NEGATIVE : A negative image will be displayed on the screen.

Press to select the MODE.

PRESENT TIME OF DAY

START TIME FINISH TIME

PRESENT TIME OF DAY

START setting

Note: This function does not guarantee the complete prevention of permanent after-images. The potential for the occurrence

of permanent after-images is merely decreased.

Press to select each mode items.

START TIME FINISH TIME

OFF

INTERVAL : Operates when SHOW DURATION and SAVER DURATION are set

up and those times arrive.

TIME OF DAY : Operates when START TIME and FINISH TIME are set up and those

times arrive.

ON : Operates when START is selected and the (ACTION) is pressed.

When the Mode is set to ON, press to

PRESENT TIME OF DAY

select START.

START TIME FINISH TIME

Press to start SCREENSAVER. The menu screen will disappear and the SCREENSAVER will be activated. To

stop the SCREENSAVER under ON, press the R button.

SCREENSAVER (For preventing after-images )

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

INTERVAL

SHOW DURATION

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

SAVER DURATION

START

PRESENT TIME OF DAY

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

INTERVAL

SHOW DURATION

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

SAVER DURATION

START

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

OFF

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

START

PRESENT TIME OF DAY

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

TIME OF DAY

START TIME

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

FINISH TIME

START

PRESENT TIME OF DAY

10 : 00

SCREENSAVER

FUNCTION MODE

WHITE BAR SCROLL

TIME OF DAY

START TIME

0 : 00 0 : 00

SIDE BAR ADJUST

BRIGHT

FINISH TIME

START

10 : 00

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

Setup of SCREENSAVER Time

After selecting TIME OF DAY or INTERVAL, the relevant SET UP TIME will become available for selection and the OPERATING TIME may be set. (Time cannot be set when “MODE” is “ON” or “OFF.”)

PRESENT TIME OF DAY

Press to select START TIME / FINISH TIME (When TIME OF DAY is selected). Press to select SHOW DURATION / SAVER DURATION (When INTERVAL is selected).

Press to set up.

button: Forward

Notes:

• Pressing

“ ” or “ ”

button once changes the TIME 1minute.

button: Back

[However, switching occurs every 15 minutes when Periodic Time is selected.]

• Pressing

“ ” or “ ”

button continuously changes the TIME by 15 minutes.

Note: Timer function will not work unless “PRESENT TIME OF DAY” is set.

START TIME FINISH TIME

SCREENSAVER

FUNCTION MODE START TIME FINISH TIME SIDE BAR ADJUST WOBBLING PEAK LIMIT

SCREENSAVER

FUNCTION MODE SHOW DURATION SAVER DURATION SIDE BAR ADJUST WOBBLING PEAK LIMIT

START

PRESENT TIME OF DAY

WHITE BAR SCROLL

TIME OF DAY

BRIGHT

PRESENT TIME OF DAY

WHITE BAR SCROLL

INTERVAL

BRIGHT

10 : 00

7 : 00 8 : 00

OFF OFF

10 : 00

1 : 00 0 : 15

OFF OFF

Reduces screen after-image

These functions prevent the occurrence of an “after-image” on the display when turned ON.

WOBBLING : Automatically shifts the display image at a dot level pitch (therefore unnoticeable to the eye) over time

PEAK LIMIT : Suppresses image contrast (peak brightness).

1 2

to prevent after-image of sharper contour of image.

SET UP

Press to display the SET UP menu screen. Press to select “SCREENSAVER”.

Press to display SCREENSAVER menu. Press to select “WOBBLING” or

“PEAK LIMIT”.

Press to select “ON” or “OFF”.

SCREENSAVER

PRESENT TIME OF DAY

START FUNCTION MODE

START TIME FINISH TIME

SIDE BAR ADJUST WOBBLING PEAK LIMIT

10 : 00

WHITE BAR SCROLL

OFF

0 : 00 0 : 00

BRIGHT

OFF OFF

SCREENSAVER (For preventing after-images )

SIDE BAR ADJUST

Do not display a picture in 4:3 mode for an extended period, as this can cause an after-image to remain on the side bars on either side of the display field. To prevent the appearance of such an after-image, change the brightness of the side bars.

This function may be applicable to the non-picture area.

To display the SCREENSAVER screen. (Refer to the previous page, operation guide steps 1 and 2)

Press to select the SIDE BAR ADJUST.

Press to select OFF, DARK, MID, BRIGHT.

OFF DARK MID BRIGHT

Press to exit from SCREENSAVER.

side bars

4:3

Screen Display

after-images

Non picture area

Picture out Picture Picture and Picture

SCREENSAVER

PRESENT TIME OF DAY

START FUNCTION MODE

START TIME FINISH TIME

SIDE BAR ADJUST WOBBLING PEAK LIMIT

WHITE BAR SCROLL

TIME OF DAY

10 : 00

0 : 00 0 : 00

BRIGHT

OFF OFF

Notes:

• Setting the side bar to bright mode for an extended period may result in occurence of after-images.

• The side bar may flash (alternate black / white) depending on the picture being shown on the screen. In such an

occurrence, use the Cinema mode.

Digital Zoom

This displays an enlargement of the designated part of the displayed image.

Display the “Operation Guide”.

ZOOM

MOVE

Press to access Digital Zoom.

The “Operation Guide” will be displayed.

INPUT

SURROUND

VOL

N R


MULTI

PIP

PICTURE POS. /SIZE

Select the area of the image to be enlarged.

SET UP

SOUND

ZOOM

SWAP SELECT MOVE

ASPECT

OFF TIMER

button MUTE button

VOL button

OFF TIMER button

Press on the enlargement location to select.

The cursor will move.

SURROUND

Select the magnification required for the enlarged display.

Each time this is pressed, the magnification factor changes. This is shown in the image being displayed.

• During Digital Zoom, only the following keys can be operated.

R - STANDBY G POWER ON

INPUT MENU

ENTER

VOL

×1 ×2 ×3

Return to normal display (quit Digital Zoom).

Press to exit from the Digital Zoom.

Notes:

(1) When power goes OFF (including “Off Timer” operation), Digital Zoom terminates. (2) The Digital Zoom function cannot be selected while in the following operation states:

• “Multi-screen” (MULTI DISPLAY).(see page 31)

• “Multi-viewer” (Picture in Picture, Picture out Picture, Picture and Picture) operation. (see page 14) (3) While Digital Zoom is in operation, “Adjusting Picture Pos./Size” cannot be used. (4) For RGB / PC input signals, normal multi-display magnification is only available at the VGA, SVGA and XGA resolution. (5) The Digital Zoom capability is functional for the following component signals: 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 24sF, 750 (720) / 60p · 50p, 1250 (1080) / 50i (6) The Digital Zoom capability is functional for the following composite signals: NTSC, PAL, SECAM (7)

Using this function to display an enlarged picture for the purpose of public display or commercial gain may infringe on copyright laws.

Reduces power consumption

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SET UP 2/2

AUTO POWER OFF

OFF

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

• POWER SAVE:

• STANDBY SAVE:

• POWER MANAGEMENT:

• AUTO POWER OFF:

When this function is turned ON, luminous level of the plasma display is suppressed, so power consumption is reduced.

When this function is turned ON, power consumption of the microcomputer is reduced during power supply standby (see page 13,14,15), so standby power of the set is reduced.

The unit power supply is turned ON or OFF depending on whether or not there is a signal during PC input mode. This function is enabled when it is turned ON. (Only during input from PC(mini D-sub) terminal)

Equipment power supply is turned OFF when there is no signal. When this is set to On, the power supply of the unit goes Off 10 minutes after the input signals stop. This function is effective for input signals except input from PC (mini D-sub) terminal.

Press to select

“POWER SAVE” “STANDBY SAVE” “POWER MANAGEMENT” “AUTO POWER OFF”.

Press to select “ON” or “OFF”.

ON OFF

SET UP

Note:

“POWER MANAGEMENT” and “AUTO POWER OFF” are effective during normal viewing (one picture screen) only.

Customizing the Input labels

This function can change the label of the Input signal to be displayed.

Notes:

While selecting a Input signal through Optional Video Input Card connected to Slot 1 to Slot 3, the Input label will depend on each Optional Video Input Card.

INPUT LABELS for Slot 1 to Slot 3 and mini D-sub:

[Slot1 Input] INPUT1/VIDEO1/COMPONENT1/RGB1/RGB1(digital)/PC1/DVD1/CATV1/VCR1/STB1 [Slot2 Input] INPUT2/VIDEO2/COMPONENT2/RGB2/RGB2(digital)/PC2/DVD2/CATV2/VCR2/STB2 [Slot3 Input] INPUT3/VIDEO3/COMPONENT3/RGB3/PC3/DVD3/CATV3/VCR3/STB3 [PC (mini D-sub) Input] PC/COMPONENT/RGB/DVD/STB

Press to exit from SETUP.

Press to select INPUT LABEL.

Press to change the INPUT LABEL.

Setup for MULTI DISPLAY

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SET UP 2/2

AUTO POWER OFF

OFF

MULTI DISPLAY SETUP

SET UP TIMER

PRESENT TIME SETUP

By lining up Plasma Displays in groups of 4 or 9 as illustrated below, an enlarged picture may be displayed across all

screens.

For this mode of operation, each plasma display has to be set up with a DISPLAY number to determine its location.

group of 4 (2×2) group of 9 (3×3)

How to setup MULTI DISPLAY

SET UP

Press to display the SETUP menu screen.

Press to select the MULTI DISPLAY SETUP.

Press to display the “MULTI DISPLAY SETUP” menu.


SURROUND

SOUND

VOL

INPUT

SET UP

Press to select the MULTI DISPLAY SETUP.

Press to select “ON” or “OFF”.

MULTI DISPLAY SETUP

MULTI DISPLAY SETUP ARRANGEMENT LOCATION

2 2

Setup for MULTI DISPLAY

How to set the Display location number for each Plasma Display

Press to select ARRANGEMENT (2nd step).

Press to select “2×2”, “3×3”.

Press to select LOCATION.

Press to select the required arrangement number. (A1-C3 : Refer to the following)

DISPLAY NUMBER locations for each arrangement.

(2×2)

(3×3)

MULTI DISPLAY SETUP

MULTI DISPLAY SETUP ARRANGEMENT

LOCATION

MULTI DISPLAY SETUP

MULTI DISPLAY SETUP ARRANGEMENT

LOCATION

2 2

A1 A2

B1 B2

A1 A2 A3

B1 B2 B3

C1 C2 C3

Notes:

(1) For RGB / PC input signals, normal multi-display magnification is only available at the VGA, SVGA and XGA resolution. (2) The multi-display capability is functional for the following component signals: 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 24sF, 750 (720) / 60p · 50p, 1250 (1080) / 50i (3) The multi-display capability is functional for the following composite signals: NTSC, PAL, SECAM

Press twice to exit from SETUP.

SET UP for Input Signals

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

COMPONENT / RGB IN SELECT

Select to match the signals from the source connected to the COMPONENT / RGB input terminals. Y, PB, PR signals R, G, B, HD, VD signals

“COMPONENT”

“RGB”

SET UP

Press to display the SET UP menu screen.

INPUT

Press to select the “COMPONENT / RGB IN

SURROUND

VOL


MULTI

SWAP SELECT MOVE

PIP

SOUND

SET UP

ZOOM

SELECT”.

Press to select the desired mode.

COMPONENT RGB

Press to exit from adjust mode.

Note:

Selection may not be possible, depending on which optional board is installed.

3D Y / C FILTER – For NTSC Video images

Select “SIGNAL” from the “SET UP” menu during VIDEO (S VIDEO) input signal mode. (“SIGNAL [VIDEO]” menu is displayed.)

Note:

When ON, this setting only affects NTSC input signals.

Press to select the “3D Y / C FILTER (NTSC)”.

Press to set ON / OFF.

Press to exit from adjust mode.

Press

SIGNAL

3D Y/C FILTER (NTSC

COLOR SYSTEM 3:2 PULLDOWN ASPECT AUTO (4:3

(ACTION) button

)

[

VIDEO

AUTO

OFF

NORMAL

]

SET UP for Input Signals

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

COLOR SYSTEM / ASPECT AUTO

Select SIGNAL from the “SET UP” menu during VIDEO (S VIDEO) input signal mode.(“SIGNAL [VIDEO]” menu is displayed.)

Press to select the “COLOR SYSTEM” or “ASPECT AUTO”.

Press to select each function.

Mode

COLOR SYSTEM

If the image becomes unstable:

With the system set on Auto, under conditions of low level or noisy input signals the image may in rare cases become unstable. Should this occur, set the system to match the format of the input signal.

Function

Set the If set to “AUTO”, the

COLOR SYSTEM

to match that of the input signal.

is automatically selected from “PAL ”, “SECAM” and

SIGNAL

3D Y/C FILTER (NTSC COLOR SYSTEM 3:2 PULLDOWN ASPECT AUTO (4:3

Press

(ACTION) button

)

[

VIDEO

AUTO

OFF

NORMAL

“NTSC”, but not from “M-NTSC”. To view M-NTSC format pictures, you must manually

ASPECT AUTO (4:3)

set to “M-NTSC”.

Set to “NORMAL” to view 4:3 images in an unchanged format when “ASPECT AUTO” is selected. If you would like to view 4:3 images in Just format, set to “JUST”.

AUTO PAL SECAM M NTSC NTSC

3:2 PULLDOWN

When ON, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which are recorded at 24 frames per second. If the picture is not stable, turn the setting to OFF.

]

Select “SIGNAL” from the “SET UP” menu during VIDEO (S VIDEO) or COMPONENT input signal.(“SIGNAL [VIDEO]” or “SIGNAL [COMPONENT]” menu is displayed.)

Note:

When ON, this setting only affects the following signal input:

• NTSC / PAL signal input during “VIDEO (S VIDEO)” input signal.

• 525i(480i) signal input during “COMPONENT” input signal.

Press to select 3:2 PULLDOWN.

Press to set ON / OFF.

Press to exit from adjust mode.

Press

SIGNAL

3D Y/C FILTER (NTSC COLOR SYSTEM 3:2 PULLDOWN ASPECT AUTO (4:3

SIGNAL

3:2 PULLDOWN

(ACTION) button

)

AUTO

OFF

NORMAL

[

COMPONENT

OFF

[

VIDEO

]

SYNC

SET UP 1/2

SIGNAL

SCREENSAVER

INPUT LABEL

COMPONENT/RGB-IN SELECT

RGB

RGB1

OSD LANGUAGE

ENGLISH

(US)

POWER SAVE

OFF

STANDBY SAVE

POWER MANAGEMENT

OFF

Select SIGNAL from the “SET UP” menu during RGB input signal.

Press to select each item.

Press to exit from adjust mode.

SET UP for Input Signals

Press

SIGNAL

SYNC

H V

(ACTION) button

H & V

FREQ. kHz

31.5

60.0

FREQ. Hz

[

RGB

]

Setting RGB sync signal

Confirm that the input is set to RGB INPUT (this setting is valid only for RGB INPUT signal).

H & V:

The H and V sync signals are input from the HD / VD connector.

ON G: Uses a synchronized signal on the Video G signal, which is input

from the G connector.

CS: Uses a synchronized signal of Composite Sync input.

H-FREQ. (kHz) / V-FREQ. (Hz)

Displays the H (Horizontal) / V (Vertical) frequencies.

This display is valid only for RGB input and PC input signals. Display range:

Horizontal 15 - 110 kHz Vertical 48 - 120 Hz

SYNC

H-FREQ. kHz V

FREQ. Hz

31.5

60.0

H & V

ON G

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.


Interference

Normal Picture

No Picture

Symptoms

Sound

Noisy Sound

No Sound

Normal Sound

Checks

Electrical Appliances Cars / Motorcycles Fluorescent light

Volume (Check whether the mute function has been activated on the remote control.)

Not plugged into AC outlet Not switched on PICTURE and BRIGHTNESS / Volume setting (Check by pressing the power switch or stand-by button on the remote control.)

If a signal with a non-applicable color system format, or frequency is input, only the input terminal indication is displayed.

Color controls set at minimum level. (see page 22, 23) COLOR SYSTEM (see page 34)

No Color

This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input signal. However, this is not a malfunction.

Plasma Display panel

Symptoms

Some parts of the screen do not light up.

After-images appear

The plasma display panel is manufactured using an extremely high level of precision technology, however, sometimes some parts of the screen may be missing picture elements or have luminous spots. This is not a malfunction.

Note:

The permanent after-image on the Plasma Display resulting from fixed image use is not an operating defect and as such is not covered by the Warranty. This product is not designed to display fixed images for extended periods of time.

Normal Sound

Check

Whirring sounds can be heard from the display unit.

The display unit is fitted with a cooling fan to dissipate heat generated during normal use.The whirring sound is caused by rotation of the fan and is not a malfunction.

VIDEO / COMPONENT / RGB / PC input signals

R AUDIO L

SLOT1

R AUDIO L

S VIDEO IN

SLOT2 SLOT3

VIDEO OUT

VIDEO IN

VD HD

COMPONENT/RGB IN

PR/CR/R PB/CB/B

Y/G

AUDIO

SERIALPC IN

VIDEO input

VIDEO input [Applicable when Multi Screen and Digital Zoom]

Signal name

1 NTSC 15.73 59.94 2 PAL 15.63 50.00 3 PAL60 15.73 59.94 4 SECAM 15.63 50.00 5 Modified NTSC 15.73 59.94

Applicable input signals for PC Input (mini D-sub 15P) (

Signal name

1 525 (480) /60i 15.73 59.94 2 525 (480) /60p 31.47 59.94 3 625 (575) /50i 15.63 50.00 4 625 (575) /50p 31.25 50.00 5 750 (720) /60p 45.00 60.00 6 750 (720) /50p 37.50 50.00 7 1,125 (1,080) /60i 33.75 59.94 8 1,125 (1,080) /50i 28.13 50.00 9 1,125 (1,080) /24p 27.00 24.00

10 1,125 (1,080) /24sF 27.00 48.00

11 1,250 (1,080) /50i 31.25 50.00

12 640 × 400 @70 31.47 70.00 13 640 × 480 @60 31.47 59.94 14 Macintosh13” (640 × 480) 35.00 66.67 15 640 × 480 @75 37.50 75.00 16 800 × 600 @60 37.88 60.32 17 800 × 600 @75 46.88 75.00 18 800 × 600 @85 53.67 85.06 19 Macintosh16” (832 × 624) 49.73 74.55 20 1,024 × 768 @60 48.36 60.00 21 1,024 × 768 @70 56.48 70.07 22 1,024 × 768 @75 60.02 75.03 23 1,024 × 768 @85 68.68 85.00 24 Macintosh21” (1,152 × 870) 68.68 75.06 25 1,280 × 1,024 @60 63.98 60.02 26 1,280 × 1,024 @75 79.98 75.03 27 1,280 × 1,024 @85 91.15 85.02 28 1,600 × 1,200 @60 75.00 60.00

Horizontal Vertical

frequency(kHz) frequency(Hz)

Horizontal Vertical

frequency(kHz) frequency(Hz)

COMPONENT / RGB input

Mark)

∗

PC RGB / COMPONENT input

COMPONENT RGB PC

When Multi Screen

and Digital Zoom

∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗∗ ∗∗∗ ∗∗∗∗ ∗∗∗∗

∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗

Note: Signals without above specification may not be displayed properly.

Specifications

Power Source Power Consumption

Maximum Stand-by condition Power off condition

Plasma Display panel

Contrast Ratio

Screen size

(No.of pixels)

Operating condition

Temperature

Humidity

Applicable signals

Color System

Scanning format

PC signals

Connection terminals

COMPONENT/RGB

SERIAL

SPEAKERS (6 Ω)

Accessories Supplied

Remote Control Transmitter

Batteries

Fixing bands

Ferrite core

Dimensions

××

× H

× D)

××

NTSC, PAL, PAL60, SECAM, Modified NTSC 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 50i · 24p · 24sF ···· SMPTE274M, 1250 (1080) / 50i

(HIGH-DENSITY MINI D-SUB 15PIN) R,G,B/0.7 Vp-p (75-ohm)

AUDIO IN (M3 JACK) 0.5 Vrms (high impedance) EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE

40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)

GD-V422U GD-V502U

120 V AC, 50 Hz / 60 Hz

max. Amps. 5 A max. Amps. 5.5 A

Save OFF 1.6W, Save ON 0.9W Save OFF 1.6W, Save ON 0.9W

Drive method : AC type 42-inch,

920 mm (W) × 518 mm (H),

786,432 (1,024(W) × 768 (H))

VIDEO IN/OUT (BNC) S VIDEO IN (MINI DIN 4PIN) AUDIO IN (RCA PIN JACK × 2) Y/G (BNC)

PB/B (BNC), PR/R (BNC) HD (BNC), VD (BNC) AUDIO IN (RCA PIN JACK × 2)

0.2 W 0.2 W Drive method : AC type 50-inch,

16:9 aspect ratio

3000 : 1

1,056 mm (diagonal)

1,049,088 (1,366 (W) × 768 (H))

[3,072 × 768 dots]

32 °F - 104 °F (0 °C - 40 °C)

20 % - 80 %

XGA display

VGA, SVGA, XGA

SXGA, UXGA ······ (compressed)

Horizontal scanning frequency 15 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

1.0 Vp-p (75-ohm or high impedance) Y: 1 Vp-p (75-ohm), C: 0.286 Vp-p (75-ohm)

0.5 Vrms (high impedance)

1.0 Vp-p/composite (75-ohm)

0.7 Vp-p/non-composite (75-ohm)

0.7 Vp-p (75-ohm)

1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms (high impedance)

Component Y : 1.0 Vp-p (75-ohm : include sync) PB/CB : ± 0.35 Vp-p (75-ohm) PR/CR : ± 0.35 Vp-p (75-ohm)

HD, VD/1.0 - 5.0 Vp-p (high impedance)

16W [8 W + 8 W] (10 % THD)

EUR646532

2 × AA Size

(TMME203 or TMME 187) × 2

Small size × 1, Large size × 2

47.6” (1,210 mm) × 28.5” (724 mm) × 3.7” (95 mm)

3.5"

40.2" (1,020 mm)

(89 mm)

16:9 aspect ratio

1,106 mm (W) × 622 mm (H),

1,269 mm (diagonal)

[4,098 × 768 dots]

47.6" (1,210 mm)

3.7"

(95 mm)

Mass (Weight)

VOL

INPUTMENU ENTER

— +

R - STANDBY G POWER ON

24" (610 mm)

approx. 66.1 lbs (main unit only)

approx. 75.4 lbs (with speakers)

VOL

INPUTMENU ENTER

— +

R - STANDBY G POWER ON

approx. 97.0 lbs (main unit only)

approx. 107.1 lbs (with speakers)

28.5" (724 mm)

Note:

Design and specifications are subject to change without notice. Mass and dimensions shown are approximate.

GD-V422U / GD-V502U PLASMA DISPLAY MONITOR

VICTOR COMPANY OF JAPAN, LIMITED

Printed in Japan

TQZW366-1

PLASMA DISPLAY MONITOR

GD-V422PCE GD-V502PCE

INSTRUCTIONS

Dear JVC Customer

Trademark Credits

VGA is a trademark of International Business Machines Corporation.

•

Macintosh is a registered trademark of Apple Computer, USA.

•

S-VGA is a registered trademark of the video Electronics Standard Association.

•

Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.

Note:

Important Safety Notice ............................................. 3

Safety Precautions ..................................................... 4

Accessories ................................................................6

Accessories Supply ................................................... 6

Remote Control Batteries .......................................... 6

Connections ............................................................... 7

PC Input Terminals connection ................................. 8

SERIAL Terminals connection ................................... 9

Basic Controls .......................................................... 10

MULTI PIP ............................................................... 10

Power On / Off and input signal selection ............. 12

AC cord connection ................................................. 12

Power On / Off ........................................................ 12

Select the input signal ............................................. 13

Selecting the On-Screen Menu Language .............. 13

On-Screen Menu Displays ....................................... 14

ASPECT Controls ..................................................... 16

Adjusting Picture Pos./ Size.................................... 17

Picture Adjustments ................................................ 18

Advanced settings ................................................... 19

Sound Adjustment ................................................... 20

Mute ........................................................................ 20

Digital Zoom ............................................................. 21

PRESENT TIME Setup / Set up TIMER ................... 22

PRESENT TIME Setup ........................................... 22

Set up TIMER.......................................................... 23

Screensaver (For preventing after-images) ........... 24

Setup of Screensaver Time..................................... 25

Reduces screen after-image ................................... 25

Side Panel Adjustment ............................................ 26

Reduces power consumption ................................. 27

Customizing the Input labels ................................... 27

Setup for MULTI DISPLAY ....................................... 28

How to Setup MULTI DISPLAY ............................... 28

How to set the display location number

for each Plasma Display ............ 29

Setup for Input Signals ............................................ 30

Component / RGB-in Select.................................... 30

3D Y / C Filter – For NTSC AV images ........................... 30

Colour system / Aspect Auto ................................... 31

Cinema reality ......................................................... 31

Sync ........................................................................ 32

H-Freq. (kHz) / V-Freq. (Hz).................................... 32

Troubleshooting ....................................................... 33

Input signal can be displayed ................................. 34

Specifications ........................................................... 35

Important Safety Notice

WARNING:

1) To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or moisture. Do not place containers with water (flower vase, cups, cosmetics, etc.) above the set. (including on shelves above, etc.)

2) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualified service personnel.

3) Do not remove the earthing pin on the power plug. This apparatus is equipped with a three pin earthing-type power plug. This plug will only fit an earthing-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact an electrician. Do not defeat the purpose of the earthing plug.

4) This is a class A product. In a domestic environment this product may cause radio interference in which case you may be required to take adequate measures.

CAUTION

This appliance is intended for use in environments which are relatively free of electromagnetic fields. Using this appliance near sources of strong electromagnetic fields or where electrical noise may overlap with the input signals could cause the picture and sound to wobble or cause interference such as noise to appear. To avoid the possibility of harm to this appliance, keep it away from sources of strong electromagnetic fields.

To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

FOR UK ONLY

IMPORTANT: THE MOULDED PLUG

FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5 amp fuse is fitted in this plug. Shall the fuse need to be replaced, please ensure that the replacement fuse has a rating of 5 amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark

If the plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local JVC Dealer.

If the fitted moulded plug is unsuitable for the socket outlet in your home, then the fuse shall be removed and the plug cut off and disposed of safety. There is a danger of severe electrical shock if the cut off plug is inserted into any 13 amp socket.

If a new plug is to be fitted, please observe the wiring code as shown below. If in any doubt, please consult a qualified electrician.

WARNING: THIS APPARATUS MUST BE EARTHED. IMPORTANT:

The wires in this mains lead are coloured in accordance with the following code:

Green-and-Yellow: Earth Blue: Neutral Brown: Live

ASA

or the BSI mark

on the body of the fuse.

As the colours of the wire in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows.

The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked with the letter E or by the Earth symbol

The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with the letter L or coloured RED.

How to replace the fuse. Open the fuse compartment with a screwdriver and replace the fuse.

or coloured GREEN or GREEN-AND-YELLOW.

Safety Precautions

WARNING

Setup

This Plasma Display is for use only with the following optional accessories. Use with any other type of optional accessories may cause instability which could result in the possibility of injury.

(All of the following accessories are manufactured by JVC)

Speakers

•

Stand Unit

•

Video Input Card

•

Wall Mounting Unit

•

Wall Mounting Unit (angled)

•

Ceiling Suspension Unit

•

Always be sure to ask a qualified technician to carry out set-up.

Do not place the Plasma Display on sloped or unstable surfaces.

The Plasma Display may fall off or tip over.

•

Do not place any objects on top of the Plasma Display.

If water is spills onto the Plasma Display or foreign objects get inside it, a short-circuit may occur which could result

•

in fire or electric shock. If any foreign objects get inside the Plasma Display, please consult your local JVC dealer.

...................................................

.................................................

.......................................

....................................

......................

............................

TS-C422SPG (GD-V422PCE) TS-C5001SPG (GD-V502PCE) TS-C50P5G IF-C50P2G TS-C50P6G TS-C50P2G TS-C50P3G

If using the Stand Unit (optional accessory), leave a space of at least 10 cm at the top, left and right, at least 6 cm at the bottom, and at least 7 cm at the rear. If using some other setting-up method, leave a space of at least 10 cm at the top, bottom, left and right, and at least 1.9 cm at the rear.

Avoid installing this product near electronic equipment that is easy to receive electromagnetic waves.

It may cause interference in image, sound, etc. In particular, keep video equipment away from this product.

•

When using the Plasma Display

The Plasma Display is designed to operate on 220 - 240 V AC, 50Hz/60Hz. Do not cover the ventilation holes.

Doing so may cause the Plasma Display to overheat, which can cause fire or damage to the Plasma Display.

•

Do not stick any foreign objects into the Plasma Display.

Do not insert any metal or flammable objects into the ventilations holes or drop them onto the Plasma Display, as

•

doing so can cause fire or electric shock.

Do not remove the cover or modify it in any way.

High voltages which can cause severe electric shocks are present inside the Plasma Display. For any inspection,

•

adjustment and repair work, please contact your local JVC dealer.

Securely insert the power cord plug as far as it will go.

If the plug is not fully inserted, heat may be generated which could cause fire. If the plug is damaged or the wall

•

socket plate is loose, they shall not be used.

Do not handle the power cord plug with wet hands.

Doing so may cause electric shocks.

•

Do not do anything that may damage the power cable. When disconnecting the power cable, pull on the plug body, not the cable.

Do not damage the cable, make any modifications to it, place heavy objects on top of it, heat it, place it near any

•

hot objects, twist it, bend it excessively or pull it. To do so may cause fire and electric shock. If the power cable is damaged, have it repaired at your local JVC dealer.

If the Plasma Display is not going to be used for any prolonged length of time, unplug the power cord plug from the wall outlet.

Safety Precautions

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odour starts to come out from the Plasma Display, immediately unplug the power cord plug from the wall outlet.

If you continue to use the Plasma Display in this condition, fire or electric shock could result. After checking that the

•

smoke has stopped, contact your local JVC dealer so that the necessary repairs can be made. Repairing the Plasma Display yourself is extremely dangerous, and shall never be done.

If water or foreign objects get inside the Plasma Display, if the Plasma Display is dropped, or if the cabinet becomes damages, disconnect the power cord plug immediately.

A short circuit may occur, which could cause fire. Contact your local JVC dealer for any repairs that need to be

•

made.

CAUTION

When using the Plasma Display

Do not bring your hands, face or objects close to the ventilation holes of the Plasma Display.

Heated air comes out from the ventilation holes at the top of Plasma Display will be hot. Do not bring your hands

•

or face, or objects which cannot withstand heat, close to this port, otherwise burns or deformation could result.

Be sure to disconnect all cables before moving the Plasma Display.

If the Plasma Display is moved while some of the cables are still connected, the cables may become damaged,

•

and fire or electric shock could result.

Disconnect the power cord plug from the wall socket as a safety precaution before carrying out any cleaning.

Electric shocks can result if this is not done.

•

Clean the power cable regularly to prevent it becoming dusty.

If dust built up on the power cord plug, the resultant humidity can damage the insulation, which could result in fire.

•

Pull the power cord plug out from the wall outlet and wipe the mains lead with a dry cloth.

Cleaning and maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft, lint-free cloth.

If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water to

•

which a small amount of neutral detergent has been added, and then wipe it evenly with a dry cloth of the same type until the surface is dry.

Do not scratch or hit the surface of the panel with fingernails or other hard objects, otherwise the surface may

•

become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been

•

added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.

Do not allow any detergent to come into direct contact with the surface of the Plasma Display.

•

If water droplets get inside the unit, operating problems may result.

Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the

•

cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact with articles made from rubber or PVC.

Accessories

Accessories Supply

Check that you have the accessories and items shown

Operating Instruction book

Remote Control Transmitter EUR646532

INPUT

SURROUND

VOL


SET UP

PICTURE POS. /SIZE

MULTI PIP

SOUND

SWAP SELECT MOVE

PLASMA DISPLAY

ZOOM

ASPECT

OFF TIMER

GD-V422PCE GD-V502PCE

AC cord

AC cord (For UK only)

Remote Control Batteries

Batteries for the Remote Control Transmitter (2 × R6 Size)

Ferrite core (small size) × 1

Fixing bands

Ferrite core (large size) × 2

Requires two R6 batteries.

1. Turn the transmitter face down. Press and slide off the battery cover.

2. Install the batteries as shown in the battery compartment. (Polarity + or – must match the

3. Replace the cover and slide in reverse until the lock snaps.

markings in the compartment.)

Two “R6” size

Helpful Hint:

For frequent remote control users, replace old batteries with Alkaline batteries for longer life.

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.

Observe the following precaution:

1. Batteries shall always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5. Battery replacement is necessary when remote control acts sporadically or stops operating the Plasma Display.

Connections

When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation.

(Example: GD-V422PCE)

Speakers (Optional accessories)

SPEAKERS Terminals (R)

AC cord connection (see page 12)

– AC cord fixing

1. Open the clamper.

Clamper

SPEAKERS Terminals (L)

Note: Connect the power cord before combining with

accessories such as the Stand Unit. When combining with accessories such as the Stand Unit, be very careful not to pinch the power cord.

2. Insert the AC cord and close the clamper securely.

AC cord

Note: The power plug in the illustration may not be the type fitted to your set.

3. Slide up the clamper and fix

the AC cord plug securely.

When loosen the clamper:

– Cable fixing bands Secure any excess cables with bands as required.

Pass the attached cable fixing band through the clip as shown in the figure.

Optional Video Input Card insert Slots (covered)

SLOT1 SLOT2

Note:

Insert the optional Video Input Cards before combining the Plasma Display with the Stand Unit.

To secure cables connected to Terminals, wrap the cable fixing band around them then pass the pointed end through the locking block, as shown in the figure.

While ensuring there is sufficient slack in cables to minimize stress (especially in the power cord), firmly bind all cables with the supplied fixing band.

To tighten: To loosen:

Pull

SLOT3

From EXTERNAL monitor terminal on Computer (see page 8)

Push the catch

Pull

AUDIO

SERIALPC IN

From SERIAL terminal on Computer

Connections

PC Input Terminals connection

COMPUTER

R - STANDBY G POWER ON

Conversion adapter (if necessary)

Connect a cable which matches the audio output terminal on the computer.

Less than

(10 cm)

Ferrite core (small size)

Audio

(supplied)

VOL

INPUTMENU ENTER

Ferrite core (large size) (supplied)

RGB

PC cable

Less than

(10 cm)

mini D-sub 15p

Stereo plug

AUDIO

PC IN

Installing the ferrite core (Small size)

Pull back the tabs (in two places)

Installing the ferrite core (Large size)

Pull back the tabs (in two places)

Open

Press the cable through and close

Open

Press the cable through and close

Notes:

(1)

Computer signals which can be input are those with a horizontal scanning frequency of 15 to 110 kHz and vertical

scanning frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

(2) The display resolution is a maximum of 768 × 768 dots (GD-V422PCE), 1,024 × 768 dots (GD-V502PCE) when

the aspect mode is set to “4:3”, and 1,024 × 768 dots (GD-V422PCE), 1,366 × 768 dots (GD-V502PCE) when the aspect mode is set to “16:9”. If the display resolution exceeds these maximums, it may not be possible to show fine detail with sufficient clarity.

(3) The PC input terminals are DDC1/2B-compatible. If the computer being connected is not DDC1/2B-compatible,

you will need to make setting changes to the computer at the time of connection. (4) Some PC models cannot be connected to the set. (5) There is no need to use an adapter for computers with DOS/V compatible mini D-sub 15P terminal. (6) The computer shown in the illustration is for example purposes only. (7) Additional equipment and cables shown are not supplied with this set. (8) Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specified

frequency range. (9) Component Input is possible with the pin 1, 2, 3 of the mini D-sub 15P Connector.

Signal Names for mini D-sub 15P Connector

1514131211

67839

Pin Layout for PC Input Terminal

Pin No.

1 2 3 4 5

Signal Name

GND (Ground) GND (Ground)

R (PR/CR)

G (Y)

B (PB/CB)

Pin No.

6 7 8 9

Signal Name GND (Ground) GND (Ground) GND (Ground)

NC (not connected)

GND (Ground)

Pin No.

11 12 13 14 15

Signal Name

GND (Ground)

SDA

HD/SYNC

SCL

SERIAL Terminals connection

The SERIAL terminal is used when the Plasma Display is controlled by a computer.

Connections

COMPUTER

9876

53214

Ferrite core

RS-232C Straight cable

(large size) (supplied)

SERIAL

Pin layout for RS-232C

Installing the ferrite core

(Large size)

D-sub 9p

Less than

/16

Open

(10 cm)

Notes:

(1) Use the RS-232C cable to connect the computer to the Plasma Display. (2) The computer shown is for example purposes only. (3) Additional equipment and cables shown are not supplied with this set.

Communication parameters

Signal level

Synchronization method

Baud rate

Parity

Character length

Stop bit

Flow control

RS-232C compliant

Asynchronous

9600 bps

None 8 bits

1 bit

RS-232C Conversion cable

D-sub 9-pin female

2 3 5

•

Details

R X D T X D

GND

Non use

Shorted

Basic format for control data

STX

Start (02h)

Colon Parameter(s)

3-character command (3 bytes)

(1 - 5 bytes)

ETX:C2C1 C3 P2P1 P3 P4 P5

End (03h)

Notes:

(1) If multiple commands are transmitted, be sure to

wait for the response for the first command to come from this unit before sending the next command.

(2) If an incorrect command is sent by mistake, this

unit will send an “ER401” command back to the computer.

Command

Command PON POF AVL

AMT

IMS

DAM

Parameter None None

0 1 None SL1 SL2 SL3 PC1 None NORM ZOOM FULL JUST SELF

Power ON Power OFF Volume 00 - 63 Audio mute OFF Audio mute ON Input select (toggle) Slot1 input Slot2 input Slot3 input PC input Screen mode select (toggle) 4 : 3 Zoom 16 : 9 Just Auto

Control details

With the power off, this display responds to PON command only.

Basic Controls

R - STANDBY G POWER ON

INPUT MENU ENTER

Main Power On / Off Switch

Remote control

Power Indicator

sensor

The Power Indicator will light.

Power-OFF .. Indicator not illuminated (The unit

•

will still consume some power as long as the

MENU Screen ON / OFF

Each time the MENU button is pressed, the menu screen will switch. (see page 14)

power cord is still inserted into the wall outlet.)

Stand-by ......Red

•

Power-ON ........Green

•

DPMS .............. Orange (With PC input signal and

•

during operation of PC’s screensaver.)

INPUT button (INPUT1, INPUT2, INPUT3 and PC IN Selection)

(see page 13)

C.A.T.S sensor Plasma C.A.T.S (Contrast Automatic Tracking System)

Plasma C.A.T.S automatically senses the ambient light conditions and adjusts the brightness and gradation accordingly, to optimise contrast. (Effective when Picture mode is set to Auto.)

Status button

Press the “Status” button to display the current system status.

4:3

Input label

Aspect mode (see page 16)

Off timer

The off timer indicator is displayed only when the

Off timer 90

off timer has been set.

MULTI PIP

MULTI

Each time pressing this button main picture and sub picture will be displayed as

PIP

follows bellow.

Normal

Viewing

[Picture and Picture] [Picture in Picture]

Main picture Sub picture

MULTI

PIP

MULTI

[Picture out Picture]

Main picture Sub picture Main picture Sub picture

PIP

VOL

Enter / Aspect button

(see page 14, 16)

Normal Viewing Picture Set up

Sound Picture Pos./ Size

Volume Adjustment

Volume Up “ + ” Down “ – ” When the menu screen is displayed.

“ + ”: press to move the cursor up “ – ”: press to move the cursor down

(see page 17-20)

PICTURE button

(see page 18)

MULTI

PIP

N button

SWAP SWAP SWAP

SWAP

Press to swap main picture and sub picture.

SELECT

ZOOM

MOVE

Notes: (1) Sound output is from the main picture.

Press the SELECT button. Under main picture and sub picture display, select the picture which you would like to change input modes.

INPUT

SURROUND

VOL

INPUT

Press to change input signal.

Press the MOVE button. Each time the location of the sub picture will be moved.

Notes: (1) This button is effective only in the picture in picture.

(2)

The sub picture may be hidden by the on screen display, depending on its position.

(2) Using this function to display picture in picture for the purpose of public display

or commercial gain may infringe on copyright laws.

[Example]

Main picture label is bright Sub picture label is bright

PC1

VIDEO1

Input modes switching is possible

Main picture label is changed Sub picture label is changed

VIDEO2 VIDEO1

Picture is changed

SELECT

PC1

VIDEO1

PC1

VIDEO3

Basic Controls

Stand-by (ON / OFF) button

The Plasma Display must first be plugged into the wall outlet and turned on at the power switch (see page 12). Press this button to turn the Plasma Display On, from Stanby mode. Press it again to turn the Plasma Display Off to Stanby mode.

SURROUND button

The benefits of surround sound are enormous. You can be completely enveloped in sound; just as if you were at a concert hall or cinema.

The surround setting switches on and off each time the SURROUND button is pressed.

INPUT button (

INPUT1, INPUT2, INPUT3 and PC IN

Press to select INPUT1, INPUT2, INPUT3 and PC IN input SLOTS sequentially. (see page 13)

INPUT

SURROUND

Sound mute On / Off (see page 20)

Volume Adjustment

Press the Volume Up “+” or Down “–” button to increase or decrease the sound volume level.

VOL

R button (see page 14-15)

Press the R button to return to previous menu screen.

On Off

Surround

Note:

The surround settings are memorized separately for each Sound mode (Normal, Auto).

Selection)


MULTI

PICTURE POS. /SIZE

SWAP SELECT MOVE

PIP

PLASMA DISPLAY

SOUND

SET UP

ZOOM

ASPECT

OFF TIMER

ACTION button

Press to make selections.

POSITION buttons SOUND button (see page 20)

Press to adjust the SOUND.

Digital Zoom (see page 21)

ZOOM MOVE

Press to access Digital Zoom.

SET UP button

(see page 14-15)

This displays an enlargement of the designated part of the displayed image.

PICTURE POS./ SIZE button

(see page 17)

ASPECT button

Press to adjust the aspect. (see page 16)

OFF TIMER button

30 60

PC button

Press the “PC” input mode selection button to select the PC input mode.

When three minutes remain, “Off timer 3” will flash. The off timer is cancelled if a power interruption occurs.

This button is used to switch directly to PC input mode.

Note:

In 2 screen display, the same input mode cannot be selected for the main picture and sub picture.

Power On / Off and input signal selection

AC cord connection

Connecting the AC cord plug to the Plasma Display.

Power On / Off

VOL

INPUTMENU ENTER

– +

R - STANDBY G POWER ON

Fix the AC cord plug securely to the Plasma Display with the clamper. (see page 7)

Connecting the AC plug to the Wall Outlet

Note:

AC plug types vary between countries / regions.

Press the Main power switch on the Plasma Display to turn the Plasma Display on: Power-On.

Power Indicator: Green

If the power indicator is lit red, press the power button on the remote control to turn the Plasma Display on.

Power Indicator

Remote Control Sensor

When the Power is turned on for the first time, the Language selection screen is displayed.

From the second time on, language selection can be done from the setup menu. (see page 13)

Select the desired language using the

and

keys and press the ACTION

button.

INPUT

SURROUND

VOL

Example: The screen below is displayed for a while after the Plasma

Display is turned on. (setting condition is an example.)

OSD Language

Deutsch

Fran ais

Italiano

a ol

)

English (UK

ENGLISH (US

Select

)

Set

Press the

From the second time on, the below screen is

displayed for a while (setting condition is

an example).

4:3

button on the remote control to turn the

Plasma Display off.

Power Indicator: Red (standby)

Press the

button on the remote control to turn the

Plasma Display on.

Power Indicator: Green

Turn the power to the Plasma Display off by pressing the

Main power switch on the Plasma Display, when the

Plasma Display is on or in standby mode.

Note: During operation of the power management function, the power

indicator turns orange in the power off state.

Power On / Off and input signal selection

Setup 1/2

Signal

Screensaver

Input label

Component/RGB-in select

RGB

RGB1

OSD Language

English (UK

)

Power save

Off

Standby save

Power management

Off

Select the input signal

INPUT

Press the INPUT button to select the input signal to be played back from the equipment which has been connected to the Plasma Display.

Select the input signals to be connected by installing the optional Video Input Card.

VOL

INPUTMENU ENTER

R - STANDBY G POWER ON

Input signals will change as follows:

PC ININPUT1 INPUT2 INPUT3

MENU ENTERINPUT

VOL

INPUT

Notes:

(1) Input terminal will not be selected if the Video Input Card is not

SURROUND

installed into the SLOT.

(2) Select to match the signals from the source connected to the

VOL

component / RGB input terminals. (see page 30)

(3) In 2 screen display, the same input mode cannot be selected for

the main picture and sub picture.

Selecting the On-Screen Menu Language

SURROUND


SOUND

VOL

INPUT

SET UP

Press to display the Set Up menu.

Press to select the OSD Language.

Press to select your preferred language.

Selectable languages

English(UK) Deutsch Français Italiano Español ENGLISH(US)

.......

(Chinese)

On-Screen Menu Displays

To Picture adjust menu (see page 18)


Normalise Picture Mode Contrast Brightness Colour Tint Sharpness White balance Advanced settings

Normal

0 0 0 3

Normal

Press to select “On”.

Press to enter Advanced settings.

To Advanced settings (see page 18, 19)

Advanced settings

Normalise

Black extension

Input level

W/B High R W/B High B W/B Low R W/B Low B Gamma AGC

Normal

0 0 0

0 0 0 0

2. 2 Off

The MENU button on the unit can also be pressed.

INPUT MENU ENTER

VOL

– +

Each time the MENU button is pressed, the menu screen will switch.

Normal Viewing Picture Set up

Sound Picture Pos./ Size

INPUT

SURROUND

VOL


MULTI

SWAP SELECT MOVE

PIP

SOUND

SET UP

ZOOM

Press to select.

[ from the unit ]

INPUT MENU ENTER

Press to select.

Press to access each adjust

VOL

– +

screen.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

RGB

RGB1

Off On Off

English (UK

)

PICTURE POS. /SIZE

To Sound adjust menu (see page 20)

Sound

Normalise Sound Mode Bass

Treble Balance Surround

Normal

Normal 0 0 0

Off

To Picture Pos./ Size adjust menu (see page 17)

During “AV(S Video)” and “Component” input signal.

Picture Pos./Size

Normalise

Normal

H-Pos H-Size V-Pos V-Size

During “RGB” and “PC” input signal.

Picture Pos./Size

Normalise

Normal

H-Pos H-Size V-Pos V-Size Clock Phase

PLASMA DISPLAY

ASPECT

OFF TIMER

Setup 2/2

Auto power off

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup

Off

Screensaver

Function Mode

White bar scroll

Time Designation

Start Time

0 : 00 0 : 00

Side panel

High

Finish Time

Start

PRESENT TIME

10 : 00

Screensaver

Function Mode

White bar scroll

Interval

Periodic Time

0 : 00 0 : 00

Side panel

High

Off

Operating Time

Start

PRESENT TIME

10 : 00

On-Screen Menu Displays

Press to

access each

INPUT MENU ENTER

VOL

– +

adjust screen.

Press the R button to return to

[ from the unit ]

Press to return to previous

previous menu screen.

menu screen.

To Signal screen for AV(S Video) (see page 30, 31)

[

Auto

Off

4 : 3

]

Signal

3D Y/C Filter (NTSC Colour system Cinema reality Aspect Auto (4:3

)

Note: “Signal” setup menu displays different setting condition for each input signals. (see page 13)

To setup Screensaver (see page 24-26)

To Signal screen for Component (see page 31)

Signal

Cinema reality

[

Component

]

Off

Press to select Start Time / Finish Time (When Time Designation is selected).

To Signal screen for RGB and PC (see page 32)

Signal

Sync

H V

Press to select Periodic Time / Operating Time (When Interval is selected).

Screensaver

Press to Setup.

Start Function Mode Start Time Finish Time Side panel Wobbling Peak limit

Freq. kHz

31.5

60.0

Freq. Hz

PRESENT TIME

White bar scroll

Time Designation

[

RGB

H & V

10 : 00

7 : 00 8 : 00

High

Off Off

]

To setup Multidisplay screen (see page 28)

MULTI DISPLAY Setup

MULTI DISPLAY Setup Ratio

Location

2 2

To Set up Timer selection screen (see page 22, 23)

Set up TIMER

POWER ON Function POWER ON Time POWER OFF Function POWER OFF Time

PRESENT TIME

2 : 30

Off

0 : 00

Off

0 : 00

To PRESENT TIME Setup (see page 22)

PRESENT TIME Setup

Set

PRESENT TIME

10 : 00

Press the R button to return to “Screensaver” menu.

Press to select POWER ON Time / POWER OFF Time.

Press to Set up POWER ON Time / POWER OFF Time.

Press the R button to return to “Set up TIMER” menu.

Screensaver

Start Function Mode Periodic Time Operating Time Side panel Wobbling Peak limit

Set up TIMER

POWER ON Function POWER ON Time POWER OFF Function POWER OFF Time

Set up TIMER

POWER ON Function POWER ON Time POWER OFF Function POWER OFF Time

PRESENT TIME

White bar scroll

PRESENT TIME

10 : 00

Interval

1 : 00 0 : 15

High

Off Off

2 : 30

Off

6 : 00

Off

23 : 15

2 : 30

6 : 00

23 : 15

ASPECT Controls

4 : 3 Zoom 16 : 9

Auto Just

The Plasma Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format picture.

INPUT

SURROUND

VOL


MULTI

PICTURE POS. /SIZE

SWAP SELECT MOVE

PIP

PLASMA DISPLAY

SOUND

SET UP

ASPECT

OFF TIMER

ASPECT

ZOOM

Notes:

(1) For PC signal input, the mode switches between “4:3”, “Zoom” and “16:9” only. (2) For a 1125 (1080) / 60i · 50i · 24p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p signal input during

(3)

“Component” and “RGB” input signal, the mode is set to “16:9” mode, and switching is not possible. Auto can be selected only during Video signal input.

The aspect mode is memorized separately for each input terminal (INPUT1, INPUT2, INPUT3 and PC IN).

ASPECT button

The aspect mode changes each time the ASPECT button is pressed.

[from the unit]

INPUT MENU ENTER

VOL

– +

The aspect mode changes each time the ENTER button is pressed.

[During MULTI PIP Operations] (1) Picture and Picture, Picture in Picture :

4 : 3 16 : 9

(2) Others : Aspect switching is not possible.

Mode

4 : 3

Zoom

16 : 9

Just

Auto

4 : 3

416

For an elongated image

For a 4:3 image


4:3 will display a 4:3 picture at its standard 4:3 size.

Zoom

16 : 9

Just

3 9

Zoom mode magnifies the central section of the picture.

16:9 will display the picture at its maximum size but with slight elongation.

Just mode will display a 4:3 picture at its maximum size but with aspect correction applied to the center of the screen so that elongation is only apparent at the left and right edges of the screen. The size of the picture will depend on the original signal.

Auto

The display will automatically become enlarged (depending on the picture source), allowing you to

view the picture at its maximum size.

Note:

Image is expanded

Auto mode is designed to automatically adjust the aspect ratio to handle a mix of 16:9 and 4:3 program material. Certain 4:3 program material, such as

Changes in accordance

with the Auto mode setting (see page 31).

stock market data screens, may occasionally cause the image size to change unexpectedly. When viewing such programs, it is recommended that the ASPECT be set to 4:3.

Explanation

Notes: (1) Do not allow the picture to be displayed in 4:3 mode for an extended period, as this can cause a permanent

after-image to remain on the Plasma Display Panel.

(2) Using this function to display a picture with the aspect ratio changed from the original for the purpose of

public display or commercial gain may infringe on copyright laws.

Adjusting Picture Pos./ Size

Adjusting screen


POS. /SIZE

During “AV(S Video)” and “Component” input signal.

Picture Pos./Size

Normalise

H-Pos H-Size V-P os V-Size

Normal

Press to display the Picture Pos./ Size menu.

Press to select H-Pos / H-Size / V-Pos / V-Size / Clock Phase.

During “RGB” and “PC” input signal.

Picture Pos./Size

Normalise

Normal

H-Pos H-Size V-P os V-Size Clock Phase

Press to adjust Pos./ Size.

Press to exit from adjust mode.

INPUT

SURROUND

VOL

N R


MULTI

PICTURE POS. /SIZE

SWAP SELECT MOVE

PIP

PLASMA DISPLAY

SOUND

SET UP

ASPECT

OFF TIMER

Notes:

(1) Adjustment details are

memorized separately for

different input signal formats (Adjustments for component signals are memorized for 525 (480) / 60i

· 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 24p· 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p each, and RGB / PC signals are memorized for each frequency.)

(2) If a “Cue” or “Rew” signal from a VCR or

DVD player is received, the picture position will shift up or down. This picture position movement cannot be controlled by the Picture Pos./ Size function.

H-Pos

H-Size

V-Pos

V-Size

Clock Phase

(RGB/PC in Mode)

When the Position Left

“ ”

button is pressed.

“ ”

button is pressed.

“ ”

button is pressed.

“ ”

button is pressed.

When the Position Right

Flickering and distortion can be eliminated by using the Position Left to carry out adjustment.

“ ”

button is pressed.

“ ”

button is pressed.

“ ”

button is pressed.

“ ”

button is pressed.

or Right

“ ”

button

Note: Using the size adjustment function to display a picture with the aspect ratio changed from the original for the

purpose of the public display or commercial gain may infringe on copyright laws.

Helpful Hint ( /

Normalise

Normalisation)

While the Picture Pos./ Size display is active, if either the N button on the remote control is pressed at any time or the

(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

Picture Adjustments


Press to display the Picture menu.

Select to adjust each item.

Press to select the menu to adjust.

Select the desired level by looking at the picture behind the menu.


Normalise Picture Mode Contrast Brightness Colour Tint Sharpness White balance Advanced settings

Normal

0 0 0 3

Normal

Press to select “On”.

Press to enter Advanced settings .

Advanced settings On Enables fine picture adjustment at a professional level (see next page).

Advanced settings

Normalise Black extension Input level W/B High R

W/B High B W/B Low R W/B Low B Gamma AGC

Normal

0 0 0

0 0 0 0

2. 2 Off

Advanced settings Off Displays images with settings of the Picture menu.


Normal

0 0 0 3

Normal

Off

Press the left

or right

Normalise Picture Mode Contrast Brightness Colour Tint Sharpness White balance Advanced settings

button to switch between

modes.

Auto Normal

Cinema Dynamic

Auto

Automatically selects the mode that best suits the brightness of the environment.

Normal

For viewing in standard (evening lighting) environments. This menu selects the normal levels of Brightness and Contrast.

Dynamic

For viewing in brighter environments. This menu selects higher than normal Brightness and Contrast

levels of

Cinema

Ideal for movies.

Note:

If you would like to change the picture and colour of the selected Picture mode to something else, adjust using the items in the Picture menu. (see next page)

Press the left

or right

button to switch between

modes.

Normal Cool Warm

Helpful Hint ( /

Normalise

Normalisation)

While the “Picture” menu is displayed, if either the N button on the remote control is pressed at any time or the (ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

Picture Adjustments

Item

Contrast

Brightness

Colour

Tint

(NTSC only)

Sharpness

Note:

In PICTURE, there is not a noticeable change even when contrast is increased with a bright picture or reduced with a dark picture.

Effect Adjustments

Selects the proper brightness and

Less More

Darker Brighter

Less More

Reddish Greenish

Less More

density for the room.

Adjusts for easier viewing of dark pictures such as night scenes and black hair.

Adjusts colour saturation.

Adjust for nice skin colour.

Adjusts picture sharpness.

Notes:

(1) “Colour” and “Tint” settings cannot

be adjusted for “RGB” and “PC” input signals.

(2) You can change the level of each

function (Contrast, Brightness, Colour, Tint, Sharpness) for each Picture menu.

(3) The setting details for normal,

dynamic and cinema respectively are memorized separately for each input mode (INPUT1, INPUT2, INPUT3 and PC IN).

(4) The “Tint” setting can be adjusted

for NTSC signal only during “AV (S Video)” input signal.

Advanced settings

Item

Black

extension

Effect

Less More

Adjusts the dark shades of the image in gradation. (This cannot be adjusted when the input signal is RGB or PC.)

Details

Input level

Less More

W / B High R

W / B High B

W / B Low R

W / B Low B

Gamma

AGC

Notes:

(1) Carry out “W / B” adjustment as follows.

A Adjust the white balance of the bright sections using the “W / B High R” and “W / B High B” settings. B Adjust the white balance of the dark sections using the “W / B Low R” and “W / B Low B” settings. C Repeat steps A and B to adjust.

Steps A and B affect each other’s settings, so repeat each step in turn to make the adjustment. (2) The adjustment values are memorized separately for each input mode (INPUT1, INPUT2, INPUT3 and PC IN). (3) The adjustment range values should be used as an adjustment reference.

Less More

Down Up

Off On

Adjustment of parts which are extremely bright and hard to see.

Adjusts the white balance for light red areas.

Adjusts the white balance for light blue areas.

Adjusts the white balance for dark red areas.

Adjusts the white balance for dark blue areas.

S Curve

Increases the brightness of dark signal automatically.

2.0

2.2

2.5

Helpful Hint ( /

On the remote control unit, while the “Advanced settings” menu is displayed, if either the N button is pressed at any time or the

(ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

Normalise

Normalisation)

Sound Adjustment

Select to adjust each item.

Bass

Adjusts low sounds

Treble

Adjusts high sounds

Balance

Adjusts left and right volumes

SOUND

Press to display the Sound menu.

Press to select the desired adjustment menu.

Select the desired level by listening to the sound.

Sound

Normalise Sound Mode Bass Treble Balance Surround

Normal

Normal 0 0 0

Off

Normal

Auto

INPUT

SURROUND

VOL

N R


MULTI

PIP

Emits the original sound.

Automatically controls proper volume level.

SOUND

SWAP SELECT

SET UP

ZOOM

MOVE

Surround

Select On or Off

To end adjustments

•

Press the R button

Note:

Press the SURROUND button to directly turn the surround effect On and Off. (see page 11) Bass, Treble and Surround settings are memorized separately for each Sound mode (Normal, Auto).

Helpful Hint ( /

While the “Sound” menu is displayed, if either the N button on the remote control is pressed at any time or the (ACTION button) is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

Normalise

Normalisation)

Mute

Useful when answering the phone or receiving unexpected visitors.

Press this button to mute the sound. Press again to reactivate sound. Sound is also reactivated when power is turned off or volume level is changed.

Digital Zoom

This displays an enlargement of the designated part of the displayed image.

Display the “Operation Guide”.

ZOOM MOVE

Press to access Digital Zoom.

The “Operation Guide” will be displayed.

Exit

INPUT

SURROUND

VOL

N R


MULTI

PIP

PICTURE POS. /SIZE

Select the area of the image to be enlarged.

SET UP

SOUND

ZOOM

SWAP SELECT MOVE

ASPECT

OFF TIMER

button MUTE button

VOL button

OFF TIMER button

Press on the enlargement location to select.

SURROUND

• During Digital Zoom, only the following keys can be operated.

The cursor will move.

R - STANDBY G POWER ON

INPUT MENU ENTER

– +

VOL

Exit

Select the magnification required for the enlarged display.

Each time this is pressed, the magnification factor changes. This is shown in the image being displayed.

×1 ×2 ×3

Return to normal display (quit Digital Zoom).

Press to exit from the Digital Zoom.

Notes:

(1) When power goes OFF (including “Off Timer” operation), Digital Zoom terminates. (2) The Digital Zoom function cannot be selected while in the following operation states:

• “Multi-screen” (MULTI DISPLAY). (see page 28)

• “Multi-viewer” (Picture in Picture, Picture out Picture, Picture and Picture) operation. (see page 10)

(3) While Digital Zoom is in operation, “Adjusting Picture Pos./ Size” cannot be used. (4) For RGB / PC input signals, normal multi-display magnification is only available at the VGA, SVGA and XGA resolution. (5) The Digital Zoom capability is functional for the following component signals: 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 1125 (1080) / 60i · 50i · 24sF, 750 (720) / 60p · 50p, 1250 (1080) / 50i (6) The Digital Zoom capability is functional for the following composite signals: NTSC, PAL, SECAM (7) Using this function to display an enlarged picture for the purpose of public display or commercial gain may infringe

on copyright laws.

PRESENT TIME Setup / Set up TIMER

The timer can switch the Plasma Display On or Off.

Before attempting Timer Set, confirm the PRESENT TIME and adjust if necessary. Then set POWER ON Time / POWER OFF Time.

INPUT

SURROUND


SOUND

VOL

SET UP

PRESENT TIME Setup

Display the PRESENT TIME Setup screen.

SET UP

Press to display the Setup menu screen.

Press to select Set up TIMER or PRESENT TIME Setup.

Press to display the Set up TIMER screen or PRESENT TIME Setup screen.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

Setup 2/2

Auto power off

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup

RGB

RGB1

English (UK

Off On Off

)

Off

To set up PRESENT TIME, follow the procedure described below.

Press to select PRESENT TIME.

Press to set up PRESENT TIME.

button: Forward

button: Back

Notes:

• Pressing

“ ” or “ ” “ ” or “ ”

button once changes PRESENT TIME 1minute. button continuously changes PRESENT TIME by 15 minutes.

Press to select Set.

Press to store PRESENT TIME Setup.

Note:

Set cannot be selected unless PRESENT TIME is set.

PRESENT TIME Setup

PRESENT TIME

Set

PRESENT TIME

PRESENT TIME Setup

PRESENT TIME

Set

PRESENT TIME

0 : 00

10 : 00

SET UP

Press to exit from PRESENT TIME Setup.

Set up TIMER

Display the Set up TIMER screen.

PRESENT TIME Setup / Set up TIMER

Notes:

• Pressing

“ ” or “ ” “ ” or “ ”

Press to select POWER ON Time / POWER OFF Time.

Press to set up POWER ON Time / POWER OFF Time.

button: Forward

button: Back

button once changes POWER ON Time / POWER OFF Time 1minute. button continuously changes POWER ON Time / POWER OFF Time by 15 minutes.

Press to select POWER ON Function / POWER OFF Function.

Press to select On.

Set up TIMER

PRESENT TIME

POWER ON Function POWER ON Time POWER OFF Function POWER OFF Time

Set up TIMER

PRESENT TIME

POWER ON Function POWER ON Time POWER OFF Function POWER OFF Time

2 : 30

Off

0 : 00

Off

0 : 00

2 : 30

6 : 00

23 : 15

Note:

Timer function will not work unless “PRESENT TIME” is set.

Press twice to exit from Setup.

Screensaver (For preventing after-images)

Do not display a still picture, especially in 4:3 mode, for any length of time. If the display must remain on, a Screensaver should be used.

SET UP

Reversal / Scroll selection

Press to display the Setup menu screen.

Setup 1/2

Press to select the Screensaver.

Press to select the Screensaver screen.

Press to select the Function.

Press to select the desired function.

White bar scroll Image Reversal

Component/RGB-in select

Input label

Power save Standby save Power management OSD Language

Screensaver

Start Function Mode

Start Time Finish Time

Side panel Wobbling Peak limit

Signal

Screensaver

PRESENT TIME

White bar scroll

White bar scroll : The white bar will scroll from left to right. Image Reversal : Negative image will be displayed on the screen.

RGB

RGB1

Off On Off

English (UK

10 : 00

Off

0 : 00 0 : 00

High

Off Off

)

Mode selection

Start setting

Screensaver

Press to select the Mode.

Press to select each mode items.

Off

Start Function Mode

Start Time Finish Time

Side panel Wobbling Peak limit

PRESENT TIME

White bar scroll

10 : 00

Off

0 : 00 0 : 00

High

Off Off

Interval : Operates when Periodic Time and Operating Time are setup and those

times arrive.

Time Designation : Operates when Start Time and Finish Time are setup and those

times arrive.

On : Operates when Start is selected and the (ACTION) is pressed.

Screensaver

When the Mode is set to On, press to select Start.

Start Function Mode

Start Time Finish Time

Side panel Wobbling Peak limit

PRESENT TIME

White bar scroll

10 : 00

0 : 00 0 : 00

High

Off Off

Press to start Screensaver. The menu screen will disappear and the Screensaver will be activated. To stop

the Screensaver under On, press the R button.

Note: This function does not guarantee the complete prevention of permanent after-images. The potential for the

occurrence of permanent after-images is merely decreased.

Screensaver (For preventing after-images )

Screensaver

Function Mode

White bar scroll

Time Designation

Start Time

0 : 00 0 : 00

Side panel

High

Finish Time

Start

PRESENT TIME

10 : 00

Screensaver

Function Mode

White bar scroll

Interval

Periodic Time

0 : 00 0 : 00

Side panel

High

Off

Operating Time

Start

PRESENT TIME

10 : 00

Screensaver

Function Mode

White bar scroll

Side panel

High

Time Designation

Start Time

0 : 00 0 : 00

Finish Time

Screensaver

Function Mode

White bar scroll

Side panel

High

Interval

Periodic Time

0 : 00 0 : 00

Operating Time

Screensaver

Function Mode

White bar scroll

Side panel

High

Off

Start Time

0 : 00 0 : 00

Finish Time

Setup of Screensaver Time

After selecting Time Designation or Interval, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “Mode” is “on” or “off.”)

Start

PRESENT TIME

10 : 00

Start

PRESENT TIME

10 : 00

Press to select Start Time / Finish Time (When Time Designation is selected). Press to select Periodic Time / Operating Time (When Interval is selected).

Press to setup.

button: Forward button: Back

Notes:

• Pressing [However, switching occurs every 15 minutes when Periodic Time is selected.]

• Pressing

“ ” or “ ”

button once changes the Time 1minutes.

button continuously changes the Time by 15 minutes.

Start

Screensaver

Start Function Mode Start Time Finish Time Side panel Wobbling Peak limit

Screensaver

Start Function Mode Periodic Time Operating Time Side panel Wobbling Peak limit

PRESENT TIME

White bar scroll

Time Designation

PRESENT TIME

White bar scroll

10 : 00

7 : 00 8 : 00

High

Off Off

10 : 00

Interval

1 : 00 0 : 15

High

Off Off

Note: Timer function will not work unless “PRESENT TIME” is set.

Reduces screen after-image

These functions prevent the occurrence of an “after-image” on the display when turned ON.

Wobbling: Automatically shifts the display image at a dot level pitch (therefore unnoticeable to the eye) over

time to prevent after image of sharper contour of image.

Peak Limit: Suppresses image contrast (peak brightness).

Setup 1/2

Component/RGB-in select

Input label

Power save Standby save Power management OSD Language

Screensaver

Start Function Mode

Start Time Finish Time

Side panel Wobbling Peak limit

1 2

SET UP

Press to display the Setup menu screen. Press to select “Screensaver”.

Press to display Screensaver menu.

Press to select “Wobbling” or “Peak limit”.

Press to select “On” or “Off”.

Signal

Screensaver

PRESENT TIME

White bar scroll

RGB

RGB1

Off

English (UK

10 : 00

Off

0 : 00 0 : 00

High

Off Off

)

Screensaver (For preventing after-images )

Side Panel Adjustment

Do not display a picture in 4:3 mode for an extended period, as this can cause an after-image to remain on the side panels either side of the display field. To prevent the appearance of such an after-image, illuminate the side panels.

This function may be applicable to the non-picture area.

To display the Screensaver screen. (Refer to the previous page, operation guide steps 1 and 2)

Press to select the Side panel.

Press to select Off, Low, Mid, High.

Off Low Mid High

Press to exit from Screensaver.

side panel

4:3

Screen Display

after-images

Non picture area

Picture out Picture Picture and Picture

Screensaver

Start Function Mode Start Time Finish Time Side panel Wobbling Peak limit

PRESENT TIME

White bar scroll

Time Designation

10 : 00

0 : 00 0 : 00

High

Off Off

Notes:

• Setting the side panel to High mode for an extended period may result in occurrence of after-images.

• The side panels may flash (alternate black / white) depending on the picture being shown on the screen. In such an occurrence, use the Cinema mode.

Reduces power consumption

Setup 2/2

Auto power off

Off

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup

• Power save: When this function is turned On, luminous level of the plasma display is suppressed, so

power consumption is reduced.

• Standby save: When this function is turned On, power consumption of the microcomputer is reduced during

power supply standby (see page 10, 11, 12), so standby power of the set is reduced.

• Power management: The unit power supply is turned On or Off depending on whether or not there is a signal

during PC input mode. This function is enabled when it is turned On. (Only during input from PC (MiniD-sub) terminal)

• Auto power off: Equipment power supply is turned Off when there is no signal.

When this is set to On, the power supply of the unit goes Off 10 minutes after the input signals stop. This function is effective for input signals except input from PC (Mini D-sub) terminal.

Press to select

“Power save” “Standby save” “Power management” “Auto power off”.

Press to select “On” or “Off”.

On Off

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

RGB

RGB1

Off

English (UK

)

SET UP

Press to exit from Setup.

Note:

“Power management” and “Auto power off” are effective during normal viewing (one picture screen) only.

Customizing the Input labels

This function can change the label of the Input signal to be displayed.

Press to select Input label.

Press to change the Input label.

Notes:

While selecting an Input signal through Optional Video Input Card connected to Slot1 to Slot3, the Input label will depend on each Optional Video Input Card.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

RGB

RGB1

Off

English (UK

)

Input labels for Slot1 to Slot3 and miniD-sub:

Setup for MULTI DISPLAY

By lining up Plasma Displays in groups of 4 or 9 as illustrated below, an enlarged picture may be displayed across

all screens.

For this mode of operation, each plasma display has to be set up with a Display number to determine its location.

group of 4 (2×2) group of 9 (3×3)

How to Setup MULTI DISPLAY

SET UP

Press to display the Setup menu screen.

Press to select the MULTI DISPLAY Setup.

Press to display the “MULTI DISPLAY Setup” menu.


SURROUND

SOUND

VOL

INPUT

SET UP

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

Setup 2/2

Auto power off

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup

RGB

RGB1

Off On Off

English (UK

Off

)

Press to select the MULTI DISPLAY Setup.

Press to select “On” or “Off”.

MULTI DISPLAY Setup

MULTI DISPLAY Setup Ratio

Location

2 2

Setup for MULTI DISPLAY

MULTI DISPLAY Setup

MULTI DISPLAY Setup Ratio

2 2

Location

How to set the display location number for each Plasma Display

Press to select Ratio (2nd step).

Press to select “2×2”, “3×3”.

Press to select Location.

Press to select the required arrangement number. (A1-C3 : Refer to the following)

Display Number locations for each arrangement

MULTI DISPLAY Setup

MULTI DISPLAY Setup Ratio

Location

2 2

Notes:

( 2 × 2 ) ( 3 × 3 )

A1 A2

B1 B2

A1 A2 A3

B1 B2 B3

C1 C2 C3

Press twice to exit from Setup.

Setup for Input Signals

Component / RGB-in Select

Select the input signals to be connected by installing the Optional Video Input Card. (Refer to the Operating Instructions for the optional Video Input Card.) Select to match the signals from the source connected to the Component / RGB input terminals. Y, P B, PR signals R, G, B, HD, VD signals

“Component”

“RGB”

SET UP

Press to display the Setup menu screen.

INPUT

SURROUND

VOL

Press to select the “Component / RGB-in Select”.

Press to select the desired input signal.


MULTI

SWAP SELECT MOVE

PIP

SOUND

SET UP

ZOOM

Press to exit from adjust mode.

Note:

Selection may not be possible, depending on which optional board is installed.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

RGB

RGB1

Off On Off

English (UK

Component RGB

)

3D Y / C Filter – For NTSC AV images

Select “Signal” from the “Setup” menu during AV(S Video) input signal. (“Signal [AV]” menu is displayed.)

Press to select the “3D Y / C Filter (NTSC)”.

Press to set On / Off.

Press to exit from adjust mode.

Note:

When On, this setting only affects NTSC input signals.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver

Power save Standby save Power management OSD Language

Press

Signal

3D Y/C Filter (NTSC Colour system Cinema reality Aspect Auto (4:3

(ACTION) button

)

RGB

RGB1

Off On Off

English (UK

Auto

Off

4 : 3

)

[

]

Colour system / Aspect Auto

Auto PAL SECAM M.NTSC NTSC

Setup for Input Signals

Select Signal from the “Setup” menu during AV(S Video) input signal. (“Signal [AV]” menu is displayed.)

Press to select the “Colour System” or “Aspect Auto”.

Press to select each functions.

If the picture image becomes unstable:

Mode

Colour system

Set the colour system to match that of the input signal.

Function

If set to “Auto”, the colour system is automatically selected from “PAL ”, “SECAM” and “NTSC”, but not from “M-NTSC”. To view M-NTSC format pictures, you must manually set to “M-NTSC”.

Setup 1/2

Component/RGB-in select

Input label

Signal

Screensaver Power save Standby save Power management OSD Language

Press

Signal

3D Y/C Filter (NTSC Colour system Cinema reality Aspect Auto (4:3

(ACTION) button

)

RGB

RGB1

English (UK

Auto

4 : 3

Off On Off

Off

)

[

]

Aspect Auto (4:3)

Set to “4 : 3” to view 4:3 images in an unchanged format when Aspect Auto is selected. If you would like to view 4:3 images in Just format, set to “Just”.

Cinema reality

When on, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which are recorded at 24 frames per second. If the picture is not stable, turn the setting to off.

Setup 1/2

Select “Signal” from the “Setup” menu during AV(S Video) or Component input signal.(“Signal [AV]” or “Signal [Component]” menu is displayed.)

Press to select Cinema reality.

Press to set On / Off.

Press to exit from adjust mode.

Note:

When On, this setting only affects the following signal input:

• NTSC / PAL signal input during “AV(S Video)” input signal.

• 525i(480i) 625i(575i) signal input during “Component” input signal.

Component/RGB-in select

Input label

Power save Standby save Power management OSD Language

Press

Signal

3D Y/C Filter (NTSC Colour system Cinema reality Aspect Auto (4:3

Signal

Cinema reality

Signal

Screensaver

(ACTION) button

)

English (UK

[

Component

RGB

RGB1

Off On Off

Auto

Off

4 : 3

Off

)

[

]

Setup for input signals

Sync

Select Signal from the “Setup” menu during RGB input signal.

Press to adjust.

Press to exit from adjust mode.

Setup 1/2

Component/RGB-in select

Input label

Power save Standby save Power management OSD Language

Press

Signal

Screensaver

(ACTION) button

RGB1

English (UK

RGB

Off On Off

[

RGB

)

]

Setting RGB sync signal:

Confirm that the input is set to RGB input (this setting is valid only for RGB input signal).

H & V: The H and V sync signals are input from the HD / VD connector. on G: Uses a synchronized signal on the Video G signal, which is input

from the G connector.

CS: Uses a synchronized signal of Composite Sync input.

H-Freq. (kHz) / V-Freq. (Hz)

Sync

Freq. kHz

H V

31.5

60.0

Freq. Hz

H & V

on G

Displays the H (Horizontal) / V (Vertical) frequencies.

This display is valid only for RGB input and PC input signals. Display range:

Horizontal 15 - 110 kHz Vertical 48 - 120 Hz

H-Freq. kHz

Freq. Hz

31.5

60.0

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.


Interference

Normal Picture

No Picture

Symptoms

Sound

Noisy Sound

No Sound

Normal Sound

Checks

Electrical Appliances Cars / Motorcycles Fluorescent light

Volume (Check whether the mute function has been activated on the remote control.)

Not plugged into AC outlet Not switched on Picture and Brightness / Volume setting (Check by pressing the power switch or standby button on the remote control.)

If a signal with a non-applicable colour system format, or frequency is input, only the input terminal indication is displayed.

Colour controls set at minimum level (see page 18, 19) Colour system (see page 31)

No Colour

This Plasma Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type of input signal. However, this is not a malfunction.

Plasma Display panel

Symptoms

Some parts of the screen do not light up.

After-images appear

Note:

Normal Sound

Check

Whirring sounds can be heard from the display unit.

The display unit is fitted with a cooling fan to dissipate heat generated during normal use.The whirring sound is caused by rotation of the fan and is not a malfunction.

Input signal can be displayed

Applicable input signals for PC Input (mini D-sub 15P) (∗ Mark)

Signal name

1 525 (480) / 60i 15.73 59.94 2 525 (480) / 60p 31.47 59.94 3 625 (575) / 50i 15.63 50.00 4 625 (575) / 50p 31.25 50.00 5 750 (720) / 60p 45.00 60.00 6 750 (720) / 50p 37.50 50.00 7 1,125 (1,080) / 60i 33.75 59.94 8 1,125 (1,080) / 50i 28.13 50.00

9 1,125 (1,080) / 24p 27.00 24.00 10 1,125 (1,080) / 24sF 27.00 48.00 11 1,250 (1,080) / 50i 31.25 50.00 12 640 × 400 @70 Hz 31.47 70.00 13 640 × 480 @60 Hz 31.47 59.94 14 Macintosh13” (640 × 480) 35.00 66.67 15 640 × 480 @75 Hz 37.50 75.00 16 800 × 600 @60 Hz 37.88 60.32 17 800 × 600 @75 Hz 46.88 75.00 18 800 × 600 @85 Hz 53.67 85.06 19 Macintosh16” (832 × 624) 49.73 74.55 20 1,024 × 768 @60 Hz 48.36 60.00 21 1,024 × 768 @70 Hz 56.48 70.07 22 1,024 × 768 @75 Hz 60.02 75.03 23 1,024 × 768 @85 Hz 68.68 85.00 24 Macintosh21” (1,152 × 870) 68.68 75.06 25 1,280 × 1,024 @60 Hz 63.98 60.02 26 1,280 × 1,024 @75 Hz 79.98 75.03 27 1,280 × 1,024 @85 Hz 91.15 85.02 28 1,600 × 1,200 @60 Hz 75.00 60.00

Horizontal Vertical

frequency (kHz) frequency (Hz) and Digital Zoom

Component RGB

When Multi Screen

∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗ ∗∗ ∗∗ ∗ ∗∗ ∗

∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗∗ ∗ ∗ ∗ ∗ ∗

Note:

Signals without above specification may not be displayed properly.

Specifications

Power Source Power Consumption

Normal use

Stand-by condition

Power off condition

Plasma Display panel

Contrast Ratio

Screen size

(No.of pixels)

Operating condition

Temperatuer

Humidity

Applicable signals

Colour System

Scanning format

PC signals

Connection terminals

SERIAL

SPEAKERS (6 Ω)

Accessories Supplied

Remote Control Transmitter

Batteries

Fixing bands

Ferrite core

Dimensions

××

× H

××

× D)

××

NTSC, PAL, PAL60, SECAM, Modified NTSC 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 50i · 24p · 24sF ···· SMPTE274M, 1250 (1080) / 50i

(HIGH-DENSITY MINI D-SUB 15PIN) R,G,B/0.7 Vp-p (75-ohm)

AUDIO IN (M3 JACK) 0.5 Vrms (high impedance) EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE

GD-V422PCE GD-V502PCE

220 - 240 V AC, 50Hz/60 Hz

335W 445 W

Save off 1.9 W, Save on 1.1 W

0.4 W

Drive method : AC type Drive method : AC type

42-inch, 16:9 aspect ratio 50-inch, 16:9 aspect ratio

3000:1

920 mm (W) × 518 mm (H)

× 1,056 mm (diagonal)

786,432 (1,024 (W) × 768 (H))

[3,072 × 768 dots]

1,106 mm (W) × 622 mm (H)

× 1,269 mm (diagonal)

1,049,088 (1,366 (W) × 768 (H))

[4,098 × 768 dots]

0 °C - 40 °C 20 % - 80 %

XGA display

VGA, SVGA, XGA

SXGA, UXGA ···· (compressed)

Horizontal scanning frequency 15 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

Component Y : 1.0 Vp-p (75-ohm : include sync) P

B/CB : ± 0.35 Vp-p (75-ohm)

R/CR : ± 0.35 Vp-p (75-ohm)

HD, VD/1.0 - 5.0 Vp-p (high impedance)

16W [8 W + 8 W] (10 % THD)

EUR646532

2 × R6 Size

(TMME203 or TMME 187) × 2

Small size × 1, Large size × 2

1,020 mm × 610mm × 89mm 1,210 mm × 724mm × 95mm

1,020 mm

89 mm

1,210 mm

95 mm

610 mm

VOL

– +

INPUTMENU ENTER R - STANDBY G POWER ON

VOL

– +

INPUTMENU ENTER R - STANDBY G POWER ON

Mass (weight)

main unit only

with speakers

approx. 29.5 kg net approx. 43.5 kg net

approx. 33.7 kg approx. 48.1 kg

Notes:

(1) Design and specifications are subject to change without notice. Mass and dimensions shown are approximate. (2) This equipment complies with the EMC standards listed below.

EN55022, EN61000-3-2, EN61000-3-3, EN61000-6-2.

724 mm

GD-V422PCE / GD-V502PCE PLASMA DISPLAY MONITOR

VICTOR COMPANY OF JAPAN, LIMITED

Printed in Japan

TQZW367-1

JVC GD V502U, GD-V422U User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

PLASMA DISPLAY MONITOR

Important Safety Instructions

Table of Contents

FCC STATEMENT

Safety Precautions

Accessories

Connections

Power ON / OFF

Basic Controls

On-Screen Menu Displays

Input Signal Selection

ASPECT Controls

Adjusting PICTURE POSITION/SIZE

SOUND Adjustment

PICTURE Adjustments

PRESENT TIME SETUP / SET UP TIMER

SCREENSAVER (For preventing after-images)

Digital Zoom

Reduces power consumption

Setup for MULTI DISPLAY

SET UP for Input Signals

Troubleshooting

VIDEO / COMPONENT / RGB / PC input signals

Specifications

PLASMA DISPLAY MONITOR

Table of Contents

Important Safety Notice

Safety Precautions

Accessories

Connections

Basic Controls

Power On / Off and input signal selection

On-Screen Menu Displays

ASPECT Controls

Adjusting Picture Pos./ Size

Picture Adjustments

Sound Adjustment

Digital Zoom

PRESENT TIME Setup / Set up TIMER

Screensaver (For preventing after-images)

Reduces power consumption

Setup for MULTI DISPLAY

Setup for Input Signals

Troubleshooting

Input signal can be displayed

Specifications
