JVC GC-A70 User Manual
Digital Camera
A
GC-A70
INSTRUCTIONS
Thank you for purchasing this JVC product. Before beginning to operate this
unit, please read the instruction manual carefully in order to make sure that the
best possible performance is obtained. If you have any question, consult your
JVC dealer.
To HomePage of JVC
LNT0011-001
[Back] [Next]
“ SOME DO’S AND DON’TS ON THE SAFE USE OF EQUIPMENT ”
This equipment has been designed and manufactured to meet international safety standards but, like any electrical
equipment, care must be taken if you are to obtain the best results and safety is to be assured.
Do
read the operating instructions before you attempt to use the equipme nt.
Do
ensure that all electrical connections (including the mains plug, extension leads and inter-connections between pieces of
equipment) are properly made and in accordance with the manuf acturer’s instructions. Switch off and withdraw the mains
plug when making or changing connections.
Do
consult your dealer if you are ever in doubt about the installation or operation or safety of your equipment.
Do
be careful with glass panels or doors on equipment.
DON'T
continue to operate the equipment if you are in any doubt about it working normally, or if it is damaged in any way—switch
off—withdraw the mains plug and consult your dealer.
DON'T
remove any fixed cover as this may expose dangerous voltages.
DON'T
leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended
operation or has a standby mode. Switch off using the switch on the equipment and make sure that your family know how
to do this. Special arrangements may need to be made for infirm or handicapped people.
DON'T
use equipment such as personal stereos or radios so that you are distracted from the requirements of road safety. It is
illegal to watch television when driving.
DON'T
listen to headphones at high volume as such use can permanently damage your hearing.
DON'T
obstruct the ventilation of the equipment, for example with curtains or on soft furnishings. Overheating will cause damag e
and shorten the life of the equipment.
DON'T
use makeshift stands and NEVER fix legs with wood screws. To ensure complete safety always fit the manufacturer’s
approved stand or legs with the fixing screws supplied according to the instructions.
DON'T
allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL
NEVER let anyone especially children push anything into holes, slots or any other opening in the case. This could result in
a fatal electrical shock.
NEVER guess or make changes with electrical equipment of any kind. It is better to be safe than sorry!
[Back] [Next]
FCC INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, it may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equ ipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
z
Reorient or relocate the receiving antenna.
z
Increase the separation between the equipment and receiver.
z
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected .
z
Consult the dealer or an experienced radio/TV technician for help.
CAUTION
Changes or modifications not approved by JVC could void user’s authority to operate the equipment.
Contact
Address: JVC AMERICAS CORP.,
1700 Valley Road, Wayne, New Jersey 07470
Telephone: (973) 317-5000
INFORMATION (for CANADA)
This Class B digital apparatus complies with Canadian ICES-003.
RENSEIGNEMENT (Pour le CANADA)
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
[Back] [Next]
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
SAFETY PRECAUTIONS
The lightning flash with arrowhead symbol, within an equil ateral tri an gle, is int end ed to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
CAUTIONS
About moisture condensation . . .
You may have observed that pouring a cold liquid into a glass will cause drops of water to form on the glass’ outer
surface. This same phenomenon occurs on the lens of the camera when it is moved from a cool place to a warm place,
after heating a cold room, under extremely humid conditions or in a place directly subjected to the cool air from an air
conditioner.
Serious malfunctioning
If malfunctioning occurs, immediately stop using the unit and remove the battery, then consult your local JVC dealer.
MAIN UNIT
1. For safe use, please do NOT . . .
...open the camera’s chassis due to high voltage inside.
...disassemble or modify the unit.
...allow inflammables, water or metallic objects to enter the unit.
...remove the batteries while the power is on.
...look through the viewfinder directly at the sun or extremely bright light.
...point the lens directly into the sun. Th is can lead to malfunctioning of the internal circuitry. There is also a risk of fire
or electric shock.
...subject it to shock or excessive vibration.
...connect any USB cable to this unit except the one provided.
2. Avoid using the unit in the following places:
z
Where the camera will be subject to dust, soot, steam, or excessive heat.
z
Where the camera will be subject to excessive shock or vibration.
z
Where the camera will be subject to extremely low (under 0°C or 32°F) or extremely high (over 40°C or 104°F)
temperatures.
z
In direct sunlight.
z In a closed car in summer.
z
Near a heater.
z Near a television set.
z
Near appliances generating strong magnetic or electric fields (speakers, broadcasting antennas, etc.).
3. To protect the unit, DO NOT . . .
...allow it to become wet.
...drop the unit or strike i t ag ainst hard objects.
...subject it to shock or excessive vibration during transportation.
...keep the lens directed at extremely bright objects for long periods.
...swing it excessively when using the hand strap or neck strap.
MEMORY CARDS
1. To properly use and store your memory cards, be sure to read the following cautions:
z
Make sure the memory card bears the SD or Multimedia Card mark.
z Make sure the memory card is positioned properly when inserting.
z
While the memory card is being accessed (during recording, playback, deletion, formatting etc.), never unload the
memory card or turn off the digital camera.
z
Store memory cards...
...away from heaters or other heat sources.
...out of direct sunlight.
...where they will not be subject to unnecessary shock or vibration.
...where they will not be exposed to strong magnetic fields (such as those ge nerated by motors, transformers or
magnets).
LCD MONITOR
z To prevent damage to the LCD monitor, do NOT subject it to undue force or shocks.
z
To prolong its service life, avoid rubbing it with a coarse cloth.
ALKALINE BATTERIES
1. For safe use, do NOT . . .
...attempt to charge the alkaline batteries.
...reverse the polarities of the batteries.
...carry or store a battery together with objects such as metal pens, necklaces, coin s or hairpins. This could short-
circuit the positive and negative poles of the battery.
...heat or attempt to disassemble a battery.
...expose the battery to water or fire.
...subject a battery to strong impacts, such as hitting it with a hammer, stepping on it or dropping it.
...forget to remove the batteries from the unit if the camera is not to be used for an extended period of time, so as to
prevent leakage.
Any of these may cause the battery to split or leak, causing fire or injury.
2. Use only the specified batteries with this camera. The use of other power sources may cause a fire.
3. When discarding batteries, environmental problems must be considered and the local rules or laws governing
the disposal of these batteries must be followed strictly.
HOW TO HANDLE A CD-ROM
z
Take care not to soil or scratch the mirror surface (opposite to the printed surface). Do not write anything or put a
sticker on either the front or back surface. If the CD-ROM gets dirty, gently wipe it with a soft cloth outward from the
center hole using a circ ul ar motion.
z
Do not use conventional disc cleaners or cleaning spray.
z
Do not bend the CD-ROM or touch its mirror surface.
z
Do not store your CD-ROM in a dusty, hot or humid environment. Keep it away from direct sunlight.
FLASH
z Do not fire the flash at a person, particularly an infant, at short range for this may cause impairment of eyesight.
z
Do not touch light-emitting portion after flash. This may cause burn.
BEFORE USING THE CAMERA
z We recommend that you take some test shots before you actually start, to accustom yourself to the camera.
z
We cannot bear any responsibility for an inability to shoot, record, or play back material normally in the event of a
problem with this camera.
z We shall not be liable for any incidental, consequential or exemplary damage, loss of profits or any demand made by
any third party due to your use of this product or the provided software.
z
Store backups of important images/video clips on a personal computer, etc. We cannot bear any responsibility for
pictures stored in memory that are lost or altered.
z It is prohibited to use still images/video clips taken with this camera for commercial purposes without the consent of
the copyright owner.
z
Please be aware that the shooting subject may appear whitish or halation may occur in following conditions:
{
When a very bright subject is taken in a short distance.
{
When a subject which has a very bright part is taken in strong sunlight.
Notes:
z Microsoft and Windows are either registered trademarks or tradema rks of Microsoft Corporation in the United States
and/or other countries.
z
Other trademarks are the properties of their respective owners.
[Back] [Next]
FUN THINGS YOU CAN DO
This camera is an all-in-one compact size digital and USB PC-camera. With it, you can:
z Take digital pictures/video clips in an instant.
Easily capture digital images and download them to your computer.
z
Videoconference on the Internet.
Keep in touch with distant family and friends. See and talk with people on the Internet face-to-face.
z Send captured images with your e-mail messages.
[Back] [Next]
WHAT'S INCLUDED?
Please check to see that the following items are included in the package. If any item is missing, please enquire at your
nearest JVC-authorized dealer.
Notes:
z
Microsoft and Windows are either registered trademarks or tradema rks of Microsoft Corporation in the United States
and/or other countries.
z Other trademarks are the properties of their respective owners.
[Back] [Next]
SYSTEM REQUIREMENTS (PC)
z
Microsoft® Windows® 98/98SE/Me/2000/XP (Pre-installed Model)
z Intel® Pentium® Processor 166 MHz or higher
z
Free USB Port
z Minimum RAM: 32 MB (Windows XP: 128 MB)
z
250 MB of available hard disk space
z Color display: 800x600 or better
z
CD-ROM drive
Notes:
z
Microsoft and Windows are either registered trademarks or tradema rks of Microsoft Corporation in the United States
and/or other countries.
z Other trademarks are the properties of their respective owners.
[Back] [Next]
FEATURES
LCD Monitor
Design
Digital Zoom
Multipurpose
Built-in Digital
Memory
Power Supply
A 1.5-inch color TFT LCD monitor with high image quality of 2 megapixels that enables monitoring
of images while shooting, and immediately after recording.
Features a compact, posh metallic design.
Digital zooming of x2, x3 and x4 and macro mode (switching by lens) with a 45 cm close-up
capability for wide variety of shooting scenes.
A Digital Still Camera, usable as a movie camera (Video Clip: AVI w/o Sound) or Webcam as well
as a Multi Digital Camera.
Equipped with built-in 8 MB flash memory (that retain images even in the absence of a pow er
supply) and SD/MMC compatible memory slot, the number of images can be increase simply by
adding memory card.
Supplied by easily purchased AA-size alkaline batteries (x2, option).
In addition, it operates with USB power source when connected to a PC through a USB port (i.e.
when transferring images from the built-in memory to the PC or using as a Webcam).
[Back] [Next]
r
V
r
r
GETTING TO KNOW THE CAMERA
Controls, Connectors and Indicators
Built-in Flash
Viewfinder window
Self-Timer lamp
Lens
Normal / Macro switch dial
Strap holder
Status indicato
iewfinde
[POWER] button
[MODE] button
LCD monito
USB Port Cover
USB port
Shutter button
[RESOLUTION] &
Quality / Left button
[DISPLAY] /Up button
[OK/ ZOOM] button
Flash mode /Right button
Self-Timer /Down button
[MENU] button
Battery/Memory Card
compartment door
Tripod socket
[Back] [Next]
y
2
3
GETTING STARTED
Be sure to insert the (AA-siz e Al kaline) batteries before trying to capture images with your camera.
Inserting the Batteries
1. Slide the Battery/Memory card compartment door (located on the right
side of the camera) in the direction indicated by the arrow to open it.
. Insert the AA-size batteries as indicated on the inner side of the door.
. Close back the door and turn on the camera.
Checking Batteries( : Full battery power)
The Battery Indicator will be displayed on the status LCD monito r while the
camera is on. Depending on the durability and usage of the batteries, the
number of pictures that can be recorded varies. Note that power is
consumed by the following operations even when not recording, reducing
the number of images that can be recorded.
z
Extensive use of the LCD monitor in the Play/Erase mode.
z Performing settings.
Notes:
z Please ensure that the batteries are inserted in the correct way. Do not reverse the and polarities.
z
The recommended battery type is AA size ALKALINE.
z
Never use manganese batteries.
z Low temperatures (under 0°C or 32°F) will reduce the output efficiency of the batteries, thereby shortening the
operation time of the camera.
z
The use of Flash is not recommended when the battery level is low.
z Never mix old and new batteries.
z
Remove the batteries if the camera is not to be used for an extended period of time, to p reven t leaks or corrosion.
z Before discarding batteries, cover the positive and negative terminals with adhesive tape.
z
The Battery Indicator reflects the level of remaining battery power. When the indicator appears as shown above, th e
batteries are weak and need to be replaced.
Attaching the Hand Strap or Neck Strap
Always use the provided hand strap or n eck strap when carrying the camera. Please note that the company cannot be
held responsible for any accidental drop of the camera due to improper use of the ha nd stra p or neck strap.
To attach the strap to
our camera:
1. Thread the thinner looped end of the strap through the stra p holde r.
2
2
3
4
2
3
4
. Insert the other end of the strap through the thin loop and pull it all the way out. Ensure that the strap is securely
tightened unto the camera.
Note:
z Be careful not to bump the camera or entangle the strap.
Inserting and Removing the SD / Multimedia Card
This camera can be used with either an SD card or a Multimedia card (MMC).
When traveling and capturing a lot of images, it is convenient to make use of an SD or a Multimedia card. When a card is
inserted into the camera, still images/video clips captured will be stored in the card’s memory.
When the card is removed, the camera’s internal memory will be used as the stora ge media .
Inserting the Memory Card
1. Turn off the camera's power by pressing the [POWER] button.
. Open the Battery/Memory card compartment door.
. Firmly insert the memory card into the memory card slot as far as it can go,
with the memory card electrodes (metal contacts) end facing the camera.
(Refer to the right figure.)
. Close back the door firmly.
Removing the Memory Card
1. Turn off the camera's power by pressing the [POWER] button.
. Open the Battery/Memory card compartment door.
. Push the memory card in as far as it can go and release. The card will
spring back and protrude slightly. Pull it out with your fingers.
. Close back the door firmly.
Notes:
z
SD and Multimedia cards are purchased separately.
z Pay attention to the card direction when inserting. Wrong direction and forced insert can break it.
z
When the memory card is inserted, access to the camera's internal memory is not possible.
z Cards available in the market, and those already formatted for PC and other devices may not be identified by this
camera. Therefore, before using them, it is necessary to format them first with this camera.
z
While the power of the camera is on, do not open the battery cover to replace the memory card or batteries as this
may cause irrecoverable corruption of card data.
z The memory card is a sensitive device so it should not be subject to any shock. Do not touch the metal part of the
card with your hand.
z
When the memory card is write-protected, it cannot be used (A message “WRITE PROTECT” will appear on the LCD
monitor). You have to disable the write-protection first.
Switching the Power ON / OFF
Press the [POWER] button to toggle ON / OFF.
The Status Indicator will lit up immediately upon power on. The light will
go off after a while (the length of time varies with the capacity of the
memory card that is inserted in the camera) and the camera will then
be ready for use.
Switching the LCD Monitor ON / OFF
The LCD monitor is automatically activated when the power is switched
on. However, since the LCD monitor consumes battery power fast, we
recommend that you turn off the LCD monitor and use the optical
viewfinder as far as possible when capturing still images. To switch the
LCD monitor ON or OFF, toggle the [DISPLAY]/Up button. When the
LCD Monitor is OFF, the status indicator lights up to indicate Power ON
status.
Notes:
z The “DATE/TIME” setting screen will appear on the LCD monito r upo n its activation in the case of a newly purchased
camera or if the camera has not been used for a long time.
z
When the camera is in the Play/Erase mode, the LCD monitor cannot be turned off. The still image/ video clip taken
most recently will be shown on the LCD monitor. Further, in the case that no image/video clip exists in the memory,
the message “NO IMAGE” will be shown on the LCD monitor. When the camera is in the Video Clip Mode, the LCD
monitor cannot be turned off either.
z
When no operation is performed within a certain time interval (user set value: “1min”, “3min”, “5min”, “10min”,
“Cancel”; Default value: “3min”), the camera will automatically turn off.
[Back] [Next]
2
OPERATIONS
CAMERA MODE
VIDEO CLIP MODE
PLAY /ERASE MODE
Shooting Basics Shooting Basics Play Basics
Customized Shooting
z
Zooming
z
Using Flash
z
Using Self-Timer
z
Setting the Image Resolution &
Customized Shooting is not applicable to the Video Clip and Play/Erase Mode.
Quality
z
“SETUP MENU”
z “SLIDE SHOW”
z
“ERASE”
z “COPY TO CARD”
z
“DPOF”
z
“SETUP MENU”
z “QUICK VIEW”
z
“EV&WHITE BALANCE”
Menu Settings
z
“SETUP MENU”
z “EV&WHITE BALANCE”
Setting the various mode:
1. Press the [POWER] button.
. Press the [MODE] button until the desired mode is displayed.
Loading...
