JVC FS-H10 User Manual
COMPACT COMPONENT SYSTEM
FS-H10
TIMER
TIMER SET
STANDBY/ON
ON/OFF
RANDOM SLEEP
INTRO
REPEAT
REMAIN
ST/MONOPROGRAM
TUNER
TAPE CD
/BAND
CD
BEAT CUT
DISPLAY
/CLOCK SET
SOUND
VOLUME
MUTING
/BASS
RM-SFSH10J REMOTE CONTROL
—Consists of CA-FSH10 and SP-FSH10
STANDBY/ON
STANDBY
COMPACT COMPONENT SYSTEM
CD SYNCHRO RECORDING
FS-H10
VOLUME
OPEN
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1092-001A
[J]
Warnings, Cautions and Others
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
For U.S.A.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
G-1
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION— STANDBY/ON button!
Disconnect the mains plug to shut the power off completely (all
lamps and indications go off). The STANDBY/ON button in
any position does not disconnect the mains line.
• When the unit is on standby, the STANDBY lamp lights red.
• When the unit is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
15 cm
15 cm
For Canada/pour le Canada
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQUAU FOND.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED THE
CLASS B LIMITS FOR RADIO NOISE EMISSIONS FROM
DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED
“DIGITAL APPARATUS,” ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE
BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMERIQUES DE CLASSE B PRESCRITES
DANS LA NORME SUR LE MATERIEL BROUILLEUR:
“APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
CAUTION: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1 Front:
No obstructions and open spacing.
2 Sides/ Top/ Back:
No obstructions should be placed in the areas shown by the dimensions below.
3 Bottom:
Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.
Front view
15 cm
1 cm
15 cm
1 cm
15 cm
Side view
FS-H10
10 cm
FS-H10
G-2
Introduction
We would like to thank you for purchasing one of our JVC products.
Before operating this unit, read this manual carefully and thoroughly to
obtain the best possible performance from your unit, and retain this manual
for future reference.
About This Manual
This manual is organized as follows:
• This manual mainly explains operations using the
buttons on the remote control.
You can use the buttons both on the remote control and
on the unit for the same operations if they have the
same or similar names (or marks), unless mentioned
otherwise.
• Basic and common information that is the same for many
functions is grouped in one place, and is not repeated for
each procedure. For instance, we do not repeat the
information about turning on/off the unit, setting the
volume, changing the sound effects, and others, which are
explained in the section “Basic and Common Operations”
on pages 8 and 9.
• The following symbols are used in this manual:
Gives you warning and caution to prevent
damage or risk of fire/electric shock.
In addition, we put information here about
conditions which will prevent getting the best
possible performance from the unit.
Gives you information and hints you need to
know.
Power sources
• When unplugging the unit from the wall outlet, always pull
on the plug, not the AC power cord.
DO NOT handle the AC power cord with wet
hands.
Moisture condensation
Moisture may condense on the lenses inside the unit in the
following cases:
• After starting to heat the room.
• In a damp room.
• If the unit is brought directly from a cold to a warm place.
Should this occur, the unit may malfunction. In this case,
leave the unit turned on for a few hours until the moisture
evaporates, unplug the AC power cord, then plug it in again.
Others
• Should any metallic object or liquid fall into the unit,
unplug the AC power cord and consult your dealer before
operating any further.
• If you are not going to operate the unit for an extended
period of time, unplug the AC power cord from the wall
outlet.
DO NOT disassemble the unit since there are no
user serviceable parts inside.
Precautions
Installation
• Install in a place which is level, dry and neither too hot nor
too cold—between 5˚C (41˚F) and 35˚C (95˚F).
• Install the unit in a location with adequate ventilation to
prevent internal heat buildup.
• Leave sufficient distance between the unit and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
DO NOT install the unit in a location near heat
sources, or in a place subject to direct sunlight,
excessive dust or vibration.
1
If anything goes wrong, unplug the AC power cord and
consult your dealer.
Contents
Location of the Buttons and Controls ............................. 3
Main Unit .................................................................................. 3
Remote Control ......................................................................... 5
Getting Started .................................................................. 6
Unpacking ................................................................................. 6
Putting the Batteries into the Remote Control .......................... 6
Connections ............................................................................... 6
Basic and Common Operations ....................................... 8
Setting the Clock ....................................................................... 8
Turning On the Power ............................................................... 8
Selecting the Source .................................................................. 9
Adjusting the Volume ................................................................ 9
Selecting the Sound Modes ....................................................... 9
Reinforcing the Bass Sound ...................................................... 9
Listening to FM and AM Broadcasts............................. 10
Tuning in to a Station .............................................................. 10
Presetting Stations ................................................................... 11
Tuning in to a Preset Station ................................................... 11
Playing Back Discs .......................................................... 12
Playing Back the Entire Disc—Normal Play .......................... 12
Basic Disc Operations ............................................................. 13
Programming the Track Playing Order—Program Play.......... 13
Playing at Random—Random Play ......................................... 14
Repeating Tracks—Repeat Play .............................................. 14
Playing only Introductions—Intro Play .................................. 14
Displaying the Remaining Time during Playback................... 14
Playing Back Tapes .......................................................... 15
Playing Back a Tape ................................................................ 15
Recording ......................................................................... 16
Recording from the Radio ....................................................... 16
Recording Discs—Disc Synchronized Recording .................. 17
Using the Timers.............................................................. 18
Using the Daily Timer ............................................................. 18
Using the Sleep Timer ............................................................. 19
Maintenance..................................................................... 20
Troubleshooting ............................................................... 21
Specifications ................................................................... 22
2
Location of the Buttons and Controls
Become familiar with the buttons and controls on your unit.
Main Unit
Top view
1
Front view
2
3
4
9
p
q
w
PHONES
STANDBY/ON
TIMER ON/OFF
STANDBY
SOUND
/BASS
TAPE TUNER CD
COMPACT COMPONENT SYSTEM
BAND
MULTI
CONTROL
OPEN
VOLUME
CD
CONTROL
5
6
7
8
e
r
CD SYNCHRO RECORDING
OPEN
t
Inside the front cover
y
3
Display window on the front panel
Continued
12 3 4 56
ON OFF
1ALL PROG RANDOM INTRO TOTAL REMAIN
See pages in parentheses for details.
Main unit
1 Disc cover (12)
2 PHONES jack (9)
3 TIMER ON/OFF button (8, 19)
4 SOUND/BASS button (9)
5 0 OPEN (disc cover open) (12, 13)
6 Source buttons
• TAPE, TUNER/BAND, CD
Pressing one of these buttons also turns on the unit.
7 CD CONTROL buttons (8, 12, 13)
• #¥8, 7
8 MULTI CONTROL buttons
• ¡¥¢, 4¥1
9 Display window
p STANDBY/ON button (8, 19)
q STANDBY lamp (8)
w Cassette holder (15)
e VOLUME + / – buttons (9)
r Remote sensor (5)
t Front cover (15)
y Tape operation buttons (15 – 17)
• ‡ (recording), # (play), ! (fast backward),
⁄ (fast forward), &/) (stop/cassette holder open),
* (pause)
SLEEP ST MONO SOUND BASS
7
CD
SYNC
MHz
kHz
e8
Display window
1 (timer) indicator
2 ON/OFF (timer on-time/off-time) indicators
3 SLEEP indicator
4 FM mode indicators
• ST (stereo), MONO
5 SOUND indicator
6 BASS indicator
7 CD SYNC (syncro) indicator
8 Main display
• Shows the source name and other information.
9 Repeat indicators
• , 1, ALL
p PROG (program) indicator
q RANDOM indicator
w INTRO indicator
e Time indicators
• TOTAL, REMAIN
r Frequency indicators
• MHz, kHz
rwqp9
To open the front cover
4
Remote Control
See pages in parentheses for details.
TIMER
ON/OFF
RANDOM SLEEP
TUNER
/BAND
SOUND
/BASS
1
2
3
4
5
6
7
TIMER SET
INTRO
REMAIN
TAPE CD
BEAT CUT
DISPLAY
/CLOCK SET
MUTING
STANDBY/ON
REPEAT
ST/MONOPROGRAM
CD
VOLUME
9
p
q
w
e
r
t
y
u
1 TIMER SET button (18, 19)
2 INTRO button (14)
3 RANDOM button (14)
4 REMAIN button (14)
5 BEAT CUT button (10, 16)
6 DISPLAY/CLOCK SET button (8)
7 MUTING button (9)
8 SOUND/BASS button (9)
9 STANDBY/ON button (8, 19)
p TIMER ON/OFF button (19)
q SLEEP button (19)
w PROGRAM button (8, 11, 13, 18, 19)
e REPEAT ST/MONO button (10, 14)
r Source buttons
• TAPE, TUNER/BAND, CD
Pressing one of these buttons also turns on the unit.
t CD 3/8 button (12, 13)
y Multi control buttons
• ,
• 4, 7, ¢
u VOLUME + / – buttons (9)
8
RM-SFSH10J REMOTE CONTROL
STANDBY/ON
STANDBY
COMPACT COMPONENT SYSTEM
CD SYNCHRO RECORDING
VOLUME
When using the remote control, point it at the
remote sensor on the front panel.
5
Getting Started
Continued
Unpacking
After unpacking, check to be sure that you have all the
following items.
The number in parentheses indicates the quantity of each
piece supplied.
• AM loop antenna (1)
• Remote control (1)
• Batteries (2)
If any item is missing, consult your dealer immediately.
Putting the Batteries into the Remote Control
Insert the batteries—R03(UM-4)/AAA(24F)—into the
remote control by matching the polarity (+ and –) on the
batteries with the + and – marking on the battery
compartment.
When the remote control can no longer operate the unit,
replace both batteries at the same time.
1
Connections
To connect speakers
You can connect the speakers using the speaker cords.
1
Speaker
cord
Black
L
R
SPEAKER
IMPEDANCE
Ω
4-16
Red
Red
Black
2,3
Speaker
cord
R03(UM-4)/
AAA(24F)
2
3
• DO NOT use an old battery together with a new
one.
• DO NOT use different types of batteries together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use the
remote control for an extended period of time.
Otherwise, the remote control will be damaged
from battery leakage.
Right speaker Left speaker
1
Hold the clamp of the speaker terminal.
2
Insert the end of the speaker cord into the
terminal.
Match the polarity of the speaker terminals: red (ª) to
red (ª) and black (·) to black (·).
3
Release your finger from the clamp.
IMPORTANT:
• Use only speakers with the same speaker impedance as
indicated by the speaker terminals on the rear of the unit.
• DO NOT connect more than one speaker to one
speaker terminal.
6
To connect AM and FM antennas
NOW you are ready to plug in the unit.
2
FM antenna
FM
ANTENNA
AM
LOOP
1
AM loop antenna
(supplied)
1
Connect the supplied AM loop antenna to the
AM LOOP terminal.
Place the antenna away from the unit and adjust its
position for the best reception.
IMPORTANT:
Be sure to check that all connections have been made
before plugging in the power cord.
2
Adjust the position for the FM antenna for
the best reception.
For better reception of both FM and AM
• Make sure the antenna conductors do not touch any other
terminals or connecting cords.
• Keep the antennas away from metallic parts of the unit,
connecting cords, and the AC power cord.
7
Basic and Common Operations
Continued
Setting the Clock
Before operating the unit any further, first set the unit’s clock.
When you plug in the power cord, “AM12:00” starts flashing
on the display.
You can set the clock when the unit is either turned on or in
standby mode.
• In the following procedure, the clock is set to 12-hour
system.
On the remote control ONLY:
1
When the unit is in standby mode,
press and hold PROGRAM until the
hour indication starts flashing.
• When the unit is on, press DISPLAY/CLOCK SET to
enter clock mode, then press and hold PROGRAM.
2
Press 4 or ¢ to adjust
the hour, then press
PROGRAM.
• When you press and hold 4 or
¢, the hour indication changes
continuously.
The minute indication start flashing.
PROGRAM
PROGRAM
To select 12-hour or 24-hour clock system
You can select 12-hour or 24-hour for the clock system only
while the unit is in standby mode.
On the unit ONLY:
To change the clock setting, press
TIMER ON/OFF while holding down 7.
• Each time you press TIMER ON/OFF,
the clock change alternates between
12-hour and 24-hour system.
TIMER ON/OFF
To show the clock when the unit is turned on
CD
CONTROL
On the remote control ONLY:
Press DISPLAY/CLOCK SET.
• Each time you press the button, the display
changes the clock indication and the normal
indication alternately.
To change the clock
Repeat steps 1 to 3 of the procedure “Setting the Clock.”
DISPLAY
/CLOCK SET
Turning On the Power
3
Press 4 or ¢ to adjust
the minute, then press
PROGRAM.
• When you press and hold 4 or
¢, the minute indication changes
continuously.
The built-in clock starts.
• When you unplug the AC power cord or if a power failure
occurs
The clock is reset to “AM12:00” right away. If this happens, set
the clock again.
• The clock may gain or lose 1 to 2 minutes per month
If this happens, reset the clock.
PROGRAM
To turn on the unit, press STANDBY/ON.
The STANDBY lamp on the unit goes off.
• When you press the source button—TAPE,
TUNER/BAND and CD, the unit automatically
turns on.
To turn off the unit (standby), press STANDBY/ON
again.
The STANDBY lamp on the unit lights red.
• “AM12:00” flashes on the display until you set the built-in
clock. After setting the clock, the clock time will appear on
the display while the unit is on standby.
• A little power is always consumed even while the unit is in
standby mode.
To switch off the power supply completely, unplug the AC
power cord from the AC outlet.
When you unplug the AC power cord or if a power
failure occurs
The clock is reset to “AM12:00” right away. If this happens, set the
clock again.
STANDBY/ON
8
Selecting the Source
Selecting the Sound Modes
To select the source, press TAPE,
TUNER/BAND, or CD.
TAPE CD
TUNER
/BAND
• When you select TAPE or CD as
the source, playback does not start
automatically.
To operate the tuner (FM or AM), see pages 10 and 11.
To operate the CD player, see pages 12 – 14.
To operate the tape deck, see page 15.
To record on a tape, see pages 16 and 17.
Adjusting the Volume
You can adjust the volume level only while the unit is turned
on. The volume level can be adjusted between “VOL MIN,”
“VOL 1” – “VOL 39,” and “VOL MAX.”
• The volume level has no effect on recording.
To increase the volume, press VOLUME +.
To decrease the volume, press VOLUME –.
• When you press and hold either button, you
can change the volume level continuously.
VOLUME
You can select one of the 4 sound modes.
• This function also affects the sound from headphones.
• This function only affects the playback sound, and does not
affect your recording.
To select the sound modes, press SOUND/BASS
repeatedly.
SOUND
/BASS
• Each time you press the button, the sound mode
changes as follows:
POP
FLAT
(Canceled)
CLASSIC
ROCK
JAZZ
POP: More presence in the vocals and midrange.
CLASSIC: Enriched sound with fine treble and ample bass.
ROCK: Powerful sound emphasizing treble and bass.
JAZZ: Accented lower frequencies for jazz-type music.
FLAT: Equalizer effect is canceled.
When the sound mode is activated, the SOUND indicator
lights up on the display.
To turn off the sound temporarily
On the remote control ONLY:
Press MUTING.
The volume level turn down and “MUTING”
starts flashing on the display.
To restore the sound, press MUTING again.
• Adjusting the volume level also cancels the muting.
For private listening
Connect a pair of headphones to the PHONES jack. No sound
comes out of the speakers. Be sure to turn down the volume before
connecting or putting on the headphones.
DO NOT turn off (standby) the unit with the volume
set to an extremely high level; Otherwise, the
sudden blast of sound can damage your hearing,
speakers and/or headphones when you turn on the
unit or start playing any source.
REMEMBER you cannot adjust the volume level
while the unit is in standby mode.
MUTING
Reinforcing the Bass Sound
The richness and fullness of the bass sound is clearly
maintained regardless of how low you set the volume—Hyper
Bass Sound.
• This function also affects the sound from headphones.
• This function only affects the playback sound, and does not
affect your recording.
To get the effect, press and hold SOUND/BASS
until “HBS ON” appears and the BASS indicator
lights up on the display.
• Each time you press and hold the button, the effect
alternates on (“HBS ON”) and off (“HBS OFF”).
To cancel the effect, press and hold SOUND/BASS again
until “HBS OFF” appears and the BASS indicator goes off.
SOUND
/BASS
9
Listening to FM and AM Broadcasts
Tuning in to a Station
1
Press TUNER/BAND to select either
“FM” or “AM.”
The unit automatically turns on and tunes in to
the previously received station—either FM or AM.
• Each time you press the button, the band alternates
between FM and AM.
2
Press and hold ¢ or 4
(or ¡/¢ or 4/1 on
the unit) for more than 1
second.
• ¢ (¡/¢): Increases the frequencies.
• 4 (4/1): Decreases the frequencies.
The unit starts searching for stations and stops when a
station of sufficient signal strength is tuned in.
• If an FM program is broadcast in stereo, the ST (stereo)
indicator lights up on the display (only when the
reception is good).
TUNER
/BAND
To change the FM reception mode
On the remote control ONLY:
When an FM stereo broadcast is hard to receive
or noisy, press REPEAT ST/MONO so that the
MONO indicator lights up on the display.
Reception will improve.
To restore the stereo effect, press REPEAT ST/MONO
again so that the MONO indicator goes off. In stereo mode,
you can hear stereo sound when a stereo program is
broadcast.
To reduce the beat—Beat Cut
REPEAT
ST/MONO
On the remote control ONLY:
If the beats are heard while listening a
broadcast, press BEAT CUT.
BEAT CUT
To stop during searching, press ¢ or 4 (or ¡/¢ or
4/1 on the unit).
When you repeatedly press ¢ or 4 (or ¡/¢ or
4/1 on the unit)
The frequency changes step by step.
10
Presetting Stations
Tuning in to a Preset Station
You can preset 20 FM and 20 AM stations manually.
In some cases, test frequencies have been already stored
for the tuner since the factory examined the tuner preset
function before shipment. This is not a malfunction. You
can preset the stations you want into memory by following
the presetting method.
• There is a time limit in doing the following steps. If the
setting is canceled before you finish, start again from step 2.
On the remote control ONLY:
1
Tune in to the station you want to preset.
• See “Tuning in to a Station” on page 10.
2
Press PROGRAM.
The PROG (program) indicator and “00” start
flashing on the display.
3
Press or to select a preset
PROGRAM
number.
On the remote control ONLY:
1
Press TUNER/BAND to select either
“FM” or “AM.”
The unit automatically turns on and tunes in to
the previously received station—either FM or AM.
• Each time you press the button, the band alternates
between FM and AM.
2
Press or to select a preset
number.
TUNER
/BAND
4
Press PROGRAM again.
The PROG indicator and the selected preset
number stop flashing.
5
To preset more stations, repeat steps 1 to
PROGRAM
4
above, allocating a different preset number to
each station.
• Storing a new station on an already assigned number erases
the previously stored one.
When you unplug the AC power cord or if a power
failure occurs
The preset stations will remain in the unit.
11
Playing Back Discs
Continued
This unit has been designed to play back the following
discs—CD, CD-R, and CD-RW.
When playing a CD-R or CD-RW
User-edited CD-Rs (CD-Recordable) and CD-RWs (CDReWritable) can be played only if they are already
“finalized.”
• Usually you can play back your original CD-Rs or CDRWs recorded in music CD format. However, sometimes
they may not play depending on their characteristics or
recording conditions.
• Before playing CD-Rs or CD-RWs, read their instructions
or cautions carefully.
• Some CD-Rs or CD-RWs may not play on this unit because
of their disc characteristics, damage or stain on them, or if
the player’s lens is dirty.
• CD-RWs may require a longer readout time. This is
because the reflectance of CD-RWs is lower than for
regular discs.
General notes
In general, you will have the best performance by keeping
your discs and the mechanism clean.
• Store discs in their cases, and keep them in cabinets or on
shelves.
• Keep the unit’s disc trays closed when not in use.
4
Press CD.
The unit automatically turns on and the
source changes to the CD player.
After loading the disc, total track number and
total playing time appear on the display.
Total track number Total playing time
5
Press CD 3/8.
The first track of the disc starts playing.
Current track number
Elapsed playing time
• The disc automatically stops when the last track has
finished playing.
CD
CD
Continued use of irregular shape discs (heart-shape,
octagonal, etc.) can damage the unit.
Playing Back the Entire Disc—Normal Play
1
Press 0 OPEN on the unit.
The disc cover opens.
• You can insert a disc while listening to another source.
2
Place a disc correctly with its label side up.
Good Not good
3
Close the disc cover gently.
To stop playing, press 7.
To remove the disc, press 0 OPEN on the unit.
• If the disc cannot be read correctly (because it is scratched,
for example) or an unreadable CD-R or CD-RW is inserted
Playback will not start.
• If no disc is inserted
“NO DISC” appears on the display.
DO NOT try to open the disc cover by hand as it
will be damaged.
12
Basic Disc Operations
While playing a disc, you can do the following operations.
To stop playing for a moment
During play, press CD 3/8.
While pausing, the elapsed playing time flashes on
the display.
To resume playing, press CD 3/8 again.
To go to another track
Before or during play, press ¢ or
4 repeatedly.
• ¢ : Skips to the beginning of the
next or succeeding tracks.
• 4 : Goes back to the beginning of the current or previous
tracks.
To locate a particular point in a track
During play, press and hold ¢ or
4.
• ¢ : Fast-forwards the tracks.
• 4 : Fast-reverses the tracks.
CD
3
Press ¢ or 4 to select
the track number, then
press PROGRAM.
Track number
4
Repeat step 3 to program other tracks you
Program step number
PROGRAM
want.
5
Press CD 3/8.
The tracks are played in the order you have
programed.
If you try to program a 61st track
“FULL” will appear on the display.
To stop playing, press 7.
CD
Programming the Track Playing Order
—Program Play
You can arrange the order in which tracks play before you
start playing. You can program up to 60 tracks.
On the remote control ONLY:
1
Place a disc.
• If the current source is not the CD player, press CD.
2
Press PROGRAM.
The PROG (program) indicator starts flashing
on the display.
• If a program has been stored in memory, the program is
called up.
PROGRAM
To check the program contents
Press PROGRAM repeatedly in stop mode.
The program number and track number are
displayed in succession.
To modify the program
Press PROGRAM repeatedly in stop mode to
select the number which you want to change the
track, then repeat step 3 above.
To clear the program
Press 7 in stop mode.
The PROG indicator disappears from the display.
• Pressing 0 OPEN to open the disc cover will also
erase the programed tracks.
PROGRAM
PROGRAM
13
Playing at Random—Random Play
Playing only Introductions—Intro Play
You can play the tracks at random.
On the remote control ONLY:
Press RANDOM before or during
RANDOM
playing.
The RANDOM indicator lights up on the display.
To exit from Random Play, press RANDOM again.
RANDOM
The RANDOM indicator goes off.
• It is not possible to activate the random play function
during Program Play.
Repeating Tracks—Repeat Play
You can have all the tracks, the program or individual track
currently playing, repeat as many times as you like.
On the remote control ONLY:
Press REPEAT ST/MONO repeatedly
before or during playing.
• Each time you press the button, Repeat Play
changes as follows, and the following repeat
indicator lights up on the display:
ALL
Canceled
1
REPEAT
ST/MONO
You can play only the introductions of the tracks.
On the remote control ONLY:
Press INTRO.
The INTRO indicator lights up and the first 10-
second portion of each track is played back in order.
To cancel Intro Play, press INTRO again.
The INTRO indicator goes off.
• Intro Play remains in effect even when you select another
play mode (Program or Random Play).
INTRO
Displaying the Remaining Time during
Playback
You can display the remaining time of the current track/disc
and the elapsed time of the current track/disc during playing.
On the remote control ONLY:
Press REMAIN repeatedly.
• Each time you press the button, the display
changes as follows, and the following indicators
light up on the display:
REMAIN TOTAL REMAIN
REMAIN
Repeat indicators
ALL: In Normal Play, repeats all the tracks.
In Program Play, repeats all the tracks in the
program.
In Random Play, repeats all the tracks in
random order.
1: Repeats one track.
To cancel Repeat Play, press REPEAT ST/MONO
REPEAT
ST/MONO
repeatedly until the repeat indicator goes off.
• Repeat Play remains in effect even when you select
another play mode (Normal, Program, Random, or Intro
Play).
• In Random Play, 1 cannot be selected. If 1 has
been selected when you press RANDOM, it is canceled.
• If you select 1 in Random Play, Random Play is
canceled.
No indication
TOTAL
REMAIN: Shows the remaining time of the current
track.
TOTAL REMAIN: Shows the remaining time and track
number of the disc.
TOTAL: Shows the elapsed time of the disc.
No indication: Shows the elapsed time of the current
track.
14
Loading...
