Enter below the Model No. and Serial No.
which are located either on the rear, bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT1348-001D
[J]
Warnings, Cautions and Others
Mises en garde, précautions et indications diverses
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
Caution: Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
2. Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below.
3. Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm
or more.
Attention: Aération correcte
Pour prévenir tout risque de décharge électrique ou d’incendie et éviter toute détérioration, installez l’appareil de la manière
suivante:
1. Avant: Bien dégagé de tout objet.
2. Côtés/dessus/dessous: Assurez-vous que rien ne bloque les espaces indiqués sur le schéma ci-dessous.
3. Dessous: Posez l’appareil sur une surface plane et horizontale. Veillez à ce que sa ventilation correcte puisse se faire en le
plaçant sur un support d’au moins dix centimètres de hauteur..
Front
Face
15 cm
1 cm
15 cm
1 cm
15 cm
Side
Côté
Cooling fan*
Ventilateur de
SP-FSGD7
CA-FSGD7
refroidissement*
10 cm
SP-FSGD7
15 cm
* About the cooling fan
A cooling fan is mounted on the rear panel of the unit to prevent abnormal temperature inside the unit, thus assuring normal operation of
theunit. The cooling fan automatically starts rotating to intake external cool air when the volume is increased up to more than a certain level.
* À propos du ventilateur de refroidissement
Un ventilateur de refroidissement se trouve sur le panneau arrière de l’appareil afin d’éviter la création d’une température
anormale à l’intérieur de l’appareil et permettre ainsi un fonctionnement normal de l’appareil. Le ventilateur de refroidissement
commence à tourner et à aspirer de l’air frais automatiquement quand le volume est augmenté au-dessus d’un certain niveau.
15 cm
CA-FSGD7
G-1
For U.S.A.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION
Changes or modifications not approved by JVC
could void the user’s authority to operate the
equipment.
For the main unit:
Declaration of Conformity
Model Number:FS-GD7
Trade Name:JVC
Responsible Party: JVC Americas Corp.
Address:1700 Valley Road, Wayne
New Jersey 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
For Canada/pour le Canada
CAUTION:
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
ATTENTION:
ELECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQUAU FOND.
TO PREVENT ELECTRIC SHOCK,
POUR EVITER LES CHOCS
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to section 820-40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
For Canada/pour le Canada
THIS DIGITAL APPARATUS DOES NOT EXCEED
THE CLASS B LIMITS FOR RADIO NOISE
EMISSIONS FROM DIGITAL APPARATUS AS SET
OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL
APPARATUS,” ICES-003 OF THE DEPARTMENT
OF COMMUNICATIONS.
CET APPAREIL NUMERIQUE RESPECTE LES
LIMITES DE BRUITS RADIOELECTRIQUES
APPLICABLES AUX APPAREILS NUMIRIQUES DE
CLASSE B PRESCRITES DANS LA NORME SUR LE
MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE
MINISTRE DES COMMUNICATIONS.
• Install in a place which is level, dry and neither too hot nor
too cold—between 5°C and 35°C (41°F and 95°F).
• Install the System in a location with adequate ventilation to
prevent internal heat buildup inside the System.
DO NOT install the System in a location
near heat sources, or in a place subject to
direct sunlight, excessive dust or vibration.
• Leave sufficient distance between the System and the TV.
• Keep the speakers away from the TV to avoid interference
with TV.
Power sources
• When unplugging the System from the wall outlet, always
pull on the plug, not the AC power cord.
DO NOT handle the AC power cord with
wet hands.
Moisture condensation
Moisture may condense on the lenses inside the System in
the following cases:
• After starting to heat the room
• In a damp room
• If the System is brought directly from a cold to a warm
place.
Should this occur, the System may malfunction. In this case,
leave the System turned on for a few hours until the moisture
evaporates, unplug the AC power cord, then plug it in again.
Internal heat
•
A cooling fan is mounted on the rear panel to prevent heat
buildup inside the main unit (see page G-1).
For safety, observe the following carefully:
• Make sure there is good ventilation around
the main unit. Poor ventilation could
overheat and damage the System.
• DO NOT block the cooling fan and the
ventilation openings or holes. If they are
blocked by a newspaper or cloth, etc., the
heat may not be able to get out.
Others
• Should any metallic object or liquid fall into the System,
unplug the AC power cord and consult your dealer before
operating any further.
DO NOT disassemble the System since there
are no user serviceable parts inside.
• If you are not going to operate the System for an extended
period of time, unplug the AC power cord from the wall
outlet.
If anything goes wrong, unplug the AC power cord and
consult your dealer.
How to Read This Manual
To make in this manual as simple and easy-to-understand as
possible, we have adapted the following methods:
•
Button and control operations are explained as listed in the
table below. In this manual, the operations using the remote
control is mainly explained; however, you can use the
buttons and controls on the main unit if they have the same
(or similar) name and marks
•
Some related tips and notes are explained later in the
sections “Learning More about This System” (on
pages 37 to 38) and “Troubleshooting” (on page 40), but
not in the same section explaining the operations.
want to know more about the functions, or if you have a
doubt about the functions, go to these sections and you will
find the answers.
Indicates that you press the button
briefly
Indicates that you press the button
briefly and repeatedly
option you want is selected.
Indicates that you press one of the
buttons.
Indicates that you
button for a specified period.
• The number inside the arrow
• If no number is inside the arrow,
Indicates that you turn the control
toward the specified direction(s).
Indicates that this operation is only
possible using the remote control.
Main Unit
ONLY
Indicates that this operation is only
possible using the buttons and controls on
the main unit.
.
If you
.
until an
press and hold
indicates the period of press (in this
example, 2 seconds).
press and hold until the entire
procedure is complete or until you
get a result you want.
the
2
Getting Started
Step 1:Unpack the package and
check the accessories.
Step 2: Prepare the remote control.
Step 1: Unpack
After unpacking, check to be sure that you have all the
following items. The number in parentheses indicates the
quantity of each piece supplied.
• FM antenna (1)
• AM loop antenna (1)
• Remote control (1)
• Composite video cord (1)
• Batteries (2)
If any item is missing, consult your dealer immediately.
Step 2: Prepare the Remote Control
Insert the batteries into the remote control by matching the
polarity (+ and –) correctly.
1
2
R6(SUM-3)/AA(15F)
Step 3: Hook up the components such
as AM/FM antennas, speakers,
etc. (see pages 4 to 6).
Finally plug the AC power cord.
Now you can operate the System.
3
• DO NOT use an old battery together with a
new one.
• DO NOT use different types of batteries
together.
• DO NOT expose batteries to heat or flame.
• DO NOT leave the batteries in the battery
compartment when you are not going to use
the remote control for an extended period of
time. Otherwise, the remote control will be
damaged from battery leakage.
3
Step 3: Hook Up
If you need more detailed information, see page 6.
Illustrations of the input/output terminals below are typical
examples.
When you connect other components, refer also to their
manuals since the terminal names actually printed on the rear
may vary.
Turn the power off to all components before connections.
AM loop antenna (supplied)
Turn it until the best reception is
obtained.
SUBWOOFER
DECODER
TV
AUDIO INPUT
OPTICAL
DIGITAL IN
VIDEO INPUT
VIDEO INPUT
VIDEO INPUT
Y
P
b
P
r
Yellow
Green
Blue
Red
Audio cord (not supplied)
Optical digital cord (not supplied)
S-VIDEO cord (not supplied)
Composite video cord (supplied)
Component video cord (not supplied)
To a wall outlet
Plug the AC power cord only after all
connections are complete.
4
For better FM/AM reception
Outdoor FM
antenna
Vynile-covered wire (not supplied)
Extend it horizontally.
AM loop antenna
Keep it connected.
Disconnect the supplied FM antenna, and connect to an outdoor FM antenna
using a 75 Ω wire with coaxial type connector.
(not supplied)
FM antenna (supplied)
Extend it so that you can
obtain the best reception.
SUBWOOFER
OUT
OPTICAL
DIGITAL OUT
VIDEO OUT
S-VIDEO
COMPONENT
VIDEO
AM LOOP
75Ω
EXT
Y
Pb
Pr
ANTENNA
FM
AM
SPEAKERS
IMPEDANCE
L
R
6-16Ω
Gray cord (+)
connect to red (+) terminal
Gray cord with black stripe (–)
connect to black (–) terminal
5
To assemble and connect the AM loop antenna
To assemble the AM loop antenna
Remote
Changing the Scanning Mode
ONLY
This System supports progressive scanning.
If you connect a progressive TV through the COMPONENT
jacks, you can enjoy a high quality picture from the built-in
DVD player by selecting progressive mode.
PROGRE
INTER
To connect the AM loop antenna
1 Hold
2 Insert
3 Release
• If the AM loop antenna wire or speaker cords are covered
with vinyl, remove the vinyl to expose the tip of the
antenna by twisting the vinyl.
• Make sure the antenna conductors do not touch any other
terminals, connecting cords and power cord. Also, keep the
antennas away from metallic parts of the System,
connecting cords, and the AC power cord. This could cause
poor reception.
To connect the speaker cords
Connect the right speaker to the R terminals, and the left
speaker to the L terminals.
1 Hold2 Insert3 Release
(at the same time)
PROGRE
(Progressive)
INTER
(Interlaced)
Progressive scanning.
For a progressive TV. The
PROGRESSIVE indicator lights.
Interlaced scanning.
For a conventional TV.
When connecting the speaker cords, match the polarity of
the speaker terminals: gray cord (+) to red (+) and gray cord
with black stripe (–) to black (–).
• DO NOT connect more than one speaker to
each terminal.
• DO NOT allow the conductor of the speaker
cords to be in touch with the metallic parts of
the System.
6
Before Operating the System
DIGITAL VIDEO
SUPER VIDEO
Playable Disc Types
This System has been designed to play back the following
discs:
Disc TypeMark (Logo)
DVD Video
DVD Audio
Video CD
(VCD)
Super Video
CD (SVCD)
Audio CD
CD-R
CD-RW
DVD-R
DVD-RW
In addition to the above discs, this system can play back audio
data recorded on CD Text, CD-G (CD Graphics), and CDExtra.
• The following discs cannot be played back:
DVD-ROM, DVD-RAM, DVD+R, DVD+RW, CD-I (CD-I
Ready), CD-ROM, Photo CD, SACD, etc.
Playing back these discs will generate noise and damage the
speakers.
The System can play back CD-R or CD-RW
recorded in the Audio CD, Video CD, SVCD,
MP3, and JPEG formats.
The System can play back DVD-R or DVDRW recorded in the video format.
COMPACT
DIGITAL AUDIO
Video
Format
NTSC
• In this manual, “file” and “track” are interchangeably used
for MP3/JPEG operations.
*
Note on Region Code
DVD players and DVDs have their own Region Code numbers.
This System can play back only DVDs recorded with the NTSC
color system whose Region Code numbers including “1.”
Ex.:
If a DVD with the improper Region Code numbers is loaded,
“RGN ERR (REGION CODE ERROR)” appears on the display
and playback will not start.
Region
Code*
Number
1
or
ALL
DVD Video—digital audio formats
The System can play back the following digital audio
formats.
•
Linear PCM:
format used for CDs and most studio masters.
•
Dolby Digital:
Dolby Laboratories, which enables multi-channel encode
to create the realistic surround sound.
•
DTS (Digital Theater Systems):
audio, developed by Digital Theater Systems, Inc., which
enables multi-channel like Dolby Digital. As the
compression ratio is lower than for Dolby Digital, it
provides wider dynamic range and better separation.
When playing a multi-channel encoded DVD, the System
properly converts these multi-channel signals into 2
channels, and emits the downmixed sound from the
speakers.
•
To enjoy the powerful sound of these multi-channel
encoded DVDs,
with a proper built-in decoder to the digital output terminal
on the rear.
IMPORTANT: Before playing a disc, make sure of
the following...
• Turn on the TV and select an appropriate input mode on
the TV to view the pictures or on-screen displays on the
TV screen.
• For disc playback, you can change the initial setting to
your preference. See “Setup Menu Operations” on
page 32.
If “” appears on the TV screen when you press a
button,
tried to do, or data required for that operation is not
recorded on the disc.
• Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, “MLP Lossless”, and the double-D
symbol are trademarks of Dolby Laboratories.
• “DTS” and “DTS 2.0
Digital Theater Systems, Inc.
“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation registered in the US, Japan and other
countries.
Uncompressed digital audio, the same
Compressed digital audio, developed by
Compressed digital
connect a proper decoder or an amplifier
the disc cannot accept the operation you have
+ DIGITAL OUT
” are trademarks of
Caution for DualDisc playback:
The Non-DVD side of a “DualDisc” does not comply with the
“Compact Disc Digital Audio” standard. Therefore, the use of
Non-DVD side of a DualDisc on this product may not be
recommended.
7
Display Indicators
The indications on the display teach you a lot of things while you are operating the System.
Before operating the System, be familiar with when and how the indicator illuminates on the display.
1
23456
89
1
Disc tray indicators
• 1–5: Disc tray number indicators.
• (tray indicator):
– Lights when the disc is detected.
– Blinking while playing back a disc.
– Goes off when there is no disc in the tray.
• (disc indicator): Lights below when the tray indicator
indicates the current selected disc.
2
MP3 indicator
• Lights when the current track is recorded in MP3 format.
3
FM reception indicators
• MONO: Lights when FM reception mode is monaural.
• ST (stereo): Lights while an FM stereo station with
sufficient signal strength is tuned in.
4
Main display
• While listening to radio; band (or preset number) and
station frequency appear.
• While selecting “AUX”; “AUX” appears.
• While playing a disc; see “Indications on the main
display while operating a disc” on page 9.
5
SOUND TURBO indicator
• Lights when SOUND TURBO II is activated (see
page 15).
6
AHB (active hyper bass) PRO indicator
• Lights when AHB PRO is activated (see page 15).
7
SLEEP indicator
• Lights when the Sleep Timer is activated. (see page 18)
p
q
7
we
8
Disc operation indicators
•: Lights when Repeat mode is activated.
• 1: Lights when One Track Repeat is activated.
• 1DISC: Lights when One Disc Repeat is activated.
• ALL: Lights when All Disc Repeat is activated.
• A-B: Lights when A-B Repeat is activated.
• GROUP: Lights when Group Repeat is activated.
• RANDOM: Lights when Random Play mode is
activated.
• PROGRAM: Lights when Program Play mode is
activated.
9
3D PHONIC indicator
• Lights when 3D PHONIC is activated (see page 13).
p
Clear Voice indicator
• Lights when Clear Voice function is activated (see
page 16).
q
B.S.P. indicator
• Lights when the current disc is DVD Audio with
browsable still picture (see page 21).
w
BONUS indicator
• Lights when a DVD Audio with a bonus group is
detected (see page 20).
e
PROGRESSIVE indicator
• Lights when progressive scanning mode is selected (see
page 6).
r
A. (auto) STANDBY indicator
• Lights when Auto Standby is activated.
• Flashes when disc playback stops with Auto Standby
activated.
t
Timer indicators
•: Lights when Daily Timer stands by; flashes while
working.
• 1/2/3: Lights up when a Daily Timer (1, 2, or 3) stands
by; flashes while setting or working.
r
t
8
Indications on the main display while operating a disc
While playing back a disc:While disc play is stopped:
• DVD Video:
Chapter no.
Elapsed playing time
• DVD Video:
• By pressing SHIFT+DISPLAY, you can show the current
title and chapter numbers for a few seconds.
• DVD Audio:
Track no.
Elapsed playing time
• DVD Audio:
• By pressing SHIFT+DISPLAY, you can show the current
group and track numbers for a few seconds.
• Audio CD:• Audio CD:
Track no.
• SVCD/VCD:
Elapsed playing time
• SVCD/VCD:
Elapsed playing time*Track no.
Total track no.*
Total title no.
Track no.Group no.
Total playing timeTotal track no.
Total playing time
* “PBC” appears while playing a disc with PBC.
• MP3:
Track no.
Elapsed playing time
* Changes to “PBC” when stopping PBC playback.
• MP3:
Current track no.Current group no.
• By pressing DISPLAY, you can show the current group
and track numbers for a few seconds.
• JPEG:• JPEG:
Group no.
File no.
Current group no.
Current file no.
• If “RESUME” is “ON” (see page 35), “RESUME” appears when you stop playback (except for Audio CD and MP3/JPEG
discs).
9
SET
Numeric
buttons
DISPLAY
RETURN
8
3
TOP MENU
GROUP/TITLE
4,¢
FM/PLAY
MODE
SHIFT
3D PHONIC
Daily Operations
Turn on the power.
1
The STANDBY lamp on the main unit turns off.
1
2
1/¡
DISC
SELECT
MENU
2,3,5,∞
ENTER
7
• Without pressing AUDIO, the System turns on
by pressing one of the source selecting buttons in the
next step.
Select the source.
2
Playback automatically starts if the selected source is
ready to start.
• If you press AUX or USB, start playback on the
external component.
Adjust the volume.
3
4
Operate the target source as explained
later.
To turn off (standby) the System
—Playback
The STANDBY lamp on the main unit
lights up.
•A small amount of power is always
consumed even while on standby.
1
2
3
4
For private listening
Connect a pair of headphones to the PHONES jack on the
main unit. The sound will no longer come out of the
speakers. Be sure to turn down the volume before
connecting or putting on the headphones.
• Disconnecting the headphones will activate the
speakers again.
DO NOT turn off (standby) the System with
the volume set to an extremely high level;
otherwise, the sudden blast of sound can
damage your hearing, speakers and/or
headphones when you turn on the System or
start playback.
Remote
To turn off the clock indication
While the System is turned off...
• Press the button again, to
display the clock
indication.
(at the same time)
ONLY
10
Listening to the Radio
To select the band (FM or AM)
FMAM
To tune in to a station
While FM or AM is selected...
Remote control:
1 sec.
Frequency starts changing on the display.
When a station (frequency) with sufficient signal strength is
tuned in, the frequency stops changing.
• When you repeatedly press the button, the frequency
changes step by step.
To stop searching manually,
If the received FM station is hard to listen
The MONO indicator lights on the display.
Reception will improve though stereo effect is
lost—Monaural reception mode.
To restore the stereo effect,
again (the MONO indicator goes off).
Main unit:
1 sec.
press either button.
press the button
Remote
ONLY
Remote
To preset the stations
You can preset 30 FM and 15 AM stations.
1
Tune in to a station you want to preset.
• You can also store the monaural reception mode for FM
preset stations if selected.
Activate the preset number entry mode.
2
• Finish the following process while the indication on the
display is flashing (5 seconds).
Select a preset number for the station you store.
3
4
Store the station.
ONLY
Examples:
To select preset number 5,
press 5.
To select preset number
15, press +10, then 5.
To select preset number
30, press +10, +10, then
10.
Remote
To tune in to a preset station
1
Select a band (FM or AM).
ONLY
FMAM
2
Select a preset number you have stored.
You can also use the 1/¡ buttons to select a preset
•
station.
11
Playing Back a Disc
Before operating a disc, be familiar how a disc is recorded.
• DVD Video comprises of “
“
Chapters
which includes “
of only “
• For JPEG playback, see “Operations on the
CONTROL Screen” on page 28.
,” DVD Audio/MP3 comprise of “
Tracks
Tracks
.”
To insert a disc
You can insert a disc while playing another source.
Main Unit:
Titles
” which includes
”
Groups
,” and CD/SVCD/VCD comprise
On-screen guide icons
• During DVD Video playback, the following icons may
appear on the TV screen:
At the beginning of a scene containing multiangle views.
At the beginning of a scene containing multiaudio sounds.
At the beginning of a scene containing multisubtitles.
• The following icons will be also shown on the TV screen
to indicate your current operation (for more details, see
page 25).
, , , , , ,
To select a disc
Remote Control:
To close the disc tray and start playback,
same lever again.
• When current selected disc tray open, you can use
DVD/CD 3
(depending on how the disc is programmed internally).
•
When you press up 0 EJECT for the next tray you want to
place another disc onto, the first disc tray automatically
closes and then next tray comes out.
To start:To pause:To stop:
•
While playing DVD/SVCD/VCD:
the stop point, and when you start playback again by
pressing DVD/CD 3
have stopped—Resume Play. (“RESUME” appears on the
display when you stop playback.)
To stop completely while Resume is activated,
twice. (To cancel Resume, see “RESUME” on page 35.)
• When operating the System, the on-screen guide icon (see
the following table) appears on the TV screen.
To deactivate the on-screen guide icons, see “ON
SCREEN GUIDE” on page 35.
to close the disc tray and start playback
or
To release, press
DVD/CD 3
, it starts from the position where you
press down the
.
This System can store
press 7
DISC 1
DISC 2
DISC 3
DISC 5DISC 4
• When current source is not disc, press DVD/CD 3
the disc player as the source during “PLAY” flashing on
the display.
Main Unit:
Remote
To select a title/group
While playing...
(at the same time)
• Group name appears for MP3 discs.
ONLY
to select
To select a chapter/track
While playing...
• First time you press 4
can go back to the beginning
of the current chapter/track.
, you
12
Loading...
+ 35 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
