for digital signage and large screen presentations
Complete hardware and software solution
from a single supplier
Digital presentation screens are an efficient information and display medium with
a wide range of applications. This state-of-the-art visual presentation system is
both dynamic and mobile – and it can reach audiences that have never been
reached before. Get your information and message across efficiently. Get it
across dynamically. Get it across with digital signage.
JVC Professional offers you not only an extensive range of purpose-designed
hardware and software, but also a highly experienced support network with the
benefit of having already completed many, many projects. The JVC advantage is
that one proven and reliable signage specialist gives you the answers to all the
possible questions you could have about the right system for you.
The JVC Professional display range
All JVC Professional’s LCDs have one thing in common – they have been
developed and produced by professionals and for professionals. Apart from
the many innovative user functions and JVC’s world-famous reliability, the range
offers outstanding picture quality. To be convinced, you only have to look at the
images for yourself and then wonder at all the innovative features. Displays do
not come better than these professional high definition monitors from JVC.
03
JVC’s software for the dynamic distribution of information
TV-TOOLS digital signage
TV-TOOLS software package is at the heart of every digital signage installation.
It ensures that the required message reaches the intended audience at the right
time and in the right place. Create added value for all your target groups – whether
specific visitors, customers, groups of employees or just the public at large.
Develop and distribute differentiated audio-visual information in real time in different
locations – your strategy gives you the flexibility to determine which content, at
which location and at what time of day. Customised messages are well received
in today‘s information society!
With TV-TOOLS you also have all the options you need to control and monitor
individual display screens and their content on a network-wide basis – the
monitoring software is complemented by the power to record and analyse content
for the purpose of invoicing advertisers for their time slots. Built-in intelligence
and an easy-to-understand program interface leave you with more time for the
essentials of signage – namely, content design and – by extension – customer
satisfaction.
Electronic posters and animated pictures in your showroom capture attention and
heighten your customers‘ emotions. Academic studies show that digital signage
solutions will increase sales by an average of 60% more than classic rigid POS
advertising media.
Designer
• No limits in the design of
content on your PC
• Flexible choice of content
type: video, still images,
flash animations, RSS and
websites, inter alia
• Time-controlled and on
demand scheduling
• Data base control capability
• Dynamic integration of
product or price information
from SQL databases
Scheduler
• Play-out possible around
the clock
• Can be scheduled months
in advance
• Control of display screens
• Management of all Players
• Background music as
available option
• Can also display Power-
Points if necessary
• Plays HD video, WMV and
MPEG les inter alia
Play-out
• Centralised control of on-demand
video
• Invoices advertis-
ing space and
maintenance
Player
• Receives the programme content via the network
(LAN, WAN, FTP)
• Supports a wide range of display types: plasma, LCD, projectors,
info-terminals
• Direct message over-writing function available for highly impor-
tant or critical messages
• Self-diagnostics with re-booting capability to overcome PC
malfunctions (watchdog function)
• Status information auto-generated via email or SMS
Designer &
Scheduler
Player
1
2
3
IP
4
5
6
n
Complete network solution: JVC provides
an integrated professional digital signage
solution, including software and displays.
LCD
LCD
LCD
LCD
Matrix
Projector
Info-terminal
04
Let your communications be the winner
Build up the excitement in stadiums and other sporting venues
Many sports venue operators have discovered the benefit of using JVC technology to control their
dynamic communications from one central point. They can provide fans and VIPs with stimulating
commentary on what‘s happening on and off the field, whilst also offering an intuitive guidance
system. It will generate revenue by displaying sponsor advertisements. Besides large sporting events,
such systems can also be used in concerts and at corporate events, where they will also ensure a
rapid payback.
Commerzbank Arena Frankfurt
Number of displays used
121
Sizes
Control softwareTV-TOOLS
Contents
Neuchatel Stadium
Number of displays used
Sizes
Control softwareTV-TOOLS
Contents
06
26" – 46"
Guidance system,
VIP information,
Advertising space
28
32" – 40"
Guidance system,
Crowd information,
Game statistics
Think globally, act locally – It‘s easy with JVC
Sanofi Aventis – France
Sanofi Aventis, a pharmaceutical multinational based in France, has just started using digital signage
to communicate the latest events in a consistent way to employees in all 12 of its French plants. It
was essential for the company to deploy a dynamic system so as not to interrupt the plants‘ normal
production operations.
Sanofi defined three types of information to be communicated through the system: business,
leisure and locally relevant data. Their chosen system: JVC‘s TV-TOOLS all-in-one solution. One of
the TV-TOOLS features most valued by the company is the ability, based on central permissions,
to enter content locally to supplement the nationwide information program. This allows local human
resource departments to display health and safety messages that relate specifically to their own plant.
Sanofi Aventis‘ entire installation in France consists of 80 playout screens as well as ten Designer and
Scheduler stations.
Pharmaceutical manufacturer Sanofi Aventis
Number of displays used
80
Design/Scheduler locations
Connection
Control softwareTV-TOOLS
Contents
Corporate data,
Health & safety info
10
LAN and W-LAN
07
Creative, impressive, flexible – Use the opportunities available to you
We‘ve got the right solution for you
No matter where, no matter how – JVC Professional technology will always
keep you informed. Benefit from dynamic, animated communication from
JVC Professional display systems.
Point of Sale
Over half of all buying decisions are made at the point of sale.
The signage gets the customers‘ attention in a targeted fashion
and encourages them to buy certain products. Price reductions
can be implemented quickly and easily. Digital signage is already
the commercial language of the future.
Security
JVC Professional display systems are ideally suited for security
systems and security monitoring. Several pictures can be
featured at the same time in perfect picture quality on the
big screens. Connecting up several surveillance cameras in
combination with the PiP or PbP functions
to create a professional security system, performing even
sophisticated surveillance tasks.
(¹)
make it possible
Hotels, restaurants and canteensFoyers and waiting areas
Displays create a positive impression in large and spacious
foyers and entrance halls. Even the usual waiting period at the
doctor’s can be made much more acceptable by the accurate
targeting of so-called infotainment. A direction finder helps
visitors quickly and efficiently to get where they need to be.
08
Digital signage is the ideal tool to provide a smart looking list of
that day’s activities and functions. In company canteens it can
recommend the dish of the day and can also tell employees
about the latest company news and events. This makes for
highly effective company communication.
CAD
Trade fairs, conference centres, malls
The professional JVC signage system within the CAD function
creates working conditions which will achieve optimal results.
CAD designers can develop their products and produce 3D
displays and drawings to a high technical standard, because
the finest of lines and the minutest of details get displayed
thanks to the unsurpassed high definition quality.
Large rooms require large presentations. The JVC signage
system draws attention in a creative manner to the major
exhibits within of an art gallery or simply provides general
visitor information. Used as a location finder, visitors can
quickly find their way around the museum. The neutral
shade of the black aluminium bezel blends gracefully in
with any interior.
The all-in-one solution makes it easier to find one‘s way in
large, open public spaces such as exhibition halls, conference
centres and shopping malls. Whether used for location finding
or event information, the display lets you reach visitors quickly
and efficiently. The ambient light control function (ALC)
display also ensures the right level of picture brightness and
brings energy savings with it.
(²)
on the
Video conferencingMuseums
Ideally suited for use at video conferences. The design
programme will provide optimal space for important content –
and with excellent picture quality. The PiP and PbP
allow flexible arrangement of different simultaneous video
pictures.
(¹)
modes
(¹)
see page 11 (²) only CO-46 LCD-BD
09
Feature| Model
GD-F65L1GD-F52L1GD-F46L1CO-46LCD-BDGM-H40L2
Screen size65"52"46"46"40"
Full HD
Portrait /Landscape
Multiscreen matrix
PiP/PbP
RS-232C
ALC
24/7 operation
Metal cabinet
Scheduling function
Signal detection
Unbranded
yesnoon request
1920
1080
Features
Professional functions with user settings
Multiscreen matrix
Ideally suited for impressive graphic displays. Delight your
audiences with displays in corridors or life-sized screens in
the foyer. A combination of up to 25 (5x5) screens in an
image-wall brings about extensive presentation opportunities.
The centralised, monitored signal distribution of TV-TOOLS
ensures constant picture quality and maximum operating
stability.
Portrait and landscape formats
Depending on the content to be displayed, the monitors
may be installed in vertical or horizontal format.* The portrait
format is especially suitable for display boards and guidance
systems, while the landscape format is ideal for video
conferencing and promotions.
* GD-F65L1 and CO-46LCD-BD are Landscape only
Multiscreen matrix: one large display through the synchronised use
of several monitors (up to 25).
LCD 1
Signal
splitter
LCD 25
The multiscreen matrix is managed by a separate signal splitter,
thus providing the added advantage of increased operational
stability.
PortraitLandscape
10
%.%2'9
3!6).'
UPTO
ENERGY
SAVING
Full HD – imaging at its sharpest
JVC professional displays
1,920 x 1,080 full HD resolution. See it to believe it.
(¹)
applies to GD-F65L1, GD-F52L1 and GD-F46L1
(¹)
provide perfect picture quality in
768
pixels
1,366
pixels
1,920
pixels
1,080
pixels
ALC (Ambient light control)
Automatic brightness control
to ensure optimal adjustment of the image parameters to
suit ambient conditions at all times. The advantages are:
Optimised legibility in varying light conditions. Energy
savings of up to 60%, providing lower TCO (Total cost
of ownership).
ALC can be switched off to allow manual adjustment.
(²)
only with CO-46 LCD-BD
(²)
operates via a light sensor
Professional RS-232 interface
All these JVC monitors can be externally controlled via
wired serial interface. Using RS-232 protocol means that
all widely available remote control systems can be directly
interfaced.
HD Ready display
with 3.2 million pixel resolution
Ambient Light Control
Central control via the universal RS-232 interface
Full HD display
with 6.2 million pixel resolution
LCD
Flexible image management
Images from digital sources can be input through the Picture
in Picture (PiP) and Picture by Picture (PbP) functions. This can
be both an attractive and effective way to display information.
Robust metal alloy cabinet – very light
Black anodised aluminium housing with VESA mountings
emphasise the high-quality design and build. Light for easy
transportation and rapid installation. Omission of the
manufacturer‘s logo
(³)
only with the CO-46LCD-BD, other displays on request
(³)
makes for a brand-neutral installation.
Scheduling function
With the help of this function the user can set the time of
the automatic „on“ and „off“ mode and thereby save energy.
Signal detection
JVC Professional LCD monitors immediately detect and
adjust themselves to the incoming signals.
Picture in Picture (PiP) Mode
Having VESA xing points means a wide range of wall mountings
and desktop stands are available.
Shown: Wall mount PE-100682-VESA
11
GD-F65 L1
1254
882
247
002172
200200
200
002 172
200200
200
1254
882
247
002172
149
59
66
92
200200
200
882
200200
65" professional full HD, LCD display
(landscape)
Ideal for digital signage application with TV-Tools.
Full HD resolution, 1080p (1,920 x 1,080 pixels)
Multiscreen matrix with combination options of up to
25 (5x5) screens – 2x2, 3x3, 4x4 and 5x5.
Professional RS-232 serial interface.
24/7 continuous operation, with up to 50,000 hours typical
life for the back-light unit.
A black anodised aluminium cabinet provides maximum
protection.
Opening width (1432)
Screw holes for
650
mounting brackets
(M10 x 4 holes)
440
860
External speaker
AV audio input
PC/AV audio output
PC audio input
PC analog input (BNC)
RS232C output
Composite video input (BNC)
(D-Sub 9 pin)
Opening height (807)
1572
8585
126 7
1485
GD-F52 L1
52" professional full HD, LCD display
(landscape and portrait)
Ideal for digital signage application with TV-Tools
Full HD resolution, 1080p (1,920 x 1,080 pixels)
Multiscreen matrix with combination options of up to
25 (5x5) screens – 2x2, 3x3, 4x4 and 5x5.
Professional RS-232 serial interface.
24 /7 continuous operation, with up to 50,000 hours
(landscape) and 30,000 hours (portrait) typical life for the
back-light unit.
A black anodised aluminium cabinet provides maximum
protection.
VESA holes
1254
Opening width (1157)
200200
200
393155
595
2020
(D-Sub 9 pin)
PC analog input
(Mini D-Sub 15pin)
AV digital input (DVI-D)
PC digital input (DVI-D)
PC/AV digital output (DVI-D)
149
92
95
RS232C input
Component input (BNC)
742
12
882
(653)
Opening height
200271
PC analog input (BNC)
RS232C output
(D-Sub 9 pin)
Composite video input (BNC)
66
(D-Sub 9 pin)
RS232C input
Component input (BNC)
AV digital input (DVI-D)
PC digital input (DVI-D)
PC/AV digital output (DVI-D)
PC analog input
(Mini D-Sub 15pin)
External speaker
AV audio input
PC/AV audio output
PC audio input
±3119,5
86,8±2
269,2±2
01
10
10
01
956 3±
617 3±
01
600
4,9212±004
±3119,5
86,8 ±2
269,2± 2
01
01
01
01
600
4,9212±004
01
600
4,921 2±004
±3119,5
86,8±2
269,2±2
1102,8±3
610±2
01
01
10
10
01
9563±
6173±
01
600
4,9212±004
GD-F46L1
200
002
78
882
1113
200
Maßeinheit: mm
5.822
200
002
200
Maßeinheit: mm
5.822
200
002
78
041
25
42
882
1113
185
756
200
Maßeinheit: mm
5.822
200
78
041
882
200
Maßeinheit: mm
46" professional full HD, LCD display
(landscape and portrait)
Ideal for digital signage application with TV-Tools
Full HD resolution, 1080p (1,920 x 1,080 pixels)
Multiscreen matrix with combination options of up to
25 (5x5) screens – 2x2, 3x3, 4x4 and 5x 5.
Professional RS-232 serial interface.
24 /7 continuous operation, with up to 50,000 hours
(landscape) and 30,000 hours (portrait) typical life for the
back-light unit.
A black anodised aluminium cabinet provides maximum
protection.
VESA holes
1113
Opening width (1023)
(576)
Opening height
200200
200228,5
657
5812452
PC analog input (BNC)
RS232C output
(D-Sub 9 pin)
Composite video input (BNC)
External speaker
PC/AV audio output
AV audio input
140
882
87
PC analog input
(Mini D-Sub 15pin)
AV digital input (DVI-D)
PC digital input (DVI-D)
PC/AV digital output (DVI-D)
(D-Sub 9 pin)
RS232C input
Component input (BNC)
PC audio input
CO-46LCD-BD
46" professional LCD display
(landscape)
Ideal for digital signage use with TV-Tools.
Multiscreen matrix with combination options of up to
16 (4x4) screens – 2x2, 2x3, 3x2, 3x 3, 3x 4, 4x3 and 4x4.
Professional RS-232 serial interface.
Picture optimisation for ambient light conditions (ALC)
ensures best quality pictures and saves up to 60% on
energy costs.
15 hours‘ operation per day.
Aluminium cabinet provides maximum protection at
minimum weight
Screw holes for
mounting brackets (M8 x 4),
Opening width (1019,2)
3
3
±
±
659
716
610±2
1102,8±3
Opening height (574,6)
max. screw-deapth 65 mm)
600
119,5±3
2
±
129,4
400
86,8±2
269,2±2
RF-IN
Scart 1
Scart 2
YUV
YUV-L
YUV-R
S-VIDEO
S-VIDEO L
S-VIDEO R
VGA-HDSUB
RS232
Connector
via seperate
HDMI 2
HDMI 1
Audio-OutAudio-In
Line-Out SUB
VGA-R
VGA-L
DIG OUT COAX
Line-Out R
Line-Out L
13
GM-H40L2
)LOT)LOT
40" professional LCD display
(landscape and portrait)
Ideal for digital signage application with TV-Tools
Housing design for flush wall-mounting, cooling by
means of a side-mounted vents.
Wide selection of input and control connections.
Easily removable front bezel for colour change.
Highly effective anti-burn-in systems and circuitry.
Self-diagnosis with indicator lights.
Anti-theft device.
Ambient light sensor for automatic brightness
adjustment and energy saving
Rapid switching between inputs
986
123
595
Specifications
ModelGD-F65L1GD-F52L1GD-F46L1CO-46LCD-BDGM-H40L2
Screen
AlignmentLandscapeLandscape / PortraitLandscape / PortraitLandscapeLandscape / Portrait
Screen size65"52"46"46"40"
Height to width ratio16:916:916:916:916:9
Resolution1,920 x 1,080 pixel (Full HD) 1,920 x 1,080 pixel (Full HD) 1,920 x 1,080 pixel (Full HD) 1,366 x 768 pixel1,366 x 768 pixel
Display colours16.7 million colours (8 bit)16.7 million colours (8 bit)16.7 million colours (8 bit))16.7 million colours (8 bit)16.7 million colours (8 bit)
Viewing angle176° typical 176° typical176° typical178° typical170° typical
Contrast2000:1 typical1700:1 typical1700:1 typical1200:1 typical /
Brightness450 cd / m² max.TBA450 cd/m² max.500 cd/m² max.400 cd /m² max.
Optional IF-C unit for active-through input of analogue
component signals
Superb image display of up to UXGA in native resolution
Compatible with 15K analogue RGB signal
Input
Optional IF-C unit for input of analogue RGB and
analogue component signals
Superb image display of up to UXGA in native
resolution
Compatible with 15K analogue RGB signal
OUTININOUT
SDI signal chain connection capability via
bridge out
Embedded audio bridged out
1080/14psF, 1080/24p and 1080/30p
compatibility
15
TV-TOOLS
Highlights
Real time multi-media display system with optimised syncs for really smooth transitions,
video effects and animations
The creation module, Designer, makes it easy to combine all different types of AV materialThe point on the network from which the different displays are controlled and scheduled
can be different from the point of creation and located anywhere on a network because
the Designer, Scheduler and Player modules all operate independently
Different display programmes can be handled simultaneously and be scheduled months
in advance
The system can support more than one Designer station and can all be operated
simultaneously
Changes to content are transmitted invisibly at the same time as the regular transmission
to the player. The network’s bandwidth is protected by sending only the new or changed
elements
High level of secure communication on account of single selectable TCP port Innite possibilities for scheduling ahead by date and by display programmeCreation and management of the play-out clustersControl monitor can be connected to the Player PCReal time messaging overlays the play-out programme
Live incorporation of data updates, all in real time
Several players can receive update data simultaneously by using FTP serversProgramme content can be changed locally at Player PC, but only with the necessary
permissions being securely granted by central control
Possibility also to put limited periods of scheduling under local controlRemote control of playout devices which are equipped with RS-232C control interface
Compatibility
Graphics: BMP, GIF, IFF, JPEG, PCX, PNG, Targa, TIFF, WMFAnimation: TGA, Flash, AVI, Quicktime, GIFAudio: WAV, MP3, MIDI, CD AudioVideo: MPEG-1, MPEG-2, MPEG-4, DivX, WMV WM9 Windows Media Video and AVIFonts: TrueType
