JVC FS-H10C, FS-H10J Instructions Manual

COMPACT COMPONENT SYSTEM

FS-H10

TIMER

TIMER SET

STANDBY/ON

ON/OFF

RANDOM SLEEP

INTRO

REPEAT

REMAIN

ST/MONOPROGRAM

TUNER

TAPE CD

/BAND

CD

BEAT CUT

DISPLAY

/CLOCK SET

SOUND

VOLUME

MUTING

/BASS

RM-SFSH10J REMOTE CONTROL

—Consists of CA-FSH10 and SP-FSH10

STANDBY/ON

STANDBY

COMPACT COMPONENT SYSTEM

FS-H10

CD SYNCHRO RECORDING

VOLUME

OPEN

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No.

Seri al No.

LVT1092-001A

[J]

Warnings, Cautions and Others

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

CAUTION— STANDBY/ON button!

Disconnect the mains plug to shut the power off completely (all lamps and indications go off). The STANDBY/ON button in any position does not disconnect the mains line.

• When the unit is on standby, the STANDBY lamp lights red.

• When the unit is turned on, the STANDBY lamp goes off.

The power can be remote controlled.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

G-1

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

15 cm

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND.

For Canada/pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS. CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR: “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

CAUTION: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front:

No obstructions and open spacing.

2 Sides/ Top/ Back:

No obstructions should be placed in the areas shown by the dimensions below.

3 Bottom:

Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.

Front view

15 cm

1 cm

15 cm

1 cm

15 cm

Side view

FS-H10

10 cm

FS-H10

G-2

Introduction

We would like to thank you for purchasing one of our JVC products.

Before operating this unit, read this manual carefully and thoroughly to

obtain the best possible performance from your unit, and retain this manual

for future reference.

About This Manual

This manual is organized as follows:

• This manual mainly explains operations using the buttons on the remote control. You can use the buttons both on the remote control and on the unit for the same operations if they have the same or similar names (or marks), unless mentioned otherwise.

• Basic and common information that is the same for many functions is grouped in one place, and is not repeated for each procedure. For instance, we do not repeat the information about turning on/off the unit, setting the volume, changing the sound effects, and others, which are explained in the section “Basic and Common Operations” on pages 8 and 9.

• The following symbols are used in this manual:

Gives you warning and caution to prevent damage or risk of fire/electric shock. In addition, we put information here about conditions which will prevent getting the best possible performance from the unit.

Gives you information and hints you need to know.

Power sources

• When unplugging the unit from the wall outlet, always pull on the plug, not the AC power cord.

DO NOT handle the AC power cord with wet hands.

Moisture condensation

Moisture may condense on the lenses inside the unit in the following cases:

• After starting to heat the room.

• In a damp room.

• If the unit is brought directly from a cold to a warm place.

Should this occur, the unit may malfunction. In this case, leave the unit turned on for a few hours until the moisture evaporates, unplug the AC power cord, then plug it in again.

Others

• Should any metallic object or liquid fall into the unit, unplug the AC power cord and consult your dealer before operating any further.

• If you are not going to operate the unit for an extended period of time, unplug the AC power cord from the wall outlet.

DO NOT disassemble the unit since there are no user serviceable parts inside.

Precautions

Installation

• Install in a place which is level, dry and neither too hot nor too cold—between 5˚C (41˚F) and 35˚C (95˚F).

• Install the unit in a location with adequate ventilation to prevent internal heat buildup.

• Leave sufficient distance between the unit and the TV.

• Keep the speakers away from the TV to avoid interference with TV.

DO NOT install the unit in a location near heat sources, or in a place subject to direct sunlight, excessive dust or vibration.

1

If anything goes wrong, unplug the AC power cord and consult your dealer.

Contents

Location of the Buttons and Controls ............................. 3

Main Unit .................................................................................. 3

Remote Control ......................................................................... 5

Getting Started .................................................................. 6

Unpacking ................................................................................. 6

Putting the Batteries into the Remote Control .......................... 6

Connections ............................................................................... 6

Basic and Common Operations ....................................... 8

Setting the Clock ....................................................................... 8

Turning On the Power ............................................................... 8

Selecting the Source .................................................................. 9

Adjusting the Volume ................................................................ 9

Selecting the Sound Modes ....................................................... 9

Reinforcing the Bass Sound ...................................................... 9

Listening to FM and AM Broadcasts............................. 10

Tuning in to a Station .............................................................. 10

Presetting Stations ................................................................... 11

Tuning in to a Preset Station ................................................... 11

Playing Back Discs .......................................................... 12

Playing Back the Entire Disc—Normal Play .......................... 12

Basic Disc Operations ............................................................. 13

Programming the Track Playing Order—Program Play.......... 13

Playing at Random—Random Play ......................................... 14

Repeating Tracks—Repeat Play .............................................. 14

Playing only Introductions—Intro Play .................................. 14

Displaying the Remaining Time during Playback................... 14

Playing Back Tapes .......................................................... 15

Playing Back a Tape ................................................................ 15

Recording ......................................................................... 16

Recording from the Radio ....................................................... 16

Recording Discs—Disc Synchronized Recording .................. 17

Using the Timers.............................................................. 18

Using the Daily Timer ............................................................. 18

Using the Sleep Timer ............................................................. 19

Maintenance..................................................................... 20

Troubleshooting ............................................................... 21

Specifications ................................................................... 22

2

Location of the Buttons and Controls

Become familiar with the buttons and controls on your unit.

Main Unit

Top view

1

Front view

2 3

4

9

p

q

w

PHONES

STANDBY/ON

TIMER ON/OFF

STANDBY

SOUND

/BASS

BAND

TAPE TUNER CD

COMPACT COMPONENT SYSTEM

CD SYNCHRO RECORDING

MULTI

CONTROL

OPEN

VOLUME

CD

CONTROL

5 6

7

8

e

r

Inside the front cover

3

OPEN

t

y

Display window on the front panel

Continued

12 3 4 56

ON OFF

1ALL PROG RANDOM INTRO TOTAL REMAIN

See pages in parentheses for details.

Main unit

1 Disc cover (12) 2 PHONES jack (9) 3 TIMER ON/OFF button (8, 19) 4 SOUND/BASS button (9) 5 0 OPEN (disc cover open) (12, 13) 6 Source buttons

• TAPE, TUNER/BAND, CD

Pressing one of these buttons also turns on the unit.

7 CD CONTROL buttons (8, 12, 13)

• #¥8, 7

8 MULTI CONTROL buttons

• ¡¥¢, 4¥1

9 Display window p STANDBY/ON button (8, 19) q STANDBY lamp (8) w Cassette holder (15) e VOLUME + / – buttons (9) r Remote sensor (5) t Front cover (15) y Tape operation buttons (15 – 17)

• ‡ (recording), # (play), ! (fast backward), ⁄ (fast forward), &/) (stop/cassette holder open), * (pause)

SLEEP ST MONO SOUND BASS

7

CD

SYNC

MHz kHz

e8

Display window

1 (timer) indicator 2 ON/OFF (timer on-time/off-time) indicators 3 SLEEP indicator 4 FM mode indicators

• ST (stereo), MONO

5 SOUND indicator 6 BASS indicator 7 CD SYNC (syncro) indicator 8 Main display

• Shows the source name and other information.

9 Repeat indicators

• , 1, ALL

p PROG (program) indicator q RANDOM indicator w INTRO indicator e Time indicators

• TOTAL, REMAIN

r Frequency indicators

• MHz, kHz

rwqp9

To open the front cover

4

Remote Control

See pages in parentheses for details.

TIMER

ON/OFF

RANDOM SLEEP

TUNER

/BAND

SOUND

/BASS

1 2 3

4

5

6

7

TIMER SET

INTRO

REMAIN

TAPE CD

BEAT CUT

DISPLAY

/CLOCK SET

MUTING

STANDBY/ON

REPEAT

ST/MONOPROGRAM

CD

VOLUME

9 p

q w

e

r

t

y

u

1 TIMER SET button (18, 19) 2 INTRO button (14) 3 RANDOM button (14) 4 REMAIN button (14) 5 BEAT CUT button (10, 16) 6 DISPLAY/CLOCK SET button (8) 7 MUTING button (9) 8 SOUND/BASS button (9) 9 STANDBY/ON button (8, 19) p TIMER ON/OFF button (19) q SLEEP button (19) w PROGRAM button (8, 11, 13, 18, 19) e REPEAT ST/MONO button (10, 14) r Source buttons

• TAPE, TUNER/BAND, CD

Pressing one of these buttons also turns on the unit.

t CD 3/8 button (12, 13) y Multi control buttons

• ,

• 4, 7, ¢

u VOLUME + / – buttons (9)

8

RM-SFSH10J REMOTE CONTROL

STANDBY/ON

STANDBY

COMPACT COMPONENT SYSTEM

CD SYNCHRO RECORDING

VOLUME

When using the remote control, point it at the remote sensor on the front panel.

5

Getting Started

Continued

Unpacking

After unpacking, check to be sure that you have all the following items. The number in parentheses indicates the quantity of each piece supplied.

• AM loop antenna (1)

• Remote control (1)

• Batteries (2)

If any item is missing, consult your dealer immediately.

Putting the Batteries into the Remote Control

Insert the batteries—R03(UM-4)/AAA(24F)—into the remote control by matching the polarity (+ and –) on the batteries with the + and – marking on the battery compartment. When the remote control can no longer operate the unit, replace both batteries at the same time.

1

Connections

To connect speakers

You can connect the speakers using the speaker cords.

1

Speaker cord

Black

L

R

SPEAKER

IMPEDANCE

Ω

4-16

Red

Black

2,3

Speaker cord

R03(UM-4)/ AAA(24F)

2

3

• DO NOT use an old battery together with a new one.

• DO NOT use different types of batteries together.

• DO NOT expose batteries to heat or flame.

• DO NOT leave the batteries in the battery compartment when you are not going to use the remote control for an extended period of time. Otherwise, the remote control will be damaged from battery leakage.

Right speaker Left speaker

1

Hold the clamp of the speaker terminal.

2

Insert the end of the speaker cord into the terminal.

Match the polarity of the speaker terminals: red (ª) to red (ª) and black (·) to black (·).

3

Release your finger from the clamp.

IMPORTANT:

• Use only speakers with the same speaker impedance as indicated by the speaker terminals on the rear of the unit.

• DO NOT connect more than one speaker to one speaker terminal.

6

To connect AM and FM antennas

NOW you are ready to plug in the unit.

2

FM antenna

FM

ANTENNA

AM

LOOP

1

AM loop antenna (supplied)

1

Connect the supplied AM loop antenna to the AM LOOP terminal.

Place the antenna away from the unit and adjust its position for the best reception.

IMPORTANT:

Be sure to check that all connections have been made before plugging in the power cord.

2

Adjust the position for the FM antenna for the best reception.

For better reception of both FM and AM

• Make sure the antenna conductors do not touch any other terminals or connecting cords.

• Keep the antennas away from metallic parts of the unit, connecting cords, and the AC power cord.

7

Basic and Common Operations

Continued

Setting the Clock

Before operating the unit any further, first set the unit’s clock. When you plug in the power cord, “AM12:00” starts flashing on the display. You can set the clock when the unit is either turned on or in standby mode.

• In the following procedure, the clock is set to 12-hour system.

On the remote control ONLY:

1

When the unit is in standby mode, press and hold PROGRAM until the hour indication starts flashing.

• When the unit is on, press DISPLAY/CLOCK SET to enter clock mode, then press and hold PROGRAM.

2

Press 4 or ¢ to adjust the hour, then press PROGRAM.

• When you press and hold 4 or ¢, the hour indication changes

continuously.

The minute indication start flashing.

PROGRAM

To select 12-hour or 24-hour clock system

You can select 12-hour or 24-hour for the clock system only while the unit is in standby mode.

On the unit ONLY:

To change the clock setting, press

TIMER ON/OFF while holding down 7.

• Each time you press TIMER ON/OFF, the clock change alternates between 12-hour and 24-hour system.

TIMER ON/OFF

To show the clock when the unit is turned on

CD

CONTROL

On the remote control ONLY:

Press DISPLAY/CLOCK SET.

• Each time you press the button, the display changes the clock indication and the normal indication alternately.

To change the clock

Repeat steps 1 to 3 of the procedure “Setting the Clock.”

DISPLAY

/CLOCK SET

Turning On the Power

3

Press 4 or ¢ to adjust

the minute, then press PROGRAM.

• When you press and hold 4 or ¢, the minute indication changes

continuously.

The built-in clock starts.

• When you unplug the AC power cord or if a power failure occurs

The clock is reset to “AM12:00” right away. If this happens, set the clock again.

• The clock may gain or lose 1 to 2 minutes per month

If this happens, reset the clock.

PROGRAM

To turn on the unit, press STANDBY/ON. The STANDBY lamp on the unit goes off.

• When you press the source button—TAPE, TUNER/BAND and CD, the unit automatically turns on.

To turn off the unit (standby), press STANDBY/ON again. The STANDBY lamp on the unit lights red.

• “AM12:00” flashes on the display until you set the built-in clock. After setting the clock, the clock time will appear on the display while the unit is on standby.

• A little power is always consumed even while the unit is in standby mode.

To switch off the power supply completely, unplug the AC power cord from the AC outlet.

When you unplug the AC power cord or if a power failure occurs

The clock is reset to “AM12:00” right away. If this happens, set the clock again.

STANDBY/ON

8

Selecting the Source

Selecting the Sound Modes

To select the source, press TAPE, TUNER/BAND, or CD.

TAPE CD

TUNER

/BAND

• When you select TAPE or CD as the source, playback does not start automatically.

To operate the tuner (FM or AM), see pages 10 and 11. To operate the CD player, see pages 12 – 14. To operate the tape deck, see page 15. To record on a tape, see pages 16 and 17.

Adjusting the Volume

You can adjust the volume level only while the unit is turned on. The volume level can be adjusted between “VOL MIN,”

“VOL 1” – “VOL 39,” and “VOL MAX.”

• The volume level has no effect on recording.

To increase the volume, press VOLUME +. To decrease the volume, press VOLUME –.

• When you press and hold either button, you can change the volume level continuously.

VOLUME

You can select one of the 4 sound modes.

• This function also affects the sound from headphones.

• This function only affects the playback sound, and does not

affect your recording.

To select the sound modes, press SOUND/BASS repeatedly.

SOUND

/BASS

• Each time you press the button, the sound mode changes as follows:

POP

FLAT

(Canceled)

CLASSIC

ROCK

JAZZ

POP: More presence in the vocals and midrange. CLASSIC: Enriched sound with fine treble and ample bass. ROCK: Powerful sound emphasizing treble and bass. JAZZ: Accented lower frequencies for jazz-type music. FLAT: Equalizer effect is canceled.

When the sound mode is activated, the SOUND indicator lights up on the display.

To turn off the sound temporarily

On the remote control ONLY:

Press MUTING.

The volume level turn down and “MUTING” starts flashing on the display.

To restore the sound, press MUTING again.

• Adjusting the volume level also cancels the muting.

For private listening

Connect a pair of headphones to the PHONES jack. No sound comes out of the speakers. Be sure to turn down the volume before connecting or putting on the headphones.

DO NOT turn off (standby) the unit with the volume set to an extremely high level; Otherwise, the sudden blast of sound can damage your hearing, speakers and/or headphones when you turn on the unit or start playing any source. REMEMBER you cannot adjust the volume level while the unit is in standby mode.

MUTING

Reinforcing the Bass Sound

The richness and fullness of the bass sound is clearly maintained regardless of how low you set the volume—Hyper Bass Sound.

• This function also affects the sound from headphones.

• This function only affects the playback sound, and does not

affect your recording.

To get the effect, press and hold SOUND/BASS until “HBS ON” appears and the BASS indicator lights up on the display.

• Each time you press and hold the button, the effect alternates on (“HBS ON”) and off (“HBS OFF”).

To cancel the effect, press and hold SOUND/BASS again until “HBS OFF” appears and the BASS indicator goes off.

SOUND

/BASS

9

Listening to FM and AM Broadcasts

Tuning in to a Station

1

Press TUNER/BAND to select either “FM” or “AM.”

The unit automatically turns on and tunes in to the previously received station—either FM or AM.

• Each time you press the button, the band alternates between FM and AM.

2

Press and hold ¢ or 4 (or ¡/¢ or 4/1 on the unit) for more than 1 second.

• ¢ (¡/¢): Increases the frequencies.

• 4 (4/1): Decreases the frequencies.

The unit starts searching for stations and stops when a station of sufficient signal strength is tuned in.

• If an FM program is broadcast in stereo, the ST (stereo) indicator lights up on the display (only when the reception is good).

TUNER

/BAND

To change the FM reception mode

On the remote control ONLY:

When an FM stereo broadcast is hard to receive or noisy, press REPEAT ST/MONO so that the

MONO indicator lights up on the display. Reception will improve.

To restore the stereo effect, press REPEAT ST/MONO again so that the MONO indicator goes off. In stereo mode, you can hear stereo sound when a stereo program is broadcast.

To reduce the beat—Beat Cut

REPEAT

ST/MONO

On the remote control ONLY:

If the beats are heard while listening a broadcast, press BEAT CUT.

BEAT CUT

To stop during searching, press ¢ or 4 (or ¡/¢ or 4/1 on the unit).

When you repeatedly press ¢ or 4 (or ¡/¢ or 4/1 on the unit)

The frequency changes step by step.

10

Presetting Stations

Tuning in to a Preset Station

You can preset 20 FM and 20 AM stations manually.

In some cases, test frequencies have been already stored for the tuner since the factory examined the tuner preset function before shipment. This is not a malfunction. You can preset the stations you want into memory by following the presetting method.

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start again from step 2.

On the remote control ONLY:

1

Tune in to the station you want to preset.

• See “Tuning in to a Station” on page 10.

2

Press PROGRAM.

The PROG (program) indicator and “00” start flashing on the display.

3

Press or to select a preset

PROGRAM

number.

On the remote control ONLY:

1

Press TUNER/BAND to select either “FM” or “AM.”

The unit automatically turns on and tunes in to the previously received station—either FM or AM.

• Each time you press the button, the band alternates between FM and AM.

2

Press or to select a preset number.

TUNER

/BAND

4

Press PROGRAM again.

The PROG indicator and the selected preset number stop flashing.

5

To preset more stations, repeat steps 1 to

PROGRAM

4

above, allocating a different preset number to each station.

• Storing a new station on an already assigned number erases the previously stored one.

When you unplug the AC power cord or if a power failure occurs

The preset stations will remain in the unit.

11

Playing Back Discs

Continued

This unit has been designed to play back the following discs—CD, CD-R, and CD-RW.

When playing a CD-R or CD-RW

User-edited CD-Rs (CD-Recordable) and CD-RWs (CDReWritable) can be played only if they are already “finalized.”

• Usually you can play back your original CD-Rs or CDRWs recorded in music CD format. However, sometimes they may not play depending on their characteristics or recording conditions.

• Before playing CD-Rs or CD-RWs, read their instructions or cautions carefully.

• Some CD-Rs or CD-RWs may not play on this unit because of their disc characteristics, damage or stain on them, or if the player’s lens is dirty.

• CD-RWs may require a longer readout time. This is because the reflectance of CD-RWs is lower than for regular discs.

General notes

In general, you will have the best performance by keeping your discs and the mechanism clean.

• Store discs in their cases, and keep them in cabinets or on shelves.

• Keep the unit’s disc trays closed when not in use.

4

Press CD.

The unit automatically turns on and the source changes to the CD player. After loading the disc, total track number and total playing time appear on the display.

Total track number Total playing time

5

Press CD 3/8.

The first track of the disc starts playing.

Current track number

Elapsed playing time

• The disc automatically stops when the last track has finished playing.

CD

Continued use of irregular shape discs (heart-shape, octagonal, etc.) can damage the unit.

Playing Back the Entire Disc—Normal Play

1

Press 0 OPEN on the unit.

The disc cover opens.

• You can insert a disc while listening to another source.

2

Place a disc correctly with its label side up.

Good Not good

3

Close the disc cover gently.

To stop playing, press 7.

To remove the disc, press 0 OPEN on the unit.

• If the disc cannot be read correctly (because it is scratched, for example) or an unreadable CD-R or CD-RW is inserted

Playback will not start.

• If no disc is inserted “NO DISC” appears on the display.

DO NOT try to open the disc cover by hand as it will be damaged.

12

Basic Disc Operations

While playing a disc, you can do the following operations.

To stop playing for a moment

During play, press CD 3/8. While pausing, the elapsed playing time flashes on the display.

To resume playing, press CD 3/8 again.

To go to another track

Before or during play, press ¢ or 4 repeatedly.

• ¢ : Skips to the beginning of the

next or succeeding tracks.

• 4 : Goes back to the beginning of the current or previous

tracks.

To locate a particular point in a track

During play, press and hold ¢ or

4.

• ¢ : Fast-forwards the tracks.

• 4 : Fast-reverses the tracks.

CD

3

Press ¢ or 4 to select the track number, then press PROGRAM.

Track number

4

Repeat step 3 to program other tracks you

Program step number

PROGRAM

want.

5

Press CD 3/8.

The tracks are played in the order you have programed.

If you try to program a 61st track

“FULL” will appear on the display.

To stop playing, press 7.

CD

Programming the Track Playing Order —Program Play

You can arrange the order in which tracks play before you start playing. You can program up to 60 tracks.

On the remote control ONLY:

1

Place a disc.

• If the current source is not the CD player, press CD.

2

Press PROGRAM.

The PROG (program) indicator starts flashing on the display.

• If a program has been stored in memory, the program is called up.

PROGRAM

To check the program contents

Press PROGRAM repeatedly in stop mode. The program number and track number are displayed in succession.

To modify the program

Press PROGRAM repeatedly in stop mode to select the number which you want to change the track, then repeat step 3 above.

To clear the program

Press 7 in stop mode. The PROG indicator disappears from the display.

• Pressing 0 OPEN to open the disc cover will also

erase the programed tracks.

PROGRAM

13

Playing at Random—Random Play

Playing only Introductions—Intro Play

You can play the tracks at random.

On the remote control ONLY: Press RANDOM before or during

RANDOM

playing.

The RANDOM indicator lights up on the display.

To exit from Random Play, press RANDOM again.

RANDOM

The RANDOM indicator goes off.

• It is not possible to activate the random play function during Program Play.

Repeating Tracks—Repeat Play

You can have all the tracks, the program or individual track currently playing, repeat as many times as you like.

On the remote control ONLY:

Press REPEAT ST/MONO repeatedly before or during playing.

• Each time you press the button, Repeat Play changes as follows, and the following repeat indicator lights up on the display:

ALL

Canceled

1

REPEAT

ST/MONO

You can play only the introductions of the tracks.

On the remote control ONLY:

Press INTRO.

The INTRO indicator lights up and the first 10- second portion of each track is played back in order.

To cancel Intro Play, press INTRO again. The INTRO indicator goes off.

• Intro Play remains in effect even when you select another play mode (Program or Random Play).

INTRO

Displaying the Remaining Time during Playback

You can display the remaining time of the current track/disc and the elapsed time of the current track/disc during playing.

On the remote control ONLY:

Press REMAIN repeatedly.

• Each time you press the button, the display changes as follows, and the following indicators light up on the display:

REMAIN TOTAL REMAIN

No indication

TOTAL

REMAIN

Repeat indicators

ALL: In Normal Play, repeats all the tracks.

In Program Play, repeats all the tracks in the program. In Random Play, repeats all the tracks in random order.

1: Repeats one track.

To cancel Repeat Play, press REPEAT ST/MONO repeatedly until the repeat indicator goes off.

• Repeat Play remains in effect even when you select another play mode (Normal, Program, Random, or Intro Play).

• In Random Play, 1 cannot be selected. If 1 has been selected when you press RANDOM, it is canceled.

• If you select 1 in Random Play, Random Play is canceled.

REPEAT

ST/MONO

REMAIN: Shows the remaining time of the current

track.

TOTAL REMAIN: Shows the remaining time and track

number of the disc.

TOTAL: Shows the elapsed time of the disc. No indication: Shows the elapsed time of the current

track.

14

Playing Back Tapes

For Tape operations, use buttons inside the front cover on the unit.

Playing Back a Tape

You can play back type I tapes only.

On the unit ONLY:

1

Open the front cover.

2

Press &/) (stop/cassette holder open).

The cassette holder opens.

4

Close the cassette holder gently.

5

Press TAPE.

The unit automatically turns on and the source changes to the tape deck.

• You can select to the tape by pressing TAPE on the remote control.

6

Press # (play).

The tape starts playing.

• When the end of the tape is reached, playing stops.

To stop playing, press &/).

TAPE

3

Put a cassette in with the exposed part of the tape down.

To stop playing for a moment, press * (pause).

To resume playing, press * again.

To fast forward or rewind the tape, press ⁄ or !.

• The tape stops at the end of the fast forwarding or rewinding. To release the locked button, press &/).

To remove the cassette, press &/) while playback is stopped.

• DO NOT turn off the unit while playing back or recording a tape.The cassette deck or tapes may be damaged.

• The use of C-120 or longer tape is not recommended, since characteristic deterioration may occur and this tape easily jams in the pinch rollers and the capstans.

• This unit is not compatible with type II and type IV tapes.

15

Recording

Continued

IMPORTANT:

• It should be noted that it may be unlawful to re-record pre-recorded tapes, records, or discs without the consent of the owner of copyright in the sound or video recording, broadcast or cable program and in any literary, dramatic, musical, or artistic embodied therein.

• The recording level is automatically set correctly, so it is not affected by the other sound settings. Thus, during recording you can adjust the sound you are actually listening to without affecting the recording level.

• If recordings you have made have excessive noise or static, the unit may be too close to a TV. Increase the distance between the TV and the unit.

• You can only use type I tape for recording.

• DO NOT turn off the unit while playing back or recording a tape.The cassette deck or tapes may be damaged.

• DO NOT use type II and type IV tapes since the unit is not compatible with such tapes.

• The use of C-120 or longer tape is not recommended, since characteristic deterioration may occur and this tape easily jams in the pinch rollers and the capstans.

Recording from the Radio

On the unit ONLY:

1

Put a recordable cassette in with the exposed part of the tape down.

• See also page 15.

2

Close the cassette holder gently.

3

Press TUNER/BAND to select either “FM” or “AM.”

• When recording from discs, see “Recording Discs—Disc Synchronized Recording” on page 17.

4

Tune in to the station you want to record.

5

Press ‡ (recording).

‡ and # lock down, and the recording starts.

BAND

TUNER

At the start and end of cassette tapes

There is leader tape which cannot be recorded onto. Thus, when recording from discs, FM/AM broadcasts, or external equipment, wind the leader tape first to ensure that the recording will be made without losing any music.

To protect your recordings

Cassettes have two small tabs on the back to protect against unexpected erasure or re-recording. To protect your recording, remove these tabs. To re-record on a protected tape, cover the holes with adhesive tape.

Adhesive tape

You cannot press ‡ in the following cases:

• If no cassette is inserted.

• If a protected tape is inserted.

To stop recording for a moment, press * (pause). To resume recording, press * again.

To stop recording, press &/).

To remove the cassette, press &/) while

recording is stopped.

To record an AM station—Beat Cut

On the remote control ONLY:

While recording an AM broadcast, beats may be heard (which are never heard when listening to the broadcast without recording it). If this occurs, press BEAT CUT repeatedly, while recording, until the beats are reduced.

• Each time you press the button, the display changes alternates “BEAT 01” and “BEAT 02.”

BEAT CUT

16

Recording Discs —Disc Synchronized Recording

You can start disc play and recording at the same time.

On the unit ONLY:

1

Put a recordable cassette in with the exposed part of the tape down.

• See also page 15.

2

Close the cassette holder gently.

3

Press CD select the CD player as the source.

4

Press ‡ (recording).

The CD SYNC indicator appears on the display and the CD starts playback automatically and the recording starts.

CD

• When the end of the tape is reached, recording stops and the CD player is paused.

• If you press ‡ while playing back the CD, the CD player

return to the beginning of that track and the track is recorded on the tape.

You cannot press ‡ in the following cases:

• If no cassette is inserted.

• If a protected tape is inserted.

To stop recording for a moment, press *. The recording is paused, but the CD playback does not stop. To resume recording, press * again.

To stop recording, press &/). The recording stops and the CD playback is paused.

To remove the cassette, press &/) while recording is stopped.

17

Using the Timers

Continued

Daily Timer and Sleep Timer are available.

• Before using these timers, make sure the built-in clock is set correctly (see page 8).

Using the Daily Timer

You can set the Daily Timer when the unit is either turned on or in standby mode.

How the Daily Timer actually works

When the on-time comes, the unit automatically turns on and then the off-time comes, the unit automatically turns off (standby).

• Once the timer has been set, it will be activated at the same time everyday until the timer is turned off and the timer setting remains in memory until you change it.

Before you start...

When using “TUNER” as the source to play, make sure to select the desired station before turning off the power.

• In the following procedure, the clock is set to 12-hour system.

• There is a time limit in doing the following steps. If the setting is canceled before you finish, start again from step 1.

On the remote control ONLY:

3

Press TIMER SET.

The (timer) and the OFF (off-time) indicators flash and the off-time setting appears on the display. If you does not need to change the off-time setting, go to step 5.

• If you change the on-time setting, the off-time setting changes to “– –:– –.” You need to set the off-time setting.

4

Press PROGRAM to set the off-time you want the unit to turn off.

The hour indication starts flashing on the display.

1) Press ¢ or 4 to set the

hour, then press PROGRAM.

2) Press ¢ or 4 to set the

minute, then press PROGRAM.

TIMER SET

PROGRAM

1

Press TIMER SET.

The (timer) and the ON (on-time) indicators flash and the on-time setting appears on the display. If you does not need to change the on-time setting, go to step 3.

2

Press PROGRAM to set the on-time you want the unit to turn on.

The hour indication starts flashing on the display.

1) Press ¢ or 4 to set the hour, then press PROGRAM.

2) Press ¢ or 4 to set the minute, then press PROGRAM.

TIMER SET

PROGRAM

5

Press TIMER SET.

The (timer) indicator flashes and the source name appears on the display. If you does not need to change the source, go to step 7.

6

Press PROGRAM to select the source to play.

The source name starts flashing on the display.

• Press ¢ or 4 to select “CD” or “TUNER,” then press PROGRAM.

TIMER SET

PROGRAM

18

7

Press TIMER SET.

The display changes normal indication and exit the timer setting mode.

8

Press TIMER ON/OFF to activate the daily timer mode.

Each time you press the button, the Daily Timer alternates on and off. While activating the Daily Timer, the (timer) indicator lights up on the display.

• You can active the Daily Timer by pressing TIMER ON/OFF on the unit.

9

Press STANDBY/ON to turn off the unit if the unit is on.

TIMER SET

TIMER

ON/OFF

Using the Sleep Timer

With the Sleep Timer, you can fall asleep to your favorite music or radio program.

• You can set the Sleep Timer only when the unit is turned on.

How the Sleep Timer actually works

The unit automatically turns off after the specified length of time passes.

On the remote control ONLY:

1

Press SLEEP.

The SLEEP indicator lights up on the display.

SLEEP

To deactivate the timer temporarily, press TIMER ON/OFF until the (timer) indicator goes off.

To activate and change the timer, repeat steps 1 to 8 on pages 18 and 19.

• To activate the timer again without changing the setting, press TIMER ON/OFF until the (timer) indicator lights up on the display.

If the unit is already turned on when the timer on-time comes

The timer does not works.

When you unplug the AC power cord or if a power failure occurs

The timer will be canceled. You need to set the clock first, then set the timer again.

TIMER

ON/OFF

• Each time you press the button, the length of time changes as follows:

90

801070 60 50

OFF

2

Wait for about 5 seconds after specifying the

20 30 40

length of time.

To check the remaining time until shut-off time, press

SLEEP once. The remaining time until shut-off time appeears for about 5 seconds.

To change the shut-off time, press SLEEP repeatedly until the length of time you want appears.

To cancel the setting, press SLEEP repeatedly until “OFF” appears and the SLEEP indicator goes off on the display.

• Turning off the unit also cancels the Sleep Timer.

19

If you set the Sleep Timer after the Daily Timer starts playing the selected source

The Daily timer is canceled. The unit turns off when the Sleep Timer shut-off time comes.

If you set the Sleep Timer while playing back or recording a tape

Do not shut the unit off with the Sleep Timer while a tape is running. If the unit turns off while playing back or recording a tape, the cassette deck or tapes may be damaged.

Maintenance

To get the best performance of the unit, keep your discs, tapes and mechanism clean.

General Notes

In general, you will have the best performance by keeping your discs, tapes and the mechanism clean.

• Store discs and tapes in their cases, and keep them in cabinets or on shelves.

Cleaning the unit

• Stains on the unit

Should be wiped off with a soft cloth. If the unit is heavily stained, wipe it with a cloth soaked in water-diluted neutral detergent and wrung well, then wipe clean with a dry cloth.

• Since the unit may deteriorate in quality, become damaged or have its paint peel off, be careful about the following:

– DO NOT wipe it with a rough cloth. – DO NOT wipe it too vigorously. – DO NOT wipe it with thinner or benzine. – DO NOT apply any volatile substance such as an

insecticide to it.

– DO NOT allow any rubber or plastic to remain in contact

with it for a long time.

Handling discs

• Remove the disc from its case by holding it at the edge while pressing the center hole lightly.

• Do not touch the shiny surface of the disc, or bend the disc.

• Put the disc back in its case after use to prevent warping.

• Be careful not to scratch the surface of the disc when placing it back in its case.

• Avoid exposure to direct sunlight, temperature extremes, and moisture.

Handling cassette tapes

• If the tape is loose in its cassette, take up the slack by inserting a pencil in one of the reels and rotating.

• If the tape is loose, it may get stretched, cut, or caught in the cassette.

• Be careful not to touch the tape surface.

• Avoid storing tapes in any of the following places: – In dusty places – In direct sunlight or heat – In moist areas – On a TV or speaker – Near a magnet

To keep the best recording and playback sound quality

You need to clean the heads.

• Clean the heads after every 10 hours of use with a wet-type head cleaning tape (available at electronic and audio shops). When the head becomes dirty, the following symptoms will occur: – Sound quality is reduced. – Sound level decreases. – Sound drops out.

• Do not play dirty or dusty tapes.

• Do not touch the highly-polished head with any metallic or magnetic tools.

Capstan

To clean the disc

Wipe the disc with a soft cloth in a straight line from center to edge.

DO NOT use any solvent—such as conventional record cleaner, spray, thinner, or benzine—to clean the disc.

Head

Pinch Roller

To demagnetize the head

Turn off the unit, and use a head demagnetizer (available at electronic and audio shops).

20

Troubleshooting

If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service.

Symptom

Power does not come on.

No sound is heard.

Hard to listen to broadcasts because of noise.

The disc does not play.

Impossible to record.

Operations are disabled.

Unable to operate the unit by the remote control.

Possible Cause

The power cord is not connected to an AC outlet.

• Connections are incorrect or loose.

• A pair of headphones is connected.

• Antennas are disconnected.

• The AM loop antenna is too close to

the unit.

• The FM antenna is not properly extended and positioned.

The disc is upside down.

Small tabs on the back of the cassette are removed.

The built-in microprocessor has malfunctioned due to external electrical interference.

• The path between the remote control and the remote sensor on the unit is blocked.

• The batteries are exhausted.

• You are using the remote control too

far from the unit.

Action

Insert the plug into the socket.

• Check all connections and make corrections. (See pages 6 and 7.)

• Unplug the headphones from the PHONES jack.

• Reconnect the antenna correctly and securely.

• Change the position and direction of the AM loop antenna.

• Extend FM antenna and orient to the best reception position.

Put the disc in with the label side up.

Cover the holes with adhesive tape.

Unplug the AC power cord then plug it back in.

• Remove the obstruction.

• Replace the batteries. (See page 6.)

• Signals cannot reach the remote

sensor. Move closer to the unit.

21

Specifications

Design and specifications are subject to change without notice.

Amplifier Section—CA-FSH10

Output Power:

5 W per channel, min. RMS, driven into 4 Ω at 1 kHz with no more than 10% total harmonic distortion.

Speakers/Impedance: 4 Ω – 16 Ω

Tuner

FM tuning range: 87.5 MHz—108.0 MHz AM tuning range: 530 kHz—1 710 kHz

CD player

Dynamic range: 60 dB Signal-to-noise ratio: 60 dB Wow and flutter: Immeasurable

Cassette deck

Frequency response:

Normal (type I): 100 Hz—10 000 Hz

Wow and flutter: 0.35 % (WRMS)

General

Power requirement: AC 120 V , 60 Hz Power consumption: 22 W (at operation)

4.5 W (on standby)

Dimensions (W/H/D) (approx.):

145 mm x 209 mm x 226 mm (5 3/4 in. x 8 1/4 in. x 8 15/16 in.)

Mass (approx.): 2.6 kg (5.8 lbs)

Supplied accessories

See page 6.

Speaker Section—SP-FSH10

Type: Full range bass-reflex type Speakers: 10 cm cone x1 Power handling capacity: 5 W Impedance: 4 Ω Frequency range: 100 Hz to 15 kHz Dimensions (W/H/D) (approx.):

135 mm x 209 mm x 152 mm

(5 2/8 in. x 8 1/4 in. x 6 in.)

Mass (approx.): 1.3 kg (2.9 lbs) each

22

LIMITED WARRANTY

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period as shown below. ("The Warranty Period")

PARTS LABOR

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts thereof may be brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen size 25 inches and above which are covered on an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized service center, please call toll free: (800) 537-5722.

If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with a copy of your bill of sale plus a letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location of which will be given to you by the toll-free number.

If you have any questions concerning your JVC Product, please contact our Customer Relations Department.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by JVC to render such service, or if affixed to any attachment not provided with the products, or if the model number or serial number has been altered, tampered with, defaced or removed;

2. Initial installation and installation and removal for repair;

3. Operational adjustments covered in the Owner's Manual, normal maintenance, video and audio head cleaning;

4. Damage that occurs in shipment, due to act of God, and cosmetic damage;

5. Signal reception problems and failures due to line power surge;

6. Video Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus (Needle) are covered for 90 days from the date of purchase;

7. Accessories

8. Batteries (except that Rechargeable Batteries are covered for 90 days from the date of purchase);

There are no express warranties except as listed above.

THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.

JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE TO TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

1

YR

1

YR

AUDIO-1

JVC COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF REFURBISHED PRODUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY INFORMATION PACKAGED WITH EACH REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. which is located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No. : Serial No. :

Purchase data : Name of dealer :

1700 Valley Road Wayne, NJ 07470

Authorized Service Centers

®

QUALITY SERVICE

HOW TO LOCATE YOUR JVC SERVICE CENTER

TOLL FREE: 1 (800) 537-5722

http://www.jvc.com

Dear Customer, In order to receive the most satisfaction from your purchase,please read the instruction booklet before operating the unit.In the event that repairs are necessary, please call 1 (800)537-5722 for your nearest authorized servicer or visit our website at www.JVC.com Remember to retain your Bill of Sale for Warranty Service.

Do not service the television yourself

Caution

To prevent electrical shock,do not open the cabinet.There are no user serviceable parts inside.Please refer to qualified service personnel for repairs.

Accessories

To purchase accessories for your JVC product,please call toll free:1 (800)882-2345 or on the web at www.JVC.com

BT-51001-5 (0301)

VICTOR COMPANY OF JAPAN, LIMITED

EN

0603MWMMDWORI

JVC

COMPACT COMPONENT SYSTEM

SYSTEME DE COMPOSANTS COMPACT

English

Français

FS-H10

TIMER

TIMER SET

STANDBY/ON

ON/OFF

RANDOM SLEEP

INTRO

REPEAT

REMAIN

ST/MONOPROGRAM

TUNER

TAPE CD

/BAND

CD

BEAT CUT

DISPLAY

/CLOCK SET

SOUND

VOLUME

MUTING

/BASS

RM-SFSH10J REMOTE CONTROL

—Consists of CA-FSH10 and SP-FSH10

STANDBY/ON

STANDBY

COMPACT COMPONENT SYSTEM

FS-H10

CD SYNCHRO RECORDING

VOLUME

OPEN

MANUEL D’INSTRUCTIONS

INSTRUCTIONS

For Customer Use:

Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No.

Seri al No.

LVT1092-002A

[C]

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated

dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

CAUTION— STANDBY/ON button!

Disconnect the mains plug to shut the power off completely (all lamps and indications go off). The STANDBY/ON button in any position does not disconnect the mains line.

• When the unit is on standby, the STANDBY lamp lights red.

• When the unit is turned on, the STANDBY lamp goes off.

The power can be remote controlled.

ATTENTION—Touche STANDBY/ON

Déconnectez la fiche secteur pour mettre l’appareil complètement hors tension (tous les témoins et toutes les indications s’éteignent). La touche STANDBY/ON dans n’importe quelle position ne déconnecte pas l’appareil du secteur.

• Quand l’appareil est en mode d’attente, le témoin STANDBY est allumé en rouge.

• Quand l’appareil est sous tension, le témoin STANDBY s’éteint.

L’alimentation ne peut pas être commandée à distance.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret

de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

G-1

15 cm

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND.

For Canada/pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS. CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR: “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

CAUTION: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front:

No obstructions and open spacing.

2 Sides/ Top/ Back:

No obstructions should be placed in the areas shown by the dimensions below.

3 Bottom:

Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.

ATTENTION: Aération correcte

Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez l’appareil de la manière suivante: 1 Avant:

Bien dégagé de tout objet.

2 Côtés/dessus/dessous:

Assurez-vous que rien ne bloque les espaces indiqués sur le schéma ci-dessous.

3 Dessous:

Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation correcte puisse se faire en le plaçant sur un support d’au moins dix centimètres de hauteur.

Front view Face

15 cm

1 cm

FS-H10

1 cm

Side view Côté

15 cm

FS-H10

10 cm

G-2

Introduction

English

We would like to thank you for purchasing one of our JVC products.

Before operating this unit, read this manual carefully and thoroughly to

obtain the best possible performance from your unit, and retain this manual

for future reference.

About This Manual

This manual is organized as follows:

• This manual mainly explains operations using the buttons on the remote control. You can use the buttons both on the remote control and on the unit for the same operations if they have the same or similar names (or marks), unless mentioned otherwise.

• Basic and common information that is the same for many functions is grouped in one place, and is not repeated for each procedure. For instance, we do not repeat the information about turning on/off the unit, setting the volume, changing the sound effects, and others, which are explained in the section “Basic and Common Operations” on pages 8 and 9.

• The following symbols are used in this manual:

Gives you warning and caution to prevent damage or risk of fire/electric shock. In addition, we put information here about conditions which will prevent getting the best possible performance from the unit.

Gives you information and hints you need to know.

Power sources

• When unplugging the unit from the wall outlet, always pull on the plug, not the AC power cord.

DO NOT handle the AC power cord with wet hands.

Moisture condensation

Moisture may condense on the lenses inside the unit in the following cases:

• After starting to heat the room.

• In a damp room.

• If the unit is brought directly from a cold to a warm place.

Should this occur, the unit may malfunction. In this case, leave the unit turned on for a few hours until the moisture evaporates, unplug the AC power cord, then plug it in again.

Others

• Should any metallic object or liquid fall into the unit, unplug the AC power cord and consult your dealer before operating any further.

• If you are not going to operate the unit for an extended period of time, unplug the AC power cord from the wall outlet.

DO NOT disassemble the unit since there are no user serviceable parts inside.

Precautions

Installation

• Install in a place which is level, dry and neither too hot nor too cold—between 5˚C and 35˚C.

• Install the unit in a location with adequate ventilation to prevent internal heat buildup.

• Leave sufficient distance between the unit and the TV.

• Keep the speakers away from the TV to avoid interference with TV.

DO NOT install the unit in a location near heat sources, or in a place subject to direct sunlight, excessive dust or vibration.

1

If anything goes wrong, unplug the AC power cord and consult your dealer.
